Last updated January 20, 2021
An interactive guide to setting up your Xerox B210 Printer for printing.
Get Started
Before you start!
Back to Previous Page |
|
Back to Start |
|
|
|
This package will step you through the setup process of installing the software and drivers you need to print and scan, and connect the printer to the network.
You will be asked questions along the way to identify the appropriate process steps to follow.
After performing the step or to answer the question, |
|
|||
click on the red arrows |
to proceed onto the next |
|
||
step. To go back, click on the gray arrow |
on the |
|
||
Next |
||||
top right of the page. |
|
|
||
|
|
|
||
|
|
|
Follow the hyperlinks to read instructional articles, watch videos, or obtain file downloads from support.xerox.com
2
Terminology You Need to Know
Back to Previous Page |
|
Back to Start |
|
|
|
Network: A system of linked devices that share resources, such as Internet access and printers, connected through a common wireless (Wi-Fi) or wired (supported by Ethernet cords) network router.
Wi-Fi Direct: This is a feature on your printer/MFP that when enabled, emits a wireless signal that Wi-Fi capable devices (e.g. phones, computers) can directly connect to for printing. You can connect your device to the printer’s wireless signal just like you would connect to an Internet router’s Wi-Fi signal.
Computer’s Operating System (OS): This is the software version that your computer is running. Your operating system determines which print drivers and Xerox applications you will use for printing and scanning.
Utility, or Utility Pack: This is a set of files, software and tools that must be downloaded to your computer to setup your printer. After being downloaded, the files may need to be installed manually on your PC, or will be automatically installed with the help of an imbedded “wizard” or executable file. The package contents vary based on your PC’s OS, but they generally contain drivers for printing, scanning and faxing as well as Wi-Fi setup assistant. They may contain applications that allow you to fax, scan, or access your printer’s advanced settings from your desktop.
CentreWare Internet Services (CWIS): This is your printer’s web interface where you can manage advanced settings. You access it by entering your printer’s IP address in your web browser. Your printer must be on the network or have
Wi-Fi direct enabled in order to access CWIS.
Next
3
Unpacking and Powering On
Perform the following steps:
1)Unpack the box and locate the installation poster and USB cord
2)Remove all the internal packaging and tape
3)Plug the printer into an outlet and power on
4)Load the paper
Click here to view a video about unboxing your printer.
Back to Previous Page |
|
Back to Start |
|
|
|
Next
4
Choose Your Device
Select the type of device you are setting up to print from.
If you will be printing from multiple devices, setup to print from your computer first.
Back to Previous Page |
|
Back to Start |
|
|
|
Windows Computer
Macintosh Computer
Android or iOS Mobile device Other
5
Back to Previous Page |
|
Back to Start |
|
|
|
How do you want to connect the printer to the Windows computer?
Through the network via Wi-Fi
This method wirelessly connects your printer to your home office network. Any computer or device that is also on the network can print to it. You must have a wireless router and a good WiFi signal.
You can also enable Wi-Fi direct to print from devices that are not on the network. The networked printer can be configured to emit a signal that devices can directly connect to.
Through the network with an Ethernet cord
This method connects your printer to your network using a cable. Any computer or device that is also on the network can print to it. The Ethernet cord is not provided.
If you do not have a wireless network router, you can use Wi-Fi direct to print from devices that are not on the network. The networked printer can be configured to emit a signal that devices can directly connect to.
Directly with a USB cord
This method directly connects your printer to your computer using a USB cord. Your printer must be located within the cord’s reach of the computer. The USB cord was shipped with your printer.
This method is not recommended if you plan to print from mobile devices.
6
Back to Previous Page |
|
Back to Start |
|
|
|
Prepare for Driver Installation and Connection Setup
Perform these steps at your PC:
1.Connect the printer and the computer using the provided USB cable
2.Install the software by either installing the CD that was shipped
with your printer or downloading the utility file Xerox_B210_Windows_PrintDriver_Utilities_Signed.zip from here.
3. Run the executable (.exe) file
The program will connect to the printer, walk you through |
|
|
adding the printer to the network, install the Easy Printer |
|
|
Next |
||
Manager software and drivers, and print a test page. |
||
|
||
|
To view a video about using the utility, click here.
Note: to manually add the printer to the network using WPS, refer to the KB articles for Wi-Fi and wired setups.
7
Setup Wi-Fi Direct
Enable Wi-Fi Direct from the “Easy Printer Manager” application on your computer.
Wi-Fi Direct can be used as a backup connection, to support wireless printing from non-networked devices, and to access advanced settings in CWIS.
1.Open Easy Printer Manager > Select Advanced Settings > hover over Device Settings, then select Network Settings. For Wi-Fi Direct, select On to enable the feature.
2.Make note of the IP Address displayed. It will be used later to access the printer's web interface (CentreWare Internet Services).
3.For Network Key, enter a password that contains at least 8 characters. This password will be used later to connect to the printer's Wi-Fi Direct signal.
4.Click Save to save the settings.
8
Back to Previous Page |
|
Back to Start |
|
|
|
Next
Back to Previous Page |
|
Back to Start |
|
|
|
Enable or Disable the Banner Page
If you need to enable or disable the banner page from printing with each print job, this can be configured in CWIS.
The banner page is a cover page that contains information identifying the user and job name.
Click here to read the knowledge base instructions.
Next
9
Back to Previous Page |
|
Back to Start |
|
|
|
You are all done!
You have completed the setup and install process for this device.
Choose what you would like to do next.
Setup another device
Done
10
Back to Previous Page |
|
Back to Start |
|
|
|
Choose Your Mac’s Operating System Version
Choose the appropriate range of operating system versions that your Macintosh PC is running.
10.15 or above
10.14 or below
11
Connect with the USB Cord
Plug one end of the USB cord into your printer and the other end into your computer.
The cord was shipped with your printer.
Note: You will have an opportunity to setup a network connection later. The USB connection is required for the initial setup.
Back to Previous Page |
|
Back to Start |
|
|
|
Next
12
Back to Previous Page |
|
Back to Start |
|
|
|
Install “Xerox_B2xx_Series_Print_Scan_Drivers”
Download the print driver file package from |
|
|
|
|
|
|
support.xerox.com. |
|
|
|
|
|
|
This file package is called |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Xerox_B2xx_Series_Print_Scan_Drivers_.dmg |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Note: B210 does not support scan. This package |
|
|
|
|
|
|
|
|
Next |
|
|||
contains the B210 Print Driver file along with other |
|
|
|
|||
drivers for the B205 and B215 models. |
|
|
|
|
|
|
To download the driver, click here. |
|
|
|
|
|
|
|
|
|
|
|
|
|
13
Install “MAC_Printer”
Back to Previous Page |
|
Back to Start |
|
|
|
Select and install the print driver: “MAC_Printer”
This file will load the printing software to the computer and connect to the printer.
To view a video about installing the driver files, and the
navigation to print a test page, click here. |
Next |
|
14
Back to Previous Page |
|
Back to Start |
|
|
|
How do you want to connect the printer to your devices?
Read the benefits of each method and click on your selection.
Through the network via Wi-Fi
This method wirelessly connects your printer to your home office network. Any computer or device that is also on the network can print to it. You must have a wireless router and a good WiFi signal.
You can also enable Wi-Fi direct to print from devices that are not on the network. The networked printer can be configured to emit a signal that devices can directly connect to.
Through the network with an Ethernet cord
This method connects your printer to your network using a cable. Any computer or device that is also on the network can print to it. The Ethernet cord is not provided.
If you do not have a wireless network router, you can use Wi-Fi direct to print from devices that are not on the network. The networked printer can be configured to emit a signal that devices can directly connect to.
Directly with a USB cord
This method directly connects your printer to your computer using a USB cord. Your printer must be located within the cord’s reach of the computer. The USB cord was shipped with your printer.
This method is not recommended if you plan to print from mobile devices, or use Centreware Internet Services to access the printer’s Advanced
Settings.
15
Back to Previous Page |
|
Back to Start |
|
|
|
Add the Printer to the Wi-Fi Network using WPS
Use WPS to add the printer to the Wi-Fi network.
Perform the following steps:
1.Activate WPS from your router, if required. Some routers have a WPS button on them and others require configuration from the router’s interface/web page. Refer to your router’s user documentation.
2.Push and hold WPS button on the printer for 2 seconds.
3.Wait 2-3 minutes for the blue WPS button to stop flashing.
4.Wait approximately 1 minute for the printer to obtain a valid IP address.
5.Press the red Stop button to print a configuration report and verify that an IP address was obtained.
For more detailed steps to verify the IP address, click here.
Next
Try a different method to setup WiFi
16
Add the Printer to the Network
Connect the printer to the network hub with an Ethernet cord and configure the printer for this connection.
Perform these steps from the printer’s control panel.
1.Push and hold the WPS button on the printer for 2 seconds.
2.Wait 2-3 minutes for the blue WPS button to stop flashing and for the default wireless connection to time-out.
3.Wait approximately 20 seconds to allow DHCP to discover the IP address using the wired connection.
4.Press the red Stop button to print a configuration report and verify that an IP address was obtained.
For more detailed steps to verify the IP address, click here.
17
Back to Previous Page |
|
Back to Start |
|
|
|
Next
Back to Wireless Setup |
|
Back to Wired Setup |
|
Back to Start |
|
|
|
|
|
Setup Wi-Fi Direct
Enable Wi-Fi Direct from the printer’s web |
|
interface (CWIS). |
|
Wi-Fi Direct can be used as a backup connection |
|
method if your network goes down, or to support |
|
wireless printing from devices that are not on the |
|
printer’s network. |
|
Note: This step applies to printers that are on a network using Wi-Fi or |
|
an Ethernet cord. |
Next |
|
To enable Wi-Fi direct, follow the knowledge base instructions found here.
18
Back to Previous Page |
|
Back to Start |
|
|
|
Print a Test Page
Validate you can print over the network connection.
Remove the USB cable. Print any document from your computer.
Next
19
Back to Previous Page |
|
Back to Start |
|
|
|
Enable or Disable the Banner Page
If you need to enable or disable the banner page from printing with each print job, this can be configured in CWIS.
The banner page is a cover page that contains information identifying the user and job name.
Note: This step applies to printers that are on a network using Wi-Fi or an Ethernet cord.
Next
Click here to read the knowledge base instructions.
These directions are not applicable to Mac 10.15+ PCs connected over USB, because Easy Printer Manager software (which is not supported for Mac 10.15+) is required to access CWIS and enable Wi-Fi Direct.
20
Back to Previous Page |
|
Back to Start |
|
|
|
Printing Over USB
Keep your printer connected to the computer with the USB cable and you will be able to print and scan using the drivers you installed.
Next
21
Back to Printing Over USB |
|
Back to Configuring Banner Page |
|
Back to Start |
|
|
|
|
|
You are all done!
You have completed the setup and install process for this device.
Choose what you would like to do next.
Setup another device
Done
