VMware Horizon 6.2, Horizon View - 6.2 Administrator’s Guide

Administering View Cloud Pod

Architecture

VMware Horizon 6

Version 6.2

This document supports the version of each product listed and supports all subsequent versions until the document is replaced by a new edition. To check for more recent editions of this document, see http://www.vmware.com/support/pubs.

EN-001911-00

Administering View Cloud Pod Architecture

You can find the most up-to-date technical documentation on the VMware Web site at:

http://www.vmware.com/support/

The VMware Web site also provides the latest product updates.

If you have comments about this documentation, submit your feedback to:

docfeedback@vmware.com

VMware, Inc.

3401 Hillview Ave. Palo Alto, CA 94304 www.vmware.com

2 VMware, Inc.

Administering View Cloud Pod Architecture 5

Introduction to Cloud Pod Architecture 7

Understanding Cloud Pod Architecture 7

Configuring and Managing a Cloud Pod Architecture Environment 8

Cloud Pod Architecture Limitations 8

Designing a Cloud Pod Architecture Topology 9

Creating Cloud Pod Architecture Sites 9

Entitling Users and Groups in the Pod Federation 10

Finding and Allocating Desktops and Applications in the Pod Federation 10

Global Entitlement Example 12

Cloud Pod Architecture Topology Limits 12

Cloud Pod Architecture Port Requirements 13

Security Considerations for Cloud Pod Architecture Topologies 13

Setting Up a Cloud Pod Architecture Environment 15

Initialize the Cloud Pod Architecture Feature 15

Join a Pod to the Pod Federation 16

Create and Configure a Global Entitlement 17

Create and Configure a Site 20

Assign a Home Site to a User or Group 20

Test a Cloud Pod Architecture Configuration 21

Example: Setting Up a Basic Cloud Pod Architecture Configuration 22

VMware, Inc.

Managing a Cloud Pod Architecture Environment 27

View a Cloud Pod Architecture Configuration 27

View Pod Federation Health in View Administrator 29

View Desktop and Application Sessions in the Pod Federation 29

Determine the Effective Home Site for a User 30

Add a Pod to a Site 30

Modifying Global Entitlements 31

Remove a Home Site Association 34

Remove a Pod From the Pod Federation 35

Uninitialize the Cloud Pod Architecture Feature 35

lmvutil Command Reference 37

lmvutil Command Use 37

Initializing the Cloud Pod Architecture Feature 40

Disabling the Cloud Pod Architecture Feature 41

Managing Pod Federations 41

Administering View Cloud Pod Architecture

Managing Sites 43

Managing Global Entitlements 46

Managing Home Sites 53

Viewing a Cloud Pod Architecture Configuration 55

Managing SSL Certificates 60

Index 63

4 VMware, Inc.

Administering View Cloud Pod Architecture

Administering View Cloud Pod Architecture describes how to configure and administer a Cloud Pod Architecture environment in VMware Horizon® 6, including how to plan a Cloud Pod Architecture topology and set up, monitor, and maintain a Cloud Pod Architecture configuration.

Intended Audience

This information is intended for anyone who wants to set up and maintain a Cloud Pod Architecture environment. The information is written for experienced Windows or Linux system administrators who are familiar with virtual machine technology and data center operations.

VMware Technical Publications Glossary

VMware Technical Publications provides a glossary of terms that might be unfamiliar to you. For definitions of terms as they are used in VMware technical documentation, go to

http://www.vmware.com/support/pubs.

VMware, Inc.

Administering View Cloud Pod Architecture

6 VMware, Inc.

Introduction to Cloud Pod

Security

Server

User

View

Connection

Server

View

Connection

Server

Security

Server

View

Connection

Server

View

Connection

Server

Security

Server

Security

Server

London Pod

London Datacenter

Interpod

communication

Remote desktop or application

New York Pod

New York Datacenter

Global Data Layer

Architecture 1

The Cloud Pod Architecture feature uses standard View components to provide cross-datacenter administration, global and flexible user-to-desktop mapping, high availability desktops, and disaster recovery capabilities.

This chapter includes the following topics:

“Understanding Cloud Pod Architecture,” on page 7

“Configuring and Managing a Cloud Pod Architecture Environment,” on page 8

“Cloud Pod Architecture Limitations,” on page 8

Understanding Cloud Pod Architecture

With the Cloud Pod Architecture feature, you can link together multiple View pods to provide a single large desktop and application brokering and management environment.

A View pod consists of a set of View Connection Server instances, shared storage, a database server, and the vSphere and network infrastructures required to host desktop virtual machines and application pools. In a traditional View implementation, you manage each pod independently. With the Cloud Pod Architecture feature, you can join together multiple pods to form a single View implementation called a pod federation.

A pod federation can span multiple sites and datacenters and simultaneously simplify the administration effort required to manage a large-scale View deployment.

Figure 1‑1. Basic Cloud Pod Architecture Topology

In the example topology, two previously standalone View pods in different datacenters are joined together to form a single pod federation. An end user in this environment can connect to a View Connection Server instance in the New York datacenter and receive a desktop or application in the London data center.

VMware, Inc.

Administering View Cloud Pod Architecture

Sharing Key Data in the Global Data Layer

View Connection Server instances in a pod federation use the Global Data Layer to share key data. Shared data includes information about the pod federation topology, user and group entitlements, policies, and other Cloud Pod Architecture configuration information.

In a Cloud Pod Architecture environment, shared data is replicated on every View Connection Server instance in a pod federation. Entitlement and topology configuration information stored in the Global Data Layer determines where and how desktops are allocated across the pod federation.

View sets up the Global Data Layer on each View Connection Server instance in a pod federation when you initialize the Cloud Pod Architecture feature.

Sending Messages Between Pods

View Connection Server instances communicate in a Cloud Pod Architecture environment by using an interpod communication protocol called the View InterPod API (VIPA).

View Connection Server instances use the VIPA communication channel to launch new desktops, find existing desktops, and share health status data and other information. View configures the VIPA communication channel when you initialize the Cloud Pod Architecture feature.

Configuring and Managing a Cloud Pod Architecture Environment

You use View Administrator and the lmvutil command-line interface to configure and manage a Cloud Pod Architecture environment. lmvutil is installed as part of the View installation. You can also use View Administrator to view pod health and desktop session information.

NOTE You cannot use View Administrator to create and manage Cloud Pod Architecture home sites. You must use the lmvutil command to perform these tasks.

Cloud Pod Architecture Limitations

The Cloud Pod Architecture feature is not supported in an IPv6 environment.

8 VMware, Inc.

Designing a Cloud Pod Architecture

Topology 2

Before you begin to configure the Cloud Pod Architecture feature, you must make decisions about your Cloud Pod Architecture topology. Cloud Pod Architecture topologies can vary, depending on your goals, the needs of your users, and your existing View implementation. If you are joining existing View pods to a pod federation, your Cloud Pod Architecture topology is typically based on your existing network topology.

This chapter includes the following topics:

“Creating Cloud Pod Architecture Sites,” on page 9

“Entitling Users and Groups in the Pod Federation,” on page 10

“Finding and Allocating Desktops and Applications in the Pod Federation,” on page 10

“Global Entitlement Example,” on page 12

“Cloud Pod Architecture Topology Limits,” on page 12

“Cloud Pod Architecture Port Requirements,” on page 13

“Security Considerations for Cloud Pod Architecture Topologies,” on page 13

Creating Cloud Pod Architecture Sites

In a Cloud Pod Architecture environment, a site is a collection of well-connected pods in the same physical location, typically in a single datacenter. The Cloud Pod Architecture feature treats pods in the same site equally.

When you initialize the Cloud Pod Architecture feature, it places all pods into a default site called Default First Site. If you have a large implementation, you might want to create additional sites and add pods to those sites.

The Cloud Pod Architecture feature assumes that pods in the same site are on the same LAN, and that pods in different sites are on different LANs. Because WAN-connected pods have slower network performance, the Cloud Pod Architecture feature gives preference to desktops and applications that are in the local pod or site when it allocates desktops and applications to users.

Sites can be a useful part of a disaster recovery solution. For example, you can assign pods in different datacenters to different sites and entitle users and groups to pools that span those sites. If a datacenter in one site becomes unavailable, you can use desktops and applications from the available site to satisfy user requests.

VMware, Inc.

Administering View Cloud Pod Architecture

Entitling Users and Groups in the Pod Federation

In a traditional View environment, you use View Administrator to create entitlements. These local entitlements entitle users and groups to a specific desktop or application pool on a View Connection Server instance.

In a Cloud Pod Architecture environment, you create global entitlements to entitle users or groups to multiple desktops and applications across multiple pods in the pod federation. When you use global entitlements, you do not need to configure and manage local entitlements. Global entitlements simplify administration, even in a pod federation that contains a single pod.

View stores global entitlements in the Global Data Layer. Because global entitlements are shared data, global entitlement information is available on all View Connection Server instances in the pod federation.

You entitle users and groups to desktops by creating global desktop entitlements. Each global desktop entitlement contains a list of member users or groups, a list of the desktop pools that can provide desktops for entitled users, and a scope policy. The desktop pools in a global entitlement can be either floating or dedicated pools. You specify whether a global entitlement is floating or dedicated during global entitlement creation.

You entitle users and groups to applications by creating global application entitlements. Each global application entitlement contains a list of the member users or groups, a list of the application pools that can provide applications for entitled users, and a scope policy.

A global entitlement's scope policy specifies where View looks for desktops or applications when it allocates desktops or applications to users in the global entitlement. It also determines whether View looks for desktops or applications in any pod in the pod federation, in pods that reside in the same site, or only in the pod to which the user is connected.

As a best practice, you should not configure local and global entitlements for the same desktop pool. For example, if you create both local and global entitlements for the same desktop pool, the same desktop might appear as a local and a global entitlement in the list of desktops and applications that Horizon Client shows to an entitled user. Similarly, you should not configure both local and global entitlements for application pools created from the same farm.

Finding and Allocating Desktops and Applications in the Pod Federation

View Connection Server instances in a Cloud Pod Architecture environment use shared global entitlement and topology configuration information from the Global Data Layer to determine where to search for and how to allocate desktops and applications across the pod federation.

When a user requests a desktop or application from a global entitlement, View searches for an available desktop or application in the pools that are associated with that global entitlement. By default, View gives preference to the local pod, the local site, and pods in other sites, in that order.

For global desktop entitlements that contain dedicated desktop pools, View uses the default search behavior only the first time a user requests a desktop. After View allocates a dedicated desktop, it returns the user directly to the same desktop.

You can modify the search and allocation behavior for individual global entitlements by setting the scope policy and configuring home sites.

10 VMware, Inc.

Chapter 2 Designing a Cloud Pod Architecture Topology

Understanding the Scope Policy

When you create a global desktop entitlement or global application entitlement, you must specify its scope policy. The scope policy determines the scope of the search when View looks for desktops or applications to satisfy a request from the global entitlement.

You can set the scope policy so that View searches only on the pod to which the user is connected, only on pods within the same site as the user's pod, or across all pods in the pod federation.

For global desktop entitlements that contain dedicated pools, the scope policy affects where View looks for desktops the first time a user requests a dedicated desktop. After View allocates a dedicated desktop, it returns the user directly to the same desktop.

Using Home Sites

A home site is a relationship between a user or group and a Cloud Pod Architecture site. With home sites, you can ensure that a user always receives desktops and applications from a specific site rather than receiving desktops and applications based on the user's current location. The Cloud Pod Architecture feature includes the following types of home site assignments.

Global home site

Per-global-entitlement home site

A home site that is assigned to a user or group.

If a user who has a home site belongs to a group that is associated with a different home site, the home site associated with the user takes precedence over the group home site assignment.

Global homes sites are useful for controlling where roaming users receive desktops and applications. For example, if a user has a home site in New York but is visiting London, View looks in the New York site to satisfy the user's desktop request rather than allocating a desktop closer to the user. Global home site assignments apply for all global entitlements.

IMPORTANT Global entitlements do not recognize home sites by default. To make a global entitlement use home sites, you must select the Use home site option when you create or modify the global entitlement.

A home site that is associated with a global entitlement.

When you use the lmvutil command to create a home site for a user or group, you can use the --entitlementName option to specify a global entitlement. Per-global-entitlement home sites override global home site assignments.

For example, if a user who has a home site in New York accesses a global entitlement that associates that user with the London home site, View looks in the London site to satisfy the user's application request rather than allocating an application from the New York site.

When you use the lmvutil command with the --createGroupHomeSite option to create a per-globalentitlement home site, you must explicitly entitle all Active Directory user groups that contain the home site users. If you have nested user groups, it is not sufficient to entitle only the parent group. In this case, the parent group is explicitly entitled to the global entitlement, but the subgroups are not, and the

--createGroupHomeSite option fails.

Configuring home sites is optional. If a user does not have a home site, View searches for and allocates desktops and applications as described in “Finding and Allocating Desktops and Applications in the Pod

Federation,” on page 10.

VMware, Inc. 11

New York Datacenter

Pod Federation

Global Entitlement

“My Global Pool”

Members: NYUser1 NYUser2

Pools: pool1 pool2 pool3

Scope: Any

pool1 pool2

NY Pod

London Datacenter

pool3 pool4

LDN Pod

NYUser1

Administering View Cloud Pod Architecture

Global Entitlement Example

In this example, NYUser1 is a member of the global desktop entitlement called My Global Pool. My Global Pool provides an entitlement to three floating desktop pools, called pool1, pool2, and pool3. pool1 and pool2 are in a pod called NY Pod in the New York datacenter and pool3 and pool4 are in a pod called LDN Pod in the London datacenter.

Figure 2‑1. Global Entitlement Example

Because My Global Pool has a scope policy of ANY, the Cloud Pod Architecture feature looks for desktops across both NY Pod and LDN Pod when NYUser1 requests a desktop. The Cloud Pod Architecture feature does not try to allocate a desktop from pool4 because pool4 is not part of My Global Pool.

If NYUser1 logs into NY Pod, the Cloud Pod Architecture feature allocates a desktop from pool1 or pool2, if a desktop is available. If a desktop is not available in either pool1 or pool2, the Cloud Pod Architecture feature allocates a desktop from pool3.

Cloud Pod Architecture Topology Limits

A typical Cloud Pod Architecture topology consists of two or more View pods, which are linked together in a pod federation. Pod federations are subject to certain limits.

Table 2‑1. Pod Federation Limits

Object Limit

Users 20,000

Pods 4

Sites 2

View Connection Server instances 20

12 VMware, Inc.

Chapter 2 Designing a Cloud Pod Architecture Topology

Cloud Pod Architecture Port Requirements

Certain network ports must be opened on the Windows firewall for the Cloud Pod Architecture feature to work. When you install View Connection Server, the installation program can optionally configure the required firewall rules for you. These rules open the ports that are used by default. If you change the default ports after installation, or if your network has other firewalls, you must manually configure the Windows firewall.

Table 2‑2. Ports Opened During View Connection Server Installation

TCP Port Description

22389 The Global Data Layer LDAP instance runs on this port. Shared data is replicated on every View

Connection Server instance in a pod federation. Each View Connection Server instance in a pod federation runs a second LDAP instance to store shared data.

8472 The View Interpod API (VIPA) communication channel runs on this port. View Connection Server

instances use the VIPA communication channel to launch new desktops and applications, find existing desktops, and share health status data and other information.

Security Considerations for Cloud Pod Architecture Topologies

To use View Administrator or the lmvutil command to configure and manage a Cloud Pod Architecture environment, you must have the Administrators role. Users who have the Administrators role on the root access group are super users.

When a View Connection Server instance is part of a replicated group of View Connection Server instances, the rights of super users are extended to other View Connection Server instances in the pod. Similarly, when a pod is joined to a pod federation, the rights of super users are extended to all of the View Connection Server instances in all of the pods in the pod federation. These rights are necessary to modify global entitlements and perform other operations on the Global Data Layer.

If you do not want certain super users to be able to perform operations on the Global Data Layer, you can remove the Administrators role assignment and assign the Local Administrators role instead. Users who have the Local Administrators role have super user rights only on their local View Connection Server instance and on any instances in a replicated group.

For information about assigning roles in View Administrator, see the View Administration document.

VMware, Inc. 13

Administering View Cloud Pod Architecture

14 VMware, Inc.

Setting Up a Cloud Pod Architecture

Environment 3

Setting up a Cloud Pod Architecture environment involves initializing the Cloud Pod Architecture feature, joining pods to the pod federation, and creating global entitlements.

You must create and configure at least one global entitlement to use the Cloud Pod Architecture feature. You can optionally create sites and assign home sites.

This chapter includes the following topics:

“Initialize the Cloud Pod Architecture Feature,” on page 15

“Join a Pod to the Pod Federation,” on page 16

“Create and Configure a Global Entitlement,” on page 17

“Create and Configure a Site,” on page 20

“Assign a Home Site to a User or Group,” on page 20

“Test a Cloud Pod Architecture Configuration,” on page 21

“Example: Setting Up a Basic Cloud Pod Architecture Configuration,” on page 22

Initialize the Cloud Pod Architecture Feature

Before you configure a Cloud Pod Architecture environment, you must initialize the Cloud Pod Architecture feature.

You need to initialize the Cloud Pod Architecture feature only once, on the first pod in a pod federation. To add pods to the pod federation, you join the new pods to the initialized pod.

During the initialization process, View sets up the Global Data Layer on each View Connection Server instance in the pod, configures the VIPA communication channel, and establishes a replication agreement between each View Connection Server instance.

Procedure

1 Log in to the View Administrator user interface for any View Connection Server instance in the pod.

You can initialize the Cloud Pod Architecture feature from any View Connection Server instance in a pod.

2 In View Administrator, select View Configuration > Cloud Pod Architecture and click Initialize the

Cloud Pod Architecture feature.

3 When the Initialize dialog box appears, click OK to begin the initialization process.

View Administrator shows the progress of the initialization process. The initialization process can take several minutes.

VMware, Inc.

Administering View Cloud Pod Architecture

After the Cloud Pod Architecture feature is initialized, the pod federation contains the initialized pod and a single site. The default pod federation name is Horizon Cloud Pod Federation. The default pod name is based on the host name of the View Connection Server instance. For example, if the host name is CS1, the pod name is Cluster-CS1. The default site name is Default First Site.

4 When View Administrator prompts you to reload the client, click OK.

After the View Administrator user interface is refreshed, Global Entitlements appears under Catalog and Sites appears under View Configuration in the View Administrator Inventory panel.

5 (Optional) To change the default name of the pod federation, select View Configuration > Cloud Pod

Architecture, click Edit, type the new name in the Name text box, and click OK.

6 (Optional) To change the default name of the pod, select View Configuration > Sites, select the pod,

click Edit, type the new name in the Name text box, and click OK.

7 (Optional) To change the default name of the site, select View Configuration > Sites, select the site,

click Edit, type the new name in the Name text box, and click OK.

What to do next

To add more pods to the pod federation, see “Join a Pod to the Pod Federation,” on page 16.

Join a Pod to the Pod Federation

During the Cloud Pod Architecture initialization process, the Cloud Pod Architecture feature creates a pod federation that contains a single pod. You can use View Administrator to join additional pods to the pod federation. Joining additional pods is optional.

IMPORTANT Do not stop or start a View Connection Server instance while you are joining it to a pod federation. The View Connection Server service might not restart correctly. You can stop and start the View Connection Server after it is successfully joined to the pod federation.

Prerequisites

Make sure the View Connection Server instances that you want to join have different host names. You

cannot join servers that have the same name, even if they are in different domains.

Initialize the Cloud Pod Architecture feature. See “Initialize the Cloud Pod Architecture Feature,” on

page 15.

Procedure

1 Log in to the View Administrator user interface for a View Connection Server instance in the pod that

you are joining to the pod federation.

2 In View Administrator, select View Configuration > Cloud Pod Architecture and click Join the pod

federation.

3 In the Connection Server text box, type the host name or IP address of any View Connection Server

instance in any pod that has been initialized or is already joined to the pod federation.

4 In the User name text box, type the name of a View administrator user on the already initialized pod.

Use the format domain\username.

5 In the Password text box, type the password for the View administrator user.

6 Click OK to join the pod to the pod federation.

View Administrator shows the progress of the join operation. The default pod name is based on the host name of the View Connection Server instance. For example, if the host name is CS1, the pod name is Cluster-CS1.

16 VMware, Inc.

7 When View Administrator prompts you to reload the client, click OK.

After the View Administrator user interface is refreshed, Global Entitlements appears under Catalog and Sites appears under View Configuration in the View Administrator Inventory panel.

8 (Optional) To change the default name of the pod, select View Configuration > Sites, select the pod,

click Edit, type the new name in the Name text box, and click OK.

After the pod is joined to the pod federation, it begins to share health data. You can view this health data on the dashboard in View Administrator. See “View Pod Federation Health in View Administrator,” on page 29.

NOTE A short delay might occur before health data is available in View Administrator.

What to do next

You can repeat these steps to join additional pods to the pod federation.

Create and Configure a Global Entitlement

You use global entitlements to entitle users and groups to desktops and applications in a Cloud Pod Architecture environment. Global entitlements provide the link between users and their desktops and applications, regardless of where those desktops and applications reside in the pod federation.

Chapter 3 Setting Up a Cloud Pod Architecture Environment

A global entitlement contains a list of member users or groups, a list of the pools that can provide desktops or applications for entitled users, and a set of policies. You can add both users and groups, only users, or only groups, to a global entitlement. You can add a particular pool to only one global entitlement.

Prerequisites

Decide which type of global desktop entitlement to create, the users, groups, and pools to include in the

global entitlement, and the scope of the global entitlement. See “Entitling Users and Groups in the Pod

Federation,” on page 10.

Decide whether the global entitlement should use home sites. See “Using Home Sites,” on page 11.

Create the desktop or application pools to include in the global entitlement. For information about

creating pools, see the Setting Up Desktop and Application Pools in View document.

Decide which users and groups to include in the global entitlement.

Initialize the Cloud Pod Architecture feature. See “Initialize the Cloud Pod Architecture Feature,” on

page 15.

Procedure

1 Log in to the View Administrator user interface for any View Connection Server instance in the pod

federation.

2 In View Administrator, select Catalog > Global Entitlements and click Add.

3 Select the type of global entitlement to add and click Next.

Option Description

Desktop Entitlement

Application Entitlement

Adds a global desktop entitlement.

Adds a global application entitlement.

VMware, Inc. 17

Administering View Cloud Pod Architecture

4 Configure the global entitlement.

a Type a name for the global entitlement in the Name text box.

The name can contain between 1 and 64 characters. This is the name that appears in the list of available desktops and applications in Horizon Client for an entitled user.

b (Optional) Type a description of the global entitlement in the Description text box.

The description can contain between 1 and 1024 characters.

c If you are configuring a global desktop entitlement, select a user assignment policy.

The user assignment policy specifies the type of desktop pool that a global desktop entitlement can contain. You can select only one user assignment policy.

Option Description

Floating

Dedicated

d Select a scope policy for the global entitlement.

The scope policy specifies where to look for desktops or applications to satisfy a request from the global entitlement. You can select only one scope policy.

Creates a floating desktop entitlement. A floating desktop entitlement can contain only floating desktop pools.

Creates a dedicated desktop entitlement. A dedicated desktop entitlement can contain only dedicated desktop pools.

Option Description

All sites

Within site

Within pod

View looks for desktops or applications on any pod in the pod federation.

View looks for desktops or applications only on pods in the same site as the pod to which the user is connected.

View looks for desktops or applications only in the pod to which the user is connected.

e (Optional) If users have home sites, configure a home site policy for the global entitlement.

Option Description

Use home site

Entitled user must have home site

Causes View to look for desktops or applications in the user's home site. If the user does not have a home site and the Entitled user must have home site option is not selected, the site to which the user is currently connected is assumed to be the home site.

Causes the global entitlement to be available only if the user has a home site. This option is available only when the Use home site option is selected.

f (Optional) Use the Automatically clean up redundant sessions option to specify whether to

automatically clean up redundant sessions.

NOTE This option is available only for floating desktop entitlements and global application entitlements.

Multiple sessions can occur when a pod that contains a session goes offline, the user logs in again and starts another session, and the problem pod comes back online with the original session. When multiple sessions occur, Horizon Client prompts the user to select a session. This option determines what happens to sessions that the user does not select. If you do not select this option, users must manually end their own extra sessions, either by logging off in Horizon Client or by launching the sessions and logging them off.

18 VMware, Inc.

Chapter 3 Setting Up a Cloud Pod Architecture Environment

g If you are configuring a global desktop entitlement, select the default display protocol for desktops

in the global destkop entitlement and specify whether to allow users to override the default display protocol.

h If you are configuring a global desktop entitlement, select whether to allow users to reset desktops

in the global desktop entitlement.

i Select whether to allow users to use the HTML Access feature to access desktops or applications in

the global entitlement.

With HTML Access, end users can use a Web browser to connect to remote desktops and applications and are not required to install any client software on their local systems.

5 Click Next and add users or groups to the global entitlement.

a Click Add, select one or more search criteria, and click Find to filter Active Directory users or

groups based on your search criteria.

b Select the Active Directory user or group to add to the global entitlement and click OK.

You can press the Ctrl and Shift keys to select multiple users and groups.

6 Click Next, review the global entitlement configuration, and click Finish to create the global

entitlement.

The global entitlement appears on the Global Entitlements page.

7 Select the pools that can provide desktops or applications for the users in the global entitlement you

created.

a Log in to the View Administrator user interface for any View Connection Server instance in the

pod that contains the pool to add to the global entitlement.

b In View Administrator, select Catalog > Global Entitlements.

c Double-click the global entitlement.

d On the Local Pools tab, click Add, select the pools to add, and click Add.

You can press the Ctrl and Shift keys to select multiple pools.

Pools that are already associated with a global entitlement, or that do not meet the criteria for the policies you selected for the global entitlement, are not displayed. For example, if you enabled the HTML Access policy, you cannot select pools that do not allow HTML Access.

IMPORTANT If you add multiple application pools to a global application entitlement, you must add the same application. For example, do not add Calculator and Microsoft Office PowerPoint to the same global application entitlement. If you add different applications to the same global application entitlement, entitled users might receive different applications at different times.

e Repeat these steps on a View Connection Server instance in each pod that contains a pool to add to

the global entitlement.

The Cloud Pod Architecture feature stores the global entitlement in the Global Data Layer, which replicates the global entitlement on every pod in the pod federation. When an entitled user uses Horizon Client to connect to a View Connection server in the pod federation, the global entitlement name appears in the list of available desktops and applications.

NOTE If a View administrator changes the pool-level display protocol or protocol override policy after a desktop pool is associated with a global desktop desktop entitlement, users can receive a desktop launch error when they select the global desktop entitlement. If a View administrator changes the pool-level virtual machine reset policy after a desktop pool is associated with the global desktop entitlement, users can receive an error if they try to reset the desktop.

VMware, Inc. 19

Administering View Cloud Pod Architecture

Create and Configure a Site

If your Cloud Pod Architecture topology contains multiple pods, you might want to group those pods into different sites. The Cloud Pod Architecture feature treats pods in the same site equally.

Prerequisites

Decide whether your Cloud Pod Architecture topology should include sites. See “Creating Cloud Pod

Architecture Sites,” on page 9.

Initialize the Cloud Pod Architecture feature. See “Initialize the Cloud Pod Architecture Feature,” on

page 15.

Procedure

1 Log in to the View Administrator user interface for any View Connection Server instance in the pod

federation.

2 Create the site.

a In View Administrator, select View Configuration > Sites and click Add.

b Type a name for the site in the Name text box.

The site name can contain between 1 and 64 characters.

c (Optional) Type a description of the site in the Description text box.

The site name can contain between 1 and 1024 characters.

d Click OK to create the site.

3 Add a pod to the site.

Repeat this step for each pod to add to the site.

a In View Administrator, select View Configuration > Sites and select the site that currently contains

the pod to add to the site.

The names of the pods in the site appear in the lower pane.

b Select the pod to add to the site and click Edit.

c Select the site from the Site drop-down menu and click OK.

Assign a Home Site to a User or Group

A home site is the relationship between a user or group and a Cloud Pod Architecture site. Home sites ensure that users always receive desktops and applications from a particular datacenter, even when they are traveling. Creating home sites is optional.

Prerequisites

Decide whether to assign home sites to users or groups in your Cloud Pod Architecture environment.

See “Using Home Sites,” on page 11.

Group the pods in your pod federation into sites. See “Create and Configure a Site,” on page 20.

Global entitlements do not use home sites by default. When creating a global entitlement, you must

select the Use home site option to cause View to use a user's home site when allocating desktops from that global entitlement. See “Create and Configure a Global Entitlement,” on page 17.

Initialize the Cloud Pod Architecture feature. See “Initialize the Cloud Pod Architecture Feature,” on

page 15.

20 VMware, Inc.

Chapter 3 Setting Up a Cloud Pod Architecture Environment

Become familiar with the lmvutil command authentication options and requirements and verify that

you have sufficient privileges to run the lmvutil command. See “lmvutil Command Authentication,” on page 38.

Procedure

To create a home site for a user, run the lmvutil command with the --createUserHomeSite option.

You can run the command on any View Connection Server instance in the pod federation.

lmvutil --createUserHomeSite --userName domain\username --siteName name [--entitlementName name]

Option Description

--userName

--siteName

--entitlementName

Name of the user. Use the format domain\username.

Name of the site to associate with the user as the home site.

(Optional) Name of a global entitlement to associate with the home site. When a user selects the specified global entitlement, the home site overrides the user's own home site. If you do not specify this option, the command creates a global user home site.

For example:

lmvutil --authAs adminEast --authDomain domainEast --authPassword "*" --createUserHomeSite -userName example\adminEast --siteName "Eastern Region" --entitlementName "Agent Sales"

To create a home site for a group, run the lmvutil command with the --createGroupHomeSite option.

You can run the command on any View Connection Server instance in the pod federation.

lmvutil --createGroupHomeSite --userName domain\username --siteName name [--entitlementName name]

Option Description

--groupName

--siteName

--entitlementName

Name of the group. Use the format domain\groupname.

Name of the site to associate with the group as the home site.

For example:

lmvutil --authAs adminEast --authDomain domainEast --authPassword "*"

--createGroupHomeSite --groupName example\adminEastGroup --siteName "Eastern Region"

--entitlementName "Agent Sales"

Test a Cloud Pod Architecture Configuration

After you initialize and configure a Cloud Pod Architecture environment, perform certain steps to verify that your environment is set up properly.

Prerequisites

Install the latest version of Horizon Client on a supported computer or mobile device.

Verify that you have credentials for a user in one of your newly created global entitlements.

Procedure

1 Start Horizon Client.

VMware, Inc. 21

Administering View Cloud Pod Architecture

2 Connect to any View Connection Server instance in the pod federation by using the credentials of a user

in one of your new global entitlements.

After you connect to the View Connection Server instance, the global entitlement name appears in the list of available desktops and applications.

3 Select the global entitlement and connect to a desktop or application.

The desktop or application starts successfully. Which desktop or application starts depends on the individual configuration of the global entitlement, pods, and desktop and application pools. The Cloud Pod Architecture feature attempts to allocate a desktop or application from the pod to which you are connected.

What to do next

If the global entitlement does not appear when you connect to the View Connection Server instance, use View Administrator to verify that the entitlement is configured correctly. If the global entitlement appears but a desktop or application does not start, all desktop or application pools might be fully assigned to other users.

Example: Setting Up a Basic Cloud Pod Architecture Configuration

This example demonstrates how you can use the Cloud Pod Architecture feature to complete a Cloud Pod Architecture configuration.

In this example, a health insurance company has a mobile sales force that operates across two regions, the Central region and the Eastern region. Sales agents use mobile devices to present insurance policy quotes to customers and customers view and sign digital documents.

Rather than store customer data on their mobile devices, sales agents use standardized View floating desktops. Access to customer data is kept secure in the health insurance company's datacenters.

The health insurance company has a data center in each region. Occasional capacity problems cause sales agents to look for available desktops in a non-local data center, and WAN latency problems sometimes occur. If sales agents disconnect from desktops but leave their sessions logged in, they must remember which datacenter hosted their sessions to reconnect to their desktops.

To solve these problems, the health insurance company designs a Cloud Pod Architecture topology, initializes the Cloud Pod Architecture feature, joins its existing pods to the pod federation, creates sites for each of its data centers, entitles its sales agents to all of its desktop pools, and implements a single View URL.

1 Designing the Example Topology on page 23

The insurance company designs a Cloud Pod Architecture topology that includes a site for each region.

2 Initializing the Example Configuration on page 23

To initialize the Cloud Pod Architecture feature, the View administrator logs in to the View Administrator user interface for a View Connection Server instance in East Pod 1, selects View Configuration > Cloud Pod Architecture, and clicks Initialize the Cloud Pod Architecture feature.

3 Joining Pods in the Example Configuration on page 24

The View administrator uses View Administrator to join Central Pod 1 and Central Pod 2 to the pod federation.

4 Creating Sites in the Example Configuration on page 24

The View administrator uses View Administrator to create a site for the Eastern and Central datacenters and adds pods to those sites.

22 VMware, Inc.

east1.example

East Pod 1

Eastern Region

east2.example east3.example

east4.example east5.example

central1.example

Central Pod 1

Central Region

central2.example central3.example

central4.example central5.example

central6.example

Central Pod 2

central7.example central8.example

central9.example central10.example

Sales A Sales B

Sales A

Sales B

Sales A

Sales B

Chapter 3 Setting Up a Cloud Pod Architecture Environment

5 Creating Global Desktop Entitlements in the Example Configuration on page 24

The View administrator uses View Administrator to create a single global desktop entitlement that entitles all sales agents to all desktops in the sales agent desktop pools across all pods in the pod federation.

6 Creating a View URL for the Example Configuration on page 25

The insurance company uses a single View URL and employs a DNS service to resolve sales.example to the nearest pod in the nearest data center. With this arrangement, sales agents do not need to remember different URLs for each pod and are always directed to the nearest data center, regardless of where they are located.

Designing the Example Topology

The insurance company designs a Cloud Pod Architecture topology that includes a site for each region.

Figure 3‑1. Example Cloud Pod Architecture Topology

In this topology, the Eastern region site contains a single pod, East Pod 1, that consists of five View Connection Server instances called east1.example through east5.example.

The Central region site contains two pods, Central Pod 1 and Central Pod 2. Each pod contains five View Connection Server instances. The View Connection Servers in the first pod are called central1.example through central5.example. The View Connection Server instances in the second pod are called central6.example through central10.example.

Each pod in the topology contains two desktop pools of sales agent desktops, called Sales A and Sales B.

Initializing the Example Configuration

Because the View administrator uses the View Administrator user interface for a View Connection Server instance in East Pod 1, the pod federation initially contains East Pod 1. The pod federation also contains a single site, called Default First Site, which contains East Pod 1.

VMware, Inc. 23

Administering View Cloud Pod Architecture

Joining Pods in the Example Configuration

The View administrator uses View Administrator to join Central Pod 1 and Central Pod 2 to the pod federation.

1 To join Central Pod 1, the View administrator logs in to the View Administrator user interface for a

View Connection Server instance in Central Pod 1, selects View Configuration > Cloud Pod Architecture, clicks Join the pod federation, and provides the host name or IP address of a View Connection Server instance in East Pod 1.

Central Pod 1 is now joined to the pod federation.

2 To join Central Pod 2, the View administrator logs in to the View Administrator user interface for a

View Connection Server instance in Central Pod 2, selects View Configuration > Cloud Pod Architecture, clicks Join the pod federation, and provides the host name or IP address of a View Connection Server instance in East Pod 1 or Central Pod 1.

Central Pod 2 is now joined to the pod federation.

After Central Pod 1 and Central Pod 2 are joined to the pod federation, all 10 View Connection Server instances across both pods in the Central region are part of the pod federation.

Creating Sites in the Example Configuration

The View administrator uses View Administrator to create a site for the Eastern and Central datacenters and adds pods to those sites.

1 The View administrator logs in to the View Administrator user interface for any View Connection

Server instance in the pod federation.

2 To create a site for the Eastern datacenter, the View administrator selects View Configuration > Sites

and clicks Add.

3 To create a site for the Central datacenter, the View administrator selects View Configuration > Sites

and clicks Add.

4 To move East Pod 1 to the site for the Eastern datacenter, the View administrator selects View

Configuration > Sites, selects the site that currently contains East Pod 1, selects East Pod 1, clicks Edit, and selects the Eastern datacenter site from the Site drop-down menu.

5 To move Central Pod 1 to the site for the Central datacenter, the View administrator selects View

Configuration > Sites, selects the site that currently contains Central Pod 1, selects Central Pod 1, clicks Edit, and selects the Central datacenter site from the Site drop-down menu.

6 To move Central Pod 2 to the site for the Central datacenter, the View administrator selects View

Configuration > Sites, selects the site that currently contains Central Pod 2, selects Central Pod 2, clicks Edit, and selects the Central datacenter site from the Site drop-down menu.

The pod federation site topology now reflects the geographic distribution of pods in the insurance company's network.

Creating Global Desktop Entitlements in the Example Configuration

1 To create and add users to the global desktop entitlement, the View administrator logs in to the View

Administrator user interface for a View Connection Server in the pod federation, selects Catalog > Global Entitlements, clicks Add, and selects Desktop Entitlement.

24 VMware, Inc.

Chapter 3 Setting Up a Cloud Pod Architecture Environment

The View administrator adds the Sales Agents group to the global desktop entitlement. The Sales Agent group is defined in Active Directory and contains all sales agent users. Adding the Sales Agent group to the Agent Sales global desktop entitlement enables sales agents to access the Sales A and Sales B desktop pools on the pods in the Eastern and Central regions.

2 To add the desktop pools in East Pod 1 to the global desktop entitlement, the View administrator logs

in to the View Administrator user interface for a View Connection Server instance in East Pod 1, selects

Catalog > Global Entitlements, double-clicks the global desktop entitlement, clicks Add on the Local Pools tab, selects the desktop pools to add, and clicks Add.

3 To add the desktop pools in Central Pod 1 to the global desktop entitlement, the View administrator

logs in to the View Administrator user interface for a View Connection Server instance in Central Pod 1, selects Catalog > Global Entitlements, double-clicks the global desktop entitlement, clicks Add on the Local Pools tab, selects the desktop pools to add, and clicks Add.

4 To add the desktop pools in Central Pod 2 to the global desktop entitlement, the View administrator

logs in to the View Administrator user interface for a View Connection Server instance in Central Pod 2, selects Catalog > Global Entitlements, double-clicks the global desktop entitlement, clicks Add on the Local Pools tab, selects the desktop pools to add, and clicks Add.

Creating a View URL for the Example Configuration

When a sales agent connects to the View URL in Horizon Client, the Agent Sales global entitlement appears on the list of available desktop pools. When a sales agent selects the global desktop entitlement, the Cloud Pod Architecture feature delivers the nearest available desktop in the pod federation. If all of the desktops in the local data center are in use, the Cloud Pod Architecture feature selects a desktop from the other data center. If a sales agent leaves a desktop session logged in, the Cloud Pod Architecture feature returns the sales agent to that desktop, even if the sales agent has since traveled to a different region.

VMware, Inc. 25

Administering View Cloud Pod Architecture

26 VMware, Inc.

Managing a Cloud Pod Architecture

Environment 4

You use View Administrator and the lmvutil command to view, modify, and maintain your Cloud Pod Architecture environment. You can also use View Administrator to monitor the health of pods in the pod federation.

This chapter includes the following topics:

“View a Cloud Pod Architecture Configuration,” on page 27

“View Pod Federation Health in View Administrator,” on page 29

“View Desktop and Application Sessions in the Pod Federation,” on page 29

“Determine the Effective Home Site for a User,” on page 30

“Add a Pod to a Site,” on page 30

“Modifying Global Entitlements,” on page 31

“Remove a Home Site Association,” on page 34

“Remove a Pod From the Pod Federation,” on page 35

“Uninitialize the Cloud Pod Architecture Feature,” on page 35

View a Cloud Pod Architecture Configuration

You can use View Administrator or the lmvutil command to view information about global entitlements, pods, and sites. You can use only the lmvutil command to view information about home sites.

This procedure shows how to use View Administrator to view information about global entitlements, pods, and sites. To use the lmvutil command to view this information, see Chapter 5, “lmvutil Command

Reference,” on page 37.

Prerequisites

Become familiar with the lmvutil command authentication options and requirements and verify that you have sufficient privileges to run the lmvutil command. See “lmvutil Command Authentication,” on page 38.

Procedure

To list all of the global entitlements in your configuration, in View Administrator, select Catalog >

Global Entitlements.

You can use the View Administrator user interface for any View Connection Server instance in the pod federation.

VMware, Inc.

Administering View Cloud Pod Architecture

To list the desktop or application pools in a global entitlement, in View Administrator, select Catalog >

Global Entitlements, double-click the global entitlement name, and click the Local Pools tab.

Only the pools in the local pod appear on the Local Pools tab. If a global entitlement includes desktop or application pools in a remote pod, you must log in to the View Administrator user interface for a View Connection Server instance in the remote pod to see those pools.

To list the users or groups associated with a global entitlement, in View Administrator, select Catalog >

Global Entitlements, double-click the global entitlement, and click the Users and Groups tab.

You can use the View Administrator user interface for any View Connection Server instance in the pod federation.

To list the pods in the pod federation, in View Administrator, select View Configuration > Cloud Pod

Architecture.

You can use the View Administrator user interface for any View Connection Server instance in the pod federation.

To list the sites in the pod federation, in View Administrator, select View Configuration > Sites.

You can use the View Administrator user interface for any View Connection Server instance in the pod federation.

To list the home sites for a user, run the lmvutil command with the --showUserHomeSites option.

lmvutil --showUserHomeSites --userName domain\username [--entitlementName name]

Option Description

--userName

--entitlementName

Name of the user for whom to list home sites. Use the format domain\username.

(Optional) Name of a global entitlement. Use this option to list the home sites for a user and global entitlement combination.

For example:

lmvutil --authAs adminEast --authDomain domainEast --authPassword "*" --showUserHomeSites -userName example\adminEast

To list the home sites for a group, run the lmvutil command with the --showGroupHomeSites option.

lmvutil --showGroupHomeSites --groupName domain\groupname [--entitlementName name]

Option Description

--groupName

--entitlementName

Name of the group for which to list home sites. Use the format domain\groupname.

(Optional) Name of a global entitlement. Use this option to list the home sites for a group and global entitlement combination.

For example:

lmvutil --authAs adminEast --authDomain domainEast --authPassword "*" --showGroupHomeSites -groupName example\adminEastGroup

28 VMware, Inc.

Chapter 4 Managing a Cloud Pod Architecture Environment

View Pod Federation Health in View Administrator

View constantly monitors the health of the pod federation by checking the health of each pod and View Connection Server instances in those pods. You can view the health of a pod federation in View Administrator.

You can also view the health of a pod federation from the command line by using the vdmadmin command with the -H option. For information about vdmadmin syntax, see the Setting Up Desktop and Application Pools in View document.

IMPORTANT View event databases are not shared across pods in a pod federation.

Procedure

1 Log in to the View Administrator user interface for any View Connection Server instance in the pod

federation.

2 In View Administrator, select Inventory > Dashboard.

The Remote Pods section in the System Health pane lists all pods, their member View Connection Server instances, and the known health status for each View Connection Server instance.

A green health icon indicates that the View Connection Server instance is online and available for the Cloud Pod Architecture feature. A red health icon indicates that the View Connection Server instance is offline or the Cloud Pod Architecture feature cannot connect to the View Connection Server instance to confirm its availability.

View Desktop and Application Sessions in the Pod Federation

You can use View Administrator to search for and view desktop and application sessions across the pod federation.

You can search for desktop and application sessions by user, pod, or brokering pod. The user is the end user who is connected to the desktop or application, the pod is the pod on which the desktop or application is hosted, and the brokering pod is the pod to which the user was connected when the desktop or application was first allocated.

Procedure

1 Log in to the View Administrator user interface for any View Connection Server instance in the pod

federation.

2 In View Administrator, select Inventory > Search Sessions.

3 Select search criteria and begin the search.

Option Action

Search by user

Search by pod

Search by brokering pod

a Select User from the drop-down menu.

b Click in the text box.

c Select search criteria in the Find User dialog box and click OK.

d Click Search to begin the search.

a Select Pod from the drop-down menu and select a pod from the list of

pods that appears.

b Click Search to begin the search.

a Select Brokering Pod from the drop-down menu and select a pod from

the list of pods that appears.

b Click Search to begin the search.

VMware, Inc. 29

Administering View Cloud Pod Architecture

The search results include the user, type of session (desktop or application), machine, pool or farm, pod, brokering pod ID, site, and global entitlements associated with each session. The session start time, duration, and state also appear in the search results.

NOTE The brokering pod ID is not immediately populated for new sessions in the search results. This ID usually appears in View Adminstrator between two and three minutes after a session begins.

Determine the Effective Home Site for a User

Because you can assign home sites to both users and groups, a single user can have multiple home sites. Home sites associated with global entitlements can override home sites associated with users and groups. For these reasons, it can be difficult to determine the effective home site for a particular user. You can use the lmvutil command to list a user's effective home site.

Prerequisites

Procedure

On any View Connection Server instance in the pod federation, run the lmvutil command with the

--resolveUserHomeSite option.

lmvutil --resolveUserHomeSite --entitlementName name --userName domain\username

Option Description

--entitlementName

--userName

For example:

lmvutil --authAs adminEast --authDomain domainEast --authPassword "*" --resolveUserHomeSite

--userName domainCentral\adminCentral

Add a Pod to a Site

You can use View Administrator to add a pod to an existing site.

Procedure

1 Log in to the View Administrator user interface for any View Connection Server instance in the pod

federation.

2 In View Administrator, select View Configuration > Sites.

3 Select the site that currently contains the pod to add to the site.

Name of a global entitlement. This option enables you to determine the effective home site for a user and global entitlement combination, which might be different from the home site that is configured for the user.

Name of the user whose home site you want to list. Use the format domain\username.

The names of the pods in the site appear in the lower pane.

4 Select the pod to add to the site and click Edit.

5 Select the site from the Site drop-down menu and click OK.

30 VMware, Inc.

Modifying Global Entitlements

You can add and remove desktop pools, users, and groups from global entitlements. You can also delete global entitlements and modify global entitlement attributes and policies.

Add a Pool to a Global Entitlement

You can use View Administrator to add a desktop pool to an existing global desktop entitlement, or add an application pool to an existing global application entitlement. You can add a particular pool to only one global entitlement.

Prerequisites

Create the desktop or application pool to add to the global entitlement. See the Setting Up Desktop and Application Pools in View document.

Procedure

1 Log in to the View Administrator user interface for any View Connection Server instance in the pod

that contains the pool to add to the global entitlement.

2 In View Administrator, select Catalog > Global Entitlements.

Chapter 4 Managing a Cloud Pod Architecture Environment

3 Double-click the global entitlement.

4 On the Local Pools tab, click Add, select the desktop or application pool to add, and click Add.

You can press the Ctrl and Shift keys to select multiple pools.

NOTE Pools that are already associated with a global entitlement or that do not meet the criteria for the global entitlement policies you selected are not displayed.

Remove a Pool from a Global Entitlement

You can use View Administrator to remove a pool from a global entitlement.

Procedure

1 Log in to the View Administrator user interface for any View Connection Server instance in the pod

that contains the pool to remove.

2 In View Administrator, select Catalog > Global Entitlements.

3 On the Local Pools tab, select the pool to remove from the global entitlement and click Delete.

Add a User or Group to a Global Entitlement

You can use View Administrator to add a user or group to an existing global entitlement.

Procedure

1 Log in to the View Administrator user interface for any View Connection Server instance in the pod

federation.

VMware, Inc. 31

Administering View Cloud Pod Architecture

2 In View Administrator, select Catalog > Global Entitlements and double-click the global entitlement.

3 On the Users and Groups tab, click Add.

4 Click Add, select one or more search criteria, and click Find to filter Active Directory users or groups

based on your search criteria

5 Select the Active Directory user or group to add to the global entitlement and click OK.

You can press the Ctrl and Shift keys to select multiple users and groups.

Remove a User or Group From a Global Entitlement

You can use View Administrator to remove a user or group from a global entitlement.

Procedure

1 Log in to the View Administrator user interface for any View Connection Server instance in the pod

federation.

2 In View Administrator, select Catalog > Global Entitlements and double-click the global entitlement.

3 On the Users and Groups tab, select the user or group to delete and click Delete.

You can press Ctrl or Shift to select multiple users and groups.

4 Click OK in the confirmation dialog box.

Modify Attributes or Policies for a Global Entitlement

You can use View Administrator to modify the name and description attributes and scope and other policies of a global entitlement.

NOTE You cannot modify the type of desktop pool that a global desktop entitlement can contain.

Procedure

1 Log in to the View Administrator user interface for any View Connection Server instance in the pod

federation.

2 In View Administrator, select Catalog > Global Entitlements

3 Select the global entitlement and click Edit.

4 To modify the name or description of the global entitlement, type a new name or description in the

Name or Description text box in the General pane.

The name can contain between 1 and 64 characters. The description can contain between 1 and 1024 characters.

32 VMware, Inc.

Chapter 4 Managing a Cloud Pod Architecture Environment

5 To modify a global entitlement policy, select or deselect the policy in the Policy pane.

Policy Description

Scope

Use home site

Entitled user must have home site

Automatically clean up redundant sessions

Default display protocol

HTML Access

Specifies where to look for desktops or applications that satisfy a desktop or application request from the global entitlement. You can select only one scope policy.

All sites - View looks for desktops or applications on any pod in the

pod federation.

Within site - View looks for desktops or applications only on pods in

the same site as the pod to which the user is connected.

Within pod - View looks for desktops or applications only in the pod

to which the user is connected.

Causes the global entitlement to be available only if the user has a home site. This option is available only when the Use home site option is selected.

Logs off extra user sessions for the same entitlement.. This option is available only for floating desktop entitlements and application entitlements.

(Global desktop entitlement only) Specifies the default display protocol for desktops in the global desktop entitlement.

Select whether to allow users to use the HTML Access feature to access desktops or applications in the global entitlement. With HTML Access, end users can use a Web browser to connect to remote desktops and are not required to install any client software on their local systems.

6 To modify the application path, version, and publisher information for a global application entitlement,

type values in the application text boxes.

NOTE If you add an application pool to the global application entitlement after you modify these values, the values are overwritten with values from the application pool.

7 Click OK to save your changes.

Delete a Global Entitlement

You can use View Administrator to permanently delete a global entitlement. When you delete a global entitlement, all of the users who are dependent on that global entitlement for desktops cannot access their desktops. Existing desktop sessions remain connected.

Procedure

1 Log in to the View Administrator user interface for any View Connection Server instance in the pod

federation.

2 In View Administrator, select Catalog > Global Entitlements.

3 Click the global entitlement to delete and click Delete.

VMware, Inc. 33

Administering View Cloud Pod Architecture

4 Click OK in the confirmation dialog box.

Remove a Home Site Association

You can use the lmvutil command to remove the association between a user or group and a home site. You can also remove the association between a home site and a global entitlement for a specified user or group.

Prerequisites

Procedure

To remove the association between a home site and a user, run the lmvutil command with the

--deleteUserHomeSite option.

You can run this command on any View Connection Server instance in the pod federation.

lmvutil --deleteUserHomeSite --userName domain\username [--entitlementName name]

Option Description

--userName

--entitlementName

For example:

Name of the user. Use the format domain\username.

(Optional) Name of a global entitlement. Use this option to remove the association between the home site and a global entitlement for the specified user.

lmvutil --authAs adminEast --authDomain domainEast --authPassword "*" --deleteUserHomeSite -userName domainCentral\adminCentral

To remove the association between a home site and a group, run the lmvutil command with the

--deleteGroupHomeSite option.

You can run this command on any View Connection Server instance in the pod federation.

lmvutil --deleteGroupHomeSite --groupName domain\groupname [--entitlementName name]

Option Description

--groupName

--entitlementName

Name of the group. Use the format domain\groupname.

(Optional) Name of a global entitlement. Use this option to remove the association between the home site and a global entitlement for the specified group.

For example:

lmvutil --authAs adminEast --authDomain domainEast --authPassword "*" --deleteGroupHomeSite

--groupName domainCentral\adminCentralGroup

34 VMware, Inc.

Remove a Pod From the Pod Federation

You can use View Administrator to remove a pod that was previously joined to the pod federation. You might want to remove a pod from the pod federation if it is being recommissioned for another purpose or if it was wrongly configured.

To remove the last pod in the pod federation, you unitialize the Cloud Pod Architecture feature. See

“Uninitialize the Cloud Pod Architecture Feature,” on page 35.

IMPORTANT Do not stop or start a View Connection Server instance while it is being removed from a pod federation. The View Connection Server service might not restart correctly.

Procedure

1 Log in to the View Administrator user interface for any View Connection Server instance in the pod

that you want to remove from the pod federation.

2 In View Administrator, select Cloud Pod Architecture and click Unjoin in the Pod Federation pane.

3 Click OK to begin the unjoin operation.

View Administrator shows the progress of the unjoin operation.

4 When View Administrator prompts you to reload the client, click OK.

Chapter 4 Managing a Cloud Pod Architecture Environment

After the View Administrator user interface is refreshed, Global Entitlements no longer appears under Catalog and Sites no longer appears under View Configuration in the View Administrator Inventory

panel.

Uninitialize the Cloud Pod Architecture Feature

You can use View Administrator to uninitialize the Cloud Pod Architecture feature.

Prerequisites

You need to uninitialize the Cloud Pod Architecture feature on only one pod in the pod federation. If the pod federation contains multiple pods, you must unjoin the other pods before you begin the uninitialization process. See “Remove a Pod From the Pod Federation,” on page 35.

Procedure

1 Log in to the View Administrator user interface for any View Connection Server instance in the pod.

2 In View Administrator, select View Configuration > Cloud Pod Architecture.

3 In the Pod Federation pane, click Uninitialize.

4 Click OK to begin the uninitialization process.

After the uninitialization process is finished, your entire Cloud Pod Architecture configuration, including sites, home sites, and global entitlements, is deleted.

5 When View Administrator prompts you to reload the client, click OK.

After the View Administrator user interface is refreshed, Global Entitlements no longer appears under Catalog and Sites no longer appears under View Configuration in the View Administrator Inventory panel.

VMware, Inc. 35

Administering View Cloud Pod Architecture

36 VMware, Inc.

lmvutil Command Reference 5

You use the lmvutil command-line interface to configure and manage a Cloud Pod Architecture implementation.

NOTE You can use the vdmutil command-line interface to perform the same operations as lmvutil.

This chapter includes the following topics:

“lmvutil Command Use,” on page 37

“Initializing the Cloud Pod Architecture Feature,” on page 40

“Disabling the Cloud Pod Architecture Feature,” on page 41

“Managing Pod Federations,” on page 41

“Managing Sites,” on page 43

“Managing Global Entitlements,” on page 46

“Managing Home Sites,” on page 53

“Viewing a Cloud Pod Architecture Configuration,” on page 55

“Managing SSL Certificates,” on page 60

lmvutil Command Use

The syntax of the lmvutil command controls its operation.

Use the following form of the lmvutil command from a Windows command prompt.

lmvutil command_option [additional_option argument] ...

Alternatively, you can use the vdmutil command to perform the same operations as the lmvutil command. Use the following form of the vdmutil command from a Windows command prompt.

vdmutil command_option [additional_option argument] ...

The additional options that you can use depend on the command option.

By default, the path to the lmvutil and vdmutil command executable files is C:\Program

Files\VMware\VMware View\Server\tools\bin. To avoid entering the path on the command line, add the

path to your PATH environment variable.

VMware, Inc.

Administering View Cloud Pod Architecture

lmvutil Command Authentication

To use the lmvutil command to configure and manage a Cloud Pod Architecture environment, you must run the command as a user who has the Administrators role.

You can use View Administrator to assign the Administrators role to a user. See the View Administration document.

The lmvutil command includes options to specify the user name, domain, and password to use for authentication.

Table 5‑1. lmvutil Command Authentication Options

Option Description

--authAs

--authDomain

--authPassword Password for the View administrator user specified in the --authAs option. Entering

Name of a View administrator user. Do not use domain\username or user principal name (UPN) format.

Fully qualified domain name for the View administrator user specified in the

--authAs option.

"*" instead of a password causes the lmvutil command to prompt for the password and does not leave sensitive passwords in the command history on the command line.

For example, the following lmvutil command logs in the user domainEast\adminEast and initializes the Cloud Pod Architecture feature.

lmvutil --authAs adminEast --authDomain domainEast --authPassword "*" --initialize

You must use the authentication options with all lmvutil command options except for --help and

--verbose.

lmvutil Command Output

The lmvutil command returns 0 when an operation succeeds and a failure-specific non-zero code when an operation fails.

The lmvutil command writes error messages to standard error. When an operation produces output, or when verbose logging is enabled by using the --verbose option, the lmvutil command writes output to standard output.

The lmvutil command produces only US English output.

lmvutil Command Options

You use the command options of the lmvutil command to specify the operation to perform. All options are preceded by two hyphens (--).

For lmvutil command authentication options, see “lmvutil Command Authentication,” on page 38.

Table 5‑2. lmvutil Command Options

Option Description

--activatePendingCertificate

--addGroupEntitlement

Activates a pending SSL certificate. See “Activating a

Pending Certificate,” on page 60.

Associates a user group with a global entitlement. See

“Adding a User or Group to a Global Entitlement,” on

page 52.

38 VMware, Inc.

Chapter 5 lmvutil Command Reference

Table 5‑2. lmvutil Command Options (Continued)

Option Description

--addPoolAssociation

--addUserEntitlement

--assignPodToSite

--createGlobalApplicationEntitlement

--createGlobalEntitlement

--createSite

--createGroupHomeSite

--createPendingCertificate

--createUserHomeSite

--deleteGlobalApplicationEntitlement

--deleteGlobalEntitlement

--deleteSite

--deleteGroupHomeSite

--deleteUserHomeSite

--editSite

--ejectPod

--help Lists the lmvutil command options.

--initialize

--join

--listAssociatedPools

--listEntitlements

--listGlobalApplicationEntitlements

--listGlobalEntitlements

Associates a desktop pool with a global desktop entitlement or an application pool with a global application entitlement. See “Adding a Pool to a Global Entitlement,” on page 50.

Associates a user with a global entitlement. See “Adding a

User or Group to a Global Entitlement,” on page 52

Assigns a pod to a site. See “Assigning a Pod to a Site,” on page 44.

Creates a global application entitlement. See “Creating a

Global Entitlement,” on page 46.

Creates a global desktop entitlement. See “Creating a

Global Entitlement,” on page 46.

Creates a site. See “Creating a Site,” on page 44.

Associates a user group with a home site. See “Configuring

a Home Site,” on page 54.

Creates a pending SSL certificate. See “Creating a Pending

Certificate,” on page 60.

Associates a user with a home site. See “Configuring a

Home Site,” on page 54.

Deletes a global application entitlement. See “Deleting a

Global Entitlement,” on page 50.

Deletes a global deskop entitlement. See “Deleting a Global

Entitlement,” on page 50.

Deletes a site. See “Deleting a Site,” on page 45.

Removes the association between a user group and a home site. See “Deleting a Home Site,” on page 55.

Removes the association between a user and a home site. See “Deleting a Home Site,” on page 55.

Modifies the name or description of a site. See “Changing a

Site Name or Description,” on page 45.

Removes an unavailable pod from a pod federation. See

“Removing a Pod From a Pod Federation,” on page 42.

Initializes the Cloud Pod Architecture feature. See

“Initializing the Cloud Pod Architecture Feature,” on

page 40.

Joins a pod to a pod federation. See “Joining a Pod to the

Pod Federation,” on page 42.

Lists the desktop pools that are associated with a global desktop entitlement or the application pools that are associated with a global application entitlement. See

“Listing the Pools in a Global Entitlement,” on page 56.

Lists associations between users or user groups and global entitlements. “Listing the Users or Groups in a Global

Entitlement,” on page 57.

Lists all global application entitlements. See “Listing Global

Entitlements,” on page 56.

Lists all global desktop entitlements. See “Listing Global

Entitlements,” on page 56.

VMware, Inc. 39

Administering View Cloud Pod Architecture

Table 5‑2. lmvutil Command Options (Continued)

Option Description

--listPods

--listSites

--listUserAssignments

--removePoolAssociation

--resolveUserHomeSite

--removeGroupEntitlement

--removeUserEntitlement

--showGroupHomeSites

--showUserHomeSites

--uninitialize

--unjoin

--updateGlobalApplicationEntitlement

--updateGlobalEntitlement

--updatePod

--verbose

Lists the pods in a Cloud Pod Architecture topology. See

“Listing the Pods or Sites in a Cloud Pod Architecture Topology,” on page 59.

Lists the sites in a Cloud Pod Architecture topology. See

“Listing the Pods or Sites in a Cloud Pod Architecture Topology,” on page 59.

Lists the dedicated desktop pod assignments for a user and global entitlement combination. See “Listing Dedicated

Desktop Pool Assignments,” on page 59.

Removes the association between a desktop pool and a global entitlement. See “Removing a Pool from a Global

Entitlement,” on page 51.

Shows the effective home site for a user. See “Listing the

Effective Home Site for a User,” on page 58.

Removes a user group from a global entitlement. See

“Removing a User or Group From a Global Entitlement,”

on page 53.

Removes a user from a global entitlement. See “Removing

a User or Group From a Global Entitlement,” on page 53.

Shows all of the home sites for a group. See “Listing the

Home Sites for a User or Group,” on page 57.

Shows all of the home sites for a user. See “Listing the

Home Sites for a User or Group,” on page 57.

Disables the Cloud Pod Architecture feature. See

“Disabling the Cloud Pod Architecture Feature,” on

page 41.

Removes an available pod from a pod federation. See

“Removing a Pod From a Pod Federation,” on page 42.

Modifes a global application entitlement. See “Modifying a

Global Entitlement,” on page 48.

Modifies a global desktop entitlement. See “Modifying a

Global Entitlement,” on page 48.

Modifies the name or description of a pod. See “Changing

a Pod Name or Description,” on page 43.

Enables verbose logging. You can add this option to any other option to obtain detailed command output. The lmvutil command writes to standard output.

Initializing the Cloud Pod Architecture Feature

Use the lmvutil command with the --initialize option to initialize the Cloud Pod Architecture feature. When you initialize the Cloud Pod Architecture feature, View sets up the Global Data Layer on each View Connection Server instance in the pod and configures the VIPA communication channel.

Syntax

lmvutil --initialize

40 VMware, Inc.

Usage Notes

Run this command only once, on one View Connection Server instance in the pod. You can run the command on any View Connection Server instance in the pod. You do not need to run this command for additional pods. All other pods join the initialized pod.

This command returns an error message if the Cloud Pod Architecture feature is already initialized or if the command cannot complete the operation.

Example

lmvutil --authAs adminEast --authDomain domainEast --authPassword "*" --initialize

Disabling the Cloud Pod Architecture Feature

Use the lmvutil command with the --uninitialize option to disable the Cloud Pod Architecture feature.

Syntax

lmvutil --uninitialize

Chapter 5 lmvutil Command Reference

Usage Notes

Before you run this command, use the lmvutil command with the --unjoin option to remove any other pods in the pod federation.

Run this command on only one View Connection Server instance in a pod. You can run the command on any View Connection Server instance in the pod. If your pod federation contains multiple pods, you need to run this command for only one pod.

This command returns an error message if the Cloud Pod Architecture feature is not initialized, if the command cannot find the pod, or if the pod federation contains other pods.

Example

lmvutil --authAs adminEast --authDomain domainEast --authPassword "*" --uninitialize

Managing Pod Federations

The lmvutil command provides options to configure and modify pod federations.

Joining a Pod to the Pod Federation on page 42

Use the lmvutil command with the --join option to join a pod to the pod federation.

Removing a Pod From a Pod Federation on page 42

Use the lmvutil command with the --unjoin or --ejectPod option to remove a pod from a pod federation.

Changing a Pod Name or Description on page 43

Use the lmvutil command with the --updatePod option to update or modify the name or description of a pod.

VMware, Inc. 41

Administering View Cloud Pod Architecture

Joining a Pod to the Pod Federation

Use the lmvutil command with the --join option to join a pod to the pod federation.

Syntax

lmvutil --join joinServer serveraddress --userName domain\username --password password

Usage Notes

You must run this command on each pod that you want to join to the pod federation. You can run the command on any View Connection Server instance in a pod.

This command returns an error message if you provide invalid credentials, the specified View Connection Server instance does not exist, a pod federation does not exist on the specified server, or the command cannot complete the operation.

Options

You must specify several options when you join a pod to a pod federation.

Table 5‑3. Options for Joining a Pod to a Pod Federation

Option Description

--joinServer

--userName

--password Password of the user specified in the --userName option.

DNS name or IP address of any View Connection Server instance in any pod that has been initialized or is already part of the pod federation.

Name of a View administrator user on the already initialized pod. Use the format domain\username.

Example

lmvutil --authAs adminEast --authDomain domainEast --authPassword "*" --join

--joinServer 123.456.789.1 --userName domainCentral\adminCentral --password secret123

Removing a Pod From a Pod Federation

Use the lmvutil command with the --unjoin or --ejectPod option to remove a pod from a pod federation.

Syntax

lmvutil --unjoin

lmvutil --ejectPod --pod pod

Usage Notes

To remove a pod from a pod federation, use the --unjoin option. You can run the command on any View Connection Server instance in the pod.

To remove a pod that is not available from a pod federation, use the --ejectPod option. For example, a pod might become unavailable if a hardware failure occurs. You can perform this operation on any pod in the pod federation.

IMPORTANT In most circumstances, you should use the --unjoin option to remove a pod from a pod federation.

42 VMware, Inc.

Chapter 5 lmvutil Command Reference

These commands return an error message if the Cloud Pod Architecture feature is not initialized, the pod is not joined to a pod federation, or if the commands cannot perform specified operations.

Options

When you use the --ejectPod option, you use the --pod option to identify the pod to remove from the pod federation.

Example

lmvutil --authAs adminEast --authDomain domainEast --authPassword "*" --unjoin

lmvutil --authAs adminEast --authDomain domainEast --authPassword "*" --ejectPod

--pod "East Pod 1"

Changing a Pod Name or Description

Use the lmvutil command with the --updatePod option to update or modify the name or description of a pod.

Syntax

lmvutil --updatePod --podName podname [--newPodName podname] [--description text]

Usage Notes

This command returns an error message if the Cloud Pod Architecture feature is not initialized or if the command cannot find or update the pod.

Options

You can specify these options when you update a pod name or description.

Table 5‑4. Options for Changing a Pod Name or Description

Option Description

--podName

--newPodName

--description

Example

lmvutil --authAs adminEast --authDomain domainEast --authPassword "*"

--updatePod --podName "East Pod 1" --newPodName "East Pod 2"

Managing Sites

You can use lmvutil command options to create, modify, and delete Cloud Pod Architecture sites. A site is a grouping of View pods.

Name of the pod to update.

(Optional) New name for the pod. A pod name can contain between 1 and 64 characters.

(Optional) Description of the site. The description can contain between 1 and 1024 characters.

Creating a Site on page 44

Use the lmvutil command with the --createSite option to create a site in a Cloud Pod Architecture topology.

Assigning a Pod to a Site on page 44

Use the lmvutil command with the --assignPodToSite option to assign a pod to a site.

VMware, Inc. 43

Administering View Cloud Pod Architecture

Changing a Site Name or Description on page 45

Use the lmvutil command with the --editSite option to edit the name or description of a site.

Deleting a Site on page 45

Use the lmvutil command with the --deleteSite option to delete a site.

Creating a Site

Use the lmvutil command with the --createSite option to create a site in a Cloud Pod Architecture topology.

Syntax

lmvutil --createSite --siteName sitename [--description text]

Usage Notes

This command returns an error message if the Cloud Pod Architecture feature is not initialized, the specified site already exists, or the command cannot create the site.

Options

You can specify these options when you create a site.

Table 5‑5. Options for Creating a Site

Option Description

--siteName

--description

Name of the new site. The site name can contain between 1 and 64 characters.

(Optional) Description of the site. The description can contain between 1 and 1024 characters.

Example

lmvutil --authAs adminEast --authDomain domainEast --authPassword "*" --createSite

--siteName "Eastern Region"

Assigning a Pod to a Site

Use the lmvutil command with the --assignPodToSite option to assign a pod to a site.

Syntax

lmvutil --assignPodToSite --podName podname --siteName sitename

Usage Notes

Before you can assign a pod to a site, you must create the site. See “Creating a Site,” on page 44.

This command returns an error message if the Cloud Pod Architecture feature is not initialized, the command cannot find the specified pod or site, or if the command cannot assign the pod to the site.

Options

You must specify these options when you assign a pod to a site.

44 VMware, Inc.

Chapter 5 lmvutil Command Reference

Table 5‑6. Options for Assigning a Pod to a Site

Option Description

--podName

--siteName

Name of the pod to assign to the site.

Name of the site.

You can use the lmvutil command with the --listPods option to list the names of the pods in a Cloud Pod Architecture topology. See “Listing the Pods or Sites in a Cloud Pod Architecture Topology,” on page 59.

Example

lmvutil --authAs adminEast --authDomain domainEast --authPassword "*"

--assignPodToSite --podName "East Pod 1" --siteName "Eastern Region"

Changing a Site Name or Description

Use the lmvutil command with the --editSite option to edit the name or description of a site.

Syntax

lmvutil --editSite --siteName sitename [--newSiteName sitename] [--description text]

Usage Notes

This command returns an error message if the specified site does not exist or if the command cannot find or update the site.

Options

You can specify these options when you change a site name or description.

Table 5‑7. Options for Changing a Site Name or Description

Option Description

--siteName

--newSiteName

--description

Name of the site to edit.

(Optional) New name for the site. The site name can contain between 1 and 64 characters.

(Optional) Description of the site. The description can contain between 1 and 1024 characters.

Example

lmvutil --authAs adminEast --authDomain domainEast --authPassword "*" --editSite

--siteName "Eastern Region" --newSiteName "Western Region"

Deleting a Site

Use the lmvutil command with the --deleteSite option to delete a site.

Syntax

lmvutil --deleteSite --sitename sitename

Usage Notes

This command returns an error message if the specified site does not exist or if the command cannot find or delete the site.

VMware, Inc. 45

Administering View Cloud Pod Architecture

Options

You use the --sitename option to specify the name of the site to delete.

Example

lmvutil --authAs adminEast --authDomain domainEast --authPassword "*"

--deleteSite --sitename "Eastern Region"

Managing Global Entitlements

You can use lmvutil command options to create, modify, and list global desktop entitlements and global application entitlements in a Cloud Pod Architecture environment.

Creating a Global Entitlement on page 46

To create a global desktop entitlement, use the lmvutil command with the

--createGlobalEntitlement option. To create a global application entitlement, use the lmvutil command with the --createGlobalApplicationEntitlement option.

Modifying a Global Entitlement on page 48

To modify a global desktop entitlement, use the lmvutil command with the

--updateGlobalEntitlement option. To modify a global application entitlement, use the lmvutil command with the --updateGlobalApplicationEntitlement option.

Deleting a Global Entitlement on page 50

To delete a global desktop entitlement, use the lmvutil command with the

--deleteGlobalEntitlement option. To delete a global application entitlement, use the lmvutil command with the --deleteGlobalApplicationEntitlement option.

Adding a Pool to a Global Entitlement on page 50

Use the lmvutil command with the --addPoolAssociation option to add a desktop pool to a global desktop entitlement or an application pool to a global application entitlement.

Removing a Pool from a Global Entitlement on page 51

Use the lmvutil command with the --removePoolAssociation option to remove a desktop pool from a global desktop entitlement or an application pool from a global application entitlement.

Adding a User or Group to a Global Entitlement on page 52

To add a user to a global entitlement, use the lmvutil command with the --addUserEntitlement option. To add a group to a global entitlement, use the lmvutil command with the

--addGroupEntitlement option.

Removing a User or Group From a Global Entitlement on page 53

To remove a user from a global entitlement, use the lmvutil command with the

--removeUserEntitlement option. To remove a group from a global entitlement, use the lmvutil command with the --removeGroupEntitlement option.

Creating a Global Entitlement

To create a global desktop entitlement, use the lmvutil command with the --createGlobalEntitlement option. To create a global application entitlement, use the lmvutil command with the

--createGlobalApplicationEntitlement option.

Global entitlements provide the link between users and their desktops and applications, regardless of where those desktops and applications reside in the pod federation. Global entitlements also include policies that determine how the Cloud Pod Architecture feature allocates desktops and applications to entitled users.

46 VMware, Inc.

Chapter 5 lmvutil Command Reference

Syntax

lmvutil --createGlobalEntitlement --entitlementName name --scope scope {--isDedicated | --isFloating} [--description text] [--disabled] [--fromHome] [--multipleSessionAutoClean] [--requireHomeSite] [--defaultProtocol value] [--htmlAccess]

lmvutil --createGlobalApplicationEntitlement --entitlementName name --scope scope [--description text] [--disabled] [--fromHome] [--multipleSessionAutoClean] [--requireHomeSite] [--htmlAccess]

Usage Notes

You can use these commands on any View Connection Server instance in a pod federation. View stores new data in the Global Data Layer and replicates that data in all pods in the pod federation.

These commands return an error message if the global entitlement already exists, the scope is invalid, the Cloud Pod Architecture feature is not initialized, or the commands cannot create the global entitlement.

Options

You can specify these options when you create a global entitlement. Some options apply only to global desktop entitlements.

Table 5‑8. Options for Creating Global Entitlements

Option Description

--entitlementName

--scope

--isDedicated

--isFloating

--disabled

--description

--fromHome

Name of the global entitlement. The name can contain between 1 and 64 characters. The global entitlement name appears in the desktops and applications list in Horizon Client for entitled users.

Scope of the global entitlement. Valid values are as follows:

ANY. View looks for resources on any pod in the pod federation.

SITE. View looks for resources only on pods in the same site as the

pod to which the user is connected.

LOCAL. View looks for resources only in the pod to which the user is

connected.

Creates a dedicated desktop entitlement. A dedicated desktop entitlement can contain only dedicated desktop pools. To create a floating desktop entitlement, use the --isFloating option. A global desktop entitlement can be either dedicated or floating. You cannot specify the

--isDedicated option with the --multipleSessionAutoClean option.

Applies only to global desktop entitlements.

Creates a floating desktop entitlement. A floating desktop entitlement can contain only floating desktop pools. To create a dedicated desktop entitlement, specify the --isDedicated option. A global desktop entitlement can be either floating or dedicated.

Applies only to global desktop entitlements.

(Optional) Creates the global entitlement in the disabled state.

(Optional) Description of the global entitlement. The description can contain between 1 and 1024 characters.

(Optional) If the user has a home site, causes View to look for resources on the user's home site. If the user does not have a home site, View begins searching for resources on the site to which the user is currently connected.

VMware, Inc. 47

Administering View Cloud Pod Architecture

Table 5‑8. Options for Creating Global Entitlements (Continued)

Option Description

--multipleSessionAutoClean

--requireHomeSite

--defaultProtocol

--htmlAccess

(Optional) Logs off extra user sessions for the same entitlement. Multiple sessions can occur when a pod that contains a session goes offline, the user logs in again and starts another session, and the problem pod comes back online with the original session.

When multiple sessions occur, Horizon Client prompts the user to select a session. This option determines what happens to sessions that the user does not select.

If you do not specify this option, users must manually end their own extra sessions, either by logging off in Horizon Client or by launching the sessions and logging them off.

(Optional) Causes the global entitlement to be available only if the user has a home site. This option is applicable only when the --fromHome option is also specified.

(Optional) Default display protocol for desktops in the global desktop entitlement. Valid values are RDP and PCOIP.

Applies only to global desktop entitlements.

(Optional) When you specify this option, users can use the HTML Access feature to access resources in the global entitlement. With HTML Access, end users can use a Web browser to access remote resources and are not required to install any client software on their local systems.

Examples

lmvutil --authAs adminEast --authDomain domainEast --authPassword "*" --createGlobalEntitlement

--entitlementName "Windows 8 Desktop" --scope LOCAL --isDedicated

lmvutil --authAs adminEast --authDomain domainEast --authPassword "*" -createGlobalApplicationEntitlement --entitlementName "Microsoft Office PowerPoint" --scope LOCAL

Modifying a Global Entitlement

To modify a global desktop entitlement, use the lmvutil command with the --updateGlobalEntitlement option. To modify a global application entitlement, use the lmvutil command with the

--updateGlobalApplicationEntitlement option.

Syntax

lmvutil --updateGlobalEntitlement --entitlementName name [--scope scope] [--description text] [--disabled] [--enabled] [--fromHome] [--disableFromHome] [--multipleSessionAutoClean] [--disableMultipleSessionAutoClean][--requireHomeSite] [--disableRequireHomeSite] [--defaultProtocol value] [--htmlAccess] [--disableHtmlAccess]

lmvutil --updateGlobalApplicationEntitlement --entitlementName name [--scope scope] [--description text] [--disabled] [--enabled] [--fromHome] [--disableFromHome] [--multipleSessionAutoClean] [--disableMultipleSessionAutoClean] [--requireHomeSite] [--disableRequireHomeSite] [--htmlAccess] [--disableHtmlAccess] [--appVersion value] [--appPublisher value] [--appPath value]

Usage Notes

You can use these commands on any View Connection Server instance in a pod federation. View stores new data in the Global Data Layer and replicates that data among all pods in the pod federation.

These commands return an error message if the global entitlement does not exist, the scope is invalid, the Cloud Pod Architecture feature is not initialized, or the commands cannot update the global entitlement.

48 VMware, Inc.

Chapter 5 lmvutil Command Reference

Options

You can specify these options when you modify a global entitlement. Some options apply only to global desktop entitlements or only to global application entitlements.

Table 5‑9. Options for Modifying Global Entitlements

Option Description

--entitlementName

--scope

--description

--disabled

--enabled

--fromHome

--disableFromHome (Optional) Disables the --fromHome option function if the --fromHome

--multipleSessionAutoClean

--disableMultipleSessionAutoClean (Optional) Disables the --multipleSessionAutoClean option function

--requireHomeSite

--disableRequireHomeSite (Optional) Disables the --requireHomeSite option function if the

--defaultProtocol

--htmlAccess

--disableHtmlAccess (Optional) Disables the --htmlAccess option function if the

Name of the global entitlement to modify.

Scope of the global entitlement. Valid values are as follows:

ANY. View looks for resources on any pod in the pod federation.

SITE. View looks for resources only on pods in the same site as the

pod to which the user is connected.

LOCAL. View looks for resources only in the pod to which the user

is connected.

(Optional) Description of the global entitlement. The description can contain between 1 and 1024 characters.

(Optional) Disables a previously enabled global entitlement.

(Optional) Enables a previously disabled global entitlement.

option was previously specified for the global entitlement.

When multiple sessions occur, Horizon Client prompts the user to select a session. This option determines what happens to sessions that the user does not select.

If you do not specify this option, users must manually end their own extra sessions, either by logging off in Horizon Client or by launching the sessions and logging them off.

if the --multipleSessionAutoClean option was previously specified for the global entitlement.

(Optional) Causes the global entitlement to be available only if the user has a home site. This option is applicable only when the --fromHome option is also specified.

--requireHomeSite option was previously specified for the global entitlement.

(Optional) Default display protocol for desktops in the global desktop entitlement. Valid values are RDP and PCOIP.

Applies only to global desktop entitlements.

--htmlAccess option was previously specified for the global entitlement.

VMware, Inc. 49

Administering View Cloud Pod Architecture

Table 5‑9. Options for Modifying Global Entitlements (Continued)

Option Description

--appVersion

--appPublisher

--appPath (Optional) Full pathname of the application, for example, C:\Program

Examples

lmvutil --authAs adminEast --authDomain domainEast --authPassword "*" --updateGlobalEntitlement

--entitlementName "Windows 8 Desktop" --scope ANY --isDedicated

lmvutil --authAs adminEast --authDomain domainEast --authPassword "*"

--updateGlobalApplicationEntitlement --entitlementName "Microsoft Office PowerPoint" --scope ANY

Deleting a Global Entitlement

To delete a global desktop entitlement, use the lmvutil command with the --deleteGlobalEntitlement option. To delete a global application entitlement, use the lmvutil command with the

--deleteGlobalApplicationEntitlement option.

(Optional) Version of the application.

Applies only to global application entitlements.

(Optional) Publisher of the application.

Applies only to global application entitlements.

Files\app1.exe.

Applies only to global application entitlements.

Syntax

lmvutil --deleteGlobalEntitlement --entitlementName name

lmvutil --deleteGlobalApplicationEntitlement --entitlementName name

Command Usage

These commands return an error message if the specified global entitlement does not exist, the Cloud Pod Architecture feature is not initialized, or the commands cannot delete the global entitlement.

Options

You use the --entitlementName option to specify the name of the global entitlement to delete.

Examples

lmvutil --authAs adminEast --authDomain domainEast --authPassword "*"

--deleteGlobalEntitlement --entitlementName "Windows 8 Desktop"

lmvutil --authAs adminEast --authDomain domainEast --authPassword "*"

--deleteGlobalApplicationEntitlement --entitlementName "Microsoft Office PowerPoint"

Adding a Pool to a Global Entitlement

Use the lmvutil command with the --addPoolAssociation option to add a desktop pool to a global desktop entitlement or an application pool to a global application entitlement.

Syntax

lmvutil --addPoolAssociation --entitlementName name --poolId poolid

50 VMware, Inc.

Chapter 5 lmvutil Command Reference

Usage Notes

You must use this command on a View Connection Server instance in the pod that contains the pool. For example, if pod1 contains a desktop pool to associate with a global desktop entitlement, you must run the command on a View Connection Server instance that resides in pod1.

Repeat this command for each pool to become part of the global entitlement. You can add a particular pool to only one global entitlement.

IMPORTANT If you add multiple application pools to a global application entitlement, you must add the same application. For example, do not add Calculator and Microsoft Office PowerPoint to the same global application entitlement. If you add different applications, the results will be unpredictable and entitled users will receive different applications at different times.

This command returns an error message if the Cloud Pod Architecture feature is not initialized, the specified entitlement does not exist, the pool is already associated with the specified entitlement, the pool does not exist, or the command cannot add the pool to the global entitlement.

Options

You can specify these options when you add a pool to a global entitlement.

Table 5‑10. Options for Adding a Pool to a Global Entitlement

Option Description

--entitlementName

--poolID

Name of the global entitlement.

ID of the pool to add to the global entitlement. The pool ID must match the pool name as it appears on the pod.

Example

lmvutil --authAs adminEast --authDomain domainEast --authPassword "*" --addPoolAssociation

--entitlementName "Windows 8 Desktop" --poolId "Windows 8 Desktop Pool A"

Removing a Pool from a Global Entitlement

Use the lmvutil command with the --removePoolAssociation option to remove a desktop pool from a global desktop entitlement or an application pool from a global application entitlement.

Syntax

lmvutil --removePoolAssociation --entitlementName name --poolID poolid

Usage Notes

This command returns an error message if the Cloud Pod Architecture feature is not initialized, the specified global entitlement or pool does not exist, or if the command cannot remove the pool from the global entitlement.

Options

You can specify these options when you remove a pool from a global entitlement.

VMware, Inc. 51

Administering View Cloud Pod Architecture

Table 5‑11. Options for Removing a Pool from a Global Entitlement

Option Description

--entitlementName

--poolID

Name of the global entitlement.

ID of the pool to remove from the global entitlement. The pool ID must match the pool name as it appears on the pod.

Example

lmvutil --authAs adminEast --authDomain domainEast --authPassword "*"

--removePoolAssociation --entitlementName "Windows 8 Desktop" --poolID "Windows 8 Desktop Pool A"

Adding a User or Group to a Global Entitlement

To add a user to a global entitlement, use the lmvutil command with the --addUserEntitlement option. To add a group to a global entitlement, use the lmvutil command with the --addGroupEntitlement option.

Syntax

lmvutil --addUserEntitlement --userName domain\username --entitlementName name

lmvutil --addGroupEntitlement --groupName domain\groupname --entitlementName name

Usage Notes

Repeat these commands for each user or group to add to the global entitlement.

These commands return an error message if the specified entitlement, user, or group does not exist or if the command cannot add the user or group to the entitlement.

Options

You can specify these options when you add a user or group to a global entitlement.

Table 5‑12. Options for Adding a User or Group to a Global Entitlement

Option Description

--userName

--groupName

--entitlementName

Name of a user to add to the global entitlement. Use the format domain\username.

Name of a group to add to the global entitlement. Use the format domain\groupname.

Name of the global entitlement to which to add the user or group.

Examples

lmvutil --authAs adminEast --authDomain domainEast --authPassword "*" --addUserEntitlement

--userName domainCentral\adminCentral --entitlementName "Agent Sales"

lmvutil --authAs adminEast --authDomain domainEast --authPassword "*"

--addGroupEntitlement --groupName domainCentral\adminCentralGroup --entitlementName "Agent Sales"

52 VMware, Inc.

Chapter 5 lmvutil Command Reference

Removing a User or Group From a Global Entitlement

To remove a user from a global entitlement, use the lmvutil command with the

--removeUserEntitlement option. To remove a group from a global entitlement, use the lmvutil command with the --removeGroupEntitlement option.

Syntax

lmvutil --removeUserEntitlement --userName domain\username --entitlementName name

lmvutil --removeGroupEntitlement --groupName domain\groupname --entitlementName name

Usage Notes

These commands return an error message if the Cloud Pod Architecture feature is not initialized, if the specified user name, group name, or entitlement does not exist, or if the command cannot remove the user or group from the entitlement.

Options

You must specify these options when you remove a user or group from a global entitlement.

Table 5‑13. Options for Removing a User or Group From a Global Entitlement

Option Description

--userName

--groupName

--entitlementName

Name of a user to remove from the global entitlement. Use the format domain\username.

Name of a group to remove from the global entitlement. Use the format domain\groupname.

Name of the global entitlement from which to remove the user or group.

Examples

lmvutil --authAs adminEast --authDomain domainEast --authPassword "*"

--removeUserEntitlement --userName domainCentral\adminCentral --entitlementName "Agent Sales"

lmvutil --authAs adminEast --authDomain domainEast --authPassword "*"

--removeGroupEntitlement --groupName domainCentral\adminCentralGroup --entitlementName "Agent Sales"

Managing Home Sites

You can use lmvutil command options to create, modify, delete, and list home sites. You can associate a user or group with a home site to restrict desktop and application choice to a particular site.

Configuring a Home Site on page 54

To create a home site for a user, use the lmvutil command with the --createUserHomeSite option. To create a home site for a group, use the lmvutil command with the --createGroupHomeSite option. You can also use these options to associate a home site with a global desktop entitlement or global application entitlement.

Deleting a Home Site on page 55

To remove the association between a user and a home site, use the lmvutil command with the

--deleteUserHomeSite option. To remove the association between a group and a home site, use the

lmvutil command with the --deleteGroupHomeSite option.

VMware, Inc. 53

Administering View Cloud Pod Architecture

Configuring a Home Site

Syntax

lmvutil --createUserHomeSite --userName domain\username --siteName name [--entitlementName name]

lmvutil --createGroupHomeSite --groupName domain\groupname --siteName name [--entitlementName name]

Usage Notes

You must create a site before you can configure it as a home site. See “Creating a Site,” on page 44.

These commands return an error message if the Cloud Pod Architecture feature is not initialized, the specified user or group does not exist, the specified site does not exist, the specified entitlement does not exist, or the commands cannot create the home site.

Options

You can specify these options when you create a home site for a user or group.

Table 5‑14. Options for Creating a Home Site for a User or Group

Option Description

--userName

--groupName

--siteName

--entitlementName

Name of a user to associate with the home site. Use the format domain\username.

Name of a group to associate with the home site. Use the format domain\groupname.

Name of the site to associate with the user or group as the home site.

(Optional) Name of a global desktop entitlement or global application entitlement to associate with the home site. When a user selects the specified global entitlement, the home site overrides the user's own home site. If you do not specify this option, the command creates a global user or group home site.

Examples

lmvutil --authAs adminEast --authDomain domainEast --authPassword "*" --createUserHomeSite -userName domainEast\adminEast --siteName "Eastern Region" --entitlementName "Agent Sales"

lmvutil --authAs adminEast --authDomain domainEast --authPassword "*"

--createGroupHomeSite --groupName domainEast\adminEastGroup --siteName "Eastern Region"

--entitlementName "Agent Sales"

54 VMware, Inc.

Chapter 5 lmvutil Command Reference

Deleting a Home Site

To remove the association between a user and a home site, use the lmvutil command with the

--deleteUserHomeSite option. To remove the association between a group and a home site, use the

lmvutil command with the --deleteGroupHomeSite option.

Syntax

lmvutil --deleteUserHomeSite --userName domain\username [--entitlementName name]

lmvutil --deleteGroupHomeSite --groupName domain\groupname [--entitlementName name]

Usage Notes

These commands return an error message if the specified user or group does not exist, the specified global entitlement does not exist, or if the commands cannot delete the home site setting.

Options

You can specify these options when you remove the association between a user or group and a home site.

Table 5‑15. Options for Deleting a Home Site

Option Description

--userName

--groupName

--entitlementName

Name of a user. Use the format domain\username.

Name of a group. Use the format domain\groupname.

(Optional) Name of a global desktop entitlement or global application entitlement. You can use this option to remove the association between the home site and a global entitlement for the specified user or group.

Examples

lmvutil --authAs adminEast --authDomain domainEast --authPassword "*" --deleteUserHomeSite

--userName domainEast\adminEast

lmvutil --authAs adminEast --authDomain domainEast --authPassword "*"

--deleteGroupHomeSite --groupName domainEast\adminEastGroup

Viewing a Cloud Pod Architecture Configuration

You can use lmvutil command options to list information about a Cloud Pod Architecture configuration.

Listing Global Entitlements on page 56

To list all global desktop entitlements, use the lmvutil command with the

--listGlobalEntitlements option. To list all global application entitlements, use the lmvutil command with the --listGlobalApplicationEntitlements option.

Listing the Pools in a Global Entitlement on page 56

Use the lmvutil command with the --listAssociatedPools option to list the desktop or application pools that are associated with a specific global entitlement.

Listing the Users or Groups in a Global Entitlement on page 57

Use the lmvutil command with the --listEntitlements option to list all the users or groups associated with a specific global entitlement.

VMware, Inc. 55

Administering View Cloud Pod Architecture

Listing the Home Sites for a User or Group on page 57

To list all the configured home sites for a specific user, use the lmvutil command with the

--showUserHomeSites option. To list all the configured home sites for a specific group, use the

lmvutil command with the --showGroupHomeSites option.

Listing the Effective Home Site for a User on page 58

Use the lmvutil command with the --resolveUserHomeSite option to determine the effective home site for a specific user. Because home sites can be assigned to users and groups and to global entitlements, it is possible to configure more than one home site for a user.

Listing Dedicated Desktop Pool Assignments on page 59

Use the lmvutil command with the --listUserAssignments option to to list the dedicated desktop pool assignments for a user and global entitlement combination.

Listing the Pods or Sites in a Cloud Pod Architecture Topology on page 59

To view the pods in the pod federation, use the lmvutil command with the --listPods option. To view the sites in the pod federation, use the lmvutil command with the --listSites option.

Listing Global Entitlements

To list all global desktop entitlements, use the lmvutil command with the --listGlobalEntitlements option. To list all global application entitlements, use the lmvutil command with the

--listGlobalApplicationEntitlements option.

Syntax

lmvutil --listGlobalEntitlements

lmvutil --listGlobalApplicationEntitlements

Usage Notes

These commands return an error message if the Cloud Pod Architecture feature is not initialized or if the commands cannot list the global entitlements.

Examples

lmvutil --authAs adminEast --authDomain domainEast --authPassword "*" --listGlobalEntitlements

lmvutil --authAs adminEast --authDomain domainEast --authPassword "*"

--listGlobalApplicationEntitlements

Listing the Pools in a Global Entitlement

Use the lmvutil command with the --listAssociatedPools option to list the desktop or application pools that are associated with a specific global entitlement.

Syntax

lmvutil --listAssociatedPools --entitlementName name

Usage Notes

This command returns an error message if the Cloud Pod Architecture feature is not initialized or if the specified global entitlement does not exist.

56 VMware, Inc.

Chapter 5 lmvutil Command Reference

Options

You use the --entitlementName option to specify the name of the global entitlement for which to list the associated desktop or application pools.

Example

lmvutil --authAs adminEast --authDomain domainEast --authPassword "*" --listAssociatedPools

--entitlementName "Agent Sales"

Listing the Users or Groups in a Global Entitlement

Use the lmvutil command with the --listEntitlements option to list all the users or groups associated with a specific global entitlement.

Syntax

lmvutil --listEntitlements {--userName domain\username | --groupName domain\groupname | -entitlementName name}

Usage Notes

This command returns an error message if the Cloud Pod Architecture feature is not initialized or if the specified user, group, or entitlement does not exist.

Options

You can specify these options when you list global entitlement associations.

Table 5‑16. Options for Listing Global Entitlement Associations

Option Description

--userName

--groupName

--entitlementName

Name of the user for whom you want to list global entitlements. Use the format domain\username. This option lists all global entitlements associated with the specified user.

Name of the group for which you want to list global entitlements. Use the format domain\groupname. This option lists all global entitlements associated with the specified group.

Name of a global entitlement. This option lists all users and groups in the specified global entitlement.

Example

lmvutil --authAs adminEast --authDomain domainEast --authPassword "*" --listEntitlements

--userName example\adminEast

Listing the Home Sites for a User or Group

To list all the configured home sites for a specific user, use the lmvutil command with the

--showUserHomeSites option. To list all the configured home sites for a specific group, use the lmvutil command with the --showGroupHomeSites option.

Syntax

lmvutil --showUserHomeSites --userName domain\username [--entitlementName name]

lmvutil --showGroupHomeSites --groupName domain\groupname [--entitlementName name]

VMware, Inc. 57

Administering View Cloud Pod Architecture

Usage Notes

These commands return an error message if the Cloud Pod Architecture feature is not initialized or if the specified user, group, or global entitlement does not exist.

Options

You can specify these options when you list the home sites for a user or group.

Table 5‑17. Options for Listing the Home Sites for a User or Group

Option Description

--userName

--groupName

--entitlementName

Example

lmvutil --authAs adminEast --authDomain domainEast --authPassword "*" --showUserHomeSites

--userName example\adminEast

Name of a user. Use the format domain\username.

Name of a group. Use the format domain\groupname.

(Optional) Name of a global entitlement. Use this option if you want to show the home sites for a user or group and global entitlement combination.

lmvutil --authAs adminEast --authDomain domainEast --authPassword "*" --showGroupHomeSites

--groupName example\adminEastGroup

Listing the Effective Home Site for a User

Syntax

lmvutil --resolveUserHomeSite --entitlementName name --userName domain\username

Usage Notes

This command returns an error message if the Cloud Pod Architecture feature is not initialized or if the specified global entitlement or user does not exist.

Options

You must specify these options when you list the effective home site for a user.

Table 5‑18. Options for Listing the Effective Home Site for a User

Option Description

--entitlementName

--userName

Name of the user whose home site you want to list. Use the format domain\username.

Example

lmvutil --authAs adminEast --authDomain domainEast --authPassword "*"

--resolveUserHomeSite --userName domainEast\adminEast

58 VMware, Inc.

Chapter 5 lmvutil Command Reference

Listing Dedicated Desktop Pool Assignments

Use the lmvutil command with the --listUserAssignments option to to list the dedicated desktop pool assignments for a user and global entitlement combination.

Syntax

lmvutil --listUserAssignments {--userName domain\username | --entitlementName name | --podName name | --siteName name}

Usage Notes

The data produced by this command is managed internally by the Cloud Pod Architecture brokering software.

This command returns an error if the Cloud Pod Architecture feature is not initialized or if the command cannot find the specified user, global entitlement, pod, or site.

Options

You must specify one of the following options when you list user assignments.

Table 5‑19. Options for Listing User Assignments

Option Description

--userName

--entitlementName

--podName

--siteName

Name of the user for whom you want to list assignments. Use the format domain\username. This option lists the global entitlement, pod, and site assignments for the specified user.

Name of a global entitlement. This option lists the users assigned to the specified global entitlement.

Name of a pod. This option lists the users assigned to the specified pod.

Name of a site. This option lists the users assigned to the specified site.

Example

lmvutil --authAs adminEast --authDomain domainEast --authPassword "*" --listUserAssignments --podName "East Pod 1"

Listing the Pods or Sites in a Cloud Pod Architecture Topology

To view the pods in the pod federation, use the lmvutil command with the --listPods option. To view the sites in the pod federation, use the lmvutil command with the --listSites option.

Syntax

lmvutil --listPods

lmvutil --listSites

Usage Notes

These commands return an error message if the Cloud Pod Architecture feature is not initialized or if the commands cannot list the pods or sites.

VMware, Inc. 59

Administering View Cloud Pod Architecture

Example

lmvutil --authAs adminEast --authDomain domainEast --authPassword "*" --listPods

lmvutil --authAs adminEast --authDomain domainEast --authPassword "*" --listSites

Managing SSL Certificates

You can use lmvutil command options to create and activate pending SSL certificates in a Cloud Pod Architecture environment.

The Cloud Pod Architecture feature uses signed certificates for bidirectional SSL to protect and validate the VIPA communication channel. The certificates are distributed in the Global Data Layer. The Cloud Pod Architecture feature replaces these certificates every seven days.

To change a certificate for a specific View Connection Server instance, you create a pending certificate, wait for the Global Data Layer replication process to distribute the certificate to all View Connection Server instances, and activate the certificate.

The lmvutil command certificate options are intended for use only if a certificate becomes compromised and a View administrator wants to update the certificate sooner than seven days. These options affect only the View Connection Server instance on which they are run. To change all certificates, you must run the options on every View Connection Server instance.

Creating a Pending Certificate on page 60

Use the lmvutil command with the --createPendingCertificate option to create a pending SSL certificate.

Activating a Pending Certificate on page 60

Use the lmvutil command with the --activatePendingCertificate option to activate a pending certificate.

Creating a Pending Certificate

Use the lmvutil command with the --createPendingCertificate option to create a pending SSL certificate.

Syntax

lmvutil --createPendingCertificate

Usage Notes

This command returns an error message if the Cloud Pod Architecture feature is not initialized or if the command cannot create the certificate.

Example

LMVUtil --authAs adminEast --authDomain domainEast --authPassword "*"

--createPendingCertificate

Activating a Pending Certificate

Use the lmvutil command with the --activatePendingCertificate option to activate a pending certificate.

Syntax

lmvutil --activatePendingCertificate

60 VMware, Inc.

Chapter 5 lmvutil Command Reference

Usage Notes

You must use the lmvutil command with the --createPendingCertificate option to create a pending certificate before you can use this command. Wait for the Global Data Layer replication process to distribute the certificate to all View Connection Server instances before you activate the pending certificate. VIPA connection failures and resulting brokering problems can occur if you activate a pending certificate before it is fully replicated to all View Connection Server instances.

This command returns an error message if the Cloud Pod Architecture feature is not initialized or if the command cannot activate the certificate.

Example

lmvutil --authAs adminEast --authDomain domainEast --authPassword "*"

--activatePendingCertificate

VMware, Inc. 61

Administering View Cloud Pod Architecture

62 VMware, Inc.

Index

allocating desktops 10 architectural overview of Cloud Pod

Architecture 7

configuration

tasks 15 viewing 27, 55

desktop sessions 29

example of a basic configuration 22

global entitlements

adding desktop pools 31 adding pools 50 adding users and groups 31, 52 creating 17, 24, 46 deleting 33, 50 introduction 10 listing 56 listing pools 56 listing users and groups 57 managing 46 modifying 31, 48 modifying attributes and policies 32 removing desktop pools 31 removing pools 51

removing users and groups 32, 53 Global Data Layer 8 glossary 5

home sites

assigning 20

configuring 54

effective 58

introduction 11

listing 57, 59

managing 53

removing associations 34, 55

initializing 15, 23, 40 intended audience 5 introduction 7

limitations 8 lmvutil command

authenticating 38 command options 38 introduction 37 output 38 syntax 37

management interfaces 27

pending certificates

activating 60

creating 60 pod names, changing 43 pod federations

joining pods 16, 24, 42

managing 41

removing pods 35, 42

viewing health 29

scope policy settings 11 security considerations 13 sites

adding pods 30, 44

changing a name or description 45

creating 20, 24, 44

deleting 45

introduction 9

managing 43 SSL certificates 60

TCP port requirements 13 testing 21 topology

designing 9, 23

VMware, Inc. 63

Administering View Cloud Pod Architecture

limits 12 viewing 59

uninitializing 35 unitializing 41

View URL 25 VIPA communication channel 8

64 VMware, Inc.

VMware Horizon 6.2, Horizon View - 6.2 Administrator’s Guide

Specifications and Main Features

Frequently Asked Questions

User Manual

Contents

Administering View Cloud Pod Architecture

Understanding Cloud Pod Architecture

Sharing Key Data in the Global Data Layer

Sending Messages Between Pods

Configuring and Managing a Cloud Pod Architecture Environment

Cloud Pod Architecture Limitations

Creating Cloud Pod Architecture Sites

Entitling Users and Groups in the Pod Federation

Finding and Allocating Desktops and Applications in the Pod Federation

Understanding the Scope Policy

Using Home Sites

Global Entitlement Example

Cloud Pod Architecture Topology Limits

Cloud Pod Architecture Port Requirements

Security Considerations for Cloud Pod Architecture Topologies

Initialize the Cloud Pod Architecture Feature

Join a Pod to the Pod Federation

Create and Configure a Global Entitlement

Create and Configure a Site

Assign a Home Site to a User or Group

Test a Cloud Pod Architecture Configuration

Example: Setting Up a Basic Cloud Pod Architecture Configuration

Designing the Example Topology

Initializing the Example Configuration

Joining Pods in the Example Configuration

Creating Sites in the Example Configuration

Creating Global Desktop Entitlements in the Example Configuration

Creating a View URL for the Example Configuration

View a Cloud Pod Architecture Configuration

View Pod Federation Health in View Administrator

View Desktop and Application Sessions in the Pod Federation

Determine the Effective Home Site for a User

Add a Pod to a Site

Modifying Global Entitlements

Add a Pool to a Global Entitlement

Remove a Pool from a Global Entitlement

Add a User or Group to a Global Entitlement

Remove a User or Group From a Global Entitlement

Modify Attributes or Policies for a Global Entitlement

Delete a Global Entitlement

Remove a Home Site Association

Remove a Pod From the Pod Federation

Uninitialize the Cloud Pod Architecture Feature

lmvutil Command Reference 5

lmvutil Command Use

lmvutil Command Authentication

lmvutil Command Output

lmvutil Command Options

Initializing the Cloud Pod Architecture Feature

Disabling the Cloud Pod Architecture Feature

Managing Pod Federations

Joining a Pod to the Pod Federation

Removing a Pod From a Pod Federation

Changing a Pod Name or Description

Managing Sites

Creating a Site

Assigning a Pod to a Site

Changing a Site Name or Description

Deleting a Site

Managing Global Entitlements

Creating a Global Entitlement

Modifying a Global Entitlement

Deleting a Global Entitlement

Adding a Pool to a Global Entitlement

Removing a Pool from a Global Entitlement

Adding a User or Group to a Global Entitlement

Removing a User or Group From a Global Entitlement

Managing Home Sites

Configuring a Home Site

Deleting a Home Site

Viewing a Cloud Pod Architecture Configuration

Listing Global Entitlements

Listing the Pools in a Global Entitlement

Listing the Users or Groups in a Global Entitlement

Listing the Home Sites for a User or Group
