D55-E0
INSTALLATION GUIDE
VIZIO
Please read this guide before using the product.
D43-E2, D50-E1, D55-E0, & D65-E0
English - ii
IMPORTANT SAFETY INSTRUCTIONS
Your TV is designed and manufactured to operate within dened
design limits. Misuse may result in electric shock or re. To prevent
your TV from being damaged, the following instructions should be
observed for the installation, use, and maintenance of your TV. Read
the following safety instructions before operating your TV. Keep these
instructions in a safe place for future reference.
• To reduce the risk of electric shock or component damage, switch o the
power before connecting other components to your TV.
• Read these instructions.
• Keep these instructions.
• Heed all warnings.
• Follow all instructions.
• Do not use this apparatus near water.
• Clean only with dry cloth.
• Do not block any ventilation openings. Install in accordance with the
manufacturer’s instructions.
• Do not install near any heat sources such as radiators, heat registers,
stoves, or other apparatus (including ampliers) that produce heat.
• Do not defeat the safety purpose of the polarized or grounding-type
plug. A polarized plug has two blades with one wider than the other. A
grounding type plug has two blades and a third grounding prong. The
wide blade or the third prong are provided for your safety. If the provided
plug does not t into your outlet, consult an electrician for replacement
of the obsolete outlet.
• Protect the power cord from being walked on or pinched particularly at
plugs, convenience receptacles, and the point where they exit from the
apparatus.
• Only use attachments/accessories specied by the manufacturer.
• Use only with the cart, stand, tripod, bracket, or table specied by the
manufacturer, or sold with the apparatus. When a cart is used, use
caution when moving the cart/apparatus combination to avoid injury
from tip-over.
• Unplug this apparatus during lightning storms or when unused for long
periods of time.
• Refer all servicing to qualied service personnel. Servicing is required
when the apparatus has been damaged in any way, such as power-supply
Safety Information
cord or plug is damaged, liquid has been spilled or objects have fallen into
the apparatus, the apparatus has been exposed to rain or moisture, does
not operate normally, or has been dropped.
• When moving your TV from an area of low temperature to an area of high
temperature, condensation may form in the housing. Wait before turning on
your TV to avoid causing re, electric shock, or component damage.
• A distance of at least three feet should be maintained between your TV and
any heat source, such as a radiator, heater, oven, amplier etc. Do not install
your TV close to smoke. Operating your TV close to smoke or moisture may
cause re or electric shock.
• Slots and openings in the back and bottom of the cabinet are provided for
ventilation. To ensure reliable operation of your TV and to protect it from
overheating, be sure these openings are not blocked or covered. Do not
place your TV in a bookcase or cabinet unless proper ventilation is provided.
• Never push any object into the slots and openings on your TV cabinet. Do
not place any objects on the top of your TV. Doing so could short circuit parts
causing a re or electric shock. Never spill liquids on your TV.
• Your TV should be operated only from the type of power source indicated
on the label. If you are not sure of the type of power supplied to your home,
consult your dealer or local power company.
• Do not apply pressure or throw objects at your TV. This may compromise the
integrity of the TV. The manufacturer’s warranty does not cover user abuse
or improper installations.
• The power cord must be replaced when using dierent voltage than the
voltage specied. For more information, contact your dealer.
• When connected to a power outlet, power is always owing into your TV. To
totally disconnect power, unplug the power cord.
• The lightning ash with arrowhead symbol within an equilateral triangle is
intended to alert the user to the presence of un-isolated, dangerous voltage
within the inside of your TV that may be of sucient magnitude to constitute
a risk of electric shock to persons.
• Do not overload power strips and extension cords. Overloading can
result in re or electric shock.
• The wall socket should be installed near your TV and easily accessible.
• Only power of the marked voltage can be used for your TV. Any other voltage
than the specied voltage may cause re or electric shock.
• Do not touch the power cord during lightning. To avoid electric shock, avoid
handling the power cord during electrical storms.
• Unplug your TV during a lightning storm or when it will not be used for long
period of time. This will protect your TV from damage due to power surges.
English - iii
• Do not attempt to repair or service your TV yourself. Opening or removing
the back cover may expose you to high voltages, electric shock, and other
hazards. If repair is required, contact your dealer and refer all servicing to
qualied service personnel.
• WARNING: Keep your TV away from moisture. Do not expose your TV to
rain or moisture. If water penetrates into your TV, unplug the power cord
and contact your dealer. Continuous use in this case may result in re or
electric shock.
• Do not use your TV if any abnormality occurs. If any smoke or odor becomes
apparent, unplug the power cord and contact your dealer immediately. Do
not try to repair your TV yourself.
• Avoid using dropped or damaged appliances. If your TV is dropped and the
housing is damaged, the internal components may function abnormally.
Unplug the power cord immediately and contact your dealer for repair.
Continued use of your TV may cause re or electric shock.
• Do not install your TV in an area with heavy dust or high humidity. Operating
your TV in environments with heavy dust or high humidity may cause re
or electric shock.
• Follow instructions for moving your TV. Ensure that the power cord and any
other cables are unplugged before moving your TV.
• When unplugging your TV, hold the AC/DC power adapter, not the cord.
Pulling on the power cord may damage the wires inside the cord and cause
re or electric shock. When your TV will not be used for an extended period
of time, unplug the power cord.
• To reduce risk of electric shock, do not touch the connector with wet hands.
• Insert batteries in accordance with instructions. Incorrect polarities may
cause the batteries to leak which can damage the remote control or injure
the operator. Do not expose batteries to excessive heat such as sunshine,
re or the like.
• If any of the following occurs, contact the dealer:
• The power cord fails or frays.
• Liquid sprays or any object drops into your TV.
• Your TV is exposed to rain or other moisture.
• Your TV is dropped or damaged in any way.
• The performance of your TV changes substantially.
• This apparatus shall not be exposed to dripping or splashing and no objects
lled with liquids, such as vases, shall be placed on the apparatus.
• The mains plug or appliance coupler is used as the disconnect device, the
disconnect device shall remain readily operable.
• CAUTION: These servicing instructions are for use by qualied service
personnel only. To reduce the risk of electric shock, do not perform any
servicing other than that contained in the operating instructions unless you
are qualied to do so.
• The lightning ash with arrowhead symbol within an equilateral triangle
is intended to alert the user to the presence of uninsulated DANGEROUS
VOLTAGE within the product’s enclosure that may be of sucient magnitude
to constitute a risk of electrical shock to persons.
• Please use caution around the TV: pulling or pushing on the TV may
cause the TV to tip or fall over resulting in personal injury and/or
property damage.
• WARNING: Exposure to loud sounds can damage your hearing
causing hearing loss and tinnitus (ringing or buzzing in the ears). With
continued exposure to loud noises, ears may become accustomed to the
sound level, which may result in permanent damage to hearing without any
noticeable discomfort.
• Install the TV where it cannot be pulled, pushed or knocked over.
• Do not allow children to hang onto the product.
• Store the accessories (remote, batteries, etc.) in a location safely out of the
reach of children.
• The American Academy of Pediatrics discourages television viewing for
children younger than two years of age.
• Use only with a UL-listed wall mount bracket rated for the weight/ load of
the television.
• WARNING: Never place a television set in an unstable location. A television
set may fall, causing serious personal injury or death. Many injuries,
particularly to children, can be avoided by taking simple precautions such as:
• Using cabinets or stands recommended by the manufacturer of the
television set.
• Only using furniture that can safely support the television set
• Ensuring the television set is not overhanging the edge of the supporting
furniture.
• Not placing the television set on tall furniture (for example, cupboards or
bookcases) without anchoring both the furniture and the television set
to a suitable support.
• Not placing the television set on cloth or other materials that may be
located between the television set and the supporting furniture.
• Educating children about the dangers of climbing on furniture to reach
the television set or its controls.
• If your existing television set is being retained and relocated, the same
considerations as above should be applied.
English - iv
Television Antenna Connection Protection
Ground Clamp
Antenna Lead In Wire
Antenna Discharge Unit
(NEC Section 810-20)
Grounding Conductors
(NEC Section 810-21)
Ground Clamps
Power Service Grounding Electrode System
(NEC ART 250, part H)
Electric Service Equipment
• If an outside antenna/satellite dish or cable system is to be connected to the TV,
make sure that the antenna or cable system is electrically grounded to provide
some protection against voltage surges and static charges.
• Article 810 of the National Electrical Code, ANSI/NFPSA 70, provides information
with regard to proper grounding of the mast and supporting structure, grounding
of the lead-in wire to an antenna discharge unit, size of the grounding conductors,
location of antenna discharge unit, connection to grounding electrodes, and
requirements of the grounding electrode.
• Lightning Protection: For added protection of the TV during a lightning storm or
when it is left unattended or unused for long periods of time, unplug the TV from
the wall outlet and disconnect the antenna or cable system.
• Power Lines: Do not locate the antenna near overhead light or power circuits, or
where it could fall into such power lines or circuits. Remember, the screen of the
coaxial cable is intended to be connected to earth in the building installation.
English - v
Table of Contents
Safety Information ....................................................................................................... ii
Television Antenna Connection Protection ............................................................... iv
Package Contents ......................................................................................................... vii
Basic Remote ................................................................................................................ 8
Inserting and Replacing Batteries. .............................................................................. 9
Installing the TV Stands ............................................................................................... 10
First-Time Setup............................................................................................................ 12
Viewing the On-Screen User Manual .......................................................................... 17
Accessibility Settings .................................................................................................... 19
Connecting to the Internet with Wi-Fi ........................................................................ 20
Getting Started with VIZIO Internet Apps Plus
®
........................................................ 22
Additional Connections ................................................................................................ 24
Connecting an Audio Device ....................................................................................... 24
Top Tips ......................................................................................................................... 26
Regulatory Information................................................................................................ 27
Limited Warranty .......................................................................................................... 28
Limited Warranty Mexico............................................................................................. 30
Legal Information ......................................................................................................... 32
English - vi
NEED HELP?
Award-Winning Customer Care At Your Convenience.
Se habla Español • Nous parlons Français
Hours of Operation:
Monday - Friday:
7 a m t o 11 pm (CSt)
Saturday - Sunday:
9 a m t o 6 p m (CSt)
Phone: (844) 254-8088 (toll-free)
You can also contact our
popular support team at:
Live chat
support available
Find help with:
•
New product setup
• Connecting your devices
• Technical problems
• Product updates and more
Go to: SUPPORT.VIZIO.COM
English - vii
Package Contents
Quick Start Guide
(1 x English, 1 x French/ Spanish)
VIZIO TV Display TV
Stands
4 x Phillips
Screws
Power
Cable
IR Remote
w/Batteries
English - 8
Basic Remote
APP LAUNCHER
Quickly launch the pictured App.
(Also turns the TV on if it is o.)
DASH
Use with number pad to manually enter a
digital sub-channel.
(For example, 18-4 or 18-5.)
PIC
Opens the picture mode menu.
For Text to Speech hold key for 10 seconds.
LAST
Return to the channel last viewed.
CHANNEL UP/DOWN
Change the channel.
V BUTTON
Open the VIA dock.
GUIDE
Display the info window.
ARROW
Navigate the on-screen menu.
INFO
Display the info window.
MENU
Display the on-screen menu.
POWER
Turn TV on or o.
ENTER
Conrm channel or passcode
entered using the number pad.
NUMBER PAD
Manually enter a channel.
WIDE
Change the display mode.
For Zoom Mode hold key for 10 seconds.
MUTE
Turn the audio o or on.
VOLUME UP/DOWN
Increase or decrease loudness of the audio.
BACK
Go to the previous on-screen menu.
OK
Select the highlighted menu option.
EXIT
Close the on-screen menu.
CLOSED CAPTIONS
Open the closed caption menu.
For video description hold key for 10 seconds.
A/V CONTROLS
Control USB media player and some apps.
INPUT
Change the currently-displayed input.
* Long key press for accessibility options may be shorter than 10 seconds
English - 9
Inserting and Replacing Batteries.
Two AAA batteries are included for you to use with
the basic remote control.
To insert/replace the batteries:
1. Remove the battery cover by pressing gently on
the logo and sliding away from the remote. Insert
two AAA batteries (included).
2. Be sure to align the + and - signs on the batteries
and remote. Gently slide the battery cover back
into place.
Visit http://support.vizio.com/ if you
have any questions.
1
WARNING: keep the remote control
batteries away from children. It may
cause choking and/or lead to a re or
chemical burn if mishandled. Do not
dispose of batteries in re. Replace only
with batteries of the correct type.
—
—
+
+
2
When needed, VIZIO recommends
replacing the batteries that came with
this remote with two, new Duracell ‘AAA’
alkaline batteries.
English - 10
1
Installing the TV Stands
Remove any plastic lm from the TV and stands.
Place the TV screen-down on a clean, at surface. To
prevent scratches or damage to the screen, place the
TV on a soft surface such as a carpet, rug, or blanket,
and avoid any sharp edges.
Make sure the top and bottom edges of the screen
are being supported by the surface to avoid damage.
It is recommended that two people take
part in the stand installation.
P
Î
English - 11
2
Insert the stands into the base of the TV. (The stands
are identical.)
Secure each stand to the TV with two (2) Phillips
screws (included).
Insert the screws into the back of the TV and tighten
them using a Phillips screwdriver.
When you are nished, place the TV on a stable, level
surface.
Note: The image shown here is for illustrative purposes only and may be subject to change.
The actual number of ports and their locations may vary, depending on the model.
Loading...
