Ubiquiti UMA-D-US Quick Start Guide

Directional Dual-Band Antenna
for UAP-AC-M

Model: UMA-D

Introduction

Thank you for purchasing the Ubiquiti Networks® UniFi®

802.11ac Indoor/Outdoor Mesh Antenna. This Quick Start
Guide is designed to guide you through installation and
includes warranty terms.

Package Contents

UMA-D Antenna Ball Joint Mount Lock Ring

Screws
(Qty. 4)

Metal Strap RF Cables

TERMS OF USE: Ubiquiti radio devices must be professionally installed. Shielded Ethernet
cable and earth grounding must be used as conditions of product warranty. TOUGHCable™ is
designed for outdoor installations. It is the professional installer’s responsibility to follow local
country regulations, including operation within legal frequency channels, output power, and
Dynamic Frequency Selection (DFS) requirements.

Screw Anchors

(Qty. 4)

(Qty. 2)

Hex Bolt Wall Mount

Plate

Directional Dual-Band Antenna
for UAP-AC-M

Model: UMA-D

Quick Start

Guide

Installation Requirements

• UniFi AC Mesh Access Point, model UAP-AC-M

• Wall-mounting: drill and 6 mm drill bit

• Pole-mounting: 7 mm socket wrench

• Phillips screwdriver

• Shielded Category 5 (or above) cabling with drain wire
should be used for all outdoor wired Ethernet connections
and should be grounded through the AC ground of the PoE.

We recommend that you protect your networks from
harmful outdoor environments and destructive ESD events
with industrial-grade, shielded Ethernet cable from Ubiquiti
Networks. For more details, visit www.ubnt.com/toughcable

• Surge protection should be used for all outdoor installations.
We recommend that you use two Ethernet Surge Protectors,
model ETH-SP, one near the UAP-AC-M and the other at the
entry point to the building. The ETH-SP will absorb power
surges and safely discharge them into the ground.

UMA-D

US-8-150W

ETH-SP

UAP-AC-M

ETH-SP

To LAN

Diagram Showing Use of Ethernet Surge Protectors

Hardware Installation

The UniFi antenna can be mounted on a wall or pole. Perform
the following steps for proper installation:

Wall Mount

To mount the UniFi antenna on a wall, use the included Wall
Mount Plate, Screws, and Screw Anchors.

1. Place the Wall Mount Plate at the desired location on the

wall in the orientation shown below.

2. Pre-drill the holes using a 6 mm drill bit.

3. Insert a Screw Anchor into each hole.

4. Secure the Wall Mount Plate with four Screws.

5. Insert the Ball Joint Mount into the Lock Ring.

6. Secure the Ball Joint Mount to the Wall Mount Plate using

the Hex Bolt.

7. Attach the antenna to the Ball Joint Mount and turn the

Lock Ring to secure it. Keep the Lock Ring loose enough to
allow the antenna to pivot for aiming.

8. Connect one end of the RF Cables to the antenna.

9. Connect the other end of the RF Cables to the UAP-AC-M.

Pole Mount

1. Insert the Ball Joint Mount into the Lock Ring with the

threads of the Lock Ring facing the ball joint.

2. Open the Metal Strap and feed it through the base of the

Ball Joint Mount.

3. Wrap the Metal Strap around the pole. Use a 7 mm socket

wrench to turn the screw clockwise and securely fasten the
clamp to the pole.

4. Attach the antenna to the Ball Joint Mount and turn the

Lock Ring to secure it. Keep the Lock Ring loose enough to
allow the antenna to pivot for aiming.

5. Connect one end of the RF Cables to the antenna.

*640-00331-03*

640-00331-03

6. Connect the other end of the RF Cables to the UAP-AC-M.

Specifications

Dimensions 201.3 x 128.0 x 32.5 mm

Weight

With Mount
Without Mount

Enclosure Outdoor UV Stabilized Plastic

Supported Frequency Range 2.4 - 2.5 GHz

HPOL Beamwidth

2.4 GHz
5 GHz

VPOL Beamwidth

2.4 GHz
5 GHz

Elevation Beamwidth

2.4 GHz
5 GHz

Maximum VSWR 2.5:1

Polarization Dual-Linear

Cross-Pol Isolation

2.4 GHz
5 GHz

Antenna Gain

2.4 GHz
5 GHz

Mounting Wall/Pole (Kits Included)

UMA-D

(7.93 x 5.04 x 1.28")

480 g (16.93 oz)
400 g (14.11 oz)

5.1 - 5.9 GHz

10 dBi
15 dBi

25 dB
30 dB

90°
45°

90°
45°

90°
45°
