RAV4

2010

QUICK REFERENCE

GUIDE

2010

INDEX

RAV4

This Quick Reference Guide is a summary of basic vehicle operations. It contains brief descriptions of fundamental operations so you can locate and use the vehicle’s main equipment quickly and easily

The Quick Reference Guide is not intended as a substitute for the Owner’s Manual located in the vehicle’s glove box. We strongly encourage you to review the Owner’s Manual and supplementary manuals so you will have a better understanding of the vehicle’s capabilities and limitations.

Your dealership and the entire staff of Toyota Motor Sales, U.S.A., Inc. wish you many years of satisfied driving in your new RAV4.

A word about safe vehicle operations

This Quick Reference Guide is not a full description of RAV4 operations. Every RAV4 owner should review the Owner’s Manual that accompanies this vehicle.

Pay special attention to the boxed information highlighted in color throughout the Owner’s Manual. Each box contains safe

ating instructions to help you avoid injury or equipment

oper malfunction.

All information in this Quick Reference Guide is current at the time of printing. T changes at any time without notice.

oyota reserves the right to make

OVERVIEW

FEATURES/OPERATIONS

SAFETY AND

EMERGENCY FEATURES

Engine maintenance 9 Fuel tank door release and cap 8 Hood release 8 Indicator symbols 4-5 Instrument cluster 4 Instrument panel 2-3

Keyless entry* 6 Smart Key system* 7

Active torque control 4WD (4WD models) 11 Air Conditioning/Heating 18-19 Audio 20-21 Automatic Transmission 10 Clock 19 Cruise control 23 Door locks 16 Downhill Assist Control system (DAC) 22 Hill-start Assist Control (HAC) 23 Light control-Instrument panel 19 Lights & turn signals 14 Moonroof 16 Parking brake 10 Power outlets-12V DC 22 Power outlets-120V AC 22 Seat adjustments-Front 12 Seat adjustments-Second row seats 12 Seat heaters 18 Seats-Head restraints 11 Seats-Folding down second row seats 13 Seats-Stowing third row seats 13 Telephone controls (Bluetooth®)17 Tilt and telescopic steering wheel 17 VSC OFF button 16 Windows 15 Windshield wipers & washers 15

Doors-Child safety locks 24 Seatbelts 24 Seatbelts-Shoulder belt anchor 24 Spare tire & tools 25 Tire Pressure Monitoring (warning) System 24

OVERVIEW

FEATURES/OPERATIONS

SAFETY AND EMERGENCY FEATURES

* Visit your Toyota dealer for information on customizing this feature.

OVERVIEW

Instrument panel

Steering wheel controls

Without telephone controls

With manual Air Conditioning system

OVERVIEW

With telephone controls

Steering wheel audio controls

Telephone controls

Multi-information display switch Speech command button

Cruise control Headlight, turn signal and front fog light Wiper and washer controls Four-wheel drive lock switch (4WD models) Audio system/Navigation system

1,2

Emergency flasher switch Air Conditioning controls “ENGINE START STOP” button (Smart Key) Engine immobilizer indicator Front passenger seatbelt reminder light Clock and Air Conditioning display

control

With automatic Air Conditioning system

Front passenger occupant classification indicator Rear window and outside rearview mirror defogger switch

12V DC Power outlet Seat heater switch

VSC OFF switch Ignition switch (standard key) Tilt and telescopic steering release Downhill Assist Control switch 120V AC Power outlet ON/OFF switch

Instrument panel light control

If equipped

Vehicles with navigation system: for details, refer to the “Navigation System Owner’s Manual.”

FEATURES/OPERATIONS

SAFETY AND EMERGENCY FEATURES

2 3

OVERVIEW

Instrument cluster

Tachometer Service indicator and reminder Speedometer Engine coolant temperature Fuel gauge Odometer, two trip meters and trip information display Odometer/trip meter switch and trip meter reset button

Indicator symbols

Brake system warning

Driver/Front passenger seatbelt reminder (alarm will sound if speed is over 12 mph)

Charging system warning

Low engine oil pressure warning

Malfunction/Check Engine indicator

Low fuel level warning

Engine oil replacement reminder

Airbag SRS warning

Automatic Transmission fluid temperature warning

Low Tire Pressure Warning

4WD warning

Electric power steering system warning

Low windshield washer fluid level warning

ront passenger occupant classification indicator

Headlight low/high beam indicator

Turn signal indicator

Front fog light indicator

Automatic Transmission indicator (4-speed)

Automatic Transmission indicator (5-speed)

Four-wheel drive lock indicator

Vehicle Stability Control OFF indicator

Slip indicator/Hill-start Assist Control indicator/Downhill Assist Control indicator

AUTO Limited Slip Differential indicator

Downhill Assist Control indicator

Cruise control indicator

Anti-lock Brake System warning

1,2

Smart Key system warning

Traction Control OFF indicator

OVERVIEW

FEATURES/OPERATIONS

SAFETY AND EMERGENCY FEATURES

Open door warning

If indicator does not turn off within a few seconds of starting engine, there may be a malfunction. Have vehicle inspected by your Toyota dealer.

For details, refer to “Four-wheel drive lock switch,” Section 2-4, 2010 Owner’s Manual.

4 5

If this light flashes, refer to “Cruise control,” Section 2-4, 2010 Owner’s Manual.

OVERVIEW

Keyless entry

Beep sound can be switched ON or OFF. Refer to the Owner’s Manual for more details.

Locking operation

Without Smart Key system

Unlocking operation

Without Smart Key system

NOTE: If a door is not opened within 60 seconds of unlocking, all doors will

relock for safety.

Panic button

With Smart Key system

Push ONCE: Driver door

TWICE: All doors

Push

Smart Key system* (if equipped)

Start function

Green indicator ON

Carrying

Depress brake pedal

NOTE: Gear shift lever must be in Park and brake pedal depressed.

Power (without starting engine)

Without depressing the brake pedal, pressing the “ENGINE START STOP” switch will change the operation mode in succession from:

ACCESSORY

OFF

Locking operation

Power ON; the engine not running.

All systems OFF.

Accessories such as the radio will operate.

Unlocking operation

Front door lock

Push

Front door unlock*

Grasp

OVERVIEW

FEATURES/OPERATIONS

Push and hold

Carry remote to lock/unlock

Back door lock/unlock

Push

Carry remote to lock/unlock

* Driver door unlocking function can be programmed to unlock driver door

only, or all doors. Grasping passenger door handle will unlock all doors.

NOTE: Doors may also be locked/unlocked using remote.

Grasp

SAFETY AND EMERGENCY FEATURES
