INWALL RANGE USER MANUAL

CONTENTS

2SAFETY INSTRUCTIONS

3 -4 PRODUCT IDENTIFICATION

5-6 INSTALLATION GUIDELINES

7PRODUCT DIMENSIONS

8TECHNICAL SPECIFICATIONS

9WARRANTY STATEMENT

10 DECLARATION OF CONFORMITY

1

SAFETY INSTRUCTIONS

1. Read these instructions.

2. Keep these instructions.

3.Heed all warnings.

4.Follow all instructions.

5.The user is responsible for fixing the hardware to the surface to ensure safe operation. The fixings must support the weight of the product – please consult the manual’s specification page for the appropriate weights. Please consult the relevant construction codes in your region for further information on suitable hardware fixing methods.

6.Some regional construction codes require the use of a secondary method of securing loudspeakers to surfaces to provide security of a back-up support. A secondary support line should be attached from the safety loop on the rear of the product to a source point on the wall. Please consult the relevant construction codes in your region.

7.Tannoy will not be held accountable for any damage caused by incorrect installation.

2

PRODUCT IDENTIFICATION

IW60 EFX FRONT

Isolation mounts

Isolation mount

Isolation mount

4” Dual ConcenticTM driver

6.5” Dual ConcenrticTM driver

IW60 EFX TOP

Spring terminal posts

Relay switch socket

Phase switch

3
