Blu-ray Disc/DVD Home Theatre System

Operating Instructions

4-261-384-12(1)

BDV-E985W

WARNING

Do not install the appliance in a confined space, such as a bookcase or built-in cabinet.

To reduce the risk of fire, do not cover the ven tilation opening of the apparatus with newspapers, tablecloths, curtains, etc. Do not place the naked flame sources such as lighted candles on the apparatus.

To reduce the risk of fire or electric shock, do not expose this apparatus to dripping or splashing, and do not place objects filled with liquids, such as vases, on the apparatus.

Do not expose batteries or apparatus with battery-installed to excessive heat such as sunshine, fire or the like.

To prevent injury, this apparatus must be securely attached to the floor/wall in accordance with the installation instructions.

Indoor use only.

CAUTION

The use of optical instruments with this product will increase eye hazard. As the laser beam used in this Blu-ray Disc / DVD Home Theatre System is harmful to eyes, do not attempt to disassemble the cabinet.

Refer servicing to qualified personnel only.

This appliance is classified as a CLASS 3R LASER product. Visible and invisible laser radiation is emitted when the laser protective housing is opened, so be sure to avoid direct eye exposure.

This marking is located on the laser protective housing inside the enclosure.

This appliance is classified as a CLASS 1 LASER product. This marking is located on the rear exterior.

For the main unit

The nameplate is located on the bottom exterior.

Precautions

On power sources

• The unit is not disconnected from the mains as long as it is connected to the AC outlet, even if the unit itself has been turned off.

• As the main plug is used to disconnect the unit from the mains, connect the unit to an easily accessible AC outlet. Should you notice an abnormality in the unit, disconnect the main plug from the AC outlet immediately.

On watching 3D video images

Some people may experience discomfort (such as eye strain, fatigue, or nausea) while watching 3D video images. Sony recommends that all viewers take regular breaks while watching 3D video images. The length and frequency of necessary breaks will vary from person to person. You must decide what works be st. If you experience any discomfort, you should stop watching the 3D video images until the discomfort ends; consult a doctor if you believe necessary. You should also review (i) the instruction manua l and/or the caution message of any other device used with, or Blu-ray Disc

contents played with this product and (ii) our website (http:// esupport.sony.com/) for the latest information. The vision of young children (especially those under six years old) is still under development. Consult your doctor (such as a pediatrician or eye doctor) before allowing young children to watch 3D video images.

Adults should supervise young children to ensure they follow the recommendations listed above.

For the wireless transceiver (EZWRT50)

(For the customers in Singapore)

Copy Protection

Please be advised of the advanced content protection systems used in both Blu-ray Disc media. These systems, called AACS (Advanced Access Content System) and CSS (Content Scramble System), may contain some restrictions on playback, analog output, and other similar features. The operation of this product and the restrictions placed may vary depending on the date of purchase, as the gove rning board of the AACS may adopt or change its restriction rules after the time of purchase.

and DVD

Copyrights and Trademarks

• This system incorporates with Dolby* Digital and Dolby Pro Logic (II) adaptive matrix surround decoder and the DTS** Digital Surround System.

* Manufactured under lic ense

from Dolby Laboratories. Dolby, Pro Logic, and the double-D symbol are

trademarks of Dolby Laboratories.

** Manufactured under license

under U.S. Patent #’s: 5,451,942; 5,956,674; 5,974,380; 5,978,762; 6,226,616; 6,487,535; 7,212,872; 7,333,929; 7,392,195; 7,272,567 & other U.S. and worldwide patents issued & pending. DTS, DTS-HD and the Symbol are registered trademarks, & DTS-HD Master Audio, and the DTS logos are trademarks of DTS, Inc. Product includes software. © DTS, Inc. All Rights Reserved.

• This system incorporates HighDefinition Multimedia Interface

(HDMI

) technology. HDMI, the HDMI logo and HighDefinition Multimedia Interface are trademarks or registered trademarks of HDMI Licensing LLC in the United States and other countries.

• Java is a trademark of Oracle and/ or its affiliates.

• “BD-LIVE” and “BONUSVIEW” are trademarks of Blu-ray Disc Association.

• “Blu-ray Disc” is a trademark.

• “Blu-ray Disc,” “DVD+RW,” “DVD-RW,” “DVD+R,” “DVDR,” “DVD VIDEO,” and “CD” logos are trademarks.

• “Blu-ray 3D” and “Blu-ray 3D” logo are trademarks of Blu-ray Disc Association.

• “BRAVIA” is a trademark of Sony Corporation.

• “AVCHD” and the “AVCHD” logo are trademarks of Panasonic Corporation and Sony Corporation.

• , “XMB,” and “xross media bar” are trademarks of Sony Corporation and Sony Computer Entertainment Inc.

• “PLAYSTATION” is a trademark of Sony Computer Entertainment Inc.

• Music and video recognition technology and related data are provided by Gracenote

. Gracenote is the industry standard in music recognition technology and related content delivery. For more information, please visit www.gracenote.com. CD, DVD, Blu-ray Disc, and music and video-relate d data from Gracenote, Inc., copyright © 2000-present Gracenote. Gracenote Software, copyright © 2000-present Gracenote. One or more patents owned by Gracenot e apply to this product and service. See the Gracenote website for a nonexhaustive list of applicable Gracenote patents. Gracenote, CDDB, MusicID, MediaVOCS, the Gracenote logo and logotype, and the “Powered by Gracenote” logo are either registered trademarks or trademarks of Gracenote in the United States and/or other countries.

• The Wi-Fi CERTIFIED™ Logo is a certification mark of the Wi-Fi Alliance.

• The Wi-Fi Protected Setup™ Mark is a mark of the Wi-Fi Alliance.

• “Wi-Fi CERTIFIED™” and “WiFi Protected Setup™” are trademarks of the Wi-Fi Alliance.

• “PhotoTV HD” and th e “PhotoTV HD” logo are trademarks of Sony Corporation.

• MPEG Layer-3 audio coding technology and patents licensed from Fraunhofer IIS and Thomson.

• iPhone, iPod, iPod classic, iPod nano, and iPod touch are trademarks of Apple Inc., registered in the U.S. and other countries.

• “Made for iPod,” and “Made for iPhone” mean that an electronic accessory has been designed to connect specifically to iPod or iPhone, respectively, and ha s been certified by the developer to meet Apple performance standards. Apple is not responsible for the operation of this device or its compliance with safety and regulatory standards. Please note that the use of this accessory with iPod or iPhone may affect wireless performance.

• Windows Media is either a registered trademark or trademark of Microsoft Corporation in the United States and/or other countries. This product contains technology subject to certain intellectual property rights of Microsoft. Use or distribution of this technology outside of this product is prohibited without the ap propriate license(s) from Microsoft. Content owners use Microsoft PlayReady

™

content access technology to protect their intellectual property, including copyrighted content. This device uses PlayReady technology to access PlayReady-protected content and/or WMDRMprotected content. If the device fails to properly enforce restrictions on content usage, content owners may require Microsoft to revoke the device’s ability to consume PlayReadyprotected content. Revocation should not affect unprotected content or content protected by other content access technologies. Content owners may require you to upgrade PlayReady to access their content. If you decline an upgrade, you will not be able to access content that requires the upgrade.

•DLNA®, the DLNA Logo and DLNA CERTIFIED trademarks, service marks, or certification marks of the Digital Living Network Alliance.

• All other trademarks are trademarks of their respective owners.

• Other system and product names are generally trademarks or registered trademarks of the manufacturers. ™ and ® marks are not indicated in this document.

™

are

About These Operating Instructions

• The instructions in these Operating Instructions describe the controls on the remote. You can also use the controls on the unit if they have the same or similar names as those on the remote.

• In this manual, “disc” is used as a general reference for BDs, DVDs, Super Audio CDs, or CDs unl ess otherwise specified by the text or illustrations.

• Some illustrations are presented as conceptual drawings, and may be different from the actual products.

• The items displayed on the TV screen may vary depending on the area.

• The default setting is underlined.

Table of Contents

About These Operating Instructions ....... 4

Unpacking...............................................6

Index to Parts and Controls.....................8

Getting Started

Step 1: Installing the System....... 14

Step 2: Connecting the System... 18 Step 3: Connecting to the

Network.................................... 24

Step 4: Setting up the Wireless

System ..................................... 26

Step 5: Performing the Easy

Setup........................................ 27

Step 6: Selecting the Source....... 28

Step 7: Enjoying Surround

Sound....................................... 29

Playback

Playing a Disc .......................................32

Playing from a USB Device..................33

Enjoying an iPod/iPhone.......................34

Playing via a Network...........................36

Available Options .................................39

Sound Adjustment

Selecting the Effect to Suit

the Source .......................................41

Selecting the Audio Format, Multilingual

Tracks, or Channel..........................41

Enjoying Multiplex Broadcast

Sound ..............................................42

Tuner

Listening to the Radio...........................43

Other Operations

Using the Control for HDMI Function for

“BRAVIA” Sync ............................45

Calibrating the Appropriate Settings

Automatically .................................46

Setting the Speakers..............................47

Using the Sleep Timer ..........................48

Deactivating the Buttons on

the Unit ...........................................48

Controlling Your TV with the Supplied

Remote............................................49

Changing the Brightness of the Front

Panel Display.................................. 49

Saving Power in Standby Mode ........... 49

Browsing Websites............................... 49

Further Settings for the Wireless

System ............................................ 51

Setting up the Network......................... 52

Settings and Adjustments

Using the Setup Display ....................... 56

[Network Update]................................. 56

[Screen Settings]................................... 57

[Audio Settings].................................... 58

[BD/DVD Viewing Settings]................ 59

[Parental Control Settings] ................... 60

[Music Settings].................................... 60

[System Settings].................................. 60

[Network Settings]................................ 61

[Easy Setup].......................................... 62

[Resetting] ............................................ 62

Additional Information

Precautions............................................ 63

Notes about the Discs ........................... 64

Troubleshooting.................................... 65

Playable Discs....................................... 71

Playable Types of Files......................... 72

Supported Audio Formats..................... 73

Specifications........................................ 74

Language Code List.............................. 76

Index ..................................................... 77

Unpacking

• Front speakers (2)

• Surround speakers (2)

• Center speaker (1)

• Speaker-bottom covers (4)

• Bases (4)

• Lower parts of the front and surround speakers (4)

• Screws (silver) (4)

• Screws (black) (12)

• FM wire antenna (aerial) (1)

• Calibration mic (1)

• High Speed HDMI cable (1) (Saudi Arabian, Singapore, Thai, and Taiwan models only)

• Dock for iPod/iPhone (TDM-iP30) (1) (Singapore and Thai models only)

• USB cable (1) (Singapore and Thai models only)

• Surround amplifier (1)

• Subwoofer (1)

• Speaker cords (5, red/white/ green/gray/blue)

•Video cord (1)

• Remote commander (remote) (1)

• R6 (size AA) batteries (2)

• Wireless transceivers (2)

• Operating Instructions

• Quick Setup Guide

• Speaker Installation Guide

• Software License Information

Preparing the remote

Insert two R6 (size AA) batteries (supplied) by matching the 3 and # ends on the batteries to the markings inside the compartment.

Index to Parts and Controls

For more information, refer to the pages indicated in parentheses.

Front panel

VOL VOL FUNCTION

A Front panel display B Soft-touch buttons/indicators

Z (open/close) (page 32)

Opens or closes the disc tray.

N (play)

Starts or re-starts playback (resume play). Plays a slideshow when a disc containing

JPEG image files is inserted.

x (stop)

Stops playback and remembers the stop point (resume point). The resume point for a title/track is the last point you played or the last photo for a photo folder.

VOL +/–

Adjusts the system’s volume.

FUNCTION

Selects the playback source.

C (USB) port (page 33)

Used for connecting a USB device.

D Power indicator

Lights up while the system is turned on.

E Disc tray (page 32) F "/1 (on/standby)/Remote sensor

Turns on the unit, or sets it to standby mode.

About soft-touch buttons/ indicators

These buttons function when the soft-touch button indicators are lit. You can turn on/off the indicators by setting [Illumination/Display] (page 60). When you set [Illumination/Display] to [Simple/Off], the indicators turn off. In this case, touch any softtouch button. When the indicators light up, touch the desired button.

• These buttons work when you touch them lightly. Do not press on them with excessive force.

Front panel display

About the indications in the front panel display

A Displays the system’s playing status. B Lights up when repeat play is

activated.

C Lights up when stereo sound is

received. (Radio only)

D Lights up when the system is playing

via the PARTY STREAMING function.

E Lights up when the HDMI (OUT) jack is

correctly connected to an HDCP (Highbandwidth Digital Content Protection)compliant device with HDMI or DVI (Digital Visual Interface) input.

F Lights up when muting is on. G Displays the system’s status, such as

radio frequency, etc.

H Lights up when outputting 720p/1080i/

1080p video signals from the HDMI (OUT) jack or 720p/1080i video signals from the COMPONENT VIDEO OUT jacks*.

* COMPONENT VIDEO OUT jacks are

equipped on non-European/non-Saudi Arabian models.

Rear panel

SPEAKERS

FRONT R FRONT L CENTER

SUBWOOFER

VIDEO OUT

A SPEAKERS jacks (page 18) B COMPONENT VIDEO OUT jacks (page

19) (for non-European/non-Saudi Arabian models)

C (USB) port (page 33) D SAT/CABLE (DIGITAL IN COAXIAL)

jack (page 21)

E Wireless transceiver (EZW-RT50) slot

(page 26)

F ANTENNA (FM COAXIAL 75Ω) jack

(page 23)

COMPONENT VIDEO OUT

PBP

ARC

OUT

IN 1 IN 2

LAN (100)

DIGITAL IN

OPTICAL

CABLE

DIGITAL IN

SAT/

COAXIAL

EZW-RT50

AUDIO IN

ECM-AC2

COAXIAL

AUDIO

A.CAL MIC

ANTENNA

G A.CAL MIC jack (pages 27, 46) H AUDIO (AUDIO IN L/R) jacks (page 21) I TV (DIGITAL IN OPTICAL) jack (page

19)

J LAN (100) terminal (page 24) K HDMI (IN 2) jack (page 21) L HDMI (IN 1) jack (page 21) M HDMI (OUT) jack (page 19) N VIDEO OUT jack (page 19)

Surround amplifier

Front panel

LINK/STANDBY

A "/1 (Power)

Turns the surround amplifier on/off.

B LINK/STANDBY indicator

You can check the status of wireless transmission between the main unit and surround amplifier.

Indicator Status

Turns green. The system is turned on,

Turns orange. The system is turned on,

Flashes green quickly.

Flashes green or orange slowly.

Turns red. The surround amplifier is in

Turns off. The surround amplifier is

Flashes red. The surround amplifier’s

wireless transmission is activated and surround signals are being received.

wireless transmission is activated with the Secure Link function, and surround signals are being received.

The wireless transceiver is not inserted correctly into the wireless transceiver slot.

Wireless transmission is deactivated.

standby mode while the system is in standby mode or wireless transmission is deactivated.

turned off.

protection is active.

Rear panel

IMPEDANCE USE

EZW-RT50

SPEAKERS

SECURE LINK

C Wireless transceiver (EZW-RT50) slot D SPEAKERS jacks E SECURE LINK button (page 51)

Starts the Secure Link function.

3-16

Remote control

SPEAKERS

AUDIO

BRAVIA Sync

FUNCTION

TOP MENU

RETURN OPTIONS

SOUND MODE

PRESET

TUNING

DIMMER

SLEEP

DISPLAY

HOME

231

564

8097

POP UP/ MENU

SOUND MODE

PRESET

TUNING

Number 5, , 2 +, and N buttons have a tactile dot. Use the tactile dot as a reference when operating the remote.

• : For TV operations (For details, see “Controlling Your TV with the Supplied Remote” (page 49).)

A Z (open/close)

Opens or closes the disc tray.

SPEAKERS TVy AUDIO

Selects whether TV sound is output from the system’s speakers or the TV’s speaker(s). This function works only when you set [Control for HDMI] to [On] (page 60).

TV "/1 (on/standby) (page 49)

Turns on the TV or sets it to standby mode.

"/1 (on/standby) (pages 27, 43)

Turns on the system or sets it to standby mode.

B Number buttons (pages 44, 49)

Enters the title/chapter numbers, preset station number, etc.

(audio) (pages 41, 42)

Selects the audio format/track.

(subtitle) (page 59)

Selects the subtitle language when multilingual subtitles are recorded on a BDROM/DVD VIDEO.

C Color buttons (red/green/yellow/blue)

Short cut keys for selecting items on some BD menus (can also be used for Java interactive operations on BDs).

D TOP MENU

Opens or closes the BD’s or DVD’s Top Menu.

POP UP/MENU

Opens or closes the BD-ROM’s Pop-up Menu, or the DVD’s menu.

OPTIONS (pages 29, 39, 49)

Displays the options menu on the TV screen or in the front panel display. (The location differs based on the selected function.)

RETURN

Returns to the previous display.

C/X/x/c

Moves the highlight to a displayed item.

(enter)

Enters the selected item.

E SOUND MODE +/– (page 41)

Selects the sound mode.

HOME (pages 27, 43, 46, 47, 49, 52, 56)

Enters or exits the system’s home menu.

F Playback operation buttons

See “Playback” (page 32).

./> (previous/next)

Skip to the previous/next chapter, track, or file.

(replay/advance)

Briefly replay the current scenes for 10 seconds./Briefly fast forwards the current scenes for 15 seconds.

m/M (fast/slow/freeze frame)

Fast reverse/fast forward the disc during playback. Each time you press the button, the search speed changes.

Activates slow-motion play when pressed for more than one second in pause mode. Plays one frame at a time when pressed in pause mode.

Slow-motion and single-frame playback are not available for Blu-ray 3D Discs.

N (play)

Starts or re-starts playback (resume play). Activates One-Touch Play (page 45) when

the system is on and set to the “BD/DVD” function.

X (pause)

Pauses or re-starts playback.

x (stop)

Stops playback and remembers the stop point (resume point). The resume point for a title/track is the last point you played or the last photo for a photo folder.

H DISPLAY (pages 32, 36, 49)

Displays playback and web browsing information on the TV screen.

Displays the preset radio station, frequency, etc., in the front panel display. Displays the stream information/decoding status in the front panel display when the function is set to other than “BD/DVD.” When the system is set to the “HDMI1,” “HDMI2,” “TV,” or “SAT/CABLE” function, the stream information/decoding status appears only when a digital signal is input. The stream information/decoding status may not appear depending on the stream or item being decoded.

I DIMMER (page 49)

Changes the brightness of the front panel display.

SLEEP (page 48)

Sets the sleep timer.

FUNCTION (pages 28, 43)

Selects the playback source.

(favorites)

Displays the Internet contents added to the Favorites List. You can save 18 favorite Internet contents.

Radio operation buttons

See “Tuner” (page 43).

PRESET +/–

TUNING +/–

G (muting)

Turns off the sound temporarily.

2 (volume) +/– (page 43)

Adjusts the volume.

TV 2 (volume) +/–

Adjusts the TV volume.

TV t (TV input)

Switches the TV’s input source between the TV and other input sources.

Getting Started

Step 1: Installing the System

Getting Started

How to position the system

Install the system by referring to the illustration below.

• Use caution when placing the speakers and/or speaker stands attached to the speakers on a specially treated (waxed,

oiled, polished, etc.) floor, as staining or discoloration may result.

• Do not lean or hang on a speaker, as it may fall down.

A Front speaker (L (left)) B Front speaker (R (right)) C Center speaker D Surround speaker (L (left)) E Surround speaker (R (right)) F Subwoofer G Unit H Surround amplifier

• To assemble the speakers, refer to the supplied “Speaker Installation Guide.”

• You can install the speakers on a wall. For details, refer to the supplied “Speaker Installation Guide.”

About the subwoofer’s speaker cord

You can arrange the subwoofer’s speaker cord by changing which direction it protrudes from the bottom of the subwoofer.

Bottom of the subwoofer

When packing is opened: Speaker cord is connected.

• To avoid short-circuiting the speakers, make sure that the speaker cord connection is not like the following examples. If there is a problem, correct it.

Examples of an improper speaker cord connection

Stripped speaker cord is touching another speaker terminal

Stripped cords are touching each other due to excessive removal of insulation

Getting Started

When installing the subwoofer with the wide side facing forward

Toward the listening position

Getting Started

1 Secure the speaker cord in the speaker cord holder to the right of the speaker terminal.

Speaker cord holder to the right of the speaker terminal

Speaker cord

2 Thread the speaker cord through the gap along the side of the subwoofer.

Gap

When installing the subwoofer with the narrow side facing forward

Toward the listening position

1 Secure the speaker cord in the speaker cord holder to the left of the speaker terminal.

Speaker cord holder to the left of the speaker terminal

Speaker cord

2 Thread the speaker cord through the gap along the side of the subwoofer.

Gap

Getting Started

Step 2: Connecting the System

For connecting the system, read the information on the following pages. Do not connect the AC power cords (mains leads) of the unit and surround amplifier to a wall outlet (mains) until all the other connections are made. To assemble the speakers, refer to the supplied “Speaker Installation Guide.”

Getting Started

• When you connect another component with a volume control, turn down the volume of the other components to a level where sound is not distorted.

Connecting the speakers

To connect speaker cords to the speaker

You need to connect a speaker cord to each of the front, center, and surround speakers. The connector of the speaker cords and the color tube are color-coded based on the speaker type. Be sure to match the speaker cords to the appropriate terminals on the speakers: the speaker cord with the color tube to 3, and the speaker cord without the color tube to #. Do not catch the speaker cord insulation (rubber covering) in the speaker terminals.

Rear or bottom of the speaker

Connector

Color tube

(+)

(–)

To connect speaker cords to the unit and surround amplifier

Connect the speaker cords to match the color of the SPEAKERS jacks of the unit and surround amplifier. When connecting to the unit and surround amplifier, insert the connector until it clicks.

White (Front left speaker (L))

Red (Front right speaker (R))

Rear panel of the unit

SPEAKERS

FRONT R FRONT L CENTER

SUBWOOFER

Purple (Subwoofer)

Green (Center speaker)

Blue (Surround left speaker (L))

IMPEDANCE USE

SPEAKERS

Rear panel of the surround amplifier

Gray (Surround right speaker (R))

3-16

Connecting the TV

Connect the system to your TV to display the image of the system on your TV, and listen to TV sound via the system’s speakers.

Getting Started

Depending on the jacks and functions on your TV, select the connection method.

• When your TV has an HDMI jack that is marked “ARC

”: Connection A

• When your TV has an HDMI jack: Connections A and D

• When your TV has component video input jacks (for non-European/non-Saudi Arabian models):

Connections B and D

• When your TV does not have jacks above: Connections C and D

Video connections

Audio connection

ABC D

HDMI cable

Image quality

Signal flow

: Video signal

: Audio signal

Component video cable

(not supplied)

ABC D

Video cord

HDMI IN

Green

COMPONENT VIDEO IN

PBP

Digital optical cord

(not supplied)

VIDEO IN DIGITAL OUT

Red

Yellow

Blue

OPTICAL

Blue

Rear panel of the unit

Audio Return Channel. For details, see “About Audio Return Channel” (page 20).

The High Speed HDMI cable is supplied with Saudi Arabian, Singapore, Thai, and Taiwan models only.

Green

VIDEO OUT

COMPONENT VIDEO OUT

PBP

ARC

OUT

Red

IN 1 IN 2

Yellow

DIGITAL IN

OPTICAL

The video cord is supplied with Saudi Arabian and Taiwan models only.

Available only when your TV is compatible with the Audio Return Channel function.

A HDMI cable connection

If your TV has an HDMI jack, connect to the TV with an HDMI cable. This will provide better image quality compared to other types of connections. When connecting with an HDMI cable, you need to select the type of output signal when performing the Easy Setup (page 27). For further HDMI settings, see “[HDMI Settings]” (page 60).

Getting Started

About Audio Return Channel

If your TV is compatible with the Audio Return Channel function, an HDMI cable connection also sends a digital audio signal from the TV. You do not need to make a separate audio connection for listening to TV sound. For setting the Audio Return Channel function, see [Audio Return Channel] (page 60).

B Component video cable connection (for non-European/non-Saudi Arabian models)

If your TV does not have an HDMI jack, but has component video input jacks, connect to the TV with a component video cable. Picture quality will be improved compared to using a video cord connection. When connecting with a component video cable, you need to select the type of output signal in the Easy Setup (page 27).

C Video cord connection

If your TV does not have an HDMI jack or a component video input jack, make this connection.

D Digital optical cord connection

This connection sends an audio signal to the system from the TV. To listen to TV sound via the system, perform this connection. With this connection, the system receives a Dolby Digital multiplex broadcast signal and you can enjoy multiplex broadcast sound.

• You can enjoy the TV sound by selecting the “TV” function (page 28).

• If your TV does not have a digital optical output jack, you can connect the unit and your TV with an audio cord for listening to TV sound via the system. For connection details, see “Connecting the other components” (page 21).

Connecting the other components

When a component you wish to connect to the system has an HDMI (OUT) jack

You can connect a component that has an HDMI (OUT) jack such as a set-top box/digital satellite receiver or PLAYSTATION®3, etc., with an HDMI cable. An HDMI cable connection can send both video and audio signals. By connecting the system and the component using an HDMI cable, you can enjoy high-quality digital picture and sound via the HDMI (IN 1) or HDMI (IN 2) jack.

Rear panel of the unit

ARC

OUT

IN 1 IN 2

HDMI cable (not supplied) Use HDMI (IN 1) or HDMI (IN 2).

To the HDMI OUT jack of the set-top box/

HDMI OUT

digital satellite receiver or PLAYSTATION

3, etc.

Getting Started

• Video signals from the HDMI (IN 1/2) jacks are sent to the HDMI (OUT) jack only when the “HDMI1” or “HDMI2” function is selected.

• To send an audio signal from the HDMI (IN 1/2) jacks to the HDMI (OUT) jack, you may need to change the audio output setting. For details, see [Audio Output] in [Audio Settings] (page 58).

When the component does not have an HDMI OUT jack

Connect the system so that video signals from the system and other component are sent to the TV, and audio signals from the component are sent to the system as follows.

Video out

Component

Getting Started

System

Audio out

Signal flow

: Video signal

: Audio signal

If the component plays sound only, connect the audio output of the component to the system.

Depending on the jacks on the component, select the connection method.

• Component which has a digital coaxial output jack: A

• Component which does not have a digital coaxial output jack: B

Rear panel of the unit

DIGITAL IN

SAT/

COAXIAL

CABLE

AUDIO IN

AUDIO

: Signal flow

Red

A Digital coaxial cord (not supplied)

White

B Audio cord (not supplied)

L R

AUDIO OUT

Red

To the audio out jacks of the VCR, digital satellite receiver, PlayStation, or portable audio source, etc.

To the digital coaxial out jack of the VCR or digital satellite receiver, etc.

COAXIAL

DIGITAL OUT

White

• If you make connection above, set [Control for HDMI] in [HDMI Settings] of [System Settings] to [Off] (page 60).

• You can enjoy component sound by selecting the “SAT/CABLE” function for connection A, or the “AUDIO” function for connection B (page 28).

Connecting the antenna (aerial)

Rear panel of the unit

COAXIAL

ANTENNA

FM wire antenna (aerial)

(supplied)

• Be sure to fully extend the FM wire antenna (aerial).

• After connecting the FM wire antenna (aerial), keep it as horizontal as possible.

• If you have poor FM reception, use a 75-ohm coaxial cable (not supplied) to connect the unit to an outdoor FM antenna (aerial).

Getting Started

Step 3: Connecting to the Network

• To connect the system to your network, you need to make network settings that suit your usage environment and components. For details, see “Setting up the Network” (page 52) and “[Network Settings]” (page 61).

Select the method based on your LAN (Local Area Network) environment.

Getting Started

Rear panel of the unit

Internet

ADSL modem/ cable modem

LAN cable (not supplied)

LAN (100)

Broadband router

LAN 1 LAN 2 LAN 3 LAN 4WANETHER

USB Wireless LAN Adapter (not supplied)

1 Wired Setup

Use a LAN cable to connect to the LAN (100) terminal on the unit.

2 USB Wireless Setup

Use a wireless LAN via the USB Wireless LAN Adapter (Sony UWA-BR100* only). The USB Wireless LAN Adapter may not be available in some regions/countries.

* As of November 2010.

Turn the unit off before connecting the extension cable or inserting the USB Wireless LAN Adapter. After inserting the USB Wireless LAN Adapter to the base and connecting the extension cable to the

(USB) port (front or rear), turn the unit on again.

+ 56 hidden pages

Sony BDV-E985W Users guide

Specifications and Main Features

Frequently Asked Questions

User Manual

WARNING

About These Operating Instructions

Unpacking

Preparing the remote

Index to Parts and Controls

Front panel

Front panel display

Rear panel

Surround amplifier

Remote control

Getting Started

Step 1: Installing the System

How to position the system

About the subwoofer’s speaker cord

Step 2: Connecting the System

Connecting the speakers

Connecting the TV

Connecting the other components

Connecting the antenna (aerial)

Step 3: Connecting to the Network
