SANDWICH TOASTER SSMW 750 C3
SANDWICH TOASTER
Operating instructions
IAN 313476
SANDWICHMAKER
Bedienungsanleitung
Before reading, unfold the page containing the illustrations and familiarise yourself with all functions of
the device.
Klappen Sie vor dem Lesen die Seite mit den Abbildungen aus und machen Sie sich anschließend mit allen
Funktionen des Gerätes vertraut.
GB / IE / NI Operating instructions Page 1
DE / AT / CH Bedienungsanleitung Seite 21
A
B
C
E
D
Index
Introduction ...................................................2
Copyright ............................................................... 2
Limited liability ........................................................... 2
Intended use ............................................................ 2
Items supplied .................................................3
Disposal of the packaging .................................................. 3
Appliance description ...........................................4
Technical data .................................................5
Safety instructions .............................................5
Exchanging the removable plates .................................8
Placement of the removable plates ........................................... 8
Extracting the removable plate .............................................. 8
Commissioning ................................................9
Operation ...................................................10
Toasting sandwiches ..................................................... 10
Baking waffles ..........................................................10
Grilling ................................................................ 11
Cleaning .....................................................12
Storage .....................................................13
Troubleshooting ..............................................13
Recipes ......................................................14
Dutch Tomato Toast ......................................................14
Italian Toast ............................................................15
Hawaiian Toast .........................................................16
Waffles ............................................................... 16
Apple waffles ........................................................... 17
Shrimp skewer ..........................................................17
Disposal .....................................................18
Kompernass Handels GmbH warranty ............................18
Service ................................................................ 20
Importer ............................................................... 20
SSMW 750 C3
GB│IE│NI
│
1 ■
Introduction
Congratulations on the purchase of your new appliance!
You have clearly decided in favour of a modern, high quality product. These
operating instructions are a component of this product. They contain important
information in regard to safety, use and disposal. Before using the product,
familiarise yourself with all of these operating and safety instructions. Use this
appliance only as described and only for the purposes indicated. In addition,
pass these documents on, together with the product, to any future owner.
Copyright
This documentation is copyright protected.
Any copying or reproduction of it, including as extracts, as well as the reproduction
of images, also in an altered state, is only permitted with the written authorisation
of the manufacturer.
Limited liability
All technical information, data and instructions for the installation, connection
and operation contained in these operating instructions correspond to the latest
available at the time of printing and, to the best of our knowledge, take into
account our previous experience and know-how.
No claims can be derived from the details, illustrations and descriptions in these
instructions.
The manufacturer assumes no responsibility for damage caused by failure to observe these instructions, improper use, incompetent repairs, making unauthorised
modifications or for using unapproved replacement parts.
Intended use
This appliance is intended exclusively for the toasting of filled sandwiches, baking
waffles and the grilling of foodstuffs.
This appliance is intended exclusively for use in domestic households. Do not use
the appliance for commercial applications!
■ 2 │ GB
│IE│
NI SSMW 750 C3
Items supplied
The appliance is delivered with the following components as standard:
▯ Sandwich Toaster
▯ 2 Removable plates “Sandwich”
▯ 2 Removable plates “Waffles”
▯ 2 Removable plates “Grill”
▯ Operating instructions
1) Remove the appliance, the removable plates and the operating instructions
from the carton.
2) Remove all packing material.
NOTICE
► Check the contents to ensure everything is present and for visible damage.
► If the delivery is not complete or has been damaged due to defective
packaging or transportation, contact the Service Hotline (see section
Service).
Disposal of the packaging
The packaging protects the appliance from transport damage. The packaging
materials are selected from the point of view of their environmental friendliness
and disposal technology and are therefore recyclable.
The recirculation of packaging into the material circuit saves on raw material and
reduces the amount of waste generated. Dispose of packaging material that is
no longer needed as per the regionally established regulations.
Dispose of the packaging in an environmentally friendly manner.
Note the labelling on the packaging and separate the packaging material
components for disposal if necessary. The packaging material is labelled with
abbreviations (a) and numbers (b) with the following meanings:
1–7: Plastics,
20–22: Paper and cardboard,
80–98: Composites.
NOTICE
► If possible preserve the appliance's original packaging during the warranty
SSMW 750 C3
period so that, in the event of a warranty claim, you can pack the appliance
ideally for its return.
GB│IE│NI
│
3 ■
Appliance description
Illustration A:
1 Locking device
2 Heating coil
3 Lower mountings
4 Heating coil
5 Locking devices
6 Rear mountings
Illustration B (Sandwich plates):
7 Upper latches
8 Lower and rear latches
9 Front latches
Illustration C (Waffle plates):
7 Upper latches
8 Lower and rear latches
9 Front latches
Illustration D (Grill plates):
7 Upper latches
8 Lower and rear latches
9 Front latches
Illustration E:
0 Lid locking device
q Control lamp “Power”
w Control lamp “Ready”
e Cable retainer
■ 4 │ GB
│IE│
NI SSMW 750 C3
Technical data
Voltage 220 – 240 V ∼ AC, 50/60 Hz
Power consumption 750 W
All of the parts of this appliance that come into
contact with food are food-safe.
Safety instructions
WARNING! RISK OF ELECTRIC SHOCK!
► Arrange for damaged power cables and/or plugs to be
replaced as soon as possible by a qualified specialist or by
Customer Services.
► Use the appliance only in dry indoor areas, not outdoors.
NEVER submerse the appliance in water or other liquids!
If you do, then you could receive a potentially fatal
electric shock.
► When cleaning, ensure that water cannot permeate into
the appliance. NEVER clean the appliance under running
water.
► Ensure that the appliance can never come into contact with
water. NEVER use the appliance adjacent to water or close
to vessels containing liquids.
► Ensure that the power cable never gets wet or moist when
the appliance is in use. Lay the cable such that it cannot be
clamped or otherwise damaged.
► After use, disconnect the power cable from the mains power
socket to turn off the unit.
► NEVER open the housing of the appliance.
SSMW 750 C3
GB│IE│NI
│
5 ■
WARNING! RISK OF INJURY!
► This appliance may be used by children of at least 8 years
of age and persons with reduced physical, sensory or mental capabilities or lack of experience and/or knowledge if
they are supervised by a person responsible for their safety
or receive from this person instruction in how the appliance is
to be used, and they have understood the potential risks.
► Children should not play with the appliance.
► Cleaning and user maintenance should not be performed by
children, unless they are older than 8 years of age and are
supervised. Children younger than 8 years of age are to be
kept away from the appliance and the power cable.
► The appliance can become hot when it is in use. Therefore,
only touch the handles.
► Let the appliance cool down completely before cleaning it,
exchanging the removable plates or putting it into storage.
► Use caution when removing the finished foods (sandwiches,
waffles, etc.). The appliance, as well as the sandwiches, will
be very hot.
► Use the appliance only on a stable, non-slippery and level
surface.
► Do not use an external timing switch or a separate remote
control system to operate the appliance.
Attention! Hot surfaces!
■ 6 │ GB
│IE│
NI SSMW 750 C3
CAUTION! RISK OF FIRE!
► This appliance may not be used in close vicinity to
flammable material.
► Do not leave the appliance unattended at any time when it
is in use.
► Operate the appliance only on heat resistant surface.
► Do not operate the appliance unsupervised.
CAUTION! PROPERTY DAMAGE!
► To avoid damaging the non-stick coating of the Sandwich
Maker, remove your cooked foods only with a plastic or
wooden spatula or some other suitable, non-metallic
implement.
► Do not use abrasive cleansers or sharp objects for cleaning.
SSMW 750 C3
GB│IE│NI
│
7 ■
Exchanging the removable plates
You can choose between 3 different removable plates:
– Removable plates “Sandwich”: for the preparation of filled sandwiches.
– Removable plates “Waffles”: for baking waffles.
– Removable plates “Grill”: for grilling meat, fish, etc.
WARNING! RISK OF ELECTRIC SHOCK
► Disconnect the plug from the mains power socket before exchanging the
removable plates.
WARNING! RISK OF INJURY!
► Let the appliance cool down before exchanging the removable plates!
Risk of Burns!
Placement of the removable plates
1) Open the sandwich maker by releasing the lid locking device 0 and lifting
the lid.
2) Upper removable plate: First slide the lower latches 8 into the lower mountings 3.
3) Now press the upper latches 7 onto the locking devices 1, so that the
upper latches 7 spring under the locking devices 1 and the removable
plate is firmly seated.
4) Lower removable plate: First slide the rear latches 8 into the rear mountings 6.
5) Now press the front latches 9 onto the locking devices 5 so that the
latches 9 spring under the locking devices 5 and the removable plate is
firmly seated.
6) Press firmly once in the centre of the lower removable plate to ensure that it
is securely inserted.
Extracting the removable plate
1) Upper removable plate: Slide the locking devices 1 upwards and simultaneously tilt the removable plate forward so that you can lift it out from
underneath the lower mountings 3.
2) Lower removable plate: Pull the locking devices 5 forward and lift the
removable plate so that you can pull it out from the rear mountings 6.
■ 8 │ GB
│IE│
NI SSMW 750 C3
Commissioning
Carry out the following procedure with each of the 3 pairs of removable plates.
■ Smear the non-stick coating on the removable plates with oil suitable for
cooking.
WARNING! RISK OF INJURY!
► Let the appliance cool down before exchanging the removable plates!
Risk of Burns!
■ Install a pair of removable plates into the appliance.
■ Insert the plug into a mains power socket.
■ Close the appliance and lock it with the lid locking device 0.
■ Let the appliance heat up for about 10 minutes.
NOTICE
► With the first usage a slight smell can arise (minimal smoke development is
also possible). This is normal and dissipates after a short time. Provide for
sufficient ventilation. For example, open a window.
■ Disconnect the plug and allow the appliance to cool down.
■ Clean the removable plates and the appliance as described in the chapter
“Cleaning”.
The appliance is now ready for use.
SSMW 750 C3
GB│IE│NI
│
9 ■
Operation
Toasting sandwiches
1) Select the removable plates “sandwich” and install them.
CAUTION! PROPERTY DAMAGE!
► Never use two different removable plates at the same time.
2) Close the lid and lock it with the lid locking device 0.
3) Insert the plug into a mains power socket. The red control lamp “Power” q
glows.
4) As soon as the appliance is heated up, the green control lamp “Ready” w
glows.
5) Open the lid and insert two prepared sandwiches on the lower removable plate.
6) Close the lid and lock it with the lid locking device 0. You can choose from
two locking positions. If the sandwich is still too thick, so that the lid locking
device 0 cannot be closed, reduce the amount of filling.
CAUTION! PROPERTY DAMAGE!
► To avoid damaging the non-stick coating of the Sandwich Maker, remove
your cooked foods only with a plastic or wooden spatula or some other
suitable, non-metallic implement.
7) The sandwiches are ready after about 5 – 6 minutes. This time information
can, depending on the type of filling and personal tastes, vary. Open the lid
and take the sandwiches out.
8) When you no longer wish to prepare any more sandwiches, disconnect the
plug from the mains power socket.
Baking waffles
1) Select the removable plates “waffles” and install them.
CAUTION! PROPERTY DAMAGE!
► Never use two different removable plates at the same time.
2) Close the lid and lock it with the lid locking device 0.
3) Insert the plug into a mains power socket. The red control lamp “Power” q
glows.
4) As soon as the appliance is heated up, the green control lamp “Ready” w glows.
■ 10 │ GB
│IE│
NI SSMW 750 C3
Grilling
5) Open the lid and place about 2 – 3 large tablespoons of batter into each of
the two waffle baking surfaces on the lower removable plate.
6) Now close the lid. Do not lock the lid!
CAUTION! PROPERTY DAMAGE!
► To avoid damaging the non-stick coating of the Sandwich Maker, remove
your waffles only with a plastic or wooden spatula or some other suitable,
non-metallic implement.
7) The waffles are ready after about 5 – 7 minutes. This time information can,
depending on the type of batter used and personal tastes, vary. Open the
lid and take the waffles out.
8) When you no longer wish to prepare any more waffles, disconnect the plug
from the mains power socket.
1) Select the removable plates “grill” and install them.
CAUTION! PROPERTY DAMAGE!
► Never use two different removable plates at the same time.
2) Close the lid and lock it with the lid locking device 0.
3) Insert the plug into a mains power socket. The red control lamp “Power” q
glows.
4) As soon as the appliance is heated up, the green control lamp “Ready” w
glows.
5) Open the lid and place the food to be grilled on the lower removable plate.
6) Now close the lid. Do not lock the lid!
7) From time to time check the degree of browning by lifting the lid.
CAUTION! PROPERTY DAMAGE!
► To avoid damaging the non-stick coating of the Sandwich Maker, remove
8) When the food is cooked through, take it from the removable plate.
9) When the appliance is no longer needed, remove the plug from the mains
power socket.
SSMW 750 C3
your cooked foods only with a plastic or wooden spatula or some other
suitable, non-metallic implement.
GB│IE│NI
│
11 ■
Loading...
