SilverCrest SMW 800 C2 User Manual [de]

MICROWAVE SMW 800 C2

MICROWAVE

Operating instructions

FOUR À MICRO-ONDES

Mode d'emploi

MIKROWELLE

Bedienungsanleitung

MIKROVÅGSUGN

Bruksanvisning

MAGNETRON

Gebruiksaanwijzing

IAN 102982/102984

Before reading, unfold the page containing the illustrations and familiarise yourself with all functions of the device.

Vik ut bildsidan och ha den till hands när du läser igenom anvisningarna och gör dig bekant med apparatens / maskinens funktioner.

Avant de lire le mode d'emploi, ouvrez la page contenant les illustrations et familiarisez-vous ensuite avec toutes les fonctions de l'appareil.

Vouw vóór het lezen de pagina met de afbeeldingen open en maak u vertrouwd met alle functies van het apparaat.

Klappen Sie vor dem Lesen die Seite mit den Abbildungen aus und machen Sie sich anschließend mit allen Funktionen des Gerätes vertraut.

GB / IE Operating instructions Page 1 SE Bruksanvisning Sidan 23 FR / BE Mode d'emploi Page 45 NL / BE Gebruiksaanwijzing Pagina 67 DE / AT / CH Bedienungsanleitung Seite 89

B C

Contents

Introduction 2

Intended use 2

Package contents 2

Appliance description 2

Combination cooking 13

Combination 1 14 Combination 2 14

Automatic menu 15

Starting the Automatic Menu 15

Technical data 2

Safety guidelines 3

Earthing information/ installation 8

Radio interference with other appliances 8

Before you begin 9

Basic principles of microwave cookery 9 Suitable cookware 9

First use 10

Setting up the appliance 10 Preparing the appliance 10

Operation 11

Setting the clock 11 Setting the kitchen timer 11 Child lock 12

Heating and cooking 12

Microwave operation 12 Microwave operation, quick start 13

Grill operation 13

Programmes in detail 16

Programme 1: Pasta 16 Programme 2: Fish 16 Programme 3: Rice 17 Programme 4: Chicken 17 Programme 5: Heating up 17 Programme 6: Potatoes 17 Programme 7: Roasting 17 Programme 8: Kebabs 18 Programme 9: Beverages 18

Defrosting 18

Preset start time (Preset) 19

Cleaning and care 19

Storage 20

Troubleshooting 20

Warranty and service 21

Disposal 21

Importer 21

SMW 800 C2

Introduction

Congratulations on the purchase of your new

appliance. You have selected a high quality product.

The operating instructions are part of this product. They contain important information on safety, usage and disposal. Before using the product, familiarise yourself with all handling and safety instructions. Use the product only as described and for the range of applications speciﬁ ed. Please also pass these operating instructions on to any future owner(s).

Intended use

This appliance is intended exclusively for heating up and preparing foodstuﬀ s according to the described procedures.

Any modiﬁ cations to the appliance shall be deemed to be improper use and implies substantial danger of accidents. The manufacturer shall assume no liability for damage attributable to misuse.

This appliance is intended solely for use in private homes.

Do not use it for commercial applications, or in industrial or laboratory situations!

Package contents

■ Microwave oven

■ Rotator assembly

■ Glass plate

■ Grill stand

■ Operating instructions

■ Quick guide

Appliance description

Figure A:

1 Display 2 Glass plate 3 Rotator assembly 4 Door handle 5 Ventilation slits

Figure B:

6 Timer/clock button 7 Combination button 8 Stop button 9 Control dial / Start/Quick start 0 Defrost button q Grill button w Microwave button

Figure C: e Grill stand

Technical data

Rated voltage: 230–240 V ~, 50Hz Max. power consumption: 1200 W Maximum power output – Microwave: 800 W Max. power consumption – Grill: 1000 W Microwave frequency: 2450 MHz

SMW 800 C2

Safety guidelines

Read the following important safety information carefully and keep it for further reference.

DANGER – ELECTRIC SHOCK!

► The appliance must only be connected to a correctly installed and earthed

mains power socket. Ensure that the rating for your local power supply corresponds with the details on the rating plate of the appliance.

► Ensure that the power cable does not become wet or moist during use.

Route the cable in such a way that it cannot be crushed or damaged.

► Keep the power cable well away from sources of heat. Do not route it in

front of the microwave oven door. The heat could damage the cable.

► Remove the plug from the mains power socket when the appliance is being

cleaned or in the event of a fault. Just switching oﬀ the appliance is not suﬃ cient, as the appliance is subject to mains voltage for as long as the plug is connected to the mains power socket.

► Always remove the plug from the mains power socket when the appliance

is not in use.

► To prevent accidents, have defective plugs and/or power cables replaced

immediately by a qualiﬁ ed specialist technician or our Customer Service department.

► The appliance and its connecting cable must be kept away from children. ► Never submerse the appliance, the power cable or the plug in water or

other liquids.

► Never pour ﬂ uids into the ventilation openings or the safety locks. If liquids

ever get into the vents, switch oﬀ the microwave oven immediately and pull the plug from the mains power socket. Have the appliance checked by qualiﬁ ed specialists.

Never submerge the appliance in water or other liquids.

SMW 800 C2

WARNING! RISK OF INJURY!

► If the door or the door seal is damaged, do not continue using the appli-

ance under any circumstances. Have the appliance repaired as soon as possible by qualiﬁ ed specialists.

► Never attempt to repair the appliance yourself. Removal of the appliance

housing could cause the release of microwave energy. Arrange for the repair to be carried out only by qualiﬁ ed specialists.

► This appliance may be used by children aged 8 years or more and by

persons with reduced physical, sensory or mental capabilities or lack of experience and/or knowledge if they are supervised, or have been instructed in the safe use of the appliance and have understood the potential risks.

► The appliance must not be used as a plaything by children. ► Cleaning and user maintenance must not be carried out by children, unless

they are aged 8 or over and are supervised.

► Children younger than eight years of age must be kept away from the

appliance and the power cable.

► Use this appliance only for its intended purpose as described in this

manual. Do not use any caustic chemicals or vapours in this appliance. This microwave oven is designed especially for heating, cooking, grilling, or drying foodstuﬀ s. It is not intended for use in industrial applications or laboratories.

► Keep children well away from the microwave oven when it is in use.

Risk of burns!

► Under no circumstances should you remove the microwave oven housing. ► If the lamp in the interior of the microwave oven needs replacing, have this

done by a qualiﬁ ed specialist.

► People ﬁ tted with a heart pacemaker should consult their doctor about the

possible risks of using a microwave oven before using it.

► Liquids or other food products should not be heated in sealed containers

as they can easily explode.

Caution! Hot surface!

SMW 800 C2

WARNING! RISK OF INJURY!

► It is dangerous for anyone apart from trained technicians to carry out main-

tenance or repair work that requires the removal of the housing, since this provides protection against radiation exposure due to microwave energy.

► Do not perform any repairs on the appliance. All repairs must be per-

formed by our Customer Service Unit or by a qualiﬁ ed specialist technician.

► Never touch the microwave oven door, housing, ventilation openings, ac-

cessories or the crockery directly after the cooking process. The parts will be very hot. Allow them to cool down before cleaning them.

► Ensure that the plug is easily accessible at all times, so that it can be re-

moved quickly in the event of an emergency.

► Do not allow the power cable to hang down from a table or work surface.

Children could pull on it.

► After heating, always open containers, popcorn bags, etc. so that the

opening faces away from your body. Escaping steam could cause scalds.

► Never stand directly in front of the microwave oven when opening the door.

Escaping steam could cause scalds.

► Do not fry foods in the microwave. Hot oil can damage parts of the appli-

ance and utensils and even cause skin burns.

► Always shake up or stir heated up jars of baby food or baby bottles!

The contents can heat up unevenly and burn or scold your baby. Always check the temperature before you feed your baby!

► Do not modify the microwave oven. ► Always check the temperature before eating, to avoid a potentially life-

threatening burning injury, for instance, to babies. Cooking utensils can become hot from the heat emitted by the food, therefore you may require oven gloves to touch them. Cooking utensils must also be checked to ensure they are microwaveable.

SMW 800 C2

WARNING! RISK OF INJURY!

► When heating drinks in the microwave, bubbling may be delayed when

the drink boils. Therefore, be careful when handling the container. To avoid sudden boiling or risks of injury:

– Place a glass rod in the liquid, if possible, for as long as it is being

heated.

– To avoid an unexpected reboiling, leave the liquid to stand in the micro-

wave oven for about 20 seconds after heating.

► Proceed with caution when heating liquids. Use only open containers, so

that any air bubbles produced can escape.

► Eggs in their shells and hard-boiled eggs should not be heated in the micro-

wave oven as they could explode, even after completion of the heating process. Food with thick skins, such as potatoes, whole pumpkins, apples and chestnuts must be pricked before cooking.

► The drying of foods or clothing or the warming of heating pads, slippers,

sponges, damp cloths or similar can lead to injuries, ignition of the material or ﬁ res.

WARNING! RISK OF FIRE!

► When heating food in plastic or paper containers, the cooking utensils

must be monitored frequently due to the danger of ignition.

► Do not place ﬂ ammable materials close to the microwave oven or the

ventilation openings.

► Remove all metallic closures from the packaging of the foodstuﬀ that you

intend to heat. Risk of ﬁ re!

► When making popcorn, use only microwaveable popcorn bags.

SMW 800 C2

WARNING! RISK OF FIRE!

► Do not use the microwave oven to warm up cushions ﬁ lled with kernels,

cherry stones or gels. Risk of ﬁ re!

► Do not use the microwave oven for storing foodstuﬀ s or other objects. ► Do not exceed the cooking times given by the manufacturer. ► Do not place any objects on the microwave oven when it is in use.

This will block the ventilation openings!

► Do not place the microwave oven next to other appliances discharging

heat, for example, an oven.

► Clean the microwave oven thoroughly after warming up greasy foods,

especially if they were not covered. They could possibly overheat and ignite. Allow the appliance to cool down completely before cleaning it.

► Do not thaw frozen fat or oil in the microwave oven. The fat or oil could

ignite.

► Do not use an external timer switch or a separate remote control system to

operate the appliance.

► If the appliance starts to give oﬀ smoke it should be switched oﬀ immediately

or the plug removed from the mains, and the door should be kept closed to smother any ﬂ ames that might otherwise escape.

► Do not place plastic containers in the microwave oven immediately after

a grill, combi or automatic menu process. The plastic could melt.

► Ensure that you maintain a minimum clearance of 10 cm from neighbouring

walls/surfaces. Keep a gap of at least 20 cm free above the microwave.

SMW 800 C2

ATTENTION! PROPERTY DAMAGE!

► Never operate the appliance in the operating mode "microwave" or using

combination cooking processes if there is no food inside.

► Never operate the microwave oven when it is empty. ► Never insert any foreign objects into the ventilation openings or the door

safety locks.

► Do not use metallic utensils which could reﬂ ect microwaves and lead to

sparking. Do not place cans in the microwave oven.

► The microwave oven may not be set up in areas with high humidity or

where moisture could collect.

► Do not lean on the microwave oven door. ► Insuﬃ cient cleanliness of the appliance could lead to the destruction of

the upper surfaces, which themselves aﬀ ect its useful lifespan and could possibly lead to dangerous situations.

► Do not move the microwave oven when it is in use.

Earthing information/ installation

■ This appliance must be earthed. This appliance

is to be connected only to a correctly earthed power socket. An individual circuit solely for the connection of the microwave is recommended.

DANGER – ELECTRIC SHOCK!

Improper use of the earthing connector could

►

increase the risk of an electric shock.

NOTE

If you have any questions about earthing or

►

the instructions on the use of this electrical appliance, please consult an electrician or a maintenance technician.

■ Neither the manufacturer nor the dealer can

accept liability for damage to the microwave oven or injury to persons resulting from failure to comply with the instructions for electrical connection.

Radio interference with other appliances

The operation of the microwave may cause interference on your radio, television or similar appliances.

If such interference occurs, it can be reduced or corrected by the following remedial measures:

■ Clean the door and the sealing surface of the

microwave.

■ Reorient the receiving antenna of the radio or

television.

■ Position the microwave in a diﬀ erent location to

the receiver.

■ Move the microwave away from the receiver.

■ Plug the microwave into another wall socket.

The microwave and the receiver should be connected to diﬀ erent circuits.

SMW 800 C2

Before you begin

Basic principles of microwave cookery

■ Arrange the food with consideration.

■ Place the thickest parts near the edges.

■ Pay attention to the cooking time. Select the

shortest possible stated cooking time and increase as required. Food that is cooked too long can begin to smoke or catch ﬁ re.

■ Cover the food during cooking with a lid suit-

able for microwave cookery. The lid prevents splashing and helps in the even cooking of the food.

■ While cooking, turn the food in the microwave

once so that items such as chicken or hamburgers are cooked more quickly.

■ Large pieces of food, such as joints of meat,

must be turned at least once.

■ Completely rearrange foods, such as meatballs,

after half the cooking time. Turn them over and move the meatballs from the middle of the cookware to the edge.

Suitable cookware

■ The ideal material for a microwave oven is

microwave-permeable, allowing the energy to penetrate the container to heat the food. Microwaves cannot permeate metal. For this reason, metal containers and cookware should not be used.

■ When using the microwave for heating, do not

use products made of recycled paper. These can contain minute fragments of metal, which can generate sparks and/or ﬁ res.

■ We recommend the use of round/oval cook-

ware instead of square or oblong containers, as food in corner areas tends to overcook.

■ The following list provides general hints to assist

you in selecting the correct cookware.

Micro-

Cookware

Heat-resistant glass

Non-heat-resistant glass

Heat-resistant ceramics

Microwaveable plastic dishes Yes No No

Kitchen roll Yes No No Metal trays/plates

Grill stand No Yes No Aluminium foil No Yes No Foil containers No Yes No

WARNING! RISK OF FIRE!

► Never use the grill stand e or other metallic

objects when you are using the appliance in the microwave mode or in the combination cooking process. Metals reﬂ ect the microwave radiation and this leads to the generation of sparks. This can cause a ﬁ re and irreparably damage the appliance!

wave

oven

Yes Yes Yes

No No No

Yes Yes Yes

No Yes No

Grill

Com-

bin-

ation

SMW 800 C2

First use

ATTENTION! MATERIAL DAMAGE!

Never operate the appliance when it is empty.

►

There is a danger of overheating, especially in the "microwave" and "combination cooking process" modes!

ATTENTION! MATERIAL DAMAGE!

Do not install the microwave above a cooker

►

or any other appliance generating heat. Installation in such a location could cause damage to the appliance and thus invalidation of the warranty.

Setting up the appliance

WARNING! RISK OF FIRE!

► This microwave oven is not suitable for instal-

lation in a kitchen cabinet. Suﬃ cient ventilation for the appliance cannot be assured in enclosed cabinets. The appliance could be damaged and there is an additional risk of a ﬁ re!

■ Select an level surface oﬀ ering suﬃ cient space

for the adequate ventilation of the appliance:

■ Ensure that you maintain a minimum clearance

of 10 cm from neighbouring walls/surfaces. Make sure that the door of the microwave oven can be opened easily.

■ Keep a gap of at least 20 cm free above the

microwave.

■ Ensure that the electrical plug is accessible with-

out problem, so that it can be easily reached and removed in case of danger.

■ Do not remove the feet underneath the micro-

wave oven.

■ Do not block the ventilation openings 5. If you

do, it could cause damage to the appliance.

■ Install the appliance as far away as possible

from radios and televisions. The operation of the microwave oven can cause malfunctions of radio and television reception.

Preparing the appliance

1) Remove all packaging materials and any stickers from the appliance.

NOTE

Do not remove the light grey mica cover plate, which is mounted in the cooking chamber to protect the magnetron.

2) Place the rotator assembly 3 on the drive axle in the cooking chamber so that this is ﬁ tted securely onto the drive axle.

3) Place the glass plate 2 centrally on the rotator assembly 3.

4) Insert the plug into a mains power socket. Use a 230–240V ~, 50 Hz, mains power socket with a 16 amp fuse. It is recommended that the microwave oven is powered from its own power circuit. If you are unsure about how to connect the microwave oven, consult a specialist.

Before using the microwave oven, the appliance must be heated up without food to remove any remaining production residues.

Place a microwaveable and heat-proof bowl ﬁ lled with water in the microwave.

Switch the appliance on in grill mode.

1) Press the Grill button q This selects Grill mode. The icon appears in the display 1.

2) Adjust the control dial 9 to a cooking time of 3 minutes.

3) Press Start/Quick start 9 process.

once.

to start the grilling

SMW 800 C2

NOTE

During initial use, the generation of light

►

smoke and a slight smell can occur, this is due to the production residues. This not harmful. Provide for suﬃ cient ventilation. For example, open a window.

4) After 3 minutes, the appliance will switch itself oﬀ automatically. Signal tones sound.

5) Open the door. Wait until it has cooled down completely.

6) Pull the mains plug from the socket and then clean the appliance, the rotator assembly 3 and the glass plate 2 with a damp cloth and then dry it thoroughly.

Operation

Setting the kitchen timer

The microwave oven is provided with a kitchen timer which you can use independently of the microwave operation.

1) Press the Timer/clock button 6

appliance is in standby mode. “00:00” and the icon for the kitchen timer on the display 1.

2) Set the desired time using the rotary dial 9.

You can select any time range from 10 seconds to 95 minutes.

3) Press the Start/Quick start button 9

The appliance beeps. The countdown begins.

► To stop the countdown timer, press the Stop

button 8 . The kitchen timer is cancelled, the icon disappears and the current time appears in the display 1.

when the

appear

Setting the clock

When you use the microwave oven for the ﬁ rst time, or there has been a power cut, the display 1 shows “1 : 0 1”.

1) Press and hold the Timer/clock button 6 until “Hr 12” appears on the display 1. If you want to switch to 24-hour mode, turn the control dial 9 until “Hr 24” appears. Conﬁ rm your selection by pressing the Start/ Quick Start button 9

2) Now set the required hour by turning the control dial 9.

3) Press the Start/Quick start button 9 The minute indicator appears.

4) Now set the required minutes by turning the control dial 9.

5) When the clock is correctly set, press the Start/ Quick Start button 9 indicate that the clock is running.

. The colon blinks to

As soon as the programmed time period has expired, you will hear three beeps.

NOTE

If you want to use the timer at the same time

►

as a cooking or grilling function, start this as described previously while the microwave is already running.

► After you have started the timer, the time and

settings of the selected cooking or grill function will be shown after about 3 seconds. The timer continues in the background, the icon appears on the display 1 to indicate that the timer is active. If you wish to check the progress of the kitchen timer, press the Timer/clock button 6

. The timer appears for a short time on the display. If the set cooking or grill function is ﬁ nished before the time has expired, the timer will continue to run in the background. You will hear 3 beeps as soon as the time has expired and the icon disappears.

SMW 800 C2

Child lock

Activate this setting to prevent accidental operation

by children or other persons not familiar with the operation of the appliance.

The child lock icon and the appliance cannot be put into operation as long as this function is activated.

■ Press and hold the Stop button 8 until you

hear a beep and the child lock icon on the display 1. The buttons and the control dial are now deactivated.

■ To deactivate the child lock, press and hold the

Stop button 8 until you hear an extended beep and the child lock icon

appears in the display 1

appears

disappears.

Heating and cooking

NOTE

You can cancel all input processes by pressing the Stop 8 button.

The appliance reverts to standby mode.

Microwave operation

WARNING! RISK OF FIRE!

Never use the grill stand e or other metallic objects when you are using the appliance in the microwave mode. Metals reﬂ ect the microwave radiation and this leads to the generation of sparks. This can cause a ﬁ re and irreparably damage the appliance!

NOTE

During the cooking process, drops of water can form on the oven door or on the housing. This is normal and is not an indication of a malfunction. When the appliance has cooled down, wipe the moisture oﬀ with a dry cloth.

1) Press the microwave button w . “P800 (800 watts) appears on the display 1 and the icon.

2) Turn the control dial 9 to set the desired output level (P800–P100).

3) Conﬁ rm your selection by pressing the Start/ Quick Start button 9

4) Now select the desired operating time by turning the control dial 9.

5) Conﬁ rm the set operating time by pressing the Start/Quick Start button 9

6) The microwave process starts.

SMW 800 C2

NOTE

Pausing the cooking process

Press the Stop button 8 cooking process. The appliance pauses the cooking process and stops countdown of the remaining time. Press the Start/Quick start button 9

Cancel the cooking process

Press the Stop button 8 cooking process. The appliance reverts to standby mode.

Check the output level

During the cooking process, press the Microwave button w brieﬂ y on the display 1 (P100–P800)

7) When a cooking process is complete, “End”

appears on the display 1 and you will hear 4 beeps. If the door of the microwave is not opened, the appliance beeps again after about 2 minutes.

to resume the cooking process.

. The set output level is shown

once to pause a

twice to stop the

Microwave operation, quick start

With this function you can start cooking immediately for 30 seconds (or longer, up to 12 minutes) at 800 W.

■ Press the button Start/Quick start button 9

once. The icon appears in the display 1 as well as “30”. After a brief moment, the cooking process starts for 30 seconds. The countdown begins.

If you wish to cook for a longer period, press the Start/Quick start button 9 desired time (up to 12 minutes) is reached.

repeatedly until the

Grill operation

You can use the grill function for thin slices of meat, steaks, burgers, sausages or chicken pieces. It is also excellent for use in making topped sandwiches and gratins.

NOTE

Always use the grill stand e for grilling. This

►

will help you to achieve an optimal grilling result.

► Always place the grill stand e on the glass

plate 2.

1) Press the Grill button q

function. The icon appears on the display 1 as well as “10”.

2) Set the required cooking time with the control

dial 9. The maximum possible cooking time setting is 95 minutes.

3) To start the grill function, press the button

Start/Quick start 9

4) Turn the meat after about half of the cooking time.

5) When a grill process is complete, “End” appears on the display 1 and you will hear 4 beeps. If the door of the microwave is not opened, the appliance beeps again after about 2 minutes.

to activate the grill

Combination cooking

WARNING! RISK OF INJURY!

If the appliance is operated in the combination cooking mode, children may only use the appliance under adult supervision due to the high temperatures.

This function combines the grill function and the normal microwave operation. In combination mode, a certain amount of time is automatically set aside for cooking and the remaining time for grilling in a single process. You may notice a quiet clicking noise when the oven is switching between modes.

SMW 800 C2

WARNING! RISK OF FIRE!

Never use the grill stand e or other metallic objects when you are using the appliance in the combination cooking mode. Metals reﬂ ect the microwave radiation and this leads to the generation of sparks. This can cause a ﬁ re and irreparably damage the appliance!

Combination 1

In Combination 1 the microwave component is 30% and the grill element amounts to 70% of the cooking time.

This is suitable for ﬁ sh or gratins, for example.

1) Press the Combination button 7 .

and as “:10”.

2) Conﬁ rm your selection by pressing the Start/

Quick Start button 9

3) Set the required cooking time with the control

dial 9. The maximum possible cooking time setting is 95 minutes.

4) To start, press the Start/Quick start button 9

Example: “Simple potato gratin”:

■ Cut approx. 500 g of potatoes into thin slices,

and place these in an ovenproof gratin dish.

■ Pour between 150 and 200 ml of cream over

them, and then season everything with salt and pepper.

■ Sprinkle grated cheese on top.

The cooking time is approx. 30–40 minutes.

appear on the display 1 as well

Combination 2

In Combination 2 the microwave component is 55 % and the grill element amounts to 45 % of the cooking time.

This is suitable for puddings, omelettes, poultry dishes or lasagne.

1) Press the Combination button 7

and as “:10”.

2) Turn the control dial until

display 1. Conﬁ rm your selection by pressing the Start/Quick Start button 9

3) Set the required cooking time with the control

dial 9. The maximum possible cooking time setting is 95 minutes.

4) To start, press the Start/Quick start button 9

Example: lasagne (ready meal, defrosted)

A “lasagne” ready meal weighing 400 g requires around 15 minutes to cook.

NOTE

The time information for the combination cooking examples can vary considerably due to diﬀ ering ingredients or food qualities. The speciﬁ ed times are merely guidelines.

Please check the cooking results and adjust the cooking time to suit if necessary.

appear on the display 1 as well

appears on the

SMW 800 C2

Automatic menu

For foods that are prepared in the Automatic menu modus, it is not necessary to programme in the duration of the cooking process and the power level. You only need to enter the type of food you wish to cook and its weight.

WARNING! RISK OF INJURY!

► The cooking utensils and the food may be

very hot after cooking! Use oven gloves or similar to remove the food from the microwave!

button 9

no. Symbol Food

Pasta 100–300 g

Fish 100–1000 g

Weight

(millilitres)

WARNING! RISK OF FIRE!

When using programmes with incorporated grill function (programme nos. 4, 7 and 8), you should not use any form of covering or cookware that is not heat resistant, as these could melt or ignite!

NOTE

The microwave calculates the time/output level for fresh foods. Frozen foods will not be adequately cooked with the times programmed into the microwave.

If required, defrost frozen foods using the defrost programme beforehand (see section "Defrosting").

Starting the Automatic Menu

NOTE

Always place the food item in a suitable container or on a plate. Bear in mind that liquids such as grease, etc. can drain from the food during the cooking or heating process. The container/plate should therefore be large enough to avoid the overﬂ owing of liquids.

1) Turn the control dial 9 slowly to the left. A

number (e.g. “A-02” for Auto Programme 2 (ﬁ sh)) appears on the display 1, and the “Fish” icon ﬂ ashes. Select the appropriate automatic menu for your foodstuﬀ (1 to 9). After you have selected automatic menu mode, you can also access the desired automatic menu with a clockwise rotation. Conﬁ rm your selection by pressing the Start/Quick Start

2) You can now set the desired weight/number

of servings by rotating the control dial 9.

3) Press Start/Quick start 9

cooking process.

4) When the cooking/grill process is complete,

“End” appears on the display 1 and you will hear 4 beeps.

Rice 100–1000 g

Chicken 800–1400 g

Heating

Potatoes 150–600 g

Roasting 300–1300 g

Kebabs 100–700 g

Beverages 200–600 ml

100–1000 g

to start the

SMW 800 C2

If the door of the microwave is not opened, the appliance beeps again after about 2 minutes.

NOTE

In order to achieve an even cooking or

►

heating result in programmes 4, 7 and 8, the food should be turned over after about two thirds of the cooking time. The microwave will remind you to turn the food over:

– "turn" appears in the display 1 and you

will hear a beep.

– Open the door and turn the food over.

Be careful, the food may already be very hot.

– Press the Start/Quick start button 9

to resume the cooking process.

If you wish to dispense with turning, simply ignore the beeps. The microwave will automatically continue its programme.

NOTE

Please note that the size, shape and the type

►

of foodstuﬀ aﬀ ects the result of the cooking process.

► If the meal is not properly cooked upon

completion of the automatic menu, continue cooking for a couple of minutes using the Quick start programme. For programmes that involve the use of the grill function (programme numbers 4, 7 and 8), the food can be cooked further with the grill function. Continued cooking with the grill function also increases the browning of the food.

Programmes in detail

Programme 1: Pasta

This programme uses only microwave power. This programme runs for

between 25 and 35 minutes depending on the weight set.

■ When cooking pasta, use a tall container as

there is a risk of it boiling over.

■ Use the same amount of water as when cooking

pasta conventionally. The pasta should “ﬂ oat” in the water.

■ Boil the water ﬁ rst:

– set the highest possible microwave output

level of the microwave (P800) and start heating. You will need about 10 minutes to boil one litre of water.

■ Then carefully add the pasta. After this, you can

start the automatic menu for pasta.

■ Finally, allow the pasta to stand for approx.

3 minutes.

Programme 2: Fish

This programme uses only microwave power. This programme runs for between 3:30 and

16 minutes depending on the weight set.

■ Lay the pieces of ﬁ sh on a microwaveable plate,

add a little butter or another fat, add ﬂ avouring to taste and then start the automatic menu for ﬁ sh.

SMW 800 C2

Programme 3: Rice

This programme uses only microwave power. Depending on the weight set, this programme runs

for between 16 and 36 minutes.

■ When cooking rice, use a tall container as there

is a risk of it boiling over. Use around 400 ml water for 200 g of rice. Regardless of the amount of water you use the weight setting “200 g”. Always use the weight of the rice for your setting.

■ Place the rice in the container, ﬁ ll it with the

required volume of liquid and then allow the rice to swell for approx 3 minutes.

■ Cover the container. Ensure that it is not sealed

airtight. After this, you can start the automatic menu for rice.

Programme 4: Chicken

This programme runs over several cooking stages, using microwave power and the grill function. Depending on the weight set, this programme runs for between 39 and 50 minutes.

■ Place the chicken on a microwaveable plate.

■ Season to taste and then start the automatic

menu for chicken.

■ A whole chicken must be turned over, otherwise

the side facing upwards could dry out. For this reason the microwave oven automatically halts the programme after about 2/3 of the time has elapsed and beeps. Turn the chicken and then press the Start/Quick start button 9 again to resume the programme.

once

Programme 5: Heating up

This programme uses only microwave power. This programme runs for between 1:00 and

6:20 minutes depending on the the weight set.

■ Place the plate with the food that you wish to

heat up on the glass plate 2 in the cooking chamber and then start the automatic menu for heating up.

Programme 6: Potatoes

This programme uses only microwave power. This programme runs for between 3:50 and

11 minutes depending on the the weight set.

■ Use unpeeled potatoes for the cooking process.

■ As far as possible, use potatoes of the same

size.

■ Prick the skins a couple of times.

■ Place the unpeeled potatoes onto a microwave-

able plate or into a receptacle. If possible, the potatoes should not touch each other.

Programme 7: Roasting

This programme runs over several cooking stages, using microwave power and the grill function. Depending on the weight set, this programme runs for between 16 and 60 minutes.

■ Place the roast on a microwaveable plate.

Season the meat to taste and then start the automatic menu for roasting.

■ A whole roast must be turned over, otherwise

the side facing upwards could dry out. For this reason the microwave oven automatically halts the programme after about 2/3 of the time has elapsed and beeps. Turn the meat over and then press the button Start/Quick start 9 again to resume the programme.

once

SMW 800 C2

Programme 8: Kebabs

This programme runs over several cooking stages,

using microwave power and the grill function. Depending on the weight set, this programme runs for between 9 and 27 minutes.

■ Place the kebabs on a microwaveable plate.

Season the meat to taste and then start the automatic menu for kebabs.

■ The kebabs must be turned over to ensure even

cooking. For this reason the microwave oven automatically halts the programme after about 2/3 of the time has elapsed and beeps. Turn the kebabs over and then press the button Start/ Quick start 9 programme.

once again to resume the

Defrosting

You can use this function to defrost meat, poultry and ﬁ sh. The defrosting time and the power level are calculated and set automatically once you have entered the weight.

1) Press the Defrost button 0 appears in the display 1.

2) Use the control dial 9 to enter the weight of the food to be defrosted. You can enter a weight of between 100 g and 1800 g.

3) Press the Start/Quick start button 9 The appliance calculates the defrosting time automatically. It appears in the display 1 and starts to count down.

. The icon

Programme 9: Beverages

This programme uses only microwave power. This programme runs for between 1:30 and 3:50 minutes depending on the the quantity set.

■ Place the beverage that you wish to heat up on

the glass plate 2 in the cooking chamber. If you wish to place several glasses or cups in the microwave oven, ensure that the receptacles do not touch each other.

NOTE

To avoid sudden boiling:

– If possible, place a glass rod in the liquid

while it is being heated.

– To avoid unexpected reboiling, leave the

liquid to stand in the microwave oven for about 20 seconds after heating.

After about 1/2 of the time, you will hear a beep and “turn” appears on the display 1. Open the door and turn the food. Close the door again and press the Start/Quick Start button 9 the defrosting process.

NOTE

If you wish to dispense with turning, simply ignore the beeps. The defrosting programme will continue despite the beeps!

to resume

SMW 800 C2

Preset start time (Preset)

With this programme, you can preset a speciﬁ c start time to cook or grill your food. If the programming is carried out correctly, the appliance starts automatically at the programmed time.

6) Press the Start/Quick start button 9 The

icon ﬂ ashes. The start time is displayed. The microwave oven automatically starts the cooking process at the programmed time. The appliance gives oﬀ a beep when it starts.

TIPS

The clock must be correctly set to be able to

►

select the function "Preset start time".

► The "Preset start time" function does not work

in combination with the "Defrost" function, automatic programme 5 or the quick start function.

1) Set the desired microwave function (cooking, grilling or automatic menu (except auto programme 5)):

– For microwave operation: Press the micro-

wave button w , select a power output level and adjust the cooking time with the control dial 9.

– For grill operation: Press the Grill button q

to activate the grill function. Set the

desired grilling time with the control dial 9.

– For the automatic menu: Use the control

dial 9 to select the appropriate programme for your food (excluding auto programme 5). Conﬁ rm your selection by pressing the Start/ Quick Start button 9 dial 9 to set the desired weight/number of servings.

2) Press the Timer/clock button 6 ﬂ ashes on the display 1 and the

appear in the display 1.

3) Turn the control dial 9 to program the hours.

4) Press the Start/Quick Start button 9 now the minutes appear.

5) Turn the control dial 9 to program the minutes.

. Turn the control

. “01:”

icon will

TIPS

To erase the saved start time and thus cancel the saved procedure, press the Stop button 8 .

symbol disappears and the time is

The displayed.

Cleaning and care

DANGER – ELECTRIC SHOCK!

Before cleaning the appliance, disconnect

►

the power plug from the mains power socket! There is a risk of electric shock!

NEVER immerse the appliance in water or any other liquid!

ATTENTION! MATERIAL DAMAGE!

Do not use abrasive or aggressive cleaning

►

materials. These may damage the surfaces of your appliance.

■ Always keep the interior of the microwave oven

clean.

■ If splashes of food or spilt liquids stick to the

walls of the microwave, wipe them oﬀ with a damp cloth.

■ Use a mild detergent if the microwave is more

heavily soiled.

■ Avoid using cleaning sprays and other aggres-

sive cleaning agents, as they can cause stains, smears or clouding of the door surface.

■ Clean the external surfaces with a damp cloth.

■ To avoid damage to the functional components

in the interior of the microwave, do not allow liquids to seep in through the ventilation slits 5.

SMW 800 C2

■ Remove splashes or soiling. Clean the door,

both sides of the viewing window, door seals and adjacent components with a damp cloth. Do not use abrasive cleaning agents.

■ If condensation accumulates on or around the

outside of the door, wipe it oﬀ with a soft cloth. This can happen if the microwave is operated in extremely humid conditions.

■ Clean the glass plate 2 regularly. You can also

clean the glass plate 2 in the dishwasher or in hot water with a little washing-up liquid.

■ Wipe the rotator assembly 3 oﬀ with a damp

cloth.

■ Clean the grill stand e in hot dishwater and

dry it well.

■ Remove odours regularly. Put a deep microwave

bowl with a cup of water, juice and peel of a lemon into the microwave. Heat for 5 minutes. Wipe oﬀ thoroughly and rub dry with a soft cloth.

■ If the bulb in the microwave needs replacing,

arrange for it to be exchanged by a dealer or consult our Service Department.

Storage

■ Store the cleaned appliance in a clean, dust-free

and dry place.

The appliance does not respond to pressing the buttons.

■ The Child lock is activated. Deactivate the Child

lock (see chapter “Operation“).

The appliance does not start the cooking/ heating process.

■ The door is not properly closed. Close the door

properly.

■ The plug is not inserted into a mains power

socket. Connect the plug to the power supply.

The glass plate 2 makes a loud noise when turning.

■ The glass plate 2 is not correctly positioned

on the rotator assembly 3.

■ Centre the glass plate 2 on the rotator

assembly 3.

■ The rotator assembly 3 and/or the ﬂ oor of the

cooking chamber are dirty. Clean the rotator assembly 3 and the ﬂ oor of the cooking area.

Troubleshooting

There is nothing on the display 1.

■ The plug is not inserted into a mains power

socket. Check the plug.

■ The mains power socket is defective. Try another

mains power socket.

■ The display 1 is defective. Contact Customer

Service.

SMW 800 C2

Warranty and service

The warranty for this appliance is for 3 years from the date of purchase. The appliance has been manufactured with care and meticulously examined before delivery. Please retain your receipt as proof of purchase. In the case of a warranty claim, please make contact by telephone with our Customer Service Department. Only in this way can a post-free despatch for your goods be assured.

The warranty covers only claims for material and manufacturing defects, but not for transport damage, wearing parts or for damage to fragile components, e.g. buttons or batteries. This product is for domestic use only and is not intended for commercial use. The warranty is void in the case of abusive and improper handling, use of force and internal tampering not carried out by our authorised service branch. Your statutory rights are not restricted in any way by this warranty. The warranty period is not extended by repairs made under the warranty. This applies also to replaced and repaired parts. Damages and defects extant at the time of purchase must be reported immediately after unpacking, resp. no later than two days after the date of purchase. Repairs made after the lapse of the warranty period are subject to charge.

Disposal

Never dispose of the appli-

ance in the normal domestic waste. This product is subject to the provisions of European Directive 2012/19/EU.

Dispose of the appliance via an approved waste disposal company or your municipal waste disposal facility. Please observe applicable regulations. Please contact your waste disposal centre if you are in any doubt.

The packaging for this product is made

from environmentally friendly material and can be disposed of at your local recycling plant.

Importer

KOMPERNASS HANDELS GMBH BURGSTRASSE 21 44867 BOCHUM GERMANY www.kompernass.com

Service Great Britain

Tel.: 0871 5000 720 (£ 0.10/Min.) E-Mail: kompernass@lidl.co.uk

IAN 102982/102984

Service Ireland

Tel.: 1890 930 034 (0,08 EUR/Min., (peak))

(0,06 EUR/Min., (oﬀ peak)) E-Mail: kompernass@lidl.ie

IAN 102982/102984

Hotline availability: Monday to Friday 08:00 - 20:00 (CET)

SMW 800 C2

Innehållsförteckning

Inledning 24

Föreskriven användning 24

Leveransens innehåll 24

Beskrivning 24

Tekniska data 24

Säkerhetsanvisningar 25

Information om jordning/ installation 30

Störningar på andra apparater 30

Innan du sätter igång 31

Grundprinciper för att laga mat i mikrovågsugn 31

Lämpliga kokkärl 31

Första användningstillfället 32

Ställa upp mikrovågsugnen 32 Förbereda produkten 32

Användning 33

Ställa klockan 33 Ställa in kökstimer 33 Knapplås 34

Kombinationsdrift 35

Kombination 1 36 Kombination 2 36

Automeny 37

Starta automeny 37

Programmen i detalj 38

Program 1: Pasta/Nudlar 38 Program 2: Fisk 38 Program 3: Ris 39 Program 4: Kyckling 39 Program 5: Uppvärmning 39 Program 6: Potatis 39 Program 7: Stekar 39 Program 8: Grillspett med kött 40 Program 9: Drycker 40

Upptining 40

Ställa in starttid (Preset) 41

Rengöring och skötsel 41

Förvaring 42

Åtgärda fel 42

Garanti och service 43

Koka och steka 34

Mikrovågsdrift 34 Snabbstart av mikrovågsdrift 35

Grilldrift 35

SMW 800 C2

Kassering 43

Importör 43

Inledning

Ett stort grattis till din nyinköpta produkt. Du har valt en produkt med hög kvalitet. Bruksan-

visningen ingår som en del av leveransen. Den innehåller viktig information om säkerhet, användning

och återvinning. Läs noga igenom alla användaroch säkerhetsanvisningar innan du börjar använda produkten. Använd endast produkten enligt beskrivningarna och i de syften som anges här. Lämna över all dokumentation tillsammans med produkten om du överlåter den till någon annan person.

Föreskriven användning

Den här produkten ska endast användas för att värma och tillaga livsmedel på de sätt som beskrivs här.

All form av förändring på produkten är förbjuden och innebär avsevärda risker. Tillverkaren ansvarar inte för skador som uppstår på grund av felaktig användning.

Produkten är endast avsedd för privat bruk i hemmet. Använd den inte yrkesmässigt, industriellt eller i

laboratorier!

Leveransens innehåll

■ Mikrovågsugn

■ Sjärnformat fäste

■ Glastallrik

■ Grillstativ

■ Bruksanvisning

■ Snabbinstruktion

Beskrivning

Bild A:

1 Display 2 Glastallrik 3 Stjärnformat fäste 4 Luckhandtag 5 Ventilationsöppningar

Bild B:

6 Timer/Klocka-knapp 7 Kombinationsknapp 8 Stoppknapp 9 Skruvreglage / Start/Snabbstart-knapp 0 Upptiningsknapp q Grillknapp w Mikrovågsknapp

Bild C: e Grillstativ

Tekniska data

Nominell spänning: 230 - 240 V ~, 50 Hz Max eﬀ ektförbrukning: 1200 W Maximal uteﬀ ekt mikrovågor: 800 W Max eﬀ ektförbrukning Grill: 1000 W Mikrovågsfrekvens: 2450 MHz

SMW 800 C2

Säkerhetsanvisningar

Läs följande viktiga säkerhetsinformation noggrant och spara den för framtida bruk!

FARA - RISK FÖR ELCHOCK!

► Produkten får endast anslutas till ett godkänt och jordat eluttag. Nätspän-

ningen måste överensstämma med angivelserna på produktens typskylt.

► Akta så att kabeln inte blir våt eller fuktig när du använder produkten.

Lägg den så att den inte kan klämmas fast någonstans eller skadas.

► Håll kabeln på avstånd från värmekällor. Lägg den inte framför mikro-

vågsugnens lucka. Då kan den skadas av värmen.

► Dra alltid ut kontakten ur uttaget när produkten rengörs eller vid eventuella

fel. Det räcker inte att bara stänga av den, eftersom det ﬁ nns spänning kvar i produkten så länge kontakten sitter i uttaget.

► Dra alltid ut kontakten ur uttaget när du inte ska använda produkten. ► Låt omedelbart en auktoriserad fackverkstad eller vår kundtjänst byta ut

skadade kontakter och kablar för att undvika olyckor.

► Produkten och dess anslutningsledning ska hållas på avstånd från barn. ► Doppa aldrig ner kabeln eller kontakten i vatten eller andra vätskor. ► Se till så att det aldrig kommer in vätska i ventilationsöppningarna eller

luckspärren. Skulle det ändå råka komma in vätska ska du omedelbart stänga av mikrovågsugnen och dra ur kontakten ur eluttaget. Låt sedan en yrkesman kontrollera mikrovågsugnen.

Du får absolut inte doppa ner produkten i vatten eller andra vätskor.

SMW 800 C2

VARNING! RISK FÖR PERSONSKADOR!

► Om luckan eller tätningarna runt den är skadade får du absolut inte

använda mikrovågsugnen längre. Lämna då genast in den till kvaliﬁ cerad fackpersonal för reparation.

► Försök aldrig själv att reparera produkten. Om höljet tas av kan mikrovågs-

energin komma ut. Låt endast kvaliﬁ cerad fackpersonal reparera produkten.

► Den här produkten kan användas av barn som är minst 8 år och av personer

med begränsad fysisk, sensorisk eller mental förmåga eller bristande erfarenhet och/eller kunskap om de hålls under uppsikt eller instruerats i hur produkten används på ett säkert sätt och inser vilka risker det innebär.

► Barn får inte leka med produkten. ► Endast barn över 8 år som hålls under uppsikt får rengöra och serva

produkten.

► Barn under 8 år ska hållas på avstånd från produkten och anslutnings-

kabeln.

► Använd endast mikrovågsugnen till det den är avsedd för enligt beskriv-

ningen i denna bruksanvisning. Använd inga frätande kemikalier eller ångor i produkten. Den här mikrovågsugnen är byggd speciellt för att värma, koka/steka grilla eller torka livsmedel. Den är inte avsedd att användas inom industrin eller i laboratorier.

► Håll barnen på avstånd från luckan när mikrovågsugnen används.

Risk för brännskador!

► Du får absolut inte under några som helst omständigheter öppna

mikrovågsugnens hölje.

► Låt bara kvaliﬁ cerade yrkesmän byta lampa inne i mikrovågsugnen. ► Personer som använder pacemaker bör rådfråga sin läkare om eventuella

risker innan de använder mikrovågsugnen.

► Vätskor och andra livsmedel får inte värmas i förslutna behållare, eftersom

det ﬁ nns risk för explosion.

Akta! Het yta!

SMW 800 C2

VARNING! RISK FÖR PERSONSKADOR!

► Det är farligt för alla som saknar motsvarande utbildning att göra under-

håll- och reparationsarbeten som kräver att höljet tas bort. Höljet skyddar mot strålning från mikrovågsenergi.

► Försök inte själv reparera produkten. Alla reparationer måste utföras av

kundtjänst eller kvaliﬁ cerad fackpersonal.

► Rör inte vid luckan, höljet, ventilationsöppningarna, tillbehör, porslin,

bestick etc. omedelbart efter användningen. Dessa delar blir mycket heta. Låt alla delar kallna innan du rengör dem.

► Se till så att kontakten alltid är lättåtkomlig så att det går snabbt att bryta

strömförbindelsen vid nödsituationer.

► Låt aldrig kabeln hänga ner från bord eller arbetsbänkar. Småbarn kan

dra i den.

► Öppna alltid burkar, popcornpåsar, etc. som värmts i mikron med öppning-

en riktad från kroppen. Ångan som kommer ut kan ge brännskador.

► Stå inte mitt framför mikrovågsugnen när du öppnar luckan. Ångan som

kommer ut kan ge brännskador.

► Fritera inte i mikrovågsugnen. Het olja kan skada delar av mikrovågsugnen

och redskap och i värsta fall orsaka brännskador.

► Skaka alltid eller rör om innehållet i uppvärmda nappﬂ askor och liknande

behållare! Det kan hända att innehållet är ojämnt uppvärmt så att barnet bränner sig. Kontrollera alltid temperaturen innan du matar barnet!

► Bygg inte om mikrovågsugnen. ► Kontrollera alltid temperaturen innan du serverar den mat som värmts i

mikrovågsugnen för att undvika att t ex spädbarn får livsfarliga brännskador. Köksredskap kan bli mycket varma av den varma maten och man kan behöva använda grytlappar eller liknande när man tar i dem. Alla kokkärl måste vara testade för att tåla mikrovågsugn.

SMW 800 C2

+ 84 hidden pages
