MANICURE & PEDICURE SET SMPS 7 D2
MANICURE & PEDICURE SET
Operating instructions
IAN 291826
MANIKÜRE-PEDIKÜRE-SET
Bedienungsanleitung
Before reading, unfold the page containing the illustrations and familiarise
yourself with all functions of the device.
Klappen Sie vor dem Lesen die Seite mit den Abbildungen aus und machen
Sie sich anschließend mit allen Funktionen des Gerätes vertraut.
GB / IE / NI Operating instructions Page 1
DE / AT / CH Bedienungsanleitung Seite 21
Contents
Introduction ...................................2
Information concerning these operating instructions ............2
Copyright .............................................2
Limitation of liability .....................................2
Warning notes .........................................3
Intended use ...........................................3
Safety ........................................4
Basic safety guidelines ...................................4
Package contents .......................................8
Controls ......................................9
Technical data ................................10
Use of the appliance ...........................11
Attachments ..........................................11
Working with the appliance ..............................12
Cleaning .....................................15
Storage .....................................15
Disposal .....................................16
Disposal of the appliance ................................16
Disposal of packaging ..................................16
Notes on the Declaration of Conformity ...........17
Kompernass Handels GmbH warranty ............17
Service ..............................................20
Importer .............................................20
SMPS 7 D2
GB│IE│NI
│
1 ■
Introduction
Information concerning these operating instructions
Congratulations on the purchase of your new appliance.
You have selected a high-quality product. The operating instructions
are part of this product. They contain important information about
safety, usage and disposal. Before using the product, familiarise
yourself with all handling and safety guidelines. Use the product only
as described and for the range of applications specified. Keep these
operating instructions in a safe place. Please also pass these operating
instructions on to any future owner(s).
Copyright
This documentation is protected by copyright.
All rights reserved, including those of photographic reproduction,
duplication and distribution by means of particular methods (such
as data processing, data media and data networks), in whole or in
part, as well as substantive and technical changes.
Limitation of liability
All technical information, data and information for installation and
operation contained in these operating instructions corresponds to
the latest version(s) at the time of printing and, to the best of our
knowledge, takes into account our previous experience and know-how.
No claims can be derived from the details, illustrations and descriptions
in these instructions.
The manufacturer assumes no responsibility for damage caused
by failure to observe these instructions, improper use, incompetent
repairs, unauthorised modifications or for the use of non-approved
replacement parts.
■ 2 │ GB
│IE│
NI
SMPS 7 D2
Warning notes
The following warnings are used in these operating instructions:
WARNING
A warning at this hazard level indicates a potentially
hazardous situation.
Failure to avoid this hazardous situation could result in physical
injury.
► Follow the instructions in this warning to prevent physical injury.
CAUTION
A warning at this hazard level indicates potential
material damage.
Failure to avoid this situation could result in material damage.
► Follow the instructions in this warning to prevent material damage.
NOTE
►
A note provides additional information that will assist you in
using the appliance.
Intended use
This appliance is intended solely for the care and maintenance of
fingernails, toenails and feet. It is intended for domestic use only.
The mains adapter is intended for indoor use only.
It is not intended for any other use or use beyond that specified.
SMPS 7 D2
GB│IE│NI
│
3 ■
WARNING
Danger if not used for intended purpose!
Failure to use the appliance for its intended purpose and/or
any other type of use can be hazardous.
► Use the appliance only for its intended purpose.
► Observe the procedures described in these operating instructions.
Claims of any kind for damage arising as a result of incorrect use
will not be accepted.
The risk shall be borne solely by the user.
Safety
In this section, you will find important safety
instructions for using the appliance. Improper
use may result in personal injury and material
damage.
Basic safety guidelines
To ensure safe operation of the appliance, follow
the safety guidelines set out below
WARNING – RISK OF INJURY!
■ Prior to use, check the appliance for visible
external damage. Do not operate a appliance
that has been damaged or dropped.
■ 4 │ GB
│IE│
NI
SMPS 7 D2
This appliance may be used by children aged
■
8 years and above and by persons with limited
physical, sensory or mental capabilities or lack
of experience and knowledge, provided that
they are under supervision or have been told
how to use the appliance safely and are aware
of the potential risks. Children must not use
the appliance as a plaything. Cleaning and
user maintenance tasks may not be carried
out by children unless they are supervised.
■ All repairs must be carried out by authorised
specialist companies or by the Customer Service
department. Improper repairs can pose significant risks to the user. The warranty claim will
also be invalidated.
■ Extended use may cause extreme warming
of the skin. Therefore, take frequent breaks.
Otherwise, there is a risk of burns!
■ Do not use the appliance while bathing or
showering.
SMPS 7 D2
GB│IE│NI
│
5 ■
Never touch the appliance with wet or moist
■
hands.
■ Always operate the appliance with the supplied
power adapter.
■ This appliance should only be supplied with
SELV (safety extra low voltage) in compliance with the labelling on the appliance.
■ To prevent accidents, have defective plugs
and/or power cables replaced immediately
by a qualified specialist technician or our
Customer Service department.
CAUTION – PROPERTY DAMAGE
■ Defective components must always be replaced
with original replacement parts. Compliance
with safety requirements can only be guaranteed
if original replacement parts are used.
■ Protect the appliance from penetration by
moisture and liquids.
■ Protect the appliance against knocks, dampness,
dust, chemicals, extremes of temperature,
etc. and keep it away from sources of heat
(ovens, radiators).
■ Never use the appliance under blankets, pil-
lows, etc.
■ 6 │ GB
│IE│
NI
SMPS 7 D2
Do not store the appliance where it could fall
■
into a bath tub or wash basin.
■ NEVER submerse the appliance in water or
other liquids!
■ Always remove the mains adapter from the
mains outlet; never pull on the power cable.
■ Ensure that the drive can always rotate freely.
Otherwise, the appliance may overheat and
be damaged beyond repair.t.
■
■ To disconnect the power supply to the appli-
The mains adapter is intended for indoor
use only.
ance, pull the mains adapter from the socket
outlet.
■ The mains power socket that is used must be
easily accessible so that the mains adapter
can be quickly removed from the mains
power socket in the event of an emergency.
■ In the event of a malfunction (unusual noises
or smoke) or during thunderstorms, disconnect
the mains adapter from the power socket.
■ Never try to open the housing of the mains
adapter – there is a risk of electrocution.
SMPS 7 D2
GB│IE│NI
│
7 ■
To avoid damage caused by unwanted
■
warming, do not cover the mains power
adapter.
■ Repairs to the appliance during the warranty
period may only be carried out by a customer
service department authorised by the manufacturer. Otherwise no additional warranty claims
can be considered for subsequent damage.
Package contents
The appliance is supplied with the following components as standard:
▯ Hand element
▯ Power adapter
▯ 7 attachments:
- Sapphire cone
- Felt cone
- 2 sapphire discs (rough/fine)
- Hardened skin remover
- Cylindrical miller
- Flame miller
▯ Storage bag
▯ Operating instructions
♦ Remove all parts of the appliance from the packaging and
remove all packaging materials.
WARNING
Risk of suffocation!
► Packaging material must not be used as a plaything.
Risk of suffocation.
■ 8 │ GB
│IE│
NI
SMPS 7 D2
NOTE
► Check the package for completeness and for visible signs of
damage.
► If the consignment is incomplete or damaged due to defective
packaging or carriage, contact the Service hotline (see the
chapter Service).
Controls
Attachment fitting
2
button (increase speed)
3
button (reduce speed)
4
LED rotation direction indicator
(red = clockwise/green = anti-clockwise)
5
On/off/direction switch
6
Connector socket
7
Hand element
8
Mains adapter
9
Connector plug
10
Sapphire cone
11
Felt cone
12
Sapphire disc (rough)
13
Sapphire disc (fine)
14
Flame miller
15
Cylindrical miller
16
Hardened skin remover
17
Storage bag
SMPS 7 D2
GB│IE│NI
│
9 ■
Technical data
Mains adapter: ZD8H300025BS
Input voltage 100 - 240 V ∼, 50/60 Hz
Current consumption 0.3 A
Output voltage/output current 30 V
Protection class
Switched-mode power supply
Efficiency class 5
Enclosed safety transformer
Nominal ambient temperature (ta) 40°C
Polarity
Appliance
Input voltage 30 V
Current consumption 250 mA
Operating speeds
Protection class
Polarity
■ 10 │ GB
│IE│
NI
II /
2000 - 4600 rpm
III /
/ 250 mA
SMPS 7 D2
Use of the appliance
Attachments
■ Sapphire cone 10:
For removing dry skin, hardened skin or calluses on the soles and
heels.
♦ Guide the sapphire cone
to be treated using a circular motion while exerting gentle pressure.
Do not press too firmly, and always guide the appliance carefully to the surface to be treated. Apply a moisturising cream
after every treatment.
11
■ Felt cone
:
For smoothing and polishing nail edges after filing, and for cleaning
the nail surface.
♦ Use the felt cone
and to clean the nail surface after grinding. Always polish in a
circular motion and never let the felt cone
■ Sapphire disc
12/13
For filing and working the nails.
Work the edge of the nail using the sapphire disc
the inner disc rotates and the outer edge does not move, you can file
your nails accurately without damaging your skin with the rapidly
rotating disc.
♦ Always work from the outside of the nail to the tip.
■ Flame miller
14
:
You can use the flame miller
♦ Guide the flame miller
cut away the affected nail part.
10
over the parts of the sole and heel
11
to polish and smooth the edge of the nail
11
stay in one place.
:
12/13
. Since only
14
to free ingrown nails.
14
carefully onto the treatment area and
SMPS 7 D2
GB│IE│NI
│
11 ■
