MANICURE & PEDICURE SET SMPS 7 A1
MANICURE & PEDICURE SET
Operating instructions
MANIKÜRE-PEDIKÜRE-SET
Bedienungsanleitung
IAN 102612
ΣΕΤ ΜΑΝΙΚΙΟΥΡ-ΠΕΝΤΙΚΙΟΥΡ
Οδηүίες χρήσης
Before reading, unfold the page containing the illustrations and familiarise
yourself with all functions of the device.
Πριν ξεκινήσετε την ανάγνωση, ανοίξτε τις δυο σελίδες με τις εικόνες και
εξοικειωθείτε με όλες τις λειτουργίες της συσκευής.
Klappen Sie vor dem Lesen die Seite mit den Abbildungen aus und machen
Sie sich anschließend mit allen Funktionen des Gerätes vertraut.
GB / IE / CY Operating instructions Page 1
GR / CY Οδηүίες χρήσης Σελίδα 19
DE / AT / CH Bedienungsanleitung Seite 37
Contents
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Information concerning these operating instructions . . . . . . . . . . . .2
Copyright . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
Limitation of liability . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
Warning notes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
Intended use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Basic safety guidelines . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Package contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
Controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Technical data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Use of the appliance . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Attachments . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
Working with the appliance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
Cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Storage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Disposal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Disposal of the appliance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
Disposal of packaging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
Notes on the Declaration of Conformity . . . . . . . . . . .17
Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Importer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
GB
IE
CY
SMPS 7 A1
1
GB
Introduction
IE
CY
Information concerning these operating instructions
Congratulations on the purchase of your new appliance.
You have selected a high-quality product. The operating instructions
are part of this product. They contain important information about
safety, usage and disposal. Before using the product, familiarise
yourself with all handling and safety guidelines. Use the product only
as described and for the range of applications specifi ed. Keep these
operating instructions in a safe place. Please also pass these operating instructions on to any future owner(s).
Copyright
This documentation is protected by copyright.
All rights reserved, including those of photographic reproduction,
duplication and distribution by means of particular methods (such
as data processing, data media and data networks), in whole or in
part, as well as substantive and technical changes.
Limitation of liability
All technical information, data and information for installation and
operation contained in these operating instructions corresponds to
the latest version(s) at the time of printing and, to the best of our
knowledge, takes into account our previous experience and know-how.
No claims can be derived from the details, illustrations and descriptions in these instructions.
The manufacturer assumes no responsibility for damage caused
by failure to observe these instructions, improper use, incompetent
repairs, unauthorised modifi cations or for the use of non-approved
replacement parts.
2
SMPS 7 A1
Warning notes
The following warnings are used in these operating instructions:
WARNING
A warning at this hazard level indicates a potentially hazardous situation.
Failure to avoid this hazardous situation could result in physical
injury.
► Follow the instructions in this warning to prevent physical
injury.
CAUTION
A warning at this hazard level indicates potential
material damage.
Failure to avoid this situation could result in material damage.
► Follow the instructions in this warning to prevent material
damage.
NOTE
A note provides additional information that will assist you in
►
using the appliance.
Intended use
This appliance is intended solely for the care and maintenance of
fi ngernails, toenails and feet. It is intended for domestic use only.
The mains adapter is intended for indoor use only.
It is not intended for any other use or use beyond that specifi ed.
GB
IE
CY
SMPS 7 A1
3
GB
IE
CY
WARNING
Danger if not used for intended purpose!
Failure to use the appliance for its intended purpose and/or
any other type of use can be hazardous.
► Use the appliance only for its intended purpose.
► Observe the procedures described in these operating instruc-
tions.
Claims of any kind for damage arising as a result of incorrect use
will not be accepted.
The risk shall be borne solely by the user.
Safety
In this section, you will fi nd important safety instructions for using the appliance. Improper use may
result in personal injury and material damage.
Basic safety guidelines
To ensure safe operation of the appliance, follow
the safety guidelines set out below
WARNING – RISK OF INJURY!
■ Prior to use, check the appliance for visible ex-
ternal damage. Do not operate a appliance that
has been damaged or dropped.
■ This appliance may be used by children aged
8 years and above and by persons with limited
physical, sensory or mental capabilities or lack of
experience and knowledge, provided that they
4
SMPS 7 A1
are under supervision or have been told how to
use the appliance safely and are aware of the
potential risks. Children must not use the appliance as a plaything. Cleaning and user maintenance tasks may not be carried out by children
unless they are supervised.
■ All repairs must be carried out by authorised
specialist companies or by the Customer Service
department. Improper repairs can pose signifi cant risks to the user. The warranty claim will also
be invalidated.
■ Extended use may cause extreme warming of the
skin. Therefore, take frequent breaks. Otherwise,
there is a risk of burns!
■ Do not use the appliance while bathing or show-
ering.
■ Never touch the appliance with wet or moist hands.
■ Always operate the appliance with the supplied
power adapter.
■ To prevent accidents, have defective plugs and/
or power cables replaced immediately by a
qualifi ed specialist technician or our Customer
Service department.
GB
IE
CY
SMPS 7 A1
5
GB
CAUTION – PROPERTY DAMAGE
IE
CY
■ Defective components must always be replaced
with original replacement parts. Compliance with
safety requirements can only be guaranteed if
original replacement parts are used.
■ Protect the appliance from penetration by mois-
ture and liquids.
■ Protect the appliance against knocks, dampness,
dust, chemicals, extremes of temperature, etc.
and keep it away from sources of heat (ovens,
radiators).
■ Never use the appliance under blankets, pillows,
etc.
■ Do not store the appliance where it could fall
into a bath tub or wash basin.
■ NEVER submerse the appliance in water or other
liquids!
■ Always remove the mains adapter from the mains
outlet; never pull on the power cable.
■ Ensure that the drive can always rotate freely.
Otherwise, the appliance may overheat and be
damaged beyond repair.
■ The mains adapter is intended for indoor use only.
■ To disconnect the power supply to the appliance,
pull the mains adapter from the socket outlet.
6
SMPS 7 A1
■ The mains power socket that is used must be eas-
ily accessible so that the mains adapter can be
quickly removed from the mains power socket in
the event of an emergency.
■ In the event of a malfunction (unusual noises or
smoke) or during thunderstorms, disconnect the
mains adapter from the power socket.
■ Never try to open the housing of the mains
adapter – there is a risk of electrocution.
■ To avoid damage caused by unwanted warming,
do not cover the mains power adapter.
■ Repairs to the appliance during the warranty
period may only be carried out by a customer
service department authorised by the manufacturer. Otherwise no additional warranty claims
can be considered for subsequent damage.
GB
IE
CY
SMPS 7 A1
7
Package contents
GB
IE
The appliance is supplied with the following components as standard:
CY
▯ Hand element
▯ Power adapter
▯ 7 attachments:
- Sapphire cone
- Felt cone
- 2 sapphire discs (rough/fi ne)
- Hardened skin remover
- Cylindrical miller
- Flame miller
▯ Storage bag
▯ Operating instructions
♦ Remove all parts of the appliance from the packaging and
remove all packaging materials.
WARNING
Risk of suff ocation!
► Packaging material must not be used as a plaything.
Risk of suff ocation.
NOTE
Check the package for completeness and for visible signs of
►
damage.
► If the consignment is incomplete or damaged due to defective
packaging or carriage, contact the Service hotline
(see the chapter Service).
8
SMPS 7 A1
Controls
Attachment fi tting
2
Hi button (increase speed)
3
Lo button (reduce speed)
4
LED rotation direction indicator
5
On/off /direction switch
6
7
8
Mains adapter
9
10
Sapphire cone
11
Felt cone
12
Sapphire disc (rough)
13
Sapphire disc (fi ne)
14
Cylindrical miller
15
Flame miller
16
Hardened skin remover
17
GB
IE
CY
Connector socket
Hand element
Connector plug
Storage bag
SMPS 7 A1
9
GB
Technical data
IE
CY
Mains adapter: ZD8H300025BS
Input voltage 100–240 V ˜ 50/60 Hz
Current consumption 0.3 A
Output voltage/output current 30 V
Protection class
Appliance
Input voltage 30 V
Current consumption 250 mA
Protection class
Operating speeds
/ 250 mA
II /
III /
Level 1: 3800 rpm
Level 2: 4600 rpm
Use of the appliance
Attachments
■ Sapphire cone 10:
For removing dry skin, hardened skin or calluses on the soles and
heels.
♦ Guide the sapphire cone 10 over the parts of the sole and heel
to be treated using a circular motion while exerting gentle pressure. Do not press too fi rmly, and always guide the appliance
carefully to the surface to be treated. Apply a moisturising
cream after every treatment.
10
SMPS 7 A1
■ Felt cone 11:
For smoothing and polishing nail edges after fi ling, and for cleaning
the nail surface.
♦ Use the felt cone 11 to polish and smooth the edge of the nail
and to clean the nail surface after grinding. Always polish in a
circular motion and never let the felt cone
11
stay in one place.
■ Sapphire disc 12/13:
For fi ling and working the nails.
WARNING – RISK OF INJURY!
Excessive speeds and applying too much pressure,
can cause the sapphire disc to rapidly penetrate
into deeper, healthy skin layers.
This can cause injuries and damage to the periosteum!
► Always take care when removing corns. If in doubt, consult a
pedicurist, podologist or dermatologist.
GB
IE
CY
Work the edge of the nail using the sapphire disc
12/13
. Since only
the inner disc rotates and the outer edge does not move, you can fi le
your nails accurately without damaging your skin with the rapidly
rotating disc.
♦ Always work from the outside of the nail to the tip.
■ Cylindrical miller 14:
For grinding off thick toenail surfaces and rough smoothing of the
surfaces.
You can use the cylinder miller
14
to grind off thick nail surfaces.
♦ Always hold the cylinder miller 14 parallel to the nail surface
and use light pressure and circular movements to grind off the
surface.
SMPS 7 A1
11
GB
CY
IE
■ Flame miller 15:
You can use the fl ame miller
♦ Carefully guide the fl ame miller 15 to the treatment area and
remove the aff ected parts of the nail.
■ Hardened skin remover 16:
For large-scale and rapid removal of thick hardened skin or calluses
on the sole or heel of your foot.
♦ Guide the hardened skin remover 16 over the parts of the sole
and heel to be treated while exerting gentle pressure.
Working with the appliance
WARNING – RISK OF INJURY!
Excessively long or intensive treatment can also
injure deeper layers of skin.
► Therefore, check the treatment progress and results regularly.
Diabetics in particular are less sensitive on their hands and
feet.
NOTE
The attachments do not have as much eff ect on softened
►
skin. Therefore, do not carry out any pretreatment in a water
bath before using the appliance.
15
to free ingrowing toenails.
12
SMPS 7 A1
1) Find a well-lit place to work. There must be a mains power outlet
in close proximity.
2) Insert the appropriate attachment for your purpose in the attachment fi tting . The attachment must sit securely.
9
3) Attach the connector plug
connector socket
6
of the hand element 7.
4) Plug the mains adapter
of the mains adapter 8 to the
8
into a mains power outlet.
5) Always start the treatment at slow speed and only increase it
when necessary. Press the Hi button
2
to increase the speed.
If you want to reduce the speed, press the Lo button 3.
6) Slide the on/off /direction switch 5 in the desired direction.
The selected direction of rotation is shown by the coloured LED
direction indicator
4
as follows:
– Green LED = clockwise
– Red LED = anti-clockwise
7) The appliance operates at the slowest speed.
NOTE
Always select the direction of rotation for treating the nails in
►
their direction of growth. If possible, treat the nails from the
outside towards the inside (to the nail tip). Otherwise, the
nails will split more easily.
► If you feel that the nails could crack during treatment, select
the other direction.
8) You can now start working.
GB
IE
CY
SMPS 7 A1
13
GB
IE
CY
WARNING – RISK OF BURNS!
Risk due to severe heat development!
► While you are working, never let the attachments remain in
one location. Friction leads to increased heat generation and
may cause injuries.
► Always work with a circular motion.
9) Move the on/off /direction switch
power adapter
8
fi nished the treatment.
NOTE
If you have treated hardened skin, apply a moisturising
►
cream to the treated areas after completing the procedure.
5
to "0" and disconnect the
from the mains power socket when you have
14
SMPS 7 A1
Cleaning
WARNING
Risk of electrical shocks!
► Always disconnect the mains adapter 8 from the mains
power socket before cleaning the appliance!
CAUTION – PROPERTY DAMAGE!
Do not use chemical, aggressive or abrasive cleaning
►
agents. These can damage the surface of the appliance.
♦ Clean the hand element 7 and the mains adapter 8 with a
damp cloth. For stubborn soiling use a mild detergent on the
cloth. Ensure that no water or moisture can penetrate the
appliance. Dry everything thoroughly.
♦ For hygienic reasons, we recommend cleaning the attachments
with a clean cloth or brush moistened with alcohol after every
use. Dry everything thoroughly.
Storage
♦ After you have cleaned the appliance, put it back in the storage
17
bag
.
♦ Store the appliance in a dry and clean location.
GB
IE
CY
SMPS 7 A1
15
Loading...
