Silvercrest SBTF 10 B2 Operating instructions

Bluetooth®Hands-Free Kit SBTF 10 B2

Bluetooth

Operating instructions

Bluetooth®handsfree

Návod k obsluze

Hands-Free Kit

KOMPERNASS GMBH

BURGSTRASSE 21 · D-44867 BOCHUM

www.kompernass.com

ID-Nr.: SBTF 10 B2-06/11-V2

IAN: 69169

Handsfree sada s funkciou Bluetooth

Návod na obsluhu

CONTENT PAGE

Safety instructions 3 Correct Usage 5 Introduction 6 Items supplied 6 Technical data 7 Operating Elements 7 Installing the hands-free appliance in a vehicle 8 Switching the hands-free appliance on and off 9 Coupling the hands-free appliance with a mobile

telephone 9 Coupling the hands-free appliance with several

mobile telephones 11 Separating the connection 11 Re-establishing the connection 12

Using the hands-free appliance 12 Charging 5 V Devices 14 Troubleshooting 14 Cleaning and Care 15 Disposal 16 Warranty & Service 17 Importer 18 Information regarding the conformity declaration 19

Please read these operating instructions carefully and fold out the page with illustrations when you do so. Closely heed this information when operating the appliance. Should you have any further questions regarding use, please contact the service department responsible for your country. Keep these operating instructions in a safe place and pass them on to whomsover might later acquire the appliance.

BLUETOOTH®HANDS-FREE KIT

Safety instructions

Symbol definitions:

: This symbol points out the particular risks associated with handling, ope-

ration or manipulation.

: This symbol stands for special tips and operating instructions.

Traffic safety has priority!

• Comply with all local laws. When driving, your hands must ALWAYS be free to operate the vehicle safely. Traffic safety must ALWAYS take priority whilst driving.

• Only manipulate the hands-free appliance on those occasions in which the traffic situation permits it and in which you will not endanger, injure, obstruct or cause annoyance to other road users.

• Do not permit your concentration on the road traffic to be compromised by the manipulation and displays of the handsfree appliance!

• Become familiar with the operation of it before driving off and practice the safe operation of the facility!

• Install the hands-free appliance in the vehicle such that your view is not obstructed and that the appliance is not located in an impact zone in the passenger compartment or in the inflation area of airbags.

General safety instructions

• Do not attempt to open or repair the appliance. Should you do so, appliance safety can no longer be assured and the warranty becomes void.

• Have the defective device repaired by customer service or an authorised specialist only. No liability will be accepted for damage caused by misuse, improper handling, use of force or unauthorized modification.

• Never subject the appliance to moisture, extreme temperatures or extreme vibrations.

• Do not allow children and people subject to supervision play with the appliance, they could injure themselves or cause damage to the appliance.

Connection to other mobile telephones

• If you wish to connect the appliance to another appliance, read the operating instructions to obtain detailed safety instructions. Do not connect it to a product that is not compatible.

High frequency signals in vehicles

HF signals can, under circumstances, negatively influence the function of not properly installed or not sufficiently shielded electronic systems in vehicles, e.g. electronic ABS, electronic tempo controllers and airbag systems. For further information about your vehicle or its possible ancillaries make contact with the respective manufacturer or their representative.

Correct Usage

The Bluetooth®Hands-Free Kit SBTF 10 B2 is designed for use in vehicles with a voltage of 12-24 V. The handsfree phone system uses both Bluetooth nology as well as a digital signal processor (DSP) to carry out telephone functions. In addition, mobile devices with an operating voltage of 5V (MP3 players, cell phones, etc.) can be charged via the USB port. This device may be used ONLY for private domestic purposes, not for industrial or commercial applications. The product at hand is, by default, NOT intended for use in medicinal, lifesaving or life support applications. All of the additional connecting cables and external devices used MUST match the safety-related, electromagnetic compatability and shielding quality standards of the device at hand. With regard to CE Conformity, this device fulfills all of the relevant norms and guidelines. In the event of modifications being made to the device without agreement from the manufacturer, compliance with these norms and guidelines can no longer be assured. Use only the accessories specified by the manufacturer. If you are using the device outside the territory of the Federal Republic of Germany you must pay heed to the national regulations resp. the laws of the country in which it is being used.

radio tech-

Introduction

Bluetooth®is a wireless communication system with a short range. It makes possible wireless connections between Bluetooth mobile telephones, PDA and PCs. Bluetooth dard for operation in the internationally recognised ISM Frequency Range (Industrial, Scientific and Medical). Within the ISM Frequency Range (2.402 - 2.480 GHz), a data transfer range of ca. 10 Meters (Klasse II) is achieved. The disturbance susceptibility through other users of the ISM Frequency Range, such as for example microwaves, WLAN (802.116) or garage door openers, is minimised by so-called „Frequency-Hopping“. With Frequency-Hopping, a change of frequency levels takes place at up to 1600 times per second, thereby Bluetooth

is also reckoned to be relatively tap-proof.

The HSP (Headset-Profil) makes possible standard functions such as voice transference, as well as the acceptance and rejection of calls.

The HFP (Handsfree-Profil) makes possible the hands-free call functions of a mobile telephone, for example with the help of voice commands.

appliances, such as for example

relates itself to a worldwide stan-

Items supplied

Bluetooth®Hands-Free Kit Operating instructions

Technical data

Operational voltage: 12-24 V / 1000 mA Bluetooth Supported Bluetooth Output Voltage USB port: 5 V / 1 A Fuse: F2AL / 250 V Dimensions (L x W x H): 15.8 x 5.3 x 2.3 cm Weight: 72 g Operational temperature: +5° to +40°C Storage temperature: -10° to +60°C Humidity: 5 to 90% (no condensation)

Specification: Version 3.0 + EDR, up to a range of 10 meters

profiles: HSP and HFP

Operating Elements

1 Vehicle connector plug 2 Microphone 3 +/- Buttons 4 USB port 5 Loudspeakers 6 LED status indicator 7 Multi-function button

Installing the hands-free appliance in a vehicle

So that the hands-free appliance can function correctly, it is connected to the vehicle cigar lighter socket or on-board power socket and provided with electricity from there.

• Ensure that the hands-free appliance engages completely and that the operation

of the vehicle is not negatively influenced. The LED status indicator 6 blinks twice every 3 seconds and a short high signal tone sounds once. The appliance is in standby mode.

Note:

It is possible that the cigar lighter only functions when the vehicle ignition is switched on. In cases of doubt, consult the operating instructions for the particular vehicle.

Caution:

For vehicles in which the cigar lighter, resp. the vehicle circuit plug, also functions when the ignition is switched off:

• Use the hands-free appliance only when the motor is running. Otherwise, the

vehicle batteries could become discharged over an extended period of time.

Note:

When you are not using the hands-free equipment remove it from the vehicles cigarette lighter socket. Store it in a dry, dust free location protected from direct sunlight.

Switching the hands-free appliance on and off

Switching on: The appliance is switched off.

• Press and hold the multi-function button 7 for 3 seconds, until a short and high signal tone is heard. The LED status indicator 6 blinks twice every 3 seconds.

Switching off: The appliance is in standby mode.

• Press and hold the multi-function button 7 for 3 seconds, until a long and deep signal tone is heard. The LED status display 6 extinguishes.

Coupling the hands-free appliance with a mobile telephone

The hands-free appliance has been especially developed for mobile telephones that support the Bluetooth Further information about Bluetooth operating instructions for your mobile telephone. Before you can use the hands-free appliance, you must connect it with a compatible mobile telephone (pairing).

• Check to make sure the mobile telephone is switched on.

• Programme the mobile telephone so that it searches for Bluetooth A detailed description of how to do this is to be found in the operating instructions for your mobile telephone.

• Ensure that the hands-free appliance is correctly set up and switched off.

Profile „Handsfree (HFP) and Headset (HSP)“.

radio technology is to be found in the

appliances.

• To switch the device off, press and hold the multi-function button 7 for about 3 seconds. A long, low signal tone will be heard and the LED status display 6 extinguishes.

• Position the hands-free appliance and the mobile telephone so that they are not more than 1 metre away from each other.

• Press and hold down the multi-function button 7 for 6 seconds until, after 3 seconds a short, high signal tone and after a further 3 seconds a succession of low and high signal tones are heard. The LED status display 6 lights up constantly and the hands-free equipment is now in the coupling mode.

• Select the hands-free provision „Car Kit“ from the list of available appliances for the mobile telephone.

• Enter in the pre-programmed passcode "9999" and then confirm it, which couples the appliances with each other. You will hear a long high signal tone and the LED status indicator 6 blinks every 3 seconds.

• You can now use the hands-free appliance.

Note:

When using the latest mobile phones, (Smartphones) those that are equipped with Bluetooth 2.0 or a more modern version, it is possible that the pass code "9999" need not be entered. If the coupling is not completed within 2 minutes, the hands-free appliance switches itself off. The LED status display 6 extinguis- hes and you will hear a long and deep signal tone. With some mobile telephones it is possible that coupling does not automatically take place. In this case coupling must be carried out additionally on the mobile telephone. The LED status display 6 blinks twice every 3 seconds until this has been carried out. Further information can be found in your mobile telephone’s operating instructions.

Coupling the hands-free appliance with several mobile telephones

You can couple the hands-free appliance with up to eight mobile telephones. However, it can only be connected with one mobiletelephone. If a further mobile telephone is coupled with the hands-free appliance, the coupling information of the first coupled mobile telephone is erased. When the hands-free appliance is switched on, within a few seconds it attempts to make a connection to the last used mobile phone. Should a connection not be possible, the hands-free appliance nonetheless remains recognisable for other mobile telephones. To use the hands-free appliance with a linked mobile phone that is not the last used mobile phone, the connection must be made via the Blue-

tooth

menu of the mobile phone.

Separating the connection

If you wish separate the mobile telephone from the hands-free appliance, for example, to connect it to another Bluetooth

• Switch the hands-free appliance off or

• separate the connection over the Bluetooth You need not erase the coupling with the hands-free appliance in the Bluetooth menu to separate the connection.

appliance:

menu in the mobile telephone.

Re-establishing the connection

If you want to reconnect the hands-free appliance with the last used mobile phone:

• Check to see that Bluetooth the hands-free appliance on.

When connecting to a previously coupled mobile telephone it is not necessary to enter a pass-code. You can set your mobile telephone so that when the hands-free equipment is switched on a connection with the mobile telephone is automatically established. As soon as the hands-free equipment is connected to the previously coupled mobile telephone a short, high signal tone is emitted confirming the connection. Further information regarding automatic coupling can be found in your mobile telephone’s operating instructions.

is activated in the mobile telephone, then switch

Using the hands-free appliance

After successful coupling, the following functions are available to you. Some of the described functions are only possible with a mobile telephone that supports the Handsfree Profile (HFP).

Call function

• Use your mobile telephone in the usual way to make a call.

• For redialing of the last number called, shortly press the multi-function button 7 twice.

• For activation of voice dialling, shortly press the multi-function button 7 once.

Note:

Voice dialing is only available with mobile telephones that support this function. Further information regarding voice dialing is to be found in the operating instructions for your mobile telephone.

Accepting and ending a call

When you receive a call the LED status display 6 blinks and you hear a call tone from the hands-free appliance. If the call signal in your mobile phone is switched off, the ringing tone is nonetheless sounded via the hands-free appliance.

• Press the multi-function button 7 shortly once, to accept the call.

• Press the multi-function button 7 shortly once, to terminate the accepted call. You can also accept and terminate the call over the mobile telephone.

Automatic call acceptance

If automatic call acceptance is activated in the mobile telephone, it accepts the incoming call after a determined time period and then passes it on to the hands-free appliance. Further information regarding automatic call acceptance is to be found in the operating instructions for your mobile telephone.

Rejection of a call

• Press the multi-function button 7 for 3 seconds to reject an incoming telephone call.

Adjusting the volume of the hands-free appliance

You can adjust the sound volume level of the hands free device with the +/- buttons 3.

• During a call, repeatedly press the + resp. - buttons 3 until the desired sound volume level is obtained. The attainment of the maximum sound volume level is indicated by a short signal tone.

Charging 5 V Devices

• Check the max. input voltage (5V) and the max. power input (1000 mA) of the device which you want to charge. For this, consult the operating manual of the device.

• Connect the device to be charged with the USB port 4 on the hands free device. The device now receives its power supply from the hands free device. If the device is equipped with a charging indicator light, this will indicate that the device is being charged.

Troubleshooting

If you cannot connect the hands-free appliance with a compatible mobile telephone, proceed as follows:

• Ensure that the Bluetooth

• Ensure that the hands-free appliance is correctly installed, switched on and supplied with electricity.

• If you use several Bluetooth Bluetooth

connection of the mobile telephone is separated.

function in the mobile telephone is activated.

appliances, ensure that a previously created

• Ensure that the hands-free appliance is distanced a maximum of 10 metres from the mobile telephone and that there are no barriers or electronic devices between them.

If these measures do not correct the problem, please contact the appropriate service partner for your country.

Cleaning and Care

Danger of electrocution!

• Before cleaning, always separate the electricity supply from the appliance!

• NEVER submerse the appliance in water or other liquids!

• Do not permit liquids to permeate into the housing!

• Never open the housing of the appliance! There are no user-serviceable elements inside.

• Do not use strong detergents, solvents or abrasive cleaning agents to clean the appliance. These could damage the housing surfaces.

• Clean the housing surfaces with a slightly moist soft cloth.

Disposal

Do not dispose of the appliance in your normal domestic waste. This product is subject to the European guideline 2002/96/EC.

Dispose of the appliance through an approved dis-posal centre or at your community waste facility. Observe the currently applicable regulations. In case of doubt, please contact your waste disposal centre.

Dispose of all packaging materials in an environmentally responsible manner.
