GSM REMOTE SUPERVISION

GB 051 Set for cellular phone Siemens C35i, M35 or S35

Automatic Information Transfer over the GSM Network

USER GUIDE

LEVEL

Dear Customers,

We would like to congratulate you on purchasing our product – GSM Remote Supervision
GB 051. This way you are getting a high-class and technically highly modern product.

GSM Remote Supervision GB 051 allows first-class and highly effective protection of cars
or properties. It provides protection which cannot be easily disabled by cutting the phone
line, protection which sends an ALARM message within 3 seconds and which allows also
continuous control of protected area. Information about disturbance is sent in a form of
phone call with warning signal or in a form of SMS message to your cell phone or by fax,
even by e-mail if required.

GB 051 also allows monitoring of protected area and remote control of household
appliances by cell phone or by e-mail.

Cell phone connected to GB 051 can be used simultaneously for outgoing and incoming
calls without restriction of the unit’s security function.

Thanks to high reliability of information transfer and low purchasing and operation costs
GB 051 can be used also for transmission of technological information.

GB 051 is universal communication device which can be configured by PC or cell phone to
carry out requested functions, handling during operation is easy.

Before setting Remote Supervision GB 051 into operation, please, read this command
manual carefully. It will not only introduce you the correct installation and handling of this
product but at the same time will help you fully utilize all its technical potentialities.

2

TABLE OF CONTENTS – GSM Remote Supervision GB 051

1. Product Description................................ ................................ ........................ 4

1.2. Contents of Delivery................................ ................................ ............... 5

2. Safety Commands................................ ................................ ......................... 5

3. Installation and Setting into Operation................................ ............................ 6

3.1. Assembly of GSM Remote Supervision................................ ................... 6

3.2. Wiring and connecting the GSM Remote Supervision unit....................... 6

3.3. Inserting the SIM Card and Connecting to the Cell Phone....................... 7

3.4. Indication by LED................................ ................................ ................... 9

4. Programming by SMS Messages................................ ................................ ...9

4.1. PIN in GSM Remote Supervision................................ .......................... 10

4.2. RESET of GSM Remote Supervision................................ .................... 11

4.3. INIT – Re-initialization of Values Set from Production............................ 12

4.4. ICALL – Regular Calling Free of Charge................................ ............... 12

4.5. MCALL – Monthly Calling................................................................ .....12

4.6. ACALL – Automatic Alarm Calling......................................................... 13

4.7. INFOSMS – Sending of Information Messages about Operation........... 13

4.8. SMSINT – Interval for Dispatch of SMS Messages about Operation......14

4.9. ALARMSMS – Alarm SMS Messages................................ ................... 14

4.10. OUT – Set-up of Level of Outputs by SMS messages........................... 15

4.11. LIST – Detection of Set-up................................ ................................ ....16

4.12. CALLBACK – Monitoring of Protected Area................................ .......... 16

5. Programming from PC................................ ................................ .................. 17

6. Operation during Failure of External Power Supply................................ .......17

7. List of Programming Commands – Control SMS Messages.......................... 18

8. Basic Technical Parameters................................ ................................ ......... 19

GUARANTEE CERTIFICATE................................ ............................................ 20

GUARANTEE CONDITIONS................................ ................................ ............. 21

STATEMENT OF CONSENSUS................................ ................................ ....... 22

3

1. Product Description

1.1. Description of Function

GSM Remote Supervision GB 051 consists of plastic box, which is firmly joined to
the battery of cell phone. Communication cable with connector gets out of this box
into cell phone, which is used by GB 051 for realization of phone connection and
reception and sending of SMS messages.

On the upper side of the box there is a cut-off terminal board with terminals for
power supply, for interface to PC, control inputs and 8 input/output cables to alarm
switchboard, to detectors or to switching electronics.

Cable with a connector on the lower side of the box is intended for connecting a
mobile phone Siemens (one of those: C35i, M35, S35). There is also a connector
for data cable for connection to a PC that enables comfortable set up of required
configuration data. All configuration parameters can also be set using SMS
messages sent from a mobile phone or Internet.

Red light emitting diode (LED) on the left side signalizes basic operational states,
e.g.: correct function, function from backup power supply, GSM connection in
ready mode, action in progress, etc.

It is possible to prepare separate text of SMS message and to specify two
numbers of cell phones, to which message shall be sent for each of the 8 inputs.

Prepared text of SMS message is sent to specified numbers by activation of one
of the 8 inputs and phone call with warning alarm signal is carried out to a
predefined number. In case it is not possible to send SMS message or call, the
attempt is repeated 10 times in the intervals of 5 minutes.

Each input can be used at the same time as output and it is possible to set up
requested value of inputs using SMS message sent from cell phone or Internet.

It is possible to request call with additional sound monitoring of the room by
incoming SMS message.

It is still possible to use cell phone connected to GB 051 to carry out outgoing and
incoming calls.

GB 051 is self-controlled – it sends information about failure of power supply,
messages about reset, initialization, about configuration change but also
information messages about operation in set intervals.

4

1.2. Contents of Delivery

Sets

Label Component description

GB 051 010

GB 051 010 GSM Remote Control only ● ●
GB 051 011 GSM Remote Control with the Siemens C35i mobile phone ● ●
SA 012 602 AC/DC Adapter 220 V / 12 V DC, 600 mA, cable 1,5 m long ● ●
Connector ● ● ● ●
13 004 027 Siemens C35i mobile phone only ○ ○

13 004 028

ED 001 001 External 3 dB antenna with magnet, 3 meter cable
ED 001 002 Flat external antenna to be glued-on glass or plastic

ED 051 011
ED 051 050 Connector reduction for the ED 050 001 converter

01 002 008 NiMH battery for the Siemens C35i mobile phone
ED 050 300 Double power switch 230 V / 5 A

ED 050 400
ED 050 401
ED 060 601

External FME antenna reduction cable for the
Siemens C35i mobile phone

Converter for connection between a PC and the GB
051 k PC, configuration software included

Motion detector
Motion detector with remote control
Push button connectable into a panel

○ ○ ○ ○
○ ○ ○ ○

○ ○ ○ ○
○ ○ ○ ○
○ ○ ○ ○

○ ○ ○ ○
○ ○ ○ ○
○ ○ ○ ○
○ ○ ○ ○
○ ○ ○ ○

GB 051 011

GB 051 010A

GB 051 011A

Note: (●) included in the predefined set
(○) optional accessory for the product type

2. Safety Commands

• GB 051 is conformable with technical standards for operation in our mains.

• Power source with voltage 10–16 V DC must be used for power supply. Dimension
for peak current is 500mA.

• While cover is removed parts under voltage can be exposed. Device must be
disconnected from all power sources including backup battery before maintenance
or exchange of parts or filled boards.

• While fitting together and assembling the equipment avoid cut-off of interconnecting
cables or their damage by edges.

• No fluids must enter the device. Danger of fire, destruction of device or injury by
electric current impend. In case it occurs pull power source out of the plug
immediately and consult specialist.

• Avoid forceful mechanic stress of device.

• Do not place device into rooms with high temperatures, strong vibrations or high
humidity.

• In case you moved device from cool to warm room do not set it into operation
immediately. Water condenses on device and operation under these circumstances
can cause damage of device. Let device warm up to temperature of room. Wait
until condensed water evaporates.

5

The GB 051 unit must be stocked always with the mobile phone connector
disconnected – when disconnected from external power supply, the GB 051 is
supplied from the mobile phone battery and the battery can be damaged by getting

!

completely flat.

3. Installation and Setting into Operation

3.1. Assembly of GSM Remote Supervision

GSM Remote Supervision by LEVEL is designed for operation in dry places.
During assembly avoid hot places and places where device would be exposed to
direct solar radiation or places close to heating elements.
Do not place GSM Remote Supervision or aerial mast close to phone exchange
or other electronic devices or lines. Due to high-frequency electromagnetic field
these devices could be interfered.
Due to interference it is not advisable to operate device close to other power or
high-frequency devices.

Before assembly prove by cell phone if there is sufficient level of signal required
by GSM network in selected place. Pay attention to delay in indicating of signal
level.

When using for protection of property, arrange protection of area against break-in

by detector.

3.2. Wiring and connecting the GSM Remote Supervision unit

Top view Connector description

1) input/output No. 1

2) input/output No. 2

3) input/output No. 3

4) input/output No. 4

5) input/output No. 5

6) input/output No. 6

7) ground

8) input/output No. 7

9) input/output No. 8

10) power supply + 12 V

Bottom view Connector description

1. Init

2. Ground

3. Reset

4. TxD

5. RxD

6. +Ucc

6

RESET

By connection clips no. 2 and 3 (ground and reset) the unit reset will
be run, while all the set configuration value will remain in place.
The value of days in service will be set to 0.

INIT Detailed description of how to carry on the initialization can be found

in Chapter 4.1. The GSM Remote Control device will be set into
default manufacturer’s settings by the initialization.

Recommended linkage of outputs: Recommended linkage of inputs:

If GSM signal is insufficient external antenna can be connected to cell phone.

Professional solution of switching electrical devices on and off is provided by the
230 V/5 A double power switch ED 050 300 that can be purchased as optional
accessory.

For connection with a PC use always the ED 051 011 converter with cable that
connects into the connector at the bottom side of the unit and into the RS 232
interface in your PC. If you need to connect the PC using the older ED 050 001
converter, use the new optional accessory ED 051 050 (cable with reduction,
Control Panel software included).

The GB 051 device is able to work fully without external power supply for
approximately 12 hours being supplied from the mobile phone battery.

3.3. Inserting the SIM Card and Connecting to the Cell Phone

GSM Remote Supervision can be used only with cell phones Siemens C35, M35

and S35. Do not attempt to connect other phones, it may cause device or phone
damage.

Always use only NiMH battery with the GB 051. Using a Li-Ion battery might result

in unstable function of the GSM Remote Supervision; this type of battery can
cause the mobile phone to turn off without the possibility of starting up
automatically

7

Cell phone must be in basic configuration, only parameters specified further can
be changed.

A SIM card inserted in the GB 051 device must be configured in one of the two
ways described below:
a) If SIM is not blocked by PIN code, then the PIN value in GB 051 is irrelevant –

in this case you can skip this instruction and continue to
assembly the GB 051 and the cell phone.

b) If SIM is blocked by PIN, and then the PIN in GB 051 must be the same with

the PIN at the SIM in mobile phone. The default PIN code in the GB 051 unit
is set from production as “0000” (This will also be the PIN value after unit’s
initialization).

How to change PIN code in the Siemens mobile phones:
In menu select Setup – Security – Codes – Change PIN and the phone will ask
you to enter first the current PIN and then to enter and verify the new PIN code –
enter PIN “0000”.

Description of first assembly:

1. Insert the SIM card and battery into the cell phone, put on the back cover.

2. Stick the GB 051 unit together with the back cover of the mobile phone,
connectors must be faced down.

3. Interconnect the GB 051 with connector in the cell phone.

4. Connect the 12 V external power supply connector.

5. After the power supply is connected, the GB 051 will automatically turn on
the phone and if the PIN code is requested by the phone, the unit will
automatically enter the PIN predefined in configuration.

6. Wait to see the cell phone to connect to the GSM network, the LED should
start blinking slowly.

7. Following this it is recommended to send a command SMS as described
below to set a new PIN (other than 0000) in the GB 051 and the SIM card for
security reasons. This will also verify the correct functionality of the GB 051
device – by confirming it can receive the command SMS and set reply
message back.

After the inquiry on the phone display enter PIN with phone keyboard and wait
until phone logs in. From this moment GSM Remote Supervision is able to accept
control SMS messages.

Therefore send control message (command) to cell phone connected to GB 051:

XX0000PINVpppp

Where:

XX means two capital letters X
0000 is the current PIN in GB 051 (manufacturer setting is 0000)
PIN is the key word of the command

V is the “space” symbol

pppp is the new PIN value

8
