Receipt of the Multi-Loader _____________________________________________________________________________________ 9
Presentation _____________________________________________________________________________________________ 10
Description of the HMI _____________________________________________________________________________________ 11
Description of the status Bar. ________________________________________________________________________________ 12
Connecting the Multi-Loader ___________________________________________________________________________________ 13
Connection to a PC _______________________________________________________________________________________ 13
Connection to a drive ______________________________________________________________________________________ 14
Connection to the graphic terminal (VW3A1101) _________________________________________________________________ 15
Compatibility ____________________________________________________________________________________________ 15
Loading a configuration from a device and more. ________________________________________________________________ 16
Transferring the configuration to a device and more. (use Quick Store) _______________________________________________ 17
Lists of faults codes __________________________________________________________________________________________ 33
BBV48778 03/20113
Important information
The addition of this symbol to a Danger or Warning safety label indicates that an electrical hazard exists, which will result in
personal injury if the instructions are not followed.
This is the safety alert symbol. It is used to alert you to potential personal injury hazards. Obey all safety messages that follow
this symbol to avoid possible injury or death.
NOTICE
Read these instructions carefully, and look at the equipment to become familiar with the device before trying to install, operate, or maintain
it. The following special messages may appear throughout this documentation or on the equipment to warn of potential hazards or to call
attention to information that clarifies or simplifies a procedure
DANGER
DANGER indicates an imminently hazardous situation, which, if not avoided, will result in death or serious injury.
WARNING
WARNING indicates a potentially hazardous situation, which, if not avoided, can result in death, serious injury or
equipment damage.
CAUTION
CAUTION indicates a potentially hazardous situation, which, if not avoided, can result in injury or equipment
damage.
CAUTION
CAUTION indicates a potentially hazardous situation, which, if not avoided, can result in equipment damage.
PLEASE NOTE
The word "drive" as used in this manual refers to the controller portion of the adjustable speed drive as defined by NEC.
Electrical equipment should be installed, operated, serviced, and maintained only by qualified personnel. No responsibility is assumed by Schneider Electric for any consequences arising out of the use of this product.
Read and understand these instructions before performing any procedure with this product.
DANGER
UNINTENDED EQUIPMENT OPERATION
• Read and understand this manual before installing or operating the Multi-loader.
• Any changes made to a device using the Multi-loader must be performed by qualified personnel.
• Read and understand the device manuals before you load or duplicate the Configuration from one device to another device.
• Ensure that you select the Configuration suitable for your application
• Before you load a new product firmware, read and understand the procedure "transferring the device update file" described on page 30
Failure to follow these instructions will result in death or serious injury.
.
DANGER
HAZARD OF ELECTRIC SHOCK, EXPLOSION, OR ARC FLASH
• Read and understand this manual before using the Multi-Loader. Operation of the Multi-Loader must be performed by qualified
personnel.
• Read and understand the installation and programming manuals applicable to the drive that you are using with the Multi-Loader.
Installation, adjustment, repair, and maintenance must be performed by qualified personnel.
• The user is responsible for compliance with all international and national electrical code requirements with respect to grounding the
equipment.
• Many parts in this drive, including the printed circuit boards, operate at the line voltage. DO NOT TOUCH. Use only electrically insulated
tools.
• DO NOT touch unshielded components or terminal strip screw connections with voltage present.
• DO NOT short across terminals PA/+ and PC/- or across the DC bus capacitors.
• Install and close all covers before applying power or starting and stopping the drive.
Failure to follow these instructions will result in death or serious injury.
BBV48778 03/20115
Documentation structure
The following Multi-Loader documents are also available on www.schneider-electric.com.
Simplified manual
This manual is a simplified version of the user manual. It is delivered with the Multi-Loader.
User manual
This manual describes how to connect, configure and update the Multi-Loader.
6BBV48778 03/2011
Setup procedure
1. Receive and inspect the Multi-Loader
Check that the reference printed on the label is the same as that on the
purchase order.
Remove the Multi-Loader from its packaging and check that it has not
been damaged in transit.
2.Connect the Multi-Loader (see page 13)
v To a PC
v To a device
3. Duplicate device configurations (see
page 16
v Load a configuration onto the Multi-Loader
v Transfer a configuration to a device
v Transfer a configuration to several devices (Quick
Store)
and 17)
4. Multi-Loader menus
(see page 18
)
BBV48778 03/20117
Introduction
A) The device's configuration file is copied to the Multi-Loader's SD card. See the procedure on page 16.
B) The configuration file is generated by SoMove then transferred to the Multi-Loader's SD card. See the procedure on page 16
.
1) The user selects and then transfers the configuration file from the Multi-Loader to the device. See the procedure on page 17
.(Step
1 to 3)
2) Once the initial transfer is complete, the user can use Quick Store mode, which allows the Multi-Loader to load the same update file
on several devices in succession. (See page 17
Step 1 to 4)
Duplicating or generating configuration files
A) Configuration duplicated
B) Configuration generated
2) Transfer to several
1) Transfer to one device
SoMove
devices using Quick Store
1) The user downloads the device's specific update file.
2) The user transfers the device's firmware update file from the PC
to the Multi-Loader's SD card. See "Connection to a PC" on page 13
.
3) The user selects and then transfers the product's firmware update
file from the Multi-Loader to the drive. See the procedure on page 30
.
4) Once the initial transfer is completed, the user can use Quick
Store mode, which allows the Multi-Loader to load the same
updated file on several devices.
Updating device firmware
2) Transfer the update file
3) Transfer
1) Download the
device's firmware
update file
4) Transfer via Quick
Store
The Multi-Loader is a standalone tool for transferring configuration files to devices with their power on or off.
• The Multi-Loader is used to set device parameters by loading a configuration file onto the device(s). (Devices must have the same
reference. A consistency check is performed before the data transfer). On some devices the parameters can be set with them still in
their box or before they are powered up.
- This portable tool has been designed to load up to fifty devices a day and has a battery life of six days. However, this depends
on the transfer time, the size of the configuration files and other parameters associated with the settings for the Multi-Loader and
the connected devices.
- It can configure ten drives in less than five minutes.
- The Multi-Loader can provide the power supply for certain devices if they are turned off during the transfer.
• The Multi-Loader is also a firmware update tool.
-The "Password FW" mode can be used to help protect against incorrect operation by means of a password. See the "Password
FW" menu on page
27.
All representations of the ATV12 drive throughout this document are given by way of example only to symbolize a device. Please refer to
the device compatibility tables on pages 15
and 29.
All bold blue text in the manual (e.g. "Main menu / Action") corresponds to the messages displayed on the Multi-Loader screen.
8BBV48778 03/2011
Receipt of the Multi-Loader
Product reference:
Check that the product reference printed on the label is the same as that on the delivery note. This should also correspond with the number
on the purchase order.
Contents of the Multi-Loader box (VW3A8121)
Check that the Multi-Loader box contains the following:
• 1 x Multi-Loader
• 4 x LR6 (AA) batteries
• 1 x SD card
• 1 x standard USB type A to Mini-B cable
• 1 x RJ45 (RJ45/RJ45) cable
• 1 x RJ45 female/female adapter (VW3A1105)
• 1 x carry case
• 1 x simplified manual (English and French)
• 1 x impact resistant cover
Available as an option
• Multi-Loader Cordset (VW3A8126)
BBV48778 03/20119
Receipt of the Multi-Loader
27.4 mm / 1.09 In
65 mm / 2.6 In
181.51 mm / 7.26 In
Presentation
Figure 1
Weight
250 grams (including batteries)
Data storage
One SD card is supplied with the Multi-Loader. Any standard SD card (not SDHC card) is compatible with the tool.
Language
The menus are in English, Japanese, French, German, Italian or Spanish.
Power supplies
Two options are available for powering the Multi-Loader:
1) With internal power supply:
• 4 x LR6 (AA) alkaline batteries (batteries included)
• NiMh rechargeable batteries (batteries and charger not included)
2) With external power supply :
• USB type A to Mini-B cable direct on the PC power supply
Battery life
Depending on the type of batteries used, the Multi-Loader can transfer up to 300 configuration files.
Power save feature
To prolong battery life, a standby function is activated within a programmable time delay; the Multi-Loader is reactivated by pressing the
ON/OFF button. (See the display parameters menu on page 28
Connection to a powered-up PC or device can also help conserve battery power, as the power supply from the connected device takes over
from the batteries.
10BBV48778 03/2011
.)
Receipt of the Multi-Loader
D
A
BC
E
F
G
H
K
L
I
J
Description of the HMI
Figure 2
LetterDescriptionComments
A
B
CRJ11 connector with label coverThis connector is reserved for Schneider Electric product support.
D
EBattery compartmentThe Multi-Loader can take normal batteries or rechargeable batteries.
FON/OFF buttonPress for 2 seconds to turn the tool on or off.
G
HScreenThe screen comprises 2 lines of 16 characters. (see page 12)
KUp arrow key For menu navigation.
LDown arrow key For menu navigation.
Mini-B USB connectorThe connection between the Multi-Loader (USB Mini-B type) and the PC
(USB type A) is via a 1 m (3.28 feet) USB type A to Mini-B cable.
RJ 45 connectorThe connection between the Multi-Loader and the device is via a RJ45
cable to load and transfer configuration files or updated application
SD card slotThe SD card receives and stores the files. One SD card is supplied with
the Multi-Loader.
Quick Store keyPress this key to transfer data from the Multi-Loader to the device after
IESC keyReturns to the previous screen.
JENT keyConfirms the parameter selection or cancels messages.
an initial transfer.
BBV48778 03/201111
Receipt of the Multi-Loader
Status
Bar section 1
Line 2
Line 1
Status
Bar section 2
Status
Bar section 3
Status
Bar section 4
Battery full
Battery 75%
Battery 25%
Battery low (less
then 20%)
Battery 50%
Status
Bar section 1
Status
Bar section 2
Status
Bar section 3
Status
Bar section 4
Multi-Loader is
sending 5VDC to
device
Multi-Loader is
sending 10VDC
to device
Multi-Loader is
getting 10V input
from device
Multi-Loader is
connected to PC
Multi-Loader is
connected to
USB Power
supply
Multi-Loader is
running on
Battery power
Multi-Loader is
running on USB
power
Multi-Loader is
running on RJ45
power
Description of the status Bar.
The drawings below show names and functions of main parts display.
12BBV48778 03/2011
Connecting the Multi-Loader
A: USB type A connector B: USB Mini-B type connector
SD card reader
Figure 3Figure 4
This section describes the various ways of connecting the Multi-Loader.
Connection to a PC
There are two ways of storing files on the SD card:
- Insert the SD card in the Multi-Loader and connect the Multi-Loader to the PC with the standard USB type A to Mini-B cable (see
Figure 3 below) . The Multi-Loader is power supply by the PC.
Or
- Insert the SD card in the SD card reader on the PC (see Figure 4 below)
A
B
For both these methods, the SD card is recognized as an external storage device; no driver is required. The SD card operates in Windows
Explorer using the same copy/paste actions as any standard external storage medium.
Note:
• The PC must be on and operational before connecting the Multi-Loader to avoid an incorrect start up of the PC.
• The SD card must not be removed when the Multi-Loader is on and a transfer is in progress. Otherwise, data on the SD card may be
lost.
• The file name can have 32 characters and the special characters are forbidden.
• The following priority rules come into play when the Multi-Loader is connected to a PC:
- If no transfer is in progress between the Multi-Loader and the drive, the connection to the drive is ignored and the Multi-Loader is
detected by the PC.
- If a transfer is in progress between the Multi-Loader and the drive, the user has to wait until the transfer is complete. The MultiLoader should be reconnect to the pc for can be detected.
- If the Multi-Loader is connected to the PC without a SD card, it is necessary to disconnect the Multi-Loader before inserting SD
card to be recognized by the PC as an external storage device.
- If the Multi-Loader is connected to the PC without a SD card, it is power supply by the PC. Insert the SD card to be recognized
by the Multi-Loader, you can transfer configuration file.
Source of configuration files
There are two ways of managing configuration files:
- If a device's configuration is to be duplicated, it is copied to another device via the Multi-Loader. See "Loading a configuration
from device" on page
- If the configuration file is generated by SoMove software, it must then be transferred to the Multi-Loader's SD card. See
"Downloads" on page
BBV48778 03/201113
16 and "Configuration transfers" on page 17
32 and "Connection to a PC" above.
Connecting the Multi-Loader
The drive is in its packaging
When the drive is off, the Multi-Loader is powered
The drive is mounted, wired, and powered-up
or
the drive is power on
When the drive is on, the Multi-Loader is powered by the drive via the RJ45 cable.
Connection to a drive
There are three ways of transferring configuration files.
Note: When the drive is in its box, the Multi-Loader Cordset option can be used for quicker and easier in-box connection (no locking tab on
the connector), thus speeding up the transfer and keeping the packaging intact.
DANGER
HAZARD OF ELECTRIC SHOCK, EXPLOSION, OR ARC FLASH - EXPOSURE TO ENERGIZED PARTS
• Adhere to NFPA 70E guidelines when using the Multi-Loader.
• The Multi-Loader is to be used only by qualified personnel as defined in NFPA 70E
• Read and understand the manuals for the applicative drive before accessing the communication port of the drive.
• Ensure that the RJ45 cable is not damaged
Failure to follow these instructions will result in death or serious injury.
Schneider Electric recommends that all power from the drive and enclosures housing the drive is disconnected before performing this
procedure. If you choose not to follow this recommendation, you must adhere to NFPA 70E guidelines.
1. Remove all power from the drive and all enclosures housing the drive and wait 15 minutes to allow the DC bus of the drive to
discharge.
2. Insert the Multi-Loader's communication cable into the drive's RJ45 communication port. Refer to the drive's installation manual for
more information about how to perform this task.
3. Install and close all covers and doors before applying power to the drive. The drive must be powered on before performing an upload or
download.
4. Perform the desired transfer.
5. Upon completing the transfer, remove all power from the drive and the enclosures housing the drive and wait 15 minutes to allow the DC
bus of the drive to discharge.
6. Remove the Multi-Loader communication cable from the drive.
7. Install and close all covers and doors before reapplying power to the drive.
8. Confirm that the correct program is in the drive.
14BBV48778 03/2011
Connecting the Multi-Loader
Connection to the graphic terminal (VW3A1101)
The Multi-Loader can be connected to the graphic terminal via its RJ45 female/female adapter (VW3A1105). This adapter is needed for
updating the graphic terminal.
Configuration transfers
Compatibility
The table below shows the devices that are compatible with the Multi-Loader. It shows which type of file can be transferred depending on
the state of the device.
The Multi-Loader can be used to:
• Transfer configuration ("*.cfg") files via the RJ45 cable supplied with the Multi-Loader or using the Multi-Loader Cordset option
(VW3A8126).
DevicePower onPower off
ATV12
ATV212
ATV32
ATV312
Lexium 32
ATV31
ATV71
ATV61
Device compatible with the Multi-Loader tool
Note: When transferring files, devices must have the same reference. Any incompatibility will prompt an message "Wrong
reference Fault" and the transfer operation will not be done. (See the table of detected fault on page 25
BBV48778 03/201115
.)
Configuration transfers
Main menu
Action
->
ENT
Device -> MLD
LoadFrmDxx?
Action Config
Device -> MLD
LoadFrmDxx?
<<<<
LoadFrmDxx?
<<<<<<<<
LoadFrmDxx?
<<<<<<<<<<<<
Load config
Successfu
l
Replace
LoadFrmDxx?
ENT
ENT
ENT
ENT
MLD
Device
Action Config
1
2
Are there
more
99 files on the
card ?
YesNo
Loading a configuration from a device and more.
This procedure allows the user to retrieve a configuration file ("file.cfg") from a device and load it onto the Multi-Loader's SD card.
STEPActions
1
2
Note 1: The file will be stored in a folder (folder name is the first 5 letters of the device ID) kept in a directory called ‘LoadFrmDev’
located at root.
Note 2: Loading a configuration from an ATV61/71 device with option board could generate, a short time, the display of [Incorrect
config.] (CFF) fault on the device during the operation.
• Turn the Multi-Loader on using the ON/OFF button "F" (see page 11).
• Connect the Multi-Loader to the device using the RJ45 cable (see page 14
).
• Press "ENT" when the screen displays Main menu / Action.
• Select the Action Config / Device -> MLD menu using the arrow keys and press "ENT".
• Device -> MLD / LoadFromDevice appears on the screen. Press ENT until the transfer starts.
• Load Config Successful: The configuration has been loaded successfully onto the Multi-Loader;
disconnect the RJ45 cable from the device. The device configuration file ("file.cfg") is now loaded onto the
Multi-Loader's SD card.
• Pressing "ENT" returns the user to the "Action Config" menu.
• For another loading configuration into the Multi-Loader, repeat the step 1 and step 2.
16BBV48778 03/2011
Configuration transfers
MLD -> Device
Filename1
MLD -> Device
Filename
2
MLD -> Devic e
Filename N
Action Config
MLD -> Device
FilenameX
>>>>
FilenameX
>>>>>>>>
FilenameX
>>>>>>>>>>>>
Store config
Successful
Main menu
Action
EN
T
ENT
EN
T
EN
T
ENT
ENT
Store config
Successful
Store config
Successful
Store config
Successful
Store config
Successful
1
2
3
4
Device 3
Device 4
Device n
Transferring the configuration to a device and more. (use Quick Store)
DANGER
UNINTENDED EQUIPMENT OPERATION
• Read and understand this manual before installing or operating the Multi-Loader.
• Any changes made to a device using the Multi-Loader must be performed by qualified personnel.
• Read and understand the device manuals before you load or duplicate the Configuration from one device to another device.
• Ensure that you select the Configuration suitable for your application
Failure to follow these instructions will result in death or serious injury.
This procedure allows the user to select the configuration file to be transferred to the device and use the Quick Store function (see page
22
) to duplicate configurations.
The user must already have:
- Loaded the device configuration file (*.cfg) onto the Multi-Loader (see page 16)
Or
- Generated the configuration file using SoMove and loaded this file onto the Multi-Loader (filename1, filename 2, etc.)
STEPTransfer
1
2
3
4
Note : Storing a configuration to an ATV61/71 device with option board could generate, a short time, the display of [Incorrect config.]
(CFF) fault on the device during the operation.
BBV48778 03/201117
• Turn the Multi-Loader on using the ON/OFF button "F" (see page 11).
• Connect the Multi-Loader to the device using the RJ45 cable (see page 14).
• Press "ENT" when the screen displays Main menu / Action.
• Press "ENT" when the screen displays Action Config / MLD -> Device.
• Select the file to be transferred using the arrow keys and press "ENT" to start the transfer. If no device is connected,
a message (No device connected) appears on the screen (see page
• The configuration has been transferred successfully from the Multi-Loader; disconnect the RJ45 cable from the device.
25).
• Pressing "ENT" returns the user to the "Action Config / MLD -> Device" menu or see STEP 4 for the Quick store.
• Connect the Multi-Loader to the next device, then press the Quick Store key
• Store Config Successful: The configuration has been loaded successfully onto the second device; remove the RJ45
cable from the device. This action can be carried out as many times as necessary
Multi-Loader menus
Main menu
Actio n
Action Config
MLD -> Device
Action Config
Device -> M LD
Action Flash
Firmware
ON
Multiloader
Version X.X
2s
OFF
Main menu
Parameters
Parameters
Battery
Parameters
Diagnostic
Parameters
Password FW
Parameters
Display
Main menu
Device
EN
T
EN
T
EN
T
EN
T
EN
T
ENT
EN
T
ENT
ENT
ENT
Esc
Esc
Esc
Esc
Esc
Esc
Esc
Main menu
About MLD
Build:AB,CD
dd-mm-yy,hh:mm
EN
T
ENT
EN
T
ENT
Esc
Page 22
Quick
Store
Page 23
Page 19
Page 20
Page 21
Page 24
Page 25
Page 27
Page 28
Multi-Loader main menu
On power-up, the Multi-Loader / Version "x.x"menu is displayed on the screen.
The diagram below shows the various menus that can be accessed from the Multi-Loader main menu.
Main menu / Action accesses the following functions:
- Load from Multi-Loader to device
- Load from device to Multi-Loader
- update software of device
Main menu / Device accesses the following information:
- Device type
- Device version
Main menu / Parameters accesses:
- Battery parameters
- Diagnostic parameters
- Password parameters
- Display parameters
Main menu / About MLD accesses:
- Multi-Loader version information
The Quick Store key "G" (see page 11) allows the user to transfer the most recent configuration file or update the device (see page 22).
Note : Quick Store mode is disabled when the Multi-Loader is loading files.
18BBV48778 03/2011
Multi-Loader menus
Device
connected?
Transfer
complete
SD card
readable?
The file is saved
for Quick Store
mode
Incomplete or
incorrect transfer
Incorrect configuration
file for this device
Two types
of error message
Page 22
Quick Store
mode?
YesNo
Transfer in
progress
Yes
No
No
Yes
YesNo
Action: Store configuration from Multi-Loader to device
The diagram below shows the Action Config / MLD -> Device menu accessible from Main menu / Action.
Action Config / MLD -> Device: This menu accesses the transfer function for loading configurations from the Multi-Loader to the device.
Main
menu
EN
SD card
Fault
No device
connected
T
EN
T
Action Config
MLD -> Device
EN
MLD -> Device
Filename 1
EN
T
T
Esc
MLD -> Device
Filename
FilenameX
>>>>
FilenameX
>>>>>>>>
FilenameX
>>>>>>>>>>>>
EscEsc
MLD - > Device
2
EN
T
FilenameN
EN
T
Quick
Stor e
Store config
Successful
Store
config fault
Wrong reference
fault
BBV48778 03/201119
Multi-Loader menus
Device
connected?
Transfer
complete?
SD card
readable?
Are there more 99
files in the card ?
Transfer in
progress
No
No
No
No
Yes
Yes
Yes
Yes
Action: Load configuration from device to Multi-Loader
The diagram below shows the Action Config / Device -> MLD menu accessible from Main menu / Action.
Action Config / Device -> MLD: This menu accesses the transfer function for loading configurations from the device to the Multi-Loader.
Action Config
Device -> MLD
EN
T
EN
No devic e
connected
SD card
Fault
T
EN
T
Device -> MLD
LoadFromDevice
Replace
LoadFrmDxx?
EN
T
LoadFrmDxx
<<<<
LoadFrmDxx
<<<<<<<<
LoadFrmDxx
<<<<<<<<<<<<
Esc
Esc
Load config
Successfu
l
EN
Load
config fault
EN
T
T
Note1: The file will be stored in a folder (folder name is the first 5 letters of the device ID) kept in a directory called ‘LoadFrmDev’ located
at root.
Note 2: The maximun number of configurations for each range are 99.
20BBV48778 03/2011
Multi-Loader menus
Filename 1Filename 2Filename N
Action Flash
Firmwar e
FilenameX
>>>>
FilenameX
>>>>>>>>
FilenameX
>>>>>>>>>>>>
Flash FW
Successful
Flash F W
Fault - 0X..
Enter password
000
Enter password
NNN
Wrong
password
SD card
Fault
Replace
Firmware?
Quick
Store
Main
menu
No device
connected
Flash FW Flash FW
Flash FW
Esc
ENT
ENT
Esc
EN
T
EN
T
ENT
EscEsc
Esc
EN
T
ENTENT
EN
T
ENTENT
Esc
The file is
saved for
Quick Store
mode
Quick Store
mode?
Yes
No
Transfer
complete?
No
Yes
Page 22
Transfer in
progress
SD card
readable?
No
Yes
Update
authorized
Password
correct?
No
Yes
Value between
[000 and 999]
Default value [000]
Press and hold the
up or down arrow
key to define the
password more
quickly
Update
authorized?
No
Yes
Yes
No
Device
connected?
See lists of
faults codes
page 33
Action: Update device using Multi-Loader
The diagram below shows the Action Flash / Firmware menu accessible from Main menu / Action.
Action Flash / Firmware: This menu accesses the transfer function for loading the software update file onto the device.
It is possible to protect the firmware update transfer. See the Parameters / Password FW menu on page 27
.
An RJ45 cable is required for updating the device firmware (see the compatibility table on page 29
turned on, the Multi-Loader provides the power supply.
). If a device is updated without being
BBV48778 03/201121
Multi-Loader menus
No file
selected
SD card
Fault
No device
connecte
d
EN
T
EN
T
ENT
SD card
readable?
Device
connected?
Two file types
File selected?
File
present on the
SD card?
Exit Quick Store
mode
Page 19
Page 21
Configuration
file
FW file
Yes
Yes
Yes
Yes
No
No
No
No
Quick Store mode
This mode is used to transfer the latest configuration file (page 17) or latest device firmware updated file (page 30). (1)
The diagram below shows the Quick Store mode, which can be accessed after using either of the Action Config / MLD -> Device or Action
Flash / Firmware menus.
(1)Files can only be transferred between devices with the same reference.
22BBV48778 03/2011
Note 1: If the Multi-Loader is already loading a file, the Quick Store key is inactive.
Note 2: Quick Store mode can only be used after an initial transfer to a device has been completed.
Multi-Loader menus
Main menu
Device
Device
Type
Device
SW Version
Range
ATVXXXXXXXX
SW Version
Vxx.xx
No device
connected
ENT
Esc
ENT
ENT
ENT
ENT
ENT
Esc
Esc
Esc
Device
connected?
Device
connected?
No
Yes
No
Yes
Supervision
The diagram below shows the device main menu, accessible from Main menu / Device. This supervisory menu is used to check the
reference and version of the device connected to the Multi-Loader.
Device Type: This menu accesses the reference of the connected device.
Device SW version: This menu accesses the software version of the connected device.
BBV48778 03/201123
Multi-Loader menus
Battery
Charge leve l
Battery
Alarm leve l
Parameters
Battery
ENT
Alarm leve l
20%
Esc
Charge leve l
႑႑႑႑႑႑႑႑႒ ႒
Esc
Esc
Esc
Alarm leve l
NN%
Battery
Set battery type
Esc
Set battery type
Normal
Esc
Esc
Set battery type
Rechargeable
ENT
ENT
ENT
ENT
ENT
ENT
ENT
Save this level
Save the battery type
Value between
[0 and 50]%
Press and hold the up
or down arrow key to
define this level value
more quickly
Parameter settings: Batteries
The diagram below shows the Parameters / Battery menu accessible from Main menu / Parameters.
Battery / Charge level: This menu displays the Multi-Loader charge level.
Battery / Alarm level: This menu is used to set message activation at a particular charge level. It warns the user about the battery charge
status according to the value set (see message fault detected on page 25
Battery / Set battery type: This menu is used to select the type of battery used by the Multi-Loader (normal batteries or rechargeable
batteries). Users must ensure that the correct battery type is selected so that the Multi-Loader can accurately display the charge level. This
also affects message activation.
).
24BBV48778 03/2011
Multi-Loader menus
Parameters
Diagnostic
Diagnostic
Fault History
Diagnostic
Clear faults
Fault History
fault 1
Fault History
fault 2
Fault History
fault 3
Are you sure to
clear faults?
Clear faults
History done
Esc
Esc
Esc
Esc
Esc
Esc
EN
T
ENT
ENT
EN
T
EN
T
List of cleared
faults codes
See the table of
faults codes below
Parameter settings: Diagnostics
The diagram below shows the Parameters / Diagnostic menu accessible from Main menu / Parameters.
Diagnostic / Fault History: This menu accesses the detected fault history.
Diagnostic / Clear Faults: This menu is used to clear the detected fault history
DANGER
UNINTENDED EQUIPMENT OPERATION DUE TO TRANSFER INTERRUPTION
If an interruption occurs during the transfer of configuration to the device :
• Identify and correct the cause of interruption.
• Repeat the transfer.
Failure to follow these instructions will result in death or serious injury.
Multi-Loader displayProbable causeRemedy
-Make sure you have a set of replacement
batteries to hand, as the current set have little
life left.
-Remains not enough time of use.
-Replace the batteries immediately. No more
transfers can be made.
-Check the RJ45 cable and both of its
connectors. Make sure the connection is
secure for the duration of the transfer. Restart
the transfer operation.
-Check that the configuration file is compatible
with the device to be configured.
Alert: Low
Battery Level
Low battery
config fault
Wrong reference
Switch off
Store
Fault
The battery charge is low. The appearance of this
message depends on the charge level defined by
the user. (See setting the detection page 24
The battery charge is too low. The Multi-Loader will
turn off.
Incomplete or incorrect transfer to the device
Bad transfer to the device; the configuration file
selected is not compatible with the destination
device.
.)
BBV48778 03/201125
Multi-Loader menus
Parameter settings: Diagnostics
Multi-Loader displayProbable causeRemedy
Load
config fault
Flash FW
Fault
No device
connected
No file
selected
Wrong
password
SD card
fault
FLSH MSD
Error
Incomplete or incorrect transfer from the MultiLoader to the device
Incomplete or incorrect device update
The device is not connected or is incorrectly
connected.
No configuration file is selected.
There is no file present on the SD card.
The password is incorrect.
The card is not recognized.
Incomplete or incorrect Multi-Loader update
-Check the RJ45 cable and both of its
connectors. Restart the transfer operation.
-Check the RJ45 cable and both of its
connectors. Make sure the connection is
secure for the duration of the transfer. Restart
the transfer operation.
-Check the RJ45 cable and both of its
connectors. Make sure the connection is
secure for the duration of the transfer.
Connect the RJ45 cable.
-Select a file to transfer.
-Follow the procedure for loading configuration
files described on page 16
- Enter the password correctly (the default
password is [000]).
-Check that the SD card is inserted correctly.
-Check that the SD card is formatted correctly.
-Check that the SD card is inserted correctly.
-Check the version files for updating MultiLoader. See page 31
.
26BBV48778 03/2011
Multi-Loader menus
Parameters
Password FW
Old password
000
Esc
Wrong
password
New password
000
Esc
Old password
NNN
Esc
New password
NNN
Esc
ENT
EN
T
EN
T
ENT
Is there a
password?
Is the
password
correct?
Password saved,
firmware updating
protected
Press and hold the
up or down arrow
key to define the
password more
quickly
Value between
[000 and 999]
Default value
[000]
Press and hold the
up or down arrow
key to define the
password more
quickly
Yes
Yes
No
No
Parameter settings: Password
Parameters / Password FW
The diagram below shows the Parameters / Password FW menu accessible from Main menu / Parameters.
Parameters / Password FW: This code helps protect the device from accidental firmware updating.
BBV48778 03/201127
Multi-Loader menus
Parameters
Display
Display
Contrast
Set contrast
50
Esc
Display
Backlight
Set backlight
ON
Esc
Esc
Set backlight
OFF
Display
Sleep mode
Set sleep mode
05 min
Esc
Esc
Display
Language
Esc
Esc
Esc
Esc
Esc
Set contrast
NN
Set sleep mode
NN min
Esc
ENT
EN
T
ENT
ENTENT
ENT
ENT
ENT
ENT
ENT
Language
Français
Language
日本語
Language
English
Language
Italiano
Language
Deutch
Language
Español
Esc
Esc
Esc
Esc
Esc
Esc
EN
T
EN
T
EN
T
EN
T
EN
T
EN
T
Saves the
contrast value
Saves the
backlight value
Saves the sleep
mode value
Press and hold the
up or down arrow
key to define the
sleep mode value
more quickly
Press and hold the
up or down arrow
key to define the
contrast value more
quickly
Value between
[0 and 100]
Value between
[1 and 60] min
Save language
Parameter settings: Display
The diagram below shows the Parameters / Display menu accessible from Main menu / Parameters.
Display / Contrast: This menu is used to set the display screen contrast.
Display / Backlight: This menu is used to set the display screen backlight.
Display / Sleep mode: This menu is used to set the Multi-Loader's sleep mode.
Display / Language: This menu accesses the language selection for the Multi-Loader interface.
28BBV48778 03/2011
Updating device application
Compatibility
DANGER
UNINTENDED EQUIPMENT OPERATION
• Read and understand this manual before installing or operating the Multi-Loader.
• Any changes made to a device using the Multi-Loader must be performed by qualified personnel.
• Before you load a new product firmware, read and understand the procedure "transferring the device update file" describes page 30
• Ensure that you select the Firmware suitable for your application
Failure to follow these instructions will result in death or serious injury.
The Multi-Loader can be used to update a device's firmware ("*.fw") file via the RJ45 cable provided in the box or using the Multi-Loader
Cordset (available as an option) as required.
The table below shows the devices that are compatible with the Multi-Loader. It shows which type of file can be transferred depending on
the state of the device.
DevicePower off
Graphic terminal
(VW3A1101)
Lexium 32
.
Device compatible with the Multi-Loader tool
Note1: The update file must be compatible with the device. Any incompatibility will prompt a message "Wrong reference Fault" and the
transfer operation will not be done. (See table on page 25
Note2: When updating device firmware, you must ensure that all downloaded files are copied to the Multi-Loader's SD card ("*.fw" file and
executable file).
Note3: Ensure that you update the product device label and the keypad label after updating device application.
.)
BBV48778 03/201129
Procedure
Device 1
Device 2
Device n
1
3
2
3
Transferring the device update file
This procedure describes how to select the device update file. The user can then use Quick Store mode for the rest of the operation (see
page 22
). The user must already have:
- Downloaded the update file from www.schneider-electric.com (see page 31)
AND
- Transferred the file to the Multi-Loader (see page 13, Connection to a PC)
Main menu
Action
EN
T
Action Config
MLD -> Device
Action Flash
Firmwar e
ENT
Flash FW
Successful
STEP
Flash FW Flash FW
Filename 1Filename 2Filename N
ENT
ENT
ENT
FilenameX
>>>>
FilenameX
>>>>>>>>
FilenameX
>>>>>>>>>>>>
Flash FW
Successful
Flash FW
ENT
Flash FW
Successful
Flash FW
Successful
TransferQuick Store
• Turn the Multi-Loader on using the ON/OFF button "F" (see page 11).
1
• Connect the Multi-Loader to the device using the RJ45 cable (see page 14
• Press "ENT" when the screen displays Main menu / Action.
• Select the Action Flash / Firmware menu using the arrow keys and press "ENT".
).
2
• Select the file to be transferred using the arrow keys and press "ENT" to start the transfer. If no device is
connected, a message (No device connected) appears on the screen (see page 25
).
• The firmware update file has been loaded
successfully onto the device; disconnect the
RJ45 cable from the device.
3
• Pressing "ENT" returns the user to the "Action
Config" menu if no other devices require
updating.
• Connect the Multi-Loader to the next device,
then press the Quick Store key.
• Flash FW Successful: The firmware update
file has been loaded successfully onto the
device; disconnect the RJ45 cable from the
device.
• This action can be carried out as many times as
necessary.
30BBV48778 03/2011
Updating the Multi-Loader tool
There are two methods for updating the Multi-Loader:
• The user connects the Multi-Loader to the PC (with the SD card in the Multi-Loader) and transfer the file for updated application device
to the card SD. The Multi-Loader is then updated as soon as it is turned on.
Or
• The user copies the update file to the SD card, (with the SD card in the PC) then inserts the SD card into the Multi-Loader; the MultiLoader is then updated as soon as it is turned on.
To download the files required for updating the Multi-Loader tool, see "Downloads" on page 32.
OLD format
To upgrade Firmware for Multi-Loader from versions between V1.10 and V3.03, following six files need to be copied to SD card.
New format u V3.04
To upgrade Firmware for Multi-Loader from versions V3.04, following two files need to be copied to SD card.
y V3.03
• MLDAPP.FW
• APPADDR.BIN
•APPDATA.BIN
•MLDMSD.FW
• MSDADDR.BIN
• MSDDATA.BIN
• MLDAPP.mld
• MLDMSD.mld
Update procedure
Step
• Check that the SD card is inserted correctly in the
1
2
3
4
5
6The Multi-Loader launches the update automatically.6The Multi-Loader launches the update automatically.
Multi-Loader.
• Turn the Multi-Loader on using button "F" (see
page 11
• Connect the Mini-B connector to the Multi-Loader
and the type A connector to the PC (see page 13
The Multi-Loader is recognized as an external storage
device.
• Drag and drop the unzip files into the root directory on
the SD card by the PC
Wait until the files have loaded.
Once the files have loaded successfully, remove the
USB cable from the PC and the Multi-Loader.
• Turn the Multi-Loader off using button "F" (see
page 11
• Turn the Multi-Loader on using button "F" (see
page 11
).
).
).
USB/PC
ActionsActions
Step
• Insert the SD card in the SD card reader on the PC
1
).
2
3
4
5
(see page 13
The SD card is recognized as an external storage device.
• Drag and drop the unzip files into the root directory
on the SD card by the PC
Wait until the files have loaded.
• Once the files have loaded successfully, remove
the SD card from the PC.
• Insert the SD card in the Multi-Loader.
• Turn the Multi-Loader on using button "F" (see
page 11
SD card/PC
).
).
BBV48778 03/201131
Downloads
SoMove software
SoMove allows you to prepare the configurations to be loaded onto a device. It is freeware available for downloading from
www.schneider-electric.com.
Device update file
Contact your local Schneider Electric Customer Support Center for all device firmware updates.
Multi-Loader updated file
To request Multi-Loader update files, contact your local Schneider Electric Customer Support Center or download it directly from the
Schneider Electric website.
32BBV48778 03/2011
Lists of faults codes
DANGER
UNINTENDED EQUIPMENT OPERATION DUE TO TRANSFER INTERRUPTION
If an interruption occurs during the transfer of configuration to the device :
• Identify and correct the cause of interruption.
• Repeat the transfer.
Failure to follow these instructions will result in death or serious injury.
CodesDisplay on the Multi-LoaderCodesDisplay on the Multi-Loader
GeneralSpecific application FW
Flash FW
FAULT - 0x01
Flash FW
FAULT - 0x02
Flash FW
FAULT - 0x11
Flash FW
FAULT - 0x12
Flash FW
FAULT - 0x13
Flash FW
FAULT - 0x14
Wrong memory write detectedFlash FW
FAULT - 0x21 - 0x31
Wrong check at the end of the upgrade
detected
Interruption connection detected or wrong
file
Missing file on the SD card
Path too long
File in a wrong format (Drives)Flash FW
File in a wrong format (Graphic keypad)
Flash FW
FAULT - 0x22 - 0x32
Flash FW
FAULT - 0x23 - 0x33
Flash FW
FAULT - 0x24 - 0x34
FAULT - 0x25 - 0x35
Wrong communication detected
Wrong reference detected
Wrong communication detected (baud
rate)
Wrong program erase detected
Wrong program download detected
Flash FW
FAULT - 0x9a
Flash FW
FAULT - 0x9b
Flash FW
FAULT - 0x9c
Flash FW
FAULT - 0x9d
Flash FW
FAULT - 0x91
Flash FW
FAULT - 0x92
Flash FW
FAULT - 0x93
Flash FW
FAULT - 0x94
Flash FW
FAULT - 0x95
Flash FW
FAULT - 0x96
Flash FW
FAULT - 0x97
Flash FW
FAULT - 0x98
Flash FW
FAULT - 0x99
Specific graphic keypadSpecific motor control FW
Wrong file detected Flash FW
FAULT - 0x4a
Fonts file download failedFlash FW
FAULT - 0x40
Labels file download failedFlash FW
FAULT - 0x41
Bitmaps file download failedFlash FW
FAULT - 0x42
Internal ErrorFlash FW
FAULT - 0x43
Wrong file detected Flash FW
FAULT - 0x44
Internal Error2
(Unable to open the file)
Wrong communication detectedFlash FW
Syntax error of the configuration fileFlash FW
Wrong file detected Flash FW
Wrong file detected Flash FW
Wrong configuration format file detected
No keypad connected
Wrong update labels of keypad detected
Flash FW
FAULT - 0x45
FAULT - 0x46
FAULT - 0x47
FAULT - 0x48
FAULT - 0x49
Wrong download detected
Flashing Motor Control is not allowed when
the drive is Power On
Wrong communication detected
Inquiry device failed
Selection device failed
Inquiry of clock modes failed
Selection of clock modes failed
Inquiry of write line size failed
Wrong communication detected (baud
rate)
End setting data failed
Wrong memory write detected
BBV48778 03/201133
Lists of faults codes
DANGER
UNINTENDED EQUIPMENT OPERATION DUE TO TRANSFER INTERRUPTION
If an interruption occurs during the transfer of configuration to the device :
• Identify and correct the cause of interruption.
• Repeat the transfer.
Failure to follow these instructions will result in death or serious injury.
