Samsung SNV-5010 User Manual
NETWORK CAMERA
User Manual
SNV-5010
Network Camera
User Manual
Copyright
©2011 Samsung Techwin Co., Ltd. All rights reserved.
Trademark
is the registered logo of Samsung Techwin Co., Ltd. The name of this product is the registered trademark of Samsung Techwin Co., Ltd.
Other trademarks mentioned in this manual are the registered trademark of their respective company.
Restriction
Samsung Techwin Co., Ltd shall reserve the copyright of this document. Under no circumstances, this document shall be reproduced, distributed or changed, partially or wholly, without formal authorization of Samsung Techwin.
Disclaimer
Samsung Techwin makes the best to verify the integrity and correctness of the contents in this document, but no formal guarantee shall be provided. Use of this document and the subsequent results shall be entirely on the user’s own responsibility. Samsung Techwin reserves the right to change the contents of this document without prior notice.
Warranty
If the product does not operate properly in normal conditions, please let us know. Samsung Techwin will resolve the problem for free of charge. The warranty period is 3 years. However, the followings are excluded:
•If the system behaves abnormally because you run a program irrelevant to the system operation.
•Deteriorated performance or natural worn-out in process of time
overview
IMPORTANT SAFETY INSTRUCTIONS
1. |
Read these instructions. |
|
|
2. |
Keep these instructions. |
|
|
3. |
Heed all warnings. |
● |
|
OVERVIEW |
|
||
4. |
Follow all instructions. |
|
|
|
|
||
5. |
Do not use this apparatus near water. |
|
|
6. |
Clean only with dry cloth. |
|
|
7. |
Do not block any ventilation openings, Install in accordance with the manufacturer’s |
|
|
8. |
instructions. |
|
|
Do not install near any heat sources such as radiators, heat registers, stoves, or other |
|
|
|
9. |
apparatus (including amplifiers) that produce heat. |
|
|
Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized |
|
|
|
|
plug has two blades with one wider than the other. A grounding type plug has two |
|
|
|
blades and a third grounding prong. The wide blade or the third prong are provided for |
|
|
|
your safety, If the provided plug does not fit into your outlet, consult an electrician for |
|
|
|
|
|
|
|
replacement of the obsolete outlet. |
|
|
10. Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and the point where they exit from the apparatus.
11. Only use attachments/ accessories specified by the manufacturer.
12. Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the apparatus. When a cart is used, use caution when moving the cart/apparatus combination to avoid injury from tip-over.
13. Unplug this apparatus during lighting storms or when unused for long periods of time.
14. Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped.
English _3
overview
WARNING
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS PROCUCT TO RAIN OR MOISTURE. DO NOT INSERT ANY METALLIC OBJECT THROUGH THE VENTILATION GRILLS OR OTHER OPENNINGS ON THE EQUIPMENT.
Apparatus shall not be exposed to dripping or splashing and that no objects filled with liquids, such as vases, shall be placed on the apparatus.
CAUTION
CAUTION
RISK OF ELECTRIC SHOCK.
DO NOT OPEN
CAUTION : TO REDUCE THE RISK OF ELECTRIC SHOCK.
DO NOT REMOVE COVER (OR BACK).
NO USER SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
EXPLANATION OF GRAPHICAL SYMBOLS
The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of “dangerous voltage” within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons.
The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating
and maintenance (servicing) instructions in the literature accompanying the product.
4_ overview
Class
construction
An apparatus with CLASS
construction shall be connected to a MAINS socket outlet with a protective earthing connection.
Battery
Batteries(battery pack or batteries installed) shall not be exposed to excessive heat such as sunshine, fire or the like.
Disconnection Device
Disconnect the main plug from the apparatus, if it’s defected. And please call a repair man in your location.
When used outside of the U.S., it may be used HAR code with fittings of an approved agency is employed.
CAUTION
These servicing instructions are for use by qualified service personnel only. To reduce the risk of electric shock do not perform any servicing other than that contained in the operating instructions unless you are qualified to do so.
The BNC Out terminal of the product is provided for easier installation, and is not recommended for monitoring purposes.
If you keep the BNC cable connected, a risk of lightening may cause damage or malfunction to the product.
Please use the input power with just one camera and other devices must not be connected.
OVERVIEW ●
English _5
overview
Please read the following recommend safety precautions carefully.
Do not Place this apparatus on an uneven surface.
Do not install on a surface where it is exposed to direct sunlight, near heating equipment or heavy cold area.
Do not place this apparatus near conductive material. |
Do not attempt to service this apparatus yourself. |
||||
|
|
|
|
|
|
|
|
|
|
|
|
Do not place a glass of water on the product. |
Do not install near any magnetic sources. |
Do not block any ventilation openings. |
Do not place heavy items on the product. |
||
|
|
|
|
User’s Manual is a guidance book for how to use the products. The meaning of the symbols are shown below.
y Reference : In case of providing information for helping of product’s usages
y Notice : If there’s any possibility to occur any damages for the goods and human caused by not following the instruction
ÚPlease read this manual for the safety before using of goods and keep it in the safe place.
6_ overview
This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications. Operation of this equipment in a
residential area is likely to cause harmful interference in which case the user will be required to correct the interference at his own expense.
Samsung Techwin cares for the environment at all product manufacturing stages, and is taking measures to provide customers with more environmentally friendly products.
The Eco mark represents Samsung Techwin’s devotion to creating environmentally friendly products, and indicates that the product satisfies the EU RoHS Directive.
Correct Disposal of This Product (Waste Electrical & Electronic Equipment)
(Applicable in the European Union and other European countries with separate collection systems)
This marking on the product, accessories or literature indicates that the product and its electronic accessories (e.g. charger, headset, USB cable) should not be disposed of with other household waste at the end of their working life. To prevent possible harm to the environment or human health from uncontrolled waste disposal, please separate these items from other types of waste and recycle them responsibly to promote the sustainable reuse of material resources.
Household users should contact either the retailer where they purchased this product, or their local government office, for details of where and how they can take these items for environmentally safe recycling.
Business users should contact their supplier and check the terms and conditions of the purchase contract. This product and its electronic accessories should not be mixed with other commercial wastes for disposal.
Correct disposal of batteries in this product
(Applicable in the European Union and other European countries with separate battery return systems.)
This marking on the battery, manual or packaging indicates that the batteries in this product should not be disposed of with other household waste at the end of their working life. Where marked, the chemical symbols Hg, Cd or Pb indicate that the battery contains mercury, cadmium or lead above the reference levels in EC Directive 2006/66. If batteries are not properly disposed of, these substances can cause harm to human health or the environment.
To protect natural resources and to promote material reuse, please separate batteries from other types of waste and recycle them through your local, free battery return system.
OVERVIEW ●
English _7
overview
CONTENTS
OVERVIEW
3
INSTALLATION &
CONNECTION
14
NETWORK CONNECTION AND SETUP
18
3 Important Safety Instructions
10 Product Features
10Recomended PC Specifications
11What’s Included
12At a Glance
14 |
Installation |
17 |
Connecting with other Device |
18Connecting the Camera Directly to Local Area Networking
19Connecting the Camera Directly to a DHCP Based DSL/Cable Modem
20Connecting the Camera Directly to a PPPoE Modem
21Connecting the Camera to a Broadband Router with the PPPoE/Cable Modem
22Buttons used in IP Installer
23Static IP Setup
26Dynamic IP Setup
27Port Range Forward (Port Mapping) Setup
29Connecting to the Camera from a Shared Local PC
29Connecting to the Camera from a Remote PC via the Internet
8_ overview
WEB VIEWER |
30 |
Connecting to the Camera |
31 |
Login |
|
30 |
32 |
Installing Silverlight Runtime |
34 |
Using the Live Screen |
|
SETUP SCREEN |
36 |
Setup |
36 |
Video Setup |
|
36 |
43 |
Network Setup |
49 |
Event Setup |
|
55 |
System Setup |
|
APPENDIX |
60 |
Specification |
65 |
Product Overview |
|
60 |
66 |
Troubleshooting |
68 |
Open Source Announcement |
|
70 |
GPL/LGPL Software License |
OVERVIEW ●
English _9
overview
PRODUCT FEATURES
yHD Video Quality
yMulti-Streaming
This network camera can display videos in different resolutions and qualities simultaneously using different CODECs.
MHowever, MPEG-4 video can not be played on a web page. Use CMS software if you want to play the video on a web page.
yWeb Browser-based Monitoring
Using the Internet web browser to display the image in a local network environment.
yIntelligent Video Analysis
Analyzes the event video according to the user-specified rules to recognize the event.
yONVIF (Spec 1.01) Compliance
This product supports ONVIF Core Spec. 1.01.
For more information, refer to www.onvif.org.
RECOMENDED PC SPECIFICATIONS
yCPU : Intel(R) Core(TM)2 2.00 GHz or higher
yOperating System : Windows XP, VISTA, 7
Mac OS
yResolution : 1280X1024 pixels or higher
yRAM : 1GB or higher
yWeb Browser : Internet Explorer 6.0 or higher
Firefox, Chrome, Safari
Neither a beta test version unlike the version released in the company website nor the developer version will be supported.
On Firefox v3.5 or higher, displaying warning message dialog may cause an error.
If connecting to IPv6 in Windows XP, it can cause some problem. It is recommended to connect to IPv6 in Windows 7.
y Video Memory : 128MB or higher
10_ overview
WHAT’S INCLUDED
Please check if your camera and accessories are all included in the product package.
Appearance |
Item Name |
Quantity |
Description |
|
User Manual, |
2 |
|
|
Installer S/W DVD, |
|
|
|
CMS S/W DVD |
|
|
|
Quick Guide |
1 |
|
|
Cable for the testing monitor |
1 |
Used to test the camera connection to a |
|
portable display device |
||
|
|
|
|
|
L Wrench |
1 |
Used to remove/fix the dome cover |
|
M4 Tapping Screw |
3 |
Used for securing the camera to the wall or |
|
ceiling |
||
|
|
|
OVERVIEW ●
MThe Test Monitor Cable is connected to a portable displayer and used for testing the camera.
The BNC Out terminal of the product is provided for easier installation, and is not recommended for monitoring purposes.
English _11
overview
AT A GLANCE
Appearance
Item |
Description |
Network Port |
Used to connect a PoE or LAN cable. |
b GND |
Black : Wire for earth-grounding. |
c Power Cable |
Red : Used for connection to the DC 12V adapter. |
Dome Cover |
Dome cover for the lens and unit protection. |
MWipe out a dirty surface of the lens softly with a lens tissue or cloth to which you have applied ethanol.
This model does not support LED indication. Refer to the internal system indicators for operation-related information.
JEnsure that you can find a dehumidifier of Silica gel inside the cover when removing the cover. Otherwise, the product may get moist inside.
If you find that the product gets moist due to a deteriorated dehumidifier of silica gel, contact us at the service center for technical assistance.
12_ overview
Inside
OVERVIEW ●
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Item |
|
|
Description |
|||||||
Fixing Hole |
Used for securing the camera to the wall or ceiling. |
|||||||||
b System Indicator |
ON : When the system operates normally |
|||||||||
OFF : If the system does not operate properly |
||||||||||
|
|
|
||||||||
|
|
|
Resets the camera settings to the default. Press and hold it for about 5 |
|||||||
|
|
|
seconds to turn off the system indicator and restart the system. |
|||||||
c Reset Button |
J If you reset the camera, the network settings will be adjusted so that |
|||||||||
DHCP can be enabled. If there is no DHCP server in the network, you |
||||||||||
|
|
|
must run the IP Installer program to change the basic network settings |
|||||||
|
|
|
such as IP address, Subnet mask, Gateway, etc., before you can |
|||||||
|
|
|
connect to the network. |
|||||||
Lens Cover |
Used for protecting and fixing the lens. |
|||||||||
Video Out Port |
Analog video output port. (for installation) |
|||||||||
English _13
installation & connection
INSTALLATION
Precautions before installation
Ensure you read out the following instructions before installing the camera:
ySelect an installation site (ceiling or wall) that can endure at least 5 times of the camera weight.
yStuck-in or peeled-off cables can cause damage to the product or a fire.
yFor safety purposes, keep anyone else away from the installation site. And put aside personal belongings from the site, just in case.
Disassembling
Using the L-wrench provided, loosen 3 screws by turning them counterclockwise and separate the dome cover.
Note that it is not necessary to loosen the screw completely.
14_ installation & connection
Installing the camera on the ceiling or a wall
1. Select a location where you want to install the camera.
2. Insert the provided screw into the camera hole and turn it clockwise.
Fixing Hole
3. Close the dome cover and turn it clockwise using the L-wrench.
J |
If the cover is not fixed tightly, you may |
|
|
encounter a problem with waterproofing. |
|
|
|
|
|
(IP66) |
|
CONNECTION & INSTALLATION ●
English _15
installation & connection
Adjusting the monitoring direction for the camera
Lens Cover
Adjusting the monitoring direction
You can adjust the camera direction only when the camera is fixed on the ceiling. Then, turning the camera to the left or right is referred to as “Panning”, while tilting the angle is “Tilting”. For panning, the panning limit is 10° for the clockwise, and 10° for the counterclockwise, a total of 20° enabled; further rotation is stopped by the stopper.
-Adjust the panning angle so that the camera settles in the right horizontal position. You can adjust the panning up to 10° in each one direction, and 10° in the other direction, a total of 20°.
-Adjust the tilting angle so that the camera settles in the right vertical position. You can adjust the tilting between 0° and 90°.
Methods of adjustment
1. Loosen the screws on either ends of the lens cover by turning them counter clockwise.
y The case of wall installation
After mounting the camera on the wall, adjust the panning angle so that the camera faces a desired direction when tilting.
Then, adjust the tilting angle so that the camera faces the monitoring direction.
y The case of ceiling installation
After mounting the camera on the ceiling, adjust the panning angle according to the monitoring direction. You should adjust the panning angle lest that the video be displayed upside down on the monitor.
Then, adjust the tilting angle so that the camera faces the monitoring direction.
2.When done, turn the screw clockwise to fix the tilted angle of the lens.
J For smoother Rotate adjustment, set the Tilt position between 60° ~ 80°.
16_ installation & connection
CONNECTING WITH OTHER DEVICE
|
Ethernet |
Monitor Out |
Power |
|
Monitor
Connecting to the monitor
Connect the video out port of the camera to the video input port of the monitor.
MIn the initial installation of the camera, you can connect the camera to the monitor for checking the connection status.
You must set <Video output> to <On> before the display screen can be activated. (page 38)
Connect the monitor test cable to the output port of the monitor.
Ethernet Connection
Connect the Ethernet cable to the local network or to the Internet.
Power Supply
Connect the +, - lines of the DC adaptor to the power terminal of the camera in the right polarity.
J |
Be careful not to reverse the polarity when you connect the power cable. |
|
You can also use a router featuring PoE (Power over Ethernet) to supply power to the camera. |
If PoE and DC 12V are both applied, this camera will get supplied with power from PoE. |
|
|
Please make sure the monitor and camera are turned off when connecting them. |
CONNECTION & INSTALLATION ●
English _17
network connection and setup
You can set up the network settings according to your network configurations.
CONNECTING THE CAMERA DIRECTLY TO LOCAL AREA NETWORKING
Connecting to the camera from a local PC in the LAN
1.Launch an Internet browser on the local PC.
2.Enter the IP address of the camera in the address bar of the browser.
Camera |
|
|
INTERNET |
Camera |
Firewall |
|
External Remote PC |
Local PC |
DDNS Server |
|
(Data Center, KOREA) |
<Local Network> |
|
MA remote PC in an external Internet out of the LAN network may not be able to connect to the camera installed in the intranet if the port-forwarding is not properly set or a firewall is set. In this case, to resolve the problem, contact your network administrator.
By factory default, the IP address will be assigned from the DHCP server automatically. If there is no DHCP server available, the IP address will be set to 192.168.1.100.
To change the IP address, use the IP Installer.
For further details on IP Installer use, refer to “Static IP Setup”. (Page 23)
18_ network connection and setup
CONNECTING THE CAMERA DIRECTLY TO A DHCP BASED DSL/CABLE MODEM
INTERNET
DSL/Cable
Modem
Camera
External Remote PC
DDNS Server
(Data Center, KOREA)
1.Use the cross LAN cable to connect the network cable directly to your PC.
2.Run the IP Installer and change the IP address of the camera so that you can use the web browser on your desktop to connect to the Internet.
3.Use the Internet browser to connect to the camera.
4.Move to [Setup] page.
5.Move to [Network] – [DDNS] and configure the DDNS settings.
6.Move to [Network] – [Interface], and set the network type to [DHCP].
7.Connect the camera, which was removed from your PC, directly to the modem.
8.Restart the camera.
MFor registering the DDNS settings, refer to “Registering with DDNS”. (page 45)
For configuring the DDNS settings, refer to “DDNS”. (page 45)
For setting the network type, refer to “Interface”. (page 43)
SETUP AND CONNECTION NETWORK ●
English _19
network connection and setup
CONNECTING THE CAMERA DIRECTLY TO A PPPoE
MODEM
INTERNET
PPPoE Modem
Camera
External Remote PC
DDNS Server
(Data Center, KOREA)
1.Use the cross LAN cable to connect the network cable directly to your PC.
2.Run the IP Installer and change the IP address of the camera so that you can use the web browser on your desktop to connect to the Internet.
3.Use the Internet browser to connect to the camera.
4.Move to [Setup] page.
5.Move to [Network] – [DDNS] and configure the DDNS settings.
6.Move to [Network] – [Interface], and set the network type to [PPPoE].
7.Connect the camera, which was removed from your PC, directly to the modem.
8.Restart the camera.
MFor registering the DDNS settings, refer to “Registering with DDNS”. (page 45)
For configuring the DDNS settings, refer to “DDNS”. (page 45)
For setting the network type, refer to “Interface”. (page 43)
20_ network connection and setup
CONNECTING THE CAMERA TO A BROADBAND ROUTER WITH THE PPPoE/CABLE MODEM
This is for a small network environment such as homes, SOHO and ordinary shops.
Camera |
|
|
|
|
|
|
INTERNET |
Camera |
Broadband |
PPPoE or |
PPPoE or |
Cable Modem |
Cable Modem |
||
|
Router |
|
External Remote PC |
|
|
|
Local PC
DDNS Server
(Data Center, KOREA)
Configuring the network settings of the local PC connected to a
Broadband Router
Configuring the network settings of the local PC connected to a Broadband Router, follow the instructions below.
ySelect : <Network Neighborhood> <Properties> <Local Area Connection>
<Properties> <General> <Internet Protocol (TCP/IP)> <Properties>
<Obtain an IP address automatically> or <Use the following IP address>.
yFollow the instructions below if you select <Use the following IP address>: ex1) If the address (LAN IP) of the Broadband Router is 192.168.1.1
IP address : 192.168.1.100 Subnet Mask : 255.255.255.0 Default Gateway : 192.168.1.1
ex2) If the address (LAN IP) of the Broadband Router is 192.168.0.1 IP address : 192.168.0.100
Subnet Mask : 255.255.255.0 Default Gateway : 192.168.0.1
ex3) If the address (LAN IP) of the Broadband Router is 192.168.xxx.1 IP address : 192.168.xxx.100
Subnet Mask : 255.255.255.0 Default Gateway : 192.168.xxx.1
MFor the address of the Broadband Router, refer to the product’s documentation.
Refer to the “Port Range Forward (Port Mapping) Setup” section of the Broadband Router’s documentation. (Page 27)
SETUP AND CONNECTION NETWORK ●
English _21
network connection and setup
BUTTONS USED IN IP INSTALLER
Item |
Description |
Device Name |
Model name of the connected camera. |
Click the column to sort the list by model name. |
|
|
However, search will be stopped if clicked during the search. |
b Mode |
Displays either <Static> or <Dynamic> for the current network connection |
status. |
|
c MAC(Ethernet) |
Ethernet address for the connected camera. |
Click the column to sort the list by Ethernet address. |
|
Address |
However, search will be stopped if clicked during the search. |
|
IP address. |
IP Address |
Click the column to sort the list by IP address. |
However, search will be stopped if clicked during the search. |
|
|
The factory default is “192.168.1.100”. |
Protocol |
Network setting for the camera. |
The factory default is “IPv4”. |
|
|
Cameras with the IPv6 setting will be displayed “IPv6”. |
UPnP Status |
This function is not currently implemented. |
22_ network connection and setup
Item |
Description |
URL |
DDNS URL address enabling access from the external Internet. |
However, this will be replaced with the <IP Address> of the camera if |
|
|
DDNS registration has failed. |
IPv4 |
Scans for cameras with the IPv4 setting. |
IPv6 |
Scans for cameras with the IPv6 setting. |
Search |
Scans for cameras that are currently connected to the network. |
However, this button will be grayed out if neither IPv4 nor IPv6 is checked. |
|
Auto Set |
The IP Installer automatically configures the network settings. |
Manual Set |
You should configure the network settings manually. |
m Exit |
Exits the IP Installer program. |
MFor the IP installer, use only the installer version provided in the installation DVD or use the latest one if available. You can download the latest version from the product website.
SETUP AND CONNECTION NETWORK ●
STATIC IP SETUP
Manual Network Setup
Run <IP Installer_vX.XX.exe> to display the camera search list.
At the initial startup, both [Auto Set] and [Manual Set] will be grayed out.
MFor cameras found with the IPv6 setting, these buttons will be grayed out as the cameras do not support this function.
1.Select a camera in the search list. Find the MAC (Ethernet) address labeled on the rear of the camera. Both the [Auto Set] and [Manual Set] buttons will be activated.
2.Click [Manual Set].
The Manual Setting dialog appears. The default values of <IP Address>,
<Subnet Mask>, <Gateway>, <HTTP Port> and <VNP Port> of the camera will be displayed.
English _23
network connection and setup
3.In the <Address> pane, provide the necessary information.
y MAC (Ethernet) Address : The MAC (Ethernet) address of the applicable camera will be set automatically so you don't need to input it manually.
MYou can configure the static IP settings only if the DHCP checkbox is unchecked.
If using a Broadband Router
yIP Address : Enter an address falling in the IP range provided by the Broadband Router.
ex) 192.168.1.2~254, 192.168.0.2~254, 192.168.XXX.2~254
ySubnet Mask : The <Subnet Mask> of the Broadband Router will be the <Sub-
net Mask> of the camera.
yGateway : The <Local IP Address> of
the Broadband Router will be the <Gateway> of the camera.
MThe settings may differ depending on the connected Broadband Router model. For more information, refer to the user manual of the applicable router.
Refer to the “Port Range Forward (Port Mapping) Setup” section of the Broadband Router’s documentation. (Page 27)
If not using a Broadband Router
For setting <IP Address>, <Subnet Mask>, and <Gateway>, contact your network administrator.
4.In the <Port> pane, provide necessary information.
y HTTP Port : Used to access the camera using the Internet browser, defaulted to 80. Use the spin button to change the HTTP Port value.
y VNP Port : Used to control the video signal transfer, defaulted to 4520.
5.Enter the password.
This is the login password for the “admin” user who accesses the camera. The default password is “4321”.
24_ network connection and setup
6.Click [OK].
Manual network setup will be completed.
7.When the manual setup including IP is completed, the camera will restart.
If the Broadband Router has more than one camera connected
Configure the IP related settings and the Port related settings distinctly with each other.
|
Category |
Camera #1 |
Camera #2 |
|
IP related settings |
|
IP Address |
192.168.1.100 |
192.168.1.101 |
|
Subnet Mask |
255.255.255.0 |
255.255.255.0 |
|
|
|
Gateway |
192.168.1.1 |
192.168.1.1 |
Port related settings |
|
HTTP Port |
8080 |
8081 |
|
VNP Port |
4520 |
4521 |
|
MIf the <HTTP Port> is set other than 80, you must provide the <Port> number in the address bar of the Internet browser before you can access the camera.
ex) http://IP address : HTTP Port http://192.168.1.100:8080
Auto Network Setup
Run <IP Installer_vX.XX.exe> to display the camera search list.
At the initial startup, both [Auto Set] and [Manual Set] will be grayed out.
MFor cameras found with the IPv6 setting, these buttons will be grayed out as the cameras do not support this function.
1.Select a camera in the search list.
Find the MAC (Ethernet) address labeled on the rear of the camera.
Both the [Auto Set] and [Manual Set] buttons will be activated.
2.Click [Auto Set].
The Auto Setting dialog appears.
The <IP Address>, <Subnet Mask>, and <Gateway> will be set automatically.
SETUP AND CONNECTION NETWORK ●
English _25
network connection and setup
3.Enter the password.
This is the login password for the “admin” user who accesses the camera. The default password is “4321”.
4.Click [OK].
Auto network setup will be completed.
DYNAMIC IP SETUP
Dynamic IP Environment Setup
yExample of the Dynamic IP environment
-If a Broadband Router, with cameras connected, is assigned an IP address by the DHCP server
-If connecting the camera directly to modem using the DHCP protocols
-If IPs are assigned by the internal DHCP server via the LAN
Checking the Dynamic IP
1.Run the IP Installer on the user’s local machine to display cameras allocated with <Dynamic IP> addresses in the list.
2.Select a camera in the list, and click [Manual Set] to check the <Dynamic
IP> of the camera.
If you uncheck <DHCP>, you can change IP to <Static>.
26_ network connection and setup
PORT RANGE FORWARD (PORT MAPPING) SETUP
If you have installed a Broadband Router with a camera connected, you must set the port range forwarding on the Broadband Router so that a remote PC can access the camera in it.
Manual Port Range Forwarding
1.From the Setup menu of the Broadband Router, select <Applications & Gaming> - <Port Range Forward>. For setting the port range forward for a third-party Broadband Router, refer to the user guide of that Broadband Router.
2.Select <TCP> and <UDP Port> for each connected camera to the Broadband Router.
Each port number for the Broadband Router should match that specified in <Network> - <Port> from the camera's Setup menu.
3.When done, click [Save Settings]. Your settings will be saved.
MAbove sample instructions are based on the CISCO’s Broadband Router (Model: LINKSYS).
The settings may differ depending on the connected Broadband Router model. For more information, refer to the user manual of the applicable router.
SETUP AND CONNECTION NETWORK ●
English _27
network connection and setup
Setting up Port Range Forward for several network cameras
When several network cameras are connected to one Broadband Router device, you should forward the TCP 943 port of the router to the TCP 943 port of a connected camara.
JIf you don't set properly the TCP 943 port of the router, you cannot get any video stream from the web page of the camera.
y TCP 943 port is a port for the Silverlight policy server of a camera.
When Camera1 and Camera2 are connected to a router :
User |
|
Ù Internet |
|
||||
|
|
|
|
|
Ú |
|
|
|
|
|
|
|
|
||
|
|
Broadband Router |
Ù |
||||
Start |
|
End |
|
Protocol |
|
IP Address |
|
943 |
|
943 |
|
TCP |
|
192.168.1.100 |
|
3000 |
|
3000 |
|
TCP/UDP |
|
192.168.1.100 |
|
3001 |
|
3001 |
|
TCP/UDP |
|
192.168.1.101 |
|
4520 |
|
4520 |
|
TCP/UDP |
|
192.168.1.100 |
|
4521 |
|
4521 |
|
TCP/UDP |
|
192.168.1.101 |
Ù |
8080 |
|
8080 |
|
TCP/UDP |
|
192.168.1.100 |
|
8081 |
|
8081 |
|
TCP/UDP |
|
192.168.1.101 |
|
|
|
|
|
||||
Camera1 (192.168.1.100)
Web Server Port |
8080 |
VNP Port |
4520 |
RTSP Port |
3000 |
Policy Server Port |
943 |
|
|
Camera2 (192.168.1.101) |
|
Web Server Port |
8081 |
VNP Port |
4521 |
RTSP Port |
3001 |
Policy Server Port |
943 |
yYou can set a rule of Port Forwarding on the Broadband Router device through its configuration web page.
yYou cannot change the Sliverlight policy server port of a camera. This value is fixed internally.
yYou can change the ports of the camera except the policy server port through its configuration web pages.
28_ network connection and setup
Loading...
