Samsung RT21M6213SG User Manual

Refrigerator

User manual

RT18M*/RT21M*

Free Standing Appliance

Untitled-2 1			2018-06-04 11:32:09

Contents

Contents

Safety information	3
Important safety symbols and precautions:	4
State of California Proposition 65 Warning (US only)	4
Severe warning signs for transportation and site	4
Critical installation warnings	5
Installation cautions	7
Critical usage warnings	7
Usage cautions	10
Cleaning cautions	11
Critical disposal warnings	12
This appliance is intended to be used in household and similar applications such as	12
Additional tips for proper usage	13

Installation	14
Refrigerator at a glance	14
Step-by-step installation	15
Operations	29
Feature panel	29
Special features	34
Maintenance	36
Door reversal (applicable models only)	36
Handle and care	49
Cleaning	51
Replacement	51
Troubleshooting	52
General	52
Do you hear abnormal sounds from the refrigerator?	55
Warranty (USA)	57
WARRANTY ON SAMSUNG REFRIGERATOR	57
Warranty Information (CANADA)	59
If your refrigerator needs service	59
Limited Warranty for Original Purchaser	59
Obligation to the Original Owner	59
Exclusions of the Warranty	59

2  English

Untitled-2 2			2018-06-04 11:32:09

Safety information

	• Before using your new Samsung Refrigerator, please read this manual thoroughly
	to ensure that you know how to operate the features and functions that your new
	appliance offers safely and efficiently.
	• This appliance is not intended for use by persons (including children) with reduced
	physical, sensory or mental capabilities, or lack of experience and knowledge, unless
	they have been given supervision or instruction concerning use of the appliance by a
	person responsible for their safety. Children should be supervised to ensure that they
	do not play with the appliance.
	• This appliance can be used by children aged 8 years and above and persons with
	reduced physical, sensory or mental capabilities or lack of experience and knowledge
	if they have been given supervision or instruction concerning use of the appliance
	in a safe way and understand the hazards involved. Do not let children play with the	Safety
	refrigerator. Do not let children clean the refrigerator or perform user maintenance on
	the refrigerator without supervision.
	• Warnings and Important Safety Instructions in this manual do not cover all possible	information
	of your refrigerator may differ slightly from those described in this manual. Not all
	conditions and situations that may occur.
	It is your responsibility to use common sense, caution, and care when installing,
	maintaining, and operating your appliance.
	• Because the following operating instructions cover various models, the characteristics
	warning signs may be applicable. If you have any questions or concerns, contact your
	nearest Samsung service center or find help and information online at www.samsung.
	com.
	• Refrigerant squirting out of the pipes could ignite or cause an eye injury. When
	refrigerant leaks from the pipe, avoid any naked flames and move anything flammable
	away from the product and ventilate the room immediately.
	- Failing to do so may result in fire or explosion.
	• It is hazardous for anyone other than an Authorised Service Person to service this
	appliance.

Warning; Risk of fire / flammable materials

English  3

Untitled-2 3			2018-06-04 11:32:09

Safety information

information Safety

WARNING

•R-600a is used as a refrigerant. This product contains flammable gas (Refrigerant R-600a), contact your local authority in regard to safe disposal of this product.

•In order to avoid the creation of a flammable gas-air mixture if a leak in the refrigerating circuit occurs, the size of the room in which the appliance may be sited depends on the amount of refrigerant used. The room must be 35.3 ft³ in size for every 8 g of R-600a refrigerant inside the appliance.

•The installation location should not be exposed to direct sunlight and not placed near any electric appliance or heat source, e.g. stove, oven or hob, radiator, etc.

•If you use two products side by side, for safety reason, be sure to use certified products in explosive gas atmospheres.

•Never start up an appliance showing any signs of damage. If in doubt, consult your dealer.

Important safety symbols and precautions:

WARNING

Hazards or unsafe practices that may result in severe personal injury or death.

CAUTION

Hazards or unsafe practices that may result in minor personal injury or property damage.

These warning signs are here to prevent injury to you and others. Please follow them carefully.

After reading this section, keep it in a safe place for future reference.

State of California Proposition 65 Warning (US only)

WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov.

Severe warning signs for transportation and site

WARNING

•When transporting and installing the appliance, care should be taken to ensure that no parts of the refrigerating circuit are damaged.

-Refrigerant leaking from the pipe work could ignite or cause an eye injury. If a leak is detected, avoid any naked flames or potential sources of ignition and air the room in which the appliance is standing for several minutes.

-This appliance contains a small amount of isobutane refrigerant (R-600a), a natural gas with high environmental compatibility that is, however, also flammable. When transporting and installing the appliance, care should be taken to ensure that no parts of the refrigerating circuit are damaged.

4  English

Untitled-2 4			2018-06-04 11:32:09

Critical installation warnings

WARNING

	• Do not install the refrigerator in a damp location or place where it may come in contact
	with water.
	- Deteriorated insulation on electrical parts may cause an electric shock or fire.
	• Do not place this refrigerator in direct sunlight or expose it to the heat from stoves,
	room heaters, or other appliances.
	• Do not plug several appliances into the same multiple power strip. The refrigerator	Safety
	should always be plugged into its own individual electrical outlet which has a voltage
	rating that matches the voltage listed on the refrigerator’s rating plate.
	- This provides the best performance and also prevents overloading of house wiring	information
	either end.
	circuits, which could cause a fire hazard from overheated wires.
	• If the wall socket is loose, do not insert the power plug.
	- There is a risk of electric shock of fire.
	• Do not use a power cord that has cracks or abrasion damage along its length or at
	• Do not bend the power cord excessively or place heavy objects on it.
	• Do not pull or excessively bend the power cord.
	• Do not twist or tie the power cord.
	• Do not hook the power cord over a metal object, place a heavy object on the power
	cord, insert the power cord between objects, or push the power cord into the space
	behind the appliance.
	• When moving the refrigerator, be careful not to roll over or damage the power cord.
	- This may result in an electric shock or fire.
	• Never unplug your refrigerator by pulling on the power cord. Always grip the plug
	firmly and pull straight out from the outlet.
	- Damage to the cord may cause a short-circuit, fire, and/or electric shock.
	• Do not store explosive substances such as aerosol cans with a flammable propellant in
	this appliance.
	• Do not install this appliance near a heater or flammable material.
	• Do not install this appliance in a location where gas may leak.
	- This may result in an electric shock or fire.
	• This refrigerator must be properly located and installed in accordance with the
	instructions in this manual before you use it.
	• Connect the power plug in the proper position with the cord hanging down.
	- If you connect the power plug upside down, the wire can get cut off and cause a fire
	or electric shock.
	• Make sure that the power plug is not crushed or damaged by the back of the
	refrigerator.
	• Keep the packing materials out of reach of children.
	- There is a risk of death from suffocation if a child puts the packing materials on his
	or her head.
	• The appliance must be positioned so that the plug is accessible after installation.
	- Failing to do so may result in an electric shock or fire due to electric leakage.

English  5

Untitled-2 5			2018-06-04 11:32:09

Safety information

		• Do not install this appliance in a humid, oily or dusty location, in a location exposed to
		direct sunlight and water (rain drops).
		- Deteriorated insulation of electrical parts may cause an electric shock or fire.
		• If any dust or water is in the refrigerator, pull out power plug and contact a Samsung
		Electronics service center.
		- Otherwise there is a risk of fire.
		• Do not stand on top of the appliance or place objects (such as laundry, lighted candles,
		lighted cigarettes, dishes, chemicals, metal objects, etc.) on the appliance.
		- This may result in an electric shock, fire, problems with the product, or injury.
		• You need to remove all the protective plastic film before you initially plug the product
	Safety	in.
		for door adjustment or the water tube clips.
		• Children should be supervised to ensure that they do not play with the snap rings used
	information	- There is risk of death by suffocation if a child swallows a snap ring or water tube
		clip. Keep the snap rings and water tube clips out of children’s reach.
		• The refrigerator must be safely grounded.
		- Always make sure that you have grounded the refrigerator before attempting to
		investigate or repair any part of the appliance. Power leakages can cause severe
		electric shock.
		• Never use gas pipes, telephone lines, or other potential lightning attractors as an
		electrical ground.
		- You must ground the refrigerator to prevent any power leakages or electric shocks
		caused by current leakage from the refrigerator.
		- Grounding the refrigerator improperly may result in an electric shock, fire, explosion,
		or problems with the product.
		- Improper use of the grounding plug can result in a risk of electric shock. If it is
		necessary to use an extension cord, use only a 3-wire extension cord that has a
		3-blade grounding plug and a 3-slot receptacle that will accept the plug on the
		appliance. The marked rating of the extension cord should be AC 115-120 V, 10 A, or
		more. If a grounding adapter is used, make sure the receptacle box is fully grounded.
		• Plug the power plug into the wall socket firmly. Do not use a damaged power plug,
		damaged power cord, or loose wall socket.
		- This may result in an electric shock or fire.
		• If the power cord is damaged, have it replaced immediately by the manufacturer or one
		of its service agents.
		• The fuse on the refrigerator must be changed by a qualified technician or service
		company.
		- Failing to do so may result in an electric shock or personal injury.
		• The wall socket must be easily accessible so that the appliance can be quickly
		disconnected from the wall socket in an emergency.
		• It must be outside the area of the rear of the appliance.
		• When positioning the appliance, ensure the power cord is not trapped or damaged.
		• Do not locate multiple portable socket-outlets or portable power supplies at the rear of
		the appliance.

6  English

Untitled-2 6			2018-06-04 11:32:10

Installation cautions

CAUTION

•Allow sufficient space around the refrigerator and install it on a flat surface.

-Keep the ventilation space in the appliance enclosure or mounting structure clear of obstructions.

•After the refrigerator has been installed and turned on, let it stand for 2 hours before loading it with food.

•It is strongly recommended you have a qualified technician or service company install the refrigerator.

-Failing to do so may result in an electric shock, fire, explosion, problems with the product, or injury.

•Overloading the refrigerator door may cause the refrigerator to fall, causing physical injury.

Critical usage warnings

WARNING

•Do not insert the power plug into a wall socket with wet hands.

-This may result in an electric shock.

•Do not store articles on the top of the appliance.

-When you open or close the door, the articles may fall and cause personal injury and/or material damage.

•Do not insert hands, feet, or metal objects (such as chopsticks, etc.) into the bottom or into the back of the refrigerator.

-This may result in an electric shock or injury.

-Any sharp edges may cause a personal injury.

•Do not touch the inside walls of the freezer or products stored in the freezer with wet hands.

-This may cause frostbite.

•Do not put a container filled with water on the refrigerator.

-If spilled, there is a risk of fire or electric shock.

•Do not keep volatile or flammable objects or substances (benzene, thinner, propane gas, alcohol, ether, LP gas, and other such products) in the refrigerator.

-This refrigerator is for storing food only.

-This may result in fire or explosion.

•Children should be supervised to ensure that they do not play with the appliance.

-Keep fingers out of “pinch point” areas. Clearances between the doors and cabinet are necessarily small. Be careful when you open the doors if children are in the area.

•Do not let children hang on the door or door bins. A serious injury may occur.

•Do not let children go inside the refrigerator. They could become trapped.

•Do not store pharmaceutical products, scientific materials, or temperature sensitive products in the refrigerator.

-Products that require strict temperature controls must not be stored in the refrigerator.

English  7

information Safety

Untitled-2 7			2018-06-04 11:32:10

Safety information

		• Do not place or use electrical appliances inside the refrigerator/freezer, unless they are
		of a type recommended by the manufacturer.
		• If you smell a burning smell or smoke, pull out power plug immediately and contact a
		Samsung Electronics service center.
		• If any dust or water is in Refrigerator, pull out power plug and contact your nearest
		Samsung Electronics service center.
		- Otherwise there is a risk of fire.
		• Do not let children step on a drawer.
		- The drawer may break and cause them to slip.
		• Do not leave the doors of the refrigerator open while the refrigerator is unattended and
	Safety	do not let children enter inside the refrigerator.
		- It can cause death from suffocation by entrapment or personal injury.
		• Do not allow babies or children go inside a drawer.
	information	• Do not overfill the refrigerator with food.
		- When you open the door, an item may fall out and cause personal injury or material
		damage.
		• Do not spray volatile material such as insecticide onto the surface of the appliance.
		- As well as being harmful to humans, it may also result in an electric shock, fire, or
		problems with the product.
		• Do not use or place any substances sensitive to temperature such as flammable sprays,
		flammable objects, dry ice, medicine, or chemicals near or inside of the refrigerator.
		• Do not use a hair dryer to dry the inside of the refrigerator. Do not place a lighted
		candle in the refrigerator for removing bad odours.
		- This may result in an electric shock or fire.
		• Fill the water tank, ice tray and water cubes with potable water only (tap water, mineral
		water, or purified water).
		- Do not fill the tank with tea, juice or sports drinks. This may damage the refrigerator.
		• Do not stand on top of the appliance or place objects (such as laundry, lighted candles,
		lighted cigarettes, dishes, chemicals, metal objects, etc.) on the appliance. This may
		result in an electric shock, fire, problems with the product, or injury. Do not put a
		container filled with water on the appliance.
		- If spilled, there is a risk of fire or electric shock.
		• Do not use mechanical devices or any other means to accelerate the defrosting process,
		other than those recommended by the manufacturer.
		• Do not damage the refrigerant circuit.
		• Never stare directly at the UV LED lamp for long periods of time.
		- This may result in eye strain due to the ultraviolet rays.
		• Do not put fridge shelves in upside down. The shelf stopper, which prevents the shelf
		from falling, will not work.
		- The shelf could fall and cause a personal injury.
		• Keep fingers out of “pinch point” areas. Clearances between the doors and cabinet are
		necessarily small. Be careful when you open the doors if children are in the area.
		• If a gas leak is detected, avoid any naked flames or potential sources of ignition, and air
		the room in which the appliance is standing for several minutes.
		- Do not touch the appliance or power cord.
		- Do not use a ventilating fan.
		- A spark may result in explosion or fire.
		• Use only the LED Lamps provided by the manufacturer or its service agents.
	8	English

Untitled-2 8			2018-06-04 11:32:10

	• Bottles should be stored tightly together so that they do not fall out.
	• This product is intended only for the storage of food in a domestic environment.
	• Do not attempt to repair, disassemble, or modify the refrigerator yourself.
	- Unauthorized modifications can cause safety problems. To reverse an unauthorized
	modification, we will charge the full cost of parts and labor.
	• Do not use any fuse (such as cooper, steel wire, etc.) other than a standard fuse.
	• If your refrigerator needs to be repaired or reinstalled, contact your nearest Samsung
	service center.
	- Failing to do so may result in an electric shock, fire, problems with the product, or
	injury.
	• If the interior or exterior LED lamp has gone out, contact your nearest Samsung service	Safety
	center.
	• If the refrigerator emits a burning smell or smoke, unplug the refrigerator immediately
	and contact your Samsung Electronics service center.	information
	- Failing to do so may result in an electric or fire hazard.
	• Pull the power plug out of the socket before changing the interior lamps of the
	refrigerator.
	- Otherwise, there is a risk of electric shock.
	• If you experience difficulty changing a non-LED light, contact a Samsung service center.
	• If the product is equipped with LED lamps, do not disassemble the Lamp Covers and
	LED lamps yourself.
	- Contact a Samsung service center.
	• Plug the power plug into the wall socket firmly.
	• Do not use a damaged power plug, damaged power cord or loose wall socket.
	- This may result in an electric shock or fire.

English  9

Untitled-2 9			2018-06-04 11:32:10

Safety information

Usage cautions

CAUTION

		• Do not re-freeze frozen foods that have thawed completely. Do not place carbonated or
		fizzy drinks in the freezer compartment. Do not put bottles or glass containers in the
		freezer.
		- When the contents freeze, the glass may break and cause personal injury.
		• Use only the ice maker provided with the refrigerator.
	Safety	• To get the best performance from the product:
		- Do not place food too close to the vents at the rear of the refrigerator as this can
		obstruct free air circulation in the refrigerator compartment.
	information	- Wrap food up properly or place it in airtight containers before putting it into the
		• Do not place carbonated or fizzy drinks in the freezer compartment. Do not put bottles
		refrigerator.
		- Do not place glass bottles or carbonated beverages into the freezer. They can freeze
		and break. Broken beverage containers can cause injury.
		- Please observe maximum storage times and expiration dates of frozen goods.
		or glass containers in the freezer compartment.
		- When the contents freeze, the glass may break and cause personal injury and
		property damage.
		• Service Warranty and Modification.
		- Any changes or modifications performed by a 3rd party on this finished appliance
		are not covered under Samsung warranty service, nor is Samsung responsible for
		safety issues that result from 3rd party modifications.
		• Do not block the air vents inside the refrigerator.
		- If the air vents are blocked, especially with a plastic bag, the refrigerator can be over
		cooled. If a cooling period lasts too long, the water filter may break and cause water
		leakage.
		• Wipe excess moisture from the inside and leave the doors open.
		- Otherwise, odor and mold may develop.
		• If the refrigerator is disconnected from the power supply, you should wait for at least
		five minutes before plugging it back in.
		• If the refrigerator is flooded by water, there is a risk of electric shock or fire. Pull out
		the power plug, and then contact a Samsung Electronics service center as soon as
		possible.
		• Do not strike or apply excessive force to any glass surface.
		- Broken glass may result in a personal injury and/or property damage.
		• Fill the water tank and ice cube trays with potable water only (tap water, mineral water,
		or purified water).
		- Do not fill the tank with tea or a sports drink. This may damage the refrigerator.

10  English

Untitled-2 10			2018-06-04 11:32:10

•Be careful that your fingers do not get caught in the door or the space between the door and the door hinge.

	• The lamps in the freezer and refrigerator may turn off if the doors of the freezer and	Safety
	refrigerator are left open for 2 seconds or longer.	information
	- The lamps will turn back on when the doors are closed and opened again.
	• Do not keep vegetable oil in your refrigerator’s door bins. The oil can solidify, making it
	foul-tasting and difficult to use. In addition, the open container can leak and the leaked
	oil can cause the door bin to crack. After opening an oil container, it is best to keep the
	container in a cool and shaded place such as a cupboard or pantry.
	- Examples of vegetable oil: olive oil, corn oil, grape-seed oil, etc.

Cleaning cautions

CAUTION

•Do not spray water directly on the inside or outside the refrigerator.

-There is a risk of fire or electric shock.

•Do not use a hair dryer to dry the inside of the refrigerator.

•Do not place a lighted candle in the refrigerator to remove bad odors.

-This may result in an electric shock or fire.

•Do not spray cleaning products directly on the display.

-Printed letters on the display may come off.

•If any foreign substance such as water has entered the appliance, unplug the power plug and contact your nearest Samsung service center.

-Failing to do so may result in an electric shock or fire.

•Use a clean, dry cloth to remove any foreign matter or dust from the power plug blades. Do not use a wet or damp cloth when cleaning the plug.

-Otherwise, there is a risk of fire or electric shock.

•Do not clean the appliance by spraying water directly onto it.

•Do not use benzene, thinner, or Clorox, Chloride for cleaning.

-They may damage the surface of the appliance and may cause a fire.

•Never put fingers or other objects into the dispenser hole.

-It may cause a personal injury or material damage.

•Before cleaning or performing maintenance, unplug the appliance from the wall socket.

-Failing to do so may result in an electric shock or fire.

•Use a clean sponge or soft cloth and a mild detergent in warm water to clean the refrigerator.

English  11

Untitled-2 11

2018-06-04 11:32:10

information Safety

Safety information

•Do not use abrasive or harsh cleansers such as window sprays, scouring cleansers, flammable fluids, muriatic acid, cleaning waxes, concentrated detergents, bleaches, or cleansers containing petroleum products on exterior surfaces (doors and cabinet), plastic parts, door and interior liners, and gaskets.

- These can scratch or damage the material.

•Do not clean glass shelves or covers with warm water when they are cold. Glass shelves and covers may break if exposed to sudden temperature changes or impacts such as bumping or dropping.

Critical disposal warnings

WARNING

•DANGER: Risk of child entrapment. Before you throw away your old refrigerator or freezer:

-Take off the doors and door latch.

-Leave the shelves in place so that children cannot easily climb inside.

-Children trapped inside a refrigerator can hurt themselves or suffocate to death.

•Please dispose of the packaging material from this product in an environmentally friendly manner.

•Ensure that none of the pipes on the back of the refrigerator are damaged prior to disposal.

•R-600a is used as a refrigerant. This product contains flammable gas (Refrigerant R-600a), contact your local authority in regard to safe disposal of this product.

•When disposing of this refrigerator, remove the door/door seals and door latch so that small children or animals cannot become trapped inside. Children should be supervised to ensure that they do not play with the appliance. If trapped inside, a child may get hurt or suffocate to death.

-If trapped inside, the child may get hurt or suffocate to death.

•Cyclopentane is used in the insulation. The gases in the insulation material require a special disposal procedure. Please contact your local authorities in regard to the environmentally safe disposal of this product.

•Keep all packaging materials well out of the reach of children, as packaging materials can be dangerous to children.

-If a child places a bag over his or her head, the child could suffocate.

This appliance is intended to be used in household and similar applications such as

•staff kitchen areas in shops, offices and other working environments;

•farm houses and by clients in hotels, motels and other residential type environments;

•bed and breakfast type environments;

•catering and similar non-retail applications.

12  English

Untitled-2 12			2018-06-04 11:32:10

Additional tips for proper usage

	• In the event of a power failure, call the local office of your electric company and ask
	how long the failure is going to last.
	- Most power failures that are corrected in an hour or two will not affect your
	refrigerator temperatures. However, you should minimize the number of door
	openings while the power is off.
	- Should the power failure last more than 24 hours, remove and discard all frozen
	food.
	• The refrigerator might not operate consistently (frozen contents can thaw or
	temperatures can become too warm in the frozen food compartment) if sited for an	Safety
	below the temperatures for which the appliance is designed.
	extended period of time in a location where ambient air temperatures are constantly
	• Some foods (bananas, etc.) should not be refrigerated. Refrigeration can cause these	information
	foods to deteriorate.
	• Your appliance is frost free, which means there is no need to manually defrost your
	appliance. This will be carried out automatically.
	• Temperature rise during defrosting complies with ISO requirements. If you want to
	prevent an undue rise in the temperature of frozen food while the appliance defrosts,
	wrap the frozen food in several layers of newspaper.
	• Do not re-freeze frozen foods that have thawed completely.

English  13

Untitled-2 13			2018-06-04 11:32:10

Installation

Follow these instructions carefully to ensure the proper installation of this refrigerator and to prevent accidents before using it.

WARNING

•Use the refrigerator only for its intended purpose as described in this manual.

•Any servicing must be performed by a qualified technician.

•Dispose of the product packaging material in compliance with the local regulations.

Refrigerator at a glance

NOTE

The illustrations of the refrigerator and its component parts shown in this manual may differ from your actual refrigerator and its component parts, depending on the model and your country.

			01 Control Panel
			02 Auto Ice Maker (Optional)
Installation	01		03 Twist Ice Maker (Type A) *
	04		07 Refrigerator shelves
	02	10	04 Freezer shelf
	03		06 Guard container
	05		08 Vegetable shelf
			09 Vegetable Drawer
	06		10 Freezer Guard
	07		11 Refrigerator guard
		11	* applicable models only
	08
	09

14  English

Untitled-2 14			2018-06-04 11:32:10

Step-by-step installation

STEP  1  Select a site

Select a site that:

•Has a solid, level surface without carpeting or flooring that may obstruct ventilation

•Is away from direct sunlight

•Has adequate room for opening and closing the door

•Is away from any heat sources

•Provides room for maintenance and servicing

•Has a temperature range between 50 °F (10 °C) and 109 °F (43 °C)

Installation

English  15

Untitled-2 15			2018-06-04 11:32:10

Installation

Clearance

See the pictures and table below for space requirements for installation.

B

A

D

C

Installation

01

03

03

05

02

04

16  English

	Model	RT18*	RT21*
	Depth "A"	31 7/8”	31 7/8”
		(810 mm)	(810 mm)
	Width “B”	28 3/4”	32 7/8”
		(729 mm)	(836 mm)
	Height “C”	65 3/4”	66 3/4”
		(1669 mm)	(1694 mm)
	Overall Height	66 3/4”	67 3/4”
	“D”	(1697 mm)	(1722 mm)

	Model	RT18*	RT21*
	01	more than 2” (50 mm)
		recommended
	02	121°	121°
	03	at least 2”	at least 2”
		(50 mm)	(50 mm)
	04	44”	50 2/5”
		(1117 mm)	(1280 mm)
	05	57 7/8”	59 7/8”
		(1470 mm)	(1521 mm)

Untitled-2 16			2018-06-04 11:32:11

STEP  2  Flooring

•The surface you install the refrigerator on must support a fully loaded refrigerator. (Approximately 200 lb or

90 kg.)

•To protect the floor, put a large piece of cardboard along the path to the refrigerator's final installation location.

•Once the refrigerator is in its final

position, do not move it unless necessary to protect the floor. If you have to move the refrigerator, place thick paper or cloth such as old carpets along the path of movement.

Installation

English  17

Untitled-2 17			2018-06-04 11:32:11

Installation

STEP  3  Adjust the leveling legs

A

C B

Installation

A

18  English

The refrigerator comes with 3 leveling legs, 1 on the door and 2 on the unit. Level the refrigerator by manually adjusting

the leveling leg (A) on the door and the leveling leg (C) on the opposite side of the unit. The other leveling leg (B) on the unit is for stability purposes.

Turn the leveling legs clockwise to lower the position, or turn counter clockwise to raise.

CAUTION

•In all cases including door reversal, to prevent the refrigerator from tipping, make sure the leveling leg (A) on the door is on the floor and fully supporting the weight of the door.

•Using only 2 legs on the unit can cause the refrigerator to tip over.

Leave the legs at least (A) mm from the floor as shown.

•(A) 39 mm for RT18*

•(A) 43 mm for RT21*

Untitled-2 18			2018-06-04 11:32:11

STEP  4  Connect the water line (optional)

Connect the water line to the ice maker. For the ice maker to operate properly, a water pressure of 20-125 psi is required. After you have connected the water line, make sure the water storage tank inside the refrigerator is properly filled.

CAUTION

Do not reuse an old hose set. Use the new hose sets supplied with your refrigerator only.

•The water line installation is not covered by the Warranty of this product. Read carefully through these instructions to protect your property and prevent possible damage.

•Banging pipes (water banging in the pipes) can cause damage to the refrigerator, and lead to water leakage or flooding. If you encounter this problem, contact a plumber for professional assistance.

•To prevent burns and product damage, do not connect the water line to a hot water source.

•Do not install the water line in areas where temperatures fall below the freezing point.

•When using any electrical device (such as a motorized drill) during installation, be sure the device is insulated and properly grounded to prevent electric shock.

•All installations must be in accordance with local plumbing code requirements.

•The water filter must be replaced as instructed by the manufacturer or the retailer.

•To purchase additional water filters, contact the manufacturer or the retailer of the filter.

NOTE

•You can purchase the water line installation kit from your retailer. We recommend using a kit that contains copper tubing and a 6 mm (1/4”) compression nut.

•In an area with low water pressure (below 20 psi), you can install a booster pump to compensate for the low pressure.

English  19

Installation

Untitled-2 19			2018-06-04 11:32:11

Installation

Installation

To assemble the water line installation kit

1. Shut off the main water source.

2. Insert the pipe clamp (B) and the shutoff valve (C) into the cold water line (A).

C

3. Connect the water line installation kit

(A) to the shut-off valve (B).

A

B

To connect the water line to the refrigerator

WARNING

Make sure to connect the water line only to a potable water source.

There are several items you must purchase to complete this connection. You may find these items sold as a kit at your local hardware store.

	•	1/4” copper tubing
Copper Tubing	•	1/4” compression nut (1 pc)
	•	Ferrule (2 pc)
Plastic Tubing	•	1/4” plastic tubing  Molded end (Bulb)

20  English

Untitled-2 20			2018-06-04 11:32:12

A.Refrigerator

B.Household water supply line

			01 Compression nut (1/4”)
			02 Ferrule (Not supplied)
		A	03 Copper tubing (Not supplied)
		04	04 Plastic tubing (Assembled)
	01		05 Compression fitting
		05	06 Molded end (Bulb)
			07 Compression nut (B) (1/4”) (Not
	02	06	supplied)
			08 Plastic tubing (A) (Not supplied)
		07	NOTE
			RT**M6215* models ship with parts 01 and
	03	08
		B	05 while RT**M6213* models are available
			with the optional Auto Ice Maker Kit.
			Installation

1. Connect the household water line to the assembled compression fitting.

- If you are using copper tubing, slip the compression nut (B) (not supplied) and ferrule (not supplied) on the copper tubing (not supplied) as shown.

- If you are using plastic tubing (A), insert the molded end (Bulb) of the plastic tubing

(A) into the compression fitting.

CAUTION

If you use plastic tubing, (A) do not use it without the molded end (Bulb).

2.Tighten the compression nut (B) onto the compression fitting. Do not over-tighten the compression nut (B).

3.Turn the water on and check for any leakage. If you find water drops or leakage in the connection areas, turn off the main water supply. Check the connections and, if necessary, tighten.

4.After you turn on the refrigerator, let the ice maker makes ice for 1 to 2 days. Over that period of time, throw out the first 1 or 2 buckets of ice the ice maker makes to ensure all impurities have been removed from the water line.

NOTE

•If you have to repair or disassemble the water line, cut off 1/4“ of the plastic tubing to make sure you get a snug, leak-free connection.

•Leaving the water line disconnected may cause the water valve to produce a buzzing sound over time.

•If water is not supplied to the refrigerator, make sure to turn the ice maker off.

English  21

Untitled-2 21			2018-06-04 11:32:12

Installation

Installation

Installing a Water Filter (optional)

The water filter and the water filter installation kit containing necessary parts illustrated in this section are not provided. You must purchase the water filter and the water filter installation kit at a local hardware store.

To connect to the water supply line

				01 Cold water line
		01		02 Pipe clamp
				03 Plastic line
07		02	03	04 Compression nut
				05 Compression sleeve
				06 Packing nut
06	05	04		07 Shut off valve

	08 Filter cartridge
	09 Cartridge holder
09	10 Cut vertically by 90 degrees

08

10

1.Shut off the main water line and turn the ice maker off.

2.Locate the nearest cold potable water line.

3.Follow the instructions mentioned in the water filter installation kit.

4.After connecting the water line to the inlet of the cartridge holder with the plastic line fully inserted, insert and tighten the filter cartridge.

5.Turn on the water line and flush 11 liters of water (approximately 6 minutes) through the filter before use.

CAUTION

• The water line must be connected outside of the refrigerator.

• Do not use copper lines.

• If cutting the tubing for resizing, make sure the ends of the tubing are vertically clean cut.

22  English

Untitled-2 22			2018-06-04 11:32:12

To connect the water line to the refrigerator

01 Cartridge holder

02 Plastic clip

03 Plastic line

04 Filter cartridge

01

02

03

04

1.Connect the plastic line from the rear of the refrigerator to the outlet of the cartridge holder until the plastic line is fully inserted.

2.Clamp both ends of the cartridge holder using the plastic clips.

3.Turn the water line on and check for leaks.

CAUTION

•Use only potable water.

•The filter cartridge is not provided. You must purchase it at a local hardware store.

•When moving the refrigerator for line connection, use caution so that you don't step on the power cord or water line (for the ice maker).

English  23

Installation

Untitled-2 23			2018-06-04 11:32:12

Installation

STEP  5  Unpack and put accessories in place

The accessories that ship with this refrigerator are properly packed for transportation and safety reasons. Unpack those accessories and put them in place.

Door guards

There are four door guards provided with the product. Insert two door guards each to the freezer and the fridge.

Installation

24  English

Untitled-2 24			2018-06-04 11:32:13

STEP  6  Install the Auto Ice Maker (optional)

To purchase a new auto ice maker (part type : RA-TIMO63PP/AA), visit the Samsung website (www.samsung.com) or contact your retailer.

Ice maker kit

Ice maker

Ice bucket

Tools required (not provided)

Installation

Phillips screwdriver

English  25

Untitled-2 25			2018-06-04 11:32:13

Installation

Installation

To install the ice maker kit

WARNING

To prevent electrical shock, make sure the refrigerator is turned off before installation.

1. See the figure on the left, and then locate the cover on the inner upper corner of the main unit.

2. Remove the screws (x2) from the cover, and then remove the cover by pulling it to the front.

3. Connect the wire connector of the ice maker to the socket (marked in the figure) on the main unit. Make sure the connector is fully inserted to prevent system failure.

4. Insert the ice maker into the front side of the 2 grommets as shown. Then, push the ice maker inwards to the end. To prevent deviation of the ice maker, make sure the ice maker fits into position.

26  English

Untitled-2 26			2018-06-04 11:32:14

5. Tighten the provided screws (x2) to attach the ice maker firmly to the refrigerator.

-Make sure the screw holes are aligned with each other before tightening the screws.

6.Put the ice bucket on the shelf as shown.

ABy design, the ice bucket is supposed to sit behind the ice maker. Otherwise, the ice cubes from the ice maker will not collect in the bucket as intended.

7.When installation is complete, turn the refrigerator on, and then press Test Switch (A) on the ice maker to check if the ice maker operates and supplies water for the ice tray normally.

Installation

CAUTION

•If you don’t intend to use the ice maker, or if you are going for a business trip or vacation, turn off the ice maker.

•Do not turn the ice maker on without the ice bucket in place. The ice cubes produced by the ice maker will drop into and scatter through out the freezer.

•Noises may occur when the ice maker is making ice or being supplied with water, or when ice cubes drop into the ice bucket. However, this is not a system failure. When the ice bucket is full, none of these noises will occur.

•The first time you use the ice maker, or after you have replaced the water filter, the ice made by the ice maker may have a carbon residue. If this happens, discard the first full load of ice. Note that the carbon residue is harmless to humans.

English  27

Untitled-2 27			2018-06-04 11:32:14

Installation

STEP  7  Initial settings

By completing the following steps, the refrigerator should be fully functioning.

1.Plug the power cord into the wall socket to turn the refrigerator on.

2.Open the door, and check if the interior light lights up.

3.Set the temperature to the coldest setting, and wait for about an hour. Then, the freezer should be slightly chilled, and the motor should be running smoothly.

4.Wait until the refrigerator reaches the set temperature. The refrigerator is now ready for use.

STEP  8  Final check

		When installation is complete, confirm that:
		• The refrigerator is plugged into an electrical outlet and grounded properly.
		• The refrigerator is installed on a flat, level surface with a reasonable clearance from the
		wall or the cabinet.
		• The refrigerator is level and is sitting firmly on the floor.
	Installation	• The door opens and closes freely, and the interior light turns on automatically when you
		open the door.

28  English

Untitled-2 28			2018-06-04 11:32:14

Operations

Feature panel

Type A

02

03

01 05 04 05

Type B

02 03

01 05

04 05

01 Power Freeze /	02 Freezer / Freezer Convert
Ice Maker (applicable models only)
03 Fridge / Fridge On/Off	04 Power Cool
05 Sabbath mode

Operations

English  29

Untitled-2 29			2018-06-04 11:32:15

Operations

Operations

01  Power Freeze / Ice Maker (applicable models only)

Power Freeze speeds up the freezing process at maximum fan speed. The freezer keeps running at full speed for several hours and then returns to the previous temperature.

	• To activate Power Freeze, press and hold Power Freeze for 3
	seconds (Type A), or press and release Power Freeze within 3
	seconds (Type B). The corresponding indicator ( ) lights up, and
	the refrigerator will speed up the freezing process for you.
	• For Type B, do not hold down Power Freeze for 3 seconds or more.
	This will activate the ice maker, not Power Freeze.
Power Freeze	• To deactivate, press and hold Power Freeze for 3 seconds (Type A),
	or press and release Power Freeze within 3 seconds (Type B). The
	freezer returns to the previous temperature setting.

•To freeze large amounts of food, activate Power Freeze for at least 20 hours before putting food in the freezer.

•The freezer keeps running at full speed for 50 hours and then returns to the previous temperature.

		NOTE
		Using Power Freeze increases power consumption. Make sure you
		turn it off and have the Freezer return to its previous temperature if
		you no longer need Power Freeze on.
		By default, the refrigerator is set to make ice with the ice maker
		indicator on.
		To disable this function, press and hold Ice Maker for 3 seconds.
	Ice Maker	We recommend disabling the function in the following cases:
		• The ice bucket is already full of ice.
	(applicable
		• You want to decrease power consumption.
	models only)	• When removing the ice maker while it is operating, the ice maker
		automatically turns off, and the ice maker button (holding down
		Power Freeze) will be disabled.
		• If reattaching the removed ice maker while the refrigerator is on,
		the ice maker automatically turns on.

02  Freezer / Freezer Convert (3 sec)

The Freezer button can be used to set the freezer temperature.

		CAUTION
	Freezer	• To prevent system failure or food spoiling, do not set the
		temperature to Colder in summer (when temperatures are above
		95 °F (35 °C)).

•Do not store glass bottles containing liquid in the freezer. Glass bottles will crack or break into pieces when the liquid freezes.

30  English

Untitled-2 30			2018-06-04 11:32:15
