ProSoft Technology RLX-IFH24S-A User Manual

RLX-IFHS

RadioLinx Industrial Wireless

RadioLinx® Industrial Frequency
Hopping Serial Radios

November 19, 2013

USER MANUAL

Your Feedback Please

We always want you to feel that you made the right decision to use our products. If you have suggestions, comments,
compliments or complaints about our products, documentation, or support, please write or call us.

How to Contact Us

ProSoft Technology

5201 Truxtun Ave., 3rd Floor
Bakersfield, CA 93309
[phone]
[phone] (Fax)
www.prosoft-technology.com
[e-mail]

Copyright © 2013 ProSoft Technology, Inc., all rights reserved.

RLX-IFHS User Manual
November 19, 2013

ProSoft Technology ®, ProLinx ®, inRAx ®, ProTalk ®, and RadioLinx ® are Registered Trademarks of ProSoft
Technology, Inc. All other brand or product names are or may be trademarks of, and are used to identify products
and services of, their respective owners.

ProSoft Technology® Product Documentation

In an effort to conserve paper, ProSoft Technology no longer includes printed manuals with our product shipments.
User Manuals, Datasheets, Sample Ladder Files, and Configuration Files are provided on the enclosed CD-ROM,
and are available at no charge from our web site: www.prosoft-technology.com

Part Number

Max Gain

Part Number

Max Gain

Part Number

Max Gain

A902S-OA

2 dBi

A2424NJ-DB

24 dBi

A2410NJ-DY

10 dBi

A907NJ-OC

7 dBi

A082503-80-OBH

3 dBi

A2415NJ-DY

15 dBi

A908NJ-DY

8 dBi

A911NJ-DY

11 dBi

A2402S-OS

2 dBi

A2402S-OSLP

2 dBi

A2403NBH-OC

3 dBi

A2404NBHW-OC

4 dBi

A2404NJ-OC

4 dBi

A2405S-OA

5 dBi

A2405S-OM

5 dBi

A2505S-OS

5 dBi

A2406NJ-OC

6 dBi

A2406NJ-OCD

6 dBi

A2408NJ-OC

8 dBi

A2409NJ-OCD

9 dBi

A2415NJ-OC

15 dBi

A902NJ-OC

2 dBi

A902S-OA

2 dBi

A903NBH-OC

3 dBi

A903S-OM

3 dBi

A905NJ-OC

5 dBi

A907NJ-OC

7 dBi

A2408NJ-DP

8 dBi

A2413NJ-DP

13 dBi

A2416NJ-DP

16 dBi

A2419NJ-DP

19 dBi

A912NJ-DP

12 dBi

A2419NJ-DB

19 dBi

Important Safety Information

The following Information and warnings pertaining to the radio module must be heeded:

WARNING – EXPLOSION HAZARD – DO NOT REPLACE ANTENNAS UNLESS POWER HAS BEEN SWITCHED
OFF OR THE AREA IS KNOWN TO BE NON-HAZARDOUS.

"THIS DEVICE CONTAINS A TRANSMITTER MODULE, FCC ID: . PLEASE SEE FCC ID LABEL ON BACK OF
DEVICE."

"THIS DEVICE USES AN INTERNAL COMPACT FLASH RADIO MODULE AS THE PRIMARY RADIO
COMPONENT. THE COMPACT FLASH RADIO MODULE DOES NOT HAVE AN FCC ID LABEL. THE COMPACT
FLASH RADIO MODULE HAS NO USER SERVICEABLE PARTS."

"THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES. OPERATION IS SUBJECT TO THE FOLLOWING
TWO CONDITIONS: (1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE, AND (2) THIS DEVICE
MUST ACCEPT ANY INTERFERENCE RECEIVED, INCLUDING INTERFERENCE THAT MAY CAUSE
UNDESIRED OPERATION."

"CHANGES OR MODIFICATIONS NOT EXPRESSLY APPROVED BY THE PARTY RESPONSIBLE FOR
COMPLIANCE COULD VOID THE USER’s AUTHORITY TO OPERATE THE EQUIPMENT."

Industry Canada Requirements:
"THIS DEVICE HAS BEEN DESIGNED TO OPERATE WITH AN ANTENNA HAVING A MAXIMUM GAIN OF 24 dB.

AN ANTENNA HAVING A HIGHER GAIN IS STRICTLY PROHIBITED PER REGULATIONS OF INDUSTRY
CANADA. THE REQUIRED ANTENNA IMPEDANCE IS 50 OHMS."

"TO REDUCE POTENTIAL RADIO INTERFERENCE TO OTHER USERS, THE ANTENNA TYPE AND ITS GAIN
SHOULD BE CHOSEN SUCH THAT THE EQUIVALENT ISOTROPICALLY RADIATED POWER (EIRP) IS NOT
MORE THAN THAT REQUIRED FOR SUCCESSFUL COMMUNICATION."

"THE INSTALLER OF THIS RADIO EQUIPMENT MUST INSURE THAT THE ANTENNA IS LOCATED OR
POINTED SUCH THAT IT DOES NOT EMIT RF FIELD IN EXCESS OF HEALTH CANADA LIMITS FOR THE
GENERAL POPULATION; CONSULT SAFETY CODE 6, OBTAINABLE FROM HEALTH CANADA."

Recommended Antennas

An adapter may be needed for some of the listed antennas to operate with the specified radio.

Antenna spacing requirements for user safety

It is important to keep the radio's antenna a safe distance from the user. To meet the requirements of FCC part

2.1091 for radio frequency radiation exposure, this radio must be used in such a way as to guarantee at least 20 cm
between the antenna and users. Greater distances are required for high-gain antennas. The FCC requires a
minimum distance of 1 mW *cm2 power density from the user (or 20 cm, whichever is greater).

If a specific application requires proximity of less than 20 cm, the application must be approved through the FCC for
compliance to part 2.1093.

Important Installation Instructions

This equipment is suitable for use in Class I, Division 2, Groups A, B, C and D OR non-hazardous locations only.
WARNING – EXPLOSION HAZARD – DO NOT DISCONNECT EQUIPMENT UNLESS POWER HAS BEEN

REMOVED OR THE AREA IS KNOWN TO BE NON-HAZARDOUS.
WARNING – EXPLOSION HAZARD - SUBSTITUTION OF ANY COMPONENTS MAY IMPAIR SUITABILITY FOR

CLASS I, DIVISION 2.
Power must be provided from NEC Class 2 Circuit or a Limited Power Source.

EU Requirements

1. For outdoor use, France has a frequency restriction of 2.4 GHz to 2.454 GHz for an output power greater than 10
mW and below 100 mW.

2. For outdoor use in France, the output power is restricted to 10 mW in the frequency range of 2.454 GHz to 2.4835
GHz.

3. 5.15 GHz to 5.35 GHz is restricted to 200 mW EIRP throughout the European Union.

RadioLinx IFH: FCC Part 15 & Industry Canada Rules

The statements contained in this "Regulatory Approvals" section are required. If the ProSoft Technology, RadioLinx
wireless modem and switches are used as a component of any device, these statements must be a component of
that device’s product documentation.

RadioLinx IFHS: COMPLIANCE STATEMENT

The ProSoft Technology, RadioLinx devices comply with Part 15 of the FCC Rules as well as Industry Canada Rules.
Operation is subject to the following two conditions:

 This device may not cause harmful interference, and,
 This device must accept any interference received, including interference that may cause undesired operation.

In Canada, this device is to be operated indoors only and away from windows to provide maximum shielding and to
prevent radio interference to the Canadian licensed service. Equipment (or its transmit antenna) that is installed
outdoors in Canada is subject to licensing.

Note: The ProSoft Technology, RadioLinx module is labeled with an FCC ID number and a Canadian Certification
Number. If this label is not visible when installed in an end-device, the outside of the device MUST also display a
label referring to the enclosed RadioLinx. Use wording on the label similar to the following:
RLX-IFH9S: "Transmitter Module FCC ID: OQ7OS2400, Canada 36561031989A"
RLX-IFH24S: "Transmitter Module FCC ID: NS907P22, Canada 3143A07P22"
OR
RLX-IFH9S: "This device contains Transmitter Module FCC ID: OQ7OS2400, Canada 36561031989A"

ANSI/ISA

CSA

ATEX

CSA/CB

FCC/IC

ETSI

RLX-IFH24S: "This device contains Transmitter Module FCC ID: NS907P22, Canada 3143A07P22"
WARNING: Changes or modifications to this radio module not expressly approved by its manufacturer, ProSoft
Technology, may void the user’s authority to operate the equipment.

Agency Approvals & Certifications

Wireless Approvals

Visit our web site at www.prosoft-technology.com for current wireless approval information.

Hazardous Locations

Ordinary Locations

Agency Approvals & Certifications

Wireless Approvals

Visit our website at www.prosoft-technology.com for current wireless approval information.

RLX-IFHS ♦ RadioLinx Industrial Wireless Contents
RadioLinx® Industrial Frequency Hopping Serial Radios User Manual

Contents

Your Feedback Please ........................................................................................................................ 2

How to Contact Us .............................................................................................................................. 2

ProSoft Technology® Product Documentation .................................................................................... 2

Important Safety Information ............................................................................................................... 3

Recommended Antennas ................................................................................................................... 3

Antenna spacing requirements for user safety ................................................................................... 4

Please Read This Notice .................................................................... Error! Bookmark not defined.

EU Requirements ................................................................................................................................ 4

RadioLinx IFH: FCC Part 15 & Industry Canada Rules ...................................................................... 4

RadioLinx IFHS: COMPLIANCE STATEMENT .................................................................................. 4

Agency Approvals & Certifications ...................................................................................................... 5

Agency Approvals & Certifications ...................................................................................................... 5

Guide to the RLX-IFHS User Manual 11

1 Start Here 13

1.1 About the RadioLinx Industrial Frequency Hopping Radios ................................... 14

1.1.1 Product Specifications - RLX-IFH9S ....................................................................... 14

1.1.2 Product Specifications - RLX-IFH24S ..................................................................... 16

1.2 Package Contents ................................................................................................... 18

1.3 System Requirements ............................................................................................. 19

1.4 Install ControlScape FH Configuration Software .................................................... 20

1.5 Planning the Network .............................................................................................. 21

1.5.1 Installation Questions .............................................................................................. 22

1.5.2 ProSoft Wireless Designer ...................................................................................... 23

1.6 Configuring the Radios ............................................................................................ 25

1.6.1 Start ControlScape FH ............................................................................................ 25

1.6.2 Set Up the Network ................................................................................................. 26

1.6.3 General Radio Configuration ................................................................................... 31

1.6.4 Set Up the Master Radio ......................................................................................... 32

1.6.5 Add Remote Radios ................................................................................................ 36

1.6.6 Add Repeaters ........................................................................................................ 37

1.6.7 Graphically Define the RF Link ............................................................................... 38

1.6.8 Save the Network Configuration ............................................................................. 40

1.6.9 Transfer the Configuration to the Remote Radios .................................................. 41

1.7 Planning the Physical Installation ............................................................................ 44

1.8 Test the Network Installation Plan ........................................................................... 45

1.9 Verify Communication ............................................................................................. 46

1.9.1 View Operating Network.......................................................................................... 46

1.9.2 Viewing Signal Strength .......................................................................................... 47

1.9.3 Query a Radio Directly ............................................................................................ 48

1.9.4 Query a Radio Remotely ......................................................................................... 49

2 Installing the Radios 51

2.1 Radio Hardware ...................................................................................................... 52

2.1.1 Radio power requirements ...................................................................................... 52

2.1.2 Connecting antennas .............................................................................................. 53

ProSoft Technology, Inc. Page 7 of 107
November 19, 2013

Contents RLX-IFHS ♦ RadioLinx Industrial Wireless
User Manual RadioLinx® Industrial Frequency Hopping Serial Radios

2.2 Connecting the Radio to a Network Device ............................................................ 54

2.2.1 Cable Connections ................................................................................................. 54

3 Diagnostics and Troubleshooting 59

3.1 Diagnostics Overview ............................................................................................. 60

3.2 LED Indicators ........................................................................................................ 61

3.3 Sources of Interference .......................................................................................... 62

3.3.1 Change a Network's Channel ................................................................................. 63

3.3.2 Viewing Radio Channel Noise Level ...................................................................... 64

3.3.3 IFHE Spectrum Analyzer Dialog Box ...................................................................... 65

3.4 Troubleshoot ControlScape FH Error Messages.................................................... 66

3.4.1 Radio Configuration Status Dialog Box .................................................................. 66

3.4.2 Automatic Baud Detection Dialog Box .................................................................... 66

3.4.3 Invalid Password Dialog Box .................................................................................. 66

3.4.4 Connection Errors ................................................................................................... 67

3.5 Troubleshoot Missing Radios ................................................................................. 68

3.6 RadioLinx OPC Server ........................................................................................... 69

3.6.1 System Requirements ............................................................................................ 69

4 Reference 71

4.1 Antennas ................................................................................................................. 72

4.1.1 Antenna location, spacing, and mounting ............................................................... 72

4.1.2 Antenna Pattern ...................................................................................................... 73

4.1.3 Antenna Gain .......................................................................................................... 73

4.1.4 Antenna Polarity ..................................................................................................... 74

4.1.5 Whip antennas ........................................................................................................ 74

4.1.6 Collinear array antennas ......................................................................................... 75

4.1.7 Yagi Array Antenna ................................................................................................. 76

4.1.8 Parabolic reflector antennas ................................................................................... 77

4.1.9 Adding bi-directional amplifiers ............................................................................... 77

4.2 Cable Connections ................................................................................................. 79

4.2.1 Radio RS-485 Cable Specification ......................................................................... 79

4.2.2 Radio RS-232 Cable Specifications ....................................................................... 80

4.3 Serial Port Basics ................................................................................................... 81

5 Support, Service & Warranty 83

Contacting Technical Support .......................................................................................................... 83

5.1 Return Material Authorization (RMA) Policies and Conditions ............................... 85

5.1.1 Returning Any Product ............................................................................................ 85

5.1.2 Returning Units Under Warranty ............................................................................. 86

5.1.3 Returning Units Out of Warranty ............................................................................. 86

5.2 LIMITED WARRANTY ............................................................................................ 87

5.2.1 What Is Covered By This Warranty ........................................................................ 87

5.2.2 What Is Not Covered By This Warranty .................................................................. 88

5.2.3 Disclaimer Regarding High Risk Activities .............................................................. 88

5.2.4 Intellectual Property Indemnity ............................................................................... 89

5.2.5 Disclaimer of all Other Warranties .......................................................................... 89

5.2.6 Limitation of Remedies ** ....................................................................................... 90

5.2.7 Time Limit for Bringing Suit ..................................................................................... 90

5.2.8 No Other Warranties ............................................................................................... 90

Page 8 of 107 ProSoft Technology, Inc.
November 19, 2013

RLX-IFHS ♦ RadioLinx Industrial Wireless Contents
RadioLinx® Industrial Frequency Hopping Serial Radios User Manual

5.2.9 Allocation of Risks ................................................................................................... 90

5.2.10 Controlling Law and Severability ............................................................................. 91

Glossary of Terms 92

Index 105

ProSoft Technology, Inc. Page 9 of 107
November 19, 2013

Contents RLX-IFHS ♦ RadioLinx Industrial Wireless
User Manual RadioLinx® Industrial Frequency Hopping Serial Radios

Page 10 of 107 ProSoft Technology, Inc.
November 19, 2013

RLX-IFHS ♦ RadioLinx Industrial Wireless Guide to the RLX-IFHS User Manual

Function

Section to Read

Details

Introduction
(Must Do)



Start Here (page 12)

This section introduces the customer to the
module. Included are: package contents,
system requirements, hardware installation, and
basic configuration.

Configuring the Radios



Set Up the Network
(page 26)

Set Up the Master
Radio (page 32)

Add Remote Radios
and Repeaters
(page 36)

Save the Radio
Configuration (page

35)

This section describes the procedure for
designing and configuring a network of RLX­IFHS radios.

Installing the Radios



Radio Hardware
(page 52)

Connecting
antennas (page 53)

Connecting Radios
to a Device Network
(page 54, page 54)

This section describes how to install the radio
hardware, connect antennas, and connect the
radios to networked devices.

Diagnostic and
Troubleshooting



Verify
Communication
(page 61, page 46)

Diagnostics and
Troubleshooting
(page 59, page 60)

This section describes how to verify
communications with the network. Diagnostic
and Troubleshooting procedures.

Reference
Physical Installation
Antenna Selection
Glossary



Reference (page 71)
Product

Specifications (page

14)

These sections contain general references
associated with this product, Specifications, and
the Functional Overview.

Support, Service, and
Warranty

Index



Support, Service
and Warranty (page

83)

This section contains Support, Service and
Warranty information.

Index of chapters.

RadioLinx® Industrial Frequency Hopping Serial Radios User Manual

Guide to the RLX-IFHS User Manual

ProSoft Technology, Inc. Page 11 of 107
November 19, 2013

Guide to the RLX-IFHS User Manual RLX-IFHS ♦ RadioLinx Industrial Wireless
User Manual RadioLinx® Industrial Frequency Hopping Serial Radios

Page 12 of 107 ProSoft Technology, Inc.
November 19, 2013

RLX-IFHS ♦ RadioLinx Industrial Wireless Guide to the RLX-IFHS User Manual

In This Chapter

 About the RadioLinx Industrial Frequency Hopping Radios .................. 14

 Package Contents ................................................................................. 18

 System Requirements ........................................................................... 19

 Install ControlScape FH Configuration Software ................................... 20

 Planning the Network ............................................................................ 21

 Configuring the Radios .......................................................................... 25

 Planning the Physical Installation .......................................................... 44

 Test the Network Installation Plan ......................................................... 45

 Verify Communication ........................................................................... 46

RadioLinx® Industrial Frequency Hopping Serial Radios User Manual

1 Start Here

ProSoft Technology, Inc. Page 13 of 107
November 19, 2013

Guide to the RLX-IFHS User Manual RLX-IFHS ♦ RadioLinx Industrial Wireless

Frequency

902MHz to 928MHz

Security

128 bit AES encryption

Network Topology

Point-to-point, point-to-multipoint, store and
forward repeater

Error Detection

32 bit CRC, ARQ (Automatic Resend Query)

Radio Type

Frequency Hopping Spread Spectrum

Transmit Power (Programmable)

100 mW to 1 W
20 dBm to 30 dBm

Channel data rates
(Programmable)

230, 172, 115 or 19.2 kbps

Receiver Sensitivity (Typical)

230 kbps: -106 dBm @ 10-6 BER
172 kbps: -108 dBm @ 10-6 BER

19.2 kbps: -116 dBm @ 10-6 BER

Outdoor Range

30+ miles pt-pt with high gain directional
antennas and RF line-of-sight

User Manual RadioLinx® Industrial Frequency Hopping Serial Radios

1.1 About the RadioLinx Industrial Frequency Hopping Radios

1.1.1 Product Specifications - RLX-IFH9S

The RLX-IFH9S provides powerful and secure wireless serial communications
and is well suited for demanding, long-range (up to 30+ miles) SCADA and other
serial applications in tough environments. Operating in the license-free 900 MHz
band, the RLX-IFH9S penetrates foliage and walls / ceilings better than higher
frequency radios. With both RS-232 and RS-485 serial ports, serial protocols
such as Modbus RTU, DF1, ASCII and DNP3 are supported. The RLX-IFH9S is
user configurable as a master, repeater and remote radio and employs the 128
bit AES encryption algorithm approved by the United States government for top
secret information.

RLX-IFH9S radios are quickly and easily configured using the included, graphical
ControlScape software. An OPC server software is also included and allows
users to monitor radio network health with any OPC client based HMI software.

General Specifications

Radio

Page 14 of 107 ProSoft Technology, Inc.
November 19, 2013

RLX-IFHS ♦ RadioLinx Industrial Wireless Guide to the RLX-IFHS User Manual

Enclosure

Extruded aluminum with DIN and panel mount

Size

104 ´ 94 ´ 53 mm (W ´ H ´ D)

4.1 ´ 3.7 ´ 2.1 inches

Vibration

IEC 60068-2-6 (20g, 3-Axis)

Shock

IEC 60068-2-27 (5g, 10Hz to 150Hz)

Serial Data Ports (2)

DB9, RS-232
RS-422 and RS-485
300 bps to 230 kbps

Configuration Port

DB9, RS-232

Antenna Ports

(1) RP-SMA connector

Weight

1.0 lbs (454 g)

Operating Temperature

–40° C to +75° C

Humidity

Up to 100% RH, without condensation

External Power

10Vdc to 24Vdc

Power Consumption

12 W peak

UL

ISA 12.12.01 Class I Div 2 Groups A, B, C & D, T5.
Must be installed inside an IP54 enclosure that requires tool
access.

CSA/cUL

C22.2 No. 213-M1987

ATEX Category 3, Zone 2
II 3 G
Ex nA IIC T5 X

-30 C <= Ta <= +60 C

WARNING – EXPLOSION HAZARD – DO NOT DISCONNECT EQUIPMENT
UNLESS POWER HAS BEEN SWITCHED OFF OR THE AREA IS KNOWN TO BE
NON-HAZARDOUS.

AVERTISSEMENT – RISQUE D'EXPLOSION – AVANT DE DÉCONNECTER
L'EQUIPMENT, COUPER LE COURANT OU S'ASSURER QUE L'EMPLACEMENT
EST DÉSIGNÉ NON DANGEREUX.

RadioLinx® Industrial Frequency Hopping Serial Radios User Manual

Hardware Specifications

Environmental

Agency Approvals & Certifications

ProSoft Technology, Inc. Page 15 of 107
November 19, 2013

Guide to the RLX-IFHS User Manual RLX-IFHS ♦ RadioLinx Industrial Wireless

Frequency

2.400GHz to 2.4835GHz

Security

128 bit AES encryption

Network Topology

Point-to-point, point-to-multipoint, store and
forward repeater

Error Detection

32 bit CRC, ARQ (Automatic Resend Query)

Radio Type

Frequency Hopping Spread Spectrum

Transmit Power (Programmable)

10 mW to 1 W (FCC - A model)
10 mW to 100 mW (ETSI - E model)

Channel data rates
(Programmable)

230, 172, 115 or 19.2 kbps

Receiver Sensitivity (Typical)

230 kbps: -106 dBm @ 10-6 BER
172 kbps: -108 dBm @ 10-6 BER

19.2 kbps: -116 dBm @ 10-6 BER

Outdoor Range

15+ miles pt-pt with high gain directional
antennas and RF line-of-sight (Americas
version)

User Manual RadioLinx® Industrial Frequency Hopping Serial Radios

1.1.2 Product Specifications - RLX-IFH24S

The RLX-IFH24S provides powerful and secure wireless serial communications
and is well suited for demanding, long-range (up to 15+ miles) SCADA and other
serial applications in tough environments. Operating in the internationally license­free 2.4 GHz band, the RLX-IFH24S offers an alternative when 900 MHz radios
cannot be used due to government regulations, band saturation, or customer
preference. With both RS-232 and RS-485 serial ports, serial protocols such as
Modbus RTU, DF1, ASCII and DNP3 are supported. The RLX-IFH24S is user
configurable as a master, repeater and remote radio and employs the 128 bit
AES encryption algorithm approved by the United States government for top
secret information.

RLX-IFH24S radios are quickly and easily configured using the included,
graphical ControlScape software. An OPC server software is also included and
allows users to monitor radio network health with any OPC client based HMI
software.

General Specifications

Radio

Page 16 of 107 ProSoft Technology, Inc.
November 19, 2013

RLX-IFHS ♦ RadioLinx Industrial Wireless Guide to the RLX-IFHS User Manual

Enclosure

Extruded aluminum with DIN and panel mount

Size

104 x 94 x 53 mm (W x H x D)

4.1 x 3.7 x 2.1 inches

Serial Data Port

DB9, RS-232
RS-422 / RS-485
300 bps to 230 kbps

Configuration Port

DB9, RS-232

Antenna Ports

(1) RP-SMA connector

Weight

1.0 lbs (454 g)

Operating Temperature

–40° C to +75° C

Humidity

Up to 100% RH, without condensation

Vibration

IEC 60068-2-6 (20g, 3-axis)

Shock

IEC 60068-2-27 (5g, 10Hz to 150Hz

External Power

10Vdc to 24Vdc

Power Consumption

12 W peak

UL

ISA 12.12.01 Class I Div 2 Groups A, B, C & D, T5.
Must be installed inside an IP54 enclosure that requires tool
access.

CSA/cUL

C22.2 No. 213-1987

ATEX Category 3, Zone 2
II 3 G
Ex nA IIC T5 X

-30 C <= Ta <= +60 C

WARNING – EXPLOSION HAZARD – DO NOT DISCONNECT EQUIPMENT
UNLESS POWER HAS BEEN SWITCHED OFF OR THE AREA IS KNOWN TO BE
NON-HAZARDOUS.

AVERTISSEMENT – RISQUE D'EXPLOSION – AVANT DE DÉCONNECTER
L'EQUIPMENT, COUPER LE COURANT OU S'ASSURER QUE L'EMPLACEMENT
EST DÉSIGNÉ NON DANGEREUX.

RadioLinx® Industrial Frequency Hopping Serial Radios User Manual

Hardware Specifications

Environmental

Agency Approvals & Certifications

ProSoft Technology, Inc. Page 17 of 107
November 19, 2013

Guide to the RLX-IFHS User Manual RLX-IFHS ♦ RadioLinx Industrial Wireless

Qty.

Part Name

Part Number

Part Description

1

RLX-IFHS Radio

RLX-IFHS

RadioLinx® Industrial Frequency Hopping
Serial Radios

1

Cable

Cable #15, RS232

For RS232 Connection to the CFG Port

1

Connector

002-0082

5 pin connector for RS-485/RS-422 Port

1

Antenna

A2405S-OA
A902S-OA

5dBi Omni Articulating Antenna (RLX­IFH24S)

2dBi Omni Articulating Antenna (RLX­IFH9S)

1

Power Supply

RL-PS007-2

AC Power Adapter, 12V1.6A w/2 pin & 4
plug Set

1

ProSoft Solutions CD

Contains sample programs, utilities and
documentation for the RLX-IFHS module.

User Manual RadioLinx® Industrial Frequency Hopping Serial Radios

1.2 Package Contents

The following components are included with your RLX-IFHS radio, and are all
required for installation and configuration.

Important: Before beginning the installation, please verify that all of the following items are
present.

If any of these components are missing, please contact ProSoft Technology
Support for replacement parts.

Page 18 of 107 ProSoft Technology, Inc.
November 19, 2013

RLX-IFHS ♦ RadioLinx Industrial Wireless Guide to the RLX-IFHS User Manual
RadioLinx® Industrial Frequency Hopping Serial Radios User Manual

1.3 System Requirements

The following system requirements are the recommended minimum
specifications to successfully install and run ControlScape FH:

 Microsoft Windows compatible PC
 Windows 2000 with Service Pack 2 or higher, or Windows XP Professional

with Service Pack 2 or higher, or Windows 2003.

 300 mHz Pentium processor (or equivalent)
 128 megabytes of RAM
 20 megabytes of free disk space

In addition, you will need
 Available serial port (COM port) or USB to Serial adapter cable with

necessary drivers, required for communication between ControlScape FH
software and the RadioLinx FH module.

ProSoft Technology, Inc. Page 19 of 107
November 19, 2013

Guide to the RLX-IFHS User Manual RLX-IFHS ♦ RadioLinx Industrial Wireless
User Manual RadioLinx® Industrial Frequency Hopping Serial Radios

1.4 Install ControlScape FH Configuration Software

1 Insert the ProSoft Solutions CD in your CD-ROM drive. On most computers,

a menu screen will open automatically. If you do not see a menu within a few
seconds, follow these steps:

a Click the Start button, and then choose Run.
b In the Run dialog box, click the Browse button.
c In the Browse dialog box, click "My Computer". In the list of drives,

choose the CD-ROM drive where you inserted the ProSoft Solutions CD.

d Select the file prosoft.exe, and then click Open.
e On the Run dialog box, click OK.

2 On the CD-ROM menu, select Setup Software under RLX-FH Frequency

Hopping. This action opens the Setup Wizard for ControlScape FH.

3 Follow the instructions on the installation wizard to install the program with its

default location and settings.

4 When the installation finishes, you may be prompted to restart your computer

if certain files were in use during installation. The updated files will be
installed during the restart process.

Page 20 of 107 ProSoft Technology, Inc.
November 19, 2013

RLX-IFHS ♦ RadioLinx Industrial Wireless Guide to the RLX-IFHS User Manual
RadioLinx® Industrial Frequency Hopping Serial Radios User Manual

1.5 Planning the Network

Before you configure and install the network, you should create a plan for it. To
begin, determine where you need radios and then choose locations for them
accordingly. For example, you might decide to install your master radio near a
PC in a central plant location (You can use the PC to configure the radios
through ControlScape FH). If the plant is an oil refinery, for example, you might
decide to install radios near the oil tanks.

The following illustration shows how a radio network of RLX-IFH24S radios could
be deployed to connect a variety of PLCs using a variety of industrial protocols.
You could deploy a similar network of RLX-IFH9S radios.

The next important issue is how to link the radios. Unless the radios are very
close together, you must make sure that each pair of radio antennas in the
network has a line of sight between them. In other words, you must be able to
see from one antenna to another, either with the naked eye or binoculars.

If a line of sight does not exist between antennas, you must choose a site for
installing a repeater radio, which will create a bridge between the radio antennas.
As part of your planning, you may need to conduct a site survey. ProSoft
Technology can perform this survey, you can do it yourself, or you can hire a
surveyor.

ProSoft Technology, Inc. Page 21 of 107
November 19, 2013

Guide to the RLX-IFHS User Manual RLX-IFHS ♦ RadioLinx Industrial Wireless

How many radios in your network?

Static IP Address, Subnet Mask and
Gateway addresses for each RadioLinx
device

Connection to an existing wired or wireless Ethernet network, either
directly from the PC, or through an Ethernet switch or hub

Master ID

Repeater
ID

Remote ID

Locations

Is there a Line of Sight between them?

Selected the appropriate antennas for your network?

What type of network protocols do you need to
support?

What type of cable connections do your network
devices require?

User Manual RadioLinx® Industrial Frequency Hopping Serial Radios

The simplest way to design the physical network of radios, antennas, connectors,
cables, amplifiers and other accessories, is to use ProSoft Wireless Designer
(page 23). This application determines your hardware needs based on your
answers to a few questions, and then generates a Bill of Materials specifying all
the components you will need for your installation.

Consider printing your network plan from ProSoft Wireless Designer for
references as you configure your network in ControlScape FH.

Protect radios from direct exposure to weather, and provide an adequate, stable
power source. Make sure that your plan complies with the radio’s power
requirements (page 52) and cable specifications.

Important: Radios and antennas must be located at least 8 inches (20 cm) away from personnel.

1.5.1 Installation Questions

Answer the following questions to make your installation easier, and to familiarize
yourself with your system and what you want to do.

Page 22 of 107 ProSoft Technology, Inc.
November 19, 2013

RLX-IFHS ♦ RadioLinx Industrial Wireless Guide to the RLX-IFHS User Manual
RadioLinx® Industrial Frequency Hopping Serial Radios User Manual

1.5.2 ProSoft Wireless Designer

ProSoft Wireless Designer simplifies the task of specifying a ProSoft Wireless
installation, and provides a variety of views containing an accurate description of
each site in a wireless network, including:

 Visual diagram of site layout
 Location (latitude/longitude, based on GPS coordinates)
 Radio type, frequency range, and country-specific channel and power

requirements

 Length, type and estimated signal loss for cables
 Required accessories, including lightning protection, cable adaptors and

antennas

 Complete parts list
Use ProSoft Wireless Designer when conducting a site audit for a customer, and

then provide the customer with a complete list of components and a detailed
description for each site and link. Customers can use this information to
understand and visualize their network, and provide necessary information for
technical support and maintenance.

Functional Specifications:

 Contains a database of all currently available RadioLinx radios, antennas,

cables, connectors and accessories

 Exports Parts List, Site and Link Details, and Wizard settings into a variety of

common file formats, for import into applications such as spreadsheets,
databases and word processors

 Checks wireless link feasibility based on path length and recommended

accessories

 Predicts signal strength based on distance, local regulations and hardware

choices

 Fully documents your ProSoft Wireless network plan
ProSoft Wireless Designer simplifies the task of specifying a ProSoft Wireless

installation, and provides a variety of views containing an accurate description of
each site in a wireless network, including

 Visual diagram of site layout
 Location (latitude/longitude, based on GPS coordinates)
 Radio type, frequency range, and country-specific channel and power

requirements

 Length, type and estimated signal loss for cables
 Required accessories, including lightning protection, cable adaptors and

antennas

 Complete parts list
Use ProSoft Wireless Designer when conducting a site audit for a customer, and

then provide the customer with a complete list of components and a detailed
description for each site and link. Customers can use this information to
understand and visualize their network, and provide necessary information for
technical support and maintenance.



ProSoft Technology, Inc. Page 23 of 107
November 19, 2013

Guide to the RLX-IFHS User Manual RLX-IFHS ♦ RadioLinx Industrial Wireless
User Manual RadioLinx® Industrial Frequency Hopping Serial Radios

System Requirements

ProSoft Wireless Designer is designed for computers running Microsoft Windows
and Microsoft .NET Framework version 2.0 or newer.

Minimum hardware requirements are:

 400 MHz or faster Pentium PC
 128 MB RAM
 CD-ROM drive
 280 MB available hard drive space

The Microsoft .NET Framework version 2.0 is not supported on Windows 95 or
Windows NT 4, or Windows 3.x.

It is highly recommended for all platforms that you upgrade to the latest Windows
Service Pack and critical updates available from http://www.windowsupdate.com
to ensure the best compatibility and security.

Page 24 of 107 ProSoft Technology, Inc.
November 19, 2013

RLX-IFHS ♦ RadioLinx Industrial Wireless Guide to the RLX-IFHS User Manual
RadioLinx® Industrial Frequency Hopping Serial Radios User Manual

1.6 Configuring the Radios

Configuration of your RLX-IFHS radios consists of the following steps:

 Start ControlScape FH (page 25)
 Plug In the Cables (page 34)
 Set Up the Network (page 26)
 Set Up the Master Radio (page 32)
 Add Remote Radios (page 36)
 Add Repeaters (page 37)
 Graphically Define the RF link (page 38)
 Save the Network Configuration (page 40)
 Save the Radio Configuration (page 35)

1.6.1 Start ControlScape FH

You will use an application (software program) called ControlScape FH to
configure the RLX-IFHS radios and the radio network. If you have not already
installed ControlScape FH, please do so now. Refer to Install ControlScape FH
Configuration Software (page 20) for information on how to install the program.

To start ControlScape

1 Click the Start button, and then choose Programs
2 In the Programs menu, navigate to the ProSoft Technology folder, and then

choose RadioLinx ControlScape FH.

3 Allow a few moments for the program to load. When the program has finished

loading, you will see a screen like this:

ProSoft Technology, Inc. Page 25 of 107
November 19, 2013

Guide to the RLX-IFHS User Manual RLX-IFHS ♦ RadioLinx Industrial Wireless
User Manual RadioLinx® Industrial Frequency Hopping Serial Radios

1.6.2 Set Up the Network

From the ControlScape FH Main Menu, select:
 Configure

o New Network

A Network Properties dialog box is displayed where the basic parameters of the
new network are defined. The items on this dialog box depend on what type of
radio you select. The following example shows a RadioLinx IFHS (Industrial
Frequency Hopping Serial) radio.

Refer to Network Properties dialog box for more information on the settings.

Network Types - IFH Radios

Note: Available network types depend on the type of radio you are configuring. Not all network
types are available on all radios.

IFH Radios

 P2P - Peer to Peer (page 27)
 PMP - Point to Multipoint (page 28)
 E2E - Everyone to Everyone (page 29)
 PTP - Point to Point (page 30)

Note: There is only one Master radio for each network.

Page 26 of 107 ProSoft Technology, Inc.
November 19, 2013

RLX-IFHS ♦ RadioLinx Industrial Wireless Guide to the RLX-IFHS User Manual
RadioLinx® Industrial Frequency Hopping Serial Radios User Manual

Peer to Peer Networks

Peer-to-Peer (P2P) supports communication (through the Master) between two
or more remote units. Each radio can be configured to send its messages to one
other radio, or to broadcast to all radios in the network.

In the following illustration, the master radio is configured to broadcast to both
radios. Each remote radio is configured to send data back to the master.

ProSoft Technology, Inc. Page 27 of 107
November 19, 2013

Guide to the RLX-IFHS User Manual RLX-IFHS ♦ RadioLinx Industrial Wireless
User Manual RadioLinx® Industrial Frequency Hopping Serial Radios

Point to Multipoint Networks

Point to Multipoint configuration creates the network to broadcast data from the
Master radio to the other radios in the network. All of the other radios return their
data to the Master radio.

A Point to Multipoint network is well suited for a polled network such as Modbus
RTU, DF1 or Modbus TCP/IP. Communications from remote radios is directed
back to master radio. Master radio broadcasts to all other radios.

In the following illustration, the Master radio is configured to broadcast data to
Radios 2, 3 and 4.

Page 28 of 107 ProSoft Technology, Inc.
November 19, 2013

RLX-IFHS ♦ RadioLinx Industrial Wireless Guide to the RLX-IFHS User Manual
RadioLinx® Industrial Frequency Hopping Serial Radios User Manual

Everyone to Everyone Networks

Everyone-to-Everyone (E2E) configuration creates a network where all units
communicate with all other units, through the Master. Note that this mode is very
bandwidth-intensive, because all data is transmitted to all radios.

In the following illustration, each radio broadcasts to all the other radios.

ProSoft Technology, Inc. Page 29 of 107
November 19, 2013

Guide to the RLX-IFHS User Manual RLX-IFHS ♦ RadioLinx Industrial Wireless
User Manual RadioLinx® Industrial Frequency Hopping Serial Radios

Point to Point Networks

Point-to-Point configuration transfers data between two radios (points) in the
network. In the network shown below, the Master Radio and Radio 4 transfer
data between each other. Radios 2 and 3 only act as bridges to get the data
between them.

Page 30 of 107 ProSoft Technology, Inc.
November 19, 2013

RLX-IFHS ♦ RadioLinx Industrial Wireless Guide to the RLX-IFHS User Manual
RadioLinx® Industrial Frequency Hopping Serial Radios User Manual

1.6.3 General Radio Configuration

Note: If possible, you should configure all the radios side by side in an office setting and make sure
they link before you install them in the field. If feasible, it would be even better if you could set up
the entire system in the office and make sure your equipment communicates properly through the
radio network.
Important: If the radios are close enough to each other that their received signal strength is
greater than -40dBm, performance may be degraded. Disconnect antennas from radios during
bench testing, or move the radios further apart from each other.

Configure the radios themselves after the network is designed. Radios are
configured ONE AT A TIME USING THE CONFIGURATION PC.

Use the specified cable (page 80) and connect the radio to the Configuration
PC's COM port as specified in the PC's serial port dialog box.

Access the Radio Configuration dialog box to set network-specific parameters
for each individual radio. Starting from the ControlScape FH Main Menu, select:

 Configure

o Modify (the network by name)

The Graphical Layout Screen is displayed. There are two different methods of
bringing the dialog box up from the screen:

 double-click the icon of the radio to be configured,
OR

 select the icon of the radio to be configured by selecting it with a single

left-click of the mouse and then choose the following menu items:

o Properties / Radio

ProSoft Technology, Inc. Page 31 of 107
November 19, 2013

Guide to the RLX-IFHS User Manual RLX-IFHS ♦ RadioLinx Industrial Wireless
User Manual RadioLinx® Industrial Frequency Hopping Serial Radios

The Radio Configuration dialog box is displayed - the image of the dialog box is
different depending on which network type (page 26) the radio is incorporated
into.

Continue to configure the radios depending on their network type:

Note: The network types available depend on the type of radio you select. Not all network types
are supported on all radios. Refer to the user manual for your radio to determine what network
types are available.

1.6.4 Set Up the Master Radio

RadioLinx IFH radios are designed to act as a "wire replacement" to connect a
local device (for example, a PLC) with one or more remote devices (for example,
another PLC, an HMI, or a field device such as a valve, meter, bar code scanner,
or other measurement or control device).

Every radio network requires one Master radio, and one or more Remote radios.
You must configure the Master radio before configuring the remote radios, as the
remote radio configurations rely on the settings you choose for the Master radio.

When you create a new network, ControlScape FH automatically populates the
network with a pair of radios, as shown in the following illustration.

Page 32 of 107 ProSoft Technology, Inc.
November 19, 2013

RLX-IFHS ♦ RadioLinx Industrial Wireless Guide to the RLX-IFHS User Manual
RadioLinx® Industrial Frequency Hopping Serial Radios User Manual

Double-click the left mouse button on the Master Radio to open the Radio
Properties dialog box.

Most of the settings on this dialog box are straightforward. The default settings
will work with many devices without modification, however you will need to know
the communication parameters to use if the wired device requires different
settings. This information is normally available in the user manuals for the device.

Certain devices may require additional configuration, if the default configuration
is not adequate for reliable data transfer. For example, you may need to adjust
transmit power to reduce interference with other devices transmitting on the
same frequency, or to fine-tune the packet settings to accommodate timing and
packet size requirements for an industrial protocol. Click the Advanced button to
make these additional options visible.

When you have finished making your selections, click OK to save the radio
configuration.

ProSoft Technology, Inc. Page 33 of 107
November 19, 2013

Guide to the RLX-IFHS User Manual RLX-IFHS ♦ RadioLinx Industrial Wireless
User Manual RadioLinx® Industrial Frequency Hopping Serial Radios

Plug In the Cables

You must transfer these settings to the Master radio in order for these changes to

take effect. ControlScape FH will update the radio’s internal settings through the

serial connection between your computer and the Configuration port on the radio.
1 Connect a straight-through 9 pin Serial cable from the serial port on your PC

to the Config port on the top (antenna side) of the radio.

Important: You must use the serial port labeled Config to connect from the configuration PC to the
radio. The serial port on the bottom of the radio, labeled RS-232, is reserved for connections to
external network devices, and cannot be used to configure the radio.

2 Connect the AC power adapter cord to the port labeled 10 - 24 VDC 6W on

the bottom of the radio, and then plug the power adapter into an electrical
outlet.

When the radio is powered up, it will go through a brief self-test during which the
LEDs (page 61) on the front of the radio will illuminate. The Power/Status LED
should be green, meaning that the radio has power.

Page 34 of 107 ProSoft Technology, Inc.
November 19, 2013

RLX-IFHS ♦ RadioLinx Industrial Wireless Guide to the RLX-IFHS User Manual
RadioLinx® Industrial Frequency Hopping Serial Radios User Manual

Transfer the Configuration to the Master Radio

To send the new configuration settings to the Master radio, click the Configure
Radio button on the Radio Configuration dialog box.

ControlScape FH will prompt you to choose the radio to configure.

ControlScape FH will display a progress indicator as it attempts to connect to the
radio.

When the configuration is completed successfully, the following message is
displayed.

When the configuration has been transferred successfully, ControlScape FH will
update the Radio Configuration dialog box with information retrieved from the
radio, including the radio’s Serial Number and Last Date Configured.

ProSoft Technology, Inc. Page 35 of 107
November 19, 2013

Guide to the RLX-IFHS User Manual RLX-IFHS ♦ RadioLinx Industrial Wireless
User Manual RadioLinx® Industrial Frequency Hopping Serial Radios

1.6.5 Add Remote Radios

The radios can be displayed in different colors, or you can use the default color.
The color of a radio does not affect the function of the network, however, there
may be an application that can be more clearly represented with color-coded
radios.

Important: When defining a color, the color must be defined before the radio is added.

From the ControlScape FH Main Menu, select:
 Radio

o Add Radio

The new radio icon image appears and is superimposed over part of the Master
Radio icon.

Move (click and drag) the additional Remote radio icon off the Master Radio icon.

Continue on to Graphically Define the RF Link (page 38) to define the
communication links between radios.

Note: See When to Re-Configure Radios (page 42) to ensure all radios will be updated.

Page 36 of 107 ProSoft Technology, Inc.
November 19, 2013

RLX-IFHS ♦ RadioLinx Industrial Wireless Guide to the RLX-IFHS User Manual
RadioLinx® Industrial Frequency Hopping Serial Radios User Manual

1.6.6 Add Repeaters

The following illustration shows how to Add a Repeater to the Network. After
selecting the add repeater function from the menu, a repeater icon will appear on
the Graphical User Interface (GUI).

The repeater radio will have a link point (black dot) on both the right and left side
of each repeater radio. The remote radio has only one link point located on the
left side of the radio. As with all new radios, it will show the radio needs to be
updated.

Initially, a new network will start out with a Master radio and a Remote radio
connected by the RF link. To add a Repeater, the RF link (page 38) between the
Master and Remote will need to be deleted. After the Repeater is in place and
RF links are connected, the Repeater's setting can be adjusted.

Important: The items on this dialog box depend on what type of radio you select. The example in
this topic shows a RadioLinx IFHS (Industrial Frequency Hopping Serial) radio. Refer to the user
manual for your radio for an explanation of each configuration item.

ProSoft Technology, Inc. Page 37 of 107
November 19, 2013

Guide to the RLX-IFHS User Manual RLX-IFHS ♦ RadioLinx Industrial Wireless
User Manual RadioLinx® Industrial Frequency Hopping Serial Radios

1.6.7 Graphically Define the RF Link

Radio communication links between radios must be defined. ControlScape FH
uses lines between radios to graphically define the RF communication links in a
network.

From the network's Graphical Layout Screen:
Use the left mouse button to select the Master radio's link point (the black dot to

the right of the Master radio icon).

Note: Select the Master radio's link point (only) and not the Master radio icon itself. If the Master
radio is selected (surrounded by a colored box), left-click anywhere else on the screen to de-select
the Master radio icon.

Hold the left mouse button down and drag the RF link to the Remote radio's link
point (located to the left of the Remote radio). As the mouse is being dragged, a
line will appear between the Master and Remote radios. This is the graphical
representation of the RF communication link. After the mouse button is
released an arrowhead will appear at the end of the graphical link line at the
Remote radio's link point.

Page 38 of 107 ProSoft Technology, Inc.
November 19, 2013

RLX-IFHS ♦ RadioLinx Industrial Wireless Guide to the RLX-IFHS User Manual
RadioLinx® Industrial Frequency Hopping Serial Radios User Manual

To remove a RF link between two radios, select the line between the radios.

Press the Delete key to remove the graphical link line between the radios. Now a
repeater could be added between the two radios or the radios could be
connected to other radios.

ProSoft Technology, Inc. Page 39 of 107
November 19, 2013

Guide to the RLX-IFHS User Manual RLX-IFHS ♦ RadioLinx Industrial Wireless
User Manual RadioLinx® Industrial Frequency Hopping Serial Radios

1.6.8 Save the Network Configuration

Save the Network’s definition if:

 A new network has been defined
 Changes have been made to the network’s definition

From the Main Menu, select:
 File

o Save

The standard windows Save As dialog box will be displayed; the network name
can be accepted as it is or it can be edited here.

Note: This is the last time that the network’s name can be changed within ControlScape FH. If you

need to rename a network you have already saved, you can rename the .LUS file in Windows
Explorer.

Select:
 Save

Notes: DO NOT change the default directory. The ControlScape FH Setup/Diagnostic Application
uses the default directory to maintain network-related data.

The Network’s Definition can be printed.

Page 40 of 107 ProSoft Technology, Inc.
November 19, 2013

RLX-IFHS ♦ RadioLinx Industrial Wireless Guide to the RLX-IFHS User Manual
RadioLinx® Industrial Frequency Hopping Serial Radios User Manual

If this is the first time this network has been saved, the Password dialog box
appears.

Enter the new password and click OK. If no password protection is desired, leave
the password blank and click OK.

1.6.9 Transfer the Configuration to the Remote Radios

To send the new configuration settings to the Remote radio(s), click the
Configure Radio button on the Radio Configuration dialog box.

Important: The first time you configure a remote radio, you must connect directly to the radio with
a serial cable to transfer the configuration as a "Local" radio, because the configuration includes
information the radio requires in order to function as part of the network. After you have configured
the remote radio for the first time locally, you can disconnect the cable, install the radio in its
permanent location, and reconfigure it over the air through the Master radio.

ControlScape FH will prompt you to choose the location of radio to configure.

ProSoft Technology, Inc. Page 41 of 107
November 19, 2013

Guide to the RLX-IFHS User Manual RLX-IFHS ♦ RadioLinx Industrial Wireless
User Manual RadioLinx® Industrial Frequency Hopping Serial Radios

ControlScape FH will display a progress indicator as it attempts to connect to the
radio.

Repeat these steps for each Remote radio on your network.
When the configuration has been transferred successfully, ControlScape FH will

update the Radio Configuration dialog box with information retrieved from the
radio, including the radio’s Serial Number and Last Date Configured.

When to Re-Configure Radios

All radios need to be configured before initial installation in a network. In general,
after radios are functioning in a network, they do not need to be re-configured if
the network changes. The program will instruct when the radios need to be
configured, as illustrated below:

After all the radios are configured, the graphical layout will be displayed as
follows:

Page 42 of 107 ProSoft Technology, Inc.
November 19, 2013

RLX-IFHS ♦ RadioLinx Industrial Wireless Guide to the RLX-IFHS User Manual
RadioLinx® Industrial Frequency Hopping Serial Radios User Manual

Reconfiguring a Remote Radio

To reconfigure the Remote radio(s), click the Configure Radio button on the
Radio Configuration dialog box.

Important: The first time you configure a remote radio, you must connect directly to the radio with
a serial cable to transfer the configuration, because the configuration includes information the radio
requires in order to function as part of the network. After you have configured the remote radio for
the first time, you can disconnect the cable, install the radio in its permanent location, and
reconfigure it over the air through the Master radio.

ControlScape FH will prompt you to choose the location of radio to configure.

Repeat these steps for each Remote radio on your network.

ProSoft Technology, Inc. Page 43 of 107
November 19, 2013

Guide to the RLX-IFHS User Manual RLX-IFHS ♦ RadioLinx Industrial Wireless
User Manual RadioLinx® Industrial Frequency Hopping Serial Radios

1.7 Planning the Physical Installation

A network's performance is affected by attributes specific to the installation site.
Consider the following cautions, where possible, to optimize your network
installation:

 Design the network to use less than 2048 radios (per network)
 Place radios within the specified 15 miles of each other
 Add repeater to extend distance or where line of sight is limited
 Radios or antennas CANNOT be placed within 8 inches (20 cm) of where

people will be

Though radio frequency communication is reliable, sometimes its performance
can be affected by intangibles. A good network installation plan includes time
and resources for performance testing and installation changes.

Test the installation plan (page 45) before the network installation is complete.

Page 44 of 107 ProSoft Technology, Inc.
November 19, 2013

RLX-IFHS ♦ RadioLinx Industrial Wireless Guide to the RLX-IFHS User Manual
RadioLinx® Industrial Frequency Hopping Serial Radios User Manual

1.8 Test the Network Installation Plan

Test proposed installations before finalizing the installation.
After you have configured the network and the radios:

 install the Master radio in its proposed permanent location
 cable the Configuration PC to the Master radio
 place the Remote radios in their proposed locations
 temporarily place each radio's antenna near its proposed mounting location.

The temporary placement of the antenna can be by hand, however, with this
testing method, one person must hold the antenna while another monitors the
Remote radio's signal strength as displayed on the Configuration PC.

To improve the signal quality of each Remote's communication:

 increase the height of the antenna's placement
 use higher-gain antennas
 increase the radio's transmission power, cable the radio to the Configuration

PC, and reconfigure it

 select a new location for the Remote radio and/or its antenna
 decrease the length of antenna cable
 determine and resolve sources of "electrical" noise which may be interfering

with the radio transmission

 add a repeater between the radios that are not communicating, or reconfigure

an existing radio as a repeater if line of sight is available

Note: See When to Re-Configure Radios (page 42) to ensure all radios are updated.

ProSoft Technology, Inc. Page 45 of 107
November 19, 2013

Guide to the RLX-IFHS User Manual RLX-IFHS ♦ RadioLinx Industrial Wireless
User Manual RadioLinx® Industrial Frequency Hopping Serial Radios

1.9 Verify Communication

ControlScape FH provides several ways to verify that the radios are configured
and communicating with each other.

1.9.1 View Operating Network

To view a graphical representation of a network’s communication links, connect a

radio to the Configuration PC.
From the ControlScape FH Main Menu, select:
 Diagnostic / Network

o the network by name (from the displayed list of configured networks)

Select which radio is connected to the Configuration PC from the Radio Name
drop down list. The IP Address of the radio connected to the configuration PC is
automatically displayed.

Note: For IFH radios, full network diagnostics are available only when you are connected to the
Master radio. If you are connected to a Remote or a Repeater radio, you will only be able to
retrieve status information for the radio to which you are currently connected.

Page 46 of 107 ProSoft Technology, Inc.
November 19, 2013

RLX-IFHS ♦ RadioLinx Industrial Wireless Guide to the RLX-IFHS User Manual
RadioLinx® Industrial Frequency Hopping Serial Radios User Manual

Following is the ControlScape FH’s graphical representation of a network with
intact communication links. The functioning RF communication links are

represented solid colored lines.

The colored lines indicate the signal strength of each radio, see Viewing Signal
Strength. If any of the communication links show red dashed lines see Broken
Links in a Radio Network (page 68).

1.9.2 Viewing Signal Strength

After a network is configured, the Signal Strength of the Remote radios can be
monitored. This is helpful when the radios are being physically installed (page

44).
To monitor the Remote radio’s Signal strength:
From the ControlScape FH Main Menu, select:
 Diagnostic / Network

o the network by name (from the displayed list of configured networks)

After the network is displayed, double click the Remote radio to open the Radio
Status dialog box. This dialog box shows information about the radio, including
serial number, hardware and firmware information, and signal strength. The
appearance of this dialog box depends on the radio model and type.

ProSoft Technology, Inc. Page 47 of 107
November 19, 2013

Guide to the RLX-IFHS User Manual RLX-IFHS ♦ RadioLinx Industrial Wireless
User Manual RadioLinx® Industrial Frequency Hopping Serial Radios

1.9.3 Query a Radio Directly

A radio can be queried so that it reports its settings to the Configuration PC.
Radios may be queried directly (through a cable connected to the Configuration
PC) or remotely (through communication with the Master radio cabled to the
Configuration PC). If necessary, check the serial port settings to determine which
COM port is configured for the ControlScape FH network.

To directly query a radio (either Master or Remote), cable (page 80) the radio to
the Configuration PC. From the ControlScape FH Setup/Application Main Menu,
select:

 Diagnostic

o Radio

The Radio Parameters dialog box appears. Click the Get Data button to receive
data. The following illustration shows the Serial Radio Parameters dialog
BEFORE getting data

Page 48 of 107 ProSoft Technology, Inc.
November 19, 2013

RLX-IFHS ♦ RadioLinx Industrial Wireless Guide to the RLX-IFHS User Manual
RadioLinx® Industrial Frequency Hopping Serial Radios User Manual

The following illustration shows the Serial Radio Parameters dialog AFTER
getting data

Click the Done button to close the Radio Parameters dialog box.
Generally, a radio is queried if there is a network failure (An error dialog box will

appear if there is no communication between the cabled radio and the
Configuration PC).

1.9.4 Query a Radio Remotely

A radio can be queried so that it reports its settings to the Configuration PC.
Radios may be queried remotely (through communication with the Master radio
cabled to the Configuration PC) or directly (through a cable connected to the
Configuration PC) so that it reports its settings to the Configuration PC (If
necessary, check the serial port settings to determine which COM port is
configured for the ControlScape FH network).

Revision information is available by querying radios through the Diagnostic
menu.

To remotely query a radio, cable (page 80) the Master radio to the Configuration
PC. From the ControlScape FH Setup/Application Main Menu, select:

 Diagnostic / Network

o the network, by name (as shown).

ProSoft Technology, Inc. Page 49 of 107
November 19, 2013

Guide to the RLX-IFHS User Manual RLX-IFHS ♦ RadioLinx Industrial Wireless
User Manual RadioLinx® Industrial Frequency Hopping Serial Radios

From the Diagnostic Network Menu, select the Remote radio’s icon, then:
 Radio

o Properties

OR
 Double-click the radio’s icon

The Radio Status dialog box displays the following fields and parameters:

Note: The master radio status box does not include signal quality parameters.

Page 50 of 107 ProSoft Technology, Inc.
November 19, 2013

RLX-IFHS ♦ RadioLinx Industrial Wireless Guide to the RLX-IFHS User Manual

In This Chapter

 Radio Hardware .................................................................................... 52

 Connecting the Radio to a Network Device ........................................... 54

RadioLinx® Industrial Frequency Hopping Serial Radios User Manual

2 Installing the Radios

Important: If the radios are close enough to each other that their received signal strength is
greater than -40dBm, performance may be degraded. Disconnect antennas from radios during
bench testing, or move the radios further apart from each other.
Tip: To make it easier to physically identify the radios you are configuring, apply a label to each
radio indicating the radio name.

After you have configured each radio using ControlScape FH, you can install the
radios and test their performance. Install the radios in their proposed permanent
locations, then temporarily place each radio’s antenna near its proposed
mounting location. The temporary placement of the antenna can be by hand;
however, with this testing method, one person must hold the antenna while
another monitors the radio’s signal strength.

To see how a radio is linked in the network, make sure that the radio is
connected to a PC, and then open the Diagnostic menu and choose your
network in ControlScape FH.

The Diagnostic view shows a diagram of the network’s wireless connections. Use

this view to see whether all the radios are linked. Refer to Improve Signal Quality
(page 53) for more information on overcoming poor connectivity.

ProSoft Technology, Inc. Page 51 of 107
November 19, 2013

Guide to the RLX-IFHS User Manual RLX-IFHS ♦ RadioLinx Industrial Wireless

Label Connect to...
+ 10 to 24 VDC
— DC Ground

User Manual RadioLinx® Industrial Frequency Hopping Serial Radios

2.1 Radio Hardware

The RLX-IFHS radio consists of the following components, as illustrated and
explained below:

One antenna port (page 53)
LEDs that indicate the status of the radio
Serial cable ports
Power connection (page 52)

2.1.1 Radio power requirements

The RLX-IFHS radio accepts voltages between 10 and 24 VDC, with an average
power draw of less than 6 watts. A detachable power connector comes with the
radio, as shown. The connector terminals are labeled + (positive DC connection)
and - (DC ground connection). You can use the provided AC-to-DC power supply
adapter that is pre-wired with a power connector, or you can use power from
another source, for example the power supply for the PLC or the networked
devices.

The DC power wires must be less than 3 m to meet regulatory requirements.

Page 52 of 107 ProSoft Technology, Inc.
November 19, 2013

RLX-IFHS ♦ RadioLinx Industrial Wireless Guide to the RLX-IFHS User Manual
RadioLinx® Industrial Frequency Hopping Serial Radios User Manual

2.1.2 Connecting antennas

Each radio must have an antenna connected to the Main antenna port on the
radio; without an antenna for each radio, the network will not function.

All antennas for radios that communicate directly with each other should be
mounted so they have the same antenna polarity. Small antennas with a reverse­polarity SMA connector can be mounted directly on the radio. Screw the antenna
onto the antenna port connector until it is snug.

Larger antennas and antennas that do not have a reverse-gender SMA
connector must be mounted separately and connected to the radio using a
coaxial antenna cable. Because the antenna cable attenuates the RF signal, use
an antenna cable length that is no longer than necessary to ensure optimum
performance.

Important: If the radio is to be used in a hazardous location, the radio must be mounted in an
enclosure approved for hazardous locations. The radio requires a separate cable connection to the
SMA connector that leads to an internal antenna.

Improve signal quality

If you need to improve a radio’s signal quality, try the following steps:

 Adjust the direction of the high-gain antennas.
 Increase the height of the antenna’s placement.
 Use higher-gain antennas or external preamplifiers.
 Select a new location for the radio and/or its antenna.
 Decrease the length of the antenna cable.
 Determine and resolve sources of interfering electrical noise.
 Add a repeater between radios that are not communicating.

ProSoft Technology, Inc. Page 53 of 107
November 19, 2013

Guide to the RLX-IFHS User Manual RLX-IFHS ♦ RadioLinx Industrial Wireless
User Manual RadioLinx® Industrial Frequency Hopping Serial Radios

2.2 Connecting the Radio to a Network Device

2.2.1 Cable Connections

The application ports on the RLX-IFHS module support RS-232, RS-422, and
RS-485 interfaces.

The application ports are located on the bottom of the radio. Do not use the
"CONFIG" port on the top of the radio to connect your device network.

 The RS-232 port uses a standard DB9 connector.
 The RS-485/RS-422 port uses a custom connector, supplied with the radio.

Refer to the following diagrams to construct a port cable suitable for your
application.

RS-232

When the RS-232 interface is selected, the use of hardware handshaking
(control and monitoring of modem signal lines) depends on the requirements of
the networked device. If no hardware handshaking will be used, the cable to
connect to the port is as shown below:

Page 54 of 107 ProSoft Technology, Inc.
November 19, 2013

RLX-IFHS ♦ RadioLinx Industrial Wireless Guide to the RLX-IFHS User Manual
RadioLinx® Industrial Frequency Hopping Serial Radios User Manual

RS-232 Modem Connection

This type of connection is required between the radio and a modem or other
communication device.

The "Use CTS Line" parameter for the serial device should be set to 'Yes' for
most modem applications.

RS-232: Null Modem Connection (Hardware Handshaking)

This type of connection is used when the device connected to the radio requires
hardware handshaking (control and monitoring of modem signal lines).

ProSoft Technology, Inc. Page 55 of 107
November 19, 2013

Guide to the RLX-IFHS User Manual RLX-IFHS ♦ RadioLinx Industrial Wireless
User Manual RadioLinx® Industrial Frequency Hopping Serial Radios

RS-232: Null Modem Connection (No Hardware Handshaking)

This type of connection can be used to connect the radio to a computer or field
device communication port.

Note: If the serial device is configured with to use the CTS line, then a jumper is required between
the RTS and the CTS line on the radio connection.

RS-485

The RS-485 interface requires a single two or three wire cable. The Common
connection is optional and dependent on the RS-485 network. The cable required
for this interface is shown below:

Note: The red switch on the bottom of the RLX-IFHS radio allows you to specify whether the

termination resistors are external or Internal in regards to the radio’s RS-485/RS-422 connector.
Terminating resistors are generally not required on the RS-485 network, unless you are
experiencing communication problems that can be attributed to signal echoes or reflections. In this
case, try changing the settings for termination on the radio.

Page 56 of 107 ProSoft Technology, Inc.
November 19, 2013

RLX-IFHS ♦ RadioLinx Industrial Wireless Guide to the RLX-IFHS User Manual
RadioLinx® Industrial Frequency Hopping Serial Radios User Manual

RS-422

ProSoft Technology, Inc. Page 57 of 107
November 19, 2013

Guide to the RLX-IFHS User Manual RLX-IFHS ♦ RadioLinx Industrial Wireless
User Manual RadioLinx® Industrial Frequency Hopping Serial Radios

Page 58 of 107 ProSoft Technology, Inc.
November 19, 2013

RLX-IFHS ♦ RadioLinx Industrial Wireless Guide to the RLX-IFHS User Manual

In This Chapter

 Diagnostics Overview ............................................................................ 60

 LED Indicators ....................................................................................... 61

 Sources of Interference ......................................................................... 62

 Troubleshoot ControlScape FH Error Messages ................................... 66

 Troubleshoot Missing Radios ................................................................ 68

 RadioLinx OPC Server .......................................................................... 69

RadioLinx® Industrial Frequency Hopping Serial Radios User Manual

3 Diagnostics and Troubleshooting

ProSoft Technology, Inc. Page 59 of 107
November 19, 2013

Guide to the RLX-IFHS User Manual RLX-IFHS ♦ RadioLinx Industrial Wireless
User Manual RadioLinx® Industrial Frequency Hopping Serial Radios

3.1 Diagnostics Overview

Use the Diagnostic function in ControlScape FH to:

 view a graphical representation of the overall function of a network
 query an individual radio and display its operating parameters

The information obtained from the diagnostics function can be used to:

 optimize network function
 determine the source of failed communication

Page 60 of 107 ProSoft Technology, Inc.
November 19, 2013

RLX-IFHS ♦ RadioLinx Industrial Wireless Guide to the RLX-IFHS User Manual

LED

Description

Power/Status

This green LED indicates that the radio has power.

RF Transmit

This yellow LED indicates RF transmission.

RF Receive

This green LED indicates RF reception.

232 / 485

On (illuminated) for RS-232, Off for RS-485/422

Signal Strength

If only one of these three LEDs is illuminated, then the radio is linked. If two
LEDs are illuminated, the radio’s signal strength is fair. If all three LEDs are
illuminated, the signal strength is good.

When a repeater or remote is not linked, the LEDs will illuminate one at a time
in a cycle from top to bottom. When the repeater or remote is linked, the
LEDs will illuminate from bottom to top, with a blinking LED meaning a
median signal strength between the lower LED and the blinking LED.

RadioLinx® Industrial Frequency Hopping Serial Radios User Manual

3.2 LED Indicators

The RLX-IFHS front panel includes a set of LEDs that indicate the radio’s status.
After you first plug in the power cable to the radio, the Power/Status LED should

be green, meaning that the radio has power. The RF Transmit and RF Receive
LEDs should blink.

ProSoft Technology, Inc. Page 61 of 107
November 19, 2013

Guide to the RLX-IFHS User Manual RLX-IFHS ♦ RadioLinx Industrial Wireless
User Manual RadioLinx® Industrial Frequency Hopping Serial Radios

3.3 Sources of Interference

The RadioLinx radio modem operates more reliably than a radio using
conventional technology due to the frequency hopping spread spectrum
technique. While RadioLinx radios are less susceptible to interference due to this
technique, interference (radio "noise") may still occur. Radios are designed to
detect specific radio frequencies. An "interferer" is an unwanted signal that has
been transmitted at the same frequency that the radio was designed to detect.

There are many man-made and natural sources of electromagnetic interference
(lightning, power lines, switching power supplies, fluorescent lighting, microwave
ovens, cordless phones, and so on). To decrease the effects of interference on
network function:

 Use a directional (high gain) antenna at the Remote radio locations, if

possible

 Verify that each network operating in close proximity to each other has BEEN

ASSIGNED TO A DIFFERENT CHANNEL (page 63)

 Install networks in rural areas (if at all possible) where they will likely

encounter less man-made noise than in urban or suburban areas

 Enable encryption
 Change a radio's network output power (refer to the Radio Settings -

Transmit Power sections in the Radio Configuration (page 31) screens for
each type of network):

o Increase power to "drown out" competing noise
o Decrease power of the radios on the network if they are interfering with

another network in the vicinity

Page 62 of 107 ProSoft Technology, Inc.
November 19, 2013

RLX-IFHS ♦ RadioLinx Industrial Wireless Guide to the RLX-IFHS User Manual
RadioLinx® Industrial Frequency Hopping Serial Radios User Manual

3.3.1 Change a Network's Channel

For Transparent, Dialup Modem Emulation and Ethernet Protocols, from the
Graphical Layout Screen of an existing network, select:

 Properties

o Radio Network

The Networks Properties dialog box will then display.

Important: The items on this dialog box depend on what type of radio you select. The following
example shows a network of RadioLinx IFHS (Industrial Frequency Hopping Serial) radios. Refer to
the user manual for your radio for an explanation of each configuration item.

Select an unused Network Channel from the drop-down list.
Refer to the user manual for your radio for an explanation of other configuration

items on this dialog box.

Note: Some fields are "grayed-out" in this dialog box because these parameters cannot be
changed from here.
Note: See When to Re-Configure Radios (page 42) to ensure all radios will be updated.

ProSoft Technology, Inc. Page 63 of 107
November 19, 2013

Guide to the RLX-IFHS User Manual RLX-IFHS ♦ RadioLinx Industrial Wireless
User Manual RadioLinx® Industrial Frequency Hopping Serial Radios

3.3.2 Viewing Radio Channel Noise Level

All radio networks experience background "noise", known as Electromagnetic
Interference (EMI), which consists of such things as stray signals from other
radios on the same frequency, or random interference generated by non-radio
devices that "leak" or emanate EMI as a by-product or side effect of their actual
function. There are also natural sources of EMI, including atmospheric
disturbances and sunspots. The "snow" on an unused or distant television
channel, or "static" on a car radio when passing under high voltage power lines,
are two common examples of background noise.

Unwanted noise, or EMI, on a data network can cause data transmission errors,
or stop a radio network from functioning at all. Most modern devices, including
RadioLinx radios, are designed to prevent unwanted emanation of EMI from the
device. Radios are also typically designed to tolerate a certain amount of
interference from other devices, however when the amount of noise reaches a
certain threshold, typically within 10dB of a link's RSSI, the radio may be unable
to distinguish between wanted and unwanted signals.

ControlScape can help you diagnose transmission problems with a graphical
representation of radio channel noise. You can use this diagnostic information
during a site survey to check for RF signals already present in an area, or to
detect network issues caused by RF interference.

To detect the radio channel noise level for a particular radio, open the UTILITIES
menu, and then choose IFHE SPECTRUM ANALYZER. Select the radio by IP

ADDRESS, and then click OPEN. ControlScape will then scan within the radio, and

measure the noise in the its frequency band. This data can help determine if
there is a signal that is interfering with radio communications. The radio will
continue to periodically scan its frequency band until you click the CLOSE button,
or you select a different radio to scan.

Note: The information in this dialog box is valid only for radios accessible through a wired Ethernet
network. Scans for radios reachable only over the RF network may not be accurate.
Note: Radio network communications are interrupted while the Spectrum Analyzer is active.
Normal communication will resume when you close the dialog box.

Page 64 of 107 ProSoft Technology, Inc.
November 19, 2013

RLX-IFHS ♦ RadioLinx Industrial Wireless Guide to the RLX-IFHS User Manual
RadioLinx® Industrial Frequency Hopping Serial Radios User Manual

3.3.3 IFHE Spectrum Analyzer Dialog Box

The Spectrum Analyzer Dialog Box opens when you open the Utilities menu, and
then select IFHE Spectrum Analyzer. Use this dialog box to help diagnose
network issues.

Note: The information in this dialog box is valid only for radios accessible through a wired Ethernet
network. Scans for radios reachable only over the RF network may not be accurate.
Note: Radio network communications are interrupted while the Spectrum Analyzer is active.
Normal communication will resume when you close the dialog box.

 IP Address: The IP address for the radio to test. Enter an IP address directly,

or click Select Radio to choose a radio.

 Select Radio: Opens the Radio Discovery Tool dialog box. Choose a radio

from the list, and then click OK to select the radio.

 Open: Click to begin testing the radio.
 Close: Click to quit testing the radio and close the Spectrum Analyzer dialog

box.

 Noise Level graphs: The two graphs on this dialog box show current and

peak spectrum values, divided by frequency range. Each bar represents one
of the channels within the frequency range the radio can use.

 Hold: Click to freeze the peak value graph.
 Clear: Click to unfreeze the peak value graph.
 Show Mean Value: Displays the average value of the multiple

measurements taken on each channel during a scan period.

 Show Max Value: Displays the maximum value of the multiple

measurements taken on each channel during a scan period.

ProSoft Technology, Inc. Page 65 of 107
November 19, 2013

Guide to the RLX-IFHS User Manual RLX-IFHS ♦ RadioLinx Industrial Wireless
User Manual RadioLinx® Industrial Frequency Hopping Serial Radios

3.4 Troubleshoot ControlScape FH Error Messages

ControlScape FH displays informative error messages for many types of
communication problems. The following topics describe how to interpret these
messages.

3.4.1 Radio Configuration Status Dialog Box

The Radio Configuration Status dialog box opens when you attempt to
communicate with a radio network in Diagnostic mode, and ControlScape FH is
not able to connect with any radios on the network.

 Click Retry to attempt an automatic baud rate detection sequence.
 Click Cancel to quit attempting to connect to a radio.

3.4.2 Automatic Baud Detection Dialog Box

If ControlScape is unable to open the COM port on the configuration PC, you will
be prompted to check the port configuration. The Automatic Baud Detection
dialog box opens when you click Yes on the message box prompt "The

connected radio is not responding. Do you want to attempt an automatic baud
rate detection sequence?"

ControlScape will attempt to open the port using all available combinations of
baud rate, data bits, parity and stop bits. This procedure may take several
minutes; if you know the correct settings for your COM port, click Cancel, and
then use the Serial Settings dialog box to configure the port.

3.4.3 Invalid Password Dialog Box

The Invalid Password dialog box opens when you enter the network password
incorrectly. Check the status of the Caps Lock key on your keyboard, and then
try entering the password again.

 OK: Click the OK button to save your selection and close the dialog box.
 Help: Click the Help button to read the online help for ControlScape.

Page 66 of 107 ProSoft Technology, Inc.
November 19, 2013

RLX-IFHS ♦ RadioLinx Industrial Wireless Guide to the RLX-IFHS User Manual
RadioLinx® Industrial Frequency Hopping Serial Radios User Manual

3.4.4 Connection Errors

If ControlScape FH is not able to communicate with a radio, it will open a
message box describing the problem.

To troubleshoot communication problems, follow these steps:
 Verify that you can communicate with the Master radio through a serial cable

connection (page 34)

 Verify that ControlScape FH is configured to use the correct serial port on

your PC

 Verify that the communication port on the PC is not in use by another

application or device. In particular, look for and temporarily disable
communication drivers that are commonly installed with PLC programming
tools, and close any other applications, for example HyperTerminal, that may
be using the serial port.

 Verify that the Master radio and remote radios are powered up (page 52)
 Verify that the Remote radios are connected to antennas, (page 53) and are

correctly sited (page 53) to receive signals from the Master radio

 Eliminate sources of interference (page 62).
If you are still unable to connect to a radio, contact ProSoft Technical Support

(page 83) for assistance.

ProSoft Technology, Inc. Page 67 of 107
November 19, 2013

Guide to the RLX-IFHS User Manual RLX-IFHS ♦ RadioLinx Industrial Wireless
User Manual RadioLinx® Industrial Frequency Hopping Serial Radios

3.5 Troubleshoot Missing Radios

To view the communication link any radio can be cabled to the Configuration PC
for network diagnostics.

One of the most common reasons radios do not communicate is an incorrect
setting in the "Send Data To" field in the Radio Configuration dialog box. Verify
that the radio is sending to and receiving from the correct radio ID.

If radios do not communicate, investigate some of the sources of interference
(page 62).

Page 68 of 107 ProSoft Technology, Inc.
November 19, 2013

RLX-IFHS ♦ RadioLinx Industrial Wireless Guide to the RLX-IFHS User Manual
RadioLinx® Industrial Frequency Hopping Serial Radios User Manual

3.6 RadioLinx OPC Server

The RadioLinx OPC Server seamlessly links customer applications to RadioLinx
radios. Any application that can act as an OPC Client, such as an HMI, can
interact with any type of RadioLinx radio. It allows the applications to get signal
strength, serial number and throughput information, as well as other useful
statistics.

The RadioLinx OPC Server operates in the background on any PC. It
independently manages all requests from OPC Clients for information on
RadioLinx radios. The OPC Clients are typically HMI programs, but can also be
easily monitored by Microsoft Excel. The clients can be programs running either
on the same PC as the OPC Server or on a separate PC connected via a
network connection.

You can install the RLX OPC Server from the ProSoft Solutions CD-ROM,
included with your RLX-IFHS radio.

3.6.1 System Requirements

The following system requirements are the recommended minimum
specifications to successfully install and run RadioLinx OPC Driver.

 Microsoft Windows compatible PC
 Windows XP Professional with Service Pack 2 or higher, Windows VISTA, or

Windows 2003

 Microsoft .NET Framework version 3.0 or higher
 300 mHz Pentium processor (or equivalent)
 128 megabytes of RAM
 300 megabytes of available disk space

ProSoft Technology, Inc. Page 69 of 107
November 19, 2013

Guide to the RLX-IFHS User Manual RLX-IFHS ♦ RadioLinx Industrial Wireless
User Manual RadioLinx® Industrial Frequency Hopping Serial Radios

Page 70 of 107 ProSoft Technology, Inc.
November 19, 2013

RLX-IFHS ♦ RadioLinx Industrial Wireless Guide to the RLX-IFHS User Manual

In This Chapter

 Antennas ............................................................................................... 72

 Cable Connections ................................................................................ 79

 Serial Port Basics .................................................................................. 81

RadioLinx® Industrial Frequency Hopping Serial Radios User Manual

4 Reference

ProSoft Technology, Inc. Page 71 of 107
November 19, 2013

Guide to the RLX-IFHS User Manual RLX-IFHS ♦ RadioLinx Industrial Wireless
User Manual RadioLinx® Industrial Frequency Hopping Serial Radios

4.1 Antennas

When you are ready to connect antennas to the radio, see Connecting antennas
(page 53).

You must also consider three important electrical characteristics when selecting
antennas:

 Antenna pattern (page 73)
 Antenna gain (page 73)
 Antenna polarity (page 74)
 Antenna location, spacing, and mounting (page 72)

4.1.1 Antenna location, spacing, and mounting

Consider the following points regarding antenna location, spacing, and mounting:
 When placing antennas, ensure a clear line of sight between the master

radio's antenna and all of the other radio antennas.

 If the site base contains obstructing terrain or structures, mount the antenna

on a tower or rooftop to provide a line-of-sight path. The line-of-sight
consideration becomes more important as the transmission path becomes
longer.

 Mount the antennas as high off the ground as is practical. The higher an

antenna is above the ground, the greater its range.

 Mount the antennas away from massive structures. Radio signals bounce off

metal walls, for example, which can compromise a clear signal.

 Mount antennas to minimize the amount of nearby metal structures in the

antenna pattern.

 Mount the antennas and install radios away from sources of RF interference.
 Use the shortest possible antenna cable length. Signals lose power over the

cable's distance.

 Choose antennas that are appropriate for the network's intended function.
 If antennas are on radios on the same network, mount them so they have the

same polarity. If the antennas are on separate networks, mount them so they
have a different antenna polarity—for example, mount one antenna vertically
and the other horizontally.

 Space radios at least three feet (one meter) apart so they do not overload

each other. If antennas must be near each other:

o Mount omnidirectional antennas directly above each other.
o Position directional antennas so they do not point at nearby antennas.

Place antennas side by side if they point in the same direction. Place
antennas back to back if they point in opposite directions.

Page 72 of 107 ProSoft Technology, Inc.
November 19, 2013

RLX-IFHS ♦ RadioLinx Industrial Wireless Guide to the RLX-IFHS User Manual
RadioLinx® Industrial Frequency Hopping Serial Radios User Manual

4.1.2 Antenna Pattern

Information between two wireless devices is transferred via electromagnetic
energy radiated by one antenna and received by another. The radiated power of
most antennas is not uniform in all directions and has varying intensities. The
radiated power in various directions is called the pattern of the antenna. Each
antenna should be mounted so that its direction of strongest radiation intensity
points toward the other antenna or antennas with which it will exchange signals.

Complete antenna patterns are three-dimensional, although often only a two­dimensional slice of the pattern is shown when all the antennas of interest are
located in roughly the same horizontal plane, along the ground rather than above
or below one another.

A slice taken in a horizontal plane through the center (or looking down on the
pattern) is called the azimuth pattern. A view from the side reveals a vertical
plane slice called the elevation pattern.

An antenna pattern with equal or nearly equal intensity in all directions is
omnidirectional. In two dimensions, an omnidirectional pattern appears as a
circle (in three dimensions, an omnidirectional antenna pattern would be a
sphere, but no antenna has true omnidirectional pattern in three dimensions). An
antenna is considered omnidirectional if one of its two dimensional patterns,
either azimuth or elevation pattern, is omnidirectional.

Beamwidth is an angular measurement of how strongly the power is
concentrated in a particular direction. Beamwidth is a three dimensional quantity
but can be broken into two-dimensional slices just like the antenna pattern. The
beamwidth of an omnidirectional pattern is 360 degrees because the power is
equal in all directions.

4.1.3 Antenna Gain

Antenna gain is a measure of how strongly an antenna radiates in its direction of
maximum radiation intensity compared to how strong the radiation would be if the
same power were applied to an antenna that radiated all of its power equally in
all directions. Using the antenna pattern, the gain is the distance to the furthest
point on the pattern from the origin. For an omnidirectional pattern, the gain is 1,
or equivalently 0 dB. The higher the antenna gain is, the narrower the
beamwidth, and vice versa.

The amount of power received by the receiving antenna is proportional to the
transmitter power multiplied by the transmit antenna gain, multiplied by the
receiving antenna gain. Therefore, the antenna gains and transmitting power can
be traded off. For example, doubling one antenna gain has the same effect as
doubling the transmitting power. Doubling both antenna gains has the same
effect as quadrupling the transmitting power.

ProSoft Technology, Inc. Page 73 of 107
November 19, 2013

Guide to the RLX-IFHS User Manual RLX-IFHS ♦ RadioLinx Industrial Wireless
User Manual RadioLinx® Industrial Frequency Hopping Serial Radios

4.1.4 Antenna Polarity

Antenna polarization refers to the direction in which the electromagnetic field
lines point as energy radiates away from the antenna. In general, the polarization
is elliptical. The simplest and most common form of this elliptical polarization is a
straight line, or linear polarization. Of the transmitted power that reaches the
receiving antenna, only the portion that has the same polarization as the
receiving antenna polarization is actually received. For example, if the
transmitting antenna polarization is pointed in the vertical direction (vertical
polarization, for short), and the receiving antenna also has vertical polarization,
the maximum amount of power possible will be received. On the other hand, if
the transmit antenna has vertical polarization and the receiving antenna has
horizontal polarization, no power should be received. If the two antennas have
linear polarizations oriented at 45° to each other, half of the possible maximum
power will be received.

4.1.5 Whip antennas

You can use a 1/2 wave straight whip or 1/2 wave articulating whip (2 dBi)
antenna with RLX-IFHS radios. These antennas are the most common type in
use today. Such antennas are approximately 5 inches long, and are likely to be
connected to a client radio (connected directly to the radio enclosure). These
antennas do not require a ground plane. Articulating antennas and non­articulating antennas work in the same way. An articulating antenna bends at the
connection.

Page 74 of 107 ProSoft Technology, Inc.
November 19, 2013

RLX-IFHS ♦ RadioLinx Industrial Wireless Guide to the RLX-IFHS User Manual
RadioLinx® Industrial Frequency Hopping Serial Radios User Manual

4.1.6 Collinear array antennas

A collinear array antenna is typically composed of several linear antennas
stacked on top of each other. The more stacked elements it has, the longer it is,
and the more gain it has. It is fed in on one end.

The antenna pattern is torroidal. Its azimuthal beamwidth is 360°
(omnidirectional). Its vertical beamwidth depends on the number of
elements/length, where more elements equal narrower beamwidth. The antenna
gain also depends on the number of elements/length, where more elements
produce higher gain. Typical gain is 5 to 10 dBi.

The antenna polarity is linear, or parallel to the length of the antenna.

ProSoft Technology, Inc. Page 75 of 107
November 19, 2013

Guide to the RLX-IFHS User Manual RLX-IFHS ♦ RadioLinx Industrial Wireless
User Manual RadioLinx® Industrial Frequency Hopping Serial Radios

4.1.7 Yagi Array Antenna

A yagi antenna is composed of an array of linear elements, each parallel to one
another and attached perpendicular to and along the length of a metal boom. The
feed is attached to only one of the elements. Elements on one side of the fed
element are longer and act as reflectors; elements on the other side are shorter
and act as directors. This causes the antenna to radiate in a beam out of the end
with the shorter elements. The pattern depends on the overall geometry,
including the number of elements, element spacing, element length, and so on.
Sometimes the antenna is enclosed in a protective tube hiding the actual
antenna geometry.

The antenna pattern (page 73) is a beam pointed along the boom toward the end
with the shorter elements. The beamwidth varies with antenna geometry but
generally is proportional to the length (where longer length produces a narrower
beam).

The antenna gain (page 73) varies with antenna geometry but generally is
proportional to the length (where longer length produces higher gain). Typical
values are 6 to 15dBi.

The antenna polarity is Linear (parallel to the elements, perpendicular to the
boom).

Refer to the Antenna Types overview section for other types of approved
antennas.

Page 76 of 107 ProSoft Technology, Inc.
November 19, 2013

RLX-IFHS ♦ RadioLinx Industrial Wireless Guide to the RLX-IFHS User Manual
RadioLinx® Industrial Frequency Hopping Serial Radios User Manual

4.1.8 Parabolic reflector antennas

A parabolic reflector antenna consists of a parabolic shaped dish and a feed
antenna located in front of the dish. Power is radiated from the feed antenna
toward the reflector. Due to the parabolic shape, the reflector concentrates the
radiation into a narrow pattern, resulting in a high- gain beam.

The antenna pattern is a beam pointed away from the concave side of the dish.
Beamwidth and antenna gain vary with the size of the reflector and the antenna
construction. Typical gain values are 15 to 30 dBi.

The antenna polarity depends on the feed antenna polarization.

4.1.9 Adding bi-directional amplifiers

A bi-directional amplifier may be needed if an application requires long lengths of
coaxial cable to reach the antenna. The amplifier is designed to put maximum
transmit power right at the antenna and boost the received signal primarily to
overcome the cable loss. You can only use an amplifier from ProSoft Technology
that is specifically approved for use with the RLX-IFHS radio, and only in
countries where the amplifier option is approved.

The bi-directional amplifier is designed to operate with a coaxial cable loss
between the radio and amplifier of 6.5 dB to 20 dB. The output is always 1/2W,
regardless of the input level. With less than 6.5-dB loss, the amplifier maximum
input rating will be exceeded. With more than 20- dB cable loss, the amplifier will
not turn on.

Refer to Amplifier chart (page 77) to view the minimum and maximum lengths of
various cable types required when you use a bi-directional amp.

Refer to Amplifier Diagram (page 78) for an installation diagram of the amplifier
and its power supply.

ProSoft Technology, Inc. Page 77 of 107
November 19, 2013

Guide to the RLX-IFHS User Manual RLX-IFHS ♦ RadioLinx Industrial Wireless

Cable Type

Cable loss/
100' (dB)

Minimum
length (feet)

Loss (dB)

Maximum
length (feet)

Loss (dB)

LMR195

18.2

36

6.5

109

20

LMR400

6.9

94

6.5

289

20

LMR600

4.4

148

6.5

454

20

LDF4-50A

3.9

167

6.5

512

20

LDF5-50A

2

325

6.5

1000

20

User Manual RadioLinx® Industrial Frequency Hopping Serial Radios

Amplifier chart

The following chart lists the minimum and maximum lengths of various cable
types required when you use a bi-directional amplifier.

Amplifier diagram

The following illustration shows proper installation of the amplifier and its power
supply. The DC injector can be located by the radio, and the amplifier should be
at the antenna. The bi-directional amplifier is weather proof and can be mounted
outdoors. Refer to the bi-directional amplifier instructions for more information.

Refer to the amplifier chart (page 77) for minimum and maximum cable lengths.

Page 78 of 107 ProSoft Technology, Inc.
November 19, 2013

RLX-IFHS ♦ RadioLinx Industrial Wireless Guide to the RLX-IFHS User Manual
RadioLinx® Industrial Frequency Hopping Serial Radios User Manual

4.2 Cable Connections

4.2.1 Radio RS-485 Cable Specification

Note: In a 2-Wire Network the Rx+ and the Tx+ as well as the Rx- and the Tx- must be jumpered
externally for this configuration.

ProSoft Technology, Inc. Page 79 of 107
November 19, 2013

Guide to the RLX-IFHS User Manual RLX-IFHS ♦ RadioLinx Industrial Wireless
User Manual RadioLinx® Industrial Frequency Hopping Serial Radios

4.2.2 Radio RS-232 Cable Specifications

The Radio is a DCE device.
The PC is a DTE device.
The following shows the wiring of the straight-through DB-9 serial cable used to

connect:

 A radio to a PLC, PC, or other DTE device
 A radio to another DCE device

Straight-through Serial Cable

Null Modem Cable Wiring Diagram

Page 80 of 107 ProSoft Technology, Inc.
November 19, 2013

RLX-IFHS ♦ RadioLinx Industrial Wireless Guide to the RLX-IFHS User Manual
RadioLinx® Industrial Frequency Hopping Serial Radios User Manual

4.3 Serial Port Basics

PC communications depend primarily on serial and parallel ports to interface the
PC to the outside world. A "port" is a connection or plug-in that gives access to
the PC. The port allows the computer to communicate with devices such as
printers, input devices (serial mouse), and modems.

The serial port is more difficult to interface to than the parallel port because most
serial devices require that the serial transmission consists of characters that are
converted into a parallel format. This conversion is accomplished with a
communications controller chip, (UART: Universal Asynchronous
Receiver/Transmitter).

Two common serial interface standards are RS-232 and RS-485. The RS-232
protocol is an industry standard protocol while the RS-485 protocol is commonly
used in the industrial automation market.

There are two types of devices to which a serial-cabled device can communicate:
 DCE (Data Communications Equipment): modem, plotter, "RadioLinx Radio

Modem".

 DTE (Data Terminal Equipment): PC or terminal
Serial ports have two common connector styles:

 DB25 pin connector
 DB 9 pin connector

Today’s typical PC has one parallel port and two DTE serial ports (both are male
connectors). To connect two DTE devices to each other, the easiest (and
recommended) connection method is with a Null Modem cable (female
connectors on each end). This is commonly used as a quick and inexpensive
way to transfer files between two PCs without having to install a dedicated
network card in each PC.

Note: The RadioLinx radio modem is a DCE device.

ProSoft Technology, Inc. Page 81 of 107
November 19, 2013

Guide to the RLX-IFHS User Manual RLX-IFHS ♦ RadioLinx Industrial Wireless

Pin Name

Pin Number
DB9 / DB25

Function

Transmit Data (TXD)

Pin 3 / 2

Serial Data Output

Receive Data (RXD)

Pin 2 / 3

Serial Data Input

Clear-To-Send (CTS)

Pin 7 / 4

This line indicates that the modem is ready to exchange data.

Data-Carrier-Detect (DCD)

Pin 1 / 8

This line becomes active when the modem detects a carrier from the
modem on the other end of the phone line.

Data-Set-Ready (DSR)

Pin 6 / 6

This tells the UART that the modem is ready to establish a link.

Data-Terminal-Ready
(DTR)

Pin 4 / 20

This tells the modem that the UART is ready to exchange data.
Request -To -Send (RTS)

Pin 7 / 4

This line informs the modem that the UART is ready to exchange data.

Ring Indicator (RI)

Pin 9 / 22

Goes active when modem detects a ringing signal

Signal Ground (SG)

Pin 5 / 7

Signal ground

Characteristic

RS-232

RS-485

Maximum cable length

100 feet

4000 feet

Maximum bits/sec.

20kbps

100Mbps

User Manual RadioLinx® Industrial Frequency Hopping Serial Radios

The following table contains the pin functions for both the DB25 and the DB9
connectors:

Communication signals diminish in strength as they travel through cable. The
maximum cable lengths for RS-232 are less than RS-485 because the RS-232
interface is more susceptible to noise. The data performance of RS-232 and RS­485 is similar as long as the cable requirements are met. The following table
gives an estimation of the cable length requirements for the two serial interface
protocols:

There are different ways to transfer data serially; simplex, half-duplex, and full­duplex. Simplex communication mode allows transmission of data in one
direction only. In the half-duplex mode, data can be transferred in both
directions, but not simultaneously. That means data can be transferred over a
single pair of wires, but the data can only be transferred in one direction at a
time. Full-duplex mode utilizes two pairs of wires and the data can be
transferred in both directions simultaneously.

Page 82 of 107 ProSoft Technology, Inc.
November 19, 2013

RLX-IFHS ♦ RadioLinx Industrial Wireless Guide to the RLX-IFHS User Manual

In This Chapter

 Contacting Technical Support ............................................................... 83

 Return Material Authorization (RMA) Policies and Conditions ............... 85

 LIMITED WARRANTY ........................................................................... 87

RadioLinx® Industrial Frequency Hopping Serial Radios User Manual

5 Support, Service & Warranty

Contacting Technical Support

ProSoft Technology, Inc. (ProSoft) is committed to providing the most efficient
and effective support possible. Before calling, please gather the following
information to assist in expediting this process:

1 Product Version Number
2 System architecture
3 Network details

If the issue is hardware related, we will also need information regarding:

1 Module configuration and associated ladder files, if any
2 Module operation and any unusual behavior
3 Configuration/Debug status information
4 LED patterns
5 Details about the serial, Ethernet or fieldbus devices interfaced to the module,

if any.

Note: For technical support calls within the United States, an after-hours answering system allows
24-hour/7-days-a-week pager access to one of our qualified Technical and/or Application Support
Engineers.

ProSoft Technology, Inc. Page 83 of 107
November 19, 2013

Guide to the RLX-IFHS User Manual RLX-IFHS ♦ RadioLinx Industrial Wireless

Internet

Web Site: www.prosoft-technology.com/support
E-mail address: [e-mail]

Asia Pacific
(location in Malaysia)

Tel: [phone], E-mail: [e-mail]
Languages spoken include: Chinese, English

Asia Pacific
(location in China)

Tel: [phone] x888, E-mail: [e-mail]
Languages spoken include: Chinese, English

Europe
(location in Toulouse,

France)

Tel: [phone],
E-mail: [e-mail]
Languages spoken include: French, English

Europe
(location in Dubai, UAE)

Tel: [phone],
E-mail: [e-mail]
Languages spoken include: English, Hindi

North America
(location in California)

Tel: [phone],
E-mail: [e-mail]
Languages spoken include: English, Spanish

Latin America
(Oficina Regional)

Tel: [phone],
E-Mail: [e-mail]
Languages spoken include: Spanish, English

Latin America
(location in Puebla, Mexico)

Tel: [phone],
E-mail: [e-mail]
Languages spoken include: Spanish

Brasil
(location in Sao Paulo)

Tel: [phone],
E-mail: [e-mail]
Languages spoken include: Portuguese, English

User Manual RadioLinx® Industrial Frequency Hopping Serial Radios

Page 84 of 107 ProSoft Technology, Inc.
November 19, 2013

RLX-IFHS ♦ RadioLinx Industrial Wireless Guide to the RLX-IFHS User Manual
RadioLinx® Industrial Frequency Hopping Serial Radios User Manual

5.1 Return Material Authorization (RMA) Policies and Conditions

The following Return Material Authorization (RMA) Policies and Conditions
(collectively, "RMA Policies") apply to any returned product. These RMA Policies
are subject to change by ProSoft Technology, Inc., without notice. For warranty
information, see Limited Warranty (page 87). In the event of any inconsistency
between the RMA Policies and the Warranty, the Warranty shall govern.

5.1.1 Returning Any Product

a) In order to return a Product for repair, exchange, or otherwise, the

Customer must obtain a Return Material Authorization (RMA) number
from ProSoft Technology and comply with ProSoft Technology shipping
instructions.

b) In the event that the Customer experiences a problem with the Product for

any reason, Customer should contact ProSoft Technical Support at one of
the telephone numbers listed above (page 83). A Technical Support
Engineer will request that you perform several tests in an attempt to
isolate the problem. If after completing these tests, the Product is found to
be the source of the problem, we will issue an RMA.

c) All returned Products must be shipped freight prepaid, in the original

shipping container or equivalent, to the location specified by ProSoft
Technology, and be accompanied by proof of purchase and receipt date.
The RMA number is to be prominently marked on the outside of the
shipping box. Customer agrees to insure the Product or assume the risk
of loss or damage in transit. Products shipped to ProSoft Technology
using a shipment method other than that specified by ProSoft Technology,
or shipped without an RMA number will be returned to the Customer,
freight collect. Contact ProSoft Technical Support for further information.

d) A 10% restocking fee applies to all warranty credit returns, whereby a

Customer has an application change, ordered too many, does not need,
etc. Returns for credit require that all accessory parts included in the
original box (i.e.; antennas, cables) be returned. Failure to return these
items will result in a deduction from the total credit due for each missing
item.

ProSoft Technology, Inc. Page 85 of 107
November 19, 2013

Guide to the RLX-IFHS User Manual RLX-IFHS ♦ RadioLinx Industrial Wireless
User Manual RadioLinx® Industrial Frequency Hopping Serial Radios

5.1.2 Returning Units Under Warranty

A Technical Support Engineer must approve the return of Product under ProSoft
Technology’s Warranty:

a) A replacement module will be shipped and invoiced. A purchase order will

be required.

b) Credit for a product under warranty will be issued upon receipt of

authorized product by ProSoft Technology at designated location
referenced on the Return Material Authorization

i. If a defect is found and is determined to be customer generated, or if

the defect is otherwise not covered by ProSoft Technology s warranty,
there will be no credit given. Customer will be contacted and can
request module be returned at their expense;

ii. If defect is customer generated and is repairable, customer can

authorize ProSoft Technology to repair the unit by providing a
purchase order for 30% of the current list price plus freight charges,
duties and taxes as applicable.

5.1.3 Returning Units Out of Warranty

a) Customer sends unit in for evaluation to location specified by ProSoft

Technology, freight prepaid.

b) If no defect is found, Customer will be charged the equivalent of $100

USD, plus freight charges, duties and taxes as applicable. A new
purchase order will be required.

c) If unit is repaired, charge to Customer will be 30% of current list price

(USD) plus freight charges, duties and taxes as applicable. A new
purchase order will be required or authorization to use the purchase order
submitted for evaluation fee.

The following is a list of non-repairable units:

o 3150 - All
o 3750
o 3600 - All
o 3700
o 3170 - All
o 3250
o 1560 - Can be repaired, only if defect is the power supply
o 1550 - Can be repaired, only if defect is the power supply
o 3350
o 3300
o 1500 - All

Page 86 of 107 ProSoft Technology, Inc.
November 19, 2013

RLX-IFHS ♦ RadioLinx Industrial Wireless Guide to the RLX-IFHS User Manual
RadioLinx® Industrial Frequency Hopping Serial Radios User Manual

5.2 LIMITED WARRANTY

This Limited Warranty ("Warranty") governs all sales of hardware, software, and
other products (collectively, "Product") manufactured and/or offered for sale by
ProSoft Technology, Incorporated (ProSoft), and all related services provided by
ProSoft, including maintenance, repair, warranty exchange, and service
programs (collectively, "Services"). By purchasing or using the Product or
Services, the individual or entity purchasing or using the Product or Services
("Customer") agrees to all of the terms and provisions (collectively, the "Terms")
of this Limited Warranty. All sales of software or other intellectual property are, in
addition, subject to any license agreement accompanying such software or other
intellectual property.

5.2.1 What Is Covered By This Warranty

a) Warranty On New Products: ProSoft warrants, to the original purchaser,

that the Product that is the subject of the sale will (1) conform to and
perform in accordance with published specifications prepared, approved
and issued by ProSoft, and (2) will be free from defects in material or
workmanship; provided these warranties only cover Product that is sold as
new. This Warranty expires three (3) years from the date of shipment for
Product purchased on or after January 1st, 2008, or one (1) year from the
date of shipment for Product purchased before January 1st, 2008 (the
"Warranty Period"). If the Customer discovers within the Warranty Period
a failure of the Product to conform to specifications, or a defect in material
or workmanship of the Product, the Customer must promptly notify
ProSoft by fax, email or telephone. In no event may that notification be
received by ProSoft later than 39 months from date of original shipment.
Within a reasonable time after notification, ProSoft will correct any failure
of the Product to conform to specifications or any defect in material or
workmanship of the Product, with either new or remanufactured
replacement parts. ProSoft reserves the right, and at its sole discretion,
may replace unrepairable units with new or remanufactured equipment.
All replacement units will be covered under warranty for the 3 year period
commencing from the date of original equipment purchase, not the date of
shipment of the replacement unit. Such repair, including both parts and

labor, will be performed at ProSoft’s expense. All warranty service will be

performed at service centers designated by ProSoft.

b) Warranty On Services: Materials and labor performed by ProSoft to repair

a verified malfunction or defect are warranteed in the terms specified
above for new Product, provided said warranty will be for the period
remaining on the original new equipment warranty or, if the original
warranty is no longer in effect, for a period of 90 days from the date of
repair.

ProSoft Technology, Inc. Page 87 of 107
November 19, 2013

Guide to the RLX-IFHS User Manual RLX-IFHS ♦ RadioLinx Industrial Wireless
User Manual RadioLinx® Industrial Frequency Hopping Serial Radios

5.2.2 What Is Not Covered By This Warranty

a) ProSoft makes no representation or warranty, expressed or implied, that

the operation of software purchased from ProSoft will be uninterrupted or
error free or that the functions contained in the software will meet or

satisfy the purchaser’s intended use or requirements; the Customer

assumes complete responsibility for decisions made or actions taken
based on information obtained using ProSoft software.

b) This Warranty does not cover the failure of the Product to perform

specified functions, or any other non-conformance, defects, losses or
damages caused by or attributable to any of the following: (i) shipping; (ii)

improper installation or other failure of Customer to adhere to ProSoft’s

specifications or instructions; (iii) unauthorized repair or maintenance; (iv)
attachments, equipment, options, parts, software, or user-created
programming (including, but not limited to, programs developed with any
IEC 61131-3, "C" or any variant of "C" programming languages) not
furnished by ProSoft; (v) use of the Product for purposes other than those
for which it was designed; (vi) any other abuse, misapplication, neglect or
misuse by the Customer; (vii) accident, improper testing or causes
external to the Product such as, but not limited to, exposure to extremes
of temperature or humidity, power failure or power surges; or (viii)
disasters such as fire, flood, earthquake, wind and lightning.

c) The information in this Agreement is subject to change without notice.

ProSoft shall not be liable for technical or editorial errors or omissions
made herein; nor for incidental or consequential damages resulting from
the furnishing, performance or use of this material. The user guide
included with your original product purchase from ProSoft contains
information protected by copyright. No part of the guide may be duplicated
or reproduced in any form without prior written consent from ProSoft.

5.2.3 Disclaimer Regarding High Risk Activities

Product manufactured or supplied by ProSoft is not fault tolerant and is not
designed, manufactured or intended for use in hazardous environments requiring
fail-safe performance including and without limitation: the operation of nuclear
facilities, aircraft navigation of communication systems, air traffic control, direct
life support machines or weapons systems in which the failure of the product
could lead directly or indirectly to death, personal injury or severe physical or
environmental damage (collectively, "high risk activities"). ProSoft specifically
disclaims any express or implied warranty of fitness for high risk activities.

Page 88 of 107 ProSoft Technology, Inc.
November 19, 2013

RLX-IFHS ♦ RadioLinx Industrial Wireless Guide to the RLX-IFHS User Manual
RadioLinx® Industrial Frequency Hopping Serial Radios User Manual

5.2.4 Intellectual Property Indemnity

Buyer shall indemnify and hold harmless ProSoft and its employees from and

against all liabilities, losses, claims, costs and expenses (including attorney’s

fees and expenses) related to any claim, investigation, litigation or proceeding

(whether or not ProSoft is a party) which arises or is alleged to arise from Buyer’s

acts or omissions under these Terms or in any way with respect to the Products.
Without limiting the foregoing, Buyer (at its own expense) shall indemnify and
hold harmless ProSoft and defend or settle any action brought against such
Companies to the extent based on a claim that any Product made to Buyer
specifications infringed intellectual property rights of another party. ProSoft

makes no warranty that the product is or will be delivered free of any person’s

claiming of patent, trademark, or similar infringement. The Buyer assumes all
risks (including the risk of suit) that the product or any use of the product will
infringe existing or subsequently issued patents, trademarks, or copyrights.

a) Any documentation included with Product purchased from ProSoft is

protected by copyright and may not be duplicated or reproduced in any
form without prior written consent from ProSoft.

b) ProSoft’s technical specifications and documentation that are included

with the Product are subject to editing and modification without notice.

c) Transfer of title shall not operate to convey to Customer any right to make,

or have made, any Product supplied by ProSoft.

d) Customer is granted no right or license to use any software or other

intellectual property in any manner or for any purpose not expressly
permitted by any license agreement accompanying such software or other
intellectual property.

e) Customer agrees that it shall not, and shall not authorize others to, copy

software provided by ProSoft (except as expressly permitted in any
license agreement accompanying such software); transfer software to a
third party separately from the Product; modify, alter, translate, decode,
decompile, disassemble, reverse-engineer or otherwise attempt to derive
the source code of the software or create derivative works based on the
software; export the software or underlying technology in contravention of
applicable US and international export laws and regulations; or use the
software other than as authorized in connection with use of Product.

f) Additional Restrictions Relating To Software And Other Intellectual

Property
In addition to compliance with the Terms of this Warranty, Customers

purchasing software or other intellectual property shall comply with any
license agreement accompanying such software or other intellectual
property. Failure to do so may void this Warranty with respect to such
software and/or other intellectual property.

5.2.5 Disclaimer of all Other Warranties

The Warranty set forth in What Is Covered By This Warranty (page 87) are in lieu
of all other warranties, express or implied, including but not limited to the implied
warranties of merchantability and fitness for a particular purpose.

ProSoft Technology, Inc. Page 89 of 107
November 19, 2013

Guide to the RLX-IFHS User Manual RLX-IFHS ♦ RadioLinx Industrial Wireless
User Manual RadioLinx® Industrial Frequency Hopping Serial Radios

5.2.6 Limitation of Remedies **

In no event will ProSoft or its Dealer be liable for any special, incidental or
consequential damages based on breach of warranty, breach of contract,
negligence, strict tort or any other legal theory. Damages that ProSoft or its
Dealer will not be responsible for include, but are not limited to: Loss of profits;
loss of savings or revenue; loss of use of the product or any associated
equipment; loss of data; cost of capital; cost of any substitute equipment,
facilities, or services; downtime; the claims of third parties including, customers of
the Purchaser; and, injury to property.

** Some areas do not allow time limitations on an implied warranty, or allow the exclusion or
limitation of incidental or consequential damages. In such areas, the above limitations may not
apply. This Warranty gives you specific legal rights, and you may also have other rights which vary
from place to place.

5.2.7 Time Limit for Bringing Suit

Any action for breach of warranty must be commenced within 39 months
following shipment of the Product.

5.2.8 No Other Warranties

Unless modified in writing and signed by both parties, this Warranty is
understood to be the complete and exclusive agreement between the parties,
suspending all oral or written prior agreements and all other communications
between the parties relating to the subject matter of this Warranty, including
statements made by salesperson. No employee of ProSoft or any other party is
authorized to make any warranty in addition to those made in this Warranty. The
Customer is warned, therefore, to check this Warranty carefully to see that it
correctly reflects those terms that are important to the Customer.

5.2.9 Allocation of Risks

This Warranty allocates the risk of product failure between ProSoft and the
Customer. This allocation is recognized by both parties and is reflected in the
price of the goods. The Customer acknowledges that it has read this Warranty,
understands it, and is bound by its Terms.

Page 90 of 107 ProSoft Technology, Inc.
November 19, 2013

RLX-IFHS ♦ RadioLinx Industrial Wireless Guide to the RLX-IFHS User Manual
RadioLinx® Industrial Frequency Hopping Serial Radios User Manual

5.2.10 Controlling Law and Severability

This Warranty shall be governed by and construed in accordance with the laws of
the United States and the domestic laws of the State of California, without
reference to its conflicts of law provisions. If for any reason a court of competent
jurisdiction finds any provisions of this Warranty, or a portion thereof, to be
unenforceable, that provision shall be enforced to the maximum extent
permissible and the remainder of this Warranty shall remain in full force and
effect. Any cause of action with respect to the Product or Services must be
instituted in a court of competent jurisdiction in the State of California.

ProSoft Technology, Inc. Page 91 of 107
November 19, 2013

Glossary of Terms RLX-IFHS ♦ RadioLinx Industrial Wireless
User Manual RadioLinx® Industrial Frequency Hopping Serial Radios

Glossary of Terms

Symbols & Numeric

802.11

A group of wireless specifications developed by the IEEE. It details a wireless
interface between devices to manage packet traffic.

802.11a

Operates in the 5 GHz frequency range with a maximum 54 Mbit/sec signaling
rate.

802.11b

Operates in the 2.4 GHz Industrial, Scientific, and Measurement (ISM) band.
Provides signaling rates of up to 11 Mbit/sec and is the most commonly used
frequency.

802.11g

Similar to 802.11b but supports signaling rates of up to 54 Mbit/sec. Operates in
the heavily used 2.4 GHz ISM band but uses a different radio technology to boost
throughput.

802.11i

Sometimes Wi-Fi Protected Access 2 (WPA 2). WPA 2 supports the 128-bit and
above advanced encryption Standard, along with 802.1x authentication and key
management features.

802.11n

Designed to raise effective WLAN throughput to more than 100 Mbit/sec.

802.11s

Deals with mesh networking.

A

Access Point

A generic term for an 802.11 radio that "attaches" other 802.11 radios (clients) to
a wired network. APs can also bridge to one another.

Ad hoc Mode

Wireless network framework in which devices can communicate directly with one
another without using an AP or a connection to a regular network.

AES

Advanced Encryption Standard. New standard for encryption adopted by the U.S.
government for secure communications.

Page 92 of 107 ProSoft Technology, Inc.
November 19, 2013

RLX-IFHS ♦ RadioLinx Industrial Wireless Glossary of Terms
RadioLinx® Industrial Frequency Hopping Serial Radios User Manual

Amplifier

A device connected to an antenna used to increase the signal strength and
amplify weak incoming signals.

Antenna

A device connected to a wireless transceiver that concentrates transmitted and
received radio waves to increase signal strength and thus the effective range of a
wireless network.

ASCII

American Standard Code for Information Interchange. A communication mode in
which each eight-bit byte in a message contains one ASCII character code.
ASCII characters (or hexadecimal characters) are sometimes used as a key to
encrypt data and ensure its secure transmission.

Association

Process whereby two 802.11 radios establish communications with each other.
Requirements for communication include common SSID (network names) and
encryption settings.

Authenticate

The process of confirming the identity of someone connecting to a network.

Authentication Server

A back-end database server that confirms the identity of a supplicant to an
authenticator in an 802.1x-authenticated network.

B

Band

Another term for spectrum used to indicate a particular set of frequencies.
Wireless networking protocols work in either the 2.4 GHz or the 5 GHz bands.

Bandwidth

(See Throughput)

Base Station

See Wireless Gateway

Baud Rate

The speed of communication between devices on the network. All devices must
communicate at the same rate.

bps

Bits per Second. A measure of data transmission speed across a network or
communications channel; bps is the number of bits that can be sent or received
per second.

ProSoft Technology, Inc. Page 93 of 107
November 19, 2013

Glossary of Terms RLX-IFHS ♦ RadioLinx Industrial Wireless
User Manual RadioLinx® Industrial Frequency Hopping Serial Radios

C

Channel

One portion of the available radio spectrum that all devices on a wireless network
use to communicate. Changing the channel on the access point/router can help
reduce interference.

Client

A client is a software program, or the device on which that program runs, that
makes requests for information from a software program, or the device on which
that program runs, in a client-server relationship.

A Client on an Ethernet network is equivalent to a Master on a serial network.

Configuration PC

A Computer that contains the configuration tools for the RLX-IFHS.

D

dBi

Decibels referenced to an "ideal" isotropic radiator in free space; frequently used
to express antenna gain

dBm

Decibels referenced to one milliwatt (mW); an "absolute" unit used to measure
signal power (transmit power output or received signal strength)

DCE

Data communications equipment. A modem, for example.

Decibel (dB)

A measure of the ratio between two signal levels; used to express gain (or loss)
in a system.

Default Gateway

The IP address of a network router where data is sent if the destination IP
address is outside the local subnet. The gateway is the device that routes the
traffic from the local area network to other networks such as the Internet.

Device-to-Device Network (Peer-to-Peer Network)

Two or more devices that connect using wireless network devices without the
use of a centralized wireless access point. Also known as a peer-to-peer
network.

Page 94 of 107 ProSoft Technology, Inc.
November 19, 2013

RLX-IFHS ♦ RadioLinx Industrial Wireless Glossary of Terms
RadioLinx® Industrial Frequency Hopping Serial Radios User Manual

DHCP

The dynamic host configuration protocol is an Internet protocol, similar to BootP,
for automating the configuration of computers that use TCP/IP. DHCP can be
used to automatically assign IP addresses, to deliver IP stack configuration
parameters, such as the subnet mask and default router, and to provide other
configuration information, such as the addresses for printer, time, and news
servers.

Direct Sequence Spread Spectrum

One of two approaches (with frequency hopping spread spectrum) for sorting out
overlapping data signals transmitted via radio waves. 802.11b uses DSSS

Directional Antenna

Transmits and receives radio waves off the front of the antenna.

Diversity Antenna

An antenna system that uses multiple antennas to reduce interference and
maximize reception and transmission quality.

DTE

Data Terminal Equipment, for example, a computer or terminal.

Dual Band

A device that is capable of operating in two frequencies. On a wireless network,
dual-band devices are capable of operating in both the 2.4 GHz (802.11b/g) and
5 GHz (802.11a) bands.

E

EAP

Extensible Authentication Protocol. A protocol that provides an authentication
framework for both wireless and wired Ethernet enterprise networks.

EIRP

Equivalent isotropically radiated power (EIRP) is the amount of power that would
have to be emitted by an isotropic antenna (that evenly distributes power in all
directions and is a theoretical construct) to produce the peak power density
observed in the direction of maximum antenna gain.

Encryption

Method of scrambling data so that only the intended viewers can decipher and
understand it.

ESD

Electrostatic Discharge. Can cause internal circuit damage to the coprocessor.

ESSID

Extended Service Set Identifier. A name used to identify a wireless network.

ProSoft Technology, Inc. Page 95 of 107
November 19, 2013

Glossary of Terms RLX-IFHS ♦ RadioLinx Industrial Wireless
User Manual RadioLinx® Industrial Frequency Hopping Serial Radios

F

Firmware

Firmware is the embedded software code that that runs in the module to direct
module function (similar to the BIOS in a personal computer). This is
distinguished from the Setup/Diagnostic Application software that is installed on
the Configuration PC.

Frequency Hopping

A radio that rapidly changes its operating frequency several times per second
following a pre-determined sequence of frequencies. The transmitting and
receiving radios are programmed to follow the same frequency hopping
sequence.

Frequency Hopping Spread Spectrum

Changes or hops frequencies in pattern known to both sender and receiver.
FHSS is little influenced by radio stations, reflections, or other environmental
factors. However, it is much slower than DSSS.

Fresnel Zone

An elliptical area on either side of the straight line of sight that must also be clear
for a long-range wireless network to work.

Full-Duplex

A communications circuit or system designed to simultaneously transmit and
receive two different streams of data. Telephones are an example of a full-duplex
communication system. Both parties on a telephone conversation can talk and
listen at the same time. If both talk at the same time, their two signals are not
corrupted.

G

Gain

The amount by which an antenna concentrates signal strength in a wireless
network.

Gateway

In wireless terms, a gateway is an access point with additional software
capabilities such as providing NAT and DHCP.

H

Half-Duplex

A communications circuit or system designed to transmit and receive data, but
not both simultaneously. CB or walkie-talkie radios are an example of a half­duplex communication system. Either parties on a radio conversation may talk or
listen; but both cannot talk at the same time without corrupting each other's
signal. If one operator is "talking", the other must be "listening" to have
successful communication.

Page 96 of 107 ProSoft Technology, Inc.
November 19, 2013

RLX-IFHS ♦ RadioLinx Industrial Wireless Glossary of Terms
RadioLinx® Industrial Frequency Hopping Serial Radios User Manual

Hz

Hertz. The international unit for measuring frequency equivalent to the older unit
of cycles per second. One megahertz (MHz) is one million hertz. One gigahertz
(GHz) is one billion hertz. The standard US electrical power frequency is 60 Hz.

802.11a devices operate in the 5 GHz band; 802.11b and g devices operate in
the 2.4 GHz band.

I

IEEE

Institute of Electrical and Electronics Engineers, Inc. IEEE is a professional
organization with members in over 175 countries and is an authority in technical
areas such as computer engineering and telecommunications. IEEE developed
the 802.11 specifications.

IP Address

A 32-bit identification number for each node on an Internet Protocol network.
These addresses are represented as four sets of 8-bit numbers (numbers from 0
to 255), separated by periods ("dots").

Networks using the TCP/IP Protocol route messages based on the IP address of
the destination. Each number can be 0 to 255. For example, 192.168.0.100 could
be an IP address. Each node on the network must have a unique IP address.

K

Key

A set of information (often 40 to as much as 256 bits) that is used as a seed to an
encryption algorithm to encrypt (scramble) data. Ideally, the key must also be
known by the receiver to decrypt the data.

L

LAN

A system of connecting PCs and other devices within the same physical
proximity for sharing resources such as internet connections, printers, files, and
drives. When Wi-Fi is used to connect the devices, the system is known as a
wireless LAN or WLAN.

LED

Light-emitting diode.

Line of Sight (LoS)

A clear line from one antenna to another in a long-range wireless network.

Link point

The graphical point next to a radio icon that represents the connection point for
RF communications between radios. An RF connection between two radios is
called an RF Link and is represented as a graphical black line between the
radio’s link points.

ProSoft Technology, Inc. Page 97 of 107
November 19, 2013

Glossary of Terms RLX-IFHS ♦ RadioLinx Industrial Wireless
User Manual RadioLinx® Industrial Frequency Hopping Serial Radios

M

MAC ID

Media Access Control address. Every 802.11 device has its own MAC address.
This is a unique identifier used to provide security for wireless networks. When a
network uses a MAC table, only the 802.11 radios that have had their MAC
addresses added to the network’s MAC table are able to get on the network.

Master device

Device that is connected to the Master radio.

Mbps

Megabits per second, or millions of bits per second. A measure of bandwidth.

Megahertz

A measure of electromagnetic wave frequency equal to one million hertz. Often
abbreviated as MHz and used to specify the radio frequency used by wireless
devices.

Mesh Networking

Features free standing, non wired network nodes that communicate among one
another and form self-configuring networks, with only one node required to hook
into a wired LAN. The other nodes are simply plugged into an electrical outlet, so
cabling is much less of an issue.

MIC

Message Integrity Check. One of the elements added to the TKIP standard. A
"signature" is added by each radio on each packet it transmits. The signature is
based on the data in the packet, a 64-bit value (key) and the MAC address of the
sender. The MIC allows the receiving radio to verify (check) that the data is not
forged.

MIMO

Multiple Input Multiple Output refers to using multiple antennas in a Wi-Fi device
to improve performance and throughput. MIMO technology takes advantage of a
characteristic called multipath, which occurs when a radio transmission starts out
at Point A and the reflects off or passes through surfaces or objects before
arriving, via multiple paths, at Point B. MIMO technology uses multiple antennas
to collect and organize signals arriving via these paths.

Modbus

The Modbus protocol provides the internal standard that the MODICON®
controllers use for parsing messages. During communications on a Modbus
network, the protocol determines how each controller will know its device
address, recognize a message addressed to it, determine the kind of action to be
taken, and extract any data or other information contained in the message. If a
reply is required, the controller will construct the reply message and send it using
Modbus protocol.

Page 98 of 107 ProSoft Technology, Inc.
November 19, 2013

RLX-IFHS ♦ RadioLinx Industrial Wireless Glossary of Terms
RadioLinx® Industrial Frequency Hopping Serial Radios User Manual

Modem

Stands for MODulator-DEModulator, a device that converts digital signals to
analog signals and vice-versa. Analog signals can be transmitted over
communications links such as telephone lines.

N

Network

A series of stations or nodes connected by some type of communication medium.
A network may consist of a single link or multiple links.

Node

An address or software location on the network.

Null Modem Cable

A specialty cross-communication cable with female connectors on each end used
for direct connection between devices when no modems are present. Commonly
used as a quick and inexpensive way to transfer files between two PCs without
installing a dedicated network card in each PC.

P

Panel Antenna

An antenna type that radiates in only a specific direction. Panel antennas are
commonly used for point-to-point situations. Sometimes called Patch antennas.

Parabolic Antenna

An antenna type that radiates a very narrow beam in a specific direction.
Parabolic antennas offer the highest gain for long-range point-to-point situations.

Peer-to-Peer Network

Each radio in a Peer-to-Peer network has the ability to receive data from - and
transmit data to - any other radio in the network.

Point-Multipoint (Broadcast) Network

A network type where a single master radio sends data to every remote radio in
the network. This is done repeatedly until every remote radio individually receives
and acknowledges the data. Each remote radio sends pending data to the
master radio that receives and acknowledges data sent from each remote. In this
configuration, there are multiple remote radios referenced to a single master
radio.

Point-Multipoint (Modbus) Network

A network with a single Master radio and multiple Remote radios. The devices
cabled to the radios communicate through the Modbus standard protocol. The
Master radio sends data to a Remote radio based on the Modbus address of the
Modbus device. The data is only sent to the single Remote device based on its
address. Each Remote radio sends its data only to the Master radio. The Master
and Remote radios acknowledge that data was received correctly.

ProSoft Technology, Inc. Page 99 of 107
November 19, 2013

Glossary of Terms RLX-IFHS ♦ RadioLinx Industrial Wireless
User Manual RadioLinx® Industrial Frequency Hopping Serial Radios

Point-to-Multipoint

A wireless network in which one point (the access point) serves multiple other
points around it. Indoor wireless networks are all point-to-multipoint, and long­range wireless networks that serve multiple clients usually employ either a single
omnidirectional antenna or multiple sector antennas.

Point-to-Point Network

A network consisting of a single Master radio and a single Remote radio. All data
from the Master is received and acknowledged by one Remote. All data from the
single Remote is received and acknowledged by the Master radio.

Poll

A method of electronic communication.

Power Supply

Device that supplies electrical power to the I/O chassis containing the processor,
coprocessor, or other modules.

Protocol

The language or packaging of information that is transmitted between nodes on a
network.

Q

QoS

Quality of Service. Required to support wireless multimedia applications and
advanced traffic management. QoS enables Wi-Fi access points to prioritize
traffic and optimize the way shared network resources are allocated among
different applications.

R

RADIUS

Remote Access Dial-In Service. This describes a general method for allowing
remote users access to a network. It authenticates the user, specifies passwords
and access rights to network resources. It also keeps track of accounting for
when and how long the user is logged onto the network. It was originally used for
dial-in users, accessing corporate networks via modems. It is now being
specified as part of the 802.11i standard to control access of users to wireless
networks. Any of several protocols can be used by the wireless client to
communicate with the RADIUS server to gain access to the network resources.
These protocols include EAP-TLS (Windows), LEAP (Cisco) and EAP-TTLS.

Range

The distance covered by a wireless network radio device. Depending on the
environment and the type of antenna used, Wi-Fi signals can have a range of up
to a mile.

Page 100 of 107 ProSoft Technology, Inc.
November 19, 2013
