Pilz PNOZ 11 Data Sheet

E-STOP relay, safety gate monitor
Up to Category 4, EN 954-1
PNOZ 11
Safety relay for monitoring E-STOP pushbuttons and safety gates.
PNOZ 11
Unit features
` Positive-guided relay outputs:
– 7 safety contacts (N/O), instanta-
neous
– 1 auxiliary contact (N/C), instan-
taneous
` Connection options for:
– E-STOP pushbutton – Safety gate limit switch – Reset button
` LED indicator for:
– Switch status channel 1/2 – Supply voltage – Reset circuit – Input circuits
` Semiconductor output signals:
– Switch status channel 1/2 – Supply voltage is present
` See order reference for unit types
Unit description
The safety relay meets the require­ments of EN 60204-1 and IEC 60204­1 and may be used in applications with
` E-STOP pushbuttons ` Safety gates
Safety features
The relay conforms to the following safety criteria:
` The circuit is redundant with built-in
self-monitoring.
` The safety function remains effecti-
ve in the case of a component failu­re.
` The correct opening and closing of
the safety function relays is tested automatically in each on-off cycle.
` The tranformer is short circuit-
proof.
Block diagram
B1 B2 13 23 33 43
=
=
A1 A2 Y1 Y2
Power
S11 S12 S21 S22
=
Feed-
back
~
S31 S32
InputInput
0 V 24 V
Y30 Y31 Y32 Y35
Input
Reset/
Start
S37S33 S34
Reset/
Start
K1
K2
14 24 34 44
53 63 73 81
54 64 74 82
Pilz GmbH & Co. KG, Sichere Automation, Felix-Wankel-Straße 2, 73760 Ostfildern, Germany Telephone: +49 711 3409-0, Telefax: +49 711 3409-133, E-Mail: pilz.gmbh@pilz.de
NSG-D-2-058-12/04
E-STOP relay, safety gate monitor
Up to Category 4, EN 954-1
PNOZ 11
Function description
` Single-channel operation: no red-
undancy in the input circuit, earth faults in the reset circuit are detec­ted.
` Dual-channel operation with detec-
tion of shorts across contacts: red­undant input circuit, detects – earth faults in the reset and input
circuit,
Timing diagram
1 2
POWER
Reset/Start
Input
Output safe
Output aux.
Out semi RUN
Out semi CH
t1 t2
t1 t2
– short circuits in the input circuit
and, with a monitored reset, in the reset circuit too,
– shorts between contacts in the
input circuit.
` Automatic start: Unit is active once
the input circuit has been closed.
` Manual reset: Unit is active once
the input circuit is closed and then the reset circuit is closed.
` M on it or ed re se t: Un i t i s ac ti ve on c e
ab
t1
t1
t2
– the input circuit is closed and
then the reset circuit is closed and opened again.
– the reset circuit is closed and
then opened again once the in­put circuit is closed.
` Increase in the number of available
contacts by connecting contact ex­pander modules or external contac­tors/relays.
ab
t2
t1
3
t2
t1
t2
Key
` Power: Supply voltage ` Reset/start: Reset circuit S33-S34,
S34-S37
` Input: Input circuits S11-S12, S21-
S22, S31-S32
` Output safe: Safety contacts 13-14,
23-24, 33-34, 43-44, 53-54, 63-64, 73-74
Wiring
Please note:
` Information given in the “Technical
details” must be followed.
` Outputs 13-14, 23-24, 33-34, 43-
44, 53-54, 63-64, 73-74 are safety contacts, output 81-82 is an auxilia­ry contact (e.g. for display).
` To prevent contact welding, a fuse
should be connected before the output contacts (see technical de­tails).
` Calculation of the max. cable runs
in the input circuit:
l
max
R
lmax
=
I
max
Rl / km
` Output aux: Auxiliary contacts 81-
82
` Out semi RUN: Semiconductor out-
put supply voltage Y35
` Out semi CH: Semiconductor out-
put switch status Y32
` c: Automatic reset ` d: Manual reset
R
= max. overall cable resi-
lmax
stance (see technical details)
/ km = cable resistance/km
R
l
` Use copper wire that can withstand
60/75 °C.
` Sufficient fuse protection must be
provided on all output contacts with capacitive and inductive loads.
` e: Monitored reset ` a: Input circuit closes before reset
circuit
` b: Reset circuit closes before input
circuit
: Switch-on delay
` t
1
` t2: Delay-on de-energisation
Telephone: +49 711 3409-0, Telefax: +49 711 3409-133, E-Mail: pilz.gmbh@pilz.de
NSG-D-2-058-12/04Pilz GmbH & Co. KG, Sichere Automation, Felix-Wankel-Straße 2, 73760 Ostfildern, Germany
-2
E-STOP relay, safety gate monitor
Up to Category 4, EN 954-1
PNOZ 11
Preparing for operation
` Supply voltage
Supply voltage AC DC
A1
A2
B2 PE
L1
N
` Input circuit
Input circuit Single-channel Dual-channel E-STOP
without detection of shorts across contacts
S21 S22
S12 S11 S32
S31
S1
E-STOP with detection of shorts across con­tacts
S11 S12
Safety gate without detection of shorts across contacts
S21 S22
S12 S11 S32
S31
S1
B1
B2
S22 S32 S31 S21
L+
L-
S1
Safety gate with detection of shorts across con­tacts
Pilz GmbH & Co. KG, Sichere Automation, Felix-Wankel-Straße 2, 73760 Ostfildern, Germany Telephone: +49 711 3409-0, Telefax: +49 711 3409-133, E-Mail: pilz.gmbh@pilz.de
S11 S12
S22 S21 S32
S31
S1
NSG-D-2-058-12/04
S2
E-STOP relay, safety gate monitor
Up to Category 4, EN 954-1
PNOZ 11
` Reset circuit
Reset circuit E-STOP wiring, safety gate Safety gate (dual-channel) Automatic reset
S33
Manual reset
Monitored reset
S34
S3
S33
S34
S3 S33 S34
S37
S33 S34
` Feedback loop
Feedback loop Automatic reset Manual/monitored reset: Link
Contacts from external contactors
13 (23 ... 73) 14 (24 ... 74)
Y1 Y2
Y1
Y2
K5
K6
K5
K6
L1 N
Y1 Y2
13 (23 ... 73) 14 (24 ... 74)
Y1
Y2
K5
K6
K5
K6
S2S1
L1 N
` Semiconductor output
Y31 Y32 Y35 Y30
Telephone: +49 711 3409-0, Telefax: +49 711 3409-133, E-Mail: pilz.gmbh@pilz.de
24 V DC SPS Input SPS Input 0 V
NSG-D-2-058-12/04Pilz GmbH & Co. KG, Sichere Automation, Felix-Wankel-Straße 2, 73760 Ostfildern, Germany
-4
E-STOP relay, safety gate monitor
Up to Category 4, EN 954-1
PNOZ 11
` Key
S1 E-STOP pushbutton
S1/S2 Two-hand button
S1/S2
E-STOP pushbutton/ safety gate switch
S3 Reset button
Switch operated
Gate open
Gate closed
Pilz GmbH & Co. KG, Sichere Automation, Felix-Wankel-Straße 2, 73760 Ostfildern, Germany Telephone: +49 711 3409-0, Telefax: +49 711 3409-133, E-Mail: pilz.gmbh@pilz.de
NSG-D-2-058-12/04
E-STOP relay, safety gate monitor
Up to Category 4, EN 954-1
PNOZ 11
Terminal configuration
Installation
` The safety relay should be installed
in a control cabinet with a protec­tion type of at least IP54.
` Use the notch on the rear of the unit
to attach it to a DIN rail.
` Ensure the unit is mounted securely
on a vertical DIN rail (35 mm) by using a fixing element (e.g. retaining bracket or an end angle).
Dimensions
Y1
S22S21
B1A1 13
POWER CH. 1 IN CH. 2 IN START CH. 1 CH. 2
Y2
14
S33
S11
S12
PNOZ 11
24
S34
23
44
34
121 (4.76")
S34 S37S31 S32 Y30 Y31 Y32 Y35
33
43
13142324333443445354636473 81
54
7464 82
/B2
816353 73
8274
A2
75 (2.95")
87 (3.42")
Telephone: +49 711 3409-0, Telefax: +49 711 3409-133, E-Mail: pilz.gmbh@pilz.de
90 (3.54")
NSG-D-2-058-12/04Pilz GmbH & Co. KG, Sichere Automation, Felix-Wankel-Straße 2, 73760 Ostfildern, Germany
-6
E-STOP relay, safety gate monitor
Up to Category 4, EN 954-1
PNOZ 11
Notice
Service life graph
This data sheet is only intended for use during configuration. For installation and operation, please refer to the ope-
10
AC1: 230 V
rating instructions supplied with the unit.
DC13: 24 V
1
D Nennbetriebstrom (A)
GB Nominal operating current (A)
F Courant coupé (A)
Technical details
Electrical data
Supply voltage Supply voltage U Supply voltage U
AC 24 V, 42 V, 48 V, 110 - 120 V, 230 - 240 V
B
DC 24 V
B
Voltage tolerance -15 %/+10 % Power consumption at U Power consumption at U
AC 9.0 VA
B
DC 3.5 W
B
Frequency range AC 50 - 60 Hz Residual ripple DC 160 % Voltage and current at input circuit DC: 24.0 V 50.0 mA reset circuit DC: 24.0 V 45.0 mA feedback loop DC: 24.0 V 45.0 mA Output contacts in accordance with EN 954-1 Category 4 Safety contacts (N/O): 7
Utilisation category in accordance with EN 60947-4-1 Safety contacts: AC1 at 240 V I
Safety contacts: AC1 at 400 V I
Safety contacts: DC1 at 24 V I
Auxiliary contacts: AC1 at 240 V I
Auxiliary contacts: DC1 at 24 V I
Utilisation category in accordance with EN 60947-5-1 Safety contacts: AC15 at 230 V I Safety contacts: DC13 at 24 V (6 cycles/min) I Auxiliary contacts: AC15 at 230 V I Auxiliary contacts: DC13 at 24 V (6 cycles/min) I
0.1
E Corriente nominal de servicio (A)
I Corrente di esercizio nominale (A)
NL Nominale bedrijfsstroom (A)
10 100 1000 10000
D Schaltspielzahl x 10 GB Cycles x 10 F Nombre de manvres x 10
Auxiliary contacts (N/C): 1
: 0.01 A , I
min
P
: 2,000 VA
max
: 0.01 A , I
min
: 2,000 VA
P
max
: 0.01 A , I
min
P
: 200 W
max
: 0.01 A , I
min
P
: 2,000 VA
max
: 0.01 A , I
min
: 200 W
P
max
: 5.0 A
max
: 7.0 A
max
: 5.0 A
max
: 7.0 A
max
3
3
: 8.00 A
max
: 5.00 A
max
: 8.0 A
max
: 8.0 A
max
: 8.0 A
max
DC1: 24 V
AC1: 400 V
AC15: 230 V
E Número de ciclos x 10 I Numero dei cicli di commutazione x 10
3
NL Aantal schakelingen x 10
3
3
3
Pilz GmbH & Co. KG, Sichere Automation, Felix-Wankel-Straße 2, 73760 Ostfildern, Germany Telephone: +49 711 3409-0, Telefax: +49 711 3409-133, E-Mail: pilz.gmbh@pilz.de
NSG-D-2-058-12/04
E-STOP relay, safety gate monitor
Up to Category 4, EN 954-1
PNOZ 11
Electrical data
External contact fuse protection to EN 60947-5-1 Blow-out fuse, quick Safety contacts: 10 A Auxiliary contacts: 10 A Blow-out fuse, slow Safety contacts: 6 A Auxiliary contacts: 6 A Circuit breaker 24 VAC/DC, characteristic B/C Safety contacts: 6 A Auxiliary contacts: 6 A Semiconductor outputs (short circuit proof) 24.0 V DC, 20 mA External supply voltage 24.0 V DC
Voltage tolerance -20 %/+20 % Max. overall cable resistance R single-channel at U single-channel at U dual-channel with detect. of shorts across contacts at U dual-channel with detect. of shorts across contacts at U
Times
Switch-on delay with automatic reset max. 450 ms with automatic reset after power on max. 480 ms with manual reset typ. 335 ms with manual reset max. 450 ms with monitored reset max. 450 ms Delay-on de-energisation with E-STOP typ. 17 ms with E-STOP max. 30 ms with power failure typ. 40 ms with power failure max. 60 ms Recovery time at max. switching frequency 1/s after E-STOP 50 ms after power failure 100 ms Min. start pulse duration with a monitored reset 30 ms Simultaneity, channel 1 and 2 Supply interruption before de-energisation 10 ms
Environmental data
EMC EN 60947-5-1, EN 61000-6-2 Vibration in accordance with EN 60068-2-6 Frequency 10 - 55 Hz Amplitude 0.35 mm Climatic suitability EN 60068-2-78 Airgap creepage VDE 0110-1 Ambient temperature -10 - 55 °C Storage temperature -40 - 85 °C Protection type Mounting (e.g. control cabinet) IP54 Housing IP40 Terminals IP20
Mechanical data
Housing material Housing PPO UL 94 V0 Front ABS UL 94 V0
DC 50 Ohm
B
AC 100 Ohm
B
input circuits, reset circuits
lmax
DC 15 Ohm
B
AC 20 Ohm
B
Telephone: +49 711 3409-0, Telefax: +49 711 3409-133, E-Mail: pilz.gmbh@pilz.de
NSG-D-2-058-12/04Pilz GmbH & Co. KG, Sichere Automation, Felix-Wankel-Straße 2, 73760 Ostfildern, Germany
-8
E-STOP relay, safety gate monitor
Up to Category 4, EN 954-1
PNOZ 11
Mechanical data
Max. cross section of external conductors with screw terminals 1 core flexible 0.20 - 4.00 mm², 24 - 10 AWG 2 core, same cross section, flexible: with crimp connectors, without insulating sleeve 0.20 - 2.50 mm², 24 - 14 AWG without crimp connectors or with TWIN crimp connectors 0.20 - 2.50 mm², 24 - 14 AWG Torque setting with screw terminals 0.60 Nm Dimensions Height 87.0 mm Width 90.0 mm Depth 121.0 mm Weight 640 g
The standards current on 09/01 apply.
Max. continuous current
Number of contacts I 1 8 A 8 A 2 8 A 8 A 3 8 A 6.80 A 4 6.90 A 5.90 A 5 6.20 A 5.30 A 6 5.60 A 4.80 A 7 5.20 A 4.50 A
Order reference
Type Features Terminals Order no.
PNOZ 11 24 VAC 24 VDC Screw terminals 774 080 PNOZ 11 42 VAC 24 VDC Screw terminals 774 081 PNOZ 11 48 VAC 24 VDC Screw terminals 774 082 PNOZ 11 110 - 120 VAC 24 VDC Screw terminals 774 085 PNOZ 11 230 - 240 VAC 24 VDC Screw terminals 774 086
(A) at UBDC I
max
(A) at UBAC
max
Pilz GmbH & Co. KG, Sichere Automation, Felix-Wankel-Straße 2, 73760 Ostfildern, Germany Telephone: +49 711 3409-0, Telefax: +49 711 3409-133, E-Mail: pilz.gmbh@pilz.de
NSG-D-2-058-12/04
