3-IN-1 CORDLESS IMPACT DRILL PSBSA 20-Li B2
3-IN-1 CORDLESS IMPACT DRILL
Translation of the original instructions
PERCEUSE/VISSEUSE À PERCUSSION
SANS FIL 3 EN 1
Traduction des instructions d’origine
3-IN-1-AKKU-SCHLAGBOHRSCHRAUBER
Originalbetriebsanleitung
3-I-1 BATTERIDREVEN
SLAGBORE-/SKRUEMASKINE
Oversættelse af den originale driftsvejledning
3-IN-1-ACCU-KLOPBOORSCHROEVENDRAAIER
Vertaling van de originele gebruiksaanwijzing
IAN 326374_1904
Before reading, unfold the page containing the illustrations and familiarise yourself with all functions of
the device.
Før du læser, vend siden med billeder frem og bliv bekendt med alle apparatets funktioner.
Avant de lire le mode d’emploi, ouvrez la page contenant les illustrations et familiarisez-vous ensuite avec
toutes les fonctions de l’appareil.
Vouw vóór het lezen de pagina met de afbeeldingen open en maak u vertrouwd met alle functies van het
apparaat.
Klappen Sie vor dem Lesen die Seite mit den Abbildungen aus und machen Sie sich anschließend mit allen
Funktionen des Gerätes vertraut.
GB / IE/NI Translation of the original instructions Page 1
DK Oversættelse af den originale driftsvejledning Side 13
FR / BE Traduction des instructions d’origine Page 25
NL / BE Vertaling van de originele gebruiksaanwijzing Pagina 39
DE / AT / CH Originalbetriebsanleitung Seite 53
A
Charging
times
Charging
currents
max. 2.4 A
Charger
PLG 20 A1
max. 3.5 A
Charger
PLG 20 A2
max. 4.5 A
Charger
PLG 20 A3
Battery pack
PAP 20 A1
2 Ah
60 min
2.4 A
60 min
2.4 A
45 min
3.5 A
3 Ah
Battery pack
PAP 20 A2
90 min
2.4 A
60 min
3.5 A
45 min
4.5 A
4 Ah
Battery pack
PAP 20 A3
120 min
2.4 A
80 min
3.5 A
60 min
4.5 A
All Parkside tools and the chargers PLG 20 A1 / PLG 20 A2 / PLG 20 A3 of the X20V Team series
are compatible with the PAP 20 A1 / PAP 20 A2 / PAP 20 A3 battery pack.
20V max.
18V
Contents
Introduction ......................................................2
Intended use ................................................................ 2
Features ................................................................... 2
Package contents ............................................................ 2
Technical data .............................................................. 2
General power tool safety warnings .................................3
1. Work area safety .......................................................... 3
2. Electrical safety ........................................................... 3
3. Personal safety ............................................................ 4
4. Power tool use and care .................................................... 4
5. Battery tool use and care .................................................... 5
6. Service .................................................................. 5
Safety instructions for drills .........................................5
Original accessories / auxiliary equipment ........................................ 6
Safety guidelines for battery chargers ............................................ 6
Before use .......................................................6
Charging the battery pack (see fig. A) ............................................ 6
Attaching/disconnecting the battery pack to/from the appliance ....................... 7
Checking the battery charge level ............................................... 7
Fitting the additional handle .................................................... 7
Changing tools .............................................................. 7
Torque preselection/selecting the operating mode .................................. 7
2-speed gearbox ............................................................ 7
Use .............................................................8
Switching on and off .........................................................8
Adjusting the rotational speed .................................................. 8
Changing the direction of rotation ............................................... 8
Tips and tricks ............................................................... 8
Maintenance and cleaning ..........................................8
Kompernass Handels GmbH warranty ...............................9
Service .........................................................10
Importer .......................................................10
Disposal ........................................................10
Translation of the original Conformity Declaration .....................11
Ordering a replacement battery ....................................12
Telephone ordering ......................................................... 12
PSBSA 20-Li B2
GB│IE│NI
│
1 ■
3-IN-1 CORDLESS IMPACT DRILL
PSBSA 20-Li B2
Introduction
Congratulations on the purchase of your new appliance. You have chosen a high-quality product. The
operating instructions are part of this product. They
contain important information about safety, usage
and disposal. Before using the product, please
familiarise yourself with all operating and safety
instructions. Use the product only as described and
for the range of applications specified. Please also
pass these operating instructions on to any future
owner.
Intended use
This appliance is intended for screwing in and
removing screws as well as drilling in wood, metal,
ceramic and plastic and impact drilling in bricks
and masonry. It is not suitable for impact drilling
in natural stone such as granite. The light on this
appliance is intended to illuminate the immediate
work area of the appliance.
Use this product only as described and for the
areas of applications specified. The appliance is
not intended for commercial use. Any other usage
or modification of the appliance is deemed to be
improper and carries a significant risk of accidents.
The manufacturer accepts no responsibility for
damage(s) attributable to misuse.
Features
Speed selector
Rotation direction switch/lock
ON/OFF switch / Speed control
Bit
Battery charge level button
Battery display LED
Battery pack*
Release button for the battery pack
LED work light
Additional handle
Chuck
Torque preselection ring
High-speed charger*
Red charge control LED
Green charge control LED
Package contents
1 3-in-1 Cordless Impact Drill PSBSA 20-Li B2
1 additional handle
2 bits PZ1 & PZ2 (50mm)
1 carrying case
1 set of operating instructions
Technical data
3-in-1 Cordless Impact Drill: PSBSA 20-Li B2
Rated voltage: 20 V (DC)
Gearbox: 2 speed gearbox
Rated idle speed: 1st gear: n0 0–440 rpm
Hammer frequency: 0–26400 bpm
Max. torque: 45 Nm
Torque levels: 1–20 + 1 drill level /
Chuck capacity:
: Ø max. 13 mm
Max. drill diameter: 30 mm for wood
15 mm for tiles
13 mm for steel
Battery: PAP 20 A1*
Type: LITHIUM ION
Rated voltage: 20 V
Capacity: 2 Ah
Cells: 5
High-speed battery charger: PLG 20 A1*
INPUT:
Rated voltage: 230–240 V ~, 50 Hz
Rated power
consumption: 65 W
Fuse (internal): 3.15 A
OUTPUT:
Rated voltage: 21.5 V (DC)
Rated current: 2.4 A
Charging time: approx. 60 min
Protection class: II / (double insulation)
*BATTERY AND CHARGER ARE NOT INCLUDED
Noise emission value:
Noise measurement value determined in accordance
with EN 62841. The A-rated noise level of the
power tool is typically as follows:
2nd gear: n0 0–1650 rpm
+ 1 hammer level
(DC)
(AC)
T3.15A
■ 2 │ GB
│IE│
NI
PSBSA 20-Li B2
Sound pressure level: LPA = 86.7dB (A)
Uncertainty K: K
Sound power level: L
Uncertainty K: K
= 3 dB
PA
= 97.7 dB (A)
WA
= 3 dB
WA
Vibration emission value:
Total vibration values (vector total of three directions) determined in accordance with EN 62841:
Hammer drilling in concrete:
= 9.875 m/s
a
H,ID
Drilling in metal:
a
= 3.475 m/s
h,D
Uncertainty K = 1.5 m/s
Screws:
<2.5 m/s
Uncertainty K = 1.5 m/s
2
2
2
2
2
Wear hearing protection!
NOTE
► The vibration emission values and the noise
emission values given in these instructions
have been measured in accordance with
a standardised test procedure and can be
used for comparison of the power tool with
another tool.
► The specified total vibration values and the
noise emission values can also be used to
make a provisional load estimate.
WARNING!
► Depending on the manner in which the power
tool is being used, and in particular the kind of
workpiece that is being worked, the vibration
and noise emission values can deviate from
the values given in these instructions during
actual use of the power tool.
► Try to keep the load as low as possible.
Measures to reduce the vibration load are,
e.g. wearing gloves and limiting the working
time. Wherein all states of operation must be
included (e.g. times when the power tool is
switched off and times where the power tool is
switched on but running without load).
General power tool
safety warnings
WARNING!
► Read all safety warnings, instructions, il-
lustrations and specifications provided with
this power tool. Failure to follow all instruc-
tions listed below may result in electric shock,
fire and/or serious injury.
Save all warnings and instructions for future
reference.
The term „power tool“ in the warnings refers
to your mains-operated (corded) power tool or
battery-operated (cordless) power tool.
1. Work area safety
a) Keep work area clean and well lit. Cluttered
or dark areas invite accidents.
b) Do not operate power tools in explosive
atmospheres, such as in the presence of flammable liquids, gases or dust. Power tools cre-
ate sparks which may ignite the dust or fumes.
c) Keep children and bystanders away while
operating a power tool. Distractions can cause
you to lose control.
2. Electrical safety
a) Power tool plugs must match the outlet. Never
modify the plug in any way. Do not use any
adapter plugs with earthed (grounded)
power tools. Unmodified plugs and matching
outlets will reduce risk of electric shock.
b) Avoid body contact with earthed or ground-
ed surfaces, such as pipes, radiators, ranges
and refrigerators. There is an increased risk of
electric shock if your body is earthed or grounded.
c) Do not expose power tools to rain or wet
conditions. Water entering a power tool will
increase the risk of electric shock.
d) Do not abuse the cord. Never use the cord
for carrying, pulling or unplugging the power
tool. Keep cord away from heat, oil, sharp
edges or moving parts. Damaged or entangled
cords increase the risk of electric shock.
PSBSA 20-Li B2
GB│IE│NI
│
3 ■
e) When operating a power tool outdoors, use
an extension cord suitable for outdoor use.
Use of a cord suitable for outdoor use reduces
the risk of electric shock.
f) If operating a power tool in a damp location
is unavoidable, use a residual current device
(RCD) protected supply. Use of an RCD
reduces the risk of electric shock.
3. Personal safety
a) Stay alert, watch what you are doing and
use common sense when operating a power
tool. Do not use a power tool while you are
tired or under the influence of drugs, alcohol
or medication. A moment of inattention while
operating power tools may result in serious
personal injury.
b) Use personal protective equipment. Always
wear eye protection.
as a dust mask, non-slip safety shoes, hard hat or
hearing protection used for appropriate
conditions will reduce personal injuries.
c) Prevent unintentional starting. Ensure the
switch is in the off-position before connecting
to power source and/or battery pack, picking
up or carrying the tool. Carrying power tools
with your finger on the switch or energising
power tools that have the switch on invites accidents.
d) Remove any adjusting key or wrench before
turning the power tool on. A wrench or a key
left attached to a rotating part of the power tool
may result in personal injury.
e) Do not overreach. Keep proper footing and
balance at all times. This enables better control
of the power tool in unexpected situations.
f) Dress properly. Do not wear loose clothing or
jewellery. Keep your hair and clothing away
from moving parts. Loose clothes, jewellery or
long hair can be caught in moving parts.
g) If devices are provided for the connection of
dust extraction and collection facilities, ensure
these are connected and properly used.
Use of dust collection can reduce dust-related
hazards.
Protective equipment such
h) Do not let familiarity gained from frequent
use of tools allow you to become complacent
and ignore tool safety principles. A careless
action can cause severe injury within a fraction
of a second.
4. Power tool use and care
a) Do not force the power tool. Use the correct
power tool for your application. The correct
power tool will do the job better and safer at
the rate for which it was designed.
b) Do not use the power tool if the switch does
not turn it on and off. Any power tool that cannot be controlled with the switch is dangerous
and must be repaired.
c) Disconnect the plug from the power source
and/or remove the battery pack, if detachable, from the power tool before making any
adjustments, changing accessories, or storing
power tools. Such preventive safety measures
reduce the risk of starting the power tool accidentally.
d) Store idle power tools out of the reach of
children and do not allow persons unfamiliar
with the power tool or these instructions to
operate the power tool. Power tools are
dangerous in the hands of untrained users.
e) Maintain power tools and accessories. Check
for misalignment or binding of moving parts,
breakage of parts and any other condition
that may affect the power tool’s operation. If
damaged, have the power tool repaired before use. Many accidents are caused by poorly
maintained power tools.
f) Keep cutting tools sharp and clean. Properly
maintained cutting tools with sharp cutting
edges are less likely to bind and are easier to
control.
g) Use the power tool, accessories and tool bits
etc. in accordance with these instructions, taking into account the working conditions and
the work to be performed. Use of the power
tool for operations different from those intended
could result in a hazardous situation.
■ 4 │ GB
│IE│
NI
PSBSA 20-Li B2
h) Keep handles and grasping surfaces dry,
clean and free from oil and grease. Slippery
handles and grasping surfaces do not allow
for safe handling and control of the tool in unexpected situations.
5. Battery tool use and care
a) Recharge only with the charger specified by
the manufacturer. A charger that is suitable for
one type of battery pack may create a risk of
fire when used with another battery pack.
b) Use power tools only with specifically desig-
nated battery packs. Use of any other battery
packs may create a risk of injury and fire.
c) When battery pack is not in use, keep it away
from other metal objects, like paper clips,
coins, keys, nails, screws or other small metal
objects, that can make a connection from
one terminal to another. Shorting the battery
terminals together may cause burns or a fire.
d) Under abusive conditions, liquid may be
ejected from the battery; avoid contact. If
contact accidentally occurs, flush with water.
If liquid contacts eyes, additionally seek medical help. Liquid ejected from the battery may
cause irritation or burns.
e) Do not use a battery pack or tool that is
damaged or modified. Damaged or modified
batteries may exhibit unpredictable behaviour
resulting in fire, explosion or risk of injury.
f) Do not expose a battery pack or tool to fire
or excessive temperature. Exposure to fire
or temperature above 130 °C (265°F) may
cause explosion.
g) Follow all charging instructions and do not
charge the battery pack or tool outside the
temperature range specified in the instructions. Charging improperly or at temperatures
outside the specified range may damage the
battery and increase the risk of fire.
CAUTION! RISK OF EXPLOSION!
Never charge non-rechargeable
batteries!
Protect the rechargeable battery from
heat, for example from continuous
exposure to sunlight, fire, water and
moisture. There is a risk of explosion.
6. Service
a) Have your power tool serviced by a qualified
repair person using only identical replacement parts. This will ensure that the safety of
the power tool is maintained.
b) Never service damaged battery packs. Service
of battery packs should only be performed by
the manufacturer or authorized service providers.
Safety instructions for drills
Safety instructions for all work
■ Wear ear muffs when hammer-drilling. Expo-
sure to loud noise can lead to hearing loss.
■ Use the additional handle. Loss of control can
lead to injuries.
■ Hold the power tool only by the insulated
handles when you are carrying out work
in which the accessory tool may come into
contact with concealed power cables or the
tool’s own power cord. Contact with a live wire
may electrify exposed metal parts of the tool and
could give the operator an electric shock.
■ You can collect any dust produced using a
vacuum cleaner, for example.
Safety information for using long drill bits
■ Do not use a higher rotational speed than
the maximum permissible speed. At higher
speeds, the drill bit can bend slightly if allowed
to turn freely without being in contact with the
workpiece and this can lead to injuries.
PSBSA 20-Li B2
GB│IE│NI
│
5 ■
■ Always start drilling at a low speed and with
the drill bit in contact with the workpiece. At
higher speeds, the drill bit can bend slightly if
allowed to turn freely without being in contact
with the workpiece and this can lead to injuries.
■ Do not exert excessive pressure and only
along the length of the drill bit (no lateral
pressure). Drill bits can bend and break, which
can lead to a loss of control and injuries.
■ To avoid potential risks, dam-
aged mains cables should be replaced by the manufacturer, their
customer service department or
a similarly qualified person.
The charger is suitable for indoor use
only.
Original accessories / auxiliary
equipment
■ Use only the accessories and additional
equipment which are specified in the operating instructions and are compatible with the
appliance.
WARNING!
■ Do not use any accessories which are not
recommended by PARKSIDE. This can lead to
an electric shock and fire.
Safety guidelines for battery chargers
■ This appliance may be used
by children aged 8 years and
above and by persons with limited physical, sensory or mental
capabilities or lack of experience and knowledge, provided
that they are under supervision
or have been told how to use
the appliance safely and are
aware of the potential risks. Do
not allow children to use the appliance as a toy. Cleaning and
user maintenance tasks may not
be carried out by children unless
they are supervised.
WARNING!
■ To avoid potential risks, damaged mains ca-
bles should be replaced by the manufacturer,
their customer service department or
a similarly qualified person.
ATTENTION!
♦ This charger can only charge the following bat-
teries: PAP 20 A1 / PAP 20 A2 / PAP 20 A3
♦ A current list of battery compatibility can be
found at www.lidl.de/Akku.
.
Before use
Charging the battery pack (see fig. A)
CAUTION!
► Always unplug the appliance before you
remove the battery pack from or connect the
battery pack to the charger.
♦ Connect the battery pack
battery charger (see fig. A).
♦ Insert the power plug into the socket. The control
LED
lights up red.
♦ The green LED
process is complete and the battery pack is
ready.
CAUTION!
♦ If the red control LED
that the battery pack has overheated and
cannot be charged.
♦ If the red and green control LEDs
flash, this means that the battery pack is
broken.
indicates that the charging
to the high-speed
flashes, this means
both
■ 6 │ GB
│IE│
NI
PSBSA 20-Li B2
♦ Push the battery pack back into the appliance.
♦ Switch off the charger for at least 15 minutes
between successive charging sessions. Also
disconnect the power plug from the mains
power socket.
Attaching/disconnecting the battery
pack to/from the appliance
Inserting the battery pack:
♦ Push the rotation direction switch
middle position (lock). Allow the battery pack
to click into the handle.
Removing the battery pack:
♦ Press the release button
battery pack.
and remove the
into the
Checking the battery charge level
♦ Press the battery charge level button to
check the status of the battery (see also main
diagram).
The status/remaining charge will be shown on
the battery display LED
RED/ORANGE/GREEN = maximum charge
RED/ORANGE = medium charge
RED = low charge – charge the battery
as follows:
Fitting the additional handle
♦ Screw the additional handle onto the left or
right of the appliance depending on how you
work.
Changing tools
Your cordless screwdriver has a fully automatic
spindle lock .
When the motor is stopped, the power train locks
so that the chuck
it . Once you have attached the desired tool
and tightened it by turning the chuck , you can
continue working. The spindle lock is automatically
released when the motor starts (ON/OFF switch
pressed).
can be opened by turning
Torque preselection/selecting the
operating mode
You can adjust the torque on the torque preselector
and select between the drill setting and the
hammer drill setting
♦ Select a low level for small screws or soft
materials.
♦ Select a high level for large screws, hard
materials or removing screws.
♦ Select the drill setting for drilling work by adjusting
the torque selection ring to the position
♦ Select the hammer drill setting for hammer
drilling work by adjusting the torque selection
ring to the position
.
.
.
2-speed gearbox
CAUTION!
► Operate the speed selection switch
when the appliance is at a standstill. Otherwise the appliance can be damaged.
In first gear (speed selector switch
position: 1)
you can reach a speed of approx. 440 rpm and a
high torque. This setting is suitable for all screwing
work but also for the use of accessories.
In second gear (speed selector switch
position: 2)
you can reach a speed of approx. 1650 rpm for
carrying out drilling work.
only
in
in
PSBSA 20-Li B2
GB│IE│NI
│
7 ■
Use
Switching on and off
Switching on:
♦ To start the appliance, press the ON/OFF
switch
The LED work light lights up when the ON/OFF
switch is depressed lightly or fully. This allows
for illumination of the work area in low lighting.
Switching off:
♦ Release the ON/OFF switch
appliance.
Adjusting the rotational speed
Press the ON/OFF switch lightly for a low
speed. Increasing the pressure increases the speed.
NOTE
► The integrated motor brake ensures rapid
Changing the direction of rotation
♦ Change the direction of rotation by pressing the
rotational direction switch towards the left
or right.
Tips and tricks
♦ Before operating the appliance, check whether
the screw or drill bit is correctly positioned, i.e.
centred in the drill chuck.
♦ Screw bits are labelled according to their di-
mensions and their shape. If you are uncertain,
always check whether the bit fits tightly in the
screw head without any free play.
Torque:
♦ Smaller screws/bits can be damaged if you set
the torque or rotational speed too high.
Hard screw joints (in metal):
♦ Particularly high torques occur, for example, in
metal screw joints made using drive sockets.
Select a low rotational speed.
and keep it pressed in.
stoppage.
Tip! This symbol indicates proper
baviour.
to switch off the
Soft screw joints (e.g. in soft wood):
♦ Again, use a low rotational speed, for example
to avoid damaging the surface of the wood on
contact with the screw head. Use a countersink.
When drilling in wood, metal and other
materials, observe the following:
♦ Use a high speed for drill bits with small dia-
meter and a low speed for drill bits with large
diameter.
♦ Select a low speed for hard materials and a
high speed for soft materials.
♦ Mark the spot where you want to drill using a
centre punch or nail. Select a low rotational
speed when starting.
♦ Pull the rotating drill bit from the hole repeatedly
to remove dust and chips and clear the hole.
Drilling in metal:
♦ Use a metal drill (HSS). For optimum results,
you should cool the drill bit with oil.
Metal drill bits can also be used to drill into
plastics. Start with a 3 mm diameter drill bit
and then increase the size until the desired hole
diameter is achieved.
Drilling in brick:
♦ Use a carbide-tipped masonry drill.
(max. recommended hole diameter: Ø 15 mm)
Drilling in wood:
♦ Use a wood drill with a lathe centre; for deep
holes, use an auger bit; for large-diameter
holes, use a Forstner bit. Small screws can be
screwed directly into soft wood.
Maintenance and cleaning
WARNING! RISK OF INJURY! Always
switch the appliance off and remove
the battery before carrying out any
work on the appliance.
The cordless combi drill is maintenance-free.
■ The appliance must always be kept clean, dry
and free from oil or grease.
■ Never allow liquids to get into the appliance.
■ 8 │ GB
│IE│
NI
PSBSA 20-Li B2
■ Use a soft, dry cloth to clean the housing.
Never use petrol, solvents or cleansers which
can damage plastic.
■ If a lithium-ion battery is to be stored for an
extended period, the charge level should be
checked regularly. The optimum charge level is
between 50% and 80%. The optimum storage
environment is cool and dry.
NOTE
► Replacement parts not listed (such as carbon
brushes, switch) can be ordered via our
service hotline.
Kompernass Handels GmbH
warranty
Dear Customer,
This appliance has a 3-year warranty valid from
the date of purchase. If this product has any faults,
you, the buyer, have certain statutory rights. Your
statutory rights are not restricted in any way by the
warranty described below.
Warranty conditions
The warranty period starts on the date of purchase.
Please keep your receipt in a safe place. This will
be required as proof of purchase.
If any material or manufacturing fault occurs within
three years of the date of purchase of the product,
we will either repair or replace the product for you
or refund the purchase price (at our discretion).
This warranty service requires that you present the
defective appliance and the proof of purchase (receipt) within the three-year warranty period, along
with a brief written description of the fault and of
when it occurred.
If the defect is covered by the warranty, your product will either be repaired or replaced by us. The
repair or replacement of a product does not signify
the beginning of a new warranty period.
Warranty period and statutory claims for defects
The warranty period is not prolonged by repairs
effected under the warranty. This also applies to
replaced and repaired components. Any damage
and defects present at the time of purchase must
be reported immediately after unpacking. Repairs
carried out after expiry of the warranty period shall
be subject to a fee.
Scope of the warranty
This appliance has been manufactured in accordance with strict quality guidelines and inspected
meticulously prior to delivery.
The warranty covers material faults or production
faults. The warranty does not extend to product parts
subject to normal wear and tear or to fragile parts
which could be considered as consumable parts
such as switches, batteries or parts made of glass.
The warranty does not apply if the product has been
damaged, improperly used or improperly maintained. The directions in the operating instructions
for the product regarding proper use of the product
are to be strictly followed. Uses and actions that are
discouraged in the operating instructions or which
are warned against must be avoided.
This product is intended solely for private use and
not for commercial purposes. The warranty shall
be deemed void in cases of misuse or improper
handling, use of force and modifications / repairs
which have not been carried out by one of our
authorised Service centres.
Warranty claim procedure
To ensure quick processing of your case, please
observe the following instructions:
■ Please have the till receipt and the item number
(e.g.IAN12345) available as proof of purchase.
■ You will find the item number on the type plate
on the product, an engraving on the product,
on the front page of the operating instructions
(below left) or on the sticker on the rear or bottom of the product.
■ If functional or other defects occur, please
contact the service department listed either by
telephone or by e-mail.
■ You can return a defective product to us free of
charge to the service address that will be provided to you. Ensure that you enclose the proof
of purchase (till receipt) and information about
what the defect is and when it occurred.
PSBSA 20-Li B2
GB│IE│NI
│
9 ■
You can download these instructions
along with many other manuals,
product videos and installation
software at www.lidl-service.com.
This QR code will take you directly to
the Lidl service page (www.lidl-service.com) where
you can open your operating instructions by entering the item number (IAN) 123456.
Service
WARNING!
► Have the power tool repaired by the service
centre or a qualified electrician and only
using genuine replacement parts. This will
ensure that the safety of the appliance is
maintained.
► Always ensure that the power plug or
the mains cable is replaced only by the
manufacturer of the appliance or by an
approved customer service provider. This
will ensure that the safety of the appliance is
maintained.
Service Great Britain
Tel.: 0800 404 7657
E-Mail: kompernass@lidl.co.uk
Service Ireland
Tel.: 1890 930 034
(0,08 EUR/Min., (peak))
(0,06 EUR/Min., (off peak))
E-Mail: kompernass@lidl.ie
IAN 326374_1904
Importer
Please note that the following address is not the
service address. Please use the service address
provided in the operating instructions.
KOMPERNASS HANDELS GMBH
BURGSTRASSE 21
44867 BOCHUM
GERMANY
www.kompernass.com
Disposal
The packaging is made from environmen-
tally friendly material and can be disposed of at your local recycling plant.
Do not dispose of power tools in
your normal domestic waste!
European Directive 2012/19/EU requires that
worn-out power tools be collected separately and
recycled in an environmentally compatible manner.
Do not dispose of batteries in your
normal household waste!
Remove the batteries from the appliance before
disposal.
Defective or worn-out rechargeable batteries must
be recycled according to Directive 2006/66/EC.
Take the battery pack and/or appliance to a nearby
collection facility.
Please consult your local authorities regarding
suitable disposal of worn out power tools/battery
packs.
Dispose of the packaging in an
environmentally friendly manner.
Note the labelling on the packaging
and separate the packaging material
components for disposal if necessary.
The packaging material is labelled
with abbreviations (a) and numbers
(b) with the following meanings:
1–7: Plastics,
20–22: Paper and cardboard,
80–98: Composites.
Your local community or municipal
authorities can provide information on
how to dispose of the worn-out
product.
■ 10 │ GB
│IE│
NI
PSBSA 20-Li B2
Translation of the original Conformity Declaration
We, KOMPERNASS HANDELS GMBH, document officer: Mr. Semi Uguzlu, BURGSTR. 21,
44867 BOCHUM, GERMANY, hereby declare that this product complies with the following standards,
normative documents and EC directives:
Machinery Directive
(2006/42/EC)
EC Low Voltage Directive
(2014 / 35 / EU) (charger only)
EMC (Electromagnetic Compatibility)
(2014/30/EU)
RoHS Directive
(2011/65/EU)*
* The manufacturer bears the full responsibility for compliance with this conformity declaration. The object
of the declaration described above complies with the requirements of the Directive 2011/65/EU
of the European Parliament and Council of 8 June 2011 on the limitations of use of certain dangerous
substances in electrical and electronic appliances.
Applied harmonised standards:
EN 62841-1:2015
EN 62841-2-1:2018
EN 55014-1:2017
EN 55014-2:2015
EN 60335-2-29:2004/A2:2010
EN 60335-1:2012/A11:2014
EN 62233:2008
EN 61000-3-2:2014
EN 61000-3-3:2013
EN 50581:2012
Type/appliance designation: 3-in-1 Cordless Impact Drill PSBSA 20-Li B2
Year of manufacture: 08 - 2019
Serial number: IAN 326374_1904
Bochum, 16/08/2019
Semi Uguzlu
- Quality Manager We reserve the right to make technical changes in the context of further product development.
PSBSA 20-Li B2
GB│IE│NI
│
11 ■
Ordering a replacement battery
If you want to order a replacement battery for your appliance, you can do so easily via the Internet on
www.kompernass.com or by telephone.
Due to limited stocks, this item may sell out in a relatively short time.
NOTE
► Online ordering of replacement parts is not possible in all countries. In this case, please contact the
Service hotline.
Telephone ordering
Service Great Britain
Tel.: 0800 404 7657
E-Mail: kompernass@lidl.co.uk
Service Ireland
Tel.: 1890 930 034
(0,08 EUR/Min., (peak))
(0,06 EUR/Min., (off peak))
E-Mail: kompernass@lidl.ie
To ensure a fast processing of your order, have the article number of you appliance to hand
(e.g. IAN 326374) in case of questions. The article number can be found on the type plate or the title
page of these instructions.
■ 12 │ GB
│IE│
NI
PSBSA 20-Li B2
Indholdsfortegnelse
Indledning ......................................................14
Anvendelsesområde .........................................................14
Udstyr .................................................................... 14
Pakkens indhold ............................................................14
Tekniske data ..............................................................14
Generelle sikkerhedsanvisninger tilelværktøj ........................15
1. Sikkerhed på arbejdspladsen ...............................................15
2. Elektrisk sikkerhed ........................................................15
3. Personsikkerhed ..........................................................16
4. Anvendelse og behandling af elværktøjet ......................................16
5. Anvendelse og behandling af det batteridrevne værktøj ........................... 17
6. Service .................................................................17
Sikkerhedsinstruktioner for bor ....................................17
Originalt tilbehør / originalt ekstraudstyr ......................................... 18
Sikkerhedsanvisninger for opladere ............................................. 18
Før første brug ..................................................18
Opladning af batteripakke (se fig. A) ........................................... 18
Indsætning / udtagning af den genopladelige batteripakke .......................... 19
Kontrol af det genopladelige batteris tilstand. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Montering af ekstra-greb ..................................................... 19
Skift af værktøj ............................................................. 19
Valg af drejningsmomentforvalg / driftsform ......................................19
2-trins gear ................................................................19
Første brug .....................................................20
Tænd / sluk ............................................................... 20
Indstilling af omdrejningstal ................................................... 20
Omskiftning af omdrejningsretning ..............................................20
Tips og tricks ...............................................................20
Vedligeholdelse og rengøring ......................................21
Garanti for Kompernass Handels GmbH .............................21
Service .........................................................22
Importør .......................................................22
Bortskaffelse ....................................................22
Oversættelse af den originale overensstemmelseserklæring ............23
Bestilling af genopladeligt reservebatteri ............................24
Telefonisk bestilling ..........................................................24
PSBSA 20-Li B2
DK │ 13 ■
3-I-1 BATTERIDREVEN
SLAGBORE-/SKRUEMASKINE
PSBSA 20-Li B2
Indledning
Tillykke med købet af dit nye produkt. Du har
valgt et produkt af høj kvalitet. Betjeningsvejledningen er en del af dette produkt. Den indeholder
vigtige informationer om sikkerhed, anvendelse og
bortskaffelse. Du bør sætte dig ind i alle produktets
betjenings- og sikkerhedsanvisninger før brug. Brug
kun produktet som beskrevet og kun til de angivne
anvendelsesområder. Lad vejledningen følge med
produktet, hvis du giver det videre til andre.
Anvendelsesområde
Dette produkt er beregnet til indskruning og udtagning af skruer samt til boring i træ, metal, keramik
og plast samt til slagboring i tegl og murværk.
Produktet er ikke egnet til slagboring i natursten
som f.eks. granit. Lyset i dette produkt er beregnet
til oplysning af produktets direkte arbejdsområde.
Brug kun produktet som beskrevet og kun til de
angivne anvendelsesområder. Produktet er ikke
beregnet til erhvervsmæssig brug. Enhver anden
anvendelse eller ændring af produktet anses for at
være uden for anvendelsesområdet og indebærer
betydelige farer for uheld. Producenten påtager
sig intet ansvar for skader, der opstår som følge af
anvendelse uden for anvendelsesområdet.
Udstyr
Knap til gearvalg
Omskifter til omdrejningsretning/spærring
TÆND-/SLUK-knap/hastighedsregulator
Bit
Knap til kontrol af batteriets tilstand
Display-LED for genopladeligt batteri
Genopladelig batteripakke*
Knap til frigørelse af batteripakken
LED-arbejdslampe
Ekstra-greb
Borepatron
Forvalg af drejningsmoment
Hurtigoplader*
Rød LED til kontrol af opladning
Grøn ladekontrol-LED
Pakkens indhold
1 3-i-1 batteridreven slagbore-/skruemaskine
PSBSA 20-Li B2
1 ekstra-greb
2 bits PZ1 & PZ2 (50mm)
1 bæretaske
1 betjeningsvejledning
Tekniske data
3-i-1 batteridreven slagbore-/skruemaskine:
PSBSA 20-Li B2
Mærkespænding: 20 V
Gear: 2-trins gear
Nominel tomgangshastighed: 1. gear: n0 0 - 440 min
Slagfrekvens: 0 - 26400 min
Maks. drejningsmoment: 45 Nm
Momenttrin: 1 - 20 + 1 boretrin/
Borepatronkapacitet:
: Ø maks. 13 mm
Maks. bordiameter: 30 mm til træ
15 mm til tegl
13 mm til stål
Batteri: PAP 20 A1*
Type: LITHIUM-ION
Mærkespænding: 20 V
Kapacitet: 2 Ah
Celler: 5
Batteridrevet hurtig-ladeapparat: PLG 20 A1*
INDGANG / input:
Mærkespænding: 230 - 240 V ~, 50 Hz
Nominelt effektforbrug: 65 W
Sikring (intern): 3,15 A
UDGANG / output:
Mærkespænding: 21,5 V (jævnstrøm)
Mærkestrøm: 2,4 A
Opladningstid: ca. 60 min
Beskyttelsesklasse: II / (dobbeltisolering)
* BATTERI OG OPLADER ER IKKE I LEVERING
BEMÆRKET
(jævnstrøm)
2. gear: n0 0 - 1650 min
+ 1 hammertrin
(vekselstrøm)
-1
(jævnstrøm)
T3.15A
-1
-1
■ 14 │ DK
PSBSA 20-Li B2
Støjemissionsværdi:
Måleværdi for støj beregnet iht. EN62841. Det
A-vægtede støjniveau for elværktøjet er typisk som
følger:
Lydtrykniveau: L
Usikkerhed K: K
= 86,7 dB (A)
PA
= 3 dB
PA
Lydeffektniveau: LWA = 97,7 dB (A)
Usikkerhed K: K
= 3 dB
WA
Vibrationsemissionsværdi:
Samlede vibrationsværdier (vektorsum i tre retninger)
beregnet iht. EN62841:
Slagboring i beton:
= 9,875 m/s
a
H,ID
Boring i metal:
a
= 3,475 m/s
h,D
Usikkerhed K = 1,5 m/s
Skruer:
<2,5 m/s
Usikkerhed K = 1,5 m/s
2
2
2
2
2
Bær høreværn!
BEMÆRK
► De angivne samlede vibrationsværdier og de
angivne vibrationsemissionsværdier er målt iht.
standardiserede testmetoder og kan anvendes
til sammenligning af forskellige elværktøjer.
► De angivne samlede vibrationsværdier og
de angivne støjemissionsværdier kan også
anvendes til en indledende vurdering af faren
ved belastningen.
ADVARSEL!
► Svingnings- og støjemissionen kan afvige fra de
angivne værdier under den faktiske anvendelse
af elværktøjet afhængigt af måden, elværktøjet
anvendes på og især af emnet, der forarbejdes.
► Prøv at holde belastningen så lav som muligt.
Vibrationsbelastningen kan f.eks. reduceres
ved brug af handsker ved anvendelse af
værktøjet samt ved nedsættelse af den tid,
værktøjet bruges. Her skal der tages hensyn
til hele driftscyklussen (f.eks. perioder, hvor
elværktøjet er slukket, og perioder, hvor det
er tændt, men kører uden belastning).
Generelle
sikkerhedsanvisninger
tilelværktøj
ADVARSEL!
► Læs alle sikkerhedsanvisninger, instruktio-
ner, illustrationer og tekniske data, som
dette elværktøj er forsynet med. Hvis de
efterfølgende anvisninger ikke overholdes,
kan det medføre elektrisk stød, brand og/
eller alvorlige kvæstelser.
Opbevar sikkerhedsanvisningerne og -instruktionerne til senere brug.
Begrebet ”elværktøj”, der anvendes i sikkerhedsanvisningerne, henviser både til elværktøj, der anvendes
med ledning til lysnettet, og batteridrevet elværktøj
(uden strømledning).
1. Sikkerhed på arbejdspladsen
a) Hold arbejdspladsen ren og godt oplyst. Rod
og dårligt oplyste arbejdspladser kan medføre
uheld.
b) Arbejd aldrig med elværktøj i eksplosions-
farlige omgivelser, hvor der befinder sig
brændbare væsker, gasser eller støv. Elværk-
tøj danner gnister, som kan antænde støvet eller
dampene.
c) Hold børn og andre personer på afstand, når
elværktøjet bruges. Hvis du bliver distraheret,
kan du miste kontrollen over elværktøjet.
2. Elektrisk sikkerhed
a) Elværktøjets tilslutningsstik skal passe ind i stik-
kontakten. Stikket må ikke ændres på nogen
måde.
Der må ikke bruges adapterstik sammen med
beskyttelsesjordet elværktøj. Uændrede stik
og de rigtige stikkontakter reducerer risikoen
for elektrisk stød.
b) Undgå kropskontakt med jordforbundne
overflader som f.eks. rør, radiatorer, komfurer
og køleskabe. Der er øget risiko for elektrisk
stød, hvis din krop har jordforbindelse.
PSBSA 20-Li B2
DK │ 15 ■
c) Hold elværktøjet væk fra regn og fugt. Hvis der
kommer vand ind i elværktøjet, er der forhøjet
risiko for elektrisk stød.
d) Brug ikke tilslutningsledningen til noget, den
ikke er beregnet til, f.eks. til at bære eller
hænge værktøjet op i eller til at trække stikket
ud af stikkontakten. Hold tilslutningsledningen
på afstand af varme, olie, skarpe kanter eller
bevægelige dele. Beskadigede eller sammen-
filtrede tilslutningsledninger øger risikoen for
elektrisk stød.
e) Hvis du anvender elværktøj udendørs, må du
kun bruge forlængerledninger, som også er
godkendt til udendørs brug. Når du anvender
en forlængerledning, der er beregnet til udendørs brug, reduceres risikoen for elektrisk stød.
f) Hvis det ikke er muligt at undgå at bruge
elværktøjet i fugtige omgivelser, skal der
installeres en fejlstrømsafbryder. Installation
af en fejlstrømsafbryder reducerer risikoen for
elektrisk stød.
3. Personsikkerhed
a) Vær opmærksom og bevidst om, hvad du
laver, og arbejd fornuftigt med elværktøjet.
Brug ikke elværktøjet, hvis du er ukoncentreret
eller påvirket af narkotika, alkohol eller medicin. Selv et øjebliks uopmærksomhed ved brug
af elværktøjet kan medføre alvorlige kvæstelser.
b) B
rug personligt beskyttelsesudstyr, og bær altid
beskyttelsesbriller. Når du bruger personligt
beskyttelsesudstyr som støvmaske, skridsikre sikkerhedssko, beskyttelseshandsker, sikkerhedshjelm
og høreværn afhængigt af elværktøjets type og
anvendelse, reduceres risikoen for personskader.
c) Undgå uønsket igangsætning. Kontrollér, at
elværktøjet er slukket, før du forbinder det
med elforsyningen og/eller tilslutter batteriet,
løfter elværktøjet eller bærer det. Hvis du bæ-
rer elværktøjet rundt med fingeren på kontakten,
eller hvis elværktøjet sluttes til strømforsyningen,
mens det er tændt, kan der opstå uheld.
d) Fjern indstillingsværktøj eller skruenøgler, før
du tænder for elværktøjet. Hvis der sidder et
værktøj eller en skruenøgle på en roterende del
af elværktøjet, kan det medføre personskader.
e) Undgå unormale kropsstillinger. Sørg for, at
du står sikkert, og hold altid balancen.
Derved kan du bedre kontrollere elværktøjet i
uventede situationer.
f) Bær velegnet påklædning. Bær ikke løstsid-
dende tøj eller smykker. Hold hår og tøj på
afstand af dele, der bevæger sig. Løst tøj,
smykker eller hår kan gribe fat i dele, der bevæger sig.
g) Hvis der kan monteres støvopsugnings- og
opsamlingsanordninger, skal disse tilsluttes
og anvendes korrekt. Anvendelse af denne
type anordninger nedsætter støvrisikoen.
h) Lad dig ikke lulle ind i en falsk følelse af sikker-
hed, og tilsidesæt ikke sikkerhedsreglerne for
elværktøj, selv om du er fortrolig med elværktøjet efter mange ganges anvendelse. Uforsig-
tige handlinger kan føre til alvorlige kvæstelser
på en brøkdel af et sekund.
4. Anvendelse og behandling af
elværktøjet
a) Overbelast ikke elværktøjet. Brug et elværktøj,
der er egnet til arbejdet. Du arbejder bedre
og mere sikkert i det angivne effektområde, hvis
du bruger det rigtige elværktøj.
b) Brug ikke elværktøj med defekt kontakt.
Elværktøj, som ikke længere kan tændes og
slukkes, er farligt og skal repareres.
c) Træk stikket ud af stikkontakten og/eller fjern
det aftagelige batteri, før du foretager indstillinger på produktet, udskifter indsatsværktøj
eller lægger elværktøjet fra dig. Disse for-
holdsregler forhindrer, at elværktøjet starter ved
en fejl.
d) Opbevar elværktøj uden for børns række-
vidde, når værktøjet ikke anvendes. Personer,
som ikke kender elværktøjet, eller som ikke
har læst disse anvisninger, må ikke bruge
produktet. Elværktøj er farligt, hvis det anvendes
af uerfarne personer.
e) Vedligehold elværktøjet og dets indsatsværk-
tøj omhyggeligt. Kontrollér, om bevægelige
dele fungerer, som de skal og ikke sætter sig
fast, om dele er defekte eller så beskadigede,
at elværktøjets funktion er forringet.
■ 16 │ DK
PSBSA 20-Li B2
Få beskadigede dele repareret, inden du bruger elværktøjet. Mange uheld skyldes dårligt
vedligeholdt elværktøj.
f) Hold skærende værktøj skarpt og rent. Om-
hyggeligt vedligeholdt værktøj med skarpe skær
sætter sig ikke så ofte fast og er lettere at styre.
Brug elværktøj, indsatsværktøj, udskiftelige dele
g)
osv. iht. disse anvisninger. Tag hensyn til arbejdsbetingelserne og det arbejde, der skal udføres.
Anvendelse af elværktøj til andet end den tilsigtede
anvendelse kan føre til farlige situationer.
h) Hold håndtag og gribeflader tørre, rene og
fri for olie og fedt. Glatte håndtag og gribeflader gør sikker betjening og kontrol over elværktøjet umulig i uforudsete situationer.
5. Anvendelse og behandling af det
batteridrevne værktøj
a) Oplad kun batterierne med opladere, som
producenten har anbefalet. Hvis du bruger en
oplader, der er beregnet til en bestemt type batterier, er der fare for brand, hvis den anvendes
sammen med andre batterier.
b) Brug kun batterier, der er beregnet til elværk-
tøjet. Anvendelse af andre batterier kan medføre personskader og brandfare.
c) Når batteriet ikke benyttes, skal det holdes
borte fra kontorclips, mønter, nøgler, søm,
skruer eller andre små metalgenstande, som
kan forårsage kortslutning mellem kontakterne. Kortslutning mellem batteriets kontakter
kan medføre forbrændinger eller brand.
d) Ved forkert anvendelse kan der løbe væske
ud af batteriet. Undgå kontakt med denne
væske. Skyl efter med vand, hvis du alligevel
kommer i kontakt med væsken. Hvis væsken
kommer i øjnene, skal du søge læge. Batteri-
væske, der løber ud, kan medføre hudirritationer
eller forbrændinger.
e) Brug aldrig et beskadiget eller modificeret
batteri. Beskadigede eller modificerede batterier kan føre til uforudsigelig funktion samt til
brand, eksplosioner eller risiko for personskader.
f) Udsæt ikke batteriet for ild eller høje tem-
peraturer. Ild eller temperaturer over 130 °C
(265 °F) kan forårsage eksplosioner.
g) Følg alle anvisninger for opladning, og oplad
aldrig batteriet eller batteridrevet værktøj uden
for det temperaturinterval, som er angivet i
betjeningsvejledningen. Forkert opladning eller
opladning uden for det tilladte temperaturinterval
kan ødelægge batteriet og øge brandfaren.
FORSIGTIG! EKSPLOSIONSFARE!
Oplad aldrig batterier, der ikke er
beregnet til det.
Beskyt batteriet mod varme på grund
af f.eks. konstant sollys, ild, vand og
fugt. Fare for eksplosion.
6. Service
a) Lad kun en kvalificeret reparatør reparere dit
elværktøj og kun med originale reservedele.
Derved garanteres det, at elværktøjets sikkerhed bevares.
Vedligehold aldrig beskadigede batterier.
b)
Vedligeholdelse af batterier må kun udføres af
producenten eller et autoriseret serviceværksted.
Sikkerhedsinstruktioner for
bor
Sikkerhedsinstruktioner til alt arbejde
■ Bær høreværn ved slagboring. Støjpåvirkningen
kan medføre høretab.
■ Brug produktet sammen med det medfølgen-
de ekstra-greb. Hvis du mister kontrollen over
maskinen, kan det føre til kvæstelser.
■ Hold fast i elværktøjet på de isolerede
gribeflader, når du arbejder på steder, hvor
skruen eller indsatsværktøjet kan ramme
skjulte elledninger. Kontakten mellem skruen
eller indsatsværktøjet og en spændingsførende
ledning kan sætte produktdele af metal under
spænding og medføre elektrisk stød.
■ Opfang eventuelt ophobet støv, f.eks. med en
støvsuger.
PSBSA 20-Li B2
DK │ 17 ■
Loading...
