SABRE SAW PFS 710 D3
SABRE SAW
Translation of the original instructions
IAN 295715
SÄBELSÄGE
Originalbetriebsanleitung
Before reading, unfold the page containing the illustrations and familiarise yourself with all functions of
the device.
Klappen Sie vor dem Lesen die Seite mit den Abbildungen aus und machen Sie sich anschließend mit allen
Funktionen des Gerätes vertraut.
GB / IE / NI Translation of the original instructions Page 1
DE / AT / CH Originalbetriebsanleitung Seite 11
Contents
Introduction ......................................................2
Intended use ................................................................ 2
Features ................................................................... 2
Package contents ............................................................ 2
Technical data .............................................................. 2
General Power Tool Safety Warnings ................................3
1. Work area safety .......................................................... 3
2. Electrical safety ........................................................... 3
3. Personal safety ............................................................ 3
4. Power tool use and care .................................................... 4
5. Service .................................................................. 4
Appliance-specific safety instructions for sabre saws ................................. 5
Original accessories/auxiliary equipment ......................................... 5
Information on saw blades ..................................................... 5
Before use .......................................................5
Fitting/changing the saw blade ................................................. 5
Turning the appliance handle ................................................... 5
Adjusting the footplate ........................................................ 6
Stroke rate selection .......................................................... 6
Use .............................................................6
Switching on and off .........................................................6
Guiding the sabre blade safely ................................................. 6
Practical advice on sawing ..................................................... 6
Maintenance and cleaning ..........................................7
Kompernass Handels GmbH warranty ...............................7
Service ..........................................................8
Importer ........................................................9
Disposal .........................................................9
Translation of the original Conformity Declaration .....................10
PFS 710 D3
GB│IE│NI
│
1 ■
SABRE SAW PFS 710 D3
Introduction
Congratulations on the purchase of your new appliance. You have chosen a high-quality product. The
operating instructions are part of this product. They
contain important information about safety, usage
and disposal. Before using the product, please
familiarise yourself with all operating and safety
instructions. Use the product only as described and
for the range of applications specified. Please also
pass these operating instructions on to any future
owner.
Intended use
This appliance is designed for sawing, cutting to
length and adapting wood, plastics and construction materials. The sabre saw is suitable for rough
sawing work, straight and curved cuts and cuts off
surfaces flush. Heed the information concerning
saw blades and practical advice on sawing. Any
other uses of or modifications to the machine are
deemed to be improper usage and may result in
serious physical injury. The manufacturer accepts
no responsibility for damage(s) attributable to
misuse. This appliance is not intended for commercial use.
Features
Stroke rate adjusting wheel
Locking switch
ON/OFF switch
Handle
Footplate
Saw blade
Quick-release chuck
Work light
Locking lever for footplate
Cover for carbon brushes
Release button
Saw blade for wood
Bimetal saw blade
Package contents
1 sabre saw PFS 710 D3
1 saw blade for wood HCS 152 mm
1 bimetal saw blade 152 mm
1 set of operating instructions
Technical data
Rated voltage: 230 V ~, 50 Hz
(AC)
Rated power
consumption: 710 W
Rated idle speed: n
Stroke length: 20 mm
Max. cutting
performance: Wood 160 mm
Sawblade mounting:
Protection class: II /
Noise emission value:
Noise measurement value determined in accordance with EN 60745. The A-rated noise level of
the power tool is typically as follows:
Sound pressure level: L
Uncertainty: K = 3 dB
Sound power level: LWA = 99 dB(A)
Uncertainty: K = 3 dB
Wear hearing protection!
Vibration values (vector total of three directions)
determined in accordance with EN 60745:
Total vibration value:
Cutting boards: a
Uncertainty: K = 1.5m/s
Cutting wooden beams: a
Uncertainty: K = 1.5m/s
NOTE
► The vibration level specified in these instruc-
tions has been measured in accordance with
a standardised measuring procedure and
can be used for equipment comparisons. The
specified vibration emission value can also
be used to make an initial exposure estimate.
0–2800 rpm
0
Aluminium 18 mm
Metal 8 mm
1
/2" (12.7 mm)
= 88 dB(A)
PA
= 9.8 m/s
h,B
2
h,WB
2
(double insulation)
2
= 12.1 m/s
2
■ 2 │ GB
│IE│
NI
PFS 710 D3
WARNING!
► The vibration level will vary according to the
use of the power tool and may sometimes
be higher than the value specified in these
instructions. Regular use of the power tool in
this way may cause the user to underestimate
the vibration. Try to keep the vibration loads
as low as possible. Measures to reduce the
vibration load are, e.g. wearing gloves and
limiting the working time. Wherein all states
of operation must be included (e.g. times
when the power tool is switched off and times
where the power tool is switched on but
running without load).
General Power Tool
Safety Warnings
WARNING!
► Read all safety warnings and all instructions.
Failure to follow the warnings and instructions may result in electric shock, fire and/or
serious injury.
Save all warnings and instructions for future
reference.
The term "power tool" in the warnings refers to your
mains-operated (corded) power tool or batteryoperated (cordless) power tool.
1. Work area safety
a) Keep work area clean and well lit.
Cluttered or dark areas invite accidents.
b) Do not operate power tools in explosive
atmospheres, such as in the presence of flammable liquids, gases or dust. Power tools cre-
ate sparks which may ignite the dust or fumes.
c) Keep children and bystanders away while
operating a power tool. Distractions can cause
you to lose control.
2. Electrical safety
a) Power tool plugs must match the outlet.
Never modify the plug in any way.
Do not use any adapter plugs with earthed
(grounded) power tools. Unmodified plugs
and matching outlets will reduce risk of electric
shock.
b) Avoid body contact with earthed or ground-
ed surfaces, such as pipes, radiators, ranges
and refrigerators. There is an increased risk of
electric shock if your body is earthed or grounded.
c) Do not expose power tools to rain or wet
conditions. Water entering a power tool will
increase the risk of electric shock.
d) Do not abuse the cord. Never use the cord
for carrying, pulling or unplugging the power
tool. Keep cord away from heat, oil, sharp
edges or moving parts. Damaged or entan-
gled cords increase the risk of electric shock.
e) When operating a power tool outdoors, use
an extension cord suitable for outdoor use.
Use of a cord suitable for outdoor use reduces
the risk of electric shock.
f) If operating a power tool in a damp location
is unavoidable, use a residual current device
(RCD) protected supply. Use of an RCD re-
duces the risk of electric shock.
3. Personal safety
a) Stay alert, watch what you are doing and
use common sense when operating a power
tool. Do not use a power tool while you are
tired or under the influence of drugs, alcohol
or medication. A moment of inattention while
operating power tools may result in serious
personal injury.
b) Use personal protective equipment. Always
wear eye protection. Protective equipment such
as dust mask, non-skid safety shoes, hard hat,
or hearing protection used for appropriate
conditions will reduce personal injuries.
PFS 710 D3
GB│IE│NI
│
3 ■
c) Prevent unintentional starting. Ensure the
switch is in the off-position before connecting
to power source and/or battery pack, picking
up or carrying the tool. Carrying power tools
with your finger on the switch or energising
power tools that have the switch on invites
accidents.
d) Remove any adjusting key or wrench before
turning the power tool on. A wrench or a key
left attached to a rotating part of the power tool
may result in personal injury.
e) Do not overreach. Keep proper footing and
balance at all times. This enables better control
of the power tool in unexpected situations.
f) Dress properly. Do not wear loose clothing or
jewellery. Keep your hair, clothing and gloves
away from moving parts. Loose clothes, jewel-
lery or long hair can be caught in moving parts.
g) If devices are provided for the connection of
dust extraction and collection facilities, ensure
these are connected and properly used.
Use of dust collection can reduce dust-related
hazards.
4. Power tool use and care
a) Do not force the power tool. Use the correct
power tool for your application. The correct
power tool will do the job better and safer at
the rate for which it was designed.
b) Do not use the power tool if the switch does
not turn it on and off. Any power tool that cannotbe controlled with the switch is dangerous
and must be repaired.
c) Disconnect the plug from the power source
and/or the battery pack from the power tool
before making any adjustments, changing accessories or storing power tools. Such preven-
tive safety measures reduce the risk of starting
the power tool accidentally.
d) Store idle power tools out of the reach of
children. Do not allow persons unfamiliar
with the power tool or these instructions to
operate the power tool. Power tools are dan-
gerous in the hands of untrained users.
e) Maintain power tools. Check for misalign-
ment or binding of moving parts, breakage of
parts and any other condition that may affect
the power tools operation. If damaged, have
the power tool repaired before use. Many ac-
cidents are caused by poorly maintained power
tools.
f) Keep cutting tools sharp and clean. Properly
maintained cutting tools with sharp cutting
edges are less likely to bind and are easier to
control.
g) Use the power tool, accessories and tool bits,
etc. in accordance with these instructions,
taking into account the working conditions
and the work to be performed. Use of the
power tool for operations different from those
intended could result in a hazardous situation.
5. Service
a) Have your power tool serviced by a qualified
repair person using only identical replacement parts. This will ensure that the safety of
the power tool is maintained.
■ 4 │ GB
│IE│
NI
PFS 710 D3
Appliance-specific safety instructions
for sabre saws
To avoid the risk of injury or fire as well as
health risks:
■ Hold the power tool by the insulated
handles if carrying out work during which
the power tool may come into contact with
concealed power cables or its own power
cable. Contact with a live wire may electrify
exposed metal parts of the power tool and
could give the operator an electric shock.
■ Wear a dust mask!
Original accessories/auxiliary
equipment
■ Use only the accessories and additional
equipment that are specified in the operating instructions and are compatible with
the appliance. Using attachments or acces-
sory tools other than those recommended in
the operating instructions can lead to a risk of
injury.
Information on saw blades
You can use any saw blade provided it is fitted with
a suitable mount – 1/2" (12.7 mm) universal shaft.
Saw blades optimised for your sabre saw are
available from retail stores in different lengths for
various purposes.
NOTE
► TPI = teeth per inch = the number of teeth per
2.54 cm
Wood saw blade
Dimensions: 152 x 1.25 mm, 6 TPI
Ideal for: sawing construction wood, chipboard,
panels and plywood, and also plunge cuts.
Bimetal saw blade
Dimensions: 152 mm, 18 TPI
Ideal for: for sawing sheet metal, profiles and pipes
– flexible and break-resistant.
:
:
Before use
Fitting/changing the saw blade
WARNING!
► Always remove the plug from the power
socket before working on the appliance.
Otherwise, there is a risk of injury.
♦ Turn the quick-release chuck
stop and hold it in this position.
♦ Push the required saw blade
release chuck as far as the stop.
CAUTION!
► The teeth of the saw blade
downwards!
♦ Let go of the quick-release chuck so that it
returns to its initial position. The saw blade is
now locked.
Turning the appliance handle
RISK OF INJURY!
► Always remove the plug from the power
socket before working on the appliance. The
handle
or left. This allows the ON/OFF switch to
be moved to the most suitable position depending on the working conditions.
♦ Press the release button
to the right or left.
♦ Allow the handle
can be turned by 90° to the right
to engage.
as far as the
into the quick-
must point
and turn the handle
PFS 710 D3
GB│IE│NI
│
5 ■
Loading...
