Page 1

OIN'KYOo
AV Receiver
HT-R590
Instruction Manual
Contents
_iiiiiiiii % _!_-_ _ _
Thank you for purchasing an Onkyo AV Receiver.
Please read this manual thoroughly before making
connections and plugging in the unit.
Following the instructions in this manual will enable
you to obtain optimum performance and listening
enjoyment from your new AV Receiver.
Please retain this manual for future reference.
[ M_def°_iPod _ iPhone]
Page 2

5_
51 i
WARNING:
TO REDUCE THE RISK OF FIRE OR ELECTRIC
SHOCK, DO NOT EXPOSE THIS APPARATUS TO
RAIN OR MOISTURE.
CAUTION:
TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER (OR BACK). NO
USER-SERVICEABLE PARTS INSIDE. REFER
SERVICING TO QUALIFIED SERVICE
PERSONNEL.
Important Safety Instructions
1°
Read these instructions.
2.
Keep these instructions.
3.
Heed all warnings.
4.
Follow all instructions.
5.
Do not use this apparatus near water.
6.
Clean only with dry cloth.
7.
Do not block any ventilation openings. Install in
accordance with the manufacturer's instructions.
8°
Do not install near any heat sources such as radiators,
heat registers, stoves, or other apparatus (including
amplifiers) that produce heat.
9°
Do not defeat the safety purpose of the polarized or
grounding-type plug. A polarized plug has two blades
with one wider than the other. A grounding type plug
has two blades and a third grounding prong. The wide
blade or the third prong are provided for your safety.
If the provided plug does not fit into your outlet,
consult an electrician for replacement of the obsolete
outlet.
10.
Protect the power cord from being walked on or
pinched particularly at plugs, convenience receptacles,
and the point where they exit from the apparatus.
11.
Only use attachments/accessories specified by the
manufacturer.
12.
Use only with the cart, stand, PORTABLECARTWARNING
tripod, bracket, or table
specified by the manufacturer,
or sold with the apparatus.
When a cart is used, use
caution when moving the
cart/apparatus combination to
avoid injury from tip-over.
13.
Unplug this apparatus during lightning storms or when
unused for long periods of time.
14.
Refer all servicing to qualified service personnel.
Servicing is required when the apparatus has been
damaged in any way, such as power-supply cord or
plug is damaged, liquid has been spilled or objects
have fallen into the apparatus, the apparatus has been
exposed to rain or moisture, does not operate
normally, or has been dropped.
ED
2
The lightning flash with arrowhead symbol, within an
equilateral triangle, is intended to alert the user to the
presence of uninsulated "dangerous voltage" within
the product's enclosure that may be of sufficient
magnitude to constitute a risk of electric shock to
persons.
The exclamation point within an equilateral triangle is
intended to alert the user to the presence of important
operating and maintenance (servicing) instructions in
the literature accompanying the appliance.
15. Damage Requiring Service
Unplug the apparatus from the wall outlet and refer
servicing to qualified service personnel under the
following conditions:
A. When the power-supply cord or plug is damaged,
B. If liquid has been spilled, or objects have fallen
into the apparatus,
C. If the apparatus has been exposed to rain or water,
D. If the apparatus does not operate normally by
following the operating instructions. Adjust only
those controls that are covered by the operating
instructions as an improper adjustment of other
controls may result in damage and will often
require extensive work by aqualified technician to
restore the apparatus to its normal operation,
E. If the apparatus has been dropped or damaged in
any way, and
F. When the apparatus exhibits a distinct change in
performance this indicates a need for service.
16. Object and Liquid Entry
Never push objects of any kind into the apparatus
through openings as they may touch dangerous
voltage points or short-out parts that could result in a
fire or electric shock.
The apparatus shall not be exposed to dripping or
splashing and no objects filled with liquids, such as
vases shall be placed on the apparatus.
Don't put candles or other burning objects on top of
this unit.
17. Batteries
Always consider the environmental issues and follow
local regulations when disposing of batteries.
18. If you install the apparatus in a built-in installation,
such as a bookcase or rack, ensure that there is
adequate ventilation.
Leave 20 cm (8") of tree space at the top and sides and
10 cm (4") at the rear. The rear edge of the shelf or
board above the apparatus shall be set 10 cm (4")
away from the rear panel or wall, creating a flue-like
gap for warm air to escape.
The temperature protection operates if the apparatus
attain an abnormal high temperature.
The apparatus cannot operate until it has cooled down.
Page 3

Precautions
1. Recording Copyright--Unless it's for personal use
only, recording copyrighted material is illegal without
the permission of the copyright holder.
2. AC Fuse--The AC fuse inside the unit is not user-
serviceable. If you cannot turn on the unit, contact
your Onkyo dealer.
3. Care--Occasionally you should dust the unit all over
with a soft cloth. For stubborn stains, use a soft cloth
dampened with a weak solution of mild detergent and
water. Dry the unit immediately afterwards with a
clean cloth. Don't use abrasive cloths, thinners,
alcohol, or other chemical solvents, because they may
damage the finish or remove the panel lettering.
4. Power
WARNING
BEFORE PLUGGING IN THE UNIT FOR THE
FIRST TIME, READ THE FOLLOWING SECTION
CAREFULLY.
AC outlet voltages vary from country to country.
Make sure that the voltage in your area meets the
voltage requirements printed on the unit's rear panel
(e.g., AC 230 V, 50 Hz or AC 120 V, 60 Hz).
The power cord plug is used to disconnect this unit
from the AC power source. Make sure that the plug is
readily operable (easily accessible) at all times.
Pressing the ION/STANDBY] button to select
Standby mode does not fully disconnect from the
mains. If you do not intend to use the unit for an
extended period, remove the power cord from the AC
outlet.
5. Preventing Hearing Loss
Caution
Excessive sound pressure from earphones and
headphones can cause hearing loss.
6. Batteries and Heat Exposure
Warning
Batteries (battery pack or batteries installed) shall not
be exposed to excessive heat as sunshine, fire or the
like.
7. Never Touch this Unit with Wet Hands--Never
handle this unit or its power cord while your hands are
wet or damp. If water or any other liquid gets inside
this unit, have it checked by your Onkyo dealer.
8. Handling Notes
• If you need to transport this unit, use the original
packaging to pack it how it was when you originally
bought it.
• Do not leave rubber or plastic items on this unit for
a long time, because they may leave marks on the
case.
• This unit's top and rear panels may get warm alter
prolonged use. This is normal.
• If you do not use this unit for a long time, it may not
work properly the next time you turn it on, so be
sure to use it occasionally.
For U.S. models
FCC Information for User
CAUTION:
The user changes or modifications not expressly approved
by the party responsible for compliance could void the
user's authority to operate the equipment.
NOTE:
This equipment has been tested and found to comply with
the limits for a Class B digital device, pursuant to Part 15
of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a
residential installation.
This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful
interference to radio communications. However, there is
no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful
interference to radio or television reception, which can be
determined by turning the equipment off and on, the user
is encouraged to try to correct the interference by one or
more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and
receiver.
• Connect the equipment into an outlet on a circuit
different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV
technician for help.
For Canadian Models
NOTE: THIS CLASS B DIGITAL APPARATUS
COMPLIES WITH CANADIAN ICES-003.
For models having a power cord with a polarized plug:
CAUTION: TO PREVENT ELECTRIC SHOCK,
MATCH WIDE BLADE OF PLUG TO WIDE SLOT,
FULLY INSERT.
ModUle pour les Canadien
REMARQUE: CET APPAREIL NUMt_RIQUE DE
LA CLASSE B EST CONFORME A.LA NORME NMB-
003 DU CANADA.
Sur les modbles dont la fiche est polaris_e:
ATTENTION: POUR t_VITER LES CHOCS
I_LECTRIQUES, INTRODUIRE LA LAME LA PLUS
LARGE DE LA FICHE DANS LA BORNE
CORRESPONDANTE DE LA PRISE ET POUSSER
JUSQU' AU FOND.
Erl
3
Page 4

5_
51 i
Supplied Accessories
Make sure you have the following accessories:
Indoor FM antenna (_ page 17)
AM loop antenna (_ page 17)
Power cord (Brazilian models)(_ page 17)
Speaker setup microphone (_ page 24)
Remote controller (RC-799M) and two batteries
(AA/R6) (_ page 4)
(Note for China: The battery for the remote controller is not
supplied for this unit.)
* Ill catalogs and on packaging, the letter at the end of the product
name indicates the color. Specifications and operations are the
same regardless of color.
N Installing the batteries
• If the remote controller
doesn't work reliably,
try replacing the
batteries.
• Don't mix new' and old
batteries or different
types of batteries.
• If you intend not to use
the remote controller for a long time, remove the batteries to
prevent damage from leakage or corrosion.
• Remove expired batteries as soon as possible to prevent damage
from leakage or corrosion.
Batteries (AA/R6)
N Aiming the remote controller
To use the remote controller, point it at the AV receiver's
remote control sensor, as shown below.
Remote control sensor
AV receiver
16 ft, (5 m)
ER
4
Page 5

Contents
Introduction
Important Safety Instructions ......................................... 2
Precautions ....................................................................... 3
Supplied Accessories ...................................................... 4
Features ............................................................................ 6
Front & Rear Panels ......................................................... 7
Front Panel ..................................................................... 7
Display ............................................................................ 8
Rear Panel ..................................................................... 9
Remote Controller .......................................................... 10
Controlling the AV Receiver ......................................... 10
Connecting the AV Receiver ......................................... 1
Connecting Your Speakers .......................................... 1
About AV Connections ................................................. 1
Connecting Components with HDMI ............................ 14
Connecting Your Components ..................................... 15
Connecting Onkyo I--IIComponents ............................ 16
Connecting a Recording Component ........................... 16
Connecting Antenna ..................................................... 17
Connecting the Power Cord ......................................... 17
Turning On/Off the AV Receiver ................................... 18
Turning On ................................................................... 18
Turning Off ................................................................... 18
Playback .......................................................................... 19
Playing the Connected Component .............................. 19
Controlling Contents of USB Devices ........................... 19
Understanding Icons on the Display ............................. 20
Playing iPod/iPhone via USB ....................................... 20
Playing USB Device ..................................................... 21
Listening to AM/FM Radio ............................................ 21
Using Basic Functions .................................................. 24
Using the Automatic Speaker Setup ............................ 24
Using the Listening Modes ........................................... 27
Using the Home Menu .................................................. 31
Using the Sleep Timer .................................................. 31
Setting the Display Brightness ..................................... 32
Displaying Source Information ..................................... 32
Changing the Input Display .......................................... 32
Using the Music Optimizer ........................................... 32
Muting the AV Receiver ................................................ 33
Using Headphones ....................................................... 33
Recording ..................................................................... 33
iPod/iPhone Playback via Onkyo Dock ........................ 45
Using the Onkyo Dock .................................................. 45
Controlling Your iPod/iPhone ....................................... 45
Controlling Other Onkyo Components ........................ 47
Preprogrammed Remote Control Codes ...................... 47
Entering Remote Control Codes ................................... 47
Remote Control Codes for Onkyo Components
Connected via RI ...................................................... 47
Resetting REMOTE MODE Buttons ............................. 48
Resetting the Remote Controller .................................. 48
Controlling Other Components ..................................... 48
_ oo _ _ 1
Troubleshooting ............................................................. 50
Connection Tips and Video Signal Path ...................... 54
USB Features .................................................................. 55
About HDMI ..................................................................... 56
Using an RIHD-compatible TV, Player, or Recorder ...57
Specifications ................................................................. 59
it on and, while holding down VCR/DVR, press
M
To reset the AV receiver to its factory defaults, turn
© ON/STANDBY (3 page 50).
Advanced Setup ............................................................. 34
On-screen Setup Menus .............................................. 34
Common Procedures in Setup Menu ........................... 34
HDMI Input ................................................................... 35
Component (Component Video Input) .......................... 35
Digital Audio (Digital Audio Input) ................................. 35
Sp Config (Speaker Configuration) .............................. 36
Sp Distance (Speaker Distance) .................................. 37
Level Cal (Level Calibration) ........................................ 37
Audio Adjust ................................................................. 37
Source Setup ................................................................ 39
Hardware ...................................................................... 41
HDMI Setup .................................................................. 42
Using the Audio Settings .............................................. 43
En
5
Page 6

Features
51 i
Amplifier
• 130 Watts/Channel @ 6 ohms
• 130 Watts/Channel @ 6 ohms (IEC)
• 160 Watts/Channel @ 6 ohms (JEITA)
• Optimum Gain Volume Circuitry
• H CPS (High Current Power Supply) Massive High
Power Transformer
Processing
• HDMI (Audio Return Channel, 3D, DeepColor,
x v Color*l, Lip Sync, DTS*2 HD Master Audio, DTS
HD High Resolution Audio, Dolby TrueHD*3, Dolby
Digital Plus, DSD and Multi CH PCM)
• Dolby Pro Logic IIz*a
• NonScaling Configuration
• AForm Listening Mode Memory
• Direct Mode
• Music Optimizer*4 for Compressed Digital Music files
• 192 kHz/24 bit D/A Converters
• Powerful and Highly Accurate 32bit Processing DSP
Connections
• 4 HDMF5 Inputs and l Output
• Onkyo 1-411-11D for System Control
• 4 Digital Inputs (2 Optical/2 Coaxial)
• Component Video Switching (2 Inputs/l Output)
• Banana PlugCompatible Speaker Posts*6
• FrontPanel USB Input for Memory Devices and
iPod®/iPhone® models*7
Miscellaneous
• 40 FM/AM Presets
• Audyssey 2EQ®*8 to correct room acoustic problems
• Audyssey Dynamic EQ®*8for loudness correction
• Audyssey Dynamic Volume®*_ to maintain optimal
listening level and dynamic range
• Crossover Adjustment
(401501601701801901100112011501200Hz)
• A/V Sync Control Function (up to 400 ms)
• Auto Standby Function
• On-Screen Display via HDMI
"1 "x.v.Color" is a trademark of So W Corporation.
"2 O d_-HD
MasterAudio
Manufactured trader license trader US Patent #'s: 5,451,942;
5,956,674; 5,974,380; 5,978,762; 6,226,616; 6,487,535;
7,212,872; 7,333,929; 7,392,195; 7,272,567 & other US and
worldwide patents issued & pending DTS and the Symbol are
registered trademarks, & DTS HD, DTSHD Master Audio,
and the DTS logos are trademarks of DTS, Iuc Product
includes software
© DTS, Iuc All Rights Reserved
"3 m DOLBY
PRO LOGIC l|z I
Mauufactured under license from Dolby Laboratories Dolby,
Pro Logic and the doubleD symbol are trademarks of Dolby
Laboratories
*4 Music Optimizer TM is a trademark of Oukyo Corporation
"5Ib!_rrlw
"HDM[, the HDM[ Logo, and High Definition Multimedia
[nterface are trademarks or registered trademarks of HDM[
Licensing LLC in the United States and other countries"
*6 (Asian models)
The AV receiver does not support banana plugs
iPod iPhone
I Made for 1
iPhoue, iPod, iPod classic, iPod nano, iPod shuffle, and iPod
touch are trademarks of Apple [nc, registered in the US and
other countries
"Made for iPod" and "Made for iPhone" mean that an
electronic accessory has been designed to connect specifically
to iPod or iPhoue, respectively, and has been certified by the
developer to meet Apple performance standards Apple is not
responsible for the operation of this device or its compliance
with safety and regulatory standards
Please note that the use of this accessory with iPod or iPhoue
may affect wireless performance
DYNAMIC VOLUME
Manufactured uuder license from Audyssey Laboratories "]M,
[nc US and foreign patents pending Audyssey 2EQ®,
Audyssey Dynamic EQ® and Audyssey Dynamic Volume®
are registered trademarks of Audyssey Laboratories, Inc
2EQ
En
6
Page 7

Front & Rear Panels
[i_';ltIi _
(North American and Brazilian models)
m© ,_,
(Asian models)
O:NKYO
i u
i T i Y i f T i 7 i
The page numbers in parentheses show where you can find the main explanation for each item.
(_) _ ON/STANDBY button (18)
(_) HDMI THRU indicator (42)
(_) SUBWOOFER LEVEL buttons (43)
@ Remote control sensor (4)
(_) LISTENING MODE buttons (27)
(_) Display (8)
(Z) DIMMER button (North American and Brazilian
models) (32)
(_) MEMORY button (22)
(_) TUNING MODE button (21)
DISPLAY button (32)
(_) SETUP button (34)
TUNING, PRESET (21 to 22), arrow and ENTER
buttons
RETURN button
O MASTER VOLUME control (19)
Q MUSIC OPTIMIZER button (32, 44)
PHONES jack (33)
Q TONE and Tone Level buttons (43)
(_ Input selector buttons (19)
(_ AUX INPUT AUDIO and VIDEO jacks (15, 33)
@ USB port (15)
SETUP MICjack (24)
RT/PTY/TP button (Asian models) (23)
Erl
7
Page 8

/i i
® ® ® ® ®
/[ ', PCM []D+ TrueHD dhL_-uDMSTR ES 96124 Exp, ,FM STEREO, _ SLEEP I
I HEiMiMOpt []PL_xzEX Neo:6 , , y yyAud sse D nammEQVol AUTO I_TUNED4 MUTING
I.__ '" " ' I_
For detailed information, see the pages in parentheses.
(_) HDMI input indicator
(_) Listening mode and format indicators (27, 32)
_) Audyssey indicator (24, 39)
Dynamic EQ indicator (39)
Dynamic Vol indicator (39)
@ Tuning indicators (21)
(_) RDS indicator (Asian models) (22)
(_) SLEEP indicator (31)
(Z) MUTING indicator (33)
(_) Message area
En
8
Page 9

(North American and Asian models)
_GA_E_
2
tTW
CO_
J.®> ® ®®
2
s_r_
nE_0,E
,9®1®1®!@®1®
®
.........
(Brazilian models)
CENTER
DIGITAL IN COAXIAL and OPTICAL jacks
COMPONENT VIDEO IN and OUT jacks
HDMI IN and OUT jacks
FM ANTENNA jack and AM ANTENNA terminal
SUBWOOFER PRE OUT jack
SPEAKERS terminals
(FRONT, CENTER, SURROUND, SURROUND
BACK or FRONT HIGH)
(_ Power cord (North American and Asian models)
(_) RI REMOTE CONTROL jack
(_) Composite video and analog audio jacks
(BD/DVD IN, VCR/DVR INand OUT, CBL/SAT
IN, GAME IN, TV/CD IN)
@ MONITOR OUT V jack
G AC INLET (Brazilian models)
I See "Connecting the AV Receiver" for connection(@ pages 11 to 17). l
EF1
9
Page 10

iii i
Remote Controller
,_,_ _......
---!@ @ @ @_
®
O
___@
--0
@
For detailed information, see the pages in parentheses.
@ _) button (18)
_) REMOTE MODE/INPUT SELECTOR buttons(19,
47 to 48)
(_) TONE and Tone Level buttons (43)
@ Arrow &/¥/m/_ and ENTER buttons
(_ SETUP button (34)
(_ LISTENING MODE buttons (27)
(_ DIMMER button (32)
(_) DISPLAY button (32)
(_ MUTING button (33)
O VOL A/V button (19)
_) RETURN button
HOME button (31, 43)
SLEEP button (31)
I Controlling the tuner
To control the AV receiver's tuner, press AM or FM.
O Arrow A/¥ buttons (21)
O D.TUN button (22)
O DISPLAY button (22)
O CH +]- button (22)
Number buttons (22)
"1 SP A/B is not used for this model.
En
10
Page 11

Connecting the AV Receiver
Connecting the Speaker Cables
The following illustration shows which speaker should be connected to each pair of terminals. If you're using only one
surround back speaker, connect it to the SURROUND BACK or FRONT HIGH k terminals.
Surround back/ Surround back/
front high front high
right left
Surround Surround
rli ht left
7.1chUSEONLV
SU_OUN_BACK
Or_RONTHIGH
SURROUND
CENTER
Front right
Center
Front left
• You call specify whether surround back o1"front high speakers are connected ill the "Sp Config (Speaker Configuration)" menu
(_ page 36) or during Audyssey 2EQ (!')Room Correction and Speaker Setup (_ page 24).
N Screw-type speaker terminals
Strip 1/2" to 5/8" (12 to 15 mm) of insulation from
the ends of the speaker cables, and twist the bare
wires tightly, as shown.
1/2" to 5/8" (12 to 15 mm)
N Banana Plugs (excluding Asian models)
• If you are using banana plugs, tighten the speaker terminal before inserting the banana plug.
• Do not insert the speaker code directly into the center hole of the speaker terminal.
ER
11
Page 12

Speaker Configuration
The following table indicates the channels you should use
depending on the number of speakers that you have.
No matter how many speakers you use, a powered
subwoofer is recommended for a really powerful and solid
bass.
To get the best from your surround sound system, you
need to set the speaker settings automatically
(_ page 24) or manually (_ page 36).
Number of channels
Front speakers
Center speaker
Surround speakers
Surround back speakerq*2
Surround back speakers*2
Front high speakers*2
--777
7777 7
7--77 ¢ i_
• Don't connect more than one cable to each speaker
terminal. Doing so may damage the AV receiver.
• Don't connect one speaker to several terminals.
®
Using a Powered Subwoofer
"1 ff you're using only one surround back speaker, connect it to
the SURROUND BACK or FRONT HIGH L terruinals.
*2 Front high and surround back speakers cannot be used at the
same time.
Speaker Connection Precautions
Read the following before connecting your speakers:
• You can connect speakers with an impedance of between
6 and 16 ohms. If you use speakers with a lower
impedance, and use the amplifier at high volume levels
for a long period of time, the built-in amp protection
circuit may be activated.
• Disconnect the power cord from the wall outlet before
making any connections.
• Read the instructions supplied with your speakers.
• Pay close attention to speaker wiring polarity. In other
words, connect positive (+) terminals only to positive (+)
terminals, and negative (-) terminals only to negative (-)
terminals. If you get them the wrong way around, the
sound will be out of phase and will sound unnatural.
• Unnecessarily long, or very thin speaker cables may
affect the sound quality and should be avoided.
• Be careful not to short the positive and negative wires.
Doing so may damage the AV receiver.
• Make sure the metal core of the wire does not have
contact with the AV receiver's rear panel. Doing so may
damage the AV receiver.
To find the best position for your subwoofer, while
playing a movie or some music with good bass,
experiment by placing your subwoofer at various
positions within the room, and choose the one that
provides the most satisfying results.
• ff your subwoofer is unpowered and you're using an external
amplifier, connect the subwoofer pre out jack to an input on the
amplifier.
Powered subwoofer
1/3 of wall
I
position
position
ER
12
Page 13

r,_!,'l';/l'RE!L_ [_/'a'/';I';Y_';i'I_
Connected image with AV components
HDMI cable
. AV receiver _-
: Video & Audio
Other cables _ : Video
L AV receiver
I
- Blu-ray Disc/
TV, projector, etc. DVD player Game console
TV, projector, etc, DVD player
• Before making any AV connections, read the manuals supplied with your AV components.
• Don't connect the power cord until you've completed and double-checked all AV connections.
• Push plugs in all the way to make good connections (loose connections can cause noise or
malfunctions).
• To prevent interference, keep audio and video cables away from power cords and speaker cables.
AV Cables and Jacks
Signal Cable Jack
Video and HDM[ [__ HDMI
Audio
Video Component video y
Composite video __ v@ Yellow'
Audio
Optical digital @_ OPTICAL
audio []
Coaxial digital =CZ!I_-_
audio @ Orange
Analog audio L@ White
(RCA)
Y@ Green
p_@ Blue
_@ Red
R@ Red
Description
HDM[ connections call carry digital video and audio.
Component video separates the luminance (Y) and color
difference signals (PB, PR), providing the best picture
quality (some TV manufacturers label their component
video sockets slightly differently).
Composite video is commonly used on TVs, VCRs, and
other video equipment.
Optical digital connections allow you to enjoy digital
sound such as PCM*, Dolby Digital or DTS. The audio
quality is the same as coaxial.
Coaxial digital connections allow you to enjoy digital
sound such as PCM*, Dolby Digital or DTS. The audio
quality is the same as optical.
Analog audio connections (RCA) carry analog audio.
Blu-ray Disc/
..........: Audio
Game console
* Available sampling rate for PCM input signal is 32144.1/48188.2196 kHz. Even 176.4/192 kHz is effective in case of the HDM[
connection.
• The AV receiver does not support SCART plugs.
• The AV receiver' s optical digital jacks have shutter-type covers that open when an optical plug is inserted and close when it's removed.
Push plugs in all the way.
• To prevent shutter damage, hold the optical plug straight when inserting and removing.
ER
13
Page 14

VCR or DVD recorder/Digital Video Recorder
1I
Game console
Satellite/cable set-top box, etc, Blu-ray Disc/DVD player
Connect your components to the appropriate jacks. The default input assignments are shown below.
_: Assignment can be changed (_ page 35).
Jack Components Assignable
[nput HDM[ INI Blu-ray Disc/DVD player
HDM[ IN2 VCR or DVD recorder/Digital Video Recorder
HDM[ IN3 Satellite/cable set-top box, etc.
HDM[ IN4 Game console
Output HDM[ OUT TV, projector, etc.
See also:
• "Connection Tips and Video Signal Path" (_ page 54)
• "About HDMI" (_ page 56)
• "Using an RIHD-compatible TV, Player, or Recorder" (_ page 57)
TV, projector, etc,
N Audio return channel (ARC) function
Audio return channel (ARC) function enables an HDMI capable TV to send the audio stream to the HDMI OUT of the
AV receiver (_ page 42).
• To use ARC function, you must select the TV/CD input selector, your TV must support ARC function and "HDMI
Ctrl (RIHD)" is set to "Off' (_ page 42).
• To listen to audio received by the HDMI IN jacks through your TV's speakers:
- Set the "HDMI Ctrl (RIHD)" setting to "On" for an r'411-11O-compatible TV.
- Set the "Audio TV Out" setting to "On" (_ page 42) when the TV is not compatible with r"41I-liD or the "HDMI Ctrl (RIHD)"
setting to "OFF'.
- Set your Blu-ray Disc/DVD player's HDM[ audio output setting to PCM.
- To listen to TV audio through the AV receiver, see "Connecting Your Components" (_ page 15).
• When listening to an HDM[ component through the AV receiver, set the HDM[ component so that its video can be seen on the TV
screen (on the TV, select the input of the HDM[ component connected to the AV receiver). If the TV power is off or the TV is set to
another input source, this may result in no sound from the AV receiver or the sound may be cut off.
• When the "Audio TV Out" setting is set to "On" (_ page 42) to hear from your TV's speakers, by controlling the AV receiver's
volume, the sound will be output from the AV receiver's speakers, too. When the "HDMI Ctrl (RIHD)" setting is set to "On"
(_ page 42) to hear from speakers of r41 I-liD-compatible TV, by controlling the AV receiver's volume, the AV receiver's speakers
will produce sound while the TV's speakers are muted. To stop the AV receiver's speakers producing sound, change the settings,
change your TV's settings, or turn down the AV receiver's volume.
ER
14
Page 15

i 2 ,,d
Jo®®@
i <:!ili:_i
Connect your components to the appropriate jacks. The default input assignments are shown below.
No. Jack Components Assignable
[] AUX INPUT ]_ Camcorder, etc
] AUDIO L/R
[] USB, AUX INPUT VIDEO*I iPod/iPhone (video playback)
[] USB _2 iPod/iPhone, MP3 player, USB flash drive
[] DIGITAL IN OPTICAL 1 (GAME) Game console
2 (TV/CD) TV, CD player _/
COAXIAL 1 (BD/DVD) Blu-ray Disc/DVD player
2 (CBL/SAT) Satellite/cable set-top box, RI dock, etc.
[] COMPONENT IN 1 (BD/DVD) Blu-ray Disc/DVD player, RI dock
VIDEO IN 2 (CBL/SAT) Satellite/cable set-top box, RI dock, etc.
OUT TV, projector, etc.
[] MONITOR OUT TV, projector, etc.
BD/DVD IN Blu-ray Disc/DVD player
VCR/DVR IN VCR, DVD recorder/Digital Video Recorder,
RI dock
CBL/SAT IN Satellite/cable set-top box, etc.
GAME IN Game console, RI dock
TV/CD IN TV, CD player, cassette tape deck, MD, CD-R,
Turntable*3, RI dock
a ic R i' %
_,/: Assignment can be changed (@ page 35).
"1 When USB input is selected, you can input video signals from the AUX INPUT VIDEO jack. Video signals input from AUX
INPUT VIDEO will be output from the MONITOR OUTjack.
*2 Do not connect the AV receiver' s USB port to a USB port on your computer. Music on your computer cannot be played through the
AV receiver in this way.
*3 Connect a turntable (MM) that has a phono preamp built-in. If your turntable (MM) doesn't have it, you'll need a commercially
available phono preamp.
If your turntable has a moving coil (MC) type cartridge, you'll need a commercially available MC head amp or MC transformer as
well as a phono preamp. See your turntable's manual for details.
• With connection [], you can enjoy Dolby Digital and DTS.
• If your Blu-ray Disc/DVD player has both the main stereo and multichannel outputs, be sure to connect the main stereo
output using connection _.
N How to record the video
See "Recording" to make a connection for video recording (@ page 33).
En
15
Page 16

Make sure that each Onkyo component is
1
connected with an analog audio cable (connection
[] in the hookup examples) (3 page 15).
2
Make the R I connection (see the illustration).
If you're using an RI Dock or cassette tape deck,
3
change the Input Display (3 page 32).
With 1-41 (Remote Interactive), you can use the IY_llowing
special functions:
N System On/Auto Power On
When you start playback on a component connected via
K'tI, if the AV receiver is on Standby, it will
automatically turn on and select that component as the
input source.
N Direct Change
When playback is started on a component connected via
f-4I, the AV receiver automatically selects that
component as the input source.
N Remote Control
You can use the AV receiver's remote controller to
control your other f-4I-capable Onkyo components,
pointing the remote controller at the AV receiver's
remote control sensor instead of the component. You
must enter the appropriate remote control code first
(3 page 47).
• Use only 1"41cables for 1-41connections. 1"-41cables are supplied
with Onkyo players (DVD, CD, etc.).
• Some components have two 1"41jacks. You can connect either
one to the AV receiver. The other jack is for connecting
additional 1"-4I-capable components.
• Connect only Onkyo components to 1"-41jacks. Connecting other
manufacturer's components may cause a malfunction.
• Some components may not support all 1-41functions. Refer to
the manuals supplied with your other Onkyo components.
See "Recording" on the recording (3 page 33).
':iYii:7:;i i:i¸Y:::::i,::::: i!
-"} {{ ..........
L
VCR, DVD recorder,
cassette tape deck,
CDR, MD recorder, etc.
En
16
• The AV receiver must be turned on for recording. Recording is
not possible while it's in Standby mode.
• If you want to record directly from your TV or playback VCR to
the recording VCR without going through the AV receiver,
connect the TV/VCR's audio and video outputs directly to the
recording VCR's audio and video inputs. See the manuals
supplied with your TV and VCR for details.
• Video signals connected to composite video inputs can be
recorded only via composite video outputs. If your TV/VCR is
connected to a composite video input, the recording VCR must
be connected to a composite video output.
• The surround sound and DSP listening modes cannot be
recorded.
• Copy-protected Blu-ray discs and DVDs cannot be recorded.
• Sources connected to a digital input cannot be recorded. Only
analog inputs can be recorded.
• DTS signals will be recorded as noise, so don't attempt analog
recording of DTS CDs or LDs.
Page 17

This section explains how to connect the supplied indoor FM antenna and AM loop antenna.
The AV receiver won't pick up any radio signals without any antenna connected, so you must connect the antenna to use
the tuner.
• Be careful that you don't injure yourself when
using thumbtacks.
Insert wire, Release,
Assembling the AM loop
antenna
AM loop antenna (supplied)
North American and
Brazilian models
FM75_
Insert the plug fully
into the jack.
Asian models
FM75£_
¢
Insert the plug fully
into the jack.
Thumbtacks, etc.
Indoor FM antenna (supplied)
• Once your AV receiver is ready for use, you'll need to tune into a radio station and position the antenna to achieve the best possible
reception.
• Keep the AM loop antenna as far away as possible from your AV receiver, TV, speaker cables, and power cords.
• If you cannot achieve good reception with the supplied indoor FM antenna, try a commercially available outdoor FM antenna instead.
• [f you cannot achieve good reception with the supplied indoor AM loop antenna, try using it with a commercially available outdoor
AM antenna.
(Brazilian models)
Connect the supplied power cord to the AV
receiver's AC INLET.
To AC wall outlet
Plug the power cord into an AC wall outlet.
2
• Before connecting the power cord, connect all of your
speakers and AV components.
• Turning on the AV receiver may cause a momentary power
surge that might interfere with other electrical equipment on the
same circuit. If this is a problem, plug the AV receiver into a
different branch circuit.
• Do not use a power cord other than the one supplied with the AV
receiver. The supplied power cord is designed exclusively for
use with the AV receiver and should not be used with any other
equipment.
• Never disconnect the power cord from the AV receiver while the
other end is still plugged into a wall outlet. Doing so may cause
an electric shock. Always disconnect the power cord from the
wall outlet first, and then the AV receiver.
En
17
Page 18

Turning On/Off the AV Receiver
OON/STANDBY
...................... ii.......... , ........
ii
.........:,i!i,I........ii!!!iil;,ii;_ ,5
@
Press O ON/STANDBY on the front panel.
1
or
Press RECEIVER followed by O on the remote controller.
The AV receiver comes on, the display lights.
[o//j
1 Press O ON/STANDBY on the front panel.
or
Press RECEIVER followed by O on the remote controller.
The AV receiver will enter standby mode. To prevent any loud surprises when you turn on the AV receiver, always
turn down the volume before you turn it off.
• See "Auto Standby" about a power management setting (_ page 41),
Erl
18
Page 19

Playback
See "Controlling Other Onkyo Components" about the
operation of other components (3 page 47).
[hT'J[_ l'_ozLr--r_i
N Operating with the remote controller
Press RECEIVER followed by INPUT
1
SELECTOR.
Start playback on tile source component.
2
See also:
• "Playing iPod/iPhone via USB" (3 page 20)
• "Playing USB Device" (3 page 21 )
• "Listening to AM/FM Radio" (3 page 21 )
• "iPod/iPhone Playback via Onkyo Dock"
(3 page 45)
• "Controlling Other Onkyo Components"
(3 page 47)
3
To adjust tile volume, use VOL A/V.
Select a listening ]node and enjoy!
4
See also:
• "Using the Listening Modes" (3 page 27)
• "Audyssey" (3 page 39)
N Operating on the AV receiver
m
1 Use the input selector buttons to select the input
source.
2 Start playback on the source component. @
3 To adjust the volume, use the MASTER VOLUME
control.
4 Select a listening ]node and enjoy!
first,
Press USB
TOP MENU
Q
This button displays the top menu for each media or service.
®
i,/¥ and ENTER
These buttons navigate through the menus.
_]_
This button cycles through pages.
PLAYLIST _/_
[n Standard Mode (iPod/iPhoue), this buttou selects
playlists.
®
This button starts playback.
®
This button selects the beginning of the current song.
Pressing this button twice selects the previous song.
This button fast-reverses the current song.
II
This button pauses playback.
SEARCH
You can toggle between the playback screeu aud the list
screen during playback.
REPEAT
®
Press this button repeatedly to cycle through the repeat
modes.
To cancel repeat playback, press REPEAT repeatedly until
/ou select Off.
DISPLAY
®
This buttou switches betweeu soug iuformatious.
CH +/-
@
[u Staudard Mode (iPod/iPhoue), this buttou selects albums.
RETURN
@
This button returns to the previous menu.
Ell
19
Page 20

@
_ll,-I
This button selects the next song.
@
This button fast-forwards the current song.
@
This button stops playback.
MODE
@
You call switch between Standard Mode and Extended
Mode during iPod/iPhone playback.
RANDOM
@
This button performs random playback. All of the songs ill
the current folder will be played ill random order. When all
of the songs in the folder have been played once, they'll all
be played again in a different random order. To cancel
random playback, press this button again.
• The buttons you can use will differ depending on the devices and
media used for playback.
This section describes icons that appear on the display
during media playback.
This section explains how to play music files on the
iPod/iPhone.
Compatible iPod/iPhone models
Made for:
iPod touch ( 1sL 2nd, 3rd and 4th generation), iPod classic,
iPod with video, iPod nano (1 st, 2nd, 3r& 4th, 5th and 6th
generation), iPhone 4, iPhone 3GS, iPhone 3G, iPhone
Press USB to select the "USB" input.
1
Connect the USB cable that comes with the
2
iPod/iPhone to the USB port at the front of the AV
receiver.
While reading the contents of your iPod/iPhone, the
message "Connecting..." appears on the display.
Press MODE to switch to Extended Mode.
3
A list of your iPod/iPhone model's contents appears.
Use l/¥ to open a folder, and then press ENTER.
Displayed Icons
Icon Description
FoMer
Track
:f."
Playback
b"
Pause
.q
Fast Forward
:::':.
Fast Reverse
.g
Artist
g
Album
.... Repeat One Track
.i {:/
Repeat Folder (USB Device)
/:::::.2
:% Repeat
Shuffle
.-,. :. Shuffle Album (iPod/iPhoue)
?'i _::
• With the default settings, iPod/iPhoue is operated in
Standard Mode.
• Pressing MODE again switches back to Standard Mode.
• When you disconnect the iPod/iPhone, the AV receiver
stores the mode. This means that if you disconnect when in
Extended Mode, the AV receiver will start in Extended
Mode when you next connect the iPod/iPhoue.
• You can also use the fly, ENTER and TUNING MODE
buttons on the front panel. TUNING MODE allows you to
switch modes.
• When connecting your iPod/iPhone with a USB cable, we
recommend you use an official USB cable from Apple inc.
4 Use i,/¥ to select a music file, and press ENTER or
D._ to start playback.
• Do uot disconnect the USB device or USB cable that comes with
iPod/iPhoue to the USB port at the front of the AV receiver,
while the message "Connecting..." appears on the display.
Standard Mode control
The content information is not displayed on-screen, but
can be operated using the iPod/iPhone or the remote
controller (USB).
• The following iPod models are not supported in Standard Mode.
These iPod models can only be controlled in Extended Mode.
- iPod with video
-iPod uauo (lst generation)
EFI
2O
Page 21

Extended Mode control
The content information is displayed (lists are displayed)
on-screen, and you can control the content while looking
at the screen.
Top screen list:
Playlists, Artists, Albums, Genres, Songs, Composers,
Shuffle Songs, Now Playing
This section explains how to play music files on a USB
device (e.g., USB flash drives and MP3 players).
See also:
• "USB Features" (_ page 55).
Press USB to select the "USB" input.
1
Plug your USB device into the USB port at the
2
front of the AV receiver.
While reading the contents of your USB device, the
message "Connecting..." appears on the display.
Press ENTER.
3
A list of the device's contents appears. To open a
folder, use &/¥ to select it, and then press ENTER.
Use A/¥ to select a music file, and press ENTERor
4
to start playback.
• If the media you connect is not supported, the message "No
Storage" will appear on the display.
• If you connect a USB hard disk drive to the AV receiver's USB
port, we recommend that you use its AC adapter to power it.
• The AV receiver supports USB MP3 players that support the
USB Mass Storage Class standard, which allows USB storage
devices to be connected to computers without the need for
special drivers or software. Note that not all USB MP3 players
support the USB Mass Storage Class standard. Refer your USB
MP3 player's instruction manual for details.
• Protected WMA music files on an MP3 player cannot be played.
• Onkyo accepts no responsibility whatsoever for the loss or
damage to data stored on a USB mass storage device when that
device is used with the AV receiver. We recommend that you
back up your important music files beforehand.
• MP3 players containing music files that are managed with
special music software are not supported.
• Operation with all USB mass storage devices including the
ability to power them is not guaranteed.
• Do not connect your USB mass storage device via a USB hub.
The USB mass storage device must be connected directly to the
AV receiver's USB port.
• If the USB mass storage device contains a lot of data, the AV
receiver make take a while to read it.
• USB memory devices with security functions cannot be played.
• Do not disconnect the USB device or USB cable that comes with
iPod/iPhone to the USB port at the front of the AV receiver,
while the message "Connecting..." appears on the display.
Using the Tuner
With the built-in tuner you can enjoy AM and FM radio
stations. You can store your favorite stations as presets for
quick selection.
You can change the frequency steps (_ page 41 ).
1 Press AM or FM to select either "AM" or "FM".
In this example, FM has been selected.
Band Frequency
C'_ ";:' _:'_' h'_ ".2 ...,.
(Actual display depends on the country.)
Tuning into Radio Stations
mAuto tuning mode
Press TUNING MODE so that the AUTO indicator
1
lights on the display.
Press TUNING A/_r.
2
Searching stops when a station is found.
When tuned into a station, the TUNED indicator
lights. When tuned into a stereo FM station, the FM
STEREO indicator lights on the display, as shown.
FM STEREO
I
F_ STE_IEO
AUTO _ TUNED
i_ TUNED "q
• Tuning into weak FM stereo stations
If the signal from a stereo FM station is weak, it may be
impossible to get good reception. [n this case, switch to
manual tuning mode and listen to the station in mono.
ED
21
Page 22

m Manual tuning mode
In manual tuning mode, FM stations win be in mono.
Press TUNING MODE so that the AUTO indicator
1
goes off on the display.
Press and hold TUNING i/¥.
2
The frequency stops changing when you release the
button.
Press the buttons repeatedly to change the frequency
one step at a time.
m Selecting Presets
1 To select a preset, use PRESET 4/*- on the AV
receiver, or the remote controller's CH +/-.
• You call also use the remote controller's number buttons to
select a preset directly.
m Deleting Presets
N Tuning into stations by frequency
You can tune into AM and FM stations directly by
entering the appropriate frequency.
1 On the remote controller, press AM or FM to select
"AM" or "FM", followed by D.TUN.
(Actual display depends on the country.)
Within 8 seconds, use the number buttons to enter
2
the frequency of the radio station.
For example, to tune to 87.5 (FM), press 8, 7, 5.
If you have entered the wrong number, you can retry
after 8 seconds.
Presetting AM/FM Stations
You can store a combination of up to 40 of your favorite
AM/FM radio stations as presets.
Tune into the AM/FM station that you want to
store as a preset.
See the previous section.
2 Press MEMORY.
The preset number flashes.
(Actual display depends on the country.)
While the preset number is flashing (about 8
3
seconds), use PRESET _/_ to select a preset from
1 through 40.
Press MEMORY again to store the station or
4
channel.
The station or channel is stored and the preset number
stops flashing.
Repeat this procedure for all of your favorite AM/FM
radio stations.
En
22
Select the preset that you want to delete.
See the previous section.
2 While holding down MEMORY, press TUNING
MODE.
The preset is deleted and its number disappears from
the display.
Using RDS (Asian models)
When tuned into an RDS station, the RDS indicator lights.
When the station is broadcasting text information, the text
can be displayed.
N What is RDS?
RDS stands for Radio Data System and is a method of
transmitting data in FM radio signals. It was developed by
the European Broadcasting Union (EBU) and is available
in most European countries. Many FM stations use it these
days. In addition to displaying text information, RDS can
also help you find radio stations by type (e.g., news, sport,
rock, etc.).
The AV receiver supports four types of RDS information:
PS (Program Service)
When tuned to an RDS station that's broadcasting PS
information, the station's name will be displayed. Pressing
DISPLAY will display the frequency for 3 seconds.
RT (Radio Text)
When tuned to an RDS station that's broadcasting text
information, the text will be shown on the display as
described in the next section.
PTY (Program Type)
This allows you to search for RDS radio stations by type
(_ page 23).
TP (Traffic Program)
This allows you to search for RDS radio stations that
broadcast traffic information (_ page 23).
• [n some cases, the text characters displayed on the AV receiver
may not be identical to those broadcast by the radio station. Also,
unexpected characters may be displayed when unsupported
characters are received. This is not a malfunction.
• If the signal from an RDS station is weak, RDS data may be
displayed intermittently or not at all.
Page 23

m Displaying Radio Text (RT)
Press RT/PTY/TP once.
The RT information scrolls across the display.
• The message "Waiting" may appear while the AV receiver
waits for the RT information.
• [f the message "No Text Data" appears on the display, no
RT information is available.
m Finding Stations by Type (PTY)
You can search for radio stations by type.
1 Press RT/PTY/TP twice.
The current program type appears on the display.
2 Use PRESET _/_ to select the type of program
you want.
See the table shown later in this chapter.
3 To start tile search, press ENTER.
The AV receiver searches until it finds a station of the
type you specified, at which point it stops briefly
before continuing with the search.
4 When a station you want to listen to is found, press
ENTER.
It no stations are found, the message "Not Found"
appears.
@Listening to Traffic News (TP)
You can search for stations that broadcast traffic news.
1 Press RT/PTY/TP three times.
If the current radio station is broadcasting TP (Traffic
Program), "[TP]" will appear on the display, and
traffic news will be heard as and when it's broadcast.
If "TP" without square brackets appears, this means
that the station is not broadcasting TP.
2 To locate a station that is broadcasting TP, press
ENTER.
The AV receiver searches until it finds a station that's
broadcasting TP.
If no stations are found, the message "Not Found"
appears.
RDS program types (PTY)
Type Display
None None
News reports News
Current affairs Affairs
[nformation [nfo
Sport Sport
Education Educate
Drama Drama
Culture Culture
Science and technology Science
Varied Varied
Pop music Pop M
Rock music Rock M
Middle of the road music Easy M
Light classics Light M
Serious classics Classics
Other music Other M
Weather Weather
Finance Finance
Children's programmes Children
Social affairs Social
Religion Religion
Phone in Phone [n
Travel Travel
Leisure Leisure
Jazz music Jazz
Country music Country
National music Nation M
Oldies music Oldies
Folk music Folk M
Documentary Document
Alarm test TEST
Alarm Alarm!
Erl
23
Page 24

Using Basic Functions
Measurement procedure
With the supplied calibrated microphone,
Audyssey 2EQ® automatically determines the number of
speakers connected, their size for purposes of bass
management, optimum crossover frequencies to the
subwoofer (if present), and distances from the primary
listening position.
Audyssey 2EQ then removes the distortion caused by
room acoustics by capturing room acoustical problems
over the listening area in both the frequency and time
domain. The result is clear, well-balanced sound for
everyone. Audyssey 2EQ can be used with
Audyssey Dynamic EQ® and
Audyssey Dynamic Volume® (_ page 39).
Before using this function, connect and position all of
your speakers.
Audyssey 2EQ offers two ways of measuring: the
"Audyssey Quick Start" and "Audyssey 2EQ Full
Calibration".
• "Audyssey Quick Start" uses the measurement from
one position to perform the speaker setting only.
• "Audyssey 2EQ Full Calibration" uses the
measurement from three positions to correct room
response in addition to the speaker setting.
The Quick Start takes 2 minutes and Full Calibration takes
about 10minutes.
Total measurement time varies depending on the number
of speakers.
To create a listening environment in your home theater
that all listeners will enjoy, Audyssey 2EQ takes
measurements at up to 3 positions within the listening
area. Position the microphone at ear height of a seated
listener with the microphone tip pointed directly at the
ceiling using a tripod. Do not hold the microphone in your
hand during measurements as this will produce inaccurate
results.
@ First measurement position
Also referred to as the Main Listening Position, this
refers to the most central position where one would
normally sit within the listening environment.
Audyssey 2EQ uses the measurements from this
position to calculate speaker distance, level, polarity,
and the optimum crossover value for the subwoofer.
(_) Second measurement position
The right side of the listening area.
@ Third measurement position
The left side of the listening area.
The distances from position @ to (_) and @ to @ must be
at least 1 meter (3.3 It.).
Erl
24
/
/
..... : Listening area @ to (_): Listening position
• Make the room as quiet as possible. Background noise and Radio
Frequency [nterference (RFI) can disrupt the room
measurements. Close windows, televisions, radios, air
conditioners, fluorescent lights, home appliances, light dimmers,
or other devices. Silence the cell phone (even if it is not in use)
or place it away from all audio electronics.
• The microphone picks up test tones played through each speaker
as Audyssey 2EQ Room Correction and Speaker Setup runs.
• Audyssey 2EQ Room Correction and Speaker Setup cannot be
performed while a pair of headphones is connected.
Page 25

Turn on the AV receiver and the connected TV.
On the TV, select the input to which the AV receiver
is connected.
Set the speaker setup microphone at the Main
2
Listening Position @, and connect it to the SETUP
MIC jack.
SETUP MIC jack
Speaker setup microphone
The speaker setting menu appears.
• The on-screen setup menus appear only on a TV that is
connected to the HDMI OUT. [f your TV is connected to
the MONITOR OUT V or the COMPONENT VIDEO
OUT, use the AV receiver's display when changing
settings.
3 When you've finished making the settings, press
ENTER.
.....2E°_AU_Ose!UP............................................................:_
SurrBk/FrontHIgh
8 Use &/¥ to select an option, and then
ENTER.
2EQ:Auto Setup
<- Review Speaker Configuration ->
Subwoofer Yes
Front Small
Center Small
Surround Small
Front High None
Surf Back Small
Surf Back Ch 2ch
Crossover lOOHz
Save
Cancel
The options are:
Save:
Save the calculated settings and exit
Audyssey 2EQ Room Correction and Speaker
Setup.
Cancel:
Cancel Audyssey 2EQ Room Correction and
Speaker Setup.
• You can view the calculated settings for the speaker
configuration, speaker distances, and speaker levels by
using "_/_.
9
Use A/¥ to select a target, and use a/_ to change
the setting.
Alter the results of Audyssey 2EQ have been saved,
the menu will display the "Audyssey" (_ page 39),
"Dynamic EQ" (_ page 39), "Dynamic Volume"
(_ page 39) settings.
press
Perform the "Sp Config (Speaker Configuration)"
according to your speaker configuration:
- "SurrBk/FrontHigh" (_ page 36)
4 Use &/¥ to select "Audyssey Quick Start" or
"Audyssey 2EQ Full Calibration".
5 Press ENTER.
Audyssey 2EQ® Room Correction and Speaker Setup
starts.
Test tones are played through each speaker as
Audyssey 2EQ Room Correction and Speaker Setup
runs. This process takes a few minutes. Please
refrain from talking during measurements and do
not stand between speakers and the microphone.
Do not disconnect the speaker setup microphone
during Audyssey 2EQ Room Correction and Speaker
Setup, unless you want to cancel the setup.
If you select "Audyssey Quick Start", you will go to
step 8.
6 Place the setup microphone at the next position,
and then press ENTER.
Audyssey 2EQ performs more measurements. This
takes a few minutes.
7 When prompted, place the setup microphone at
the next position, and repeat step 6.
• When "Audyssey Quick Start" has been used for
measurement, "Audyssey" cannot be selected.
• These settings are applied to all input selectors.
Press ENTER.
10
Disconnect the speaker setup microphone.
11
!
• You can cancel Audyssey 2EQ Room Correction and Speaker
Setup at any point in this procedure simply by disconnecting the
setup microphone.
• Do not connect or disconnect any speakers during
Audyssey 2EQ Room Correction and Speaker Setup.
• If the AV receiver is muted, it will be unmuted automatically
when Audyssey 2EQ Room Correction and Speaker Setup
starts.
• Changes to the room after Audyssey 2EQ Room Correction and
Speaker Setup require you run Audyssey 2EQ Room Correction
and Speaker Setup again, as room EQ characteristics may have
changed.
ED
25
Page 26

Error Messages
Using a Powered Subwoofer
While Audyssey 2EQ® Room Correction and Speaker
Setup is in progress, one of the error messages below may
appear.
q
f'_;,;_,;;;,i'_;ig;;i;'o'_,i_;'i@ -- Error message
Cancel
The options are:
Retry:
Try again.
Cancel:
Cancel Audyssey 2EQ Room Correction and
Speaker Setup.
• Ambient noise is too high.
The background noise is too loud. Remove the source of
the noise and try again.
• Speaker matching error!
The number of speakers detected was different from
that of the first measurement. Check the speaker
connection.
• Writing Error!
This message appears if saving fails. Try saving again.
If this message appears after 2 or 3 attempts, contact
your Onkyo dealer.
• Speaker Detect Error
This message appears if a speaker is not detected. "No"
means that no speaker was detected.
If you're using a powered subwoofer and it outputs very
low-frequency sound at a low volume level, it may not be
detected by Audyssey 2EQ Room Correction and Speaker
Setup.
If the "Subwoofer" appears on the "Review Speaker
Configuration" screen as "No", increase the subwoofer' s
volume to the half-way point, set it to its highest crossover
frequency, and then try running Audyssey 2EQ Room
Correction and Speaker Setup again. Note that if the
volume is set too high and the sound distorts, detection
issues may occur, so use an appropriate volume level. If
the subwoofer has a low-pass filter switch, set it to Off or
Direct. Refer to your subwoofer's instruction manual for
details.
• See "Speaker Configuration" for appropriate settings
(÷ page 12).
Changing the Speaker Setup Manually
You can manually make changes to the settings found
during Audyssey 2EQ Room Correction and Speaker
Setup.
See also:
• "Sp Config (Speaker Configuration)" (_ page 36)
• "Sp Distance (Speaker Distance)" (_ page 37)
• "Level Cal (Level Calibration)" (_ page 37)
ED
26
Page 27

Selecting Listening Modes
See "Listening Modes" for detailed information about the listening modes (_ page 28).
m Listening Mode Buttons
RECEIVER first,
I Press
MOVIEFrV, MUSIC, GAME
MUSIC--
MOVIE/TVi
t'7
--GAME
--STEREO
4;;)
MOVIE/TV button
This button selects the listening modes intended for use
with movies and TV.
MUSIC button
This button selects the listening modes intended for use
with music.
• The Dolby Digital and DTS listening modes can only be selected if your Blu-ray Disc/DVD player is connected to the AV
receiver with a digital audio connection (coaxial, optical, or HDMI).
• The listening modes you can select depends on the format of the input signal. To check the format, see "Displaying Source
Information" (3 page 32).
• While a pair of headphones is connected, you can select the following listening modes: Mono, Direct, and Stereo.
About Listening Modes
The AV receiver's listening modes can transform your listening room into a movie theater or concert hall, with high
fidelity and stunning surround sound.
I Explanatory Notes
(_ Front speakers
_) Center speaker
(_) Surround speakers
@ Surround back speakers
(_) Front high speakers
GAME button
This button selects the listening modes intended for use
with video games.
STEREO button
This button selects the Stereo listening mode and All
Channel Stereo listening modes.
Subwoofer
En
27
Page 28

Input Source
The following audio formats are supported by the listening mode.
This is mono (monophonic) sound.
This is stereo (stereophonic) sound. Two independent audio signal channels are reproduced through two speakers.
I g-lR'o_
I N_'oal
This is 5. l-channel surround sound. This surround system has five main channels of sound aud a sixth subwoofer
chauuel (called the poiut-oue chauuel).
This is 7.l-channel surround sound. This is a further sound enhancement to 5.1 channel sound with two additional
speakers that provide greater sound envelopment and more accurate positioning of sounds.
This is DTS-ES surrouud sound. This surrouud system can produce a discrete or a matrix-encoded sixth channel from
existing DTS 5.1 encoded material.
This is Dolby Digital EX surround sound. This provides a ceuter back surrouud chauuel from 5. l-chauuel sources.
Speaker Layout
The illustration shows which speakers are activated in each channel. See "Sp Config (Speaker Configuration)" for the
speaker setup (_ page 36).
N Onkyo-Original DSP Listening Modes
Listening Mode Description
Orchestra*l Suitable for classical or operatic music, this mode emphasizes the surround
channels in order to widen the stereo image, and simulates the natural
reverberation of a large hall.
Unplugged*l Suitable for acoustic instruments, vocals, and jazz, this mode emphasizes the
front stereo image, giving the impression of being right in front of the stage.
Studio-Mix*l
TV Logic*l
Game-RPG*I Iu this mode, the sound has a dramatic feel with a similar atmosphere to
Suitable for rock or pop music, listening to music in this mode creates a
lively sound field with a powerful acoustic image, like being at a club or rock
coucert.
This mode adds realistic acoustics to TV show's produced in a TV studio,
surround effects to the entire sound, and clarity to voices.
Orchestra mode.
Game-Action*l In this mode, sound localization is distinct with emphasis on bass.
Game-Rock*l In this mode, sound pressure is emphasized to heighten live feel.
a
Game-Sports*l In this mode, reverberatiou is iucreased aud souud localizatiou decreased
slightly.
All Ch Stereo Ideal for background music, this mode fills the eutire listeuiug area with
stereo sound from the front, surround, and surround back speakers.
Full Mono In this mode, all speakers output the same souud in mouo, so the souud you
hear is the same regardless of where you are withiu the listeuiug room.
T-D (Theater-
Dimensional)_l
Erl
With this mode you can eujoy a virtual surround sound even with only two
or three speakers. This works by controlling how' sounds reach the listener's
left and right ears. Good results may not be possible if there's too much
reverb, so we recommend that you use this mode iu au euviroumeut with
little or uo uatural reverb.
28
Speaker
Layout
NNE_il
Ni1NN[_il
Page 29

m Listening Modes
Listening Mode
Direct
Stereo
Mono
Multichannel
Dolby Pro Logic IIx*3
Dolby Pro Logic II
Dolby Pro Logic IIz
Height
Dolby EX
Description
[n this mode, audio from the input source is output without surround-sound
processing. The speaker configuration (presence of speakers) and speaker
distance settings are enabled, but much of the processing set via Home menu
is disabled. A/V Sync does not have effect on the analog audio. See
"Advanced Setup" for more details (_ page 34).
Sound is output from the front left and right speakers and subwoofer.
Use this mode when watching an old movie with a mono soundtrack, or use
it with the foreign language soundtracks recorded in the left and right
channels of some movies. It can also be used with DVDs or other sources
containing multiplexed audio, such as karaoke DVDs.
This mode is for use with PCM multichannel sources.
Dolby Pro Logic IIx expands any 2-channel source for 7.l-channel
playback. It provides a very natural and seamless surround-sound experience
that fully envelops the listener. As well as music and movies, video games
can also benefit from the dramatic spatial effects and vivid imaging, ff
you're not using any surround back speakers, Dolby Pro Logic II will be
used instead of Dolby Pro Logic IIx.
Dolby PLIIx Movie
Use this mode with any stereo or Dolby Surround (Pro Logic) movie (e.g.,
TV, DVD, VHS).
Dolby PLIIx Music
Use this mode with any stereo or Dolby Surround (Pro Logic) music source
(e.g., CD, radio, cassette, TV, VHS, DVD).
Dolby PLIIx (;ame
Use this mode with video games, especially those that bear the Dolby Pro
Logic II logo.
Dolby PLIIx Movie, Dolby PLIIx Music
These modes use the Dolby Pro Logic IIx modes to expand 5.l-channel
sources for 7. l-channel playback.
Dolby Pro Logic IIz Height is designed to more effectively use existing
program material when height channel speaker outputs are present. Dolby
Pro Logic IIz Height can be used to upmix a variety of sources from movies
and music, but are particularly well-suited to upmix game content.
These modes expand 5. l-channel sources for 6.1/7.1-channel playback.
They're especially suited to Dolby EX soundtracks that include a matrix-
encoded surround back channel. The additional channel adds an extra
dimension and provides an enveloping surround sound experience, perfect
for rotating and fly-by sound effects.
Input
Source
|HI.It
|HI.It
|HI.It
Speaker
Layout
12.1113.1II5.1I
12,1113,1II5,1I
13.1II5.1II7.1I
13.1II5.1II7.1I
[_-_'4
[_-_'5
Erl
29
Page 30

Listening Mode
Dolby Digital
Dolby Digital Plus*6
Dolby TrueHD
DTS
Description
[n this mode, audio fi'om the input source is output without surround-sound
processing. The speaker configuration (presence of speakers), crossover
fi'equency, speaker distance, A/V Sync and much of the processing set via
Home menu are enabled. See "Advanced Setup" for more details
(÷ page 34).
Speaker
Layout
Ni1NN[_il
Ni1NN[_il
[NillNi11_-l*2
[NillNilI_-I
[NillNi11_-l*2
[NilNNNil
DTS-HD High
Resolution Audio
DTS-HD Master
Audio
DTS Express
DSD*7
DTS 96/24
DTS-ES Discrete_8
DTS-ES Matrix*8
Neo:6
iv
This mode is for use with DTS 96/24 sources. This is high-resolution DTS
with a 96 kHz sampling rate and 24-bit resolution, providing superior
fidelity. Use it with DVDs that bear the DTS 96/24 logo.
This mode is for use with DTS-ES Discrete soundtracks, which use a
discrete surround back channel for true 6.117. l-channel playback. The seven
totally separate audio channels provide better spatial imaging and 360-
degree sound localization, perfect for sounds that pan across the surround
channels. Use it with DVDs that bear the DTS-ES logo, especially those with
a DTS-ES Discrete soundtrack.
This mode is for use with DTS-ES Matrix soundtracks, which use a matrix-
encoded back-channel for 6.1/7. l-channel playback. Use it with DVDs that
bear the DTS-ES logo, especially those with a DTS-ES Matrix soundtrack.
This mode expands any 2-channel source for up to 7. l-channel playback. It
uses seven full-bandwidth channels of matrix decoding for matrix-encoded
material, providing a very natural and seamless surround sound experience
that fully envelops the listener.
Neo:6 Cinema
Use this mode with any stereo movie (e.g., TV, DVD, VHS).
Neo:6 Music
Use this mode with any stereo music source (e.g., CD, radio, cassette, TV,
VHS, DVD).
This mode uses Neo:6 to expand 5.l-channel sources for 6.1/7. l-channel
playback.
[NilNNI_-I_2
[NillNilI_-I
[NilNNI_-I_2
Ni1NN[_il
[NilNNNil_5
"1 These listening modes cannot be selected during USB or iPod playback.
*2 When the input source contains the encoded front high channel, front high speakers output the sound.
*3 If there are no surround back speakers, Dolby Pro Logic II is used.
*4 Surround back speakers are not supported.
*5 Front high speakers are not supported.
*6 For the Blu-ray Discs, Dolby Digital is used in a 3.1/5. l-channel speaker system.
*7 AV receiver can input the DSD signal from HDM[ IN. Setting the output setting on the player side to PCM might obtain a better
sound according to the player. [n that case, set the output setting on the player side to PCM.
*8 If there are no surround back speakers, DTS is used.
• The listening modes cannot be selected with some source formats.
Ell
30
Page 31

The Home menu provides you quick access to frequently
used menus without having to go through the long
standard menu. This menu enables you to change settings
and view the current information.
Press RECEIVER followed by HOME.
1
The Home menu will be superimposed on the TV
screen.
Use i,/¥ and ENTER to make the desired selection.
2
N Input
You can select the input source while viewing the
information as follows: the name of input
selectors, input assignments.
Press ENTER to display the current input
source, followed by i,/¥ to select the desired
input source. Pressing ENTER again switches
to the selected input source.
NAudio
You can change the following settings: "Bass",
"Treble", "Subwoofer Level", "Center Level",
"Audyssey", "Dynamic EQ",
"Dynamic Volume", "Late Night", "Music
Optimizer", and "Cinema Filter".
See also:
• "Audyssey" (_ page 39)
• "Using the Audio Settings" (_ page 43)
N Info*l
You can view the information of the following
items: "Input" and "Output".
N Listening Mode
You can select the listening modes that are
grouped in the following categories:
"MOVIE/TV", "MUSIC" and "GAME".
Use 1,1¥ to select the category and </_ to
select the listening mode. Press ENTER to
switch to the selected listening mode.
With the sleep timer, you can set the AV receiver to turn
off automatically alter a specified period.
Press RECEIVER followed by SLEEP repeatedly
1
to select the required sleep time.
The sleep time can be set from 90 to 10 minutes in 10
minute steps.
The SLEEP indicator lights on the display when the
sleep timer has been set. The specified sleep time
appears on the display for about 5 seconds, then the
previous display reappears.
• ff you need to cancel the sleep timer, press SLEEP
repeatedly until the SLEEP indicator goes off.
• To check the time remaining until the AV receiver sleeps,
press SLEEP. Note that if you press again on SLEEP as
the time being displayed is equal or inferior to 10 minutes,
the sleep timer will go off.
"1 Depending on the input source and listening mode, not all
channels shown here output the sound.
El1
31
Page 32

NINIb'I NN!R
You can adjust the brightness of the AV receiver's
display.
1 Press RECEIVER followed by DIMMER
repeatedly to select: dim, dimmer, or normal
brightness.
• (North American and Brazilian models) Alternatively,
you call use the AV receiver's DIMMER.
You can display various information about the current
input source as follows.
1 Press RECEIVER followed by DISPLAY
repeatedly to cycle through tile available
information.
The following information can typically be displayed.
Input source & 1volume*l r..,_ ........... ._,...,
Listening mode
Signal format*2
or sampling -) _:?.i i::, ?, ':,.i) .5.:._,, .S
frequency
When you connect an R I-capable Onkyo component, you
must configure the input display so that R I can work
properly.
This setting can be done only from the front panel.
1 Press TV/CD, GAME or VCR/DVR.
"TV/CD", "GAME" or "VCR/DVR" appears on the
display.
2 Press and hold down the same button (about
3 seconds) to change the input display.
Repeat this step to select the desired input display.
N TV/CD:
TV/CD --+ DOCK
t_ TAPE _1
NGAME:
GAME <-_DOCK
N VCR/DVR:
VCR/DVR +-_DOCK
• DOCK cannot be selected for multiple input selectors at
the same time.
• Enter the appropriate remote control code before using the
remote controller for the first time (_ page 47).
• Alternatively, you can use the AV receiver's DISPLAY.
"1 When AM or FM radio is used, the band, preset number, and
frequency are displayed.
*2 If the input signal is analog, "Analog" is displayed. If the
input signal is PCM, the sampling frequency is displayed. If
the input signal is digital but not PCM, the signal format is
displayed. Information is displayed for about three seconds,
then the previously displayed information reappears.
EF1
32
The Music Optimizer function enhances the sound quality
of compressed music files.
1 Press MUSIC OPTIMIZER on the front panel.
The M.Opt indicator lights on the display.
• Alternatively, you can use the remote controller's HOME
and arrow buttons.
• See "Music Optimizer" for more details (_ page 44).
Page 33

Recording Separate AV Sources
You can temporarily mute the output of the AV receiver.
1 Press RECEIVER followed by MUTING.
The output is muted and the MUTING indicator
flashes on the display.
• To tmmute, press MUTING again o1"adjust the volume.
• The mute is cancelled when the AV receiver is set to
Standby.
Connect a pair of stereo headphones with a
standard plug (1/4 inch or 6.3 ram) to the
PHONES jack.
• Always turn down the volume before connecting your
headphones.
• While the headphones plug is inserted ill the PHONES
jack, the speakers are turned off.
• When you connect a pair of headphones, the listening mode
is set to Stereo, unless it's already set to Stereo, Mono, or
Direct.
Here you can record audio and video from completely
separate sources, allowing you to overdub audio onto your
video recordings. This function takes advantage of the fact
that when an audio-only input source (TV/CD) is selected,
the video input source remains unchanged.
In the following example, audio from the CD player
connected to the TV/CD IN and video from the camcorder
connected to the AUX INPUT VIDEO are recorded by the
VCR connected to the VCR/DVR OUT jacks.
This section explains how to record the selected input
source to a component with recording capability, and how
to record audio and video from different sources.
AV Recording
Audio sources can be recorded to a recorder (e.g., cassette
tape deck, CDR, MD recorder). Video sources can be
recorded to a video recorder (e.g., VCR, DVD recorder).
Use the input selector buttons to select the source
that you want to record. 2
You can watch the source while recording. The AV
receiver's MASTER VOLUME control has no effect 3
on recording. 4
On your recorder, start recording.
2
On the source component, start playback.
3
If you select another input source during recording,
that input source will be recorded.
L
CD player VCR
Prepare the camcorder and CD player for
1
playback.
Prepare the VCR for recording.
L
A:= : Video signal
: Audio signal
Press AUX input selector.
Press TV/CD input selector.
This selects the CD player as the audio source, but
leaves the camcorder as the video source.
Start recording on the VCR and start playback on
5
the camcorder and CD player.
The video from the camcorder and the audio from the
CD player are recorded by the VCR.
_1
ED
33
Page 34

Advanced Setup
(_) Hardware @ HDMI Setup
(_ page 41) (_ page 42)
RemotelD HDMIThrough
AM/FM Freq Step Audio TV Out
Auto Standby Audio Return Ch
LIpSync
iii i
• Theon-screen setup menus are displayedwhen:
- There is no video input, o1"
-The video input is 480p, 576p, 720p, 1080i, o1"1080p.
SetupMenu
_ i H_[I_! BD/DVD
VCR/DVR
-- 2. Component
3. DigitalAudio
CBL/SAT
-- 4. SpConfig
AUX
-- 5. SpDistance
-- 6. LevelCal
TUNER
TV/GD
-- 7.AudioAdjust
-- 8. SourceSetup
@-- 9. Hardware
-- 10. HDMISetup
@ HDMI Input
(_ page 35)
VCR/DVR Left
CBUSAT FrontHigh Left
GAME Center
AUX Front High Right
/UNEF_ Right
TV/CD SurroundRight
(_) Sp Distance
(_ page 37)
SurrBack Right
SurrBack Left
Surround Left
Subwoofer
(_) Component @ Level Cal
(_ page 35) (_ page 37)
_DiDg _eff
VCR/DVR Front High Left
CBLJSAT Center
GAME Front High Right
AUX Right
/UNE// Surround Right
TV/CD SurrBack Right
SurrBack Left
Surround Left
Subwoofer
@ Digital Audio (_ Audio Adjust
(_ page 35) (_ page 37)
VCR/DVR Input Ch (Mono)
CBL/SAT Panorama
GAME Dimension
AUX Center Width
T_HR Height Gain
TV/CD Dolby EX
Center Image
Listening Angle
@ Sp Config (_ Source Setup
(_ page 36) (_ page 39)
U I Remote indicator
RECEIVER
RETURN
The on-screen setup menus appear on the connected TV
and provide a convenient way to change the AV receiver's
various settings. Settings are organized into 10 categories
on the main menu.
Carry out the settings by using the on-screen display.
1 Press RECEIVER followed by SETUP.
• [fthe main menu doesn't appear, make sure the appropriate
external input is selected on your TV.
Use &/¥ to select a menu, and then press ENTER.
2
Use &/¥ to select target, and use "_/_" to change the
3
setting.
Press SETUP to close the menu.
Press RETURN to return to the main menu.
• This procedure can also be performed on the AV receiver by
using SETUP, arrowbuttons, and ENTER.
• DuringAudyssey 2EQg_Room Correction and Speaker Setup,
messages, etc., that are displayed on theTV screen will appear
in the Display.
Explanatory Notes
En
34
Front Dynamic EO
Center ReferenceLevel
Surround Dynamic Volume
FrontHigh AN Sync
Surround Back Name
Surround Back Ch Audio Selector
Crossover P_e:_ M0d
DoubleBass
Subwoofer
-----_ Yes
,_oo
(_) Menu selection
(_) Setting target
(_) Setting options (default setting underlined)
Page 35

IfyouconnectavideocomponenttoanHDMIinput,you
mustassignthatinputtoaninputselector.Forexample,if
youconnectyourBlu-rayDisc/DVDplayertoNDMI
IN 2, you must assign "HDMI2" to the "BD/DVD" input
selector.
Here are the default assignments.
Input selector Default assignment
BD/DVD HDMII
VCR/DVR HDMI2
CBL/SAT HDMI3
(;AME HDMI4
AUX ....
TV/CD ....
m BD/DVD, VCR/DVR, CBL/SAT, GAME, AUX,
TV/CD
HDMI1, HDMI2, HDMI3, HDMI4:
Select a corresponding HDMI input that the video
component has been connected.
Select if you're not using the NDMI OUT.
Each HDMI input cannot be assigned to two input
selectors or more. When HDMI1 - HDMI4 have
already been assigned, you must set first any unused
input selectors to .... , or you will be unable to
assign HDMI1 -HDMI4 to input selector.
• When all HDMI IN is assigned to all input selector as explained
here, the digital audio input for that input selector is
automaticallyset to the same HDMIIN
• Do not assign the component connected with the HDM[ input to
TV/(TDselector when you set "HDMI Ctrl (RIHD)" settingto
"On" (3 page 42). Otherwise,appropriate CEC (Consumer
Electronics Control) operation will not be guaranteed.
[efelilltIele[:-lel#'_efelilltIele[:-leli_[;.IslflMtl#l_i
If you connect a video component to a component video
input, you must assign that input to an input selector. For
example, if you connect your Blu-ray Disc/DVD player to
COMPONENT VIDEO IN 2, you must assign "IN2" to
the "BD/DVD" input selector.
Here are the default assignments.
m BD/DVD, VCR/DVR, CBL/SAT, GAME, AUX,
TV/CD
_IN1, IN2:
Select a corresponding component video input that
the video component has been connected.
,:
Select if you're not using the COMPONENT
VIDEO OUT.
If you connect a component to a digital audio input, you
must assign that input to an input selector. For example, if
you connect your CD player to the OPTICAL IN 1, you
must assign "OPTICALI" to the "TV/CD" input
selector.
Here are the default assignments.
Input selector Default assignment
BD/DVD COAXIALI
VCR/DVR .....
CBL/SAT COAXIAL2
GAME OPTICALI
AUX .....
TV/CD OPTICAL2
m BD/DVD, VCR/DVR, CBL/SAT, GAME, AUX,
TV/CD
COAXIAL1, COAXIAL2, OPTICAL1,
OPTICAL2:
Select a corresponding digital audio input that the
component has been connected.
,:
Select if the component is connected to an analog
audio input.
• Whenan HDMI INis assigned to an inputselector in
"HDM[Input" (3 page 35), this input assignment is
automatically set to the same HDMI IN And in addition tothe
usualinputs (e.g., COAXlALI, COAXIAL2, etc.), youcanalso
select HDM[ inputs.
• Available sampling rate for PCM signals from a digital input
(optical and coaxial) is 32/44.1/48/88.2/96kHz/l 6, 20, 24 bit.
Input selector Default assignment
BD/DVD INI
VCR/DVR ....
CBL/SAT IN2
(;AME ....
AUX ....
TV/CD ....
En
35
Page 36

by Audyssey 2EQ® Room Correction and Speaker
I ome of the settings in this section are set automatically
Setup (3 page 24).
I Surround Back Ch
lch:
Select if only one surround back speaker is
connected.
2ch:
Select if two (left and right) surround back speakers
are connected.
iii i
Here you can check the settings made by Audyssey 2EQ
Room Correction and Speaker Setup, or set them
manually, which is useful if you change one of the
connected speakers after using Audyssey 2EQ Room
Correction and Speaker Setup.
This section explains how to specify
which speakers are connected and their
sizes.
For speakers with a cone diameter larger
than 6-1/2 inches (16 cm), specfly Large
(lull band). For those with a smaller Cone diameter
diameter, specify Small (default crossover 100 Hz).
The crossover frequency can be changed in the
"Crossover (Crossover Frequency)" (3 page 36).
• These settings are not available ill either of the following cases:
- a pair of headphones is connected.
- the "Audio TV Out" setting is set to "On" (_ page 42).
- "HDMI Ctrl (RIHD)" is set to "On" (_ page 42) and
you're listening through your TV speakers.
m Subwoofer
_Yes
No
m Front
Small:
Large:
Select based on the cone diameter.
• ff the "Surround Back" setting is set to "None", this setting
cannot be selected.
m Crossover (Crossover Frequency)
This setting is adwmtageous for the speakers that you
specified as "Small" in the "Sp Config (Speaker
Configuration)" (3 page 36). To get the best bass
performance from your speaker system, you need to set
the crossover frequency according to the size and
frequency response of your speakers.
40Hz, 50Hz, 60Hz, 70Hz, 80Hz, 90Hz, 100Hz,
120Hz, 150Hz, 200Hz
Use the diameter of the smallest speaker in your system
when choosing the crossover frequency.
Speaker cone diameter Crossover frequency
Over 8 in. (20 cm) 40/50160 Hz*
6-1/2 to 8 in. (16 to 20 cm) 70/80/90 Hz*
5-1/4to6-1/2 in. (13 to 16cm) 100Hz
3-1/2to5-1/4in.(9to13cm) 120Hz
Under 3-1/2 in. (9 cm) 150/200 Hz*
* Choose the setting suitable for the speaker.
• For a more accurate setting, look up the frequency response in
the manuals supplied with your speakers and set accordingly.
• Choose a higher crossover frequency if you want more sound
from your subwoofer.
m Double Bass
• ffthe "Subwoofer" setting is set to "No", this setting is fixed at
"Large" and does not appear.
m Center*l, Surround*l, Front High*l*2*3*4*5,
Surround Back*V2*3*6
Small:
Large:
Select based on the cone diameter.
None:
Select if no speaker is connected.
"1 ff the "Front" setting is set to "Small", the "Large" option
cannot be selected.
*2 ff the "Surround" setting is set to "None", this setting cannot
be selected.
*3 ff the "Surround" setting is set to "Small", the "Large"
option cannot be selected.
*4 For "Front High", the default is "None".
*5 ff the "Surround Back" setting is set to other than "None",
this setting is set to "None".
"6 ff the "Front High" setting is set to other than "None", this
setting is set to "None".
El1
36
IThis setting is not set automatically by Audyssey 2EQ
Room Correction and Speaker Setup (3 page 24).
}On
}Off
Turn this setting on to boost bass output by feeding bass
sounds from the front left, right, and center channels to the
subwoofer.
• This function can be set only if the "Subwoofer" setting is set to
"Yes", and the "Front" setting is set to "Large" (_ page 36).
I
J
Page 37

This setting is set automatically by Audyssey 2EQ0¢
Room Correction and Speaker Setup (3 page 24).
Here you can specify the distance from each speaker to the
listening position so that the sound from each speaker
arrives at the listener's ears as the sound designer
intended.
N Unit
feet:
Distances can be set in feet. Range: lft to 30ft in
1 foot steps.
meters:
Distances can be set in meters. Range: 0.3m to 9.0m
in 0.3 meter steps.
(The default setting varies from country to country.)
N Left, Front High Left, Center, Front High Right,
Right, Surround Right, Surr Back Right, Surr
Back Left, Surround Left, Subwoofer
Specify the distance from the each speaker to your
listening position.
• These settings are not available in either of the following cases:
- a pair of headphones is connected.
- the "Audio TV Out" setting is set to "On" (_ page 42).
-"HDMI Ctrl (RIHD)" is set to "On" (_ page 42) and
you're listening through your TV speakers.
• Speakers that you set to "No" or "None" in the "Sp Coufig
(Speaker Configuration)" (_ page 36) cannot be selected.
"1 For the center speaker and subwoofer, the level settings made
by using HOME are saved here as the default settings.
• If you're using a haudheld sound level meter, adjust the level of
I
each speaker so that it reads 75 dB SPL at the listening position,
measured with C-weighting and slow' reading.
1
With the Audio Adjust functions and settings, you can
adjust the sound and listening modes as you like.
Multiplex/Mono Settings
N Multiplex
Input Ch (Mux)
Main
Sub
Main/Sub
This setting determines which channel of a stereo
multiplex source is output. Use it to select audio channels
or languages with multiplex sources, multilingual TV
broadcasts, and so on.
N Mono
Input Ch (Mono)
Left + Right
Left
Right
This setting specifies the channel to be used for playing
any 2-channel digital source such as Dolby Digital. or 2-
channel analog/PCM source in the Mono listening mode.
This setting is set automatically by Audyssey 2EQRoom Correction and Speaker Setup (3 page 24).
Here you can adjust the level of each speaker with the
built-in test tone so that the volume of each speaker is the
same at the listening position.
N Left, Front High Left, Center*l, Front High Right,
Right, Surround Right, Surr Back Right, Surr
Back Left, Surround Left
-12 dB to 0 dB to +12 dB in 1 dB step.
N Subwoofer*l
-15 dB to 0 dB to +12 dB in 1 dB step.
!
• These settings cannot be calibrated in either of the following
cases:
- a pair of headphoues is connected.
- the "Audio TV Out" setting is set to "On" (_ page 42).
-"HDMI Ctrl (RIHD)" is set to "On" (_ page 42) and
you're listening through your TV speakers.
- the AV receiver is muted.
• Speakers that you set to "No" or "None" in the "Sp Coufig
(Speaker Configuration)" (_ page 36) cannot be selected.
1
Erl
37
Page 38

iii i
Dolby Settings
m PLIIx Music (2ch Input)
These settings apply to only 2-channel stereo sources.
If you're not using any surround back speakers, these
settings apply to Dolby Pro Logic II, not Dolby Pro Logic
IIx.
Panorama
_On
_Off
Turn this setting on to broaden the width of the front
stereo image when using the Dolby Pro Logic IIx Music
listening mode.
Dimension
-3 to 0 to +3
With this setting, you can move the sound field forward or
backward when using the Dolby Pro Logic IIx Music
listening mode. Higher settings move the sound field
backward. Lower settings move it forward.
If the stereo image feels too wide, or there's too much
surround sound, move the sound field forward to improve
the balance. Conversely, if the stereo image feels like it's
in mono, or there's not enough surround sound, move it
backward.
Center Width
0 to 3 to 7
With this setting, you can adjust the width of the sound
from the center speaker when using the Dolby Pro Logic
IIx Music listening mode. Normally, if you're using a
center speaker, the center channel sound is output from
only the center speaker. (If you're not using a center
speaker, the center channel sound will be distributed to the
front left and right speakers to create a phantom center).
This setting controls the front left, right, and center mix,
allowing you to adjust the weight of the center channel
sound.
PLIIz Height Gain
Low
Mid
High
The Height Gain Control in Dolby Pro Logic IIz enables
the listener to select how much gain is applied to the front
high speakers. There are three settings, "Low", "Mid" and
"High", and the front high speakers are accentuated in that
order. While "Mid" is the default listening setting, the
listener may adjust the Height Gain Control to their
personal preference.
• ffthe "Front High" settings is set to "None" (H page 36), this
setting cannot be selected.
I Dolby EX
This setting determines how Dolby EX encoded signals
are handled. This setting is unavailable if no surround
back speakers are connected. This setting is effective with
Dolby Digital, Dolby Digital Plus and Dolby TrueHD
only.
Dolby EX
Auto:
If the source signal contains a Dolby EX flag, the
Dolby EX listening mode is used.
Manual:
You can select any available listening mode.
• ffthe "Surround Back" Setting is set to "None" (H page 36),
this setting cannot be selected.
• ff the "Front High" setting is set to other than "None", this
setting is fixed at "Manual" (H page 36).
DTS Setting
m Neo:6 Music
Center Image
0 to 2 to 5
The DTS Neo:6 Music listening mode creates 6-channel
surround sound from 2-channel stereo sources, With this
setting, you can specify by how much the front left and
right channel output is attenuated in order to create the
center channel,
Setting a value "0" in the middle is set to hear a sound,
Sound is spread in left and right (the outside) so that the
set value is made big. Please adjust by liking.
Theater-Dimensional Setting
m Theater-Dimensional
Listening Angle
Wide:
Select if the listening angle is 40 degrees.
Narrow:
Select if the listening angle is 20 degrees.
With this setting, you can optimize the Theater-
Dimensional listening mode by specifying the angle of the
front left and right speakers relative to the listening
position. Ideally, the front left and right speakers should
be equidistant from the listening position and at an angle
close to one of the two available settings.
Front left _ _ Front right
speaker / speaker
'_ _,'20o/40 o
ED
38
Page 39

Preparation 1
Press the input selector buttons to select an input source.
Audyssey
Audyssey 2EQ® Room Correction and Speaker Setup.
To enable the following settings, you must first perform
I he tone for each speaker is set automatically by
the Room Correction and Speaker Setup (_ page 94).
m Audyssey
Off
Movie:
Select this setting for movie material.
The Audyssey indicator will light (_ page 8).
Music:
Select this setting for music material.
The Audyssey indicator will light (_ page 8).
• When "Audyssey Quick Start" has been used for measurement,
the "Audyssey" cannot be selected.
• Audyssey equalizing does not work for DSD sources.
• These technologies cannot be used when:
- a pair of headphones is connected, or
- Direct listening mode is selected, or
- the USB input selector is selected.
I Dynamic EQ
Off
in:
Audyssey Dynamic EQ® becomes active.
The Dynamic EQ indicator will light (_ page 8).
With Audyssey Dynamic EQ, you can enjoy great sound
even when listening at low volume levels.
Audyssey Dynamic EQ solves the problem of
deteriorating sound quality as volume is decreased by
taking into account human perception and room acoustics.
It does so by selecting the correct frequency response and
surround volume levels moment-by-moment so that the
content sounds the way it was created at any volume level
-- not just at reference level.
• These technologies cannot be used when:
- a pair of headphones is connected, or
- Direct listening mode is selected, or
- the USB input selector is selected.
I Reference Level
Audyssey Dynamic EQ Reference Level Offset
_0 dB:
It should be used when listening to movies.
_5 dB:
Select this setting for content that has a very wide
dynamic range, such as classical music.
10 dB:
Select this setting for jazz or other music that has a
wider dynamic range. This setting should also be
selected for TV content as that is usually mixed at
10 dB below film reference.
15 dB:
Select this setting for pop/rock music or other
program material that is mixed at very high listening
levels and has a compressed dynamic range.
Movies are mixed in rooms calibrated for film reference.
To achieve the same reference level in a home theater
system each speaker level must be adjusted so that
-30 dBFS band-limited (500 Hz to 2000 Hz) pink noise
produces 75 dB sound pressure level at the listening
position. A home theater system automatically calibrated
by Audyssey 2EQ will play at reference level when the
master volume control is set to the 0 dB position. At that
level you can hear the mix as the mixers heard it.
Audyssey Dynamic EQ is referenced to the standard film
mix level. It makes adjustments to maintain the reference
response and surround envelopment when the volume is
turned down from 0 dB. However, film reference level is
not always used in music or other non-film content. The
Dynamic EQ Reference Level Offset provides three
offsets from the film level reference (5 dB, 10 dB, and
15 dB) that can be selected when the mix level of the
content is not within the standard.
• If "Dynamic EQ" setting is set to "Off", these technologies
cannot be used.
I Dynamic Volume
_Oi
Light:
Light Compression Mode becomes active.
Medium:
Medium Compression Mode becomes active.
Heavy:
Heavy Compression Mode becomes active. This
setting affects volume the most. It quiets the loud
parts, such as explosions, and boosts the quiet parts
so they can be heard.
• If you make Dynamic Volume active, "Dynamic EQ" is set to
"On". The Dynamic Vol indicator will light (_ page 8).
• When "Dynamic EQ" is set to "Off', "Dynamic Volume"
becomes "Off" automatically.
• These technologies cannot be used when:
- a pair of headphones is connected, or
- Direct listening mode is selected, or
- the USB input selector is selected.
_ii_(_iiiiliI i_
_17i!ililli!i
Erl
39
Page 40

About Audyssey Dynamic EQ®
Audyssey Dynamic EQ solves the problem of
deteriorating sound quality as volume is decreased by
taking into account human perception and room
acoustics. Dynamic EQ selects the correct frequency
response and surround levels moment-by-moment at
any user-selected volume setting. The result is bass
response, tonal balance, and surround impression that
remain constant despite changes in volume. Dynamic
EQ combines information from incoming source levels
with actual output sound levels in the room, a
prerequisite for delivering a loudness correction
solution. Audyssey Dynamic EQ works well by itself.
However, if Audyssey 2EQ® is on, the two technologies
work in tandem to provide well-balanced sound for
every listener at any volume level.
Preset Name For Input Selector
m Name
- - -, Blu-ray, DVD, HD DVD, VCR, DVR, Tivo,
CableSTB, SAT STB, PS3, Wii, Xbox, PC, TV, CD,
TAPE, iPod:
To reset to the default, select "- - -".
You can enter a preset name for each individual input
selector for easy identification. When entered, the preset
name will appear on the display.
• Can not set the input selector by the same name.
• This menu cannot be used for the AM, FIll or USB input
selector.
Audio Selector
iii i
About Audyssey Dynamic Volume®
Audyssey Dynamic Volume solves the problem of large
variations in volume level between television programs,
commercials, and between the soft and loud passages of
movies. Dynamic Volume looks at the preferred volume
setting by the user and then monitors how the volume of
program material is being perceived by listeners in real
time to decide whether an adjustment is needed.
Whenever necessary, Dynamic Volume makes the
necessary rapid or gradual adjustments to maintain the
desired playback volume level while optimizing the
dynamic range. Audyssey Dynamic Volume works fine
by itself, but can also be used with
Audyssey Dynamic EQ. When both are on,
Audyssey Dynamic EQ adjusts the perceived bass
response, tonal balance, surround impression, and
dialog clarity whether watching movies, flipping
between television channels, or changing from stereo to
surround sound content, when Dynamic Volume adjusts
the volume.
A/V Sync
m A/V Sync
_0 ms to 400 ms in 10 ms steps
When using progressive scanning on your Blu-ray
Disc/DVD player, you may find that the picture and sound
are out of sync. With this setting, you can correct this by
delaying the audio signals.
To view the TV picture while setting the delay, press
ENTER.
To return to the previous screen, press RETURN.
The range of values you can adjust will depend on
whether your TV or display supports HDMI Lip Sync and
if the "LipSync" setting is set to "On" or not
(_ page 43).
• A/V Sync is disabled when the Direct listening mode is used
with all analog input source.
I Audio Selector
ARC:
The audio signal from your TV tuner can be sent to
the NDMI OUT of the AV receiver/1
With this selection the TV's audio can be
automatically selected as a priority among other
assignments.
HDMI:
This can be selected when NDMI IN has been
assigned as an input source. If both HDMI (HDMI
IN) and digital audio inputs (COAXIAL IN or
OPTICAL IN) have been assigned, HDMI input is
automatically selected as a priority.
COAXIAL:
This can be selected when COAXIAL IN has been
assigned as an input source. If both coaxial and
HDMI inputs have been assigned, coaxial input is
automatically selected as a priority.
OPTICAL:
This can be selected when OPTICAL IN has been
assigned as an input source. If both optical and
HDMI inputs have been assigned, optical input is
automatically selected as a priority.
Analog:
The AV receiver always outputs analog signals.
You can set priorities of audio output when there are both
digital and analog inputs.
• The setting is stored individually for each input selector.
• This setting can be made only for the input source that is
assigned as HDMI IN, COA×IAL IN, or OPTICAL IN. If both
HDM[ (HDMI IN) and digital audio inputs (COAXIAL IN or
OPTICAL IN) are assigned, HDM[ input will be selected as a
priority by setting to "ARC" (_ page 42). To select the digital
audio input, see "Digital Audio (Digital Audio Input)"
(_ page 35).
"1 You can select "ARC" if you select the TV/CD input selector.
But you cannot select it if you've selected "OFF' in the
"Audio Return Ch" setting (_ page 42).
Ell
4O
Page 41

Setting the Incoming Digital Signal (Fixed
Mode)
m Fixed Mode
Off:
The format is detected automatically. If no digital
input signal is present, the corresponding analog
input is used instead.
PCM:
Only 2-channel PCM format input signals will be
heard. If the input signal is not PCM, the PCM
indicator will flash and noise may also be produced.
DTS:
Only DTS (but not DTS-HD) tkwmat input signals
will be heard. If the input signal is not DTS, the DTS
indicator will flash and there will be no sound.
When "HDMI", "COAXIAL" or "OPTICAL" is
selected in the "Audio Selector" setting, you can then
specify the signal type in "Fixed Mode".
Normally, the AV receiver detects the signal format
automatically. However, if you experience either of the
following issues when playing PCM or DTS material, you
can manually set the signal format to PCM or DTS.
• If the beginnings of tracks from a PCM source are cut
off, try setting the format to PCM.
• If noise is produced when fast forwarding or reversing a
DTS CD, try setting the format to DTS.
• The setting will be reset to "Off' when you change the setting ill
the "Audio Selector" (_ page 40).
OSD Setting
Changing the remote controller's ID
1 While holding down RECEIVER, press and hold
down SETUP until the remote indicator lights
(about 3 seconds) (_ page 34).
2 Use the number buttons to enter ID 1, 2, or 3.
The remote indicator flashes twice.
Tuner
I AM/FM Freq Step (North American and Brazilian
models)
10kHz/200kHz:
9kHz/50kHz:
Select the frequency step according to your area.
I AM Freq Step (Asian models)
10kHz:
9kHz:
Select the frequency step according to your area.
For AM/FM tuning to work properly, you must specify the
AM/FM frequency step used in your area. Note that when
this setting is changed, all radio presets will be deleted.
Auto Standby
I Auto Standby
_iff
_in
When "Auto Standby" is set to "On", AV receiver will
automatically perform standby operation if there is no
operation for 30 minutes with no audio and no video
signal input.
"Auto Standby" will display on the display and OSD
from 30 seconds before the Auto Standby functions.
Default setting: in (Asian models), iff (North
American and Brazilian models)
m Volume OSD
On
Off
You can select it you wish to display the volume level on-
screen, when it is adjusted.
Remote Control Settings
m Remote ID
_l, 2, or 3
When several Onkyo components are used in the same
room, their remote ID codes may overlap. To differentiate
the AV receiver from the other components, you can
change its remote ID from 'T', to "2" or "3".
• ff you do change the AV receiver's remote [D, be sure to change
the remote controller to the same [D (see below), otherwise, you
won't be able to control it with the remote controller.
• Depending on some sources, the Auto Standby function may
activate during playback.
Erl
41
Page 42

51 i
mHDMI Ctrl (RIHD)
_off
Turn this setting on to allow f-qlHD-compatible
components connected via HDMI to be controlled by the
AV receiver (_ page 57).
• When set to "On" and close the menu, the name of connected
r"41 I-liD-compatible components and "RIHD On" are
displayed on the AV receiver.
"Search..." --> "(name)" --> "RIHD On"
When the AV receiver cannot receive the name of the
component, it is displayed as "Player*" or "Recorder*", etc
("*" means the number of two or more component).
• When an r"41 I-liD-compatible component is connected to the
AV receiver via the HDM[ cable, the name of the connected
component is displayed on the AV receiver display. For
example, while you are watching TV broadcasting, if you
operate a Blu-ray Disc/DVD player (being powered on) by the
remote control of the AV receiver, the name of the Blu-ray
Disc/DVD player is displayed on the AV receiver.
• Set to "Off" when a connected piece of equipment is not
compatible or it is unclear whether the equipment is compatible
or not.
• If movement is unnatural when set to "On", change the setting
to "Off".
• Refer to the connected component's instruction manual for
details.
• When "HDMI Ctrl (RIHD)" setting is set to "On", the power
consumption on standby mode slightly increases. (Depending on
the TV status, the AV receiver will enter standby mode as usual.)
N HDMI Through
_Off
Auto:
Detects the signal and automatically selects the input
source.
BD/DVD, VCR/DVR, CBL/SAT, GAME, AUX,
TV/CD:
Selects the input source for which the HDMI
Through function is enabled.
Last:
The HDMI Through function is activated on the
input source selected at the time of setting the AV
receiver to Standby mode.
When enabling the HDMI Through function, regardless of
whether the AV receiver is On or in Standby, both audio
and video stream from an HDMI input will be output to
the TV or other components via HDMI connection. The
HDMI THRO and HDMI indicators light when enabled.
This setting is set to "Auto" automatically when the above
"HDMI Ctrl (RIHD)" is set to "On".
!
• Only the input source assigned to the HDMI IN via
"HDMI Input" is enabled (@ page 35).
• The power consumption during standby mode will increase
during the HDM[ through function; however in the following
cases, the power consumption can be saved:
- The TV is in standby mode.
- You are watching a TV program.
• Refer to the connected component's instruction manual for
details.
• Depending on the connected component, the correct input source
may not be selected with the setting set to "Auto".
• This setting is set to "OFF' automatically when the "HDMI Ctrl
(RIHD)" setting is set to "OFF'.
N Audio TV Out
_Off
_On
This preference determines whether the incoming audio
signal is output from the HDMI output. You may want to
turn this preference on if your TV is connected to the
HDMI output and you want to listen to the audio from a
connected component through your TV's speakers.
Normally, this should be set to "Off".
• Listening mode cannot be changed when this setting is set to
"On" and the input source is not HDM[.
• If "On" is selected and the signal can be output from the TV, the
AV receiver will output no sound through its speakers. [n this
case, "TV Speaker" appears on the display by pressing
DISPLAY.
• When "HDMI Ctrl (RIHD)" is set to "On", this setting is fixed
to "Auto".
• With some TVs and input signals, no sound may be output even
when this setting is set to "On".
• When the "Audio TV Out" setting is set to "On", or "HDMI
Ctrl (RIHD)" is set to "On" and you're listening through your
TV's speakers (_ page 14), if you turn up the AV receiver's
volume control, the sound will be output from the AV receiver's
front left and right speakers. To stop the AV receiver's speakers
producing sound, change the settings, change your TV's
settings, or turn down the AV receiver's volume.
N Audio Return Ch (ARC)
_Off
Auto:
The audio signal from your TV tuner can be sent to
the HDMI OUT of the AV receiver.
The audio return channel (ARC) function allows an ARC
capable TV to send the audio stream to the HDMI OUT of
the AV receiver. To use this function, you must select the
TWCD input selector and your TV must support ARC
function.
• ff you set "Audio Return Ch" to "Auto", the "Audio Selector"
settings of the TV/CD input selector will be automatically
switched to "ARC" (_ page 40).
• The "Audio Return Ch" setting can be set only when the above
"HDMI Ctrl (RIHD)" setting is set to "On".
• This setting is set to "Auto" automatically when the above
"HDMI Ctrl (RIHD)" is set to "On" first time.
En
42
Page 43

m LipSync
Off
On
This function allows the AV receiver to automatically
correct any delay between the video and the audio, based
on the data from the connected monitor.
• This function works only if your HDMl-compatible TV supports
HDM[ Lip Sync.
After changing the settings of the "HDMI Ctrl
(RIHD)", "HDMI Through" or "Audio Return Ch",
turn off the power to all connected pieces of equipment
and then turn them on again. Refer to the instructions
for all connected pieces of equipment.
You canchange various audio settings from the Home
menu (_ page 31).
Speaker Levels
m Subwoofer Level*l
-15 dB to 0 dB to +12 dB in 1 dB steps
m Center Level
-12 dB to 0 dB to +12 dB in 1 dB steps
You can adjust the volume of each speaker while listening
to an input source.
These temporary adjustments are cancelled when the AV
receiver is set to Standby. To save the setting you made
here, go to "Level Cal (Level Calibration)" (_ page 37)
before setting the AV receiver to Standby.
• You cannot use this function while the AV receiver is muted.
• Speakers that are set to "No" or "None" in the "Sp Config
(Speaker Configuration)" (_ page 36) cannot be adjusted.
"1 This procedure can also be performed on the AV receiver by
using its SUBWOOFER LEVEL.
Audyssey
1 Press RECEIVER followed by HOME.
2 Use &/, and ENTER to select "Audio", and then
use l/¥/_/_ to make the desired selection.
!
• These settings are not available ill either of the following cases:
- a pair of headphones is connected.
- the "Audio TV Out" setting is set to "On" (_ page 42) and
all input selector other than HDM[ is selected.
- "HDMI Ctrl (RIHD)" is set to "On" (_ page 42) and
you're listening through your TV speakers.
Tone Control Settings
I Bass
-10 dB to 0 dB to +10 dB in 2 dB steps
You can boost or cut low-frequency sounds output
from the front speakers.
m Treble
-10 dB to 0 dB to +10 dB in 2 dB steps
You can boost or cut high-frequency sounds output
from the front speakers.
You can adjust the bass and treble for the front speakers,
except when the Direct listening mode is selected.
m Audyssey
See "Audyssey" of "Source Setup" (_ page 39).
m Dynamic EQ
See "Dynamic EQ" of"Source Setup" (_ page 39).
m Dynamic Volume
See "Dynamic Volume" of "Source Setup" (_ page 39).
• These technologies can be used when all the following
conditions are met:
- Room Correction and Speaker Setup is completed. Note that
"Audyssey" requires the "Audyssey 2EQ Full Calibration"
method.
- Any listening mode other than Direct is selected.
- A pair of headphones is not connected.
- The input selector other than USB is selected.
• The setting is stored individually for each input selector.
Operating on the AV receiver
1 Press TONE on the AV receiver repeatedly to
select either "Bass" or "Treble".
2 Use + and - on the AV receiver to adjust.
• To bypass the bass and treble tone circuits, select the Direct
listening mode.
Ell
43
Page 44

Late Night Function CinemaFILTER
iii i
m Late Night
For Dolby Digital and Dolby Digital Plus sources, the
options are:
}Off
Low:
Small reduction in dynamic range.
High:
Large reduction in dynamic range.
For Dolby TrueHD sources, the options are:
Auto:
The Late Night function is set to "On" or "OFF'
automatically.
Off
On
Turn this setting on to reduce the dynamic range of Dolby
Digital material so that you can still hear quiet parts even
when listening at low volume levels--ideal for watching
movies late at night when you don't want to disturb
anyone.
• The effect of the Late Night function depends on the material
that you are playing and the intention of the original sound
designer, and with some material there will be little or no effect
when you select the different options.
• The Late Night function call be used only when the input source
is Dolby Digital, Dolby Digital Plus, or Dolby TrueHD.
• The Late Night function is set to "OFF' when the AV receiver is
set to Standby. For Dolby TrueHD sources, it will be set to
"Auto".
I Cinema Filter
_Off
_On
Turn this setting on to soften overly [)right movie
soundtracks, which are typically mixed for reproduction in
a movie theater.
CinemaFILTER can be used with the following listening
modes: Dolby Digital, Dolby Digital EX, Dolby Digital
Plus, Dolby TrueHD, Dolby Pro Logic IIx Movie, Dolby
Pro Logic II Movie, Dolby Pro Logic IIz Height,
Multichannel, DTS, DTS-ES, DTS Neo:6 Cinema, DTS
96124, Neo:6, DTS-HD High Resolution Audio, DTS-HD
Master Audio and DTS Express.
• The CinemaFILTER may not work when used with certain input
sources.
Music Optimizer
m Music Optimizer
_Off
_On
Turn this setting on to enhance the sound quality of
compressed music files. Use it with music files that use
"lossy" compression, such as MP3.
• Alternatively, you can usethe AV receiver's MUSIC
OPTIMIZER.
• The Music Optimizer function only works with PCM digital
audio input signals with a sampling rate below' 48 kHz and
analog audio input signals. The Music Optimizer is disabled
when the Direct listening mode is selected.
• The setting is stored individually for each input selector.
• TheM.Opt indicator will light (_ page 8).
Erl
44
Page 45

iPod/iPhone Playback via Onkyo Dock
iPod/iPhone Alarm
It you use the Alarm function on your iPod/iPhone to
start playback, the AV receiver will turn on at the
specified time and select your iPod/iPhone as the input
source automatically.
• Linked operations do not work with video playback or when the
alarm is set to play a sound.
• If you use your iPod/iPhone with ally other accessories,
iPod/iPhone playback detection may not work.
mOperating Notes
• Use the AV receiver's volume control to adjust the playback
RI Dock
With the RI Dock, you can easily play the music stored on
your Apple iPod/iPhone through the AV receiver and
enjoy great sound, and watch iPod/iPhone slideshows and
videos on your TV. In addition, the onscreen display
(OSD) allows you to view, navigate, and select your
iPod/iPhone model's contents on your TV, and with the
supplied remote controller, you can control your
iPod/iPhone from the comfort of your sofa. You can even
use the AV receiver's remote controller to operate your
iPod/iPhone.
volume.
• While your iPod/iPhone is inserted in R[ Dock, its volume
control has no effect.
• If youdoadjust thevolumecontrol on youriPod/iPhonewhile
it's inserted inRI Dock, becareful that it's not set too loud
before you reconnect your earphones.
• On the iPod with video and iPod nano (1 st generation), the click
wheel is disabled during playback.
• Enterthe appropriate remote control code before using the AV
receiver's remote controller for thefirst time (_ page 47).
• Connectthe RI Dock to the AV receiverwith an f-qlcable
(÷ page 16).
• Set theR[ Dock's R[ MODE switch to "HDD" or
"HDD/DOCK".
• Set theAV receiver's Input Display to "DOCK" (_ page 32).
I System Function
System On
When you turn on the AV receiver, RI Dock and
iPod/iPhone turn on automatically. In addition, when RI
Dock and iPod/iPhone are on, the AV receiver can be
turned on by pressing 0.
Auto Power On
It you press the remote controller's _ (Playback)
while the AV receiver is on Standby, the AV receiver
will automatically turn on, select your iPod/iPhone as
the input source, and your iPod/iPhone will start
playback.
Direct Change
It you start iPod/iPhone playback while listening to
another input source, the AV receiver will automatically
switch to the input to which RI Dock is connected.
Other Remote Controllers
You can use the remote controller that came with the
AV receiver to control other iPod/iPhone functions. The
available functionality depends on the AV receiver.
By pressing REMOTE MODE that's been programmed
with the remote control code for your Dock, you can
control your iPod/iPhone in the Dock with the following
buttons.
See "Remote Control Codes for Onkyo Components
Connected via I-4I" for details on entering a remote
control code (@ page 47).
See to the Dock's instruction manual for more
information.
E RI Dock
• Set the RI Dock's RI MODE switch to "HDD" or
"HDD/DOCK".
• O may not work with a remote control code (without
RI). In this case, make an RI connection and enter a
remote control code 81993 (with ffqI).
With the RI Control
In this case, make an ffq!connection and enter a remote
control code 81993 (with ffqI).
• Set the AV receiver's Input Display to "DOCK"
(_ page 32).
Without the RI Control
You must enter a remote control code 82990 first
(_ page 47).
Ell
45
Page 46

REMOTE MODE first,
I Press the appropriate
_: Available buttons
o
Ooc
o
@
(_'1
TOP MENU*2
®
®
AITI41_, ENTER
PLAYLIST 4/=.-
®
P.-, I I, II, <<, _, I-<<, _=.-i
REPEAT
®
RANDOM
DISPLAY*3
®
MUTING
®
ALBUM +/-
®
®
VOL A/T
MENU
@
MODE*4
@
m
• With some iPod/iPhone models and generations, certain buttons may not work as expected.
• For detailed operation of the iPod/iPhone, please refer to the instruction manual.
"1 This button does not turn the Onkyo DS-A2 or DS-A2X R[ Dock on or off. Your iPod/iPhone may not respond the first time you
press this button, in which case you should press it again.
This is because the remote controller transmits the On and Standby commands alternately, so if your iPod/iPhone is already on, it
will remain on when the remote controller transmits an On command.
Similarly, if your iPod/iPhone is already off, it will remain off when the remote controller transmits an Off command.
*2 TOP MENU works as a Mode button when used with a DS-A2 R[ Dock.
*3 DISPLAY turns on backlight for 30 seconds.
*4 Resume mode
With the Resume function, you can resume playback of the song that was playing when you removed your iPod/iPhone from the R[
Dock or changed the OSD mode to Off.
,/
,/
,/
,/
,/
,/
,/
,/
,/
,/
,/
,/
,/
En
46
Page 47

Controlling Other Onkyo Components
You can use the AV receiver's remote controller to
control your other Onkyo AV components. This section
explains how to enter the remote control code (with the
default underlined) for a component that you want to
control: DVD, CD, etc.
Onkyo components that are connected via f'41are
controlled by pointing the remote controller at the AV
receiver, not the component. This allows you to control
components that are out of view, in a rack, for example.
The following REMOTE MODE are preprogrammed
with remote control codes for controlling the components
listed. You do not need to enter a remote control code to
control these components.
For details on controlling these components, see the pages
indicated.
BD/DVD Onkyo Blu-ray Disc player (_ page 48)
TV/CD Onkyo CD player (_ page 48)
You'll need to enter a code for each component that you
want to control.
Look up the appropriate remote control code in the
Remote Control Codes for Onkyo Components
Connected via f'4 I.
While holding down REMOTE MODE to which
2
you want to enter a code, press and hold down
DISPLAY (about 3 seconds).
• Remote control codes cannot be entered for RECEIVER
• Apart fi'om RECEIVER, remote control codes fi'om any
category can be entered for REMOTE MODE. However,
these buttons also work as input selector buttons
(_ page 19), so choose a REMOTE MODE that
corresponds with the input to which you connect your
component. For example, if you connect your CD player to
the CD input, choose TV/CD when entering its remote
control code.
Within 30 seconds, use the number buttons to enter
3
the 5-digit remote control code.
The remote indicator flashes twice.
If the remote control code is not entered successfully,
the remote indicator will flash once slowly.
1 Make sure the Onkyo component is connected with
an f'41 cable and an analog audio cable (RCA).
See "Connecting Onkyo f'41 Components" for details
(_ page 16).
2 Enter tile appropriate remote control code for
REMOTE MODE referring to the previous section.
42157:
Onkyo cassette tape deck with f"/I
81993:
Onkyo Dock with f"/I
3 Press REMOTE MODE, point the remote
controller at the AV receiver, and operate the
component.
Controlling Onkyo components without R I
If you want to control an Onkyo component by pointing
the remote controller directly at it, or you want to control
an Onkyo component that's not connected via f'4 I, use the
following remote control codes:
30627:
Onkyo DVD player without R I
71817:
Onkyo CD player without R I
32900/33000:
Onkyo Blu-ray Disc player
32901/33004
Onkyo HD DVD player
70868:
Onkyo MD recorder without 1-41
71323:
Onkyo CD recorder without 1-41
82990:
Onkyo Dock without f"/I
;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;4i
ER
47
Page 48

You can reset a REMOTE MODE to its default remote
control code.
While holding down REMOTE MODE that you
1
want to reset, press and hold down HOME until the
remote indicator lights (about 3 seconds).
Within 30 seconds, press REMOTE MODE again.
2
The remote indicator flashes twice, indicating that the
button has been reset.
Each of REMOTE MODE is preprogrammed with a
remote control code. When a button is reset, its
preprogrammed code is restored.
You can reset the remote controller to its default settings.
1 While holding down RECEIVER, press and hold
down HOMEuntil the remote indicator lights
(about 3 seconds).
2 Within 30 seconds, press RECEIVER again.
The remote indicator flashes twice, indicating that the
remote controller has been reset.
By pressing REMOTE MODE that's been programmed
with the remote control code for your component, you can
control Onkyo component as below.
For details on entering a remote control code for a
different component (_ page 47).
Controlling a Blu-ray Disc/DVD Player, HD
DVD Player
BD/DVD is preprogrammed with the remote control code
for controlling a component that supports the 1-411-11_'1.
The component must be able to receive remote control
commands via r'411-11O and be connected to the AV
receiver via HDMI.
Use the following remote control codes:
32910/33001/31612:
Blu-ray Disc/DVD player with r411-11O
"1 The [-'411-1lO supported by the AV receiver is the CEC
system control function of the HDM[ standard.
En
48
Page 49

REMOTE MODE first,
Press the appropriate 1
_: Available buttons
}-
@--
qD--
= SEARCH REPEAT RANDOM MODE
@
I._=
Buttons \
(b
TOP MENU
®
A/_D</=.- ENTER
SETUP
@
®
_.-, I I, II, <-<, _,
SEARCH
®
REPEAT
RANDOM
MODE
Number: 1 to 9, 0
Number: +10
DISPLAY
MUTING
®
DISC +/-
@
MENU
I}
RETURN
@
AUDIO
@
CLR
"1 The r"-_l-IID function is not supported. The r"-_l-IID
supported by the AV receiver is the CEC system control
function of the HDM[ standard.
*2 These buttons function as colored buttons or A, B, C, D
buttons.
"3 II (Pause) functions as reverse playback.
• See the "Controlling Your iPod/iPhone" about the operation of
iPod/iPhone (@ page 45).
l_ X
_3 Irn_
_,/* 1
_/'1
_>
a
,_'u
;,y.
v' v'
v'
v'
/'3
v'
v'
v'
v' v'
v'
;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;I;Ai
IIC=T{? )I,A
• With some components, certain buttons may not work as
expected, and some may not work at all.
En
49
Page 50

Troubleshooting
If you have any trouble using the AV receiver, look for a
solution in this section. If you can't resolve the issue
yourself, contact your Onkyo dealer.
If you can't resolve the issue yourself, try resetting the
AV receiver before contacting your Onkyo dealer.
To reset tile AV receiver to its factory defaults, turn
it on and, while holding down VCR/DVR, press
ON/STANDBY."Clear" will appear on the display
and the AV receiver will enter Standby mode.
VOR/DVR
Note that resetting the AV receiver will delete your
radio presets and custom settings.
} Remote indicator
RECEIVER
N When the power is restored after a power
interruption, "CHECK SP WIRE" appears on the
display
The protection circuitry has been activated.
Remove the power cord fl'om the wall outlet
immediately. Disconnect all speaker cables and
input sources, and then leave the AV receiver with
its power cord disconnected for 1 hour. After that,
reconnect the power cord and set the volume to
maximum. [f the AV receiver stays on, set then the
volume to minimum, disconnect the power cord, and
reconnect your speakers and input sources. If the AV
receiver turns off when you set the volume to
maximum, disconnect the power cord, and contact
your Onkyo dealer.
N There's no sound, or it's very quiet
Make sure that the digital input source is selected 35
properly.
Make sure that the inputs and outputs of all
components are connected properly.
14-16
i HOME
To reset the remote controller to its factory defaults,
while holding down RECEIVER, press and hold down
HOME until the remote indicator lights (about 3
seconds). Within 30 seconds, press RECEIVER
again.
N Can't turn on the AV receiver
Make sure that the power cord is properly plugged
into the wall outlet.
N The AV receiver turns off unexpectedly
When the set Auto Standby starts running, the AV 41
receiver will automatically go standby.
Make sure that the input source is properly selected. 19
Check the volume. The AV receiver is designed for 19
home theater enjoyment. It has a wide volume range,
allowing precise adjustment.
While a pair of headphones is connected to the
PHONES jack, no sound is output from the
speakers.
Check the digital audio output setting on the
connected device. On some game consoles, such as
those that support DVD, the default setting is off.
If your turntable uses an MC cartridge, you must
connect an MC head amp, or an MC transformer.
Not all listening modes use all speakers.
Make sure that the speaker setup microphone is not
still connected.
33
15
27
EB
50
Page 51

mOnly the front speakers produce sound
Wheu the Stereo o1"Mouo listeuiug mode is selected, 29
ouly the front speakers and subwoofer produce
souud.
i-
mOnly the center speaker produces sound
ff you use the Dolby Pro Logic IIx Movie, Dolby Pro --
Logic IIx Music, or Dolby Pro Logic IIx Garue
listening ruode with a mouo source, such as all AM
radio station or ruono TV prograru, the sound is
concentrated in the center speaker.
mThe surround speakers produce no sound
When the T-D (Theater-Dimensional), Stereo o1"
Mono listening mode is selected, the surrouud
speakers produce uo souud.
Make stare the speakers are configured correctly. 36
N The center speaker produces no sound
When the Stereo or Mouo listeuiug mode is selected, 29
the ceuter speaker produces uo souud.
mThe front high or surround back speakers
produce no sound
Depending on the current listening mode, no sound 27-28
may be produced by the front high or surround back
speakers. Select auother listeuiug anode.
mThe speaker volume cannot be set as required
Check to see if a maximum volume has beeu set. 19
m Noise can be heard
Usiug cable ties to bundle audio cables with power
cords, speaker cables, aud so on may degrade the
audio performauce, so dou't do it.
29
N The Late Night function doesn't work
Make stare the source material is Dolby Digital,
Dolby Digital Plus, or Dolby TrueHD.
44
N About DTS signals
When DTS program material ends and the DTS
bitstream stops, the AV receiver remains in DTS
listening mode and the DTS indicator remains on.
This is to prevent noise when you use the pause, fast
forward, or fast reverse function on your player. If
you switch your player from DTS to PCM, because
the AV receiver does not switch formats
immediately, you may not hear any sound, in which
case you should stop your player for about three
seconds, and then resume playback.
Make stare the speakers are configured correctly. 36
N The subwoofer produces no sound
Wheu you play source material that coutaius uo
iuformatiou iu the LFE channel, the subwoofer
produces uo souud.
N There's no sound with a certain signal format
Check the digital audio output setting ou the
couuected device. Ou some game consoles, such as
those that support DVD, the default settiug is off.
Depeudiug on the input signal, some listening modes 27-28
cannot be selected.
N Can't get 6.1/7.1 playback
If no surrouud back speakers or front high speakers
are couuected, 6. 1/7.1 playback is uot possible.
When playing DTS program material, using the
pause, fast forward, or fast reverse function on your
player may produce a short audible noise. This is not
a malfunction.
N
The beginning of audio received by an HDMI IN
can't be heard
Since it takes longer to ideutify the format of an
HDMI signal than it does for other digital audio
signals, audio output may not start immediately.
N There's no picture
Make stare that all video connecting plugs are pushed 13
iu all the way.
ff the video source is connected to a component
video input, you must assign that input to an input
selector, and your TV must be connected to
COMPONENT VIDEO OUT.
15, 35
EF1
51
Page 52

If the video source is connected to all HDMI input, 14, 35
you must assign that input to all input selector, and
your TV must be connected to the HDMI OUT.
N Can't control other components
[f it's all Onkyo component, make sure that the f"41
cable and analog audio cable are connected properly.
Connecting only an f"41 cable won't work.
16
N There's no picture from a source connectedto
an HDMI IN
Reliable operation with an HDMI-to-DVI adapter is 57
not guaranteed. In addition, video signals from a PC
are not guaranteed.
N The on-screen menus don't appear
On your TV, make sure that the video input to which --
the AV receiver is connected is selected.
r_
N Reception is noisy, FM stereo reception is
noisy, or the FM STEREO indicator doesn't light
Relocate your antenna.
Listen to the station in mono.
Passing cars and airplanes can cause interference.
antenna.
22
f_/':_?ST_[o/';TmI_IFJ'4
If you' ve connected a cassette tape deck, to the
32
TWCD IN jack, or an RI Dock to the TWCD IN or
GAME IN or VCR/DVR INjacks, for the remote
controller to work properly, you must set the display.
To control an Onkyo component that's connected
via f"41, point the remote controller at the AV
receiver. Be sure to enter the appropriate remote
control code first.
47
N Can't record
On your recorder, make stare the correct input is
selected.
[I/.'/:11./_'_t'4_:,/_],'5"_.'iIf nothing improves the reception, install an outdoor --
N Can't access the music files on a USB device
Make sure the USB device is plugged in properly. --
N The remote controller doesn't work
Before operating this unit, be stare to press
RECEIVER.
Install new batteries. Don't mix different types of 4
batteries, or old and new batteries.
Make stare that the AV receiver is not subjected to
direct sunshine or inverter-type fluorescent lights.
Relocate if necessary.
Make stare you've selected the correct remote
controller anode.
Make stare to set the same ID on both the AV
receiver and remote controller.
Ell
52
10, 48
41
USB memory devices with security functions cannot 21
be played.
[oJh'FOl_
N Standby power consumption
[n the following cases, the power consumption may 42
reach up to a maximum of 37 W:
- "HDMI Ctrl (RIHD)" setting is set to "On".
(Depending on the TV status, the AV receiver
will enter Standby mode as usual.)
- The "HDMI Through" setting is set to other than
"Off".
N The sound changes when I connect my
headphones
When a pair of headphones is connected, the
listening mode is set to Stereo, unless it's already set
to Stereo, Mono, or Direct.
Page 53

m How do I change the language of a multiplex
source
Use the "Input Ch (Mux)" setting on the "Audio 37
Adjust" menu to select "Main" or "Sub".
mThe R I functions don't work
To use 1"-41, you umst make all 1"-41connection and
an analog audio connection (RCA) between the
component and AV receiver, even if they are
connected digitally.
16
N The following settings can be made for the
composite video inputs
You must use the buttons on the unit to make these
settings.
On the AV receiver, press the input selector for the
input source that you want to set and the SETUP button
simultaneously. While holding down the input selector
button, press SETUP until "Video ATT:ON" appears
on the display. Then, release both buttons. To reactivate
the setting, repeat the above process so that "Video
ATT:OFF" appears on the display, and release the
buttons.
• Video Attenuation
This setting can be made for the BD/DVD, VCR/DVR,
CBL/SAT, GAME, or AUX input.
If you have a games console connected to the composite
video input, and the picture isn't very clear, you can
attenuate the gain.
Video ATT:OFF: (default).
Video ATT:ON: Gain is reduced by 2 dB.
N If the picture on your TV/monitor connected to
HDMI OUT is unstable, try switching the
DeepColor function off
To turn off the DeepColor function, simultaneously
press the CBL/SAT and OON/STANDBY buttons on
the AV receiver. While holding down CBL/SAT, press
r3ON/STANDBY until "Off" appears on the display.
Then, release both buttons. To reactivate the DeepColor
function, repeat the above process until "On" appears
on the display and release the buttons.
The AV receiver contains a microcomputer for signal
processing and control functions. In very rare situations,
severe interference, noise from an external source, or
static electricity may cause it to lockup. In the unlikely
event that this happens, unplug the power cord from the
wall outlet, wait at least five seconds, and then plug it
back in again.
Onkyo is not responsible for damages (such as CD
rental fees) due to unsuccessful recordings caused by
the unit's malfunction. Before you record important
data, make sure that the material will be recorded
correctly.
Before disconnecting the power cord from the wall
l
outlet, set the AV receiver to Standby.
]
EF1
53
Page 54

Connection Tips and Video Signal Path
The AV receiver supports several connection formats for compatibility with a wide range of AV equipment. The format
you choose will depend on the formats supported by your components. Use the following sections as a guide.
• Theon-screen setup menus are displayedwhen:
- There is no video input, o1"
-The video input is 480p, 576p, 720p, 1080i, o1"1080p.
Video component can be connected by using any one of the
following video connection formats: composite video,
component video, or HDMI, the latter offering the best
picture quality.
When choosing a connection format, bear in mind that the
AV receiver doesn't convert between formats, so only
outputs of the same format as the input will output the signal.
Audio component can be connected by using any of the
following audio connection formats: analog, optical,
coaxial, or HDMI.
When choosing a connection format, bear in mind that the
AV receiver does not convert digital input signals for
analog line outputs and vice versa. For example, audio
signals connected to an optical or coaxial digital input are
not output by the analog VCR/DVR OUT.
If signals are present at more than one input, the inputs
will be selected automatically in the following order of
priority: HDMI, digital, analog.
Video Signal Flow Chart
Blu-ray Disc/DVD player, etc,
Composite Component HDMI
AV receiver
0 ®= O
Composite Component HDMI
I TV, projector, etc, I
Audio Signal Flow Chart
[ Blu-ray Diso/DVD player, etc. ]
Analog Optical Coaxial HDMI
AV receiver
Analog HDMI
TV, projector, etc. ]
"1 Depends on the "audio TV Out" setting (3 page 42).
*2 This setting is available, when "Audio Return Ch"
setting is set to "Auto" (3 page 42), you must select
the TV/GD input selector and your TV must support
ARC function.
ED
54
Page 55

USB Features
• USB mass storage device class (but not always
guaranteed).
• FATI6 or FAT32 file system format.
• Each folder may contain up to 255 music files and
folders, and folders may be nested up to 8 levels deep.
• USB hubs and USB devices with hub functions are not
supported.
For and playback from a USB device, the AV receiver
supports the following music file formats.
Variable bit-rate (VBR) files are supported. (Playing times
may not display correctly.)
N MP3 (.mp3 or .MP3)
• MP3 files must be MPEG-I/MPEG-2.5 Audio Layer 3
format with a sampling rate of 8 kHz, 11.025 kHz,
12 kHz, 16 kHz, 22.05 kHz, 24 kHz, 32 kHz, 44.1 kHz,
48 kHz and a bit-rate of between 8 kbps and 320 kbps.
Incompatible files cannot be played.
m WMA (.wma or .WMA)
WMA stands for Windows Media Audio and is an audio
compression technology developed by Microsoft
Corporation. Audio can be encoded in WMA format by
using Windows Media® Player.
• WMA files must have the copyright option turned off.
• Sampling rates of 32 kHz, 44.1 kHz, 48 kHz and bitrates
of between 48 kbps and 320 kbps are supported.
• WMA DRM/Pro/Voice formats are not supported.
N AAC (.aacl.m4al.mp41.3gpl.3g21.AACI.M4AI
.MP4/.3GP or .3G2)
AAC stands for MPEG-2/MPEG-4 Audio.
• Sampling rates of 16 kHz, 22.05 kHz, 24 kHz, 32 kHz,
44.1 kHz, 48 kHz and bitrates of between 8 and
320 kbps, are supported.
N FLAC (.flac or .FLAC)
FLAC is a file format for lossless audio data compression.
• Sampling rates of 32 kHz, 44.1 kHz and 48 kHz are
supported.
• Quantization bit: 16 bit, 24 bit
En
55
Page 56

About HDMI
Designed to meet the increased demands of digital TV, HDMI (High Definition Multimedia Interface) is a new digital
interface standard for connecting TVs, projectors, Blu-ray Disc/DVD players, set-top boxes, and other video
components. Until now, several separate video and audio cables have been required to connect AV components. With
HDMI, a single cable can carry control signals, digital video, and up to eight channels of digital audio (2-channel PCM,
multichannel digital audio, and multichannel PCM).
The HDMI video stream (i.e., video signal) is compatible with DVI (Digital Visual Interface)*1, so TVs and displays with
a DVI input can be connected by using an HDMI-to-DVI adapter cable. (This may not work with some TVs and displays,
resulting in no picture.)
The AV receiver uses HDCP (High-bandwidth Digital Content Protection)_2, so only HDCP-compatible components can
display the picture.
Audio Return Channel, 3D, x.v.Color, DeepColor, Lip Sync, DTS-HD Master Audio, DTS-HD High Resolution
The AV receiver's HDMI interface is based on the following:
Audio, Dolby TrueHD, Dolby Digital Plus, DSD and Multichannel PCM
• 2-channel linear PCM (32-192 kHz, 16120124bit)
• Multichannel linear PCM (up to 7.1 ch, 32-192 kHz, 16120124 bit)
• Bitstream (DSD, Dolby Digital, Dolby Digital Plus, Dolby TrueHD, DTS, DTS-HD High Resolution Audio, DTS-HD
Master Audio)
Your Blu-ray Disc/DVD player must also support HDMI output of the above audio formats.
The AV receiver supports HDCP (High-bandwidth Digital Content Protection)*2, a copy-protection system for digital
video signals. Other devices connected to the AV receiver via HDMI must also support HDCP.
"1 DVI (Digital Visual Interface): The digital display interface standard set by the DDWG*3 ill 1999.
*2 HDCP (High-bandwidth Digital Content Protection): The video encryption technology developed by [ntel for HDM[/DVL It's
designed to protect video content and requires a HDCP-compatible device to display the encrypted video.
*3 DDWG (Digital Display Working Group): Lead by [ntel, Compaq, Fujitsu, Hewrlett Packard, IBM, NEC, and Silicon Image, this
open industry group's objective is to address the industry's requirements for a digital connectivity specification for high-
performance PCs and digital displays.
• The HDM[ video stream is compatible with DVI (Digital Visual [nterface), so TVs and displays with a DVI input can be connected by
using an HDM[-to-DVI adapter cable. (Note that DVI connections only carry video, so you'll need to make a separate connection for
audio.) However, reliable operation with such an adapter is not guaranteed. [n addition, video signals from a PC are not supported.
• The HDM[ audio signal (sampling rate, bit length, etc.) may be restricted by the connected source component. If the picture is poor or
there's no sound from a component connected via HDM[, check its setup. Refer to the connected component's instruction manual for
details.
Ell
56
Page 57

Using an RIHD-compatible TV, Player, or Recorder
1-41I-IlD, which stands for Remote Interactive over HDMI, is the name of the system control function found on Onkyo
components. The AV receiver can be used with CEC (Consumer Electronics Control), which allows system control over
HDMI and is part of the HDMI standard. CEC provides interoperability between various components, however,
operation with components other than 1-41l-llD-compatible components cannot be guaranteed.
The following components are 1-41l-llD-compatible. (As
of January 2011 )
NTV
• Toshiba REGZA-LINK compatible TV
• Sharp TV
@Players/Recorders
• Onkyo and Integra r4ll-IlD compatible players
• Toshiba REGZA LINK compatible players and
recorders (only when used together with Toshiba
REGZA LINK compatible TV)
• Sharp players and recorders (only when used together
with Sharp TV)
* Models other than those mentioned above may have some
interoperability if compatible with CEC which is part of the
HDM[ Standard, but operation cannot be guaranteed.
• Do not connect the r-'411-llD-compatible component more than
the following number to the HDM[ input terminal so that the
linked operations work properly.
-Blu-ray Disc/DVD player is up to three.
-Blu-ray Disc recorder/DVD recorder/Digital Video Recorder
is up to three.
- Cable/Satellite Set-top box is up to four.
• Do not connect the AV receiver to the other AV receiveffAV
amplifier via HDM[.
• When the r"411-llD-compatible component more than the
above-mentioned is connected, the linked operations are not
guaranteed.
@ For r-UHO-compatible TV
The following linked operation is possible by connecting
the AV receiver to an _Jl-llD-compatible TV.
• The AV receiver will enter Standby mode when the
power of the TV is turned to Standby.
• You can set on the menu screen of the TV to either
output the audio from the speakers connected to the AV
receiver, or from the speakers of the TV.
• It is possible to output the video/audio from the antenna
or from the input jack of the TV from the speakers
connected to the AV receiver. (A connection such as
optical digital cable or similar is required above the
HDMI cable.)
• Input to the AV receiver can be selected with the remote
controller of the TV.
• Operations such as volume adjustment or similar for the
AV receiver can be performed from the remote
controller of the TV.
@ For r-UHO-compatible players/recorders
The following link operation is possible by connecting the
AV receiver to an _ l-liD-compatible player/recorder,
• When the playback is started on the player/recorder,
input of the AV receiver will switch to the HDMI input
of the player/recorder that is playing back,
• Operation of the player/recorder is possible with the
remote controller supplied with the AV receiver,
* Not all functions may operate depending on the model.
En
57
Page 58

m How to connect and setup
Confirm the connecting and setting.
1
1. Connect the HDMI OUT jack to the HDMI input
jack of the TV.
Blu-ray Oisc/OVO player, etc.
HDMI
connection
[=AV receivej
DIGITALAUDIO _ _ HDMI
connection connection
(OPTICAL)
TV, projector, etc.
2. Connect the audio output from the TV to the
OPTICAL IN 2 jack of the AV receiver using an
optical digital cable.
• When the audio return channel (ARC) function is used with
an ARC capable TV, this connection is not necessary
(÷ page 42).
3. Connect the HDMI output of the B lu-ray
Disc/DVD player/recorder to the HDMI IN 1 jack
of the AV receiver.
• It is necessary to assign the HDM[ input when connecting
the Blu-ray Disc/DVD player/recorder to other jacks
(_ page 35). Do not assign the components connected to
the HDM[ IN to the TV/CD input at this time. Appropriate
CEC (Consumer Electronics Control) operation can not be
guaranteed.
Each of tile "HDMI Setup" is changed to the
2
following setting.
• HDMI Ctrl (RIHD): On
• Audio Return Ch (ARC): Auto
See details of each setting (@ page 42).
3 Confirm the settings.
1. Turn on the power for all connected components.
2. Turn off the power of the TV, and confirm that
the power of the connected components is turned
off automatically with the link operation.
3. Turn on the power of the Blu-ray Disc/DVD
player/recorder.
4. Start playback of the Blu-ray Disc/DVD
player/recorder, and confirm the following.
• The power of the AV receiver is turned on
automatically, and input with the Blu-ray
Disc/DVD player/recorder connected is
selected.
• The power of the TV is turned on
automatically, and input with the AV receiver
connected is selected.
5. Following the operating instructions of the TV,
select "Use the TV speakers" from the menu
screen of the TV, and confirm that the audio is
output from the speakers of the TV, and not from
the speakers connected to the AV receiver.
6. Select "Use the speakers connected from the AV
receiver" from the menu screen of the TV, and
confirm that the audio is output from the speakers
connected to the AV receiver, and not from the
TV speakers.
• Perform the above operations when you initially use the
AV receiver, when the settings of each component are
changed, when the main power of each component is
turned off, when the power cable is disconnected from the
power supply, or when there has been a power outage.
4 Operate with the remote controller.
For buttons that can be operated (@ page 47).
• Audio from DVD-Audio or Super Audio CD may not
output from the TV speakers. You will be able to output the
audio from the TV speakers by setting the audio output of
the DVD player to 2ch PCM. (It may not be possible
depending on the player models.)
• Even if you set to output audio on the TV speakers, audio
will be output from the speakers connected to the AV
receiver when you adjust the volume or switch the input on
the AV receiver. To output audio from the TV speakers, re-
do the operations on the TV.
• Do not connect the 1-41cable when connecting to the 1-41
and I-41 audio control compatible components.
• When you select anything other than the HDM[jack where
the AV receiver is connected as the input on the TV, input
on the AV receiver will be switched to "TV/CD".
• The AV receiver will automatically power on in
conjunction when it determines it to be necessary. Even if
the AV receiver is connected to an r411-I1_ compatible
TV or player/recorder, it will not power on if it is not
necessary. It may not power on in conjunction when the TV
is set to output audio from the TV.
• Linked functions with the AV receiver may not work
depending on the model. Operate the AV receiver directly
in such cases.
ED
58
Page 59

Specifications
Amplifier Section
Rated Output Power
All channels:
Maximum Effective Output Power
Dynamic Power*
*lEC60268-Short-tenn nlaximum output power
THD+N (Total Harmonic Distortion+Nolse)
Damping Factor 60 (Front, 1 kHz, 8 f2)
Input Sensitivity and Impedance (Unbalance)
Rated RCA Output Level and Impedance
Maximum RCA Output Level and Impedance
Frequency Response 20 Hz - 50 kHz/+l dB, -3 dB (DSP bypass)
Tone Control Characteristics
Signal to Noise Ratio 100 dB (LINE, IHF-A)
Speaker Impedance 6 f_ - 16 f_
(North American)
80 watts minimum continuous power per
channel, 8 ohm loads, 2 channels driven
from 20 Hz to 20 kHz, with a maximum
total harmonic distortion of 0.7 % (FTC)
130 watts minimum continuous power
per channel, 6 ohm loads, 1 channel
driven at 1 kHz, with a maximum total
harmonic distortion of 1% (FTC)
(Others)
1 ch × 130W at 6 ohms, 1 kHz, 1 ch driven
of 1% (IEC)
(Asian)
1 ch × 160W at 6 ohms, 1 kHz, 1 ch driven
(JEITA)
180 W (3 fL Front)
160 W (4 fL Front)
100 W (8 fL Front)
0.08% (20 Hz - 20 kHz, half power)
200 mV/47 kf2 (LINE)
200 mV/2.2 kf] (REC OUT)
2 V/2.2 kf2 (REC OUT)
_+10 dB, 50 Hz (BASS)
_+10 dB, 20 kHz (TREBLE)
Video Section
Input Sensitivity/Output Level and Impedance
1 Vp-p/75 f_ (Component Y)
0.7 Vp-p/75 f2 (Component PB/Cm PIJCI0
1 Vp-p/75 f] (Composite)
Component Video Frequency Response
5 Hz - 100 MHz/+0 dB, -3 dB
Tuner Section
FM Tuning Frequency Range
(North American and Brazilian)
87.5 MHz - 107.9 MHz
(Asian) 87.5 MHz - 108.0 MHz
AM Tuning Frequency Range
Preset Channel 40
522/530 kHz - 1611/1710 kHz
General
Power Supply (North American and Brazilian)
Power Consumption (North American and Brazilian) 4.5 A
Stand-by Power Consumption
Dimensions 435 mm X 150 mm× 328 mm
(W × H × D) 17-1/8" × 5-7/8" × 12-15/16"
Weight (North American) 8.2 kg (18.1 lbs.)
AC 120 V, 60 Hz
(Asian) AC 220 - 240 V, 50 Hz
(Others) 480 W
(North American and Brazilian) 0.2 W
(Asian) 0.3 W
(Brazilian) 8.1 kg (17.9 lbs.)
(Others) 9.0 kg (19.8 lbs.)
NHDMI
Input IN 1, IN 2, IN 3, IN 4
Output OUT
Video Resolution 1080p
Audio Format Dolby TrueHD, DTS Master Audio,
Supported 3D, Audio Return Channel, DeepColor,
N Video Inputs
Component IN 1, IN 2
Composite BD/DVD, VCR/DVR, CBL/SAT, GAME,
N Video Outputs
Component
Composite
N Audio Inputs
Digital
Analog
N Audio Outputs
Analog
Subwoof'er Pre Output
Speaker Outputs
Phones
N Others
Setup Mic 1
USB 1 (Front)
RI 1
Specifications and features are subject to change
without notice.
DVD-Audio, DSD
x.v.Color, LipSync, CEC (RIHD)
AUX
OUT
MONITOR OUT, VCR/DVR OUT
Optical: 2
Coaxial: 2
BD/DVD, VCR/DVR, CBL/SAT, GAME,
TV/CD, AUX
VCR/DVR
1
Main (L, R, C, SL, SR, SBL/FHL,
SBR/FHR)
l (6.3 _)
EF1
59
Page 60

ONKYO SOUND & VISION CORPORATION
2-1, Nisshin-cho, Neyagawa-shi, OSAKA 572-8540, JAPAN
Tel: 072-831-8023 Fax: 072-831-8163
ONKYO U.S.A. CORPORATION
18 Park Way, Upper Saddle River, N,J, 07458, U,S,A,
Tel: 800-229-1687, 201-785-2600 Fax: 201-785-2650
http ://www, us,on kyo,com/
ONKYO EUROPE ELECTRONICS GmbH
Liegnitzerstrasse 6, 82194 Groebenzell, GERMANY
Tel: +49-8142-4401-0 Fax: +49-8142-4401-555
http ://www, eu ,onkyo,com/
ONKYO EUROPE ELECTRONICS GmbH (UK BRANCH)
The Coach House 81A High Street, Marlow, Buckinghamshire, SL7 lAB, UK
Tel: +44-(0)1628-473-350 Fax: +44-(0)1628-401-700
ONKYO CHINA LIMITED
Unit 1 & 12, 9/E Ever Gain Plaza Tower 1,88, Container Port Road, Kwai Chung,
N,T., Hong Kong, Tel: 852-2429-3118 Fax: 852-2428-9039
http ://www, ch,onkyo,com/
SN 29400621
(c) Copyright 2011ONKYO SOUND & VISIONCORPORATIONJapan. All rights reserved.
Yl101-1
* 2 9 4 0 0 6 2 1 *
