Omron K3HB-S DATASHEET

Linear Sensor Indicator

K3HB-S

Visual clarity and instantaneous measurement.
Control status and judgement results can be ascertained
at a glance using the display color and position meter.

Features

■ Intelligent

● High-speed Response at 2,000 Times per Second

Capable of high-speed sampling at 2,000 times/second.
Peak-hold and bottom-hold functions allow accurate mea­surement of peak and bot t om values.

Sampling at 15 times/second Sampling at 2,000 times/second

96

Timing of
internal
sampling

100

Time

● Calculations Based on T wo Input Signals

Calculations, such as K−A, A+B, A−B, and K−(A+B), can be
performed on two analog input signals. This enables highly
precise thickness and level-difference measurement. The
input ranges can be set independently so, for example, sig­nals between 4 and 20 mA can be han dl ed by one input w hi le
signals between 1 and 5 V are handled by the other.

Peak value

Timing of
internal
sampling

0

Time

■ Clear

● Red-Green Display Allows Easy Recognition of Judg-

ment Results

The measurement value display can be set to switch between
red and green in accordance with the st atus of comparative
outputs. This means t hat the status can be ascertained at a
distance.

● Position Meter Enables Easy Monitoring of Operating

Status Trends

The present value with respect to the measurement or display
range (full scale) can b e v iewed on a b ar di splay. This means
that the operating status can be grasped intuitively, allowing
easy judgement of levels and threshold values.

Position meter

Monitoring Levels inside Tanks

● A Wide Variety of Measurement Functions Including

Timing Signal Input

Choose the input process ing method sui table for the applica­tion from a selection of five measurement modes, such as
sampling hold, peak hol d, and bot t om hol d.

Input

Timing signal

input

ON
OFF

Peak hold

Sampling hold

Bottom hold

Time (t)

● Modular Construction for Adapting to Various Specifi-

cations

Monitoring Differences from Reference Points

Displacement sensor

Reference level

Workpiece

● Equipped with SV Display for Reliable Setting

Both the parameter na me and value set for that parameter
can be viewed at the same time in setting mode.

● Short Body with Depth of Only 95 mm (from Behind

the Front Panel)

A short body of onl y 95 m m cont ributes to the development of
slimmer and smaller control panels and installat ions.

27%

shorter

than earlier

models

Depth: 95 mm

2 Linear Sensor Indicator K3HB-S

Linear Sensor Indicator

K3HB-S

A Linear Sensor Indicator Capable of High­speed Response at 2,000 Times per Second

• Effectiv e for high-spee d measurement and discrimina tion with a
sampling period of 0.5 ms an d an output respons e time of 1 ms
max.

• Allows OK/NG judgement using display that can be switched
between green or red.

• Equipped with a position meter that represents measured
amounts and relative positions.

• Zero calibration can be performed easily with the forced zero
function.

• Short body with depth of only 95 mm (from behind the front
panel).

• Recognized to U.S. and Canadian requirements under the
component Recognition Program of UL.

• Conforms to CE marking.

Model Number Structure

■Model Number Lege nd

Base Units and Optional Boards can be ordered individually or as sets.

Base Units

K3HB-S@

15

1. Input Sensor Codes

SD: DC voltage/current input

5. Supply Voltage

100-240VAC: 100 to 240 VAC
24VAC/VDC: 24 VAC/VDC

Optional Board

• Sensor Power Supply/Output Boards

K33-@

2

• Relay/Transistor Output Boards

K34-@

3

• Event Input Boards

K35-@

4

Base Units with Optional Boards

K3HB-S@-@@@

1 2 3 4

2. Sensor Power Supply/Output Type Codes

CPA: 12-VDC 80-mA model with PASS -output (PASS: SPDT)
A: 12-VDC 80-mA model

3. Relay/Transistor Output Type Codes

C1: H/L models with relay outputs (H, L: SPDT)
C2: HH/H/L/LL models with relay outputs (HH, H, L, LL: SPST-NO)
T1: 5 comparative transistor outputs (NPN open collector)
T2: 5 comparative transistor outputs (PNP open collector)

4. Event Input Type Codes

1: Models with terminal blocks (NPN open collector)
2: Models with terminal blocks (PNP open collector)
3: Models with connectors (NPN open collector)
4: Models with connectors (PNP open collector)

5

Linear Sensor Indicator K3HB-S 3

Ordering Information

■DC Voltage/Current Input (for All Models)

(Each model has a multirange, thus corresponding to the following voltage and current ranges.)

Current measurement range Voltage measurement range

0.000 to 20.000 mA or

4.000 to 20.000 mA

■Base Units

0.000 to 5.000 V or 1.000 to 5.000 V or
–5.000 to 5.000 V or –10.000 to 10.000 V

Model Supply voltage Part number Applicable sensor

100 to 240 VAC K3HB-SSD

P

24 VAC/VDC K3HB-SSD

100-240VAC

24VAC/VDC

K33-CPA
K33-A

power supply/
output boards

Applicable relay/
transistor output

boards

K34-C1
K34-C2
K34-T1
K34-T2

Applicable event

input boards

K35-1
K35-2
K35-3
K35-4

4 Linear Sensor Indicator K3HB-S

Specifications

■Ratings

Power supply voltage 100 to 240 VAC (50/60 Hz) 24 VAC (50/60 Hz) or 24 VDC
Permissible power supply voltage

range
Power co ns um ption

(with maximum load)
(See note.)

Input signals DC voltage/current (0 to 20 mA, 4 to 20mA, 0 to 5 V, 1 to 5V,
Measurement method Sequential comparison system
Sensor power suppl y 12 VDC ±10%, 80 mA (only for models with sensor power supply)
Event input Timing input NPN open collector or no-voltage contact signal (Refer to Event Input Rating s on page 7 for details.)

Startup
compensation
timer input

Hold input
Reset input
Forced-zero input
Bank input

Output
(Depends on
model.)

Display method Negative LCD (backlit LED) display

Main functions Scaling function, 2-input calculation function, measurement operation selection, averaging, high pass

Ambient operating temperature
Ambient operating humidity 25% to 85%
Storage temperature
Altitude 2,000 m max.
Accessories Waterproof packing, 2 fixtures, terminal cover, unit stickers, operation manual

Note: A control power supply capacity greater than the rated v alue is required when power is turned ON. Particular attention is required when using

two or more DC power supply models. When power is turned ON or when the startup compensation timer operates, all outputs will turn OFF
if the Unit is not performing measurement.

Relay contact
output

Transistor output HH/H/PASS/L/LL (NPN open collector; Maximum load voltage: 24 VDC; Maximum load current: 50 mA;

85% to 110% of the rated power supply voltage

18 VA max. 24 VAC: 11 VA max.

PNP open collector

H/L, 2 outputs, both SPDT
250 VAC/30 VDC, 5 A (resistive load), electrical life ex pectan cy of 100,000 operations

HH/H/L/LL, 4 outputs, all SPST-NO
250 VAC/30 VDC, 5 A (resistive load), electrical life ex pectan cy of 100,000 operations

PASS, 1 output, SPDT
250 VAC/30 VDC, 5 A (resistive load), electrical life ex pectan cy of 100,000 operations

Leakage current: 100
HH/H/PASS/L/LL (PNP open collector; Maximum load voltage: 24 VDC; Maximum load current: 50 mA;

Leakage current: 100

7-segment digital display (PV character height: 14.2 mm (green/red); SV character height: 4.9 mm
(green))

filter, forced-zero, zero-limit, output hysteresis, output OFF delay, output test, teaching, display value
selection, display color selection, key protection, bank selection, display refresh period, maximum/
minimum hold, reset

−10 to 55 °C (with no icing or condensation)

−25 to 65 °C (with no icing or condensation)

µA max.)

µA max.)

24 VDC: 7 W max.

±5V, ±10 V), 2 channels

Linear Sensor Indicator K3HB-S 5

■Characteristics

Sampling period 0.5 ms (1 input), 1.0 ms (2 inputs)
Maximum number of display digits 5 digits (
Comparative output

response time
(transistor output)

Insulation resistance 20 M
Dielectric strength 2,300 VAC for 1 min between terminals and case
Noise immunity 100 to 240-V A C models:

Vibration resistance
Shock resistance

Weight Approx. 230 g (Base Unit only)
Enclosure ratings Front panel: Conforms to NEMA 4X for indoor use (equivalent to IP66)

Memory protection EEPROM (non-volatile memory); Number of rewrites: 100,000 times
Installation environment Overvoltage category II, pollution degree 2 (as per IEC61010-1)
Safety standards UL3121-1, CSA C22.2 No. 1010.1 (evaluated by UL)

EMC EMI: EN61326+A1 industrial applications

1 input ON to OFF: 1 ms max.; OFF to ON: 1.5ms max.
2 inputs ON to OFF: 2 ms max.; OFF to ON: 2.5 ms max.

1-ns rising edge and pulse width of 1
24-VA C/VDC models:

ns rising edge and pulse width of 1
Frequency: 10 to 55 Hz; Acceleration: 50 m/s
Transistor output models: 150m/s

Contact output models: 100m/s

Rear case: IP20
Terminals: IP00 + finger protection (VDE0106/100)

EN61010-1 (IEC61010-1): Pollution degree 2/overvoltage category 2 (evaluated by TÜV Product Ser­vice.)
EN61326: 1997, A1: 1998, A2: 2001

Terminal interference wave voltage
CISPR 11 Group 1, Class A: CISPR16-1/-2

Electromagnetic interference wave
CISPR 11 Group 1, Class A: CISPR16-1/-2

EMS: EN61326+A1 industrial applications
Electrostatic discharge (ESD)

EN61000-4-2: 4 kV (contact), 8 kV (in air)
Radiating radio-frequency electromagnetic field

EN61000-4-3: 10 V/m 1 kHz sine wave amplitude modulation (80 MHz to 1 GHz)
Burst

EN61000-4-4: 2 kV (power line), 1 kV (I/O signal line)
Surge

EN61000-4-5: 1 kV with line (power line), 2 kV with ground (power line)
Radio-frequency electric interference

EN61000-4-6: 3 V (0.15 to 80 MHz)
Momentary power interruptions from voltage dips

EN61000-4-11: 0.5 cycle, 0

−19,999 to 99,999)

Ω min. (at 500 VDC)

±1,500 V at power supply terminals in normal or common mode (waveform with 1-

±1,500 V at power supply terminals in normal or common mode (wavef orm with

°, 180°, 100% (rated voltage)

µs/100 ns)

µs/100 ns)

2

; 10 sweeps of 5 min each in X, Y, and Z directions

2

, 3 times each in 3 axes, 6 directions

2

, 3 times each in 3 axes, 6 directions

6 Linear Sensor Indicator K3HB-S

■Input Ranges (or Measurements Ranges and Accu racy)

Input

specification

DC current/voltage
input

Input type Measurement

0 to 20 mA 0.000 to 20.000 mA

4 to 20 mA 4.000 to 20.000 mA 2.000 to 22.000 mA
0 to 5 V 0.000 to 5.000 V
1 to 5 V 1.000 to 5.000 V 0.500 to 5.500 V

±5V ±5.000 V ±5.000 V
±10 V ±10.000 V ±11.000 V ±14.5 V

range

■Event Input Ratings

Input type S-TMR, HOLD, RESET , ZE RO, B ANK1, BANK2, BANK4 TIMING

Contact input ON: 1 k

No-contact input ON residual voltage: 2 V max.

Ω max.

OFF: 100 k

OFF leakage current: 0.1 mA max.
Load current: 4 mA max .
Maximum applied voltage: 30 VDC max.

Ω min.

■Output Ratings

Contact Output

Item Resistive loads

Rated load 250 VAC, 5 A

Rated through
current

Mechanical life
expectancy

Electrical life ex­pectancy

(250 VAC, cos

30 VDC, L/R=0 ms)

30 VDC, 5 A
5A

5,000,000 operations

100,000 operations

φ=1;

Inductive loads

(250 VAC, cosφ=0.4;

30 VDC, L/R=7 ms)

250 VAC, 1 A
30 VDC, 1 A

Indication range Accuracy

−2.000 to

22.000 mA

−0.500 to 5.500 V 1 MΩ min. ±10 V

One input: ±0.1%
FS

Two inputs:
FS

±5°C)

(at 23

±1 digit max.

±1 digit max.

±0.2%

---

ON residual voltage: 3 V max.
OFF leakage current: 1.5 mA max.
Load current: 17 mA max.
Maximum applied voltage: 30 VDC max.

Input impedance Maximum

120

Ω max. ±31 mA

absolute rated

input

Transistor Output

Maximum load voltage 24 VDC
Maximum load current 50 mA
Leakage current 100

µA max.

Linear Sensor Indicator K3HB-S 7

Connections

■Terminal Arrangement

ABCDE

1
2
3
4
5
6

A Operating Power Supply

100 to 240-VAC models

A1

A2

B Sensor Power Supply/Output

12-VDC, 80-mA

models with PASS output

(K33-CPA)

24-VAC/VDC models

12-VDC, 80-mA

A1

A2

models

(K33-A)

Note: Insulation is used between signal input, event

E Analog Input

E1

Current
input

Voltage
input

E2
E3
E4
E5

NC

E6

Models with terminal blocks

input, output, and power supply terminals.

Input B

Input A
COM

Input A

Input B

Input ranges

0.000 to 20.000mA

4.000 to 20.000mA

0.000 to 5.000V

1.000 to 5.000V

D Event Input

±5.000V

±10.000V

Connection terminals

1 input (1NA) 2 inputs

E2 − E3

E4 − E3

(NPN Open Collector)

Models with connectors

(K35-1) (K35-3)

D1

TIMING

D2

S-TMR
HOLD

D3

RESET

D4

ZERO

D5

COM

D6

(K35-2) (K35-4)

1 : TIMING
3 : HOLD
5 : ZERO
7 : BANK4
9 : BANK1

Applicable connector:
XG4M-1030 (OMRON)

1

9

E2 − E3

E1 − E3

E4 − E3

E5 − E3

2

10

(INA)

(INB)

(INA)

(INB)

2 : S-TMR
4 : RESET
6 : COM
8 : BANK2
10 : COM

B1

PASS

NC

+

−

B2
B3
B4

Sensor power

B5

supply
12 VDC

B6

80 mA

NC

+

−

C Relay/Transistor Outputs

H/L models

with relay outputs

(K34-C1)

C1

H

C2
C3
C4

L

C5
C6

B1
B2
B3
B4

Sensor power

B5

supply
12 VDC

B6

80 mA

HH/H/L/LL models

with relay outputs

(K34-C2)

C1

HH

C2

H

C3

COM

L

C4

LL

C5
C6

COM

HH/H/PASS/L/LL models

with NPN transistor outputs

(K34-T1)

C1

HH

C2

H

C3

PASS

L

C4

LL

C5
C6

COM

HH/H/PASS/L/LL models

with PNP transistor outputs

(K34-T2)

C1

HH

C2

H

C3

PASS

L

C4

LL

C5
C6

COM

8 Linear Sensor Indicator K3HB-S

Output Circuits

■Internal Block Diagra m

Key

Display

indicates
electrically isolated
regions.

Analog input terminal

Event input terminal

Sensor power supply

Input
circuit

Event

input
circuit

Filter

Power supply circuit

Power supply

AD

converter

EEPROM

Wave-

shaping

circuit

Drive
circuit

■I/O Circuit Diagrams

Analog Inputs (DC V oltage and Current)

• Use terminal E3 as the analog common.

B

−

+

A+B=1 M

AD

Ω

E4, E5

Voltage input

COM

V

A

E3

Drive
circuit

Drive

Micro-

computer

Constant voltage circuit 2Constant voltage circuit 1

Current input

circuit

E1, E2

COM

I

E3

Transistor output

Contact output

−

+

110 Ω (TYP)

AD

Event Inputs

• Use terminal D6 as the common terminal.

• Use open collector or no-voltage contacts for event input.

Note: PNP types are also available.

S-TMR : D2

HOLD : D3

RESET : D4

ZERO : D5

COM

D6

12 V

4.7 KΩ

3.9 KΩ

12 V

TIMING

COM

D1

D6

560 Ω

750 Ω

Linear Sensor Indicator K3HB-S 9
