Olympus TG-5 IM005 User Manual

DIGITAL CAMERA

TG-5

Instruction Manual

Model No. : IM005

Thank you for purchasing an Olympus digital camera. Before you start to

use your new camera, please read these instructions carefully to enjoy optimum performance and a longer service life. Keep this manual in a safe place for future reference.

We recommend that you take test shots to get accustomed to your camera

before taking important photographs.

The screen and camera illustrations shown in this manual were produced

during the development stages and may differ from the actual product.

If there are additions and/or modifications of functions due to firmware

update for the camera, the contents will differ. For the latest information, please visit the Olympus website or contact your Olympus Consumer Support Team in your region.

Unpack the box contents

The following items are included with the camera. If anything is missing or damaged, contact the dealer from whom you purchased the camera.

Digital camera Strap

USB-AC adapter (F-5AC) USB cable (CB-USB12)

Other accessories not shown: Warranty card

Contents may vary depending on purchase location.

Attaching the camera strap

• Pull the strap tight so that it does not come loose.

Lithium Ion Battery

(LI-92B)

Names of parts

1 Connector cover 2 Connector cover lock 3 LOCK knob 4 Speaker 5 Strap eyelet 6 Lens 7 Self-timer lamp/LED Illuminator/

AF illuminator

8 Flash 9 Lens ring release button 0 Stereo microphone a GPS antenna b n button c Zoom lever d Control dial e LOG switch f Indicator lamp g Shutter button h Monitor

• FGHI instruct to press the up/down/left/right arrow pad.

i INFO (Information display) button j R (Movie)/select button k Mode dial l q (Playback) button m A button n /Wi-Fi button o HDMI micro connector p Micro-USB connector q Tripod socket r Battery/card compartment cover s

Battery/card compartment cover lock

t Arrow pad u F (Up) / F (Exposure

compensation) button

v I (Right) /# (Flash) button w G (Down) /

jY (Sequential shooting/ Self-timer) /  (Erase) button

x H (Left)/mode function button

Preparations for shooting

Inserting and removing the battery and card

Follow Steps 1, 2 and 3 to open the battery/card

compartment cover.

• Turn off the camera before opening the battery/card compartment cover.

Battery/card compartment cover lock

Battery/card compartment cover

Insert the battery while sliding the battery lock knob in the

direction of the arrow.

• Insert the battery as illustrated with the C mark toward the battery lock knob.

• If you insert the battery in the wrong direction, the camera is not turned on. Be sure to insert it in the correct direction.

• Slide the battery lock knob in the direction of the arrow to unlock, and then remove the battery.

LOCK knob

Battery lock knob

Insert the card straight until it clicks into place.

• Do not touch the metallic parts of the card directly.

• Always use the specified cards with this camera. Do not insert other types of memory cards.

Write-protect

switch

Cards compatible with this camera

SD/SDHC/SDXC/Eye-Fi (with Wireless LAN function) card (commercially available) (for compatibility card details, visit the Olympus website.)

To remove the card

Press the card in until it clicks and comes out slightly, then remove the card.

Follow Steps 1, 2 and 3 to close battery/card compartment

cover.

• When using the camera, be sure to close the battery/card compartment cover.

Charging the battery

Check that the battery is in the camera, and connect the USB

cable and USB-AC adapter.

• The battery is not fully charged at shipment. Before use, be sure to charge the battery until the indicator lamp turns off (up to 3 hours).

Connecting the camera

USB-AC adapter

AC outlet

Indicator lamp On: Charging Off: Charged

Connector cover

Micro-USB connector

USB cable

(supplied)

A menu will be displayed; highlight

[Charge] and press the A button.

USB

Storage

MTP Print

Charge

Exit

For charging the battery abroad, see “Using your charger and USB-AC adapter abroad” (P. 100).

• Never use any cable other than supplied or Olympus-designated USB cable. This may cause smoking or burning.

• The included F-5AC USB-AC adapter (hereafter referred to as USB-AC adapter) differs depending on the region where you purchased the camera. If you received a plug-in type USB-AC adapter, plug it directly into AC outlet.

• Be sure to unplug the power plug of the USB-AC adapter from the wall outlet when the charging is complete.

Set

• For details on the battery, see “SAFETY PRECAUTIONS” (P. 120). For details on the USB-AC adapter, see “SAFETY PRECAUTIONS” (P. 120).

• If the indicator lamp does not light, reconnect the USB cable and USB-AC adapter to the camera.

• If the message “No Connection” is displayed in the monitor, disconnect and reconnect the cable.

When to charge the batteries

Charge the battery when

Error messageFlashes in red

the error message shown on the right appears.

Battery Empty

Turning on the camera and making the initial settings

When you turn on the camera for the first time, a screen appears enabling to set the language for the menus and messages displayed in the monitor, and the date and time. To change the selected date and time, see “Setting the clock manually, choosing a time zone, and using GPS to set the clock d [X Settings]” (P. 70)

Press the n button to turn the camera on, highlight your

language using FGHI (arrow pad) or the control dial, and press the A button.

• In the case that the power is not turned on when you press the n button, check the direction of the battery. g “Inserting and removing the battery and card” (P. 4)

Use FG (arrow pad) or

the control dial to select the year ([Y]).

Press I (arrow pad) to

2017

Cancel

save the setting for [Y].

2017

Cancel

Select the month ([M]), day ([D]), hour and minute ([Time]),

and the date display order ([Y/M/D]) using FGHI (arrow pad) as described in Steps 2 and 3, and then press the A button.

Use FG (arrow pad) to

select the time zone and then press the A button.

• Daylight saving time can be turned on or off using the INFO button.

YMD Time

Time Zone

UTC+09:00 (12:30)

Seoul Toky o

Y/M/D

M/D

Set

Using basic functions

Taking photographs (P mode)

Press the n button to turn on the camera.

When the camera is turned on, the monitor will turn on.

Set the mode dial to P.

In mode P, the camera automatically adjusts shutter speed and aperture in response to subject brightness.

Frame the shot.

• When holding the camera, take care not to cover the flash, microphone or other important parts with your fingers, etc.

Press the shutter button

halfway down to focus.

The focus indicator will blink to show that the camera is not in focus. Focus again.

• The shutter speed and aperture displays will blink to show that the camera is unable to achieve optimal exposure.

To take the picture, gently

press the shutter button all the way down while being careful not to shake the camera.

Press halfway

Press

halfway

Focus indicator

S-IS ONS-IS

125

125 F5.6

Shutter

speed

Press the rest of

the way down

0.0±0.0

Aperture value

01:02:0301:02:03

10231023

ISO-A

200

FHD

30p

Viewing photographs (Playing back images)

Turn on the camera. Press the q button.

• Your most recent photograph is displayed.

• Press HI (arrow pad) or rotate the control dial to view other pictures. Control dial

Displays the

previous frame

Displays the next frame

q button

Arrow pad

Index display/Calendar display

• To switch from single-frame to index playback, rotate the zoom lever counterclockwise. Repeating the process will increase the number of images displayed, ending in a calendar display. g [G Settings] (P. 62)

• Use FGHI (arrow pad) or the control dial to move the cursor.

• Rotate the zoom lever clockwise to proceed in turn from calendar to index to single-frame playback.

2017.02.26 12:30:00 20

Still image

Counter-

clockwise

2017.02.2612:30:00 21

Clockwise

20.5°C 1012hPa10m

4:3

100-0020

Close-up playback

• In single-frame playback, you can zoom in or out using the zoom lever: rotate the lever clockwise to zoom in from 2× to 14× and counterclockwise to zoom out. Press the A button to return to single-frame playback.

• Press FGHI (arrow pad) to scroll an image to the direction of the button you pressed.

• To view other images at the same zoom ratio, press the

INFO button and then press HI (arrow pad). Press the INFO button again to re-enable scrolling. You can also

view other images using the control dial.

Selecting Multiple Images

You can select multiple images for [R] (P. 13), [Erase Selected] (P. 16), and [Share Order Selected] (P. 13) operations. Press the R (movie) button to select the image currently displayed during playback or highlighted in the index display (P. 10). Selected images are indicated by a v icon. Press the button again to deselect the image.

Using the Playback Menu

The playback menu can be displayed by pressing the A button during playback. Highlight the desired option and select it by pressing the A button. The options displayed vary with the type of image selected.

Available Options

RAW JPEG RAW+JPEG Movies

Play

RAW Data Edit JPEG Edit Play Movie Movie Edit Share Order

Rotate

Image Overlay

Erase

RRR

―

―――

―

RRRR

RRR

RRRR

―

RRRR

―

RRR

―

Play H

Voice memos (P. 13) are played back when the associated image is displayed. Volume can be adjusted using FG (arrow pad). Press  or A to end voice memo playback.

RAW Data Edit

Creates a JPEG copy of a RAW image according to the selected settings. g [RAW Data Edit] (P. 57)

JPEG Edit

Edit JPEG images. g [JPEG Edit] (P. 57)

Play Movie

View the current movie. g “Movie playback” (P. 15)

―

Movie Edit

Edit movies. g [In-Movie Image Capture (Movie Edit)] (P. 59), [Movie Trimming (Movie Edit)] (P. 59)

Share Order

Select images for later transfer to a smartphone. You can also view the images currently selected for transfer. Press FG (arrow pad) to select images for transfer. Selected images are indicated by a h icon; to deselect, press FG (arrow pad) again. You can also select multiple images and then mark them all for transfer simultaneously. g “Selecting Multiple Images” (P. 11), “Transferring images to a smartphone” (P. 74)

Protect images from accidental deletion. Pressing FG (arrow pad) marks images with a 0 (protect) icon. Press FG (arrow pad) again to remove protection. You can also select multiple images and then protect them simultaneously. g “Selecting Multiple Images” (P. 11)

R Audio can be added to still images (up to 30 sec. long). g [R] (P. 59)

Rotate

Rotate the current image. The image rotates each time you press FG (arrow pad); press the A button to complete the operation.

• The rotated image is saved in its current orientation.

• Movies and protected images cannot be rotated.

This function displays images stored on the card one after another. g [L] (P. 56)

Image Overlay

Up to 3 frames of RAW images taken with the camera can be overlaid and saved as a separate image. g [Image overlay] (P. 60)

Choose print options (the number of copies and date imprinting) for the images on the memory card. g “Print reservation (DPOF)” (P. 86)

Erase

Delete the current image. g “Erasing images during playback” (P. 16)

Recording movies

REC 00:01REC 00:01

0:07:480:07:48

LL R

Press the R (movie) button

to start recording.

• The movie is shot in the set shooting mode. Note that the shooting mode effects may not be obtained for some shooting modes.

• Sound is also recorded.

• When using a camera with a CMOS image sensor, moving objects may appear distorted due to the rolling shutter phenomenon. This is a physical phenomenon whereby distortion occurs in the filmed image when shooting a fastmoving subject or due to camera shaking. In particular, this phenomenon becomes more noticeable when using a long focal length.

Press the R (movie) button again to stop recording.

• When recording movies, use an SD card that supports an SD speed class of 10 or higher.

• Use a UHS-I card with a UHS speed class of 3 or better if:

[4K] or [High-speed] is selected for A (movie mode)/[Super Fine] is selected for bit rate

• When the mode dial is rotated to A, you can choose sub modes for recording 4K or high-speed movies. g “A (movie mode)” (P. 25)

Recording time

Recording length

M-IS ONM-IS

REC 00:01REC 00:01

0.00.0

0:07:480:07:48

ISO

AUTO

AFAF

FHD

30p

Movie playback

Pressing the A button when a movie is selected in

Movie

single-frame playback displays the playback menu. Highlight [Play Movie] and press the A button to start movie playback.

Back

Operations During Playback

Pause

Fast forward

Rewind

Adjusting the volume

Press the A button to pause playback. To resume playback, press the A button again.

Press I (arrow pad) to fast forward. Press I (arrow pad) again to increase the fast forward speed.

Press H (arrow pad) to rewind. Press H (arrow pad) again to increase the rewind speed.

Use FG (arrow pad) to adjust the volume.

Operations while playback is paused

Cueing

Advancing and

rewinding one frame at

a time

Resuming playback

Use F (arrow pad) to display the first frame and press G to display the last frame.

Use HI (arrow pad) or the control dial to advance or rewind one frame at a time. Keep HI (arrow pad) pressed for continuous advance or rewind.

Press the A button to resume playback.

To stop movie playback

Press the  button.

• We recommend using OLYMPUS Viewer 3 (P. 90) to view movies on a computer. Be sure to use the latest version. Connect the camera to the computer before launching OLYMPUS Viewer 3 for the first time.

Play Movie

Movie Edit

Share Order

Erase

Set

Erasing images during playback

Display the image you want to erase and press .

• To erase a movie, select the movie to erase and press .

Back

Press FG (arrow pad) to select [Yes], and press the A

Erase

Yes

Set

button.

• Grouped images are erased as a group (P. 11).

• Multiple images or all images can be erased at a time (P. 70).

Scrolling Panoramas

Panoramas made up of multiple images joined together can be viewed in a scrolling display.

Select a panorama in single-frame

playback. Rotate the zoom lever clockwise.

• Press FGHI (arrow pad) to scroll the image in the direction of the pressed button.

• During playback, you can rotate the zoom lever clockwise to zoom in from 2× to 14× or counterclockwise to zoom out. Press the A button to return to single-frame playback.

• To view other images at the same zoom ratio, press the INFO button and then press HI (arrow pad). Press the INFO button again to re-enable scrolling. You can also view other images using the control dial.

Viewing area

Monitor display

Shooting screen displays

0a c d

x2.0

1.4x1.4 2.0

34678e

S-IS ONS-IS

D C B A z y

LOG

w v

592

BKT

FD-1FD-1

FocusFocus

125125 F5.6

tusrq

2.0+2.0

No. Name

Card write indicator

Grid Guide

Bracketing icon

AF fine-tuning guide

AF target mark

Accessory

Digital zoom ratio*

Time lapse shooting

Face priority

Movie sound

Wind noise reduction

Attitude indicator (pitch)

Optical zoom ratio/

magnification* Internal temperature warning

Flash (blinks: charging in progress,

lights up: charging completed) Focus indicator

*1 Displayed at all times if [n Microscope Control] (P. 27) is in use.

1.4x1.4

f g

ISO-A

200

AUTOWBAUTO

AFAF

4:3

FHD

30p

01:02:0301:02:03

10231023

No. Name

Picture Mode

ISO sensitivity

White balance

AF mode

Aspect

Image quality (still images)

Record mode (movies)

Movie recording length

Number of storable still pictures

Attitude indicator (roll)

Top: Flash intensity control

Bottom: Exposure compensation Exposure compensation

Aperture value

Shutter speed

Histogram

Shooting mode

No. Name

Custom mode

LOG icon/warning

GPS icon

Metering

o/Y

A B C D E

/Pro Capture shooting Flash Compensation Flash mode Image stabilization Battery check

Reading a histogram

If the peak fills too much of the frame, the image will appear mostly black.

The green section shows luminance distribution within the screen’s center.

If the peak fills too much of the frame, the image will appear mostly white.

Switching the displays

Press the INFO button to cycle through the displays as follows: Basic Information*1, Image Only, Histogram Display (Custom1), Attitude Indicator (Custom2).

• You can change Custom1 and Custom2 settings. g [G/Info Settings] > [LV-INFO] (P. 62)

• Hold the INFO button and rotate the control dial to rotate the shooting information display.

*1 Not displayed in A mode (movie mode) unless recording is in progress.

The Attitude Indicator

The attitude indicator shows the amount of camera tilt. The vertical bar shows pitch, and the horizontal bar shows roll.

• The indicator is intended as a guide only.

• Error in the display can be corrected via calibration (P. 69).

Playback mode display

Switching the displays

Press the INFO button to cycle through the displays as follows: Simplified, Overall, Image Only.

• Histogram and highlight/shadow displays can be added to the playback information display. g [G/Info Settings] > [q Info] (P. 62)

Simplified display

Overall display

Image only

21465 78

×10×10

145°23’ 59” W

10m

4:3

HDR 1

×10×10

125125

+2.0+2.0 25mm25mm

AUTO

4:3

efhi

2017.02.26 12:30:00 15

lk m o

2017.02.26 12:30:00 15

wxyzA

39°12’ 30” N

20.5°C 1012hPa

100-0015

F5.6F5.6

+1.0+1.0 G+4G+4A+4A+4

sRGBsRGBISO 400ISO 400

NaturalNatural

1/84000×3000

100-0015

9 0 a b c d

p q r s t u v

No. Name *1 *2 *3

Battery check

Including GPS

information Eye-Fi transfer

data/Wi-Fi Print reservation/

number of prints Share order

Adding sound

Protect

Image selected

Latitude

Longitude

Direction

information Atmospheric

File number

Frame number

Image quality

Aspect ratio

Focus Stacking/

HDR image Altitude/Water

depth Temperature

(water temperature)

RRR

––

No. Name *1 *2 *3

– –

–

– –

– – – –

–

Recording date

and time Aspect border*

AF area pointer –

Shooting mode –

Shutter speed –

Exposure

compensation Aperture value –

Focal length –

Flash intensity

control White balance

compensation Color space –

Picture mode –

Compression rate –

Image size –

ISO sensitivity –

White balance –

Metering mode –

Histogram –

RRR

–

*1 Simplified display *2 Overall display *3 Image only

*4 Displayed only if an aspect ratio other than 4:3 is selected with a RAW image

quality option.

Shooting using basic functions

Using the shooting modes

Selecting shooting mode

Turn the mode dial to set the shooting mode to the indicator.

• After selecting O, A, ^, or k, select the sub mode.

List of shooting mode

B (iAUTO mode) ........................P. 21

P (Program mode) ........................P. 9

A (A mode) .................................P. 22

C1 (Custom mode 1)...................P. 22

C2 (Custom mode 2)...................P. 22

• Some features may be unavailable depending on the shooting mode and camera settings. g “List of settings available in each shooting mode” (P . 11 1), “List of A settings” (P . 1 12), “List of O settings” (P . 114), “List of ^ settings” (P. 113)

• In certain shooting modes, the camera may take a few moments for image processing after taking a picture.

B (iAUTO mode)

A full auto mode in which the camera automatically optimizes settings for the current scene. The camera does all the work, which is convenient for beginners.

Rotate the mode dial to B.

Press the shutter button halfway down to focus.

The focus indicator will blink to show that the camera is not in focus. Focus again.

Press the shutter button all the way down to shoot.

O (Scene Mode) ......................P. 22

A (movie mode) .........................P. 25

^ (Underwater mode) ..............P. 26

k (Microscope mode) ..................P. 27

A (A mode)

When an aperture value is set, the camera automatically sets an appropriate shutter speed. You can change the aperture by rotating the control dial or by pressing F and then FG (arrow pad).

C1/C2 (Custom mode)

If you store shooting settings in [Reset/Assign Custom Modes] (P. 52), you can call up and shoot using the stored shooting settings.

• You can register different settings in C1 and C2.

O (scene mode)

Only by selecting a sub mode according to the subject or the scene, you can shoot with an proper setting.

Sub mode 1 Sub mode 2 Application

Portrait Suitable for portrait shooting.

Smoothes out skin tones and texture. This mode is suitable when viewing images on a high-definition TV.

Suitable for portraits featuring a landscape in the background.

Suitable for portrait shooting against a background of night view.

Suitable for photographs of children and other active subjects.

Suitable for tripod shooting of night scenes.

Suitable for portrait shooting against a background of night view.

Suitable for shooting night scenes without a tripod. Reduces blur when shooting low light/illuminated scenes.

Suitable for shooting fireworks at night.

People

Nightscapes

e-Portrait

Portrait +

Landscape Portrait +

Nightscape Children

Nightscape

Portrait +

Nightscape

Handheld Starlight

Fireworks

Sub mode 1 Sub mode 2 Application

The camera automatically shoots multiple images, takes newly bright areas only, and composites them into a single image.

Nightscapes

Motion

Scenery

Indoors

Live Composite

Sport Suitable for fast action shooting.

Children

Landscape Suitable for landscape shooting.

Sunset Suitable for shooting the sunset.

Beach & Snow

Panorama

Backlight HDR

Candlelight

Portrait Suitable for portrait shooting.

e-Portrait

Children

Backlight HDR

With normal long exposure, an image of light trace such as star trails with bright buildings tends to get too bright. You can capture them without over exposure while checking the progress.

Suitable for photographs of children and other active subjects.

Suitable for shooting at snowcapped mountains, seascapes in the sun, and other whitish scenes.

You can shoot and combine multiple images to create an image with a wide angle of view (panoramic image).

Suitable for contrasting scenes. This mode captures multiple images and merges them into one, properly exposed image.

Suitable for shots of candlelit scenes. Warm colors are preserved.

Smoothes out skin tones and texture. This mode is suitable when viewing images on a high-definition TV.

Suitable for photographs of children and other active subjects.

Suitable for contrasting scenes. This mode captures multiple images and merges them into one, properly exposed image.

Rotate the mode dial to O.

Use FGHI (arrow pad) or the control

Sub mode 1

dial to highlight an option for sub mode 1 and press the A button to select.

Use HI (arrow pad) or the control dial

to highlight an option for sub mode 2 and

People

Motion Scenery

Indoors

Nightscapes

Sub mode 2

Portrait

press the A button to select.

• Press the  button to return to the sub mode 1 display.

• When the mode dial is rotated to O, the sub mode 1 display can be viewed by pressing H (arrow pad).

• The live control (P. 34) can also be used to select sub mode 2.

d Live Composite

1 Press the shutter button halfway down to focus.

• Mount the camera securely on a tripod to reduce blur caused by camera shake.

• If the focus indicator blinks, the camera is not in focus. When the focus indicator is flashing, you can focus at infinity by pressing the A button while the shutter button is pressed halfway.

2 To take the picture, gently press the shutter button all the way down while

being careful not to shake the camera.

• The camera configures the proper settings automatically and starts shooting.

• After pressing the shutter button, there is a time lag until shooting starts.

• A combined panorama image is displayed per certain period of time.

3 Press the shutter button again to stop shooting.

• The recording length in one shooting is up to three hours.

s Panorama

1 Press the shutter button to take the first frame. 2 Pan the camera slowly to frame the

second shot.

• A target mark will be displayed.

3 Move the camera slowly so that the

pointer and the target mark overlap. The camera releases the shutter automatically when the pointer and the target overlap.

• To combine only two frames, press the A button.

4 Repeat step 3 to take a third frame. The camera automatically combines the

frames into a single panorama image.

• To cancel the panorama function, press the  button.

Target mark

Pointer

Cancel Save

Screen when combining images from left to right

A (movie mode)

In addition to normal footage, you can record high-resolution 4K movies or shoot high-speed movies that play back in slow motion.

Sub mode Application

Standard Record normal movies.

4K Record high-definition 4K movies.

High-speed Record fast-moving subjects for slow-motion playback.

Rotate the mode dial to A.

Use HI (arrow pad) or the control dial

Standard

to highlight a sub mode and press the A button to select.

4K HS

Press the R (movie) button to start recording.

• To end recording, press the R (movie) button again.

• When the mode dial is rotated to A, the sub mode display can be viewed by pressing H (arrow pad).

Image Quality

You can adjust image quality using live controls. g “Record mode (movies)” (P. 39)

^ (Underwater mode)

Only by selecting a sub mode according to the subject or the scene, you can shoot underwater photographs with a proper setting.

Sub mode Application

Underwater

]

Snapshot Underwater Wide Suitable for shooting underwater.

Underwater Macro Suitable for shooting close-up view underwater.

Underwater HDR

Optimized for underwater photography that uses natural light.

Suitable for contrasting underwater scenes. This mode captures multiple images and merges them into one, properly exposed image. This mode may not function well for shooting a fastmoving subject.

Rotate the mode dial to ^.

Use HI (arrow pad) or the control dial

Underwater Snapshot

to highlight a sub mode and press the A button to select.

Press the shutter button all the way down to take the picture.

• To take a series of shots at the same focus distance, use AFL (P. 32) or MF (P. 37).

• When the mode dial is rotated to ^, the sub mode display can be viewed by pressing H (arrow pad).

k (Microscope mode)

Images can be taken from up to 1 cm away from the subject. In this mode you can shoot images with a large depth of field, and perform focus bracket shooting of a set number of images.

Rotate the mode dial to k.

Use HI (arrow pad) or the control dial

Microscope

to highlight a sub mode and press the A button to select.

Sub mode Application

Microscope Images can be taken from up to 1 cm away from the subject.

The camera shoots a number of images, automatically

Focus

Stacking*

Focus

Bracketing

Microscope

Control

*1 There may be situations in which it is not possible to create composite image

due to camera shake.

Press the shutter button all the way down to shoot.

• To take a series of shots at the same focus distance, use AFL (P. 32) or MF (P. 37).

• When the mode dial is rotated to k, the sub mode display can be viewed by pressing H (arrow pad).

shifting the focus in each image. These can then be combined into a composite image with a large depth of field.

Two images are recorded, the first frame and the composite image.

In this mode, the camera shoots a number of images, automatically shifting the focus in each image. The number of images and shooting steps are set in [Focus BKT] (P. 55).

Optimized for close-ups with the subject magnified in the monitor.The magnification level when the shooting distance is 1 cm is displayed on the monitor. Pressing I (arrow pad) can change the magnification level. At high magnification levels, the image may be grainy.

Using the zoom

Zoom in to photograph distant objects or zoom out to increase the area visible in the frame. Zoom can be adjusted using the zoom lever.

W side T side

Using shooting options (Set by direct button)

Frequently used functions are assigned to IFG (arrow pad). Just by pressing the button, you can select the assigned function directly. Some features may be unavailable depending on the shooting mode and camera settings. g “List of settings available in each shooting mode” (P. 111)

Flash

You can use a flash when shooting.

Press the # button to display options.

Use HI (arrow pad) or the control dial to highlight a flash

mode and press the A button to select.

AUTO

Flash Auto

Fill In

Redeye

Flash Off The flash does not fire.

Red-Eye Slow

SLOW

The flash fires automatically in low light or backlight conditions.

The flash fires regardless of the light conditions.

This function allows you to reduce the redeye phenomenon.

Combines slow sync with red-eye reduction.

Slow shutter speeds are used to brighten dimly-lit backgrounds.

Control flash output manually. If you

Manual

Remote Control

LED On

], after the pre-flashes, it takes about 1 second before the shutter is

• In [ released. Do not move the camera until shooting is complete.

• [

] may not work effectively under some shooting conditions.

• The shutter speed becomes slower in [#SLOW]. Use a tripod and secure the camera.

• Some features may be unavailable depending on the shooting mode and camera settings.

highlight “Manual” and press the INFO button before pressing the A button, you can adjust flash output using (arrow pad) or the control dial.

The dedicated underwater strobe or the Olympus wireless RC flash is used to take pictures. For details, see “Taking pictures with the Olympus Wireless RC Flash System” (P. 105).

The LED turns on when a picture is taken. This is effective for taking close up pictures.

FGHI

Exposure compensation

Compensates the brightness (appropriate exposure) adjusted by the camera.

Rotate the control dial, or press the F button and use HI

(arrow pad).

• Depending on the shooting mode and camera settings, you may not be able to adjust exposure compensation using the control dial.

• Choose positive (“+”) values to make pictures brighter, negative (“–”) values to make pictures darker.

Negative (–) No compensation (0) Positive (+)

Single/Sequential

Hold the shutter-release button all the way down to take a series of photographs.

Press the jY button to display the direct menu.

Press HI (arrow pad) or rotate the control dial to highlight an

option and then press the A button.

Single

Sequential

High

Sequential

Low

Pro Capture

• During sequential and Pro Capture shooting, focus, exposure, and white balance are fixed at the values for the first shot.

• During sequential shooting, if the battery check blinks due to low battery, the camera stops shooting and starts saving the pictures you have taken on the card. The camera may not save all of the pictures depending on how much battery power remains.

Shoots 1 frame at a time when the shutter button is pressed (normal shooting mode).

Hold the shutter-release button all the way down to take a series of photographs.

• To choose a frame advance rate, highlight [Sequential High] and press the INFO button before you press the A button. Choose from frame advance rates of approximately 10 frames per second (10 fps) or 20 frames per second (20 fps). Use FGHI (arrow pad) or the control dial to highlight a frame advance rate and press the A button to select.

Pictures will be taken at about 5 fps while the shutter button is pressed all the way down.

Sequential shooting begins when you press the shutter button halfway. Press the shutter button all the way down to begin recording captured images to the card, including those for a halfway press.

“Pro Capture” (P. 31)

+ 104 hidden pages
