Declaration of Conformity
Model Number: C-7070 Wide Zoom
Trade Name: OLYMPUS
Responsible Party :
En
Address: Two Corporate Center Drive, PO Box 9058, Melville, NY
Telephone Number : 1-631-844-5000
Tested To Comply With FCC Standards
FOR HOME OR OFFICE USE
This device complies with Part 15 of the FCC rules. Operation is subject to the following
two conditions:
(1) This device may not cause harmful interference.
(2) This device must accept any interference received, including interference that may
cause undesired operation.
FCC Notice
• Radio and Television Interference
Change or modifications not expressly approved by the manufacturer may void the
user’s authority to operate this equipment. This equipment has been tested and found to
comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful interference
in a residential installation.
This equipment generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference
to radio communications.
However, there is no guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following measures:
- Adjust or relocate the receiving antenna.
- Increase the distance between the camera and receiver.
- Connect the equipment to an outlet on a circuit different from that to which the receiver
is connected.
- Consult your dealer or an experienced radio/TV technician for help. Only the
OLYMPUS-supplied USB cable should be used to connect the camera to USB enabled
personal computers (PC).
Any unauthorized changes or modifications to this equipment would void the user’s
authority to operate.
For customers in Canada
This Class B digital apparatus meets all requirements of the Canadian InterferenceCausing Equipment Regulations.
11747-9058 U.S.A.
For customers in Europe
“CE” mark indicates that this product complies with the European requirements
for safety, health, environment and customer protection. “CE” mark cameras
are intended for sales in Europe.
2
Manual Contents
How to use the camera .................................................. 4
Using the OLYMPUS Master
software on your computer lets
you enjoy editing, viewing, and
printing the pictures downloaded
from your camera.
Using a card...
Pictures taken with this
camera are stored on
card media (e.g. xDPicture Card). By storing
the relevant print
reservation data with the
images on the card, you
can print pictures at a
photo store or on a
PictBridge-compatible
printer.
Using a printer...
With a PictBridge-compatible
printer, you can print pictures
directly from your camera.
Using a TV...
You can use a TV to view
pictures or playback
movies from your camera.
4
DRIVE
WB
SELECT
DRIVE
MODE MENU
± 0.3± 0.7
WB
± 1.0
BKT
3
MODE MENU
5
Using the mode dial...
Use the mode dial to select a shooting
or playback mode.
the optimum settings for the shooting
conditions from 7 different situations.
Using the arrow pad and Z
button...
The arrow pad and Z button are for selecting and
setting menu options as well as viewing pictures
frame by frame.
Using the menus...
Shooting and playback-related
functions are set from the menus
OK
GO
displayed on the monitor.
Using the direct
buttons...
Direct buttons let you perform
functions such as erasing or
protecting pictures or setting the
flash mode, making camera
operation easy.
f
lets you select
En
5
Safety Precautions
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION: TO REDUCE THE RISK OF ELECTRICAL SHOCK, DO NOT
REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED OLYMPUS SERVICE PERSONNEL.
Lightning flash with an arrowhead, enclosed in a triangle, alerts you to the presence of uninsulated voltage
points inside the product which could cause a serious electrical shock.
An exclamation mark enclosed in a triangle alerts you to important operating and maintenance instruc tions in
the documentation provided with the product.
WARNING!
TO AVOID THE RISK OF FIRE OR ELECTRICAL SHOCK, NEVER EXPOSE THIS PRODUCT TO WATER OR
En
OPERATE IN A HIGH HUMIDITY ENVIRONMENT.
General Precautions
Read All Instructions — Before you use the product, read all operating
instructions.
Save These Instructions — Save all safety and operating instructions for future
reference.
Heed Warnings — Read carefully and follow all warning labels on the product and
those described in the instructions.
Follow Instructions — Follow all instructions provided with this product.
Cleaning — Always unplug this product from the wall outlet before cleaning. Use
only a damp cloth for cleaning. Never use any type of liquid or aerosol cleaner,
or any type of organic solvent to clean this product.
Attachments — For your safety, and to avoid damaging the product, use only
accessories recommended by Olympus.
Water and Moisture — Never use this product around water (near a bathtub,
kitchen sink, laundry tub, wet basement, swimming pool or in the rain). For
precautions on products with weatherproof designs, read the weatherproofing
sections of their manuals.
6
Safety Precautions
Location — To avoid damage to the product and prevent personal injury, never
place this product on an unstable stand, tripod, bracket, table or cart. Mount
only on a stable tripod, stand, or bracket. Follow the instructions that describe
how to safely mount the product, and use only the mounting devices
recommended by the manufacturer.
Power Sources — Connect this product only to the power source described on
the product label. If you are not sure about the type of power supply in your
home, consult your local power company. Refer to your operating instructions
for information on using the product with a battery.
Grounding, Polarization — If this product can be used with a specified AC
adapter, the adapter may be equipped with a polarized alternating current line
plug (a plug with one blade wider than the other). This safety feature allows the
plug to fit into the power outlet only one way. If you cannot insert the plug into
the wall outlet, pull it out, reverse it, and then reinsert it. If the plug still fails to
fit, contact an electrician and have the receptacle replaced.
Protecting the Power Cord — The power supply cord should be placed so it will
not be walked on. Never put a heavy object on the power cord or wrap it around
the leg of a table or chair. Keep the area around the power cord connection
points, at the power outlet, and at the product connection, free of all AC adapter
or accessory power cords.
Lightning — If a lightning storm occurs while using a specified AC adapter,
remove it from the wall outlet immediately. To avoid damage from unexpected
power surges, always unplug the AC adapter from the power outlet and
disconnect it from the camera when the camera is not in use.
Overloading — Never overload wall outlets, extension cords, power strips, or
other power connection points with too many plugs.
Foreign Objects, Liquid Spillage — To avoid personal injury caused by fire or
electrical shock from contact with internal high voltage points, never insert a
metal object into the product. Avoid using the product where there is a danger
of spillage.
Heat — Never use or store this product near any heat source such as a radiator,
heat register, stove, or any type of equipment or appliance that generates heat,
including stereo amplifiers.
Servicing — Refer all servicing to qualified personnel. Attempting to remove the
covers or disassemble the product, could expose you to dangerous high
voltage points.
En
7
Safety Precautions
Damage Requiring Service — If you notice any of the conditions described below
while using a specified AC adapter, unplug it from the wall outlet and refer
servicing to qualified service personnel:
a) Liquid has been spilled onto the product or some other object has fallen into
the product.
b) The product has been exposed to water.
c) The product does not operate normally despite following operating
instructions. Adjust only the controls described in the operating instructions
as improper adjustment of other controls could damage the product and
require extensive repair work by a qualified technician.
d) The product has been dropped or damaged in any way.
e) The product exhibits a distinct change in performance.
Replacement Parts — When replacement parts are required, make sure that the
service center uses only parts with the same characteristics as the originals, as
recommended by the manufacturer. Unauthorized substitution of parts could
En
result in fire, electrical shock, or create other hazards.
Safety Check — Upon completion of servicing or repairs, ask the service
technician to perform safety checks to determine that the product is in good
working order.
Legal and other notices
• Olympus makes no representations or warranties regarding any damages, or
benefit expected by using this unit lawfully, or any request from a third person,
which are caused by the inappropriate use of this product.
• Olympus makes no representations or warranties regarding any damages or
any benefit expected by using this unit lawfully which are caused by erasing
picture data.
Disclaimer of Warranty
• Olympus makes no representations or warranties, either expressed or implied,
by or concerning any content of these written materials or software, and in no
event shall be liable for any implied warranty of merchantability or fitness for any
particular purpose or for any consequential, incidental or indirect damages
(including but not limited to damages for loss of business profits, business
interruption and loss of business information) arising from the use or inability to
use these written materials or software or equipment. Some countries do not
allow the exclusion or limitation of liability for consequential or incidental
damages, so the above limitations may not apply to you.
• Olympus reserves all rights to this manual.
8
Safety Precautions
WARNING
Unauthorized photographing or use of copyrighted material may violate applicable
copyright laws. Olympus assumes no responsibility for unauthorized
photographing, use or other acts that infringe upon the rights of copyright owners.
Copyright Notice
All rights reserved. No part of these written materials or this software may be
reproduced or used in any form or by any means, electronic or mechanical,
including photocopying and recording or the use of any type of information storage
and retrieval system, without the prior written permission of Olympus. No liability
is assumed with respect to the use of the information contained in these written
materials or software, or for damages resulting from the use of the information
contained therein. Olympus reserves the right to alter the features and contents of
this publication or software without obligation or advance notice.
Trademarks
• IBM is a registered trademark of International Business Machines Corporation.
• Microsoft and Windows are registered trademarks of Microsoft Corporation.
• Macintosh is a trademark of Apple Computer Inc.
• All other company and product names are registered trademarks and/or
trademarks of their respective owners.
• The standards for camera file systems referred to in this manual are the “Design
Rule for Camera File System/DCF” standards stipulated by the Japan
Electronics and Information Technology Industries Association (JEITA).
En
9
UNPACKING THE BOX CONTENTS
If you find any contents missing or damaged, contact the place of purchase.
En
Digital CameraLens Cap/
Card
USB CableAV Cable
Lens Cap String
Lithium Ion Battery (BLM-1)
Strap
Lithium Ion Battery Charger
(BCM-2)
OLYMPUS Master CD-ROM
Warranty CardRegistration Card
Basic Manual (this manual)
Advanced Manual (CD-ROM)
Contents vary depending on the area where you purchased this camera.
10
UNPACKING THE BOX CONTENTS
Attaching the strap and lens cap
Attach the lens cap string to the
1
lens cap.
Pull the ends of the strap out of the
2
stopper and ring.
Stopper
Pass the lens cap string through the strap, and attach the strap
3
to the camera.
Â
Ring
En
Strap
eyelet
Note
Be careful when carrying the camera by the strap, as it can easily catch on
stray objects, causing injury or damage.
Follow the steps, and attach the strap correctly. Olympus is not responsible
for any damages resulting from the strap coming loose due to incorrect
attachment.
11
CHARGING THE BATTERY
The battery is not fully charged at the time of purchase. Charge the
battery fully with the BCM-2 charger before use.
Connect the power cable.
1
En
BCM-2 battery
charger
n
Power cable
AC wall outlet
o
Insert the battery into the charger.
2
Remove the protection cap.
mark
Protection cap
Charging indicator
mark
TIPS
The BLM-1 battery usually takes approximately 5 hours to charge.Meaning of the charging indicator:
This camera uses one Olympus BLM-1 lithium ion battery. No other type of
battery can be used.
Attach the protection cap when transporting or storing the battery.The charger can be used within the range of AC 100 V to AC 240 V (50/60
Hz). When using the charger abroad, you may need a plug adapter to convert
the plug to the shape of the AC wall outlet. For details, ask at your local
electrical shop or travel agent.
Do not use travel voltage converters as they could damage your charger.
12
LOADING THE BATTERY
Make sure the power switch is set to OFF.
1
Battery compartment cover
Power switch
Open the battery compartment cover.
2
Slide the battery
n
compartment lock
from = to ).
Insert the battery.
3
Battery lock
knob
The battery lock secures the
battery when correctly loaded.
Lift
o
To remove the battery
Press the battery lock knob in
the direction of the arrow to
release the battery. Turn the
camera upright, and let the
battery fall into your hand.
Battery lock knob
En
13
LOADING THE BATTERY
Close the battery compartment cover.
4
o
The battery
Note
En
Power consumption by the camera varies depending on which functions are
used.
Power is consumed continuously during the conditions described below
causing the battery to become exhausted quickly.
Using an exhausted battery may cause the camera to turn off without
displaying the battery level warning.
Close
n
Slide the battery
compartment lock
from ) to =.
The monitor is turned on.The monitor is on in playback mode for an extended period of time.The zoom is used repeatedly.The shutter button is pressed halfway repeatedly in shooting mode,
activating the auto focus.
The fulltime AF is turned on.The camera is connected to a computer or printer.
14
INSERTING A CARD
Make sure the power switch is set to OFF.
1
Open the card cover.
2
Insert a card.
3
Notch
Contact
Insert the card into the rear
slot while keeping it straight.
The slot clicks when the card
is inserted fully.
En
Card cover
To remove the card
Push the card and release. The
1
2
card ejects slightly from the slot.
Grasp the end, and remove.
15
INSERTING A CARD
Note
Inserting the card incorrectly can cause the contacts to become
damaged or the card can become stuck.
The card may not record properly if it is not inserted all the way in.Releasing your finger quickly after pushing the card all the way in may
cause it to eject forcefully out of the slot.
Close the card cover.
4
The card
The cards that can be used with this camera are the xD-Picture Card (16
to 512 MB), CompactFlash, and Microdrive.
En
An xD-Picture Card is supplied.
Index area
You can use this space to write the contents of the card.
Contacts
The part where the data transferred from the camera
enters the card.
Note
This camera may not recognize a non-Olympus card or a card that was
formatted on another device (e.g. computer). Make sure to format the card on
this camera before use.
Do not push the card in with a pen or similar hard or pointed object.Never open the battery compartment cover or card cover, or remove the
battery or card while the camera is turned on. Doing so could destroy the data
stored on the card. Once destroyed, data cannot be restored.
Do not stick labels on the card as this could prevent the card from being
ejected.
16
TURNING THE CAMERA ON
Remove the lens cap.
1
Pull the monitor out and rotate it.
2
ÂÂ
En
17
TURNING THE CAMERA ON
F2.8
1/1000
0.0
3072 2304
HQ
Set the mode dial to P, and turn the power switch
on.
3
Set ON to (.
En
Battery check indicator
Shooting mode
F2.8
1/1000
P
HQ
3072 2304
Note
To save battery power, the camera automatically enters the sleep mode and
stops operating after about 3 minutes of non-operation. The camera activates
again as soon as you operate the shutter button or zoom lever.
4 hours after the camera enters sleep mode, the camera retracts the lens and
turns off automatically. Turn the camera on to use.
If the camera is continuously used for a long period of time, the internal
temperature of the camera may rise. In such cases, the power may
automatically turn off. Please wait before using again.
0.0
303030
The monitor turns on and the lens
extends.
18
TURNING THE CAMERA ON
When you first turn on the camera
Setting the date and time
The first time you use the camera, [Y/M/D]
is displayed prompting you to set the date
and time. See “Setting the date and time” in
Chapter 7 of the Advanced Manual. The
camera can be operated without making
this setting.
Y/M/D
Languages available on the camera
Available languages may vary according to
where you purchased the camera. The
instructions given in this manual and the
Advanced Manual apply to the camera
screens in English. See “Selecting a
language” in Chapter 7 of the Advanced
Manual.
SELECT
ENGLISH
FRANCAIS
ESPAÑOL
PORTUGUES
GO
Battery power
The battery check indicator changes according to how much power is
remaining.
ef
Lit (green)
(Disappears after a while)
Ready to shoot.
Blinking (red)
The battery needs charging
soon.
[BATTERY EMPTY]
is displayed.
No power is left. Charge the
battery.
En
OK
19
TAKING A PICTURE
F2.8
1/1000
0.0
3072 2304
HQ
1/1000
F2.8
0.0
3072 2304
HQ
Compose the picture.
1
AF target mark
Shutter button
Card access lamp
En
2
P
HQ
1/1000
3072 2304
0.0
303030
F2.8
Focus on your subject.
Green lamp
# mark
1/1000
F2.8
0.0
303030
HQ
3072 2304
Position the AF target mark on your
subject using the monitor.
Press the shutter button halfway and
hold.
The green lamp lights when the
focus and exposure are locked.
(Focus lock)
The # mark lights when the flash is
about to fire.
The AF target mark moves to the
focus position.
The monitor displays the shutter
speed and aperture determined by
the camera.
20
Take the picture.
1/1000
F2.8
0.0
3072 2304
HQ
3
TAKING A PICTURE
Press the shutter button fully.
1/1000
F2.8
0.0
HQ
3072 2304
Note
Press the shutter button gently. If it is pressed forcefully, the camera may
move causing the pictures to blur.
Never open the battery compartment cover, remove the battery or disconnect
the AC adapter while the card access lamp is blinking. Doing so could destroy
stored pictures or prevent storage of pictures you have just taken.
Recorded pictures are saved on the card regardless of whether the camera
is turned off or the battery is replaced or removed.
When taking pictures against strong backlight, the area of the picture in
shadow may appear colored.
303030
The card access lamp blinks while
the picture is recorded onto the card.
Memory gauge
Memory gauge
When the shutter button is pressed, the memory gauge lights and the
picture is recorded to the card. The memory gauge changes according to
the current status. This indicator is not displayed while recording movies.
ShootShootShoot
abcd
Before taking
any pictures
(Off)
After taking one
(Lit)
After taking
several pictures
(Lit)
Wait
Maximum reached
(All lit)
Wait until the indicator
turns off again before
taking more pictures.
En
21
REVIEWING A PICTURE
HQ
11 15
30 3030
100
0030
Press the QUICK VIEW button.
1
Arrow pad
100
-
’0404.
1212.
0030
11 15
:
30
En
Use the arrow pad to display the picture you want.
2
HQ
10 pictures back
Control dial
QUICK VIEW button
You can display the last picture you
took while staying in any shooting
mode.
Press the QUICK VIEW button
again or press the shutter button
lightly when you are ready to take
another picture.
22
The control dial can also be used
Turn left:
Displays the previous picture.
10 pictures forward
Next picturePrevious picture
to select pictures.
Turn right:
Displays the next picture.
TURNING THE CAMERA OFF
Turn the power switch off.
1
Set OFF to (.
The monitor turns off.The lens retracts.
Close the monitor.
2
Now that you have mastered how to shoot and
play, refer to the Advanced Manual for additional
camera features and applications.
And to get the most out of your digital images, be
sure to install the OLYMPUS Master software on
the supplied CD-ROM for enhanced editing,
storing, and sharing of your images.
Turn the monitor face down to keep
it protected.
En
23
Specifications
Camera
Product type: Digital camera (for shooting and playback)
