Nokia Asha 306 User Guide

Nokia 306 User Guide

Issue 1.0

2Contents

Contents

Safety 4

Get started 5

Keys and parts 5
Insert a SIM card and battery 6
Insert or remove a memory card 8
Charge the battery 9
Charge the battery over USB 10
Switch the phone on or off 10
GSM antenna 10
Connect a headset 11
Attach a strap 11

Basic use 11

Your touch screen phone 11
Support 14
Access codes 15
Lock the keys and screen 15
Copy contacts and other stuff from
your old phone 15
Use your phone without a SIM card 16

Calls 16

Make a call 16
Divert calls to your voice mailbox or
another phone number 16
Make a conference call 17

Contacts 18

Save a name and phone number 18
Use speed dial 18
Send your contact info 18

Messaging 19

Send a message 19
Read a received message 19

Write text 20

Write text using the on-screen
keypad 20
Use the on-screen keyboard 21
Use predictive text 22

Connectivity 23

Bluetooth 23
USB data cable 24
WLAN connections 25

Clock and calendar 26

Change the time and date 26
Set an alarm 26
Browse your calendar in different
views 26
Add a calendar entry 26

Photos and videos 26

Take a photo 27
Record a video 27
Send a photo or video 27
Organise files 28

Music and audio 28

Play a song 28
FM radio 28

Phone management 30

Update phone software using your
phone 30
Update phone software using your
PC 31
Restore original settings 31
Back up your photos and other
content to a memory card 31

Web 32

About the web browser 32
Browse the web 32
Clear your browsing history 32

Maps 33

About Maps 33
Search for a place 33

Product and safety information 33

Contents 3

4Safety

Safety

Read these simple guidelines. Not following them may be dangerous or illegal. For
further info, read the complete user guide.

SWITCH OFF IN RESTRICTED AREAS

Switch the device off when mobile phone use is not allowed or when it may
cause interference or danger, for example, in aircraft, in hospitals or near
medical equipment, fuel, chemicals, or blasting areas. Obey all instructions
in restricted areas.

ROAD SAFETY COMES FIRST

Obey all local laws. Always keep your hands free to operate the vehicle while
driving. Your first consideration while driving should be road safety.

INTERFERENCE

All wireless devices may be susceptible to interference, which could affect
performance.

QUALIFIED SERVICE

Only qualified personnel may install or repair this product.

BATTERIES, CHARGERS, AND OTHER ACCESSORIES

Use only batteries, chargers, and other accessories approved by Nokia for
use with this device. Do not connect incompatible products.

KEEP YOUR DEVICE DRY

Your device is not water-resistant. Keep it dry.

PROTECT YOUR HEARING

To prevent possible hearing damage, do not listen at high volume levels for
long periods. Exercise caution when holding your device near your ear while
the loudspeaker is in use.

Get started

Keys and parts

1 Earpiece
2 Screen
3 Call key
4 Microphone
5 Charger connector
6 Micro-USB connector
7 Headset connector (Nokia AV connector 3.5 mm)
8 Volume up/Zoom in key
9 Volume down/Zoom out key
10 Lock key
11 End/Power key

Get started 5

12 Camera lens. Before using the camera, remove the protective tape from the lens.
13 Memory card slot
14 Loudspeaker

6 Get started

Insert a SIM card and battery

Note: Switch the device off and disconnect the charger and any other device before

removing any covers. Avoid touching electronic components while changing any
covers. Always store and use the device with any covers attached.

Important: This device is designed to be used with a standard SIM card (see figure)
only. Use of incompatible SIM cards may damage the card or the device, and may
corrupt data stored on the card. Please consult your mobile operator for the use of
a SIM card that has a mini-UICC cutout.

Important: To prevent damage to the SIM card, always remove the battery before
you insert or remove the card.

This phone is intended for use with a BL-4U battery. Always use original Nokia
batteries.

The SIM and its contacts can be easily damaged by scratches or bending, so be careful
when handling, inserting, or removing the card.

1 Put your fingernail in the gap on the right edge of the phone, then carefully lift

and remove the back cover (1).

2 If the battery is in the phone, lift it out (2).

Get started 7

3 Slide the SIM under the metal tab (3). Make sure the contact area of the card is

face down and the tab holds the SIM in place (4).

4 Line up the battery contacts, push the battery in (5), then replace the back cover

(6).

8 Get started

Insert or remove a memory card

Use only compatible microSD cards approved by Nokia for use with this device.
Incompatible cards may damage the card and the device and corrupt data stored on
the card.

Your phone supports memory cards with a capacity of up to 32 GB.

You can insert or remove the memory card without switching the phone off.

Insert a memory card

1 Use your fingernail to open the cover of the memory card slot.
2 Push the memory card in with the contact area face up until it locks into place.
3 Close the cover of the memory card slot.

Get started 9

Remove the memory card

Important: Do not remove the memory card when an app is using it. Doing so may

damage the memory card and the device and corrupt data stored on the card.

1 Open the memory card slot cover.
2 Push the card in until it's free, then pull it out.

3Close the cover.

Charge the battery

Your battery has been partially charged at the factory, but you may need to recharge
it before you can switch on your phone for the first time. If the phone indicates a low
charge, do the following:

1 Connect the charger to a wall outlet.
2 Connect the charger to the phone.
3 When the phone indicates a full charge, disconnect the charger from the phone,

then from the wall outlet.

You do not need to charge the battery for a specific length of time, and you can use
the phone while it is charging.

If the battery is completely discharged, it may take several minutes before the
charging indicator is displayed or before any calls can be made.

10 Get started

If the battery has not been used for a long time, to begin charging, you may need to
connect the charger, then unplug and reconnect it.

Charge the battery over USB

Battery low, but you don't have a charger with you? You can use a compatible USB
cable to connect to a compatible device, such as a computer.

To avoid breaking the charger connector, be careful when connecting or
disconnecting the charger cable.

You can use USB charging when a wall outlet is not available. Data can be transferred
while charging the device. The efficiency of USB charging power varies significantly,
and it may take a long time for charging to start and the device to start functioning.

Switch the phone on or off

Press and hold the power key

until the phone vibrates.

You may be prompted to get the configuration settings from your network service
provider. For more information on this network service, contact your network service
provider.

GSM antenna

The figure shows the GSM antenna area marked in grey.

Basic use 11

Avoid touching the antenna area while the antenna is in use. Contact with antennas
affects the communication quality and may reduce battery life due to higher power
level during operation.

Connect a headset

Do not connect products that create an output signal, as this may damage the device.
Do not connect any voltage source to the Nokia AV connector. If you connect an
external device or headset, other than those approved by Nokia for use with this
device, to the Nokia AV connector, pay special attention to volume levels.

Attach a strap

Straps may be available separately.

Basic use

Your touch screen phone
Change settings quickly

Rather than going into the phone menus, in most views, you can quickly change some
settings by swiping down from the top of the screen.

12 Basic use

You can:

• See if you have missed calls or unread messages

• Change the profile, for example, to silence your phone

• Open the music player, for example, to pause the currently playing song

• Open or close mobile data internet connections

• Check for WLAN networks, and connect to them

• Switch Bluetooth on or off

Use the touch screen

To use your phone, tap or tap and hold the touch screen.

Open an app or item

Tap the app or item.

Tap and hold to see more options

Place your finger on an item until the menu opens.
