Nec XP3791, XM3761 user manual

R

37

Xtra

37

Xtra

79TH1624
Printed in Japan

Itasca, Illinois 60143-1248
1250 N. Arlington Heights Road, Suite 500

NEC Technologies, Inc.

1993 by NEC Technologies, Inc.
NEC is registered trademark of NEC Corporation.
MultiSync is a registered trademark of NEC Technologies, Inc. in the U.S.A.

R

37

Xtra

Multimedia Monitor

User's Manual

37

Xtra

R

1

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO

NOT REMOVE COVER. NO USER-SERVICEABLE
PARTS INSIDE. REFER SERVICING TO QUALIFIED
SERVICE PERSONNEL.

This symbol warns the user that uninsulated voltage within the unit may
have sufficient magnitude to cause electric shock. Therefore, it is danger­ous to make any kind of contact with any part inside of this unit.

This symbol alerts the user that important literature concerning the opera­tion and maintenance of this unit has been included. Therefore, it should
be read carefully in order to avoid any problems.

WARNING

TO PREVENT FIRE OR SHOCK HAZARDS, DO NOT EXPOSE THIS UNIT TO
RAIN OR MOISTURE. ALSO DO NOT USE THIS UNIT'S POLARIZED PLUG
WITH AN EXTENSION CORD RECEPTACLE OR OTHER OUTLETS, UNLESS
THE PRONGS CAN BE FULLY INSERTED. REFRAIN FROM OPENING THE
CABINET AS THERE ARE HIGH-VOLTAGE COMPONENTS INSIDE. REFER
SERVICING TO QUALIFIED SERVICE PERSONNEL.

DOC compliance Notice

This Class B digital apparatus meets all requirements of the Canadian
Interference-Causing Equipment Regulations.

WARNING

This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in
a residential installation. This equipment generates, uses, and can radiate
radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.

• Consult the dealer or an experienced radio / TV technician for help.

As an E

NERGY STAR ® partner, NEC Technologies has determined that this product

meets the E

NERGY STAR is a U.S. registered mark.

E

NERGY STAR ® guidelines for energy efficiency.

Warnings and Safety Precaution

The NEC MultiSync Multimedia monitors XP37 Xtra and XM37 Xtra are de­signed and manufactured to provide long, trouble-free service. No mainte­nance other than cleaning is required. Use a soft cloth and if necessary, mild
detergent. Do not use commercial spray cleaners which may damage the
surface. In case of damage, arrange for repairs at an authorized NEC Ser­vice Center.

For operating safety and to avoid damage to the unit, read carefully and
observe the following instructions.

To avoid shock and fire hazards:

1. Provide adequate space for ventilation to avoid internal heat build-up.
Do not cover rear vents or install in a closed cabinet or shelves.
The unit is equipped with cooling fans on the top. If you enclose the unit in
a cabinet or rack, be sure there is adequate space at the top and rear of
the unit to allow heated air to rise and escape. A cabinet or shelves in
which the unit is placed must be maintained below 40°C

2. Do not use the power cord polarized plug with extension cords or outlets
unless the prongs can be completely inserted.

3. Do not expose unit to rain or moisture.

4. Avoid damage to the power cord, and do not attempt to modify the
power cord. Do not place the unit on the power cord. Damage to the
cord may cause shock or fire.

Handle the power cord carefully and avoid excessive bending. A
damaged cord can cause electric shock or fire.

5. Unplug unit during electrical storms or if unit will not be used over a long
period.

6. Do not open the cabinet which has potentially dangerous high voltage

components inside. If the unit is damaged in this way the warranty will be
void. Moreover, there is a serious risk of electric shock.

7. Do not attempt to service or repair the unit. NEC is not liable for any bodily
harm or damage caused if unqualified persons attempt service or open
the back cover. Refer all service to authorized NEC Service Centers.

To avoid damage and prolong operating life:

1. Use only with 100-120V/220-240V 50/60Hz AC power supply. Continued
operation at line voltages other than 100-120V/220-240 Volts
shorten the life of the unit, and might even cause a fire hazard.

2. Handle the unit carefully when moving and do not drop.

3. Locate set away from heat, excessive dust, and direct sunlight.

4. Protect the inside of the unit from liquids and small metal objects. In case
of accident, unplug the unit and have it serviced by an authorized NEC
Service Center.

5. Unplug unit before cleaning. Use only a soft cloth and mild detergent.
Commercial household sprays and cleaners may damage the CRT sur­face and cabinet.

7. Do not place liquids on top of the unit. If liquid has been spilled into the
unit, unplug the unit and have it serviced by an authorized NEC Service
Center.

8. This unit is designed for indoor installation use only. Do not use the unit
for purposes other than originally intended.

9. Do not use the unit on an unstable surface.

10.Do not set the unit on end when in use or stock.

11.Rest your eyes periodically.

AC will

2

ATTENTION

RISQUE D’ELECTROCUTION

NE PAS OUVRIR

MISE EN GARDE: AFIN DE REDUIRE LES RISQUES D’ELECTRO-

CUTION, NE PAS DEPOSER LE COUVERCLE, IL
N’Y A AUCUNE PIECE UTILISABLE A L’INTERIEUR
DE CET APPAREIL. NE CONFIER LES TRAVAUX
D’ENTRETIEN QU’A UN PERSONNEL QUALIFIE.

Ce symbole a pour but de prévenir l’utilisateur de la présence
d’une tension dangereuse, non isolée se trouvant à l’intérieur de
l’appareil. Elle est d’une intensité suffisante pour constituer un
risque d’électrocution. Eviter le contact avec les pièces à
l’intérieur de cet appareil.

Ce symbole a pour but de prévenir l’utilisateur de la présence
d’importantes instructions concernant l’entretien et le
fonctionnement de cet appareil. Par conséquent, elles doivent
être lues attentivement afin d’éviter des problèmes.

AVERTISSEMENT

AFIN DE REDUIRE LES RISQUES D’INCENDIE OU D’ELECTROCUTION, NE PAS
EXPOSER CET APPAREIL A LA PLUIE OU A L’HUMIDITE. AUSSI, NE PAS
UTILISER LA FICHE POLARISEE AVEC UN PROLONGATEUR OU UNE AUTRE
PRISE DE COURANT SAUF SI CES LAMES PEUVENT ETRE INSEREES A FOND.
NE PAS OUVRIR LE COFFRET, DES COMPOSANTS HAUTE TENSION SE
TROUVENT A L’INTERIEUR. LAISSER A UN PERSONNEL QUALIFIE LE SOIN DE
REPARER CET APPAREIL.

DOC avis de conformation

Cet appareil numérigue de la classe B respecte toutes les exigences du
Réglement sur le Matériel Brouilleur du Canada.

Mises en garde et précautions de sécurité

Les moniteurs MultiSync Multimédia XP37 Xtra et XM37 Xtra de NEC ont été
conçus et fabriqués pour assurer une longue durée de service sans
problèmes. Aucun entretien à l’exception du nettoyage n’est nécessaire.
Utiliser un chiffon doux et un détergent doux, si nécessaire. Ne pas utiliser
des aérosols de nettoyage du commerce qui risquent d’endommager la
surface de cet appareil. Si l’appareil est endommagé, confier les travaux
de réparation à un centre de service agréé NEC.

Pour un fonctionnement sûr et afin d’éviter d’endommager l’appareil, lire
attentivement et respecter les instructions suivantes.

Afin d’éviter tout risque d’électrocution et d’incendie:

1. Réserver un espace libre suffisant pour la ventilation afin d’éviter une
accumulation de chaleur interne. Ne pas couvrir les trous d’aération
arrière ou installer l’appareil dans un coffret fermé ou sur une étagère.

L’appareil est équipé d’ailettes de refroidissement sur le dessus. Si l’appareil

est logé dans un coffret ou sur une étagère, s’assurer qu’il y a un espace
libre suffisant pour la dissipation de la chaleur. Si l’appareil est posé sur un
coffret ou une étagère, la température doit être maintenue en dessous
de 40°C.

2. Ne pas utiliser la fiche polarisée du cordon d’alimentation avec des
prolongateurs ou des prises de courant, sauf si les lames peuvent être
insérées à fond.

3. Ne pas exposer à la pluie ou à l’humidité.

4. Eviter d’endommager le cordon d’alimentation, et ne pas modifier le
cordon d’alimentation.Ne pas poser l’appareil sur le cordon
d’alimentation. Des dommages sur le cordon pourrait provoquer une
électrocution ou un incendie.

Manipuler le cordon d’alimentation avec soin et éviter de le plier
excessivement. Un cordon endommagé peut provoquer une
électrocution ou un incendie.

5. Débrancher l’appareil pendant les tempêtes ou si l’appareil n’est pas
utilisé pendant une longue période.

6. Ne pas ouvrir le coffret. Des composants de haute tension se trouvent à
l’intérieur. Si l’appareil est endommagé de cette manière, la garantie
devient caduque. De plus, il y a risque d’électrocution.

7. Ne pas essayer de réparer ou entretenir l’appareil soi-même. NEC ne
saura être tenu pour responsable pour toute blessure ou dommage causé
par des personnes non qualifiées qui essayent de réparer ou d’ouvrir le
couvercle arrière. Confier toute réparation à un centre de service agréé
NEC.

Pour éviter des dommages et prolonger la durée de service de l’appareil:

1. N’utiliser qu’une source d’alimentation de 100-120 V/220-240V 50/60 Hz
CA. Le fait d’utiliser l’appareil en continu à des tensions de ligne
supérieures à 100-120/220-240 Volts CA réduit sa durée de vie et risque de
provoquer un incendie.

2. Manipuler l’appareil avec soin pendant son déplacement et ne pas le
faire tomber.

3.

Eloigner l’appareil des endroits chauds, très poussiéreux et exposés en plein soleil.

4. Eviter que des liquides et des petits objets métalliques pénètrent à
l’intérieur de l’appareil. En cas d’accident, débrancher l’appareil et le
confier à un centre de service agréé NEC.

5. Débrancher l’appareil avant le nettoyage. Utiliser seulement un chiffon
doux et un détergent doux.
Des aérosols et produits de nettoyage disponibles dans le commerce
risquent d’endommager l’écran et le coffret.

6. Ne pas empiler les unités les unes sur les autres, afin

endommager.

7. Ne pas poser de liquides sur l’appareil. Si du liquide se répand dans
l’appareil, débrancher l’appareil et le faire réparer par un centre de
réparation agrée NEC.

8. Cet appareil est conçu uniquement pour une installation en intérieur. Ne
pas utiliser cet appareil dans des conditions autres que celles initialement
spécifiées.

9. Ne pas utiliser l’appareil sur une surface instable.

10.Ne pas mettre l’appareil sur fin lorsqu’il est en marche ou en train de
mémoriser.

11.Reposez vos yeux périodiquement.

d’éviter de les

3

LIMITED WARRANTY

NEC Multimedia Monitor Products

NEC Technologies, Inc.(hereafter NECTECH)warrants this product to be free from
defects in material and workmanship under the following terms.

HOW LONG IS THE WARRANTY

Parts and labor are warranted for (1) One Year and CRT’s for (1) One year from the
date of the first customer purchase.

WHO IS PROTECTED

This warranty may be enforced only by the first purchaser.

WHAT IS COVERED AND WHAT IS NOT COVERED

Except as specified below, this warranty covers all defects in material or workmanship
in this product. The following are not covered by the warranty:

1. Any product which is not distributed in the U.S.A. Canada, and Mexico by
NECTECH or which is not purchased in the U.S.A. Canada, and Mexico from an
authorized NECTECH dealer.
If you are uncertain as to whether a dealer is authorized, please contact NECTECH
at 800-836-0655. Any questions or problems you have with our XP37Xtra/
XM37Xtra, contact NECTECH at 800-836-0655.

2. Any product on which the serial number has been defaced, modified or removed.

3. Damage, deterioration or malfunction resulting from:

• Accident, misuse, abuse, neglect, fire, water, lightning or other acts of nature,

unauthorized product modification, or failure to follow instructions supplied with

the product.

•Repair or attempted repair by anyone not authorized by NECTECH.

•Any shipment of the product (claims must be presented to the carrier).

•Removal or installation of the product.

•Any other cause which does not relate to a product defect.

•Burns or residual images upon the phosphor of the tubes.

4. Cartons, carrying cases, batteries, external cabinets, magnetic tapes, or any
accessories used in connection with the product.

WHAT WE WILL PAY FOR AND WHAT WE WILL NOT PAY FOR

We will pay labor and material expenses for covered items, but we will not pay for the
following:

1. Removal or installation charges.

2. Costs of initial technical adjustments(set-up), including adjustment of user controls.
These costs are the responsibility of the NECTECH dealer from whom the product
was purchased.

3. Payment of shipping charges.

HOW YOU CAN GET WARRANTY SERVICE

1. To obtain service on your product, consult the dealer from whom you purchased the
product, or ship it prepaid to any authorized NECTECH service center.

2. Whenever warranty service is required, the original dated invoice (or a copy) must be
presented as proof of warranty coverage, and should be included in any shipment of
the product. Please also include in any mailing, your name, address and a description

of the problem(s). Failure to comply with NECTECH Service Procedures may cause a

delay in repairing the unit.

3. For the name of the nearest NECTECH authorized service center, call NECTECH
at 800-836-0655.

LIMITATION OF IMPLIED WARRANTIES

All implied warranties, including warranties of merchantability and fitness for a
particular purpose, are limited in duration to the length of this warranty.

EXCLUSION OF DAMAGES

NECTECH’s liability for any defective product is limited to the repair or replacement
of the product at our option. NECTECH shall not be liable for:

1. Damage to other property caused by any defects in this product, damages based
upon inconvenience, loss of use of the product, loss of time, commercial loss; or

2. Any other damages whether incidental, consequential or otherwise. Some states do
not allow limitation on how long an implied warranty lasts and/or do not allow the
exclusion or limitation of incidental or consequential damages, so the above
limitations and exclusions may not apply to you.

HOW STATE LAW RELATES TO THE WARRANTY

This warranty gives you specific legal rights, and you may also have other rights which
vary from state to state.

FOR MORE INFORMATION, TELEPHONE [phone]

NEC TECHNOLOGIES, INC.
1250 N. Arlington Heights Road, Suite 500
Itasca. Illinois 60143-1248

NOTE: All products returned to NECTECH for service MUST have prior approval.
To get approval, call NEC Technologies at 800-836-0655.

4

CONTENTS

1. Introduction

Introduction to the MultiSync XP37 Xtra/XM37 Xtra .............................................................. 1

Feature Highlights ...................................................................................................................... 1

2. Part Names and Functions

Front View / Rear View ............................................................................................................. 3

Terminal Board ........................................................................................................................... 5

Remote Control Unit ............................................................................................................... 11

Battery Installation and Replacement / Remote Control Cautions / Operating Range ................

Functions of DIP SW ................................................................................................................. 17

3. Installation

Wiring Diagram ........................................................................................................................ 19

Connecting Your PC or Macintosh Computer .................................................................... 21

Connecting Your VCR or Laser Disc Player .......................................................................... 22

Connecting Your Document Camera.................................................................................. 22

Connecting Your NEC IPS 4000 Image Processor ................................................................ 22

Daisy-chaining Your monitors ................................................................................................ 23

D-Sub 15 Pin RGB Signal Composition .................................................................................. 24

External Speaker Connections .............................................................................................. 25

4. Operation

Power/General Controls/Degaussing ................................................................................... 27

Using OSM Controls ................................................................................................................. 28

Direct Control Screen ............................................................................................................. 29

Accessing OSM........................................................................................................................ 32

15

OSM Menus .............................................................................................................................. 32

Visual Controls Group ............................................................................................................. 32

H-position/H-width/Pin-cushion Controls Group .................................................................. 33

V-position/V-height/V-linearity Controls Group ................................................................... 33

Keystone/Tilt/Rotation/Scan Select Controls Group ........................................................... 34

RGB Controls Group ................................................................................................................ 35

OSM Location/OSM Turn Off Time Control ........................................................................... 35

Source Information .................................................................................................................. 36

DV Controls Group .................................................................................................................. 36

Volume Control ....................................................................................................................... 37

Reset Control ........................................................................................................................... 37

OSM System Control Menu .................................................................................................... 39

PC/External Control Function ................................................................................................ 42

Command Reference ............................................................................................................ 44

5. Troubleshooting ............................................................................................................. 45

6. Specifications ................................................................................................................ 47

7. Timing Charts

Input Signal Reference Chart ................................................................................................ 53

Typical Input Signal Timing .....................................................................................................57

Signal Identification for Raster Preset.................................................................................... 61

8. Service and Support ..................................................................................................... 63

This manual covers both the XP37 Xtra and the XM37 Xtra multimedia monitors. The operating
procedures are common to both models.

5

79644641

POWER

ON

RGB 2RGB 1VIDEO 2VIDEO 1

POSITION/CONTROL PROCEED

EXIT

SCAN

NORMALSIDE PINHEIGHTWIDTH

BRIGHT

CONTRAST

MUTE

NORMAL

VOLUME

OFFDEGAUSS

MULTIMEDIA MONITOR
RD-346E

OSM and IPM are trademarks of NEC Technologies, Inc.
IBM PC/AT, PS/2, VGA, S-VGA, 8514/A and XGA are registered
trademarks of International Business Machines Corporation.
Apple and Macintosh are registered trademarks of Apple Computer,
Inc.
Microsoft is a registered trademark of Microsoft Corporation. Windows is
a trademark of Microsoft Corporation.

Introduction

Introduction to the MultiSync XP37 Xtra/XM37 Xtra
Monitor

This section introduces you to your new MultiSync XP37 Xtra/XM37 Xtra
monitor, provides a list of materials that comes with your monitor and
describes the features and controls.

The features you’ll enjoy include:

•Simple controls

Let you make all necessary adjustments and selections with one
button simplicity from the remote control.

•37” CRT(36” viewable image size)

• True displayable 1024 x768 resolution

1

• Flexible inputs
Connect up to four different inputs at once and switch among them
with a touch of a button to seamlessly integrate information from a
computer and VCR into one presentation.

• Signal loop-through
Lets you run up to 2 monitors from one source, which can greatly
simplify connections and reduce hardware requirements.

• Attractive cabinets
A sleek, sophisticated cabinet design complements your presentation
environment and enhances the professionalism of your presentations.

• Microsoft Plug and Play compatibility
The monitor includes this standard that automatically optimizes display
settings:
Supports most IBM VGA, S-VGA, XGA, Macintosh or any other RGB
signals within a horizontal frequency range or 15.75/31 to 100 kHz
(15.75/31 to 70 kHz for XM37 Xtra) and a vertical frequency range of 45
to 120 Hz. This includes NTSC, PAL, SECAM, and M-NTSC standard video
signals.

• The supplied RGB cable allows hook up to IBM-PC compatible.
(For Macintosh, use the supplied pin adapter.)

• The analog BNC RGB terminals accept component signal.

• Front bezel controls

• Universal power supply from 100Vac to 120Vac and 220Vac to
240Vac.

Contents of the Package

The following lists all of the items included in your MultiSync multimedia
monitor package. Please save the original box and packing materials
for future transportation or shipment of this monitor.

1. MultiSync XP37 Xtra (XP-3791)/XM37 Xtra (XM-3761) multimedia
monitor

2. Power cord

3. Wireless remote control unit and two AA batteries

4. RGB cable (15-Pin Mini D-Sub To 15-pin Mini D-Sub Connector)

5. Pin adapter for Macintosh

6. User' s manual

7. Quick set up card

8. Registration card : Please fill out and return the registration card as
soon as possible.

PROCEED VIDEO 1

VIDEO 2 RGB 1 RGB 2

▼▼

＋

EXIT

−

POWER
/STANDBY

2

6

79644641

POWER

ON

RGB 2RGB 1VIDEO 2VIDEO 1

POSITION/CONTROL PROCEED

EXIT

SCAN

NORMALSIDE PINHEIGHTWIDTH

BRIGHT

CONTRAST

MUTE

NORMAL

VOLUME

OFFDEGAUSS

MULTIMEDIA MONITOR
RD-346E

VIDEO 1 VIDEO 2 RGB AUDIO RGB 1

REMOTE

EXTERNAL CONTROL

DIP SW

AC IN

SPEAKER SELECT

EXT SPEAKER

RGB 2

AUDIO AUDIO

HIGH 75Ω

R

MONO

IN

THROUGH

OUT

IN

THROUGH

OUT

THROUGH

OUT

IN

BNC S

HIGH 75Ω

THROUGH

OUT

IN

R

THROUGH

OUT

IN

R

THROUGH

OUT

IN

BNC S

HIGH 75Ω

IN

THROUGH

OUT

R/CR/PRG/Y/Y B/VB/PBH/CS V

HIGH 75ΩHIGH 75Ω

SPEAKRES MUST
HAVE MORE THAN
5WATT RATING
INPEDANCE 8 OHM

RIGHT LEFT

INT EXT

IN

OUT

12345678

ON

()
L

MONO

()

L

MONO

()

L

MONO

()

L

Part Names and Functions

3

Front View

PROCEED VIDEO 1

EXIT

89

7

VIDEO 2 RGB 1 RGB 2/DTV

▼

▼



＋

−

4321

56

PROCEED VIDEO 1

VIDEO 2 RGB 1 RGB 2

▼▼

＋

EXIT

−

POWER
/STANDBY

POWER

/STANDBY

Rear View

0

Terminal Board

1 POWER ..................... Press to turn the main power on and off

when the AC power is supplied.

2

POWER/STANDBY

....

When this indicator is green, the monitor is
on; when the indicator is red, it is in standby.

Remote Sensor Window...

3

Receives infrared signal from the handheld
remote control.

4 RGB 2/DTV/+ ............. Press to select an RGB video source that is

connected to the RGB 2 input terminals
(BNC type). When you are in the OSM
mode, this button works as the plus button.

5 RGB 1/- ...................... Press to select an RGB video source that is

connected to the RGB 1 input terminal (D­SUB 15 pin type).
When you are in the OSM mode, this button
works as the minus button.

6 VIDEO 2/ ................. Press to select an NTSC, PAL, SECAM or

M-NTSC compatible video source that is
connected to the VIDEO 2 input terminal
(BNC type or S-VIDEO 2 IN). When you are

in the OSM mode, this button works as the up
button.

NOTE: S-VIDEO IN terminals will take
preference over VIDEO IN terminals when
the video source is connected to each
terminal and VIDEO 1 or 2 selected.

7 VIDEO 1/

................. Press to select an NTSC, PAL, SECAM or M-

NTSC compatible video source that is
connected to the VIDEO 1 input terminal
(BNC type or S-VIDEO 1 IN). When you are in
the OSM mode, this button works as the
down button.

8 EXIT ........................... Press to exit the OSM mode. The OSM

screen disappears.

9 PROCEED .................Press to access OSM. The OSM screen is

displayed.

0

Remote Control Holder.....

Place remote control unit here when not in
use.

4

7

Terminal Board

VIDEO 1 VIDEO 2 RGB AUDIO RGB 1

REMOTE

PC/EXT CTL

DIP SW

AC IN

SPEAKER SELECT

EXT SPEAKER

RGB 2

AUDIO AUDIO

HIGH 75Ω

R

MONO

IN

THROUGH

OUT

IN

THROUGH

OUT

THROUGH

OUT

IN

BNC S

HIGH 75Ω

THROUGH

OUT

IN

R

THROUGH

OUT

IN

R

THROUGH

OUT

IN

BNC S

HIGH 75Ω

IN

THROUGH

OUT

R/CR/PRG/Y/Y B/CB/PBH/CS V

HIGH 75ΩHIGH 75Ω

SPEAKRES MUST
HAVE MORE THAN
5WATT RATING
INPEDANCE 8 OHM

RIGHT LEFT

INT EXT

IN

OUT

12345678

ON

()

L

MONO

()

L

MONO

()

L

5

VIDEO 1 VIDEO 2 RGB AUDIO RGB 1

()

R

MONO

BNC S

IN

THROUGH

OUT

HIGH 75Ω

AUDIO AUDIO

()

MONO

L

R

IN

THROUGH

OUT

IN

THROUGH

OUT

IN

THROUGH

OUT

BNC S

HIGH 75Ω

()

MONO

L

R

L

IN

THROUGH

OUT

R/CR/PRG/Y/Y B/CB/PBH/CS V

IN

THROUGH

OUT

A PC/ECT CTL IN (D-Sub 15-pin)

This terminal is used when power ON/OFF, input selection, AUDIO
MUTE, PICTURE MUTE, and DEGAUSS are operated externally
(by external control). See also page 42 for external control port pin
assignments. You can also use this connector to connect your PC to
control the MultiSync XP37 Xtra/XM37 Xtra monitor. This allows you
to utilize your PC and serial communication protocol to control the
monitor.

NOTE: Select EXT. CONTROL ON by setting pin No. 6 of DIP SW
to the ON position when operating the monitor by external control.
NOTE: When in the EXT. CONTROL mode, the following
operations of the supplied wireless remote control are not possible:
Power control ON/ OFF, Input selection, and Degauss switch ON/
OFF.

PC/ECT CTL OUT (D-Sub 15-pin).....Connect to a second monitor’s

EXTERNAL CONTROL input to relay the signal input at the
EXTERNAL CONTROL IN. The EXTERNAL CONTROL OUT
terminal is used to connect several monitors together and allows
all of the monitors to be controlled by one external control. No. 6
pin (EXT. CONTROL) of DIP SW must be set to the ON position on
all of the monitors.

B REMOTE IN/OUT

Connect the optional remote cable, included with the optional
remote control, to the REMOTE IN terminal. The REMOTE OUT
terminal is used to connect several monitors together and allows all
of the monitors to be controlled by one remote control.

IN

THROUGH

OUT

RGB 2

HIGH 75Ω

HIGH 75ΩHIGH 75Ω

C EXT SPEAKER

D DIP Switch

E AC Input

SPEAKRES MUST
HAVE MORE THAN
5WATT RATING
INPEDANCE 8 OHM

C

SPEAKER SELECT

INT EXT

EXT SPEAKER

RIGHT LEFT

BA

REMOTE

IN

OUT

ON

PC/EXT CTL

DIP SW

12345678

AC IN

D

E

NOTE: Up to 50 monitors can be connected in the serial
connection. (This can be done only when the optional
supplied remoto cable is used.)

RIGHT + ....... Connect RIGHT speaker positive wire here.

RIGHT - ........ Connect RIGHT speaker negative wire here.

LEFT - .......... Connect LEFT speaker negative wire here.

LEFT + ......... Connect LEFT speaker positive wire here.

SPEAKER SELECT INT/EXT Select Switch.....Set to the INT

position for built-in monitor speakers. Set to the EXT position
for speakers connected to the EXT SPEAKER terminals.

NOTE: The speaker cables must be less than 3m in length.

DIP SW..... This DIP switch sets Sync. Control, the Intelligent

Power Manager, external control on/off, remote control on/off,
and OSM system control on/off. See pages 17 and 18 for more
details.

Connect the supplied power cord’ s three-pin plug here.

Insert the prongs completely.

6

8

Terminal Board

7

H

VIDEO 1 VIDEO 2 RGB AUDIO RGB 1

BNC S

IN

THROUGH

OUT

HIGH 75Ω

AUDIO AUDIO

()

MONO

L

R

IN

THROUGH

OUT

IN

THROUGH

OUT

IN

THROUGH

OUT

BNC S

HIGH 75Ω

()

MONO

L

R

G

()

R

MONO

L

IN

THROUGH

OUT

R/CR/PRG/Y/Y B/CB/PBH/CS V

IN

THROUGH

OUT

F RGB 1 (Mini D-SUB 15 pin)

RGB Input/Throughout.....Attach either end of the RGB Cable to a

computer, and then attach the other end to Input terminal. You can
then use Throught out terminal, if you wish, to output the computer
signal to a monitor. (If you do use a second monitor, turn the
monitor switch to “on.”)

75 Ω/HIGH Impedance Select Switch.....This switch should be “75Ω”

for normal use without external termination or when your RGB
signal should be terminated with 75Ω. Switch to the “HIGH”
position when you have another monitor attached to your RGB
through-put connector.

G RGB AUDIO

AUDIO R IN.....This is where you connect RGB right audio output

from a computer or another RGB source.

AUDIO L(MONO)IN.....This is where you connect RGB left audio

output from a computer or another RGB source.

AUDIO R THROUGH OUT.....Connect to a second monitor’ s

RGB right audio input.

AUDIO L THROUGH OUT.....Connect to a second monitor’s

RGB left audio input.

IN

THROUGH

OUT

RGB 2

F

HIGH 75Ω

HIGH 75ΩHIGH 75Ω

SPEAKRES MUST
HAVE MORE THAN
5WATT RATING
INPEDANCE 8 OHM

SPEAKER SELECT

INT EXT

EXT SPEAKER

RIGHT LEFT

REMOTE

IN

OUT

ON

PC/EXT CTL

DIP SW

12345678

AC IN

H VIDEO 2

VIDEO 2 IN (BNC type).....Connect another VCR or laser disk player

here to display the video.

S-VIDEO 2 IN.....Connect S-Video input from another external

source like a VCR.

THROUGH OUT (BNC type).....Connect to a second monitor’ s video

input to relay the video signal input at VIDEO 2 IN.

THROUGH OUT (S-VIDEO).....Connect to a second monitor’ s S-

connector input to relay the video signal input at S-VIDEO 2 IN.

75 Ω/HIGH Impedance Select Switch for BNC type.....Set to “75 Ω”

during normal operation. In multiple connections using VIDEO 2
IN and THROUGH OUT (BNC type) terminals, set to “HIGH” on all
but the last monitor. Set to “75 Ω” on the last monitor only.

AUDIO R IN.....This is your right channel audio input for stereo

sound.

AUDIO L IN (MONO).....This is your left channel audio input for

stereo sound coming from video equipment or audio system. It
also serves as the mono audio input.

AUDIO R THROUGH OUT.....Connect to a second monitor’ s right

channel audio input.

AUDIO L THROUGH OUT.....Connect to a second monitor’ s left

channel audio input.

8

9

Terminal Board

9

I

VIDEO 1 VIDEO 2 RGB AUDIO RGB 1

IN

THROUGH

OUT

RGB 2

BNC S

IN

THROUGH

OUT

HIGH 75Ω

AUDIO AUDIO

()

MONO

L

R

IN

THROUGH

OUT

IN

THROUGH

OUT

IN

THROUGH

OUT

BNC S

HIGH 75Ω

()

MONO

L

R

()

R

MONO

L

IN

THROUGH

OUT

R/CR/PRG/Y/Y B/CB/PBH/CS V

IN

THROUGH

OUT

I VIDEO 1

VIDEO 1 IN (BNC type).....Connect a VCR or laser disk player here

to display the video.

S-VIDEO 1 IN.....Here is where you connect S-Video input from an

external source like a VCR.

THROUGH OUT (BNC type).....Connect to a second monitor’ s video

input to relay the video signal input at VIDEO 1 IN.

THROUGH OUT (S-VIDEO).....Connect to a second monitor’ s S-

connector input to relay the video signal input at S-VIDEO 1 IN.

75 Ω/HIGH Impedance Select Switch for BNC type.....Set to “75 Ω”

during normal operation. In multiple connections using VIDEO 1
IN and THROUGH OUT (BNC type) terminals, set to “HIGH” on
all but the last monitor. Set to “75 Ω” on the last monitor only.

AUDIO R IN.....This is your right channel audio input for stereo

sound.

AUDIO L IN (MONO).....This is your left channel audio input for

stereo sound coming from video equipment or audio system. It
also serves as the mono audio input.

AUDIO R THROUGH OUT.....Connect to a second monitor’ s right

channel audio input.

AUDIO L THROUGH OUT.....Connect to a second monitor’ s left

channel audio input.

J

HIGH 75Ω

HIGH 75ΩHIGH 75Ω

SPEAKRES MUST
HAVE MORE THAN
5WATT RATING
INPEDANCE 8 OHM

SPEAKER SELECT

INT EXT

EXT SPEAKER

RIGHT LEFT

REMOTE

IN

OUT

ON

PC/EXT CTL

DIP SW

12345678

AC IN

J RGB 2

R/C

R/PR,G/Y/Y,B/CB/PB, H/CS and V IN (BNC).....These are analog

RGB input terminals.
Connect external components with R, G, B, H/CS, and V output
terminals to these analog RGB input terminals. Be sure that the
RGB connection cable is correctly attached to the corresponding
terminals.

R/C

R/PR,G/Y/Y,B/CB/PB, H/CS and V THROUGH OUT (BNC).....Connect

to a second monitor’s RGB inputs to relay the RGB signal inputs at
R, G, B, H/CS, and V IN.

75 Ω/HIGH Impedance Select Switches for RGB and H/CS&V.....Set to

“75 Ω” during normal operation. In multiple connections using R,
G, B, H/CS and V IN and OUT terminals, set to “HIGH” on all but
the last monitor. Set to “75 Ω” on the last monitor only.

10

10

Remote Control Unit

2

POSITION/ CONTROL PROCEED

4

BRIGHT

CONTRAST

MULTIMEDIA MONITOR
RD-346E

POWER

OFFDEGAUSS

NORMAL

MUTE

ON

RGB 2RGB 1VIDEO 2VIDEO 1

EXIT

SCAN

NORMALSIDE PINHEIGHTWIDTH

VOLUME

79644641

1

3
5

6

11

NOTE: When not in use the remote control unit is conveniently stowed in the
holder on the rear panel.

1 POWER ON/OFF

Press POWER ON to turn the monitor on when the POWER/STANDBY
indicator is lit amber.
Press POWER OFF to turn the monitor off and the monitor will go into the
standby condition.

2 DEGAUSS

Press to demagnetize the picture tube in the manual operation. See also
page 27.

3 Input Select

VIDEO 1 ..... Press to select an NTSC, PAL, SECAM or M-NTSC

compatible video source from a VCR, laser disc player, document camera,
or an S-Video source from a VCR connected to the VIDEO 1 IN terminal.

VIDEO 2 ..... Press to select an NTSC, PAL, SECAM or M-NTSC

compatible video source from a VCR, laser disc player, document camera,
or an S-Video source from a VCR connected to the VIDEO 2 IN terminal.

RGB 1 ....... Press to select an RGB video source from a computer

connected to the RGB 1 IN terminal.

RGB 2 ....... Press to select an RGB/component video source from a

computer, NEC scan converter or YPBPR/YCBCR Signal source connected
to the RGB 2 IN terminal.

OSM Control
4 POSITION/CONTROL

POSITION( ) ...... Adjusts the vertical position of the image up and

down, and the horizontal position of the image from left to right.

CONTROL ( + / - ) ..... Moves the bar in the + or - direction to increase or

decrease the adjustment in an OSM menu.

CONTROL( / )..Select one of the controls in an OSM menu. Press to

select a higher item in the menu; press to select a lower item in the menu.

5 PROCEED

Press to access OSM. When an adjustment item is selected, a press of this

button returns to its icon selection screen.

6 EXIT

Press to exit the OSM mode.

NOTE: The direct keys such as BRIGHT, CONTRAST, WIDTH, HEIGHT,
SIDE PIN can access each control while in the OSM mode.

12

11

7

8

B

POWER

ON

OFFDEGAUSS

RGB 2RGB 1VIDEO 2VIDEO 1

POSITION/ CONTROL PROCEED

EXIT

SCAN

NORMALSIDE PINHEIGHTWIDTH

NORMAL

BRIGHT

CONTRAST

MUTE

VOLUME

9

0

A
D
F

13

Raster Control

7 WIDTH (+ / -)

Adjusts the horizontal size of the image.

8 HEIGHT (+ / -)

Adjusts the vertical size of the image.

9 SIDE PIN (+ / -)

Adjusts the curvature of the edges of the left and right side of the display
image either inward or outward. The image should be adjusted to attain a
straight line on the left and right sides.

0 SCAN SELECT

Each time this key is pressed, the picture size switches from OVER SCAN
for large size to UNDER SCAN for small size and vice versa. Normally select
OVER SCAN for video display and UNDER SCAN for RGB display.

A NORMAL

This key resets the raster adjustment settings of user changeable memory
and recalls the factory preset data.

C

MULTIMEDIA MONITOR
RD-346E

79644641

E

Visual Control

B BRIGHT ( / )

Adjusts the overall image and screen brightness.
Press and hold for a brighter picture.
Press and hold for a darker picture.

C CONTRAST ( / )

Adjusts the image brightness in relation to the background.
Press and hold for higher contrast.
Press and hold for lower contrast.
NOTE: The VISUAL CONTROL storing operation is effective only for the
input currently used (VIDEO1, VIDEO 2, RGB 1 or RGB 2).

D NORMAL

This key resets the visual control settings and recalls the factory preset data.

NOTE: The brightness and contrast adjustment level are factory preset at
the optimum position.

E MUTE

Press to cancel sound ; press again to restore sound.

NOTE: The other ways to restore sound are to press POWER OFF, then
ON or to press VOLUME keys on the remote control unit.

F VOLUME ( / )

Adjusts the volume.
Press and hold to increase sound.
Press and hold to decrease sound.

14

12

Battery Installation and Replacement

The remote control is powered by two 1.5V AA batteries.

15

2. Install the two new batteries, making
down. Press down on the battery
compartment grip and slide the
compartment in the direction of the
arrow.

sure that their polarity matches the (+)
(-) diagrams inside the battery
compartment. Incorrect polarity could
damage the remote control unit.

Remote Control Cautions

• Do not drop or mishandle the remote control unit.

• Do not get the remote control unit wet. If the remote gets wet, wipe it dry
immediately.

• Avoid heat and humidity.

• When not using the remote control unit for a long period, remove the
batteries.

• Do not use new and old batteries together, or use different types of batteries
together.

• Do not take apart the batteries, heat them, or throw them into a fire.

3. Close the battery compartment cover.1. Turn the remote control unit upside

PROCEED VIDEO 1

VIDEO 2 RGB 1 RGB 2

▼▼

EXIT

＋

−

POWER
/STANDBY

Operating Range

• The infrared signal operates by line-of-sight up to a distance of
approximately 22 feet/7 m and within a 60 degree angle of the remote
sensor of the monitor.

• The monitor will not function if there are objects between the remote control
and the sensor or if strong light falls on the sensor. Weak batteries will also
prevent the remote control from properly operating the monitor.

30°

POSITION/CONTROL PROCEED

CONTRAST

BRIGHT

MULTIMEDIA MONITOR
RD-346E

30°

POWER

OFFDEGAUSS

ON

RGB 2RGB 1VIDEO 2VIDEO 1

EXIT

SCAN

NORMALSIDE PINHEIGHTWIDTH

NORMAL

MUTE

VOLUME

79644641

16

13

Functions of DIP SW

17

ON

12345678

ON

OFF

Functions and Settings of DIP SW

This DIP switch is used for Sync. Control, Intelligent Power Manager, External
control, wireless control, and OSM control. To change a switch setting use a
pointed object, such as a pen or pencil, to push the switch to the desired
position.

Set all the pins except No.7 to the OFF position during normal operation.
The pins nos 2,3 and 5 are not used.

Pin No 1 (Sync. Control )

The No. 1 pins set Sync. Control.
Set the No. 1 pin to the OFF/OPEN position during normal operation. The
monitor automatically determines if the input signal is separate sync,
composite sync or sync on green signal in this order.
Set the No. 1 pin to the ON/SHORT position when sync on green signals are
necessary for synchronization with an external component.

Pin No. 4 (Intelligent Power Manager)

This function saves power.

When Intelligent Power Manager control is on, by using the monitor’ s
horizontal and vertical SYNC signals, the monitor can be prompted into the
different IPM modes. The following is the description of the LED indicator for
the IPM power saving modes:

Mode

On
Standby
Standby

Suspend

Off

Power Off

NOTE: The Intelligent Power Manager works only for the RGB input. If
selecting the VIDEO input, or when connecting to no signal source, the
Intelligent Power Manager does not work.

LED Indicator

Green
Red (Steady)
Amber(Blinking quickly)

Amber(Blinking moderately)

Amber(Blinking slowly)

No Light

Power Saving

None
None
Minimum

(Quickest recovery)

Moderate

(Moderate recovery)

Maximum

(EPA<8 watts, Slowest recovery)

No Power Used (Fully Off)

Pin No. 6 (EXT. CONTROL)

When this switch is set to ON, the External Control function is activated. See
page 42 for pin assignments. If you have some monitors you do not want to
control by remote, set to OFF.

Pin No. 7 (REMOTE ON/OFF)

When this switch is set to ON, the monitor can be controlled by the wireless
remote control unit.

Pin No. 8 (OSM System Control Menu ON/OFF)

When this switch is set to ON, the system control menu is displayed. In this
menu the following features are enabled:
Power on mode set (POWER ON MODE)
Rear control key on/off (KEY CONTROL)
Language selection (LANGUAGE)
Video mode (auto/manual) selection (VIDEO MODE)
OSM on/off (OSM ON/OFF)
PC-control on/off (PC-CONTROL)
For the setting procedures to set the items, see pages 39 to 41.

18

14

19

Installation

Wiring Diagram

IBM XGA/SuperVGA/VGA or Compatibles
or Macintosh G3 series

RGB cable (Supplied)
To Mini D-SUB 15 Pin input

XP37 Xtra/XM37 Xtra

VIDEO 1 VIDEO 2 RGB AUDIO RGB 1

BNC S

IN

THROUGH

OUT

HIGH 75Ω

AUDIO AUDIO

()

MONO

L

R

IN

THROUGH

OUT

IN

THROUGH

OUT

IN

THROUGH

OUT

BNC S

HIGH 75Ω

()

MONO

L

R

()

R

L

IN

THROUGH

OUT

R/CR/PR G/Y/Y B/CB/PB

IN

THROUGH

OUT

MONO

THROUGH

RGB 2

IN

OUT

HIGH 75Ω

H/CS V

HIGH 75ΩHIGH 75Ω

SPEAKERS MUST
HAVE MORE THAN
5WATT RATING
INPEDANCE 8 OHM

Macintosh or
Compatibles

Pin adapter for Macintosh
(supplied)

RGB cable (Supplied)
To Mini D-SUB 15 Pin input

SPEAKER SELECT

INT EXT

EXT SPEAKER

RIGHT LEFT

REMOTE

IN

OUT

ON

12345678

AC IN

EXTERNAL
CONTROL

To EXTERNAL CONTROL
(Mini D-SUB 15 Pin input)

PC/EXT CTL

To R,G,B,H/CS, V inputs (BNC)

DIP SW

NEC IPS 4000

Image Processo

To VIDEO IN R, L, inputs

Document camera, VCR, Video copy stand
or Multimedia application

NOTE: The two D-Sub 15-pin RGB 1 connectors here can be used to either input or
output video to or from a PC or Macintosh computer. Either connector can be used for
input or output, however they cannot both be used for input simultaneously. It can
damage your computer.

To Y/CB/CR, Y/PB/PR inputs (BNC)

PROCEED VIDEO 1

VIDEO 2 RGB 1 RGB 2

▼▼

EXIT

＋

−

XP37Xtra/XM37Xtra

DTV Tunerr

or

DVD Player

POWER
/STANDBY

20

15

Connecting Your PC or Macintosh Computer

Connecting your PC or Macintosh computer to your MultiSync XP37 Xtra/
XM37 Xtra will enable you to display your computer's screen image. All of
these following display standards are supported:

VGA 640 x 480 for graphics, VGA 640 x 400 for graphics, VGA 640 x 350 for
graphics, VGA 720 x 400 for text, VGA 720 x 350 for text, SuperVGA 800 x
600, and XGA 1024 x 768, 1280x1024 standards above 60 Hz such as Sun,
Silicon Graphics, HP, workstation standards; Macintosh at 640 x 480, 832 x
624, 1024 x 768, and 1152 x870(XP37 Xtra only).

To connect to a PC, Macintosh or computer equipped with a XGA/SuperVGA/
VGA adapter or compatible graphics adapter, simply:

1. Turn off the power to your monitor and computer.

2. If your PC does not support XGA/SuperVGA/VGA you will need to install an
XGA/SuperVGA/VGA graphics board. Consult your computer's owner's
manual for your XGA/SuperVGA/VGA configuration. If you need to install a
new board, see the manual that comes with your new graphics board for
installation instructions.

3. Use the signal cable that’s supplied to connect your PC or Macintosh com­puter to the RGB1 input terminal. For older Macintosh, use the supplied pin
adapter to connect to your Mac’s video port.

21

NOTE: The new Macintosh computer such as G3 will have the 15-pin HD
connector.
The XP37 Xtra/XM37 Xtra’s “Plug and Play” data will be downloaded to
the Macintosh.
Therefore, the pin adapter will not be necessary.

4. Turn on the monitor and the computer.
NOTE: Refer to your computer's owner's manual for more information

about your computer's video output requirements and any special identifi­cation or configuring your monitor's image and monitor may require.
NOTE: With Sync on Green signals, images may not display properly.
If this happens, input the signals to “RGB” and at “DV Control Group - RGB
SOURCE SELECT”, select No. 2 = RGB.
(For details on “DV Control Group”, refer to page 36.)

Connecting Your DTV Tuner or DVD Player

Using the RGB 2 terminal will enable you to display a component signal from
your DTV tuner or DVD player with component output.

1. Turn off the power to your monitor and your DTV tuner or DVD player.

2. Use the optional component video cable between the RGB 2 (Y/PB/PR,Y/CB/

CR) terminal of your monitor and the output of your DTV tuner or DVD player.

3. Turn on the monitor and your DTV tuner or DVD player.

Connecting Your VCR or Laser Disc Player

Using a common RCA cable and RCA audio cables (not provided) to connect
your VCR or laser disc player to your MultiSync XP37 Xtra/XM37 Xtra monitor.
To make these connections, simply:

1. Turn off the power to your monitor and VCR or laser disc player.

2. Connect one end of your RCA video cable to the video output connector on
the back of your VCR or laser disc player, connect the other end to the
VIDEO 1 or 2 input terminal(BNC-type) of the monitor. NOTE: You will need
an RCA to BNC adaptor (not included) to convert to the XP37Xtra/XM37
Xtra monitor. Use standard RCA audio patch cords to connect the audio
from your VCR or laser disc player to your monitor (if your VCR or laser disc
player has this capability). Be careful to keep your right and left channel
connections correct for stereo sound.

3. Turn on the monitor and the VCR or laser disc player.

NOTE: Refer to your VCR or laser disc player owner's manual for more
information about your equipment's video output requirements.
NOTE: S-VIDEO IN terminals will take preference over VIDEO IN termi­nals when a component is connected to each terminal and VIDEO 1 or 2
selected.

Connecting Your Document Camera

You can connect your MultiSync XP37 Xtra/XM37 Xtra monitor to a document
camera. To do so, simply:

1. Turn off the power to your monitor and document camera.

2. Use a standard video cable to connect your document camera to the VIDEO
1 or 2 input terminal(BNC-type) of the monitor.

3. Turn on the monitor and the document camera.

NOTE: Refer to your document camera's owner's manual for more
information about your camera's video output requirements .

Connecting Your NEC IPS 4000 Image Processor

You can connect an NEC IPS 4000Image Processor to the monitor to improve
the quality of your video images. To do so:

1. Turn off the power to your monitor and scan converter.

2.Use a cable (RGB HV 5 conductor BNC/BNC) supplied with the scan
converter to connect the RGB 2 inputs of the monitor.

3. Turn on the monitor and the scan converter.

22

16

Daisy-chaining Your monitors

The REMOTE IN/OUT terminals allow you to control monitors by one remote
control.

NOTE: The connection of three XP37 Xtra/XM37 Xtra monitors or more with
THROUGH OUT (VIDEO 1 or 2) terminals may degrade image quality.

To do so:

When using the VIDEO inputs:
THROUGH OUT (VIDEO 1) Connections

1. Connect THROUGH OUT 1 BNC or S-VIDEO 1 OUT to external compo­nents to relay the signal input at VIDEO 1 IN(BNC-type), or S-VIDEO 1 IN.

2. Connect the external component mono audio or stereo left channel audio
input to L AUDIO.

3. Connect the external component stereo right channel audio input to R AU­DIO.

4. Set the 75Ω/HIGH impedance select switch of the corresponding input sig­nal (BNC, S-VIDEO) on all but the last monitor to “HIGH” position. Only the
last monitor is set to “75Ω” position.

THROUGH OUT (VIDEO 2) Connections

1. Connect THROUGH OUT 2 BNC or S-VIDEO 2 OUT to external component
to relay the signal input at VIDEO 2 IN(BNC-type) or S-VIDEO 2 IN.

2. Connect the external component mono audio or stereo left channel audio
input to L AUDIO.

23

3. Connect the external component stereo right channel audio input to R AU­DIO.

4. Set the 75Ω/HIGH impedance select switch of the corresponding input signal
(BNC, S-VIDEO) on all but the last monitor to “HIGH” position. Only the last
monitor is set to the “75Ω” position.

5. Connect the REMOTE OUT of the monitor to the REMOTE IN of the next
monitor using the optional remote cable.

When using the RGB inputs:

THROUGH OUT Connections

1. (RGB1): Connect Mini D-Sub 15-pin THROUGH OUT to an RGB input con­nector of other monitors.
(RGB2): Connect the R.G.B.H/CS and V THROUGH OUT terminals to relay
the signal input at the R.G.B.H/CS and V IN terminals.

2. Set all the 75Ω/HIGH impedance select switches on all but the last monitor to
“HIGH” position. Only the last monitor is set to the “75Ω” position.

3. Connect the REMOTE IN of the monitor to the REMOTE OUT of the next
monitor using the optional remote cable.

NOTE: ''Plug and Play'' is available only for the monitor connected directly to
a personal computer with the Mini D-Sub 15-pin RGB connector. Therefore,
''Plug and Play'' does not work for monitors connected with the THROUGH
OUT terminal. This is because only the RGB video, the horizontal, and the
vertical sync. signal is output from the THROUGH OUT terminals.

NOTE: ''Plug and Play'' is not available for the RGB 2 BNC terminals.

D-Sub 15 Pin RGB Signal Composition

Pin Assignments and Signal Levels for 15 pin RGB (Analog)

2

5

34

9

10

13

1415

1

8

6

7

12

11

D-SUB 15pin RGB Input Connector (ANALOG ONLY)

Pin No.

1
2

3
12
13
14
15

4

5

6

7

8
11
10

9

Signal to be connected (D-SUB 15 pin)

RED
GREEN or Sync Green
BLUE
SDA
H. or Composite sync
V.SYNC
SCL
GND
GND
GND
GND
GND
GND
No Connection
No Connection

24

17

25

79644641

POWER

ON

RGB 2RGB 1VIDEO 2VIDEO 1

POSITION/CONTROL PROCEED

EXIT

SCAN

NORMALSIDE PINHEIGHTWIDTH

BRIGHT

CONTRAST

MUTE

NORMAL

VOLUME

OFFDEGAUSS

MULTIMEDIA MONITOR
RD-346E

VIDEO 1 VIDEO 2 RGB AUDIO RGB 1

REMOTE

EXTERNAL CONTROL

DIP SW

AC IN

SPEAKER SELECT

EXT SPEAKER

RGB 2

AUDIO AUDIO

HIGH 75Ω

R

MONO

IN

THROUGH
OUT

IN

THROUGH
OUT

THROUGH
OUT

IN

BNC S

HIGH 75Ω

THROUGH
OUT

IN

R

THROUGH
OUT

IN

R

THROUGH
OUT

IN

BNC S

HIGH 75Ω

IN

THROUGH
OUT

R/CR/PRG/Y/Y B/VB/PBH/CS V

HIGH 75ΩHIGH75Ω

SPEAKRES MUST
HAVE MORE THAN
5WATT RATING
INPEDANCE 8 OHM

RIGHT LEFT

INT EXT

IN

THROUGH
OUT

12345678

ON

()
L

MONO

()
L

MONO

()

L

MONO

()
L

SPEAKER SELECT

INT

EXT

RIGHT

＋

−

＋

−

4 ft.

120cm

4 ft.

120cm

Left

Right

HJJKKKASDFFF

BNGGDFDFGHY

ZZXXC

CCVDFVFF

ADFGRTRYT

ADFGRTRYT

SFGHHHJJ SFGHHHJJ

DFFGGGG

AFHUJTT

AFHUJTT

DFFGGGG

2Q 2Q

2Q

2Q

JGHDYSTEOYII DYASGHIROYUKIAIZAWA

THROUGH

OUT

IN

R

R

L

LINE OR
AUX INPUT

LINE OR
AUX INPUT

STEREO AMP

L (MONO)

External Speaker Connections

External speakers may be connected to the monitor to reproduce sound from
VIDEO 1, VIDEO 2, RGB 1 or RGB 2 signal sources.

External speakers may be connected directly to the EXTERNAL SPEAKERS
terminals or indirectly by connecting a stereo system amplifier to the audio
outputs.

WARNING: Speakers that are installed next to the monitor must be
shielded against electromagnetic radiation which can cause color distortion
in the CRT and is not covered under the warranty.

If non-shielded speakers are used, they must be located a minimum of 4 feet
away from the monitor.

CAUTION: Unplug the monitor and all connected components before con­necting external speakers. Use only speakers with 8-ohm impedance and a
power output rating of 5 watts or more.

To connect external speakers directly to the monitor:

1. Strip the ends of the speaker wires.

2. Press down a button below the EXTERNAL SPEAKERS terminals, insert
the speaker wire and release the button to secure a speaker wire connec­tion:
[a] Connect the right speaker (located at right side of the monitor when

viewed from the front) positive (+) wire to RIGHT +.
[b] Connect the right speaker negative (-) wire to RIGHT -.
[c] Connect the left speaker negative (-) wire to LEFT -.
[d ]Connect the left speaker positive wire (+) to LEFT +.

3. Set SPEAKER SELECT switch at EXT.

NOTE: The speaker cables must be less than 3m in length.

VIDEO or

RGB AUDIO L and R outputs of XP37Xtra/XM37Xtra

To connect the monitor to stereo system speakers:

1. Connect L AUDIO output to the stereo amplifier L AUX input.

2. Connect R AUDIO output to the stereo amplifier R AUX input.

3. Set SPEAKER SELECT switch at EXT to use external speakers only. For
center channel audio fill, set SPEAKER SELECT at INT for sound from both
monitor and external speakers.

IMPORTANT: Do not connect speakers to both the monitor EXTERNAL
SPEAKERS terminals and to the stereo amplifier. This could damage both
the monitor and the speakers.

26

18

27

Operation

Power

This section describes how to select a computer or video source and how to
adjust the picture and sound.

General Controls

Before you turn on your MultiSync XP37 Xtra/XM37 Xtra monitor ensure that
the computer or video source is turned on.

1)To adjust:

1. Turn On The Monitor
The power button is on the front panel of the monitor. By turning this switch on,
the STANDBY/POWER indicator will turn to green and the monitor will
become ready to use. OSM is also usable from the rear panel.
After you press the POWER OFF button on the remote control, the monitor will
go into its standby mode and the STANDBY/POWER indicator will glow red.

2. Select The Computer Or Video Source
Press the “VIDEO 1” or “VIDEO 2” (VCR, document camera, or laser disc
player), or “RGB 1” or ” RGB 2”(computer) button on the remote control to
display the image. Or press the button on the rear panel to select your video
source: “VIDEO 1”, “VIDEO 2”, “RGB 1”, or “RGB 2”.

NOTE 1: In the U.S.A. the standard video signal format is NTSC, therefore
make sure that the AUTO or NTSC is selected on OSM system control
menu. See page 41.

NOTE 2: Select the over scan mode for VIDEO display.

3. Adjust The Raster or The Picture Control.
You can adjust the raster such as the horizontal size, vertical size or side
pincushion correction, and the brightness and contrast of the image with the
remote control.

4. Turning Off The monitor.
Press the POWER OFF button on the remote control or press the POWER
button on the front panel.

Degaussing

The earth's magnetic field and other magnetic sources can magnetize a color
picture tube causing patches of impure colors. This monitor automatically
demagnetizes the picture tube for 5 seconds each time the monitor is switched
on. Sometimes during transportation a severe magnetic field can be
encountered which may require demagnetizing to clear the problem. Also, if
powered on for extended periods of time, magnetic fields can be produced by
the CRT itself, causing color impurities. In these cases, use the DEGAUSS
key once to demagnetize the picture tube. Pressing this key once
demagnetizes the picture tube for 5 seconds.
CAUTION: Please allow a minimum of 30 minutes to elapse between uses of
the DEGAUSS key, when not switching from mode to mode. Do not hold the
key down continuously to avoid decreasing the life of the degauss circuitry.

Using OSM Controls

NEC's OSM, or On-Screen Manager, System offers the ultimate form of
monitor controls. Keys on the remote control unit or front panel allow you to
easily navigate through menus and adjust controls.
OSM controls include extended controls such as Brightness, Contrast, Size,
Position, Pin cushion, Keystone, Vertical Linearity, Scan Select and other
OSM utilities. Adjustments are saved instantly. The currently addressed
control can be reset to factory settings by pressing the NORMAL key.

OSM keys on the remote control unit function as follows:
PROCEED : accesses the OSM controls. When an

adjustment item is selected, a press of this
button returns to its icon selection screen.

-in the color temperature: proceeds to the
control for RGB gain and bias.

EXIT : exits the OSM controls.

-in the RGB gain and bias: return to the color
temperature screen.

POSITION CONTROL up/down : selects one of the control items.
POSITION CONTROL-/+ : increase or decrease the settings level.

: selects a group icon at top of the OSM screen

when any one of them is highlighted without
any specific control selected.

NORMAL (RASTER/VISUAL) : resets the currently selected control to the

factory setting.

-when a specific group icon is highlighted, this
key resets all the specific controls settings or all
the settings.

-when a specific control is selected: this key
resets the selected adjustments.

NOTE: The NORMAL function is not valid in
the OSM Turn Off Time, Language Select
menus, and Volume Control.

28

19

Direct Control Screen

You can adjust the raster, visual and sound using the direct key on the remote
control.

29

c. HEIGHT

Press to adjust the vertical size of the image.

To switch to another control screen, press any one of the other keys.
*To end the OSM display, press EXIT.
*If no key operation is made within 3 seconds, the OSM display will disappear.

a. POSITION/CONTROL

Press to move the image right. Press to move the image left.

Press to move the image up. Press to move the image down.

b. WIDTH

Press to adjust the horizontal size of the image.

f. NORMAL (raster)

Press to reset all the stored adjustment raster data and recall the factory
preset data. When a specific control is selected, this key resets the
selected raster adjustments.

d. SIDE PIN

Press to adjust the curvature of the edges of the left and right side of the
display image either inward or outward. The image should be adjusted to
attain a straight line on the left and right sides.

e. SCAN

Press to select the scan mode: over scan and under scan.

g. BRIGHT

Press to adjust the brightness of video display.

Specific adjustment item to be rest

h. CONTRAST

Press to adjust the contrast of video display.

30

20

i. NORMAL( visual)

Press to reset all the stored adjustment visual data and recall the factory
preset data. When a specific control is selected, this key resets the selected
visual adjustments.

31

j. MUTE

Press to turn off the sound for a short period of time; press again to restore
the sound.

k. VOLUME

Press to increase the sound: press to decrease the sound.

NOTE:

When pressing a key that does not correspond to the function currently
in use, the following message will be displayed on the monitor.

Accessing OSM

Press the PROCEED key on the remote control or rear panel.
To turn off OSM
Press the EXIT key on the remote control or rear panel.

RGB 2RGB 1VIDEO 2VIDEO 1

POSITION/ CONTROL PROCEED

EXIT

PROCEED

EXIT

OSM Menus

On-Screen Manager' s menu of Controls gives you an overview of the
selection of controls available.

RGB

BRIGHTNESS
CONTRAST
SHARPNESS
COLOR
TINT

PROCEED VIDEO 1

DVDV

EXIT

▼

VIDEO 2

▼

Visual Controls Group

The visual controls allow you to adjust the picture controls such as
brightness, contrast, color, tint, and sharpness.

RGB

DVDV

BRIGHTNESS
CONTRAST
SHARPNESS
COLOR
TINT

BRIGHTNESS :
CONTRAST :
SHARPNESS :
COLOR :
TINT :

Pressing + or - increases or decreases the image brightness level.
Pressing + or - increases or decreases the image contrast level.
Pressing + or - increases or decreases the image sharpness level.
Pressing + or - increases or decreases the image color saturation level
Pressing + or - increases or decreases the red and green values.

NOTE: The color, tint and sharpness controls are not available for RGB
input. For RGB2 input signals, you can select the RGB CTL menu under

RGB2 SOURCE SELECT in “DV” to change the color, tint, and sharpness
controls.The tint is not available for PAL and SECAM input.

NOTE: Pressing the visual NORMAL key resets all the visual controls to the
factory settings when only the visual controls group icon is highlighted.

32

21

H-position/H-width/Pin-cushion Controls Group

RGB

DV

RGB

DV

The H-position/H-width/Pin-cushion Controls allow you to adjust the horizontal
position, horizontal size and pin-cushion of the image.

DV

H-POSITION
H-WIDTH
PIN-CUSHION
PIN-BALANCE
PIN-CORNER

RGB

DV

H-POSITION
H-WIDTH
PIN-CUSHION
PIN-BALANCE
PIN-CORNER

RGB

33

V-position/V-height/V-linearity Controls Group

The V-position/V-height/V-linearity Controls allow you to adjust the vertical
position, vertical size and vertical linearity of the image.

DV

V -POSITION
V -HEIGHT
V-LINEARITY1
V-LINEARITY2

V -POSITION
V -HEIGHT
V-LINEARITY1
V-LINEARITY2

RGB

H-POSITION : Pressing + or - moves the image horizontally right or left.
H-WIDTH : Pressing + or - decreases or increases the horizontal size of

the image (wider or narrower).

PIN-CUSHION : Pressing + or - decreases or increases the curvature of the

sides either inward or outward.

PIN-BALANCE : Pressing + or - decreases or increases the curvature of the

sides to right or to left.

PIN-CORNER : Pressing + or - decreases or increases the curvature of the four

corners inward or outward.

NOTE: The V-LINEARITY controls allow you to adjust the spacing of the
areas on the screen. The object of this control is to ensure that a one-inch
circle is a true one-inch circle where ever it is drawn on the screen.

• draw equally spaced horizontal lines using a drawing application that has a
ruler.

•use the V-LINEARITY 1 and 2 controls to adjust the spacing between
the lines near the top and the bottom of your screen.

V-POSITION : Pressing + or - moves the image vertically up or down.
V-HEIGHT : Pressing + or - increases or decreases the vertical size of the

image (taller or shorter).

V-LINEARITY 1 : Pressing + increases the spacing between the lines near the

top and decreases the lines near the bottom at the same time;
pressing - increases the spacing between the lines near the
bottom and decreases the lines near the top at the same time.

V-LINEARITY 2 : Pressing + or - increases or decreases the spacing between

the lines near the top of your screen and near the bottom of
your screen at the same time.

Keystone/Tilt/Rotate/Scan Select Controls Group

The Keystone/Tilt/Rotation/Scan Select Controls allow you to adjust the raster
rotation or angle of the sides of your display and to select either Under Scan
(for RGB display) or Over Scan (for VIDEO display).

DV

KEYSTONE
TILT
ROTATE
SCAN SELECT

KEYSTONE
TILT
ROTATE
SCAN SELECT

RGB

OVERUNDER

KEYSTONE (trapezoidal) : Pressing + or - increases or decreases the bottom of

the screen to be the same as the top.

TILT : Pressing + or - increases or decreases the tilt of your

display.

ROTATE (raster rotation)

: Pressing + or - rotates the entire display clockwise or

counter clockwise.

SCAN SELECT : Pressing + or - selects the over scan mode or the

under scan mode.

34

22

RGB Controls Group

RGB

DV

RGBDVRGB

DV

The RGB Controls allow you to adjust the color temperature and the white
balance for RGB input.

RGB

COLOR TEMP.

DV

COLOR TEMP.

1 2 3 10500˚K

PRESS'PROCEED'FOR
RGB GAIN/BIAS SETTINGS

RGB

COLOR TEMP. : Pressing + selects the color temperature: 10500 K, 9300K,

6500K or custom.

RGB

R-GAIN(WHITE LEVEL)
G-GAIN(WHITE LEVEL)
B-GAIN(WHITE LEVEL)
R-BIAS(BLACK LEVEL)
G-BIAS(BLACK LEVEL)
B-BIAS(BLACK LEVEL)

DV

R-GAIN(WHITE LEVEL)
G-GAIN(WHITE LEVEL)
B-GAIN(WHITE LEVEL)
R-BIAS(BLACK LEVEL)
G-BIAS(BLACK LEVEL)
B-BIAS(BLACK LEVEL)

RGB

Pressing the PROCEED key proceeds to the RGB gain and bias adjustment.
This adjustment allows you to adjust the white balance.

R, G, B-GAIN : Pressing + or - increases or decreases the gain level for each color.
R, G, B-BIAS : Pressing + or - increases or decreases the bias level for each color.

DV

DV

35

OSM Location/OSM Display Time Control

You can choose where you would like OSM image to appear on your screen.
Selecting OSM location allows you to manually adjust the OSM menu left,
right, up, or down. The OSM menu will stay on as long as it is in use. In the
OSM Turn Off Time submenu, you can select how long the monitor waits after
the last touch of a key to shut off the OSM menu. The preset choices are 5,
10, 30, and 120 seconds. Note that 30 seconds is the factory preset.

RGB

OSM H-POSITION
OSM V-POSITION
OSM DISPLAY TIME

DV

OSM H-POSITION
OSM V-POSITION
OSM DISPLAY TIME

RGB

OSM H-POSITION : Pressing + or - moves the OSM menu right or left.
OSM V-POSITION : Pressing + or - moves menu up or down.
OSM DISPLAY TIME : Pressing + or - selects the preset time in increasing or

DV

Source Information

Source Information provides you information about the current resolution
display and technical data including the horizontal and vertical frequency.

NOTE: These adjustments are for RGB mode only.

DV

70.0KHZ

70.0HZ
NEG
NEG

SOURCE INFO
VIDEO1
NTSC 4.43

RGB

DV

SOURCE INFO
RGB1
H-FREQ
H-FREQ
H-POL
V-POL

RGB

H-FREQ : indicates the horizontal frequency of the current input signal.
V-FREQ : indicates the vertical frequency of the current input signal.
H-POL : indicates the polarity of the horizontal sync. signal.
V-POL : indicates the polarity of the vertical sync. signal.
NEG : indicates the polarity is negative.
POS : indicates the polarity is positive.

DV Controls Group

The DV controls allow you to select an RGB2 signal format, to emphasize the
brightness of neutral tint, and to enhance the contrast by emphasizing black.

RGB2 SOURCE SELECT
GAMMA
DYNAMIC PICTURE
1 2 3 4 5 AUTO

RGB2 SOURCE SELECT
GAMMA
DYNAMIC PICTURE
1 2 3 4 OFF

RGB2 SOURCE SELECT
GAMMA
DYNAMIC PICTURE

RGB2 SOURCE SELECT : Pressing + selects AUTO, RGB, YCBCR, YP BPR, or

RGB CTL in this order.

Normally selecting AUTO allows the monitor to
automatically distinguish between RGB and
component (YCBCR/YPBPR) signals.

36

23

If the monitor does not reproduce the color for a
component signal correctly, the monitor will select
YCBCR/YPBPR in accordance with an output format of
the connected equipment such as DVD player or DTV
tuner.

Selecting RGB CTL allows you to adjust the Color,
Tint, Sharpness, Gamma, Dynamic Picture control for
RGB signals -provided horizontal frequencies of
these RGB signals must be 60 kHz and below.
This mode is recommended for displaying movie or
graphics.

NOTE: Component signals (YPBPR) refers to the
signals of 1920 x 1080/60/2:1 and 1280 x 720/60/
1:1.

GAMMA : Pressing + s emphasizes the brightness of neutral

tint; - the darkness of neutral tint.

DYNAMIC PICTURE : Pressing + rotates OFF, LOW, MEDIUM or HIGH in

this order.
Selecting HIGH emphasizes black color on a picture.

37

Volume Control

The Volume control allows you to adjust the volume.

RGB

VOLUME
BASS
TREBLE
BALANCE
SURROUND MODE

VOLUME : Pressing + or - increases or decreases the volume.

NOTE: When you mutes the sound, the MUTE display appears.

BASS : Increases or decreases the bass.
TREBEL : Increases or decreases the treble.
BALANCE : Adjusts the balance between the right and left speakers.
SURROUND MODE : Selects OFF, MOVIE, and MUSIC in this order.

1. OFF : Turns off the surround effect.

2. MOVIE : Gives a surround effect for cinema.

3. MUSIC : Gives a surround effect for music.

DV

Reset Control

The Reset control allows you to return image parameters to factory presets.

All Raster Settings

ALL RASTER NORMAL
ALL VISUAL NORMAL
ALL NORMAL

PRESS
'PROCEED' TO RESET

RGB

The above warning statement will appear to confirm that you do want to reset
all raster settings. If you want to reset all raster settings, press PROCEED.

The following items can be reset:
H-POSITION, H-WIDTH, PIN-CUSHION, PIN-BALANCE, PIN-CORNER, V­POSI, V-HEIGHT, V-LIN1, V-LIN2, KEYSTONE, TILT and ROTATION.

DV

All Visual Settings

The above warning statement will appear to confirm that you do want to reset
all visual settings. If you want to reset all visual settings, press PROCEED.
The following items can be reset:
BRIGHTNESS, CONTRAST, COLOR, TINT, SHARPNESS, COLOR TEMP.,
R-GAIN, G-GAIN, B-GAIN, R-BIAS, G-BIAS, and B-BIAS.

38

24

Specific Item Settings

39

OSM System Control Menu

The OSM System control menu allows you to set a various conditions of the
monitor.

Specific adjustment
item to be reset.

The above warning statement will appear to confirm that you do want to reset
individual settings.

NOTE:

• In addition to OSM controls, adjustments can be directly accessed with the
remote control keys. When adjusting with the remote control keys, the on­screen display for the related adjustment appears instead of the OSM
menu.

• When OSM ON/OFF is set at OFF in the System Control menu(see the
following section ), OSM controls are not available while the remote control
direct access is possible.

OSM windows have the following elements:
Right-oriented delta symbol: indicates further choices are available. Use the

up or down keys to highlight the item. Pressing
+ proceeds to the selected control screen.

Left-oriented delta symbol : indicates that you can exit the current control.

Pressing - returns you to its original System
control menus.

NOTE: This control is available only when No. 8 pin of the DIP switch is set
at the ON position. The DIP switch is located on the back cabinet.

OSM keys on the remote control unit function as follows:
POSITION CONTROL up/down : highlights one of the control items in the System

control menus.

POSITION CONTROL + : proceeds to the selected menu choice.
POSITION CONTROL - : exits the current control and returns to its

original System control menus.

EXIT : exits the OSM controls.

POWER ON MODE

This control allows you to set the monitor to default to any one of its inputs
each time the monitor is turned on.

KEY CONTROL

This control allows you to disable the keys on the rear panel such as
PROCEED, EXIT, VIDEO 1, VIDEO 2, RGB 1, RGB 2, down, up, -, and +. If
you accidentally hit any one of the buttons, it does not affect the monitor.

40

25

1

2

34

5

11

12

13

1415

6

7

8

9

10

LANGUAGE

OSM menus are available in six languages: English, German, French,
Spanish, Italian, and Swedish.

VIDEO MODE

This control allows you to select the NTSC, PAL, or SECAM video standard.
Normally select AUTO.

41

OSM ON/OFF

This control allows you to enable the OSM control.
The OSM control is available when ON is selected. When the OSM does not
appear, the visual and raster controls are available with the remote control.

PC-CONTROL

This control allows you to activate the PC-control function.
For more information see the following pages.

PC/External Control Function

PC/External Control Port Pin Assignments

Mini D-SUB 15pin (Input/Throughout)

Pin No.

1
6
2

7
11
12

3

8

9

4

5
10
13
14
15

Signal Name

No Connection
Receive Data
No Connection
Transimit Data
No Connection
Clear to Send
No Connection
Request to Send
Ground
Input Select
Input Select
Power ON/OFF
No Connection
Degauss ON/OFF
Signal Ground

EXT-CTL
EXT-CTL

EXT-CTL

EXT-CTL

NOTE: ❊EXT-CTL ON : EXT-CTL active

PC CTL can work regardless of whether EXT-CTL is set or not.
Pin No.8 is connected to pin No. 12.

External Control

POWER OFF

POWER ON

DEGAUSS OFF

DEGAUSS ON

Pin No.

VIDEO1
VIDEO2

RGB1
RGB2

OFF: EXT-CTL inactive

4

OPEN

GND

OPEN

GND

-

-

-

-

5

OPEN
OPEN

GND
GND

-

-

-

-

10

-

-

-

-

OPEN

GND

-

-

14

-

-

-

-

-

-

OPEN

GND

42

26

43

8bit 8bit 8bit 8bit 8bit 8bit 8bit 8bit

Command 1

UNIT ID

Command 2

Data length

Data

Check Sum

Command reference

You can control the main functions from external equipment such as personal
computer using the PC/EXT CTL terminals. The following sections explain the
interface.

Interface Condition

• RS-232C

• Baud rate ------------------------- 9600 bps

• Data length ----------------------- 8 bits

• Parity ------------------------------- Odd parity

• Stop bit ---------------------------- 1 bit

• Communications mode-------- Full duplex

Control Data Format

Command 1 ........Code based on the command system

UNIT ID ...............Code allocated to each equipment (Allocate 80H to the

XP37 Xtra/XM37 Xtra)

Command 2 .........Code allocated to the main functions of the XP37 Xtra/XM37

Xtra

Data Length ........Number of bytes of the data that is transmitted

Data ....................Data transmitted

Check Sum .........Lower eight digits of sum total of the first byte to the byte

immediately before the last.

Command Communication Sequence

When external equipment such as a personal computer gives the command to
the XP37 Xtra/XM37 Xtra, the XP37 Xtra/XM37 Xtra returns an ACK. So make
sure that the external equipment receives this ACK.

Command sending/receiving sequence

External equipment

(PC)

The XP37 Xtra/XM37 Xtra returns an ACK if it has received the command
correctly.
If it has not received the command correctly due to data error, it will return
nothing. Therefore, when the external equipment send a command, make
sure that it received the ACK.

Command

XP37 Xtra/XM37 Xtra

ACK

PC CONTROL COMMAND LIST FOR USE WITH THE XP37 Xtra/XM37 Xtra

PC → XP37 Xtra/XM37 Xtra

COM1

9F

XP37 Xtra/XM37 Xtra → PC

COM1

3F

7F

Example: Input switching (VIDEO 1) from the PC to the XP37 Xtra/XM37

PC → XP37 Xtra/XM37 Xtra

COM1

DF

XP37 Xtra/XM37 Xtra → PC

COM1

3F

COM2

4E

4F

A1

COM2

4E
4F
B0
A1

Xtra(when the address selector equals 0)

UA80COM2B0Length

UA

80

COM2B0Length00Data 1

Contents

Power On
Power Off

Degauss Control

Contents

Power On (ACK)

Power Off (ACK)

Input Switching (ACK)

Degauss Control(ACK)

Data 1

02

00

6F

Data 2
VIDEO1 : 01
VIDEO2 : 02
RGB1 : 03
RGB2 : 04

Length

00
00
00

Length

00
00
00
01

Sum

12
13
14
15

44

27

Troubleshooting

Before arranging for service by the NEC Service Center, check the following to be sure repairs are needed.

45

Problem

No Picture or Sound

Sound OK; poor picture
with VIDEO signal input.

Sound OK; poor picture with
RGB signal input.

Picture OK; poor or no sound.

Poor sound from external speakers
or stereo system speakers

Remote control does not work.

Possible Cause

Power cord unplugged.
Power outlet inactive.
Power of external equipment is not ON.
External equipment has been incorrectly connected.
Incorrect input selection.

Improper control setting.
Local interference.
Cable interconnections.
Input impedance is not correct level.

Improper control setting.
Incorrect 15 PIN connector pin connections.

Cable interconnections.
Volume is not adjusted.
Poor audio connections from external source.
Improper control settings.
MUTE key is ON.

Cable interconnections.
Improper volume setting.

Weak batteries.

Obstacle between Remote Control and Sensor
Window. (Wireless)

You are not within the effective operating range.
(Wireless)

Incorrect setting of No. 7 pin of the DIP SW. (Wireless)

Correction

Plug in power cord.
Be sure wall switch is on and outlet has power.
Switch to ON or connect to an active AC outlet.
Correct all connections.
Press correct RGB1, RGB 2, VIDEO 1 or VIDEO 2 button.

Adjust picture controls as needed.
Try another location for the monitor.
Be sure all connections are secure.
Check 75 ohm high impedance select switch.

Adjust picture controls as needed.
Check pin assignments and connections.

Be sure all connections are secure.
Adjust volume.
Correct audio connections.
Adjust volume controls.
Press again to restore sound.

Secure all cable connections.
Check volume controls of all components.

Install new batteries.

Point remote control directly at Sensor Window.

Use the remote control unit within 30° left and right
of center (at a distance of within 22ft).

Set Pin no. 7 of DIP SW to ON/SHORT.

POWER/STANDBY indicator is
blinking

When in the EXT. CONTROL mode, the remote
control unit will not operate the monitor.

Horizontal and/or vertical sync signal is not present
when the Intelligent Power Manager control is on.

Set Pin no.6 of DIP SW to OFF/OPEN.

Check the input signal.

If the POWER/STANDBY indicator is blinking in red, turn off the monitor immediately and contact
your dealer or authorized NEC Service Center.

46

28

Specifications

Picture tube 36 inch Visual size; 37 inch CRT size (Diagonal), Type M90AHL50X

RGB Input Terminals RGB 1 : Mini D-SUB 15pin RGB 2: (R/CR/PR/,G/Y/Y,B/CB/PB, H/CS and V)

RGB Output Terminals Mini D-SUB 15 pin RGB 2 : BNC (R, G, B, H/CS and V)

THROUGH OUT

Video Input Terminals 1.0Vp-p, 75 Ohms unbalanced (BNC-Jack), Composite video signal, Sync-negative.

VIDEO 1/2 Y : 1.0Vp-p, 75 Ohms unbalanced, Sync-negative.
S-VIDEO (Video 1/2) C : 0.28Vp-p, 75 Ohms unbalanced, Color burst level.

47

108 degree deflection
Stripe trio pitch Ph 0.90 mm at center, Ph 1.10 mm at corner/Pv 0.7 mm
Invar mask, Medium-short persistence phosphor
Dynamic focus

: Video : Analog 0.7Vp-p/75 Ohms (Positive)

: Sync. : Separate Sync. TTL level, 0.7 - 4.0Vp-p/75 Ohms..........RGB 2 only

Horizontal Sync. (Positive/Negative)

Vertical Sync. (Positive/Negative)
: Composite Sync. TTL Level (Positive/Negative)
: Composite Sync. On Green Video 0.3Vp-p (Negative)

Video Output Terminals

THROUGH OUT (Video 1, 2) 1.0Vp-p, 75 Ohms unbalanced (BNC Jack), Composite video signal, Sync-negative.
THROUGH OUT (S-VIDEO 1, 2) Y : 1.0Vp-p, 75 Ohms unbalanced, Sync-negative.

C : 0.28Vp-p, 75 Ohms unbalanced, Color burst level.

Audio Input Terminals Left (Mono) : 0.5 Vrms, high impedance (Pin-Jack)

VIDEO 1, 2 / RGB Right : 0.5Vrms, high impedance (Pin-Jack)

Audio Output Terminals Left : 0.5 +0.1 Vrms, less than 22 K Ohms (Pin-Jack)

THROUGH OUT Right : 0.5 +0.1 Vrms, less than 22 K Ohms (Pin-Jack)

External Control mini D-SUB 15pin (IN/THROUGH OUT)

(IN/THROUGH OUT)

SOUND Output

Internal 2.5W+2.5W (THD 10%) at 16 Ohm
External 5W+5W (THD10%) at 8 Ohm

Speaker Oval type 9 X 5.5 cm

16 Ohm, 2pcs.

Display Colors Analog Input: Unlimited colors
Synchronization Range Horizontal: XP37Xtra; 15.7/31 KHz to 95 KHz XM37Xtra; 15.7/31 KHz to 65 KHz (Automatically)

Vertical:40 Hz to 120 Hz (Automatically)

48

29

Maximum Resolution RGB 1024( H) X768(V) pixels

VIDEO Horizontal: 500 lines /S-VIDEO Horizontal : 600 lines

Video Bandwidth RGB: 70 MHz at-3dB

YPBPR, YCBCR and RGB CTL : 25MHz at-3dB
VIDEO: 6 MHz at-3dB

Display Area RGB : 95% Scan (Typically)

VIDEO: 7% Overscan

Blanking Horizontal: 15.75kHz: 7.0µsec, 30kHz<fH<50kHz:3.3µsec,

51kHz<fH<80kHz:2.9µsec, 81kHz<fH<100kHz:2.7µsec

Vertical: 0.4 msec

Current Rating AC 100-120/220-240 V, 50/60 Hz
Power Consumption XP37 Xtra(XP-3791): 3.6 A (maximum) / XM37 Xtra(XM-3761): 3.6A (maximum)
Dimensions 872(W) x 744(H) x 625(D) mm / 34.4(W) x 29.3(H) x 24.6(D) inches
Weight 101 kg / 223 lbs
Environmental Considerations Operating Temperature : 0℃ to 40℃

Humidity : 0 to 90%
Altitude : 0 to 10,000 feet

Storage Temperature : -10℃ to 50℃

Humidity : 0 to 95%
Altitude : 0 to 45,000 feet

49

Regulations : UL/C-UL Approved (UL 1950/ CSA 950)

Meets FCC class B requirements
Meets DOC Canada Class B requirements
Meets DHHS requirements
Meets RED ACT

All specifications are subject to change without notice.

50

30

Dimensions

51

24.6''

(625mm)

29.3''

(744mm)

VIDEO 1 VIDEO 2 RGB AUDIO RGB 1

()

R

MONO

L

BNC S

BNC S

IN

IN

IN

THROUGH

THROUGH

OUT

THROUGH

OUT

OUT

R/CR/PRG/Y/Y B/VB/PBH/CS V
()
MONO

L

HIGH 75Ω

HIGH 75Ω

IN

AUDIO AUDIO

()

()

MONO

L

MONO

L

R

R

IN

IN

THROUGH

OUT

THROUGH

THROUGH

OUT

OUT

(400mm)

IN

THROUGH

OUT

HIGH 75Ω

RGB 2

HIGH 75ΩHIGH 75Ω

15.8''

SPEAKER SELECT

EXTERNAL CONTROL

REMOTE

INT EXT

IN

EXT SPEAKER

RIGHT LEFT

SPEAKRES MUST

THROUGH

HAVE MORE THAN

OUT
5WATT RATING
INPEDANCE 8 OHM

DIP SW

ON

12345678

AC IN

25.6''

(650mm)

34.4''

(872mm)

PROCEED VIDEO 1

VIDEO 2 RGB 1 RGB 2

▼▼

＋

EXIT

−

POWER

/STANDBY

3.6''(90mm)

18.3''

(463mm)

52

31

Timing Charts

Input Signal Reference Chart

Separate Sync.

HORIZONTAL

53

VIDEO

CD E

Composite Sync.

VERTICAL

HORIZONTAL

B

QR

P

C

B

A

VIDEO

O

VIDEO

DE

A

S

Sync. Polarity: Positive / Negative

VERTICAL

VIDEO

QR

P

O

S

Sync. Polarity: Positive / Negative

54

32

Composite Sync. & Video (Sync. on Green)

55

HORIZONTAL

B

C

VIDEO

D

A

E

VIDEO

VERTICAL

P

PQ

Recommended Sync Signal Timing

Horizontal sync duty should be 3 to 30%.
Horizontal sync width should exceed 0.9 µsec.
Horizontal back porch should exceed 2.0 µsec at sync on green and 1.2 µsec at others except when at 15KHz.
Horizontal blanking should exceed: 7.0µse at fH 15.75kHz, 3.3µsec at 30 kHz<fH<50kHz, 2.9µusec at 51kHz<fH<80kHz,
and 2.7µsec at 81kHz<fH<95kHz
Vertical sync duty should be 0.2 to 10%.
Vertical sync width should exceed 40 µsec or 2 horizontal lines.
Vertical sync width plus back porch should exceed 0.4 msec.
Interlaced signals are not recommended.
Interlaced signals with composite sync may not be displayed.

R

O

Sync. Polarity: Negative

S

56

33

Typical Input Signal Timing

57

Resolution

Horizontal Frequency

(A) Horizontal Period

(B) Horizontal Pulse Width

(C) Horizontal Back Porch

(D) Horizontal Active Area

(E) Hrizontal Front Porch

640×350

31.469KHz

31.778µsec

3.813µsec

1.589µsec

26.058µsec

0.318µsec

VGA Compatible

720×400

31.469KHz

31.778µsec

3.813µsec

1.589µsec

26.058µsec

0.318µsec

640×480

31.469KHz

31.778µsec

3.813µsec

1.589µsec

26.058µsec

0.318µsec

720×350

39.444KHz

25.352µsec

3.042µsec

1.522µsec

20.282µsec

0.508µsec

XGA-2 Compatible

720×400

39.444KHz

25.352µsec

3.042µsec

1.522µsec

20.282µsec

0.508µsec

640×480

39.375KHz

25.397µsec

3.048µsec

1.524µsec

20.317µsec

0.508µsec

Mac Ⅱ, Quadra,
or LC Compatible

640×480

35.000KHz

28.570µsec

2.120µsec

3.170µsec

22.810µsec

0.180µsec

VESA
640×480
at 72Hz

Resolution

Horizontal Frequency

(A) Horizontal Period

(B) Horizontal Pulse Width

(C) Horizontal Back Porch

(D) Horizontal Active Area

(E) Horizontal Front Porch

*VGA, XGA, XGA-2, and 8514/A are the trademarks of International Business Machines Corporation.
*Macintosh II, Quadra, and LC are the trademarks of Apple Computer Inc.
*VESA is the trademark of a non-profit organization, Video Electronics Standards Association.

640×480

37.860KHz

26.413µsec

1.270µsec

4.063µsec

20.317µsec

0.762µsec

VESA
800×600
at 56Hz

800×600

35.156KHz

28.444µsec

2.000µsec

3.556µsec

22.222µsec

0.667µsec

VESA
800×600
at 60Hz

800×600

37.879KHz

26.400µsec

3.200µsec

2.200µsec

20.000µsec

1.000µsec

VESA
800×600
at 72Hz

800×600

48.077KHz

20.800µsec

2.400µsec

1.280µsec

16.000µsec

1.120µsec

MAC Ⅱ
&
Quadra

832×624

49.725KHz

20.111µsec

1.117µsec

3.910µsec

14.524µsec

0.559µsec

8514/A & XGA
Interlaced
Compartible

1024×768

35.587KHz

28.100µsec

3.910µsec

1.247µsec

22.760µsec

0.178µsec

VESA
1024×768
at 60Hz

1024×768

48.363KHz

20.677µsec

2.092µsec

2.462µsec

15.754µsec

0.369µsec

HDTV

1028×720

45.000KHz

22.222µsec

1.077µsec

2.963µsec

17.226µsec

0.956µsec

HDTV
Interlaced

1920×1080

33.750KHz

29.630µsec

1.185µsec

1.993µsec

25.845µsec

0.606µsec

58

34

59

Resolution

Vertical Frequency

(O)Vertical Period

(P) Vertical Pulse Width

(Q)Vertical Back Porch

(R) Vertical Active Area

(S) Vertical Front Porch

640×350

70.080Hz

14.268msec

0.064msec

1.716msec

11.504msec

0.985msec

VGA Compatible

720×400

70.080Hz

14.268msec

0.064msec

0.890msec

13.156msec

0.159msec

640×480

59.940Hz

16.683msec

0.064msec

0.793msec

15.762msec

0.064msec

720×350

87.850Hz

11.383msec

0.051msec

1.496msec

8.873msec

0.963msec

XGA-2 Compatible

720×400

87.850Hz

11.383msec

0.051msec

0.862msec

10.141msec

0.329msec

640×480

75.000Hz

13.333msec

0.051msec

0.813msec

12.190msec

0.279msec

Mac Ⅱ, Quadra,
or LC Compatible

640×480

66.667Hz

15.000msec

0.090msec

1.110msec

13.710msec

0.090msec

Resolution

Vertical Frequency

(O) Vertical Period

(P) Vertical Pulse Width

(Q) Vertical Back Porch

(R) Vertical Active Area

(S) Vertical Front Porch

*1 First field
*2 Second field

VESA
640×480
at 72Hz

640×480

72.809Hz

13.735msec

0.079msec

0.740msec

12.678msec

0.238msec

VESA
800×600
at 56Hz

800×600

56.250Hz

17.778msec

0.057msec

0.626msec

17.067msec

0.028msec

VESA
800×600
at 60Hz

800×600

60.317Hz

16.579msec

0.106msec

0.607msec

15.840msec

0.026msec

VESA
800×600
at 72Hz

800×600

72.187Hz

13.853msec

0.125msec

0.478msec

12.480msec

0.770msec

MAC Ⅱ
&
Quadra

832×624

74.550Hz

13.414msec

0.060msec

0.784msec

12.549msec

0.020msec

8514/A & XGA
Interlaced
Compartible

1024×768

86.960Hz

11.499msec

0.112msec

0.577/

0.563msec

10.824msec

0.000/

0.014msec

VESA
1024×768
at 60Hz

1024×768

60.000Hz

16.667msec

0.124msec

0.600msec

15.880msec

0.062msec

HDTV

1280×720

60.000Hz

16.6667msec

0.1111msec

0.4444msec

16.0000msec

0.1111msec

HDTV
Interlaced

1920×1080

60.000Hz

16.6667µsec

0.1481µsec

0.444msec*

0.4593msec*

16.0148msec*

16.9852msec*

0.0593msec*

0.0741msec*

60

1

2

1

2

1

2

35

Signal Identification for Raster Preset

MODE1

15.5-21.0KHz

MODE2

31.0-33.0KHz

MODE3

33.0-37.0KHz

MODE4

37.0-43.0KHz

MODE5

43.0-49.0KHz

MODE6

49.0-54.0KHz

MODE7

54.0-58.0KHz

MODE8

58.0-64.0KHz

MODE9

64.0-74.0KHz

MODE10

74.0-85.0KHz

MODE11

85.0-100.0KHz

NOTE:
L=Without Sync
H=With Sync
''-'' =ignored

Polarity State Frequency

Hor

NEG
NEG
POS
POS
NEG
NEG
NEG
POS
POS
NEG
NEG
NEG
POS
POS
POS
NEG
NEG
NEG
POS
POS
NEG
NEG
NEG
POS
POS
NEG
NEG
NEG
POS
POS
NEG
NEG
NEG
POS
POS
NEG
NEG
NEG
POS
POS
NEG
NEG
NEG
POS
POS
NEG
NEG
NEG
POS
POS
NEG
NEG
NEG
POS
POS
NEG

-

-

Ver

NEG

POS

NEG

POS
NEG
NEG

POS
NEG

POS
NEG
NEG

POS
NEG

POS

POS
NEG
NEG

POS
NEG

POS
NEG
NEG

POS
NEG

POS
NEG
NEG

POS
NEG

POS
NEG
NEG

POS
NEG

POS
NEG
NEG

POS
NEG

POS
NEG
NEG

POS
NEG

POS
NEG
NEG

POS
NEG

POS
NEG
NEG

POS
NEG

POS
NEG

-

-

Hor

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

Factory : 15(13 preset for XM37 Xtra)
User : 22(20 preset for XM37 Xtra)

夝 : Multi preset (max:4preset)

Ver

61

NEC

Hor

-

­H
H
H
H
L
H
H
H
H
L
H
H
H
H
H
L
H
H
H
H
L
H
H
H
H
L
H
H
H
H
L
H
H
H
H
L
H
H
H
H
L
H
H
H
H
L
H
H
H
H
L
H
H
H
H
L

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

Ver

80 or less

80 or greater

PRESET

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

YES1
YES2

YES3

YES4

YES5

YES6

YES7

YES8

YES9

YES10

YES11

YES12

YES13

YES14

YES15

USER

PRESET

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

­YES10

-

­YES11

­YES12
YES13

-

-

­YES14

­YES15

-

-

-

-

-

-

YES16
YES17

­YES18

-

-

­YES19
YES20

-

-

-

­YES21

-

-

-

­YES22

-

VIDEO NTSC

YES1

VIDEO PAL/SECAM

YES2

夝
夝
夝
夝
夝

VESAI-Standard 640x480(31.5KHz/60Hz)

YES3

IBM 640x350 (31.5KHz/71Hz)

夝

IBM 640x400 (31.5KHz/71Hz)

夝
夝
夝

MAC 13" (35.00KHz/66.67Hz)

YES4

夝
夝

VESA 800x600 (35.156KHz/56.250Hz)

YES5

VESA 1024x768 (35.522KHz/43.479Hz)

夝

HDTV (33.75KHz/60Hz)

YES6

VESA 640x480 (37.50KHz/75.00Hz)

YES7

夝
夝

VESA 800x600 (37.89KHz/60.317Hz)

YES8

640x480 (38.4KHz/72Hz)

YES9

VESA 1024x768 (48.363KHz/60.004Hz)

夝
夝

VESA 800x600 (46.875KHz/75.000Hz)
HDTV (45.00KHz/60Hz)
MAC 16'' (49.7KHz/75Hz)

夝
夝
夝

MAC 16'' (49.7KHz/75Hz) Sync on green
VESA 1024x768 (56.476KHz/70.069Hz)

夝
夝
夝
夝

MAC 19'' (60.02KHz/75Hz)

夝
夝
夝

VESA 1024x768 (60.023KHz/75.029Hz)

PC98 1280x1024 (64.6KHz/60Hz)

夝
夝

VESA 1024x768 (68.677KHz/84.997Hz)

夝
夝
夝

VESA 1280x1024(79.976KHz/75.025Hz)

夝
夝
夝
夝

VESA 1600x1200 (93.75KHz/75.0Hz)

夝

REMARKSMODE

62

36

63

Service and Support Policies

NEC Technologies is committed to providing the highest quality service
and support for your MultiSync presentation monitor. A customer
service group that is dedicated to the support of this product line is
available to provide a single point of contact for technical support,
trouble shooting, service and repair issues.

Please address all questions concerning the following subjects to the
phone number listed below:

For technical support or any questions concerning the
operation of this product.

To arrange for on-site repair service during the warranty period
or after its expiration.

For the location of your nearest authorized NEC service center.
To report a DOA product and verify its status for return

authorization.

1-800-836-0655

Due to the size and weight of large screen presentation monitor
products, it is preferable to solve problems on-site rather than to incur
the expense and risk of damage in return shipping. NECís service
policies and procedures make it as effortless as possible for you to
receive factory authorized and trained service at your location.

On-site Service/Repair Policy

NEC offers on-site service and repair for all of our MultiSync presentation
monitor products of 37" and larger screen size. Warranty repair is
provided by our service-authorized Visual Systems Division Dealers and
network of factory-trained independent service providers. If you are
experiencing a problem with your monitor, please contact the
authorized NEC Visual Systems Division dealer from which it was
purchased. If this is a reseller who is unable to provide service, call NEC
directly at 1-800-836-0655.

DOA Policy

A product is considered DOA if it fails to function according to current
published specifications because of defects in NECTECH factory
materials and/or workmanship during the first 30 days from the date of
purchase by the end user. After the 30 day period any defective
product will be considered a warranty repair.

A product is NOT considered DOA if it is functional but the box is
damaged or it is missing contents such as manuals, cables, etc.

NECTECH reserves the right to repair rather than replace any
product.

Eligibility/Return for Exchange Procedure

If a product is suspected of being DOA, customers must call NECTECH
VSD Technical Support. A representative will assist in making the
product fully functional or verify it as a DOA.

VSD Technical Support 1-800-836-0655
NEC technical support will provide a procedure for repair instead of
exchange.

If the product is determined to be DOA, the Technical Support
Representative will request the following information in order to issue a
Material Return Authorization (MRA) number:

Product model number
Serial number
A complete description of the problem

If approved, an MRA number and return address will be issued. All
product to be returned must be shipped freight pre-paid in its original
carton to a designated NECTECH facility. The customer assumes the
risk of loss. The defective product must be received by NECTECH within
21 calendar days from the date the MRA was issued.

Any questions concerning service and repair policies or procedures
can also be addressed in writing to:

NEC Technologies
Visual Systems Division
Customer Service
1250 North Arlington Heights Road
Itasca, Illinois 60143

64

37

DECLARATION OF CONFORMITY

This device complies with Part 15 of FCC Rules. Operation is subject to the following two conditions. (1) This device may
not cause harmful interference, and (2) this device must accept any interference received, including interference that may
cause undesired operation.

U.S. Responsible Party:
Address:

Tel. No.:

Type of Product:

Equipment Classification:

Models:

NEC Technologies, Inc.
1250 North. Arlington Heights Road
Itasca, Illinois 60143-1248
[phone]

Multi media monitor

Class B Peripheral

XP-3791, XM-3761

We hereby declare that the equipment specified above

conforms to the technical standards as specified in the FCC Rules.

38
