External Control NEC LCD Monitor
Rev.1.2 (G3)
INDEX
I. Application
................................................................................ 4
II. Preparation
2. Connectors and wiring
2.1 RS-232C Remote control
2.2 LAN control
2.3 Multi Monitors Connection
III. Communication specification
3. Communication Parameter
3.1 RS-232C Remote control
3.2 LAN control
3.3 Communication timing
4. Communication Format
4.1 Header block format (fixed length)
4.2 Message block format
4.3 Check code
4.4 Delimiter
5. Message type
............................................................................... 5
.................................................................... 5
............................................................... 5
........................................................................... 5
............................................................... 7
................................................................ 7
............................................................... 7
........................................................................... 7
................................................................. 7
................................................................... 8
................................................................ 11
.......................................................................... 13
............................................................................ 14
........................................................................... 15
.............................................................. 6
...................................................... 9
5.1 Get current Parameter from a monitor.
5.2 "Get parameter" reply
5.3 Set parameter
5.4 "Set parameter" reply
5.5 Commands
5.5.1 Save Current Settings
5.5.2 Get Timing Report and Timing reply.
5.5.3 NULL Message
IV. Control Commands
6. Typical procedure example
6.1. How to change the “Backlight” setting.
6.2. How to read the measurement value of the built-in temperature sensors.
6.3. Operation Code (OP code) Table
6.4. Operation Code (OP code) Table for INPUT CONFIGURATION
7. Power control procedure
7.1 Power status read
........................................................................ 18
........................................................................... 20
....................................................................... 23
................................................................. 16
................................................................. 19
. ............................................................ 20
.................................................................... 22
............................................................... 23
................................................................. 45
.................................................................... 45
................................................. 15
................................................ 21
................................................ 23
....................................................... 29
............................. 44
.................. 26
7.2 Power control
........................................................................ 47
(1/130)
8. Asset Data read and write
................................................................ 49
8.1 Asset Data Read Request and reply
8.2 Asset Data write
9. Date & Time read and write
9.1 Date & Time Read
9.2 Date & Time Write
10. Schedule read and write
10.1 Schedule Read
10.2 Schedule Write
11. Self diagnosis
11.1 Self-diagnosis status read
12. Serial No. & Model Name Read
12.1 Serial No. Read
12.2 Model Name Read
13. Security Lock
13.1 Security Lock Control
14. Direct TV Chanel Read & Write
..................................................................... 51
.............................................................. 53
.................................................................... 53
.................................................................... 55
................................................................ 58
...................................................................... 58
...................................................................... 63
.......................................................................... 73
............................................................ 73
.......................................................... 75
...................................................................... 75
................................................................... 77
.......................................................................... 79
................................................................ 79
.......................................................... 81
.................................................... 49
14.1 Direct TV Chanel Read & Reply
14.2 Direct TV Chanel Write & Reply
15. Daylight Saving read & write
15.1 Daylight Saving Read
15.2 Daylight Saving Write
16. Firmware Version
16.1 Firmware Version Read
17. Auto ID
17.1 Auto ID Execute
17.2 Auto ID Complete
17.3 Auto ID Reset
18. Input Name
18.1 Input Name Read
18.2 Input Name Write
18.3 Input Name Reset
19. Power Save Mode
................................................................................ 89
...................................................................... 87
..................................................................... 89
.................................................................... 91
....................................................................... 93
............................................................................ 94
.................................................................... 94
.................................................................... 96
................................................................... 98
..................................................................... 100
............................................................ 83
................................................................ 83
................................................................ 85
.............................................................. 87
....................................................... 81
....................................................... 82
19.1 Power Save Mode Read
19.2 Power Save Mode Write
19.3 Auto Power Save Time Read
19.4 Auto Power Save Time Write
19.5 Auto Standby Time Read
............................................................. 100
............................................................. 102
............................................................ 107
......................................................... 104
........................................................ 105
(2/130)
19.6 Auto Standby Time Write
............................................................ 108
20. Setting Copy
20.1 Setting Copy Read
20.2 Setting Copy Write
20.3 Setting Copy Start
21. Security Enable
21.1 Security Enable Read
21.2 Security Enable Write
22. LAN MAC Address
22.1 LAN MAC Address Read
23. Proof of Play
23.1
Set Proof of Play Operation Mode
23.2
Get Proof of Play Current
23.3
Get Proof of Play Status
23.4 Get Proof of Play Number to Number
.......................................................................... 110
.................................................................. 110
.................................................................. 112
.................................................................. 114
....................................................................... 116
............................................................... 116
............................................................... 118
..................................................................... 120
............................................................. 120
.......................................................................... 122
......................................................... 124
......................................................... 126
................................................. 122
................................................. 128
(3/130)
I. Application
This document defines the communications method for control of the NEC LCD monitor, MultiSync X841UHD,
X981UHD, X651UHD when using an external controller.
(4/130)
II. Preparation
2. Connectors and wiring
2.1 RS-232C Remote control
Connector: 9-pin D-Sub
Cable: Cross (reversed) cable or null modem cable
(Please refer “Controlling the LCD monitor via RS-232C Remote control” on User’s manual.)
2.2 LAN control
Connector: RJ-45 10/100 BASE-T
Cable: Category 5 or higher LAN cable
(5/130)
2.3 Multi Monitors Connection
You can control multiple monitors by using RS-232C, REMOTE IN or LAN daisy-chain connection.
Mai n M onitor
Connector
IN OUT
RS-232C
LAN2
LAN1
Sub Monit ors
Connector
IN OUT
LAN1 LAN2 REMOTE IN
(Please refer “Controlling the LCD monitor via LAN control” on User’s manual.)
In this connection, a command is transmitted to the connected MultiSync on the following environment.
1.
AUTO ID function is performed on Main Monitor.
(Please refer “MULTI DISPLAY of OSD (On-Screen-Display) Controls” on User’s manual.)
2.
Destination byte of Command Header is "MONITOR ID = ALL", "GROUP ID" or "MONITOR ID of Sub Monitor".
(Please refer section 4.1.)
(6/130)
III. Communication specification
3. Communication Parameter
3.1 RS-232C Remote control
(1) Communication system Asynchronous
(2) Interface RS-232C
(3) Baud rate 9600bps
(4) Data length 8bits
(5) Parity None
(6) Stop bit 1 bit
(7) Communication code ASCII
3.2 LAN control
(1) Communication system TCP/IP (Internet protocol suite)
(2) Interface Ethernet (CSMA/CD)
(3) Communication layer Transport layer (TCP)
* Using the payload of TCP segment.
(4) IP address (Default) Automatic setup
* If you need to change,
Please refer “Network settings” on User’s manual.
(5) Port No. 7142 (Fixed)
(Note)
The monitor will disconnect the connection if no packet data is received for 15 minutes.
And the controller (PC) has to re-connect to control the monitor again, after 15 minutes or more.
3.3 Communication timing
The controller should wait for a reply packet before the next command is sent.
(Note)
When the following commands are sent, a controller should wait for specified period after receiving
the reply command before sending the next command.
l
Power On, Power Off: 15 seconds
l
Input, PIP Input, Auto Setup, Factory Reset: 10 seconds
(7/130)
Header
Delimiter
Set Parameter
Get Parameter Reply
Get Parameter
Header
Delimiter
Header
Delimiter
Header
Delimiter
Header
Delimiter
Header
Delimiter
Header
Delimiter
Header
Delimiter
Header
Delimiter
Header
Delimiter
4. Communication Format
Header Message Check Code Delimiter
The command packet consists of four parts, Header, Message, Check code and Delimiter.
Recommended sequence of a typical procedure to control a monitor is as follows,
[A controller and a monitor, two-way communication composition figure]
■ For the general command (see the part "6.3. Operation Code (OP code) Table”)
Get Parameter
Message
Check Code
Get Parameter Reply
Message
Check Code
Message
Check Code
Set Parameter Reply
Message
Check Code
Message
Check Code
Message
Check Code
Save Current Setting Command
Message
Check Code
Save Current Setting Command Reply
Message
Check Code
Monitor Controller
The controller sends command to
get a value from the monitor that
you want to change.
The monitor replies a current value
of the requested item.
The controller sends commands to
set an adjusted value.
The monitor replies to the
controller for confirmation.
The controller sends command to
get a value for confirmation.
The monitor replies an adjusted
value.
The controller requests to store
the adjusted value to the monitor.
The monitor replies to the
controller for confirmation.
■ For the special command (see the part 7 to 23. and 5.5.2)
Command
Message
Command Reply
Message
Check Code
Check Code
(8/130)
Monitor Controller
The control does not suitable for
above fixed protocol; use the
proper command for each control.
Please refer section 5.5 and
section 7 to 23.
The monitor replies a proper
message defined for each control.
Destination
Destination
Destination
Header
4.1 Header block format (fixed length)
Message Check code Delimiter
SOH Reserved
'0'
1st 2nd 3rd 4th 5th 6th -7th
Destination
Source Message
Type
Message
Length
1stbyte) SOH: Start of Header
ASCII SOH (01h)
nd
2
byte) Reserved: Reserved for future extensions.
On this monitor, it must be ASCII '0'(30h).
rd
3
byte) Destination: Destination equipment ID. (Receiver)
Specify a commands receiver’s address.
The controller sets the “MONITOR ID” or “GROUP ID” of the monitor controlled in here.
On the reply, the monitor sets ‘0’ (30h), always.
“MONITOR ID”, “GROUP ID” to “Destination Address” conversion table is as follows,
Monitor
ID
1 41h(‘A’) 26 5Ah(‘Z’) 51 73h 76 8Ch
2 42h(‘B’) 27 5Bh 52 74h 77 8Dh
3 43h(‘C’) 28 5Ch 53 75h 78 8Eh
4 44h(‘D’) 29 5Dh 54 76h 79 8Fh
5 45h(‘E’) 30 5Eh 55 77h 80 90h
6 46h(‘F’) 31 5Fh 56 78h 81 91h
7 47h(‘G’) 32 60h 57 79h 82 92h
8 48h(‘H’) 33 61h 58 7Ah 83 93h
9 49h(‘I’) 34 62h 59 7Bh 84 94h
10 4Ah(‘J’) 35 63h 60 7Ch 85 95h
11 4Bh(‘K’) 36 64h 61 7Dh 86 96h
12 4Ch(‘L’) 37 65h 62 7Eh 87 97h
13 4Dh(‘M’) 38 66h 63 7Fh 88 98h
14 4Eh(‘N’) 39 67h 64 80h 89 99h
15 4Fh(‘O’) 40 68h 65 81h 90 9Ah
16 50h(‘P’) 41 69h 66 82h 91 9Bh
17 51h(‘Q’) 42 6Ah 67 83h 92 9Ch
18 52h(‘R’) 43 6Bh 68 84h 93 9Dh
19 53h(‘S’) 44 6Ch 69 85h 94 9Eh
20 54h(‘T’) 45 6Dh 70 86h 95 9Fh
21 55h(‘U’) 46 6Eh 71 87h 96 A0h
22 56h(‘V’) 47 6Fh 72 88h 97 A1h
23 57h(‘W’) 48 70h 73 89h 98 A2h
24 58h(‘X’) 49 71h 74 8Ah 99 A3h
25 59h(‘Y’) 50 72h 75 8Bh 100 A4h
ALL 2Ah(‘*’)
Group
ID
A 31h(‘1’) D 34h(‘4’) G 37h(‘7’) J 3Ah(‘:’)
B 32h(‘2’) E 35h(‘5’) H 38h(‘8’)
C 33h(‘3’) F 36h(‘6’) I 39h(‘9’)
Destination
Address
Destination
Address
Monitor
ID
Group
ID
Address
Destination
Address
Monitor
ID
Group
ID
Destination
Address
Address
Monitor
ID
Group
ID
Address
Destination
Address
(9/130)
Ex.) If you want to control a monitor that has the "ID No." as '1', specify a destination address
'A'(41h). If you want to control all of the monitors which are connected by a daisy chain, specify
a destination address ‘*’(2Ah).
th
4
byte) Source: Source equipment ID. (Sender)
Specify a sender address.
The controller must be ‘0’ (30h).
On the reply, the monitor sets the own MONITOR ID in here.
th
5
byte) Message Type: (Case sensitive.)
Refer to section 4.2 “Message block format” for more details.
ASCII 'A' (41h): Command.
ASCII 'B' (42h): Command reply.
ASCII 'C' (43h): Get current parameter from a monitor.
ASCII 'D' (44h): "Get parameter" reply.
ASCII 'E' (45h): Set parameter.
ASCII 'F' (46h): "Set parameter" reply.
th
6
-7th bytes) Message Length:
Specify the length of the message (that follows the header) from STX to ETX.
This length includes STX and ETX.
The byte data must be encoded to ASCII characters.
Ex.) The byte data 3Ah must be encoded to ASCII characters '3' and 'A' (33h and 41h).
The byte data 0Bh must be encoded to ASCII characters '0' and 'B' (30h and 42h).
(10/130)
Message
Hi
Hi Lo Hi Lo Hi Lo Hi Lo
4.2 Message block format
“Message block format” is allied to the “Message Type” in the “Header”.
Refer to the section 4.1 “Header block format” for more detail.
1)Get current parameter
The controller sends this message when you want to get the status of the monitor.
For the status that you want to get, specify the “OP code page” and “OP code”,
refer to “Appendix A. Operation code table”.
“Message format” of the “Get current parameter” is as follows,
Ø
2)Get Parameter reply
The monitor will reply with the status of the requested item specified by the controller
in the “Get parameter message”.
“Message format” of the “Get parameter reply” is as follows,
STX Result OP code
Hi Lo Hi Lo Hi Lo Hi Lo MSB
Ø
STX OP code
page
Lo Hi Lo
Refer to section 5.1 “Get current parameter from a monitor.” for more details.
OP code
page
Refer to section 5.2 “Get parameter reply” for more details.
Header
OP code
Check code Delimiter
ETX
Type Max value Current Value ETX
LSB MSB
LSB
3)Set parameter
The controller sends this message to change a setting of the monitor.
Message format of the “Set parameter” is as follows,
STX
Ø
4)Set Parameter reply
The monitor replies with this message for a confirmation of the “Set parameter message”.
STX
5)Command
Result OP code
Ø
“Command message” format depends on each command.
OP code
page
Hi Lo Hi Lo MSB
Refer to section 5.3 “Set parameter” for more details.
Message format of the “Set parameter reply” is as follows,
page
Refer to section 5.4 “Set parameter reply” for more details.
OP code
OP code
Set Value ETX
LSB
Type Max value Requested setting
MSB
Value
LSB MSB
ETX
LSB
Usually, this “command message” is used for some non-slider controls and some special operations,
(11/130)
such as “Save current settings”, “Get timing report”, “power control”, “Schedule”, etc. Refer to
section 5.5 “Commands message” for more details.
6)Command reply
The monitor replies to a query from the controller.
“Command reply message” format depends on each command.
Refer to section 5.5 “Commands message” for more details.
(12/130)
Check code
n+1
Header
Message
Check
Delimiter
SOH Reserved
Destination
Sour
ce
Message
Message length
STX OP code
OP code
Set Value
ETX
0
8
9
10
11
12
13
14
15
16
17
4.3 Check code
Header Message
Check code is the Block Check Code (BCC) between the Header and the End of Message except SOH.
27 26 25 24 23 22 21 20
SOH D0
Reserved D1
Destination D2
Source D3
Type D4
Length(H) D5
Length(L) D6
STX D7
Data D8
| |
| |
ETX Dn
Check code D
P P P P P P P P
D
= D1 XOR D2 XOR D3 XOR ,,, D
n+1
n
XOR: Exclusive OR
Delimiter
Following is an example of a Check code (BCC) calculation.
code
Address
Address
type
page
(BCC)
01 30 41 30 45 30 41 02 30 30 31 30 30 30 36 34 03 77
D
D1 D2 D3 D4 D5 D6 D7 D
D
D
D
D
D
D
D
D
D
Check code (BCC) D
= D1 xor D2 xor D3 xor … xor D14 xor D15 xor D16
17
= 30h xor 41h xor 30h xor 45h xor 30h xor 41h
xor 02h xor 30h xor 30h xor 31h xor 30h xor 30h
xor 30h xor 36h xor 34h xor 03h
= 77h
0D
D18
(13/130)
Delimiter
4.4 Delimiter
Packet delimiter code; ASCII CR(0Dh).
Header Message Check code
(14/130)
Hi
5. Message type
5.1 Get current Parameter from a monitor.
STX OP code
page
Lo Hi Lo
1st 2nd-3rd 4th–5th 6th
OP code ETX
Send this message when you want to get the status of a monitor.
For the status that you want to get, specify the “OP code page” the “OP code”, refer to “Appendix
A. Operation code table”.
st
1
byte) STX: Start of Message
ASCII STX (02h)
nd-3rd
2
bytes) OP code page: Operation code page.
Specify the “OP code page” for the control which you want to get the status.
Refer to “Appendix A Operation code table” for each item.
OP code page data must be encoded to ASCII characters.
Ex.) The byte data 02h must be encoded to ASCII characters '0' and '2' (30h and 32h).
OP code page 02h -> OP code page (Hi) = ASCII '0' (30h)
OP code page (Lo) = ASCII '2' (32h)
Refer to Operation code table. (Appendix A)
th–5th
4
bytes) OP code: Operation code
Refer to “Appendix A Operation code table” for each item.
OP code data must be encoded to ASCII characters.
Ex.) The byte data 3Ah must be encoded to ASCII characters '3' and 'A' (33h and 41h).
OP code 3Ah -> OP code (Hi) = ASCII '3' (33h)
OP code (Lo) = ASCII 'A' (41h)
Refer to Operation code table.
th
6
byte) ETX: End of Message
ASCII ETX (03h)
(15/130)
Hi Lo Hi Lo Hi Lo Hi Lo
st
th
5.2 "Get parameter" reply
STX
Result OP code
OP code Type Max value Current Value ETX
page
MSB
1
2nd-3rd 4th–5th 6th –7th 8th -9th 10th -13th 14th -17th 18
LSB MSB
LSB
The monitor replies with a current value and the status of the requested item (operation code).
st
1
byte) STX: Start of Message
ASCII STX (02h)
nd-3rd
2
bytes) Result code.
These bytes indicate a result of the requested commands as follows,
00h: No Error.
01h: Unsupported operation with this monitor or unsupported operation under current condition.
This result code from the monitor is encoded to ASCII characters.
Ex.) The byte data 01h is encoded to ASCII character '0' and '1' (30h and 31h).
th–5th
4
bytes) OP code page: Operation code page.
These bytes indicate a replying item's OP code page.
This returned value from the monitor is encoded to ASCII characters.
Ex.) The byte data 02h is encoded to ASCII character '0' and '2' (30h and 32h).
Refer to the operation code table.
th
6
–7thbytes) OP code: Operation code
These bytes indicate a replying item's OP code.
This returned value from the monitor is encoded to ASCII characters.
Refer to the operation code table.
Ex.) The byte data 1Ah is encoded to ASCII character '1' and 'A' (31h and 41h).
th
8
-9thbytes) Type: Operation type code
00h: Set parameter
01h: Momentary
Like the Auto Setup function which automatically changes the parameter.
This returned value from the monitor is encoded to ASCII characters.
Ex.) The byte data 01h is encoded to ASCII character '0' and '1' (30h and 31h).
th
10
-13thbytes) Max. value: Maximum value which monitor can accept. (16bits)
This returned value from the monitor is encoded to ASCII characters.
Ex.) '0','1','2' and '3' means 0123h (291)
th
14
-17thbytes) Current Value: (16bits)
This returned value from the monitor is encoded to ASCII characters.
Ex.) '0','1','2' and '3' means 0123h (291)
(16/130)
18thbyte) ETX: End of Message
ASCII ETX (03h)
(17/130)
st
th
5.3 Set parameter
STX
OP code
OP code Set Value ETX
page
Hi Lo Hi Lo MSB
1
2nd-3rd 4th-5th 6th-9th 10
LSB
Send this message to change monitor’s adjustment and so on.
The controller requests a monitor to change value.
st
1
byte) STX: Start of Message
ASCII STX (02h)
nd-3rd
2
bytes) OP code page: Operation code page
This OP code page data must be encoded to ASCII characters.
Ex.) The byte data 02h must be encoded to ASCII '0' and '2' (30h and 32h).
Refer to the Operation code table.
th-5th
4
bytes) OP code: Operation code
This OP code data must be encoded to ASCII characters.
Ex.) OP code 1Ah -> OP code (Hi) = ASCII '1' (31h)
OP code (Lo) = ASCII 'A' (41h)
Refer to the Operation code table.
th-9th
6
bytes) Set value: (16bit)
This data must be encoded to ASCII characters.
Ex.) 0123h -> 1
2
3
4
th
10
byte) ETX: End of Message
st
(MSB) = ASCII '0' (30h)
nd
= ASCII '1' (31h)
rd
= ASCII '2' (32h)
th
(LSB) = ASCII '3' (33h)
ASCII ETX (03h)
(18/130)
st
th
5.4 "Set parameter" reply
STX
1
Result OP code
page
Hi Lo Hi Lo Hi Lo Hi Lo MSB
2nd-3rd 4th-5th 6th-7th 8th-9th 10th-13th 14th -17th 18
OP code Type Max value Requested setting
Value
LSB MSB
The Monitor echoes back the parameter and status of the requested operation code.
st
1
byte) STX: Start of Message
ASCII STX (02h)
nd-3rd
2
bytes) Result code
ASCII '0''0' (30h, 30h): No Error.
ASCII '0''1' (30h, 31h): Unsupported operation with this monitor or unsupported operation under
current condition.
th-5th
4
bytes) OP code page: Echoes back the Operation code page for confirmation.
Reply data from the monitor is encoded to ASCII characters.
Ex.) OP code page 02h -> OP code page = ASCII '0' and '2' (30h and 32h)
Refer to Operation code table.
th-7th
6
bytes) OP code: Echoes back the Operation code for confirmation.
Reply data from the monitor is encoded to ASCII characters.
ETX
LSB
Ex.) OP code 1Ah -> OP code (Hi) = ASCII '1' (31h)
OP code (Lo) = ASCII 'A' (41h)
Refer to Operation code table
th-9th
8
bytes) Type: Operation type code
ASCII '0''0' (30h, 30h): Set parameter
ASCII '0''1' (30h, 31h): Momentary
Like Auto Setup function, that automatically changes the parameter.
th
10
-13thbytes) Max. value: Maximum value that monitor can accept. (16bits)
Reply data from the monitor is encoded to ASCII characters.
Ex.) '0''1''2''3' means 0123h (291)
th
14
-17thbytes) Requested setting Value: Echoes back the parameter for confirmation. (16bits)
Reply data from the monitor is encoded to ASCII characters.
Ex.) '0''1''2''3' means 0123h (291)
th
18
byte) ETX: End of Message
ASCII ETX (03h)
(19/130)
5.5 Commands
"Command message format" depends on each command. Some commands are shown with usage. Refer to section
7 to 13.
5.5.1 Save Current Settings.
The controller requests for the monitor to store the adjusted value.
Command code
STX
'0' 'C'
Ø
Ø
ASCII: 01h-30h-41h-30h-41h-30h-34h-02h-30h-43h-03h-CHK-0Dh
The monitor replies the packet for confirmation as follows;
SOH-'0'-'0'-'A'-'B'-'0'-'6'-STX-'0'-'0'-'0'-'C'-ETX-CHK- CR
Send "OC"(30h, 43h) as Save current settings command.
Complete "Save Current setting" command packet as follows;
SOH-'0'-'A'-'0'-'A'-'0'-'4'-STX-'0'-'C'-ETX-CHK- CR
ETX
(20/130)
5.5.2 Get Timing Report and Timing reply.
The controller requests the monitor to report the displayed image timing.
STX
Ø
Ø
ASCII: 01h-30h-41h-30h-41h-30h-34h-02h-30h-37h-03h-CHK-0Dh
The monitor replies status as the following format;
STX
Ø
Ø
Ø
Command code
'0' '7'
Send "07"(30h, 37h) as Get Timing Report command.
Complete "Get Timing Report" command packet as follows;
SOH-'0'-'A'-'0'-'A'-'0'-'4'-STX-'0'-'7'-ETX-CHK- CR
Command SS H Freq. V Freq. ETX
'4' 'E' Hi Lo MSB
SS: Timing status byte
Bit 7 = 1: Sync Frequency is out of range.
Bit 6 = 1: Unstable count
Bit 5-2 Reserved (Don't care)
Bit 1 1:Positive Horizontal sync polarity.
0:Negative Horizontal sync polarity.
Bit 0 1:Positive Vertical sync polarity.
0:Negative Vertical sync polarity.
H Freq: Horizontal Frequency in unit 0.01kHz
V Freq: Vertical Frequency in unit 0.01Hz
ETX
LSB
MSB
LSB
Ex.) When H Freq is '1''2''A''9' (31h, 32h, 41h, 39h), it means 47.77kHz.
(21/130)
5.5.3 NULL Message
STX
The NULL message returned from the monitor is used in the following cases;
Ø
Ø
Ø
Ø
01h-30h-30h-41h-42h-30h-34h-02h-42h-45h-03h-CHK-0Dh
SOH-'0'-'0'-'A'-'B'-'0'-'4'-STX-'B'-'E'-ETX-CHK- CR
Command code
'B' 'E'
To tell the controller that the monitor does not have any answer to give to the host (not
ready or not expected)
A null message will be returned by the monitor if the “Start Proof of Play” command is sent
and the monitor has already started Proof of Play.
A null message will be returned by the monitor if the “Stop Proof of Play” command is sent
and the monitor has not started Proof of Play.
Complete "NULL Message" command packet as follows;
ETX
(22/130)
IV. Control Commands
6. Typical procedure example
The following is a sample of procedures to control the monitor, these are examples of "Get parameter",
"Set parameter" and "Save current settings".
6.1. How to change the “Backlight” setting.
Step 1. The controller requests the Monitor to reply with the current brightness setting and capability
to support this operation. (Get parameter)
Header Message Check code
SOH-'0'-Monitor ID-
'0'-'C'-'0'-'6'
Header
SOH (01h): Start of Header
'0' (30h): Reserved
Monitor ID: Specify the Monitor ID from which you want to get a value.
Ex.) If Monitor ID is '1', specify 'A'.
'0' (30h): Message sender is the controller.
'C' (43h): Message type is "Get parameter command".
'0'-'6' (30h, 36h): Message length is 6 bytes.
Message
STX (02h): Start of Message
'0'-'0' (30h, 30h): Operation code page number is 0.
'1'-'0' (31h, 30h): Operation code is 10h (in the OP code page 0).
ETX (03h): End of Message
Check code
BCC: Block Check Code
Refer to the section 4.3 “Check code” for a BCC calculation.
Delimiter
CR (0Dh): End of packet
Step 2. The monitor replies with current Backlight setting and capability to support this operation.
Header Message Check code
SOH-'0'-'0'-Monitor ID-
'D'-'1'-'2'
Header
SOH (01h): Start of Header
'0' (30h): Reserved
'0' (30h): Message receiver is the controller.
Monitor ID: Indicate a replying Monitor ID.
Ex.) When this byte is set to 'A', the replying Monitor ID is '1'.
'D' (44h): Message Type is "Get parameter reply".
'1'-'2' (31h, 32h): Message length is 18 bytes.
Message
STX (02h): Start of Message
'0'-'0' (30h, 30h): Result code. No error.
'0'-'0' (30h, 30h): Operation code page number is 0.
'1'-'0' (31h, 30h): Operation code is 10h (in the page 0).
'0'-'0' (30h, 30h): This operation is "Set parameter" type.
'0'-'0'-'6'-'4' (30h, 30h, 36h, 34h): Backlight max value is 100(0064h).
'0'-'0'-'3'-'2' (30h, 30h, 33h, 32h): Current Backlight setting is 50(0032h) .
ETX (03h): End of Message
Check code
BCC: Block Check Code
Refer to the section 4.3 “Check code” for a BCC calculation.
STX-'0'-'0'-'1'-'0'-ETX BCC CR
STX-'0'-'0'-'0'-'0'-'1'-'0'-'0'-'0'
-'0'-'0'-'6'-'4'-'0'-'0'-'3'-'2'-ETX
Delimiter
Delimiter
BCC CR
(23/130)
Delimiter
CR (0Dh): End of packet
Step 3. The controller request the monitor to change the Backlight setting
Header Message Check code
SOH-'0'-Monitor ID-
'0'-'E'-'0'-'A'
Header
SOH (01h): Start of Header
'0' (30h): Reserved
Monitor ID: Specify the Monitor ID of which you want to change a setting.
Ex.) If Monitor ID is '1', specify 'A'.
'0' (30h): Message sender is the controller.
'E' (45h): Message Type is "Set parameter command".
'0'-'A' (30h, 41h): Message length is 10 bytes.
Message
STX (02h): Start of Message
'0'-'0' (30h, 30h): Operation code page number is 0.
'1'-'0' (31h, 30h): Operation code is 10h (in the page 0).
'0'-'0'-'5'-'0' (30h, 30h, 35h, 30h): Set Backlight setting 80(0050h).
ETX (03h): End of Message
Check code
BCC: Block Check Code
Refer to the section 4.3 “Check code” for a BCC calculation.
Delimiter
CR (0Dh): End of packet
Step 4. The monitor replies with a message for confirmation.
Header Message Check
SOH-'0'-'0'- Monitor ID –
'F'-'1'-'2'
Header
SOH (01h): Start of Header
'0' (30h): Reserved
'0' (30h): Message receiver is the controller.
Monitor ID: Indicate a replying Monitor ID.
Ex.) When this byte is set to 'A', the replying Monitor ID is '1'.
'F' (46h): Message Type is "Set parameter reply".
'1'-'2' (31h, 32h): Message length is 18 bytes.
Message
STX (02h): Start of Message
'0'-'0' (30h, 30h): Result code. No error.
'0'-'0' (30h, 30h): Operation code page number is 0.
'1'-'0' (31h, 30h): Operation code is 10h (in the page 0).
'0'-'0' (30h, 30h): This operation is "Set parameter" type.
'0'-'0'-'6'-'4' (30h, 30h, 36h, 34h): Backlight max value is 100(0064h).
'0'-'0'-'5'-'0' (30h, 30h, 35h, 30h): Received a Backlight setting was 80(0050h) .
ETX (03h): End of Message
Check code
BCC: Block Check Code
Refer to the section 4.3 “Check code” for a BCC calculation.
Delimiter
CR (0Dh): End of packet
STX-'0'-'0'-'1'-'0'-
'0'-'0'-'5'-'0'-ETX
STX-'0'-'0'-'0'-'0'-'1'-'0'—'0'-'0'-
'0'-'0'-'6'-'4'-'0'-'0'-'5'-'0'-ETX
BCC CR
Delimiter
code
BCC CR
Delimiter
(24/130)
Ø
Repeat Step 1 and Step 2, if you need to check the Backlight setting. (Recommended)
Step 5. Request the monitor to store the Backlight setting. (Save Current Settings Command)
Header Message Check code
SOH-'0'-Monitor ID-
'0'-'A'-'0'-'4'
Header
SOH (01h): Start of Header
'0' (30h): Reserved
Monitor ID: Specify the Monitor ID which you want to store the setting.
Ex.) If Monitor ID is '1', specify 'A'.
'0' (30h): Message sender is the controller.
'A' (41h): Message type is "Command".
'0'-'4' (30h, 34h): Message length is 4 bytes.
Message
STX (02h): Start of Message
'0'-'C' (30h, 43h): Command code is 0Ch as "Save current settings".
ETX (03h): End of Message
Check code
BCC: Block Check Code
Refer to the section 4.3 “Check code” for a BCC calculation.
Delimiter
CR (0Dh): End of packet
STX-'0-'C'-ETX BCC CR
Delimiter
(25/130)
6.2. How to read the measurement value of the built-in temperature sensors.
MultiSync X841UHD, X981UHD, X651UHD have three built-in temperature sensors.
The controller can monitor inside temperatures by using those sensors with external control.
The following shows the procedure for reading the temperatures from the sensors.
Step 1. Select a temperature sensor which you want to read.
Header Message Check code
SOH-'0'-Monitor ID-
'0'-'E'-'0'-'A'
Header
SOH (01h): Start of Header
'0' (30h): Reserved
Monitor ID: Specify the Monitor ID which you want to get a value.
Ex.) If Monitor ID is '1', specify 'A'.
'0' (30h): Message sender is the controller.
'E' (45h): Message Type is "Set parameter command".
'0'-'A' (30h, 41h): Message length is 10 bytes.
Message
STX (02h): Start of Message
'0'-'2' (30h, 32h): Operation code page number is 2.
'7'-'8' (37h, 38h): Operation code is 78h (on page 2).
'0'-'0'-'0'-'1' (30h, 30h, 30h, 31h): Select the temperature sensor #1 (01h).
00h: No meaning
01h: Sensor #1
02h: Sensor #2
03h: Sensor #3
ETX (03h): End of Message
Check code
BCC: Block Check Code
Refer to the section 4.3 “Check code” for a BCC calculation.
Delimiter
CR (0Dh): End of packet
Step 2. The monitor replies for confirmation.
STX-'0'-'2'-'7'-'8'-
'0'-'0'-'0'-'1'-ETX
BCC CR
Delimiter
Header Message Check code Delimiter
SOH-'0'-'0'-Monitor ID-
'F'-'1'-'2'
Header
SOH (01h): Start of Header
'0' (30h): Reserved
'0' (30h): Message receiver is the controller.
Monitor ID: Indicates a replying Monitor ID.
Ex.) When this byte is set to 'A', the replying Monitor ID is '1'.
'F' (46h): Message Type is "Set parameter reply".
'1'-'2' (31h, 32h): Message length is 18 bytes.
Message
STX (02h): Start of Message
'0'-'0' (30h, 30h): Result code. No error.
'0'-'2' (30h, 32h): Operation code page number is 2.
'7'-'8' (37h, 38h): Operation code is 78h (in the page 2).
'0'-'0' (30h, 30h): This operation is "Set parameter" type.
STX-'0'-'0'-'0'-'2'-'7'-'8'-'0'-'0'-
'0'-'0'-'0'-'3'-'0'-'0'-'0'-'1'-ETX
(26/130)
BCC CR
'0'-'0'-'0'-'3' (30h, 30h, 30h, 33h): Number of temperature sensors are 3 (0003h).
'0'-'0'-'0'-'1' (30h, 30h, 30h, 31h): temperature sensor is #1.
ETX (03h): End of Message
Check code
BCC: Block Check Code
Refer to the section 4.3 “Check code” for a BCC calculation.
Delimiter
CR (0Dh): End of packet
Step 3. The controller requests the monitor to send the temperature from the selected sensor.
Header Message Check code
SOH-'0'-Monitor ID-
'0'-'C'-'0'-'6'
Header
SOH (01h): Start of Header
'0' (30h): Reserved
Monitor ID: Specify the Monitor ID which you want to get a value.
Ex.) If Monitor ID is '1', specify 'A'.
'0' (30h): Message sender is the controller.
'C' (43h): Message Type is "Get parameter".
'0'-'6' (30h, 36h): Message length is 6 bytes.
Message
STX (02h): Start of Message
'0'-'2' (30h, 32h): Operation code page number is 2.
'7'-'9' (37h, 39h): Operation code is 79h (in the page 2).
ETX (03h): End of Message
Check code
BCC: Block Check Code
Refer to the section 4.3 “Check code” for a BCC calculation.
Delimiter
CR (0Dh): End of packet
Step 4. The monitor replies a temperature of selected sensor.
Header Message Check code
SOH-'0'-'0'-Monitor ID-
'D'-'1'-'2'
Header
SOH (01h): Start of Header
'0' (30h): Reserved
'0' (30h): Message receiver is the controller.
Monitor ID: Indicate a replying Monitor ID.
Ex.) When this byte is set to 'A', the replying Monitor ID is '1'.
'D' (44h): Message Type is "Get parameter reply".
'1'-'2' (31h, 32h): Message length is 18 bytes.
Message
STX (02h): Start of Message
'0'-'0' (30h, 30h): Result code. No error.
'0'-'2' (30h, 32h): Operation code page number is 2.
'7'-'9' (37h, 39h): Operation code is 79h (in the page 2).
'0'-'0' (30h, 30h): This operation is "Set parameter" type.
'F'-'F'-'F'-'F' (46h, 46h, 46h, 46h): Maximum value.
'0'-'0'-'3'-'2' (30h, 30h, 33h, 32h): The temperature is 25 degrees Celsius.
STX-'0'-'2'-'7'-'9'-ETX BCC CR
STX-'0'-'0'-'0'-'2'-'7'-'9'-'0'-'0'
-'F'-'F'-'F'-'F'-'0'-'0'-'3'-'2'-ETX
Delimiter
Delimiter
BCC CR
(27/130)
Readout value is 2's complement.
ETX (03h): End of Message
Check code
BCC: Block Check Code
Refer to the section 4.3 “Check code” for a BCC calculation.
Delimiter
CR (0Dh): End of packet
Temperature [Celsius]
+125.0 0000 0000 1111 1010 00FAh
+ 25.0 0000 0000 0011 0010 0032h
+ 0.5 0000 0000 0000 0001 0001h
0 0000 0000 0000 0000 0000h
- 0.5 1111 1111 1111 1111 FFFFh
- 25.0 1111 1111 1100 1110 FFCEh
- 55.0 1111 1111 1001 0010 FF92h
Readout value
Binary Hexadecimal
(28/130)
6.3. Operation Code (OP code) Table
Item OP
code
page
BACKLIGHT 00h 10h 0: dark
CONTRAST 00h 12h 0: low
SHARPNESS 00h 8Ch 0: dull
BRIGHTNESS 00h 92h 0: dark
COLOR TEMPERATURE 00h 54h 0:2600K
COLOR TEMPERATURE
(CUSTOM)
R GAIN 00h 16h 0: Dark
B GAIN 00h 18h 0: Dark
G GAIN 00h 1Ah 0: Dark
COLOR CONTROL 00h RED:
PICTU R E
GAMMA CORRECTION 02h 68h 0: No mean
UHD UPSCALING 11h 09h 0: No mean
00h 14h 9: 10000K
OP code Parameter Remarks
9Bh
YELLOW:
9Ch
GREEN:
9Dh
CYAN:
9Eh
BLUE:
9Fh
MAGENTA:
A0h
|
100(64h): bright
|
100(64h): high
|
24(18h): sharp
|
100(64h): bright
|
74(4Ah):10000K
11(0Bh): CUSTOM
|
255(FFh): Bright
|
255(FFh): Bright
|
255(FFh): Bright
0:
|
100(64h):(center)
|
200(C8h):
1: NATIVE
4: 2.2
8: 2.4
7: S GAMMA
5: DICOM SIM.
6: PROGRAMABLE1
13(0Dh): PROGRAMABLE2
14(0Eh): PROGRAMABLE3
1: LOW
2: MIDDLE
3: HIGH
100K/step
(29/130)
Item OP
code
page
PICTURE MODE 02h 1Ah 0: No mean
SVE-(1-5)
SETTINGS
PRESET 10h 51h 0: No mean
LUMINANCE 02h B3h 0(0%): Dark
WHITE 00h 54h 0:2600K
00h 14h 2: NAVIVE
WHITE x 10h 52h 250(00FAh): 0.250
WHITE y 10h 53h 250(00FAh): 0.250
GAMMA 02h 68h 0: No mean
CUSTOM VALUE 02h E8h 0: 0.5(MIN)
BLACK 10h 54h 1: 0.1(MIN)
RED x 10h 55h 550(0226h): 0.550
RED y 10h 56h 200(00C8h): 0.200
GREEN x 10h 57h 100(0064h): 0.100
OP code Parameter Remarks
1: sRGB
3: HIGHBRIGHT
4: STANDARD
5: CINEMA
8: CUSTOM1
9: CUSTOM2
13(0Dh): SVE-1 SETTING
14(0Eh): SVE-2 SETTING
15(0Fh): SVE-3 SETTING
16(10h): SVE-4 SETTING
17(11h): SVE-5 SETTING
1: sRGB
2: Adobe RGB SIM
3: DCI SIM
4: REC-Bt709
5: HIGHBRIHGT
6: FULL
7: DICOM SIM
8: PROGRAMMABLE1
9: PROGRAMMABLE2
10(0Ah): PROGRAMMABLE3
11(0Bh): PROGRAMMABLE4
12(0Ch): PROGRAMMABLE5
13(0Dh): eciRGB v2
|
600(0258h)(100%): Bright
Note: Conversion equation
Value = (OSD Value/100)
*(600-40)+40
|
74(4Ah):10000K
11(0Bh): CUSTOM
|
480(01E0h): 0.480
|
480(01E0h): 0.480
5: DICOM SIM.
9: CST
11(0Bh): sRGB
12(0Ch): L STAR
|
350(015Eh): 4.0(MAX)
|
50(32h): 5.0(MAX)
|
800(0320h): 0.800
|
400(0190h): 0.400
|
350(015Eh): 0.350
sRGB:
PC mode
only
CINEMA:
A/V mode
only
(30/130)
Item OP
code
page
GREEN y 10h 58h 500(01F4h): 0.500
BLUE x 10h 59h 0: 0.000
BLUE y 10h 5Ah 0: 0.000
COLOR VISION EMU 10h 5Bh 0: No mean
UNIFORMITY 02h EEh 0: OFF
METAMERISM 10h 5Ch 0: No mean
RESET
(PICTURE)
ASPECT 02h 70h 0: No mean
Zoom Control ZOOM 11h 2Ch 0-89(59h): No mean
02h CBh 0: No mean
OP code Parameter Remarks
|
900(0384h): 0.900
|
250(00FAh): 0.250
|
150(0096h): 0.150
1: OFF
2: P
3: D
4: T
5: GRAY
|
5
1: OFF
2: ON
2: Reset Picture category
1: NORMAL
2: FULL
3: WIDE
4: ZOOM
6: DYNAMIC
7: 1:1
90(5Ah): 90%
91(5Bh): 91%
|
100(64h): 100%
|
300(12Ch): 300%
ADJUS T
H ZOOM 11h 2Dh 0-89(59h): No mean
90(5Ah): 90%
91(5Bh): 91%
|
100(64h): 100%
|
300(12Ch): 300%
Momentary
Wide:
Dynamic
A/V mode only
The
following
commands can
also be used.
OP code page
02h
OP code 6Fh
Parameter
0: No mean
1: 100%
2: 101%
|
201(C9h):
300%
The
following
commands can
also be used.
OP code page
02h
OP code 6Ch
Parameter
0: No mean
1: 100%
2: 101%
|
201(C9h):
300%
(31/130)
Item OP
code
page
V ZOOM 11h 2Eh 0-89(59h): No mean
H POS 02h CCh 0: Left side
V POS 02h CDh 0: Down side
IMAGE FLIP 02h D7h 0: No mean
OSD FLIP 10h B8h 0: No mean
RESET
(ADJUST)
VOLUME 00h 62h 0: whisper
BALANCE
TREBLE 00h 8Fh O: Min.
BASS 00h 91h 0: Min.
AUDI O
SURROUND 02h 34h 0: No mean
MULTI PICTURE AUDIO 10h 80h 0: No mean
LINE OUT 10h 81h 0: No mean
02h CBh 0: No mean
00h 93h O: Left
00h 94h 0: No mean
OP code Parameter Remarks
90(5Ah): 90%
91(5Bh): 91%
|
100(64h): 100%
|
300(12Ch): 300%
|
200(C8h): Right side
|
200(C8h): Up side
1: NONE
2: H FLIP
3: V FLIP
4: 180 ROTATE
1: OFF
2: ON
3: Reset Adjust category
|
100(64h): loud
|
30(1Eh):(Center)
|
60(3Ch): Right
1: MONAURAL
2: STEREO
|
6:(Center)
|
12(0Ch): Max.
|
6:(Center)
|
12(0Ch): Max.
1: OFF
2: ON
3: PICTURE1
4: PICTURE2
5: PICTURE3
6: PICTURE4
1: FIXED
2: VARIABLE
The
following
commands can
also be used.
OP code page
02h
OP code 6Dh
Parameter
0: No mean
1: 100%
2: 101%
|
201(C9h):
300%
Momentary
(32/130)
Item OP
code
page
AUDIO INPUT 02h 2Eh 0: No mean
AUDIO DELAY 10h CAh 0: No mean
DELAY TIME 10h CBh 0: (small)
RESET
(AUDIO)
OFF TIMER 02h 2Bh 0: Off
SCHEDULE
ENABLE 02h E5h 0: No mean
DISABLE 02h E6h 0: No mean
02h CBh 0: No mean
OP code Parameter Remarks
SCHDU L E
SCHEDULE SETTINGS Refer to section 10
DATE & TIME Refer to section 9
DAYLIGHT SAVING Refer to section 9 and 15
RESET
(SCHEDULE)
KEEP MULTI PICTURE MODE 10h 82h 0: No mean
MULTI PICTURE 02h 72h 0: No mean
PICTURE NUMBER
/ PICTURE MODE
MULTI PIC T URE CON T RO L
ACTIVE PICTURE 11h 0Bh 0: No mean
ACTIVE FRAME 11h 0Dh 0: No mean
02h CBh 0: No mean
1: Off
2: PIP
5: PBP (PBP1, PBP2, PBP3)
10h B5h If MULTI PICTURE is set PIP
0: No mean
2: 2WINDOWS, PIP
3: 3WINDOWS, PIP
If MULTI PICTURE is set PBP
0: No mean
1: 2WINDOWS, PBP1
3: 3WINDOWS, PBP1
4: 3WINDOWS, PBP2
5: 3WINDOWS, PBP3
6: 4WINODWS, PBP1
1: PICTURE1
2: PICTURE2
3: PICTURE3
4: PICTURE4
1: OFF
2: ON
1: LINE IN
4: HDMI
6: OPTION
7: DPORT
8: DPORT2
10(0Ah): HDMI2
11(0Bh): HDMI3
12(0Ch): HDMI4
1: OFF
2: ON
|
100(64h): (large)
Momentary
4: Reset Audio category
1 hour/step
1: 1 hour
|
24(18h): 24 hours
1: No.1 Enable
|
7: No.7 Enable
1: No.1 Disable
|
7: No.7 Disable
Momentary
5: Reset
Schedule category
1: OFF
2: ON
(33/130)
Item OP
code
page
INPUT SELECT
PICTURE SIZE 10h B9h 0(small)
POSITION
PICTURE ASPECT 10h 83h 0: No mean
ROTATE ROTATE ALL 11h 16h 0: No mean
TEXT TICKER MODE 10h 08h 0: No mean
RESET
(PIP)
PICTURE1 11h 0Eh 0: No mean
PICTURE2 11h 0Fh
PICTURE3 11h 10h
PICTURE4 11h 11h
X 02h 74h 0: left
Y 02h 75h 0: top
PICTURE1 11h 12h
PICTURE2 11h 13h
PICTURE3 11h 14h
PICTURE4 11h 15h
POSITION 10h 09h 0: Top/Left
SIZE 10h 0Ah 0-1: Do not set.
DETECT 10h 0Ch 0: No mean
PICTURE1 11h 2Ah 0: No mean
PICTURE2 11h 2Bh
02h CBh 0: No mean
OP code Parameter Remarks
3: DVI1
4: DVI2
13(0Dh): OPTION
15(0Fh): DPORT
16(10h): DPORT2
17(11h): HDMI1
18(12h): HDMI2
130(82h): HDMI3
131(83h): HDMI4
3: DVI1
4: DVI2
13(0Dh): OPTION
15(0Fh): DPORT
16(10h): DPORT2
17(11h): HDMI1
18(12h): HDMI2
130(82h): HDMI3
131(83h): HDMI4
|
80(large)
|
100(64h): right
|
100(64h): bottom
1: NORMAL
2: FULL
3: WIDE
4: ZOOM
1: OFF
2: ON
1: OFF
2: HORIZONTAL
3: VERTICAL
|
100(64h): Bottom/Right
2: Narrow(2/24)
|
8: Wide(8/24)
1: AUTO
2: OFF
Momentary
6: Reset PIP Category
(34/130)
Item OP
OP code Parameter Remarks
code
page
LANGUAGE 00h 68h 0: No mean
1: ENGLISH
2: GERMAN
3: FRENCH
4: SPANISH
5: JAPANESE
6: ITALIAN
7: SWEDISH
9: RUSSIAN
14(0Eh): CHINESE
MENU DISPLAY TIME 00h FCh 0-1: Do not set.
2: 10s
3: 15s
|
48(30h): 240s
OSD POSITION X 02h 38h 0: Left
|
255(FFh): Right
Y 02h 39h 0: Down
|
255(FFh): Up
INFORMATION OSD 02h 3Dh 0:Disable information OSD
3-10(0Ah):
OSD timer [seconds]
MONITOR
MODEL NAME Refer to section 12
INFORMATION
OS D
SERIAL Refer to section 12
FIRMWARE1 Refer to section 16
FIRMWARE2
FIRMWARE3
FIRMWARE4
CARBON
SAVINGS
10h 10h
(g)
0 – 999(3E7h)(g)
0 – 65535(FFFF
ｈ
)(kg)
/11h
(kg)
CARBON
USAGE
10h 26h
(g)
/27h
0 – 999(3E7
ｈ
0 – 65535(FFFF
)(g)
ｈ
)(kg)
(kg)
OSD TRANSPARENCY 02h B8h 0: No mean
1: OFF
2: ON
OSD ROTATION 02h 41h 0: Landscape
1: Rotated
INPUT NAME Refer to section 18
NAME RESET
MEMO 10h BAh 0: No mean
1: Display a Memo
2: Undisplay a Memo
RESET
(OSD)
02h CBh 0: No mean
7: Reset OSD category
MONITOR ID 02h 3Eh 1-100:ID
GROUP ID 10h 7Fh 0: No assignment
1: Group A
2: Group B
3: Group AB
4: Group C
5: Group AC
MULTI DIS P LA Y
|
1023(3FFh):Group
ABCDEFGHIJ
OSD Language
5sec/step
Read Only
Read Only
Momentary
Bit0:Group A
Bit1:Group B
Bit2:Group C
Bit3:Group D
Bit4:Group E
Bit5:Group F
Bit6:Group G
Bit7:Group H
Bit8:Group I
Bit9:Group J
(35/130)
Item OP
code
page
IR LOCK
SETTING
POWER ON DELAY 02h D8h 0: Off (0sec)
LINK TO ID 10h BCh 0: No mean
POWER INDICATOR 02h BEh 0: No mean
SETTING COPY Refer to section 20
RESET
(MULTI DISPLAY)
POWER SAVE Refer to section 19
HEAT
STATUS
MODE SELECT 10h D4h 0: No mean
POWER 10h D5h 0: No mean
VOLUME 10h D6h 0: No mean
MIN VOL 10h D7h 0 (whisper)
MAX VOL 10h D8h 0 (whisper)
INPUT 10h D9h 0: No mean
UNLOCK SELECT 10h DAh 0: No mean
10h DBh
10h DCh
02h CBh 0: No mean
FAN1/2/3 02h 7Ah
DISPL A Y P R OTE CTIO N
BACKLIGHT Refer to section 11 (Self-diagnosis status read)
OP code Parameter Remarks
1: UNLOCK
2: ALL LOCK
3: CUSTOM LOCK
1: UNLOCK
2: LOCK
1: UNLOCK
2: LOCK
|
100(64h) (laud)
|
100(64h) (laud)
1: UNLOCK
2: LOCK
3: DVI1
4: DVI2
13(0Dh): OPTION
15(0Fh): DPORT
16(10h): DPORT2
17(11h): HDMI1
18(12h): HDMI2
130(82h): HDMI3
131(83h): HDMI4
132(84h): PRESET1
133(85h): PRESET2
134(86h): PRESET3
|
50(32h): 50sec
1: OFF
2: ON
1: ON
2: OFF
8: Reset Multi Display
Category
Select target FAN. (7Ah)
/7Bh
0: No mean
1: FAN#1
2: FAN#2
3: FAN#3
Read status of target
FAN.(7Bh)
0: OFF
1: ON
2: ERROR
The
following
commands can
also be used.
OP code page
02h
OP code 3Fh
Parameter
0: No mean
1: NORMAL
4: LOCK
Momentary
Read Only
(36/130)
offset from max.
offset from max.
offset from max.
Item OP
code
page
TEMPERATURE
SENSOR1/2/3
FAN CONTROL COOLING FAN 02h 7Dh 0: No mean
FAN SPEED 10h 3Fh 0: No mean
SENSOR1 10h E0h/E1h E0h: Set centigrade
SENSOR2 10h E2h/E3h E2h: Set centigrade
SENSOR3 10h E4h/E5h E4h: Set centigrade
SCREEN
SAVER
SIDE BORDER COLOR 02h DFh 0: Black
CHANGE PASSWORD N/A
SECURITY Refer to section 21
RESET
(DISPLAY PROTECTION)
GAMMA 02h DBh 0: No mean
BACKLIGHT 02h DCh 0: No mean
MOTION INTERV
AL
ZOOM 10h 35h 0 : 95%
02h 79h Return value is 2’s
02h DDh 0: OFF(0s)
02h CBh 0: No mean
OP code Parameter Remarks
complement.
(0.5°C step)
1: AUTO
2: ON
1: HIGH
2: LOW
0 – 65535(FFFFh)
E1h: Set
0 – 10(0Ah)
0 – 65535(FFFFh)
E3h: Set
0 – 10(0Ah)
0 – 65535(FFFFh)
E5h: Set
0 – 10(0Ah)
1: OFF
2: ON
1: OFF
2: ON
|
90(5Ah): 900s
|
5 : 100%
|
10(0Ah) : 105%
|
100(64h): White
9: Reset
Display Protection
Category
Offset
affects to a
selected
sensor.
Select
sensor
(Page02h
OPcode78h)
1 : SENSOR #1
2 : SENSOR #2
3 : SENSOR #3
value
value
value
10s/step
Momentary
(37/130)
please set up
Item OP
code
page
MAC ADDRESS
(NETWORK INFORMATION)
IP ADDRESS SETTING N/A
LAN POWER 10h D3h 0: No mean
DDC/CI 10h BEh 0: No mean
PING N/A
EXTER N AL C ONT ROL
IP ADDRESS RESET N/A
RESET
(EXTERNAL CONTROL)
INPUT DETECT 02h 40h 0: FIRST DETECT
CUSTOM
DETECT
LONG
CABLE
COMP
INPUT
CHANGE
PRIORITY1 10h 2Eh 0: No mean
PRIORITY2 10h 2Fh
PRIORITY3 10h 30h
DVI1 02h F0h 0: No mean
DVI2 11h 1Ah
HDMI1 11h 1Bh
HDMI2 11h 1Ch
HDMI3 11h 1Dh
HDMI4 11h 1Eh
INPUT
CHANGE
Refer to section 22
02h CBh 0: No mean
10h 86h 0: No mean
ADVAN C ED O PTI ON1
INPUT1 10h CEh 0: No mean
INPUT2 10h CFh
TERMINAL
SETTING
HDMI/DVI SELECT 11h 18h 0: No mean
INPUT
CONFIGURATION
Refer to section 6.4
OP code Parameter Remarks
1: OFF
2: ON
1: OFF
2: ON
12(0Ch): Reset External
Control Category
1: LAST DETECT
2: NONE
3: VIDEO DETECT
4: CUSTOM DETECT
3: DVI1
4: DVI2
13(0Dh): OPTION
15(0Fh): DPORT
16(10h): DPORT2
17(11h): HDMI1
18(12h): HDMI2
130(82h): HDMI3
131(83h): HDMI4
132(84h): PRESET1
133(85h): PRESET2
134(86h): PRESET3
1: MODE0
2: MODE1
3: MODE2
4: MODE3
1: NORMAL
2: QUICK
3: SUPER
3: DVI1
4: DVI2
13(0Dh): OPTION
15(0Fh): DPORT
16(10h): DPORT2
17(11h): HDMI1
18(12h): HDMI2
130(82h): HDMI3
131(83h): HDMI4
132(84h): PRESET1
133(85h): PRESET2
134(86h): PRESET3
1: HDMI
2: DVI
3: HDMI/DVI
Momentary
When you set
up "SUPER",
INPUT1 and
INPUT2
first.
(38/130)
Item OP
DVI MODE 02h CFh 0: No mean
OP code Parameter Remarks
code
page
1: DVI-PC
2: DVI-HD
DisplayPort 10h F1h/F2h Select target DPORT.
(F1h)
0: No mean
1: DPORT
2: DPORT2
Read / Write status of
target DPORT.(F2h)
0: No mean
1: 1.1a
2: 1.2
BIT RATE 11h 19h 0: No mean
1: RBR
2: HBR
3: HBR2
HDMI SIGNAL 10h 40h 0: No mean
1: EXPAND
2: RAW
DEINTERLACE 02h 25h 0: No mean
1: Off
2: ON
MOVIE
SETTING
OVER SCAN 02h E3h 0: No mean
OPTION
SETTING
120Hz 10h 87h 0: No mean
TOUCH
PANEL
RESET
(ADVANCED OPTION1)
TELECINE 02h 23h 0: No mean
1: OFF
2: AUTO
ADAPTIVE CONTRAST 02h 8Dh 0: No mean
1: OFF
2: LOW
4: HIGH
1: OFF
2: ON
OPTION POWER 10h 41h 0: OFF
1: ON
AUDIO 10h B0h 0: No mean
1: ANALOG
2: DIGITAL
INTER
NAL
PC
STANDBY 10h C4h 0: No mean
PC SOURCE 10h C5h 0: No mean
OFF
WARNING
AUTO
OFF
START
UP PC
FORCE
QUIT
10h C0h 0: No mean
1: OFF
2: ON
10h C1h 0: No mean
1: OFF
2: ON
10h C2h 0: No mean
1: Execute
10h C3h 0: No mean
1: Execute
1: ON
2: OFF
1: OFF
2: ON
1: AUTO
2: EXTERNAL PC
02h CBh 0: No mean
10(0Ah): Reset Advanced
option1 category
Momentary
(39/130)
ADVAN C ED O PTI ON2
Item OP
OP code Parameter Remarks
code
page
AUTO
AUTO BRIGHTNESS 02h 2Dh 0: OFF
DIMMING
BACKLIGHT
11h 4Eh 0: No mean
DIMMING
ROOM LIGHT
10h C8h 0: No mean
SENSING
BACK
LIGHT
SETTING
MAX
LIMIT
IN
BRIGHT
IN
10h C9h 0 – 100(64h)
10h 33h
10h 34h 0 – 100(64h)
DARK
SENSIN
02h B4h Current luminance read Read only
G LUX
HUMAN
HUMAN SENSING MODE 10h 75h 0: No mean
SENSING
10h DDh 0: No mean
10h C6h 0: dark
10h DEh 0: No mean
10h DFh/D0h 0: No mean
BACK
LIGHT
VOLUME
ON/OFF
BACK
LIGHT
ON/OFF
VOLUME 10h C7h 0: whisper
ON/OFF
INPUT 10h D0h 0: No mean
3: DVI1
4: DVI2
13(0Dh): OPTION
INPUT
SELECT
15(0Fh): DPORT
16(10h): DPORT2
17(11h): HDMI1
18(12h): HDMI2
130(82h): HDMI3
131(83h): HDMI4
132(84h): PRESET1
133(85h): PRESET2
WAITING TIME 10h 78h 30(1Eh): short
INTELLI WIRELESS DATA 10h ECh 0: No mean
RESET
02h CBh 0: No mean
(ADVANCED OPTION2)
FACTORY RESET 02h CBh 0: No mean
1: ON
1: OFF
2: ON
1: OFF
2: MODE1
3: MODE2
0 – 100(64h)
1: DISABLE
2: AUTO OFF
4: CUSTOM
1: Off
2: On
|
100(64h): light
1: Off
2: On
|
100(64h): loud
1: Off
2: On
134(86h): PRESET3
|
600(258h): long
*1step: 1sec.
1: OFF
2: ON
11(0Bh): Reset Advanced
option category
1: Factory Reset
Momentary
Momentary
(40/130)
Item OP
OP code Parameter Remarks
code
page
INPUT 11h 06h 0: No mean
3: DVI1
4: DVI2
13(0Dh): OPTION
15(0Fh): DPORT
16(10h): DPORT2
17(11h): HDMI1
18(12h): HDMI2
130(82h): HDMI3
131(83h): HDMI4
132(84h): PRESET1
133(85h): PRESET2
134(86h): PRESET3
AUDIO INPUT 02h 2Eh 0: No mean
1: LINE IN
4: HDMI
6: OPTION
7: DPORT
8: DPORT2
10(0Ah): HDMI2
11(0Bh): HDMI3
12(0Ch): HDMI4
VOLUME UP/DOWN 00h 62h 0: whisper
|
100(64h): loud
MUTE 00h 8Dh 0: UNMUTE(Set only)
1: MUTE
2: UNMUTE
SCREEN MUTE 10h B6h 0: No mean
1: SCREEN MUTE ON
2: SCREEN MUTE OFF
MTS 02h 2Ch 0: No mean
1: Main
2: Sub
3: Main + Sub
PICTURE MODE 02h 1Ah 0: No mean
1: sRGB
3: HIGHBRIGHT
4: STANDARD
5: CINEMA
8: CUSTOM1
9: CUSTOM2
13(0Dh): SVE-1 SETTING
14(0Eh): SVE-2 SETTING
15(0Fh): SVE-3 SETTING
16(10h): SVE-4 SETTING
17(11h): SVE-5 SETTING
ASPECT 02h 70h 0: No mean
1: NORMAL
2: FULL
3: WIDE
4: ZOOM
6: DYNAMIC
7: 1:1 (Off/dot by dot)
MULTI PICTURE MODE ON/OFF
STILL ON/OFF
02h 72h 0: No mean
1: Off
2: PIP
4: STILL
5: PBP(PBP1, PBP2, PBP3)
The
following
commands can
also be used.
OP code page
00h
OP code 60h
Parameter
0: No mean
3: DVI1
4: DVI2
13: OPTION
15: DPORT
16: DPORT2
17: HDMI1
18: HDMI2
This
operation
requires
supported
option TV
tuner.
sRGB:
PC mode
only
CINEMA:
A/V mode
only
WIDE:
A/V mode only
(41/130)
Item OP
code
page
PICTURE NUMBER 10h B5h If MULTI PICTURE is set PIP
MULTI PICTURE INPUT 02h 73h 0: No mean
ACTIVE PICTURE 11h 0Bh 0: No mean
ROTATE ROTATE ALL 11h 16h 0: No mean
PICTURE1 11h 12h
PICTURE2 11h 13h
PICTURE3 11h 14h
PICTURE4 11h 15h
STILL CAPTURE 02h 76h 0: OFF
SIGNAL INFORMATION 02h EAh 0: No mean
TV-CHANNEL UP/DOWN 00h 8Bh 0: No mean
SELECT TEMPERATURE SENSOR 02h 78h 0: No mean
READOUT A TEMPERATURE 02h 79h Returned value is 2's
TEMPE R ATU R E S ENSO R
READOUT CARBON FOOTPRINT
(g)
READOUT CARBON FOOTPRINT
(kg)
READOUT CARBON USAGE
(g)
CARBO N FO O TPR INT
10h 10h 0:
10h 11h 0:
10h 26h 0:
OP code Parameter Remarks
0: No mean
2: 2WINDOWS, PIP
3: 3WINDOWS, PIP
If MULTI PICTURE is set PBP
0: No mean
1: 2WINDOWS, PBP1
3: 3WINDOWS, PBP1
4: 3WINDOWS, PBP2
5: 3WINDOWS, PBP3
6: 4WINODWS, PBP1
3: DVI1
4: DVI2
13(0Dh): OPTION
15(0Fh): DPORT
16(10h): DPORT2
17(11h): HDMI1
18(12h): HDMI2
130(82h): HDMI3
131(83h): HDMI4
1: PICTURE1
2: PICTURE2
3: PICTURE3
4: PICTURE4
1: OFF
2: ON
1: CAPTURE
1: OFF
2: ON
1: UP
2: DOWN
1: SENSOR #1
2: SENSOR #2
3: SENSOR #3
complement.
Refer to section 6.2
|
999(3E7h):
|
65535(FFFFh):
|
999(3E7h):
Momentary
This
operation
requires
supported
option TV
tuner.
Read only
Read only
Read only
Read only
(42/130)
Item OP
READOUT CARBON USAGE
(kg)
OP code Parameter Remarks
code
page
10h 27h 0:
|
65535(FFFFh):
Read only
(43/130)
"LEFT
6.4. Operation Code (OP code) for INPUT CONFIGURATION
Item OP
code
page
PRESET1 11h 1Fh 0: No mean
PRESET2 11h 20h 0: No mean
PRESET3 11h 21h 0: No mean
SELECT INPUT TOP LEFT 11h 22h 0: No mean
TOP RIGHT 11h 23h
BOTTOM LEFT 11h 24h
BOTTOM RIGHT 11h 25h
LEFT 11h 26h Set up, when
RIGHT 11h 27h
TOP 11h 28h
BOTTOM 11h 29h
OP code Parameter Remarks
1: OFF
2: LEFT & RIGHT
(HDMIx2 or DVIx2)
3: TOP & BOTTOM
(HDMIx2 or DVIx2)
4: DIVIDE QUARTERS
(HDMI
1: OFF
2: LEFT & RIGHT
(HDMIx2 or DVIx2)
3: TOP & BOTTOM
(HDMIx2 or DVIx2)
1: OFF
2: LEFT & RIGHT
(DPORTx2)
3: TOP & BOTTOM
(DPORTx2)
3: DVI1
4: DVI2
13(0Dh): OPTION
15(0Fh): DPORT
16(10h): DPORT2
17(11h): HDMI1
18(12h): HDMI2
130(82h): HDMI3
131(83h): HDMI4
ｘ
4)
Set up, when
PRESET1 is set
as "DIVIDE
QUARTERS".
PRESET1, 2 or 3
is set as
& RIGHT" or
"TOP & BOTTOM".
(44/130)
7. Power control procedure
7.1 Power status read
1) The controller requests the monitor to reply a current power status.
Header Message Check code
SOH-'0'-Monitor ID-
'0'-'A'-'0'-'6'
Header
SOH (01h): Start of Header
'0' (30h): Reserved
Monitor ID: Specify the Monitor ID from which you want to get status.
Ex.) If Monitor ID is '1', specify 'A'.
'0' (30h): Message sender is the controller.
'A' (41h): Message Type is "Command".
'0'-'6' (30h, 36h): Message length is 6 bytes.
Message
STX (02h): Start of Message
'0'-'1'-'D'-'6': Get power status command.
ETX (03h): End of Message
Check code
BCC: Block Check Code
Refer to the section 4.3 “Check code” for a BCC calculation.
Delimiter
CR (0Dh): End of packet
2) The monitor returns with the current power status.
STX-'0'-'1'-'D'-'6'-ETX BCC CR
Delimiter
Header Message Check
SOH-'0'-'0'-Monitor ID-
'B'-'1'-'2'
Header
SOH (01h): Start of Header
'0' (30h): Reserved
'0' (30h): Message receiver is the controller.
Monitor ID: Indicate a replying Monitor ID.
Ex.) When this byte is set to 'A', the replying Monitor ID is '1'.
'B' (42h): Message Type is "Command reply".
'1'-'2' (31h, 32h): Message length is 18 bytes.
Message
STX (02h):Start of Message
'0'-'2' (30h, 32h): Reserved data
'0'-'0' (30h, 30h): Result code
00: No Error.
01: Unsupported.
'D'-'6'(44h, 36h): Display power mode code
'0'-'0' (30h, 30h): Parameter type code is "Set parameter".
'0'-'0'-'0'-'4' (30h, 30h, 30h, 34h): Power mode is 4 types.
'0'-'0'-'0'-'1' (30h, 30h, 30h, 31h): Current power mode
ETX (03h): End of Message
Check code
BCC: Block Check Code
STX-'0'-'2'-'0'-'0'-'D'-'6'-'0'-'0'-
'0'-'0'-'0'-'4'-'0'-'0'-'0'-'1'-ETX
<Status>
0001: ON
0002: Stand-by (power save)
0003: Suspend (power save)
0004: OFF (same as IR power off)
Delimiter
code
BCC CR
(45/130)
Refer to the section 4.3 “Check code” for a BCC calculation.
Delimiter
CR (0Dh): End of packet
(46/130)
7.2 Power control
1) The controller requests the monitor to control monitor power.
Header Message Check code
SOH-'0'-Monitor ID-
'0'-'A'-'0'-'C'
Header
SOH (01h): Start of Header
'0' (30h): Reserved
Monitor ID: Specify the Monitor ID which you want to change a setting.
Ex.) If Monitor ID is '1', specify 'A'.
'0' (30h): Message sender is the controller.
'A' (41h): Message type is "Command".
'0'-'C (30h, 43h): Message length is 12 bytes.
Message
STX (02h): Start of Message
'C'-'2'-'0'-'3'-'D'-'6' (43h, 32h, 30h, 33h, 44h, 36h): power control command
'0'-'0'-'0'-'1' (30h, 30h, 30h, 31h): Power mode
ETX (03h): End of Message
Check code
BCC: Block Check Code
Refer to the section 4.3 “Check code” for a BCC calculation.
Delimiter
CR (0Dh): End of packet
STX-'C'-'2'-'0'-'3'-'D'-'6'-
'0'-'0'-'0'-'1'-ETX
0001: ON
0002, 0003: Do not set.
0004: OFF (same as the power off by IR)
BCC CR
Delimiter
2) The monitor replies a data for confirmation.
Header Message Check code Delimiter
SOH-'0'-'0'-Monitor ID-
'B'-'0'-'E'
Header
SOH (01h): Start of Header
'0' (30h): Reserved
'0' (30h): Message receiver is the controller.
Monitor ID: Indicate a replying Monitor ID.
Ex.) When this byte is set to 'A', the replying Monitor ID is '1'.
'B' (42h): Message type is "Command reply".
'N'-'N': Message length
Note.) The maximum data length that can be written to the monitor at a time is 32bytes.
Ex.) The byte data 20h is encoded as ASCII characters '2' and '0' (32h and 30h).
Message
STX (02h): Start of Message
'0'-'0' (30h, 30h): Result code. No error.
'C'-'2’,'0'-'3'-'D'-'6' (43h, 32h, 30h, 33h, 44h, 36h): power control reply command
Ø
The monitor replies same as power control command to the controller.
'0'-'0'-'0'-'1' (30h, 30h, 30h, 31h): Power mode
ETX (03h): End of Message
STX-'0'-'0'-'C'-'2'-'0'-'3'-'D'-'6'-
'0'-'0'-'0'-'1'-ETX
0001: ON
0002, 0003: Do not set.
0004: OFF (same as the power off by IR)
BCC CR
(47/130)
Check code
BCC: Block Check Code
Refer to the section 4.3 “Check code” for a BCC calculation.
Delimiter
CR (0Dh): End of packet
(48/130)
8. Asset Data read and write
MultiSync X841UHD, X981UHD, X651UHD have the area for to store user’s asset data of up to 64bytes.
8.1 Asset Data Read Request and reply
This command is used in order to read Asset Data.
1) The controller requests the monitor to reply with Asset data.
Header Message Check code
SOH-'0'-Monitor ID-
'0'-'A'-'0'-'A'
Header
SOH (01h): Start of Header
'0' (30h): Reserved
Monitor ID: Specify the Monitor ID from which you want to get data.
Ex.) If Monitor ID is '1', specify 'A'.
'0' (30h): Message sender is the controller.
'A' (41h): Message type is "Command".
'0'-'A' (30h, 41h): Message length is 10 bytes.
Message
STX (02h): Start of Message
'C'-'0'-'0'-'B' (43h, 30h, 30h, 42h): Asset read request command.
'0'-'0' (30h, 30h): Offset data from top of the Asset data.
At first set 00h: Read data from the top of Asset data area.
'2'-'0' (32h, 30h): Read out data length is 32bytes.
Secondly set 20h: Read data from the 32bytes offset point in the Asset data area.
Maximum readout length is 32bytes at a time.
ETX (03h): End of Message
Check code
BCC: Block Check Code
Refer to the section 4.3 “Check code” for a BCC calculation.
Delimiter
CR (0Dh): End of packet
2) The monitor replies Asset data to the controller.
Header Message Check code
SOH-'0'-'0'-Monitor ID-
'B'-N-N
Header
SOH (01h): Start of Header
'0' (30h): Reserved
'0' (30h): Message receiver is the controller.
Monitor ID: Indicate a replying Monitor ID.
Ex.) When this byte is set to 'A', the replying Monitor ID is '1'.
'B' (42h): Message type is "Command reply"
N-N: Message length
Note.) This length includes STX and ETX.
Message
STX (02h): Start of Message
'C'-'1'-'0'-'B' (43h, 31h, 30h, 42h): Asset read reply command
Data(0) – Data(N): Retuned Asset data
Ex.) When Data(n) is 1234h, replying data is (31h 32h, 33h, 34h).
ETX (03h): End of Message
Check code
BCC: Block Check Code
STX-'C'-'0'-'0'-'B'-
'0'-'0'-'2'-'0'-ETX
BCC CR
STX-'C'-'1'-'0'-'B'-
Data(0)-Data(1)---Data(N)-ETX
Delimiter
BCC CR
Delimiter
(49/130)
Refer to the section 4.3 “Check code” for a BCC calculation.
Delimiter
CR (0Dh): End of packet
(50/130)
8.2 Asset Data write
This command is used in order to write Asset Data.
1) The controller requests the monitor to write Asset data.
Header Message Check code
SOH-'0'-Monitor ID-
'0'-'A'-N-N
Header
SOH (01h): Start of Header
'0' (30h): Reserved
Monitor ID: Specify the Monitor ID in which you want to write data.
Ex.) If Monitor ID is '1', specify 'A'.
'0' (30h): Message sender is the controller.
'A' (41h): Message type is "Command".
N-N: Message length
Note.) The maximum data length that can be written to the monitor at a time is 32bytes.
Message
STX (02h): Start of Message
'C'-'0'-'0'-'E' (43h, 30h, 30h, 45h): Asset Data writes command
'0'-'0'(30h, 30h): Offset address from top of Asset data.
00h : Write data from top of the Asset data area.
Data(0) –- Data(N): Asset data. The data must be ASCII characters strings.
ETX (03h): End of Message
Check code
BCC: Block Check Code
Refer to the section 4.3 “Check code” for a BCC calculation.
Delimiter
CR (0Dh): End of packet
STX-'C'-'0'-'0'-'E'-'0'-'0'-
Data(0)-Data(1)---Data(N)-ETX
BCC CR
Delimiter
2) The monitor replies a data for confirmation.
Header Message Check code
SOH-'0'-'0'-Monitor ID-
'B'-N-N
Header
SOH (01h): Start of Header
'0' (30h): Reserved
'0' (30h): Message receiver is the controller.
Monitor ID: Indicate a replying Monitor ID.
Ex.) When this byte is set to 'A', the replying Monitor ID is '1'.
'B' (42h): Message type is "Command reply".
N-N: Message length
Note.) The maximum data length that can be written to the monitor at a time is 32bytes.
Message
STX (02h): Start of Message
'0'-'0': Result code. No error.
'C'-'0'-'0'-'E' (43h, 30h, 30h, 45h): Asset Data write command
'0'-'0'(30h, 30h): Offset address from top of Asset data.
00h : Write data into from top of the Asset data area.
Data(0) –- Data(N): Asset data. The data must be ASCII characters strings.
ETX (03h): End of Message
Check code
BCC: Block Check Code
Refer to the section 4.3 “Check code” for a BCC calculation.
Delimiter
STX-'0'-'0'-'C'-'0'-'0'-'E'-'0'-'0'-
Data(0)-Data(1)---Data(N)-ETX
Delimiter
BCC CR
(51/130)
CR (0Dh): End of packet
(52/130)
9. Date & Time read and write
9.1 Date & Time Read
This command is used in order to read the setting of Date & Time.
1) The controller requests the monitor to reply with the Date & Time.
Header Message Check code
SOH-'0'-Monitor ID-
'0'-'A'-'0'-'6'
Header
SOH (01h): Start of Header
'0' (30h): Reserved
Monitor ID: Specify the Monitor ID of which you want to get status.
Ex.) If Monitor ID is '1', specify 'A'.
'0' (30h): Message sender is the controller.
'A' (41h): Message type is "Command".
'0'-'6'(30h, 36h): Message length
Message
STX (02h): Start of Message
'C'-'2'-'1'-'1' (43h, 32h, 31h, 31h): Date & time read request command.
ETX (03h): End of Message
Check code
BCC: Block Check Code
Refer to the section 4.3 “Check code” for a BCC calculation.
Delimiter
CR (0Dh): End of packet
2) The monitor replies Date & Time to the controller.
Header Message Check code
SOH-'0'-'0'-Monitor ID-
'B'-'1'-'4'
Header
SOH (01h): Start of Header
'0' (30h): Reserved
'0' (30h): Message receiver is the controller
Monitor ID: Indicate a replying Monitor ID
Ex.) When this byte is set to 'A', the replying Monitor ID is '1'.
'B' (42h): Message type is "Command reply"
'1'-'4'(31h, 34h): Message length
Message
STX (02h): Start of Message
'C'-'3'-'1'-'1' (43h, 33h, 31h, 31h): Date & Time read reply command
'YY'-'MM'-'DD'-'WW'-'HH'-'MN'-'DS': Date & Time data
YY: Year (offset 2000)
'0'-'0'(30h, 30h): 2000
|
'6'-'3'(36h, 33h): 2099 (99 = 63h)
MM: Month
'0'-'1'(30h, 31h): January
|
'0'-'C'(30h, 43h): December
DD: Day
'0'-'1'(30h, 31h): 1
|
'1'-'E'(31h, 45h): 30(=1Eh)
STX-'C'-'2'-'1'-'1'-ETX BCC CR
STX-'C'-'3'-'1'-'1'-
YY-MM-DD-WW-HH-MN-DS-ETX
BCC CR
Delimiter
Delimiter
(53/130)
'1'-'F'(31h, 46h): 31(=1Fh)
WW: weekdays
'0'-'0'(30h, 30h): Sunday
'0'-'1'(30h, 31h): Monday
'0'-'2'(30h, 32h): Tuesday
'0'-'3'(30h, 33h): Wednesday
'0'-'4'(30h, 34h): Thursday
'0'-'5'(30h, 35h): Friday
'0'-'6'(30h, 36h): Saturday
HH: Hours
'0'-'0'(30h, 30h): 0
|
'1'-'7'(31h, 37h): 23 (=17h)
MN: Minutes
'0'-'0'(30h, 30h): 0
|
'3'-'B' (33h, 42h): 59 (=3Bh)
DS: Daylight saving (Summer time)
'0'-'0'(30h, 30h): NO
'0'-'1'(30h, 31h): YES
ETX (03h): End of Message
Check code
BCC: Block Check Code
Refer to the section 4.3 “Check code” for a BCC calculation.
Delimiter
CR (0Dh): End of packet
(54/130)
9.2 Date & Time Write
This command is used in order to write the setting of the Date & Time.
1) The controller requests the monitor to write Date & Time.
Header Message Check code Delimiter
SOH-'0'-Monitor ID-
'0'-'A'-'1'-'2'
STX-'C'-'2'-'1'-'2'-
YY-MM-DD-WW-HH-MN-DS-ETX
BCC CR
Header
SOH (01h): Start of Header
'0' (30h): Reserved
Monitor ID: Specify the Monitor ID of which you want to change the setting.
Ex.) If Monitor ID is '1', specify 'A'.
'0' (30h): Message sender is the controller.
'A' (41h): Message type is "Command".
'1'-'2'(31h, 32h): Message length
Message
STX (02h): Start of Message
'C'-'2'-'1'-'2' (43h, 32h, 31h, 32h): Date & Time write command
'YY'-'MM'-'DD'-'WW'-'HH'-'MN'-'DS': Date & Time data
YY: Year (offset 2000)
'0'-'0'(30h, 30h): 2000
|
'6'-'3'(36h, 33h): 2099 (99 = 63h)
MM: Month
'0'-'1'(30h, 31h): JANUARY
|
'0'-'C'(30h, 43h): DECEMBER
DD: Day
'0'-'1'(30h, 31h): 1
|
'1'-'E'(31h, 45h): 30(=1Eh)
'1'-'F'(31h, 46h): 31(=1Fh)
WW: weekdays
'0'-'0'(30h, 30h): SUNDAY
'0'-'1'(30h, 31h): MONDAY
'0'-'2'(30h, 32h): TUESDAY
'0'-'3'(30h, 33h): WEDNESDAY
'0'-'4'(30h, 34h): THURSDAY
'0'-'5'(30h, 35h): FRIDAY
'0'-'6'(30h, 36h): SATURDAY
HH: Hours
'0'-'0'(30h, 30h): 0
|
'1'-'7'(31h, 37h): 23 (=17h)
MN: Minutes
'0'-'0'(30h, 30h): 0
|
'3'-'B' (33h, 42h): 59 (=3Bh)
DS: Daylight saving (Summer time)
'0'-'0'(30h, 30h): NO
'0'-'1'(30h, 31h): YES
ETX (03h): End of Message
Check code
BCC: Block Check Code
Refer to the section 4.3 “Check code” for a BCC calculation.
(55/130)
Delimiter
CR (0Dh): End of packet
2) The monitor replies a data for confirmation.
Header Message Check code
SOH-'0'-'0'-Monitor ID-
'B'-'1'-'6'
Header
SOH (01h): Start of Header
'0' (30h): Reserved
'0' (30h): Message receiver is the controller.
Monitor ID: Indicate a replying Monitor ID.
Ex.) When this byte is set to 'A', the replying Monitor ID is '1'.
'B' (42h): Message type is "Command reply".
'1'-'6'(31h, 36h): Message length
Message
STX (02h): Start of Message
'C'-'3'-'1'-'2' (43h, 33h, 31h, 32h): Date & Time write reply command
ST: Date & Time Status command
'0'-'0'(30h, 30h): No error
'0'-'1'(30h, 31h): Error
'YY'-'MM'-'DD'-'WW'-'HH'-'MN'-'DS': Date & Time data
YY: Year (offset 2000)
'0'-'0'(30h, 30h): 2000
|
'6'-'3'(36h, 33h): 2099 (99 = 63h)
MM: Month
'0'-'1'(30h, 31h): JANUARY
|
'0'-'C'(30h, 43h): DECEMBER
DD: Day
'0'-'1'(30h, 31h): 1
|
'1'-'E'(31h, 45h): 30(=1Eh)
'1'-'F'(31h, 46h): 31(=1Fh)
WW: weekdays
'0'-'0'(30h, 30h): SUNDAY
'0'-'1'(30h, 31h): MONDAY
'0'-'2'(30h, 32h): TUESDAY
'0'-'3'(30h, 33h): WEDNESDAY
'0'-'4'(30h, 34h): THURSDAY
'0'-'5'(30h, 35h): FRIDAY
'0'-'6'(30h, 36h): SATURDAY
HH: Hours
'0'-'0'(30h, 30h): 0
|
'1'-'7'(31h, 37h): 23 (=17h)
MN: Minutes
'0'-'0'(30h, 30h): 0
|
'3'-'B' (33h, 42h): 59 (=3Bh)
DS: Daylight saving (Summer time)
'0'-'0'(30h, 30h): NO
'0'-'1'(30h, 31h): YES
ETX (03h): End of Message
STX-'C'-'3'-'1'-'2'-ST-
YY-MM-DD-WW-HH-MN-DS-ETX
BCC CR
Delimiter
(56/130)
Check code
BCC: Block Check Code
Refer to the section 4.3 “Check code” for a BCC calculation.
Delimiter
CR (0Dh): End of packet
(57/130)
10. Schedule read and write
10.1 Schedule Read
This command is used in order to read the setting of the Schedule.
1) The controller requests the monitor to read Schedule.
Header Message Check code
SOH-'0'-Monitor ID-
'0'-'A'-'0'-'8'
Header
SOH (01h): Start of Header
'0' (30h): Reserved
Monitor ID: Specify the Monitor ID of which you want to get status.
Ex.) If Monitor ID is '1', specify 'A'.
'0' (30h): Message sender is the controller.
'A' (41h): Message type is "Command".
'0'-'8'(30h, 38h): Message length
Message
STX (02h): Start of Message
'C'-'2'-'2'-'1' (43h, 32h, 32h, 31h): Schedule read request command.
PG: Program No.
Ø
The data must be ASCII characters strings.
ETX (03h): End of Message
Check code
BCC: Block Check Code
Refer to the section 4.3 “Check code” for a BCC calculation.
Delimiter
CR (0Dh): End of packet
2) The monitor replies Schedule to the controller.
Header Message Check
SOH-'0'-'0'-Monitor ID-
'B'-'2'-'6'
Header
SOH (01h): Start of Header
'0' (30h): Reserved
'0' (30h): Message receiver is the controller.
Monitor ID: Indicate a replying Monitor ID.
Ex.) When this byte is set to 'A', the replying Monitor ID is '1'.
'B' (42h): Message type is "Command reply".
'2'-'6'(32h, 36h): Message length
Message
STX (02h): Start of Message
'C'-'3'-'2'-'1' (43h, 33h, 32h, 31h): Schedule read reply command
PG-ON HOURS-ON MIN-OFF HOURS-OFF MIN-INPUT-WD-FL-P MODEEXT1-EXT2-EXT3-EXT4-EXT5-EXT6-EXT7: Schedule data
PG: Program No.
'0'-'0'(30h, 30h): Program No.1
|
'0'-'6'(30h, 36h): Program No.7
ON_HOUR: Turn on time (hour)
'0'-'0'(30h, 30h): 00
|
'1'-'7'(31h, 37h): 23 (=17h)
'1'-'8'(31h, 38h): ON timer isn't set.
STX-'C'-'2'-'2'-'1'-PG-ETX BCC CR
STX-'C'-'3'-'2'-'1'-PG-ON HOUR-ON MIN-
OFF HOUR-OFF MIN-INPUT-WD-FL-P MODEEXT1-EXT2-EXT3-EXT4-EXT5-EXT6-EXT7-ETX
Delimiter
Delimiter
code
BCC CR
(58/130)
ON_MIN: Turn on time (minute)
'0'-'0'(30h, 30h): 0
|
'3'-'B'(33h, 42h): 59
'3'-'C'(33h, 43h): On timer isn't set.
OFF_HOUR: Turn off time (hour)
'0'-'0'(30h, 30h): 00
|
'1'-'7'(31h, 37h): 23 (=17h)
'1'-'8'(31h, 38h): Off timer isn't set.
OFF_MIN: Turn off time (minute)
'0'-'0'(30h, 30h): 0
|
'3'-'B'(33h, 42h): 59 (=3Bh)
'3'-'C'(33h, 43h): Off timer isn’t set.
INPUT: Timer input
'0'-'0'(30h,30h): No mean (works on last memory)
'0'-'3'(30h,33h): DVI1
'0'-'4'(30h,34h): DVI2
'0'-'D'(30h,44h): OPTION
'0'-'F'(30h,46h): DPORT
'1'-'0'(31h,30h): DPORT2
'1'-'1'(31h,31h): HDMI
'1'-'2'(31h,32h): HDMI2
'8'-'2'(38h,32h): HDMI3
'8'-'3'(38h,33h): HDMI4
WD: Week setting
bit 0: MONDAY
bit 1: TUESDAY
bit 2: WEDNESDAY
bit 3: THURSDAY
bit 4: FRIDAY
bit 5: SATURDAY
bit 6: SUNDAY
EX.
'0'-'1'(30h, 31h): MONDAY
'0'-'4'(30h, 34h): TUESDAY
'0'-'F'(30h, 46h): MONDAY, TUESDAY, WEDNESDAY and THURSDAY
'7'-'F'(37h, 46h): MONDAY to SUNDAY
FL: Option
bit 0: 0:once 1:Everyday
bit 1: 0:once 1:Every week
bit 2: 0:Disable 1:Enable
EX.
'0'-'1'(30h, 31h): Disable, Everyday
'0'-'4'(30h, 34h): Enable, once
P MODE: Picture mode
'0'-'0'(30h,30h): No mean (works on last memory)
'0'-'1'(30h,31h): sRGB
'0'-'3'(30h,33h): HIGHBRIGHT
'0'-'4'(30h,34h): STANDARD
'0'-'5'(30h,34h): CINEMA
'0'-'8'(30h,38h): CUSTOM1
'0'-'9'(30h,39h): CUSTOM2
'0'-'D'(30h,44h): SVE-1 SETTING
'0'-'E'(30h,45h): SVE-2 SETTING
'0'-'F'(30h,46h): SVE-3 SETTING
'1'-'0'(31h,30h): SVE-4 SETTING
'1'-'1'(31h,31h): SVE-5 SETTING
(59/130)
EXT1: Extension1
'0'-'0'(30h,30h): (On this monitor, it is always ‘00’)
EXT2: Extension 2
'0'-'0'(30h,30h): (On this monitor, it is always ‘00’)
EXT3: Extension 3
'0'-'0'(30h,30h): (On this monitor, it is always ‘00’)
EXT4: Extension 4
'0'-'0'(30h,30h): (On this monitor, it is always ‘00’)
EXT5: Extension 5
'0'-'0'(30h,30h): (On this monitor, it is always ‘00’)
EXT6: Extension 6
'0'-'0'(30h,30h): (On this monitor, it is always ‘00’)
EXT7: Extension 7
'0'-'0'(30h,30h): (On this monitor, it is always ‘00’)
ETX (03h): End of Message
Check code
BCC: Block Check Code
Refer to the section 4.3 “Check code” for a BCC calculation.
Delimiter
CR (0Dh): End of packet
(60/130)
***Following command also can be used for to keep backward compatibility, in order to
read the setting of the Schedule.
1) The controller requests the monitor to read Schedule.
Header Message Check code
SOH-'0'-Monitor ID-
'0'-'A'-'0'-'8'
Header
SOH (01h): Start of Header
'0' (30h): Reserved
Monitor ID: Specify the Monitor ID of which you want to get status.
Ex.) If Monitor ID is '1', specify 'A'.
'0' (30h): Message sender is the controller.
'A' (41h): Message type is "Command".
'0'-'8'(30h, 38h): Message length
Message
STX (02h): Start of Message
'C'-'2'-'1'-'3' (43h, 32h, 31h, 33h): Schedule read request command.
PG: Program No.
Ø
The data must be ASCII characters strings.
ETX (03h): End of Message
Check code
BCC: Block Check Code
Refer to the section 4.3 “Check code” for a BCC calculation.
Delimiter
CR (0Dh): End of packet
2) The monitor replies Schedule to the controller.
Header Message Check code
SOH-'0'-'0'-Monitor ID-
'B'-'1'-'6'
Header
SOH (01h): Start of Header
'0' (30h): Reserved
'0' (30h): Message receiver is the controller.
Monitor ID: Indicate a replying Monitor ID.
Ex.) When this byte is set to 'A', the replying Monitor ID is '1'.
'B' (42h): Message type is "Command reply".
'1'-'6'(31h, 36h): Message length
Message
STX (02h): Start of Message
'C'-'3'-'1'-'3' (43h, 33h, 31h, 33h): Schedule read reply command
PG-ON HOURS-ON MIN-OFF HOURS-OFF MIN-INPUT-WD-FL: Schedule data
PG: Program No.
'0'-'0'(30h, 30h): Program No.1
|
'0'-'6'(30h, 36h): Program No.7
ON_HOUR: Turn on time (hour)
'0'-'0'(30h, 30h): 00
|
'1'-'7'(31h, 37h): 23 (=17h)
'1'-'8'(31h, 38h): ON timer isn't set.
Delimiter
STX-'C'-'2'-'1'-'3'-PG-ETX BCC CR
STX-'C'-'3'-'1'-'3'-PG-ON HOUR-ON MIN-
OFF HOUR-OFF MIN-INPUT-WD-FL-ETX
Delimiter
BCC CR
(61/130)
ON_MIN: Turn on time (minute)
'0'-'0'(30h, 30h): 0
|
'3'-'B'(33h, 42h): 59
'3'-'C'(33h, 43h): On timer isn't set.
OFF_HOUR: Turn off time (hour)
'0'-'0'(30h, 30h): 00
|
'1'-'7'(31h, 37h): 23 (=17h)
'1'-'8'(31h, 38h): Off timer isn't set.
OFF_MIN: Turn off time (minute)
'0'-'0'(30h, 30h): 0
|
'3'-'B'(33h, 42h): 59 (=3Bh)
'3'-'C'(33h, 43h): Off timer isn’t set.
INPUT: Timer input
'0'-'0'(30h, 30h): DVI1
'0'-'7'(30h,30h): No mean (Works on last memory)
WD: Week setting
bit 0: MONDAY
bit 1: TUESDAY
bit 2: WEDNESDAY
bit 3: THURSDAY
bit 4: FRIDAY
bit 5: SATURDAY
bit 6: SUNDAY
EX.
'0'-'1'(30h, 31h): MONDAY
'0'-'4'(30h, 34h): TUESDAY
'0'-'F'(30h, 46h): MONDAY, TUESDAY, WEDNESDAY and THURSDAY
'7'-'F'(37h, 46h): MONDAY to SUNDAY
FL: Option
bit 0: 0:once 1:Everyday
bit 1: 0:once 1:Every week
bit 2: 0:Disable 1:Enable
EX.
'0'-'1'(30h, 31h): Disable, Everyday
'0'-'4'(30h, 34h): Enable, once
ETX (03h): End of Message
Check code
BCC: Block Check Code
Refer to the section 4.3 “Check code” for a BCC calculation.
Delimiter
CR (0Dh): End of packet
(62/130)
10.2 Schedule Write
This command is used in order to write the setting of the Schedule.
1) The controller requests the monitor to write Schedule.
Header Message Check code
SOH-'0'-Monitor ID-
'0'-'A'-'2'-'6'
STX-'C'-'2'-'2'-'2'-PG-ON HOUR-ON MIN-
OFF HOUR-OFF MIN-INPUT-WD-FL-P MODE-
EXT1-EXT2-EXT3-EXT4-EXT5-EXT6-EXT7-ETX
Header
SOH (01h): Start of Header
'0' (30h): Reserved
Monitor ID: Specify the Monitor ID of which you want to change a setting.
Ex.) If Monitor ID is '1', specify 'A'.
'0' (30h): Message sender is the controller.
'A' (41h): Message type is "Command".
'2'-'6'(32h, 36h): Message length.
Message
STX (02h): Start of Message
'C'-'2'-'2'-'2' (43h, 32h, 32h, 32h): Schedule writes command
PG-ON HOURS-ON MIN-OFF HOURS-OFF MIN-INPUT-WD-FL-P MODE
EXT1-EXT2-EXT3-EXT4-EXT5-EXT6-EXT7: Schedule data
PG: Program No.
'0'-'0'(30h, 30h): Program No.1
|
'0'-'6'(30h, 36h): Program No.7
ON_HOUR: Turn on time (hour)
'0'-'0'(30h, 30h): 00
|
'1'-'7'(31h, 37h): 23 (=17h)
'1'-'8'(31h, 38h): ON timer isn't set.
ON_MIN: Turn on time (minute)
'0'-'0'(30h, 30h): 0
|
'3'-'B'(33h, 42h): 59
'3'-'C'(33h, 43h): On timer isn’t set.
OFF_HOUR: Turn off time (hour)
'0'-'0'(30h, 30h): 00
|
'1'-'7'(31h, 37h): 23 (=17h)
'1'-'8'(31h, 38h): Off timer isn't set.
OFF_MIN: Turn off time (minute)
'0'-'0'(30h, 30h): 0
|
'3'-'B'(33h, 42h): 59 (=3Bh)
'3'-'C'(33h, 43h): Off timer isn’t set.
Note:
* The same time as ON time and OFF time cannot be set.
* Set '1'-'8' to ON/OFF_HOUR and '3'-'C' to ON/OFF_MIN, when ON/OFF time is deleted.
INPUT: Timer input
'0'-'0'(30h,30h): No mean (works on last memory)
'0'-'3'(30h,33h): DVI1
'0'-'4'(30h,34h): DVI2
'0'-'D'(30h,44h): OPTION
'0'-'F'(30h,46h): DPORT
'1'-'0'(31h,30h): DPORT2
'1'-'1'(31h,31h): HDMI
'1'-'2'(31h,32h): HDMI2
Delimiter
BCC CR
(63/130)
'8'-'2'(38h,32h): HDMI3
'8'-'3'(38h,33h): HDMI4
* Please select active input on your system (setting).
* If you select inactive input here, the input change execution will be ignored.
WD: Week setting
bit 0: MONDAY
bit 1: TUESDAY
bit 2: WEDNESDAY
bit 3: THURSDAY
bit 4: FRIDAY
bit 5: SATURDAY
bit 6: SUNDAY
EX.
'0'-'1'(30h, 31h): MONDAY
'0'-'4'(30h, 34h): TUESDAY
'0'-'F'(30h, 46h): MONDAY, TUESDAY, WEDNESDAY and THURSDAY
'7'-'F'(37h, 46h): MONDAY to SUNDAY
FL: Option
bit 0: 0:once 1:Everyday
bit 1: 0:once 1:Every week
bit 2: 0:Disable 1:Enable
* When bit 0 and bit 1 are '1', it behaves as Everyday.
EX.
'0'-'1'(30h, 31h): Disable, Everyday
'0'-'4'(30h, 34h): Enable, once
P MODE: Picture mode
'0'-'0'(30h,30h): No mean (works on last memory)
'0'-'1'(30h,31h): sRGB
'0'-'3'(30h,33h): HiGHBRIGHT
'0'-'4'(30h,34h): STANDARD
'0'-'5'(30h,34h): CINEMA
'0'-'8'(30h,38h): CUSTOM1
'0'-'9'(30h,39h): CUSTOM2
'0'-'D'(30h,44h): SVE-1 SETTING
'0'-'E'(30h,45h): SVE-2 SETTING
'0'-'F'(30h,46h): SVE-3 SETTING
'1'-'0'(31h,30h): SVE-4 SETTING
'1'-'1'(31h,31h): SVE-5 SETTING
* Please select active picture mode on your system (setting).
* If you select inactive picture mode here, the input change execution will be ignored.
EXT1: Extension1
'0'-'0'(30h,30h): (On this monitor, it is always ‘00’)
EXT2: Extension 2
'0'-'0'(30h,30h): (On this monitor, it is always ‘00’)
EXT3: Extension 3
'0'-'0'(30h,30h): (On this monitor, it is always ‘00’)
EXT4: Extension 4
'0'-'0'(30h,30h): (On this monitor, it is always ‘00’)
EXT5: Extension 5
'0'-'0'(30h,30h): (On this monitor, it is always ‘00’)
EXT6: Extension 6
'0'-'0'(30h,30h): (On this monitor, it is always ‘00’)
EXT7: Extension 7
'0'-'0'(30h,30h): (On this monitor, it is always ‘00’)
ETX (03h): End of Message
(64/130)
Check code
BCC: Block Check Code
Refer to the section 4.3 “Check code” for a BCC calculation.
Delimiter
CR (0Dh): End of packet
2) The monitor replies a data for confirmation.
Header Message Check
SOH-'0'-'0'-Monitor ID-
'B'-'2'-'8'
Header
SOH (01h): Start of Header
'0' (30h): Reserved
'0' (30h): Message receiver is the controller.
Monitor ID: Indicate a replying Monitor ID.
Ex.) When this byte is set to 'A', the replying Monitor ID is '1'.
'B' (42h): Message type is "Command reply".
'2'-'8'(32h, 38h): Message length
Message
STX (02h): Start of Message
'C'-'3'-'2'-'2' (43h, 33h, 32h, 32h): Schedule writes reply command
ST: Schedule Status command
'0'-'0'(30h, 30h): No error
'0'-'1'(30h, 31h): Error
PG-ON HOURS-ON MIN-OFF HOURS-OFF MIN-INPUT-WD-FL-P MODE
EXT1-EXT2-EXT3-EXT4-EXT5-EXT6-EXT7: Schedule data
PG: Program No.
'0'-'0'(30h, 30h): Program No.1
|
'0'-'6'(30h, 36h): Program No.7
ON_HOUR: Turn on time (hour)
'0'-'0'(30h, 30h): 00
|
'1'-'7'(31h, 37h): 23 (=17h)
'1'-'8'(31h, 38h): ON timer isn't set.
ON_MIN: Turn on time (minute)
'0'-'0'(30h, 30h): 0
|
'3'-'B'(33h, 42h): 59
'3'-'C'(33h, 43h): On timer isn’t set.
OFF_HOUR: Turn off time (hour)
'0'-'0'(30h, 30h): 00
|
'1'-'7'(31h, 37h): 23 (=17h)
'1'-'8'(31h, 38h): Off timer isn't set.
OFF_MIN: Turn off time (minute)
'0'-'0'(30h, 30h): 0
|
'3'-'B'(33h, 42h): 59 (=3Bh)
'3'-'C'(33h, 43h): Off timer isn’t set.
INPUT: Timer input
'0'-'0'(30h,30h): No mean (works on last memory)
'0'-'3'(30h,33h): DVI1
'0'-'4'(30h,34h): DVI2
'0'-'D'(30h,44h): OPTION
'0'-'F'(30h,46h): DPORT
'1'-'0'(31h,30h): DPORT2
STX-'C'-'3'-'2'-'2'-ST-PG-ON HOUR-ON MIN-
OFF HOUR-OFF MIN-INPUT-WD-FL-P MODE-
EXT1-EXT2-EXT3-EXT4-EXT5-EXT6-EXT7-ETX
Delimiter
code
BCC CR
(65/130)
'1'-'1'(31h,31h): HDMI
'1'-'2'(31h,32h): HDMI2
'8'-'2'(38h,32h): HDMI3
'8'-'3'(38h,33h): HDMI4
WD: Week setting
bit 0: MONDAY
bit 1: TUESDAY
bit 2: WEDNESDAY
bit 3: THURSDAY
bit 4: FRIDAY
bit 5: SATURDAY
bit 6: SUNDAY
EX.
'0'-'1'(30h, 31h): MONDAY
'0'-'4'(30h, 34h): TUESDAY
'0'-'F'(30h, 46h): MONDAY, TUESDAY, WEDNESDAY and THURSDAY
'7'-'F'(37h, 46h): MONDAY to SUNDAY
FL: Option
bit 0: 0:once 1:Everyday
bit 1: 0:once 1:Every week
bit 2: 0:Disable 1:Enable
* When bit 0 and bit 1 are '1', it behaves as Everyday.
EX.
'0'-'1'(30h, 31h): Disable, Everyday
'0'-'4'(30h, 34h): Enable, once
P MODE: Picture mode
'0'-'0'(30h,30h): No mean (works on last memory)
'0'-'1'(30h,31h): sRGB
'0'-'3'(30h,33h): HIGHBRIGHT
'0'-'4'(30h,34h): STANDARD
'0'-'5'(30h,34h): CINEMA
'0'-'8'(30h,38h): CUSTOM1
'0'-'9'(30h,39h): CUSTOM2
'0'-'D'(30h,44h): SVE-1 SETTING
'0'-'E'(30h,45h): SVE-2 SETTING
'0'-'F'(30h,46h): SVE-3 SETTING
'1'-'0'(31h,30h): SVE-4 SETTING
'1'-'1'(31h,31h): SVE-5 SETTING
EXT1: Extension1
'0'-'0'(30h,30h): (On this monitor, it is always ‘00’)
EXT2: Extension 2
'0'-'0'(30h,30h): (On this monitor, it is always ‘00’)
EXT3: Extension 3
'0'-'0'(30h,30h): (On this monitor, it is always ‘00’)
EXT4: Extension 4
'0'-'0'(30h,30h): (On this monitor, it is always ‘00’)
EXT5: Extension 5
'0'-'0'(30h,30h): (On this monitor, it is always ‘00’)
EXT6: Extension 6
'0'-'0'(30h,30h): (On this monitor, it is always ‘00’)
EXT7: Extension 7
'0'-'0'(30h,30h): (On this monitor, it is always ‘00’)
ETX (03h): End of Message
Check code
(66/130)
BCC: Block Check Code
Refer to the section 4.3 “Check code” for a BCC calculation.
Delimiter
CR (0Dh): End of packet
3) The controller requests the monitor to write Enable/Disable Schedule.
Header Message Check code
SOH-'0'-Monitor ID-
'0'-'A'-'0'-'A'
Header
SOH (01h): Start of Header
'0' (30h): Reserved
Monitor ID: Specify the Monitor ID of which you want to change a setting.
Ex.) If Monitor ID is '1', specify 'A'.
'0' (30h): Message sender is the controller.
'A' (41h): Message type is "Command".
'0'-'A'(30h, 41h): Message length
Message
STX (02h): Start of Message
'C'-'2'-'1'-'5' (43h, 32h, 31h, 35h): Enable/Disable Schedule writes command
PG-EN: Enable/Disable Schedule data
PG: Program No.
'0'-'0'(30h, 30h): Program No.1
|
'0'-'6'(30h, 36h): Program No.7
EN: Enable /Disable
'0'-'0'(30h, 30h): Disable
'0'-'1'(30h, 31h): Enable
ETX (03h): End of Message
Check code
BCC: Block Check Code
Refer to the section 4.3 “Check code” for a BCC calculation.
STX-'C'-'2'-'1'-'5'-PG-EN-ETX BCC CR
Delimiter
Delimiter
CR (0Dh): End of packet
4) The monitor replies a data for confirmation.
Header Message Check code
SOH-'0'-'0'-Monitor ID-
'B'-'0'-'C'
Header
SOH (01h): Start of Header
'0' (30h): Reserved
'0' (30h): Message receiver is the controller.
Monitor ID: Indicate a replying Monitor ID.
Ex.) When this byte is set to 'A', the replying Monitor ID is '1'.
'B' (42h): Message type is "Command reply".
'0'-'C' (30h, 43h): Message length
Message
STX (02h): Start of Message
'C'-'3'-'1'-'5' (43h, 33h, 31h, 35h): Enable/Disable Schedule writes reply command
ST: Enable/Disable Schedule Status command
'0'-'0'(30h, 30h): No error
'0'-'1'(30h, 31h): Error
PG-EN: Enable/Disable Schedule data
PG: Program No.
'0'-'0'(30h, 30h): Program No.1
|
'0'-'6'(30h, 36h): Program No.7
STX-'C'-'3'-'1'-'5'-ST-PG-EN-ETX BCC CR
Delimiter
(67/130)
EN: Enable /Disable
'0'-'0'(30h, 30h): Disable
'0'-'1'(30h, 31h): Enable
ETX (03h): End of Message
Check code
BCC: Block Check Code
Refer to the section 4.3 “Check code” for a BCC calculation.
Delimiter
CR (0Dh): End of packet
(68/130)
***Following command also can be used for to keep backward compatibility, in order to
write the setting of the Schedule.
1) The controller requests the monitor to write Schedule.
Header Message Check code
SOH-'0'-Monitor ID-
'0'-'A'-'1'-'6'
STX-'C'-'2'-'1'-'4'-PG-ON HOUR-ON MIN-
OFF HOUR-OFF MIN-INPUT-WD-FL-ETX
BCC CR
Header
SOH (01h): Start of Header
'0' (30h): Reserved
Monitor ID: Specify the Monitor ID of which you want to change a setting.
Ex.) If Monitor ID is '1', specify 'A'.
'0' (30h): Message sender is the controller.
'A' (41h): Message type is "Command".
'1'-'6'(31h, 36h): Message length.
Message
STX (02h): Start of Message
'C'-'2'-'1'-'4' (43h, 32h, 31h, 34h): Schedule writes command
PG-ON HOURS-ON MIN-OFF HOURS-OFF MIN-INPUT-WD-FL: Schedule data
PG: Program No.
'0'-'0'(30h, 30h): Program No.1
|
'0'-'6'(30h, 36h): Program No.7
ON_HOUR: Turn on time (hour)
'0'-'0'(30h, 30h): 00
|
'1'-'7'(31h, 37h): 23 (=17h)
'1'-'8'(31h, 38h): ON timer isn't set.
ON_MIN: Turn on time (minute)
'0'-'0'(30h, 30h): 0
|
'3'-'B'(33h, 42h): 59
'3'-'C'(33h, 43h): On timer isn’t set.
OFF_HOUR: Turn off time (hour)
'0'-'0'(30h, 30h): 00
|
'1'-'7'(31h, 37h): 23 (=17h)
'1'-'8'(31h, 38h): Off timer isn't set.
OFF_MIN: Turn off time (minute)
'0'-'0'(30h, 30h): 0
|
'3'-'B'(33h, 42h): 59 (=3Bh)
'3'-'C'(33h, 43h): Off timer isn’t set.
INPUT: Timer input
'0'-'0'(30h, 30h): DVI1
'0'-'7'(30h, 37h): (Works on last memory)
* Please select active input on your system (setting).
* If you select inactive input here, the input change execution will be ignored.
WD: Week setting
bit 0: MONDAY
bit 1: TUESDAY
bit 2: WEDNESDAY
bit 3: THURSDAY
bit 4: FRIDAY
bit 5: SATURDAY
bit 6: SUNDAY
Delimiter
(69/130)
EX.
'0'-'1'(30h, 31h): MONDAY
'0'-'4'(30h, 34h): TUESDAY
'0'-'F'(30h, 46h): MONDAY, TUESDAY, WEDNESDAY and THURSDAY
'7'-'F'(37h, 46h): MONDAY to SUNDAY
FL: Option
bit 0: 0:once 1:Everyday
bit 1: 0:once 1:Every week
bit 2: 0:Disable 1:Enable
* When bit 0 and bit 1 are '1', it behaves as Everyday.
EX.
'0'-'1'(30h, 31h): Disable, Everyday
'0'-'4'(30h, 34h): Enable, once
ETX (03h): End of Message
Check code
BCC: Block Check Code
Refer to the section 4.3 “Check code” for a BCC calculation.
Delimiter
CR (0Dh): End of packet
2) The monitor replies a data for confirmation.
Header Message Check
SOH-'0'-'0'-Monitor ID-
'B'-'1'-'8'
Header
SOH (01h): Start of Header
'0' (30h): Reserved
'0' (30h): Message receiver is the controller.
Monitor ID: Indicate a replying Monitor ID.
Ex.) When this byte is set to 'A', the replying Monitor ID is '1'.
'B' (42h): Message type is "Command reply".
'1'-'8'(31h, 38h): Message length
Message
STX (02h): Start of Message
'C'-'3'-'1'-'4' (43h, 33h, 31h, 34h): Schedule writes reply command
ST: Schedule Status command
'0'-'0'(30h, 30h): No error
'0'-'1'(30h, 31h): Error
PG-ON HOURS-ON MIN-OFF HOURS-OFF MIN-INPUT-WD-FL: Schedule data
PG: Program No.
'0'-'0'(30h, 30h): Program No.1
|
'0'-'6'(30h, 36h): Program No.7
ON_HOUR: Turn on time (hour)
'0'-'0'(30h, 30h): 00
|
'1'-'7'(31h, 37h): 23 (=17h)
'1'-'8'(31h, 38h): ON timer isn't set.
ON_MIN: Turn on time (minute)
'0'-'0'(30h, 30h): 0
|
'3'-'B'(33h, 42h): 59
'3'-'C'(33h, 43h): On timer isn’t set.
OFF_HOUR: Turn off time (hour)
'0'-'0'(30h, 30h): 00
|
STX-'C'-'3'-'1'-'4'-ST-PG-ON HOUR-ON MIN-
OFF HOUR-OFF MIN-INPUT-WD-FL-ETX
Delimiter
code
BCC CR
(70/130)
'1'-'7'(31h, 37h): 23 (=17h)
'1'-'8'(31h, 38h): Off timer isn't set.
OFF_MIN: Turn off time (minute)
'0'-'0'(30h, 30h): 0
|
'3'-'B'(33h, 42h): 59 (=3Bh)
'3'-'C'(33h, 43h): Off timer isn’t set.
INPUT: Timer input
'0'-'0'(30h, 30h): DVI1
'0'-'7'(30h,30h): No mean (Works on last memory)
WD: Week setting
bit 0: MONDAY
bit 1: TUESDAY
bit 2: WEDNESDAY
bit 3: THURSDAY
bit 4: FRIDAY
bit 5: SATURDAY
bit 6: SUNDAY
EX.
'0'-'1'(30h, 31h): MONDAY
'0'-'4'(30h, 34h): TUESDAY
'0'-'F'(30h, 46h): MONDAY, TUESDAY, WEDNESDAY and THURSDAY
'7'-'F'(37h, 46h): MONDAY to SUNDAY
FL: Option
bit 0: 0:once 1:Everyday
bit 1: 0:once 1:Every week
bit 2: 0:Disable 1:Enable
* When bit 0 and bit 1 are '1', it behaves as Everyday.
EX.
'0'-'1'(30h, 31h): Disable, Everyday
'0'-'4'(30h, 34h): Enable, once
ETX (03h): End of Message
Check code
BCC: Block Check Code
Refer to the section 4.3 “Check code” for a BCC calculation.
Delimiter
CR (0Dh): End of packet
3) The controller requests the monitor to write Enable/Disable Schedule.
Header Message Check code
SOH-'0'-Monitor ID-
'0'-'A'-'0'-'A'
Header
SOH (01h): Start of Header
'0' (30h): Reserved
Monitor ID: Specify the Monitor ID of which you want to change a setting.
Ex.) If Monitor ID is '1', specify 'A'.
'0' (30h): Message sender is the controller.
'A' (41h): Message type is "Command".
'0'-'A'(30h, 41h): Message length
Message
STX (02h): Start of Message
'C'-'2'-'1'-'5' (43h, 32h, 31h, 35h): Enable/Disable Schedule writes command
PG-EN: Enable/Disable Schedule data
PG: Program No.
'0'-'0'(30h, 30h): Program No.1
|
STX-'C'-'2'-'1'-'5'-PG-EN-ETX BCC CR
Delimiter
(71/130)
'0'-'6'(30h, 36h): Program No.7
EN: Enable /Disable
'0'-'0'(30h, 30h): Disable
'0'-'1'(30h, 31h): Enable
ETX (03h): End of Message
Check code
BCC: Block Check Code
Refer to the section 4.3 “Check code” for a BCC calculation.
Delimiter
CR (0Dh): End of packet
4) The monitor replies a data for confirmation.
Header Message Check code
SOH-'0'-'0'-Monitor ID-
'B'-'0'-'C'
Header
SOH (01h): Start of Header
'0' (30h): Reserved
'0' (30h): Message receiver is the controller.
Monitor ID: Indicate a replying Monitor ID.
Ex.) When this byte is set to 'A', the replying Monitor ID is '1'.
'B' (42h): Message type is "Command reply".
'0'-'C' (30h, 43h): Message length
Message
STX (02h): Start of Message
'C'-'3'-'1'-'5' (43h, 33h, 31h, 35h): Enable/Disable Schedule writes reply command
ST: Enable/Disable Schedule Status command
'0'-'0'(30h, 30h): No error
'0'-'1'(30h, 31h): Error
PG-EN: Enable/Disable Schedule data
PG: Program No.
'0'-'0'(30h, 30h): Program No.1
|
'0'-'6'(30h, 36h): Program No.7
EN: Enable /Disable
'0'-'0'(30h, 30h): Disable
'0'-'1'(30h, 31h): Enable
ETX (03h): End of Message
Check code
BCC: Block Check Code
Refer to the section 4.3 “Check code” for a BCC calculation.
STX-'C'-'3'-'1'-'5'-ST-PG-EN-ETX BCC CR
Delimiter
CR (0Dh): End of packet
Delimiter
(72/130)
11. Self diagnosis
11.1 Self-diagnosis status read
This command is used in order to read the Self-diagnosis status.
1) The controller requests the monitor to read Self-diagnosis status.
Header Message Check code
SOH-'0'-Monitor ID-
'0'-'A'-'0'-'4'
Header
SOH (01h): Start of Header
'0' (30h): Reserved
Monitor ID: Specify the Monitor ID which you want to get status.
Ex.) If Monitor ID is '1', specify 'A'.
'0' (30h): Message sender is the controller.
'A' (41h): Message type is "Command".
'0'-'4'(30h, 34h): Message length
Message
STX (02h): Start of Message
'B'-'1' (42h, 31h): Self-diagnosis command
ETX (03h): End of Message
Check code
BCC: Block Check Code
Refer to the section 4.3 “Check code” for a BCC calculation.
Delimiter
CR (0Dh): End of packet
STX-'B'-'1'-ETX BCC CR
Delimiter
2) The monitor replies a result of the self-diagnosis.
Header Message Check code
SOH-'0'-'0'-Monitor ID-
'B'-N-N
Header
SOH (01h): Start of Header
'0' (30h): Reserved
'0' (30h): Message receiver is the controller.
Monitor ID: Indicate a replying Monitor ID.
Ex.) When this byte is set to 'A', the replying Monitor ID is '1'.
'B' (42h): Message type is "Command reply".
N-N: Message length
Note.) The maximum data length that can be written to the monitor at a time is 32bytes.
Ex.) The byte data 20h is encoded as ASCII characters '2' and '0' (34h and 30h).
Message
STX (02h): Start of Message
'A'-'1' (41h, 31h): Application Test Report reply command
ST: Result of self-tests
'0'-'0'(30h, 30h):00: Normal
'7'-'0'(37h, 30h):70: Standby-power +3.3V abnormality
'7'-'1'(37h, 31h):71: Standby-power +5V abnormality
'7'-'2'(37h, 32h):72: Panel-power +12V abnormality
'7'-'8'(37h, 38h):78: Inverter power/Option slot2 power +24V Abnormality
'8'-'0'(38h, 30h):80: Cooling fan-1 abnormality
'8'-'1'(38h, 31h):81: Cooling fan-2 abnormality
('8'-'2'(38h, 32h):82: Cooling fan-3 abnormality)
'9'-'0'(39h, 30h):90: LED Backlight abnormality
'9'-'1'(39h, 31h):91: LED Backlight abnormality
'A'-'0'(41h, 30h):A0: Temperature abnormality – shutdown
'A'-'1'(41h, 31h):A1: Temperature abnormality – half brightness
'A'-'2'(41h, 32h):A2: SENSOR reached at the temperature that the user had specified.
STX-'A'-'1'-
ST(0)-ST(1) --------ST(n)-ETX
Delimiter
BCC CR
(73/130)
'B'-'0'(42h, 30h):B0: No signal
'D'-'0'(44h, 30h):D0: PROOF OF PLAY buffer reduction
'E'-'0'(45h, 30h):E0: System error
ETX (03h): End of Message
Check code
BCC: Block Check Code
Refer to the section 4.3 “Check code” for a BCC calculation.
Delimiter
CR (0Dh): End of packet
(74/130)
12. Serial No. & Model Name Read
12.1 Serial No. Read
This command is used in order to read a serial number.
1) The controller requests the monitor to read a serial number.
Header Message Check code
SOH-'0'-Monitor ID-
'0'-'A'-'0'-'6'
Header
SOH (01h): Start of Header
'0' (30h): Reserved
Monitor ID: Specify the Monitor ID which you want to get serial number.
Ex.) If Monitor ID is '1', specify 'A'.
'0' (30h): Message sender is the controller.
'A' (41h): Message type is "Command".
'0'-'6'(30h, 36h): Message length
Message
STX (02h): Start of Message
'C'-'2'-'1'-'6' (43h, 32h, 31h, 36h): Serial No. command
ETX (03h): End of Message
Check code
BCC: Block Check Code
Refer to the section 4.3 “Check code” for a BCC calculation.
Delimiter
CR (0Dh): End of packet
STX-'C'-'2'-'1'-'6'-ETX BCC CR
Delimiter
2) The monitor replies the serial No. data to the controller.
Header Message Check code
SOH-'0'-'0'-Monitor ID-
'B'-N-N
Header
SOH (01h): Start of Header
'0' (30h): Reserved
'0' (30h): Message receiver is the controller.
Monitor ID: Indicate a replying Monitor ID.
Ex.) When this byte is set to 'A', the replying Monitor ID is '1'.
'B' (42h): Message type is "Command reply".
N-N: Message length
Note.) The maximum data length that can be returned from the monitor at a time is
32bytes.
Ex.) The byte data 20h is encoded as ASCII characters '2' and '0' (32h and 30h).
Message
STX (02h): Start of Message
'C'-'3'-'1'-'6' (41h, 33h, 31h, 36h): Serial No. reply command
Data(0)-Data(1)----Data(n):Serial Number
Ø
The byte data 20h is encoded as ASCII characters '2' and '0' (32h and 30h).
Ex.) Foe example when receiveing Serial Number data 33h 31h 33h 32h 33h 33h 33h 34h
Step1: Serial Number data is encoded as character string.
Example:
33h 31h 33h 32h 33h 33h 33h 34h -> '3','1','3','2','3','3','3','4'
Step2: Decode pairs of ASCII characters to hexadecimal values.
Example:
'3','1','3','2','3','3','3','4' -> 31h 32h 33h 34h
Step3: Byte data represents the ASCII string data.
Example:
31h 32h 33h 34h -> "1234"
Result: Serial Number is "1234".
STX-'C'-'3'-'1'-'6'-
Data(0)-Data(1)---Data(n)-ETX
Delimiter
BCC CR
(75/130)
Note: No null termination character is sent.
ETX (03h): End of Message
Check code
BCC: Block Check Code
Refer to the section 4.3 “Check code” for a BCC calculation.
Delimiter
CR (0Dh): End of packet
(76/130)
12.2 Model Name Read
This command is used in order to read the Model Name.
1) The controller requests the monitor to read Model Name.
Header Message Check code
SOH-'0'-Monitor ID-
'0'-'A'-'0'-'6'
Header
SOH (01h): Start of Header
'0' (30h): Reserved
Monitor ID: Specify the Monitor ID which you want to get Model Name.
Ex.) If Monitor ID is '1', specify 'A'.
'0' (30h): Message sender is the controller.
'A' (41h): Message type is "Command".
'0'-'6'(30h, 36h): Message length
Message
STX (02h): Start of Message
'C'-'2'-'1'-'7' (43h, 32h, 31h, 37h): Model Name command
ETX (03h): End of Message
Check code
BCC: Block Check Code
Refer to the section 4.3 “Check code” for a BCC calculation.
STX-'C'-'2'-'1'-'7'-ETX BCC CR
Delimiter
CR (0Dh): End of packet
2) The monitor replies the model name data to the controller.
Header Message Check code
SOH-'0'-'0'-Monitor ID-
'B'-N-N
Header
SOH (01h): Start of Header
'0' (30h): Reserved
'0' (30h): Message receiver is the controller.
Monitor ID: Indicate a replying Monitor ID.
Ex.) When this byte is set to 'A', the replying Monitor ID is '1'.
'B' (42h): Message type is "Command reply".
N-N: Message length
Note.) The maximum data length that can be returned from the monitor at a time is
32bytes.
Ex.) The byte data 20h is encoded as ASCII characters '2' and '0' (32h and 30h).
Message
STX (02h): Start of Message
'C'-'3'-'1'-'7' (43h, 33h, 31h, 37h): Model Name reply Command
Data(0) -Data(1)----Data(n):Model name
Ø
The byte data 20h is encoded as ASCII characters '2' and '0' (32h and 30h).
Ex.) Foe example when receiving Model Name data 35h 30h 33h 34h 33h 30h 33h 33h
Step1: Model Name data is encoded character string.
Example:
35h 30h 33h 34h 33h 30h 33h 33h -> '5','0','3','4','3','0','3','3'
Step2: Decode pairs of ASCII characters to hexadecimal values.
Example:
'5','0','3','4','3','0','3','3' -> 50h 34h 30h 33h
Step3: Byte data represents the ASCII string data.
Example:
50h 34h 30h 33h -> "P403"
Result: Model Name is "P403".
Note: No null termination character is sent.
ETX (03h): End of Message
Check code
BCC: Block Check Code
STX-'C'-'3'-'1'-'7'-
Data(0) -Data(1)—----Data(n)-ETX
Delimiter
Delimiter
BCC CR
(77/130)
Refer to the section 4.3 “Check code” for a BCC calculation.
Delimiter
CR (0Dh): End of packet
(78/130)
13. Security Lock
13.1 Security Lock Control
This command sets the condition of security lock function to "LOCK" or "UNLOCK".
If security pass codes 1st to 4th are matched with monitor resisted pass codes, then this command
is executed, and reply no error status and a new condition.
If codes aren't matched with them then setting isn't changed, and reply error status and a current
condition.
If the monitor receives this command while waiting for Pass codes inputs, then it only checks Pass
cords (and releases image muting if Pass codes are OK) and doesn't apply "EN" parameter.
1) The controller requests the monitor to set the condition of security lock.
Header Message Check code
SOH-'0'-MonitorID-
'0'-'A'-'1'-'0'
Header
SOH (01h): Start of Header
'0' (30h): Reserved
Monitor ID: Specify the Monitor ID of which you want to change a setting.
Ex.) If Monitor ID is '1', specify 'A'.
'0' (30h): Message sender is the controller.
'A' (41h): Message type is "Command".
'1'-'0'(31h, 30h): Message length
Message
STX (02h): Start of Message
'C'-'2'-'1'-'D' (43h, 32h, 31h, 44h): Security Lock Control command
EN-P1-P2-P3-P4: Lock condition control data
EN: SECURE MODE
'0'-'0'(30h, 30h): OFF
'0'-'1'(30h, 31h): START-UP LOCK
'0'-'2'(30h, 32h): CONTROL LOCK
'0'-'3'(30h, 33h): BOTH LOCK
P1: Security Pass code 1st
'0'-'0'(30h, 30h): "0"
|
'0'-'9'(30h, 39h): "9"
P2: Security Pass code 2nd
'0'-'0'(30h, 30h): "0"
|
'0'-'9'(30h, 39h): "9"
P3: Security Pass code 3rd
'0'-'0'(30h, 30h): "0"
|
'0'-'9'(30h, 39h): "9"
P4: Security Pass code 4th
'0'-'0'(30h, 30h): "0"
|
'0'-'9'(30h, 39h): "9"
ETX (03h): End of Message
Check code
BCC: Block Check Code
Refer to the section 4.3 “Check code” for a BCC calculation.
Delimiter
CR (0Dh): End of packet
STX-'C'-'2'-'1'-'D'-
EN-P1-P2-P3-P4-ETX
Delimiter
BCC CR
(79/130)
2) The monitor replies the result to the controller.
Header Message Check code
SOH-'0'-'0'-Monitor ID-
'B'-'0'-'A'
STX-'C'-'3'-'1'-'D'-
ST-EN-ETX
BCC CR
Header
SOH (01h): Start of Header
'0' (30h): Reserved
'0' (30h): Message receiver is the controller.
Monitor ID: Indicate a replying Monitor ID.
Ex.) When this byte is set to 'A', the replying Monitor ID is '1'.
'B' (42h): Message type is "Command reply".
'0'-'A'(30h, 41h): Message length
Message
STX (02h): Start of Message
'C'-'3'-'1'-'D' (43h, 33h, 31h, 44h): Security Lock Control reply command
ST-EN: Lock condition result data
ST: Status
'0'-'0'(30h, 30h): No error
'0'-'1'(30h, 31h): Error
EN: SECURE MODE (Current condition)
'0'-'0'(30h, 30h): OFF
'0'-'1'(30h, 31h): START-UP LOCK
'0'-'2'(30h, 32h): CONTROL LOCK
'0'-'3'(30h, 33h): BOTH LOCK
ETX (03h): End of Message
Check code
BCC: Block Check Code
Refer to the section 4.3 “Check code” for a BCC calculation.
Delimiter
CR (0Dh): End of packet
Delimiter
(80/130)
14. Direct TV Chanel Read & Write
When DTV unit (Option unit) is installed, channel settings is read and write directly.
14.1 Direct TV Chanel Read & Reply
1) The controller requests the monitor to read channel information.
Header Message Check code
SOH-'0'-Monitor ID-
'0'-'A'-'0'-'6'
Header
SOH (01h): Start of Header
'0' (30h): Reserved
Monitor ID: Specify the Monitor ID which you want to get Model Name.
Ex.) If Monitor ID is '1', specify 'A'.
'0' (30h): Message sender is the controller.
'A' (41h): Message type is "Command".
'0'-'6'(30h, 36h): Message length
Message
STX (02h): Start of Message
'C'-'2'-'2'-'C' (43h, 32h, 32h, 43h): Direct TV Channel Read command
ETX (03h): End of Message
Check code
BCC: Block Check Code
Refer to the section 4.3 “Check code” for a BCC calculation.
STX-'C'-'2'-'2'-'C'-ETX BCC CR
Delimiter
CR (0Dh): End of packet
2) The monitor replies the result to the controller.
Header Message Check code
SOH-'0'-'0'-Monitor ID-
'B'-'1'-'2'
STX-'C'-'3'-'2'-'C'-
MajorCH-MinorCH-ETX
BCC CR
Header
SOH (01h): Start of Header
'0' (30h): Reserved
'0' (30h): Message receiver is the controller.
Monitor ID: Indicate a replying Monitor ID.
Ex.) When this byte is set to 'A', the replying Monitor ID is '1'.
'B' (42h): Message type is "Command reply".
'1'-'2'(31h, 32h): Message length = 18bytes
Message
STX (02h): Start of Message
'C'-'3'-'2'-'C' (43h, 33h, 32h, 43h): Direct TV Channel read reply command
MajorCH: Major Channel (00000000h – FFFFFFFFh),
'0'-'0'-'0'-'0'-'0'-'0'-'0'-'0' - 'F'-'F'-'F'-'F'-'F'-'F'-'F'-'F'
MinorCH: Minor Channel (0000h – FFFFh),
'0'-'0'-'0'-'0' - 'F'-'F'-'F'-'F'
ETX (03h): End of Message
Check code
BCC: Block Check Code
Refer to the section 4.3 “Check code” for a BCC calculation.
Delimiter
CR (0Dh): End of packet
Delimiter
Delimiter
(81/130)
14.2 Direct TV Chanel Write & Reply
1) The controller requests the monitor to write channel information.
Header Message Check code
SOH-'0'-Monitor ID-
'0'-'A'-'1'-'2'
Header
SOH (01h): Start of Header
'0' (30h): Reserved
Monitor ID: Specify the Monitor ID which you want to get Model Name.
Ex.) If Monitor ID is '1', specify 'A'.
'0' (30h): Message sender is the controller.
'A' (41h): Message type is "Command".
'1'-'2'(31h, 32h): Message length = 18bytes
Message
STX (02h): Start of Message
'C'-'2'-'2'-'D' (43h, 32h, 32h, 44h): Direct TV Channel write command
MajorCH: Major Channel (00000000h – FFFFFFFFh),
'0'-'0'-'0'-'0'-'0'-'0'-'0'-'0' - 'F'-'F'-'F'-'F'-'F'-'F'-'F'-'F'
MinorCH: Minor Channel (0000h – FFFFh),
'0'-'0'-'0'-'0' - 'F'-'F'-'F'-'F'
ETX (03h): End of Message
Check code
BCC: Block Check Code
Refer to the section 4.3 “Check code” for a BCC calculation.
STX-'C'-'2'-'2'-'D'-
Delimiter
BCC CR
MajorCH-MinorCH-ETX
Delimiter
CR (0Dh): End of packet
2) The monitor replies the result to the controller.
Header Message Check code
SOH-'0'-'0'-Monitor ID-
'B'-'1'-'2'
STX-'C'-'3'-'2'-'D'-
MajorCH-MinorCH-ETX
BCC CR
Header
SOH (01h): Start of Header
'0' (30h): Reserved
'0' (30h): Message receiver is the controller.
Monitor ID: Indicate a replying Monitor ID.
Ex.) When this byte is set to 'A', the replying Monitor ID is '1'.
'B' (42h): Message type is "Command reply".
'1'-'2'(31h, 32h): Message length = 18bytes
Message
STX (02h): Start of Message
'C'-'3'-'2'-'D' (43h, 33h, 32h, 43h): Direct TV Channel write reply command
MajorCH: Major Channel (00000000h – FFFFFFFFh),
'0'-'0'-'0'-'0'-'0'-'0'-'0'-'0' - 'F'-'F'-'F'-'F'-'F'-'F'-'F'-'F'
MinorCH: Minor Channel (0000h – FFFFh),
'0'-'0'-'0'-'0' - 'F'-'F'-'F'-'F'
ETX (03h): End of Message
Check code
BCC: Block Check Code
Refer to the section 4.3 “Check code” for a BCC calculation.
Delimiter
CR (0Dh): End of packet
Delimiter
(82/130)
15. Daylight Saving read & write
15.1 Daylight Saving Read
This command is used in order to read the setting of Daylight Saving.
1) The controller requests the monitor to reply a Daylight Saving setting.
Header Message Check code
SOH-'0'-Monitor ID-
'0'-'A'-'0'-'8'
Header
SOH (01h): Start of Header
'0' (30h): Reserved
Monitor ID: Specify the Monitor ID of which you want to change a setting.
Ex.) If Monitor ID is '1', specify 'A'.
'0' (30h): Message sender is the controller.
'A' (41h): Message type is "Command".
'0'-'8'(30h, 38h): Message length (8bytes)
Message
STX (02h): Start of Message
'C'-'A'-'0'-'1' (43h, 41h, 30h, 31h): Daylight Saving Command
'0'-'0' (30h. 30h): Read
ETX (03h): End of Message
Check code
BCC: Block Check Code
Refer to the section 4.3 “Check code” for a BCC calculation.
Delimiter
CR (0Dh): End of packet
2) The monitor replies Date & Time to the controller.
Header Message Check
SOH-'0'-'0'-Monitor ID-
'B'-'2'-'0'
STX-'C'-'A'-'0'-'1'-'0'-'0'-ETX BCC CR
STX-'C'-'B'-'0'-'1'-'0'-'0'-ST-BM-BD1-BD
-BT1-BT2-EM-ED1-ED2-ET1-ET2-TD-ETX
Delimiter
Delimiter
code
BCC CR
Header
SOH (01h): Start of Header
'0' (30h): Reserved
'0' (30h): Message receiver is the controller.
Monitor ID: Indicate a replying Monitor ID.
Ex.) When this byte is set to ‘A’, replying monitor’s ID is ‘1’.
'B' (42h): Message type is "Command reply".
'2'-'0'(32h, 30h): Message length (32bytes)
Message
STX (02h): Start of Message
'C'-'B'-'0'-'1' (43h, 42h, 30h, 31h): Daylight Saving Setting reply command
'0'-'0' (30h, 30h): Read
ST: Error Status
No Error : 00h (30h, 30h)
Error : 01h (30h, 31h)
BM: BEGIN MONTH
JANUARY – DECEMBER: 01h (30h, 31h) - 12h (31h, 32h)
BD1: BEGIN DAY1
FIRST : 01h (30h, 31h)
SECOND : 02h (30h, 32h)
THIRD : 03h (30h, 33h)
FOUR : 04h (30h, 34h)
(83/130)
LAST : 05h (30h, 35h)
BD2: BEGIN DAY2 (Day of the week)
SUNDAY : 01h (30h, 31h)
MONDAY : 02h (30h, 32h)
TUESDAY : 03h (30h, 33h)
WEDNESDAY : 04h (30h, 34h)
THURSDAY : 05h (30h, 35h)
FRIDAY : 06h (30h, 36h)
SATURDAY : 07h (30h, 37h)
BT1: BEGIN TIME1 (Hour)
00h (30h, 30h) – 23 (32h, 33h)
BT2: BEGIN TIME2 (Minute)
00h (30h, 30h) – 59 (35h, 39h)
EM: END MONTH
JANUARY – DECEMBER: 01h (30h, 31h) - 12h (31h, 32h)
ED1: END DAY1
FIRST : 01h (30h, 31h)
SECOND : 02h (30h, 32h)
THIRD : 03h (30h, 33h)
FOUR : 04h (30h, 34h)
LAST : 05h (30h, 35h)
ED2: END DAY2 (Day of the week)
SUNDAY : 01h (30h, 31h)
MONDAY : 02h (30h, 32h)
TUESDAY : 03h (30h, 33h)
WEDNESDAY : 04h (30h, 34h)
THURSDAY : 05h (30h, 35h)
FRIDAY : 06h (30h, 36h)
SATURDAY : 07h (30h, 37h)
ET1: END TIME1 (Hour)
00h (30h, 30h) – 23 (32h, 33h)
ET2: END TIME2 (Minute)
00h (30h, 30h) – 59 (35h, 39h)
TD: TIME DIFFERENCE
+01:00 : 00h (30h, 30h)
+00:30 : 01h (30h, 31h)
-00:30 : 02h (30h, 32h)
-01:00 : 03h (30h, 33h)
ETX (03h): End of Message
Check code
BCC: Block Check Code
Refer to the section 4.3 “Check code” for a BCC calculation.
Delimiter
CR (0Dh): End of packet
(84/130)
15.2 Daylight Saving Write
This command is used in order to write the setting of the Daylight Saving.
1) The controller requests the monitor to write Daylight Saving.
Header Message Check code
SOH-'0'-Monitor ID-
'0'-'A'-'1'-'E'
Header
SOH (01h): Start of Header
'0' (30h): Reserved
Monitor ID: Specify the Monitor ID of which you want to change a setting.
Ex.) If Monitor ID is '1', specify 'A'.
'0' (30h): Message sender is the controller.
'A' (41h): Message type is "Command".
'1'-'E'(31h, 45h): Message length (30bytes)
Message
STX (02h): Start of Message
'C'-'A'-'0'-'1' (43h, 41h, 30h, 31h): Daylight Saving Setting Command
'0'-'1' (30h, 31h): Write
BM: BEGIN MONTH
JANUARY – DECEMBER: 01h (30h, 31h) - 12h (31h, 32h)
BD1: BEGIN DAY1
FIRST : 01h (30h, 31h)
SECOND : 02h (30h, 32h)
THIRD : 03h (30h, 33h)
FOUR : 04h (30h, 34h)
LAST : 05h (30h, 35h)
BD2: BEGIN DAY2 (Day of the week)
SUNDAY : 01h (30h, 31h)
MONDAY : 02h (30h, 32h)
TUESDAY : 03h (30h, 33h)
WEDNESDAY : 04h (30h, 34h)
THURSDAY : 05h (30h, 35h)
FRIDAY : 06h (30h, 36h)
SATURDAY : 07h (30h, 37h)
BT1: BEGIN TIME1 (Hour)
00h (30h, 30h) – 23 (32h, 33h)
BT2: BEGIN TIME2 (Minute)
00h (30h, 30h) – 59 (35h, 39h)
EM: END MONTH
JANUARY – DECEMBER: 01h (30h, 31h) - 12h (31h, 32h)
ED1: END DAY1
FIRST : 01h (30h, 31h)
SECOND : 02h (30h, 32h)
THIRD : 03h (30h, 33h)
FOUR : 04h (30h, 34h)
LAST : 05h (30h, 35h)
ED2: END DAY2 (Day of the week)
SUNDAY : 01h (30h, 31h)
MONDAY : 02h (30h, 32h)
TUESDAY : 03h (30h, 33h)
WEDNESDAY : 04h (30h, 34h)
THURSDAY : 05h (30h, 35h)
FRIDAY : 06h (30h, 36h)
SATURDAY : 07h (30h, 37h)
ET1: END TIME1 (Hour)
00h (30h, 30h) – 23 (32h, 33h)
ET2: END TIME2 (Minute)
00h (30h, 30h) – 59 (35h, 39h)
TD: TIME DIFFERENCE
STX-'C'-'A'-'0'-'1'-'0'-'1'-BM-BD1-BD2-
BT1-BT2-EM-ED1-ED2-ET1-ET2-TD-ETX
BCC CR
Delimiter
(85/130)
+01:00 : 00h (30h, 30h)
+00:30 : 01h (30h, 31h)
-00:30 : 02h (30h, 32h)
-01:00 : 03h (30h, 33h)
ETX (03h): End of Message
Check code
BCC: Block Check Code
Refer to the section 4.3 “Check code” for a BCC calculation.
Delimiter
CR (0Dh): End of packet
2) The monitor replies a written in result.
Header Message Check code
SOH-'0'-'0'-Monitor ID-
'B'-'0'-'A'
Header
SOH (01h): Start of Header
'0' (30h): Reserved
'0' (30h): Message receiver is the controller.
Monitor ID: Indicate a replying Monitor ID.
Ex.) When this byte is set to ‘A’, replying monitor’s ID is ‘1’.
'B' (42h): Message type is "Command reply".
'0'-'A'(30h, 41h): Message length (10bytes)
Message
STX (02h): Start of Message
'C'-'B'-'0'-'1' (43h, 42h, 30h, 31h): Daylight Saving Setting Command
'0'-'1' (30h, 31h): Write
ST: Error Status
No Error : 00h (30h, 30h)
Error : 01h (30h, 31h)
ETX (03h): End of Message
STX-'C'-'B'-'0'-'1'-'0'-'1'-ST-ETX BCC CR
Delimiter
Check code
BCC: Block Check Code
Refer to the section 4.3 “Check code” for a BCC calculation.
Delimiter
CR (0Dh): End of packet
(86/130)
16. Firmware Version
16.1 Firmware Version Read
This command is used in order to read a firmware version.
1) The controller requests the monitor to reply a firmware version.
Header Message Check code
SOH-'0'-Monitor ID-
'0'-'A'-'0'-'8'
Header
SOH (01h): Start of Header
'0' (30h): Reserved
Monitor ID: Specify the Monitor ID of which you want to change a setting.
Ex.) If Monitor ID is '1', specify 'A'.
'0' (30h): Message sender is the controller.
'A' (41h): Message type is "Command".
'0'-'8'(30h, 38h): Message length (8bytes)
Message
STX (02h): Start of Message
'C'-'A'-'0'-'2' (43h, 41h, 30h, 32h): Firmware Version Command
TY: Firmware Type
Firmware1 : 00h (30h, 30h)
Firmware2 : 01h (30h, 31h)
Firmware3 : 02h (30h, 32h)
Firmware4 : 03h (30h, 33h)
ETX (03h): End of Message
Check code
BCC: Block Check Code
Refer to the section 4.3 “Check code” for a BCC calculation.
Delimiter
CR (0Dh): End of packet
STX-'C'-'A'-'0'-'2'-TY-ETX BCC CR
Delimiter
2) The monitor replies a firmware version to the controller.
Header Message Check code
SOH-'0'-Monitor ID-
'0'-'B'-'1'-'1'
Header
SOH (01h): Start of Header
'0' (30h): Reserved
'0' (30h): Message receiver is the controller.
Monitor ID: Indicate a replying Monitor ID.
Ex.) When this byte is set to ‘A’, replying monitor’s ID is ‘1’.
'B' (42h): Message type is "Command reply".
'1'-'1'(31h, 31h): Message length (17bytes)
Message
STX (02h): Start of Message
'C'-'B'-'0'-'2' (43h, 42h, 30h, 32h): Firmware Version Read reply
ST: Error Status
No Error : 00h (30h, 30h)
Error : 01h (30h, 31h)
TY: Firmware Type
Firmware1 : 00h (30h, 30h)
Firmware2 : 01h (30h, 31h)
MV: Major Version:
STX-'C'-B'-'0'-'2'-ST-TY-MV-
PP-BV1-BV2-BV3-BR1-BR2-ETX
BCC CR
Delimiter
(87/130)
00h (30h, 30h) – 09h (30h, 39h)
PP: Period:
2Eh (32h, 45h) (fixed)
BV1: Minor (Basic) Version1:
00h (30h, 30h) – 09h (30h, 39h)
BV2: Minor (Basic) Version2:
00h (30h, 30h) – 09h (30h, 39h)
BV3: Minor (Basic) Version3:
00h (30h, 30h) – 09h (30h, 39h)
BR1: Branch Version1:
A:41h (34h, 31h) – Z:5Ah (35h, 41h)
BR2: Branch Version1:
A:41h (34h, 31h) – Z:5Ah (35h, 41h)
Check code
BCC: Block Check Code
Refer to the section 4.3 “Check code” for a BCC calculation.
Delimiter
CR (0Dh): End of packet
(88/130)
17. Auto ID
17.1 Auto ID Execute
This command is used in order to execute Auto ID function.
1) The controller requests the monitor to execute Auto ID function.
Header Message Check code
SOH-'0'-Monitor ID-
'0'-'A'-'0'-'8'
Header
SOH (01h): Start of Header
'0' (30h): Reserved
Monitor ID: Specify the Monitor ID of which you want to change a setting.
Ex.) If Monitor ID is '1', specify 'A'.
'0' (30h): Message sender is the controller.
'A' (41h): Message type is "Command".
'0'-'8'(30h, 38h): Message length (8byte)
Message
STX (02h): Start of Message
'C'-'A'-'0'-'A' (43h, 41h, 30h, 41h, 30h, 31h): Auto ID Command
'0'-'1' (30h, 30h): Execute
ETX (03h): End of Message
Check code
BCC: Block Check Code
Refer to the section 4.3 “Check code” for a BCC calculation.
Delimiter
CR (0Dh): End of packet
2) The monitor replies receipt result.
Header Message Check code
SOH-'0'-'0'-Monitor ID-
'B'-'0'-'A'
STX-'C'-'A'-'0'-'A'-'0'-'1'-ETX BCC CR
STX-'C'-'B'-'0'-'A'-'0'-'1'-ST-ETX BCC CR
Delimiter
Delimiter
Header
SOH (01h): Start of Header
'0' (30h): Reserved
'0' (30h): Message receiver is the controller.
Monitor ID: Indicate a replying Monitor ID.
Ex.) When this byte is set to ‘A’, replying monitor’s ID is ‘1’.
'B' (42h): Message type is "Command reply".
'0'-'A'(30h,41h): Message length (10byte)
Message
STX (02h): Start of Message
'C'-'B'-'0'-'A' (43h, 42h, 30h, 41h, 30h, 31h): Auto ID Reply Command
'0'-'1' (30h, 30h): Execute
ST: Error Status
No Error : 00h (30h, 30h)
Error : 01h (30h, 31h)
ETX (03h): End of Message
Check code
BCC: Block Check Code
Refer to the section 4.3 “Check code” for a BCC calculation.
(89/130)
Delimiter
CR (0Dh): End of packet
(90/130)
17.2 Auto ID Complete
This command is used in order to notify complete status of Auto ID.
1) The monitor sends the controller to complete status of Auto ID.
Header Message Check code
SOH-'0'-Monitor ID-
'0'-'A'-'0'-'C'
Header
SOH (01h): Start of Header
'0' (30h): Reserved
Monitor ID: Specify the Monitor ID of which you want to change a setting.
Ex.) If Monitor ID is '1', specify 'A'.
'0' (30h): Message sender is the controller.
'A' (41h): Message type is "Command".
'0'-'C'(30h,43h): Message length (12byte)
Message
STX (02h): Start of Message
'C'-'A'-'0'-'A'-'0'-'2' (43h, 41h, 30h, 41h, 30h, 32h): Auto ID
'0'-'2' (30h,32h): Complete
ST: Error Status
No Error : 00h (30h, 30h)
Error : 01h (30h, 31h)
MON: DETECTED MONITORS
01h (30h, 31h) - 64h (36h, 34h)
ETX (03h): End of Message
Check code
BCC: Block Check Code
Refer to the section 4.3 “Check code” for a BCC calculation.
Delimiter
CR (0Dh): End of packet
2) The controller replies to the monitor.
Header Message Check code
SOH-'0'-'0'-Monitor ID-
'B'-'0'-'A'
STX-'C'-'A'-'0'-'A'-'0'-'2'-ST-MON-ETX BCC CR
STX-'C'-'B'-'0'-'A'-'0'-'2'-ST-ETX BCC CR
Delimiter
Delimiter
Header
SOH (01h): Start of Header
'0' (30h): Reserved
'0' (30h): Message receiver is the controller.
Monitor ID: Indicate a replying Monitor ID.
Ex.) When this byte is set to ‘A’, replying monitor’s ID is ‘1’.
'B' (42h): Message type is "Command reply".
'0'-'A'(30h,41h): Message length (10byte)
Message
STX (02h): Start of Message
'C'-'B'-'0'-'A' (43h, 42h, 30h, 41h): Auto ID Reply Command
'0'-'2' (30h,32h): Complete
ST : Error Status
No Error : 00h (30h, 30h) *Fixed
ETX (03h): End of Message
(91/130)
Check code
BCC: Block Check Code
Refer to the section 4.3 “Check code” for a BCC calculation.
Delimiter
CR (0Dh): End of packet
(92/130)
17.3 Auto ID Reset
This command is used in order to reset Auto ID.
1) The controller requests the monitor to reset Auto ID.
Header Message Check code
SOH-'0'-Monitor ID-
'0'-'A'-'0'-'8'
Header
SOH (01h): Start of Header
'0' (30h): Reserved
Monitor ID: Specify the Monitor ID of which you want to change a setting.
Ex.) If Monitor ID is '1', specify 'A'.
'0' (30h): Message sender is the controller.
'A' (41h): Message type is "Command".
'0'-'8'(30h, 38h): Message length (8byte)
Message
STX (02h): Start of Message
'C'-'A'-'0'-'A' (43h, 41h, 30h, 41h): Auto ID Command
'0'-'3' (30h, 33h): Reset
ETX (03h): End of Message
Check code
BCC: Block Check Code
Refer to the section 4.3 “Check code” for a BCC calculation.
Delimiter
CR (0Dh): End of packet
2) The monitor replies to the controller.
Header Message Check code
SOH-'0'-'0'-Monitor ID-
'B'-'0'-'A'
STX-'C'-'A'-'0'-'A'-'0'-'3'-ETX BCC CR
STX-'C'-'B'-'0'-'A'-'0'-'3'-ST-ETX BCC CR
Delimiter
Delimiter
Header
SOH (01h): Start of Header
'0' (30h): Reserved
'0' (30h): Message receiver is the controller.
Monitor ID: Indicate a replying Monitor ID.
Ex.) When this byte is set to ‘A’, replying monitor’s ID is ‘1’.
'B' (42h): Message type is "Command reply".
'0'-'A'(30h,41h): Message length (10byte)
Message
STX (02h): Start of Message
'C'-'B'-'0'-'A' (43h, 42h, 30h, 41h): Auto ID Reply
'0'-'3' (30h, 33h): Reset
ST: Error Status
No Error : 00h (30h, 30h)
Error : 01h (30h, 31h)
ETX (03h): End of Message
Check code
BCC: Block Check Code
Refer to the section 4.3 “Check code” for a BCC calculation.
Delimiter
CR (0Dh): End of packet
(93/130)
18. Input Name
18.1 Input Name Read
This command is used in order to read the setting of Input Name.
1) The controller requests the monitor to reply Input Name setting.
Header Message Check code
SOH-'0'-Monitor ID-
'0'-'A'-'0'-'8'
Header
SOH (01h): Start of Header
'0' (30h): Reserved
Monitor ID: Specify the Monitor ID of which you want to change a setting.
Ex.) If Monitor ID is '1', specify 'A'.
'0' (30h): Message sender is the controller.
'A' (41h): Message type is "Command".
'0'-'8'(30h, 38h): Message length (8bytes)
Message
STX (02h): Start of Message
'C'-'A'-'0'-'4' (43h, 41h, 30h, 34h): Input Name Command
'0'-'0' (30h. 30h): Read
ETX (03h): End of Message
Check code
BCC: Block Check Code
Refer to the section 4.3 “Check code” for a BCC calculation.
Delimiter
CR (0Dh): End of packet
2) The monitor replies Input Name to the controller.
Header Message Check
SOH-'0'-'0'-Monitor ID-
'B'-LN(H)-LN(L)
STX-'C'-'A'-'0'-'4'-'0'-'0'-ETX BCC CR
STX-'C'-'B'-'0'-'4'-'0'-'0'-
Data(0)-Data(1)-Data(2)- --- -Data(n)-ETX
Delimiter
Delimiter
code
BCC CR
Header
SOH (01h): Start of Header
'0' (30h): Reserved
'0' (30h): Message receiver is the controller.
Monitor ID: Indicate a replying Monitor ID.
Ex.) When this byte is set to ‘A’, replying monitor’s ID is ‘1’.
'B' (42h): Message type is "Command reply".
LN(H)-LN(L): Message length (byte length), from STX to ETX
Ex.) The byte data 20h is encoded as ASCII characters '2' and '0' (32h and 30h).
Message
STX (02h): Start of Message
'C'-'B'-'0'-'4' (43h, 42h, 30h, 34h): Input Name command reply
'0'-'0' (30h, 30h): Read
Data(n) : Input name *n = Max 14
Ø
The byte data 20h is encoded as ASCII characters '2' and '0' (32h and 30h).
Ex.) For example when receiving Data(n) of 35h 36h 34h 37h 34h 31h
Step1: Input Name data is encoded as character code.
Example:
35h 36h 34h 37h 34h 31h -> '5'-'6'-'4'-'7'-'4'-'1'
Step2: Decode pairs of ASCII characters to hexadecimal values.
Example:
'5'-'6'-'4'-'7'-'4'-'1' -> 56h 47h 41h
Step3: Byte data represents the ASCII string data.
(94/130)
Result: Input Name is “VGA”.
Note: No null termination character is sent.
ETX (03h): End of Message
Check code
BCC: Block Check Code
Refer to the section 4.3 “Check code” for a BCC calculation.
Delimiter
CR (0Dh): End of packet
Example:
56h 47h 41h -> “VGA”
(95/130)
18.2 Input Name Write
This command is used in order to write the setting of Input Name.
1) The controller requests the monitor to write Input Name.
Header Message Check
SOH-'0'-Monitor ID-
'0'-'A'- LN(H)-LN(L)
Header
SOH (01h): Start of Header
'0' (30h): Reserved
Monitor ID: Specify the Monitor ID of which you want to change a setting.
Ex.) If Monitor ID is '1', specify 'A'.
'0' (30h): Message sender is the controller.
'A' (41h): Message type is "Command".
LN(H)-LN(L): Message length (byte length), from STX to ETX
Ex.) The byte data 20h is encoded as ASCII characters '2' and '0' (32h and 30h).
Message
STX (02h): Start of Message
'C'-'A'-'0'-'4' (43h, 41h, 30h, 34h): Input name Command
'0'-'1' (30h, 31h): Write
Data(n) : Input name *n = Max 14
Ø
The byte data 20h is encoded as ASCII characters '2' and '0' (32h and 30h).
Ex.) In the case of Input Name "VGA"
Step1: Input Name data is handled as character code.
Example:
"VGA" -> 56h 47h 41h (ASCII)
Step2: The hexadecimal value of each original character is encoded as two ASCII
characters representing the value.
Example:
56h 47h 41h -> '5'-'6'-'4'-'7'-'4'-'1'
Result: The following data is assigned to Data(n).
35h 36h 34h 37h 34h 31h
ETX (03h): End of Message
Check code
BCC: Block Check Code
Refer to the section 4.3 “Check code” for a BCC calculation.
Delimiter
CR (0Dh): End of packet
2) The monitor replies a written in result.
Header Message Check code
SOH-'0'-'0'-Monitor ID-
'B'-'0'-'A'
STX-'C'-'A'-'0'-'4'-'0'-1'-
Data(0)-Data(1)-Data(2)- --- -Data(n)-ETX
STX-'C'-'B'-'0'-'0'-'0'-'1'-ST-ETX BCC CR
Delimiter
code
BCC CR
Delimiter
Header
SOH (01h): Start of Header
'0' (30h): Reserved
'0' (30h): Message receiver is the controller.
Monitor ID: Indicate a replying Monitor ID.
Ex.) When this byte is set to ‘A’, replying monitor’s ID is ‘1’.
'B' (42h): Message type is "Command reply".
'0'-'A'(30h, 41h): Message length (10bytes)
Message
STX (02h): Start of Message
'C'-'B'-'0'-'4' (43h, 42h, 30h, 34h): Input name Command
'0'-'1' (30h, 31h): Write
(96/130)
ST: Status
00h (30h, 30h): No Error
01h (30h, 31h): Error
ETX (03h): End of Message
Check code
BCC: Block Check Code
Refer to the section 4.3 “Check code” for a BCC calculation.
Delimiter
CR (0Dh): End of packet
(97/130)
18.3 Input Name Reset
This command is used in order to reset the Input Name.
1) The controller requests the monitor to reset Input Name.
Header Message Check code
SOH-'0'-Monitor ID-
'0'-'A'-'0'-'8'
Header
SOH (01h): Start of Header
'0' (30h): Reserved
Monitor ID: Specify the Monitor ID of which you want to change a setting.
Ex.) If Monitor ID is '1', specify 'A'.
'0' (30h): Message sender is the controller.
'A' (41h): Message type is "Command".
'0'-'8'(30h, 38h): Message length (8bytes)
Message
STX (02h): Start of Message
'C'-'A'-'0'-'4' (43h, 41h, 30h, 34h): Input Name Command
'0'-'2' (30h. 32h): Reset
ETX (03h): End of Message
Check code
BCC: Block Check Code
Refer to the section 4.3 “Check code” for a BCC calculation.
Delimiter
CR (0Dh): End of packet
2) The monitor replies result.
Header Message Check code
SOH-'0'-'0'-Monitor ID-
'B'-'0'-'A'
STX-'C'-'A'-'0'-'4'-'0'-'2'-ETX BCC CR
STX-'C'-'B'-'0'-'0'-'0'-'2'-ST-ETX BCC CR
Delimiter
Delimiter
Header
SOH (01h): Start of Header
'0' (30h): Reserved
'0' (30h): Message receiver is the controller.
Monitor ID: Indicate a replying Monitor ID.
Ex.) When this byte is set to ‘A’, replying monitor’s ID is ‘1’.
'B' (42h): Message type is "Command reply".
'0'-'A'(30h, 41h): Message length (10bytes)
Message
STX (02h): Start of Message
'C'-'B'-'0'-'4' (43h, 42h, 30h, 34h): Input name Command
'0'-'2' (30h, 32h): Reset
ST: Status
00h (30h, 30h): No Error
01h (30h, 31h): Error
ETX (03h): End of Message
Check code
BCC: Block Check Code
Refer to the section 4.3 “Check code” for a BCC calculation.
(98/130)
Delimiter
CR (0Dh): End of packet
(99/130)
19. Power Save Mode
19.1 Power Save Mode Read
This command is used in order to read the Power Save Mode.
1) The controller requests the monitor to read Power Save Mode
Header Message Check code
SOH-'0'-Monitor ID-
'0'-'A'-'0'-'8'
Header
SOH (01h): Start of Header
'0' (30h): Reserved
Monitor ID: Specify the Monitor ID of which you want to change a setting.
Ex.) If Monitor ID is '1', specify 'A'.
'0' (30h): Message sender is the controller.
'A' (41h): Message type is "Command".
'0'-'8'(30h,38h): Message length (8byte)
Message
STX (02h): Start of Message
'C'-'A'-'0'-'B' (43h, 41h, 30h, 42h): Power Save Mode command
'0'-'0' (30h, 30h): Read
ETX (03h): End of Message
Check code
BCC: Block Check Code
Refer to the section 4.3 “Check code” for a BCC calculation.
Delimiter
CR (0Dh): End of packet
2) The monitor replies Power Save Mode to the controller.
Header Message Check code
SOH-'0'-'0'-Monitor ID-
'B'-'0'-'A'
STX-'C'-'A'-'0'-'B'-0'-'0'-ETX BCC CR
STX-'C'-'B'-'0'-'B'-'0'-'0'-MODE-ETX BCC CR
Delimiter
Delimiter
Header
SOH (01h): Start of Header
'0' (30h): Reserved
'0' (30h): Message receiver is the controller.
Monitor ID: Indicate a replying Monitor ID.
Ex.) When this byte is set to ‘A’, replying monitor’s ID is ‘1’.
'B' (42h): Message type is "Command reply".
'0'-'A'(30h,41h): Message length (10byte)
Message
STX (02h): Start of Message
'C'-'B'-'0'-'B' (43h, 42h, 30h, 42h): Power Save Mode Reply
'0'-'0' (30h, 30h): Read
MODE: POWER SAVE MODE
00h (30h, 30h): AUTO POWER SAVE
01h (30h, 31h): AUTO STANDBY
02h (30h, 32h): POWER SAVE OFF
ETX (03h): End of Message
Check code
BCC: Block Check Code
Refer to the section 4.3 “Check code” for a BCC calculation.
(100/130)
Loading...
