PERFORMANCE SERIES
FRONT-LOADING AUTOMATIC WASHER
USE & CARE GUIDE
LAVEUSE AUTOMATIQUE À CHARGEMENT FRONTAL
GUIDE D’UTILISATION ET D’ENTRETIEN
FOR QUESTIONS ABOUT FEATURES, OPERATION/PERFORMANCE, PARTS, ACCESSORIES OR SERVICE
VISIT OUR WEBSITE AT WWW.MAYTAG.COM
Certified to Sanitize
Certifié pour aseptiser
W10176966D
CALL: 1.800.688.9900
IN CANADA, CALL: 1.800.807.6777
IN CANADA, WWW.MAYTAG.CA
Designed to use only HE High Efficiency detergent
Conçu pour l’utilisation d’un détergent haute efficacité seulement
AU CANADA, POUR DES QUESTIONS À PROPOS DES CARACTÉRISTIQUES, DU FONCTIONNEMENT/
RENDEMENT, DES PIÈCES, DES ACCESSOIRES OU DU SERVICE, COMPOSEZ LE : 1.800.807.6777
OU VISITEZ NOTRE SITE INTERNET À
WWW.MAYTAG.CA
TABLE OF CONTENTS
WASHER SAFETY ......................................................................................................................3
INSTALLATION REQUIREMENTS.............................................................................................4
Tools and Parts.....................................................................................................................4
Options ................................................................................................................................5
Location Requirements.........................................................................................................6
Drain System........................................................................................................................8
Electrical Requirements........................................................................................................8
INSTALLATION INSTRUCTIONS .............................................................................................9
Remove Transport System ....................................................................................................9
Connect the Inlet Hoses .....................................................................................................10
Connect the Drain Hose.....................................................................................................10
Secure the Drain Hose .......................................................................................................11
Level the Washer................................................................................................................11
Complete Installation .........................................................................................................11
FEATURES AND BENEFITS......................................................................................................12
WASHER USE..........................................................................................................................13
Starting Your Washer..........................................................................................................14
Using the Proper Detergent ................................................................................................14
Using the Dispenser ...........................................................................................................15
Pausing or Restarting .........................................................................................................16
Changing Cycles, Options, and Modifiers ..........................................................................16
Status Indicator...................................................................................................................17
Cycles.................................................................................................................................17
Options ..............................................................................................................................19
Modifiers ............................................................................................................................19
LAUNDRY GUIDE ..................................................................................................................20
LAUNDRY TIPS.......................................................................................................................21
Loading ..............................................................................................................................21
WASHER CARE........................................................................................................................22
Cleaning Your Washer .......................................................................................................22
Water Inlet Hoses...............................................................................................................23
Vacation, Storage, and Moving Care ..................................................................................23
TROUBLESHOOTING.............................................................................................................24
ASSISTANCE OR SERVICE.......................................................................................................27
In the U.S.A........................................................................................................................27
In Canada...........................................................................................................................27
WARRANTY ............................................................................................................................28
TABLE DES MATIÈRES
SÉCURITÉ DE LA LAVEUSE .....................................................................................................29
EXIGENCES D'INSTALLATION...............................................................................................31
Outillage et pièces..............................................................................................................31
Options ..............................................................................................................................31
Exigences d’emplacement ..................................................................................................32
Système de vidange............................................................................................................34
Spécifications électriques ...................................................................................................34
INSTRUCTIONS D'INSTALLATION .......................................................................................35
Élimination des accessoires de transport.............................................................................35
Raccordement des tuyaux d’alimentation...........................................................................36
Raccordement du tuyau de vidange ...................................................................................36
Immobilisation du tuyau de vidange ..................................................................................37
Réglage de l'aplomb de la laveuse .....................................................................................37
Achever l’installation..........................................................................................................38
CARACTÉRISTIQUES ET AVANTAGES ...................................................................................38
UTILISATION DE LA LAVEUSE...............................................................................................39
Mise en marche de la laveuse ............................................................................................40
Utilisation du détergent approprié......................................................................................40
Utilisation du distributeur...................................................................................................41
Pause ou remise en marche................................................................................................42
Changement des programmes, options et modificateurs.....................................................42
Témoins lumineux..............................................................................................................43
Programmes .......................................................................................................................43
Options ..............................................................................................................................45
Modificateurs .....................................................................................................................45
Guide de lessivage .............................................................................................................47
CONSEILS DE LESSIVAGE.......................................................................................................48
Chargement........................................................................................................................48
ENTRETIEN DE LA LAVEUSE...................................................................................................49
Nettoyage de la laveuse .....................................................................................................49
Tuyaux d'arrivée d'eau.......................................................................................................50
Précautions à prendre avant les vacances, un entreposage ou un déménagement .............50
DÉPANNAGE ..........................................................................................................................51
ASSISTANCE OU SERVICE......................................................................................................54
Aux États-Unis....................................................................................................................54
Au Canada .........................................................................................................................55
GARANTIE...............................................................................................................................55
2
WASHER SAFETY
Your safety and the safety of others are very important.
We have provided many important safety messages in this manual and on your appliance. Always read and obey all safety
messages.
This is the safety alert symbol.
This symbol alerts you to potential hazards that can kill or hurt you and others.
All safety messages will follow the safety alert symbol and either the word “DANGER” or “WARNING.”
These words mean:
You can be killed or seriously injured if you don't immediately
DANGER
WARNING
All safety messages will tell you what the potential hazard is, tell you how to reduce the chance of injury, and tell you what can
happen if the instructions are not followed.
follow instructions.
can be killed or seriously injured if you don't
You
instructions.
follow
3
INSTALLATION REQUIREMENTS
Tools and Parts
Gather the required tools and parts before starting installation. The parts supplied are in the
washer drum.
Tools needed for connecting the water inlet hoses
Pliers (that open to 1
Flashlight (optional)
Tools needed for connecting
Locking pliers (that open to 1
4
9
/16" [39.5 mm])
the drain hose
9
/16" [39.5 mm])
Tools needed for installation
Open end wrenches 17 mm and 13 mm
Level
Wood block
Ruler or measuring tape
Parts supplied:
Options
AB
Pedestal
C
F
G
DE
A.Drain hose form
B.Inlet hose (2)
C.Inlet hose washers (4)
D.Transport bolt hole plug (4)
E.Beaded strap
F.Drain hose
G.Hose clamp
Alternate Parts
Your installation may require additional parts. If you are interested in purchasing one of the
items listed here, call the toll-free number on the cover or in the “Assistance or Service”
section.
If You Have You Will Need to Buy
Laundry tub or standpipe
aller than 96" (2.4 m)
t
Overhead sewer Standard 20 gal. (76 L), 30" (762 mm) tall drain tub or
Floor drain Siphon break, Part Number 285834; additional drain hose
Drain hose too short 4 ft (1.2 m) drain hose extension kit, Part Number 285863
Water faucets beyond reach
of fil
l hoses
Sump pump system (if not already available)
utility sink and sump pump (available from local plumbing
suppliers)
Pa
rt Number 8318155; and connector kit,
Part Number 285835
2 longer water fill hoses:
6 ft (1.8 m) Part Number 76314,
10 ft (3.0 m) Part Number 350008
A pedestal will add to the total height of the washer for a total height of 53.5" (1359 mm).
Optional pedestal
This pedestal is available in several colors.
To order, call the dealer from whom you purchased your washer or refer to the “Assistance
or Service” section.
Pedestal Height Color Part Number
10" (254 mm) White MHP1000SQ
10" (254 mm) Black
MHP1000SB
15.5" (394 mm) White XHP1550VW
15.5" (394 mm) Black
XHP1550VB
15.5" (394 mm) Slate XHP1550VE
15.5" (394 mm) Crimson Red
XHP1550VF
15.5" (394 mm) Oxide XHP1550VJ
15.5" (394 mm) Evergreen XHP1550VP
Stack Kit
Are you planning to stack your Maytag washer and dryer? To do so you will need to purchase
a Stack Kit.
To order, call the dealer from whom you purchased your dryer or refer to the “Assistance or
Service” section. Ask for Part Number 8212640.
5
Location Requirements
Selecting the proper location for your washer improves performance and minimizes noise and
possible washer “walk.”
Your washer can be installed under a custom coun
or recessed area. See “Drain System.”
Companion appliance location requirements should als
your responsibility.
You will need
A water heater set to deliver 120°F (49°C) water to the washer.
A grounded electrical outlet located within 6 ft (1.8 m) of where the power cord is
attached to the back of the washer. See “Electrical Requirements.”
Hot and cold water faucets located within 4 ft (1.2 m) of the hot and cold water fill valves,
and water pressure of 20-100 psi (137.9-689.6 kPa).
A level floor with a maximum slope of 1" (250 mm) under entire washer. Installing the
washer on soft floor surfaces, such as carpets or surfaces with foam backing, is not
recommended.
A sturdy and solid floor to support the washer with a total weight (water and load) of
400 lbs (180 kg).
Do not operate your washer in temperatures below 3
washer and can cause damage in low temperatures.
Installation clearances
The location must be large enough to allow the washer door to be fully opened.
Additional spacing should be considered for ease of installation and servicing.
Additional clearances might be required for wall, door, and floor moldings.
Additional spacing of 1" (25 mm) on all sides of the washer is recommended to reduce
noise transfer.
Companion appliance spacing should also be considered.
ter, or in a basement, laundry room, closet,
o be considered. Proper installation is
2°F (0°C). Some water can remain in the
Washer Dimensions
27"
51"
(1295 mm)
(686 mm)
31½"
(800 mm)
38"
(965 mm)
Recommended installation spacing for custom undercounter installation
The dimensions shown are for the recommended spacing.
Custom undercounter installation - Washer only
39" min.
(990 mm)
1"
(25 mm
)
27"
(686 mm)
1"
(25 mm)
6
Recommended installation spacing for recessed or closet installation, with or without a pedestal
Recommended installation spacing for recessed or closet installation, with stacked washer and dryer
The dimensions shown are for the recommended spacing.
Recessed area or closet installation
1"
(25 mm)
Recessed or closet installation - Washer on pedestal
2
*
34"
(864 mm)
31½"
(800 mm)
A
(310 cm2)
(155 cm2)
4"
(102 mm)
48 in.
24 in.
2
*
B
A. Side view - closet or confined area
B. Closet door with vents
3"
(76 mm)
3"
(76 mm)
18" min.
(457 mm)
The dimensions shown are for the recommended spacing.
48 in.2 *
2
(310 cm
)
3"* (76 mm)
3"* (76 mm)
2
24 in.
*
(155 cm2)
*Required spacing
6"* (152 mm)
76"
(1930 mm)
1"* (25 mm)
1"
(25 mm)
27"
(686 mm)
1"
(25 mm)
AB
A. Recessed area
B. Side view - closet or confined area
1"
(25 mm)
31½"
(800 mm)
4"
(102 mm)
5½"**
(140 mm)
1"
(25 mm)
27"
(686 mm)
*Required spacing
**For venting out the side, 1" (25 mm) spacing is allowed.
1"
(25 mm)
7
Recommended installation spacing for cabinet installation
The dimensions shown are for the recommended spacing.
For cabinet installation, with a door, the minimum ventilation openings in the top are
required.
7" (178 mm)
7" (178 mm)
Laundry tub drain system (view C)
The laundry tub needs a minimum 20 gal. (76 L) capacity. The top of the laundry tub must
be at least 30" (762 mm) above the floor.
Floor drain system (view D)
The floor drain system requires a siphon break that may be purchased separately. See “Tools
and Parts.”
The siphon break must be a minimum of 28" (711 mm) from the bottom of the washer.
Ad
ditional hoses might be needed.
9"
(229 mm)
4"
(102 mm)
31½"
(800 mm)
1"
(25 mm)1"(25 mm)
27"
(686 mm)
1"
(25 mm)
Drain System
The washer can be installed using the standpipe drain system (floor or wall), the laundry tub
drain system, or the floor drain system. Select the drain hose installation method you need.
See “Tools and Parts.”
Standpipe drain system - wall or floor (views A & B)
The standpipe drain requires a minimum diameter standpipe of 2" (50 mm). The minimum
carry-away capacity can be no less than 17 gal. (64 L) per minute.
The top of the standpipe must be at least 30" (762 mm) high and no higher than 96" (2.4 m)
from the bottom of the washer.
28" min.
30" min.
(762 mm)
(710 mm)
CD
Electrical Requirements
WARNING
Electrical Shock Hazard
Plug into a grounded 3 prong outlet.
Do not remove ground prong.
Do not use an adapter.
Do not use an extension cord.
Failure to follow these instructions can result in death,
re, or electrical shock.
30" min.
(762 mm)
A 120 volt, 60 Hz., AC only, 15- or 20-amp, fused electrical supply is required. Time-
delay fuse or circuit breaker is recommended. It is recommended that a separate circuit
serving only this appliance be provided.
A
B
8
This washer is equipped with a power supply cord having a 3 prong grounding plug.
To minimize possible shock hazard, the cord must be plugged into a mating, 3 prong,
grounding-type outlet, grounded in accordance with local codes and ordinances. If a
mating outlet is not available, it is the personal responsibility and obligation of the
customer to have the properly grounded outlet installed by a qualified electrician.
If codes permit and a separate ground wire is used, it is recommended that a qualified
electrician determine that the ground path is adequate.
Do not ground to a gas pipe.
Check with a qualified electrician if you are not sure the washer is properly grounded.
Do not have a fuse in the neutral or ground circuit.
INSTALLATION INSTRUCTIONS
Remove Transport System
WARNING
Excessive Weight Hazard
Use two or more people to move and install washer.
Failure to do so can result in back or other injury.
IMPORTANT: Position the washer so that the rear of the washer is within approximately
3 ft (900 mm) of its final location.
There are 4 bolts in the rear panel of the washer that support the suspension system during
ansportation. These bolts also retain the power cord inside the washer until the bolts are
tr
removed.
1. Using a 13 mm wrench, loosen each of the bolts.
2. Once t
3. Once all 4 bolts are removed, discard bolt and spacers. Then pull the power cord through
4. Close the bolt holes with the 4 transport bolt hole plugs. NOTE: If the washer is to be transported at a later date, call your local service center. To avoid
suspension and structural damage to your washer, it must be properly set up for relocation by
a certified technician.
he bolt is loose, move it to the center of the hole and completely pull out the bolt,
including the plastic spacer covering the bolt.
the opening of the rear panel and close the hole with the attached cap.
9
Connect the Inlet Hoses
1. Insert new flat washers (supplied) into each end of the inlet hoses. Firmly seat the washers
in the couplings.
2. Make sure the washer drum is empty.
ach the hose with the red color indicator to the Hot (left) inlet valve. Attaching the red
3. Att
coupling first makes it easier to tighten connection with pliers. Screw on coupling by
hand until it is seated on the washer.
ach the hose with the blue color indicator to the Cold (right) water inlet valve. Screw
4. Att
on coupling by hand until it is seated on the washer.
AB
A. Coupling
B. Washer
urn on the water faucets and check for leaks.
9. T
NOTE: Replace inlet hoses after 5 years of use to reduce the risk of hose failure.
Record hose installation or
10. Periodically inspect and replace hoses if bulges, kinks, cuts, wear, or leaks are found.
replacement dates on the hoses for future reference.
Connect the Drain Hose
Remove drain hose from washer drum
1. Use
2. Slide drain hose onto washer connection.
locking pliers, squeeze hose clamp tabs together and insert over the end of drain
hose.
H
H. Hot water inlet
C. Cold water inlet
5. Using pliers, check the tightness of the hose couplings already attached to the washer.
Do not overtighten. Damage to the coupling can result.
NOTE:
6. Attac
7. Att
8. Using pliers, tighten the couplings with an additional two-thirds turn.
h hot water hose to the hot water faucet. Screw on coupling by hand until it is seated
on the washer.
ach cold water hose to the cold water faucet. Screw on coupling by hand until it is
seated on the washer.
C
3. Once drain hose is in place, release pliers.
NOTE: Do not overtighten. Damage to the coupling can result.
10
4. W
asher drain system can be installed using a floor drain, wall standpipe, floor standpipe,
or laundry tub.
Laundry tub drain or standpipe drain
Connect the drain hose form to the corrugated drain hose.
AB
A. Snap either end of the drain hose form to the drain hose at the
point where the corrugation begins.
B. Bend drain hose over drain hose for
To keep drain water from going back into the washer:
Do not straighten the drain hose, and do not force excess drain hose into standpipe.
Hose should be secure, but loose enough to
Do not lay excess hose on the bottom of the laundry tub.
m and snap into place.
provide a gap for air.
Floor drain
You may need additional parts. See Floor drain under “Tools and Parts.”
Secure the Drain Hose
1. Drape the power cord over the washer top.
ure the drain hose to the laundry tub leg or standpipe with the beaded strap provided.
2. Sec
(See illustrations A and B.)
Level the Washer
Properly leveling your washer avoids excessive noise and vibration.
1. Check the levelness of the washer by placing a level on the top edge of the washer, first
side to side, then front to back.
If the washer is against a wall, move the washer out slightly before tipping back. If the
washer is not level, first prop the front with a wood block and adjust the feet as necessary;
then prop the back and adjust feet as necessary. Repeat this step until washer is level.
2. Make sur
perfectly level (use a level).
3. After the
against the washer cabinet.
IMPORTANT: All four feet must be tightened. If the nuts are not tight against the washer
cabinet, the washer may vibrate.
he washer should not move front to back, side to side, or diagonally when pushed on its
4. T
top edges.
5. Sli
6. Confirm
e all four feet are stable and resting on the floor. Then check that the appliance is
washer is level, use a 17 mm open-end wrench to turn the nuts on the feet tightly
de the washer to its final location.
the levelness of the washer.
Complete Installation
1. Check the electrical requirements. Be sure that you have the correct electrical supply and
the recommended grounding method. See “Electrical Requirements.”
2. Check that all parts are now installed. If there is an extra part, go back through the steps to
see which step was skipped.
3. Chec
4. Dispose of/rec
5. Check that the water faucets are on.
k that you have all of your tools.
ycle all packaging materials.
AB C
If the washer faucets and the drain standpipe are recessed (see illustration C), put the
hooked end of the drain hose in the standpipe. Tightly wrap the beaded strap around the
water inlet hoses and the drain hose.
Do not force excess drain hose into the standpipe.
11
6. Check for leaks around faucets and inlet hoses.
WARNING
Electrical Shock Hazard
Plug into a grounded 3 prong outlet.
Do not remove ground prong.
Do not use an adapter.
Do not use an extension cord.
Failure to follow these instructions can result in death,
re, or electrical shock.
7. Plug into a grounded 3 prong outlet.
8. Read “Washer Use.”
9. T
o test and clean your washer, make sure there are no clothes in the washer and add one
AFFRESH™ tablet to the washer drum. Select POWER/CANCEL, the Clean Washer cycle,
and then select START/PAUSE. This cycle will take approximately 65 minutes to
complete. Allow the washer to complete the entire Clean Washer Cycle without
interruption.
FEATURES AND BENEFITS
Electronic Controls
Flexible electronic controls are easy to use whether you are a beginner or an expert.
Smart Dispensers
The Smart Dispensers make your washer truly automatic. This washer provides a threecompartment dispenser which includes separate compartments for main wash detergent,
fabric softener, and chlorine bleach. The dispenser has large pour zones. The dispenser is
self-cleaning, and can be easily removed. Laundry produ
added to the load at the proper time in the wash cycle.
cts are diluted with fresh water and
Steam Clean
This washer has a built-in steaming unit which is combined with the Steam Clean option to
provide multiple temperatures to help remove a variety of stains from garments. Steam Clean
may be active in the Whitest Whites, Heavy Duty, and Normal/Casual cycles.
12
Clean Washer with AFFRESH™ Cycle
This cycle uses steam to raise the temperature of the unit and makes the washer self-cleaning,
flushing the machine’s interior free of dirt and other residue. The use of AFFRESH™ washer
cleaner or liquid chlorine bleach with this cycle will remove and help avoid odor-causing
residue.
Auto Water Level
This washer automatically adjusts water level for optimal cleaning and rinsing performance.
Two sensors determine load size, load composition, and suds level, then the sensors adjust
the water level to the proper setting. This eliminates guesswork. The water level is just right
for every wash load size.
Super Size Capacity
Since there is no agitator, you can wash larger, bulkier items such as a king-sized bedspread.
You are also able to wash more clothes at one time, which means fewer loads.
Smooth Balance™ Suspension System
To reduce washer “walk” and “off-balance” conditions, your new washer combines:
2 Springs to isolate vibration
4 Shock absorbers at the washer base to minimize movement
Commercial Quality Stainless Steel Drum
The commercial quality stainless steel drum eliminates corrosion and enables higher spin
speeds for more water extraction, reducing drying time compared to traditional front-load
washers.
High-Efficiency Wash System
Your new front-loading, high-efficiency washer saves time with fewer, larger loads, and lowers
your water and energy bills by helping conserve resources.
Spin Speeds
This washer automatically selects the spin speed based on the cycle selected. This factory
setting can be changed, however. This washer offers up to five different spin speed choices.
Heating Element
This washer has a heating element that automatically heats the water to the optimal
temperature on select cycles. This enables stepped cleaning, a process in which warm water
is brought in and mixed with detergent first, then the water is heated. Stepped cleaning starts
the wash cycle with warm water to help remove stains (such as blood and grass). This heater is
active in the Whitest Whites, Heavy Duty, and Normal/Casual cycles.
WASHER USE
Automatic Temperature Control
The automatic temperature control electronically senses and maintains a uniform water
temperature. Automatic temperature control regulates incoming hot and cold water.
Automatic temperature control is automatically turned on when a cycle is selected.
Add Clothes
Clothes can be added to the load during the first 8 minutes of the cycle. During this time,
the Status Indicator will indicate it is
okay to add clothes.
Special Cleaning Action with Sensi-Care™ Wash System
This washer channels 100% of the water through the dispensers to assure thorough rinse-out
and mixture of all the laundry products before they touch any garments. The water is then
sprayed from the top front onto the center of the load, providing even distribution and
optimum cleaning performance. It is normal for small amounts of water to remain in the
dispensers when the wash cycle is complete.
Efficient Detergent System
This washer has a specially designed valve that closes during the wash portion of the cycle
so that 100% of the water and detergent mixture is
System ensures that no water or detergent is wasted.
used on the load. The Efficient Detergent
Dynamic Off-Balance Detection
This washer uses two sensors to detect load size and the amount of off-balance within the
load. The suspension system and controls are specially designed to redistribute the load
automatically.
NOTE: The panel shown above may be different from that of your model.
13
Starting Your Washer
WARNING: To reduce the risk of fire, electric shock, or injury to persons, read the
IMPORTANT SAFETY INSTRUCTIONS before operating this appliance.
The following is a guide to using your washer. Please refer to
for more detailed information.
Do not store laundry products on the
operation.
top surface of this washer. Vibration is normal during
specific sections of this manual
Using the Proper Detergent
Use only High Efficiency detergents. The package for this type of detergent will be marked
“HE” or “High Efficiency.” This wash system, along with less water, will create too much
sudsing with a regular non-HE detergent. Using regular detergent will likely result in washer
errors, longer cycle times, and reduced rinsing performance. It may also result in component
failures and noticeable mold or mildew. HE detergents are made to produce the right amount
of suds for the best performance. Follow the manufacturer’s instructions to determine the
amount of detergent to use.
less detergent based on load size.
Remember, concentrated detergents such as 2x or higher will use
For All Wash Cycles
1. Open the washer door by pulling on the handle. Sort laundry according to color and type
of fabric. Place a load of sorted clothes in the washer. Do not overload washer.
Overloading can cause poor cleaning.
The washer can be fully loaded, but not tightly packed. Washer door should close easily.
Mix large and small items and avoid washing single items. Load evenly.
It is recommended that you wash small items such as infant socks in a mesh garment bag.
When unloading garments, occasionally check under the gray colored seal at the
front of the tub for small items.
2. Close the washer door by pushing it firmly until the lock clicks. The washer door will
remain locked during the wash cycle.
NOTE:
After any wash cycle is completed, the door must be opened and then closed
before a new cycle can begin. The door can be opened only if START/PAUSE or POWER/
CANCEL is selected while the Add Clothes light is illuminated or if the cycle was
canceled. See “To cancel a cycle” in Changing Cycles, Options, and Modifiers section.
3. Op
en the dispenser drawer and add laundry products to the main wash detergent,
chlorine bleach, or fabric softener compartments. Close drawer slowly to avoid spills. See
“Using the Dispenser.”
urn on the washer by selecting POWER/CANCEL. Select one of the cycles by turning the
4. T
cycle selector. The indicator light for the selected cycle will illuminate. When selecting a
wash cycle, the preset Options, Wash Temp, Spin Speed, and Soil Level for the selected
cycle will illuminate. The display shows the estimated time remaining. The preset settings
provide the recommended fabric care for the selected cycle. See “Cycles.”
5. Select
6. Select
7. If desired, select SIGNAL ON/OFF. The signal is helpful when you are washing items that
8. To begin the wash cycle immediately
the desired Options, such as Max ExtractTM, Extra Rinse, and Steam Clean. Not all
options are available with all cycles. See “Options.”
the desired Modifiers, such as Soil Level, Wash Temp, and Spin Speed. Not all
modifiers are available with all cycles and options. See “Modifiers.”
should be removed from the washer as soon as it stops.
Select START/PAUSE.
If you do not select START/PAUSE within 60 minutes of choosing a cycle, the washer
automatically shuts off.
When the wash cycle is complete, the status indicator shows Done, the door unlocks,
and the wash load can be removed from the washer. The washer powers down
automatically 5 minutes after the cycle is complete and the Done light goes off. To
power down the washer manually after the wash cycle is complete, select POWER/
CANCEL once.
Use only HE High Efficiency detergent.
First Wash Cycle Without Laundry
Before washing clothes for the first time, if not completed during the final installation step,
choose the Normal/Casual cycle and run it without clothes. Use only HE High Efficiency
detergent. Use 1/2 the manufacturer’s recommended amount for a medium-size load. This
initial cycle serves to ensure the interior is clean before washing clothes.
14
Using the Dispenser
Your new washer has a dispenser drawer with three separate compartments for your laundry
products—one is for detergent, one is for liquid chlorine bleach, and one is for liquid fabric
softener. Laundry products are diluted and dispensed automatically at the proper time during
the wash cycle, making it unnecessary for you to return to the washer during the cycle to add
them.
It is normal for small amounts of water to remai
is complete.
Do not put laundry products directly into the w
when adding laundry products.
Choosing the Right Detergent
Use only High Efficiency detergents. The package for this type of detergent will be marked
“HE” or “High Efficiency.” This wash system, along with less water, will create too much
sudsing with a regular non-HE detergent. Using regular detergent will likely result in washer
errors, longer cycle times, and reduced rinsing performance. It may also result in component
failures and noticeable mold or mildew. HE detergents are made to produce the right amount
of suds for the best performance. Follow the manufacturer’s instructions to determine the
amount of detergent to use.
less detergent based on load size.
To fill dispenser compartments
1. Pull out the dispenser drawer.
2. Add
the desired laundry product to the proper compartment.
Remember, concentrated detergents such as 2x or higher will use
Use only HE High Efficiency detergent.
n in the dispensers when the wash cycle
ash tub. Always use the proper dispensers
3. Push i
n the dispenser drawer slowly and completely (to avoid a spill).
C
D
A
B
Dispenser
A. Detergent type selector
B. Main wash compartment
C. Dispenser release lever
Chlorine bleach compartment
D.
E.Fabric softener compartment
E
Main wash compartment
(Letter B in Dispenser Illustration)
Add liquid or powdered HE detergent to this com
type selector (A) must always be in the correct position for the detergent type used. Slide the
detergent type selector to the correct position.
IMPORTANT:
Liquid or powdered color-safe bleach may be added to the Main Wash compartment
along with the same type of liquid or powdered detergent.
Use the detergent and color-safe bleach manufacturer’s recommended amount for
load size.
If you are using the Delay Wash option, powdered laundry products should be used
in the main wash compartment because liquid products may seep out of the
compartment before the main wash begins.
partment for your wash cycle. The detergent
15
Liquid detergent:
A
LIQUI
SO
Do not overfill. The dispenser holds
The fabric softener is dispensed in the rinse cycle. If Extra Rinse is selected,
the fabric softener will be dispensed during the Extra Rinse.
Do not use fabric softener dispensing balls in this washer. Dispensing balls will not
operate correctly with this washer.
Do not spill or drip any fabric softener onto the clothes.
At the end of the cycle, a small amount of water may be left in the dispenser.
This is normal.
1
/4 cup (60 mL).
B
Selector in position for liquid detergent
A. Detergent type selector
B. Main wash compartment
Powdered detergent:
A
LIQUI
SO
B
Selector in position for powdered detergent
A. Detergent type selector
B. Main wash compartment
Chlorine bleach compartment
(Letter D in Dispenser Illustration)
2
Add no more than
will be automatically diluted and dispensed at the best time during the first rinse after the
wash cycle. This compartment cannot dilute powdered bleach.
Always measure liquid chlorine bleach. Use a measuring cup with a pour spout; do not
guess. Follow the manufacturer’s directions for proper use.
Do not fill beyond the “MAX” level. Overfilling could cause garment damage.
Fabric softener compartment
(Letter E in Dispenser Illustration)
Pour measured liquid fabric softener into the
NOTES:
Pour only liquid fabric softener into the dispenser.
/3 cup (160 mL) liquid chlorine bleach to this compartment. The bleach
fabric softener dispenser, if desired.
Pausing or Restarting
1. To pause the washer at any time, select START/PAUSE.
2. To continue the cycle, select START/PAUSE (for approximately 1 second).
Changing Cycles, Options, and Modifiers
Not all Options and Modifiers are available with all cycles. Cycles, Options, and Modifiers
can be changed anytime before START/PAUSE is selected.
Options and Modifiers can be changed anytime after ST
start of the selected Option or Modifier.
To cancel a cycle and begin a new cycle
1. Select PO
2. Select desired c
3. Select the desired OPTIONS.
4. Select
of the new cycle.
To cancel a cycle
1. Select PO
2. The washer powers down, the door unlocks, and clothes can be removed. NOTE: If
before the door unlocks.
To change Options or Modifiers
1. Select ST
2. Select the
3. Select
To drain the washer manually
1. Select START/PAUSE once.
2. Select DRAIN/SPIN.
3. Select
4. Wh
WER/CANCEL twice.
ycle.
START/PAUSE (for approximately 1 second) to restart the washer at the beginning
WER/CANCEL once.
the water level or the temperature is too high, the washer will drain automatically
after the cycle has started
ART/PAUSE once.
desired OPTIONS or MODIFIERS.
START/PAUSE (for approximately 1 second) to continue the cycle.
START/PAUSE (for approximately 1 second) to begin the drain.
en the spin is complete, the door unlocks. Items can be removed from the washer.
ART/PAUSE is selected and before the
16
Status Indicator
This indicator shows which portion of the cycle the washer is operating and the estimated
time remaining. It also indicates when you can add an additional item to the wash cycle and
when the controls are locked.
Adding items
This washer allows an 8-minute period in which other garments may be added to the load.
You can add items to the washer if the status indicator shows Add Clothes.
To add items
1. Select ST
o continue the cycle, close the door and select START/PAUSE (for approximately
2. T
1 second).
3. T
o unlock the door after the Add Clothes period, press POWER/CANCEL twice.
This will cancel the Wash Cycle.
Cycle done
The cycle done indicator stays on for 60 minutes, until the door of the washer is opened,
or the Power/Cancel b
Sanitize
Cycles certified by NSF International, an independent, third party testing and certification
organization are those with the sanitize temperature selection available. The certification
verified that these cycles reduce 99.9% of bacteria typically found on clothing, bedding,
and towels. There is no carryover of bacteria between loads afte
cycles with sanitize wash temperature selected have been designed to meet the requirements
of NSF Protocol P172 for Sanitizing Efficacy.
ART/PAUSE once. The washer door unlocks, and items can be added.
utton is pressed.
r the cycle is complete. Only
To lock the controls
Select and hold CONTROL LOCK button for 3 seconds.
The CONTROL LOCK status light illuminates.
To unlock the controls
Select and hold CONTROL LOCK for 3 seconds until the Control Lock status light turns off.
Door Locked
When the status light illuminates, the door is locked.
Estimated time remaining
The cycle time varies automatically based on your water pressure, water temperature,
detergent, and clothes load. The cycle time will be extended if oversudsing occurs or the load
is unbalanced. The SUDs routine removes extra suds and assures proper rinsing of your
clothes. During the unbalance routine, the time displayed may pause until this activity is
complete, then resume with the cycle. These routines may add up to a half-hour to the default
cycle time.
Cycles
Cycles can be selected by turning the Cycle control knob to the desired cycle. Each cycle
is designed for different types
of fabric and soil levels.
Certified to Sanitize
Locking controls
The Control Lock avoids unintended use of the washer. You can also use the control lock
feature to avoid unintended cycle or option changes during a cycle. When Control Lock light
is lit during a cycle, all buttons are disabled except for the Control Lock, Power/Cancel, and
Start/Pause buttons.
Each cycle has a preset Soil Level (cycle time), Water Temperature, and Spin Speed, and
may have preset options. The preset settings provide the recommended fabric care for the
selected cycle.
The preset settings can be changed anytime before START is pressed. Not all options and
modifiers are available with all cycles. (To change settings after the cycle has started, press
PAUSE once, then select the desired settings. Press START again to continue the cycle.)
Whitest Whites
This cycle is especially designed for cleaning loads of soiled white fabrics with the addition of
bleach. Hot washing temperatures assure optimal bleach activity. An additional rinse provides
optimal rinse performance to avoid chlorine residues on your laundry. This cycle combines
high-speed tumbling, longer wash time, and fast-speed spin to shorten drying time.
17
Loading...
