NEC plasma display
External Control Manual
(for PX-42VP5/42XM5/42XM3/50XM4/61XM3)
e.g., Pers
onal computer
Application
These specifications are applicable to NEC plasma monitors and
communications control from external equipment.
"Please also support the command of VP series and refer to the manual of the
conventional model about specification."
Connections
Connections should be made as described below.
1) Connector on the plasma monitor side: EXTERNAL CONTROL connector.
plasma monitor
Type of connector: D-Sub 9-pin male
No. Pin Name
1 No Connection
2 RXD (Receive data)
3 TXD (Transmit data)
4 DTR (DTE side ready)
5 GND
6 DSR (DCE side ready)
7 RTS (Ready to send)
8 CTS (Clear to send)
9 No Connection
External equipment
2
2) Connector on the external equipment side: Serial port (RS-232C) connector.
See the specifications of the equipment that is to be connected for the type of
connector and the pin assignment.
3) Wiring
Use a crossed (reverse) cable.
Wire the cable so that each pair of data lines cross between the two devices.
These data line pairs are RXD (Receive data) and TXD (Transmit data), DTR
(DTE side ready) and DSR (DCE side ready), and RTS (Ready to send) and CTS
(Clear to send).
Communication Parameters
(1) Communication system Asynchronous
(2) Interface RS-232C
(3) Baud rate 9600 bps
(4) Data length 8 bits
(5) Parity Odd
(6) Stop bit 1 bit
(7) Communication code Hex
3
8bit 8bit 8bit 8bit 8bit 8bit 8bit 8bit
Communication Format
Command 1
Unit ID 1
Unit ID 2
Command 2
Data length
Data
Check sum
Command1
Command 1, along with command 2, is a number used to distinguish each
command.
When making it operate using ID, bit1 and bit0 are set up as follows.
Bit1,Bit0 Unit ID distinction bit
11B :Usually, a form (with no ID)
10B :Usually, a form (with no ID)
01B :Set ID
00B :Video wall ID
In the case of ACK, when the lower order 4 bits is FH (as in 3FH and
7FH), this indicates that the commands and data of the supported
equipment have been received. When the lower order 4 bits is BH (as in
3BH and 7BH), this indicates that unsupported commands and data
have been received.
Unit ID1,2 (UA1,UA2)
Unit ID 1 and unit ID 2 are numbers used to identify the equipment
that is to be connected.
60H is used for the plasma monitor and 80H is used for external control
equipment such as a personal computer.
4
1) Unit ID 1: Indicates the equipment sending the signal. When
supporting Set ID by the command 1, 4 bits of low ranks of Set ID are
set up.
2) Unit ID 2: Indicates the equipment receiving the signal. When
supporting Set ID by the command 1, 4 bits of higher ranks of Set ID
are set up.
* Set ID : it is the apparatus number assigned to each plasma monitor.
5
Total 208H
Command 2
Command 2, along with command 1, is a number used to distinguish each
command.
Check Sum (CKS), Error Processing, and ACK
1) The check sum described below and RS-232C odd parity are used together for
a check of the received data. The check sum is the lower order 8 bits of one
frame of sent or received data comprising the sum total of Command 1, Unit
ID 1 and 2, Command 2, Data Length, and Data.
Check Sum Example
DFH 80H 60H 47H 01H 01H 08H
Command1 Unit ID1 Unit ID2 Command2 Data Length Data Check Sum
2) Error Processing
• When the communication interval is vacant for more than 4 ms, thereafter a
received Command 1 will be recognized. If, at this time, meaningful data
cannot be recognized, that data will not be recognized (as valid data).
• An ACK will not be returned unless the receive data error, the check sum
error, and the receive data are all taken in.
6
The control method of the set by Set ID
When controlling two or more sets of plasma monitors, if the command
using Set ID is used, it will become controllable individually.
The example of the POWER ON command to the plasma monitor which set
ID as "5" is shown below.
It is not based on ID but is the POWER ON command to all sets.
9F 80 60 4E 00 CD
In ID= "5", the value of ID-1=4 is set up.
9D 84 60 4E 00 CF
The example of a change in the single mode of a 4th page multi-system configuration and
the multi-mode is shown below.
ID of the set used as a master(etc PC) is set to 50, and it assumes that ID is shaken by
AUTO ID to each set. ID shaken at each set is as follows.
Upper left set (master) ID = 50 = 32h
Upper right set ID = 51 = 33h
Lower right set ID = 52 = 34h
Lower left set ID = 53 = 35h
Transmission Data
DD 81 63 03 03 03 01 00 CB
DD 82 63 03 03 03 02 00 CD
DD 83 63 03 03 03 03 00 CF
DD 84 63 03 03 03 04 00 D1
Transmission of the above command performs a 4th page multi SPLIT display.
Moreover, the following commands are published in order to change a 4th page
multi-display into a single mode display.
DF 80 60 03 03 01 01 00 C7
All sets become a single mode display by the above-mentioned command.
Since this command does not specify Set ID, all sets execute it.
*:Control by ID may not be able to be performed depending on connection with
external control apparatus.
7
Command Reference List
CMD1 CMD2 LEN
01 Power ON 9FH 4EH 00H
02 Power OFF 9FH 4FH 00H
03 Input Switch Change DFH 47H 01H
04 VOLUME Gain Data DFH 7FH 03H
05 AUDIO Mute ON 9FH 3EH 00H
06 AUDIO Mute OFF 9FH 3FH 00H
07 CONTRAST Gain Data DFH 7FH 03H
08 BRIGHT Gain Data DFH 7FH 03H
09 SHARPNESS Gain Data DFH 7FH 03H
10 Color Gain Data DFH 7FH 03H
11 TINT Gain Data DFH 7FH 03H
12 PICTURE MODE Select DFH 0AH 01H
13 COLOR TEMP SELECT DFH 00H 01H
14 RED Gain Data DFH 7FH 04H
15 GREEN Gain Data DFH 7FH 04H
16 BLUE Gain Data DFH 7FH 04H
17 NR MODE Set DFH C0H 01H
18 BASS Gain Data DFH 7FH 03H
19 TREBLE Gain Data DFH 7FH 03H
20 BALANCE Gain Data DFH 7FH 03H
21 SCREEN MODE Select DFH 51H 01H
22 V.POSITION Gain Data DFH 7FH 03H
23 H.POSITION Gain Data DFH 7FH 03H
24 V-HEIGHT Gain Data DFH 7FH 03H
25 H-WIDTH Gain Data DFH 7FH 03H
26 AUTO PICTURE Select DFH 7FH 03H
27 PHASE Gain Data DFH 7FH 03H
28 CLOCK Gain Data DFH 7FH 03H
29 OSM Select DFH 58H 01H
30 OSM ADJ. Gain Data DFH 1AH 02H
31 POWER MGT Select DFH 1AH 02H
32 GRAY LEVEL Set DFH C6H 01H
33 CINEMA MODE Set DFH C1H 01H
34 LONG LIFE Set DFH 6BH 03H
35 INVESE Set DFH C7H 03H
36 SCREEN WIPER Set DFH C8H 04H
37 RESET 1FH 54H 00H
38 Audio Select Set DFH 70H 02H
39 BNC INPUT DFH 8CH 01H
40 RGB Select DFH 8BH 01H
41 HD Select DFH 8AH 01H
42 LANGUAGE Select DFH 5BH 01H
8
43 COLOR SYSTEM Select DFH 5CH 01H
44 FREQUENCY Request 1FH 26H 00H
45 Input MODE Request 1FH 41H 00H
46 VIDEO ADJ Request 1FH 45H 00H
47 Audio Select Request 1FH 6FH 00H
48 Failure Mode Request 1FH 3FH 00H
49 MODEL NAME Request 1FH 17H 00H
50 D-SUB INPUT DFH 8DH 01H
51 TIMER SWITCH DFH 02H 01H
52 LOW TONE DFH 0CH 01H
53 COLOR TUNE DFH 0DH 08H
54 TIMER PROGRAM SETTING DFH 30H 08H
55 PRESENT TIME SETTING DFH 31H 03H
56 MULTI MODE Select DFH 03H 03H
57 MULTI MODE Request 1FH 3BH 00H
58 AUTO ID SET START 5FH F0H 01H
59 PLE LINK DFH F1H 03H
60 VIDEO WALL SETTING DFH F3H 02H
61 POWER DELAY ON
(DIVIDER setting : 1/4/9)
62 POWER DELAY ON
(DIVIDER setting : 16/25)
63 GAMMA Gain Data DFH 13H 04H
64 Running Sense 1FH 88H 00H
65 ORBITTER SET DFH 1EH 04H
66 OSM OBITER DFH 5FH 01H
67 OSM ANGLE DFH 60H 01H
68 Input Skip 5FH 61H 01H
1
69*
PICTURE Size DFH 2AH 01H
70 OPTION Select DFH 63H 04H
71 REPEAT Timer DFH 64H 06H
72 SERIAL No. Request 1FH 15H 00H
73 S1/S2 SELECT DFH 89H 01H
74 SOFT FOCUS DFH 65H 01H
75 PLUG and PLAY DFH 8EH 01H
76 DIGITAL SIGNAL
LEVEL SELECT
1
77*
MULTI(SPRIT) SCREEN
Select
1
78*
SUB.P DETECT DFH 7AH 01H
1
79*
ZOOM NAV DFH 7BH 01H
1
80*
PIC FREEZE DFH 7CH 01H
1
81*
PAUSE COMMAND DFH 7DH 01H
1
82*
SEAMLESS SW DFH 7EH 03H
1
83*
MULTI(SPRIT) SCREEN
PROGRAM TIMER
DFH F2H 01H
DFH F6H 01H
DFH 8FH 01H
DFH 07H 01H
DFH 32H 0AH
9
1
84*
MULTI(SPRIT) SCREEN
POWER ON MODE
1
85*
MULTI(SPRIT) SCREEN
REPEAT TIMER
86 OSM CONTRAST DFH 37H 01H
2
87*
CLOSECAPTION
(Closed Caption)
2
88*
CAPTION CONT DFH 3DH 01H
*1:This function is only 50 or 61 inch model
*2:This function is only A version
DFH 33H 04H
DFH 34H 09H
DFH 3CH 01H
10
01. Power ON
Function
The external control equipment switches on the power of the plasma monitor.
Transmission Data
9FH 80H 60H 4EH 00H CKS
ACK
The plasma monitor returns the following ACK when the power is switched
on.
3FH 60H 80H 4EH 00H CKS
NOTE: Do not set the Power ON or Power OFF command continuously.
02. Power OFF
Function
The external control equipment switches off the power of the plasma monitor.
Transmission Data
9FH 80H 60H 4FH 00H CKS
ACK
The plasma monitor returns the following ACK when the power is switched
off.
3FH 60H 80H 4FH 00H CKS
NOTE: Do not set the Power ON or Power OFF command continuously.
11
03. Input Switch Change
Function
The external control equipment switches the input of the plasma monitor.
Transmission Data
DFH 80H 60H 47H 01H DATA00 CKS
DATA00 : Input Select 01H : Video1
02H : Video2
03H : Video3
05H : HD (HD1 or DTV or DTV1)
06H : HD2(DTV2 or SCART1/SCART2)
07H : RGB1 / PC1
08H : RGB2 / PC2
0CH : RGB3 / PC3
0DH : HD3(SCART3)
ACK
The plasma monitor returns the following ACK when the input is switched.
3FH 60H 80H 47H 00H CKS
12
04. VOLUME Gain Data
Function
The external control equipment changes the VOLUME gain data of the plasma
monitor.
Transmission Data
DFH 80H 60H 7FH 03H DATA00 DATA01 DATA02 CKS
DATA00: USER SOUND Gain Flag 05H
DATA01: VOLUME Gain Flag 01H
DATA02: VOLUME Gain 00H: Step0
:
0AH: Step10 (Default)
:
2AH: Step42
ACK
7FH 60H 80H 7FH 02H DATA00 DATA01 CKS
DATA00: USER SOUND Gain Flag 05H
DATA01: VOLUME Gain Flag 01H
05. AUDIO Mute ON
Function
The external control equipment switches on AUDIO Mute of the plasma
monitor.
Transmission Data
9FH 80H 60H 3EH 00H CKS
ACK
3FH 60H 80H 3EH 00H CKS
06. AUDIO Mute OFF
Function
The external control equipment switches off AUDIO Mute of the plasma
monitor.
Transmission Data
9FH 80H 60H 3FH 00H CKS
ACK
3FH 60H 80H 3FH 00H CKS
13
07. CONTRAST Gain Data
Function
The external control equipment changes the CONTRAST gain data of the
plasma c
Transmission Data
DFH 80H 60H 7FH 03H DATA00 DATA01 DATA02 CKS
DATA00 : USER PICTURE Gain Flag 01H
DATA01 : CONTRAST Gain Flag 07H
DATA02 : CONTRAST Gain CCH : -52
:
FFH : -01
00H : 0
01H : +01
:
14H : +20
ACK
7FH 60H 80H 7FH 02H DATA00 DATA01 CKS
DATA00: USER PICTURE Gain Flag 01H
DATA01: CONTRAST Gain Flag 07H
08. BRIGHT Gain Data
Function
The external control equipment changes the BRIGHT gain data of the plasma
monitor.
Transmission Data
DFH 80H 60H 7FH 03H DATA00 DATA01 DATA02 CKS
DATA00 : USER PICTURE Gain Flag 01H
DATA01 : BRIGHT Gain Flag 08H
DATA02 : BRIGHT Gain E0H : -32
:
FFH : -01
00H : 0
01H : +01
:
20H : +32
ACK
7FH 60H 80H 7FH 02H DATA00 DATA01 CKS
14
DATA00 : USER PICTURE Gain Flag 01H
DATA01 : BRIGHT Gain Flag 08H
09. SHARPNESS Gain Data
Function
The external control equipment changes the SHARPNESS gain data of the
plasma monitor.
Transmission Data
DFH 80H 60H 7FH 03H DATA00 DATA01 DATA02 CKS
DATA00 : USER PICTURE Gain Flag 01H
DATA01 : SHARPNESS Gain Flag 06H
DATA02 : SHARPNESS Gain F0H : -16
:
FFH : -01
00H : 0
01H : +01
:
10H : +16
Only when a RGB signal is connected
DATA02 : SHARPNESS Gain 01H : 1
02H : 2
03H : 3
04H : 4
ACK
7FH 60H 80H 7FH 02H DATA00 DATA01 CKS
DATA00 : USER PICTURE Gain Flag 01H
DATA01 : SHARPNESS Gain Flag 06H
15
10. COLOR Gain Data
Function
The external control equipment changes the COLOR gain data of the plasma
monitor.
Transmission Data
DFH 80H 60H 7FH 03H DATA00 DATA01 DATA02 CKS
DATA00 : USER PICTURE Gain Flag 01H
DATA01 : COLOR Gain Flag 04H
DATA02 : COLOR Gain E0H : -32
:
FFH : -01
00H : 0
01H : +01
:
20H : +32
* COLOR Gain is from -22 (EAH) to +22 (16H) only during video.
ACK
7FH 60H 80H 7FH 02H DATA00 DATA01 CKS
DATA00 : USER PICTURE Gain Flag 01H
DATA01 : COLOR Gain Flag 04H
11. TINT Gain Data
Function
The external control equipment changes the TINT gain data of the plasma
monitor.
Transmission Data
DFH 80H 60H 7FH 03H DATA00 DATA01 DATA02 CKS
DATA00 : USER PICTURE Gain Flag 01H
DATA01 : TINT Gain Flag 05H
DATA02 : TINT Gain E0H: -32
:
* TINT Gain is from -22 (EAH) to FFH : -01
+22 (16H) only during video. 00H : 0
01H : +01
:
20H : +32
16
ACK
7FH 60H 80H 7FH 02H DATA00 DATA01 CKS
DATA00 : USER PICTURE Gain Flag 01H
DATA01 : TINT Gain Flag 05H
12. PICTURE MODE Select
Function
The external control equipment sets the picture mode of the plasma monitor.
Transmission Data
DFH 80H 60H 0AH 01H DATA00 CKS
DATA00: 01H : NORMAL
02H : THEATER1(It cannot choose in the still picture input of a
personal computer.)
03H : THEATER2(It cannot choose in the still picture input of a
personal computer.)
04H : Default
05H : Bright
ACK
7FH 60H 80H 0AH 01H DATA00 CKS
DATA00: 01H : NORMAL
02H : THEATER1
03H : THEATER2
04H : Default
05H : Bright
13. COLOR TEMP SELECT
Function
The external control equipment changes the COLOR TEMP of the plasma
monitor.
Transmission Data
DFH 80H 60H 00H 01H DATA00 CKS
DATA00 : 00H: low
01H: middle
02H: high
03H: middle low
17
ACK
7FH 60H 80H 00H 01H DATA00 CKS
DATA00 : 00H: low
01H: middle
02H: high
03H: middle low
14. RED Gain Data
Function
The external control equipment changes the RED Gain Data of the plasma
monitor.
Transmission Data
DFH 80H 60H 7FH 04H DATA00 to DATA03 CKS
DATA00 : USER PICTURE Gain Flag 01H
DATA01 : RED Gain Flag 01H
DATA02 : RED Gain1(Bias) D8H : -40
:
FFH : -01
00H : 0
01H : +01
:
1EH : +30
DATA03: RED Gain2(Drive) D8H : -40
:
FFH : -01
00H : 0
01H : +01
:
1EH : +30
ACK
7FH 60H 80H 7FH 02H DATA00 DATA01 CKS
DATA00 : USER PICTURE Gain Flag 01H
DATA01 : RED Gain Flag 01H
18
15. GREEN Gain Data
Function
The external control equipment changes the GREEN Gain Data of the plasma
monitor.
Transmission Data
DFH 80H 60H 7FH 04H DATA00 to DATA03 CKS
DATA00 : USER PICTURE Gain Flag 01H
DATA01 : GREEN Gain Flag 02H
DATA02 : GREEN Gain1(Bias) D8H : -40
:
FFH : -01
00H : 0
01H : +01
:
1EH : +30
DATA03: GREEN Gain2(Drive) D8H : -40
:
FFH : -01
00H : 0
01H : +01
:
1EH : +30
ACK
7FH 60H 80H 7FH 02H DATA00 DATA01 CKS
DATA00: USER PICTURE Gain Flag 01H
DATA01: GREEN Gain Flag 02H
19
16. BLUE Gain Data
Function
The external control equipment changes the BLUE Gain Data of the plasma
monitor.
Transmission Data
DFH 80H 60H 7FH 04H DATA00 to DATA03 CKS
DATA00 : USER PICTURE Gain Flag 01H
DATA01 : BLUE Gain Flag 03H
DATA02 : BLUE Gain1(Bias) D8H :-40
:
FFH : -01
00H : 0
01H : +01
:
1EH : +30
DATA03: BLUE Gain2(Drive) D8H :-40
:
FFH : -01
00H : 0
01H : +01
:
1EH : +30
ACK
7FH 60H 80H 7FH 02H DATA00 DATA01 CKS
DATA00: USER PICTURE Gain Flag 01H
DATA01: BLUE Gain Flag 03H
20
17. NR MODE Set
Function
The external control equipment sets the NR (Noise Reduction) mode of the
plasma monitor.
Transmission Data
DFH 80H 60H C0H 01H DATA00 CKS
DATA00: 01H : NR OFF
02H : NR-1
03H : NR-2
04H : NR-3
ACK
7FH 60H 80H C0H 01H DATA00 CKS
DATA00: 01H : NR OFF
02H : NR-1
03H : NR-2
04H : NR-3
18. BASS Gain Data
Function
The external control equipment changes the BASS gain data of the plasma
monitor.
Transmission Data
DFH 80H 60H 7FH 03H DATA00 DATA01 DATA02 CKS
DATA00 : USER PICTURE Gain Flag 05H
DATA01 : BASS Gain Flag 03H
DATA02 : BASS Gain F3H : -13
:
FFH : -01
00H : 0
01H : +01
:
0DH : +13
ACK
7FH 60H 80H 7FH 02H DATA00 DATA01 CKS
DATA00 : USER PICTURE Gain Flag 05H
DATA01 : BASS Gain Flag 03H
21
19. TREBLE Gain Data
Function
The external control equipment changes the TREBLE gain data of the plasma
monitor.
Transmission Data
DFH 80H 60H 7FH 03H DATA00 DATA01 DATA02 CKS
DATA00 : USER PICTURE Gain Flag 05H
DATA01 : TREBLE Gain Flag 04H
DATA02 : TREBLE Gain F3H : -13
:
FFH : -01
00H : 0
01H : +01
:
0DH : +13
ACK
7FH 60H 80H 7FH 02H DATA00 DATA01 CKS
DATA00: USER PICTURE Gain Flag 05H
DATA01: TREBLE Gain Flag 04H
20. BALANCE Gain Data
Function
The external control equipment changes the BALANCE gain data of the plasma
monitor.
Transmission Data
DFH 80H 60H 7FH 03H DATA00 DATA01 DATA02 CKS
DATA00 : USER PICTURE Gain Flag 05H
DATA01 : BALANCE Gain Flag 02H
DATA02 : BALANCE Gain EAH : -22
:
FFH : -01
00H : 0
01H : +01
:
16H : +22
ACK
7FH 60H 80H 7FH 02H DATA00 DATA01 CKS
DATA00: USER PICTURE Gain Flag 05H
22
DATA01: BALANCE Gain Flag 02H
21.SCREEN MODE Select
Function
The external control equipment switches the screen mode of the plasma
monitor.
Transmission Data
DFH 80H 60H 51H 01H DATA00 CKS
DATA00 02H : STADIUM
03H : ZOOM
04H : NORMAL
05H : FULL
06H : REAL
08H : UNDERSCAN
09H : 14:9
0AH : 2.35:1
ACK
7FH 60H 80H 51H 01H DATA00 CKS
DATA00 02H : STADIUM
03H : ZOOM
04H : NORMAL
05H : FULL
06H : REAL
08H : UNDERSCAN
09H : 14:9
0AH : 2.35:1
23
22. V.POSITION Gain Data
Function
The external control equipment changes the V. POSITION gain data of the
plasma monitor.
Transmission Data
DFH 80H 60H 7FH 03H DATA00 DATA01 DATA02 CKS
DATA00 : USER PICTURE Gain Flag 03H
DATA01 : V.POSITION Gain Flag 01H
DATA02 : V.POSITION Gain C0H : -64
:
FFH : -01
00H : 0
01H : +01
:
40H : +64
ACK
7FH 60H 80H 7FH 02H DATA00 DATA01 CKS
DATA00: USER PICTURE Gain Flag 03H
DATA01: V.POSITION Gain Flag 01H
24
23. H.POSITION Gain Data
Function
The external control equipment changes the H. POSITION gain data of the
plasma monitor.
Transmission Data
DFH 80H 60H 7FH 03H DATA00 DATA01 DATA02 CKS
DATA00 : USER PICTURE Gain Flag 03H
DATA01 : H.POSITION Gain Flag 02H
DATA02 : H.POSITION Gain 80H : -128
:
FFH : -01
00H : 0
01H : +01
:
7FH : +127
ACK
7FH 60H 80H 7FH 02H DATA00 DATA01 CKS
DATA00: USER PICTURE Gain Flag 03H
DATA01: H.POSITION Gain Flag 02H
24. V-HEIGHT Gain Data
Function
The external control equipment changes the V-HEIGHT gain data of the plasma
monitor.
Transmission Data
DFH 80H 60H 7FH 03H DATA00 DATA01 DATA02 CKS
DATA00 : USER PICTURE Gain Flag 03H
DATA01 : V-HEIGHT Gain Flag 07H
DATA02 : V-HEIGHT Gain 00H : 0
:
40H : +64
ACK
7FH 60H 80H 7FH 02H DATA00 DATA01 CKS
DATA00: USER PICTURE Gain Flag 03H
DATA01: V-HEIGHT Gain Flag 07H
25
25. H-WIDTH Gain Data
Function
The external control equipment changes the H-WIDTH gain data of the plasma
monitor.
Transmission Data
DFH 80H 60H 7FH 03H DATA00 DATA01 DATA02 CKS
DATA00 : USER PICTURE Gain Flag 03H
DATA01 : H-WIDTH Gain Flag 08H
DATA02 : H-WIDTH Gain 00H : 0
:
40H : +64
ACK
7FH 60H 80H 7FH 02H DATA00 DATA01 CKS
DATA00: USER PICTURE Gain Flag 03H
DATA01: H-WIDTH Gain Flag 08H
26. AUTO PICTURE Select
Function
The external control equipment switches on or off the AUTO PICTURE of the
plasma monitor.
Transmission Data
DFH 80H 60H 7FH 03H DATA00 DATA01 DATA02 CKS
DATA00 : USER PICTURE Gain Flag 03H
DATA01 : AUTO PICTURE Select Flag 09H
DATA02 00H : ON
01H : OFF
ACK
7FH 60H 80H 7FH 03H DATA00 DATA01 DATA02 CKS
DATA00 : USER PICTURE Gain Flag 03H
DATA01 : AUTO PICTURE Select Flag 09H
DATA02 00H : ON
01H : OFF
26
27. PHASE Gain Data
Function
The external control equipment changes the PHASE gain data (Phase) of the
plasma monitor.
Transmission Data
DFH 80H 60H 7FH 03H DATA00 DATA01 DATA02 CKS
DATA00 : USER PICTURE Gain Flag 03H
DATA01 : PHASE Gain Flag 03H
DATA02 : PHASE Gain 00H : 0
:
40H : +64
ACK
7FH 60H 80H 7FH 02H DATA00 DATA01 CKS
DATA00: USER PICTURE Gain Flag 03H
DATA01: PHASE Gain Flag 03H
28. CLOCK Gain Data
Function
The external control equipment changes the CLOCK gain data (ratio of
frequency division) of the plasma monitor.
Transmission Data
DFH 80H 60H 7FH 03H DATA00 DATA01 DATA02 CKS
DATA00 : USER PICTURE Gain Flag 03H
DATA01 : CLOCK Gain Flag 04H
DATA02 : CLOCK Gain C0H : -64
:
FFH : -01
00H : 0
01H : +01
:
40H : +64
ACK
7FH 60H 80H 7FH 02H DATA00 DATA01 CKS
DATA00: USER PICTURE Gain Flag 03H
DATA01: CLOCK Gain Flag 04H
27
29. OSM Select
Function
The external control equipment switches on or off the on-screen menu (OSM) of
the plasma monitor.
Transmission Data
DFH 80H 60H 58H 01H DATA00 CKS
DATA00: 01H: On-Screen menu On
02H: On-Screen menu Off
ACK
7FH 60H 80H 58H 01H DATA00 CKS
DATA00: 01H: On-Screen menu On
02H: On-Screen menu Off
*Operation is as described in the table below.
Operation
Remote
control
operation
Personal
computer
control
operation
Display of items and adjustments
on the menu
When screen
menu is ON
Yes Yes Yes No
No No Yes No
On-Screen Menu (OSM)
When screen
menu is OFF
Volume display, input display, and
screen size display
When screen
menu is ON
When screen
menu is OFF
30. OSM ADJ. Gain Data
Function
The external control equipment sets the position of the OSM menu of the
plasma monitor.
Transmission Data
DFH 80H 60H 1AH 02H DATA00 DATA01 CKS
DATA00 : OSM ADJ. Gain Flag 02H
DATA01 01H : 1
:
06H : 6
ACK
7FH 60H 80H 1AH 01H DATA00 CKS
DATA00 : OSM ADJ. Gain Flag 02H
28
31. POWER MGT Select
Function
The external control equipment switches on or off the POWER MANAGEMENT
of the plasma monitor.
Transmission Data
DFH 80H 60H 1AH 02H DATA00 DATA01 CKS
DATA00 : POWER MGT Select 03H
DATA01 01H : ON
02H : OFF
ACK
7FH 60H 80H 1AH 02H DATA00 DATA01 CKS
DATA00 : POWER MGT Select 03H
DATA01 01H : ON
02H : OFF
32. GRAY LEVEL Set
Function
The external control equipment sets the GRAY LEVEL of the plasma monitor.
Transmission Data
DFH 80H 60H C6H 01H DATA00 CKS
DATA00 : GRAY LEVEL 00H : 0
:
0FH : 15
ACK
7FH 60H 80H C6H 01H DATA00 CKS
DATA00 : GRAY LEVEL 00H : 0
:
0FH : 15
29
33. CINEMA MODE Set
Function
The external control equipment switches on or off the CINEMA MODE of the
plasma monitor.
Transmission Data
DFH 80H 60H C1H 01H DATA00 CKS
DATA00 : CINEMA MODE Set 01H : ON
02H : OFF
ACK
7FH 60H 80H C1H 01H DATA00 CKS
DATA00 : CINEMA MODE Set 01H : ON
02H : OFF
34. LONG LIFE Set
Function
The external control equipment sets the PLE, ORBITER, and INVERSE
(inverse of image brightness) of the plasma monitor.
Transmission Data
DFH 80H 60H 6BH 03H DATA00 DATA01 DATA02 CKS
DATA00 : PLE 01H : AUTO
02H : LOCK1
03H : LOCK2
04H : LOCK3
DATA01 : INVERSE 01H : ON
02H : OFF
03H :WHITE
DATA02 : ORBITER (PICTURE SHIFT) 01H : AUTO1
02H : OFF
03H : AUTO2
ACK
The plasma monitor returns the following ACK when setting the PLE,
ORBITER, and INVERSE (inverse of image brightness):
3FH 60H 80H 6BH 00H CKS
30
NOTE: The WORKING TIME and the WAITING TIME can be set in
1EH=1 hour and 30 minutes
35. INVERSE Set
Function
The external control equipment sets the INVERSE (inverse of image
brightness) and the WHITE of the plasma monitor.
Transmission Data
DFH 80H 60H C7H 03H DATA00 DATA01 DATA02 CKS
DATA00: INVERSE/WHITE 00H : No operation
01H : ON (INVERSE)
02H : OFF
03H : WHITE
DATA01 : WORKING TIME 00H : ON
01H: 03M (minutes)
02H: 06M (minutes)
:
FFH: 12H (hours) and 45M (minutes)
DATA02 : WAITING TIME 01H: 03M (minutes)
02H: 06M (minutes)
:
FFH: 12H (hours) and 45M (minutes)
ACK
3FH 60H 80H C7H 00H CKS
units of 3 minutes.
Example: 03H=9 minutes
31
1EH=1 hour and 30 minutes
36. SCREEN WIPER Set
Function
The external control equipment sets the SCREEN WIPER of the plasma
monitor.
Transmission Data
DFH 80H 60H C8H 04H DATA00 to DATA03 CKS
DATA00 : SCREEN WIPER 00H : No operation
01H : ON
02H : OFF
DATA01 : WORKING TIME 00H : ON
01H: 03M (minutes)
02H: 06M (minutes)
:
FFH: 12H (hours) and 45M (minutes)
DATA02 : WAITING TIME 01H: 03M (minutes)
02H: 06M (minutes)
:
FFH: 12H (hours) and 45M (minutes)
DATA03 : SPEED 01H : 1
:
05H : 5
ACK
3FH 60H 80H C8H 00H CKS
NOTE: The WORKING TIME and the WAITING TIME can be set in
units of 3 minutes.
Example: 03H=9 minutes
32
37. ALL RESET
Function
The external control equipment resets the user adjustment of the plasma
monitor.
Transmission Data
1FH 80H 60H 54H 00H CKS
ACK
3FH 60H 80H 54H 00H CKS
38. Audio Select Set
Function
The external control equipment sets combinations of audio and video inputs for
the plasma monitor.
Transmission Data
DFH 80H 60H 70H 02H DATA00 DATA01 CKS
DATA00 : AUDIO INPUT 01H : AUDIO1
02H : AUDIO2
03H : AUDIO3
DATA01 : VISUAL INPUT 01H : VIDEO1
02H : VIDEO2
03H : VIDEO3
05H : HD(HD1orDTVorDTV1)
06H : HD2(DTV2)
07H : RGB1/PC1
08H : RGB2/PC2
0CH : RGB3/PC3
0DH : HD3(SCART3)
ACK
The plasma monitor returns the following ACK when the input is switched.
3FH 60H 80H 70H 00H CKS
* The plasma monitor returns “Not Available” when selecting the video input
same as the one set at one of the AUDIO 1 to 3.
Example:
The plasma monitor returns “Not Available” when selecting the VIDEO1 for
AUDIO2 or VIDEO3 after VIDEO1 has been set to AUDIO1.
33
39. BNC INPUT
Function
The external control equipment sets the BNC SELECT of the plasma monitor.
Transmission Data
DFH 80H 60H 8CH 01H DATA00 CKS
DATA00 : BNC SELECT 01H : RGB
02H : Component
04H : SCART1(*:Only Europe can be chosen.)
05H : SCART2(*:Only Europe can be chosen.)
ACK
The plasma monitor returns the following ACK when setting the BNC SELECT:
7FH 60H 80H 8CH 01H DATA00 CKS
DATA00 : BNC SELECT 01H : RGB
02H : Component
04H : SCART1(*:Only Europe can be chosen.)
05H : SCART2(*:Only Europe can be chosen.)
40. RGB Select
Function
The external control equipment sets the RGB SELECT of the plasma monitor.
Transmission Data
DFH 80H 60H 8BH 01H DATA00 CKS
DATA00 01H : AUTO
02H : STILL
03H : MOTION
04H : WIDE1
05H : WIDE2
06H : DTV
07H : WIDE3
08H : WIDE4
ACK
7FH 60H 80H 8BH 01H DATA00 CKS
DATA00 01H : AUTO
02H : STILL
03H : MOTION
04H : WIDE1
34
05H : WIDE2
06H : DTV
07H : WIDE3
08H : WIDE4
41. HD Select
Function
The external control equipment sets the HD SELECT of the plasma monitor.
Transmission Data
DFH 80H 60H 8AH 01H DATA00 CKS
DATA00 01H : 1035I
02H : 1080A
03H : 1080B
ACK
7FH 60H 80H 8AH 01H DATA00 CKS
DATA00 01H : 1035I
02H : 1080A
03H : 1080B
42. LANGUAGE Select
Function
The external control equipment sets the LANGUAGE SELECT of the plasma
monitor.
Transmission Data
DFH 80H 60H 5BH 01H DATA00 CKS
DATA00: 01H : ENGLISH
02H : GERMAN
03H : FRENCH
04H : SPANISH
05H : ITALIAN
06H : SWEDISH
07H : JAPANESE
0AH : CHINESE
0BH：RUSSIAN
ACK
35
As for the change to JAPANESE (07H), SHIP needs to be set as
7FH 60H 80H 5BH 01H DATA00 CKS
DATA00: 01H : ENGLISH
02H : GERMAN
03H : FRENCH
04H : SPANISH
05H : ITALIAN
06H : SWEDISH
07H : JAPANESE
0AH : CHINESE
0BH：RUSSIAN
NOTE:
"J." When SHIP is "J", a setup of CHINESE (0AH) cannot be performed.
43. COLOR SYSTEM Select
Function
The external control equipment sets the COLOR SYSTEM of the plasma
monitor.
Transmission Data
DFH 80H 60H 5CH 01H DATA00 CKS
DATA00: 01H : 3.58NTSC
02H : 4.43NTSC
03H : PAL
04H : SECAM
0AH : AUTO
0BH : PAL60
0DH : PAL-M
0EH : PAL-N
ACK
7FH 60H 80H 5CH 01H DATA00 CKS
DATA00: 01H : 3.58NTSC
02H : 4.43NTSC
03H : PAL
04H : SECAM
0AH : AUTO
36
0BH : PAL60
0DH : PAL-M
0EH : PAL-N
44. FREQUENCY Request
Function
The external control equipment inquires the Horizontal frequency, Vertical
frequency, Horizontal sync polarity, Vertical sync polarity, Mode, and Resolution
of the plasma monitor.
Transmission Data
1FH 80H 60H 26H 00H CKS
ACK
7FH 60H 80H 26H 0BH DATA00 to DATA0A CKS
Horizontal frequency
DATA00: Integer part 00H: 0 (No signal: 00H)
:
FFH : 255
DATA01: One decimal place 00H: 0 (No signal: 00H)
:
09H : 9
Vertical frequency
DATA02: Integer part 00H: 0 (No signal: 00H)
:
FFH : 255
DATA03: One decimal place 00H: 0 (No signal: 00H)
:
09H : 9
Horizontal sync polarity
DATA04 00H : 01H : Positive
02H : Negative
Vertical sync polarity
DATA05 00H : 01H : Positive
02H : Negative
37
MODE
DATA06 00H : No signal −
01H to 80H : RGB signal Identification number of PC
mode
81H : Video signal 3.58NTSC
82H : 4.43NTSC
83H : PAL
84H : PAL-M
85H : PAL-N
86H : PAL60
87H : SECAM
88H : B/W60
89H : B/W50
A0H : HD/DVD/DTV signal 480I
A1H : 480P
A2H : 576I
A3H : 576P
A4H : 720P
A5H : 1035I
A6H : 1080I
RESOLUTION
DATA07: Dots (Low-order byte) 00H: 0 (No signal: 00H)
:
FFH 255
DATA08: Dots (High-order byte) 00H: 257 (No signal: 00H)
:
FFH
DATA09: Lines (Low-order byte) 00H: 0 (No signal: 00H)
:
FFH 255
DATA10: Lines (High-order byte) 00H: 257 (No signal: 00H)
:
FFH
38
45. Input MODE Request
Function
The display returns the current input information by the external control
equipment’ s request.
Transmission Data
1FH 80H 60H 41H 00H CKS
ACK
7FH 60H 80H 41H 01H DATA00 CKS
DATA00 : Input Select 01H : Video
02H : Video2
03H : Video3
04H : HD (HD1 or DTV or DTV1)
05H : PC1
06H : PC2
0AH : DVD (DVD1)
0CH : HD2 (DTV2)
0DH : DVD2
0EH : PC3
0FH : DVD3(SCART3)
46. VIDEO ADJ. Request
Function
The display returns the video adjustments information by the external control
equipment’s request.
Transmission Data
1FH 80H 60H 45H 00H CKS
ACK
7FH 60H 80H 45H 0CH DATA00 to DATA0B CKS
DATA00: RED Gain (Bias) D8H : -40
:
FFH : -01
00H : 0
01H : +01
:
1EH : +30
DATA01: GREEN Gain (Bias) D8H : -40
39
:
FFH : -01
00H : 0
01H : +01
:
1EH : +30
DATA02: BLUE Gain (Bias) D8H : -40
:
FFH : -01
00H : 0
01H : +01
:
1EH : +30
DATA03: COLOR Gain E0H : -32
:
* COLOR Gain is from -22 (EAH) to FFH : -01
+22 (16H) only during video. 00H : 0
01H : +01
:
20H : +32
DATA04: TINT Gain E0H : -32
:
* TINT Gain is from -22 (EAH) to FFH : -01
+22 (16H) only during video. 00H : 0
01H : +01
:
20H : +32
DATA05: SHARPNESS Gain F0H : -16
:
FFH : -01
00H : 0
01H : +01
:
10H : +16
DATA06: CONTRAST Gain CCH : -52
40
:
FFH : -01
00H : 0
01H : +01
:
14H : +20
DATA07: BRIGHT Gain E0H : -32
:
FFH : -01
00H : 0
01H : +01
:
20H : +32
DATA08: RED Gain (Drive) D8H : -40
:
FFH : -01
00H : 0
01H : +01
:
1EH : +30
DATA09: GREEN Gain (Drive) D8H : -40
:
FFH : -01
00H : 0
01H : +01
:
1EH : +30
DATA0A: BLUE Gain (Drive) D8H : -40
:
FFH : -01
00H : 0
01H : +01
:
41
1EH : +30
DATA0B: COLOR TEMP SELECT 00H: low
01H: middle
02H: high
03H: middle low
47. Audio Select Request
Function
The external control equipment inquires the current combinations of audio and
video inputs for the plasma monitor.
Transmission Data
1FH 80H 60H 6FH 00H CKS
ACK
The plasma monitor returns the following ACK:
7FH 60H 80H 6FH 03H DATA00 DATA01 DATA02 CKS
DATA00 : AUDIO1
01H-0CH : VISUAL INPUT DATA
DATA01 : AUDIO2
01H-0CH : VISUAL INPUT DATA
DATA02 : AUDIO3
01H-0CH : VISUAL INPUT DATA
<VISUAL INPUT DATA>
01H : VIDEO1
02H : VIDEO2
03H : VIDEO3
05H : HD(HD1ORDTVORDTV1)
06H : HD2(DTV2)
07H : RGB1/PC1
08H : RGB2/PC2
0CH : RGB3/PC3
0DH : HD3
42
48. Failure Mode Request
Function
The external control equipment inquires the detection of failures of the plasma
monitor.
Transmission Data
1FH 80H 60H 3FH 00H CKS
ACK
The plasma monitor returns the following ACK:
7FH 60H 80H 3FH 02H DATA00 DATA01 CKS
DATA00: FAILURE MODE 1
Bit 0 : PDP MODULE
0: Abnormal
1: Normal
Bit 1 : 1: fixed (backup)
Bit 2 : TEMPERATURE
0: Abnormal
1: Normal
Bit 3 : FAN
0: Abnormal
1: Normal
Bit 4 : TEMPERATURE SENSOR
0: Abnormal
1: Normal
Bit 5 : 1: fixed (backup)
Bit 6 : 1: fixed (backup)
Bit 7 : 1: fixed (backup)
DATA01: FAILURE MODE 2
Bit 0-7 : 1: fixed (backup)
43
49. MODEL NAME Request
Function
The external control equipment inquires the product code of the plasma
monitor.
Transmission Data
1FH 80H 60H 17H 00H CKS
ACK
The plasma monitor returns the following ACK:
7FH 60H 80H 17H 0CH DATA00 to DATA11 CKS
DATA00 : 1st character of the product code
DATA01 : 2nd character of the product code
:
DATA11 : 12th character of the product code
Received data 00H-09H : 0-9
80H : - (Hyphen)
81H : +
82H :
83H : /
84H : (
85H : )
86H : .
87H : ‘
96H : (Blank)
10H-29H : A-Z
Corresponding
character
Received data (H) 10 11 12 13 14 15 16 17 18 19
Corresponding
character
Received data (H) 1A 1B 1C 1D 1E 1F 20 21 22 23
Corresponding
character
Received data (H) 24 25 26 27 28 29
If there are fewer than 12 characters in the product code, product code
A B C D E F G H I J
K L M N O P Q R S T
U V W X Y Z
44
would be padded right with blanks.
Example: If the product code of your plasma monitor is “PX-42VP4G”, the
returned codes would be as follows.
DATA00:1FH, DATA01:27H, DATA02:80H, DATA03:04H, DATA04:02H,
DATA05:25H, DATA06:1FH, DATA07:04H, DATA08:16H, DATA09:96H,
DATA10:96H, DATA11:96H
45
50. D-SUB INPUT
Function
The external control equipment sets the D-SUB SELECT of the plasma monitor.
Transmission Data
DFH 80H 60H 8DH 01H DATA00 CKS
DATA00 : D-SUB INPUT 01H : RGB
02H : SCART3(*:Only Europe can be chosen.)
ACK
The plasma monitor returns the following ACK when setting the D-SUB
SELECT:
7FH 60H 80H 8DH 01H DATA00 CKS
DATA00 : D-SUB INPUT 01H : RGB
02H : SCART3(*:Only Europe can be chosen.)
51.TIMER SWITCH
Function
The external control equipment sets the timer reservation of the plasma
monitor.
Transmission Data
DFH 80H 60H 02H 01H DATA00 CKS
DATA00: 00H : Reservation OFF
01H : Reservation ON
ACK
7FH 60H 80H 02H 01H DATA00 CKS
DATA00: 00H : Reservation OFF
01H : Reservation ON
46
52.LOW TONE
Function
The external control equipment sets the dithering processing or error diffusion
processing of the plasma monitor.
Transmission Data
DFH 80H 60H 0CH 01H DATA00 CKS
DATA00:
01H: dithering processing(MOTION)
ACK
7FH 60H 80H 0CH 01H DATA00 CKS
DATA00:
01H: dithering processing (MOTION)
00H:AUTO
02H: dithering processing (STILL)
03H: error diffusion processing
00H:AUTO
02H: dithering processing (STILL)
03H: error diffusion processing
47
53.COLOR TUNE
Function
External control equipment can adjust RGB each color which a plasma monitor
wants to emphasize.
Transmission Data
DFH 80H 60H 0DH 07H DATA00 to DATA06 CKS
DATA00:RED
DATA01:GREEN
DATA02:BLUE
DATA03:YELLOW
DATA04:MAZENTA
DATA05:CYAN
DATA06:RESET
00H : -32
:
20H : 0
:
40H : +32
00H : -32
:
20H : 0
:
40H : +32
00H : -32
:
20H : 0
:
40H : +32
00H : -32
:
20H : 0
:
40H : +32
00H : -32
:
20H : 0
:
40H : +32
00H : -32
:
20H : 0
:
40H : +32
00H : OFF
48
01H : ON
ACK
7FH 60H 80H 0DH 00H CKS
54.TIMER PROGRAM SETTING
Function
External control apparatus sets up the timer program of a plasma monitor.
Transmission Data
DFH 80H 60H 30H 08H DATA00 to DATA07 CKS
DATA00 PROGRAM No
01H~07H :No1~No7
DATA01 DATE
01H~07H : Sunday - Saturday
08H : Every day
09H~0FH : Every week Sunday - every week Saturday
FFH : - (with No Setup)
DATA02 ON time (HOUR)
00H~09H :00~09
10H~19H :10~19
20H~23H :20~23
FFH : - (with No Setup)
DATA03 ON time (MIN)
00H~09H :00~09
10H~19H :10~19
20H~29H :20~29
30H~39H :30~39
40H~49H :40~49
50H~59H :50~59
FFH : - (with No Setup)
DATA04 OFF time (HOUR)
00H~09H :00~09
10H~19H :10~19
20H~23H :20~23
FFH : - (with No Setup)
DATA05 OFF time(MIN)
00H~09H :00~09
49
10H~19H :10~19
20H~29H :20~29
30H~39H :30~39
40H~49H :40~49
50H~59H :50~59
FFH : - (with No Setup)
DATA06 INPUT
01H : Video1
02H : Video2
03H : Video3
04H : HD1(HD1 or DTV or DTV1)
05H : HD2(DTV2 or SCART1/SCART2)
06H : RGB1
07H : RGB2
08H : RGB3
09H : HD3(SCART3)
FFH : - (with No Setup)
DATA07 MODE
01H : OBIT
02H : INV
03H : WT
04H : WIPER
FFH : - (with No Setup)
ACK
7FH 60H 80H 30H 00H CKS
50
55.PRESENT TIME SETTING
Function
External control apparatus sets up the present time of a plasma monitor.
Transmission Data
DFH 80H 60H 31H 03H DATA00 to DATA02 CKS
DATA00 Day of the week 01H-07H : 1-7 (Sunday - Saturday)
DATA01 HOUR 00H-09H:00-09
10H~19H:10~19
20H~23H:20~23
DATA02 minutes 00H-09H:00-09
10H~19H:10~19
20H~29H:20~29
30H~39H:30~39
40H~49H:40~49
50H~59H:50~59
ACK
7FH 60H 80H 31H 00H CKS
56.MULTI MODE Select
Function
External control apparatus changes MULTI MODE of a plasma monitor.
Transmission Data
DFH 80H 60H 03H 03H DATA00 DATA01 DATA02 CKS
DATA00 (SCREEN DIVIDER SETTING)
01H : Single mode
02H : Multi mode 1 screens
03H : Multi mode 4 screens
04H : Multi mode 9 screens
05H : Multi mode 16 screens
06H : Multi mode 25 screens
DATA01 (POSITION OF DIVIDE)
01H : Upper left selected (4 screens)
02H : Upper right selected (4 screens)
03H : Lower right selected (4 screens)
04H : Lower left selected (4 screens)
07H : Top left selected (9 screens)
51
2 3 4
7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25
12 13 14 16 17 18
08H : Top middle selected (9 screens)
09H : Top right selected (9 screens)
0AH : Middle left selected (9 screens)
0BH : Middle centerselected (9 screens)
0CH : Middle rightselected (9 screens)
0DH : Bottom leftselected (9 screens)
0EH : Bottom middle selected (9 screens)
0FH : Bottom right selected (9 screens)
10H : position1(16 screens,refer to figure1)
11H : position2(16 screens,refer to figure1)
:
18H : position9(16 screens,refer to figure1)
19H : position10(16 screens,refer to figure1)
:
1FH : position16 (16 screens,refer to figure1)
20H : position1(25 screens,refer to figure2)
21H : position2(25 screens,refer to figure2)
:
29H : position10(25 screens,refer to figure2)
2AH : position11(25 screens,refer to figure2)
:
32H : position19(25 screens,refer to figure2)
33H : position20(25 screens,refer to figure2)
:
38H : position25(25 screens,refer to figure2)
1 2 3 4
6 7 8 9
11
Figure1 Figure2
DATA02 (DISP MODE)
00H : SPLIT
19
1
6
5
52
01H : BRANKING
ACK
7FH 60H 80H 03H 03H DATA00 DATA01 DATA02 CKS
DATA00 (SCREEN DIVIDER SETTING)
01H : Single mode
02H : Multi mode 1 screens
03H : Multi mode 4 screens
04H : Multi mode 9 screens
05H : Multi mode 16 screens
06H : Multi mode 25 screens
DATA01 (POSITION OF DIVIDE)
01H : Upper left selected (4 screens)
02H : Upper right selected (4 screens)
03H : Lower right selected (4 screens)
04H : Lower left selected (4 screens)
07H : Top left selected (9 screens)
08H : Top middle selected (9 screens)
09H : Top right selected (9 screens)
0AH : Middle left selected (9 screens)
0BH : Middle centerselected (9 screens)
0CH : Middle rightselected (9 screens)
0DH : Bottom leftselected (9 screens)
0EH : Bottom middle selected (9 screens)
0FH : Bottom right selected (9 screens)
10H : position1(16 screens,refer to figure1)
11H : position2(16 screens,refer to figure1)
:
18H : position9(16 screens,refer to figure1)
19H : position10(16 screens,refer to figure1)
:
1FH : position16 (16 screens,refer to figure1)
20H : position1(25 screens,refer to figure2)
21H : position2(25 screens,refer to figure2)
:
29H : position10(25 screens,refer to figure2)
53
2 3 4
7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25
12 13 14 16 17 18
2AH : position11(25 screens,refer to figure2)
:
32H : position19(25 screens,refer to figure2)
33H : position20(25 screens,refer to figure2)
:
38H : position25(25 screens,refer to figure2)
1 2 3 4
6 7 8 9
11
19
Figure1 Figure2
DATA02 (DISP MODE)
00H : SPLIT
01H : BRANKING
1
6
5
Note) In the case of 4 screens or 9 screens video wall system and
connecting each PDP by wired cable, please refer to No.60.”VIDEO
WALL SETTING”.
54
57.MULTI MODE Request
Function
External control apparatus can know the MULTI MODE information on a
plasma monitor.
Transmission Data
1FH 80H 60H 3BH 00H CKS
ACK
7FH 80H 60H 3BH 02H DATA00 DATA01 DATA02 CKS
DATA00 (SCREEN DIVIDER SETTING)
01H : Single mode
02H : Multi mode 1 screens
03H : Multi mode 4 screens
04H : Multi mode 9 screens
05H : Multi mode 16 screens
06H : Multi mode 25 screens
DATA01 (POSITION OF DIVIDE)
01H : Upper left selected (4 screens)
02H : Upper right selected (4 screens)
03H : Lower right selected (4 screens)
04H : Lower left selected (4 screens)
07H : Top left selected (9 screens)
08H : Top middle selected (9 screens)
09H : Top right selected (9 screens)
0AH : Middle left selected (9 screens)
0BH : Middle centerselected (9 screens)
0CH : Middle rightselected (9 screens)
0DH : Bottom leftselected (9 screens)
0EH : Bottom middle selected (9 screens)
0FH : Bottom right selected (9 screens)
10H : position1(16 screens,refer to figure1)
11H : position2(16 screens,refer to figure1)
:
18H : position9(16 screens,refer to figure1)
19H : position10(16 screens,refer to figure1)
:
1FH : position16 (16 screens,refer to figure1)
55
2 3 4
7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25
12 13 14 16 17 18
20H : position1(25 screens,refer to figure2)
21H : position2(25 screens,refer to figure2)
:
29H : position10(25 screens,refer to figure2)
2AH : position11(25 screens,refer to figure2)
:
32H : position19(25 screens,refer to figure2)
33H : position20(25 screens,refer to figure2)
:
38H : position25(25 screens,refer to figure2)
1 2 3 4
6 7 8 9
11
Figure1 Figure2
DATA02 (DISP MODE)
00H : SPLIT
01H : BRANKING
19
1
6
5
56
58.AUTO ID SET START
Function
External control apparatus sets up ID automatically to two or more plasma
monitors.
Transmission Data
5FH 80H 60H F0H 01H DATA00 CKS
DATA00 00H~FFH: ID of a master*1 is set up.
*: When you use it by the multi-system, please remove the link input of a
*1.
master
*1: “Master” means the 1st set of PDP at the time of cable connection at
the time of AUTO ID execution.
59.PLE LINK
Function
External control apparatus sets up equally PLE between two or more plasma
monitors.
Transmission Data
DFH 80H 60H F1H 03H DATA00 to DATA02 CKS
DATA00 00H:PLE LINK ON
01H:PLE LINK OFF
DATA01 FFH
DATA02 FFH
*: This command is premised on the system configuration of two or more plasma
monitor being a multi-system. When renewal of the PSC data based on this
command is not carried out during a certain fixed period (about 2 seconds)
during PLE LINK enforcement, each plasma monitor sets PSC data as FFH.
Since this command is one-way traffic, there is no ACK.
*DATA01: Please set up FFH, when you publish this command from external
control apparatus. A master*1 sets up its own PSS data. As compared with its
own PSS data, the plasma monitor after the master which received this
command sets up the data of the larger one, and equips the output of a
command with it.
*DATA02: Please set up FFH, when you publish this command from external
control apparatus. The 1st round which PSS data has not decided is FFH.
57
*1: “Master” means the 1st set of PDP at the time of cable connection at
the time of AUTO ID execution.
60.VIDEO WALL SETTING
Function
External control apparatus sets 4screens or 9screens as a video wall.
Transmission Data
DFH 80H 60H F3H 03H DATA00 DATA01 DATA02 CKS
DATA00: 01H:1 screen
(Matrix diplay function does not work.)
04H:4 screens (2*2 video wall)
09H:9 screens (3*3 video wall)
DATA 01:
DATA 02:
02H : Video2
03H : Video3
04H : HD (HD1 or DTV or DTV1)
05H : HD2 (DTV2)
06H : HD3 (DTV3)
07H : RGB1 / PC1
08H : RGB2 / PC2
09H : RGB3 / PC3
00H-FFH:Master’s ID*1
01H : Video1
*: This command is used to following system.
1. The system configuration is video wall system (4screens or 9screens).
Then please connect each PDP by wired cable.
In the case of 16 screens or 25 screens video wall system, please refer to
No.56.”MULTI MODE Select”.
2. The ID number from a master1 display is set the continuous number.
DATA00: Specify the composition of a multi-system.
DATA01: Set master’s ID*1.
*1: “Master” means the 1st set of PDP at the time of cable connection at
the time of AUTO ID execution.
58
61.POWER DELAY ON(at 4 or 9 multiscreen)
Function
External control apparatus attaches a time lag to two or more plasma
monitors, and turns on a power supply.
Transmission Data
DFH 80H 60H F2H 01H DATA00 CKS
DATA00: 00H-FFH: Delay time (second)
*: This command is premised on two or more plasma monitor system
composition being multi-systems. In command issue of master1 OSD operation,
the value of DATA00 is 01H (1 second). This command does not have ACK for
one-way traffic.
*1: “Master” means the 1st set of PDP at the time of cable connection at
the time of AUTO ID execution.
62. POWER DELAY ON (at 16 or 25 multi screens)
Function
External control apparatus attaches a time lag to 10 or more plasma monitors,
and turns on a power supply.
Transmission Data
DFH 80H 60H F6H 01H DATA00 CKS
DATA00: 01H mode1
02H mode2
ACK
7FH 60H 80H F6H 01H DATA00 CKS
DATA00: 01H mode1
02H mode2
NOTE: When multi mode is 16 or 25, this function is available.
59
63.GAMMA GAIN Data
Function
External control apparatus changes Gamma of a plasma monitor.
Transmission Data
DFH 80H 60H 13H 02H DATA00 DATA01 CKS
DATA00: GAMMA FLAG 01H : Gamma change
DATA01: GAMMA 00H :1
01H :2
02H :3
03H :4
ACK
7FH 60H 80H 13H 01H DATA00 CKS
DATA00: GAMMA FLAG 01H : Gamma change
64.Running Sense
Function
External control apparatus grasps the power supply state of a plasma monitor.
A plasma monitor is made to recognize connection of PC CONTROL.
Transmission Data
1FH 80H 60H 88H 00H CKS
ACK
7FH 60H 80H 88H 01H DATA CKS
DATA: Bit0:Connect Condition
0: No connection
1: Connected
Bit1 0: Fixed
1:-
Bit2:Power Status
0:POWER ON
1:POWER OFF(STANBY)
Bit3 0: Fixed
Bit4 0: Fixed
Bit5 0: Fixed
Bit6 0: Fixed
Bit7 0: Fixed
60
65.ORBITER SET
Function
A picture shift function is set up. (*1)
Transmission Data
DFH 80H 60H 1EH 04H DATA00 to DATA03 CKS
DATA00: Mode 00H : OFF
01H : Auto 1 (*2)
02H : Auto 2 (*3)
03H : Manual (*4)
DATA01: The horizontal amount of movements
1 dot : 01H
to : -
20 dot : 14H
DATA02: The vertical amount of movements
One line : 01H
to : -
20 line : 14H
DATA03: Interval of operation 1 - 5 minutes : 01H - 05H
ACK
7FH 60H 80H 1EH 01H DATA00 CKS
DATA00: Mode 00H : OFF
01H : Auto 1
02H : Auto 2
03H : Manual
(*1)A picture shift function is a function which is made to carry out rotation
movement of the image, and mitigates printing on a screen.
(*2)At the time of PC input, after reducing an image, a picture shift is
performed. Reduction of an image does not carry out at the time of an
animation input.
(*3) At the time of PC input, after expanding an image, a picture shift is
performed. Expansion of an image does not carry out at the time of an
animation input.
(*4) It is not concerned with PC input and an animation input, and expansion
reduction of an image is not performed. It operates at intervals of the
horizontal and vertical amount of movements specified by DATA 01-03,
and operation.
61
66. OSM OBITER
Function
In order to decrease printing of a screen by OSM display, whenever it displays
OSM, shift operation of the OSM is carried out.
Transmission Data
DFH 80H 60H 5FH 01H DATA00 CKS
DATA00 01H : OBITER ON
02H : OBITER OFF
ACK
7FH 60H 80H 5FH 01H DATA00 CKS
DATA00 01H : OBITER ON
02H : OBITER OFF
67. OSM ANGLE
Function
The vertical display of OSM and a horizontal display are chosen.
Transmission Data
DFH 80H 60H 60H 01H DATA00 CKS
DATA00 01H : Horizontal display
02H : Vertical display
ACK
7FH 60H 80H 60H 01H DATA00 CKS
DATA00 01H : Horizontal display
02H : Vertical display
68. Input Skip
Function
In a monitor's key "an input change", when there is no signal, it flies and shifts
to the following channel.
Transmission Data
DFH 80H 60H 61H 01H DATA00 CKS
DATA00 01H : ON
02H : OFF
ACK
7FH 60H 80H 61H 01H DATA00 CKS
DATA00 01H : ON
02H : OFF
62
69. PICTURE Size
Function
Screen mode selection.
Transmission Data
DFH 80H 60H 2AH 01H DATA00 CKS
DATA00 01H : ON
02H : OFF
ACK
7FH 60H 80H 2AH 01H DATA00 CKS
DATA00 01H : ON
02H : OFF
*This function is only 50 or 61 inch model.
70. OPTION Select
Function
Power-on mode, a control lock, and IR remote are set up.
Transmission Data
DFH 80H 60H 63H 04H DATA00 to DATA03 CKS
DATA00 : Power ON mode 00H : LAST
01H : Video1
02H : Video2
03H : Video3
05H : HD (HD1 or DTV or DTV1)
06H: HD2 (DTV2 or SCART1/SCART2)
07H : RGB1 / PC1
08H : RGB2 / PC2
0CH : RGB3 / PC3
0DH : HD3(SCART3)
DATA01 : Control Lock 00H : OFF
01H : ON
DATA02 : IR remote 00H : OFF
01H : ON
DATA03 : Loop Out 00H : OFF
01H : ON
ACK
7FH 60H 80H 63H 00H CKS
63
71.REPEAT Timer
Function
External control apparatus sets up the repeat timer of a plasma monitor.
Transmission Data
DFH 80H 60H 64H 07H DATA00 to DATA06 CKS
DATA00 00H :REPEAT Timer OFF
01H :REPEAT Timer ON
DATA01 PROGRAM 1
01H :DIVIDER 1
02H :DIVIDER 4
03H :DIVIDER 9
DATA02 SOURCE 01H :Video1
02H :Video2
03H :Video3
05H :HD (HD1 or DTV-or-DTV1)
06H :HD2 (DTV2 or SCART1/SCART2
07H : RGB1 / PC1
08H : RGB2 / PC2
0CH : RGB3 / PC3
0DH : HD3 (SCART3)
DATA03 WORK TIME
01 H-FFH:1 - 255 minutes (1 minute - 4 hours and 15 minutes)
DATA04 PROGRAM 1
01H :DIVIDER 1
02H :DIVIDER 4
03H :DIVIDER 9
DATA05 SOURCE 01H :Video1
02H :Video2
03H :Video3
05H :HD (HD1 or DTV-or-DTV1)
06H :HD2 (DTV2 or SCART1/SCART2
07H : RGB1 / PC1
08H : RGB2 / PC2
0CH : RGB3 / PC3
0DH : HD3 (SCART3)
DATA06 WORK TIME
01 H-FFH:1 - 255 minutes (1 minute - 4 hours and 15 minutes)
64
ACK
7FH 60H 80H 64H 00H CKS
72. SERIAL No. Request
Function
External control apparatus read the serial number of the set recorded by
EEPROM of a plasma display.
Transmission Data
1FH 80H 60H 15H 00H CKS
ACK
7FH 60H 80H 15H 0CH DATA00 to DATA11 CKS
Even DATA00-DATA11 is set up as follows.
Setting value 00H-09H : 0 - 9
96H : Blank
10H-29H : A-Z of Alphabet
73.S1/S2 SELECT
Function
External control apparatus sets up the S1/S2 detection of a plasma monitor.
Transmission Data
DFH 80H 60H 89H 01H DATA00 CKS
DATA00 01H : AUTO
02H : OFF
ACK
7FH 60H 80H 89H 01H DATA00 CKS
DATA00 01H : AUTO
02H : OFF
65
74.SOFT FOCUS
Function
External control apparatus sets up the Soft Focus of a plasma monitor.
Transmission Data
DFH 80H 60H 65H 01H DATA00 CKS
DATA00 01H : OFF
02H : 1
03H : 2
04H : 3
05H : 4
ACK
7FH 60H 80H 65H 01H DATA00 CKS
DATA00 01H : OFF
02H : 1
03H : 2
04H : 3
05H : 4
75.PLUG and PLAY(only HDCP model)
Function
External control apparatus sets up the Plug and Play of a plasma monitor.
Transmission Data
DFH 80H 60H 8EH 01H DATA00 CKS
DATA00 01H : PC
02H : STB/DVD(HDCP signal)
ACK
7FH 60H 80H 8EH 01H DATA00 CKS
DATA00 01H : PC
02H : STB/DVD(HDCP signal)
66
76.DEGITAL SIGNAL LEVEL SELECT(only HDCP model)
Function
External control apparatus sets up the digital signal level of a plasma monitor.
Transmission Data
DFH 80H 60H 8FH 01H DATA00 CKS
DATA00 01H : LOW
02H : HIGH
ACK
7FH 60H 80H 8FH 01H DATA00 CKS
DATA00 01H : LOW
02H : HIGH
77.MULTI(SPRIT) SCREEN Select
Function
External control apparatus selects a screen mode from alternatives
mentioned below, such as single mode, side by side, picture in picture,
etc., of Plasma Monitor.
Transmission Data
DFH 80H 60H 07H 01H DATA00 CKS
DATA00: 00H: Single Screen
01H: Side by Side 1 (Same Size Screen)
02H: Side by Side 2R (Left Screen smaller)
03H: Picture in Picture 1 (sub screen Bottom Left) with size1
04H: Picturein Picture2(sub screen Bottom Right) with size1
05H: Side by Side 2L (Left Screen Bigger)
06H: Picturein Picture 1(sub screen Bottom Left) with size2
07H: Picturein Picture 2(sub screen Bottom Right) with size2
08H: Picturein Picture 1(sub screen Bottom Left) with size3
09H: Picturein Picture 2(sub screen Bottom Righ) with size3
0AH: Picturein Picture 1(sub screen Bottom Left) with size4
0BH: Picturein Picture 2(sub screen Bottom Right) withsize4
41H: Picturein Picture 3(sub screen Top Right) with size1
42H: Picturein Picture 3(sub screen Top Right) with size2
43H: Picturein Picture 3(sub screen Top Right) with size3
67
44H: Picturein Picture 3(sub screen Top Right) with size4
45H: Picturein Picture 4(sub screen Top Left) with size1
46H: Picturein Picture 4(sub screen Top Left) with size2
47H: Picturein Picture 4(sub screen Top Left) with size3
48H: Picturein Picture 4(sub screen Top Left) with size4
49H: Side by Side 3 (Same Size Screen vertical expand)
4AH: Side by Side 4 R(Left Screen smaller vertical expand)
4BH: Side by Side 4 L(Left Screen Bigger vertical expand)
In case of Side by Side mode;
20H: Active Left
21H: Active Right
In case of Picture in picture mode;
30H: Active Main
31H: Active Sub
ACK
7FH 60H 80H 07H 01H DATA00 CKS
DATA00: 00H: Single Screen
01H: Side by Side 1 (Same Size Screen)
02H: Side by Side 2R (Left Screen smaller)
03H: Picture in Picture 1 (sub screen Bottom Left) with size1
04H: Picturein Picture2(sub screen Bottom Right) with size1
05H: Side by Side 2L (Left Screen Bigger)
06H: Picturein Picture 1(sub screen Bottom Left) with size2
07H: Picturein Picture 2(sub screen Bottom Right) with size2
08H: Picturein Picture 1(sub screen Bottom Left) with size3
09H: Picturein Picture 2(sub screen Bottom Righ) with size3
0AH: Picturein Picture 1(sub screen Bottom Left) with size4
0BH: Picturein Picture 2(sub screen Bottom Right) withsize4
41H: Picturein Picture 3(sub screen Top Right) with size1
42H: Picturein Picture 3(sub screen Top Right) with size2
43H: Picturein Picture 3(sub screen Top Right) with size3
44H: Picturein Picture 3(sub screen Top Right) with size4
45H: Picturein Picture 4(sub screen Top Left) with size1
46H: Picturein Picture 4(sub screen Top Left) with size2
47H: Picturein Picture 4(sub screen Top Left) with size3
48H: Picturein Picture 4(sub screen Top Left) with size4
49H: Side by Side 3 (Same Size Screen vertical expand)
68
4AH: Side by Side 4R (Left Screen smaller vertical expand)
4BH: Side by Side 4L (Left Screen Bigger vertical expand)
In case of Side by Side mode;
20H: Active Left
21H: Active Right
In case of Picture in picture mode;
30H: Active Main
31H: Active Sub
78. SUB PICTURE DETECT SELECT
Function
External control apparatus selects whether to display the sub picture or not,
under picture in picture mode, of plasma monitor.
Transmission Data
DFH 80H 60H 7AH 01H DATA00 CKS
DATA00 01H : OFF
02H : AUTO
ACK
7FH 60H 80H 7AH 01H DATA00 CKS
DATA00 01H : OFF
02H : AUTO
79.ZOOM NAVIGATION SELECT
Function
External control apparatus selects digital zoom display of a plasma monitor,
from the alternatives mentioned below;
Transmission Data
DFH 80H 60H 7BH 01H DATA00 CKS
DATA00 01H : NORMAL
02H : Side By Side(Left Screen smaller)
03H : Picture in Picture1(Sub Screen Bottom Left)
04H : Picture in Picture2(Sub Screen Bottom Right)
05H : Picture in Picture3(Sub Screen Top Right)
06H : Picture in Picture4(Sub Screen Top Left)
ACK
7FH 60H 80H 7BH 01H DATA00 CKS
DATA00 01H : NORMAL
69
02H : Side By Side
03H : Picture in Picture1(Sub Screen Bottom Left)
04H : Picture in Picture2(Sub Screen Bottom Right)
05H : Picture in Picture3(Sub Screen Top Right)
06H : Picture in Picture4(Sub Screen Top Left)
80.PICTURE FREEZE SELECT
Function
External control apparatus selects the picture freeze function of a plasma
monitor.
Transmission Data
DFH 80H 60H 7CH 01H DATA00 CKS
DATA00 01H : OFF(single screen)
02H : Side By Side1(Same Size Screen)
03H : Picture in Picture1(Sub Screen Bottom Left)
04H : Picture in Picture2(Sub Screen Bottom Right)
05H : Picture in Picture3(Sub Screen Top Right)
06H : Picture in Picture4(Sub Screen Top Left)
07H: Side by Side2 (Same Size Screen vertical expand)
ACK
7FH 60H 80H 7CH 01H DATA00 CKS
DATA00 01H : OFF(single screen)
02H : Side By Side1
03H : Picture in Picture1(Sub Screen Bottom Left)
04H : Picture in Picture2(Sub Screen Bottom Right)
05H : Picture in Picture3(Sub Screen Top Right)
06H : Picture in Picture4(Sub Screen Top Left)
07H : Side by Side2(Same Size Screen vertical expand)
81. PICTURE FREEZE Command
Function
External control apparatus sets picture freeze or remove picture freeze of a
plasma monitor.
Transmission Data
DFH 80H 60H 7DH 01H DATA00 CKS
DATA00 01H : FREEZE
02H : FREEZE OFF
70
ACK
7FH 60H 80H 7DH 01H DATA00 CKS
DATA00 01H : FREEZE
02H : FREEZE OFF
82.SEAMLESS SWITCH SELECT
Function
External control apparatus selects the seamless switch function of a plasma
monitor.
Transmission Data
DFH 80H 60H 7EH 01H DATA00 DATA01 DATA02 CKS
DATA00: SEAMLESS SWITCH
01H :OFF
02H :ON
DATA01 : SELECT1 01H : Video1
02H : Video2
03H : Video3
05H : HD (HD1 or DTV or DTV1)
06H : HD2 (DTV2 or SCART1/SCART2)
07H : RGB1 / PC1
08H : RGB2 / PC2
0CH : RGB3 / PC3
0DH : HD3(SCART3)
DATA02 : SELECT2 01H : Video1
02H : Video2
03H : Video3
05H : HD (HD1 or DTV or DTV1)
06H : HD2 (DTV2 or SCART1/SCART2)
07H : RGB1 / PC1
08H : RGB2 / PC2
0CH : RGB3 / PC3
0DH : HD3(SCART3)
ACK
7FH 60H 80H 7EH 01H DATA00 CKS
DATA00 01H : OFF
02H : ON
71
83.MULTI （SPRIT） SCREEN PROGRAM TIMER SET
Function
External control apparatus sets multi (sprit) screen program timer of a plasma
monitor.
Transmission Data
DFH 80H 60H 32H 0AH DATA00〜DATA09 CKS
DATA00 PROGRAM No 01H〜07H :No1〜No7
DATA01 DATE 01H〜07H : Sunday~Saturday
08H : Everyday
09H〜0FH:Every Sunday~Every Saturday
FFH : - (no setteing)
DATA02 ON time(hour) 00H〜09H:00〜09
10H〜19H:10〜19
20H〜23H:20〜23
FFH : - (no setteing)
DATA03 ON time(minute) 00H〜09H : 00〜09
10H〜19H:10〜19
20H〜29H:20〜29
30H〜39H:30〜39
40H〜49H:40〜49
50H〜59H:50〜59
FFH : - (no setteing)
DATA04 OFFtime(hour 00H〜09H:00〜09
10H〜19H:10〜19
20H〜23H:20〜23
FFH : - (no setteing)
DATA05 OFFtime(minute)00H〜09H : 00〜09
10H〜19H:10〜19
20H〜29H:20〜29
30H〜39H:30〜39
40H〜49H:40〜49
50H〜59H:50〜59
FFH : - (no setteing)
DATA06 MULTI MODE 01H : Side By Side1(Same Size Screen)
02H : Side By Side2(Left Screen Smaller)
03H : Side By Side2(Left ScreenBigger)
72
04H : Picture in Picture1(Sub Screen Bottom Left)
05H : Picture in Picture2(Sub Screen Bottom Right)
06H : Picture in Picture3(Sub Screen Top Right)
07H : Picture in Picture4(Sub Screen Top Left)
DATA07 INPUT1（Left or main）
01H : Video1
02H : Video2
03H : Video3
05H : HD (HD1 or DTV or DTV1)
06H : HD2 (DTV2 or SCART1/SCART2)
07H : RGB1 / PC1
08H : RGB2 / PC2
0CH : RGB3 / PC3
0DH : HD3(SCART3)
DATA08 INPUT2(Right or Sub)
01H : Video1
02H : Video2
03H : Video3
05H : HD (HD1 or DTV or DTV1)
06H : HD2 (DTV2 or SCART1/SCART2)
07H : RGB1 / PC1
08H : RGB2 / PC2
0CH : RGB3 / PC3
0DH : HD3(SCART3)
DATA09 MODE 01H : ORBITER
02H : INVERSE
03H : WHITE
04H : WIPER
FFH : - (no setteing)
ACK
7FH 60H 80H 30H 00H CKS
73
84.MULTI （SPRIT） SCREEN POWER ON MODE SET
Function
External control apparatus sets “multi (sprit) screen power on mode” of a
plasma monitor.
Transmission Data
DFH 80H 60H 33H 04H DATA00〜DATA03 CKS
DATA00 POWER ON MODE
01H:LAST
02H:MULTI
DATA01 MULTI MODE
01H : Side By Side1(Same Size Screen)
02H : Side By Side2(Left Screen Smaller)
03H : Side By Side2(Left ScreenBigger)
04H : Picture in Picture1(Sub Screen Bottom Left)
05H : Picture in Picture2(Sub Screen Bottom Right)
06H : Picture in Picture3(Sub Screen Top Right)
07H : Picture in Picture4(Sub Screen Top Left)
DATA02 INPUT1（Left or main）
01H : Video1
02H : Video2
03H : Video3
05H : HD (HD1 or DTV or DTV1)
06H : HD2 (DTV2 or SCART1/SCART2)
07H : RGB1 / PC1
08H : RGB2 / PC2
0CH : RGB3 / PC3
0DH : HD3(SCART3)
DATA03 INPUT2(Right or Sub)
01H : Video1
02H : Video2
03H : Video3
05H : HD (HD1 or DTV or DTV1)
06H : HD2 (DTV2 or SCART1/SCART2)
07H : RGB1 / PC1
08H : RGB2 / PC2
0CH : RGB3 / PC3
74
0DH : HD3(SCART3)
ACK
7FH 60H 80H 33H 00H CKS
85.MULTI （SPRIT） REPEAT TIMER SET
Function
External control apparatus sets “multi (sprit) screen repeat timer” of a plasma
monitor.
Transmission Data
DFH 80H 60H 34H 09H DATA00〜DATA03 CKS
DATA00 REPEAT TIMER 00H:OFF
01H:ON
REPEAT1
DATA01 MULTI MODE
00H : SINGLE
01H : Side By Side1(Same Size Screen)
02H : Side By Side2(Left Screen Smaller)
03H : Side By Side2(Left ScreenBigger)
04H : Picture in Picture1(Sub Screen Bottom Left)
05H : Picture in Picture2(Sub Screen Bottom Right)
06H : Picture in Picture3(Sub Screen Top Right)
07H : Picture in Picture4(Sub Screen Top Left)
DATA02 INPUT1（Left or main）
01H : Video1
02H : Video2
03H : Video3
05H : HD (HD1 or DTV or DTV1)
06H : HD2 (DTV2 or SCART1/SCART2)
07H : RGB1 / PC1
08H : RGB2 / PC2
0CH : RGB3 / PC3
0DH : HD3(SCART3)
DATA03 INPUT2(Right or Sub)
01H : Video1
02H : Video2
03H : Video3
05H : HD (HD1 or DTV or DTV1)
75
06H : HD2 (DTV2 or SCART1/SCART2)
07H : RGB1 / PC1
08H : RGB2 / PC2
0CH : RGB3 / PC3
0DH : HD3(SCART3)
DATA04 WORK TIME 01H〜FFH : 1〜255 minutes
（1 minutes〜4 hour 15 minutes）
REPEAT2
DATA05 MULTI MODE
00H : SINGLE
01H : Side By Side1(Same Size Screen)
02H : Side By Side2(Left Screen Smaller)
03H : Side By Side2(Left ScreenBigger)
04H : Picture in Picture1(Sub Screen Bottom Left)
05H : Picture in Picture2(Sub Screen Bottom Right)
06H : Picture in Picture3(Sub Screen Top Right)
07H : Picture in Picture4(Sub Screen Top Left)
DATA06 INPUT1（Left or main）
01H : Video1
02H : Video2
03H : Video3
05H : HD (HD1 or DTV or DTV1)
06H : HD2 (DTV2 or SCART1/SCART2)
07H : RGB1 / PC1
08H : RGB2 / PC2
0CH : RGB3 / PC3
0DH : HD3(SCART3)
DATA07 INPUT2(Right or Sub)
01H : Video1
02H : Video2
03H : Video3
05H : HD (HD1 or DTV or DTV1)
06H : HD2 (DTV2 or SCART1/SCART2)
07H : RGB1 / PC1
08H : RGB2 / PC2
0CH : RGB3 / PC3
76
0DH : HD3(SCART3)
DATA08 WORK TIME
01H〜FFH : 1〜255 minutes
（1 minutes〜4 hour 15 minutes）
NOTE: When “SINGLE” is selected at DATA01 or DATA04,
”INPUT MODE 1” will be repeated.
ACK
7FH 60H 80H 34H 00H CKS
86.OSM CONTRAST SELECT
Function
External control apparatus selects the OSM contrast function of a plasma
monitor.
Transmission Data
DFH 80H 60H 37H 01H DATA00 CKS
DATA00 01H : NORMAL
02H : LOW
ACK
7FH 60H 80H 37H 01H DATA00 CKS
DATA00 01H : NORMAL
02H : LOW
77
87.CC (Closed caption) SELECT
Function
External control apparatus selects the Closed Caption function of a plasma
monitor.
Transmission Data
DFH 80H 60H 3CH 01H DATA00 CKS
DATA00 00H : OFF
01H : CC1(closed caption1)
02H : CC2(closed caption2)
03H : CC3(closed caption3)
04H : CC4(closed caption4)
05H : TEXT1
06H : TEXT2
07H : TEXT3
08H : TEXT4
ACK
7FH 60H 80H 3CH 01H DATA00 CKS
DATA00 00H : OFF
01H : CC1(closed caption1)
02H : CC2(closed caption2)
03H : CC3(closed caption3)
04H : CC4(closed caption4)
05H : TEXT1
06H : TEXT2
07H : TEXT3
08H : TEXT4
78
88.CC (Closed caption) CONTRAST SELECT
Function
External control apparatus selects the Closed Caption Contrast function of a
plasma monitor.
Transmission Data
DFH 80H 60H 3DH 01H DATA00 CKS
DATA00 01H : NORMAL
02H : LOW
ACK
7FH 60H 80H 3DH 01H DATA00 CKS
DATA00 01H : NORMAL
02H : LOW
79
Loading...
