NEC E900+ User Manual

NEC Enterprise Series

MultiSync

™

900+

User’s Manual

Contents 1 Quick Start 2-3 Controls 4-6 Recommended Use 7-8 Specifications 9 Features 10 Troubleshooting 11 References 12 Limited Warranty 13 TCO’95 14-15

78133521 5/15/98, 2:16 PM1

WARNING

TO PREVENT FIRE OR SHOCK HAZARDS, DO NOT EXPOSE THIS UNIT TO RAIN OR MOISTURE. ALSO, DO NOT USE THIS UNIT'S POLARIZED PLUG WITH AN EXTENSION CORD RECEPTACLE OR OTHER OUTLETS UNLESS THE PRONGS CAN BE FULLY INSERTED. REFRAIN FROM OPENING THE CABINET AS THERE ARE HIGH VOLTAGE COMPONENTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

CAUTION

CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, MAKE SURE POWER CORD IS UNPLUGGED FROM WALL

SOCKET. TO FULLY DISENGAGE THE POWER TO THE UNIT, PLEASE DISCONNECT THE POWER CORD FROM THE AC OUTLET. DO NOT REMOVE COVER (OR BACK) NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

This symbol warns user that uninsulated voltage within the unit may have sufficient magnitude to cause electric shock. Therefore, it is dangerous to make any kind of contact with any part inside this unit.

This symbol alerts the user that important literature concerning the operation and maintenance of this unit has been included. Therefore, it should be read carefully in order to avoid any problems.

Canadian Department of Communications Compliance Statement

DOC: This Class B digital apparatus meets all requirements of the Canadian

Interference-Causing Equipment Regulations. Cet appareil numérique de la classe B respecte toutes les exigences du

Règlement sur le matériel brouiller du Canada.

C-UL: Bears the C-UL Mark and is in compliance with Canadian Safety Regulations

according to C.S.A. 22.2 #950. Ce produit porte la marque ‘C-UL’ et se conforme aux règlements de sûrele

Canadiens selon CAN/CSA 22.2 No. 950.

FCC Information

Use the attached specified cables with the JC-1942UMW with radio and television reception. (1) Please use the supplied power cable or equivalent to ensure FCC compliance. (2) Shielded captive type signal cable.

Use of other cables and adapters may cause interference with radio and television reception.

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy, and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

• Consult your dealer or an experienced radio/TV technician for help.

If necessary, the user should contact the dealer or an experienced radio/television technician for additional suggestions. The user may find the following booklet, prepared by the Federal Communications Commission, helpful: ”How to Identify and Resolve Radio-TV Interference Problems.“ This booklet is available from the U.S. Government Printing Office, Washington, D.C., 20402, Stock No. 004-000-00345-4.

color monitor so as not to interfere

78133521 5/15/98, 2:16 PM2

Contents

Your new NEC Technologies MultiSync® E Series monitor box* should contain the following:

• MultiSync E900+™ (JC-1942UMW) Monitor with tilt/swivel base

• Power Cord

• Captive Signal Cable

• User’s Manual

• Registration Card

Power Cord

NEC Enterprise S

MultiSync

900+

User’s Manual

eries

User’s Manual Registration Card

* Remember to save your original box

and packing material to transport or ship the monitor.

78133521 5/15/98, 2:16 PM3

Captive Signal Cable

take a few moments to register your new

NEC MultiSync monitor.

By returning this card, we confirm your

date of purchase and records the model

and serial numbers. This facilitates our

ability to process warranty claims,

especially if your original proof of

purchase is lost.

Thank you for your time and for choosing

an NEC MultiSync monitor.

PRODUCT REGISTRATION

SEE, HEAR AND FEEL THE DIFFERENCE.

Note: You can now register your product on the Internet at http://www.prodreg.com/nec

NEC MultiSync Monitors

THANK YOU FOR

CHOOSING AN NEC

MultiSync

— Important —

MONITOR

To help us in our continuing efforts to

better serve and support you, and to bring

you new and innovative products, please

™

Quick Start

To attach the MultiSync® E900+™ monitor to your system, follow these instructions:

1. Turn off the power to your computer.

2. If necessary, install the display card into your system. For more information, refer to the display card manual.

3. For the PC: Connect the 15-pin mini D-SUB of the captive signal cable to the connector of the display card in your system (Figure A.1). Tighten all screws.

For the Mac: Connect the MultiSync E900+ Macintosh cable adapter (not included) to the monitor connector on the Macintosh (Figure B.1). Attach the 15-pin mini D-SUB end of the captive signal cable to the MultiSync E900+ Macintosh cable adapter on the computer (Figure B.1). Tighten all screws.

NOTE: To obtain the MultiSync E900+ Macintosh cable adapter, call

NEC Technologies at (800) 820-1230.

4. For download information on the Windows® 95 INF file for your MultiSync E900+ monitor, refer to the References section of this User’s Manual.

5. Connect one end of the power cord to the MultiSync E900+ monitor and the other end to the power outlet (Figure C.1).

6. Turn on the monitor (Figure D.1) and the computer.

NOTE: If you have any problems, please refer to the Troubleshooting section of

this User’s Manual.

78133521 5/15/98, 2:16 PM4

Figure A.1

Quick Start

Power Outlet

Figure B.1

CONTROL

78133521 5/15/98, 2:16 PM5

Power

Cord

Figure C.1

RESETPROCEEDEXIT

Figure D.1

MultiSync E

900+

Controls

OSM™ (On-Screen Manager) control buttons on the front of the monitor function as follows:

EXIT Exits the OSM menu. Exits to the OSM controls

CONTROL Moves the highlighted Moves the highlighted area / area up/down to select up/down to select one of the

CONTROL Moves the highlighted Moves the bar in the – or + –/+ area left/right to select direction to decrease or

Main Menu Sub-Menu

main menu.

one of the controls. controls.

one of the controls. increase the adjustment.

PROCEED Has no function. Only executes control

RESET Resets all the controls within Resets the highlighted control

the highlighted menu to the factory setting. to the factory setting.

NOTE: When RESET is pressed in the main and sub-menu, a warning

window will appear allowing you to cancel the reset function.

or enters sub, sub-menu.

When OSM controls are activated, icons are displayed at the top of the menu. If an arrow (➔) is displayed in a sub-menu, it indicates further choices are

available. To enter a sub, sub-menu, press PROCEED.

Brightness/Contrast Controls

Brightness: Adjusts the overall image and background screen brightness. Contrast: Adjusts the image brightness in relation to the background.

Degauss: Eliminates the buildup of stray magnetic fields which alter the correct

scan of the electron beams and affect the purity of the screen colors, focus and convergence. When activated, your screen image will jump and waver a bit as the screen is demagnetized.

Caution: Please allow a minimum of 20 minutes to elapse between uses of the Degauss Control.

Size and Position Controls

Left/Right: Moves the image horizontally (left or right). Down/Up: Moves the image vertically (up or down). Narrow/Wide: Decreases or increases the horizontal size of the image. Short/Tall: Decreases or increases the vertical size of the image.

78133521 5/15/98, 2:16 PM6
