Motorola i365IS User Manual

SouthernLINC
i365/i365IS Phone
User’s Guide
Dummy Page - To be discarded before printing
IMPORTANT NOTICE: PLEASE READ PRIOR TO USING YOUR PHONE
The SIM card provided in this kit is intended for use with the phone provided in this package.
Loss of certain features will result when using a SIM card from one of the following models: i30sx, i35s, i50sx, i55sr, i58s, i60c, i80s, i85s, i88s, i90c, i95cl series, and the i2000 series.
For more information on SIM card compatibility, go to www.motorola.com/iden.
Defects or damage to your Motorola phone that result from the use of non-Motorola branded or certified Accessories, including but not limited to replacement housings and or other peripheral accessories, are excluded from warranty coverage. Please refer to the text of Motorola's Limited One Year warranty located in this user’s guide for complete details.
DECLARATION OF CONFORMITY
Per FCC CFR 47 Part 2 Section 2.1077(a)
Responsible Party Name: Motorola, Inc. Address: 8000 West Sunrise Boulevard Plantation, FL 33322 USA Phone Number: 1 (800) 453-0920 Hereby declares that the product: Product Name: i365 (i365IS) Model Number: H01XAN6JR5AN (i365)
H01XAN6JR6AN (i365IS) Conforms to the following regulations: FCC Part 15, subpart B, section 15.107(a),
15.107(d) and section 15.109(a) Class B Digital Device As a personal computer peripheral, this device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause
harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
Note:
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
HELLOMOTO
PTT Button
Audio Jack
Volume Keys
Left Soft Key
Perform function
in lower left
display.
Talk Key
Make &
answer calls.
Menu Key
From home screen,
open main menu.
4-Way
Navigation Key
Right Soft Key
Perform function in lower right display.
Home/End Key
End calls, exit menu system.
Power Key
OK Key
In menus & lists, press to select highlighted option.
Status Indicator
Microphone
Speaker
Speaker On/Off
Key
Smart Key
Earpiece
Introducing your new Motorola i365 wireless phone. Here’s a quick anatomy lesson.
1

check it out

Home Screen
1
Press and hold the
Power Key
few seconds, or until
for a
Main Menu
Main Menu
1
T
0
L
P
D
More
u
g l
Exit
3
Press the Navigation key
up, down, left or right ( )
to highlight a menu feature.
the screen lights up, to turn on your phone.
2
Press the O key to open the
Ringtones
screen
4
Press the O key to select.
2
Motorola, Inc. Consumer Advocacy Office 1307 East Algonquin Road Schaumburg, IL 60196
www.hellomoto.com Note:
Do not ship your phone to the above address. If you need to return your phone for repairs, replacement, or warranty service, please contact the Motorola Customer Support Center at:
1-800-453-0920 (United States) 1-877-483-2840 (TTY/TDD United States for hearing impaired)
Certain mobile phone features are dependent on the capabilities and settings of your service provider’s network. Additionally, certain features may not be activated by your service provider, and/or the provider's network settings may limit the feature’s functionality. Always contact your service provider about feature availability and functionality. All features, functionality, and other product specifications, as well as the information contained in this user's guide are based upon the latest available information and are believed to be accurate at the time of printing. Motorola reserves the right to change or modify any information or specifications without notice or obligation.
MOTOROLA and the Stylized M Logo are registered in the US Patent & Trademark Office. All other product or service names are the property of their respective owners. Java and all other Java­based marks are trademarks or registered trademarks of Sun Microsystems, Inc. in the U.S. and other countries.
© Motorola, Inc., 2008.
Manual Number: NNTN7437A
3
4
contents
check it out . . . . . . . . . . . 2
menu map. . . . . . . . . . . . 7
Use and Care . . . . . . . . . 9
essentials . . . . . . . . . . . 10
about this guide . . . . . 10
SIM card. . . . . . . . . . . . 11
battery . . . . . . . . . . . . . 11
turn it on & off . . . . . . 15
enable security . . . . . . 15
make a phone call. . . . 16
answer a phone call . . 16 make a InstantLINC Mobile to Mobile call . 16 answer a InstantLINC Mobile to Mobile call . 18 store a phone number
or LINC ID. . . . . . . . . . 18
call a stored phone number or LINC ID . . . 19 your phone number
and LINC ID . . . . . . . . 20
text messages . . . . . . 20
manage memory . . . . 23
using your handset
as a modem . . . . . . . . 24
main attractions . . . . . . 26
LINC features . . . . . . . 26
one touch PTT . . . . . . 33
LINC manager . . . . . . 34
bluetooth advanced features . . . 38
basics. . . . . . . . . . . . . . . 45
display . . . . . . . . . . . . 45
main menu . . . . . . . . . 46
text entry . . . . . . . . . . 46
®
. . . . . . . . . 34
navigation key. . . . . . . 49
handsfree speaker . . . 49
transmitters . . . . . . . . 49
use GPS with map
software . . . . . . . . . . . 50
calls . . . . . . . . . . . . . . . . 53
turn off a call alert. . . . 53
recent calls . . . . . . . . . 53
redial. . . . . . . . . . . . . . 54
caller ID . . . . . . . . . . . 54
call forward. . . . . . . . . 55
voice names . . . . . . . . 55
emergency calls . . . . . 56
international calls . . . . 57
speed dial . . . . . . . . . . 57
turbo dial. . . . . . . . . . . 57
voicemail. . . . . . . . . . . 57
LINCaround . . . . . . . . 58
contents
5
customize. . . . . . . . . . . . 65
ring tones . . . . . . . . . . 65
wallpaper. . . . . . . . . . . 66
backlight . . . . . . . . . . . 67
datebook . . . . . . . . . . . 67
hide or show location
information . . . . . . . . . 68
other features . . . . . . . . 70
advanced calling . . . . . 70
contacts. . . . . . . . . . . . 71
datebook . . . . . . . . . . . 71
GPS . . . . . . . . . . . . . . . 72
handsfree . . . . . . . . . . 73
personalize . . . . . . . . . 74
pc applications. . . . . . . 74
TTY . . . . . . . . . . . . . . . 74
security . . . . . . . . . . . . 75
Safety and General
Information . . . . . . . . . . 78
Service & Repairs . . . . . 84
contents
6
Specific Absorption
Rate Data . . . . . . . . . . . . 85
Motorola Limited Warranty for the United States
and Canada . . . . . . . . . . 87
Information From the World Health
Organization . . . . . . . . . 92
Patent and Trademark
Information . . . . . . . . . . 94
Privacy and Data
Security . . . . . . . . . . . . . 95
Smart Practices
While Driving . . . . . . . . . 96
index. . . . . . . . . . . . . . . . 98
main menu
u
Settings
• (see next page)
Q
Downloads
1
Browser Apps
L
Java Apps
• Java System
t
Ring Tones
• Vibrate All
• Ringer
• Vibrate
• Silent
N
LINC Manager
• LINC Message
•LINC Picture
•LINC Event
• LINC My Info
• LINC Contact
• Configure
O
My Pictures
P
Call Forward
0
VoiceRecord
• [New VoiceRec]
D
Datebook

menu map

K
Shortcuts
•[New Entry]
• 1)Shortcuts
• 2)Cntcs[New Contact]
• 3)Ring Tones
• 4)LINC Manager
• 5)Browser Apps
• 6)Java Apps
• 7)Settings
• 8)Profiles
• 9)Call Forward
o
Profiles
p
Call Alert
M
Call Timers
• Last Call
• Phone Reset
• Phone Lifetime
•Prvt/Grp Reset
• Prvt/Grp Life
• Circuit Reset
• Circuit Lifetime
• Kbytes Reset
J
My Info
•My Name
• Line 1
• Line 2
• LINC ID
• Group ID
• Carrier IP
• IP1 Address
• IP2 Address
• Circuit Data
B
Recent Calls
l
Memo
A
Contacts
• [New Contact]
E
Messages
• [Create Message]
•Voice Mail
• Text Inbox
•Quick Notes
•Drafts
• Text Outbox
•Net Alert
• Fax Mail
c
GPS
• Position
•Privacy
• Interface
C
Bluetooth
• Hands Free
• Link to Devices
• Device History
•Setup
•Find Me
P
LINCaround
This is the standard Main Menu layout. Your phone’s menu may be a little different.
menu map
7
settings menu
Display/Info
• Wallpaper
•Text Size
• Theme
• Home Icons
• Backlight
•Clock
• Menu View
• Large Dialing
• Status Light
• Language
Phone Calls
• Set Line
•Any Key Ans
• Auto Redial
• Call Waiting
• Auto Ans
• Minute Beep
• Call Duration
• TTY
• Notifications
• DTMF Dialing
menu map
8
InstantLINC
• Tkgrp Silent
•Tkgrp Area
• One Touch PTT
• Alert Type
•LINC Notes
• On/Off LINC Features
• Store Rcvd Info
Personalize
• Menu Options
•Up Key
•Down Key
•Left Key
• Right Key
• Center Key
• Left Sftkey
• Right Sftkey
•Power Up
Vol u me
• Line 1
• Line 2
• Messages
• Earpiece
• Speaker
•Keypad
• Java Earpiece
• Java Spkr
•Data
Security
• Phone Lock
• Keypad Lock
• SIM PIN
• GPS PIN
• Change Passwds
Advanced
• Alert Timeout
• Headset/Spkr
• Connectivity
• Reset Defaults
• Return to Home
•Transmitters
• Phone Only
• Baud Rate

Use and Care

Use and Care
To care for your Motorola phone, please keep it away from:
liquids of any kind dust and dirt
Don’t expose your phone to water, rain, extreme humidity, sweat, or other moisture.
extreme heat or cold cleaning solutions
Avoid temperatures below
-10°C/14°F or above 45°C/113°F.
microwaves the ground
Don’t try to dry your phone in a microwave oven.
Don’t expose your phone to dust, dirt, sand, food, or other inappropriate materials.
To clean your phone, use only a dry soft cloth. Don’t use alcohol or other cleaning solutions.
Don’t drop your phone.
Use and Care
9

essentials

Caution:
time, read the Important Safety and Legal information included in the gray-edged pages at the back of this guide.
Before using the phone for the first

about this guide

This guide shows how to locate a menu feature as follows:
Find it: M > u >
This means that, from the home screen:
1
Press the menu key M to open the
Settings
menu.
essentials
10
Phone Calls
2
Press the navigation key to scroll to
Phone Calls
select it.
symbols
, and press the center key r to
This means a feature is network or subscription dependent and may not be available in all areas. Contact SouthernLINC Wireless for more information.
This means a feature requires an optional accessory.

SIM card

insert the SIM card
Turn off your phone and remove your battery before you install or remove a SIM card.
Carefully slide the SIM card into your phone, until it lies flat in the SIM card holder.
Warning :
remove your SIM card from your phone unless absolutely necessary.
To avoid loss or damage, do not

battery

Battery Use & Battery Safety
• Motorola recommends you always use Motorola-branded batteries and chargers.
damage caused by non-Motorola batteries and/or chargers.
Caution:
or charger may present a risk of fire, explosion, leakage, or other hazard. Improper battery use, or use of a damaged battery, may result in a fire, explosion, or other hazard.
Battery usage by children should be supervised.
The warranty does not cover
Use of an unqualified battery
essentials
11
• Important
: Motorola mobile devices are designed to work best with qualified batteries. If you see a message on your display such as
Battery
or
Unable to Charge
, take the
following steps:
Remove the battery and inspect it to confirm that it bears a Motorola “Original Equipment” hologram;
If there is no hologram, the battery is not a qualified battery;
If there is a hologram, replace the battery and retry charging it;
If the message remains, contact a Motorola Authorized Service Center.
New batteries or batteries stored for a long time may take more time to charge.
• Charging precautions:
your battery, keep it near room
essentials
12
Invalid
When charging
temperature. Never expose batteries to temperatures below 0°C (32°F) or above 45°C (113°F) when charging. Always take your mobile device with you when you leave your vehicle.
When storing your battery, keep it in a cool, dry place.
It is normal over time for battery life to decrease, and for the battery to exhibit shorter runtime between charges or require more frequent or longer charging times.
• Avoid damage to battery and mobile device.
Do not disassemble, open, crush, bend, deform, puncture, shred, or submerge the battery or mobile device. Avoid dropping the battery or mobile device, especially on a hard surface. If your battery or mobile device has been subjected to such damage, take it to a Motorola
Authorized Service Center before using.
Do not
attempt to dry it with an appliance or heat source, such as a hair dryer or microwave oven.
• Use care when handling a charged battery:
inside a pocket, purse, or other container with metal objects. Contact with metal objects (e.g., jewelry, keys, beaded chains) could complete an electrical circuit (short circuit), causing the battery to become very hot, which could cause damage or injury.
Promptly dispose of used batteries in accordance with local regulations. Contact your local recycling center for proper battery disposal.
Warning:
because they may explode.
Particularly when placing it
Never dispose of batteries in a fire
battery installation
1
Rotate the release lock counter­clockwise until it releases the battery door.
2
Remove the battery door.
essentials
13
3
Push the battery down until it snaps in place.
4
Replace the battery door and press it gently until you hear a click.
essentials
14
battery charging
New batteries are not fully charged.
charge using the charger
1
Pull out the connector cover, and insert the charger into the accessory connector on your phone as shown.
2
Plug the other end of the charger into the appropriate electrical outlet.
When you charge the battery, the battery level indicator at the upper right of the screen shows charging progress. At least one segment of the indicator must be visible to ensure full phone functionality while charging.
Tip:
Motorola batteries have circuitry that protects the battery from damage from overcharging.
Note:
This handset complies with environmental energy consumption requirements by notifying the user to unplug the charger from the power outlet when the charger is disconnected from phone/power outlet. This notice can be dismissed permanently by pressing
-
under No.

turn it on & off

To turn on your phone, press and hold
W
for a few seconds or until the display turns on. If prompted, enter your four-digit unlock code.
To turn off your phone, press and hold two seconds.
Note:
If you press the W for more than four
seconds, the handset will power “On” in
Transmitters Off
phone’s transmitters when powering up, hold the power key for less than 4 seconds. To power up the phone normally from charging mode, wait until the displayed, and then press the power key. See “transmitters” on page 49.
mode. To avoid deactivating the
Charger Attached
W
screen is
for

enable security

You must enable security the first time you power on you phone or within 10 days of first activation of your phone.
1
Press - under Ok.
2
Your are prompted to enable security. Press
-
under
Yes
. A series of screens
essentials
15
followed by the default home page displays.
3
Press o to return to the home screen.

make a phone call

Enter a phone number and press O to make a call or use a voice command. See “place a call using voice name” on page 55.
Tip:
For best performance avoid touching the
antenna with your fingers during the call. To hang up press
o
.

answer a phone call

When your phone rings and/or vibrates, you have the following options:
1
If you want to answer the call on speaker phone, press the speaker key up press the smart key
essentials
16
(
.
)
. To hang
2
If you want to answer the call using the handset, press
3
If you are using a Bluetooth headset, you can press the answer key on your Bluetooth headset. To hang up press the same key on your Bluetooth.
O
. To hang up press o.

make a InstantLINC Mobile to Mobile call

With InstantLINC Mobile to Mobile calls, you use your phone as a long-range, digital 2-way radio using one-to-one InstantLINC Mobile to Mobile calls or one-to-many Talkgroup calls.
Your LINC ID is the number at which you receive one-to-one InstantLINC Mobile to Mobile calls.
Talkgroup numbers are numbers through which you receive one-to-many group calls.
to make a InstantLINC Mobile to Mobile call
1
Enter the LINC ID you want to call.
2
Press and hold the PTT button. Begin talking after your phone emits a chirping sound.
3
Release the PTT button to listen. To end the call press
Note:
An InstantLINC Mobile to Mobile call ends automatically if there is no activity on the call for a few seconds.
o
.
send call alerts
Sending a call alert discretely lets the recipient know that you want to talk to him or her on a InstantLINC Mobile to Mobile call.
When you send a call alert, the recipient’s handset displays your name and emits a series of beeps or vibrations.
The recipient has the following options:
Option
Answer
: Begin a InstantLINC Mobile to
Mobile call with the sender.
Queue
: Store the call alert to the call alert
queue.
Clear
: Dismiss and delete the call alert.
to send a call alert
1
Enter the LINC ID you want to call as you would when making a InstantLINC Mobile to Mobile call.
2
Press - under
When the message the display, press the PTT button until the message
Alert Successful
Alert
.
Ready To Alert
appears.
appears on
essentials
17

answer a InstantLINC Mobile to Mobile call

1
When your phone emits a chirping sound or vibrates to indicate you are receiving a InstantLINC Mobile to Mobile call, wait for the caller to finish speaking.
2
Press and hold the PTT button and begin talking after your phone emits a chirping sound.
3
Release the PTT button to listen. To end the call press
answer a call alert
When you receive a call alert, you must answer, queue, or clear it. You cannot receive phone calls or InstantLINC Mobile to Mobile calls until you do.
essentials
18
o
.
to answer a call alert
1
Press the PTT button to start a InstantLINC Mobile to Mobile call with the sender.
2
Queue the call allert by pressing - under
Queue
. or Clear the call alert by pressing
Clear
.
-
under

store a phone number or LINC ID

You can store a phone number or LINC ID in
Contacts
.
Find it: M > L >
1
Enter a name for the new entry. Each entry’s name can contain 20 characters.
2
Select a specific
[New Contact]
Ringer
.
.
3
Select a type for the entry (
Work1, Work2, Home, Email, Fax, Pager, Talkgroup HUB, IP
or
Other
)
. To store a LINC ID choose
LINC ID
.
4
Enter the number for the entry and press
-
under
Done
.
Tip:
Before saving the entry, you can save more information. You can store an Email address, IP addresses, and more. You can also choose a special ringer.
After you have saved the number, the new Contacts entry is displayed.
Mobile, LINC ID

call a stored phone number or LINC ID

Shortcut:
under
From the home screen press -
Contcs
.
or
,
Find it: M > L.
,
1
Scroll to the
Tip:
By pressing the first letter of the name of the taken to all the contact names starting with the letter you pressed.
2
If the Contacts entry contains more than one number, scroll left or right until the type of the number you want to call is displayed ( etc.).
3
If you chose a phone number, press O to call the entry.
or If you chose a LINC ID or Talkgroup ID,
press and hold the PTT button to call the number.
Tip:
If the Contacts entry you scrolled to
contains a LINC ID, you can make an
Contacts
Contacts
Mobile, LINC ID, Work1, Work2, Home
entry.
you want, you will be
,
essentials
19
InstantLINC Mobile to Mobile call to that LINC ID by pressing and holding the PTT button, even if the LINC ID is not the type of number displayed.

your phone number and LINC ID

Find it: M >
Tip:
Want to see your phone number or LINC
ID while you’re on a call? Press
My Info
.
M
>
My Info
.

text messages

Your phone sends text messages using Mobile Originated Short Messaging Services (MOSMS) and receives text messages from other phones that are using MOSMS.
essentials
20
set it up
Before you begin using text messaging, you may need to set up your signature, service center number, and expiration information.
Shortcut:
under or
Find it: M > E >
Setup
The following options become available:
option
Signature
characters long).
Delivery Rpt
report once the message has been delivered.
From the home screen press -
Mesg
>
Text Inbox
> M >
Text Inbox
.
: Enter your signature (up to 11
: Set it to
On
Text Msg Setup
> M >
if you wish to receive a
.
Text Msg
option
Srvc Cntr No
service center. If you do not know this number, contact SouthernLINC Wireless.
Expire After
messages you send are saved at the service center if they cannot be delivered. After this period, they are discarded.
Cleanup
phone to delete sent messages. If you select
the number of days after which sent messages are deleted or the number of messages to be kept.
Press - under you entered.
: Enter the phone number of your
: This is the amount of time
: Set this option to On if you want your
Cleanup
, select
Clean Up After
Done
to save the information
to set
receive a text message
1
To view the message press - under
Read
2
To dismiss the message notification press
-
under
Back
.
Note:
If your phone is powered off when you receive a text message, your phone notifies you the next time you power it on. If you are out of your coverage area, your phone alerts you when you return to your coverage area.
Tip:
While reading a text and numeric message that contains a phone number, you can press
O
to call that number.
read from the Message center
1
From the home screen press - under
Mesg
>
Text Inbox
.
2
Select the message you want to read or press the number of the message you want to read. If the message fills more than one screen, scroll to read it.
Tip:
Scrolling through one message lets
.
you view the next message.
essentials
21
3
To reply to the message, press - under
Reply
or to see all other choices, including forwarding and deleting the message, calling the sender, or storing the sender’s number in
Contacts
, press M.
create and send text messages
1
From the home screen press - under
Mesg
>
[Create Message]
or You can also create a text message from
the
Text Inbox, Text Outbox
2
To address the message use the keypad to enter the phone number of the person you want to send the message to and press
r
.
3
Select
Msg
and enter the text of the message or to use a quick note press under
Browse
you want and press
essentials
22
.
, or
Drafts
.
-
and scroll to the quick note
r
.
4
Press M >
Fax, x400, Paging, Email, ERMES
5
If you want to send the message, press
-
under
without sending it, press
Note:
of delivery press
Set Send Method
Send
or to delete the message
If you want to request confirmation
M
>
and select
Delivery Report
use drafts
When you save a message as a draft, it is saved in the drafts folder.
Shortcut:
under
1
2
From the home screen press -
Mesg
>
Drafts
.
Select the draft you want to edit. You also have the choice to create new text messages from this menu.
To edit the fields you want to change, follow step 2 through step 5 in “create and send text messages” above.
, or
-
Voice
.
under
Text
Cancel
> On.
,
.
resend text messages
Shortcut:
under
1
2
From the home screen press -
Mesg
>
Text Outbox
Scroll to the message you want to resend or press the number of the message you want to resend.
Press M >
Re-send
.
.
delete sent text messages
Shortcut:
under
1
2
3
delete all unlocked sent messages
Shortcut:
under
1
From the home screen press -
Mesg
>
Text Outbox
Scroll to the message you want to delete. Press - under Press - under
From the home screen press -
Mesg >
Text Outbox
Press M >
Delete
Yes
Delete All.
.
.
to confirm.
.
2
Press - under
Yes to confirm.

manage memory

Your text inbox, outbox, and drafts folder have a set amount of memory available for storing messages.
The text inbox holds 20 messages. If the text inbox is full, you cannot receive messages until you delete some.
The outbox and drafts folder hold 30 messages each. If the outbox and drafts folder memory is full, you cannot send messages or save drafts until you delete some.
To view the amount of memory available in your text inbox, text outbox, or drafts folder:
1
From the idle screen press - under
2
Scroll to the folder whose available memory capacity you want to view.
3
Press - under
Memory
.
Mesg
.
essentials
23

using your handset as a modem

You can use your handset as a modem (Packet Data only) with a laptop, handheld device, or desktop computer. Circuit Data is not supported. In order to use your handset as a modem, you must create either a wired or wireless connection between your handset and the other device.
To connect your handset wirelessly, you must have a Bluetooth adapter for the other device.
connect via Bluetooth
Use your handset as a modem via Bluetooth. The laptop, handheld device, or desktop computer you want to connect to must have a Bluetooth adapter installed.
Check that the adapter is properly installed, and then follow the specific instructions
essentials
24
outlined in the device’s user guide to connect the device to your handset.
When used as a modem, your handset is enabled for used for small file transfers such as email.
Note:
the iDEN Wireless Data Services software (available separately). For more information on setting up your computer and your handset for Packet Data calls, contact SouthernLINC Wireless.
Data Modem
To use these services, you must install
transfer mode, which is
essentials
25

main attractions

LINC features

With LINC features, your phone can send and receive the following items through InstantLINC Mobile to Mobile calls with other phones that have this capability:
Short text messages
You can choose to send messages, pictures, events, My Info, or Contacts information to
1. Additional charges may apply.
26
1
Pictures Datebook events My Info Contact information
main attractions
1
the LINC ID you are engaged in a InstantLINC Mobile to Mobile call with, LINC IDs on the
Recent Calls
When you make or receive a InstantLINC Mobile to Mobile call, your phone automatically determines whether the phone you are engaged in a InstantLINC Mobile to Mobile call with is able to receive each of these items. Your phone saves this information for as long as the LINC ID is on your Your phone updates the saved information each time you make or receive a call to or from that LINC ID.
You can turn your phone’s ability to send and receive messages, pictures, or events information On and Off.
list, and LINC IDs stored in
Recent Calls
list or is saved in your
Contacts
Contacts
.
.
Note:
You cannot send LINC feature items
during Talkgroup calls.
Contacts Manager
list, the
.
Recent Calls
list, or from the
LINC
send messages
Note:
This feature requires a subscription. Please contacts your sales representative or SouthernLINC Wireless at 1-800-406-0151.
The LINC Messages feature lets you send short text messages through InstantLINC Mobile to Mobile calls.
When you send a message, it appears on the display of the phone you are engaged in the InstantLINC Mobile to Mobile call with.
begin a message and choose a recipient
You can begin a message during a InstantLINC Mobile to Mobile call, from the
begin a message during a InstantLINC Mobile to Mobile call
While in a InstantLINC Mobile to Mobile call, press
M
>
LINC Features
Note:
The first time you send a message,
Messaging Fees May Apply. Continue?
are prompted to respond. Press to acknowledge the message.
begin a message from the Contacts or the Recent Calls list
1
From the select the entry containing the LINC ID you want to send the message to.
2
Press M >
Contacts
>
LINC Message
or the
Recent Calls
LINC Features
>
main attractions
.
appears and you
-
under
Yes
list,
LINC Message
.
27
begin a message from the LINC Manager
The
LINC Manager
want to send the message to from the
Recent Calls
Find it: M >
Then select of entries from the that can receive messages.
lets you select the LINC ID you
Contacts
list.
LINC Manager
A Contact
or
A Recent Call
Contacts
>
LINC Message
or the
.
to see a list
Recent Calls
or
list
create messages
After you have begun a message and chosen a recipient, a screen appears that lets you create the text of the message you want to send. Your message may be up to 400 characters long.
You can choose from a list of ready-made words or short phrases called Quick Notes. You can use a Quick Note as it is or edit it before you send it. Editing a Quick Note
main attractions
28
changes the Quick Note for this message only and will not change the Quick Note on the list.
send a completed message
After you have completed your message, press the PTT button to send it.
receive messages
When you receive a message, a message notification appears on the display.
To view the message press To dismiss the message press
Dismiss
.
-
under
-
under
View
.
reply to a message
1
View the message.
2
Press - under
3
Create the message and press the PTT button to send it.
Reply
.
send pictures
Note:
This feature requires a subscription. Please contacts your sales representative or SouthernLINC Wireless at 1-800-406-0151.
You can send pictures stored in the through InstantLINC Mobile to Mobile calls. The picture you send appears on the Private call recipient’s display.
If the recipient accepts the picture, their phone saves the picture. The picture then appears in that phone’s recent call list.
The first time you send a stored picture after turning the phone on,
Continue?
appears and you are prompted to respond. You are charged only once for that picture.
Note:
You cannot make or receive InstantLINC Mobile to Mobile calls while transmitting or receiving a picture.
Picture Fees May Apply.
My Pictures
send a picture during a call
1
While in a InstantLINC Mobile to Mobile call, press
LINC Features
A list of pictures that can be included in a InstantLINC Mobile to Mobile call appears.
2
Select the picture you want to send.
3
Press the PTT button to send the picture.
4
Wait while the picture is transmitted. The InstantLINC Mobile to Mobile call is temporarily interrupted while a picture is transmitted.
5
When prompted, press the PTT button to resume the InstantLINC Mobile to Mobile call.
Note:
After you send or receive a picture via PTT with a user, that picture will be displayed every time you are in a private call with that
-
under
>
LINC Picture
or press M >
.
main attractions
29
user. That picture is saved in the media center and a link is created between that contact and the picture.
Note:
Pictures sent or received may be up to
130x130 in size and up to 100 kb.
start a call by sending a picture
from My Pictures:
Find it: M >
1
Select the picture you want to send.
2
Press M >
3
Select A list of contacts that have LINC IDs and
are able to receive pictures appears.
4
Select the name of the person you want to send the picture to.
5
Press the PTT button to send the picture.
30
My Pictures
LINC View
.
A Contact
or
A Recent Call
main attractions
.
6
When prompted, press the PTT button to resume the InstantLINC Mobile to Mobile call.
from the LINC Manager:
Find it: M >
1
Select A list of contacts that have LINC IDs and
are able to receive pictures appears.
2
Select the name of the person you want to send the picture to.
3
Select the picture you want to send.
4
Press the PTT button to send the picture.
5
Once picture has been sent, when prompted press the PTT button to resume the call.
LINC Manager
A Contact
or
A Recent Call
>
LINC Picture
.
.
receive a picture
When someone sends you a picture, your phone emits a tone or vibrates and a message appears asking if you want to accept the picture.
Pictures you receive are saved to your phone’s memory. They are accessible through
Pictures
.
When you see a message asking if you want to accept the picture, press to decline.
Tip:
If you want to stop the transmission
before it is finished, press
Note:
The first time you accept a stored
picture after turning the phone on,
May Apply. Continue?
prompted to respond. Press accept the picture.
appears and you are
Yes
to accept or No
o
.
-
Picture Fees
under
My
Yes to
clear a picture from the display
If you want to clear a picture from your phone’s display while still on a call, press >
Clear Screen
The picture will not appear on the display again the next time you receive a call from person who sent it. This does not delete the picture from
.
My Pictures
.
M
send my info
1
While in a InstantLINC Mobile to Mobile Call press the PTT button to send.
or
2
From the home screen press M > > M > button to send.
M
>
LINC View My Info
LINC View My Info
, and push
My Info
and push the PTT
main attractions
31
set my info sending option
You can control what portion of the information in sent automatically in every call or only when you choose to send it.
Find it: M >
>
Info to Send
1
Select or remove the fields you want to send.
2
Press - under
The information your phone sends always includes
Line 1,
Line 2, Carrier IP
on your sending options.
automatic sending
To control whether you send your information automatically:
Find it: M >
>
Auto Send
32
My Info
is sent and whether it is
LINC Manager
.
Done
.
My Name
and
LINC ID
, and
Circuit Data
LINC Manager
.
main attractions
>
Configure
>
LINC My Info
. You may also send
, depending
>
Configure
>
LINC My Info
1
Select On or
2
When you make a call in which your information is sent automatically, the name you entered in the
My Info
recipient’s phone, even if your name and LINC ID are not stored in the recipient’s Contacts.
Off
.
appears on the display of the
send contact information
1
While in a InstantLINC Mobile to Mobile call press
2
Select information you want to send.
3
Push the PTT button to send. or
1
From the home screen press M >
Manager > LINC Contact
M
>
LINC Contact
LINC Features
and select the contact
.
My Name
.
field of
LINC
2
Enter the LINC ID number of the person you want to send the Contact information to or press
3
Select from
4
Select the contact information you want to send and push the PTT button.
-
under
Browse
Recent Calls, Contacts
.
, or
Memo
.
turn PTT features on and off
You can turn your phone’s ability to send and receive messages, pictures, and datebook events on and off.
You cannot turn your phone’s ability to send and receive My Info and contact information on and off.
Find it: M >
Features
1
Check or uncheck
Events
LINC Manager > Configure > On/Off LINC
.
Messages, Pictures
.
and/or

one touch PTT

Find it: M >
PTT
.
One Touch PTT sets your phone to do any of the following each time you press the PTT button from the home screen:
option
Off
: Nothing happens when you press the
PTT button from the home screen.
Last Call
Group on the recent calls list.
Assigned No.
the number using your keypad, or press under
Memo
.
If you are entering a Talkgroup number, press
LINC Manager
manager” on page 34.
LINC Manager > Configure
: Call the most recent LINC ID or
: Call a LINC ID you assign. Enter
Search
. Select
#
before the number.
: Go to LINC Manager. See “LINC
Contacts, Recent Calls
>
One Touch
, or
-
main attractions
33
option
LINC Message
message. See “send messages” on page 27.
LINC Picture
pictures. See “send pictures” on page 29.
LINC Event
datebook event.
LINC My Info
Info. See “send my info” on page 31.
LINC Contact
contact. See “send contact information” on page 32.
: Go to the first screen to send a
: Go to the first screen to send
: Go to the first screen to send a
: Go to the first screen to send My
: Go to the first screen to send a
1
Select
LINC Message, LINC Picture, LINC Event, LINC
My Info
, or
LINC Contact
PTT item you are sending, select a contact and press the PTT button to send.
or
2
Select Configure
LINC My Info, One Touch PTT
. After choosing what
to configure your
, or
On/Off LINC Features
LINC Notes

bluetooth®

Your handset supports the use of wireless Bluetooth headsets.
Find it: M >
Bluetooth
.
,
.

LINC manager

The
LINC Manager
features, and other InstantLINC Mobile to Mobile call features, from the main menu.
Find it: M >
34
lets you quickly access LINC
LINC Manager
main attractions
.
turn Bluetooth On or Off
You can turn your phone’s Bluetooth feature on or off. While Bluetooth power is on, your phone can communicate with other devices.
Find it: M >
1
Select On to power Bluetooth On.
Bluetooth > Setup > Power
.
2
Select
Name
if you wish to assign a name
to your handset.
3
Select
Find Me Time
amount of time in which your handset can be found by other Bluetooth devices.
Tip:
You can turn off Bluetooth if you want to prolong battery life or if you enter an area where Bluetooth is prohibited.
to determine the
make a Bluetooth connection
connect your handset with a Bluetooth headset
Find it: M >
1
Follow the instructions on your Bluetooth headset to set it up to be found.
2
Once your Bluetooth headset is set to be found press phone will scan the Bluetooth headset until it finds it. Press
Bluetooth > Hands Free > [Find Devices]
r
on your handset. Your
r
when you see
the name of the Bluetooth headset on your screen.
3
Your handset requires that you create a bond in order to connect with a Bluetooth headset. Press are prompted to bond with the headset.
4
Enter the Bluetooth pass key. Some Bluetooth devices ship with
Bluetooth PINs. Please refer to your Bluetooth device’s user guide to locate this information.
If a device ships without a Bluetooth PIN,
.
then you can enter any PIN for that device. To establish a connection to that device, enter the same PIN for both your phone and the device. For example, if you enter 1234 as the device’s PIN, then enter 1234 as your phone’s PIN.
5
Press - under Ok.
-
under
Yes
when you
main attractions
35
Note:
This handset offers bluetooth auto pair
feature with auto pair compatible Motorola devices. When bonded via bluetooth with a certain device, the pin will not be required
connect your handset with another Bluetooth device
Find it: M >
1
Select the device you want from the list of found devices on your screen.
2
Create a bond if you are prompted to do so.
Tip:
If you have previously connected to a device, the device will be stored on your phone so you can connect with it easily.
Bluetooth > Link To Devices
.
use Bluetooth during a call
You can connect with available Bluetooth devices during a call.
main attractions
36
Note:
If the
Handsfree Devices
one device, then your phone will automatically try to connect to that device.
1
While in a call, press M >
2
Press - under Bluetooth.
3
Select the audio device you want to connect to from the list of
list contains only
Yes
to power On
Use Bluetooth
Handsfree Devices
.
send information via Bluetooth
You can use your handset to send contacts entries, or datebook events to another Bluetooth device.
The receiving device must be within 32 feet (10 meters) of your phone in order to connect with yours.
Note:
Files sent or received may be up
to 200 kb.
.
send Contacts
Shortcut:
under
1
2
3
From the home screen press -
Contcs
. Select the contact you want to send. Press M > Press - under
Send Via...
Yes
>
Bluetooth
.
to power On
Bluetooth.
4
Select the device you want to transfer the contact information to.
or Search for the device by selecting
Devices]
.
5
If prompted, bond with the device. Your phone connects with the devices and
transfers the contact.
send a Datebook event
Find it: M >
Datebook
[Find
1
Select the datebook event you want to send.
2
Press M >
Send Via...
>
Bluetooth
.
If the event you select repeats, then you will be prompted to choose whether to send the selected instance of the event or all instances of the event.
To send only the selected instance of the event, select
This Event Only
. or To send all instances of the event, select
Repeat Events
3
Press - under
.
Yes
to power On
Bluetooth.
4
Select the device you want to transfer the contact information to.
or
main attractions
37
Search for the device by selecting
Devices]
.
5
If prompted, bond with the device. Your phone connects with the device and
sends the datebook event.
[Find

advanced features

Note:
These features may not be offered by SouthernLINC Wireless. For additional intrinsically safe information, please consult the FM Supplement manual that is included with the i365IS.
group calls, talkgroups, and hubs
A group call is similar to a private call, but is made to all members of a Talkgroup at once. A Talkgroup is a predetermined group of your
38
main attractions
service provider’s customers. A hub consists of 1 to 4 Talkgroups.
You must join a Talkgroup to make or receive calls on that Talkgroup. On your phone, you join a Talkgroup by joining the hub it belongs to.
On your phone, all group calls you make are hub calls. Group calls you receive are hub calls or Talkgroup calls to Talkgroups in the hub you have joined.
Your sales representative or your service provider establishes Talkgroups and hubs for you. You can choose a name for each when you create entries for them in Contacts.
join a hub
1
Press #.
2
Enter the hub number using the keypad. or
Scroll to the hub name in Contacts or recent calls list.
3
Press - under
Join
.
create a talkgroup hub
1
Begin creating a new Contacts entry. See “store a phone number or LINC ID” on page 18.
2
Assign the hub Contacts type to the entry.
3
Assign the Talkgroup number as the number of the hub.
This creates a hub with the same number as the Talkgroup it contains. You cannot add any more Talkgroups to this hub.
view hub details
1
From the recent calls list, scroll to the hub.
2
Press M.
3
Select Hub Details
.
Find it:
M > Select Details
.
make group calls
1
Press #. Enter the hub number using the keypad.
or Scroll to the hub name in Contacts or
recent calls list.
2
Proceed as if making a InstantLINC Mobile to Mobile call.
receive group calls
When you receive a group call, the following appears on the screen:
The name of the hub
The name or number of the primary Talkgroup in the hub
The private number of the person speaking
To answer a group call:
main attractions
39
Proceed as if answering a InstantLINC Mobile to Mobile call. Only one person at a time may speak on a group call.
set talkgroup scan
1
From the main menu, select u >
InstantLINC > Scan
2
Scroll to On.
3
Press r.
To set your phone to receive group calls only from the primary Talkgroup in a hub:
Scroll to
Find it:
turn off group calls
1
2
40
M > Call Setup > Scan
From the main menu, select u >
InstantLINC > Tkgrp Silent
Scroll to On if you don’t want to hear group calls.
or
main attractions
.
Off
in step 2.
.
.
Scroll to
3
Press r.
Note:
from hearing emergency group calls.
emergency group calls
An emergency group call is a hub call that takes priority over all other phone activities in the phone making the call and sounds a special emergency tone in the phones receiving the call.
When you make an emergency group call, a group call is made using a designated emergency hub or the hub you currently belong to.
A designated emergency hub must be created for you by SouthernLINC Wireless and is stored on your SIM card.
If no designated emergency hub has been created for you, emergency group calls you
Off
if you want to hear group calls.
Setting
Tkgrp Silent
to On prevents you
make are made using the hub you currently belong to. If no designated emergency hub has been created for you and you have not joined a hub, you cannot make emergency group calls.
make an emergency group call
Caution:
Making an emergency group call ends all other activity on your phone, including 911 emergency calls.
To make an emergency group call:
1
Press and hold ( for 3 seconds to start the emergency group call.
2
Press and hold the PTT button on the side of your phone to talk. Begin talking after your phone emits a chirping sound.
3
Release the PTT button to listen.
To end an emergency group call:
Press and hold ( for 3 seconds.
An emergency group call automatically ends if there is no activity for 30 seconds.
Emergency group calls you make or receive do not appear in the recent calls list.
receive an emergency group call
When receiving an emergency group call, your phone sounds a special emergency tone, unless your phone is set to make no sounds.
To answer an emergency group call:
Proceed as if answering a InstantLINC Mobile to Mobile call.
isolated operation
Isolated Operation lets you continue to make and receive group calls on the hub you last used, within a limited coverage area, even if you lose network coverage.
When you lose network coverage during a phone call, InstantLINC Mobile to Mobile call, group call, or data transfer, the call or data
main attractions
41
transfer ends. But you can make and receive new group calls on the hub you last used.
If the
One Touch PTT
would prevent you from making group calls on the hub you last used, these setting are overridden while your phone is in Isolated Operation.
Caution:
calls in Isolated Operation, even if the hub you last used is the designated emergency hub. You must have network coverage to make emergency group calls.
If the designated emergency hub is the hub you last used when you lost network coverage, your phone treats the hub you used before the designated emergency hub as the hub you last used.
main attractions
42
settings on your phone
You cannot make emergency group
call alert status messages
You can send call alerts that include text messages up to 10 characters long. These messages are stored on your SIM card when your receive your phone. There are 10 you can choose from.
If the phone you send the call alert to has this capability, the text message appears on that phone when the call alert is received. If the phone you send the call alert to does not have this capability, the call alert appears without the text message.
send a call alert status message
1
Proceed as you would when sending any call alert.
2
When the choose the text message you want to send:
Ready to Alert
screen appears,
Scroll left or right to display the message you want to send.
or Press
-
under
Select
to view all messages
and select the one you want to send. or Press the number on you keypad
associated with the message you want to send. Press 1 and then 0 to choose message 10.
3
Press the PTT button until
Alert Successful
appears on the display.
receive a call alert status message
When you receive a call alert that includes a text message, the text message appears as the part of of the call alert information when you receive the call alert and in the recent calls list.
main attractions
43
main attractions
44

basics

1.
2.
3.
4.
5.
6.
7.
SouthernLINC
10:05 am 4/17
Contcs
Mesg
See page 1 for a basic phone diagram.

display

The home screen shows when you turn on the phone. To dial a number from the home screen, press number keys and
Note:
Your home screen may look different.
Date and
Time
Left Soft
Key Label
SouthernLINC 10:05 am 4/17
Contcs
Mesg
O
.
Right Soft Key Label
Soft key labels show the current soft key functions. For soft key locations, see page 1.
status indicators
Status indicators are shown at the top of the home screen:
1 Signal Strength Indicator:
show the strength of the network
Vertical bars
basics
45
connection. You can’t make or receive calls when
2 Active Phone Line:
1 is ready to make calls; 2 indicates phone line 2 is ready to make calls.
3Speaker On/Off
InstantLINC Mobile to Mobile calls and Talkgroup calls can be set to come through the earpiece rather than through the speaker.
4 Ringer Vibe/Off:
ring.
5 Message Indicator:
you receive a text message.
6 Packet Data:
transfer packet data or is transferring packet data when it shows a blinking arrow.
46
basics
1
or 0 shows.
1 indicates phone line
: Sounds associated with
Your phone is set to not
Shows when
Your handset is ready to
7 Battery Charge Indicator:
indicates a greater charge. Recharge the battery when your phone shows
A fuller battery
Low Battery

main menu

All your phone’s features can be accessed through the main menu. You can set the main menu to appear as
Find it: M > u >
List View
Display/Info
or
Icon View
>
Menu View
.
.

text entry

Some features let you enter text. Your phone provides convenient ways to enter
words, letters, punctuation, and numbers whenever you are prompted to enter text (for example, when adding a Contacts entry or when using Text Messaging).
.
change the character input mode
1
When you see a screen where you can enter text, press character input mode.
2
Select one of the following options:
entry method
Alpha
Word
Symbols Numeric
Tip:
to change letter capitalization (
Press a key several times for different characters.
Enter words using a predictive text entering system that lets you enter a word with fewer key presses.
Enter symbols. Enter numbers by pressing the
numbers on the keypad.
When entering text, press and hold #
M
to change the
Abc
>
ABC
>
abc
word method
The Word English text input method lets you enter text into your phone by pressing keys just once per letter.
The Word English text input method combines the groups of letters found on each phone key with a fast-access dictionary of words, and recognizes what you want to text as you type. It first offers the most commonly­used word for the key sequence you enter and lets you access other choices with one or more presses of the
enter a word using “word” character input method
1
Select the
2
Press the corresponding keys once per letter to enter a word (for example, to
).
enter the word
0
key.
Word
character input method.
Bill
, press
2455
).
basics
47
If you make a mistake, press - under
Delete
or * to erase a single character. Press and hold delete an entire entry.
3
To accept a word and insert a space, press
#
To accept a word completion (such as Billion when you entered Bill), press right.
If you get a word you don’t want, you can press the choices and pick the one you want.
-
under
Delete
.
0
key to see more word
or * to
alpha method
To enter characters by tapping the keypad:
1
Select the
2
Press the corresponding keys repeatedly until the desired letter appears. (For example, to enter the word
48
basics
Alpha
method.
Bill
, press 2
twice,
4
three times, 5 three times,
and
5
three times again.
If you make a mistake, press
Delete
to erase a single character. Press and
hold
-
under
Delete
to erase an entire
entry.
By default, the first letter of an entry is capitalized and the following letters are lowercased. After a character is entered, the cursor automatically advances to the next space after two seconds or when you enter a character on a different key.
Characters scroll in the following order:
characters
1
2 3 4
Space . 1 ? ! , @ & : ; “ - ( ) ‘ ¿ ¡ % £ $ ¥
A B C 2 Á Ã Â À Ç D E F 3 É Ê È G H I 4 Í Ì
-
under
characters
5 6 7 8 9 0 # *
J K L 5 M N O 6 Ñ Ó Õ Ô Ò P Q R S 7 ß T U V 8 Ú Ü Û Ù W X Y Z 9 + - 0 * / \ [ ] = > < # § Space Back

navigation key

handsfree speaker

You can use your phone’s handsfree speaker to make calls without holding the phone to your ear.
During a call, press the speaker key turn the handsfree speaker On.
The handsfree speaker stays on until you press
)
again.
Note:
The handsfree speaker won’t work when your phone is connected to a handsfree car kit or headset.
)
to
Press the navigation key
up, down, left, or right to scroll to items in the display. When you scroll to highlight the desired item, press
r
.

transmitters

Note:
Consult airline staff about the use of the Transmitters Off feature during flight. Turn off your phone whenever instructed to do so by airline staff.
basics
49
Transmitters Off turns off your phone’s calling features in situations where wireless phone use is prohibited, but you can use the phone’s other non-calling features when Transmitters is turned Off.
Find it: M > u >
Advanced > Transmitters > Off
.

use GPS with map software

Your phone is enabled with a highly-capable GPS receiver that sends location information to a USB port on a PC, laptop, or PDA.
Note:
No serial port connectivity is provided by your phone. Applications on the host device which are expecting to receive the GPS location information via a serial port must instead use a Virtual Serial Comm Port.
The data sent to the host device is formatted as prescribed in the National Marine
basics
50
Electronics Association 0183 V3.0 (NMEA-
0183) standard. As such it supports the following sentences: GGA, GLL, GSA, GSV, RMC, and VTG.
This handset is not a full NMEA-0183 compliant device supporting electrical RS-422/ RS-232 connectivity as dictated by the NMEA­0183 standard. Consequently it's unsuitable for conventional marine NMEA-0183 equipment use. Its intended use is for normal "terrestrial" mobile users who want to enable their USB hosting computing devices such as a PC, laptop or PDA with the phone's highly­capable GPS functionality.
get connected
1
Open the phone's bottom connector and insert a cable into the phone's bottom connector.
2
Insert the other end of the cable into a vacant USB receptacle of your host
device. A virtual USB Comm Port will be created on your host device upon successful enumeration of the phone as a USB Communications Device Class device.
3
Ensure no application in your host device is using the created COMM port. You may need to ensure that the created virtual COMM port settings are set as follows:
• Bits per second
•Data bits
• Parity
: None
•Stop bits
• Flow control
4
Start the GPS application on your host
: 4800
: 8
: 1
: None
device. Set the GPS application to start accepting NMEA-0183 formatted data from the created Virtual COMM port.
5
Set your phone to start sending NMEA­0183 formatted location information.
Find it: M >
GPS > Interface > NMEA OUT > On
.
Your phone is now actively sending location NMEA-0183 formatted GPS data to your USB host device.
To stop your phone from sending location data:
Find it: M >
Note:
GPS > Interface > NMEA OUT > Off
.
Each time you power your phone Off, NMEA OUT is automatically set to Off and you need to manually restart it using the menu selections above.
Your USB host device will generally provide charging power (5V, up to 500mA) to your phone via the cable therefore no other charging power to it will normally be required. However some laptops may require that you provide external AC/DC power to the laptop in
basics
51
order for it to provide full 500mA charging current capability to the phone.
basics
52

calls

To make and answer calls, see page 16.

turn off a call alert

You can press the volume keys to turn off a call alert before answering the call.

recent calls

The recent calls list contains information associated with calls you have made and received and call alerts you have received.
When you send or receive InstantLINC Mobile to Mobile calls, the recent call list contains the following items with those calls:
contact information received
My Info received
short text messages received
pictures sent or received
datebook events received
The recent calls list displays up to 20 of the most recent calls and call alerts.
1
Press M >
2
Scroll through the list.
Recent Calls
.
store an item to contacts from recent calls
Phone calls, InstantLINC Mobile to Mobile calls, My Info, or Contacts entries received from other phones can be stored to the Contacts list from the Recent Calls list.
Find it: M >
Recent Calls
.
calls
53
1
Scroll to or select the item you want to store.
2
Press M > as a new entry in the Contacts list.
or If
Save
>
Update Contacts
want to update. Press
3
Press - under
Save
to store the information
is not one or you options, press M
. And select the contact you
r
.
Done
to save your changes.

redial

To redial your last outgoing call, press and hold
O
or push the PTT button if it was a
InstantLINC Mobile to Mobile call.
calls
54

caller ID

Note:
This feature requires a subscription. Please contacts your sales representative or SouthernLINC Wireless at 1-800-406-0151.
Caller ID allows people to identify a caller before answering the phone by displaying the number of the incoming call. If you do not want your number displayed when you make a call, just follow these easy steps.
To block your phone number from being displayed for a specific outgoing call:
1
Press
*67
2
Enter the number you want to call.
3
Press
O
To permanently block your number, call SouthernLINC Wireless at 1-800-406-0151.
.
.

call forward

Call forwarding sends calls to the phone numbers you specify. You can forward all calls to one number or forward missed calls to different numbers depending on the reason you missed the call. You can forward phone lines 1 and 2 independently.
Find it: M >
1
To forward all calls select
To
to enter the phone number you want all
your calls forwarded to. or
2
You can specify a forwarding number for each type of missed call by selecting
Detailed
If Busy
transferring data.
If No Answer
the first 4 rings.
Call Forward
and chosing the following options:
: When your handset is on a call or
: When you do not answer on
.
All Calls
and select
If Unreachable
coverage or powered off.
: When your handset is out of

voice names

You can place calls by speaking comands to your phone if you have previously assigned a voice name to your contacts.
assign voice names to contacs
1
Press - under
Contact]
.
2
Assign a name, phone number and select
[Options]
.
3
Select
Voice Name
record the voice name.
4
Press - under
place a call using voice name
1
Press the speaker key ) until you are prompted to say the voice name.
Contcs
and select
and follow the prompt to
Back
and - under
[New
Done
.
calls
55
The handset will automatically place the call.

emergency calls

SouthernLINC Wireless may program one or more emergency phone numbers that you can call under any circumstances, even when your phone is locked or the SIM card is not inserted.
Note:
Emergency numbers vary by country. Your phone’s preprogrammed emergency number(s) may not work in all locations, and sometimes an emergency call cannot be placed due to network, environmental, or interference issues.
Your phone supports emergency calling. Emergency phone calls can be made even when your SIM card is blocked or not in your phone.
Dial 911 or your local emergency number to be connected to an emergency response
calls
56
center. If you are on an active call, you must end it before making an emergency call.
When you make an emergency call, your phone’s GPS Enabled feature can help emergency service personnel find you, if you are in a location where your phone's GPS antenna has established a clear view of the open sky and your local emergency response center has the equipment to process location information. Because of the limitations of this feature, always provide your best knowledge of your location to the emergency response center when you make an emergency call.
Note:
Emergency calls cannot be placed
while the keypad is locked.
Note:
If you have not registered on the network, emergency calls cannot be placed while your SIM card is in your phone.

international calls

Note:
This feature requires a subscription. Please contacts your sales representative or SouthernLINC Wireless at 1-800-406-0151.
If your phone service includes international dialing, press and hold 0 to insert your local international access code (indicated by +). Then, press the keypad keys to dial the country code and phone number.

speed dial

Each phone number stored in Contacts is assigned a Speed Dial number, which you can use to call that number.
1
From the home screen, use the keypad to enter the Speed Dial number assigned to the phone number you want to call.
2
Press #.
3
Press O.

turbo dial

The first nine entries in your contacts are set for turbo dial. They can be called by pressing and holding the speed dial number (1 through 9).

voicemail

Note:
To receive voice mail messages, you must first set up a voice mail account with SouthernLINC Wireless.
receiving a message
When you receive a voice mail message,
VoiceMail Message
To call the SouthernLINC Wireless voice mail system and listen to the message:
appears on the display.
New
calls
57
To check voicemail messages: Press the soft key
To dismiss the message notification: Press
r
or - under
If the caller leaves a message, this icon appears on the display, reminding you that you have a new message.
-
under
Back
.
Call
.
y

LINCaround

Note:
This is an optional feature. Go to www.southernlinc.com/downloads or contact SouthernLINC Wireless at 1-800-406-0151 about its availability for purchase.
LINCaround allows direct two-way handset­to-handset communications between two or more handsets equipped for LINCaround. You can make and receive LINCaround calls even when network service is not available. You
calls
58
can talk to anyone on your code and channel within your range.
Note:
Range will vary based on terrain, man-
made structures and atmospheric conditions. LINCaround allows you to use code or private
mode operation, use up to 10 channels and communicate with standalone LINCaround radios.
Note:
LINCaround is not compatible with
older Family Radio Services products. The following features and main menu items
will not be available while in LINCaround mode:
On-network phone calls
On-network InstantLINC Mobile to Mobile calls
Data transmission
Incoming message notification
Musical ring tones
Call forwarding
Messages
Call Timers
Call alerts
Voice records
set your phone to LINCaround
Find it: M >
After a few seconds, the appears. The channel you are set to appears on the first line of the display, the code you are set to appears on the second line of the display and softkeys.
Note:
LINCaround
set appear on the
LINCaround > Go To LINCaround
LINCaround
LA Ready
appears just above the
When switching from the network to
, the last channel and code that were
LINCaround
idle screen.
.
idle screen
While in display, indicating that there is no network signal and
Phones used in LINCaround mode should be a minimum of 6 feet apart to maximize performance and improve transmission range.
LINCaround
LINCaround
, this icon m appears on the
is active.
exit LINCaround
Find it: M >
The following message displays:
Network Please Wait
network idle screen appears.
LA Options > Exit LINCaround
. After a few seconds, the
.
Switching to
channels and codes
Your phone has 10 channels and 15 codes.
Channels
that allow you to make and receive LINCaround calls. Other parties may also be talking on the same channel.
are divided into sets of frequencies
calls
59
Codes
help minimize interference from unwanted messages and other disturbances when you are on the same channel as others.
To have a conversation, all parties must be on the same channel and code. For private LINCaround calls, the person you are calling must be in LINCaround and set to the same channel to receive your call.
Note:
When making a code call, all parties that are on your code and channel can hear your conversation.
set a channel
1
From the LINCaround idle screen, press
- under
2
Scroll to
3
Select a channel number from 1 to 10.
4
When you are finished, press -
Back
Edit
.
Channel
and press - under
under
to return to the LINCaround idle
Edit
.
screen.
calls
60
set a code
1
From the LINCaround idle screen, press
-
under
Edit
.
2
Scroll to
Code
and press -
under
Edit
.
3
Select a code number from 1 to 15 or one of the following options:
option
Receive All
: Sets your phone to receive LINCaround transmissions from any phone that is set to the same channel, regardless of the code (1-15). When you receive transmissions with the code set to
All
, the display changes from
Receive All
Receive
to the code on which the transmission was received.
Tip:
You can reply to an incoming call within 6 seconds after hearing the short ending beep by pressing the PTT button.
Note:
You cannot initiate a code call when the code is set to PTT button with the code set to
Receive All
. If you push the
Receive All
you will receive an error message.
option
Pvt Only
: Allows you to have a private conversation with another person using LINCaround. When on a private LINCaround call, no other parties can hear your conversation. In order to make a private LINCaround Call, you must use the valid 10-digit Personal Telephone Number (PTN) of the person you are calling. The person you are calling must be in LINCaround and set to the same channel to receive your call.
Note:
An error message will occur if you don’t use a valid PTN, or the person that you are trying to reach is not in LINCaround, or is set to a different channel or out of range.
,
4
When you are finished, press -
Back
to return to the LINCaround idle
under
screen.
calls
61
make and receive code calls in LINCaround
To make a code call in LINCaround:
1
Push and hold the PTT button. appears on the first line of display. Begin speaking after your phone emits the LINCaround tone.
2
Release the PTT button to listen.
Note:
The tone emitted from your phone when using LINCaround is 4 beeps and sounds different from the standard tone heard with on-network InstantLINC Mobile to Mobile and Talkgroup calls.
You could receive an error message if there are no parties on your channel or code, or if you are out of range.
When you receive a code call using LINCaround, the display.
62
calls
Receive
appears on the first line of
Transmit
Note:
An incoming LINCaround call can be
terminated at any time by pressing
o
.
make a private LINCaround call
1
Enter the 10-digit PTN of the person you want to call on your channel, or press under
Contacts
and select a contact, or scroll
to a number in the recent calls list.
2
Push and hold the PTT button. Begin speaking after your phone emits the LINCaround tone.
3
Release the PTT button to listen.
The number or name of the person you are calling will appear in the first line of the display.
-
receive a private LINCaround call
1
The number or name of the person who initiated the call will appear in the first line of the display.
2
You can reply within 6 seconds simply by pushing the PTT button.
end a private LINCaround call
A private LINCaround call will end if there is no communication for 6 seconds.
Note:
A private LINCaround call may be interrupted during the 6 second idle time by another code call.
make emergency calls while in LINCaround mode
If you attempt to make an Emergency 911 call while in LINCaround mode, your phone will
automatically exit LINCaround mode and attempt to find a network signal.
Note:
If you are out of network coverage your phone will not be able to make an emergency 911 cellular call until you go back into the network coverage area.
You must wait until the phone reconnects to the network before attempting to make an emergency 911 cellular call.
setup options
LINCaround setup options are available in the
LA Options
LINCaround modes.
access setup options in network
Find it: M >
access setup options in LINCaround
Find it: M >
screen in both network and
LINCaround
LA Options > Setup
>
Setup
.
.
calls
63
The following options become available:
option
Direct Launch
LINCaround when you select the Main Menu. If you will not see
LINCaround
have access to your setup options,
Launch
: Launchs your phone directly into
LINCaround
Direct Launch
LA Options
is set to On,
when you select
from the main menu. In order to
must be set to
Off
. Or you can access
from
Direct
setup options while in LINCaround by pressing
State Tone
tone that you are in
M
and selecting
LA Options
.
: Notifies you periodically with a
LINCaround
mode. You can select a time frame during which you want to be notified that you are in Select from
64
30 minutes, 1, 2, 3
calls
LINCaround
or 4
hours
mode. .

customize

ring tones

To set the ring tone your phone makes when you receive phone calls, call alerts, message notifications, pictures sent using InstantLINC Mobile to Mobile calls, or datebook reminders:
Note:
Only ring tones stored in your phone’s memory are available in the ring tones list. Not all audio files can be assigned as ring tones.
Find it: M >
1
Make sure
2
Scroll through the list of ring tones and select the one you want to assign. sets your phone to vibrate instead of
Ring Tones
Vibrate All
is set to
Off
.
Vibrate
making a sound; neither vibrate nor make a sound.
Tip:
Highlighting a ring tone lets you hear
it.
3
Select the features you want to assign the ring tone to.
4
When you are finished, press - under
Done
.
Note:
This icon M appears on the display if you set your phone to appears on the display if you set the phone to
Vibrate All
.
Silent sets your phone to
Silent
. This icon Q
set your phone to vibrate
You can set your phone to vibrate instead of making a sound when you receive all phone
customize
65
calls, InstantLINC Mobile to Mobile calls, Talkgroup calls, call alerts, messages notifications, pictures sent using InstantLINC Mobile to Mobile calls, and datebook reminders.
Find it: M >
Set this option to Setting this option to
off by pressing the up volume control. Setting this option to hold the up volume control to turn The
Locked
accidentally turning
Tip:
To s et volume controls: Press the volume controls to turn down the volume as far as possible to set
Vibrate All
volume control to set To set your phone to vibrate instead of making
a sound for some features but not others:
66
Ring Tones
Locked
option helps prevent you from
Vibrate All
to On. Continue to hold the down
customize
>
Vibrate All
.
On
or
Locked
.
On
lets you turn
requires you to press and
Vibrate All
off.
to On or
Locked using the
Vibrate All
to
Vibrate All
Vibrate All
Locked
.
off.
Find it: M >
1
2
3
4
Make sure Select Select the features you want to set to
make no sound. When you are finished, press - under
Done
Ring Tones
Vibrate from the list of ring tones.
.
Vibrate All
.
is set to
Off

wallpaper

You can also access downloadable wallpapers from the Wallpaper menu.
Find it: M > u >
1
Select
Wallpaper
2
Scroll through the list of pictures and press
r
choice.
Note:
You can set the wallpapers to change
automatically after a certain period of time by
Display/Info
.
to select the wallpaper of your
>
Wallpaper
.
.
turning on the Wallpaper menu.
If you want more wallpapers, you can download them into your phone for a fee. Check the phone for a catalog of items available for purchase and download.
Auto Cycle
Downloads
feature located in the
menu option on your

backlight

Set the amount of time that the display and java apps. backlights remain on, or turn off the backlight feature to extend battery life.
Find it: M >
Settings
>
Display/Info
>
Backlight

datebook

Find it: M >
Datebook > M
>
Setup
You can view or change these options:
options
Start View
: Sets Datebook to start in day view, week view, or month view when you access Datebook.
Daily Begin
This is the earliest time of day displayed in week view, if you have a 12-hour day view.
Delete After
Datebook waits to delete an event after it occurs.
Time Shift
Datebook events. This is useful if you are traveling to a different time zone.
Alert Timeout
continues to sound when you receive a Datebook reminder.
Clock
appear on the home screen; sets time and date format; sets year.
: Sets the beginning of your day.
: Sets the amount of time
: Lets you shift the times of all
: Sets the amount of time a tone
: Controls whether the time and date
customize
67

hide or show location information

Your phone is equipped with a Location feature for use in connection with location­based services that may be available in the future.
The Location feature allows the network to detect your position. Turning Location off will hide your location from everyone except 911.
Note:
Turning Location on will allow the network to detect your position using GPS technology, making some applications and services easier to use. Turning Location off will disable the GPS location function for all purposes except 911, but will not hide your general location based on the cell site serving your call. No application or service may use your location without your request or permission. GPS-enhanced 911 is not available in all areas.
customize
68
set your privacy options
Find it: M >
Select from the following options:
option
Restricted
applications may view the location of your phone. However, location information may still be available to the phone’s owner, fleet manager, or account administrator.
Unrestricted
location of your phone, without notifying you.
Ask Access
view the location of your phone, you will be prompted to give permission. However, location information may still be available to the phone’s owner, fleet manager, or account administrator.
GPS > Privacy
: No Java or similar software
: All applications may view the
: When an application attempts to
customize
69

other features

advanced calling

feature call waiting
other features
70
To accept the second call and put the active call on hold press
To accept the second call and end the active call press
O
Your phone rings with the second call for you to answer.
-
.
under
Yes
feature 3-way call
.
any key answer
Make or receive a phone call and press the second phone number, press
Tip:
the number, press see the dialing menu.
You cannot make any other calls after you have joined a 3-way call, even if one party disconnects.
To answer phone calls by pressing any key on the keypad press
Phone Calls
M
>
3 Way
. Enter
O
and - under
For quick ways to enter
M
>
Any Key Ans
M
to
> u >
> On.
Join
.

contacts datebook

feature edit/delete
contact entry
set ringer ID
Press - under a contact and press
Edit
. Change the desired
content and press
Done
.
Press - under a contact and press
Edit > Ringer
Select desired ringer, press
r
, and - under
Contcs
. Select
M
>
-
under
Contcs
. Select
M
>
.
Done
.
feature create
datebook events
see datebook event
event reminder
To create a new datebook event press
[New Event]
To see a calendar event press
left or right to see the day and up or down to see the events.
When an event reminder occurs press
Press the reminder.
M
>

Datebook

.
M
>
Datebook
. Press
-
under
-
under
Back
to close
other features
>
View
.
71
feature receive
datebook events via InstantLINC Mobile to Mobile calls
other features
72
To view the information while still in the InstantLINC Mobile to Mobile call press
r
.
The 5 most recent events received from a LINC ID are stored with the that LINC ID on the recent calls list.
To store events to the Datebook press
Save
while viewing the event
you want to store.
-
under
GPS
To improve GPS performance:
Stay in the open
Move away from other electrical or electronic devices
Remain stationary
Avoid touching the antenna with your hands
feature view
approximate location
To see your approximate location press
Position
. Scroll to view the
entire screen. To recalculate position press
Rfrsh
. This may take several
minutes.
M
>
GPS
>
feature set GPS
privacy options
change GPS PIN
To set the level of privacy for your GPS system press >
GPS
>
Privacy
.
If your GPS PIN security feature is enabled, enter your GPS PIN and select the privacy option you want.
Note:
When you receive
your phone, your GPS PIN is
0000. To change your GPS PIN
press
M
> u >
Change Passwds
Enter the current GPS PIN and enter the new 4- to 8­digit GPS PIN. Re-enter the new 4- to 8-digit GPS PIN to confirm.
>
GPS PIN
Security
.
M
>

handsfree

The use of wireless phones while driving may cause distraction. Discontinue a call if you can't concentrate on driving. Additionally, the use of wireless devices and their accessories may be prohibited or restricted in certain areas. Always obey the laws and regulations on the use of these products.
feature speaker-
phone
auto answer
To activate the speakerphone while driving press and hold the speakerphone key
To automatically answer calls when connected to a car kit or headset press >
u
>
Phone Calls
Select the amount of rings before answering.
>
)
M
Auto Ans
.
.
other features
73

personalize pc applications

feature language
backlight time length
menu style
clock display
other features
74
To set the language of your menu press
Display/Info
To select how long the display screen and keypad are backlit press
Display/Info
To display the main menu as graphic icons or a text-based list press
Info
>
To display the clock on the home screen press
u
>
Display > On
M
> u >
>
Language
M
>
Backlight
M
> u >
Menu View
.
Display/Info > Clock
.
.
> u >
.
Display/
M
>
>
feature other PC
applications
TTY
feature turn On TTY
feature
choose TTY mode
For a list of complete PC applications visit: www.motorola.com/support
From the home screen press
M
> u >
>
TTY
>
Use TTY
From the home screen press
M
> u >
>
TTY
>
Type
Select from
> On.
.
TTY, VCO
Phone Calls
Phone Calls
or
HCO
.
feature change the
TTY baud rate
change TTY mode during a call

security

feature phone lock
From the home screen press
M
> u >
>
TTY
>
Baud
Select
45.45
While in the TTY call, press
M
>
In Call Setup
Select from
To lock the phone press M >
u
>
Security
Lock Now
or
.
or
50.00
>
TTY, VCO
>
Auto Lock
Phone Calls
.
TTY
>
or
HCO
Phone Lock
.
Type
.
>
feature keypad lock
.
enable SIM PIN
change SIM PIN
Note:
You can make emergency calls on a locked phone (see page 56). A locked phone still rings or vibrates for incoming calls or messages, but you need to unlock it to answer.
To lock the keypad press M >
u
>
Security
Lock Now
or
Auto Lock
Shortcut:
keypad press To enable SIM PIN, press
M
On
.
To change the SIM PIN, press
Change Passwds
> u >
M
> u >
To lock the
>
M
Security
>
SIM PIN
Keypad Lock
.
> *.
>
SIM PIN
Security
.
>
>
>
other features
75
76
other features
Important Safety and
Legal Information
77

Safety and General Information

Safety Information
This section contains important information on the safe and efficient operation of your phone. Read this information before using your integrated multi-service portable radio.*
Exposure to Radio Frequency (RF) Energy
Your phone contains a transmitter and receiver. When it is ON, it receives and transmits RF energy. When you communicate with your phone, the system handling your call controls the power level at which your phone transmits.
Your Motorola phone is designed to comply with local regulatory requirements in your country concerning exposure of human beings to RF energy.
Portable Radio Product Operation and EME Exposure
Your Motorola radio product is designed to comply with the following national and international standards and guidelines regarding exposure of human beings to radio frequency electromagnetic energy (EME):
Safety Information
78
* The information provided in this document supersedes
United States Federal Communications Commission, Code of Federal Regulations; 47 CFR part 2 sub-part J.
American National Standards Institute (ANSI) / Institute of Electrical and Electronics Engineers (IEEE). C95. 1-1992.
Institute of Electrical and Electronics Engineers (IEEE). C95. 1-2005 Edition.
International Commission on Non-Ionizing Radiation Protection (ICNIRP) 1998.
Ministry of Health (Canada). Safety Code 6. Limits of Human Exposure to Radio frequency Electromagnetic Fields in the Frequency Range from 3 kHz to 300 GHz,
1999.
Australian Communications Authority Radio communications (Electromagnetic Radiation - Human Exposure) Standard 2003.
ANATEL, Brazil Regulatory Authority, Resolution 303 (July 2, 2002) "Regulation of the limitation of exposure to
*
the general safety information in user’s guides published prior to May 1, 2006
electrical, magnetic, and electromagnetic fields in the radio frequency range between 9 kHz and 300 GHz." "Attachment to Resolution 303 from July 2, 2002."
Operational Precautions
To assure optimal radio product performance and to be sure that human exposure to RF does not exceed the guidelines set forth in the relevant standards, always follow these instructions and precautions:
Phone Operation
When placing or receiving a phone call, hold your radio product as you would a wireline telephone.
microphone
.
Two-way radio operation
Your radio product has been designed and tested to comply with national and international standards and guidelines regarding human exposure to RF electromagnetic energy, when operated in the two-way mode (at the face, or at the abdomen when using an audio accessory) at usage factors of up to 50% talk/50% listen.
Transmit no more than the rated duty factor of 50% of the time. To transmit (talk), push the PTT button. To receive calls, release the PTT button. Transmitting 50% of the time or less, is important because this radio generates measurable RF energy only when transmitting (in terms of measuring for standards compliance).
Speak directly into the
When using your radio product as a traditional two-way radio,
vertical position with the microphone one to two inches (2.5 to 5 cm) away from the lips
If you wear a radio product on your body when transmitting, always place the radio product in a Motorola approved clip, holder, holster, case or body harness. If you do not use a body-worn accessory supplied or approved by Motorola and are not using the radio product in the intended use positions along side the head in the phone mode or in front of the face in the two-way radio mode, or if you hang your device from a lanyard around your neck, keep the device at least 2.5 centimeters (1 inch) from your body when transmitting.
hold the radio product in a
.
Approved Accessories
For a list of approved Motorola accessories call 1-800-453-0920, or visit our website at www.hellomoto.com
.
RF Energy Interference/Compatibility
Nearly every electronic device is subject to RF energy interference from external sources if inadequately shielded, designed or otherwise configured for RF energy compatibility. In some circumstances your handset may cause interference with other devices.
Safety Information
79
Follow Instructions to Avoid Interference Problems
Turn OFF your radio product where posted notices instruct you to do so.
In an aircraft, turn off your radio product whenever instructed to do so by airline staff. If your radio product offers an airplane mode or similar feature, consult airline staff about using it in flight.
Implantable Medical Devices
If you have an implantable medical devices, such as a pacemaker or defibrillator, consult your physician before using this radio product.
Persons with implantable medical devices should observe the following precautions:
ALWAYS keep the phone more than 20 centimeters (8 inches) from the implantable medical device when the phone is turned ON.
DO NOT carry the phone in a breast pocket;
Use the ear opposite the implantable medical device to minimize the potential for interference.
Turn OFF the phone immediately if you have any reason to suspect that the interference is taking place.
Read and follow the directions from the manufacturer of your implantable medical device. If you have any questions about using
Safety Information
80
your wireless phone with your implantable medical device, consult your health care provider.
Hearing Aids
Some phones may interfere with some hearing aids. In the event of such interference, you may want to consult your hearing aid manufacturer or physician to discuss alternatives.
Other Medical Devices and Health Care Facilities
If you use any other personal medical devices, consult your physician or the manufacturer or your device to determine if it is adequately shielded from RF energy. Turn off your radio product when instructed to do so in hospitals or health care facilities that may be using equipment that is sensitive to external RF energy.
Bluetooth
This device supports Bluetooth 2.0 including EDR and A2DP Stereo profiles. In order for Bluetooth devices to communicate with one another, they must utilize the same Bluetooth profile. To determine the profiles supported by other Motorola devices, visit www.hellomoto.com/bluetooth. For other devices, contact their respective manufacturer.
Certain Bluetooth features including those listed may not be supported by all compatible Bluetooth-enabled devices, and/or the functionality of such features may be limited in certain devices, or by certain wireless carriers. Contact your wireless carrier about feature availability and functionality.
Driving Precautions
032374o
032376o
Check the laws and regulations on the use of radio products in the area where you drive. Always obey them.
When using your radio product while driving, please:
Give full attention to driving and to the road. Using a phone may be distracting. Discontinue a call if you can’t concentrate on driving.
Use hands free operation, if available.
Pull off the road and park before making or answering a call if driving conditions so require.
Do not place a handset in the airbag deployment area.
Responsible driving practices can be found in the “Smart Practices While Driving” section at the end of this guide and/or at the Motorola Web site: www.motorola.com/callsmart
Note:
The use of wireless phones while driving may cause distraction. Discontinue a call if you can’t concentrate on driving. Additionally, the use of wireless devices and their accessories may be prohibited or restricted in certain areas. Always obey the laws and regulations on the use of these products.
.
Operational Warnings
Obey all posted signs when using phones in public areas.
Potentially Explosive Atmospheres
Areas with potentially explosive atmospheres are often but not always posted, and can include fueling areas such as below decks on boats, fuel or chemical transfer or storage facilities, or areas where the air contains chemicals or particles, such as grain, dust or metal powders.
When you are in such area, turn off your handset, and do not remove, install, or charge batteries unless it is a radio product type especially qualified for use in such areas as “Intrinsically Safe” (for example, Factory Mutual, CSA, or UL approved). In such areas, sparks can occur and cause an explosion or fire.
Batteries and Chargers
Caution: Improper treatment or use of batteries may present a danger of fire, explosion, leakage, or other hazard. For more information, see the “Battery Use and Battery Safety” section in this user’s guide.
Your battery, charger, or portable radio may contain symbols, defined as follows:
Symbol Definition
Important safety information follows.
Do not dispose of your battery or phone in a fire.
Safety Information
81
Symbol Definition
032375o
032378o
Li Ion BATT
Your battery or phone may require recycling in accordance with local laws. Contact your local regulatory authorities for more information.
Do not throw your battery or phone in the trash.
Your phone contains an internal lithium ion battery.
Do not let your battery, charger, or phone get wet.
Listening at full volume to music or voice through a headset may damage your hearing.
Choking Hazards
Your portable radio or its accessories may include detachable parts, which may present a choking hazard to small children. Keep your device and its accessories away from small children.
Safety Information
82
Glass Parts
Some parts of your phone may be made of glass. This glass could break if the product is dropped on a hard surface or receives a substantial impact. If glass breaks, do not touch or attempt to remove. Stop using your phone until the glass is replaced by a qualified service center.
Seizures/Blackouts
Some people may be susceptible to epileptic seizures or blackouts when exposed to flashing lights, such as when playing video games. These may occur even if a person has never had a previous seizure or blackout.
If you have experienced seizures or blackouts, or if you have a family history of such occurrences, please consult with your physician before playing video games or enabling a flashing-lights feature (if available) on your phone.
Discontinue use and consult a physician if any of the following symptoms occur: convulsion, eye or muscle twitching, loss of awareness, involuntary movements, or disorientation. It is always a good idea to hold the screen away from your eyes, leave the lights on in the room, take a 15-minute break every hour, and stop use if you are very tired.
Caution About High Volume Usage
Listening at full volume to music or voice through a headset may damage your hearing.
Repetitive Motion
When you repetitively perform actions such as pressing keys or entering finger-written characters, you may experience occasional discomfort in your hands, arms, shoulders, neck, or other parts of your body. If you continue to have discomfort during or after such use, stop use and see a physician.
Safety Information
83

Service & Repairs

If you have questions or need assistance, we’re here to help. Go to www.motorola.com/support
number of customer care options. You can also contact the
, where you can select from a
Export Law Assurances
Service & Repairs
This product is controlled under the export regulations of the United States of America and Canada. The Governments of the United States of America and Canada may restrict the exportation or re-exportation of this product to certain destinations. For further information contact the U.S. Department of Commerce or the Canadian Department of Foreign Affairs and International Trade.
Service & Repairs
84
Motorola Customer Support Center at 1 (800) 453-0920 (United States), 1 (877) 483-2840 (TTY, TDD United States for hearing impaired).

Specific Absorption Rate Data

SAR Data
ALL MODELS WITH FCC ID IHDP56HJ1 MEET THE GOVERNMENT’S REQUIREMENTS FOR EXPOSURE TO RADIO WAVE S.
Your wireless phone is a radio transmitter and receiver. It is designed and manufactured not to exceed the emission limits for exposure to radio frequency (RF) energy set by the Federal Communications Commission of the U.S. Government. These limits are part of comprehensive guidelines and establish permitted levels of RF energy for the general population. The guidelines are based on standards that were developed by independent scientific organizations through periodic and thorough evaluation of scientific studies. The standards include a substantial safety margin designed to assure the safety of all persons, regardless of age and health.
The exposure standard for wireless mobile phones employs a unit of measurement known as the Specific Absorption Rate, or SAR. The SAR limit set by the FCC is 1.6W/kg.
* In the United States and Canada, the SAR limit for mobile phones used
by the public is 1.6 watts/kg (W/kg) averaged over one gram of tissue. The standard incorporates a substantial margin of safety to give additional protection for the public and to account for any variations in measurements.
*
Tests for SAR are
conducted using standard operating positions reviewed by the FCC with the phone transmitting at its highest certified power level in all tested frequency bands. Although the SAR is determined at the highest certified power level, the actual SAR level of the phone while operating can be well below the maximum value. This is because the phone is designed to operate at multiple power levels so as to use only the power required to reach the network. In general, the closer you are to a wireless base station antenna, the lower the power output.
Before a phone model is available for sale to the public, it must be tested and certified to the FCC that is does not exceed the limit established by the requirement adopted by the government for safe exposure. The tests are performed in positions and locations (e.g., at the ear and worn on the body) as required by the FCC for each model. The highest SAR value for the model i365 (i365IS) phone when tested for use at the ear is 1.09 W/kg and when tested on the body, as described in this user guide, is 1.28 W/kg during packet data transmission. (Measurements for phones worn on the body differ among models, depending upon available accessories and FCC requirements.)
** The SAR information includes the M otorola testing protocol, assessment
procedure, and measurement uncertainty range for this product.
**
SAR Data
85
While there may be differences between the SAR levels of various phones and at various positions, they all meet the government requirement for safe exposure. Please note that improvements to this product model could cause differences in the SAR value for later products; in all cases, products are designed to be within the guidelines.
Additional information on Specific Absorption Rates (SAR) can be found on the Cellular Telecommunications Industry Association (CTIA) web-site at http://www.ctia.org Telecommunications Association (CWTA) Web site: http://www.cwta.ca
86
.
SAR Data
or the Canadian Wireless

Motorola Limited Warranty for the United States and Canada

Warran ty
What Does this Warranty Cover?
Note: FOR IDEN SUBSCRIBER PRODUCTS, ACCESSORIES AND SOFTWARE PURCHASED IN THE UNITED STATES OR CANADA
What Does this Warranty Cover?
Subject to the exclusions contained below, Motorola, Inc. warrants its Motorola iDEN Digital Mobile and Portable Handsets ("Products"), Motorola-branded or certified accessories sold for use with these Products ("Accessories") and Motorola software contained on CD-Roms or other tangible media and sold for use with these Products ("Software") to be free from defects in materials and workmanship under normal consumer usage for the period(s) outlined below.
consumer's exclusive remedy, and applies as follows to new Products, Accessories and Software purchased by
This limited warranty is a
consumers in the United States or Canada, which are accompanied by this written warranty:
Products Covered Length of Coverage
Products as defined above.
Accessories as defined above.
Products or Accessories that are Repaired or Replaced.
One (1) year
purchase by the first consumer purchaser of the product.
One (1) year
purchase by the first consumer purchaser of the product.
The balance of the original warranty or for ninety (90) days
from the date returned to the consumer, whichever is longer.
from the date of
from the date of
Warranty
87
Products Covered Length of Coverage
Software
as defined above. Applies only to physical defects in the media that embodies the copy of the software (e.g. CD-ROM, or floppy disk).
What is not covered? (Exclusions)
Normal Wear and Tear
replacement of parts due to normal wear and tear are excluded from coverage.
Ornamental Decorations
emblems, graphics, rhinestones, jewels, gemstones and their settings, and other decorative elements, are excluded from coverage.
Batteries
. Only batteries whose fully charged capacity falls below 80% of their rated capacity and batteries that leak are covered by this limited warranty.
Abuse & Misuse
improper operation, storage, misuse or abuse, accident or neglect, such as physical damage (cracks, scratches, etc.) to the surface of the product resulting from misuse; (b) contact with liquid, water, rain, extreme humidity or heavy perspiration, sand, dirt or the like, extreme heat, or food; (c) use of the Products or Accessories for
Warranty
88
Ninety (90) days from the date of purchase.
. Periodic maintenance, repair and
. Ornamental decorations such as
. Defects or damage that result from: (a)
commercial purposes or subjecting the Product or Accessory to abnormal usage or conditions; or (d) other acts which are not the fault of Motorola, are excluded from coverage.
Use of Non-Motorola Products and Accessories
damage that result from the use of Non-Motorola branded or certified Products, Accessories, Software or other peripheral equipment are excluded from coverage.
Unauthorized Service or Modification
resulting from service, testing, adjustment, installation, maintenance, alteration, including without limitation, software changes, or modification in any way by someone other than Motorola, or its authorized service centers, are excluded from coverage.
Altered Products
numbers or date tags that have been removed, altered or obliterated; (b) broken seals or that show evidence of tampering; (c) mismatched board serial numbers; or (d) nonconforming or non-Motorola housings, antennas, or parts, are excluded from coverage.
Communication Services
Products, Accessories or Software due to any communication service or signal you may subscribe to or use with the Products, Accessories or Software is excluded from coverage.
Software Embodied in Physical Media.
that the software will meet your requirements or will work in combination with any hardware or software applications provided by third parties, that the operation of the software products will be
. Products or Accessories with (a) serial
. Defects, damages, or the failure of
. Defects or
. Defects or damages
No warranty is made
uninterrupted or error free, or that all defects in the software products will be corrected.
Software NOT Embodied in Physical Media
not embodied in physical media (e.g. software that is downloaded from the internet), is provided "as is" and without warranty.
Who is covered?
consumer purchaser, and is not transferable.
What will Motorola Do?
charge repair, replace or refund the purchase price of any Products, Accessories or Software that does not conform to this warranty. We may use functionally equivalent reconditioned/refurbished/pre-owned or new Products, Accessories or parts. No data, software or applications added to your Product, Accessory or Software, including but not limited to personal contacts, games and ringer tones, will be reinstalled. To avoid losing such data, software and applications please create a back up prior to requesting service.
How to Obtain Warranty Service or Other Information?
obtain service or information, please call: Motorola iDEN Customer Services 1-800-453-0920 or
954-723-4910 or TTY-877-483-2840. Or visit us online at http://www.motorola.com/iden/support You will receive instructions on how to ship the Products,
Accessories or Software, at your expense, to a Motorola Authorized Repair Center. To obtain service, you must include: (a) a copy of your receipt, bill of sale or other comparable proof of
This warranty extends only to the first
Motorola, at its option, will at no
. Software that is
To
purchase; (b) a written description of the problem; (c) the name of your service provider, if applicable; (d) the name and location of the installation facility (if applicable) and, most importantly; (e) your address and telephone number.
What Other Limitations Are There?
WARRANTIES, INCLUDING WITHOUT LIMITATION THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, SHALL BE LIMITED TO THE DURATION OF THIS LIMITED WARRANTY, OTHERWISE THE REPAIR, REPLACEMENT, OR REFUND AS PROVIDED UNDER THIS EXPRESS LIMITED WARRANTY IS THE EXCLUSIVE REMEDY OF THE CONSUMER, AND IS PROVIDED IN LIEU OF ALL OTHER WARRANTIES, EXPRESS OF IMPLIED. IN NO EVENT SHALL MOTOROLA BE LIABLE, WHETHER IN CONTRACT OR TORT (INCLUDING NEGLIGENCE) FOR DAMAGES IN EXCESS OF THE PURCHASE PRICE OF THE PRODUCT, ACCESSORY OR SOFTWARE, OR FOR ANY INDIRECT, INCIDENTAL, SPECIAL OR CONSEQUENTIAL DAMAGES OF ANY KIND, OR LOSS OF REVENUE OR PROFITS, LOSS OF BUSINESS, LOSS OF INFORMATION OR DATA, SOFTWARE OR APPLICATIONS OR OTHER FINANCIAL LOSS ARISING OUT OF OR IN CONNECTION WITH THE ABILITY OR INABILITY TO USE THE PRODUCTS, ACCESSORIES OR SOFTWARE TO THE FULL EXTENT THESE DAMAGES MAY BE DISCLAIMED BY LAW.
Some states and jurisdictions do not allow the limitation or exclusion of incidental or consequential damages, or limitation on the length of an implied warranty, so the above limitations or exclusions may not apply to you. This warranty gives you specific
ANY IMPLIED
Warranty
89
legal rights, and you may also have other rights that vary from state to state or from one jurisdiction to another.
Laws in the United States and other countries preserve for Motorola certain exclusive rights for copyrighted Motorola software such as the exclusive rights to reproduce and distribute copies of the Motorola software. Motorola software may only be copied into, used in, and redistributed with, the Products associated with such Motorola software. No other use, including without limitation disassembly of such Motorola software or exercise of the exclusive rights reserved for Motorola, is permitted.
Patent and Software Provisions
MOTOROLA will defend, at its own expense, any suit brought against the end user purchaser to the extent that it is based on a claim that the Product or parts infringe a United States patent, and Motorola will pay those costs and damages finally awarded against the end user purchaser in any such suit which are attributable to any such claim, but such defense and payments are conditioned on the following:
a.That MOTOROLA will be notified promptly in writing by such purchaser of any notice of such claim;
b.That MOTOROLA will have sole control of the defense of such suit and all negotiations for its settlement or compromise; and
Warranty
90
c.Should the Product or parts become, or in MOTOROLA'S opinion be likely to become, the subject of a claim of infringement of a United States patent, that such purchaser will permit MOTOROLA, at its option and expense, either to procure for such purchaser the right to continue using the Product or parts or to replace or modify the same so that it becomes non-infringing or to grant such purchaser a credit for the Product or parts as depreciated and accept its return. The depreciation will be an equal amount per year over the lifetime of the Product or parts as established by MOTOROLA.
MOTOROLA will have no liability with respect to any claim of patent infringement which is based upon the combination of the Product or parts furnished hereunder with software, apparatus or devices not furnished by MOTOROLA, nor will MOTOROLA have any liability for the use of ancillary equipment or software not furnished by MOTOROLA which is attached to or used in connection with the Product or any parts thereof.
Laws in the United States and other countries preserve for MOTOROLA certain exclusive rights for copyrighted MOTOROLA software, such as the exclusive rights to reproduce in copies and distribute copies of such MOTOROLA software. MOTOROLA software may be used in only the Product in which the software was originally embodied and such software in such Product may not be replaced, copied, distributed, modified in any way, or used to produce any derivative thereof. No other use including, without limitation, alteration, modification, reproduction, distribution, or reverse engineering of such MOTOROLA software or exercise or rights in such MOTOROLA software is permitted. No license is
granted by implication, estoppel or otherwise under MOTOROLA patent rights or copyrights.
Warranty
91

Information From the World Health Organization

WHO Information
Present scientific information does not indicate the need for any special precautions for the use of mobile phones. If you are concerned, you may want to limit your own or your children’s RF
exposure by limiting the length of calls or by using hands-free devices to keep mobile phones away from your head and body.
Source: WHO Fact Sheet 193 Further information: http://www.who.int./peh-emf
Product Registration
Registration
Online Product Registration: http://www.motorola.com/us/productregistration Product registration is an important step toward enjoying your new
Motorola product. Registration permits us to contact you for product or software updates and allows you to subscribe to updates on new products or special promotions. Registration is not required for warranty coverage.
Please retain your original dated sales receipt, as you may need to provide it for warranty validation in the future.
Thank you for choosing a Motorola product.
WHO Information
92
Wireless: The New Recyclable
Recycling
Your wireless phone can be recycled. Recycling your phone reduces the amount of waste disposed in landfills and allows recycled materials to be incorporated into new products.
The Cellular Telecommunications Industry Association (CTIA) and its members encourage consumers to recycle their phones and have taken steps to promote the collection and environmentally sound recycling of end-of-life devices.
California Perchlorate Label
Perchlorate Label
Some mobile phones use an internal, permanent backup battery on the printed circuit board that may contain very small amounts of perchlorate. In such cases, California law requires the following label:
“Perchlorate Material - special handling may apply. See www.dtsc.ca.gov/hazardouswaste/perchlorate.
There is no special handling required by consumer.
As a phone user, you have an important role in ensuring that this device is recycled properly. When it comes time to give this phone up or trade it in for a new one, please remember that the phone, the charger, and many of its accessories can be recycled. It's easy. To learn more about CTIA's Recycling Program for Used Wireless Devices, please visit us at: http://recycling.motorola.young-america.com/ index.html
Recycling
93

Patent and Trademark Information

Patent and Trademark
MOTOROLA, the Stylized M Logo and all other trademarks indicated as such herein are trademarks of Motorola, Inc. ® Reg. U.S. Pat. & Tm. Off. © 2008 Motorola, Inc. All rights reserved.
Microsoft and Microsoft Internet Explorer are registered trademarks of Microsoft Corporation.
T9 is a trademark owned by Tegic Communications.
®
Text Input Patent and Trademark Information.
T9 This product is covered by U.S. Pat. 5,818,437, U.S. Pat. 5,953,541,
U.S. Pat. 6,011,554 and other patents pending. Java and all other Java-based marks are trademarks or registered
trademarks of Sun Microsystems, Inc. in the U.S. and other countries.
All other product names or services mentioned in this manual are the property of their respective trademark owners.
Patent and Trademark
94
Software Copyright Notice
The Motorola products described in this manual may include copyrighted Motorola and third party software stored in semiconductor memories or other media. Laws in the United States and other countries preserve for Motorola and third party software providers certain exclusive rights for copyrighted software, such as the exclusive rights to distribute or reproduce the copyrighted software. Accordingly, any copyrighted software contained in the Motorola products may not be modified, reverse-engineered, distributed, or reproduced in any manner to the extent allowed by law. Furthermore, the purchase of the Motorola products shall not be deemed to grant either directly or by implication, estoppel, or otherwise, any license under the copyrights, patents, or patent applications of Motorola or any third party software provider, except for the normal, non-exclusive, royalty-free license to use that arises by operation of law in the sale of a product.
Loading...
