Miele W 2585 WPS Medicwash Operating instructions

Operating instructions for Washing machine medicwash W 2585 WPS

To avoid the risk of accidents or damage to the machine it is essential to read these instructions before it is installed and used for the first time.

M.-Nr. 06 153 310

Caring for our environment

Disposal of the packing material

The transport and protective packing has been selected from materials which are environmentally friendly for disposal and can normally be recycled.

Ensure that any plastic wrappings, bags etc. are disposed of safely and kept out of the reach of babies and young children. Danger of suffocation!

Rather than just throwing these materi als away, please ensure they are of fered for recycling.

Disposal of your old appliance or machine

Electrical and electronic appliances / machines often contain materials which, if handled or disposed of incor rectly, could be potentially hazardous to human health and to the environment. They are, however, essential for the cor rect functioning of your appliance or machine. Please do not therefore dis pose of your old machine or appliance with your household waste.

Please dispose of it at your local community waste collection / recycling centre and ensure that it presents no danger to children while being stored for disposal.

It should be unplugged or disconnected from the mains electricity supply by a competent person. The plug must be rendered useless and the cable cut off directly behind it to prevent misuse. See the "Warning and Safety" section of this booklet for further details.

Contents

Caring for our environment. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

Disposal of the packing material . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

Disposal of your old appliance or machine . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

Warning and safety instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Description of the machine. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Special programmes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Delicates and Silks / programmes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Load size indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Recommended detergent dose indicator. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Rinse plus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Delay start h/min. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Time left display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Locking functions (programme locking, system lock) . . . . . . . . . . . . . . . . . . . 10

Future updates (PC) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Control panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Multi-function display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Important control panel features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Programme selector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Additional option buttons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

"Spin" button with indicator lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Before using for the first time. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Before using for the first time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Calibrating the load sensor to zero. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Washing environmentally and economically. . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Energy and water consumption . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Detergent . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Additional options (Soak, Pre-wash, Intensive) . . . . . . . . . . . . . . . . . . . . . . . . 15

When drying with a tumble dryer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Tips for allergy sufferers. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Fabrics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Detergent . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Number of rinses . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

How to wash correctly. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Brief instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Programme chart . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Contents

How to wash correctly. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Before washing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Programme selection. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

Additional options. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

Delay start. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

At the end of a programme . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

Adding or removing laundry after a programme has started . . . . . . . . . . . . . . . . 27

Interrupting a programme . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

Altering a programme once selected . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

Skipping a programme stage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

Selecting a different programme . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

Programme sequence . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

Detergent . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

Water softeners . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

Washing with several components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

Fabric conditioners and liquid starch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32

Automatic dispensing of fabric conditioner or liquid starch at the end

of a programme . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32

Locking functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

Electronic programme locking. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

Electronic system lock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34

Cleaning and care . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

External casing and fascia panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

E-Cloth . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

Extra cleaning. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

Cleaning the detergent dispenser drawer. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

Cleaning the filter in the water inlet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37

Problem solving guide. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38

The programme does not start. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38

The wash programme stops and a fault indicator light comes on. . . . . . . . . . . . . 39

A fault indicator light comes on but the wash programme continues as normal. . 40

Problems with the load size indicator and the dispensing recommendation . . . . 41

General problems or an unsatisfactory wash result. . . . . . . . . . . . . . . . . . . . . . . . 42

The drum door does not open when you press the Door button. . . . . . . . . . . . . . 44

Contents

Opening the drum door in the event of a blocked drain outlet and/

or power failure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45

Blocked drain outlet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45

Customer contact . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47

Optional accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47

Installation and connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48

Front view. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48

Rear view . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49

Installation surface. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50

Installing the washing machine . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50

Removing the transit bars . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50

Re-fitting the transit bars . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52

Levelling the machine . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53

Screwing out and adjusting the feet. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53

Building under a continuous worktop/in a kitchen run . . . . . . . . . . . . . . . . . . . 54

Washer and Dryer stack . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54

The Miele Waterproof system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55

Connection to the water supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56

Connection to the drainage system. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58

Electrical connection U.K. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59

Consumption data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60

Note for test institutes: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60

Technical data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61

Programmable functions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63

Increasing the water level . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63

Introducing an additional rinse for the Hygiene + and Cottons Universal

programmes. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64

Gentle action . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65

Top-up rinse for Hygiene + 95°C and Pillows hygiene 95°C . . . . . . . . . . . . . . . . . 66

Memory function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67

Buzzer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68

Warning and safety instructions

To avoid the risk of accidents and damage to the machine please read these instructions carefully before using it for the first time. They con tain important information on its sa fety, use and maintenance. Keep these instructions in a safe place and ensure that new users are familiar with the content. Pass them on to any future owner of the machi ne.

Correct usage

Only use the washing machine to

wash items which are specified by the manufacturer to be machine-washable on the wash-care label, and textiles composed of hand-washable wool or wool blend fabrics as well as satin, lace, silk and other hand-washable garments. Any other applications may be dangerous. The manufacturer is not liable for damage resulting from improper use or operation.

Technical safety

Before setting up the machine,

check it for any externally visible damage. Do not install and use a da maged machine.

Before connecting the machine,

ensure that the connection data on the data plate match the mains electri city supply. If in any doubt, consult a qualified electrician.

The electrical safety of this machi

ne can only be guaranteed when continuity is complete between the ma chine and an effective earthing system which complies with local and national regulations. It is most important that this basic safety requirement is present and regularly tested and where there is any doubt the household wiring system should be inspected by a qualified electrician. The manufacturer cannot be held liable for the consequences of an inadequate earthing system (e.g. electric shock).

Do not connect the machine to the

mains electricity supply by an extension lead. Extension leads do not guarantee the required safety of the machine (e.g. danger of overheating).

The machine is built in accordance

with current safety requirements. Unauthorised repairs could result in unforeseen dangers for the user, for which the manufacturer cannot accept liability. Repairs should only be undertaken by a Miele approved technician. Ensure current is not supplied to the machine until after maintenance or re pair work has been carried out.

The machine is only completely

isolated from the electricity supply when:

–

it is switched off at the wall socket and the plug is withdrawn, or

–

it is switched off at the mains, or

–

the mains fuse is withdrawn.

–

the screw-out fuse is removed (in countries where this is applicable).

Warning and safety instructions

The Miele "Water protection sy

stem" protects from water damage provided the following conditions have been met:

the machine is correctly plumbed in

–

and connected to the electricity supply.

if a fault has been identified, the ma

–

chine must be examined by a com petent person before further use, and repaired if necessary.

Faulty components must only be

replaced by genuine Miele original spare parts. Only when these parts are fitted can the safety standards of the machine be guaranteed.

If the connection cable is faulty it

must only be replaced by a Miele approved service technician to protect the user from danger.

In countries where there are areas

which may be subject to infestation by cockroaches or other vermin, pay particular attention to keeping the ma chine and its surroundings in a clean condition at all times. Any damage which may be caused by cockroaches or other vermin will not be covered by the guarantee.

Use

This equipment may only be used

in mobile installations such as ships, caravans, aircraft etc. if a risk as sessment of the installation has been carried out by a suitably qualified engi neer.

Do not install your washing machi

ne in rooms where temperatures below freezing may occur. Frozen ho ses may burst or split. The reliability of the electronic control unit may be im paired at temperatures below freezing point.

Before using the machine for the

first time, check that the transit fit tings at the rear of the machine have been removed (see section on "Installa tion"). During spinning, a transit fitting which is still in place may result in da mage to both the machine and adja cent furniture or appliances.

Turn off the stopcock if the machi-

ne is to be left for any length of time (e.g. holiday), especially if there is no floor drain (gully) in the immediate vicinity.

Flooding danger

If hooking the drain hose into a wash basin, check that the water can drain off quickly enough to prevent the sink from overflowing. Make sure the drain hose is secure, so that the force of the water flowing out of the hose does not dislodge it.

Take care to ensure that foreign

objects (e.g. nails, pins, coins, pa per clips) do not find their way into the machine with the laundry. These may damage components of the machine (e.g. suds container, drum), which in turn can result in damage to the laun dry.

Warning and safety instructions

If the correct amount of detergent

is dispensed, the machine should not need to be descaled. If, however, you do wish to descale the machine only use proprietary non-corrosive de scaling agents and strictly observe the instructions on the packaging. If in doubt, contact the Miele Customer Service Dept. or your Miele Dealer.

Textiles which have been pre-trea

ted in solvent based cleaning agents must be thoroughly rinsed in clean water before being washed in the machine.

Never use solvent based cleaning

agents, e.g. those containing benzene, in this machine, as this may result in damage to component parts and create toxic fumes. Such agents also pose a fire and explosion hazard.

Only use dyes specified by the ma-

nufacturer as being suitable for use in a domestic washing machine. Always observe the manufacturer's instructions carefully.

Colour run and dye removers con

tain sulphur compounds which can cause damage such as corrosion. Do not use these products in this machine.

Always make sure the drum is sta

tionary before reaching in to remo ve washing. Reaching into a moving drum is extremely dangerous.

Safety with children

This machine is not a toy! To avoid

the risk of injury do not allow children to play on or near it or to play with the controls. Supervise its use by the elderly or infirm, and supervise children whilst you are operating the machine.

For machines with a ‘porthole’

door, remember that the porthole glass will be hot when washing at very high temperatures. Do not let children touch it.

Accessories

Accessory parts may only be fitted

when expressly approved by Miele. If other parts are used, guarantee, performance and product liability claims will be invalidated.

Disposal of your old machine

Before discarding an old machine,

switch it off at the wall socket and unplug it. Render the plug useless. Cut off the cable directly behind the appli ance to prevent misuse. This should be done by a competent person.

The manufacturer cannot be held

liable for damage caused by non-compliance with these Warning and Safety instructions.

Description of the machine

Your machine also has the following special programmes in addition to the standard Cottons and Minimum iron programmes.

Special programmes

Hygiene +

–

This programme kills germs and hou sehold dust mites. The holding time at a temperature of 60°C in the main wash is increased.

First wash

–

Use this programme to wash any chemical residues out of new garments.

– Pillows

This programme will remove dust mites and dust mite faeces from pillows.

– Silks

–

Hand-washable fabrics which crease easily but do not contain wool can be washed in the Silks / programme.

Woollens Hand-washable or machine-

washable wool or wool blend fabrics can be washed in the programme. If the garment care label does not specify a temperature, wash using the cold setting.

Woollens

Delicates and Silks / programmes

In these programmes, the laundry is washed and spun very gently to reduce creasing and the amount of ironing re quired, thus providing "easy care" for your laundry.

Load size indicator

The washing machine is equipped with

a sensor which registers how much laundry is in the drum. This is displayed as a % figure.

Recommended detergent dose indicator

In certain programmes, when a minimum amount of laundry is loaded into the drum, the washing machine will indicate a recommended reduced amount of detergent, as a % figure. This is a % of the total amount recommended by the detergent manufacturer for a full load of laundry.

Rinse plus

If the

Rinse plus

fourth rinse is introduced in the

ne +

Cottons Universal

iron

programmes.

Your washing machine also has the fol lowing programmable functions:

–

the water level can be increased in

Hygiene +,Cottons Universal

the and the

option is selected, a

Minimum iron

and

Minimum

programmes.

Hygie

–

an additional rinse can be introduced in the

Hygiene +

sal

programmes.

and

Cottons Univer

Description of the machine

Delay start h/min

Delay start allows you to delay the start of a programme from 30 minutes up to a maximum of 24 hours.

Time left display

After the start of a programme, the duration of the programme selected will be shown in the display counting down in hours and minutes and finally in mi nutes. At some points during the wash, the time shown can change. This is nor mal.

Locking functions (programme locking, system lock)

Electronic programme locking

Electronic programme locking prevents the door from being opened or the programme cancelled during a wash programme. The electronic programme locking is automatically cancelled at the end of the programme.

Future updates (PC)

The indicator or check light marked PC is the interface used by Miele service technicians during servicing work for testing purposes and for updating the machine's programme data.

Electronic system lock

The system lock prevents anyone from using the washing machine without your knowledge. When the system lock is activated :

–

the door cannot be opened with the door button

–

a programme cannot be started.

Control panel

Description of the machine

a Multi-function display

See the following page for more information

b Start button

Starts the wash programme

c Delay start button

For delaying the start of a programme

d Additional option buttons

Indicator light on = option selected Indicator light off = option not selected

e Spin button

For selecting the final spin speed, Rinse hold or Without spin

f Indicator lights

For spin speed, Rinse hold or Wit hout spin

g Programme selector

For selecting the wash programme and temperature for that programme. The programme selector can be turned clockwise or anti-clockwise.

h Programme sequence indictor

lights

Show which section of the wash programme has been reached.

i Check lights j I-On/0-Off button

For switching the machine on or off or interrupting a programme

k Door button

Opens the machine door

Description of the machine

Multi-function display

a Display b Display indicator lights c This button has the following two

functions:

– changes the display from

Detergent %

– sets the load sensors to zero To enable you to wash environmentally

and economically:

and

Time left h/min

Load %

the duration of the programme de

–

pending on the programme and the amount of the load (Time left h/min).

Please note that on the programme selected and applies to dry laundry only.

Important: Loads of less than 25% will not regi ster in the display. However, the dis pensing recommendation will show the minimum value of 40%.

Please note that in the following programme the display will only show the time left:

– Drain /spin

The display will also show:

– Delay start – The programmable functions

(when in programming mode)

Load %

depends

–

the washing machine calculates the amount of laundry loaded. This is displayed as a % figure: 25/50/75/100%.

–

the amount of detergent required is then displayed as a % figure: 40/ 50/60/75/100%. In other words dispense this % of the total amount of detergent recommen ded by the manufacturer for a full load of laundry. The water hardness level and type of soiling also need to be considered when deciding how much detergent to use.

Description of the machine

Important control panel features

Programme selector

The programme selector is used to set the basic wash programme and the temperature for that programme.

The light ring will go out a few minutes after the end of the programme to save energy.

Additional option buttons

Additional options can be added to the basic programme.

Pressing the relevant button selects or de-selects the particular option. The indicator light will come on to show that the additional option has been selected.

If an additional option is chosen, which is incompatible with the basic programme, it cannot be selected.

"Spin" button with indicator lights

The maximum spin speed which can be selected depends on the basic pro gramme chosen.

Maximum spin speed

1600 Hygiene +, Cottons Universal,

1200 Woollens, First wash, Pillows

900 Minimum iron 600 Delicates 400 Silks

Basic programme

Quick wash, Drain/spin

Selecting the spin speed

Press the "Spin" button to select a dif

ferent spin speed. N.B.: you cannot se lect a spin speed higher than the maxi mum allowed for the basic wash pro

gramme chosen. The indicator lights show the speed se

lected.

You can also omit the spin.

Press the "Spin" button to reach:

Rinse hold

–

The laundry is not spun and remains suspended in the final rinse water. This reduces creasing if the laundry is not going to be removed from the drum immediately after the end of the programme. To continue the programme, select a spin speed. When the programme is finished the

Anti-crease/Finish

light will come on.

Turn the programme selector to the

Finish

position and press the

Door

button to open the door and remove the laundry.

–

Without spin The laundry is not spun after the final

rinse. After the water has been drai ned away the machine goes straight into the anti-crease stage. Spinning between the rinses is also omitted in this setting (rinse and interim spin).

Before using for the first time

Before using the machine for the first time ensure that it is correctly instal led and connected. See "Installation and connection". Also check that the drain filter is securely tightened to prevent the risk of water leaks during use.

Before using for the first time

The washing machine has a sensor which measures the amount of laundry in the drum. This determines the amount of detergent required. To allow the load size indicator to function correctly, you must first run a wash programme without any laundry hout detergent.

A Open the stopcock.

and wit-

Calibrating the load sensor to zero

F Press the

drum door.

G Turn the empty drum round once by

hand.

H Turn the programme selector to the

Hygiene + 95°C

The on.

Door

Load %

button and open the

position.

indicator light will come

B Press the C Turn the programme selector to the

Cottons Uni. 40°C

D Press the E At the end of the wash programme:

Turn the programme selector to

nish

The load sensor must then be cali brated to zero as you would with bathroom scales.

I-On/0-Off

Start

button.

button in.

position.

I Press and hold the button above the

Start

button until an audible tone

sounds. The sensor has now been

calibrated to zero.

The accuracy of the calibration devi ce will improve over the first few pro grammes. At first it will drop a little. For this reason, please re-calibrate the sensor to zero after each of the first few wash cycles.

If the sensor is not calibrated to zero then the values displayed by the washing machine will be incorrect.

The machine is now ready for use.

Washing environmentally and economically

Energy and water consumption

Water consumption and energy usa

–

ge are determined by the size of the load. To make the most out of your machi ne, load the maximum dry load for the programme you are using.

Use the

–

small loads. If smaller loads are washed using the

–

Hygiene +

programmes, the automatic load re cognition system will reduce the amount of water, time and energy used. This may mean that the time left shown in the display is adjusted during the course of the wash programme.

– Instead of using the

programme, use

sal 60°C

ditional option. This will give an energy saving of between 35% and 45%. The programme duration will be lon ger. This combination is sufficient for most levels of soiling. For stubborn or old stains, use the

Quick wash

and the

and select the

programme for

Cottons Universal

Hygiene + 95°C

Cottons Univer-

Intensive

Soak

option.

Detergent

Do not exceed the amounts of deter

–

gent recommended by the manufac turer on the packaging.

ad-

Reduce the amount of detergent with

–

smaller loads (as indicated in the dis play).

Additional options (Soak, Pre-wash, Intensive)

Select:

a wash programme without any addi tional options for light to normal soi ling where there are no obvious marks.

a wash programme together with the

Intensive

soiled laundry with visible staining.

– Use the additional option

ad of immediately by a main wash the same suds are used.

When drying with a tumble dryer

–

Selecting the highest possible spin speed for the wash programme will save energy when drying in a tumble dryer afterwards.

option for normal to heavily

Pre-wash

. If Soak is followed

Soak

inste-

Tips for allergy sufferers

Fabrics

Wash fabrics which will be worn

–

directly against the skin, e.g. under wear, baby clothes, socks etc., at a temperature of at least 60°C or the maximum temperature indicated on the garment care label.

Germs and household dust mites are killed at a temperature of 60°C.

The

Hygiene+

longer temperature holding time in the main wash.

When buying garments, check that

–

they can be washed at a temperature of 60°C.

– Wash new garments before wearing

them for the first time. The

First wash

ve any chemical residues from new garments.

Textiles which tend to run should be washed separately. You may wish to wash them several times before we aring them for the first time.

–

Pillows Use the

ve household dust mites from pil lows.

–

Pillow and mattress covers should be washed regularly, at least every 3 months.

programmes have a

programme will remo-

Pillows

programme to remo

Detergent

Use detergents without added fra

–

grance. We recommend using detergents

–

which have been specially designed for those with sensitive skins or aller gies.

Detergent components will vary de

–

pending on the manufacturer so it may be a good idea to try out several makes of detergent to find the one which suits you best.

Number of rinses

– The wash programmes are designed

to rinse garments very effectively.

– Pressing the

duces a fourth rinse in the

Cottons Universal

iron

programmes.

– You can also programme the

washing machine (using the pro-

grammable functions) so that a fourth rinse is introduced in the

ene +

grammes as standard.

If a fourth rinse has been program med into the washing machine, then pressing the option button will introduce a fifth rin se.

Rinse plus

and

Cottons Universal

Rinse plus

button, intro-

and

additional

Hygiene

Minimum

Hygi

pro

How to wash correctly

Brief instructions

Please note: To help familiarise yourself with how to

use your washing machine please read the sections "Before washing", "Selec ting a programme" and "At the end of a programme" in detail.

A Sort the laundry into colours and fa

bric types Selecting a programme:

B Switch on the washing machine C Open the drum door D Select a programme E Load the drum F Close the drum door G Add detergent H Select any additional option required I Select a spin speed

See the "Programme chart" in the next section for detailed information on which programmes to use for different fabrics.

J Select delay start if required K Press the

At the end of a programme:

L Open the drum door M Remove the laundry N Switch off the washing machine O Turn the programme selector to the

Finish

P Close the drum door

Start

position.

button

How to wash correctly

Programme chart

Hygiene + 95°C 9

Fabric Cottons and linen fabrics Additional options Soak, Pre-wash, Intensive, Rinse plus Notes Detergent Powder detergent, detergent for coloured fabrics, liquid de

Max. load 5 kg

Hygiene + 8

Fabric Cottons and linen fabrics, which will be in direct contact with

Additional options Soak, Pre-wash, Intensive, Rinse plus Notes – There is a longer temperature holding time in the main wash.

Detergent Powder detergent, detergent for coloured fabrics, liquid de-

Max. load 5 kg

Cottons Universal (Cottons Uni.) 876

Fabric Cottons or cotton mix fabrics, e.g. T-shirts, jeans, trousers,

Additional options Soak, Pre-wash, Intensive, Rinse plus Notes

Detergent Powder detergent, detergent for coloured fabrics, liquid de

Max. load 5 kg Note for test institutes:

For testing in accordance with EN 60456 you must use the

Only use for heavily soiled laundry.

–

tergent, tablet detergent and liquid tab detergent. See also "Detergent" section.

the skin, e.g. underwear, nappies, towelling, bed linen, pil low and mattress covers.

– For heavy soiling or where staining is visible, use the

tensive

tergent, tablet detergent and liquid tab detergent. See also "Detergent" section.

table linen.

–

For heavy soiling or where staining is visible, use the

tensive

–

For laundry with large amounts of dirt (e.g. dust, sand) use the

–

For dark coloured fabrics use a detergent for coloured fa brics, or liquid detergent.

tergent, tablet detergent and liquid tab detergent. See also "Detergent" section.

additional option.

Pre-wash

additional option.

Intensive

In-

option.

How to wash correctly

Minimum iron 8764321

Fabric For garments made of synthetic fibres, mixed fibres and for

easy care cotton shirts and blouses. Additional options Soak, Pre-wash, Intensive, Rinse plus Notes For heavy soiling or where staining is visible, use the

additional option.

Detergent Powder detergent, detergent for coloured fabrics, liquid de

tergent, detergent for delicates, tablet detergent and liquid

tab detergent. See also "Detergent" section. Max. load 2.5 kg Note for test institutes:

For testing in accordance with EN 60456 you must use the

Delicates ac

Fabric For delicate garments made of synthetic fibres, mixed fibres

and easy care cotton shirts and blouses.

Curtains, including net curtains, specified as machi-

ne-washable by the manufacturer. Additional options Soak, Pre-wash, Intensive Notes – For heavy soiling or where staining is visible, use the

tensive

–

Laundry remains relatively crease-free for easier ironing.

–

Dust in curtains usually makes using a programme with

Pre-wash

–

For curtains which crease easily, reduce the spin speed or select Without spin.

additional option.

advisable.

Intensive

Intensi

option.

In-

Detergent Liquid detergent for delicates. See also "Detergent" section. Max. load 1 kg

How to wash correctly

Silks /

Fabric Hand-washable fabrics with no wool content, e.g. satin, lace

and silk. Notes

Detergent Liquid detergent for delicates. Max. load 1 kg

Woollens /

Fabric type Machine-washable or hand-washable wool or wool blend fa

Detergent Liquid detergent for machine-washable woollens. See also

Max. load 2 kg

Quick wash 7

Fabric Very lightly soiled fabrics, which can be washed in a Cot-

Detergent Powder detergent, detergent for coloured fabrics, liquid de-

Max. load 2.5 kg

First wash 16

Fabric Use this programme to wash any chemical residues out of

Detergent Powder detergent, detergent for coloured fabrics, liquid de

Max. load 3 kg

Pillows 54

Fabric Washable pillows with feather, down or synthetic fillings. Notes Detergent Liquid detergent Max. load 2 pillows (40 x 80 cm) or 1 pillow (80 x 80 cm)

Drain/Spin

Notes Max. load 5 kg

Laundry remains relatively crease-free for easier ironing.

–

Place socks, tights, bras etc. in a washing bag.

–

brics.

"Detergent" section.

tons Universal programme.

tergent. See also "Detergent" section.

new garments.

tergent for delicates. See also "Detergent" section.

–

Please observe the instructions on the wash care label.

–

Drain only: Select

Without spin

. Do not use for woollens.

Before washing

A Sort the laundry

How to wash correctly

Do not use solvent-based clea

ning agents in this machine.

Sort the laundry by colour and by

care label symbol. Most garments have a textile care label in the collar or side seam.

Dark textiles often contain excess dye and should be washed separately se veral times before being washed toget her with other garments. Always wash whites and coloureds separately.

^ Empty all pockets.

Foreign objects (e.g. nails,

coins, paper clips, etc.) can cause damage to garments and components in the machine.

^ Badly soiled areas, e.g. collars and

cuffs, and water soluble stains can be pre-treated with bar soap, liquid detergent or detergent mixed into a solution or paste.

With particularly stubborn stains ask your dry cleaner for advice.

Delicate textiles should be washed se parately in a delicates programme (use a washing bag where appropriate).

– Curtains:

Remove lead weights and strips or place in a laundry bag.

– Underwiring and collar stiffeners:

Any loose wiring in bras, shirt collar stiffeners, etc. should be removed or sewn in.

–

Knitted garments, trousers and je ans, T-shirts and sweat shirts: Turn inside out, if recommended by the manufacturer.

–

Close any zips, fasten hooks and eyes etc before washing.

–

Fasten duvet covers to prevent smal ler items rolling up inside them.

Do not wash any items in this machine which are specified by the manufacturer as not washable on the care label. (h symbol)

How to wash correctly

Programme selection

To add detergent with the help of the dispensing recommendation feature, follow steps 2, 3 and 4 below before loading the drum.

B Switch on the washing machine

Press in the

C Open the drum door

Press the

drum door.

The washing machine is switched on. If the programme selector is at light ring around the programme selector will flash to remind you to select the programme required.

D Select a programme

^ Turn the programme selector to the

required programme.

The

Load %

As the drum is empty, the display will not yet show any number.

If a number is showing in the display and the drum is empty, rotate the drum once. If the display still shows a number after rotating the drum once, press the button above the

Start

button until an audible tone

sounds.

I-On/0-Off button.

Door

button and open the

Finish

, the

indicator light will come on.

E Load the laundry

Unfold the laundry and load loosely

in the drum. Mixing both large and small items gives better wash results and also helps distribute the load evenly during spinning.

The display shows the amount of laun dry loaded in the drum as a % (in 25% steps) of the maximum load permissible for the programme selected.

Loads of less than 25% will not regi

–

ster in the display. If the amount of laundry exceeds the

–

maximum load (100%), the value shown in the display will flash to indicate overloading. (Except with

ene +

and

Cottons Universal

grammes). Overloading causes creases and re-

duces cleaning efficiency.

F Close the drum door with a firm

swing.

Make sure that no garments are caught between the drum door and seal.

The

Detergent %

on and the amount of detergent re quired for the programme selected is shown in the display.

indicator light comes

Hygi-

pro-

G Add detergent.

The percentage amounts in the display help you to add the correct percentage amount of detergent recommended by the detergent manufacturer.

If the display shows:

40 Add 40 percent ...

(slightly less than half)

50 Add 50 percent ...

(half)

60 Add 60 percent ...

(slightly more than half)

75 Add 75 percent ...

(three quarters)

100 Add 100 percent ...

. . . of the amount recommended by the manufacturer.

Take the level of soiling and also the water hardness into account. It is important to dispense the correct amount because . . .

. . . too much detergent results in:

–

Excessive foam, which causes a low level of agitation and poor wash, rin se and spin results.

–

High water consumption (an additio nal rinse cycle will automatically switch in).

How to wash correctly

Pull out the detergent drawer and

add detergent to the compartments as follows:

Detergent for pre-wash (if selecting a pre-wash add recommended) This compartment is also used for starch formulations when starching separately.

Detergent for the main wash including Soak.

Fabric conditioner or liquid starch.

See "Detergent" section for further infor

mation.

/4of the total amount

–

A burden to the environment.

How to wash correctly

Additional options H Select additional option(s)

^ Press the appropriate additional op-

tion button.

Soak

For heavily soiled and stained items with protein stains (e.g. blood, fats and oils, cocoa).

Duration of soak: A length of time of between 30 minutes and 6 hours can be chosen, in 30 minute increments.

Deleting the soak time

Soak

Press the

til the indicator light goes out.

Pre-wash

For heavily soiled and stained items.

Intensive

For normal to heavy soiling or where staining is visible.

The duration of the main wash is increa sed.

Rinse plus

Rinses the laundry very thoroughly.

A fourth rinse is introduced in the

ene +

Cottons Universal

iron

programmes.

button repeatedly un

Hygi-

and

Minimum

–

When the "Soak" button is pressed for the first time, the indicator in the display switches from

Time left h/min

tes of the soak time are added to the programme time.

–

Each further press of the button in creases the soak time by 30 minutes up to a maximum of 6 hours. The dis play shows the time left, which is the soak time and the programme time added together.

and the first 30 minu

Detergent %

How to wash correctly

I Select a spin speed

Press the "Spin" button repeatedly un

til the indicator light for the spin speed you want comes on.

In some programmes the maximum spin speed is limited. The machine will not allow a higher spin speed to be selected.

Delay start J Select delay start if required.

^ Press the

press on the button increases the de-

layed time: – by 30 minutes up to 10 hours, – by 1 hour from 10 hours upwards. To delete delay start ^ Press the

when 24^ is showing in the display.

Delay start

button. Each

button once

K Press the Start button

This starts the programme. The pro gramme duration will appear in the dis play and the light will come on.

Time left h/min

indicator

How to wash correctly

At the end of a programme

When the light comes on the laundry can be re moved from the drum. (This light stays on at the end of the programme and re mains on until the selector is turned back to the Finish position).

L Open the drum door

Press the

M Remove the laundry

Anti-crease/Finish

Door

button.

indicator

Check that all the items have been removed. Items left in the drum could discolour other items in the next wash or become discoloured

themselves.

N Switch off the washing machine

Press the

the programme selector to The go out.

I-On/0-Off

button and turn

Anti-crease/Finish

light will then

Finish

Only remove laundry from the

machine once the drum has stop ped turning. Reaching into a moving drum is extremely dangerous and could result in injury.

Check the folds in the door seal for any small articles, e.g. buttons which might be lodged there.

O Close the drum door

Otherwise there is the danger of

objects being placed inadvertently in the drum. If these remained unnoticed and were washed in the next load, they could damage the laundry.

How to wash correctly

Adding or removing laundry after a programme has started

Laundry can be added or removed af ter the programme has started when using the following programmes:

Hygiene +

–

Cottons Universal

–

Minimum iron

–

First wash

–

Quick wash

–

Press the

drum door springs open.

^ Add or remove items. ^ Close the door.

The programme will continue automatically.

Please note:

Once a programme has started the machine cannot recognise any adjustment to the load.

Door

button in until the

The door cannot be opened, if:

the suds temperature is above 55°C.

–

the water is above a certain level.

–

programme locking is switched on.

–

the programme has reached the

–

Locked

stage.

check light will come on if

nal spin

The the Door button is pressed when the above conditions are present.

For this reason, if laundry is added or removed after the start of a programme, the machine will always complete the programme cycle for a full load.

This can alter the programme time left shown in the display.

How to wash correctly

Interrupting a programme

Switch the washing machine off with

I-On/0-Off

the

To continue with the same programme:

Switch the machine on with the

I-On/0-Off

button.

Altering a programme once selected

The machine will accept the following changes after a programme has star ted:

– at any time after the start

speed can be changed within the limits for the programme.

– up to 6 minutes after the start

additional options

plus

can be selected or de-selected and a different temperature can be selected for the programme in use.

After the start of a programme it is no longer possible to select a different pro gramme.

If the programme selector is moved, the

Anti-crease/Finish

start flashing. However, the programme sequence remains unaffected. The indi cator light will go out again when the programme selector is moved back to the programme previously chosen.

indicator light will

, the spin

Intensive,Rinse

, the

Skipping a programme stage

Turn the programme selector to

nish

As soon as the programme sequence indicator light for the programme stage you want the programme to continue at, starts flashing:

Turn the programme selector back

again to the appropriate programme within 4 seconds

Programmes cannot be altered and programme stages cannot be skip ped if programme locking has been activated.

Selecting a different programme

^ Switch the machine off with the

I-On/0-Off

^ Turn the programme selector to

nish

Switch the machine back on with the

I-On/0-Off

Select a different programme.

Press the

button.

Start

button.

Fi-

Programme sequence

This washing machine has fully electro nic controls with automatic load recog nition. It takes in the right amount of water required for the programme de pending on the amount of laundry and its absorbency rate. This means that programme cycles and durations can vary.

The programme sequences outlined below are based on the basic program me with a full load. Additional options which can be selected have not been taken into account.

The programme sequence display shows the stage the programme has reached.

Hygiene +, Cottons Universal

Main wash Water level: low Wash rhythm: normal Rinsing Water level: medium No of rinses: 3 Spinning Rinse and interim spin1): yes Final spin: yes

How to wash correctly

Main wash

Water level: low Wash rhythm: normal Rinsing Water level: high No of rinses: 3 Spinning Rinse and interim spin1): yes

Final spin: yes

Main wash Water level: high Wash rhythm: Gentle action Rinsing Water level: high No of rinses: 3 Spinning Rinse and interim spin: no Final spin: yes

Main wash Water level: medium Wash rhythm: Silks Rinsing Water level: medium No of rinses: 2 Spinning Rinse and interim spin: no Final spin: yes

Minimum iron

Delicates

Silks /

How to wash correctly

Woollens /

Main wash Water level: medium Wash rhythm: Woollens Rinsing Water level: medium No of rinses: 2 Spinning Rinse and interim spin1): yes Final spin: yes

First wash

Main wash Water level: medium Wash rhythm: normal Rinsing Water level: medium No of rinses: 2 Spinning Rinse and interim spin1): yes Final spin: yes

Pillows

Main wash

Water level: high Wash rhythm: normal Rinsing Water level: high No of rinses: 3 Spinning Rinse and interim spin: no Final spin: yes

Special features in the programme sequences:

Anti-crease: At the end of every programme, with

the exception of

Woollens

, the drum continues to turn at intervals for up to 30 minutes to help prevent creasing. The door can be opened and laundry removed at any time during the anti-crease phase.

Rinse and interim spin:

Quick wash

Main wash Water level: low Wash rhythm: normal Rinsing Water level: medium No of rinses: 2 Spinning Rinse and interim spin1): yes Final spin: yes

There is a spin between the rinses.

Saturation

Before the wash process begins, water is taken into the drum in order to satura te the pillows. The water intake ceases when the machine begins the run-up to spinning which causes the air to be evacuated from the pillows. Subsequ

ent water intake for the main wash is through the j compartment.

Omitting rinse and interim spin: Select Without spin.

Detergent

All modern detergents produced for automatic washing machines are sui table, including liquid, compact (con centrated), tablets, liquid tablets and special application detergents. Use dis pensing aids, e.g. balls, if these are supplied with the detergent. Tablets are suitable for full loads but note that it may be impractical to reduce tablets for smaller loads. Some tablets do not dis solve as rapidly as others and may not be suitable for Quick wash program mes.

Silks, woollens and knitwear containing wool mixtures and hand-washable garments should be washed using a liquid detergent specifically designed for washing woollens. Do not use biological detergents on silk as the enzymes may damage the silk!

Instructions for use and recommended amounts for a full load are given on the detergent packaging.

Liquid detergent should be dispensed using a ball provided by the manufac turer for programmes without a pre-wash.

For programmes with a pre-wash you will need to purchase a special contai ner from the Miele Spare Parts depart ment which sits in the main wash com partment j of the detergent dispenser drawer. Add liquid detergent to this container for the main wash and to compartment i for the pre-wash.

The right amount to dispense will de pend on the following:

The quantity of laundry (follow the

–

machine’s dispensing recommenda

tion and reduce the amount of deter

gent with smaller loads as indicated on the display)

The soiling level of the laundry.

–

Lightly soiled Possibly slight body odour.

Normally soiled just a few slight stains.

Heavily soiled arly visible.

– The water hardness level. Check with

your local water supplier if you do not know the water hardness level in your area.

No visible dirt or stains.

Visibly dirty and/or

Stains and soiling cle

Water softeners

A water softener can be used to cut down on the use of detergents in extremely hard water areas. Dispense according to the amount specified on the packaging. First add detergent and then the water softener. Use a quantity of detergent as for soft water. Miele do not recommend connecting the machi ne to a household water softener.

Washing with several components

If you wash using several components (e.g. special application detergents), dispense them into compartment j in the following order:

1. Detergent

2. Water softener

3. Stain remover This way the agents are distributed more efficiently.

Detergent

Fabric conditioners and liquid starch

Fabric conditioners make garments soft to handle and help prevent static cling when tumble drying.

Liquid starch stiffens and gives body to items of laundry, e.g. shirts, tablecloths and bed linen. N.B. Do not use liquid

starch for allergy sufferers.

Dispense according to the amount

specified on the packaging.

Automatic dispensing of fabric conditioner or liquid starch at the end of a programme

If liquid starch is used, it is extremely important to ensure that any liquid starch residues are removed from the machine before it is used to wash items for allergy sufferers.

After using liquid starch:

1. Clean the dispenser compartment, siphon tube and conditioning chan nel. See "Cleaning the detergent dis penser drawer".

2. Run a

Hygiene + 60°C

with powder detergent but without a load to flush out the machine.

programme

Add the fabric conditioner or liquid starch to compartment §. Do not ex

ceed the maximum level mark.

It will be automatically dispensed in the last rinse. At the end of the programme a small amount of water remains in the fabric conditioner compartment §.

Locking functions

Electronic programme locking

Programme locking prevents the ma chine from being opened or the pro gramme cancelled during a wash programme.

To activate programme locking

After the start of a programme, press

the

Start

button for at least 4 seconds until the right on the control panel) comes on.

Programme locking is now activated. The machine will now not accept any

changes and the programme will proceed through to the end.

Programme locking is deactivated automatically at the end of the programme.

Locked

check light (lower

To deactivate programme locking

Now press the

4 seconds until the light (lower right on the control panel)

goes out Exception: If the programme selector has been

moved and the cator light is flashing in the sequence display.

First, turn the programme selector

back to the programme chosen pre

viously. The

tor light will go out. ^ Now press the

4 seconds until the

light (lower right on the control panel)

goes out.

Start

button for at least

Locked

check

Anti-crease/Finish

Start

button for at least

Locked

check

indi

indica

Locking functions

Electronic system lock

The system lock prevents your ma chine being used without your know ledge.

When the system lock has been activa ted:

the drum door cannot be opened

–

Door

with the a programme cannot be started.

–

To activate the system lock

Before you begin, first ensure that: – The drum door is closed – The programme selector is at A Switch the machine on with the

I-On/0-Off

B Press the

it pressed in while carrying out steps C to E.

button and

button.

Pre-wash

button and keep

Finish

E Next slowly turn the programme se

lector anti-clockwise to

Delicates cold

The

Locked

on the control panel) will flash.

F Then release the

G Turn the programme selector to the

Finish

H Switch the washing machine off with

the

I-On/0-Off

To deactivate the system lock

Repeat steps A to F. The check light will go out.

check light (lower right

position.

button.

stage by stage

Pre-wash

button.

Locked

C Slowly turn the programme selector

clockwise

Universal 60°C

D Now slowly turn the programme se

lector anti-clockwise to

Finish

stage by stage to

stage by stage

Cottons

Disconnect the machine from the

mains electricity supply and with draw the plug from the socket before cleaning the machine.

The washing machine must not

be hosed down.

External casing and fascia panel

Clean the casing with a mild

non-abrasive cleaning agent or soap and water using a well wrung-out cloth. Wipe dry with a soft cloth.

^ The drum can be cleaned using a

suitable proprietary stainless-steel cleaning agent following the manufacturer's instructions on the packaging.

Cleaning and care

Extra cleaning

Carry out a hot wash (70°C or above) with powder detergent approx. every 6 weeks to help prevent deposits building up in the machine. These can occur when washing is mainly done at low temperatures, and also lead to unplea sant smells. If you have no reason to wash occasionally at this high tempera ture, then run a Cottons 95°C program me with detergent but no laundry at re gular intervals.

Cleaning the detergent dispenser drawer

Remove detergent residues regularly.

Do not use solvents, abrasive cleaners, glass cleaners or all-purpose cleaning agents. These might damage plastic surfa ces and other components because of the chemicals they contain.

E-Cloth

A microfibre "E-Cloth" is available from the Miele UK Spare Parts Department, which is suitable for cleaning surfaces such as stainless steel, glass, plastic and chrome without the use of chemi cals. It can be washed 300 times.

Pull out the detergent dispenser dra wer until a resistance is felt. Press down the release catch and at the same time pull the drawer right out of the machine.

Clean the detergent drawer with warm water.

Cleaning and care

Clean the siphon.

1. Remove the siphon from compartment § and rinse under warm running water. Clean the siphon tube in the same way.

2. Replace the siphon.

If starching frequently, thoroughly clean the siphon and siphon tube regularly. A build-up of starch will cause them to get clogged.

Cleaning the detergent dispenser drawer housing

^ Use a bottle brush to remove deter-

gent residues and limescale from the jets inside the detergent dispenser drawer housing.

Cleaning and care

Cleaning the filter in the water inlet

The washing machine has a filter to protect the water inlet valve.

The accessible filter in the union in the open end of the inlet hose should be checked every six months, or more of ten if there are frequent interruptions to the external water supply.

First turn off the stopcock.

Unscrew the threaded union connec

ting the free end of the inlet hose to the stopcock.

^ Remove the rubber seal 1 from the

recess.

^ Using pointed pliers, take hold of the

plastic filter bar 2 and remove.

^ Clean the plastic filter. ^ Put the filter and seal back in the re-

verse order and reconnect the hose.

Turn on the stopcock and check the connection is watertight. If water drips out, tighten the connection.

Never forget to put the filter back in place after cleaning.

Problem solving guide

With the help of the following notes minor faults in the performance of the applian ce, some of which may result from incorrect operation, can be put right without contacting the Service Department.

Repair work to electrical appliances should only be carried out by a sui

tably qualified person in accordance with local and national safety regulations. Unauthorised repairs could be dangerous.

The programme does not start.

Problem Possible cause Remedy

The Anti-crease/Finish indicator light is not on, or the Start indicator light is not flashing.

The Locked check light is flashing.

There is no power. Check that

the mains plug is plugged

–

in.

– the fuse or circuit breaker

has not tripped.

The system lock has been activated.

Deactivate the system lock.

Problem solving guide

The wash programme stops and a fault indicator light comes on.

Problem Possible cause Remedy A

The buzzer sounds and the Check drain light flashes. "– – –" appears in the display.

The buzzer sounds and the Check inlet light flashes. "– – –" appears in the display.

The buzzer sounds and the Check inlet and Check drain lights are flashing. "– – –" appears in the display.

The buzzer sounds and the Soak/Pre-wash or Rinses indicator light is flashing. "– – –" appears in the display.

The drain outlet is blocked.

The drain hose has been fixed too high.

The water inlet is blocked.

The water protection system has reacted.

There is a fault. Start the programme again.

Clean the drain filter and the drain pump as described in "Problem solving guide - Ope ning the drum door in the event of a blocked drain outlet and/or power failure".

The maximum drain height is 1 m.

Open the stopcock.

Call the Service Department.

If the fault indicator occurs again, contact the Service De partment.

A To switch off the fault indicator: switch the washing machine off with the

I-On/0-Off

button and turn the programme selector to

Finish

Problem solving guide

A fault indicator light comes on but the wash programme continues as normal

Problem Possible cause Remedy A

The Check drain light flashes.

The Check inlet light flashes.

The Excess detergent check light comes on.

The Main wash indicator light is flashing.

The Anti-crease/Finish indicator light is flashing.

The drain outlet is restricted.

The water inlet is restricted.

The filter in the water inlet hose is dirty.

Excessive foam has built up during washing.

There is a fault. Start the programme again.

The position of the programme selector was altered af ter the start of the programme. Turn the programme se lector back to the programme previously chosen.

Clean the drain filter and the drain pump as described in "Problem solving guide - Opening the drum door in the event of a blocked drain outlet and/or power failure".

Check whether

the stopcock is opened wide

–

enough.

– the inlet hose is kinked. Clean the filter.

Use less detergent next time and follow the manufacturer’s instructions on dosage given on the packaging.

If the fault indicator occurs again, contact the Service Department.

A To switch off the fault indicator: switch the washing machine off with the

I-On/0-Off

button and turn the programme selector to

Finish

Problem solving guide

Problems with the load size indicator and the dispensing recommendation

Problem Possible cause Remedy

There is no load size in the display

A load size is indicated in the display but there is no laundry present in the drum.

No load size is indi cated in the display for the Delicates,

Silks and the Wool lens programmes.

The washing machine is not switched on and / or a pro gramme has not been selec ted.

The amount of laundry in the drum is less than 25% of the maximum load for the pro gramme selected.

When the washing machine was switched on there was already laundry in the drum. This has decalibrated the sensor from the zero position.

The load size sensor has been decalibrated from the zero position.

The maximum load is 1 kg for the

Delicates

grammes and 2kg for the

ollens

programmes. In some cases the load size sensor fails to register these small quantiti es. (The dispensing recom mendation will still show the minimum value of 40%).

and

Silks

pro

Switch the washing ma chine on. Select a pro gramme and load the

drum.

The display will come on when 25% has been loa ded.

Remove the laundry from the drum and press the button above the button until an audible tone sounds. The sensor is now recalibrated to zero.

Rotate the drum once. If the display does not go out, recalibrate the sensor to zero (see above section).

Rotate the drum once.

Start

Problem solving guide

General problems or an unsatisfactory wash result.

Problem Possible cause Remedy

The machine shakes during the spin cycle.

The laundry is not spun satisfactorily.

The pump makes strange noises.

The programme se lector light ring does not come on.

Large amount of detergent residues remain in the detergent dispenser drawer.

Fabric conditioner is not completely dispensed or too much water remains in the § compart ment.

When laundry is dry it feels hard to the touch.

The machine feet are not resting evenly on the flo or.

The spin speed selected was too low.

These do not indicate a fault. They occur at the end of a pump sequence as a normal part of the operation.

The machine has switched off the light ring to save ener

gy. To switch the light ring back on again: press one of the additional option buttons or turn the programme selector.

The water pressure is too low.

Powder detergent used in conjunction with water softeners tends to become sticky.

The siphon tube is either incorrectly positioned or clogged.

Too vigorous wash action. Programme in gentle action

Not enough detergent used.

No fabric conditioner used.

Level the machine (see "In stallation").

Select a higher spin speed next time.

– Clean the filter in the water

inlet.

In future add washing powder into the dispenser drawer first, and then add the water softener.

Clean the siphon, see “Cleaning and care - Cleaning the detergent dispenser drawer”.

and more water. Increase detergent dose to

prevent limescale build up in laundry.

Use fabric conditioner in last rinse.

Problem solving guide

Problem Possible cause Remedy

Liquid detergent does not give the required re sult.

Grey, greasy particles cling to washed laundry.

A stale smell is in the drum and on laundry.

White residues which look like powder detergent are seen on dark textiles after washing.

Machine is con stantly overfoa ming/excess de tergent light is on.

Clothes are co ming out crea sed.

Liquid detergents usu ally contain no blea ching agents. They do

not remove fruit, coffee and tea stains.

Insufficient amounts of detergent have been used to break down the particles of grease in heavily soiled laundry.

Low temperature washing.

The detergent contained compounds (zeolites) to aid water softening which are not soluble in water. They have ended up on the laundry.

Machine connected to

a water softener.

Too much detergent was used.

Too little detergent was used.

Programme was over

loaded. The wrong programme

was used.

Use a general purpose detergent

–

containing a bleaching agent. Pour stain removers into compart

–

ment j of the dispenser drawer and liquid detergent into a dispen ser ball.

Never put stain removers and li

–

quid detergent together in the dis penser drawer.

Use more detergent.

–

Before washing the next load run

–

Hygiene + 95°C

a with powder detergent but without a load.

Before washing the next load run a

Hygiene + 95°C

powder detergent but without a load. – Try and brush off the residues with

a soft brush once the laundry is dry.

– Use a liquid detergent to wash

dark coloured textiles. Liquid detergents usually contain no zeoli tes.

Connect machine to mains water and dose detergent for hard water.

Reduce detergent.

Increase detergent slightly to bring back foam suppressant ingredients.

Reduce quantity of clothes in drum.

–

Check care labels and the pro gramme chart.

–

Use easy iron conditioners.

programme

programme with

Problem solving guide

The drum door does not open when you press the Door button.

Possible cause Remedy

The machine is not con nected to the electricity supply.

The washing machine is not switched on.

The electronic program me lock has been activa ted.

The electronic system lock has been activated.

Power cut. Open the drum door as described in the section

The door was not correctly engaged.

There is still water in the drum and the machine is unable to drain.

For safety reasons the drum door cannot be opened if the suds temperature is higher than 55°C.

Put the plug in the socket and switch on.

Switch the machine on with the

This is automatically deactivated at the end of a

programme. To deactivate it early see "Electronic

programme locking". To deactivate it see "Electronic system lock".

"Opening the drum door in the event of a blocked drain outlet and/or power failure".

Press hard against the lock side of the drum door and then press the

Clean the drain filter and the drain pump.

Door

I-On/0-Off

button.

Problem solving guide

Opening the drum door in the event of a blocked drain outlet and/or power failure

Switch the washing machine off.

There is a lever behind the detergent drawer fascia panel.

^ Remove the lever.

Blocked drain outlet

If the drain outlet is blocked, up to 25 litres of water will be retained in the machine.

Caution: if laundry has been

washed at a high temperature, water draining out of the machine will still be hot. Danger of scalding!

Procedure for draining the machine

Place a suitable container under the

access flap.

When draining water from the machine, do not unscrew the drain filter completely or take it right out.

Use it to open the access flap.

Unscrew the drain filter lid until water runs out.

To interrupt the flow of water:

Tighten the drain filter back up again.

Problem solving guide

Once the flow of water ceases:

Remove the drain filter completely.

^ ^ Clean it thoroughly.

Make sure the drain filter is se

curely tightened. Otherwise there is a risk of water leakage during use.

Opening the drum door

Always make sure that the drum

is stationary before reaching into the machine to remove laundry. Rea ching into a moving drum is extre mely dangerous.

Remove any foreign objects (e.g. buttons, coins, etc.) and fluff from the filter housing. Turn the impeller by hand to check that it rotates freely. Any foreign object causing an ob struction should be removed.

Put the drain filter back in place and secure.

Pull the emergency release down wards (see illustration). The drum door will open.

Problem solving guide

Customer contact

In the event of any faults which you cannot remedy yourself please contact

Your Miele dealer or

–

Your nearest Miele Service Depart

–

ment (see back cover for the add ress).

When contacting your Dealer or the Service Department, please quote the model and serial number of your appli ance, both of which are shown on the data plate visible at the top inside of the door above the porthole glass when the door is open.

Optional accessories

Optional accessories for this washing machine are available from your Miele Dealer or from the Miele Spare Parts Department.

Please note that telephone calls may be monitored and recorded for trai ning purposes.

Installation and connection

Front view

a Inlet hose with "Waterproof" system b Electricity supply cable c - f Flexible drain hose (with deta

chable swivel elbow)

g Control panel

h Detergent dispenser drawer i Drum door

j Access to drain filter, drain pump

and emergency release

k Handle recesses for moving the ma

chine

l Four height adjustable feet

Rear view

Installation and connection

a Protruding lid for holding when mo

ving the machine

b Electricity supply cable c Inlet hose with "Waterproof" system d Drain hose

e Transit bar covers f Restraining clip for inlet hose and

drain hose

g Restraining clips for transit bars

when removed

Installation and connection

Installation surface

A concrete floor is the most suitable in stallation surface for a washing machi ne, being far less prone to vibration during the spin cycle than wooden flo orboards or a carpeted surface.

Please note the following points:

The machine must be level and se

curely positioned. To avoid vibrations during spinning,

the machine should not be installed

on soft floor coverings. If installing on a wooden joist floor: ^ We recommend a plywood base

(at least 59x52x3 cm). The base

should span several joists and be

bolted to the joists and not only to the

floorboards. Check for the presence

of pipes and cables. If possible, install the machine in a cor-

ner, as this is usually the most stable part of the floor.

Installing the washing machine

To manoeuvre the machine out of its

packing case to its installation site hold

it by the edge of the lid where it protru des to the rear of the washing machine

as well as by the handle recesses at the front.

Do not lift the machine by the drum door.

Ensure that the machine feet and

the floor are dry to prevent the ma chine from slipping during the spin cycle.

Removing the transit bars

If the machine is installed on a raised plinth, it has to be secured against slippage during spinning using retaining clips (available from the Miele Spare Parts Dept).

To remove the left and right covers

1. Use a screwdriver to prise out the cover as illustrated.

2. Pull the cover forwards to remove.

Installation and connection

Using the spanner supplied turn the

left-hand transit bar 90°, then

withdraw the transit bar.

Turn the right-hand transit bar 90°,

then

withdraw the transit bar.

Installation and connection

Fit the covers on to the two holes.

Then plug the holes as shown with the caps.

The washing machine must not

be moved without the transit bars in place. Store the transit bars as shown or keep them in a safe place for future use. They must be re-fitted if the ma chine is to be moved again (e.g.when moving house).

Re-fitting the transit bars

Re-fitting is carried out by reversing the procedure.

Secure the transit bars to the back of the washing machine. Make sure that holes b are fitted over retainers a.

Levelling the machine

The machine must stand perfectly level on all four feet to ensure safe and pro per operation.

Installation and connection

Using the spanner supplied turn

counter nut 2 in a clockwise direc tion. Then turn counter nut 2 together with foot 1 to unscrew.

Incorrect installation may increase electricity and water consumption and may cause the machine to move about.

False values may also show in the Load and Detergent display.

Screwing out and adjusting the feet

The four adjustable screw feet are used to level the machine. All four feet are screwed in when the machine is deli vered.

^ Use a spirit level to check the machi-

ne is standing level.

^ Hold foot 1 securely with a pipe

wrench. Turn counter nut 2 again using the spanner supplied until it sits firmly up against the housing.

All four counternuts must be firmly up against the housing. Please also check this for the feet which did not need adjustment. Otherwise there is the danger of the machine moving about.

Installation and connection

Building under a continuous worktop/in a kitchen run

A special building under conversion

–

kit* is required. The machine lid must be replaced by a cover plate. To ensure electrical sa

fety the cover plate must be fitted. N.B. If you wish to push your machine under

a worktop and there is space to do this without removing the lid, the conver sion kit is not necessary. Otherwise the conversion kit is essential.

– For installation under a work surface

900/910 mm from the floor, a raising

kit* is required. – Connections for electricity, water and

drainage should be installed in such

a way that they remain accessible

when the machine is in place. Fitting instructions are supplied with the

conversion kit. All parts marked* are available from the

Miele Spare Parts or Sales Department.

The fitting of building under kits and stacking kits must only be underta ken by qualified and competent per sons, in accordance with the instruc tions supplied with the kit.

Washer and Dryer stack

A Miele tumble dryer can be stacked with the washing machine. A stacking kit* is necessary and can be purchased from the Miele Spare Parts Department.

Please note

a Safety distance to wall:

at least 2 cm

b Height:

Stacking kit with pull-out shelf: approx. 169 cm Stacking kit without pull-out shelf: approx. 170 cm

The load size sensor must be cali brated to zero after the washing ma chine has been installed and con nected. See "Before using for the first time".

Replacing the lid

If the lid has been removed in order to fit a stacking kit or cover plate, ensure that, if the lid is replaced, it fits securely into the rear holders. Otherwise, it is not properly secure for transport.

Installation and connection

The Miele Waterproof system

The Miele Waterproof system protects the washing machine from water dama ge.

The system consists of three main com ponents:

1) the inlet hose

2) the electronic unit and the washing

machine housing

3) the drain hose

1) Inlet hose

– The inlet hose is fitted with an addi-

tional electrical safety valve which

works like an automatic stopcock

and is housed in the inlet hose con-

nection box. – It is pressure tested to between

7,000 and 10,000 kPa. – The inlet hose has a protective slee-

ve.

2) Electronic unit and washing machine housing

Sump

–

Any leaking water is collected in a

sump in the base of the machine. A float switches off the safety valves, preventing any more water from flo wing into the machine and water in the suds container is pumped away.

Overflow protection

–

This prevents the washing machine taking in too much water. If the water level exceeds a certain level, the drain pump switches in and pumps the excess water away.

3) Drain hose

The drain hose is protected by a ventilation system which prevents the washing machine from being emptied completely.

Any leaking water from the inlet hose is fed into the sump through this pro tective sleeve. A float switches off the safety valve, preventing any more water from flowing into the machine and water in the suds container is pumped away.

Installation and connection

Connection to the water supply

The plastic casing of the safety

valve contains electrical compo nents. The Waterproof system must only be connected to its own stop cock. It must not be connected to mixer taps or similar and must not be fitted in areas where there is the risk of water or other liquids rea ching it.

Do not get wet.

The machine should be connected to the mains water supply in accordance with local and national safety regula tions. The German authorities do not re quire it to have a non-return valve as the washing machine has been desig ned to comply with DIN regulations.

The machine is designed to operate with a flow pressure of between 100 and 1,000 kPa (1-10 bar). If it is higher than 1,000 kPa it is essential to fit a pressure reducing valve.

Connection to the mains water supply should incorporate a mains stopcock

with

/4" thread. The stopcock should

be fitted by a qualified plumber.

The connection point is subject

to mains water pressure. Turn on the stopcock slowly and check for leaks. Correct the position of the washer and union if appropriate.

The washing machine is not suitable for connection to a hot water supply and connection to a household water softener is not recommended.

The protective sleeve of the hose must not be damaged or kinked.

Maintenance and care

If you intend to unscrew the Miele Waterproof system hose from the stop cock it is essential to disconnect the machine from the electricity supply first.

Only use a Miele Waterproof system hose should you need a replacement.

Installation and connection

In order to protect the water inlet val ve, the dirt filter in the water inlet val ve connection must not be removed.

Extension hose

A 1.5 metre long (metal) extension hose is available from your Miele dealer or the Miele Spare Parts Department as an optional extra.

This hose is tested to withstand pressures of up to 14,000 kPa and can be used as a flexible extension to the water supply.

N.B. Using this hose renders the Waterproof system safety valve on the inlet hose ineffective.

Installation and connection

Connection to the drainage system

The machine drains via a drain pump with a delivery head of 1 metre*.

The drain hose must not be kinked as this restricts drainage. The swivel elbow at the end of the hose can be turned in either direction, or can be detached if required, with a sharp twist and pull.

If required, the drain hose can be ex tended to a length of 5 m. The neces sary parts can be purchased from the Miele Spare Parts Department or your Miele dealer.

* For a delivery head of more than 1 m (up to a maximum of 1.8 m) a second duo-drain pump is available with the corresponding kit from the Miele Spare Parts Department or your Miele Dealer.

Drain hose connection:

1. Direct into a sink or basin:

Please note the following

Hook the hose over the edge and se

–

cure. Make sure that the water can drain

–

away freely without hindrance. Other wise there is a risk of water overflo wing or of some of the drained water being sucked back into the machine.

2. Connected securely to a plastic drain pipe with a rubber nipple. There is no need to use a non-return valve.

3. Connected securely to a standpipe.

4. Connected securely to a floor gully.

Installation and connection

Electrical connection U.K.

All electrical work should be carried out by a suitably qualified and competent person, in strict accordance with natio nal and local safety regulations.

Ensure power is not supplied to the appliance until after installation work has been carried out.

The appliance is supplied with a mains cable with moulded plug ready for con nection to a 230-240V mains supply.

The voltage and connected load are given on the data plate. Please ensure

these match the household mains supply. The fuse rating is quoted on the plug.

Connection should be made via a suitable switched socket which is easily accessible after installation.

For extra safety it is advisable to install a residual current device (RCD), with a trip current of 30 mA (in accordance with DIN VDE 0664, VDE 0100 Section

739).

Non-rewireable plugs BS 1363

The fuse cover must be refitted when changing the fuse, and if the fuse cover is lost, the plug must not be used until a

suitable replacement is obtained. The colour of the correct replacement cover is that of the coloured insert in the base of the plug, or the colour that is embos sed in words on the base of the plug (as applicable to the design of plug fit

ted). Replacement fuses should be ASTA ap

proved to BS 1362 and have the cor rect rating. Replacement fuses and fuse covers may be purchased from your local electrical supplier.

WARNING: THIS APPLIANCE MUST BE EARTHED

Do not connect via an extension lead. Extension leads do not guarantee the required safety of the appliance (e.g. danger of overheating).

Consumption data

Load Consumption data

Energy Water Duration

in kWh in litres Normal Intensive

Hygiene +

95°C 5.0 kg 1.70 60 1 h 39 min 1 h 54 min

Hygiene +

60°C 5.0 kg 1.30 69 1 h 51 min 2 h 06 min

Cottons Universal

60°C 60°C 5.0 kg 0.95 60 1 h 31 min 2 h 01 min

40°C 40°C 5.0 kg 0.50 60 1 h 31 min 2 h 01 min

Minimum iron

40°C 40°C 2.5 kg 0.45 55 1 h 18 min 1 h 33 min

Delicates

30°C 1.0 kg 0.35 67 48 min 58 min

Silks /

30°C 1.0 kg 0.24 41 36 min –

Woollens /

30°C 2.0 kg 0.23 37 40 min –

First wash

30°C 3.0 kg 0.35 32 57 min –

Pillows

60°C 1 or 2 pillows 1.00 60 1 h 00 min –

5.0 kg 0.95 60 – 2 h 01 min

5.0 kg 0.50 60 – 2 h 01 min

2.5 kg 0.45 55 – 1 h 33 min

EN 60456 test programme

Note for test institutes:

For testing in accordance with EN 60456 you must use the

Intensive

option.

Consumption data can vary from the nominal values given depending on water pressure, water hardness, water inlet temperature, room temperature, type and volume of load, fluctuations in the electricity supply and any Extras selected.

Technical data

Height 85.0 cm Width 59.5 cm Depth 58.0 cm Depth with door open 97.5 cm Weight 93 kg Maximum floor load 1600 Newton (approx. 160 kg) Capacity 5 kg dry laundry Voltage see data plate Rated load see data plate Fuse rating see data plate Consumption data see "Consumption data" Water flow pressure minimum 100 kPa (1 bar) Water flow pressure maximum 1000 kPa (10 bar) Inlet hose length 1.60 m Drain hose length 1.50 m Connection cable length 1.60 m Delivery head max. 1.00 m Drain pump length max. 5.00 m Test certificates awarded Radio / TV suppression, VDE

Programmable functions for changing standard settings

Programmable functions

The programmable functions can be used to tailor washing programmes to suit your individual requirements.

The programmable functions are activa ted with the help of the additional op tion buttons and the programme selec tor.

Increasing the water level

The water level in the main wash can be increased for the

tons Universal

programmes.

Follow steps A to G to programme and store in memory.

Before you begin, first ensure that: – The washing machine is switched off. – The drum door is closed. – The programme selector is at

Hygiene +,Cot

and the

Minimum iron

Finish

A Press the additional option buttons

Intensive

time, hold pressed in and . . .

B . . . switch the machine on with the

I-On/0-Off

C Let go of all these buttons. P 0 appe

ars in the display.

D Turn the programme selector to

cates 30°C

E The P will now flash in the display al

ternating with the number 2

In addition, one of the following will ap pear on the right of the display:

0 = increased water level is

deactivated

or: 1 = increased water level is activated F Press the

display from 0 to 1 or from 1 to 0.

G Switch the washing machine off with

the

and

button.

Start

I-On/0-Off

Rinse plus

button to change the

button.

at the same

Deli

The setting you have selected is now stored in memory and will remain so un til you alter it.

Programmable functions

Introducing an additional rinse for the Hygiene + and Cottons Universal programmes

An additional rinse is always carried out as standard in the

Cottons Universal

If the additional rinse programmable function has been activated four instead of three are carried out.

If the

Rinse plus

also selected, five out.

Follow steps A to G to programme and store in memory.

Before you begin, first ensure that: – The washing machine is switched off. – The drum door is closed. – The programme selector is at

additional option is

Hygiene +

programmes.

rinses

rinses are carried

Finish

and

A Press the additional option buttons

Intensive

time, hold pressed in and . . .

B . . . switch the machine on with the

I-On/0-Off

C Let go of all these buttons. P 0 appe

ars in the display. P 0

D Turn the programme selector to

Quick wash 40°C

E The P will now flash in the display al

ternating with the number 8.

In addition, one of the following will ap pear on the right of the display:

0 = additional rinse is deactivated

or: 1 = additional rinse is activated F Press the

display from 0 to 1 or from 1 to 0.

G Switch the washing machine off with

the

and

button.

Start

I-On/0-Off

Rinse plus

button to change the

button.

at the same

Programmable functions

Gentle action

Activating gentle action reduces the drum action and is suitable for washing slightly soiled items more gently. It should be activated for gar ments with a single bar under the care label and for articles which feel too hard after they have been dried.

If "Gentle action" is programmed into the machine, every wash cycle in the

Hygiene +

grammes will be carried out with gentle action rhythm.

The washing machine is delivered with the Gentle action setting de-activated.

Follow steps A to G to programme and store in memory.

Before you begin, first ensure that: – The washing machine is switched off. – The drum door is closed. –

The programme selector is at

and

Cottons Universal

pro

Finish

A Press the additional option buttons

Intensive

time, hold pressed in and . . .

B . . . switch the machine on with the

I-On/0-Off

C Let go of all these buttons. P 0 appe

ars in the display.

D Turn the programme selector to

wash

E The P will now flash in the display al

ternating with the number 9.

In addition, one of the following will ap pear on the right of the display:

0 = Gentle action is deactivated.

or: 1 = Gentle action is activated. F Press the

display from 0 to 1 or from 1 to 0.

G Switch the washing machine off with

the

The setting you have selected is now stored in memory and will remain so un til you alter it.

and

button.

Start

I-On/0-Off

Rinse plus

button to change the

button.

at the same

First

Programmable functions

Top-up rinse for Hygiene + 95°C and Pillows hygiene 95°C

When this is activated, additional water flows into the drum at the end of the main wash to cool the suds down. Hot suds can damage plastic drainage pipes.

Top-up rinse should be activated:

to prevent the danger of scalding if

–

the drain hose is hooked over the edge of a sink or basin.

where the drainage pipes do not

–

comply with DIN 1986.

The washing machine is delivered with the Top-up rinse deactivated.

Follow steps A to G to programme and store in memory.

Before you begin, first ensure that: – The washing machine is switched off. –

The drum door is closed.

–

The programme selector is at

Finish

A Press the additional option buttons

Intensive

time, hold pressed in and . . .

B . . . switch the machine on with the

I-On/0-Off

C Let go of all these buttons. P 0 appe

ars in the display.

D Turn the programme selector to

lows hygiene 60°C

E The P will now flash in the display al

ternating with the number 10.

In addition, one of the following will ap pear on the right of the display:

0 = Top-up rinse is deactivated

or: 1 = Top-up rinse is activated F Press the

display from 0 to 1 or from 1 to 0.

G Switch the washing machine off with

the

The setting you have selected is now

stored in memory and will remain so un til you alter it.

and

button.

Start

I-On/0-Off

Rinse plus

button to change the

button.

at the same

Pil

Programmable functions

Memory function

If an additional option is selected for a programme, and / or the spin speed is altered, the machine stores these changes in memory at the start of a programme.

When that particular programme is cho sen again, the display will show the ad ditional options and / or spin speed which have been stored for that pro gramme in the memory.

The washing machine is delivered with the memory function deactivated.

Follow steps A to G to programme and store in memory.

Before you begin, first ensure that: – The washing machine is switched off. – The drum door is closed. – The programme selector is at

Finish

A Press the additional option buttons

Intensive

time, hold pressed in and . . .

B . . . switch the machine on with the

I-On/0-Off

C Let go of all these buttons. P 0 appe

ars in the display.

D Turn the programme selector to

lows hygiene 95°C

E The P will now flash in the display al

ternating with the number 11.

In addition, one of the following will ap pear on the right of the display:

0 = the memory function is

deactivated.

or: 1 = the memory function is activated. F Press the

display from 0 to 1 or from 1 to 0.

G Switch the washing machine off with

the

and

button.

Start

I-On/0-Off

Rinse plus

button to change the

button.

at the same

Pil

The setting you have selected is now stored in memory and will remain so un til you alter it.

Programmable functions

Buzzer

When the buzzer function has been activated, an audible tone sounds at the end of a programme or when Rin se hold is reached.

The buzzer will sound for up to an hour after the programme has finished.

The washing machine is delivered with the buzzer deactivated.

Follow steps A to G to programme and store in memory.

Before you begin, first ensure that: – The washing machine is switched off. – The drum door is closed. – The programme selector is at

Finish

A Press the additional option buttons

Intensive

time, hold pressed in and . . .

B . . . switch the machine on with the

I-On/0-Off

C Let go of all these buttons. P 0 appe

ars in the display.

D Turn the programme selector to

ene + 60°C

E The P will now flash in the display al

ternating with the number 20.

In addition, one of the following will ap pear on the right of the display:

0 = buzzer is deactivated.

or: 1 = buzzer is activated.

F Press the

display from 0 to 1 or from 1 to 0.

G Switch the washing machine off with

the

and

button.

Start

I-On/0-Off

Rinse plus

button to change the

button.

at the same

Hygi

686970

The setting you have selected is now stored in memory and will remain so un til you alter it.

Alteration rights reserved/2106/medicwash W 2585 WPS

M.-Nr. 06 153 310 / 01

en-CN

Miele W 2585 WPS Medicwash Operating instructions

Specifications and Main Features

Frequently Asked Questions

User Manual
