Miele KFNS 3917 S ed Operating and Installation Instruction

Operating and installation instructions

Refrigerator with StayFresh section

FNS 3917 S ed

To avoid the risk of accidents or damage to the appliance, it is essential to read these instructions before it is installed or used for the first time.

Contents

Guide to the appliance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Caring for the environment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Warning and Safety instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

How to save energy . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Switching on and off . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Safety lock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Switching off for longer periods of time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

The correct temperature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

. . . in the refrigerator section and in the StayFresh zone . . . . . . . . . . . . . . . . . . . 15

Setting the temperature in the refrigerator section . . . . . . . . . . . . . . . . . . . . . . . . 15

Temperature range . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Setting the temperature in the StayFresh zone . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Temperature display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Temperature display brightness . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Alarm. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Switching the alarm off early . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Switching on the alarm system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Super cool . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

Using the refrigerator efficiently. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

Different storage zones . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

Warmest area . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

Coldest area . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

StayFresh zone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

Low humidity level , . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

High humidity level - . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Food which should not be stored in a refrigerator. . . . . . . . . . . . . . . . . . . . . . . . . 21

Storing food correctly. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

Fruit and vegetables. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

Different types of unpacked meats and vegetables must be kept separate.. . 22

Protein rich foods . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

Meat . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

Adjusting the interior fittings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

Automatic defrost . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

Refrigerator section and StayFresh zone. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

Contents

Cleaning and care . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

Cleaning the outer casing, the interior and accessories . . . . . . . . . . . . . . . . . . . . 25

Ventilation gaps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

Door seal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

Problem solving guide. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

Noises . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

After sales service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

Electrical connection. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32

Location . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32

Climate range . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32

Side-by-side installation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32

Ventilation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32

Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

Aligning the appliance. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

Changing the door hinging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34

StayFresh zone compartments . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37

Building in the appliance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38

Guide to the appliance

a Safety lock indicator light b On/Off button c Temperature display

d Controls for setting the temperature

left hand button: warmer right hand button: colder

e Super cool button and

indicator light

f Alarm off button

a Interior lighting b Butter and cheese compartment c Egg tray d Shelf e Fruit and vegetable containers f Bottle shelf

g StayFresh zone, dry compartment h Condensate channel and

drain hole

i Control for setting the moisture level

in the humidity controlled compartment

Guide to the appliance

j StayFresh zone, humidity controlled

compartment

Caring for the environment

Disposal of the packing material

The transport and protective packing has been selected from materials which are environmentally friendly for disposal, and can normally be recycled.

Ensure that any plastic wrappings, bags etc. are disposed of safely and kept out of the reach of babies and young children. Danger of suffocation!

Rather than just throwing these materials away, please ensure that they are recycled.

Disposal of your old appliance

Please ensure that the appliance presents no danger to children while being stored for disposal.

It should be unplugged or disconnected from the mains electricity supply by a competent person. The plug must be rendered useless and the cable cut off directly behind the appliance to prevent misuse. See the "Warning and Safety" section of this booklet for further details.

Electrical and electronic appliances often contain materials which, if handled or disposed of incorrectly, could be potentially hazardous to human health and to the environment. They are, however, essential for the correct functioning of your appliance.

Please dispose of your old appliance at your local community waste collection / recycling centre and not with your household waste.

Take care not to damage the pipework at the back of it before or during transportation to an authorised collection depot. In this way, refrigerant in the pipework and oil in the compressor will be contained, and will not leak out into the environment.

Warning and Safety instructions

This appliance complies with all relevant legal safety requirements. Improper use can, however, present a risk of both personal injury and material damage.

To avoid the risk of accidents and damage to the appliance, read these instructions carefully before installation and before using for the first time. They contain important notes on the installation, safety, operation and care of the appliance.

Keep these instructions in a safe place and pass them on to any future user.

Correct use

This appliance is intended for

domestic use only for the cool storage of food and drink. Any other usage is not supported by the manufacturer and could be dangerous. The manufacturer cannot be held liable for damage caused by incorrect or improper use of the appliance.

This appliance is not a toy! To avoid the risk of injury, do not allow children to play on or near it, or to play with the controls. Supervise its use by the elderly or infirm.

Technical safety

This appliance contains the coolant

Isobutane (R600a), a natural gas which is environmentally friendly. Although it is flammable, it does not damage the ozone layer and does not increase the greenhouse effect. The use of this coolant has, however, led to a slight increase in the noise level of the appliance. In addition to the noise of the compressor, you might be able to hear the coolant flowing around the system. This is unavoidable, but does not have any adverse effect on the performance of the appliance. Care must be taken during transportation and setting up of the appliance that no parts of the cooling system are damaged. Leaking coolant can damage the eyes. In the event of any damage:

- avoid open fires and anything which creates a spark,

- disconnect from the mains,

- air the room in which the appliance is located for several minutes and

- contact the Service Department for advice.

The more coolant there is in an

appliance, the larger the room it should be installed in. In the event of a leakage, if the appliance is in a small room, there is the danger of combustible gases building up. For every 8 g of coolant at least 1 m room space is required. The amount of coolant in the appliance is stated on the data plate inside the appliance.

Warning and Safety instructions

Before connecting the appliance to

the mains supply make sure that the rating on the data plate corresponds to the voltage and frequency of the household supply. This data must correspond in order to avoid the risk of damage to the appliance. Consult a qualified electrician if in any doubt.

The electrical safety of this

appliance can only be guaranteed when continuity is complete between the appliance and an effective earthing system which complies with local and national safety regulations. It is most important that this basic safety requirement is present and regularly tested, and where there is any doubt, the household wiring system should be inspected by a qualified electrician. The manufacturer cannot be held liable for the consequences of an inadequate earthing system (e.g. electric shock).

Safe operation of the appliance is

only assured if it has been installed and connected in accordance with these operating and installation instructions.

This equipment may only be used

in mobile installations such as ships, caravans, aircraft etc. if a risk assessment of the installation has been carried out by a suitably qualified engineer.

Installation work, maintenance and

repairs may only be carried out by suitably qualified and competent persons in accordance with current national and local safety regulations. Repairs and other work by unqualified persons could be dangerous and the

manufacturer will not be held liable. Ensure current is not supplied to the appliance until after maintenance or repair work has been carried out.

The appliance is only completely isolated from the electricity supply

when:

it has been switched off at the wall

–

socket and the plug has been withdrawn, or

the mains fuse is withdrawn, or

–

the screw-out fuse is removed (in

–

countries where this is applicable).

Do not connect the appliance to

the mains electricity supply by an extension lead. Extension leads do not guarantee the required safety of the appliance (e.g. danger of overheating).

Use

Do not store explosive materials in

the appliance or any products containing propellants (e.g. spray cans). Thermostats switching on may produce sparks which could present a fire hazard. Flammable compounds could explode.

Do not use any electrical

equipment in this appliance, e.g. ice cream makers. Danger of sparking and explosion!

If storing alcohol with a high

percentage proof, make sure it is tightly closed and stored upright. Danger of explosion.

Warning and Safety instructions

Observe the "use by" dates given

on food to avoid the risk of food poisoning. Storage times will depend on several factors, including the freshness and quality of the food as well as the temperature at which it is stored. Follow the instructions given on food manufacturer’s packaging on storage conditions required, as well as the "use by" date.

Do not use sharp edged objects to

remove frost and ice,

– – separate food which has become

frozen. They will damage the evaporator, causing irreversible damage to the appliance.

Do not use defrosting sprays or

de-icers, as they might contain substances which could damage the plastic parts or which could cause a build-up of gases and pose a danger to health.

Do not use any oils or grease on

the door seal, as these will cause the seal to deteriorate and become porous with time.

The appliance is designed for use

within certain climate ranges (ambient temperatures), and should not be used outside this range. The climate range for your appliance is stated on the data plate inside the appliance. Installing it in a room with too low an ambient temperature, e.g. a garage, will lead to the appliance switching off for longer periods so that it cannot maintain the required temperature.

Do not use a steam-cleaning

appliance to clean this appliance. Pressurised steam could reach the electrical components and cause a short circuit.

In countries where there are areas

which may be subject to infestation by cockroaches or other vermin, pay particular attention to keeping the appliance and its surroundings in a clean condition at all times. Any damage which may be caused by cockroaches or other vermin will not be covered by the guarantee.

If storing bottles of oil or food

containing high levels of fat or oil in the appliance, take care not to let the fat or oil come into contact with plastic components. These can cause stress cracks to occur in the plastic components.

Do not block the ventilation gaps in

the appliance as this would impair the efficiency of the appliance, increase the electricity consumption and could cause damage to the appliance.

Warning and Safety instructions

Disposal of your old appliance

Before disposing of an old

appliance, first make the door latch or lock unusable. This way you will prevent children from accidentally locking themselves in and endangering their lives.

Disconnect the appliance. Cut off

the cable and render any plug unusable.

Be careful not to damage any part

of the pipework whilst awaiting disposal, e.g. by

– puncturing the refrigerant channels

in the evaporator. – bending any pipework. – scratching the surface coating. Splashes of refrigerant can damage the

eyes.

The manufacturer cannot be held liable for damage caused by non-compliance with these Warning and Safety instructions.

How to save energy

Normal energy consumption Increased energy

consumption

Installation site In a ventilated room. In an enclosed, unventilated room.

Protected from direct sunlight. In direct sunlight. Not situated near to a heat source

(radiator, oven). Where the ambient room

temperature is ideal at approx. 20°C.

Temperature setting with a thermostat which is approximate (set in stages).

Temperature setting with a thermostat which is exact to the degree (digital display).

Use Only open the door when

With a medium setting of 2 to 3. With a high setting: The lower the

Cellar section 8 to 12°C On appliances with winter setting,

Refrigerator section 4 to 5 °C StayFresh zone just above 0 °C Freezer section -18°C

necessary and for as short a time as possible.

Store food in an organised way. If food is not stored in an

Allow hot food and drinks to cool down before placing them in the appliance.

Store food covered or packaged. The evaporation or condensation

Place frozen food in the refrigerator to defrost.

Do not over-fill the appliance to allow air to circulate.

Situated near to a heat source (radiator, oven).

Where there is a high ambient room temperature.

temperature in the appliance, the higher the energy consumption.

please make sure that the winter setting is switched off when the ambient temperature is warmer than 16 °C.

Frequent opening of the door for long periods will cause a loss of coldness.

organised way, searching for an item will mean the door is open for longer.

Placing hot food in the appliance will cause the compressor to run for a long time, as the appliance will have to work harder to lower the temperature.

of liquids will cause a loss of coldness in the refrigerator.

How to save energy

Normal energy consumption

Defrosting Defrost the freezer when a layer of

ice one centimetre thick has built up.

Increased energy consumption

A layer of ice hinders the cold from reaching the frozen food, and causes an increase in energy consumption.

Switching on and off

Before using for the first time

The stainless steel surface has a layer of protective foil to prevent scratching during transportation.

Do not remove this foil until the

appliance has been installed or built in. Start at one of the upper corners.

Clean stainless steel surfaces with a

suitable conditioning agent for stainless steel.

Clean the inside of the appliance and

the accessories with warm water and a little washing up liquid, and then dry with a soft cloth.

Important: To ensure the correct functioning of the appliance, let it stand for between 1½ and 2 hour after transporting it to its final location before connecting it to the mains.

Switching on

Switching off

Press the On/Off button until the

temperature display goes out.

The cooling system is switched off. (If this does not happen, the safety lock is still activated).

Safety lock

The safety lock can be activated to prevent the appliance being switched off inadvertently.

Activating or de-activating the safety lock

^ Press and hold the Super cool button

for approx. 5 seconds.

The Super cool indicator light flashes and a

; flashes in the temperature

display.

Press the On/Off button.

The temperature display lights up, the appliance starts cooling. The interior light will come on when the door is opened.

Allow the appliance to run for a few hours before placing food in it. This will ensure that the temperature is sufficiently low.

Press the Super cool button again.

; lights up in the temperature display.

You can now choose between and

; 1 by pressing the temperature

selector buttons:

0: the safety lock is de-activated, 1: the safety lock is activated.

Press the Super cool button to save the setting.

; 0

Switching on and off

The safety lock indicator light X will light up when the safety lock has been activated.

Press the On/Off button to come out

of the setting mode.

Otherwise the electronics will revert to normal operation after a couple of minutes.

Switching off for longer periods of time

If the appliance is not going to be used for a longer period of time, e.g. whilst on holiday,

^ switch the appliance off, ^ switch off at the wall socket and

withdraw the plug,

^ clean the appliance out and ^

leave the door ajar to air the appliance.

If, during a long absence, the appliance is switched off but not cleaned out and the door is left shut there is a danger of mould and odours building up inside the appliance.

The correct temperature

It is very important to set the correct temperature for storing food in the appliance. Micro-organisms will cause food which is not stored at the correct temperature to deteriorate rapidly. Temperature influences the growth rate of these micro-organisms. Reducing the temperature reduces their growth rate.

The temperature in the appliance will rise:

the more often the door is opened

–

and the longer it is kept open, – if too much food is stored in it at

once, – the warmer the food is which is being

put into it, – the higher the ambient temperature

surrounding the appliance.

The appliance is designed for use in

specific ambient temperatures

(climate ranges). Do not use in

ambient temperatures for which it is

not designed.

. . . in the refrigerator section and in the StayFresh zone

Setting the temperature in the refrigerator section

Use the two buttons underneath the temperature display to set the temperature for the refrigerator section.

Press the

left hand button: to raise the

temperature

right hand button: to reduce the

temperature

The temperature being set will flash in the display.

After setting the temperature you can see the following information in the display by pressing the buttons:

– When first pressed, the last

temperature selected flashes.

– Each subsequent press of the button

adjusts the temperature shown in 1 °C steps.

–

Keeping the button pressed in adjusts the temperature continually.

We recommend a temperature of 4 °C in the refrigerator section.

The temperature in the StayFresh zone is controlled automatically and is maintained at approx. 0 °C.

Approx. 5 seconds after letting go of the button the display will change to show the current average temperature.

The correct temperature

If you have adjusted the temperature,

wait for approx. 6 hours if the appliance is not very full and for approx. 24 hours if the appliance is full, before checking the temperature

display as it will take this long for the display to show the accurate temperature of the appliance. If, after this time, the temperature is still too high or too low, you will need to adjust it again.

Temperature range

The temperature can be adjusted from: 4 °C to 9 °C

The ambient temperature in the room and the installation location can affect the time it takes for the appliance to reach the lowest temperature. If the ambient temperature is too high, the appliance may not reach the lowest temperature.

Setting the temperature in the StayFresh zone

Press one of the temperature selector

buttons repeatedly until a in the display. Press the Super cool button again.

= appears

= lights up in the display.

You can now adjust the temperature

in the StayFresh zone by pressing the temperature selector buttons. You can choose from settings 1 to 9:

1: lowest temperature, 9: highest temperature.

= 5 is the default setting for the

StayFresh zone. If a setting of

= 1 to

= 4 is selected, the temperature

can fall below 0°C. Food could freeze!

^ Press the Super cool button to save

the setting.

The temperature in the StayFresh zone is automatically held at approx. 0 °C. It can be raised or lowered, e.g. if you want to use it for storing items like fish.

Press and hold the Super cool button for approx. 5 seconds.

The Super cool indicator light flashes and a

; flashes in the temperature

display.

Press the On/Off button to come out of the setting mode.

Otherwise the electronics will revert to normal operation after a couple of minutes.

The correct temperature

Temperature display

During normal operation, the temperature display on the control panel shows the average temperature in the refrigerator section.

If the temperature is not within the range that the appliance is able to display (0 °C to 19 °C), bars will flash in the temperature display.

The temperature display will flash, if

a different temperature is being set,

–

the temperature in the appliance has

–

risen by several degrees, indicating

that the appliance is warming up too

much. This loss of coldness is no cause for

concern if it is due to the door being left open for a while, e.g. for removing or storing a large amount of food.

Temperature display brightness

The Super cool indicator light flashes and a

; flashes in the temperature

display.

Press one of the temperature selector

buttons repeatedly until an in the display.

Press the Super cool button again.

^ appears

^ lights up in the temperature display.

^ You can now adjust the level of

brightness by pressing the temperature selector buttons. You can choose from settings 1 to 5:

1: lowest setting, 5: brightest setting.

^ Press the Super cool button to save

the setting.

The appliance is supplied with the brightness of the temperature display set as low as possible. However, if the door is opened, a setting changed or if the alarm is sounding, the temperature display will appear much brighter for approx. 1 minute.

You can adjust the level of brightness:

Press and hold the Super cool button pressed in for approx. 5 seconds.

Press the On/Off button to come out of the setting mode.

Otherwise the electronics will revert to normal operation after a couple of minutes.

Alarm

Your appliance has been fitted with an alarm to avoid energy being wasted if the door is left open and to prevent stored food becoming too warm.

The alarm will sound if the door is left open for more than approx. 60 seconds. The alarm will stop as soon as the door is closed.

If you want to keep the door open for more than approx. 60 seconds, intentionally, we recommend that you switch the alarm off.

Switching the alarm off early

Press the alarm button.

The alarm will stop.

Switching on the alarm system

The alarm system switches back on automatically as soon as the door is closed. It does not have to be switched on manually.

Super cool

The Super cool function can be used to rapidly reduce the temperature in the refrigerator section to its lowest setting (depending on the room temperature).

Switching on Super cool

Super cool is particularly recommended for faster chilling of large amounts of fresh food or drink.

^ Press the Super cool button. The

Super cool indicator light will come on.

The appliance works at full power to lower the temperature in the appliance.

Switching off Super cool

The Super cool function switches itself off automatically after approx. 6 hours. The indicator light goes out and the appliance continues running at normal power.

To save energy, the Super cool function can be switched off once food and drinks are sufficiently chilled.

Press the Super cool button. The

Super cool indicator light will go out, and the appliance will continue to operate at normal power.

Using the refrigerator efficiently

Different storage zones

Due to the natural circulation of the air in the appliance, there are different temperature zones in the refrigerator section. Cold, heavy air sinks to the lowest section of the appliance. Make use of the different zones when placing food in the appliance.

Do not store explosive materials in the appliance or any products containing propellants (e.g. spray cans). Danger of explosion.

If storing alcohol with a high percentage proof, make sure it is tightly closed, and store upright.

Warmest area

The warmest area is in the top section of the door. Use this for storing butter and cheese.

Coldest area

The coldest area in a refrigerator is normally directly above the vegetable containers. In this appliance, however, the coldest area is in the StayFresh zone.

Use the coldest areas in the refrigerator section and in the StayFresh zone for all delicate and highly perishable food, e.g.

–

fish, meat, poultry, –

sausage products, ready meals, –

dishes or baked goods containing

eggs or cream, –

fresh dough, cake mixtures, pizza or

quiche dough, –

soft cheese and other dairy

products,

If storing bottles of oil or food containing high levels of fat or oil in the appliance, take care not to let the fat or oil come into contact with plastic components. These can cause stress cracks to occur in the plastic components.

Food must not touch the back wall of the appliance, as it may freeze to the back wall.

StayFresh zone

A temperature of between 0 - 3 °C combined with a high humidity level provides the optimum storage conditions for fresh food, enabling it to be kept fresher for longer than in a refrigerator. The freshness of food when first placed in the appliance is an important factor in determining how long it stays fresh. Bear this in mind when shopping.

The temperature in the StayFresh zone is automatically held at approx. 0 °C.

–

pre-packed vegetables and other

fresh food with a label stating it

should be kept at a temperature of

approx. 4 °C.

Using the refrigerator efficiently

The StayFresh zone is divided into two areas:

The dry compartment has a relative

–

humidity level of approx. 45 %.

The humidity controlled

–

compartment has a control for

setting the humidity level between

45 % and 90 %. Slide the control to

the humidity level you require. The humidity level will also be affected

by the moisture content of the food being stored and how often the compartment is opened.

Low humidity level ,

^ To set a humidity level of approx.

45 %, slide the control for the humidity controlled compartment over to the left ,.

This humidity level is suitable for storing particularly delicate food such as fresh fish, shell fish, meat, poultry, sausage, dairy products and salads.

High humidity level -

To set a humidity level of approx.

90 %, slide the control for the humidity controlled compartment over to the right -.

This humidity level is suitable for storing fresh produce such as vegetables, salad, herbs, and seasonal fruit.

Store these types of food uncovered in the compartment.

Food which should not be stored in a refrigerator

Not all food is suitable for storing in the refrigerator. These include:

– Fruit and vegetables which are

sensitive to cold, such as bananas, avocado pears, papaya, passion fruit, aubergines/eggplant, peppers/capsicum, tomatoes and cucumbers

–

Fruit which is not yet ripe

Keep food covered or packaged in this compartment with the exception of meat.

–

Potatoes

–

Some hard cheeses, e.g. Parmesan

Using the refrigerator efficiently

Storing food correctly

Store food covered or packaged. This will prevent food smells or tastes from affecting other foods, and prevent food from drying out and also any cross-contamination of bacteria. The growth of bacteria, such as salmonella, can be avoided by setting the correct temperature and maintaining good standards of hygiene.

Fruit and vegetables

Fruit and vegetables can be stored loose in the vegetable containers. However, you should bear in mind that some types of vegetables give off a natural gas which speeds up the rate at which food perishes. Some fruit and vegetables react strongly to this gas and should not be stored together.

Examples of fruit which produce a large amount of this natural gas are:

Apples, apricots, pears, nectarines, peaches, plums, avocado pears and figs.

Examples of fruit and vegetables which react strongly to the natural gases given off by other types of fruit and vegetables are:

Kiwis, broccoli, cauliflower, Brussels sprouts, mangos, honeydew melons, apples, apricots, cucumbers, tomatoes, pears, nectarines and peaches.

Different types of unpacked meats and vegetables must be kept separate.

To avoid any microbiological cross-contamination, these foods may only be stored together if they are wrapped.

Protein rich foods

Please note that foods rich in protein deteriorate faster than others. Shell fish for example deteriorates faster than fish, and fish deteriorates faster than meat.

Meat

Store meat in suitable containers, but uncovered in the low humidity compartment. (Undo wrappings and leave containers open). The surface of the meat will dry out slightly and protect it from bacterial growth thus increasing its storage qualities. To prevent the risk of bacterial contamination keep meat stored in suitable containers and do not let different types of meat come into direct contact with each other.

Take food out of the StayFresh zone approx. 30 - 60 minutes before using it. The aroma and taste do not fully develop until the food has reached room temperature.

Adjusting the interior fittings

Moving the shelves

The shelves can be adjusted according to the height of the food.

Pull the shelf forward as far as it will

go; then lift it upwards to remove it. With the rear barrier facing upwards,

place the shelf at the required position. The rear barrier must face upwards to prevent food from touching the back of the appliance and freezing to it.

Split shelf

In order to accommodate tall items in the appliance, one of the shelves is divided. The front section can be pushed under the rear section.

^ Pull the front half of the glass shelf

forwards slightly and then push it carefully under the rear half.

Adjusting the door shelves

Push the door shelf upwards, then

remove it by pulling it forwards. Replace the door shelf at the

required position. Ensure that it is securely pushed back into position.

Moving the bottle divider

(Depending on model) The bottle divider can be moved to the

left or right to ensure that bottles are held securely in position when the door is opened and shut.

StayFresh zone compartments

^ When loading and unloading items,

pull the compartment right out by taking hold of it at the back and lifting it up to remove it.

To put it back in, pull the runners a right out and place the compartment on top of the runners. The front of

the runners must be right up against the front of the compartment b. Push the

compartment back in c.

Automatic defrost

Refrigerator section and StayFresh zone

Condensate and frost can build up on the back wall of the refrigerator section and the StayFresh zone whilst in use. These are automatically removed and defrosted by the appliance.

The condensate is drained away via a channel and drain hole into an evaporation system at the back of the appliance.

Ensure that the condensate channel and drain hole are kept clean and are never blocked so that condensate can flow away without hindrance.

Never use cleaning agents containing abrasive substances such as sand, soda, acids or chemical solvents. "Non-abrasive" cleaning agents are also unsuitable as they can cause matt areas to appear.

Stainless steel surfaces should be cleaned with a proprietary stainless steel cleaner following the manufacturer’s instructions on the packaging.

Make sure that no water can penetrate into the electronic unit or into the light.

Do not let water get into the drainage channel and drain hole when cleaning.

Do not use steam cleaning apparatus to clean the appliance. Steam could reach the electrical components and cause a short circuit.

The data plate located inside the appliance must not be removed. It contains information which is required in the event of a service call.

Before cleaning

Switch the appliance off, switch off at the socket and remove the plug.

Take any food out of the appliance and store it in a cool place.

Cleaning and care

Take out any removable parts e.g.

shelves for cleaning. The stainless steel trim can be pulled

off the front edge of the refrigerator section shelves for cleaning.

Cleaning the outer casing, the interior and accessories

Clean the refrigerator section and the

StayFresh zone at least once a month.

Accessories and shelves should all

be hand-washed. The butter dish is, however, dishwasher safe.

^ Clean the condensate channel and

drain hole frequently, so that condensate can drain away unhindered. Use a straw or similar to clear the drain if necessary.

^ Clean stainless steel surfaces with a

suitable cleaning agent following the manufacturer’s instructions on the packaging.

After cleaning, wipe the interior and accessories with a damp cloth and dry with a soft cloth. Leave the door open to air the appliance for a short while.

E-Cloth

A microfibre "E-Cloth" is available from the Miele UK Spare Parts Department which is suitable for cleaning surfaces such as stainless steel, glass, plastic and chrome without the use of chemicals.

Cleaning and care

Ventilation gaps

The ventilation gaps should be

cleaned on a regular basis with a brush or vacuum cleaner. A build up of dust will increase the energy consumption of the appliance.

Door seal

Do not use any oils or grease on the door seal as these will cause the seal to deteriorate and become porous over time.

The door seal should be cleaned regularly with clean water and then wiped dry with a soft cloth.

Metal grille at the back of the appliance

The metal grille at the back of the appliance (heat exchanger) should be dusted at least once a year. A build-up of dust will increase the energy consumption of the appliance.

When cleaning the grille, make sure that the pipework and other components do not get broken or damaged in any way.

After cleaning

Replace all shelves and accessories in the refrigerator section and the StayFresh zone and put your food back into the appliance.

Close the appliance door, insert the plug in the socket and switch the appliance back on.

Repairs to electrical appliances should only be carried out by a suitably qualified and competent person in accordance with local and national safety regulations. Repairs and other work by unqualified persons could be dangerous. The manufacturer cannot be held liable for unauthorised work.

Some minor problems can be corrected without contacting the Miele Service Department.

What to do if . . .

. . . the appliance does not get cold.

^ Check whether the appliance has

been switched on. The temperature display must be lit up.

^ Check that the plug is correctly

inserted in the socket and switched on.

Check that the fuse is not defective and that the mains fuse has not blown. If it has, contact the Miele Ser vice Department.

Problem solving guide

Check whether the metal grille (heat

exchanger) at the back of the appliance has become too dusty.

The door has been opened too

frequently, or a large amount of food has been put in at once.

Check that the door has been closed

properly.

. . . The temperature display is flashing.

The temperature has risen by several degrees in the refrigerator section because

^ large quantities of food which are too

warm have been placed in the appliance.

^ the door was left open for too long

whilst putting food into the appliance or rearranging it.

When you finish putting food into the appliance or rearranging it the electronics automatically adjust the temperature to the one last set. A loss of coldness for a short period will not

affect the food in the appliance.

. . . the temperature in the refrigerator section is too low.

Select a warmer temperature.

. . . the appliance is switching in too frequently and for too long.

Check whether the ventilation gaps have been covered over or become dusty.

. . . the following messages show in the temperature display "F0" to "F5".

There is a fault. Call the Service Department.

. . the alarm sounds.

Has the appliance door been open for longer than 60 seconds?

Close the door.

Problem solving guide

. . . the floor of the refrigerator section or the StayFresh zone is wet.

The drain hole is blocked.

Clean the condensate channel and

drain hole.

. . . the interior lighting in the refrigerator section is not working.

Was the door left open for too long?

The lighting switches itself off automatically after approx. 15 minutes.

If the door has not been left open for this length of time the interior lighting is defective.

To change it follow the instructions below. The lighting component required (cool touch lamp with light diodes) is available from the Miele Spare Parts Department.

Take care when removing the lamp cover. Do not look at the LEDs with optical instruments.

Disconnect the appliance from the mains. Switch off at the wall and withdraw the plug from the socket, or disconnect the mains fuse or remove the screw-out fuse in countries where this is applicable.

Press the lamp cover a to the ceiling

and then pull it forward to release it.

^ Unscrew the lighting component b

and disconnect the cable and plug connectors c.

Fit the new lighting component by reversing the above procedure.

If you still cannot remedy the fault having followed these suggestions, please contact the Miele Service Department.

To prevent unnecessary loss of temperature it is advisable not to open the door while waiting for the appliance to be serviced.

Noises

Normal noises What causes them

Brrrrr... Humming noise made by the motor (compressor). This noise can

Blubb, blubb.... A gurgling noise can be heard when coolant is circulating

Click.... Clicking sounds are made when the thermostat switches the

Sssrrrrr.... On multi-zone and frost-free appliances you can sometimes just

Remember that the noise of the compressor and the coolant circulating in the system is unavoidable.

get louder for brief periods when the motor is switching on.

through the pipes.

motor on and off.

hear the movement of air circulating inside the appliance.

Noises that you can easily rectify

Rattling, vibrating The appliance is uneven: Realign the appliance using a spirit

What causes them, and what can you do about them?

level, by raising or lowering the screw feet underneath the appliance.

The appliance is touching another appliance or piece of furniture: Move it away.

Drawers, baskets or shelves are unstable or sticking: Check

all removable items and refit them correctly.

Are any bottles or containers unstable or knocking against each other? Separate them.

The transport cable clips are hanging loose at the back of the appliance: Remove the clips.

After sales service

In the event of a fault which you cannot correct yourself, or if the appliance is under guarantee, please contact:

your Miele Dealer

– or

the Miele Service Department (see

–

back cover for address).

When contacting your Dealer or the Service Department, please quote the model and serial number of your appliance. This information is given on the data plate.

Please note that telephone calls may be monitored and recorded for training purposes.

Electrical connection

Electrical connection U.K.

All electrical work should be carried out by a suitably qualified and competent person in strict accordance with current local and national safety regulations (BS 7651 in the UK).

The appliance is supplied with a mains cable and moulded plug ready for connection to an a.c. single phase 220-240 V 50 Hz supply.

Please ensure that the connection data quoted on the data plate match the household mains supply.

Connection should be made via a suitable switched socket which is easily accessible. For extra safety it is advisable to install a residual current device (RCD) with a trip current of 30 mA (in accordance with DIN VDE 0664, VDE 0100, Section 739).

Do not connect the appliance to the mains electricity supply by an extension lead. Extension leads do not guarantee the required safety of the appliance (e.g. danger of overheating).

Non-rewireable plugs (BS 1363)

The fuse cover must be re-fitted when changing the fuse, and if the fuse cover is lost, the plug must not be used until a suitable replacement is obtained. The colour of the correct replacement cover is that of the coloured insert in the base of the plug, or the colour that is embossed in words in the base of the plug (as applicable to the design of the plug fitted).

Replacement fuses should be ASTA approved to BS 1362 and have the correct rating. Replacement fuses and fuse covers may be purchased from your local electrical supplier.

WARNING THIS APPLIANCE MUST BE EARTHED

The appliance must not be connected to an inverter and must not be used with a plug adapter as these can cause damage to the appliance’s electronic unit.

Installation

Do not place any appliance which gives off heat, such as a toaster or microwave oven, on top of this appliance, as this would increase the appliance’s energy consumption.

Location

The appliance should be installed in a dry, well-ventilated room. The room temperature should not go above or below the climate range for which the appliance is designed. The higher the ambient temperature of the room, the more energy the appliance requires to operate. It should not be installed where it is exposed to direct sunlight or directly adjacent to a heat-producing appliance such as an oven or a radiator.

Climate range

The appliance is designed for use within certain climate ranges (ambient temperatures), and should not be used outside this range. The climate range of the appliance is stated on the data plate inside the appliance.

Climate range Ambient room

SN-ST

SN-T

temperature

+10°C to +32°C +16°C to +32°C +18°C to +38°C

+18°C to +43°C +10 °C to +38 °C +10 °C to +43 °C

with the risk of food deteriorating and going off.

Side-by-side installation

To avoid a build-up of condensation and resultant damage, refrigerators and freezers should not generally be installed side-by-side next to another refrigerator or freezer.

However, there are certain models with insulated side wall heating which are suitable for side-by-side installation with this refrigerator.

Ask your dealer which models can be combined with your refrigerator.

^ Instructions on how to install the two

appliances side-by-side are given in the instruction booklet supplied with the matching freezer or fridge-freezer.

Ventilation

Air at the back of the appliance gets warm. To ensure sufficient ventilation, the ventilation gaps must not be covered over. The air inlet and outlet must not be covered or blocked in any way. They should be dusted on a regular basis.

Operating in a room which is too cold will cause the cooling system to switch off for too long, causing the internal temperature in the appliance to rise

Installation

Remove any cable clips from the

back of the appliance. Check that all parts at the back of the

appliance are unhindered. Carefully remove any hindrance.

Carefully push the appliance into

position. The appliance can be placed directly against a wall.

Aligning the appliance

Installation

^ To align the appliance adjust the feet

using the spanner supplied.

Changing the door hinging

The appliance is supplied right hand hinged. If left hand door hinging is required, follow the instructions below.

Removing the door handle:

First the side section of the handle must be removed:

^ Pull door handle a towards you. Side

section b slides back, creating a gap d between side section b and mounting plate c.

Place a suitable object (e.g. a spoon handle) in gap d, and slowly lever the handle towards the door.

Be careful not to let the "spoon handle" slip, causing damage to the appliance.

Remove the cover caps from the

opposite side, and fit them into the empty holes.

Changing over the door:

Open the appliance door.

^ Use a screwdriver to lever plinth a

out, then pull it forwards and out.

Use a screwdriver to remove cover b, then close the door.

Remove screw c completely.

Pull door support d together with hinge pin e downwards, then tilt it forwards and take it off.

The side section b can now be removed.

Pull side section b out of the guides on the mounting plate.

Loosen the 4 screws (Torx 15) in the mounting plate, and remove the handle.

Open the appliance door, tilt it

downwards and take it off.

^ Remove cover f, and unscrew hinge

bracket g.

Changing the door hinging

Keep it in a safe place just in case you ever decide to change the door hinging back to right hand hinging.

Screw the tappet supplied n into the

opposite side using the same screw o.

Hang the door on hinge pin h and

then close the appliance door.

In the following illustration the door is not shown in the closed position to make it easier to see what happens next.

^ Fit hinge pin h in the second hole of

hinge bracket g.

Refit bracket i and cover j turned through 180° on the opposite side.

Screw hinge bracket g into the opposite side. The M4 screw has to be screwed into the left hole of the hinge bracket.

Turn cover f through 180°, and fit it on the other side.

Remove spacer k with a screwdriver and refit it on the opposite side.

Remove plug l from the door bearing bush in the door and refit on the opposite side.

Unscrew tappet m.

Turn door support b around, pull hinge pin a out, and refit on the opposite side.

Fit both parts into hinge plate f. To do this push hinge pin a through hinge plate f into door support b. Swing the door support in, push upwards and re-assemble with screw c.

Changing the door hinging

Align the door with the appliance

housing using the long slot in hinge plate f. Then tighten screw c.

Refit plinth fascia d, pushing it firmly

into position. With the door open, position cover e

in the front of the plinth fascia, and push it firmly into position.

Refitting the handle:

Please make sure you follow the instructions below carefully when you refit the handle. The door seal will be damaged if the handle is fitted incorrectly.

Then tighten all 4 fixing screws b.

Slide the side section of the handle

d into the guides on the mounting plate until it clicks into place.

It is important to check that the side section of the handle d does not come into contact with the door seal when opening the door, as this would damage the door seal permanently.

If, after you have refitted the handle, you find that the side section does touch the door seal when the door is opened:

^ Realign mounting plate c with grub

screws a until the mounting plate and the side section of the handle d are at the correct angle and the side section does not touch the seal when the door is opened.

Loosely attach the handle to the opposite side of the door with the two front screws b.

Mounting plate c must be positioned on the side of the door so that when the door is closed it is flush with the side of the appliance. If this is not the case,

Tighten both grub screws a with the allen key provided until mounting plate c lines up correctly.

StayFresh zone compartments

Pull the compartment right out by

taking hold of it at the back and lifting it up to remove it.

^ Pull the compartment lid forwards a. ^ Push the compartment lid in towards

the side that the appliance is going to be opened from once the hinges have been changed over b, and fit it back on the runners.

Changing the door hinging

^ Push the lid in until it engages c.

To put the compartment back in, pull the runners a right out and place the compartment on top of the runners close up against the door opening side. The front of the runners must

be right up against the front of the compartment b. The compartment

will click into position. You can now push the compartment back in c.

Make sure that the compartment lid covers the compartment correctly.

Building in the appliance

600 mm wide appliances can be

installed into a kitchen run. To match the height of the rest of the kitchen, the appliance can be fitted with a suitable top box a.

The air inlet and outlet must not be covered or blocked in any way. They should be dusted on a regular basis.

When built into a kitchen run (max. depth 580 mm) the appliance can be installed directly next to a kitchen furniture housing unit. The appliance door b will protrude in front of furniture fronts at the sides by 34 mm and by 51 mm in the middle of the door. This enables the doors to be opened and shut without being obstructed.

When installed next to a wall c a distance of approx. 36 mm is needed on the hinge side between the wall and the appliance, so that the door and the handle have sufficient space for opening.

A ventilation gap of at least 50 mm depth must be allowed for behind the appliance and top box, if fitted, for air to circulate. A gap of at least 40 mm is required between the top of the appliance (or top box) and the ceiling to ensure that air can circulate without hindrance. Otherwise the appliance has to work harder, resulting in an increase in electricity consumption.

Alteration rights reserved / 5005

K 8967 S ed-1

M.-Nr. 06 777 930 / 00

en-GB

Operating and installation instructions

Frost free freezer

KFNS 3917 S ed

To avoid the risk of accidents or damage to the appliance, it is essential to read these instructions before it is installed and used for the first time.

Guide to the appliance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Caring for the environment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Warning and Safety instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

How to save energy . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Switching on and off . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Switching off for longer periods of time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

The correct temperature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Setting the temperature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Temperature display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Alarm. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Activating the alarm system. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Switching the alarm off early . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Super freeze . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Freezing fresh food . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Super freeze. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Freezing and storing food. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Maximum freezing capacity. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Isolation plate. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Important . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Storing frozen food. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Home freezing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Hints on home freezing. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Packing. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

Before placing food in the freezer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

Placing food in the freezer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

Freezer calendar . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

Marker system for frozen food . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

Defrosting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

Ice cube tray . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Cooling drinks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Freezer tray . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Cool pack. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

Defrosting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

Contents

Cleaning and care . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

Cleaning the outer casing, the interior and accessories . . . . . . . . . . . . . . . . . . . . 24

Ventilation gaps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

Door seal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

Metal grille at the back of the appliance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

Problem solving guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

Noises . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

After sales service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

Electrical connection. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

Location . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

Climate range . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

Ventilation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

Aligning the appliance. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

Installing in a side-by-side combination . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32

Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32

Joining the two appliances together . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32

Changing the door hinging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

Building in the appliance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39

Guide to the appliance

a Alarm off button and indicator light b Temperature display

c Super freeze button and indicator

light

d On/Off and temperature selector dial

a Frost free system b Freezer tray

c Freezer drawers with

freezer calendar

d Marker system for frozen food

Caring for the environment

Disposal of the packing material

The transport and protective packing has been selected from materials which are environmentally friendly for disposal, and can normally be recycled.

Ensure that any plastic wrappings, bags etc. are disposed of safely and kept out of the reach of babies and young children. Danger of suffocation!

Rather than just throwing these materials away, please ensure that they are recycled.

Disposal of your old appliance

Please ensure that the appliance presents no danger to children while being stored for disposal.

Please dispose of your old appliance at your local community waste collection / recycling centre and not with your household waste.

Warning and Safety instructions

Technical safety

This appliance complies with all relevant legal safety requirements. Improper use can, however, present a risk of both personal injury and material damage.

Keep these instructions in a safe place and pass them on to any future user.

Correct use

This appliance is intended for

domestic use only, to store deep frozen food, freeze fresh food, and to make ice. Any other usage is not supported by the manufacturer and could be dangerous. The manufacturer cannot be held liable for damage caused by incorrect or improper use of the appliance.

This appliance is not a toy! To avoid the risk of injury, do not allow children to play on or near it, or to play with the controls. Supervise its use by the elderly or infirm.

which is environmentally friendly. Although it is flammable, it does not damage the ozone layer and does not increase the greenhouse effect. The use of this coolant has, however, led to a slight increase in the noise level of the appliance. In addition to the noise of the compressor, you might be able to hear the coolant flowing around the system. This is unavoidable, but does not have any adverse effect on the performance of the appliance. Care must be taken during the transportation and installation of the appliance that no parts of the cooling system are damaged. Leaking coolant can damage the eyes. In the event of any damage:

- avoid open fires and anything which creates a spark,

- disconnect from the mains,

- air the room in which the appliance is located for several minutes and

- contact the Service Department for advice.

should be installed in. In the event of a leakage, if the appliance is in a small room, there is the danger of combustible gases building up. For every 8 g of coolant at least 1 m room space is required. The amount of coolant in the appliance is stated on the data plate inside the appliance.

This appliance contains the coolant Isobutane (R600a), a natural gas

The more coolant there is in an appliance, the larger the room it

Warning and Safety instructions

Before connecting the appliance to

the mains supply, make sure that the rating on the data plate corresponds to the voltage and frequency of the household supply. This data must correspond in order to avoid the risk of damage to the appliance. Consult a qualified electrician if in any doubt.

The electrical safety of this

appliance can only be guaranteed when continuity is complete between it and an effective earthing system, which complies with local and national safety regulations. It is most important that this basic safety requirement is present and regularly tested. Where there is any doubt, the household wiring system should be inspected by a qualified electrician. The manufacturer cannot be held liable for the consequences of an inadequate earthing system (e.g. electric shock).

Safe operation of the appliance is

only assured if it has been installed and connected in accordance with these operating and installation instructions.

Installation work, maintenance and

repairs may only be carried out by suitably qualified and competent persons in accordance with national and local safety regulations. Repairs and other work by unqualified persons could be dangerous and the manufacturer will not be held liable. Ensure current is not supplied to the appliance until after maintenance or repair work has been carried out.

The appliance is only completely

isolated from the electricity supply when:

– it has been switched off at the socket

and the plug has been withdrawn. – the mains fuse is withdrawn, or – the screw-out fuse is removed (in

countries where this is applicable).

Do not connect the appliance to

the mains electricity supply by an extension lead. Extension leads do not guarantee the required safety of the appliance (e.g. danger of overheating).

This equipment may only be used

in mobile installations such as ships, caravans, aircraft etc. if a risk assessment of the installation has been carried out by a suitably qualified engineer.

Warning and Safety instructions

Use

Never handle frozen food with wet

hands. Your hands may freeze to the frozen food. Danger of frost burn.

Do not take ice cubes out with your

bare hands and never place ice cubes or ice lollies in your mouth straight from the freezer. The very low temperature of the frozen ice or lollies can cause frost burn to the lips and tongue.

Do not allow children to play with

the appliance, for example to climb inside the drawers or to swing on the door.

Do not refreeze thawed or partially

thawed food. Defrosted food should be used up as quickly as possible, as food soon loses it nutritional value and goes off. Defrosted food may only be re-frozen after it has been cooked.

Storage times will depend on

several factors, including the freshness and quality of the food as well as the temperature at which it is stored. To avoid the risk of food poisoning, follow the instructions given on the food manufacturer’s packaging on the storage conditions required, as well as the "use by" date.

Do not store explosive materials in

the appliance or any products containing propellants (e.g. spray cans). Thermostats switching on may produce sparks which could present a fire hazard. Flammable compounds could explode.

Do not use any electrical

equipment in this appliance, e.g. ice cream makers. Danger of sparking and explosion!

Do not store cans or bottles

containing carbonated drinks or liquids which could freeze in the freezer. The cans or bottles could explode. Danger of injury and damage to the appliance.

When cooling drinks quickly in the

freezer, make sure bottles are not left in for more than one hour, otherwise they could burst. This could result in injury or damage.

Do not use sharp edged objects to –

remove frost and ice,

–

separate frozen foods or remove ice trays. They will damage the evaporator, causing irreversible damage to the appliance.

Do not use any oils or grease on

the door seals, as these will cause the seals to deteriorate and become porous with time.

Do not block the ventilation gaps in

the appliance as this would impair the efficiency of the appliance, increase the electricity consumption and could cause damage to the appliance.

Warning and Safety instructions

The appliance is designed for use

Never place electric heaters or

candles in the appliance to defrost it. These can damage the plastic parts.

Do not use defrosting sprays or

de-icers, as they might contain substances which could damage the plastic parts or which could cause a build-up of gases and pose a danger to health.

Never use a steam-cleaning

appliance to defrost or clean this appliance. Pressurised steam could reach the electrical components and cause a short circuit.

In countries where there are areas

Disposal of your old appliance

Before disposing of an old

appliance, first make the door latch or lock unusable. This way you will prevent children from accidentally locking themselves in and endangering their lives.

Disconnect it from the mains. Cut

off the cable and render any plug unusable.

Be careful not to damage any part

of the pipework whilst awaiting disposal, e.g. by

– puncturing the refrigerant channels

in the evaporator. – bending any pipework. – scratching the surface coating. Splashes of refrigerant can damage the

eyes.

The manufacturer cannot be held liable for damage caused by non-compliance with these Warning and Safety instructions.

How to save energy

Normal energy consumption Increased energy

consumption

Installation site In a ventilated room. In an enclosed, unventilated room.

Protected from direct sunlight. In direct sunlight. Not situated near to a heat source

(radiator, oven). Where the ambient room

temperature is ideal at approx. 20°C.

Temperature setting with a thermostat which is approximate (set in stages).

Temperature setting with a thermostat which is exact to the degree (digital display).

Use Only open the door when

With a medium setting of 2 to 3. With a high setting: The lower the

Cellar section 8 to 12°C On appliances with winter setting,

Refrigerator section 4 to 5 °C StayFresh zone just above 0 °C Freezer section -18°C

necessary and for as short a time as possible.

Store food in an organised way. If food is not stored in an

Allow hot food and drinks to cool down before placing them in the appliance.

Store food covered or packaged. The evaporation or condensation

Place frozen food in the refrigerator to defrost.

Do not over-fill the appliance to allow air to circulate.

Situated near to a heat source (radiator, oven).

Where there is a high ambient room temperature.

temperature in the appliance, the higher the energy consumption.

please make sure that the winter setting is switched off when the ambient temperature is warmer than 16 °C.

Frequent opening of the door for long periods will cause a loss of coldness.

organised way, searching for an item will mean the door is open for longer.

Placing hot food in the appliance will cause the compressor to run for a long time, as the appliance will have to work harder to lower the temperature.

of liquids will cause a loss of coldness in the refrigerator.

How to save energy

Normal energy consumption

Defrosting Defrost the freezer when a layer of

ice one centimetre thick has built up.

Increased energy consumption

A layer of ice hinders the cold from reaching the frozen food, and causes an increase in energy consumption.

Switching on and off

Before using for the first time

The stainless steel surfaces and the trim have a protective foil to prevent scratching during transportation.

Do not remove this foil until the

appliance has been installed or built in. Start at one of the upper corners.

Wipe stainless steel surfaces over

with a proprietary conditioning agent for stainless steel, such as Neoblank (available from the Miele UK Spare Parts Department). Follow the manufacturer’s instructions on the label, and apply sparingly with an even pressure following the direction of the grain.

^ Clean the inside of the appliance and

the accessories with warm water and a little washing-up liquid, and then dry with a soft cloth.

Important: To ensure the correct functioning of the appliance, let it stand for between 1½ and 2 hours after transporting it to its final location before connecting it to the mains.

Switching on

Using a coin, turn the On/Off dial in a

clockwise direction away from the "0" position until the temperature display lights up.

Forcing it beyond its range will damage it. Turn it only as far as it will go, then turn it back again.

The alarm indicator will light up. It will go out when the temperature in the freezer is cold enough.

To enable the temperature to get sufficiently cold inside the freezer, allow the appliance to run for a few hours before placing food in it.

Cool pack

Place the cool pack in the top drawer or, to save space, on the freezer tray. The cool pack will be at its most effective after it has been in the freezer for approx. 24 hours.

Switching off

Using a coin, turn the On/Off dial in an anti-clockwise direction back to the "0" position.

All the indicator lights will go out and the cooling system will switch off.

Switching off for longer periods of time

If the appliance is not going to be used for a longer period of time, e.g. whilst on holiday,

switch the appliance off,

switch off at the wall socket and

withdraw the plug, clean the appliance out and

leave the door ajar to air the

appliance.

If, during a long absence, the appliance is switched off but not cleaned out and the door is left shut, mould and odours are likely to build up inside the appliance.

Switching on and off

The correct temperature

To freeze fresh food and to store frozen food for a long time, a temperature colder than -18 °C is required. At this temperature the growth of micro-organisms is generally halted. As soon as the temperature rises above

-10 °C, the micro-organisms become active in the food again so that it cannot be kept as long. For this reason, partially defrosted or defrosted food must not be re-frozen. Food may be re-frozen once it has been cooked, as the high temperatures achieved when cooking destroy most micro-organisms.

The temperature in the appliance will rise:

–

the more often the door is opened and the longer it is kept open,

–

if too much food is stored in it at once,

–

if too much fresh food is being frozen at once,

–

the higher the ambient temperature surrounding the appliance. The appliance is designed for use in specific ambient temperatures (climate ranges). Do not use in ambient temperatures for which it is not designed.

Setting the temperature

The temperature is set with the temperature selector.

Using a coin, turn the dial in a

clockwise direction away from the "0" position.

Forcing it beyond its range will damage it. Turn it only as far as it will go, then turn it back again.

Temperature display

The temperature display on the control panel always shows the required temperature.

If you want the temperature in the refrigerator to be -18 °C,

turn the temperature selector clockwise from 0 until the -18°C LED lights up on the control panel.

The temperature can be set slightly colder within the displayed temperature range (e.g. between -15°C and -18 °C).

Turn the temperature selector slowly in a clockwise direction e.g. from the

-15°C LED position until the -18°C LED flashes briefly in the temperature display.

The temperature is now set in between

-15°C and -18°C.

Alarm

Your appliance has been fitted with a warning system which ensures that the temperature in the freezer cannot rise unnoticed. An alarm will sound and the alarm indicator light will flash if the temperature becomes too warm.

The alarm may sound and the alarm indicator light may flash,

if you freeze a large amount of food

–

at once without having switched on the Super freeze function beforehand.

Depending on the temperature in the freezer, you should check the condition of the food. If food has defrosted or started to defrost check that it is still safe to use, and if so, use it as quickly as possible. Defrosted food may only be re-frozen after it has been cooked.

Activating the alarm system

The alarm system is always active. It does not have to be switched on manually.

Switching the alarm off early

The alarm will stop and the indicator light will go out when the temperature reaches the correct level again. However, if the noise disturbs you, you can switch the alarm off before this if you wish.

^ Press the alarm off button.

The alarm will stop. The indicator

light will stay on until the correct

temperature has been reached. The

alarm system is then ready should it

be needed again.

Super freeze

Freezing fresh food

Fresh food should be frozen as quickly as possible. This way the nutritional value of the food, its vitamin content, appearance and taste are not impaired.

Food which takes a long time to freeze will lose more water from its cells, which then shrink. During the defrosting process, only some of this water is reabsorbed by the cells; the rest collects around the food. In practice this means that the food loses a large degree of its moisture.

If food is frozen quickly, the cells have less time to lose moisture, so they shrink less. As there is not so much moisture loss, it is easier for the food to reabsorb it during the defrosting process, and very little water collects around the defrosted food.

Super freeze

Switch the Super freeze function on before putting fresh food into the freezer.

Exceptions:

–

when putting in food that is already frozen.

–

when freezing up to 2 kg fresh food daily.

Switching on Super freeze

When freezing small quantities of food in the freezer, the Super freeze function should be switched on 6 hours

beforehand. When freezing the maximum load of food the Super

freeze function should be switched on 24 hours beforehand.

Press the Super freeze button. The

Super freeze indicator light will come on.

The coldest temperature in the temperature display on the control panel will light up and the appliance works at full power to lower the temperature.

Switching Super freeze off

The Super freeze function will switch off automatically after approx. 65 hours. The indicator light goes out and the appliance continues running at normal power.

The required temperature will then light up again in the temperature display.

To save energy the Super freeze function can be switched off once a constant temperature of -18 °C or colder has been reached in the freezer. You should also check the temperature inside the appliance from time to time.

Press the Super freeze button. The Super freeze indicator light will go out and the appliance will continue to operate at normal power.

Maximum freezing capacity

To ensure that fresh food placed in the freezer freezes through to the core as quickly as possible, the maximum freezing capacity must not be exceeded. The maximum freezing capacity for freezing within a 24-hour period is given on the data plate

"Freezing capacity ....kg/24 hrs".

Isolation plate

(depending on model, available as an optional accessory)

The isolation plate is used to isolate freezer drawers which you do not wish to use, and thus save energy. It should be used if only small amounts of food are being stored in the freezer.

Important

Freezing and storing food

Do not store food in the "inactive" drawers. The temperature is not controlled in these drawers and food stored in them would soon deteriorate.

Example

If you only require 2 freezer drawers for storing frozen food:

Place food in the top 2 freezer

drawers, leaving the other drawers empty.

– At least 2 freezer drawers must be

used for freezing food. The other drawers can be isolated if they are not needed.

–

The drawers being used for freezing must always be at the top of the freezer.

–

The isolation plate must be fitted below the lowest drawer in which food is being frozen.

–

The fewer drawers you use, the more energy you will save. Using the isolation plate increases energy savings considerably.

Take out the third drawer down and push the isolation plate in under the second drawer.

This "switches off" (isolates) the drawers below.

Freezing and storing food

Storing frozen food

When buying frozen food to store in your freezer, check

that the packaging is not damaged,

–

the use-by date,

–

the temperature at which the frozen

–

food is being stored in the shop. The length of time it can be kept is reduced if it has been stored at a temperature warmer than -18 °C.

Buy frozen food once you have

finished the rest of your shopping, and wrap it in newspaper or use a cool bag or cool box to transport it.

^ Store it in the freezer as soon as

possible.

Never re-freeze partially or fully defrosted food. Consume defrosted food as soon as possible as it will lose its nutritional value and spoil if left for too long. Defrosted food may only be re-frozen after it has been cooked.

Home freezing

Only freeze fresh food which is in a good condition.

Hints on home freezing

The following types of food are

–

suitable for freezing:

Fresh meat, poultry, game, fish,

vegetables, herbs, fresh fruit, dairy

products, pastry, leftovers, egg

yolks, egg whites and a range of

pre-cooked meals.

The following types of food are not

–

suitable for freezing:

Grapes, lettuce, radishes, sour

cream, mayonnaise, eggs in their

shells, onions, whole raw apples and

pears. – To retain colour, taste and vitamin C,

vegetables should be blanched after

they have been trimmed and

washed. To blanch: bring a large

saucepan of water to the boil,

immerse the vegetables in the fast

boiling water for 2-3 minutes,

depending on variety. Remove, and

plunge into ice-cold water to cool

quickly. Drain and pack ready for

freezing.

–

Lean meat freezes better than fatty

meat, and can be stored for

considerably longer. –

To prevent chops, steaks, cutlets or

rolled meat from freezing together in

solid blocks when packed, separate

with a sheet of plastic freezer film.

Do not season fresh foods or

–

blanched vegetables before freezing. Only season cooked food lightly before freezing, but care should be taken as the taste of some spices alters when frozen.

Do not place hot foods or drinks in

–

the freezer. This causes already frozen food to thaw, and increases the energy consumption considerably. Allow hot foods and drinks to cool down before placing them in the freezer.

Packing

^ Freeze food in portions.

Unsuitable packing material

- wrapping paper

- grease-proof paper

- cellophane

- bin bags

- plastic carrier bags

Suitable packing material

- plastic freezer film

- freezer bags

- aluminium foil

- freezer containers

Expel as much air as possible from bags etc. before sealing them, to prevent freezer-burn on food.

Close the packaging tightly with

- rubber bands

- plastic clips

- string or bag ties

- freezer tape.

Freezer bags may also be sealed using home heat sealing kits.

Freezing and storing food

Make a note of the contents and the

date of freezing on the packaging.

Before placing food in the freezer

When freezing more than 2 kg of

fresh food, switch on the Super freeze function for some time before placing the food in the freezer (see "Super freeze").

Placing food in the freezer

Fresh food can be placed in any drawer for freezing, however it is preferable to use the upper drawers.

Large quantities can be placed directly onto the glass cold plates to freeze the food quickly. To do this first take out one or more freezer drawers. The bottom drawer must not be taken out of the appliance.

Each drawer and glass cold plate can be loaded with a maximum of 25 kg. If you remove a freezer drawer make sure that you do not block the ventilation slits in the back wall of the appliance. They are important for trouble-free operation of the appliance.

When freezing large items e.g. a turkey or a large joint of meat, the glass plate in between two of the freezer drawers can be removed to give more room. This way food can be stored in the space of two drawers.

Place the food flat in the bottom of the drawers or on the glass cold plates so that it freezes through to the core as quickly as possible.

Freezing and storing food

Make sure that the packaging and

containers are dry to prevent them sticking together when frozen.

When freezing, make sure that food already frozen does not come into contact with fresh food being frozen as this could cause the frozen food to begin to defrost.

Freezer calendar

The freezer calendar on the freezer drawer gives the length of time which various foods can be stored for effectively.

Where the storage time given on the packaging differs, follow the advice on the packaging.

Marker system for frozen food

The marker system serves as a reminder of how long food has been stored.

Each freezer drawer has two slide markers with dials. The months are represented on the dials as 1 – 12.

Use the markers to indicate the type of food being frozen, and turn the dials to the appropriate number to show the month in which it was first placed in the freezer.

Defrosting

Frozen food can be defrosted in different ways:

in a microwave oven,

–

in an oven using the "Fan" or "Defrost"

–

setting,

at room temperature,

– – in the refrigerator (the cold given off

by the frozen food helps to keep the

food cold), – in a steam oven. Poultry It is particularly important to

observe food hygiene rules when defrosting poultry. Do not use the liquid from defrosted poultry. Pour it away and wash the container it was in, the sink and your hands. Danger of salmonella poisoning.

Fruit should be defrosted at room temperature in its packing, or in a covered bowl.

Slide the markers onto the guide runners on the edge of the drawers.

Most vegetables can be cooked while still frozen. Just put straight into boiling water or hot fat. The cooking time is slightly less than that of fresh vegetables due to changes in the cell structure.

Ice cube tray

(with or without release button, depending on model)

^ Press down the release button on the

ice cube tray and fill the tray with water. Any excess will flow out through the outlet.

Freezing and storing food

Freezer tray

The freezer tray is useful for freezing small items such as berries and vegetables. They can be frozen individually and therefore maintain their shape when defrosted.

^ Space the food out loosely on the

tray.

Leave food for 10 - 12 hours to freeze thoroughly on the tray. Transfer it to a freezer bag or suitable container once frozen. Place the bag or container in the freezer drawer.

^ Now pull the release button up to

seal the ice cube tray. Place the tray on the bottom of one of the freezer drawers.

Once frozen, use a blunt instrument, for example a spoon handle, to remove the ice tray from the freezer.

Ice cubes can be removed easily from the tray by twisting the tray gently or by holding it under cold running water for a short while.

Cooling drinks

When cooling drinks quickly, make sure bottles are not left in the freezer for more than one hour, as they could burst.

Freezing and storing food

Cool pack

The cool pack prevents the temperature in the freezer rising too quickly in the event of a power cut.

Place the cool pack in the upper drawer directly on top of food, or in the freezer tray to save space. The cool pack will be at its most effective after it has been in the freezer for approx. 24 hours.

If there is a power cut, place the cool pack directly on top of the frozen food in the upper drawer so that the food will be kept cold for as long as possible.

When placing fresh food in the freezer, use the cool pack to separate the fresh food from the food which is already frozen so that the frozen food does not begin to thaw.

The cool pack can also be used in a cool bag to keep food or drinks cool for a short period of time.

This freezer is equipped with a Frost free system. The freezer defrosts automatically.

The moisture generated by defrosting collects in the condensor and is automatically dissipated by the condensor from time to time.

This automatic defrosting system enables the freezer to remain permanently ice-free, however, the food stored in the freezer will not defrost.

Defrosting

Cleaning and care

Never use cleaning agents containing abrasive substances such as sand, soda, acids or chemical solvents. "Non-abrasive" cleaning agents are also unsuitable as they can cause matt areas to appear.

Stainless steel surfaces can be treated using a proprietary conditioning agent for stainless steel such as Neoblank (available from the Miele UK Spare Parts Department). Follow the manufacturer’s instructions on the packaging.

Make sure that water cannot get into the electronic unit or into the ventilation gaps.

Cleaning the outer casing, the interior and accessories

Use warm water with a little washing up liquid. Wash all accessories and drawers by hand only. Do not wash in a dishwasher.

After cleaning, wipe the interior and

accessories with a damp cloth and dry with a soft cloth. Leave the door open to air the appliance for a short while.

E-Cloth

^ A microfibre "E-Cloth" is available

from the Miele UK Spare Parts Department which is suitable for cleaning surfaces such as stainless steel, glass, plastic and chrome without the use of chemicals.

Do not use steam cleaning apparatus to clean the appliance. Pressurised steam could reach the electrical components and cause a short circuit.

The data plate located inside the appliance must not be removed. It contains information which is required in the event of a service call.

Switch the appliance off, switch off at the wall socket and remove the plug. Take any food out of the appliance and store it in a suitable cool place (e.g. cool-box or another freezer). Remove all the freezer drawers from the appliance.

Ventilation gaps

^ The ventilation gaps should be

cleaned regularly with a brush or vacuum cleaner. A build-up of dust will increase the energy consumption of the appliance.

Door seal

Do not use any oils or grease on the door seal as these will cause the seal to deteriorate and become porous over time.

The door seal should be cleaned regularly with clean water and then wiped dry with a soft cloth.

Metal grille at the back of the appliance

The metal grille at the back of the appliance (heat exchanger) should be dusted at least once a year. A build-up of dust will increase the energy consumption of the appliance.

When cleaning the grille, make sure that the pipework and other components do not get broken or damaged in any way.

After cleaning

^ Close the appliance door, insert the

plug in the socket and switch the appliance back on.

^ Switch on the Super freeze function

so that the freezer can cool down quickly. The indicator light will come on.

Cleaning and care

^ Once the temperature in the freezer

has reached the required temperature, place the food back in the freezer drawers and put them back in the freezer.

Switch off Super freeze by pressing the Super freeze button when the temperature in the freezer is a constant -18 °C or colder. The indicator light will go out.

Problem solving guide

Some minor problems can be corrected without contacting the Miele Service Department.

. . . the temperature is too low.

Turn the temperature selector to a

setting closer to "0". Super freeze has not yet switched

itself off. The Super freeze function switches itself off automatically after approx. 65 hours.

. . . the appliance is switching in too frequently and for too long.

Check whether the ventilation gaps

have been covered over or become dusty.

What to do if . . .

. . . the appliance does not get cool.

^ Make sure that the temperature

selector is not pointing to the "0" position.

^ Check that the plug is correctly

inserted in the socket and switched on.

Check that the fuse is not defective and that the mains fuse has not blown. If it has, contact the Miele Ser vice Department.

. . . the door will not open because it has been opened and closed too many times in succession.

This is not a fault. The suction caused by opening and closing the door is preventing the door from opening. Wait a few minutes and then try again. It should now open without force.

^ Check whether the metal grille (heat

exchanger) at the rear of the appliance has become dusty.

^ The door has been opened too

frequently, or a large amount of fresh food has been put in at once for freezing.

^ Check that the door has been closed

properly.

. . . the alarm sounds and the alarm indicator light flashes.

The temperature in the freezer is too warm, because

a large amount of food has been frozen at once without switching on the Super freeze function. The alarm will stop and the indicator light will go out when the temperature has reached the correct level again.

the compressor is faulty. Call the Ser vice Department.

. . . the Super freeze indicator light and the temperature display are both flashing at the same time.

There is a fault. Call the Service Department.

. . . the Super freeze indicator light does not light up, even though the appliance is working.

^ The indicator light is defective. Call

the Service Department.

...food has frozen together.

Problem solving guide

Use a blunt instrument, e.g. a spoon handle or plastic scraper, to prise it apart carefully.

If you still cannot remedy the fault having followed these suggestions, please contact the Miele Service Department.

To prevent unnecessary loss of temperature it is advisable not to open the door while waiting for the appliance to be serviced.

Noises

Normal noises What causes them

Brrrrr... Humming noise made by the motor (compressor). This noise can

Blubb, blubb.... A gurgling noise can be heard when coolant is circulating

Click.... Clicking sounds are made when the thermostat switches the

Sssrrrrr.... On multi-zone and frost-free appliances you can sometimes just

Remember that the noise of the compressor and the coolant circulating in the system is unavoidable.

get louder for brief periods when the motor is switching on.

through the pipes.

motor on and off.

hear the movement of air circulating inside the appliance.

Noises that you can easily rectify

Rattling, vibrating The appliance is uneven: Realign the appliance using a spirit

What causes them, and what can you do about them?

level, by raising or lowering the screw feet underneath the appliance.

The appliance is touching another appliance or piece of furniture: Move it away.

Drawers, baskets or shelves are unstable or sticking: Check

all removable items and refit them correctly.

Are any bottles or containers unstable or knocking against each other? Separate them.

The transport cable clips are hanging loose at the back of the appliance: Remove the clips.

After sales service

In the event of a fault which you cannot correct yourself, or if the appliance is under guarantee, please contact:

your Miele Dealer

– or

the Miele Service Department (see

–

back cover for address).

When contacting your Dealer or the Service Department, please quote the model and serial number of your appliance. This information is given on the data plate.

Please note that telephone calls may be monitored and recorded for training purposes.

Electrical connection

Electrical connection U.K.

All electrical work should be carried out by a suitably qualified and competent person in strict accordance with current local and national safety regulations (BS 7651 in the UK).

The appliance is supplied with a mains cable and moulded plug ready for connection to an a.c. single phase 220-240 V 50 Hz supply.

Please ensure that the connection data quoted on the data plate match the household mains supply.

Do not connect the appliance to the mains electricity supply by an extension lead. Extension leads do not guarantee the required safety of the appliance (e.g. danger of overheating).

Non-rewireable plugs (BS 1363)

Replacement fuses should be ASTA approved to BS 1362 and have the correct rating. Replacement fuses and fuse covers may be purchased from your local electrical supplier.

WARNING THIS APPLIANCE MUST BE EARTHED

The appliance must not be connected to an inverter and must not be used with a plug adapter as these can cause damage to the appliance’s electronic unit.

Do not place any appliance which gives off heat, such as a toaster or microwave oven, on top of this appliance, as this would increase the appliance’s energy consumption.

Installation

Ventilation

Air at the back of the appliance gets warm. To ensure sufficient ventilation, the air inlet and outlet must not be covered or blocked in any way. They should be dusted on a regular basis.

Location

The appliance should be installed in a dry, well-ventilated room. It should not be installed where it is exposed to direct sunlight or directly adjacent to a heat-producing appliance such as an oven or a radiator.

Climate range

The appliance is designed for use within certain climate ranges (ambient temperatures), and should not be used outside this range. The higher the ambient temperature of the room, the more energy the appliance requires to operate. The climate range of the appliance is stated on the data plate inside the appliance.

Climate range Ambient room

SN-ST

SN-T

temperature

+10°C to +32°C +16°C to +32°C +18°C to +38°C +18°C to +43°C +10°C to +38°C +10°C to +43°C

Installation

Remove any cable clips from the

back of the appliance. Check that all parts at the back of the

appliance are unhindered. Carefully remove any hindrance.

^ Carefully push the appliance into

position. The appliance can be placed directly against a wall.

Aligning the appliance

To align the appliance adjust the feet using the spanner supplied.

The appliance will function perfectly down to an ambient temperature of +5 °C.

Installing in a side-by-side combination

To avoid a build-up of condensation and resultant damage, refrigerators and freezers should not normally be installed side-by-side. However, this appliance has side wall heating, and can be installed side-by-side with certain other Miele appliances.

Your dealer will be able to advise you on which models are suitable.

Installation

This appliance must be installed to

the left of any refrigerator when viewed from the front. The side wall heating in the right-hand wall is insulated to prevent the build-up of condensation between the two appliances.

^ Place the two appliances as close as

possible to their final position so that they can be aligned for any unevenness in the floor. The back of the appliances still needs to be kept accessible to complete the installation.

Joining the two appliances together

You will need a spirit level, spanners, a torque screwdriver and a socket wrench.

Before starting, peel off any

protective foil from appliance. Place the appliances next to one

another so that the fronts are aligned, leaving a gap of 10 mm between them.

^ Open the appliance doors, and use a

screwdriver to lever plinth facings a out, then pull them forwards and off.

Use a screwdriver to remove covers b.

Installing in a side-by-side combination

Align both appliances using a spirit

level.

Align front feet c using a spanner

–

Remove top screws h from bearing

blocks g. Loosely attach lower bracket i with

screws h.

– Align the back feet using adjusting

device e and socket wrench f. Turn the adjusting device clockwise to raise the appliance up at the back.

^ Close the doors to check whether the

door handles are correctly aligned with one another.

Make sure that bearing blocks g are aligned with one another. If they are not, the covers will not fit properly.

^ Push the two appliances together,

and align them again.

^ Now tighten screws h.

Do not move the appliances until all the brackets are securely fitted.

Remove covers j from both appliances.

Loosely attach large upper bracket k using long screws l.

Push the two appliances together, and align them again.

Now tighten the screws l.

Installing in a side-by-side combination

Position the long stainless steel trim

Position wide brackets m at the top

and bottom on the back, and push the top bracket upwards until it is in the correct position (z).

^ Secure the brackets at the sides

using screws n.

To avoid vibrations, neither the brackets nor the screws should touch the pipework on the back of the appliances.

o lightly in the gap, making sure that it is located above bracket i.

Then push it carefully into the gap.

Use a soft cloth to do this to avoid denting the trim.

^ Carefully remove the protective foil

from the stainless steel trim.

^ Plug the two appliances into the

mains electricity supply points.

Appliances with integrated ice-maker (depending on model): Plumb the appliance into the mains water supply.

Carefully push the two appliances back into their final position. It is easier if you raise the appliances at the front, and roll them back on their rear rollers.

The height of the appliances can be aligned again if necessary.

Push short trim p into the gap at the top. Make sure that the gap in the trim faces the front. The trim must sit flush with the top of the appliances at the front.

Installing in a side-by-side combination

Fit cover q in the space between the

control panels. Make sure that the outer edges of the cover are flush with the control panels. The cover can be pulled out to adjust it to the right size. The gap in the cover must face downwards to fit properly over the stainless steel trim.

^ Break off thin tags r from plinth

facings a. Important: Make sure you remove these from the correct side i.e. from the handle side of the appliances.

Refit plinth facings , pushing firmly into position.

Refit covers b.

Changing the door hinging

The appliance is supplied left hand hinged. If right hand door hinging is required, follow the instructions below.

Removing the door handle:

First the side section of the handle must be removed:

^ Pull door handle a towards you. Side

section b slides back, creating a gap d between side section b and mounting plate c.

^ Place a suitable object (e.g. a spoon

handle) in gap d, and slowly lever the handle towards the door.

Be careful not to let the "spoon handle" slip, causing damage to the appliance.

The side section b can now be removed.

Remove the cover caps from the

opposite side, and fit them into the empty holes.

Changing over the door:

Open the appliance door.

^ Use a screwdriver to lever plinth a

out, then pull it forwards and out.

Use a screwdriver to remove cover b, then close the door.

Remove screw c completely.

Pull door support d together with bearing bolt e downwards, then tilt it forwards and take it off.

Pull side section b out of the guides on the mounting plate.

Loosen the 4 screws (Torx 15) in the mounting plate, and remove the handle.

Open the door, tilt it downwards and

take it off.

^ Remove cover f, and unscrew hinge

bracket g.

^ Fit bearing bolt h in the second hole

of hinge bracket g.

^ Refit bracket i and cover j turned

through 180° on the opposite side.

Screw hinge bracket g into the opposite side. The M4 screw has to be screwed into the left hole of the hinge bracket.

Changing the door hinging

In the following illustration the door is not shown in the closed position to make it easier to see what happens next.

^ Turn door support b through 180°,

pull bearing bolt a out, and then fit both parts into bearing block f: To do this push bearing bolt a the other way round through bearing block f into door support b. Swing the door support in, push upwards and re-assemble with screw c.

Turn cover f through 180°, and fit it on the other side.

Remove spacer k with a screwdriver and refit it on the opposite side.

Remove plug l from the door bearing bush in the door and refit on the opposite side.

Hang the door on bearing bolt h and then close the appliance door.

Changing the door hinging

Align the door with the appliance

housing using the long slot in bearing block f. Then tighten screw c.

Refit plinth facing d, pushing it firmly

into position. With the door open, position cover e

in the front of the plinth facing, and push it firmly into position.

Refitting the handle:

Please make sure you follow the instructions below carefully when you refit the handle. The door seal will be damaged if the handle is fitted incorrectly.

Then tighten all 4 fixing screws b.

Slide the side section of the handle

d into the guides on the mounting plate until it clicks into place.

It is important to check that the side section of the handle d does not come into contact with the door seal when opening the door, as this would damage the door seal permanently.

If, after you have refitted the handle, you find that the side section does touch the door seal when the door is opened:

^ Realign mounting plate c with grub

screws a until the mounting plate and the side section of the handle d are at the correct angle and the side section does not touch the door seal when the door is opened.

Loosely attach the handle to the opposite side of the door with the two front screws b.

Mounting plate c must be positioned on the side of the door so that when the door is closed it is flush with the side of the appliance. If this is not the case,

tighten both grub screws a with the allen key provided until mounting plate c lines up correctly.

600 mm wide appliances can be installed into a kitchen run. To match the height of the rest of the kitchen, the appliance can be fitted with a suitable top box a.

Building in the appliance

The air inlet and outlet must not be covered or blocked in any way. They should be dusted on a regular basis.

When installed next to a wall c a distance of approx. 36 mm is needed on the hinge side between the wall and the appliance, so that the door and the handle have sufficient space for opening.

Alteration rights reserved / 4805

FN 4957 S ed-1

M.-Nr. 06 785 320 / 00

en-GB

Miele KFNS 3917 S ed Operating and Installation Instruction

Specifications and Main Features

Frequently Asked Questions

User Manual

Contents
