Miele CVA 6405 Operating and Installation Instructions

Operating and Installation Instructions Coffee System
To prevent accidents and appliance damage read these instructions before installation or use.
M.-Nr. 09 741 560en - US, CA
Contents
IMPORTANT SAFETY INSTRUCTIONS.................................5
Preparing your appliance for an extended vacation ........................9
Guide to the coffee system .........................................10
Controls and display elements......................................12
Accessories .....................................................13
First steps to use .................................................14
Turning on .......................................................14
Water hardness ...................................................15
Operation .......................................................17
Filling the water tank ..............................................18
Filling the coffee bean container ....................................19
Turning the coffee machine on and off ...............................20
Adjusting the coffee dispensers to the cup height......................21
Preparing beverages ..............................................22
Preparing espresso, coffee or lungo (large) coffee........................22
Preparing double portions ...........................................22
Cancel preparation ................................................23
Preparing coffee beverages from ground coffee .........................23
Beverages with milk................................................25
Instructions for the milk container...................................25
Preparing beverages with milk .....................................26
Preparing hot water ................................................26
Preparing beverages from a profile....................................26
After use.........................................................26
Customizing your coffee ...........................................27
Grinder setting ....................................................27
Ground amount ...................................................28
Brewing temperature ...............................................28
Pre-brewing ground coffee ..........................................29
Setting the serving size............................................30
Setting the serving sizes while preparing beverages ......................30
Setting the serving sizes for various profiles .............................32
2
Contents
Creating a user profile.............................................33
Accessing profiles .................................................33
Creating a user profile ..............................................33
Selecting a user profile .............................................34
Changing a user profile name ........................................34
Deleting a user profile ..............................................34
Reverting to a user profile ...........................................35
Settings.........................................................36
Accessing the "Settings" menu .......................................36
Change and save settings...........................................36
Overview of possible settings ........................................37
Language........................................................39
Time of day ......................................................39
Date ............................................................39
Timer ...........................................................39
Eco mode........................................................41
Lighting .........................................................41
Info (displaying information) .........................................42
Locking the coffee system (System lock 0) .............................42
Water hardness ...................................................42
Display brightness .................................................42
Volume ..........................................................42
Factory default settings .............................................43
Showroom program (demo mode) ....................................43
3
Contents
Cleaning and care ................................................44
Overview ........................................................44
Rinsing the system.................................................46
Milk pipework.....................................................46
Milk container with lid ..............................................48
Main dispenser ...................................................49
Milk valve maintenance .............................................50
Water tank .......................................................51
Waste unit .......................................................51
Drip tray .........................................................52
Drip tray cover ....................................................53
Bean container....................................................53
Main dispenser connector ...........................................53
Interior and unit door ...............................................54
Brew unit ........................................................54
Removing the brew unit and rinsing it by hand ........................54
Degreasing the brew unit .........................................56
Exterior..........................................................57
Descaling .......................................................58
Frequently asked questions ........................................60
Cleaning clogged milk pipework ....................................69
After sales service ................................................72
Installation instructions ...........................................73
Caring for the environment.........................................74
Plumbing........................................................75
Lead free certificate ...............................................77
Electrical connection..............................................78
Installation ......................................................79
Ventilation .....................................................81
Installation.....................................................81
Adjusting the door hinges.........................................83
Adresses .......................................................87
4
IMPORTANT SAFETY INSTRUCTIONS
When using electrical appliances basic safety precautions should always be followed, including the following:
Read all instructions before installation or use of the coffee system.
Persons which lack physical, Please read these instructions carefully to prevent accidents and machine damage.
This appliance complies with current safety requirements. Improper use of the appliance can cause personal injury and material damage.
This appliance is for household use only, to prepare espresso, cappuccino and coffee. Do not use this appliance other than for its intended use. Any other use could be dangerous.
The manufacturer cannot be held responsible for damage caused by improper use of the appliance.
Proper use
This coffee system is for household
~
use and similar indoor environments only. This coffee system is not suitable for outdoor use.
Use this coffee system in standard
~
household environments only for
~
sensory or mental abilities or experience with the machine should not use it without supervision or instruction by a responsible person.
Children in the household
The coffee and hot water
,
dispensers present a danger of burning or scalding! Children's skin is more sensitive to high temperatures than that of adults. Keep children from touching the hot parts of the coffee machine or exposing parts of their bodies to the dispensers.
Keep the coffee system out of reach
~
of children.
Always supervise children in the
~
vicinity of the coffee machine. Do not allow children to play with the unit.
Danger of suffocation! Children
~
could become entangled in packaging (e.g. cling film) while playing or pull it over their heads and suffocate. Keep the packaging away from children.
the preparation of coffee beverages
such as espresso, cappuccino, latte macchiato, etc.
Any other type of use is not permitted.
5
IMPORTANT SAFETY INSTRUCTIONS
Technical safety
Installation work and repairs must
~
only be performed by a trained technician in accordance with national and local safety regulations. Repairs and other work by unauthorized persons could be dangerous and may void the warranty.
A damaged coffee system can be
~
dangerous. Before installing the coffee machine, check for externally visible damage. Do not operate a damaged unit.
Be certain your appliance is
~
properly installed and grounded by a qualified technician. To guarantee the electrical safety of this appliance, continuity must exist between the appliance and an effective grounding system. It is imperative that this basic safety requirement be met. If there is any doubt, have the electrical system of the house checked by a qualified electrician. The manufacturer cannot be held responsible for damages caused by the lack, or inadequacy, of an effective grounding system.
To prevent damage to the coffee
~
machine, make sure that the connection data on the data plate (fuse rating, voltage and frequency) matches the electrical power supply. Check this before connecting the machine. If in doubt, contact a qualified electrician.
Do not use an extension cord to
~
connect the appliance to electricity. Extension cords do not guarantee the required safety of the appliance (danger of overheating).
For safety reasons, this coffee
~
machine may only be used once it has been safely installed.
If the machine is installed in
~
combination with other appliances, a protective base should be installed between the appliance and the unit.
The coffee machine must not be
~
used in mobile installations such as boats.
Only use the coffee machine in
~
ambient temperatures between +50°F/10°C and +100°F/38 °C.
Ensure that there is sufficient
~
ventilation around the coffee machine. The ventilation openings in the surrounding cabinets and the space below the ceiling must be at least 78 3/4" condensation can form, causing damage to the coffee machine or the surrounding cabinets.
~
electric burner, or in a heated oven.
~
closed kitchen cabinet, use the coffee machine only when the cabinet door is open. Do not close the cabinet door when the coffee machine is in operation.
~
accessible after installation.
~
Only then can the manufacturer guarantee the safety of this machine.
~
the water intake hose.
2
(200 cm2). Otherwise
Do not place on or near a hot gas or
If the coffee machine is installed in a
The water supply must be
Only use Miele original spare parts.
Do not damage or kink the cover of
6
IMPORTANT SAFETY INSTRUCTIONS
The integrated waterproof system
~
will effectively protect the machine from water damage if the following conditions are met:
The coffee machine is installed
correctly (electricity and water supply).
The coffee machine is immediately
repaired if any damage is detected.
The water supply is shut off during
extended periods of non-use (e.g. vacation).
Before service or maintenance
~
disconnect the power supply by either removing the fuse, “tripping” the circuit breaker or unplugging the unit.
Never open the outer casing of the
~
appliance. Tampering with electrical connections or components and mechanical parts is dangerous and may cause machine damage.
Do not operate any appliance with a
~
damaged cord or plug, or after the appliance malfunctions or has been damaged in any manner. Contact Miele.
To protect against fire, electric
~
shock and injury to persons do not immerse cord, plugs, or coffee machine in water or other liquid.
Proper use
The coffee and hot water
,
dispensers present a danger of burning or scalding! The dispensed liquids and steam are extremely hot. The water in the drip tray may be very hot as well. Be careful when emptying it.
Please note:
– Keep away from the areas under the
coffee and hot water dispensers when beverages or steam are being dispensed.
– Do not touch hot surfaces. Use
handles or knobs.
– The spouts can spray hot liquid or
steam. Be sure the main dispenser is fitted correctly and only use it if it is clean.
Always attach the cord to the
~
appliance first, then plug it into the wall outlet. To disconnect, turn the machine off, then remove the plug from the wall outlet.
Do not let cord hang over edge of
~
table or counter, or touch hot surfaces.
To reduce the risk of injury, do not
~
drape cord over the counter top or table top where it can be pulled on by children or tripped over unintentionally.
,
Never look into the lighting directly or with an optical instrument.
Do not use the coffee machine to
~
clean objects.
Before the first use, clean the coffee
~
system and milk container thoroughly (see "Cleaning and care").
7
IMPORTANT SAFETY INSTRUCTIONS
Please note the following regarding
~
water:
Without a plumbed water supply:
Only fill the water tank with cold, fresh tap water. Hot water or other liquids can damage the coffee system.
Change the water every day to
prevent a build-up of bacteria. When using a plumbed water supply: Empty the water tank once a day.
Do not use mineral water. Mineral
water will cause a lot of limescale to build up in your coffee system and damage it.
– Do not use water from reverse
osmosis units. This could damage the appliance.
Fill the bean container with roasted
~
whole coffee beans only. Do not fill the bean container with coffee beans which have been treated or with ground coffee.
Sugar will destroy the system! Do
~
not use coffee beans which have been treated with caramel, sugar, etc. or fill the coffee system with other liquids that contain sugar.
Do not lean on the open coffee
~
machine door, or apply any pressure to it. Otherwise, the coffee machine could be damaged.
The use of accessory attachments
~
not recommended by the appliance manufacturer may result in fire, electric shock or injury to persons.
Please note the following with
~
regard to cleaning the coffee machine:
Before cleaning and maintenance
switch off the appliance and disconnect circuit breaker.
– Clean the coffee system and milk
container daily (see "Cleaning and care").
– The steam dispensed by a steam
cleaner can reach the electrical components and cause a short circuit. Never use a steam cleaner to clean the coffee machine.
Descale the coffee machine regularly with the appropriate number of Miele descaling tablets for the water hardness level in your area. Descale the machine more frequently in areas with very hard water.
Do not fill anything into the ground
~
coffee chute except ground coffee or a Miele cleaning tablet for degreasing the brew unit.
Only use plain milk. Most additives
~
contain sugar, which will clog the milk pipework and damage the coffee system.
If you use dairy milk, use only
~
pasteurized milk.
8
Degrease the brew unit regularly with the supplied Miele cleaning tablets. Depending on the natural oil content of the coffee used, the brew unit can become blocked quite quickly.
IMPORTANT SAFETY INSTRUCTIONS
For machines with stainless steel trim:
Do not use sticky notes, transparent
~
adhesive tape, masking tape or other types of adhesive on the surface of the trim. These damage the surface, causing it to lose its dirt repellent protective coating.
The surface of the stainless steel
~
trim is susceptible to scratching. Even magnets can cause scratches to appear.
Preparing your appliance for an extended vacation
If you elect to turn off the water to
~
your home for an extended period of time, please note that this may not be enough to reduce the risk of a leak. To be completely safe, you must turn off the water supply to each individual appliance. This means under the sink for a dishwasher, at the laundry bib for your washer, etc.
SAVE THESE INSTRUCTIONS
9
Guide to the coffee system
Front view
a On/Off touch control K
b Control and display elements
c Door grip
d Hot water dispenser
e Drip tray
f Main dispenser, height-adjustable, with lighting
g Milk container with lid
10
Interior view
Guide to the coffee system
h Ground coffee chute cover
i Brew unit
j Ground coffee chute
k Grind control lever
l Coffee bean container
m Water tank with inlet
n Drip tray with no-spill grid
o Waste unit
p Drip catcher cup
q Main dispenser connector cap
r Service cover
11
Controls and display elements
a On/Off touch control K Turn machine on and off
b Beverage controls Preparation of
. Espresso / Coffee
H Cappuccino k Latte macchiato
c More programs x More beverages such as lungo coffee, café latte,
hot milk, froth milk and hot water See "Mainentance" menu
d Display Information on the current action or status
e Back # Go back to previous menu level, cancel unwanted
actions
f Arrow keys Y X Show more options on the display and highlight a
selection
g OK button Confirm display messages and save settings
h "Profile" Save and manage profiles
i "Settings" Change settings, display information, or check
which settings are currently active
j Two servings ° Prepare two servings of a beverage
k Parameter , Check or change coffee preparation settings
l Optical interface (for Miele Technical Service only)
12
Accessories
Included accessories
Coffee scoop
for measuring ground coffee
Milk container with lid
for storing and preparing milk
Milk pipework cleaning agent
for cleaning the milk system (starter kit)
2 cleaning containers (large, small)
for cleaning and care
Descaling tablets
for descaling the water pipes (starter kit)
Cleaning tablets
for degreasing the brew unit (starter kit)
Test strips
for determining the water hardness
Cleaning brush
for cleaning the milk pipework
Silicone grease
for lubricating the main dispenser cap connector
Optional accessories
Miele offers a range of useful accessories, as well as cleaning and conditioning products for your coffee machine.
All-purpose micro fiber cloth
for removing fingerprints and minor contamination
Milk container with lid
for storing and preparing milk
Compact seal
Milk container lid for storage in the fridge
Milk pipework cleaning agent
for cleaning the milk system
Descaling tablets
for descaling the water pipes
Cleaning tablets
for degreasing the brew unit
Silicone grease
for lubricating the main dispenser cap connector
Main dispenser cap connector
spare part
Milk pipework angle section
spare part
Additional accessories are available. Contact Miele or visit the Miele website for more information.
13
First steps to use
Before the first use
The appliance must be correctly
^
installed and connected before the first use. See the "Installation instructions".
Remove any protective coverings.
^
Clean the coffee machine thoroughly (see "Cleaning and care") before filling it with water and coffee beans.
Turning on
When you turn the coffee machine on for the first time, you will be prompted to set the following after the welcome screen has appeared:
– Language
– Date
– Time of day
– Display (time of day)
^
Tap the On/Off button K.
Setting the language
Tap the arrow buttons until the
^
desired language is highlighted. Tap the OK button.
Tap the arrow buttons until the
^
desired country is highlighted. Tap the OK button.
The setting is now saved.
Setting the date
Tap the arrow buttons until the
^
current year appears. Tap the OK button.
^ Repeat this process for "Month" and
"Day" until the current date is set.
The setting is now saved.
Set Time of day
^ Tap the arrow buttons until the
current time appears. Tap the OK button.
The setting is now saved.
The display briefly shows the "Miele ­Welcome" message.
14
First steps to use
Display
You can choose between the following options:
On: The date and time are always
displayed even when the machine is turned off.
Off: The display will go dark as soon
as the machine is turned off.
Night dimming: The date and time
will be displayed between 5:00 and 23:00.
Tap the arrow buttons until the
^
desired display type is highlighted. Tap the OK button.
Depending on which option you select, the coffee machine may consume more energy. This is indicated by a message on the display.
The display will then show the message "Set-up successful".
The display shows the message "Fill and insert water container".
^
Fill the water container with cold, fresh tap water.
Water hardness
Water hardness is an indication of the amount of minerals dissolved in water. The higher the mineral content, the harder the water. And the harder the water, the more often the coffee machine will need to be descaled.
The coffee machine monitors the quantity of water and steam used. The number of beverages that can be dispensed before the machine needs to be descaled will depend on the water hardness level set.
Set the water hardness level on the coffee machine to the water hardness level for the local area to ensure that the machine functions correctly and is not damaged. This will ensure that the reminder to descale the machine will appear in the display at the correct time. If unsure of your water hardness contact your local water authority.
You can program four hardness levels on the machine:
Water hardness Hardness
0 - 8.7 gr/gal (0 - 8.4°dH)
8.7 - 14.6 gr/gal (8.4 - 14°dH)
14.6 - 21.9 gr/gal (14 - 21°dH)
more than
21.9 gr/gal (21°dH)
range
soft soft 1
medium medium 2
hard hard 3
hard very hard 4
Setting (hardness level)
15
First steps to use
Determine water hardness
You can also determine the water hardness with the supplied test strips.
Dip the test strip in water for about
^
one second. Then shake off any excess water. The result will be visible after about one minute.
You can now set the water hardness level for the coffee machine.
Setting the water hardness
^ Tap "Settings". ^ Tap the arrow buttons until "Water
hardness" is highlighted. Tap the OK button.
^
Tap the arrow buttons until the desired hardness level is highlighted. Tap the OK button.
The setting is now saved.
16
Operation
You can operate the coffee machine by tapping the touch buttons with your finger.
You are in the beverages menu when the display shows:
{ Miele
Select drink
To prepare a coffee beverage, tap one of the beverage buttons.
You can find more beverages in the menu "More programs" x.
Selecting and navigating a menu
To select a menu, tap the corresponding button. You will be able to start actions or alter settings in the selected menu.
If you want to select an option, tap the arrow keys X and Y until the desired option is highlighted.
To confirm the selection, tap the OK button.
Exit menu or cancel action
To exit the current menu, tap #.
If a button has not been pressed for a while, the coffee machine will revert to the drink menu.
Settings
Language F
Time of day
Timer
A scroll bar at the right of the display shows that additional options or text is available. You can display these by using the arrow keys.
The check mark ( shows which setting is currently selected.
17
Filling the water tank
If the coffee machine is connected to a plumbed water supply, the water is filled up automatically as soon as the machine is turned on.
The inlet guide at the water tank lid ensures that the water is flows in quietly.
Of course, you can also fill the water tank manually when using the coffee machine without a plumbed water supply (water tank operation).
Change the water daily to
,
prevent bacteria growth.
Before using the coffee system for the first time, clean the appliance. See "Cleaning and Care".
Open the unit door.
^
Only fill the water tank with cold, fresh tap water.
Hot or warm water or other liquids can damage the coffee machine.
Do not use mineral water to fill the water tank. Mineral water will cause serious lime scale deposits to build up in your coffee machine and damage it.
18
^
Slowly pull the water tank forward and out.
^
Remove the lid and fill the container with fresh, cold tap water to the "Max." mark.
^
Push the water tank into the unit until it clicks into place.
If the water tank has not clicked into place, pull the tank out, check and clean the niche. The valve might leak. If necessary, clean the niche and surface.
Filling the coffee bean container
You can make coffee or espresso from roasted whole coffee beans that the coffee machine will grind fresh for each portion. Add fresh beans to the coffee bean container.
Alternatively, you can make coffee or espresso from ground coffee (see "Coffee beverages prepared from ground coffee").
Only fill espresso or coffee beans in the beans container. Anything else ­including ground coffee - will damage the grinding unit.
Pull the bean container out.
^
Slide the lid back, then fill the bean
^
container with roasted coffee beans.
Caramelized or otherwise pre-treated beans or sugar containing beverages must not be filled into the appliance. It will damage the coffee system.
^ Slide the cover all the way forward
again.
^ Slide the bean container back into
the coffee machine.
^ Close the door.
19
Turning the coffee machine on and off
Turning on
When the machine is turned on, it heats up and rinses out the pipework. This cleans and heats the pipework to ready the machine for coffee preparation.
If the coffee machine still has an operating temperature higher than 140°F (60°C), rinsing will not take place.
Tap the On/Off button K.
^
Tip: If you do not want the water from the rinsing process to flow into the drip tray, place a suitable container (such as the small cleaning container) underneath the coffee dispensers before preparing the first coffee of the day.
After heating up, the machine will rinse the pipes. Hot water will flow from the coffee dispensers.
Drinks can now be prepared.
Turning off for longer periods of time
If you will not be using the coffee machine for a while:
Empty out the drip tray, the waste
^
unit and the water tank.
^ Thoroughly clean all components
including the brew unit, the main dispenser connector and the drip bowl in the door.
^ Turn the machine off.
Turning off
^
Tap the On/Off button K.
When a coffee beverage has been prepared, the coffee machine also rinses the coffee lines before turning off.
20
If you leave the door open for an extended period of time, unplug or disconnect it from the power supply to save energy.
Adjusting the coffee dispensers to the cup height
The coffee dispensers can be raised or lowered to the height of your cup or glass. If the dispensers are closer the beverage will not cool down as quickly and the crema will have a better consistency.
^ Pull the coffee dispenser down to the
same level as the rim of the cup.
or ^ Push the dispenser up until there is
enough room to fit a larger cup or glass underneath.
21
Preparing beverages
Preparing espresso, coffee or lungo (large) coffee
^ Place a cup under the main spout. ^ Tap the touch key for the desired
beverage:
. Espresso
/ Coffee
x in "More programs": Lungo
coffee
The chosen coffee beverage will now be dispensed.
To ensure that any residues from the factory testing process are removed from the brewing system, please discard the first two cups of coffee when using the machine for the first time.
Preparing double portions
You can request two portions of espresso or coffee at once in one cup or in two separate cups simultaneously.
To fill two cups at the same time,
^ Place a cup under each coffee
dispenser.
^ Tap °.
The ° symbol is illuminated. ^ Tap the touch key for the desired
beverage.
Two portions of the desired beverage will be dispensed from the coffee dispensers.
Tip: If you do not tap any beverage keys for a while, the "Double portion" ° selection will be reset.
22
Preparing beverages
Cancel preparation
You can cancel preparation while "Stop" is displayed.
Tap the OK button.
^
The coffee machine will cancel preparation.
If two portions are selected for preparation, a single tap on the OK button will only cancel preparation of the first portion. To cancel both portions, keep your finger on the OK button a bit longer.
Preparing multiple cups of coffee, one directly after another (coffee pot)
You can use the "Coffee pot" function to prepare multiple cups of coffee, one directly after another (max. 1 l), in order to fill a coffee thermos, for example. You can prepare up to 8 cups this way.
^
Place a suitably sized pot or container under the main dispensers.
You can cancel the process at any time:
Tap the OK button or x .
^
You can use the "Coffee pot" function twice. After that, the coffee machine will need to cool down for an hour to prevent damage to the unit.
Preparing coffee beverages from ground coffee
To make espresso or coffee using ground coffee, add a portion of ground coffee to the ground coffee chute.
This allows you to prepare a decaffeinated coffee even if the bean container is already filled with regular coffee beans, for example.
The coffee machine will automatically recognize that ground coffee has been placed in the chute.
Only one portion of coffee or espresso can be prepared at a time when using ground coffee.
^
Tap x .
^
Tap the arrow buttons until "Coffee pot" is highlighted. Tap the OK button.
^
Tap the arrow buttons until the desired number of cups (3 to 8) is highlighted. Tap the OK button.
^
Follow the instructions on the display.
Each cup of coffee will be individually ground, brewed and poured. Meanwhile, the display reports on the process while it is going on.
23
Preparing beverages
Filling ground coffee
Use the scoop supplied with the machine to ensure the correct amount of ground coffee is used.
Do not add more than one level scoop of ground coffee to the coffee chute. If too much ground coffee is filled into the chute the brew unit cannot process it.
The coffee machine will use all the ground coffee that you have filled into the chute for the next coffee preparation.
^ Open the appliance door.
The display shows the message "Use ground coffee?"
Preparing coffee beverages from ground coffee
If you want to prepare a coffee beverage from ground coffee:
Tap the arrow buttons until "Yes" is
^
highlighted. Tap the OK button.
You can now select which coffee beverage you want prepared from the ground coffee.
Place a cup under the main
^
dispensers.
^ Tap the button for the desired
beverage.
The desired coffee beverage will be prepared.
If you don't wish to prepare a beverage from ground coffee:
^ Tap the arrow buttons until "No" is
highlighted. Tap the OK button.
^
Pull out the cover of the ground coffee chute. Open the lid of the ground coffee chute.
^
Place a level scoop of ground coffee into the chute.
^
Close the ground coffee chute and slide the cover back into the machine. Close the door.
24
The ground coffee will be directed into the waste container.
If no button is pressed within approx. 15 seconds, the ground coffee is emptied into the waste container.
Beverages with milk
You can prepare various specialty coffee beverages with milk or Hot milk and Milk froth.
The following specialty coffee options are available:
Cappuccino consists of about two-thirds milk froth and one-third espresso.
Preparing beverages
Latte macchiato consists of one-third
each of hot milk, milk froth and espresso.
Café latte consists of hot milk and coffee.
Instructions for the milk container
The milk is not cooled in the milk container. if you do not prepare milk beverages for a while, place the milk container in the refrigerator. Good milk froth can only be prepared with cold milk (under 55°F / 13 °C).
Only use plain milk. Most sugary additives can clog the milk lines.
a Lid
b Sensor rod
c Milk intake tube
d Glass container
^ Fill the milk container to a maximum
level of 3/4" (2 cm) below the rim. Place the lid on the milk container.
Ensure that the neck and lip of the container are kept clean (both when filling and when moving the container). Contamination can cause malfunctions.
^
Slide the milk container into the front of the coffee machine.
25
Preparing beverages
Preparing beverages with milk
Place a suitable cup or glass under
^
the main dispensers.
Tap the touch key for the desired
^
beverage:
H Cappuccino
k Latte macchiato
x in "More programs":
Café latte, Hot milk, Milk froth
The desired beverage will be prepared.
Preparing hot water
Danger of scalding and burns at
,
the hot water dispenser! The dispensed water is very hot.
^ Place a suitable cup or glass under
the main dispensers.
^ Tap x. ^
Tap the arrow buttons until "Hot water" is highlighted. Tap the OK button.
Hot water is dispensed into the container under the hot water spout.
Preparing beverages from a profile
If you have already created a profile, you can select it before preparing a beverage. See "Creating a user profile".
Tap "Profile".
^
Tap "Select profile".
^
Tap the arrow buttons until the
^
desired profile is highlighted. Tap the OK button.
The name of the profile will appear in the display to show that a profile has been selected.
Now you can prepare your desired beverage.
After use
If you have prepared a beverage with milk, "Start rinse cycle" will appear on the display after a while.
^ Tap the OK button.
The milk lines will be rinsed.
Even if you do not confirm with "OK", the coffee machine will automatically rinse the milk lines after a while.
To stop dispensing water,
^
Tap the OK button.
The coffee machine will cancel preparation.
26
To ensure that your coffee system is ideally adjusted to the type of coffee you use, you can use the "Parameters" , menu to change the ground amount, adjust the brewing temperature or select the "Pre-brewing" option. You can customize these settings for each beverage.
Customizing your coffee
To prevent damage to the grinder:
Adjust the coffee grinder one level at a time.
Let the beans grind before adjusting another notch.
You can also adjust the grinder setting to suit the type of coffee you are using.
Grinder setting
When the beans are ground correctly the coffee or espresso will flow evenly into the cup and have a good crema.
The ideal crema has a hazel coloring.
There are various ways to tell whether the coffee grinder is set correctly.
The grind is too coarse if
– espresso or coffee flows into the cup
too quickly;
– the crema is very pale and uneven.
Use a finer grinder setting so the coffee beans will be ground more finely.
The grind is too fine if
espresso or coffee flows into the cup very slowly;
the crema is dark brown.
Use a coarser grinder setting so the coffee beans will be ground more coarsely.
Open the appliance door.
^
^ Push the grinder slide control to the
left by no more than one level (for a finer grind) or to the right (for a coarser grind).
^
Close the appliance door.
^
Prepare a coffee beverage.
Then you can adjust the grinder by another level.
The adjusted grinder setting will only take effect after the second coffee portion.
27
Customizing your coffee
Displaying and adjusting the parameters for a beverage
Tap ,.
^
The , symbol is illuminated.
Tap the arrow buttons until the
^
desired beverage is highlighted. Tap the OK button.
The current settings for the ground amount, brewing temperature and pre-brewing for this beverage are displayed.
Ground amount
The coffee machine can grind and brew 6-14 g of coffee per cup. The greater the quantity, the stronger the coffee or espresso.
There are various ways to tell whether the amount of coffee is set correctly:
The ground amount is too small if
– espresso or coffee flows into the cup
too quickly;
the crema is very pale and uneven;
the espresso or coffee lacks body.
Increase the amount of coffee so that more ground coffee is brewed.
The ground amount is too much if
espresso or coffee flows into the cup very slowly;
the crema is dark brown;
Tap the arrow buttons until "Amount
^
of coffee" is highlighted. Tap the OK button.
Tap the arrow keys to change the
^
ground amount. Tap the OK button.
The setting is now saved.
Brewing temperature
The ideal brewing temperature will depend on
the type of coffee,
– whether an espresso or a coffee is
being prepared, and
– the altitude of the region.
There are five brewing temperatures.
Tip: Not every coffee can tolerate high temperatures. Certain types are too delicate - the crema on top would not be as good and the taste would be impaired.
^
Tap the arrow keys until "Brewing temperature" is highlighted. Tap the OK button.
The check mark ( shows which brewing temperature is currently selected.
^
Tap the arrow keys until the desired temperature is highlighted. Tap the OK button.
The setting is now saved.
the espresso or coffee tastes bitter.
Decrease the amount of coffee so that less ground coffee is brewed.
28
Pre-brewing ground coffee
When the pre-brewing function is Turned on, the freshly ground coffee is first moistened with a little hot water. Then the remaining water is forced through the moistened coffee at high pressure. This helps release the flavor of the coffee.
You can program normal or long pre-brew or turn the Pre-brewing" function off. The default factory setting for the "Pre-brew" function is Off.
^ Tap the arrow keys until
"Pre-brewing" is highlighted. Tap the OK button.
The check mark ( shows which pre-brew option is currently selected.
^ Tap the arrow keys until the desired
setting is highlighted. Tap the OK button.
Customizing your coffee
The setting is now saved.
29
Setting the serving size
The flavor of a coffee beverage depends not only on the type of coffee, but also on the quantity of water used. You can adjust the amount of water used for each portion of espresso, coffee or hot water to suit your cup size and the type of coffee used.
For beverages prepared with milk, you can also adjust the milk and milk froth ratio in addition to the espresso or coffee size. You can also program the portion sizes of hot milk and froth.
There is a maximum amount which can be programmed for each type of drink. Preparation stops when this is reached. The maximum portion size possible for that type of beverage will then be saved.
The changed beverage size is always stored in the current profile. The name of the current profile is shown at the top left of the display.
Setting the serving sizes while preparing beverages
Setting the serving sizes for Espresso ., Coffee / and Lungo coffee /
Place the desired cup under the main
^
dispenser.
Tap ., / and / until the display
^
shows "Change".
The desired beverage is prepared and the display shows "Save".
Once the cup is filled to your desire,
^
tap the OK button.
The portion size programmed will now be dispensed every time that particular beverage is selected.
There are two ways to program the portion amount:
Using the beverage keys if you prepare a coffee beverage, or
Selecting "Beverage size" in the "Parameter" , menu.
Tip: You can cancel the amount programming while "Stop" is displayed.
If there is insufficient water in the water tank during preparation, the coffee machine will stop the programming. The beverage amount will not be saved.
30
Setting the serving size
Setting serving sizes for cappuccino and latte macchiato
Place a suitable cup or glass under
^
the main dispensers.
Tap H or k until the display
^
shows"Beverage size".
The ingredients of the drink are now displayed and their respective quantities can be changed.
Cappuccino: Milk froth, Espresso
Latte macchiato: Hot milk, Milk froth, Espresso
^ Use the arrow keys to select all
ingredients for which you wish to alter the portion size. Use the OK button to confirm your individual selections.
A check mark ( placed in front of an ingredient indicates that its quantity will be changed.
^ Tap the arrow keys until "Start" is
highlighted. Then tap the OK button.
Setting serving sizes for Café latte, hot milk and milk froth
Place a suitable cup or glass under
^
the main dispensers.
Tap ,.
^
Tap the arrow buttons until the
^
desired beverage is highlighted.
Tap the arrow buttons until "Beverage
^
size" is highlighted. Tap the OK button.
For Café Latte the quantities for individual ingredients – hot milk, coffee – can be altered as described in "Setting serving sizes for cappuccino and latte macchiato".
For Milk froth and Hot milk, proceed as described under "Setting the serving sizes for coffee and espresso".
The coffee machine will now start preparing your beverage. Portion sizes can be set for each selected ingredient when "Save" appears on the display.
^
Tap the OK button when the cup has been filled to the level you want.
^
Save the portion size required for selected ingredients.
The portion size and ingredients programmed will now be dispensed every time that particular beverage is selected.
31
Setting the serving size
Selecting the beverage size in the "Parameter" , menu
^ Tap , . ^ Tap the arrow buttons until the
desired beverage is highlighted. Tap the OK button.
^ Tap the arrow buttons until "Beverage
size" is highlighted. Tap the OK button.
From now on the beverage will be prepared according to the portion sizes set.
Setting the serving sizes for various profiles
You can customize the serving sizes of the individual beverages for each profile.
^ Tap "Profile". ^ Select the desired profile.
The name of the current profile is shown at the top left of the display.
Now you can either select "Beverage size" in the "Parameter" , menu or set the serving size while preparing the beverage, as described above.
32
Creating a user profile
If the unit is used by several people with different coffee preferences, you can create individual user profiles. You can adjust the serving size for each coffee beverage for each profile (see "Setting the serving sizes").
The name of the current profile is shown at the top left of the display.
Accessing profiles
Tap "Profile".
^
The "Profile" is illuminated.
You can now create a profile.
If you have already created a profile in addition to the standard Miele profile, you also have the following options:
Select a user profile from the
pre-set profiles already created for the unit.
Change user profile, if you wish to
change the name of a profile.
Delete user profile if you wish to delete a profile.
Revert to adjust whether the coffee machine automatically reverts to the standard Miele profile or continues to use the most recently selected user profile.
Tip: By tapping # or "Profile" you can return to the main menu.
Creating a user profile
Tap the arrow keys until "Create
^
profile" is highlighted. Tap the OK button.
Letters and numbers will now appear in the display that you can select using the arrow keys. You can also use the arrow keys to turn between numbers, capitalized or lower-case characters.
Tap the arrow keys to select the
^
desired character. Tap the OK button.
You will see the selected character in the top line of the display.
^ Repeat the process until the desired
name appears in the top line of the display.
Tip: Use the # key to delete the character entered last.
Once you have completed your entry and want to Save it,
^
use the arrow keys to select the check mark ( and tap the OK button.
If you do not want to save your entry,
^
tap the # key until all characters have been deleted and the coffee machine will revert to the previous selection.
Tip: The most recently created profile is the currently selected profile.
33
Creating a user profile
Selecting a user profile
This selection is only possible if a profile has already been created in addition to the standard Miele profile.
Tap the arrow keys until "Select a
^
user profile" is highlighted. Tap the OK button.
Use the arrow keys to select the
^
profile that you want to select. Tap the OK button.
The name of the current profile is shown at the top left of the display.
Changing a user profile name
This selection is only possible if a profile has already been created in addition to the standard Miele profile.
^ Tap the arrow keys until "Change
name" is highlighted. Tap the OK button.
Now continue as you would for "Creating a user profile":
Deleting a user profile
This selection is only possible if a profile has already been created in addition to the standard Miele profile.
Tap the arrow keys until "Delete
^
profile" is highlighted. Tap the OK button.
Use the arrow buttons to select the
^
user profile you wish to delete.
Tap the OK button.
^
A check mark ( will appear next to the name and the profile will be deleted shortly.
To delete a character, select #,
To enter a new character, first select it, then confirm using OK,
To save the name change, select ( and tap the OK button to save.
34
Reverting to a user profile
You can customize the unit so that, after each drink prepared, it automatically reverts to the standard Miele profile or retains the most recently selected custom profile.
Tap the arrow keys until "Change
^
profile" is highlighted. Tap the OK button.
You can now choose between
Manually: The unit retains the
selected user profile until another profile is selected.
After dispensing: After each drink
prepared, the unit automatically reverts to the standard Miele profile.
When turned on: Every time the unit
is turned on, it automatically selects the standard Miele profile, no matter which user profile was set before it was last turned off.
Creating a user profile
^ Tap the arrow buttons until the
desired option is highlighted. Tap the OK button.
35
Settings
The "Settings" menu allows you to customize the coffee machine for your personal needs.
Accessing the "Settings" menu
Tap "Settings".
^
Now you can review or change any settings.
The check mark ( next to the individual entry shows you which setting is currently active.
A tap on # will take you to the next menu level. A tap on "Settings" will take you back to "Select beverage".
Tip: If you have turned on the time display or selected "Night dimming", you can chance the settings without turning on the coffee machine. Tap "Settings" to do this.
Change and save settings
Tap "Settings".
^
Use the arrow buttons to select the
^
desired setting. Confirm with the OK button.
Tap the arrow buttons until the
^
desired option is highlighted.
Tap the OK button.
^
The setting is now saved.
36
Overview of possible settings
The factory default setting for each menu item is displayed in bold.
Menu item Possible settings
Language German, English, additional languages
Country
Time Display
off / on / Night dimming
Time format
12 hr / 24 hr
set
Date set
Timer Timer 1
Activate
Turn on at / Turn off after (1:00) / Turn off at
Day of the week
Monday / Tuesday / Wednesday / Thursday / Friday / Saturday /
Sunday / Accept
Activate
Turn on at (yes / no) / Turn off at (yes / no)
Timer 2
Activate
Turn on at / Turn off at
Day of the week
Monday / Tuesday / Wednesday / Thursday / Friday / Saturday /
Sunday / Accept
Activate
Turn on at (yes / no) / Turn off at (yes / no)
Eco mode Eco mode (on / off)
Lighting Display brightness
Turn off after
Info Number of drinks
Total portions / Espresso / Coffee / Large coffee / Cappuccino / Latte
macchiato / Cafè Latte / Milk froth / Hot milk / Hot water No. of uses until descaling:
System lock on / off
Water hardness soft 1
medium 2 hard 3
very hard 4
Display brightness Set the brightness
Volume Buzzer tones
Keypad tone
Settings
37
Settings
Menu item Possible settings
Plumbed water connection
Showroom program Demo mode (on / off)
Factory default settings Do not reset
on / off
Reset
38
Settings
Language
You can select your language and country for all text displayed on your machine.
Tip: If you have accidentally selected the wrong language, follow the flag icon
F to return to the "Language" option.
Time of day
You can customize the time display, the time format and the time of day.
Display (time of day)
You can choose between the following options:
on: The time of day is always
displayed even when the machine is turned off.
off: The time of day is not displayed
when the machine is turned off.
NIght dimming: The time of day is
only displayed during the day.
Depending on which option you select, the coffee machine may consume more energy. This is indicated by a message on the display.
Setting the time of day
Tap the arrow keys to set the hours and minutes.
Date
Tap the arrow keys to set the year, month and day.
Timer
Two timer options with the following timer functions are available:
The coffee machine
– turns on at a particular time, e.g. in
the morning for breakfast ("Turn on at"),
– turns off at a particular time ("Turn off
at"),
– turns off automatically after a certain
amount of time if no button is tapped or no beverage is prepared ("Turn off after"; only available for Timer 1).
You can also assign the timer functions to individual days of the week.
For "Turn on at" and "Turn off at", the timer must be activated and at least one weekday must be assigned.
Time format
The available options are:
24-hour clock (24 hr)
12-hour clock (12 hr)
39
Settings
Select timer
The available options are:
Timer 1:
Turn on at, Turn off at, Turn off after
Timer 2:
Turn on at, Turn off at
Turn on at
Please note that the coffee machine will not turn on at the required time if you have activated the system lock.
Tap the arrow keys to set the hours and minutes.
If the coffee machine has turned itself on automatically three times using the timer function "Turn on at" but no drinks have been dispensed, the machine will not turn itself on again automatically. This prevents the coffee machine from turning itself on unnecessarily, for example while you are away on holiday.
Turn off after
The timer function "Turn off after" is only available with the Timer 1 option.
If none of the buttons has been pressed or no beverage has been prepared, the coffee machine will turn itself off after 30 minutes to save energy.
You can change this default setting using the arrow keys and select a time between 15 minutes and 9 hours.
Assign weekdays (Days of the week)
Select the day of the week you want. The selected weekday is marked as 9 .
Once all desired weekdays are checked:
^ Tap the arrow key X until "Accept" is
highlighted. Tap the OK button.
The programmed times will, however, remain in memory and will be reactivated after manually turning the machine on again.
Turn off at
Tap the arrow keys to set the hours and minutes.
If you are away for a while, the stored times will be reactivated after the next time the machine is manually turned on (see "Turn on at").
40
Settings
To activate and deactivate the timer
If the timer for "Turn on at" is activated, the + symbol and the desired turn-on time will appear on the display 23:59 hours before if the time display has been set to "On" or "Overnight shutdown".
If the system lock has been activated, the timer function "Turn on at" cannot be selected.
Select the timer function you want. The selected timer function is marked as 9 .
^ Tap the arrow key X until "Accept" is
highlighted. Tap the OK button.
Eco mode
The eco mode is a power-saving mode. The steam system will only heat up once a coffee beverage or steam for hot milk and milk froth is requested.
Lighting
The following options are available:
Adjust the brightness of the lighting
while the machine is turned on.
Adjust the brightness of the lighting
while the machine is turned off.
Specify when the lighting should turn
off ("Turn off after").
Adjusting the brightness
First select:
Machine turned on
– Machine turned off
Use the arrow keys to adjust the brightness.
To turn the lighting off: ^ Tap the arrow key X until the white
bars are no longer visible and "Turned off" appears on the display.
If eco mode is turned off, milk froth and hot milk as well as coffee and espresso can be prepared consecutively. The steam system remains heated up and uses significantly more energy.
The coffee machine will indicate the changed energy consumption.
Lighting: Setting the turn-off time (Turn off after)
You can select for how long the coffee machine should be illuminated after it has been turned off.
In turned-on mode, the coffee machine will remain illuminated for another 10 minutes after the last action. You cannot change this time.
Tap the arrow keys to set the hours and minutes.
41
Settings
Info (displaying information)
In the menu option "Info" the number of portions prepared for each individual beverage can be displayed.
You can also see whether more than 50 portions can be dispensed before the machine needs to be descaled ("Please descale the coffee system. Remaining number of servings:").
To return to the previous menu,
tap the OK button.
^
Locking the coffee system (System lock 0)
You can lock the coffee machine to prevent it being used without your knowledge, by children, for example.
Activating and deactivating the system lock 0
If the system lock has been activated, the timer function "Turn on at" cannot be selected.
Temporarilydeactivatelock
While the display shows the message "To deactivate, press OK button for 6 seconds",
Water hardness
You will find the information on water hardness in the "Initial operation" chapter.
Display brightness
Use the arrow keys to adjust the display brightness.
Volume
You can adjust the volume of the buzzer and keypad tones with the arrow keys.
To turn off the sound, ^ Tap the arrow key X until the white
bars are no longer visible and "Turned off" appears on the display.
Activating and deactivating the plumbed water connection
The machine is designed to be used with a permanent supply of fresh tap water. If the plumbed water connection is turned on, the water tank is automatically refilled via the fresh water pipe. If the plumbed water connection is turned off, you will need to fill the water tank by hand.
^
touch the OK button for 6 seconds.
As soon as the coffee machine is turned off, the system is locked again.
42
Settings
Factory default settings
The (Factory default) setting can be used to reset the coffee machine settings to their original default status.
Please refer to the "Possible settings" chart for the default factory settings.
The following settings will not be reset:
- Language
- Time
- Number of beverage portions
- Profiles
Showroom program (demo mode)
Do not activate this setting for domestic use.
The coffee machine can be presented in the showroom or at exhibitions in "Demo mode". In this mode the machine lights up, but no drinks are prepared or actions carried out.
The coffee machine cannot be turned off with the On/Off button K when demo mode is activated.
43
Cleaning and care
Overview
The coffee machine must be cleaned regularly to prevent a build-up of
,
bacteria.
Recommended frequency What needs to be cleaned/maintained?
Daily (at the end of the day)
Once weekly (more often for heavier staining)
Once monthly Lubricate cap on main dispenser connector
When display advises Milk pipework (with milk line cleaner)
When necessary Bean container
Milk container and lid
Water container
Waste unit
Drip tray and no-spill grid
Main dispensers
Main dispenser connection
Clean milk valve with cleaning brush
Interior
Drip catcher on the inside of the unit door
Brewing unit
Front of unit (especially important immediately after descaling)
Brew unit (with cleaning tablets)
Descale unit
Clean clogged milk line with cleaning brush
Some components of the coffee machine are dishwasher safe. However, cleaning these in the dishwasher frequently can cause them to become discolored due to regular contact with food residues (e.g. tomatoes) in the dishwasher, or the surface can become damaged.
The following components should be cleaned only by hand:
Main dispenser cover
Milk container lid
Brewing unit
Bean container and lid
Service cover
44
Cleaning and care
Danger of burns! Let the unit cool down before you clean it, especially the water in the drip tray.
Do NOT use a steam cleaner to clean this unit. Doing so will damage the unit.
Never use cleaning products that contain sand, cleaning soda, acids, or chlorides! They will corrode the surface.
To avoid mold, growth and odors it is important to clean the machine regularly.
The main dispenser connector cap is lubricated with silicone grease. Be careful of your clothing when removing or inserting containers or other components from the inside of the unit.
All surfaces are susceptible to scratching. On glass surfaces, scratches can lead to breakage. All surfaces can become discolored if they are cleaned with unsuitable products.
Make sure to immediately wipe away any splatters during
descaling.
To better maintain your appliance avoid the following:
– cleaners containing soda, ammonia,
thinners, or chlorides
– cleaners containing descaling
agents or lime removers,
– abrasive cleaners,
– stainless steel cleaners,
– caustic (oven) cleaners,
– scouring pads, steel wool, hard
brushes,
eraser sponges,
metal scrapers.
Wipe any spills from descaling im mediately!
-
45
Cleaning and care
Rinsing the system
When a coffee drink has been prepared, the coffee machine also rinses itself before turning off. This removes any remaining coffee residue.
You can also manually rinse the system.
Tap x .
^
Tap the arrow key Y until
^
"Maintenance" is highlighted. Tap the OK button.
Tap the arrow keys until "Rinse the
^
system" is highlighted. Tap the OK button.
The lines will now be rinsed.
Milk pipework
Make sure that the milk lines are cleaned regularly and thoroughly. Milk contains natural bacteria that will grow when the lines are not sufficiently cleaned. Contamination in the unit can be a health risk.
Rinsing the milk lines
Milk residue can clog the milk pipework. If you have prepared a beverage with milk, the coffee machine will automatically rinse the milk lines after a few minutes.
You can also manually rinse the milk lines.
Tip: Place a suitable container under the coffee dispensers.
^ Tap x . ^ Tap the arrow key Y until
"Maintenance" is highlighted. Tap the OK button.
46
^
Tap the arrow keys until "Rinse milk pipework" is highlighted. Tap the OK button.
The milk lines will be rinsed. The water used for the rinsing process will run out of the coffee dispensers.
Cleaning and care
Cleaning the milk pipework using the milk line cleaner
Make sure that the milk lines are cleaned regularly and thoroughly. Milk contains natural bacteria that will grow when the lines are not sufficiently cleaned. Contamination in the unit can be a health risk.
The milk pipework must be cleaned about once a week. The coffee machine will remind you at the correct time. Three days before, the display will show the message "Days until milk pipework cleaning: XX". The remaining number of days until the milk pipework needs to be cleaned will show in the display every time the unit is turned on.
^ Tap the OK button to confirm this
message.
When the number of days left equals 0, the display will show the message "Clean milk pipework". At this time, the function for preparing beverages with milk is blocked.
To clean the milk pipework:
Tap x .
^
Tap the arrow key Y until
^
"Maintenance" is highlighted. Tap the OK button.
Tap the arrow keys until "Clean milk
^
pipework" is highlighted. Tap the OK button.
The process is started and various messages will appear on the display.
Follow the instructions.
^
When the display shows "Fill water tank with cleaning agent and lukewarm water up to the cleaning mark 8 and insert", proceed as follows:
Preparing the cleaning solution
The milk system detergent was developed specifically for this coffee machine. It is available from Miele.
To avoid damage to the unit, use only this detergent.
^
Tap the OK button.
You can only prepare espresso, coffee, lungo coffee and hot water. You can only prepare beverages with milk again once the milk pipework has been cleaned.
The cleaning program cannot be canceled once is has started. The program has to be carried through to the end.
^
Add one sachet of milk system detergent to the water tank.
47
Cleaning and care
Fill the water tank with lukewarm
^
water up to the mark 8 and stir the solution.
Please note the mixing ratio. It is important that you fill the water container with enough water. Otherwise, the cleaning process is incomplete.
^ Reinsert the water tank and close the
unit door.
Milk container with lid
Ensure that the neck and lip of the container are kept clean (both when filling and when moving the container). Otherwise the unit can malfunction.
The milk container (glass) can be
^
cleaned in the dishwasher or by hand using warm water and liquid dish soap. After cleaning, dry the milk container.
The lid of the milk container must be cleaned only by hand.
^ Follow the instructions on the display.
When the display reads, "Rinse out the water container and fill with fresh water",
^
rinse the water container carefully with clean water. Make sure that no detergent residue is left in the water tank. Fill the water tank with clean tap water.
The cleaning process is complete when the display reads, "Program finished".
48
^
Rinse the milk pipework in the lid under running water.
If no water comes out of the pipework a,
^
clean the lid as described in the chapter "Clogged milk pipework – step 1: Cleaning the milk pipework in the milk container lid".
Main dispenser
Clean the stainless steel cover of the main dispenser by hand only, using warm water and some dishwashing liquid. All other components are dishwasher safe.
^ Pull the main dispenser all the way
down a and pull the cover forward to remove b.
Cleaning and care
Release the dispenser by seizing it
^
by the sides of the magnet and pulling it to the front.
^
Push the snap-in clip slightly up a, seize the grip of the dispensing unit and pull it out towards the front b.
^
Turn the top connecting piece a and pull it off to the top. Also pull the bottom connecting piece b off to the top.
^
Pull off the dispensing nozzles c.
Do not remove the Y-piece.
^
Thoroughly clean all components.
49
Cleaning and care
Clean the surface of the main
^
dispenser with a damp sponge cloth.
Milk valve maintenance
You should put the milk valve in maintenance mode once per week to ensure good quality milk froth.
Tap x .
^
Tap the arrow key Y until
^
"Maintenance" is highlighted. Tap the OK button.
Tap the arrow keys until "Condition
^
milk valve" is highlighted. Tap the OK button.
The milk valve will go into maintenance position.
Important! Before you confirm "Leave maintenance position" with "OK", you must remove the cleaning brush. Otherwise, the coffee machine will be damaged.
^
Now reassemble the dispensing unit in reverse order. Make sure that the upper connecting piece a audibly clicks into place. Push firmly when inserting the dispensing nozzles b into the dispensing unit.
^
Reinsert the dispensing unit into the main dispenser.
^
Replace the cover.
50
^
Insert the brush into the milk valve. Move the brush back and forth.
^
Tap the OK button.
The milk valve will move into the stan dard position and the milk lines are rinsed.
-
Cleaning and care
Water tank
Change the water every day to prevent a build-up of bacteria.
Make sure that the valve, the underside of the water tank and the surface the water tank sits on are clean. Otherwise the water tank will not sit correctly.
^ The water tank can be cleaned in the
dishwasher or by hand using warm water and liquid dish soap. After cleaning, dry the water container.
Waste unit
After a certain time, the coffee machine will display a message indicating that the coffee grounds container needs to be emptied. At this point at the latest, the container must be cleaned. However, it is best to clean the waste receptacle daily. Coffee grounds can become moldy. Typically there will also be some water in the waste unit, left over from the brewing and rinsing processes.
Wash the waste unit in the
^
dishwasher, or by hand with warm water and liquid dish soap, then dry.
^ Clean the appliance space under the
unit as well.
^
Carefully clean and dry the surface the water tank sits on, particularly the slots.
51
Cleaning and care
Drip tray
Clean the drip tray daily to prevent odors and mold.
The coffee machine will show a message on the display when the drip tray is full and needs to be emptied. At this point at the latest, the drip tray must be emptied.
Danger of burns! If the coffee machine has just been rinsed, wait a while before removing the drip tray. Rinse water will run out of the coffee dispensers.
Make sure that the metal discs (contacts) on the drip tray are cleaned and dried properly. The discs will only be able to detect that the drip tray is full if they are clean and dry.
Clean the space under the drip tray.
^
Push the drip tray back into the
^
coffee machine.
Make sure the drip tray has been pushed into its niche as far as it will go.
^
Open the appliance door and carefully remove the drip tray from the appliance.
The grid in the drip tray helps keep the water in place while you move the full drip tray.
^
Wash the drip tray and the grid in the dishwasher, or by hand with warm water and liquid dish soap, then dry.
52
Cleaning and care
Drip tray cover
Remove the drip tray cover.
^
The drip tray cover can be cleaned in
^
the dishwasher or by hand using warm water and liquid dish soap.
Dry the drip tray cover thoroughly.
^
^ Replace the cover onto the drip tray.
Make sure that the front of the cover is flush with the drip tray.
Bean container
Pull the bean container out of the unit
^
and pull the lid toward the back and off.
Clean the bean container and its lid
^
by hand using warm water and liquid dish soap. Dry both components.
Slide the lid back on, then slide the
^
bean container back into the unit.
Main dispenser connector
A connecting piece between the brew unit and the main dispenser is located on the inside of the door.
^
Clean this connector on a regular basis with a damp cloth, but take care not to remove the lubricant from the cap.
^
Once a month, lubricate the cap with the supplied silicone grease.
53
Cleaning and care
Interior and unit door
Clean the interior and the unit door
^
with warm water and liquid dish soap once all removable parts have been removed.
Tip: Use a vacuum cleaner to remove dry ground coffee residue.
In the lower part of the inside door there is a drip catcher.
^ Remove this cup and clean it in the
dishwasher or by hand using warm water and liquid dish soap.
Brew unit
Clean the brew unit by hand only using hot water. Do not use soap. The moving parts of the brew unit are lubricated. Detergents will damage the brew unit.
Clean the brew unit once a week.
Removing the brew unit and rinsing it by hand
The brew unit can be removed for cleaning. To do this:
^ Open the unit door. ^ Remove the water tank, the waste
unit, and the ground coffee chute lid.
Remember to reinsert the drip catcher.
54
^
Push on the bottom of the brew unit handle a and turn the handle to the left b.
^
Press the brew unit catch c downward, and carefully pull the brewing unit out.
Cleaning and care
Carefully pull the brew unit out of the
^
coffee machine.
If you cannot remove the brew unit or can only do so with difficulty, the brew unit is not in the correct position (see "Frequently asked questions").
When the brew unit has been pulled out, do not alter the position of the brew unit handle. This would displace the brew unit and it would not fit back into the coffee machine.
^ Clean the brew unit by hand while
running it under hot water.Donot
use soap.
To replace the brew unit, repeat the previous steps in the reverse order:
Push the brew unit back into the
^
coffee machine, making sure it is straight.
^ Push the button on the bottom of the
brew unit handle a and turn the handle to the right b.
^ Close the door.
^
Rub any coffee residue from the filters. One filter is located inside the funnel, the other to the left of the funnel.
^
Dry the funnel to prevent ground coffee sticking to it during the next coffee preparation.
^
Clean the inside of the coffee machine. Use your vacuum cleaner to remove dry coffee grounds.
55
Cleaning and care
Degreasing the brew unit
Depending on the natural oil content of the coffee used, the brew unit can become blocked quite quickly. Use the cleaning tablets supplied to clean the brew unit.
These cleaning tablets have been specially formulated for use in the coffee machine to optimize degreasing. They are available from Miele.
After 200 portions, the display will show the message "Degrease brew unit". This message will be displayed until the brew unit has been degreased.
Degrease the brew unit regularly to ensure you can prepare aromatic coffee beverages and the coffee machine will function properly.
^ Turn on the unit using the On/Off
button K.
^ Tap x . ^
Tap the arrow key Y until "Maintenance" is highlighted. Tap the OK button.
When the display prompts you to "Place a cleaning tablet in the ground coffee chute and close the chute":
^ Remove the ground coffee chute
cover and open the lid.
^ Drop the cleaning tablet into the
chute.
^ Close the lid, put the cover back on,
and close the door.
^ Follow the instructions on the display.
When the display reads, "Program finished",
^
tap the OK button.
The brew unit is now cleaned.
^
Tap the arrow keys until "Degrease brew unit" is highlighted.
The cleaning program cannot be cancelled once is has started. The program has to be carried through to the end.
^
Tap the OK button.
^
Follow the instructions on the display.
56
Exterior
The surfaces can become discolored or otherwise altered if soiling is not cleaned promptly. Remove any soiling immediately.
Make sure no water can penetrate the display!
All external surfaces are susceptible to scratching. On glass surfaces, scratches can lead to breakage. All surfaces can become discolored if they are cleaned with unsuitable products.
Make sure to immediately wipe away any spills during descaling!
^ Turn off the unit using the On/Off
button K.
Cleaning and care
^ Use only a clean, soft sponge with
warm water and liquid dish soap to clean the housing. Dry all parts with a soft cloth.
Tip: You can also clean the exterior using the Miele micro fiber cloth.
57
Descaling
Limescale builds up in the coffee machine during use. The limescale buildup in the machine will depend on the hardness of your local water supply. Limescale must be removed regularly.
The machine will guide you through the descaling process. Various instructions will appear on the display, e.g. you will be prompted to empty the drip tray or fill the water container.
Descaling is required and takes approximately 20 minutes.
During the descaling program, water containing descaling agent will run out of the main dispenser and the hot water spout. This is followed by an activation period before a little more water with descaling agent is dispensed, etc.
The coffee system will remind you on the display when the descaling program needs to be carried out. The display will show "No. of uses until appliance needs descaling: 50". The remaining number of beverages that can be made before descaling will show in the display after each beverage is made.
^
Tap the OK button to confirm this message.
When the number of remaining beverages is 0, the coffee system will lock. The display will read, "Descale the appliance".
Descaling following display reminder
To immediately start the descaling
^
process, tap the OK button.
The descaling program cannot be canceled once it has started. The program must be completed through to the end.
The descaling process is started and various messages will appear in the display.
Follow the instructions.
^
When the display shows "Fill water container with lukewarm water and descaling solution up to the F symbol and insert", proceed as follows:
Preparing the descaling solution
The descaling tablets supplied have been specially formulated for use with this coffee machine. Additional descaling tablets are available from the Mieleusa.com website.
You will need two descaling tablets for the descaling process.
Only use the Miele descaling tablets. Other types of descaling agents can damage the machine and affect the taste.
You can turn the coffee machine off if you do not want to run the descaling program at this time. However, no more beverages can be prepared until the descaling program has been completed.
58
Fill the water tank to the mark with
^
lukewarm water.
Add two descaling tablets to the
^
water.
Please note the mixing ratio for the descaling tablets. It is important that you fill the water container with enough water. Too little water can cause the descaling program to be stopped prematurely.
^ Reinsert the water tank and close the
unit door.
^
Follow the instructions on the display.
When the display shows "Rinse water container and fill with fresh tap water up to the descaling symbol F ", proceed as follows:
^
Rinse the water tank carefully with clean water. Make sure that no descaling agent is left in the water tank. Fill clean tap water up to the mark F. Also empty the waste unit.
Descaling
Tap the OK button.
^
The descaling program is now complete and beverages can be prepared in the machine again.
When descaling the machine, be sure to wipe off any splashes of descaling agent immediately! These could damage the surfaces.
After descaling the machine, carefully clean the water tank and the drip tray to remove all traces of descaling agent.
How to descale before prompted
^ Tap x . ^ Tap the arrow key Y until
"Maintenance" is highlighted. Tap the OK button.
^ Tap the arrow keys until "Descale the
system" is highlighted.
The descaling program cannot be canceled once it has started. The program has to be carried through to the end.
^
Tap the OK button.
The descaling process will start.
The descaling process is complete when the display reads, "Program finished".
59
Frequently asked questions
Repairs to electrical appliances should only be carried out by a suitably
,
qualified person in accordance with local and national safety regulations. Repairs and other work by unqualified persons could be dangerous. The manufacturer cannot be held responsible for unauthorized work.
Display messages
To address the "fault", follow the instructions on the display.
^
If the fault message still appears on the display, contact Miele Technical Ser
^
vice.
Fault Possible cause and solution
-
Fault 1 to 4 80 to 83
Fault 74, 77 Fault 225, 226 Fault 235, 236
An internal fault is present.
^ Turn off the coffee machine using the On/Off button K.
Wait about one hour and then turn the unit back on.
An internal fault is present.
^ Turn off the coffee machine using the On/Off button K.
Wait about 2 minutes and then turn it on again.
60
Frequently asked questions
Fault Possible cause and solution
Fault 73 or "Check the brew
unit"
The brew unit cannot reset to the correct position or it is clogged and the ground coffee cannot be processed.
Check if you can remove the brew unit (see "Cleaning and
^
care – Brew unit").
If you can remove the brew unit, clean it (see "Cleaning
^
and care – Brew unit").
^ Push the coffee ejector of the brew unit into the correct
position (see image).
^ Reinsert the waste unit and the water tank. Do not insert
the brew unit. Close the door and turn on the coffee machine using the On/Off button K .
The brew unit motor will automatically move to the correct position.
^
When the message "Insert the brew unit" is displayed, open the door and reinsert all parts into the unit.
If you cannot remove the brew unit:
^
Turn off the coffee machine using the On/Off button K . Wait about 2 minutes and then turn it on again.
61
Frequently asked questions
Fault Possible cause and solution
"Too much ground coffee"
"Check water intake"
"Push the water container in until it engages"
There is too much ground coffee in the ground coffee chute. If more than one level scoop is put into the ground coffee
chute the brew unit cannot process it. The ground coffee will be directed into the waste container, and a fault will appear in the display.
Turn off the coffee machine using the On/Off button K .
^
Remove the brew unit and clean it (see "Cleaning and care
^
– Brew unit").
Remove the ground coffee from inside the coffee machine,
^
for example by using a vacuum cleaner.
Use the coffee scoop supplied to measure out the ground
^
coffee. Please scoop only one serving of ground coffee into the ground coffee chute.
The plumbed water intake is faulty.
^ Check for kinks in the water intake hose and open the
water supply all the way.
^ Remove the water tank and empty it. ^ Push the water tank back into the unit until it clicks into
place.
The water tank is not sitting properly in the unit.
^
Take the water tank out, then place it back in the unit.
If the water tank was not correctly filled and inserted during descaling, this fault message will appear.
^
Fill it to the descaling mark F and restart the descaling process.
62
If the fault message still appears on the display, contact Miele Technical Service.
Frequently asked questions
Unusual performance of the coffee machine
Problem Possible cause and solution
The light does not illuminate when the coffee machine is turned on.
When the coffee system is turned on using the On/Off button K the display remains dark.
The coffee machine turns off suddenly.
The lighting has been turned off.
Turn on the lighting (see "Settings – Lighting").
^
The lighting is defective.
Contact Miele Technical Service.
^
The On/Off button K was not tapped long enough.
^ Tap the depression in the On/Off button K for at least
3 seconds.
The plug is not properly plugged into the electrical outlet.
^ Insert the plug into the outlet.
The circuit breaker has tripped due to a problem with the coffee machine, the electricity supply or another machine.
^ Remove the coffee machine's plug from the electrical
outlet.
^
Contact a qualified electrician or Miele Technical Service for assistance.
The turn-off time programmed into the timer has been reached.
^
If desired, set a new turn-off time (see "Settings – Timer").
The coffee machine is turned on. The light turns off suddenly.
The plug is not properly plugged into the electrical outlet.
^
Insert the plug into the outlet.
If more than 10 minutes have passed since the coffee machine was last used, the lighting automatically turns off.
63
Frequently asked questions
Problem Possible cause and solution
The touch keys do not respond. The coffee machine can no longer be operated.
The coffee machine does not turn on at the programmed and activated "Turn on at" time.
The display messages are difficult to read.
After the unit has been turned on, the message "Push the water container in until it engages" appears although the tank is full and inserted. The unit does not rinse.
An internal fault has occurred.
Open the unit door.
^
The current process is stopped.
Disconnect the power supply by pulling the coffee
^
machine's power cord from the electrical outlet.
The system lock feature has been activated.
Deactivate the system lock (see "Settings – System lock").
^
No weekdays have been selected.
Check the timer settings and adjust if necessary (see
^
"Settings – Timer").
The coffee system was not used after being turned on three times in a row automatically.
^ Turn the machine on and prepare a beverage.
The contrast or brightness of the display is too low.
^ Adjust these settings (see "Settings – Display brightness").
There is limescale build-up in the coffee machine.
^
Turn off the coffee machine using the On/Off button K . Wait for approx. 1 hour.
^
Turn the machine on again. As soon as "Preheating phase" appears, tap the x key and select "Descale".
^
Descale the coffee machine, repeatedly if necessary.
64
Frequently asked questions
Problem Possible cause and solution
The milk lines are being rinsed but no rinse water comes out of the main dispenser. The display shows the message "Fill and insert water container".
No milk or milk froth is coming out of the main dispenser.
The display shows the message "Fill and insert milk container" although the milk container is full and in place.
"Empty drip tray" appears on the display even though the drip tray is empty.
The milk pipework or the air intake hose is clogged.
Follow the instructions in "Cleaning clogged milk
^
pipework".
The milk pipework or the air intake hose is clogged.
Follow the instructions in chapter "Cleaning clogged milk
^
pipework".
The milk container lid may be contaminated, causing the sensors to malfunction.
^ Thoroughly clean the lid and milk container (see "Cleaning
clogged milk pipework").
The drip tray is not inserted correctly.
^
Slide the drip tray all the way into the unit.
The drip tray's sensors are not working properly.
^
Turn off the coffee machine using the On/Off button K.
The door cannot be closed.
The door cannot be closed.
The metal contacts are dirty.
^
Clean and dry the contacts thoroughly (see "Cleaning and care – Drip tray").
The containers are not fully inserted.
^
Check the containers.
The door hinges are not aligned correctly.
^
Adjust the door hinges (see "Installation – Adjusting the door hinges").
65
Frequently asked questions
Problem Possible cause and solution
The unit suddenly stopped preparing a beverage.
"Please wait" or "Preheating" appears permanently. No beverages can be prepared.
If the water tank is emptied during beverage preparation, the display will show the message "Continue preparation? yes / no" after the water tank has been refilled and inserted. If you do not confirm this message with "yes" within 5 minutes, the machine will stop preparing the beverage.
The plumbed water intake is faulty.
Check for kinks in the water intake hose and open the
^
water supply all the way.
The water tank ran empty during beverage preparation but "plumbed water supply - on" is selected and the coffee machine is not connected to a plumbed water supply.
^ Check the plumbed water supply settings (see "Settings –
Plumbed water supply").
It is possible that "Plumbed water connection - on" is selected and the coffee machine is not connected to a plumbed water supply.
^ Fill the water tank. ^ Then check the plumbed water supply settings (see
"Settings – Plumbed water connection").
66
Frequently asked questions
Unsatisfactory result
Problem Possible cause and remedy
The consistency of the milk froth is unsatisfactory.
The grinding of the coffee beans sounds louder than usual.
Espresso or coffee flows into the cup too quickly.
Espresso or coffee flows into the cup too slowly.
The coffee or espresso is not hot enough.
The milk temperature is too high. Good milk froth is prepared with cold milk (< 55°F/13°C).
Check the milk temperature in the milk container.
^
The milk pipework or the air intake hose is clogged.
Follow the instructions in chapter "Cleaning clogged milk
^
pipework".
The coffee bean container has run empty during the grinding process.
^ Fill the coffee bean container with fresh beans.
There might be pebbles mixed in with the coffee beans.
^ Turn the coffee machine off immediately. Contact Miele
Technical Service.
The grind level is too coarse.
^ Set the grinder control to a finer setting (see "Adjusting the
grinder setting").
The grind level is too fine.
^
Set the grinder control to a coarser setting (see "Adjusting the grinder setting").
The cup has not been pre-heated.
The brewing temperature is set too low.
^
Set a higher brew temperature (see "Brewing temperature").
The brew unit filters are blocked.
^
Remove the brew unit and clean it by hand (see "Brew unit" ).
^
Degrease the brew unit (see "Brew unit").
67
Frequently asked questions
Problem Possible cause and remedy
The crema on the coffee or espresso is not right.
The grind level is too coarse or too fine.
Set the grinder control to a coarser or finer setting (see
^
"Adjusting the grinder setting").
The brewing temperature is too high for the type of coffee being used.
Set a lower brewing temperature (see "Brewing
^
temperature").
The coffee beans are no longer fresh.
Add fresh beans to the coffee bean container.
^
68
Cleaning clogged milk pipework
If the quality of the milk froth is unsatisfactory, the air intake hose may be clogged. Follow the instructions in "Step 2: Clean air intake hose and angled section in the door".
If no milk comes out of the main dispenser, only steam, please follow the instructions in Step 1 through 4.
First check if the milk in the milk container has spoiled. This can clog the milk lines.
To clean the clogged milk lines, take a step-by-step approach. Afterwards, check if the milk and/or milk froth preparation and quality are satisfactory.
If the milk and/or milk froth preparation and quality are still not satisfactory, repeat all the steps described without preparing beverages in between.
Step 1: Cleaning the milk pipework in the milk container lid
^ Pull the milk intake pipe a out of the
milk container lid. Make sure you also remove the gasket b.
^ Clean both under running water.
Insert the supplied cleaning brush into the stainless steel pipe and move it back and forth until all milk residue has been removed.
^
Use the cleaning brush to clean the milk pipework in the lid as well.
69
Cleaning clogged milk pipework
To reassemble the lid:
First insert the gasket in the lid. Then
^
insert the milk intake pipe into the gasket. Make sure not to slide the beveled end of the milk intake hose into the gasket.
Step 2: Cleaning the air intake hose and angle section in the door
Do not use a needle or similar sharp item. These can cause damage to the parts.
^ Pull the main dispenser all the way
down.
First detach the air intake hose a
^
from the opening c. Then pull off the angled section b.
^ Pull both hoses out of the angled
section.
^ Clean the air intake hose a using the
cleaning brush supplied. "Blowing through" can also shake loose clogged residue.
^
Open the service cover on the back of the door.
70
^ Clean the opening for the air intake
hose c in the door.
^ Clean the angle section b under
running water. If necessary, replace it with the supplied spare part.
^
Insert the brush into the milk hose d. Move the brush back and forth until all milk residue has been removed.
Cleaning clogged milk pipework
Slide the hoses back onto the angle
^
section and reinsert it. Make sure that the bridge on the angled section faces down.
^ Reinsert the air intake hose into the
opening c.
Step 3: Cleaning the milk pipework in the main dispenser
Step 4: Milk valve maintenance
Tap x .
^
Tap the arrow key Y until
^
"Maintenance" is highlighted. Tap the OK button.
Tap the arrow keys until "Condition
^
milk valve" is highlighted. Tap the OK button.
The milk valve will go into maintenance position.
Important! Before you confirm "Leave maintenance position" with "OK", you must remove the cleaning brush. Otherwise, the coffee machine will be damaged.
^ Remove and disassemble the
dispensing unit as described in "Cleaning and care – Main dispenser".
^
Rinse all parts carefully under running water.
Use the cleaning brush to clean all parts carefully. Do not use a needle or similar object to avoid piercing the silicone parts.
^
Reassemble the dispensing unit and reinsert it into the main dispenser.
^
Replace the cover.
^
Insert the brush into the milk valve. Move the brush back and forth.
^
Tap the OK button.
The milk valve will move into the stan dard position and the milk lines are rinsed.
-
71
After sales service
In the event of a fault which you cannot easily fix yourself, please contact the Miele Technical Service Department at the contact information on the back of this booklet.
When contacting the Technical Service Department, please quote the model and serial number of your appliance given on the data plate inside the appliance.
MieleCare
(USA only)
MieleCare, our Extended Service Contract program, gives you the assurance of knowing that your appliance investment is covered by 5 years of worry free ownership. MieleCare is the only Extended Service Contract in the industry that guarantees repairs by a Miele Authorized Service Provider using genuine Miele parts. Only genuine Miele parts installed by factory trained professionals can guarantee the safety, reliability, and longevity of your Miele appliance.
Please note that unless expressly approved in writing by Miele’s Service department, Extended Service Contracts offered by other providers for Miele products will not be recognized by Miele. Our goal is to prevent unauthorized (and untrained) service personnel from working on your Miele products, possibly doing further damage to them, you and/or your home.
72
To learn more about MieleCare Extended Service Contracts, please contact your appliance dealer or visit us online at:
http://mieleusa.com/mielecare
Installation instructions
Information is subject to change. Please refer to our website to obtain the most current product specification, technical & warranty information.
The installation steps are described in the enclosed "Installation Diagram".
Leave these instructions with the appliance for the consumer/user.
Information is subject to change. Please refer to our website to obtain the most current product specification, technical & warranty information.
Caring for the environment
Disposal of packing material
The cardboard box and packing materials protect the appliance during shipping. They have been designed to be biodegradable and recyclable. Please recycle.
Ensure that any plastic wrappings, bags, etc. are disposed of safely and kept out of the reach of children. Danger of suffocation!
Disposal of an old appliance
Old appliances may contain materials that can be recycled. Please contact your local recycling authority about the possibility of recycling these materials.
Ensure that the appliance presents no danger to children while being stored for disposal. Before discarding an old appliance, unplug it from the outlet, cut off its power cord and remove any doors to prevent hazards.
74
The machine must be connected to the water supply in accordance with local and national regulations.
Disconnect the machine from the electrical supply before connecting it to the water supply.
Turn off the water supply before connecting the coffee machine to the plumbing.
All units and systems used to deliver
the water to the coffee system must conform with the requirements of the respective country.
– Only connect the machine to the
cold water supply.
– The machine can be connected
without a non-return valve.
Plumbing
To ensure the best coffee quality, the
maximum length of the tubing or copper pipe should not exceed 4 ft. 11" (1.5 m). If too much water remains in the tubing the coffee quality could be affected.
Make sure that the shut-off valve is accessible after the unit has been installed.
Parts must only be replaced with original Miele spare parts, available from Miele.
– The on-site water line must have a
water shut-off valve to turn the water off if needed. If not present, have a water valve installed by a licensed plumber.
The water faucet must be accessible after installation.
Water pressure on-site: Minimum: 14.5 psi Maximum: 145 psi, if higher, install a pressure reduction valve.
Suitable 1/4" tubing or copper piping must be supplied for plumbing.
75
Plumbing
Installing the stainless steel tubing in the unit
^ Remove the water connection cover
at the lower rear side of the coffee machine.
^ Take the angled side of the stainless
steel tube and check whether the sealing ring is in place. If necessary, insert it.
^ Place the union nut of the stainless
steel tube onto the screw thread.
^ Make sure the fittings are tight.
Connection to the water supply
Disconnect the machine from the electrical supply before connecting it to the water supply.
^ Remove the water connection cover
at the lower rear side of the coffee machine.
^ Check whether the sealing ring is in
place. If necessary, insert it.
^ Screw the supplied brass
compression fitting, with the ¾" end, tightly onto the water connector of the coffee machine. (Tighten the compression fitting by hand, do not use a tool.) The fitting includes an opening for standard ¼" piping.
76
^ Connect the compression fitting to
the water supply.
^ Slowly open the shut-off valve to the
water supply and check for leaks. If necessary, check whether the sealing ring and fittings are tight.
You can now continue with the installation of the unit (see "Installation").
Lead free certificate
This product is tested and certified by the WQA against ORD0902 for California "lead free" compliance.
Miele & Cie KG Carl-Miele-Straße 29 D-3332 Gütersloh
77
Electrical connection
Make sure that the power to the machine is OFF before installing or performing maintenance or repairs.
All electrical work should be performed by a qualified electrician in strict accordance with national and local safety regulations. Installation, repairs and other work by unqualified persons could be dangerous.
Verify that the voltage, load and circuit rating information found on the data plate match the household electrical supply before installing the coffee system.
Do not connect the appliance to a power inverter or directly to power produced outside of the normal electrical grid (i.e. direct solar or wind power source).
WARNING: THIS APPLIANCE MUST BE GROUNDED
Important
The coffee system comes equipped witha6ft(1.8 m) power cord with a NEMA 5-15P molded plug for connection to a 120 V, 15 A, 60 Hz power supply.
Direct connection to such power sources can cause power surges and tripped breakers when the appliance is turned on, and could damage the appliance.
Do not connect the appliance to energy saving plugs or outlets. The reduction of power to the appliance caused by these devices will cause the appliance to run hot and may damage it and/or shorten its usable life.
If there is any question concerning the electrical connection of this appliance to your power supply, please consult a licensed electrician or contact Miele’s Technical Service Department. See back page for contact information.
78
Installation and combination options
The unit is designed to be built into cabinetry.
Installation
79
Installation
A combination with other built-in Miele appliances is possible. For combination installations, it is very important to install the unit with a protective base between the appliance and the unit (exception: installation with a built-in plate warmer).
80
Ventilation
When installing the coffee machine, make sure that the back of the unit is sufficiently ventilated so that steam and hot air can freely escape.
The ventilation openings in the surrounding cabinets and the space below the ceiling must be at least 78 3/4"² (200 cm²).
Installation
Otherwise condensation can form, causing damage to the coffee machine or the surrounding cabinets.
Installation
Make sure that power is not supplied to the appliance during installation or removal of the unit.
When built into cabinetry, only use the coffee machine in ambient temperatures between +50°F/10°C and +100°F/38 °C.
You will need two Allen wrenches size 3 and 5 for the installation.
To align the unit door flush with the kitchen cabinetry, there must be a sealing strip around the installation recess; otherwise, a sealing strip must be put in place around the unit.
If there is no sealing strip around the
^
installation recess, stick the Miele sealing strip onto the unit from the back before putting it into the recess. The sealing strip is available from Miele.
81
Installation
Tip: A place to set down the coffee
machine at the level of the installation recess is helpful. This makes it easier for you to install the unit's electrical and water connections.
^ Unscrew the four feet on the
underside of the unit by about 1/16" (2 mm) using the larger Allen wrench.
The feet can be unscrewed by up to 3/8" (10 mm).
^ Connect the unit to the water supply
(see "Plumbing").
The coffee machine is delivered with four M5 Allen head screws that you can use to align and fasten the unit in the installation recess.
Open the door and partially tighten
^
the screws.
^ Align the unit by carefully adjusting
the lower Allen head screws until the unit is centered in the installation recess.
^ To secure the unit in the cabinet,
tighten the upper Allen head screws by hand.
^
Connect the unit to the electrical supply.
^
Insert the coffee machine all the way into the installation recess.
When inserting the unit into the recess, make sure the electrical and water supply connections are not damaged.
^
Check if the coffee machine is centered and straight in the installation recess. If not, align the unit using the four feet.
82
Adjusting the door hinges
If the door cannot be opened or closed easily after installation, you will have to align the door (TX 20):
^ To adjust the door flush with the front
of the cabinet, turn the screw a.
^ To adjust the door horizontally and
vertically, turn the screw b.
Installation
8384858687
Please have the model and serial number
T
of your appliance available before contacting Technical Service.
U.S.A.
Miele, Inc.
National Headquarters
9 Independence Way Princeton, NJ 08540 Phone:
Fax: www.mieleusa.com
Technical Service & Support Nationwide
Phone: Fax:
800-843-7231 609-419-9898 609-419-4298
800-999-1360 888-586-8056
echnicalService@mieleusa.com
Canada
Importer Miele Limited
Headquarters and Miele Centre
161 Four Valley Drive Vaughan, ON L4K 4V8 www.miele.ca
Customer Care Centre
Phone:
customercare@miele.ca
Germany Manufacturer
Miele & Cie. KG Carl-Miele-Straße 29 33332 Gütersloh
800-565-6435 905-532-2272
CVA 6405
M.-Nr. 09 741 560 / 02en - US, CA
Loading...
