Medion MD 41549 user Manual

Food-processor_MD41549_EN-Delta.FH11 Fri May 07 13:51:43 2004 Seite 1

C M Y CM MY CY CMY K

FOOD PROCESSOR

MD 41549

08/04

®

Medion Electronics Ltd.

120 Faraday Park  Faraday Road

Dorcan  Swindon SN3 5JF  Wiltshire

Hot-Line 0870 7270370

++ 44 (0) 1793 715 699 (EIRE)

Fax [phone]

E-Mail: [e-mail]

www.medion.com

INSTRUCTION MANUAL

Food-processor_MD41549_EN-Delta.FH11 Fri May 07 13:51:43 2004 Seite 2

- 2 -

Supplied accessories Pages 4-5

Installation and connection Page 6

Before first use Page 6

The processing blade Page 6

The dough blade Page 7

The slicing/shredding discs Page 8

The blender Page 9

Application examples Page 10

Cleaning and maintenance Page 11

Specifications Page 11

Safety instructions Page 3

Table of contents

C M Y CM MY CY CMY K

Use the supplied pusher only to push food for cutting through the filling tube in the lid; never use your

fingers or any other items!

Use this machine for processing food in household quantities only.

NEVER process boiling food!

In order to prevent any risks, use the unit for the specified functions only.

AMBIENT CONDITIONS

Protect the unit against humidity.

Make sure that no foreign bodies or fluids get into the unit.

Do not expose the unit to dripping water or splash water.

Place the unit on a level dry worktop.

Avoid any external heat influence for example due to heaters, gas or electric cookers.

CLEANING AND MAINTENANCE

Never immerse the unit in water or other liquids.

Use only a slightly moistened cloth to clean the housing.

Use warm water only, with trade standard washing-up liquid, for cleaning the accessories.

AC POWER SUPPLY

Connect the mains cable always to a mains socket 230V ~ 50Hz which is easily accessible.

Do not use the unit with an extension cable.

MALFUNCTIONS

In case the power supply cord or the unit is damaged, disconnect the AC mains plug immediately.

If the mains connection line of this unit becomes damaged, then it must be replaced by the manufacturer

or another suitable service in order to avoid risks.

Under no circumstances should you attempt to open and/or repair this unit on your own. Refer all

servicing to our Service Centre in Mülheim or another qualified service shop.

Open the mixing bowl or the blender only after the motor has come to a complete standstill.

SAFETY INSTRUCTIONS!

GENERAL

Please read these safety instructions carefully before putting the unit into operation.

Always keep these operating instructions near at hand.

When handing over the unit to other persons, these operating instructions must also be handed over

at the same time.

Heed all warnings labelled onto the unit and specified in the operating manual.

Under no circumstances should you allow children unattended use of electrical units.

Always disconnect the mains plug, if you do not intend to use the unit and/or fit or remove

its accessories.

The unit is equipped with safety switches which only allow the unit to be switched on if the work bowl

with lid and the blender or the protective cover have been correctly fitted and snapped into place

(please note the markings).

The processing blade is very sharp. Please use only the grip to hold the blade (risk of injury).

Use the protective cover for storage outside the unit.

Never use the mixer and the work bowl at the same time.

Avoid any contact with moving parts!

Food-processor_MD41549_EN-Delta.FH11 Fri May 07 13:51:43 2004 Seite 3

- 3 -

C M Y CM MY CY CMY K

Cover for

processing

blades

Processing blade for stirring,

kneading, and chopping

Disc holder for slicing/shredding discs

Blender

For crushing, puréeing, and mixing

Food-processor_MD41549_EN-Delta.FH11 Fri May 07 13:51:43 2004 Seite 4

Supplied accessories

- 4 -

motor aperture

Lid for

Dough blade for

stirring and mixing

Spatula

Pusher

C M Y CM MY CY CMY K

Measuring jug
