Marantz PM-5003 Service Manual

Service

PM5003

PHONES

MIN

MAX

LOUDNESS

VOLUME

MUTE1AUX/DVD 2

RECORDER

CDPHONO TUNER

INPUT SELECTOR

INTEGRATED AMPLIFIER PM5003

L R

BASS

POWER ON/OFF

TREBLE BALANCE

STANDBY

B

SOURCE DIRECT

A

SPEAKERS

PM5003 /

/F B/N1B/U1B

F N/N1SG

Manual

SECTION PAGE

1. TECHNICAL SPECIFICATIONS ........................................................................................... 1

2. IDLING CURRENT ALIGNMENT .......................................................................................... 2

3. SERVICE MODE ................................................................................................................... 3

4. WIRING DIAGRAM ............................................................................................................... 5

5. BLOCK DIAGRAM ................................................................................................................ 7

6. SCHEMATIC DIAGRAM ........................................................................................................ 9

7. PARTS LOCATION .............................................................................................................. 13

8. EXPLODED VIEW AND PARTS LIST ................................................................................. 23

9. MICROPROCESSOR AND IC DATA ................................................................................... 28

10. ELECTRICAL PARTS LIST ................................................................................................. 30

11. ABOUT REPLACE THE MICROPROCESSOR WITH A NEW ONE ...............................49

Integrated Ampliﬁer

TABLE OF CONTENTS

Please use this service manual with referring to the user guide ( D.F.U. ) without fail.

PM5003

Part no. 90M01DW855010

First Issue 2008.07

MZ

MARANTZ DESIGN AND SERVICE

USA

MARANTZ AMERICA, INC

100 CORPORATE DRIVE MAHWAH, NEW JERSEY 07430 USA

EUROPE / TRADING

D&M EUROPE B. V.

P. O. BOX 8744, BUILDING SILVERPOINT BEEMDSTRAAT 11, 5653 MA EINDHOVEN THE NETHERLANDS PHONE : +31 - 40 - 2507844 FAX : +31 - 40 - 2507860

KOREA

D&M SALES AND MARKETING KOREA LTD.

CHUNG JIN B/D., #1001, 53-5, WONHYORO 3 GA, YONGSAN-GU, SEOUL, 140-719, KOREA PHONE : +82 - 2 - 323 - 2155 FAX : +82 - 2 - 323 - 2154

CANADA

D&M Canada Inc.

5-505 APPLE CREEK BLVD. MARKHAM, ONTARIO L3R 5B1 CANADA PHONE : 905 - 415 - 9292 FAX : 905 - 475 - 4159

JAPAN

D&M BUILDING, 2-1 NISSHIN-CHO, KAWASAKI-KU, KAWASAKI-SHI, KANAGAWA, 210-8569 JAPAN

D&M Holdings Inc.

CHINA

D&M SALES AND MARKETING SHANGHAI LTD.

ROOM.808 SHANGHAI AIRPORT CITY TERMINAL NO.1600 NANJING (WEST) ROAD, SHANGHAI, CHINA. 200040 TEL : 021 - 6248 - 5151 FAX : 021 - 6248 - 4434

Using superior design and selected high grade components,

Only original

MARANTZ

parts can insure that your

MARANTZ

product will continue to perform to the speciﬁcations for which

company has created the ultimate in stereo sound.

it is famous. Parts for your

MARANTZ

ORDERING PARTS :

equipment are generally available to our National Marantz Subsidiary or Agent.

Parts can be ordered either by mail or by Fax.. In both cases, the correct part number has to be speciﬁed. The following information must be supplied to eliminate delays in processing your order :

1. Complete address

2. Complete part numbers and quantities required

3. Description of parts

4. Model number for which part is required

5. Way of shipment

6. Signature : any order form or Fax. must be signed, otherwise such part order will be considered as null and void.

NOTE ON SAFETY :

Symbol Fire or electrical shock hazard. Only original parts should be used to replaced any part marked with symbol . Any other component substitution (other than original type), may increase risk of ﬁre or electrical shock hazard.

安全上の注意：

がついている部品は、安全上重要な部品です。必ず指定されている部品番号のものを使用して下さい。

SHOCK, FIRE HAZARD SERVICE TEST :

CAUTION : After servicing this appliance and prior to returning to customer, measure the resistance between either primary AC

cord connector pins ( with unit NOT connected to AC mains and its Power switch ON ), and the face or Front Panel of product and controls and chassis bottom. Any resistance measurement less than 1 Megohms should cause unit to be repaired or corrected before AC power is applied, and veriﬁed before it is return to the user/customer. Ref. UL Standard No. 60065.

In case of difﬁculties, do not hesitate to contact the Technical

Department at above mentioned address.

080702MZ

1. TECHNICAL SPECIFICATIONS

BASIC

CONNECTIONS

BASIC

OPERATION

ADVANCED

CONNECTION

REMOTE CONTROLLER

OPERATION

TROUBLESHOOTING

NAMES AND

FUNCTIONS

ENGLISH

PHONES

MIN

MAX

LOUDNESS

VOLUME

MUTE1AUX/DVD 2

RECORDER

CDPHONO TUNER

INPUT SELECTOR

INTEGRATED AMPLIFIER PM5003

L R

BASS

POWER ON/OFF

TREBLE BALANCE

STANDBY

B

SOURCE DIRECT

A

SPEAKERS

440

104.5

90.5

14

16

369.5

25

328.5

RMS Power output (40 Hz – 20 kHz simultaneous drive of both channels) 8 Ω load 6 Ω load [F] 4 Ω load

..............................................................40 W x 2

.........................................................47 W x 2

..............................................................55 W x 2

DIN Power output (40 Hz – 20 kHz simultaneous drive of both channels) 8 Ω load 4 Ω load

..............................................................45 W x 2

..............................................................60 W x 2

IHF Dynamic Power (1 kHz simultaneous drive of both channels) 8Ω load 6 Ω load [F] 4Ω load

...............................................................55 W x 2

.........................................................67 W x 2

...............................................................80 W x 2

Total harmonic distortion (40 Hz – 20 kHz simultaneous drive of both channels, 8 Ω load)

.........................................................................0.01 %

Output band width (8 Ω load, 0.06 %)

........................................................... 10 Hz – 30 kHz

Frequency response (CD, 1 W, 8 Ω load)

10 Hz – 50 kHz ........................................ +0 dB, -1 dB

Dumping factor (8 Ω load, 40 Hz – 20 kHz)

......................100

Input sensitivity/Input impedance PHONO (MM)

.............................................2.2 mV/47 kΩ

CD, LINE, TUNER, AUX/DVD, RECORDER

.............................................................200 mV/20 kΩ

Maximum allowable PHONO input level (1 kHz) MM

....................................................................... 110 mV

RIAA deviation (40 Hz – 20 kHz)

......................... ±0.5 dB

S/N (IHF-A, 1 W, 8 Ω load) PHONO (MM) : 5 mV input

..................................... 83 dB

CD, LINE, TUNER, AUX/DVD, RECORDER :

500 mV input ................................................... 100 dB

Tone control Bass (100 Hz) Treble (10 kHz)

....................................................... ±10 dB

...................................................... ±10 dB

Power requirement

[F] .....................................................AC 100 V, 50/60 Hz

[N] .....................................................AC 230 V, 50/60 Hz

[U] ..........................................................AC 120 V, 60 Hz

Power consumption EN60065/J60065 4Ω, 55W x 2 output Standby power consumption [F]

....................................................110 W

.................................................250 W

....................................0.4 W

Accessories

Remote controller (RC003PM)........................................1

AAA batteries Detachable AC power cable

..................................................................2

............................................1

Maximum outer dimensions (Amplifier) Width Height Depth Weight (Amplifier)

....................................................................440 mm

..............................................................104.5 mm

................................................................369.5 mm

...................................................6.7 kg

DIMENSIONS (unit : mm)

1

2

2. IDLING CURRENT ALIGNMENT

DC METER

ADJUST DRIVER

VR32

CN38

VR31

CN37

2. アイドリング電流調整

Adjust the Idling Current with the variable resistor VR31 and

VR32 on the PWB.

CONTROLS SETTING :

TONE (BASS & TREBLE) : MID POSITION

BALANCE : MID POSITION

VOLUME : MINIMUM POSITION

LOUDNESS : OFF POSITION

SOURCE DIRECT : OFF POSITION

Adjustment

VR

Measurement Point

VR31 CN37 5 mV ± 0.5 mV

VR32 CN38 5 mV ± 0.5 mV

基板上(下図)の半固定抵抗VR31とVR32でアイドリング電流を調整します

セッティング

TONE (BASS & TREBLE) :

:

中間位置

BALANCE : 中間位置 VOLUME : MIN位置

LOUDNESS : OFF

位置

SOURCE DIRECT : OFF位置

Measurement

Voltage

INPUT & AMPLIFIER PWB

3

3. SERVICE MODE

MUTE1AUX/DVD 2

RECORDER

CDPHONO TUNER

3. SERVICE MODE

Microprocessor (IC61) version check

Operate by using the supplied Remote controller

(RC003PM).

Press the 1. POWER button to turn on the unit.

Press 2. TAPE (RECORDER 2) button and press 5, 0, 0, 3

button on the remote controller.

(Please each button within 5 seconds)

The firmware version is displayed on the front LED.3.

(Display time is only for 3 seconds.)

Version : 16 8 4 2 1

The firmware version is displayed in the lighting position of

LED.

Ex. :

Light up RECORDER-2 [1 ], Version : 1

Light up RECORDER-2 [1 ] and AUX/DVD [4 ], Version : 5

Light up RECORDER-2 [1 ] and CD [8 ], Version : 9

Each LED light up then all LED light up.4.

Turn off the power to quit Service Mode. 5.

(The unit to the default status)

Microprocessor (IC61) VERSION 確認

操作は付属リモコン

(RC003PM)を使用します。

POWER1. ボタンを押し、本体の電源をいれます。

リモコンの

2. TAPE (RECORDER 2), 5, 0, 0, 3 ボタンを順に

押します。

(各ボタンは5秒以内に押してください)

FIRMWARE

(

表示は3秒間のみです)

LED

が点灯している箇所がバージョン表示です。

表示例：

点灯RECORDER 2 [ 点灯RECORDER 2 [ 点灯RECORDER 2 [1 ] and CD [

フロントパネルのLEDが順次点灯し、その後全点灯しま4. す。電源を切ると

(

本機は、各種設定された内容が初期化され、工場出荷時の

状態に戻ります

のバージョンがLEDにて表示されます。3.

1

], Version：1

1

] and AUX/DVD [4 ], Version：

8

], Version：

5

9

SERVICEモードが解除されます。 5.

)

Personal notes:

4

CN92(4P,2.5

CN95(11P,2.0

CN90,3P,3.96

CN33,4P,2.5

CN12(4P,2.5

CN55,2P,2.5

CN35,2P,2.0

CUP12099Z

CN96,3P,3.96

(BLACK)

TW91,2P,3.96

CN93,7P,2.0

CUP12100Z-2

CUP12100Z-7

TRANS

BN90,3P,3.96

BN92,4P,2.5

JW93

BN96,3P,3.96

CUP12100Z-4

CUP12100Z-5

CUP12100Z-6

BN55,2P,2.0

BN12,4P,2.0

CN56,4P,2.0

CB52,7PIN HEAD

BN33,4P,2.5

BN52,7PIN HEAD

BN56,4P,2.0BN35,2P,2.0

BN95,11P,2.0

BN51,UPDATE

BN93,7P,2.0

CUP12100Z-3

CUP12100Z-1

BN12

BN33

BN35

BN55

BN56

BN90

BN92

BN93

BN95

BN96

JW94

JW95

JW94

JW96

CWZPM48BN33

CWZPM5003BN33

CWZPM5003BN96

CWB2B902550EN

CWB2C902450BM

CWB2B904230EN

CWZPM5003BN90

CWZPM4001BN92

CWB2B07150EN

CWB2B911320EN

CWEE212140VV

CWEE202140VV

JW95

(RED/BLUE)

CN97,2P,2.0

BN97,2P,2.0

TRANSF.1 PWB

U-PRO & TONE PWB

POWER SW

PWB

HEADPHONE

PWB

MASTER VOLUME PWB

SUB TRANSF. PWB

INPUT & AMPLIFIER PWB

4. WIRING DIAGRAM

5 6

+15V

-15V

+

-

+

5.6V

F MUTE

-

+

-

+

-

RIAA

-

+

-VCC

+VCC

SELECTOR

DETECT

+

-

CD

L-CH

SPK SYSTEM 1

ST 5.6V

RY91

TRS1

AC 230V 50 Hz

PHONO

TONE

AMP

R-CH

SHORT

DC

PROTECT

RY32

SP CONTROL

Q393 - 394

IN

OUT

REMOTE

TONE

D911,D912,

RY33

TUNER

AUX/DVD

IC11

HEADPHONE

Q385 - 386

SP CONTROL

7915

7815

7805

IC52

SOURCE DIRECT

IC53

LOUDNESS SELECTOR

IC23

EQ AMP

FUNCTION,LED

1.SPK 1

IR ,EYE

CONTROL IN/OUT

U-COM

MOTOR DRIVE

BALANCE VOLUME

SUB TRANS

POWER TRANS

TRS2

AC 100V 50-60 Hz

F902

F901

T1.6A L 250V

T2.5A L 250V

MOMS SW

SPK SYSTEM 2

SPK RELAY

M

INPUT

SELECTOR

IC23

Rch

Lch

LOUDNESS

Rch

HVILC78212 x 1

IN

OUT

RECORDER 1

RECORDER 2

OUT

IN

TONE DEFEAT

TONE

ON

OFF

MASTER VOLUME

R CH

L CH

U-COM POWER SUPPLY

MAIN AMP

POWER

SUPPLY

VR55-1

VR55-2

VR54-1

VR54-2

TREBLE

BASE

TREBLE

BASE

IC61

RY92 AC RELAY

D901 BU804F

D913,D913

1N4003

MAIN AMPLIFIER

(JAPAN/USA VERSION ONLY)

(CVITMP86FH12MG)

T3.15A L 250V

1N4003: PM5003

: PM5003/N1B,N1SG : PM5003 /U1B,F1 B,F1 N

RT01

RECEPTACLE

(CLT5R028XW)

CONTROL

SOURCE DIRECT

IC62

(CVI74HC4094)

PROTECT

TEMPERATURE

DC OFF SET

100C HEAT

DC BALANCE DETECT

IC22

Lch

REC,IN

AMP

R CH

L CH

PRE AMPLIFIER

+15

-15

+35-35

100C TEMPERATURE

PROTECT

D932,D933

D930,D931

FLASHER IN

FUNCTION,LED

(PHONO,CD,TUNER,

AUX/DVD,RECORDER1,

RECORDER2)

2.SPK 2

3.LOUDNESS ON/OFF

4.SOURCE DIRECT

KEY IN

IC41,IC42

(CLT5I009Z)

F903

F902,F903

OL92

AC 120V 60 Hz

PROTECT

Q686 Q691

RY31

SPK RELAY

V53

0

NC

0

VR51

321

IC94

321

IC93

321

IC95

Q924

Q922

Q923

Q282

Q281

7286

4 351

RY51

7268

43

5

1

RY11

C102M

Q385

C2785Y

Q917

Q920

Q919

Q918

JK01

D102

D101

321

VccGNDROUT

IC12

RPM6936

Q101

A102M

12

34

VINVOUT

GND

VDIS

IC96

-15V

+15V

+5V

5. BLOCK DIAGRAM

87

-15V

+15V

LGND

RGND

LGND

RGND

-15V

+15V

RGND

LGND

LGNDRGND

LGND

RGND

LGND

RGND

-15V

+15V

LGND

RGND

LGND

RGND

-15V

+15V

RGND

LGND

RGND

DNGRDNGR

LGND

RGND

RGND RGND

LGND LGND

LGND

RGND

LGNDRGND

DNGRDNGLDNGRDNGLDNGRDNGLDNGRDNGL

DNGRDNGLDNGRDNGL

RGND LGND

LGND

RGND

LGND

!

PHONO-L

CD-L

TUNER-L

R-OUT

REC IN-L

AUX-R

L-OUT

L CH

R CH

MAIN-POWER

AC280V

AC28V

AC16V

-15V

PHONO-R

CD-R

TUNER-R

AUX-L

L-OUT

R-OUT

FUNCTION-MOTOR

R-OUT

L-OUT

REC1-L

REC2-L

REC1-LOUT

REC1-R

REC2-R

REC IN-R

VEEVDD

CE

VSS

DATA

CLK

+15V

REC2-LOUT

REC1-ROUT

REC2-ROUT

MAIN-FRONT

SET

RES

0V

0.1

220

1M

150P

0.022

150P

1M

220

1M

150P

0.022

150P

1M

220

1M

150P

0.022

150P

1M

220

1M

150P

0.022

150P

1M

220

1M

150P

0.022

150P

1M

220

10

1M

150P

0.022

150P

1M

10

1M

150P

0.022

150P

1M

10

1K

10/50V

NC

10

0.047(M)

0

10

1K

1.5K

10(1/4W)

C2785Y

10/50V

47K

1W 0.47

1N4003

NCNC

2200/25V

22K

47/25V

2

4

3

1

BU804F

4.7K

NC

NCNC

22K

C2316Y

1.2K 22K

13V

3.3/50V

47K

4.7K

47/25V

120

A107M

6.8K

33K

10K

C3198

22K

22/25V

47/25V

0.047

6.2V

1K

10K

0.022

22K

C2785Y

A1175Y

18k

33k47k

10K

47k

82

C2785Y

82

47k

10K

0.01uF0.01uF

0.01uF

10K

A1175Y

C2785Y

10K33k

82

33k

0.01

470

C2874B

47K

10K

NC

0.022

1M

330

100/25V

33K

6800U/50V6800U/50V

INOUT

GND

3

1

GND

OUTIN

3

2

1

2

4

6

8

1

3

5

7

9

CJJ4P058Z

2

4

6

8

1

3

5

7

9

CJJ4P058Z

2

4

6

8

1

3

5

7

9

CJJ4P058Z

+

-

+

-

+

-

1

2

3

4

5

6

7

8

9

10

2SC4467

0.22(3W)

0.01uF

C4883A

2SA1694

A1859A

220(1/4W)

10(1/4W)

47/25V

C3419Y

4.7K

A1024Y

C3206Y

150(1/4W)

33K

A1175Y

22K

6.8K

0.47/50V

22K

C3200GR

33K

15K

A1268GR

470(1/4W)

15K

470(1/4W)

100

100/25V

2222

100/25V

100

470(1/4W)

15K

470(1/4W)

A1268GR

15K

33K

C3200GR

150(1/4W)

1M

150(1/4W)

C3206Y

A1024Y

4.7K

C3419Y

47/25V

10(1/4W)

220(1/4W)

A1859A

2SA1694

C4883A

2SC4467

47K

10(1/4W)

22K

0.01uF

C2785Y

1.5K

1K

330P

1k

1 1

GND

OUTIN

321

MC7805C

2 21 1

220/50V

470P(M)

1M

470P(M)

680 680

1 2

3

4

5

CJJ4N034Z

1

2

3

4

5

CJJ4N034Z

1

LAND1LAND

330

10/50

56K

47K

220

A1024Y

C3206Y

47(1/4W)

100(1/4W)

47(1/4W)

1k

C3206Y

A1024Y

100(1/4W)

NC

320mH

100

220/25V

100

330(1W)

22

0.022(M)

1

LAND

1

LAND

1110987654321

2200/25V

654 2

3 1

654 2

3 1

0.1

470(1/2W)470(1/2W)470(1/2W)

3.3K(2W)

22

100

100/25V

16V

15K

C3198YT

4.7K

10K 15K

21

321

100K

10/50

100

100K

220/16V

100

220/25V

82K

0.039u 0.01uF

1000P

6.8K

22/16V

330

100K

2200P

100K

330

22/16V

6.8K

1000P

0.01uF

0.039u

82K

100

220/16V

100K

100

10/50

100K

220/25V

22

100

220P

8765

NJM2068M

P022P022

10/50

8765

NJM2068M

10/50

330

10/50

56K56K

47K

100

220/25V

100

271

8

34

65

CSL4A016ZU

A1268GR

C3200GR

A1268GR

C3200GR

A1268GR

C3200GR

A1268GR

22

A1268GR

0

123456789101112131415

16 17 18 19 20 21 22 23 24 25 26 27 28 29 30

LC78212

10K

1SS133M

4.7/50V

0.022

120

0.022

120

1N40031N4003

8765

NJM2068M

8765

NJM2068M

4321

NJM2068M

1000P

C3198YT

A1267Y

10K

1000P

10K

47/50V

33K

15K15K15K15K

22K

21

180

1K

10P

470P

220/25V

1 SP

2SP

1234

5678

1234

123

1234

1234 1234

0.22(3W)

OVER CURRENT

DC OFFSET

R CH

L CH

R CH

!

-6

IMPROVEMENT OF PERFORMANCE

uF = 10 uF

** THE UNIT OF CAPACITANCE IS MICROFARAD (uF)

USE ONLY MANUFACTURER'S SPECIFIED PARTS.

IMPORTANT FOR SAFETY.WHEN REPLACING ANY OF THESE COMPONENTS

** THIS SCHEMATIC DIAGRAM MAY MODIFIED AT ANY TIME WITH THE

K=1000 OHM, M=1000 KOHM.

** THE UNIT OF RESISTANCE IS OHM.

COMPONENTS IDENTIFIED BY MARK HAVE SPECIAL CHARACTERISTI

CS.

** IMPORTANT SAFETY NOTICE

!

! !

!

100C HEAT DETECT

HEAT

DC BALANCE DETECT

!

1W O.47

PROTECTOR

AMP MUTE

F MUTE

D GND

+5.6V

DATA

B-15

B+15

DC BALANCE

CLK

CE

CD

TUNER

PHONO

AUX

IN

REC-1

IN

OUT

REC-2

R CH

L CH

R CH

L CH

!

C123

C124

R201

R221

C221

C201

C202

C222

R222

R202

R204

R224

C224

C204

C203

C223

R223

R203

R207

R227

C227

C207

C208

C228

R228

R208

R206

R226

C226

C206

C205

C225

R225

R205

R211

R231

C231

C211

C212

C232

R232

R212

R210

R230

C230

C210

C209

C229

R229

R209

R214

R234

C234

C214

C213

C233

R233

R213

R235

R236

R237

R238

C286

L364

L363

R368

C368

C367

R364

R366

R365

R363

R367

R371

R375

R339

R337

Q371

C287

R285

R911

R912

D911

D912

D914

D913

C911

C912

C918

R920

R919

C919C920

D901

R901

C902

C901C903

R905

R906

Q921

R921

R914

D921

D922

C914

R915

R913

D915

C923

R275

R274

R273

Q924

R927

R923

R929

Q922

Q923

R926

R925

C926

C927

C928

D925

D923

R922

D924

R928

C929

R924

Q392

Q391

R392

R391

R394

R393

D391

D392

R395

R396

R399

Q393

Q394

R400

R398

R397

C391C392

C394 C393

D388

R385

R386

Q386

Q385

R388

R387

D383

R390

R389

C385

R286

R287

Q282

Q281

R281

R282

R280

C281

C282

C283

R283

R279

R278

C921

C922

R382

C905

C906

IC94

IC93

JK12

JK13

JK14

JK31

Q355

R359

R361

C373

Q351

Q357

Q353

R353

R355

R357

C345

Q345

R343

Q325

Q335

R335 R327

R381

Q379

R377

R379

C379

R373

D373

R383

Q309

R307

D305

R309

Q315

R315

R313

R321

R305

C305

R317R319R318 R316

C304

R304

R320

R312

R314

Q312

R308

D306

R306

Q308

R328R324

R322

R336

Q336

Q326

R344

Q346

C346

R358

R356

R354

Q354

Q358

Q352

R362 R360

Q356

R284

R338

R340

D374

R374

R378

C374

Q372

R376

R372

C289

C288

R341

CN35

CN33

IC95

CN37

CN38

C342C344

C343

C341

C307

R323

R325

C306

R334 R333

JK15

JK11

GND1

J13

J14

R241

R242

C236

C235

R246 R245

CN12

R243

R244

VR32

VR31

Q349

Q347

R351

R349

R345

R347

R352

R350

R342

Q348

Q350

R348

R346

GND2

GND3

L102

L101

R247

C237

C238

R248

R691

R692

J101

J102

CN55

C395

C396

JW11-2

JW11-1

CN95

C917

RY33

RY32

CN92

C913

R294R292R290

R295R293R291

D307D308

R311

R299

R310

R298

R300

D302D304

R301R303

D301D303

R289

R288

C309

C311

C310

C312

D309

D311

D310

D312

R943

Q917

R940

R942 R941

TH91

CN90

R103

C105

R101

R105

C109

R109

C121

R111

C111 C113

C115

R113

C117

R117

R119

C119

C120

R120

R118

C118

R114

C116

C114

C112

R112

R110

C110

R106

R102

C106

R104

C122

R121

R122

R115

R116

C104

C103

IC11

C102

C101

C216

IC22

C215

R217

R218

C218

C217

R216R215

R219

R220

R239

C219

C220

R240

RY31

Q305

Q313

Q311

Q307

Q303

Q301

Q306

Q310

Q314

Q304

Q302

R302

Q316

R297

R296

IC21

R251

D251

C241

C240

R249

C239

R250

D916

D917

IC31

IC32

IC23

C242

Q920

Q919

Q918

R953

C940

R947

C939

R952

R948R950

R944

R945

R946

R949 R951

BN97

R918

J514

J425

J330

J614

J527

J528

J708

D178

J328

J329

R939

C300

C301

C243

C244

J613

J807

J525

C246

C245

U-PRO & TONE PWB

HEADPHONE PWB

U-PRO & TONE PWB

SUB TRANSF. PWB

TRANSF.1 PWB

U-PRO & TONE PWB

MASTER VOLUME PWB

6. SCHEMATIC DIAGRAM

INPUT & AMPLIFIER PWB

9 10

3 1

2

5

6 4

3 1

2

5

6 4

3 1

2

5

6 4

1

2

3

2

45

6

7

8

9

1

2

3

+15V

-15V

+15V

LGND

RGND

LGND

RGND

LGND

RGND

LGND RGND

RGND

LGND

RGND

LGND

RGND

LGND

RGND

LGND

RGNDLGND

RGND

LGND

RGND

-15V

LGND

RGND

LGND

RGND

LGND LGND

-15V

+15V

-15V

+15V

RCGNDCHGND

DGND

DGND DGND

DGND

RCGND

LGND

RGND

CHGND

==> SILVERPM5003/N1B,N1SG,U1B,F1 B,F1 N

IMPOROVEMENT OF PERFORMANCE.

** THIS SCHEMATIC DIAGRAM MAY MODIFIED AT ANY TIME WITH THE

pF = 10 uF

** THE UNIT OF CAPACITANCE IS MICROFARAD(uF)

K = 1000 OHM. M = 1000KOHM.

** THE UNIT OF RESISTANCE IS OHM.

USE ONLY MANUFACTURER'S SPECIFIED PARTS.

IMPORTANT FOR SAFETY. WHEN REPLACING ANY OF THESE COMPONENTS

COMPONENT IDENTIFIED BY MARK HAVE SPECIAL CHARACTERISICS.

** IMPORTAT SAFETY NOTICE.

-6

BALANCE

-15V

L IN

R IN

HEAD PHONE

FLASHER IN

CE

DATA

CLK

+5.6V

DGND

F MUTE

AMP MUTE

PROTECTOR

STAND BY

MUTE

CD-R

MD/TAPE

AUX/DVD

TUNER

CD

PHONO

VR UP

VR DOWN

L-OUT

R-OUT

L-IN

R-IN

20KMNX2

ST 5.6V

GND

POWER ON

REMOCON GND

REMOTE IN

L-OUT

R-OUT

2 SPEAK

1 SPEAK

R CH

L CH

R-OUT

L-OUT

RC

RIN

LC

LIN

VR DOWN

VR UP

BASS VRTREBLE

NJM2068M

R CHL CH

R

TREBLE

BASS

TREBLE

BASS

R IN

L IN

JW52

POWER S/W

JW62

BN55

CE1

DATA

CLK

TX

RX

+5V

TEST

RESET

RM-IN

AMUT

P.ON

PRO.IN

STAND_BYFMUTE

R.S

EN1

EN2

VR-UP

VR-DN

RESET

REMOCON ON/OFF

VDD

TEST

X-IN

X-OUT

GND

MUTE

BACK.UP

CD-R

DC BALANCE DETECT

AUX/DVD

TUNER

CD

PHONO

VSS

TONELOUDNESS

SPEAKER 1SPEAKER 2

LOUDNESS ON

CLK

DATA

CE1

L IN

R IN

1 SPEAK

2 SPEAK

LOUDNESS ON

SOURCE DIRECT

L IN

R IN

MAIN-FRONT

CE2

MD/TAPE

DC BALANCE

L IN

R IN

SHIELD

ET01 ET02

STOPPER

ST +5.6V

10K

230V 50Hz : (EUR) 120V 60Hz : (USA)

REMOTE IN

POWER ON

GND

ST +5.6V

REMOTE

MAIN -POWER S/W

CLT5I009ZJ;F1N,F1B(JAPAN)

CLT5I009ZE;N1B,N1S,N1G(EUR)

F901

T3.15A L 250V;PM5003/F1N,F1B,U1B(JAPAN/USA)

T2.5A L 250V;PM5003/F1N,F1B,U1B(JAPAN/USA)

F902,F903

( JAPAN/USA ) ONLY

T1.6A L 250V;PM5003/N1B,N1S(EUR)

W001

RT01

REMOTE IN

DC8.9V

AC7.6

MAIN-POWER

MAIN-POWER MAIN-POWER

MAIN -POWER

1

2

3

4

5

6

7

8

9

PWR1

CLT5R028XW ; N1B,N1S,N1G(EUR) ;PM5003

CLT5R028YJ ; F1N,F1B(JAPAN) ;PM5003

PWR1

CLT5R028XU ; U/N1B/PM5003

+5.6V

MD/TAPE

CLT5I009ZU;U1B(UL)

TRS1

BACK UP

BACK.UP

GND

POWER DOWN

BN96

100V 50~60Hz:(JAPAN)

F1 N/F1 B/U1B

10K

10/50V

10K

220

1.5K

C107M

10K

2.7K 1.8K 1.5K

10K

1K

0.01

C107M

7 6 5 4 3 2 1

A107M

0.01

16MHz

22P

0.01

100

1000/6.3V

C2785Y

4.7K

10K

22K

2.2K

22K

4.7K

0.01

100

22K

10/50V

VOUT

GND

Vcc

123

47K

C2785Y

22K

220/16V

100P

22K

100

47K

220/16V

0.01

0.1

100

0.01

A107MA107M

D1021Y

B811Y

2.2K

47K

2.2K

47K

D1021Y

2.2K

10/50V

10

220/16V

3.3K

0.001(M)

0.1

5.6K

0.001(M)

3.3K

0.1

5.6K

10

0.01

47/25V

100

47/25V

100

1

2

3

7

8

47

0.01uF

0.01

7654321

1 2 3 4 5 6 7

CSR2A034Z

10/50V

56K

CVV2X05M104Z

4321

+

-

M

CVV9Y12B104Z

4 3 2 1

330

1 2 3 4

5678

100K

100P

10/50V

2.7K

CVV2X10B103Z

1 2 3 4

5678

HVINJM2068MDTE1

1 2 3 4

5678

HVINJM2068MDTE1

2.7K

10/50V

100P

100K

2.7K

100P

2.7K

22/50V

4.7/50V

0.033(M)

1K

33K

1K

0.033(M)

4.7/50V

33K

1.2K

0.015(M)220P

220P

0.015(M)

1.2K

33K

100K

220

12

4700P

11 10 9 8 7 6 5 4 3 2 1

120

1M

1/50V

C107M

0.01

10/50V

0.01

302928272625242322212019181716

15 14 13 12 11 10 9 8 7 6 5 4 3 2 1

CVITMP86FH12MG

10K

C107M

6 5 4 3 2 1

4321

0.1

10/50V

C102M

100

2

7

1

8

3 4

6 5

CSL4A016ZU

10k

A1175Y

C2785Y

33k

10k

100

33k

0.01

161514131211109

8 7 6 5 4 3 2 1

HVITC74HC4094FN

100

10K

A107M

1 2

2.7K

56K

10/50

330

100

330

10/50

56K

1234

567 8

NJM2068M

A1268GR

C3200GR

22

C3200GR

A1268GR

470

12K

100/25V

100

22

470

12K

330

A1268GR

C3200GR

330

1234

5 6 7 8

NJM2068M

100/25V

100

33K

A1268GR

C3200GR

22

C3200GR

A1268GR

470

12K

22

07

422

12K

330

A1268GR

C3200GR

330

220270

270

1M

470P(M)

33K

220

1M

470P(M)

22

220/25V

22

0

220

100K

22/50V

A102M

0.01

0.1

SIR34ST3F

ROUT GND Vcc

1 2 3

RPM6936

0.1uF

100/10V

100

A102M

100

3P-3.5PHI-JACK

1 2

0.0047

1000/25V

NC

4.7 (1/4W)

0.022 100/16V

D1021

47K

10K

100P

0.1

47

7654321

2 1

T 1.6A L 250V

CLT5I009ZE

142

3

CSL1E002ZE

NC

0.1

VDIS

GND

VOUT VIN

4 3

2 1

10K

4321

0.01uF

1 2 3

KJJ7A011Z

1000/6.3V

C3A206

10P

100

2

7

1

8

3 4

6 5

CSL4A016ZU

21

10

T2.5A L 250V

1SS133

10/50V

6.8K

4.7K

1SS133

5.6V

0.01

470P

1000P

220/25V

NC

0.01

NC

100P 100P

LOUDNESS

SELECTOR

UP DATA

SOURCE DIRECT

R651

C619

D651

D652

R652

D653

R653

D654

R654

D655

R656

D656

R655

D657

R659

R658

D675

R675

Q689

R619

R694 R695 R696

R660

R697

C694

Q691

BN93

Q631

Q634

C627

C693

X621

C625

C626

D621

C621

R622

C622

Q603

Q604

Q605

R604

R602

R603

R605

D601

R601

R636

R635

R637

D606

C602

R606

R608

C606

RC61

D613

R615

Q617

R626

R617

C613

C617

R625

R624

R623

R611

R607

C611

C612

C695

R612

C601

Q635Q636

Q683

Q687

Q688

R683

R685

R684

R686

Q684

R688

R687

C688

C687

R681

C681

D623

R442

C418

C420

R444

C417

R441

C419

R443

R618

C618

C507

R505

C508

R506

JK61

R698

R699

C692

C691

C423

CB52

BN52

SW31

C520

C519

R521

R522

VR51

BN33

VR53

BN12

R439

R440

IC53

R502

C504

C502

R504

VR54

VR55

IC55

IC54

R503

C501

C503

R501

R507

C509

C510

R508

C505

C506

C512

C514

R512

R514

R513

R511

C513

C511

R518

R516

C516

C518

C517

C515

R515

R517

R509

R510

R520

R519

JW52

C901

BN95

R627

R628

C633

Q692

D622

C631

C623

C630

IC61

R648

Q690

JW61-1

BN51

CN56

BN56

C632

C421

D405

Q413

R400

S102

S103

S104 S101

RY51

D502

R528

R527

Q502

Q501

R525

R526

D501

R524

R523

C521

IC62

R629

R630

Q637

Q638

Q639

Q640

BN35

D641

R641

D642

R642

D643

R643

D644

R644

R401

C401

R403

R405

R406

R404

C402

R402

C404 C403

IC41

Q404

Q402

R410

R408

Q408

Q406

D404

R418

R414

C413

R431

R422R420

D402

R416

R412

R426

Q412

Q410

R424

IC42

C414

R432

R430

Q403

Q401

R409

R407

Q407

Q405

D403

R417

R413

R421 R419

D401

R415

R411

R425

Q411

Q409

R423

R434 R436

R428

C406

R429

R433

R435

R427

C405

R438

C415

C416

R437

R446

R447

R448

R459

R450

R451

C407

C408

Q613

Q614

C656

C655

C654

C653

C652

C651

C629

D102

IC12

C127

C128

R124

Q101

R123

JK01

D101

CN96

C930

C931

C933

D927

D931

R931

C934

C932

Q925

R932

R930

C936

C925

R936

CN93

TW91

JK91

F901

JW96-2

JW96-1

TRS1

D930

D933

D932

RY92

C937C938

GND4

C935

IC96

D929

R934

JW94(N)

JW94(BLK)

BN92

C910

JW93

BN90

SW91

OL92

C620

D620

J100

C409

C410

R610

RY41

CN97

R631

R929

D934

D602

JW94-2

JW95-3

F902

F903

D908

D907

C926

R927

R928

D909

D910

D624

C690

C614

C615

C616

C411

C412

J128

C928

C927

BN96-2

BN96-1

J141

JW11

J140

C624

R600

C600

REMOTE CONT. IN/OUT

U-PRO & TONE PWB

INPUT & AMPLIFIER PWB

SUB TRANSF. PWB

INPUT & AMPLIFIER PWB

U-PRO & TONE PWB

HEADPHONE PWB

TRANSF.1 PWB

SUB TRANSF. PWB

MASTER VOLUME PWB

POWER SW PWB

1211

SUB TRANSF. A PWB

Q925

Q101

IC96

IC12

7. PARTS LOCATION

SUB TRANSF. A PWB

SUB TRANSF. B PWB

13 14

鉛フリー半田

半田付けには、鉛フリー半田

(Sn-Ag-Cu)

を使用してください。

Lead-free Solder

When soldering, use the Lead-free Solder (Sn-Ag-Cu).

Q385 Q386 Q391 Q392

Q371 Q351 Q347

Q355

Q301 Q303

Q281

Q325 Q305 Q309 Q313 Q315 Q311 Q307 Q335

Q349 Q353

Q357

Q304 Q302

Q282

Q336 Q308 Q312 Q316 Q314 Q310 Q306 Q326

Q354 Q350

Q358 Q346 Q356

Q348 Q352

Q379

Q372

Q917

Q924

Q922 Q923

Q345

Q393Q394

IC21

IC95

IC93

IC94

Q921

Q918 - Q920

INPUT & AMPLIFIER A PWB

鉛フリー半田

半田付けには、鉛フリー半田

(Sn-Ag-Cu)

を使用してください。

Lead-free Solder

When soldering, use the Lead-free Solder (Sn-Ag-Cu).

1615

IC23

IC32 IC31

IC22 IC11

INPUT & AMPLIFIER B PWB

17 18

鉛フリー半田

半田付けには、鉛フリー半田

(Sn-Ag-Cu)

を使用してください。

Lead-free Solder

When soldering, use the Lead-free Solder (Sn-Ag-Cu).
