LaCie FireWire 800 PCI Card • DESIGN BY SISMO Introduction
User Manual page 4
1. Introduction
Congratulations on the purchase of your new LaCie FireWire
800 PCI Card. Now when you connect your FireWire devices
through your LaCie FireWire 800 PCI Card, you will be able to
achieve the impressive transfer rates that FireWire makes possible.
The LaCie FireWire PCI Card has three high-speed FireWire
ports, giving you a convenient solution to connect more FireWire
peripheral devices to your computer, such as high-speed hard
drives, digital cameras, scanners and most popular D8 camcorders.
Your LaCie PCI Card Capabilities
✦ IEEE 1394b compliant, 1394a backward compat-
ible (with appropriate cables (9 to 6 pin or 9 to 4
pin cables)
✦ Three external FireWire ports
✦ Transfer files at up to 800MBits/sec
✦ Digital video capture capabilities
✦ Plug & Play convenience
✦ No drivers required
✦ Anti-static handle
Quick Links
Click a topic:
✦ Inserting your LaCie PCI Card
✦ Driver Installation
LaCie FireWire 800 PCI Card • DESIGN BY SISMO Your LaCie FireWire 800 PCI Card
User Manual page 5
2. Your LaCie FireWire 800 PCI Card
1.1. Minimum System Requirements
The LaCie FireWire 800 PCI Card is compliant with the Open
Host Controller Interface (OHCI), the Enhanced Host Controller
Interface (EHCI).
Windows
IMPORTANT INFO: The format of this card is not compat-
ible with PCI express slots, laptops or notebook computers, and
therefore cannot be installed on these types of systems.
CAUTION: Before handling and installing your LaCie FireWire
800 PCI Card, ensure that you have properly grounded yourself. Electrostatic Discharge (ESD) can quickly and easily damage or destroy your component or your computer. Please see
section 3.1. Electrostatic Discharge for information on how to
properly ground yourself.
IMPORTANT INFO: During installation or removal, always
hold your card by the anti-static gripping pad.
✦ Windows 2000, Windows XP, Windows Server 2003,
or Windows Vista
✦ One PCI slot that complies with PCI Specification
Rev.2.3 or above
✦ Pentium III or higher compatible processor
✦ 128MB RAM
Mac
✦ Mac OS 10.2.4 or higher
✦ One PCI slot that complies with PCI Specification
Rev.2.3 or above
✦ G4, G5, or Intel processor
✦ 128MB RAM
Loading...
