Chap1newBook Page 1 Friday, February 5, 1999 7:02 AM

KODAK DC200 Plus Camera

and

KODAK DC210 Plus Zoom Camera

User’s Guide

for the cameras, KODAK Installation Software , KODAK DC200/DC210 Mounter Software, and KODAK Acquire/TWAIN Software.

Visit Kodak on the World Wide Web at www.kodak.com

Chap1newBook Page 2 Friday, February 5, 1999 7:02 AM

©Eastman Kodak Company, 1999 Kodak, FlashPix, Photolife are trademarks of Eastman Kodak Company.

The FlashPix format is defined in a specification and test suite developed and published by Kodak in collaboration with Microsoft, Hewlett-Packard, and Live Picture. Only products that meet the specification and pass the test suite may use the FlashPix name and logo.

Chap1newBook Page i Friday, February 5, 1999 7:02 AM

Table of Contents

Chapter-Page

Table of Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . i

Getting Started . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-1

Camera Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-2

Your DC200/DC210 Camera . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-3

Capturing a Picture . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-1

Camera Power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-1

Take a Picture . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-2

Preview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-2

Delete One Picture . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-3

Exposure Compensation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-4

Exposure Lock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-5

Status Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-6

Pictures Remaining . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-6

Self-Timer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-7

Memory Card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-7

Close-Up —DC210 Only . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-8

Flash . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-9

Resolution . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-10

Quality . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-11

Batteries . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-12

Zoom —DC210 Only . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-14

General Maintenance and Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-15

Table of Contents

Review . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-1

View Pictures . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-1

Delete One or All Pictures . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-2

Magnify Pictures . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-3

Slide Show . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-4

Chap1newBook Page ii Friday, February 5, 1999 7:02 AM

Preferences . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-1

Quality . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-2

Resolution . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-3

Template . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-4

Date Stamp . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-5

File Type . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-6

Quickview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-7

Date and Time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-8

LCD Brightness . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-9

Format Memory Card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-10

Video Out . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-11

Language . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-12

About . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-13

Installation Software . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-1

WINDOWS System Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-1

Installing the Software . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-1

Connect . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-1

Checking Serial Port Availability . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-1

Infrared Connection —DC210 Only . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-1

Serial Cable Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-2

Mounter Software . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-1

Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7-1

Camera Communication Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7-1

Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7-2

Using Mounter Software . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7-2

Setting and Viewing Properties . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7-4

Memory Card Properties . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7-4

Picture File Properties . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7-5

Camera Properties . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7-6

Chap1newBook Page iii Friday, February 5, 1999 7:02 AM

TWAIN Software . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8-1

Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8-1

Table of Contents

Camera Communication Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8-1

Starting TWAIN Software . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8-2

Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8-2

Transferring Pictures from DC200/DC210 . . . . . . . . . . . . . . . . . . . . . . .8-3

Picture Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8-4

Preferences Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8-5

Tips and Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-1

Communicating with the Computer . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9-1

Monitor Adjustment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9-1

Printing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9-2

Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9-3

Where to

Get Help . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10-1

Software Help . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10-1

Online Services . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10-1

Faxed Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10-1

Customer Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10-2

Warranty & Regulatory Information . . . . . . . . . . . . . . . . . . . . . warranty1

Warranty Time Period . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . warranty1

Warranty Repair Coverage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . warranty1

Limitations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . warranty2

Application Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . warranty3

How to Obtain Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . warranty3

Regulatory Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . warranty4

iii

Chap1newBook Page iv Friday, February 5, 1999 7:02 AM

Chap1newBook Page 1 Friday, February 5, 1999 7:02 AM

Getting Started

Congratulations on your purchase of the new KODAK DC200 Plus Camera (referred to as DC200), and the KODAK DC210 Plus Zoom Camera (referred to as DC210). The cameras that capture pictures digitally, without the use of ﬁlm.

The DC200 camera features:

✔

built-in ﬂash with red-eye reduction

✔

an easy to use status display of camera settings removable memory card

✔ ✔

video out capabilities which allow you to connect and run a slide show on your TV

✔

color LCD to immediately see or preview your pictures software to easily transfer pictures from the camera to your computer

✔ ✔

a mode dial to activate one of four different functions on the camera:

Capture— takes, previews, or deletes a picture and adjusts

the exposure

Review— review or delete pictures Preference— adjust camera settings Connect— camera communicates with your computer

The DC210 has all of the features of the DC200 and more:

✔

infrared remote connection to compatible devices

✔

2X zoom lens (29 to 58mm) to zoom in on subjects and a close up option to set the focus at 8in. (20cm)

Getting Started

The pictures used in this manual were captured with a Kodak digital camera. This user’s guide includes operating instructions for the DC200/DC210 cameras and detailed information on the KODAK Installation Software (chapter 5), Mounter Software (chapter 7), and TWAIN Software (chapter 8). Instruction manuals for the additional software packages included on the DC200/DC210 CD are included in the camera package.

1-1

Chap1newBook Page 2 Friday, February 5, 1999 7:02 AM

Camera SpeciÞcations

Picture Pixel Resolution—

High— 1152 x 864 = 995,328 Standard— 640 x 480 = 307,200

CCD Resolution—

1160 x 872 = 1,011,520

Flash Range—

DC200— 2.23 ft. to 9.84 ft.

(0.7 to 3.0 m)

DC210—

wide— 1.6 to 9.84 ft.(0.5 to 3.0 m) telephoto— 3.2 to 8.8 ft.

(1.0 to 2.7 m)

Color— 24-bit, millions of colors Storage— external memory only

ATA Compatible Compact Flash Card

Power— 4 AA batteries Shutter Speed— 1/2 to 1/362 sec File Format— FlashPix or JPG Lens— optical quality glass

Weight— without batteries

DC200— 11.64oz. (330 g) DC210— 11 oz. (320 g)

Video Out— NTSC or PAL

Operating T emperatur e —

40 to 104° F (4.4 to 40° C)

Focus Distance—

DC200—

ﬁxed— 2.23 ft. (.68 m) to inﬁnity

DC210—

wide— 1.64 ft. (0.5 m) to inﬁnity telephoto— 3.28 ft. (1 m) to inﬁnity close up— 8 in. (20 cm)

Sensitivity— ASA/ISO rating

equivalent to 140

Accessary Lens Thread—

37 mm—DC200 only

Viewﬁnder— Real image Tripod Socket— .25 in. Focal Length—

DC200— 6.0 mm

Actual is 39mm

DC210— 2X zoom lens-4.4 to 8.8 mm

Actual is 29 to 58 mm

Equivalent for 35 mm camera

Aperture—

DC200— f/4 to f/13.5 DC210—

wide— f/4 to f/13.5 telephoto— f/4.7 to f/16

Dimensions— 5.15 X 1.87 X 3.20 in.

(131 X 48 X 82 mm)

1-2

Chap1newBook Page 3 Friday, February 5, 1999 7:02 AM

Your DC200/DC210 Camera

☞

The illustrations throughout this user’s guide are of the DC210 unless otherwise stated.

Camera Front

LIght

Infrared Transceiver

(DC210 Only)

Viewfinder FlashSelf-Timer

Getting Started

Flash Sensor

Camera Top

Status Display

FLASH

CLOSE-UP

(DC210 only)

Lens

Light Sensor

SELF-TIMER

SHUTTER

POWER

1-3

Chap1newBook Page 4 Friday, February 5, 1999 7:02 AM

Camera Back

LCD Screen

Camera Bottom

Battery Door

Camera Side

ViewfinderReady Light

DO-IT

Tripod Socket

ZOOM

(DC210 Only)

Mode Dial

Card EJECT

1-4

Card Door

Video Out

Serial

AC Adapter

Chap1newBook Page 1 Friday, February 5, 1999 7:02 AM

Capturing a

When the Mode dial is set to Capture, the camera can perform the following functions:

capture a picture

✔

preview pictures on the Liquid Crystal Display (LCD)

✔ ✔

delete a picture just taken adjust the exposure

✔

adjust some camera settings using the Status Display

✔


Camera Power

To turn the camera on/off:

Press the POWER button.

Capture

The green Ready light, on the back of the camera, and the Status Display screen turns on or off.

If the camera is turned off while a picture

☞

is being processed, the camera will ﬁnish processing the picture before turning off.

If you are not using an AC power adapter and your camera is idle for approximately 5 minutes, it automatically turns off. To turn the camera on again, press the camera’s power button.

2-1

Chap1newBook Page 2 Friday, February 5, 1999 7:02 AM

Take a Picture

To take a picture:

1 Set the Mode dial to Capture. 2 Turn the camera on.

3 Center subject in the viewﬁnder. 4 Press the SHUTTER button.

The green Ready light, Memory Card icon, Pictures Remaining number on the Status Display blink rapidly, as the camera processes the picture.

☞ You do not need to hold the camera still while the green Ready light is

blinking, but you will not be able to take another picture until it stops.

Preview

You may also use the LCD as a live viewﬁnder while in Capture mode. This allows you to preview your picture before it is taken.

☞ Using the Preview option signiﬁcantly shortens battery life.

To activate Preview:

1 Set the Mode dial to Capture. 2 Turn the camera on. 3 Press the DO-IT button.

The LCD displays the subject that is viewed from the viewﬁnder with the icons of activated camera features.

Template icon— appears if the template option is activated. See “Template” on page 4-4 for details.

Exposure Lock icon—appears if the exposure lock option is activated. See “Exposure

Lock” on page 2-5 for details.

Exposure Compensation icon— appears if the exposure value is adjusted. See “Exposure

Compensation” on page 2-4 for

details.

To exit: press the DO-IT button again to turn Preview off. The Preview setting automatically turns off when the camera is turned off.

2-2

/ /

Chap1newBook Page 3 Friday, February 5, 1999 7:02 AM

Delete One Picture

You may delete the picture that was just taken without leaving Capture mode.

☞ This delete feature is only available when the picture is shown on the LCD

and the Quickview option is activated. See “Quickview” on page 4-7.

To delete the most recent picture taken in Capture mode:

1 Set the Mode dial to Capture. 2 Turn the camera on. 3 Take a picture.

The picture is displayed on the LCD.

4 Press the button.

The delete screen appears in the LCD.

☞ The picture must be showing on the

LCD screen to activate the delete screen.

5 Press a button until the correct

delete option is highlighted.

6 Press the DO-IT button.

The picture is deleted from the memory card.

To exit: press a button until NO is highlighted and then press the DO-IT button.

Capture

2-3

Chap1newBook Page 4 Friday, February 5, 1999 7:02 AM

Exposure Compensation

The camera’s exposure value (EV) can be adjusted from -2.0 to +2.0 EV in

0.5 EV increments while in Capture mode. A +1.0 adjustment in EV, in effect doubles the amount of light allowed to reach the CCD (charge coupled de vice) in your camera. A -1.0 adjustment in EV, halves the amount the light allowed to reach the CCD in your camera. Below shows how changes in EV can effect your pictures.

If your pictures are too:

✔ dark—increase (+) the exposure compensation setting ✔ light—decrease (-) the exposure compensation setting

To change Exposure Compensation:

1 Set the Mode dial to Capture. 2 Turn the camera on.

3 Press the button.

The LCD displays the Exposure Compensation screen.

4 Use the buttons to adjust

the exposure.

5 Press DO-IT to select the Exposure setting.

To reset: the Exposure setting automatically resets to 0.0 EV when the camera is turned off.

2-4

Chap1newBook Page 5 Friday, February 5, 1999 7:02 AM

Exposure Lock

Use the Exposure Lock to take a sequence of pictures that require the same exposure. When this setting is activated, the camera maintains a constant exposure setting.

To turn on Exposure Lock:

1 Set the dial to Capture. 2 Turn the camera on.

3 Press the button two times.

The Exposure Compensation screen appears, followed by the Exposure Lock screen.

☞ Press the button a third time to

exit the exposure menu.

4 Press a button until ON

is highlighted.

5 Press the DO-IT button.

The Take a Picture screen appears.

6 Center the area you want to lock the

exposure on in the viewﬁnder

7 Press the SHUTTER button to lock in

the exposure setting.

To Reset: The Exposure Lock setting automatically resets when the camera is turned off.

Capture

2-5

Chap1newBook Page 6 Friday, February 5, 1999 7:02 AM

Status Display

The Status Display, located at the top of your camera, allows you to view and change some camera settings. The following sections offer detailed descriptions of Status Display settings.

☞ The DC200/DC210 must be turned on to view the Status Display.

Resolution

Battery Status

Flash

Quality

Close Up

(DC210 Only)

Reduction

Pictures Remaining

Self-Timer

Memory Card Status

(Inserted)Red-eye

Pictures Remaining

The Pictures Remaining icon changes automatically to indicate the remaining number of pictures which can be stored at the current quality and resolution setting. You may not select or change the Pictures Remaining icon.

When the card’s memory is full the Status Display indicates Full. You must delete existing pictures or change memory cards to capture additional pictures. To save pictures, transfer them to your computer before deleting them. For more information on how to move or delete pictures, see “Delete One Picture” on page 2-3, “Delete One or All Pictures” on page 3-2, or the software chapters.

☞ The Pictures Remaining number does not always change by one when a

picture is taken if the picture content is easily compressed.

2-6

Chap1newBook Page 7 Friday, February 5, 1999 7:02 AM

Self-Timer

Activating the Self-T imer option creates a 10-second delay between the time you press the SHUTTER button and when the picture is taken. This allows you to include yourself in the picture.

To activate the Self-Timer:

1 Set the Mode dial to Capture. 2 Turn the camera on.

3 Press the SELF-TIMER

button.

The Self-Timer icon appears on the Status Display.

4 Place the camera on a ﬂat, steady surface or tripod. 5 Press the SHUTTER button.

The red Self-Timer light, located on the front of the camera, turns on and stays lit for 8 seconds. The Self-T imer light ﬂashes for 2 additional seconds just before the pictur e is taken. The Self-T imer r eturns to the of f setting once the picture is taken.

To stop the Self-Timer: press the SELF-TIMER button again before the picture is taken.

Memory Card

The DC200/DC210 comes equipped with a KODAK Picture Card (memory card). The reusable memory card is used to store the pictures taken with the camera. The camera does not have an internal memory and will not operate without a memory card. The Card Status icon changes automatically to indicate if there is a memory card inserted in the camera. You may not select or change this icon.

No card inserted—pictures cannot be taken.

Capture

Card inserted—pictures are saved to the card’s memory.

2-7

Chap1newBook Page 8 Friday, February 5, 1999 7:02 AM

To insert a memory card:

1 Open the card door. 2 Hold the memory card with the connecting end

pointed at the camera.

3 Push the card all of the way into the card slot

and close the card door.

To remove a memory card:

1 Open the card door. 2 Press the EJECT button

3 Take hold of the card, carefully remove

The card partially slides out of the slot.

it from the slot, and close the card door.

WARNING: Do not insert or eject a card when the Ready light is blinking.

This may damage your pictures or camera.

Use only certiﬁed memory cards in your camera that carry the CompactFlash logo.

Close-Up ÑDC210 Only

The DC210 offers a Close-Up setting which allows you to set the camera’s focus distance at 8 in. (20 cm).

The red-eye reduction option for the Flash setting is not available when Close-Up is on.

☞ To accurately capture the picture in Close-Up, the Preview option

automatically starts when the CLOSE-UP button is pressed. See “Preview” on page 2-2 for detailed information. To deactivate the Preview option, press the DO-IT button.

2-8

Chap1newBook Page 9 Friday, February 5, 1999 7:02 AM

To turn on the Close-Up setting:

To cancel Close-Up: press the CLOSE UP button again and the Close-Up icon

disappears from the Status Display. The Close-Up setting is automatically turned off when the camera is turned off.

1 Set the Mode dial to Capture. 2 Turn the camera on. 3 Press the CLOSE-UP button.

The Close-Up icon appears on the Status Display.

4 View the subject on the LCD

display to accurately capture the picture.

Flash

The DC200/DC210 is equipped with a built-in ﬂash that offers an optional redeye reduction feature. The ﬂash has an effective range of approximately 2.23 to

9.84 ft. (0.7 to 3 m) for the DC200, and 1.6 to 9.8 ft. (0.5 to 3 m) for the DC210. There are ﬁve Flash settings:

Auto—ﬂash ﬁres automatically when the SHUTTER button is pressed and the camera determines that there is not enough light. This is the default setting.

Auto Red-eye—works the same as auto ﬂash except the ﬂash ﬁres once before the picture is taken to reduce the chance of red-eye and then ﬂashes a second time when the picture is taken.

Fill—ﬂash ﬁres every time you press the SHUTTER button. Use this setting when the lighting is poor or when your subject is lit from behind.

Fill Red-eye—works the same as ﬁll ﬂash except the ﬂash ﬁres once before the picture is taken to reduce the chance of red-eye and then ﬂashes a second time when the picture is taken.

Off—ﬂash is turned off and will not ﬁre.

Capture

2-9

Chap1newBook Page 10 Friday, February 5, 1999 7:02 AM

To change the Flash setting:

1 Set the Mode dial to Capture. 2 Turn the camera on. 3 Press the FLASH button to

scroll through and select the appropriate Flash settings.

To cancel the Flash setting: Flash setting returns to the default setting when the camera is turned off.

Resolution

Resolution indicates the size of the picture in pixels. The camera can be set to capture pictures in a High or Standard resolution. Your pictures include more detail with high resolution, but they will use more memory on the card than at the standard resolution setting.

You can switch freely between the two settings when taking pictures. The number of pictures the DC200/DC210 is able to store will vary accordingly.

The Resolution setting is indicated on the Status Display using the following icons:

High—the picture size is 1152 x 864 pixels. This is the default setting. Use this setting when your pictures are to be printed.

Standard—the picture size is 640 x 480 pixels. Use this setting when the pictures are for email or on-line use.

The Resolution setting is changed using the Preferences mode. See “Resolution” on page 4-3 for more information.

2-10

Chap1newBook Page 11 Friday, February 5, 1999 7:02 AM

Quality

You may set your camera to capture pictures in a Good, Better, or Best quality setting. The Quality setting indicates how much the picture is compressed to sav e space on the memory card. Your pictures include more detail with the Best or Better setting, but they will use more memory on the card than with the Good setting.

You may switch freely between the three settings when taking pictures. The number of pictures the DC200/DC210 is able to store will vary accordingly.

The Quality setting is indicated on the Status Display using the following icons:

Best—you can store approximately 4 pictures per 1 MB of storage at this Quality setting and when the Resolution is set to High. Use this setting when image quality is very important for maximum picture quality, especially for larger sized or zoom prints.

Better—you can store approximately 6 pictures per 1 MB of storage at this Quality setting and when the Resolution is set to High. Use this setting for a good picture quality and to store a large number of pictures. This setting is good for general picture taking.

Good—you can store approximately 9 pictures per 1 MB of storage at this Quality setting and when the Resolution is set to High. Use this setting to maximize the number of pictures stored.

The Quality setting is changed using the Preferences mode. See “Quality” on page 4-2 for more information.

Capture

2-11

Chap1newBook Page 12 Friday, February 5, 1999 7:02 AM

Batteries

The DC200/DC210 comes with four AA batteries. Standard 1.5V alkaline, 1.5V lithium, or rechargeable 1.2V Ni-Cd or Ni-MH batteries may be used.

The battery power icon changes automatically. You may not select or change this icon.

Full—batteries are fully charged.

Low—batteries need to be replaced.

Blinking—batteries are insufﬁcient to run camera and need to

be replaced.

☞ Pictures on memory cards are not lost if batteries are depleted.

To install the batteries:

1 Place your thumb on the battery door. 2 Slide the battery door away from the camera. 3 Insert the batteries as indicated on the battery

cover and close the battery door.

☞ Remove the batteries if the camera will not

be used for an extended period of time. This extends battery life and prevents camera damage from battery leaks or corrosion. If the batteries are removed from the camera for more than a few minutes the date and time will be deleted and must be reset.

2-12

Chap1newBook Page 13 Friday, February 5, 1999 7:02 AM

Battery Usage Guidelines

Always follow your battery manufacturer’s directions fully. Do not attempt to disassemble, recharge, short circuit, or subject the battery to high temperature or ﬁre. When removing, batteries may be hot, allow them to cool before touching.

Dispose of batteries according to Federal and Local Regulations. Failure to replace the batteries when they are low may cause the DC210 to shut

down with the camera lens extended. Your camera has been designed to operate correctly using a variety of AA-size

batteries currently available. These include 1.5-volt alkaline, 1.5-volt lithium, or

1.2-volt Nickel Metal Hydride (Ni-MH) and Nickel Cadmium (Ni-Cd) batteries. NOT ALL BATTERIES ARE CREATED EQUAL! Battery life depends

signiﬁcantly on age, usage conditions, type and brand. Digital camera requirements are very demanding on batteries. Not all battery brands perform well under these challenging conditions. In Kodak lab tests, Ni-MH rechargeable batteries delivered the best results in a variety of conditions. Ni-MH batteries are designed for high demand devices like digital cameras, and do not exhibit the “memory” effects seen with other rechargeable technologies. Kodak offers NiMH rechargeable batteries (with charger) as an optional accessory. Refer to catalog number 152 7068 (U.S. and Canada), 852 2344 (Europe), 867 9953 (UK), 870 8141 (Asia), 910 7632 (Japan).

Capture

If you elect to use alkaline batteries in your camera, you will obtain better performance from “photo-ﬂash grade” alkaline batteries, such as KODAK PHOTOLIFE Alkaline Batteries. These types of batteries last more than twice as long in digital cameras as ordinary alkaline batteries.

Ni-Cd batteries work well in digital cameras, but typically have the shortest “duty cycle,” or usable power provided between charges.

Lithium batteries typically provide the longest overall battery life, but carry a higher cost-per-picture than other non-rechargeable battery types.

When using your camera on battery power, we recommend you limit continuous LCD “Preview” or “Review” to less than 20-minutes per session. If you anticipate using your camera for longer periods in these modes, it is recommended that you do so with the camera powered by the AC adapter.

2-13

Chap1newBook Page 14 Friday, February 5, 1999 7:02 AM

Zoom ÑDC210 Only

The DC210 comes equipped with a 2X zoom lens that allows you to zoom in on your subject from Wide Angle (29mm) to TelePhoto (58mm).

Wide Angle T elePhoto

To activate the zoom:

1 Set the Mode dial to Capture. 2 Turn the camera on. 3 Press the ZOOM button.

The subject will appear closer or farther away when you look through the viewﬁnder and press the ZOOM button.

The camera’s default lens position is Wide Angle. All other lens positions are considered T elePhoto settings.

2-14

Chap1newBook Page 15 Friday, February 5, 1999 7:02 AM

General Maintenance and Safety

✔ To keep from damaging your DC200/DC210, avoid exposing it to

moisture and extreme temperatures.

✔ Clean the outside of the DC200/DC210 by wiping with a clean, dry cloth.

Never use harsh or abrasive cleaners or organic solvents on the camera or any of its parts.

✔ Never disassemble or touch the inside of the DC200/DC210. This could

result in electrical shock.

✔ If you notice smoke or a strange smell coming from the DC200/DC210,

immediately turn the camera off, wait a few minutes until the camera cools, and then remove the batteries.

✔ Cleaning the lens and back LCD screen:

1 Blow gently on the lens or LCD screen to remove dust and dirt.

2 Moisten the lens or LCD screen by breathing lightly on it.

3 Wipe the lens or LCD screen gently with a soft, lint-free cloth or an

untreated lens-cleaning tissue.

☞Do not use cleaning solutions unless they are designed

speciﬁcally for camera lenses. Do not wipe the camera lens or LCD screen with chemically treated eyeglass lens tissue as it may scratch the lens.

✔ Service agreements are available in some countries. Please contact your

Kodak dealer for more information.

Capture

2-15

Chap1newBook Page 16 Friday, February 5, 1999 7:02 AM

Chap1newBook Page 1 Friday, February 5, 1999 7:02 AM

Review

When the Mode dial is set to Review, you may use the LCD to view the pictures stored on the KOD AK Picture Card (memory card). Using the Overlay screen the camera can perform the following functions:

✔ view the amount of unused memory left on the memory card ✔ view thumbnails of the pictures ✔ delete one or all pictures from the memory card ✔ view pictures, and run a slide show from the camera on your TV

View Pictures

To view pictures:

1 Set the Mode dial to Review. 2 Turn the camera on.

The Overlay screen appears on the LCD screen with the last picture taken.

Overlay Delete

Magnify

Filmstrip of pictures stored on memory card

☞ Use the buttons to scroll through pictures. To continuously scroll,

hold down a button.

To exit: press the buttons to highlight the Overlay icon. Press DO-IT to turn off the Overlay screen. The main Review screen reappears.

Highlighted picture from center of filmstrip

Memory bar displays space left on card and current picture position

Review

3-1

/ /

Chap1newBook Page 2 Friday, February 5, 1999 7:02 AM

Delete One or All Pictures

You can delete one or all of the pictures on the memory card when in the Review mode.

To delete a picture in Review mode:

1 Set the Mode dial to Review. 2 Turn the camera on.

The last picture taken appears on the LCD screen. The Overlay screen is turned on.

3 Press a button until the Delete icon

is highlighted.

4 Press the DO-IT button.

The delete screen appears on the LCD.

5 Press a button until the appropriate

picture is highlighted on the ﬁlmstrip.

☞ T o delete all the pictures on the memory

card, press a button until ALL PICTURES is highlighted and then press the DO-IT button.

6 Press the DO-IT button.

That picture is deleted from the memory card.

To exit: press a DO-IT button. The main Review screen reappears.

button until Exit is highlighted and then press the

☞Memory cards containing images captured from other digital cameras

will have less memory space available when used in the DC200/ DC210 cameras. To free-up memory space on the memory card you must delete the images in the model of camera that captured those images.

3-2

/ /

Chap1newBook Page 3 Friday, February 5, 1999 7:02 AM

Magnify Pictures

The magnify feature allows you to view the current picture at 2x size on the LCD screen when in Review mode.

To magnify a picture in Review mode:

1 Set the Mode dial to Review. 2 Turn the camera on.

The last picture taken appears on the LCD screen. The overlay screen is turned on.

3 Press a button until the appropriate

picture is highlighted on the ﬁlmstrip.

4 Press a button until the Magnify

icon is highlighted.

5 Press the DO-IT button.

The LCD displays a magniﬁed view of the selected picture.

☞ Use the and buttons to

scroll to different parts of the picture.

To exit: press the DO-IT button to cancel the Magnify feature. The magnify feature stops and the Overlay screen reappears.

Review

3-3

Chap1newBook Page 4 Friday, February 5, 1999 7:02 AM

Slide Show

The slide show feature on the DC200/DC210 allows you to connect the camera to a TV and view the pictures from the memory card on your TV! This is especially useful when sharing pictures with family and friends.

☞ The camera’s LCD is disabled when the camera is attached to the

video cable.

To view pictures on a TV:

1 Turn your TV and the DC200/DC210

camera off.

2 Insert the video output cable into the video out

connection on the side of your camera.

3 Connect the other end of the cable to the video in

connection on your TV.

4 Turn on the camera and TV. 5 Set the Mode dial to Review. 6 Set the TV to the correct video setting.

The pictures that are stored on the memory card appear on the TV screen.

☞ You may need to adjust the Video Out

preference on the camera. See “Video out” on page 4-11 for details.

7 Press a button on the camera to scroll

through the pictures on the TV.

☞ To run a slide show, press the DO-IT

button. The slide show starts, and the pictures change every ﬁve seconds for a period of ﬁve minutes. If you are using an AC adapter, the slide show runs indeﬁnitely.

To cancel Slide Show: press the DO-IT button to stop the slide show. The slide show stops and the main Review screen reappears.

3-4

Chap1newBook Page 1 Friday, February 5, 1999 7:02 AM

Preferences

When the Mode dial is set to Preferences, the main Preferences screen appears on the LCD. Using the Preferences screen the following settings can be adjusted or activated:

✔ Quality ✔ File type ✔ Format memory card ✔ Resolution ✔ Quickview ✔ Video out ✔ Template ✔ Date/Time ✔ Language ✔ Date stamp ✔ LCD brightness ✔ About

The Preferences screens, illustrated below, display the current setting of each icon.

Current Setting

Quality Resolution

Template

Date stamp

Preferences

File type Quickview Date/time

LCD brightness

Format memory card

Video out Language

About

4-1

/ /

Chap1newBook Page 2 Friday, February 5, 1999 7:02 AM

Quality

The Quality screen is used to set the picture quality to Best, Better, or Good. See “Quality” on page 2-11 for more information on picture quality.

To set quality:

1 Set the Mode dial to Preferences. 2 Turn the camera on.

The LCD displays the Preferences screen.

3 Press a button until the Quality icon

is highlighted.

4 Press the DO-IT button.

The LCD displays the main Quality screen.

The current setting is checked (

5 Press a button until the appropriate

option is highlighted.

6 Press the DO-IT button.

The main Preferences screen reappears.

To reset: the Quality setting is maintained until another setting is selected. This setting does not change when the camera is turned off.

4-2

/ /

Chap1newBook Page 3 Friday, February 5, 1999 7:02 AM

Resolution

The Resolution screen is used to set the picture resolution to High (1152x864) or Standard (640x480). See “Resolution” on page 2-10 for more information on picture resolution.

To set resolution:

1 Set the Mode dial to Preferences. 2 Turn the camera on.

The LCD displays the Preferences screen.

3 Press a button until the Resolution

icon is highlighted.

4 Press the DO-IT button.

The LCD displays the main Resolution screen. The current setting is checked (

5 Press a button until the appropriate

option is highlighted.

6 Press the DO-IT button.

The main Preferences screen reappears.

Preferences

To reset: the Resolution setting is maintained until another setting is selected. This setting does not change when the camera is turned off.

4-3

/ / /

Chap1newBook Page 4 Friday, February 5, 1999 7:02 AM

Template

The Template screen is used to select a creative border and/or logo that is added to your picture when the picture is captured. Once a picture is captured with the template feature activated, the template cannot be removed. The memory card supplied with your camera comes with some templates already pre-loaded.

☞ For more information on using templates with your DC200/DC210

camera, refer to the readme ﬁle on the DC200/DC210 software CD.

To select a template:

1 Set the Mode dial to Preferences. 2 Turn the camera on.

The LCD displays the Preferences screen.

3 Press a button until the T emplate icon

is highlighted.

4 Press the DO-IT button.

The LCD displays the main Template screen.

The current setting is checked (

5 Press a button until the appropriate

option is highlighted.

6 Press the DO-IT button.

The main Preferences screen reappears.

☞ The template is only visible after the picture has been taken with the

camera in either Review mode, or in Capture mode with Quickview activated. See “Quickvie w” on page 4-7, or chapter 3 “Re view” on page 3-1 for details.

To cancel Template: press a button until OFF is highlighted, and then press the DO-IT button. The Template setting is maintained until another setting is selected. This setting does not change when the camera is turned off.

4-4

/ /

Chap1newBook Page 5 Friday, February 5, 1999 7:02 AM

Date Stamp

The Date Stamp screen is used to record the date on your pictures.

To turn on the Date Stamp:

1 Set the Mode dial to Preferences. 2 Turn the camera on.

The LCD displays the Preferences screen.

3 Press a button until the Date Stamp

icon is highlighted.

4 Press the DO-IT button.

The LCD displays the main Date Stamp screen. The current setting is checked (

5 Press a button until the appropriate

date stamp order is highlighted.

6 Press the DO-IT button.

The main Preferences screen reappears. The next time you take a picture the Date

Stamp will appear in the lower right hand corner of the picture on the LCD screen.

Preferences

☞ The date stamp is only visible after the picture has been taken with the

camera in either Review mode, or in Capture mode with Quickview activated. See “Quickvie w” on page 4-7, or chapter 3, “Revie w” on page 3-1 for details.

To cancel Date Stamp: press a button until OFF is highlighted, and then press the DO-IT button. The Date Stamp setting is maintained until another setting is selected. This setting does not change when the camera is turned off.

4-5

/ /

Chap1newBook Page 6 Friday, February 5, 1999 7:02 AM

File Type

The File Type screen is used to select how the picture ﬁle is saved, in a FlashPix or JPG (default setting) format. Select a format that is compatible with the software you use on your computer.

To set the ﬁle type:

1 Set the Mode dial to Preferences. 2 Turn the camera on.

The LCD displays the Preferences screen.

3 Press a button until the File Type

icon is highlighted on the second Preferences screen.

4 Press the DO-IT button.

The LCD displays the main File Type screen.

The current setting is checked (

5 Press a button until the appropriate

option is highlighted.

6 Press the DO-IT button.

The main Preferences screen reappears.

T o r eset: the File Type setting is maintained until another setting is selected. This setting does not change when the camera is turned off.

4-6

/ / /

Chap1newBook Page 7 Friday, February 5, 1999 7:02 AM

Quickview

The Quickview screen is used to turn the camera’s Quickview setting on or off. When you take a picture with Quickview on, the picture momentarily appears on the LCD seconds after the picture is taken!

☞ The Quickview option must be activated to use the delete feature available

in Capture mode. See “Delete One Picture” on page 2-3 for more details.

To turn on Quickview:

1 Set the Mode dial to Preferences. 2 Turn the camera on.

The LCD displays the Preferences screen.

3 Press a button until the Quickview

icon is highlighted on the second Preferences screen.

4 Press the DO-IT button.

The LCD displays the main Quickview screen.The current setting is checked (

5 Press a button until ON

is highlighted.

Preferences

6 Press the DO-IT button.

The main Preferences screen reappears. The next time you take a picture, it will

appear for a moment on the LCD screen.

To cancel Quickview: press a button until OFF is highlighted and then press the DO-IT button. The Quickview setting is maintained until another setting is selected. This setting does not change when the camera is turned off.

4-7

Chap1newBook Page 8 Friday, February 5, 1999 7:02 AM

Date and Time

The Date and Time screen is used to set the camera’s date and time.

To set the date and time:

1 Set the Mode dial to Preferences. 2 Turn the camera on.

The LCD displays the Preferences screen.

3 Press a button until the Date/Time

icon is highlighted on the second Preferences screen.

4 Press the DO-IT button.

The LCD displays the main Date/Time scr een with the current date and time listed.

5 Press a button to highlight the day,

month, year, hour, or minute setting.

6 Press a button to adjust the setting.

7 Repeat steps 5 and 6 until the information

is correct.

8 Press the DO-IT button.

The main Preferences screen reappears.

T o r eset: the Date and T ime setting is maintained until another setting is selected. This setting does not change when the camera is turned off.

☞ If batteries are removed from the camera for more than a few minutes, the

Date/Time will be deleted and must be reset.

☞ If batteries are removed from the camera when the camera is on, the

Date/Time may be deleted and must be reset.

4-8

/ /

Chap1newBook Page 9 Friday, February 5, 1999 7:02 AM

LCD Brightness

The LCD Brightness screen is used to adjust the brightness of the LCD screen.

To adjust the LCD brightness:

Preferences

1 Set the Mode dial to Preferences. 2 Turn the camera on.

The LCD displays the Preferences screen.

3 Press a button until the LCD

Brightness icon is highlighted on the second Preferences screen.

4 Press the DO-IT button.

The LCD displays the main LCD Brightness screen.

5 Press a button to adjust the

brightness of the LCD screen to the appropriate level.

The brightness of the LCD screen changes as the setting is adjusted.

6 Press the DO-IT button.

The main Preferences screen reappears.

To reset: the LCD Brightness setting is maintained until another setting is selected. This setting does not change when the camera is turned off.

4-9

/ / /

Chap1newBook Page 10 Friday, February 5, 1999 7:02 AM

Format Memory Card

The Format Memory Card screen formats the memory card while it is in the camera. When a memory card is formatted it erases everything, including any templates on the card, and sets up new directories and pointers on the memory card.

To format a memory card:

1 Set the Mode dial to Preferences. 2 Turn on the camera.

The LCD displays the Preferences screen.

3 Press a button until the Format

Memory Card icon is highlighted on the third Preferences screen.

4 Press the DO-IT button.

The LCD displays the main Format Memory Card screen.

5 Press a button until CONTINUE

FORMAT is highlighted.

6 Press the DO-IT button.

The card is formatted and the main Preferences screen reappears.

To cancel format: press a button until CANCEL FORMAT is highlighted and then press the DO-IT button. The card is not formatted and the main Preferences screen reappears.

4-10

/ /

Chap1newBook Page 11 Friday, February 5, 1999 7:02 AM

Video Out

The Video Out screen is used to set the camera’s video output format to NTSC or PAL. The video out format selected depends on your TV or video monitor. In most cases European countries use PAL, other countries use NTSC.

To set the video out format:

1 Set the Mode dial to Preferences. 2 Turn on the camera.

The LCD displays the Preferences screen.

3 Press a button until the Video Out

icon is highlighted on the third Preferences screen.

4 Press the DO-IT button.

The LCD displays the main Video Out screen. The current setting is checked (

5 Press a button until the appropriate

option is highlighted.

6 Press the DO-IT button.

Preferences

The main Preferences screen reappears.

To reset: the Video Out setting is maintained until another setting is selected. This setting does not change when the camera is turned off.

4-11

/ /

Chap1newBook Page 12 Friday, February 5, 1999 7:02 AM

Language

The Language screen is used to select a language interface for the camera. When a speciﬁc language is selected, the LCD screens on the back of the camera will change to reﬂect the language selected.

To select a language:

1 Set the Mode dial to Preferences. 2 Turn the camera on.

The LCD displays the Preferences screen.

3 Press a button until the Language

icon is highlighted on the third Preference screen.

4 Press the DO-IT button.

The LCD displays the main Language screen.

The current setting is checked (

5 Press a button until the appropriate

language is highlighted.

6 Press the DO-IT button.

The main Preferences screen reappears.

To change Language: press a button until another language is highlighted and then press the DO-IT button. The Language setting is maintained until another is selected. This setting does not change when the camera is turned off.

4-12

Chap1newBook Page 13 Friday, February 5, 1999 7:02 AM

About

The About screen is a view only screen that keeps a record of the camera’s use. While viewing the About screen, you can look-up the following information:

✔ ﬁrmware version ✔ total number of pictures taken over the lifetime of the camera ✔ total number of ﬂashes ﬁred over the lifetime of the camera

To view the About screen:

1 Set the Mode dial to Preferences. 2 Turn the camera on.

The LCD displays the Preferences screen.

3 Press a button until the About icon is

highlighted on the third Preferences screen.

4 Press the DO-IT button.

The LCD displays the About screen

5 Press the DO-IT button to return to the main

Preferences screen.

Preferences

4-13

Chap1newBook Page 14 Friday, February 5, 1999 7:02 AM

Chap1newBook Page 1 Friday, February 5, 1999 7:02 AM

Installation

Software

KODAK Installation Software (Installation software) quickly and easily installs the software included on the DC200/DC210 CD to your computer.

WINDOWS System Requirements

✔ WINDOWS 95, WINDOWS 98, or WINDOW NT System Software ✔ Personal computer with 486/66MHz microprocessor minimum,

PENTIUM Processor recommended

✔ 8 MB or more of RAM available, 16 MB recommended ✔ available serial port and CD-ROM drive

Installing the Software

While the Installation software is automatically loading your software, take a few minutes to ﬁll out and send in the DC200/DC210 product registration card. This allows you to receive information regarding software updates and registers some of the products included with the camera.

Close all other applications before starting the Installation software.

1 Place the DC200/DC210 CD into your CD-ROM drive.

☞ If Auto Run is turned on in WINDOWS 95, WINDOWS 98, or

WINDOWS NT, the ﬁrst install window automatically appears. Proceed to step 4. If the ﬁrst install window does not automatically appear proceed to step 2.

2 Choose Run from the Start menu.

Installation

3 Type the path to the drive that contains the CD and then type \setup.exe

For example: d:\setup.exe

5-1

Chap1newBook Page 2 Friday, February 5, 1999 7:02 AM

The install window appears.

4 Select the language you want

to install.

The W elcome window appears.

5 Click on the NEXT button.

6 Read the agreement and click

on the YES button to accept the software license agreement.

☞ If you do not accept the

license you will not be able to install the software.

5-2

7 Select which software you

wish to install and click on the NEXT button.

8 Select the name of the

Program Folder and click on the NEXT button.

☞ If necessary, type a ne w

folder name or select from the Existing Folders list.

Chap1newBook Page 3 Friday, February 5, 1999 7:02 AM

9 Verify the settings and then

click on the NEXT button.

A progress screen appears while the software is installed.

10Select the preferred restart

option and click on the FINISH button.

☞ If you have installed

the KODAK DC200/ DC210 Mounter Software you must restart your computer.

You are now ready to run the newly installed software. Detailed information on KODAK DC200/DC210 Mounter Software (chapter 7) and TWAIN Software (chapter 8) are included in this user manual. Instruction manuals for the additional software packages that were installed are included in the camera package.

When using DC200/DC210 software, if your computer does not recognize that the camera is attached and turned on, you may need to adjust the serial port and speed settings. Use the software’s Preferences or Properties window to adjust the camera communications settings.

Installation

5-3

Chap1newBook Page 4 Friday, February 5, 1999 7:02 AM

Chap1newBook Page 1 Friday, February 5, 1999 7:02 AM

Connect

When the Mode dial is set to Connect, the camera can communicate with your computer using a serial cable or infrared transceiver (DC210 only).

The camera automatically detects if it is attached to the computer via the serial cable or an infrared transceiver. While in Connect mode the camera is controlled by the computer. Except for the Mode dial and POWER button, all other camera buttons are ignored. The Ready light indicates when the camera is on.

Once the camera is connected to a computer and the DC200/DC210 software is installed, you are now ready to transfer the pictures from the camera to your computer. Refer to the appropriate chapters of this user’s guide, or the software’s quick setup guides, for more information on the software programs.

Checking Serial Port Availability

If your computer cannot communicate with the DC200/DC210 you may need to adjust the serial port and speed settings. Adjust the settings using the KODAK Mounter Software (chapter 7) or KODAK TWAIN Software (Chapter 8), or follow the instructions on the Kodak Web site at http://www.kodak.com.

Infrared Connection ÑDC210 Only

The camera can connect to a computer using an infrared transceiver connection.Your computer must be set up with an infrared connection before the camera’s infrared transceiver can be used.

Refer to the instructions included with your computer’s infrared connection package for more details on setting up an infrared transceiver connection. Additional information is available in the README ﬁle on the DC200/DC210 software CD.

☞ If you are using the camera’s infrared transceiver to connect to the

computer, and the camera automatically turns off because of inactivity, you need to press the camera’s POWER button to turn the camera back on.

Connect

6-1

Chap1newBook Page 2 Friday, February 5, 1999 7:02 AM

Serial Cable Connection

The camera can connect to a computer using the serial cable included in your camera package. In order to connect the DC200/DC210, you need to ﬁnd an available serial (COM) port on your PC. Most PCs come conﬁgured with two serial communication ports labeled COM1 and Com2, or A and B. These COM ports are usually labeled on the back of your PC. If they are not labeled, see your computer’s user guide for a diagram that illustrates all your external ports on the back of your PC.

☞ For more information on serial cable connection, refer to “Resolving

COM Port Connectivity problems for IBM-Type PCs, with KODAK Digital Cameras” section in the readme ﬁle on the DC200/DC210 software CD, or click “Service and Support” on the Kodak Web site at http://www.kodak.com.

To connect to your computer with a serial cable:

1 Set the Mode dial to Connect.

2 Plug one end of the serial cable into a COM port

on the back of your PC.

☞ If your computer has a 25-pin port, you need

to use an optional 9-pin adapter (available at your local computer store) and attach it to the port before attaching the serial cable to the computer.

3 Open the serial port on the side of your camera. 4 Plug the other end of the serial cable into the

camera’s serial port.

5 Turn on the camera.

To cancel connection: turn the Mode dial to another setting or turn the camera off.

6-2

Chap1newBook Page 1 Friday, February 5, 1999 7:02 AM

Mounter

KOD AK DC200/DC210 Mounter Software (Mounter software) is an easy w ay to view, transfer, or delete pictures stored on the memory card using your PC and WINDOWS 95, WINDOW 98, or WINDOWS NT software.

Using Mounter software, the DC200/DC210 camera icon appears in the My Computer window, and within ﬁle browsers included in many software applications.

Mounter software extends WINDO WS 95, WINDO WS 98, or WINDO WS NT to present the camera contents as though it were an extension of your hard drive. For more detailed information on working with WINDOWS 95,WINDOWS 98, or WINDOWS NT, refer to that Software’s user guide.

Installation

If you accepted the default installation settings when you installed the software from the DC200/DC210 CD (see Chapter 5 - Installation Software), Mounter software is already installed. If it is not installed, complete the instructions in Chapter 5 and select the Mounter software option.

Software

Camera Communication Settings

If your computer does not recognize that the camera is attached and turned on, you may need to adjust the serial port and speed settings. See “Communication Settings” on page 7- 8 for details or follow the instructions on the Kodak Web site at http://www.kodak.com.

7-1

Mounter

Chap1newBook Page 2 Friday, February 5, 1999 7:02 AM

Overview

Mounter software uses the following icons:

Camera icon—displays the DC200/DC210 camera.

Memory Card icon—displays picture ﬁles stored on the

memory card.

Picture File icon—displays picture ﬁles with FlashPix (FPX) or JPEG (JPG) extensions when appropriate viewing option is selected. If the picture ﬁle has been registered by another application this icon may be different.

Using Mounter Software

Mounter software allows you to open picture ﬁles into a software application, transfer, or delete picture ﬁles and adjust the camera settings. You may not copy picture ﬁles into the memory card using Mounter software. The camera needs to be connected to your computer and turned on to access your picture ﬁles.

When the camera is correctly connected to your computer the camera’s Status Display is replaced with the following screen.

Opening Picture Files

Mounter software allows you to open picture ﬁles into a registered software application. Simply double-click on the Camera icon and then double-click on the Memory Card icon to view the picture ﬁles. Double-click on a picture ﬁle to open it into a registered software application.

Transferring Pictures to your Computer

Mounter software allows you to transfer picture ﬁles from the memory card to a new location on your computer using the drag and drop method.

7-2

Chap1newBook Page 3 Friday, February 5, 1999 7:02 AM

To transfer ﬁles:

1 Double-click on the My Computer icon.

The My Computer window appears.

2 Double-click on the Camera icon.

The Memory Card icon appears.

3 Double-click on the Memory Card icon.

The Memory Card window appears listing individual picture ﬁles.

4 Open the folder that the picture ﬁles

will be dragged into.

5 Click on the picture ﬁle to highlight it

and while holding the mouse button down, drag the picture ﬁle to the new location.

The picture ﬁle appears in the new location.

☞ To select and move multiple

pictures, hold down the Control key and click on additional ﬁles.

To exit Mounter software: select Close from the File menu. The Mounter Camera icon remains in the My Computer folder even when the camera is not accessed.

Mounter

7-3

Chap1newBook Page 4 Friday, February 5, 1999 7:02 AM

Setting and Viewing Properties

Mounter software displays memory card, picture ﬁle, or camera information from the Properties window.

Memory Card Properties

The General Info tab on the Camera Card Memory Properties window displays the current setting for the memory card. You cannot change settings on this window.

☞ You must have a memory card inserted to view the properties window.

To open the Camera Memory Card Properties window:

1 Double-click on the Camera icon in the My Computer window. 2 Click on the Memory Card icon with the right mouse button. 3 Select Properties from the pop-up menu.

The Memory Card Properties window appears and displays:

✔ Resolution setting (High

or Standard)

✔ Quality setting (Good, Better , or

Best)

✔ Remaining number of pictures

that can be stored on the memory card at the current settings

✔ Number of pictures currently

stored on the memory card

To exit: click on the OK or CANCEL button.

7-4

Chap1newBook Page 5 Friday, February 5, 1999 7:02 AM

Picture File Properties

The General Info tab on the Picture File Properties window displays information about the current picture ﬁle. You cannot change any settings on this window.

To open the Picture File Properties window:

1 Double-click on the Camera icon in the My Computer window. 2 Double-click on the Memory Card icon. 3 Click on the Picture File icon with the right mouse button. 4 Select Properties from the pop-up menu.

The Picture File Properties window appears and displays:

✔ Resolution setting (High

or Standard)

✔ Quality setting (Good, Better,

or Best)

✔ Picture size, in bytes ✔ Date and time the picture

was taken

✔ Name of the picture ﬁle

To exit: click on the OK or CANCEL button.

7-5

Mounter

Chap1newBook Page 6 Friday, February 5, 1999 7:02 AM

Camera Properties

The Camera Properties window displays the Camera Settings and Capture tab cards.

Camera Settings Tab

The Camera Settings tab on the Camera Properties window is used to view and change the camera’s current settings, and open to the Communication Settings window.

To adjust the camera settings:

1 Click on the Camera icon with the right mouse button. 2 Select Camera Properties from the pop-up menu.

The Camera Properties window appears with the Camera Setting tab open.

3 Click on the appropriate button to

adjust the following settings:

✔ Quality setting ✔ Flash ✔ Self-Timer ✔ Close Up (DC210 only) ✔ Red-eye Reduction ✔ Resolution

☞ The Battery Level and Memory

Card information cannot be adjusted.

☞ Select the COMMUNICATIONS SETTINGS button to adjust the serial

port and speed. See “Communication Settings” on page 7- 8 for more details.

To exit: click on the OK button to apply the changes and exit the window . To exit the window without making any changes, click on the CANCEL button.

7-6

Chap1newBook Page 7 Friday, February 5, 1999 7:02 AM

Capture

The Capture tab on the Camera Properties window allows you to take a picture, and adjust the exposure and zoom settings, and adjust the ﬁle format while the camera is attached to the computer.

To open the Capture tab:

1 Click on the Camera icon with the right mouse button. 2 Select Camera Properties from the pop-up menu.

The Camera Properties window appears.

3 Click on the Capture tab.

The Capture tab appears.

4 If necessary click on the buttons

to adjust the:

✔ Exposure compensation ✔ Zoom (DC210 only) ✔ File format

5 Click on the TAKE A PICTURE

button to take a picture while the camera is attached to computer.

The picture appears in the Picture View Area.

☞ Select the DELETE SELECTED PICTURES or DELETE ALL PICTURES

button to delete picture ﬁles. See “Delete” on page 7- 9 for more details.

To exit: click on the OK button to apply the changes and exit the window . To exit the window without making any changes, click on the CANCEL button.

Mounter

7-7

Chap1newBook Page 8 Friday, February 5, 1999 7:02 AM

Communication Settings

The Communications Settings window allows you to view and change the serial port and port speed settings while the camera is attached to your computer. See “Camera Communication Settings” on page 7- 1 for more detailed information.

To open the Communication Setting window:

1 Click on the Camera icon with the right mouse button. 2 Select Camera Properties from the pop-up menu.

3 Click on the COMMUNICATIONS

SETTINGS button.

4 If necessary, click on the arrows to

adjust the:

✔ port, if your computer does not

recognize the camera

✔ speed, to optimize picture

transfer time

☞ If your computer is faster than

166 MHz you can click on the ADVANCED button and adjust the serial speed.

☞ If the software does not recognize the camera, continue to adjust the serial

port speed on COM1, and the other COM ports, until it is recognized. Once your computer can communicate with your camera, gradually increase speed to optimize transfer picture time.

To exit: click on the OK button to apply the changes and exit the window.To exit the window without making any changes, click on the CANCEL button.

7-8

Chap1newBook Page 9 Friday, February 5, 1999 7:02 AM

Delete

The Delete window allows you to delete the pictures from the memory card.

To delete a picture:

1 Click on the Camera icon with the right mouse button. 2 Select Camera Properties from the pop-up menu.

3 Click on the Capture tab. 4 Click on the DELETE ALL PICTURES

button to delete all the pictures from the memory card.

☞ You may also delete individual picture ﬁles using the Camera icon. Simply

double-click on the Camera icon, then double-click on the Memory Card icon. Click once on the picture ﬁle that you wish to delete. From the File pulldown menu, select Delete.

To exit: click on the OK button to apply the changes and exit the window.To exit the window without making any changes, click on the CANCEL button.

7-9

Mounter

Chap1newBook Page 10 Friday, February 5, 1999 7:02 AM

Chap1newBook Page 1 Friday, February 5, 1999 7:02 AM

TWAIN

Software

KODAK DC200/DC210 Digital Access TWAIN Acquire Software (TWAIN) for WINDOWS 95, WINDOWS 98, or WINDOWS NT is a special industrystandard interface that allows the DC200/DC210 camera to transfer pictures from your camera directly to your favorite TWAIN-compliant software, such as ADOBE PHOTODELUXE.

Installation

TWAIN

If you accepted the default installation settings when you installed the software from the DC200/DC210 CD (see Chapter 5 - Installation Software), TWAIN software is already installed. If it is not installed, complete the instructions in Chapter 5 and select the TWAIN software option.

Camera Communication Settings

If your computer does not recognize that the camera is attached and turned on, you may need to adjust the serial port and speed settings. See “Preferences Settings” on page 8-5 for details or follow the instructions on the KODAK Web site at http://www.kodak.com.

8-1

Chap1newBook Page 2 Friday, February 5, 1999 7:02 AM

Starting TWAIN Software

1 Connect the DC200/DC210 camera to your computer.

See “Connect” on page 8-1.

2 Open a TWAIN-compliant software (for example,

ADOBE PHOTODELUXE).

3 Pull down the File menu and select TWAIN Source. 4 Select Kodak DC200/DC210 Zoom Acquire TWAIN. 5 Pull down the File menu and select TWAIN Acquire.

The TWAIN software main window appears.

Overview

The following is the main window of TWAIN software. More detailed information is offered in the following sections.

Select appropriate button to retrieve pictures from your camera or computer

Select Tr ansfer to transfer pictures into the software

8-2

Picture viewing area

Select Preferences to change serial port or speed setting

Chap1newBook Page 3 Friday, February 5, 1999 7:02 AM

Transferring Pictures from DC200/DC210

The DC200/DC210 needs to be turned on and connected to your computer to transfer pictures from the camera.

1 Click on the GET PICTURES

FROM CAMERA button.

The Get Camera Pictures window appears.

☞ Select Get Pictures from

Computer to transfer pictures from an existing folder on your computer.

2 Select the picture ﬁle from the File

Selection area.

The picture ﬁle is highlighted. To select multiple ﬁles at one time, hold down the CONTROL or SHIFT key and click on the picture ﬁles.

☞ Check Show Thumbnail to

preview the picture ﬁle.

3 Click on the ADD TO LIST button.

TWAIN

The picture ﬁle is listed in the transfer window.

☞ You may also select:

✔ Remove from List to

remove a picture ﬁle from the transfer list.

✔ Remove All from List to

remove all the picture ﬁles from the transfer list.

4 Click on the OK button.

8-3

Chap1newBook Page 4 Friday, February 5, 1999 7:02 AM

To exit: click on the CLOSE button.

Picture Information

The main TWAIN software window reappears with a thumbnail of your picture.

5 Click on a picture to select it.

☞ To select multiple pictures,

hold down the Control or Shift key and click on the pictures.

6 Click on the TRANSFER button.

The picture is displayed in the previously opened TWAINcompliant software window.

The Picture Information window displays information about the picture and camera settings when the picture was taken. You may not select or change any settings on the window.

To display picture information:

Click on the in the upper left corner of the picture to open the Picture Information window.

The Picture Information window appears and displays:

✔ Name of the picture ﬁle ✔ Quality setting ✔ Resolution setting ✔ Size (in bytes) ✔ File Format ✔ Flash information ✔ Date and time picture was taken ✔ Aperture information ✔ Exposure Time, in seconds ✔ Focal Length

To exit: click on the CLOSE button.

8-4

Chap1newBook Page 5 Friday, February 5, 1999 7:02 AM

Preferences Settings

The Preferences window allows you to change serial port and speed settings. If your computer does not recognize that the camera is attached and turned on,

you may need to adjust the serial port and speed setting.

To change serial port or speed setting:

1 Click on the PREFERENCES button.

The Preferences window appears.

2 If necessary, click on the arrows and

adjust the:

✔ serial port, if your computer does

not recognize the camera

✔ port speed, to optimize picture

transfer time

3 Click on the OK button.

☞ T o reset the values to the default

settings click the RESET button.

TWAIN

☞ If the software does not recognize the camera, continue to adjust the serial

port speed on the appropriate COM port until it is recognized. Once your computer can communicate with your camera, gradually increase speed to optimize transfer picture time.

T o exit: click on the OK b utton. To exit the window without making any changes, click the CANCEL button.

8-5

Chap1newBook Page 6 Friday, February 5, 1999 7:02 AM

Chap1newBook Page 1 Friday, February 5, 1999 7:02 AM

Tips and

Communicating with the Computer

If your computer cannot communicate with the camera you may need to adjust the serial port and speed settings. Adjust the settings using the KODAK Mounter Software (chapter 7) or KODAK TWAIN Software (Chapter 8), or follow the instructions on the Kodak Web site at http://www.kodak.com

Monitor Adjustment

Your monitor display settings may need to be adjusted to view pictures from the camera.

1 Double-click on the My Computer icon. 2 Double-click on the Control Panel icon. 3 Double-click on the Display icon and click on the Settings tab. 4 From the Color Palette ﬁeld, select the highest available setting {256, High

(16-bit), or True (32-bit) color} and click the OK button.

Troubleshooting

9-1

Chap1newBook Page 2 Friday, February 5, 1999 7:02 AM

Printing

You may notice that the colors on your computer screen do not always match those in your documents or prints. This is because monitors and printers use different color systems.

You may be able to achieve more predictable results in your printed documents by:

✔ improving the quality of your paper. Copier paper may not offer the same

results as coated paper or paper made especially for ink jet printers.

✔ adjusting your printer software settings. ✔ using fresh ink cartridges. Do not use ink cartridges beyond their

life expectancy.

Remember these few tips when it comes time to print your document:

✔ color printing takes more time. The more complex your document is

increases the printing and drying time.

✔ color printing is more memory intensive than black and white. If your

computer gives you an insufﬁcient memory message, you may need to close some applications, change some settings, or add additional memory.

✔ color prints may not photocopy as clearly as black and white. If you plan

to photocopy documents, you may consider printing the document in gray scale. This setting is usually changed from the Print menu.

✔ resizing the picture to a smaller size or printing the picture on glossy

paper may increase the quality of the print.

To improve the quality of your prints, you may want to print your pictures on KODAK Inkjet Snapshot Paper (Snapshot Paper). Snapshot Paper is made to work with most inkjet printers to give you clearer, crisper, and more detailed images on your prints.

9-2

Chap1newBook Page 3 Friday, February 5, 1999 7:02 AM

Troubleshooting

If you are experiencing difﬁculties with your camera, check the following table for possible solutions. If the difﬁculties persist, refer to Chapter 11 - Where to

Get Help.

☞ Additional technical information is available in the ReadMe ﬁle located in

the KODAK DC200/DC210 Folder.

Computer Monitor Problem Cause Solution

The image on your monitor is jagged or inappropriately colored.

Memory Card Problem Cause Solution

The DC200/DC210 does not recognize your memory card.

Monitor is not set correctly.

The memory card may not be ATA compatible.

The memory card may contain compression or stacker software.

Adjust your monitor display settings. See “Monitor Adjustment” on page 9-1.

Memory cards must be ATA compatible to work with the camera.

Reformat any memory cards that contain compression or stacker software. Refer to the memory card’s user’s guide or see “Format Memory Card” on page 4-10 for instructions on reformatting the card.

Troubleshooting

9-3

Chap1newBook Page 4 Friday, February 5, 1999 7:02 AM

Windows-DC200/DC210 Camera Communications Problem Cause Solution

Computer cannot communicate with the camera.

Some Advanced Power Management utilities on laptops can turn off ports to save battery life.

Conﬂict with another serial device, such as a modem.

Camera power is off. Turn the camera on. Camera is not

connected to serial cable or cable is not connected to the computer’s COM port.

Infrared port is not responding.

Port settings in software’s AcquirePreferences may be set to the incorrect COM port.

The Mode dial is not set to Connect.

See the Power Management section of your laptop’s user guide to disable this feature.

Refer to the serial communication or corresponding section of your computer’s modem, and/or operating system’s user’s guide.

Connect serial cable to camera and COM port. See “Serial Cable Connection” on page 6-2.

Check the computer’s infrared connection. Be sure that the camera is on.

Change the COM port settings to AutoSearch or to a speciﬁc COM port.

Set the camera’s Mode dial to Connect.

9-4

Chap1newBook Page 5 Friday, February 5, 1999 7:02 AM

DC200/DC210 Camera Problem Cause Solution

Ready light does not turn on and the camera does not work.

Shutter button does not work. Camera is not turned

Camera does not turn on. Batteries are not

Batteries are low or empty.

Camera is not turned on.

on.

Mode dial is not set to Capture.

Ready light is blinking. Camera is processing picture.

The Status Display reads Full. The memory card is full.

Camera is connected to the computer.

properly installed.

Batteries are weak or dead.

Replace the batteries. Pictures remain in the camera’s memory when the battery is removed.

Turn the camera on and verify that the green Ready light turns on.

Set the Mode dial to Capture.

Wait until Ready light stops blinking before attempting to take another picture.

Transfer pictures to your computer or insert a memory card that has available memory.

Disconnect camera from computer.

Remove the batteries and install them according to the directions on the outside of the battery door.

Install new batteries.

Troubleshooting

9-5

Chap1newBook Page 6 Friday, February 5, 1999 7:02 AM

DC200/DC210 Camera Problem Cause Solution

Part of the picture is missing. Something was

blocking the lens when the picture was taken.

Y our e ye or the picture was not centered correctly in the viewﬁnder.

Picture is too dark. Flash is not on or did

not go off. The subject is too far

away for the ﬂash to have an effect.

The subject is in front of a bright light.

Picture is too light. The ﬂash is not

needed.

The subject is too close when the ﬂash was used.

The light sensor is covered.

Stored pictures are damaged. The memory card was

removed when the Ready light was blinking.

Keep hands, ﬁngers, or other objects away from the lens when taking pictures.

Leave space around subject when centering picture in viewﬁnder.

Turn on the ﬂash. See “Flash” on page 2-9.

Move so there is no more than 10 feet (3 m) between the camera and the subject.

Change your position so the light is not behind the subject.

Change to automatic ﬂash. See“Flash” on page 2-9.

Move so there is at least 1.6 ft. (0.5 m) between the camera and the subject.

Hold the camera so your hands or other objects do not cover the light sensor.

Make sure the Ready light is not blinking before removing the memory card.

9-6

Chap1newBook Page 7 Friday, February 5, 1999 7:02 AM

DC200/DC210 Camera Problem Cause Solution

Pictures remaining number does not decrease.

Picture is not clear. The lens is dirty. Clean the lens. See

LCD Messages Message Cause Solution

Memory Card is Full. Memory card is full

The image resolution does not take up sufﬁcient space to decrease the picture remaining number.

Subject too close when taking picture

Subject or the camera moved while the picture was taken.

The subject is too far away for the ﬂash to be effective.

and cannot hold additional pictures

The camera is operating normally. Continue taking pictures.

“General Maintenance and Safety” on page 2-

15. Stand at least 2.23 ft.

(.68m) with DC200; at least 8 in. (20 cm.) in close-up, 3.28 ft. (1m) in telephoto, 1.64 ft. (0.5 m) with DC210.

Hold camera steady until the picture is taken.

Move so the subject is less than 10 ft. (3 m) away.

Transfer pictures to your computer or insert a memory card that has available memory.

Troubleshooting

9-7

Chap1newBook Page 8 Friday, February 5, 1999 7:02 AM

LCD Messages Message Cause Solution

No Memory Card. There is no memory

card inserted in the camera.

Cannot read memory card. Memory card is

corrupted.

Cannot establish connection. The camera cannot

communicate with the computer.

Camera needs service. The camera is

malfunctioning.

Insert a memory card into the camera.

Insert a new or reformat the memory card.

Change the COM port settings to AutoSearch or to a speciﬁc COM port. See “Serial Cable Connection” on page 6-2.

Have the camera serviced.

9-8

Chap1newBook Page 1 Friday, February 5, 1999 7:02 AM

Where to

Help with your DC200/DC210 is available from a number of resources.

Get Help

✔ in Tips and Troubleshooting,

Chapter 9

✔ the software’s manufacturer ✔ W orld Wide Web ✔ product information by fax ✔ technical support

Software Help

Help with any software packaged with your DC200/DC210 can be obtained from the software instructions, the software’s help screens, or by contacting the manufacturer of that product.

Online Services

Contact Kodak via:

W orld Wide Web—http://www.k odak.com America Online—(keyword) KODAK CompuServe—GO KODAK Kodak Internet listserver—photo-cd@info.kodak.com; or ftp.kodak.com

Faxed Information

Kodak offers automated support for digital imaging products and services. Product information can be faxed to you by calling:

✔ your place of purchase

Help

U.S.—1-800-295-5531 Canada—1-800-295-5531 Europe—44-131-458-6962 U.K.—44-0-131-458-6962

10-1

Chap1newBook Page 2 Friday, February 5, 1999 7:02 AM

Customer Support

If you have questions concerning the operation of K odak software, or the DC200/ DC210, you may speak directly to a customer support representative. Have the camera connected to your computer, its serial number ready, and be at your computer when you call.

U.S. and Canada—call toll free, 1-888-395-6325, between the hours of 9:00 a.m. and 8:00 p.m. (Eastern Standard Time) Monday through Friday.

Europe—call the Kodak Digital Imaging Support Centre toll free number associated with your location, or the U.K. toll line, 44-131-458-6714, between the hours of 09.00 and 17.00 (GMT/CET) Monday through Friday.

Outside the U.S., Canada, and Eur ope—call the number on the follo wing pages that is associated with your location.

Country Help number Fax

Argentina 54-1-808-300 54-1-808-3328 Australia 1-800-674-831 61-3-9353-2488 Austria 0-660-7348 44-131-458-6962 Belgium 0800-72247 44-131-458-6962 Brazil 0-800-15-0000 55-12-331-8571 Caribbean 78-7-757-5500 78-7-757-8760 Chile 56-2-697-2000 56-2-697-0310 China–Shanghai 8621-64720888 8621-64726582 China–Beijing 8610-63471155 8610-63475641 Colombia 57-1-629-0266 57-1-629-0673 Denmark 80-01-09-24 44-131-458-6962 Dominican Republic 809-563-1252 809-563-1264 Egypt 20-2-394-2205 20-2-393-1119 France 0800-90-6281 44-131-458-6962 Finland 0800-117056 44-131-458-6962 Germany 0130-82-54-02 44-131-458-6962 Greece 00800-44125605 44-131-458-6962 Hong Kong 852-2564-9777 852-2564-9753

10-2

Chap1newBook Page 3 Friday, February 5, 1999 7:02 AM

Country Help number Fax

Hungary 36-1-269-71-17 36-1-269-71-13 India 91-22-617-5823 91-22-617-6004 Ireland 1-800-409391 44-131-458-6962 Italy 1678-72-996 44-131-458-6962 Japan 81-3-5488-2390 81-3-5488-4512 Korea 82-2-708-5400 82-2-708-5500 Latin America 1-305-267-4700 1-305-267-4780 Lebanon 961-1-883822 961-1-881726 Malaysia 60-3-757-2722 60-3-755-5919 Mexico 52-5-449-4300 52-5-449-4400 Middle East 971-4-444-910 971-4-447-059 Netherlands 06-0224428 44-131-458-6962 New Zealand 0800-500-135 64-9-302-8637 Norway 800-1-1848 44-131-458-6962 Panama 52-3-678-6200 52-3-678-6210 Peru 51-1-224-8610 51-1-224-8605 Philippines 63-2-810-0331 63-2-816-6718 Portugal 351-1-4149-500 351-14194-321 Russia 7-095-929-9166 7-095-929-9170 Singapore 65-470-9875 65-479-8397 South Africa 27-11-804-2852 27-11-804-5013 Spain 900-98-4485 44-131-458-6962 Sweden 020-793169 44-131-458-6962 Switzerland 0800-551034 44-131-458-6962 T aiwan 886-2-893-8210 886-2-895-1069 Thailand 66-2-271-3040 66-2-279-5073 Turke y 90-216-342-3332 90-216-343-6743 U.K. 0800-281487 44-131-458-6962 Uruguay 59-2-92-0473 59-2-92-1796 V enezuela 58-2-903-1111 58-2-943-2081

Help

10-3

Chap1newBook Page 4 Friday, February 5, 1999 7:02 AM

Chap1newBook Page 1 Friday, February 5, 1999 7:02 AM

Warranty & Regulatory Information

Warranty Time Period

Kodak warrants the KODAK DC200 plus Camera and KODAK DC210 Plus Zoom camera (excluding the batteries) to be free from malfunctions and defects in both materials and workmanship for one year from the date of purchase.

Warranty Repair Coverage

This warranty will be honored within the geographical location that the product was purchased.

If the equipment does not function properly during the warranty period due to defects in either materials or workmanship, Kodak will, at its option, either repair or replace the equipment without charge, subject to the conditions and limitations stated herein. Such repair service will include all labor as well as any necessary adjustments and/or replacement parts.

Warranty

If replacement parts are used in making repairs, these parts may be remanufactured, or may contain remanufactured materials. If it is necessary to replace the entire system, it may be replaced with a remanufactured system.

Kodak will also provide telephone assistance during the warranty period.

Warranty-1

Chap1newBook Page 2 Friday, February 5, 1999 7:02 AM

Limitations

WARRANTY SERVICE WILL NOT BE PROVIDED WITHOUT DATED PROOF OF PURCHASE. PLEASE RETURN THE WARRANTY REGISTRATION CARD WITHIN 30 DAYS OF PURCHASE.

THIS WARRANTY BECOMES NULL AND VOID IF YOU FAIL TO PACK YOUR DC200/DC210 CAMERA IN A MANNER CONSISTENT WITH THE ORIGINAL PRODUCT PACKAGING AND DAMAGE OCCURS DURING PRODUCT SHIPMENT.

THIS WARRANTY DOES NOT COVER: CIRCUMSTANCES BEYOND KODAK'S CONTROL; SERVICE OR PARTS TO CORRECT PROBLEMS RESULTING FROM THE USE OF ATTACHMENTS, ACCESSORIES OR ALTERATIONS NOT MARKETED BY KODAK; SERVICE REQUIRED AS THE RESULT OF UNAUTHORIZED MODIFICATIONS OR SERVICE; MISUSE, ABUSE; FAILURE TO FOLLOW KODAK'S OPERATING, MAINTENANCE OR REPACKAGING INSTRUCTIONS; OR FAILURE TO USE ITEMS SUPPLIED BY KOD AK (SUCH AS AD APTERS AND CABLES).

KODAK MAKES NO OTHER WARRANTIES, EXPRESS, IMPLIED, OR OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE FOR THIS EQUIPMENT OR SOFTWARE.

REPAIR OR REPLACEMENT WITHOUT CHARGE ARE KODAK'S ONLY OBLIGATION UNDER THIS WARRANTY. KODAK WILL NOT BE RESPONSIBLE FOR ANY SPECIAL, CONSEQUENTIAL OR INCIDENTAL DAMAGES RESULTING FROM THE PURCHASE, USE, OR IMPROPER FUNCTIONING OF THIS EQUIPMENT REGARDLESS OF THE CAUSE. SUCH DAMAGES FOR WHICH KODAK WILL NOT BE RESPONSIBLE INCLUDE, BUT ARE NOT LIMITED TO, LOSS OF REVENUE OR PROFIT, DOWNTIME COSTS, LOSS OF USE OF THE EQUIPMENT, COST OF ANY SUBSTITUTE EQUIPMENT, FACILITIES OR SERVICES, OR CLAIMS OF YOUR CUSTOMERS FOR SUCH DAMAGES.

Depending on your geographical location, some limitations and exclusions may not apply.

Warranty-2

Chap1newBook Page 3 Friday, February 5, 1999 7:02 AM

Application Support

For application speciﬁc support, contact your reseller, systems integrator, software manufacturer, or dealer.

How to Obtain Service

Visit us on the Internet at http://www.kodak.com Please refer to the Service and Support section of your user’s guide for the

support hotline designated to your location. When returning a DC200/DC210 camera for repair, the unit shall be packed in its

original packing materials. A problem report should also be enclosed with the equipment. If the original packaging has been discarded or is not available, packing will be at the owner's expense.

Unless a speciﬁc Kodak warranty is communicated to the purchaser in writing by a Kodak company, no other warranty or liability exists beyond the information contained above, even though defect, damage or loss may be caused by negligence or other act.

Warranty

To obtain warranty repair service contact your local Kodak representative. For assistance, refer to the Service and Support information in the KODAK DC200/ DC210 Camera User’s Guide.

Warranty-3

Chap1newBook Page 4 Friday, February 5, 1999 7:02 AM

Regulatory Information

FCC Compliance and Advisory

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:1) this device may not cause harmful interference, and

2) this device must accept any interference received, including interference that may cause undesired operation.

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.

This equipment generates, uses, and can radiate radio frequency energy and, if not installed or used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation.

If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: 1) reorient or relocate the receiving antenna; 2) increase the separation between the equipment and the receiver; 3) connect the equipment to an outlet on a circuit different from that to which the receiver is connected; 4) consult the dealer or an experienced radio/TV technician for additional suggestions.

Any changes or modiﬁcations not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. Where shielded interface cables have been provided with the product or speciﬁed additional components or accessories elsewhere deﬁned to be used with the installation of the product, they must be used in order to ensure compliance with FCC regulation.

Canadian DOC Statement

DOC Class B Compliance—This digital apparatus does not exceed the Class B limits for radio noise emissions from digital apparatus set out in the radio interference regulations of the Canadian Department of Communications.

Obervation des normes-Class B—Le présent appareil numérique n’émet pas de bruits radioélectriques dépassant les limites applicables aux appareils numériques de la Classe B prescrites dans les règlements sur le brouillage redioélectrique édictés par le Ministère des Communications du Canada.

Warranty-4

Chap1newBook Page 1 Friday, February 5, 1999 7:02 AM

Index

About, Viewing the 4-13 Adjusting Camera Settings Using

Mounter Software 7-6

Adjusting Port and Port Speed

Using TWAIN Software 8-5 With Camera Attached to the

Computer

Adjusting the Exposure 2-4 Auto Flash 2-9 Auto Red-Eye Flash 2-9

7-8

Batteries

Installing Types of 2-12

2-12

Camera

Connecting to a Computer 6-1 Getting Help or Information 10-1,

10-2

Modes 1-1 Mounter Software 7-1, 7-2, 7-4,

7-5, 7-6, 7-7, 7-8, 7-9 Package Contents 1-2 Parts 1-3, 1-4 Power 2-1 Properties 7-6 Specifications 1-2 Troubleshooting 9-1, 9-2, 9-3, 9-

4, 9-5, 9-6, 9-7, 9-8

Turning On and Off TWAIN Software

8-4, 8-5

Camera Parts

Back 1-4 Bottom 1-4 Front 1-3 Side 1-4 Top 1-3

Camera Settings

Adjusting Using Mounter

Software 7-6 Date and Time 4-8 File Type 4-6 LCD Screen Brightness 4-9 Picture Quality 4-2 Resolution 4-3 Video Output Format 4-11

Camera Settings, Changing

Activating and Stopping the Self-

Timer 2-7 Selecting the Flash Setting 2-9 Selecting the Resolution 2-10 Turning Close Up On and Off 2-8 Zooming 2-14

Capture Mode 2-1 Capturing an Image See Taking a


Close Up Setting 2-8 CompactFlash 2-8 Computer Monitor Problems 9-3 Connect Mode 6-1 Connecting the Camera to a TV 3-4 Connecting to a Computer

Using a Serial Cable 6-2

2-1

8-1, 8-2, 8-3,

INDEX

Index-1

Chap1newBook Page 2 Friday, February 5, 1999 7:02 AM

Using an Infrared Sensor 6-1

Dark Pictures 2-4 Date Stamp, Setting the 4-5 Date, Setting the 4-8 DC200/DC210

Connecting to a Computer 6-1, 6-

Getting Help or Information 10-1,

10-2

Installing Software 5-1, 5-2, 5-3 Mounter Software 7-1, 7-2, 7-4,

7-5, 7-6, 7-7, 7-8, 7-9 Package Contents 1-2 Parts 1-3, 1-4 Power 2-1 Properties 7-6 Specifications Troubleshooting 9-1, 9-2, 9-3, 9-

Turning On and Off 2-1 TWAIN Software 8-1, 8-2, 8-3,

Delete Icon 3-1 Deleting a Picture

Deleting a Picture From the

Deleting a Picture Using Mounter

Deleting All Pictures From the

Deleting all Pictures Using Deleting the Current Picture 2-3

Deleting a Picture in Capture Mode 2-

1-2

4, 9-5, 9-6, 9-7, 9-8

8-4

Memory Card 3-2

Software 7-9

Memory Card 3-2

Mounter Software 7-9

Error Messages 9-7, 9-8 Exposure

Adjusting With Camera Attached

to the Computer 7-7

Compensating for Dark or Light

Pictures 2-4

Locking the exposure setting 2-5 Exposure Compensation Icon 2-2 Exposure Lock Icon 2-2

File

Properties 7-5

Type 4-6 Files

Opening 7-2

Transferring to a Computer 7-2 Fill Flash 2-9 Fill Red-Eye Flash 2-9 Filmstrip Display 3-1 Flash Settings 2-9 FlashPix File Format 4-6 Formatting the Memory Card 4-10 Full Memory Card

2-6

Help, Getting 10-1, 10-2

Information

Getting 10-1

Regulatory warranty4 Infrared Sensor 6-1 Inserting a Memory Card 2-7 Installing Batteries 2-12 Installing Software 5-1, 5-2, 5-3

Requirements for 5-1

Index-2

Chap1newBook Page 3 Friday, February 5, 1999 7:02 AM

JPEG File Format 4-6

Kodak

Contacting 10-1 Getting Help From 10-2

Language, Setting the 4-12 Launching TWAIN Software 8-2 LCD Messages 9-7, 9-8 LCD Screen Brightness 4-9 Light Pictures 2-4

Magnify Icon 3-1 Magnifying a picture in Review Mode

3-1

Memory Bar Display 3-1 Memory Card

CompactFlash logo 2-8 Deleting a Picture From Using

Mounter Software 7-9 Deleting Pictures From 3-2 Formatting 4-10 Full 2-6 Inserting and Removing 2-7 Problems 9-3 Properties 7-4 Viewing Available Memory 3-1 Viewing Pictures On 3-1

Memory Card Icon 2-7 Modes

Capture 2-1 Connect 6-1 Preferences 4-1 Review 3-1

Monitor Problems 9-3 Monitor Settings 9-1 Mounter Software 7-1, 7-2, 7-4, 7-5,

7-6, 7-7, 7-8, 7-9

NTSC Format 4-11

Overlay Screen 3-1

Package Contents 1-2 PAL Format 4-11 Parts of the Camera 1-3, 1-4 Picture File

Properties 7-5

Picture Files

Opening 7-2 Transferring to a Computer 7-2

Picture Quality 2-11

Setting 4-2

Picture Resolution See Resolution Picture Taking See Taking a Picture Pictures Remaining 2-6 Port and Port Speed

Adjusting Using TWAIN

Software 8-5

Adjusting With Camera Attached

to the Computer 7-8

Preferences Mode 4-1 Preview Display

Exposure Compensation Icon Exposure Lock Icon 2-2 Template Icon 2-2

Previewing the Image Before Taking

the Picture 2-2

Previewing the Picture Just After

Taking It 4-7

2-2

INDEX

Index-3

Chap1newBook Page 4 Friday, February 5, 1999 7:02 AM

Printing

Screen and Print Colors Do Not

Match 9-2

Tips 9-2

Problems See Troubleshooting

Quality See Picture Quality Quickview Option 4-7

Regulatory Information warranty4 Removing a Memory Card 2-7 Requirements for Installing Software

5-1

Requirements, System 5-1 Resolution 2-10

Setting 4-3

Review Display

Delete Icon 3-1 Filmstrip Icon 3-1 Magnify Icon 3-1 Memory Bar 3-1 Overlay Icon 3-1

Review Mode 3-1

Screen Brightness 4-9 Self-Timer 2-7 Serial Connection 6-2 Serial Port

Checking Availability 6-1

Serial Port and Port Speed

Adjusting Using TWAIN

Software

Adjusting With Camera Attached

to the Computer 7-8

Service Agreement 2-15 Settings See Camera Settings

8-5

Slide Show Software

Specifications 1-2 Starting TWAIN Software 8-2 Status Display

System Requirements 5-1

3-4

Installing 5-1, 5-2, 5-3 Mounter 7-1, 7-2, 7-4, 7-5, 7-6,

7-7, 7-8, 7-9 Requirements for Installing 5-1 TWAIN 8-1, 8-2, 8-3, 8-4, 8-5

Battery Icon 2-12 Close Up Icon Flash Icon 2-9 Memory Card Icon 2-7 Picture Quality Icon 2-11 Pictures Remaining Icon 2-6 Resolution Icon 2-10 Self-Timer Icon 2-7

2-8

Taking a Picture 2-2

Adjusting the Exposure 2-4 Deleting the Current Picture 2-3 Previewing the Image Before

Taking the Picture 2-2 Previewing the Picture Just After

Taking It 4-7 Selecting the Flash Setting 2-9 Selecting the Resolution 2-10 Setting the Self-Timer 2-7 Using the Close Up Setting 2-8 With Camera Attached to the

Computer 7-7 Zooming 2-14

Template, Setting the 4-4 Time

Setting 4-8

Tips

Adjusting Monitor Settings 9-1 Printing 9-2

Index-4

Chap1newBook Page 5 Friday, February 5, 1999 7:02 AM

Transferring Picture Files to a

Computer 7-2

Transferring Pictures Using TWAIN

Software 8-3, 8-4

Troubleshooting 9-1

DC200/DC210 Problems 9-5, 9-

6, 9-7 LCD Messages 9-7, 9-8 Memory Card Problems 9-3 Monitor Problems 9-3 Screen and Print Colors Do Not

9-2

Match The Camera and Computer

Cannot Communicate 9-

1 Windows-DC200/DC210

Communication

Problems 9-3, 9-4

Turning the Camera On and Off 2-1 TWAIN Software 8-1

Adjusting Port and Port Speed 8-5 Starting 8-2 Transferring Pictures 8-3, 8-4 Viewing Picture Information 8-4

warranty3

Repair Coverage warranty1 Service Agreements 2-15

Time Period warranty1 What Comes With the Camera? 1-2 Windows System Requirements 5-1 Windows-DC200/DC210

Communication Problems 93, 9-4

Zooming 2-14

With Camera Attached to the

Computer 7-7

Video Ouput Format 4-11 Viewing a Slide Show on TV 3-4 Viewing Picture Information Using

TWAIN Software 8-4

Viewing Pictures on the Memory Card

3-1

Viewing Pictures on TV 3-4 Viewing the About Screen 4-13 Viewing the Available Memory 3-1

Warranty

Limitations warranty2 Obtaining Repair Service

Kodak DC200 Plus, DC210 Plus Zoom User Guide

Specifications and Main Features

Frequently Asked Questions

User Manual
