For Customer Use:
Enter below the Model No. and Serial
No. which are located either on the rear,
bottom or side of the cabinet. Retain this
information for future reference.
Model No.
Serial No.
AUDIO/VIDEO CONTROL RECEIVER
RX-554VBK
POWER
AUDIO
TV VCR
CD
3D-PHONIC
SURROUND
DAP MODE
TAPE
123
EFFECT DELAY
TEST
TUNER/
BAND
456
SEA MODE
REAR
–+
VCR
7/P 8 9
CENTER
–+
SEA
VIDEO
10
+10
PRESET
SOUND
ONE TOUCH
PHONO
CONTROL
OPERATION
CD-DISC
TV CH
VCR CH
–+
–+
TV VOL.
–+
TV/
VIDEO
VOLUME
–+
MUTING
RM-SR554U REMOTE CONTROL
STANDBY
POWER
RX-554V AUDIO/VIDEO CONTROL RECEIVER
PHONES SPEAKERS
12
_ON —OFF
MASTER VOLUME
–+
TUNER/BAND PRESET SEA SOURCE SURROUND ADJUST
MEMORY
INSTRUCTIONS
SETTING
ONE TOUCH OPERATION
LET0117-001B
[J]
Warnings, Cautions and Others
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK.
DO NOT REMOVE COVER (OR BACK)
NO USER SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
The lightning flash with arrowhead symbol,
within an equilateral triangle is intended to
alert the user to the presence of uninsulated
"dangerous voltage" within the product's
enclosure that may be of sufficient
magnitude to constitute a risk of electric
shock to persons.
The exclamation point within an equilateral
triangle is intended to alert the user to the
presence of important operating and
maintenance (servicing) instructions in the
literature accompanying the appliance.
WARNING: TO REDUCE THE RISK OF FIRE
OR ELECTRIC SHOCK, DO NOT EXPOSE
THIS APPLIANCE TO RAIN OR MOISTURE.
CAUTION
To reduce the risk of electrical shocks, fire, etc.:
1. Do not remove screws, covers or cabinet.
2. Do not expose this appliance to rain or moisture.
Caution –– POWER switch!
Disconnect the mains plug to shut the power off completely. The
POWER switch in any position does not disconnect the mains line.
The power can be remote controlled.
G-1
Once you have found the best DAP, 3D-PHONIC and Surround mode settings for your listening
room, note them in the table below for future reference (even though the receiver memorizes the
settings until you change them).
For actual setting procedures, see pages 22 to 32.
DAP Mode Dance Club Live Club Hall Pavilion Headphones
Rear Speaker Level*
Effect Level
3D-PHONIC Mode 3D Action 3D Drama 3D Theater
Effect Level
Surround Mode Dolby Pro Logic Dolby 3ch Logic Theater Surround
Center Mode
Delay Time
Center Speaker Level
Rear Speaker Level*
Effect Level
* The left rear speaker level and right rear speaker level for DAP and the surround modes cannot be stored separately.
G-2
Table of Contents
Parts Identification...................................................................................... 2
Easy Set Up & Operations ............................................................................ 3
Getting Started........................................................................................... 5
Before Installation...................................................................................................................................................................5
Checking the Supplied Accessories ........................................................................................................................................ 5
Connecting the FM and AM Antennas ................................................................................................................................... 6
Connecting the Speakers.........................................................................................................................................................7
Connecting Audio/Video Components ................................................................................................................................... 8
Connecting the Power Cord .................................................................................................................................................. 10
Putting Batteries in the Remote Control ............................................................................................................................... 10
Basic Operations ....................................................................................... 11
Turning the Power On and Off ............................................................................................................................................. 11
Selecting the Source to Play ................................................................................................................................................. 11
Adjusting the Volume ........................................................................................................................................................... 12
Selecting the Front Speakers.................................................................................................................................................12
Muting the Sound..................................................................................................................................................................12
Recording a Source ............................................................................................................................................................... 13
Listening with Headphones .................................................................................................................................................. 13
Basic Settings........................................................................................... 14
Adjusting the Front Speaker Output Balance ....................................................................................................................... 14
Listening at Low Volume (Loudness) ................................................................................................................................... 14
Using the Sleep Timer........................................................................................................................................................... 14
Selecting the Center Speaker Size ........................................................................................................................................ 15
One Touch Operation .................................................................................. 16
About the One Touch Operation ...........................................................................................................................................16
Using the One Touch Operation ........................................................................................................................................... 16
Receiving Radio Broadcasts ........................................................................ 17
Tuning in Stations Manually................................................................................................................................................. 17
Using Preset Tuning.............................................................................................................................................................. 17
Selecting the FM Reception Mode ....................................................................................................................................... 19
Using the Preset SEA Modes...................................................................... 20
Selecting Your Favorite SEA Mode...................................................................................................................................... 20
Activating the Surround Sounds ................................................................. 22
Using JVC 3D-PHONIC Modes........................................................................................................................................... 23
Using the DAP Modes ..........................................................................................................................................................25
Speaker Arrangements for Surround Modes ......................................................................................................................... 27
Preparing for Surround Modes ............................................................................................................................................. 28
Using Surround Modes .........................................................................................................................................................32
COMPU LINK Remote Control System ......................................................... 33
Operating Other Components ..................................................................... 34
Troubleshooting......................................................................................... 36
Specifications............................................................................................ 37
1
Parts Identification
Become familiar with the buttons and controls on the receiver before use.
#
$
%
^
&
*
1
POWER
-
CD
DAP MODE
TAPE
EFFECT DELAY
TUNER/
BAND
SEA MODE
VCR
VIDEO
PRESET
PHONO
CONTROL
TV CH
TV VOL.
–+
TV/
VIDEO
RX-554V AUDIO/VIDEO CONTROL RECEIVER
STANDBY
POWER
TV VCR AUDIO
3D-PHONIC
SURROUND
123
456
7/P 8 9
SEA
SOUND
+–
–+
RM-SR554U REMOTE CONTROL
TEST
REAR
–+
CENTER
–+
10 +10
ONE TOUCH
OPERATION
CD-DISC
VCR CH
–+
VOLUME
MUTING
23
MASTER VOLUME
–+
PHONES SPEAKERS
12
_ON —OFF
4
67
5
TUNER/BAND PRESET SEA SOURCE SURROUND ADJUST
MEMORY
=~ !
Refer to the pages in parentheses for details.
(
)
_
+
¡
™
£
¢
Front Panel
1
Remote sensor (10)
2
Display (11)
3
MASTER VOLUME control (12)
4
MEMORY button (17)
5
TUNER/BAND button and lamp (17)
6
PRESET SEA button and lamp (20)
7
SOURCE button and lamp (11)
8
SURROUND button and lamp (23, 25,
28)
9
0
-
=
~
!
@
Remote Control
#
Source buttons (CD, TAPE, TUNER/
BAND, VCR, VIDEO, PHONO)
(11, 34, 35)
$
SOUND CONTROL button (21, 24,
26, 30, 32)
To use JVC VCR, cassette deck and
CD player after adjusting preset SEA
or surround modes using SOUND
CONTROL, press the corresponding
source button (VCR, TAPE or CD)
prior to using JVC audio/video
operating buttons (£).
%
TV CH (Channel) buttons (+/–) (35)
^
TV VOL. (Volume) buttons (+/–) (35)
&
*
(
)
_
+
¡
™
VCR CH (Channel) buttons (+/–) (35)
£
¢
9
8
0
SETTING
ONE TOUCH OPERATION
@
ADJUST button and lamp (23, 25, 28)
SETTING button and lamp (14, 15)
POWER button and STANDBY lamp
(11)
PHONES jack (13)
SPEAKERS 1/2 buttons (12, 13)
Control % / fi / @ / # buttons
ONE TOUCH OPERATION button and
lamp (16)
TV/VIDEO buttton (35)
VOLUME buttons (+/–) (12)
POWER buttons (TV, VCR, AUDIO)
(11, 35)
10 keys/Audio control buttons
(18, 21, 24, 26, 30, 32, 34)
SEA PRESET button (21)
ONE TOUCH OPERATION button (16)
CD-DISC button (34)
Operating buttons for JVC audio/video
components (34, 35)
MUTING button (12)
2
Easy Set Up & Operations
If you are already familiar with audio components, these two pages just you opened give you enough
information to operate your RX-554VBK for enjoyment of surround sound in your listening room.
TV
To video input
Rear Speaker
Front
Speaker
Front
Speaker
Center Speaker
MASTER VOLUME
RX-554V AUDIO/VIDEO CONTROL RECEIVER
STANDBY
PHONES SPEAKERS
POWER
Speaker Signal Cable
ANTENNA
FM
75
FM
GND
GND
AM
LOOP
PHONO
AM
EXT
L
R
TAPE/VCR
CD TAPE
OUT
(REC)
VIDEOVIDEO
OUT
(REC)
VIDEO
IN
OUT
(PLAY)
(REC)
MONITOR
COMPU LINK-3
OUT
(SYNCHRO)
IN
(PLAY)
VCR
IN
AUDIO
LEFT
RIGHT
SUBWOOFER
OUT
CENTER
SPEAKER
(PLAY)
TUNER/BAND PRESET SEA SOURCE SURROUND ADJUST
–+
12
_ON —OFF
SETTING
MEMORY
ONE TOUCH OPERATION
Speaker Signal Cable
Speaker Signal Cable
FRONT SPEAKERS
RIGHT LEFT
–
+
–
1
2
RIGHT LEFT
++
––
+
+
–
–
+
REAR
SPEAKERS
Subwoofer
1
2
Rear Speaker
RX-554VBK
3
Speaker Signal
Cable
To audio/video input
ANTENNA
IN OUT
To RF output
If your TV does not have a video input
VCR
OUT
IN
VIDEO
AUDIO
L
AUDIO
R
To TV antenna
input
Speaker Signal
Cable
To audio/video output
TV
RX-554V AUDIO/VIDEO CONTROL RECEIVER
CT
PE
Y
P
MO
MASTER VOLUME
–+
TUNER/BAND PRESET SEA SOURCE SURROUND ADJUST
MEMORY
SETTING
ONE TOUCH OPERATION
2
. Select the source.
AUDIO
POWER
VCR
3
TV
2
TEST
VIDEO
1
EFFECT
PHONO
4
SEA MODE
7/P
PRESET
SEA
TV CH
DELAY
VIDEO
SOUND
CONTROL
TV/
5
TV VOL
6
9
REAR
8
CENTER
10
CD-DISC
+10
ONE TOUCH
OPERATION
VCR CH
VOLUME MUTING
RM-SR554U REMOTE CONTROL
CD
DAP MODE 3D-PHONIC SURROUND
TAPE
TUNER/
BAND
VCR
VCR
STANDBY
POWER
PHONES SPEAKERS
12
_ON —OFF
TV
CD
1
DAP MODE 3D-PHONIC SURROUND
TAPE
EFFECT
TUNER/
BAND
VCR
VIDEO
PHONO
POWER
VCR
4
SEA MODE
7/P
SEA
PRESET
2
DELAY
SOUND
CONTROL
TV CH
TV VOL.
TV/
VIDEO
AUDIO
5
8
3
TEST
REAR
CENTER
10
CD-DISC
6
9
+10
ONE TOUCH
OPERATION
VCR CH
VOLUME MUTING
RM-SR554U REMOTE CONTROL
1
. Turn on the power.
AUDIO
AUDIO
POWER
VCR
3
TV
2
TEST
VIDEO
SEA
TV CH
1
EFFECT
PHONO
SOUND
CONTROL
TV/
VIDEO
4
SEA MODE
TV VOL
7/P
PRESET
8
SEA
DELAY
5
REAR
8
CENTER
10
CD-DISC
SOUND
CONTROL
TV CH
TV VOL
TV/
VIDEO
9
REAR
+10
CENTER
10
ONE TOUCH
OPERATION
CD-DISC
VCR CH
VOLUME MUTING
VOLUME
RM-SR554U REMOTE CONTROL
6
9
+10
ONE TOUCH
OPERATION
VCR CH
VOLUME MUTING
-SR554U REMOTE CONTROL
CD
DAP MODE 3D-PHONIC SURROUND
TAPE
TUNER/
BAND
VCR
3
. Adjust the volume.
TA
EFFE
4
TUNER/
BAND
SEA MODE
7/P
VCR
PRESET
VIDEO
PHONO
5.
4
. Set the remote control
to sound operation
mode.
1
DA
DELA
5
4
SEA MODE
7/P
SEA
PRESET
SOUND
CONTROL
TV CH
SOUND
CONTROL
TV/
VIDEO
8
TV VOL
9
REAR
+10
CENTER
10
ONE TOUCH
OPERATION
CD-DISC
VCR CH
VOLUME MUTING
RM-SR554U REMOTE CONTROL
TAPE
EFFECT
TUNER/
BAND
VCR
VIDEO
PHONO
Surround and preset
SEA settings are
preset at the factory.
However, if you need
to make further
adjustments, see pages
20 to 32.
TV
CD
1
DAP MODE 3D-PHONIC SURROUND
TAPE
EFFECT
TUNER/
BAND
VCR
VIDEO
PHONO
POWER
VCR
4
SEA MODE
7/P
AUDIO
SURROUND
2
DELAY
5
SEA
PRESET
SOUND
CONTROL
TV CH
TV VOL
TV/
VIDEO
3
3
TEST
6
9
REAR
8
CENTER
10
CD-DISC
+10
ONE TOUCH
OPERATION
VCR CH
VOLUME MUTING
RM-SR554U REMOTE CONTROL
4
Getting Started
This section explains how to connect stereo components and speakers to the receiver, and how to connect
the power supply.
Before Installation
General
• Be sure your hands are dry.
• Turn the power off to all components.
• Read the manuals supplied with the components you are going to connect.
Locations
• Install the receiver in a location that is level and protected from moisture.
• The temperature around the receiver must be between 23˚ and 95˚ F
(–5˚ and 35˚ C).
• Make sure there is good ventilation around the receiver. Poor ventilation could cause
overheating and damage the receiver.
Handling the receiver
• Do not insert any metal object into the receiver.
• Do not disassemble the receiver or remove screws, covers, or cabinet.
• Do not expose the receiver to rain or moisture.
Checking the Supplied Accessories
Check to be sure you have all of the following items, which are supplied with the
receiver.
The number in the parentheses indicates quantity of the pieces supplied.
• Remote Control (1)
• Batteries (2)
• AM Loop Antenna (1)
• FM Antenna (1)
If anything is missing, contact your dealer immediately.
5
Connecting the FM and AM Antennas
FM Antenna Connections
1
2
3
FM Antenna
FM
AM
LOOP
ANTENNA
FM
75
GND
GND
AM
EXT
Extend the FM antenna horizontally.
Outside FM Antenna Cable
1
13/16 in.
(20 mm)
2
7/16 in.
3
(10 mm)
How to strip the 75 Ω coaxial cable and connect it to the FM
terminals
1. Strip back the outside covering of the 75 Ω coaxial cable to expose the braided
metallic mesh about 13/16 inches (20 mm).
2. Pull the mesh back and twist it into a single connector as shown in the illustration
above.
3. Strip the insulation about 7/16 inches (10 mm) back from the central wire.
4. Insert the twisted mesh and the central wire to the FM terminals, as shown in the
illustration above.
Note:
If reception is poor, connect the
outside antenna.
Before attaching a 75 Ω coaxial
cable (the kind with a round wire
going to an outside antenna),
disconnect the supplied FM wire
antenna.
AM Antenna Connections
ANTENNA
FM
FM
AM
LOOP
75
GND
AM Loop Antenna
GND
AM
EXT
1
2
Turn the loop until you have
the best reception.
Notes :
•
Make sure the antenna
conductors do not touch any
other terminals, connecting
cords and power cord. This
could cause poor reception.
Snap the tabs on the loop into
the slots of the base to assemble
the AM loop.
3
•
If reception is poor, connect an
outdoor single vinyl-covered
wire to the AM EXT terminal.
(Keep the AM loop antenna
connected.)
Outdoor Single Vinylcovered Wire
6
Getting Started
Connecting the Speakers
You can connect the following speakers:
• Two sets of front speakers to produce normal stereo sound
• One set of rear speakers to enjoy the surround effect
• One center speaker to produce more effective surround effect (to make human
voices outstanding)
• One subwoofer to enhance the bass
For each speaker (except for subwoofer), connect one end of the speaker signal
cable (not supplied) to the speaker terminal on the rear panel and the other end to
the speaker. (For connecting a subwoofer, see page 8.)
1. Open each terminal.
2. Insert the end of the speaker signal cable as shown (be
sure to remove the insulation at the end of each wire
first).
3. Close the terminals to clamp the speaker signal cables
firmly in place.
4. Connect the (–) and (+) terminals on the rear panel to
the (–) and (+) terminals marked on the speakers.
CAUTION:
When connecting speakers, use
speakers with the SAME
IMPEDANCE indicated by the
speaker terminals.
Connecting the front speakers
Connect the front speakers to the FRONT SPEAKERS terminals.
Left speaker
SPEAKERS 1
Right speaker
SPEAKERS 2
FRONT SPEAKERS
RIGHT LEFT
1
2
1
2
Connecting the rear and center speakers
Connect the rear speakers to the REAR SPEAKERS terminals and the center speaker to
the CENTER SPEAKER terminals.
Center
speaker
CENTER
SPEAKER
RIGHT LEFT
REAR
SPEAKERS
Left rear
speaker
Right rear
speaker
Notes:
•
When you connect rear
speakers, make sure that both
left and right speakers are
connected; otherwise, no
sound will come out of the
rear speakers.
•
You can register the center
speaker size after you finish
its connection. If you register
it, you do not have to set the
center speaker mode while
setting the surround mode. (If
you do not use a center
speaker, register that
information.) See page 15.
7
Connecting the subwoofer
Connect the input jack of a powered subwoofer to the SUBWOOFER OUT jack on the
rear panel, using a cable with RCA pin plugs.
SUBWOOFER
OUT
Powered subwoofer
Connecting Audio/Video Components
You can connect the following components to the receiver using cables with RCA pin
plugs.
Audio Components Video Components
• Turntable • VCR
• CD player • Video disc player
• Cassette deck • TV
CAUTION:
If you connect a sound-enhancing
device such as a graphic equalizer
between the source components
and this receiver, the sound output
through this receiver may be
distorted.
Audio component connections
If a ground cable is provided
for your turntable, connect the
cable to the GND terminal of
the AM LOOP terminals on the
rear panel.
ANTENNA
FM
75
FM
GND
PHONO
GND
AM
Turntable
LOOP
To audio output
AM
EXT
To audio output
TAPE
CD
OUT
(REC)
VIDEO
(PLAY)
IN
VIDEO
(REC)
(REC)
OUT
(PLAY)
VCR
OUT
IN
(PLAY)
To audio output
To audio input
Note:
Any turntables incorporating a
CD player
MONITOR
OUT
IN
AUDIO
LEFT
RIGHT
Cassette deck
small-output cartridge such as an
MC (moving-coil type) must be
connected to the receiver through
a commercial head amplifier or
step-up transformer. Direct
connection may result in
unsufficient volume.
8
Getting Started
Video component connections
TV
To video input
To audio/video output
Video disc player
PHONO
MONITOR
OUT
VIDEO
TAPE
CD
OUT
IN
(REC)
(PLAY)
VIDEO
OUT
(REC)
OUT
(REC)
VCR
(PLAY)
(PLAY)
IN
AUDIO
IN
LEFT
RIGHT
To audio/video input
VHS
To audio/video output
VCR
If your audio components have a COMPU LINK-3 terminals
The COMPU LINK remote control system allows you to control other JVC audio
components from the receiver or vice versa.
For detailed information about the COMPU LINK-3 remote control system, see page
33.
9
Connecting the Power Cord
Before plugging the receiver into an AC outlet, make sure that all connections have
been made.
When the power cord is connected, the STANDBY lamp above the POWER button
lights up.
Keep the power cord away from the connecting cables for the TV, VCR, and antenna.
The power cord may cause noise or screen interference. We recommend that you use a
coaxial cable to connect the antenna, since it is well-shielded against interference.
Putting Batteries in the Remote Control
Before using the remote control, put the two supplied batteries in first. When using the
remote control, aim the remote control directly at the remote sensor on the receiver.
Notes:
•
A small amount of power is
always consumed even in
standby mode. T o switch of f the
power completely, unplug the
power cord from the AC outlet.
•
If the power cord is unplugged
(or a power failure occurs),
preset settings will be erased in
a few days.
CAUTIONS:
• Do not touch the power cord
with wet hands.
• Do not pull on the power cord
to unplug the receiver. When
unplugging the receiver, always
grasp the plug itself so as not
to damage the cord.
1. On the back of the remote control, press down on the battery cover and slide
it out.
2. Insert batteries. Make sure to observe the proper polarity: (+) to (+) and (–)
to (–).
3. Slide the cover.
R6P (SUM-3)/AA (15F)
If the range or effectiveness of the remote control decreases, replace the batteries. Use
two R6P (SUM-3)/AA (15F) type dry-cell batteries.
CAUTIONS:
Follow these precautions to avoid
leaking or cracking cells:
• Place batteries in the remote
control so they match the
polarity indicated: (+) to (+) and
(–) to (–).
• Use the correct type of batteries.
Batteries that look similar may
differ in voltage.
• Always replace both batteries at
the same time.
• Do not expose batteries to heat
or flame.
10
Basic Operations
STANDBY
POWER
The following operations are commonly used when you play any sound source.
Turning the Power On and Off
On the front panel:
To turn on the power, press POWER.
The STANDBY lamp goes off. The name of the current
source (or station frequency) appears on the display.
MUTE TUNED SLEEP SEA 3D-PHONIC
AUTO STEREO PRO LOGIC 3CH LOGIC HALL LOUDNESS
DAP
CH-
L
VOLUME
MHz
kHz
Current source name appears Current volume
level is shown here
To turn off the power, press POWER again.
The STANDBY lamp lights up.
From the remote control:
To turn on the power, press AUDIO.
The STANDBY lamp goes off. The name of the current
source (or station frequency) appears on the display.
To turn off the power, press AUDIO again.
The STANDBY lamp lights up.
Selecting the Source to Play
On the front panel:
%%
1. Press SOURCE so that the Control
work for selecting the source.
The lamp above the button lights up.
%%
2. Press Control
fifi
% /
fi until the source name you want
%%
fifi
appears on the display.
fifi
% /
fi buttons
%%
fifi
VOLUME
R
AUDIO
SOURCE
From the remote control:
Press one of the source buttons directly.
CD* Listen to the CD player.
TAPE* Listen to the cassette deck.
TUNER/BAND* Listen to the radio. Each time you press
the button, the band alternates between
FM and AM.
VCR View the playback picture from the VCR.
VIDEO View the video component connected to
the VIDEO jacks.
PHONO* Listen to a record.
11
CD
TAPE
TUNER/
BAND
VCR
VIDEO
PHONO
Note:
When you press one of the
source buttons on the remote
control marked with an asterisk
(*), the receiver automatically
turns on.
Adjusting the Volume
On the front panel:
To increase the volume, turn MASTER VOLUME
MASTER VOLUME
–+
clockwise.
To decrease the volume, turn it counterclockwise.
When you turn MASTER VOLUME rapidly, the volume
level also changes rapidly.
When you turn MASTER VOLUME slowly, the volume
level also changes slowly.
From the remote control:
VOLUME
To increase the volume, press VOLUME +.
To decrease the volume, press VOLUME –.
Selecting the Front Speakers
On the front panel
only
:
When you have connected two sets of front speakers, you
can select which to use. Pressing SPEAKERS 1 or
SPEAKERS 2 activiates the respective set of speakers.
To use the set of speakers connected to the FRONT SPEAKERS 1 terminals, press
SPEAKERS 1 to set it in the _ON position, and press SPEAKERS 2 to set it in the —
OFF position.
To use the set of speakers connected to the FRONT SPEAKERS 2 terminals, press
SPEAKERS 2 to set it in the _ON position, and press SPEAKERS 1 to set it in the —
OFF position.
To use both set of speakers, press both SPEAKERS 1 and 2 to set them in the _ON
position.
To use neither set of speakers, press both SPEAKERS 1 and 2 to set them in the —
OFF position.
–+
SPEAKERS
12
_ON —OFF
CAUTION:
Always set the volume to the
minimum before starting any
source. If the volume is set at its
high level, the sudden blast of
sound energy can permanently
damage your hearing and/or ruin
your speakers.
Note:
The volume level can be adjusted
within the range of “0” (minimum)
to “62” (maximum).
Notes:
• When only one set of the front
speakers is connected to either
the FRONT SPEAKERS 1 or
2
terminals, do not press both
SPEAKERS 1 and 2 to set them
_
in the
no sound comes out of the front
speakers.
• The SPEAKERS 1 and 2 do not
affect the sound output of the
center and rear speakers.
ON position. If you do,
Muting the Sound
From the remote control
only
:
Press MUTING to turn off the sound through all
speakers and headphones connected.
MUTING
“MUTE” appears on the display and the volume turns off.
To restore the sound, press MUTING again.
Turning MASTER VOLUME or pressing VOLUME +/– also restores the sound.
12
Basic Operations
Recording a Source
You can record any source playing through the receiver to a cassette deck connected to
the TAPE jacks and the VCR connected to the VCR jacks at the same time.
While recording, you can listen to the selected sound source at whatever sound level
you like, without affecting the sound levels of the recording.
Listening with Headphones
A standard pair of headphones can be connected to the PHONES jack on the front
panel. Be sure to turn down the volume before connecting or putting on
headphones, as high volume can damage both the headphones and your hearing.
To listen with only headphones
Press both SPEAKERS 1 and 2 to set them in the —OFF position.
SPEAKERS
12
_ON —OFF
Note:
The output volume level, preset
SEA, DAP, 3D-PHONIC and
surround modes cannot affect the
recording.
Note:
The SPEAKERS 1 and 2 do not
affect the sound output of the
center and rear speakers.
13
Basic Settings
Some of the following settings are required after connecting and positioning your speakers in your listening
room, while others will make operations easier.
Adjusting the Front Speaker Output Balance
If the sounds you hear from the front right and left speakers are unequal, you can adjust
the speaker output balance.
On the front panel
1. Press SETTING so that the Control
buttons work for adjusting the balance.
The lamp above the button lights up.
only
:
%%
% /
%%
fifi
fi /
fifi
@@
@ /
@@
#
##
##
SETTING
%%
2. Press Control
the display.
3. Press Control
• Pressing Control @ decreases the right channel
output.
• Pressing Control # decreases the left channel output.
Listening at Low Volume (Loudness)
Human ears are not sensitive to bass at low volume. To compensate for this, the
Loudness function automatically boosts the bass level as you lower the volume.
On the front panel
1. Press SETTING so that the Control
Loudness function.
The lamp above the button lights up.
2. Press Control
3. Press Control
• Select “ON ” to activate the Loudness function.
The LOUDNESS indicator lights up on the display.
• Select “OFF” to cancel it.
The indicator goes off.
fifi
% /
fi until “BALANCE” appears on
%%
fifi
@@
##
@ /
# to adjust the balance.
@@
##
only
:
%%
fifi
@@
% /
fi /
%%
fifi
%%
fifi
% /
fi until “LOUDNESS” appears on the display.
%%
fifi
@@
##
@ /
# to set the Loudness function to “ON” or “OFF.”
@@
##
##
@ /
# buttons work for setting the
@@
##
Note:
If the balance is not set at the
center, “BALANCE@” or
“BALANCE #” will appear in
step 2.
Using the Sleep Timer
Using the Sleep Timer, you can fall asleep to music and know the receiver will turn off
by itself rather than play all night.
On the front panel
1. Press SETTING so that the Control
Sleep Timer.
The lamp above the button lights up.
2. Press Control
3. Press Control
The SLEEP indicator lights up on the display.
Each time you press the button, the shut-off time on the display changes as follows:
%%
% /
%%
@@
@ /
@@
2010 30 40 50 60 70 80
only
:
%%
fifi
@@
% /
fi /
%%
fifi
fifi
fi until “SLEEP” appears on the display.
fifi
##
# to set the shut-off time.
##
(Canceled)
0
##
@ /
# buttons work for setting the
@@
##
14
Basic Settings
When the shut-off time comes
The receiver turns off automatically.
To check or change the time remaining until the shut-off time
1. Press SETTING, if necessary, so that the Control % / fi / @ / # buttons work for
setting the Sleep Timer.
2. Press Control % / fi, if necessary, until “SLEEP” appears on the display.
3. Press Control @ / #.
The remaining time until the shut-off time appears in minutes.
• To change the shut-off time, press Control @ / # repeatedly.
To cancel the Sleep Timer
Press Control @ / # repeatedly in step 3 above until “0” appears on the display. (The
SLEEP indicator goes off.)
Turning off the power also cancels the Sleep Timer.
Selecting the Center Speaker Size
You can register the information about the center speaker after all connections are
completed.
If you do this registration first, you do not have to adjust the center speaker mode when
you want to activate the surround sound.
On the front panel
1. Press SETTING so that the Control
the center speaker size.
The lamp above the button lights up.
2. Press Control
display.
3. Press Control
Each time you press the button, the display changes to show the following:
SMALL LARGE NO
SMALL: Select this mode when the size of the center speaker is smaller than
LARGE: Select this mode when the size of the center speaker is the same as
NO: Select this mode when you do not use a center speaker.
%%
% /
%%
@@
@ /
@@
that of the front speakers.
that of the front speakers.
only
:
%%
fifi
@@
% /
fi /
%%
fifi
fifi
fi until “CNTR SPK” (Center Speaker) appears on the
fifi
##
# to select the appropriate item about your center speaker.
##
##
@ /
# buttons work for selecting
@@
##
Note:
This “center speaker size” setting
is so related to the center mode
setting for surround modes that
changing this setting affects and
changes the center mode to a
relevant mode, and vice versa.
For example;
•
If you select “SMALL,” the
center mode is automatically
set to “NORMAL,” and vice
versa.
•
If you select “LARGE,” the
center mode is automatically
set to “WIDE,” and vice versa.
•
If you select “NO,”
– For PRO LOGIC and
THEATER , the center mode
is set to “PHANTOM.”
– For 3CH LOGIC, the center
mode is set to “NORMAL.”
15
One Touch Operation
This receiver can memorize the optimum sound settings for each playing source.
About the One Touch Operation
JVC’s One Touch Operation function is used to assign and store different sound settings
for each different playing source. By using this function, you do not have to change the
settings every time you change the source. The stored settings for the newly selected
source are automatically recalled.
The following can be stored for each source:
• Volume level (see page 12)
• Balance (see page 14)
• Loudness (see page 14)
• Preset SEA modes (see page 20)
• 3D-PHONIC mode settings (see page 23)
• DAP mode settings (see page 25)
• Surround mode settings (see page 28)
Using the One Touch Operation
To store the sound settings
1. Press ONE TOUCH OPERATION.
The ONE TOUCH OPERATION lamp lights up, then
ONE TOUCH OPERATION
the previously memorized settings are recalled and
appear on the display in turn.
2. Adjust the sound using the functions listed above.
The newly adjusted settings are memorized.
Note:
•
If the source is TUNER/BAND,
the One Touch Operation
function memorizes the settings
each for the FM and AM band.
•
The DAP mode, surround mode
and 3D-PHONIC mode cannot
be used at the same time.
To recall the sound settings
With the ONE TOUCH OPERATION lamp lit, the settings
for the currently selected source is recalled, and appears on
ONE TOUCH
OPERATION
the display when the source is selected.
To cancel the One Touch Operation function
Press ONE TOUCH OPERATION so that the lamp goes
off.
(Even though the One Touch Operation function is canceled, the recalled sound effects
remain active.)
16
Receiving Radio Broadcasts
You can browse through all the stations or use the preset function to go immediately to a particular
station.
Tuning in Stations Manually
On the front panel
only
:
1. Press TUNER/BAND.
The indicator above the button lights up.
Each time you press the button, the band alternates
between FM and AM.
%%
2. Press Control
fifi
% /
fi until “–TUNING+” appears on
%%
fifi
the display.
@@
3. Press Control
##
@ /
# until you find the frequency you
@@
##
want.
• Pressing Control @ decreases the frequency.
• Pressing Control # increases the frequency.
Using Preset Tuning
TUNER/BAND
Notes:
•
When you hold down Control
/ # in step 3, the frequency
keeps changing until you press
Control @ / # again or a station
is tuned in.
•
When a station of sufficient
signal strength is tuned in, the
TUNED indicator lights up on
the display.
When an FM stereo program is
received, the STEREO indicator
also lights up.
@
Once a station is assigned to a channel number, the station can be quickly tuned. You
can preset up to 40 stations at random.
To store the preset stations
On the front panel
only
:
1. Tune in the station you want to preset (see above).
If you want to store the FM reception mode for this
station, select the FM reception mode you want. See
page 19 for details.
2. Press MEMORY.
MEMORY
The channel number starts flashing on the display for
about 5 seconds.
@@
3. Press Control
##
@ /
# to select a channel number
@@
##
while the channel number position is flashing.
• Pressing Control @ decreases the number.
• Pressing Control # increases the number.
4. Press MEMORY again while the selected channel
number is flashing on the display.
MEMORY
The selected channel number stops flashing.
The station is assigned to the selected channel number.
CAUTION:
Preset stations may be erased in
a few days when power is cut off
to the receiver, as when it is
unplugged from the AC outlet or
a power failure occurs. If the
preset stations are lost, simply set
the stations again.
Note:
You can press 10 keys on the
remote control to select a channel
number in step 3, if you have
pressed TUNER/BAND on the
remote control prior to starting this
preset procedures.
•
For channel number 5, press 5.
•
For channel number 15, press
+10 then 5.
•
For channel number 20, press
+10 then 10.
•
For channel number 30, press
+10, +10, then 10.
17
5. Repeat steps 1 to 4 until you store all the stations
you want.
To cancel a stored preset station
Storing a new station on a used number erases the previously stored one.
To tune in a preset station
On the front panel:
%%
fifi
1. Press TUNER/BAND so that the Control
##
# buttons work for tuner settings.
##
% /
%%
The lamp above the button lights up.
%%
2. Press Control
fifi
% /
fi until “–PRESET+” appears on
%%
fifi
the display.
@@
3. Press Control
##
@ /
# to select a preset channel.
@@
##
Each time you press the button, the preset channels change.
• Pressing Control @ changes preset channels in
decreasing order.
• Pressing Control # changes preset channels in
increasing order.
fi /
fifi
@@
@ /
@@
TUNER/BAND
From the remote control:
1. Press TUNER/BAND.
Each time you press the button, the band alternates
between FM and AM.
2. Press 10 keys to select a preset channel number.
• For channel number 5, press 5.
• For channel number 15, press +10 then 5.
• For channel number 20, press +10 then 10.
• For channel number 30, press +10, +10, then 10.
TUNER/
BAND
3D-PHONIC
DAP MODE
123
EFFECT DELAY
456
SEA MODE
7/P 8 9
SURROUND
TEST
REAR
–+
CENTER
–+
10 +10
Note:
If you adjust the sound by using
SOUND CONTROL while
listening to a station, the 10 keys
will work for adjusting the sound.
To select a preset channel
number after the sound
adjustment, press TUNER/BAND
again, so the 10 keys will work for
selecting the preset channel
numbers.
18
Receiving Radio Broadcasts
Selecting the FM Reception Mode
You can change the FM reception mode while receiving an FM broadcast.
On the front panel
1. Press TUNER/BAND so that the Control
##
# buttons work for tuner settings.
##
The lamp above the button lights up.
2. Press Control
the display.
3. Press Control
“FM MONO.”
• Normally select “FM AUTO.”
• When an FM stereo broadcast is hard to receive or
noisy, select “FM MONO.”
%%
% /
%%
@@
@ /
@@
only
:
%%
fifi
fi /
fifi
@@
@ /
@@
% /
%%
fifi
fi until “FM MODE” appears on
fifi
##
# to select either “FM AUTO” or
##
TUNER/BAND
Note:
You can store the FM reception
mode for each preset station.
FM AUT O: When a program is broadcast in stereo, you will hear stereo sound;
when in monaural, you will hear monaural sounds. This mode is
also useful to suppress static noise between stations.
The MUTE AUTO indicator lights up on the display.
FM MONO: Reception will be improved although you will lose the stereo effect.
In this mode, you will hear noise while tuning into the stations.
The MUTE AUTO indicator goes off on the display.
19
Using the Preset SEA Modes
The preset SEA (Sound Effect Amplifier) modes give you control of the way your music sounds.
Selecting Your Favorite SEA Mode
On the front panel:
1. Press PRESET SEA so that the Control
##
# buttons work for preset SEA setting.
##
The lamp above the button lights up.
%%
2. Press Control
want appears on the display.
The SEA indicator also lights up on the display.
Each time you press the button, the preset SEA modes
change as follows:
Movie Sports Music
3. Press Control
Each time you press the button, the effect level changes
as follows:
When “Movie” is selected:
MOVIE 1MOVIE 2 MOVIE 3
When “Sports” is selected:
SPORTS1SPORTS2 SPORTS3
When “Music” is selected:
JAZZ 1
COUNTRY2 COUNTRY1 MUSICAL2 MUSICAL1
fifi
% /
fi until the preset SEA mode you
%%
fifi
OFF
@@
##
@ /
# to select the effect level.
@@
##
JAZZ 2
%%
% /
%%
ROCK 1 ROCK 2
fifi
fi /
fifi
@@
@ /
@@
PRESET SEA
Notes:
• The preset SEA modes cannot
be used for recording.
• When you turn on the preset
SEA mode, the mode with its
effect level previously selected
is recalled at first.
Movie: Adds breadth to sounds so you feel like you are in a movie theater.
Sports: Makes sounds exciting.
Music: Select one of the modes below.
JAZZ: Gives a feeling of a live atmosphere. Good for
acoustic music.
ROCK: Gives a heavy sound. Both high and low frequencies
are boosted.
MUSICAL: Enhances the mid-frequency range, which the human
voice is mostly made up of.
COUNTRY: Enhances the high-frequency range so that
instruments such the violin and banjo are emphasized.
OFF: No preset SEA mode is applied (See below).
To cancel the preset SEA mode
Select “OFF” in step 2 above.
The SEA indicator goes off from the display.
20
Using the Preset SEA Modes
From the remote control:
1. Press SOUND CONTROL so that 10 keys work for
adjusting the sound.
2. Press SEA MODE until the preset SEA mode you
want appears on the display.
The previously selected mode is recalled (at its previous
effect level) and is shown on the display.
Each time you press the button, the preset SEA modes
change as follows:
Music
Sports
OFF
3. Press SEA PRESET to select the effect level.
Each time you press the button, the effect level changes
as follows:
When “Music” is selected:
JAZZ 1
COUNTRY2 COUNTRY1 MUSICAL2 MUSICAL1
When “Sports” is selected:
SPORTS1SPORTS2 SPORTS3
JAZZ 2
Movie
ROCK 1 ROCK 2
SOUND
CONTROL
SEA MODE
7/P
SEA
PRESET
When “Movie” is selected:
MOVIE 1MOVIE 2 MOVIE 3
To cancel the preset SEA mode
Selecting “OFF” in step 2 above.
The SEA indicator goes off from the display.
21
Activating the Surround Sounds
The built-in surround processor provides three groups of programs — JVC 3D-PHONIC mode, DAP (Digital
Acoustic Processor) mode, and surround modes (Dolby Surround and JVC Theater Surround).
You cannot use the DAP mode and surround mode at the same time. When you turn on the DAP mode, the surround mode is
turned off (if it has been on), and vice versa.
On JVC 3D PHONIC mode
JVC 3D-PHONIC mode gives you such a
nearly surround effect as it is reproduced
through the Dolby Surround decoder, which
is widely used to reproduce sounds with a
feeling of movement like those experienced
in movie theaters. JVC 3D-PHONIC mode is
the result of research on sound localization
technology carried out at JVC for many
years and makes it possible to reproduce the
surround sound with only two front
speakers.
On the DAP mode
The sound heard in a concert hall or club
consists of direct sound and indirect sound
— early reflections and reflections from
behind. Direct sounds reach the listener
directly without any reflection. On the other
hand, indirect sounds are delayed by the
distances of the ceiling and walls. These
direct sounds and indirect sounds are the
most important elements of the acoustic
surround effects. The DAP mode can create
these important elements, and gives you a
real “being there” feeling by using the front
speakers and rear speakers.
Early reflections
Direct sounds
Reflections from
behind
Notes:
• The surround processor has no
effect on monaural sources.
• The surround processor cannot
be used for recording.
On surround modes
With this receiver, you can use two types
of the surround mode.
Dolby Surround
Dolby Surround has been developed to
reproduce the important elements of the
acoustic surround at home.
To watch the soundtracks of video software
bearing the mark
DOLBY SURROUND
* which
includes the same encoded surround
information as found in Dolby Stereo films,
the receiver can provide you with 2 Dolby
Surround modes (Dolby Pro Logic and
Dolby 3ch Logic).
Dolby Pro Logic: Select this mode when optional center and rear speakers are
connected.
Dolby 3ch Logic: Select this mode when a center speaker is connected without rear
speakers.
JVC Theater Surround
In order to reproduce a more realistic sound field in your listening room while playing
soundtracks of video software bearing the mark
DOLBY SURROUND
, JVC Theater Surround
has been designed to give you clear vocals and to create a real ”being there” feeling.
The sound is reproduced through the front speakers, rear speakers and center
speakers.
* Manufactured under license
from Dolby Laboratories
Licensing Corporation.
Additionally licensed under
Canadian patent number
1,037,877. “Dolby,” the doubleD symbol and “Pro Logic” are
trademarks of Dolby
Laboratories Licensing
Corporation.
22
Activating the Surround Sounds
SURROUND
Using JVC 3D-PHONIC Modes
When using JVC 3D-PHONIC modes, you need only two front speakers to reproduce
the soundtracks of video software bearing the mark
DOLBY SURROUND
.
The 3D-PHONIC modes give you very realistic surround effects as if the sound is
reproduced through the Dolby Surround decoder.
On the front panel:
%%
fifi
1. Press SURROUND so that the Control
##
# buttons work for selecting the surround/DAP/3D-
##
% /
%%
PHONIC modes.
The lamp above the button lights up.
%%
2. Press Control
fifi
% /
fi until one of the 3D-PHONIC
%%
fifi
mode (“3DACTION”, “3DTHEATR” or
“3DDRAMA”) appears on the display.
Each time you press the button, surround/DAP/3DPHONIC modes change as follows:
Ex.
PROLOGIC THEATER
OFF
3DACTION*
(One of the three modes appears)
* As for the DAP modes (see page 25) and the 3D-
PHONIC modes, one of the previously selected mode
appears on the display.
@@
fi /
@ /
fifi
@@
3CHLOGIC
PAVILION*
Note:
The 3D-PHONIC mode is not
used with other surround modes
such as Dolby Surround, JVC
Theater Surround and the DAP
modes. When the 3D-PHONIC
mode is turned on, the other
surround mode, if used, will be
turned off.
Note:
When one of the 3D-PHONIC
modes is selected, the 3DPHONIC indicator also lights up
on the display.
@@
3. Press Control
##
@ /
# until the 3D-PHONIC mode you
@@
##
want appears on the display.
Each time you press the button, the 3D-PHONIC modes
change as follows:
3DACTION
3DTHEATR
3DDRAMA
3DACTION Best for action and war movies — where the action is
fast and explosive.
3DTHEATR Reproduces the sound field of a large theater.
3DDRAMA Best for dramas and romantic movies — where the
action is slow and soft.
%%
4. Press ADJUST so that Control
fifi
% /
fi buttons work
%%
fifi
for adjusting the effect level.
The lamp above the button lights up.
%%
5. Press Control
fifi
% /
fi until “–EFFECT+” appears on
%%
fifi
the display.
ADJUST
Note:
Once you have adjusted the effect
level, it is memorized for each 3DPHONIC mode.
23
@@
6. Press Control
##
@ /
# to adjust the effect level.
@@
##
Each time you press the button, the effect level changes
as follows:
EFFECT 1 EFFECT 2
EFFECT 5
EFFECT 3
EFFECT 4
As the number increases, the effect of the selected 3DPHONIC mode becomes stronger.
7. Select and play a sound source which was processed with Dolby Surround and
is labeled with
DOLBY SURROUND
mark.
To cancel the 3D-PHONIC mode
Select “OFF” in step 2.
The 3D-PHONIC indicator goes off from the display.
From the remote control:
1. Press SOUND CONTROL so that 10 keys work for
adjusting the sound.
2. Press 3D-PHONIC to select the 3D-PHONIC mode
you want.
The previously selected mode is recalled at first (at its
previous effect level) and is shown on the display.
The 3D-PHONIC indicator also lights up on the display.
Each time you press the button, the 3D-PHONIC modes
change as follows:
SOUND
CONTROL
3D-PHONIC
2
3DTHEATR
3DDRAMA
3DACTION
OFF
3. Press EFFECT to select the effect level.
Each time you press the button, the level changes as
EFFECT
4
follows:
EFFECT 1 EFFECT 2
EFFECT 5
EFFECT 3
EFFECT 4
As the number increases, the effect of the selected 3DPHONIC mode becomes stronger.
4. Select and play a sound source which was processed with Dolby Surround and
is labeled with
DOLBY SURROUND
mark.
To cancel the 3D-PHONIC mode
Select “OFF” in step 2 above.
The 3D-PHONIC indicator goes off from the display.
Note:
Once you have adjusted the effect
level, it is memorized for each 3DPHONIC mode.
24
Activating the Surround Sounds
Using the DAP Modes
You can use five DAP modes — “Dance Club, Live Club, Hall, Pavilion, and
Headphones.” These modes (except “Headphones”) require the front speakers and the
rear speakers, but do not require a center speaker to enlarge the sound field.
Among the DAP modes, “Headphones” is very special. It can create the same stereo
sound as you listen through the speakers off air while listening to a source using
headphones. So, you can feel as if you were not using the headphones and listening to
music in a room.
On the front panel:
%%
1. Press SURROUND so that the Control
% /
%%
fifi
fi /
fifi
buttons work for selecting the surround/DAP/3DPHONIC modes.
The lamp above the button lights up.
%%
2. Press Control
fifi
% /
fi until one of the DAP mode
%%
fifi
(“HEAD P,” “PAVILION,” “HALL,” “LIVE C,” or
“DANCE C”) appears on the display.
Each time you press the button, the surround/DAP/3DPHONIC modes change as follows:
@@
@ /
@@
#
##
##
SURROUND
Note:
When one of the DAP modes is
selected, the DAP indicator also
lights up on the display.
Ex.
PROLOGIC THEATER
OFF
3DACTION*
(One of the five modes appears)
3CHLOGIC
PAVILION*
* As for the 3D-PHONIC modes (see page 23) and the
DAP modes, one of the previously selected mode
appears on the display.
@@
3. Press Control
##
@ /
# until the DAP mode you want
@@
##
appears on the display.
Each time you press the button, the DAP modes change
as follows:
HEAD P
DANCE C
HEAD Phones*
Gives a spacious stereo effect when listening with headphones.
PAVILION
LIVE C
HALL
PAVILION Gives the spacious feeling of a pavilion with a high ceiling.
HALL Gives clear vocal and the feeling of a concert hall.
LIVE Club Gives the feeling of a live music club with a low ceiling.
DANCE Club Gives a throbbing bass beat.
* When you select “HEAD P,” you cannot go to the following steps. No adjustments
can be made for “Headphones.”
ADJUST
Note:
When changing the DAP modes
to “PAVILION” or “HALL,” a
reverberation sound comes out.
This is because a long
reverberation is applied to these
two modes.
4. Press ADJUST so that the Control
%%
% /
%%
buttons work for adjusting the selected mode.
The lamp above the button lights up.
%%
5. Press Control
fifi
% /
fi until “– REAR +” appears on
%%
fifi
the display.
25
fifi
fi /
fifi
@@
@ /
@@
#
##
##
Note:
Once you have adjusted the DAP
modes, the adjustment is
memorized for each DAP mode.
@@
6. Press Control
##
@ /
# to adjust the rear speaker
@@
##
output level.
• Pressing Control @ decreases the output level up to
–10 dB.
• Pressing Control # increases the output level up to
+10 dB.
%%
7. Press Control
fifi
% /
fi until “–EFFECT+” appears on
%%
fifi
the display.
@@
8. Press Control
##
@ /
# to adjust the effect level.
@@
##
Each time you press the button, the effect level changes
as follows:
EFFECT 1 EFFECT 2
EFFECT 5
EFFECT 3
EFFECT 4
As the number increases, the effect of the selected DAP
mode becomes stronger.
To cancel the DAP mode
Select “OFF” in step 2.
The DAP indicator goes off from the display.
Note:
When adjusting the effect level for
“PAVILION” or “HALL,” a
reverberation sound comes out.
This is because a long
reverberation is applied to these
two modes.
From the remote control:
1. Press SOUND CONTROL so that 10 keys work for
adjusting the sound.
2. Press DAP MODE to select the DAP mode you want.
The previously selected mode is recalled at first (at its
previous effect level) and is shown on the display.
The DAP indicator also lights up on the display.
Each time you press the button, the DAP modes change
as follows:
HALLHEAD P
LIVE C
OFF
PAVILION
DANCE C
* When you select “HEAD P” (or “OFF”), you cannot go to the following steps. No
adjustments can be made for “Headphones.”
3. Press REAR +/– to adjust the rear speaker output
level.
• Pressing REAR – decreases the output level up to
–10 dB.
• Pressing REAR + increases the output level up to
+10 dB.
4. Press EFFECT to select the effect level.
Each time you press the button, the effect level changes
as follows:
EFFECT 1 EFFECT 2
EFFECT 3
SOUND
CONTROL
DAP MODE
1
REAR
–+
89
EFFECT
4
Note:
Once you have adjusted the DAP
modes, the adjustment is
memorized for each DAP mode.
EFFECT 5
EFFECT 4
To cancel the DAP mode
Select “OFF” in step 2 above.
The DAP indicator goes off from the display.
26
Activating the Surround Sounds
With this receiver, you can use two types of the surround modes — Dolby Surround and JVC Theater
Surround.
Speaker Arrangements for Surround Modes
The following illustrations show how to obtain the optimum sound environment for
various surround modes settings. Try to find the speaker direction and location to create
the optimum sound field.
CASE 1 When you have added a center speaker and rear speakers
Front
speaker
Rear
speaker
CASE 2 When you have added rear speakers (without a center speaker)
Front
speaker
Rear
speaker
TV
Center speaker
TV
Front
speaker
Rear
speaker
Front
speaker
Rear
speaker
In this case:
1.Select “PROLOGIC” or
“THEATER.”
2.Select “NORMAL” or
“WIDE” for center mode.
See pages 28 to 31 for more
details.
In this case:
1.Select “PROLOGIC” or
“THEATER.”
2.Select “PHANTOM” for
center mode.
CASE 3 When you have added a center speaker (without rear speakers)
Front
speaker
TV
Center speaker
Front
speaker
27
See pages 28 to 31 for more
details.
In this case:
1.Select “3CHLOGIC.”
2.Select “NORMAL” or
“WIDE” for center mode.
See pages 28 to 31 for more
details.
Preparing for Surround Modes
Once you have set the surround modes, you can use the same adjustment every time you
want to activate the surrround mode you want. The receiver memorizes surround
adjustments for each mode.
On the front panel:
%%
1. Press SURROUND so that the Control
work for selecting the surround modes.
The lamp above the button lights up.
%%
2. Press Control
fifi
% /
fi to select one of the surround
%%
fifi
mode (“PROLOGIC”, “3CHLOGIC” or
“THEATER”).
Each time you press the button, the surround modes
change as follows:
Ex.
PROLOGIC THEATER
OFF
3DACTION*
PROLOGIC Select this mode when you use a center speaker and rear
speakers.
THEATER Select this mode to watch a video source with Dolby Surround
when you have connected the rear speakers (and a center
speaker). This mode gives you the feeling of a movie theater.
3CHLOGIC Select this mode when you use a center speaker without rear
speakers.
OFF Select this to turn off the surround/DAP/3D-PHONIC modes.
fifi
% /
fi buttons
%%
fifi
3CHLOGIC
PAVILION*
SURROUND
Note:
When one of the surround modes
is selected, the corresponding
indicator lights up on the display.
* You cannot select the 3D-PHONIC modes or the DAP modes in this step.
For the 3D-PHONIC modes: see pages 23 and 24.
For the DAP modes: see pages 25 and 26.
%%
fifi
@@
3. Press ADJUST so that the Control
% /
%%
fi /
fifi
@ /
@@
#
##
##
buttons work for adjusting the selected surround
mode.
The lamp above the button lights up.
%%
4. Press Control
fifi
% /
fi until “CNT MODE” (Center
%%
fifi
Mode) appears on the display.
Continued to the next page.
ADJUST
Note:
If you have already set the center
speaker size following the
procedure described on page 15,
you do not have to select the
center mode in this procedure.
28
Activating the Surround Sounds
@@
5. Press Control
Each time you press the button, the center modes change
as follows:
WIDE
WIDE Select this mode when the center speaker can reproduce the bass
NORMAL Select this mode when the center speaker cannot reproduce the
PHANTOM Select this mode when you do not use a center speaker. The center
6. Press Control
the display.
7. Press Control
rear speaker output.
Each time you press the button, the delay time changes
as follows:
DELAY 1 DELAY 2 DELAY 3
##
@ /
# to select the center mode.
@@
##
NORMAL
better than the front speakers. All signals of the center channel are
output through the center speaker.
bass better than the front speakers. The bass portions of the center
channel signals are output through the front speakers.
speaker channel signals are output through the front speakers.
%%
fifi
% /
fi until “–DELAY +” appears on
%%
fifi
@@
##
@ /
# to adjust the delay time of the
@@
##
PHANTOM
Note:
When you have selected
“3CHLOGIC,” you cannot select
“PHANTOM.”
Note:
When you have selected
“3CHLOGIC” or “THEATER,” you
cannot adjust the delay time.
DELAY 1 Select this when the distance from you to your rear speakers is
greater than that to the front speakers.
DELAY 2 Select this when the distance from you to your rear speakers is
almost equal to that to the front speakers.
DELAY 3 Select this when the distance from you to your rear speakers is less
than that to the front speakers.
%%
8. Press Control
display, then press Control
the speaker output balance.
“TEST” starts flashing on the display, and a test tone
comes out of the speakers in the following order:
Left front
speaker
fifi
% /
fi until “TEST” appears on the
%%
fifi
@@
##
@ /
# to start checking
@@
##
Center
speaker
Rear
speakers
Right front
speaker
Notes:
• No test tone comes out of the
rear speakers when you have
selected “3CHLOGIC.”
• No test tone comes out of the
center speaker when you select
“PHANTOM” for the center
mode.
29
9. If necessary, adjust the speaker output balance as
5
DELAY
follows:
• To adjust the rear speaker output level, press Control
% / fi until “– REAR +” appears on the display, then
press Control @ / #.
• To adjust the center speaker output level, press
Control % / fi until “–CENTER+” appears on the
display, then press Control @ / #.
%%
10.Press Control
display, then press Control
fifi
% /
fi until “TEST” appears on the
%%
fifi
@@
##
@ /
# twice to stop the
@@
##
test tone.
If you have selected JVC Theater Surround, go to the following steps.
%%
11.Press Control
fifi
% /
fi until “–EFFECT+” appears on
%%
fifi
the display.
@@
12.Press Control
##
@ /
# to adjust the effect level.
@@
##
Each time you press the button, the effect level changes
as follows:
EFFECT 1 EFFECT 2
EFFECT 3
Notes:
• The sound levels of the left and
right rear speakers will be the
same.
• You cannot set the sound level
of the rear speakers when you
have selected “3CHLOGIC.”
• You cannot set the sound level
of the center speaker when you
select “PHANTOM” for the
center mode.
Note:
When you have selected
“PROLOGIC” or “3CHLOGIC,”
you cannot select the effect level.
EFFECT 5
EFFECT 4
As the number increases, the effect of the Theater
Surround mode becomes stronger.
From the remote control:
If you have already set the center speaker size following the procedure described on
page 15, you can use the remote control for surround mode preparation.
1. Press SOUND CONTROL so that 10 keys work for
adjusting the sound.
2. Press SURROUND until the surround mode you
want appears on the display.
The previous mode is recalled (with its previous
settings) and is shown on the display.
The indicator for that mode also lights up on the display.
Each time you press the button, the surround modes
change as follows:
PROLOGICTHEATER 3CHLOGIC
OFF
SOUND
CONTROL
SURROUND
3
3. Press DELAY to adjust the delay time of the rear
speaker output.
Each time you press the button, the delay time changes
as follows:
DELAY 1 DELAY 2 DELAY 3
Note:
When you have selected
“3CHLOGIC” or “THEATER,” you
cannot adjust the delay time.
Continued to the next page.
30
Activating the Surround Sounds
4. Press TEST to start checking the speaker output
balance.
“TEST” starts flashing on the display, and a test tone
comes out of the speakers in the following order:
Left front
speaker
Center
speaker
Right front
speaker
Rear
speakers
5. If necessary, adjust the speaker output balance as
follows:
• To adjust the rear speaker output level, press REAR
+/–.
• To adjust the center speaker output level, press
CENTER +/–.
Pressing – decreases the output level up to –10 dB.
Pressing + increases the output level up to +10 dB.
6. Press TEST again to stop the test tone.
If you have selected JVC Theater Surround, go to the following steps.
TEST
6
REAR
–+
89
CENTER
–+
10 +10
TEST
6
Notes:
• No test tone comes out of the
rear speakers when you have
selected “3CHLOGIC.”
• No test tone comes out of the
center speaker when you select
“PHANTOM” for the center
mode.
Notes:
• The sound levels of the left and
right rear speakers will be the
same.
• You cannot set the sound level
of the rear speakers when you
have selected “3CHLOGIC.”
• You cannot set the sound level
of the center speaker when you
select “PHANTOM” for the
center mode.
7. Press EFFECT to adjust the effect level.
Each time you press the button, the effect level changes
as follows:
EFFECT 1 EFFECT 2
EFFECT 5
EFFECT 3
EFFECT 4
As the number increases, the effect of the Theater
Surround mode becomes stronger.
EFFECT
4
Note:
When you have selected
“PROLOGIC” or “3CHLOGIC,”
you cannot select the effect level.
31
Using Surround Modes
Once you have adjusted the surround mode, you can use the same adjustments every
time you want to enjoy Surround Modes.
From the front panel:
%%
1. Press SURROUND so that the Control
fifi
% /
fi buttons
%%
fifi
work for selecting the surround/DAP/3D-PHONIC
modes.
The lamp above the button lights up.
%%
2. Press Control
fifi
% /
fi to select one of the surround
%%
fifi
mode (“PRO LOGIC,” “3CH LOGIC” or
“THEATER”).
Each time you press the button, the surround/DAP/3DPHONIC modes change as follows:
Ex.
PROLOGIC THEATER
OFF
3DACTION*
3CHLOGIC
PAVILION*
* As for the 3D-PHONIC modes (see page 23) and the
DAP modes (see page 25), one of the previously
selected mode appears on the display.
3. Select and play a sound source which was processed with Dolby Surround and
is labeled with
DOLBY SURROUND
mark.
To cancel surround mode
Select “OFF” in step 2 above.
SURROUND
Note:
When one of the surround modes
is selected, the corresponding
indicator lights up on the display.
From the remote control:
SOUND
1. Press SOUND CONTROL so that 10 keys work for
adjusting the sound.
2. Press SURROUND until the mode you want appears
on the display.
The previous mode is recalled at first (with its previous
settings) and is shown on the display.
The indicator for that mode also lights up on the display.
Each time you press the button, the surround modes
change as follows:
PROLOGICTHEATER 3CHLOGIC
OFF
3. Select and play a sound source which was processed with Dolby Surround and
is labeled with
DOLBY SURROUND
mark.
To cancel surround mode
Select “OFF” in step 2 above.
CONTROL
SURROUND
3
32
COMPU LINK Remote Control System
The COMPU LINK remote control system allows you to operate JVC audio components through the remote
sensor on the receiver.
To use this remote control system, you need to connect JVC audio components through
the COMPU LINK-3 (SYNCHRO) jacks with the cable (monaural mini-plug supplied
with those components):
COMPU LINK – 3
(SYNCHRO)
CD player
Cassette deck
Turntable
This remote control system allows you to use the four functions listed below.
Remote Control through the Remote Sensor on the Receiver
You can control JVC audio components through the remote sensor on the receiver using
this remote control. Aim the remote control directly at the remote sensor on the receiver.
For details, see page 34.
Notes:
•
Without connecting the audio
components with RCA pin plugs
as described on page 8, the
COMPU LINK remote control
system cannot operate the
components.
•
Refer also to the manuals
supplied with your audio
components.
Automatic Source Selection
When you press the play (
33
3) button on a connected component or on its own remote
33
control, the receiver automatically turns on and changes the source to the component.
On the other hand, if you select a new source on the receiver or the remote control, the
selected component begins playing immediately.
In both cases, the previously selected source continues playing without sound for a few
seconds.
Automatic Power On/Off (only possible with the COMPU LINK-3
connection)
Both the CD player and cassette deck turn on and off with the receiver.
When you turn on the receiver, the CD player or cassette deck will turn on
automatically, depending on which component has been previously selected.
When you turn off the receiver, both the CD player and cassette deck will turn off.
Synchronized Recording
Synchronized recording means the cassette deck starts recording as soon as a CD (or a
record) begins playing.
To use synchronized recording, follow these steps:
1 Put a tape in the cassette deck, and a disc in the CD player (or a record on the
turntable).
2 Press the record (¶) button and the pause (8) button on the cassette deck at the
same time.
This puts the cassette deck into recording pause.
If you do not press the record (¶) button and pause (8) button at the same time, the
synchronized recording will not start.
3 Press the play (3) button on the CD player (or on the turntable).
The source changes on the receiver, and as soon as play starts, the cassette deck
starts recording. When the play ends, the cassette deck enters recording pause, and
stops about 4 seconds later.
Notes:
•
During synchronized recording,
the selected source cannot be
changed.
•
If your CD player is playing in
program mode, a 4-second
blank is recorded between tracks
so that the music scan feature
of your cassette deck can be
used on the recorded tape.
•
If the power of any component
is shut off during synchronized
recording, the COMPU LINK
remote control system may not
operate properly. In this case,
you must start again from the
beginning.
33
Operating Other Components
You can operate JVC audio and video components with this receiver’s remote control.
To operate these components with the remote control, first select a source with the source buttons on the
remote control. Then, operate that source using the remote control.
IMPORTANT:
To operate JVC audio components using this remote control:
• You need to connect JVC audio components through the COMPU LINK-3
(SYNCHRO) jacks (see page 33) in addition to the connections using cables with
RCA pin plugs (see page 8).
• Aim the remote control directly at the remote sensor on the receiver.
77
7 After pressing CD, you can perform the following
77
operations on the CD player:
3 Starts playing.
4 Returns to the beginning of the current
(or previous) track.
¢ Skips to the beginning of the next track.
7 Stops playing.
8 Pauses. To resume playing, press 3.
1 – 10, +10 Selects a track number directly.
For track number 5, press 5.
For track number 15, press +10, then 5.
For track number 20, press +10, then 10.
For track number 30, press +10, +10,
then 10.
77
7 After pressing CD-DISC, you can perform the
77
TAPE
TUNER/
BAND
VIDEO
PHONO
VIDEO
TV VCR
CD
DAP MODE
123
EFFECT DELAY
456
SEA MODE
VCR
7/P 8 9
SEA
PRESET
SOUND
CONTROL
TV CH
–+
TV VOL.
–+
TV/
VOLUME
–+
RM-SR554U REMOTE CONTROL
POWER
following operations on the CD changer:
1 – 6, 7/P Select the number of a disc installed in
a CD changer.
Then continue to operate the CD player
as described above.
For example: To find a track number 11
of disc 4
1. Press CD DISC.
2. Press 4.
3. Press CD.
4. Press +10, then 1.
AUDIO
3D-PHONIC
SURROUND
TEST
REAR
–+
CENTER
–+
10
+10
ONE TOUCH
OPERATION
CD-DISC
VCR CH
–+
MUTING
Note:
If you choose a source on the front
panel, the remote control will not
operate that source.
77
7 After pressing TAPE, you can perform the following
77
operations on the cassette deck:
3 Starts playback.
4 Fast winds a tape from right to left.
¢ Fast winds a tape from left to right.
7 Stops operation.
8 Pauses. To resume playing, press 3.
Note:
If you press SOUND CONTROL,
you cannot operate the cassette
deck with this remote control. If
this happens, press TAPE again,
so operating buttons for audio
components will work for the
cassette deck.
34
Operating Other Components
IMPORTANT:
To operate JVC video components using this remote control:
• Aim the remote control directly at the remote sensor on the VCR or TV, not on
the receiver.
77
7 After pressing VCR, you can perform the
77
following operations on the VCR:
3 Starts playback.
4 Rewinds a video tape.
¢ Fast winds a video tape.
7 Stops operation.
8 Pauses. To resume playing, press 3.
You can always do the following on the VCR:
• Change the channels on the VCR using the VCR
CH +/– button.
• Turn on and off the VCR by pressing VCR in
the POWER section.
77
7 You can always perform the following operations
77
on the TV:
• Change the TV’s input mode to either “TV” or
“VIDEO” using the TV/VIDEO button.
• Change the TV volume using the TV VOL. +/–
button.
• Change the channels on the TV using the TV CH
+/– button.
• Turn on and off the TV by pressing TV in the
POWER section.
TAPE
TUNER/
BAND
VCR
VIDEO
PHONO
VIDEO
TV VCR
CD
DAP MODE
123
EFFECT DELAY
456
SEA MODE
7/P 8 9
SEA
PRESET
SOUND
CONTROL
TV CH
–+
TV VOL.
–+
TV/
VOLUME
–+
RM-SR554U REMOTE CONTROL
POWER
AUDIO
3D-PHONIC
SURROUND
TEST
REAR
–+
CENTER
–+
10
+10
ONE TOUCH
OPERATION
CD-DISC
VCR CH
–+
MUTING
Note:
If you choose a source on the front
panel, the remote control will not
operate that source.
Notes:
• If you press SOUND
CONTROL, you cannot
operate the VCR with this
remote control. If this happens,
press the VCR again, so
operating buttons for video
components will work for the
VCR.
• If you press the VCR (the one
of the source selection) on the
remote control aiming at the
JVC TV, the TV’s input mode
will change to the video input.
35
Troubleshooting
Use this chart to help you solve daily operational problems. If there is any problem you cannot solve,
contact your JVC service center.
PROBLEM
The display does not light up.
No sound from speakers.
“OVERLOAD” starts flashing on the
display.
POSSIBLE CAUSE
The power cord is not plugged in.
Speaker signal cables are not connected.
The SPEAKERS 1 and 2 buttons are not
set correctly.
An incorrect source is selected.
Speakers are over-loaded because of high
volume.
Speakers are over-loaded because of short
circuit of speaker terminals
SOLUTION
Plug the power cord into an AC
outlet.
Check speaker wiring and
reconnect if necessary.
Press SPEAKERS 1 and 2 to set it
in the _ ON position.
Select the correct source.
Rotate the MASTER VOLUME
control counterclockwise three or
four times then press POWER on
the front panel.
If “OVERLOAD” does not
disappear, unplug the AC power
cord, then plug it back again.
Do not use the remote control when
“OVERLOAD” is shown on the
display.
Press POWER on the front panel
then check the speaker wiring.
If “OVERLOAD” does not
disappear, unplug the AC power
cord, then plug it back again.
Do not use the remote control when
“OVERLOAD” is shown on the
display.
If speaker wiring is not short
circuited, contact your dealer.
Sound from one speaker only.
Continuous hiss or buzzing during FM
reception.
Occasional cracking noise during FM
reception.
Howling during record playing.
Remote control does not work.
Speaker signal cables are not connected
properly.
The balance is set to one extreme.
Incoming signal is too weak.
The station is too far away.
An incorrect antenna is used.
Antennas are not connected properly.
Ignition noise from automobiles.
Your turntable is too close to speakers.
There is an obstruction in front of the
remote sensor on the receiver.
Batteries are weak.
Check speaker wiring and reconnect
if necessary.
Adjust the balance properly (see
page 14).
Connect an outside FM antenna or
contact your dealer.
Select a new station.
Check with your dealer to be sure
you have the correct antenna.
Check connections.
Move the antenna farther from
automobile traffic.
Move speakers away from the
turntable.
Remove the obstruction.
Replace batteries.
36
Specifications
Output Power At Stereo operation 100 watts per channel, min. RMS, driven into 8 ohms, 40 Hz to
20 kHz with no more than 0.8 % total harmonic distortion.
Amplifier
Output Power....................................................... At Surround operation
Front channels .......................................................... 100 watts per channel, min. RMS,
driven into 8 ohms at 1 kHz, with no
more than 0.8 % total harmonic
distortion.
Center channel.......................................................... 100 watts, min. RMS, driven into 8
ohms at 1 kHz, with no more than 0.8
% total harmonic distortion.
Rear channel ............................................................. 100 watts, min. RMS, driven into 8
ohms at 1kHz, with no more than 0.8
% total harmonic distortion.
Total Harmonic Distortion (8 ohms, 1 kHz) .............................................................................................. 0.8 %* at 100 watts output
(* Measured by JVC Audio Analysis
System)
Frequency Response (8 ohms)............................. PHONO (MM) ............................................................ 20 Hz to 20 kHz (±1 dB)
CD, TAPE, VIDEO, VCR .......................................... 20 Hz to 20 kHz (±1 dB)
Audio Input Sensitivity/Impedance (1 kHz)........ PHONO ....................................................................... 2.7 mV/47 k ohms
CD, TAPE, VIDEO, VCR .......................................... 220 mV/47 k ohms
Audio Output Level ............................................. TAPE, VCR ................................................................ 220 mV
Signal-to-Noise Ratio (’66 IHF/’78 IHF)............ PHONO ....................................................................... 70 dB/78 dB
CD, TAPE, VIDEO, VCR .......................................... 87 dB/80 dB
Loudness control (Volume Control at –40 dB) .......................................................................................... +5 ±2 dB at 100 Hz
Video Input Sensitivity/Impedance ..................... VCR, VIDEO .............................................................. 1 Vp-p/75 ohms
Video Output Level ............................................. VCR, MONITOR OUT ............................................... 1 Vp-p (at 1 Vp-p input),
sync negative
Signal-to-Noise Ratio ................................................................................................................................. 45 dB
37
FM tuner (IHF)
Tuning Range ............................................................................................................................................. 87.5 MHz to 108.0 MHz
Usable Sensitivity ....................................................................................................................................... 10.8 dBf (0.95 µV/75 ohms)
50 dB Quieting Sensitivity .................................. Monaural ..................................................................... 16.3 dBf (1.8 µV/75 ohms)
Stereo .......................................................................... 38.3 dBf (22.5 µV/75 ohms)
Signal-to-Noise Ratio (IHF-A weighted) ........... Monaural ..................................................................... 80 dB at 85 dBf
Stereo .......................................................................... 73 dB at 85 dBf
Total Harmonic Distortion ................................. Monaural ..................................................................... 0.15 % at 1 kHz
Stereo .......................................................................... 0.2 % at 1 kHz
Stereo Separation at REC OUT .................................................................................................................. 40 dB at 1 kHz
Capture Ratio.............................................................................................................................................. 1.5 dB (10 mV)
Alternate Channel Selectivity..................................................................................................................... 60 dB: (±400 kHz)
Frequency Response ................................................................................................................................... 30 Hz to 15 kHz: (+0.5 dB, –3 dB)
AM tuner
Tuning Range ............................................................................................................................................. 530 kHz to 1,710 kHz
Usable Sensitivity ................................................ Loop antenna ............................................................... 300 µV/m
External antenna.......................................................... 30 µV
Signal-to-Noise Ratio ................................................................................................................................. 50 dB (100 mV/m)
General
Power Requirements................................................................................................................................... AC 120 V , 60 Hz
Power Consumption ................................................................................................................................... 270 watts/360 VA
5 watts (in standby mode)
3
Dimensions (W x H x D)............................................................................................................................ 17
Mass............................................................................................................................................................ 18.8 lbs (8.5 kg )
Design & specifications are subject to change without notice.
/16 x 5 3/4 x 15 7/8 inches
(435 x 146 x 403 mm)
38
QUALITY SERVICE
HOW TO LOCATE YOUR JVC SERVICE CENTER
TOLL FREE : 1-800-537-5722
Dear customer:
In order to receive the most satisfaction from your purchase, read the instruction booklet before operating the unit. In the event that
repair is necessary, or for the address nearest your location, please refer to the factory service center list below or within the Continental
United States, Call 1-800-537—5722 for your authorized servicer. Remember to retain you Bill of Sale for Warranty Service.
—JVC
JVC SERVICE & ENGINEERING
COMPANY OF AMERICA
DIVISION OF US JVC CORP.
FACTORY SERVICE CENTER LOCATIONS
107 Little Falls Road
Fairfield, NJ 07004-2105
(201) 808-9279
5665 Corporate Avenue
Cypress, CA 90630-0024
(714) 229-8011
230 Eliot Street
Ashland, MA 0172-2377
(508) 881-5923
Sophisticated electronic products may require occasional service. Just as quality is a keyword in the engineering and production of
the wide array of JVC products, service is the key to maintaining the high level of performance for which JVC is world famous. The
JVC service and engineering organization stands behind our products.
1500 Lakes Parkway
Lawrenceville, GA 30243-5357
(404) 339-2522
2969 Mapunapuna Place
Honolulu, HI 96819-2040
(808) 833-5828
14505 Commerce Way
Miami Lakes, FL 33016-1512
(305) 362-6252
NATIONAL HEADQUARTERS
JVC SERVICE & ENGINEERING COMPANY OF AMERICA
DIVISION OF US JVC CORP.
107 Little Falls Road
Fairfield, NJ 07004-2105
If you ship the product • • •
Pack your JVC unit in the original carton or one of equivalent
size and strength. Enclose, with the unit, a letter stating the
problem or symptom that exists and also a copy of the receipt
or bill of sale you received when you purchased your JVC unit.
Print your home return address on the outside and the inside
of the carton. Send to the appropriate JVC Factory Service
Center as listed above.
To prevent electrical shock, do not open the cabinet. No user
serviceable parts inside.
Refer servicing to qualified service personnel.
705 Enterprise Street
Aurora, IL 60504-8149
(708) 851-7855
10700 Hammerly, Suite 110
Houston, TX 77043
(713) 935-9331
890 Dubuque Avenue
South San Francisco, CA 94080-1804
(415) 871-2666
Don’t service it yourself.
CAUTION
ACCESSORIES
To purchase accessories for your JVC product, you may contact your local JVC Dealer.
Or from the 48 Continental United States call toll free : 800-882-2345
(0694)
G-3
LIMITED WARRANTY AUDIO-2
JVC COMPANY OF AMERICA warrants this product and all parts thereof, except as set forth below ONLY TO THE ORIGINAL
PURCHASER AT RETAIL to be FREE FROM DEFECTIVE MATERIAL AND WORKMANSHIP from the date of original retail
purchase for the period as shown below. (“The Warranty Period.”)
PARTS LABOR
THIS LIMITED WARRANTY IS VALID ONLY IN THE FIFTY(50) UNITED STATES, THE DISTRICT OF COLUMBIA AND IN
COMMONWEALTH OF PUERTO RICO.
WHAT WE WILL DO:
If this product is found to be defective, JVC will repair or replace defective parts at no charge to the original owner. Such
repair and replacement services shall be rendered by JVC during normal business hours at JVC authorized service centers.
Parts used for replacement are warranted only for the remainder of the Warranty Period. All products and parts thereof may be
brought to a JVC authorized service center on a carry-in basis except for Television sets having a screen size 25 inches and
above which are covered on an in-home basis.
WHAT YOU MUST DO FOR WARRANTY SERVICE:
Return your product to a JVC authorized service center with a copy of your bill of sale. For your nearest JVC authorized
service center, please call toll free: (800)537-5722.
If service is not available locally, box the product carefully, preferably in the original carton, and ship, insured, with a copy of
your bill of sale plus and letter of explanation of the problem to the nearest JVC Factory Service Center, the name and location
of which will be given to you by the toll-free number.
If you have any questions concerning your JVC Product, please contact our Customer Relations Department.
WHAT IS NOT COVERED:
This limited warranty provided by JVC does not cover:
1. Products which have been subject to abuse, accident, alteration, modification, tampering, negligence, misuse, faulty
installation, lack of reasonable care, or if repaired or serviced by anyone other than a service facility authorized by JVC to
render such service, or if affixed to any attachment not provided with the products, or if the model or serial number has
been altered, tampered with, defaced or removed;
2. Initial installation and installation and removal for repair;
3. Operational adjustments covered in the Owner’s Manual, normal maintenance, video and audio head cleaning;
4. Damage that occurs in shipment, due to act of God, and cosmetic damage;
2 YRS 2 YRS
5. Signal reception problems and failures due to line power surge;
6. Video Pick-up Tubes/CCD Image Sensor, Cartridge, Stylus(Needle) are covered for 90 days from the date of purchase;
7. Accessories;
8. Batteries (except the Rechargeable Batteries are covered for 90 days from the date of purchase);
There are no express warranties except as listed above.
THE DURATION OF ANY IMPLIED WARRANTIES, INCLUDING THE IMPLIED WARRANTY OF MARCHANTABILITY, IS
LIMITED TO THE DURATION OF THE EXPRESS WARRANTY HEREIN.
JVC SHALL NOT BE LIABLE FOR THE LOSS OF USE THE PRODUCT, INCONVENIENCE, LOSS OR ANY OTHER
DAMAGES, WHETHER DIRECT, INCIDENTAL OR CONSEQUENTIAL (INCLUDING, WITHOUT LIMITATION, DAMAGE TO
TAPES, RECORDS OR DISCS) RESULTING FROM THE USE OF THIS PRODUCT, OR ARISING OUT OF ANY BREACH
OF THIS WARRANTY. ALL EXPRESS AND IMPLIED WARRANTIES, INCLUDING THE WARRANTIES OF
MERCHANTABILITY AND FITNESS FOR PARTICULAR PURPOSE, ARE LIMITED TO THE WARRANTY PERIOD SET
FORTH ABOVE.
Some states do not allow the exclusion of incidental or consequential damages or limitations on how long an implied
warranty last, so these limitations or exclusions may not apply to you. This warranty gives you specific legal rights and you
may also have other rights which vary from state to state.
JVC COMPANY OF AMERICA 41 Slater Drive
DIVISION OF US JVC CORP. Elmwood Park, New Jersey 07407
REFURBISHED PRODUCTS CARRY A SEPARATE WARRANTY, THIS WARRANTY DOES NOT APPLY. FOR DETAILS OF
REFURBISHED PRODUCT WARRANTY, PLEASE REFER TO THE REFURBISHED PRODUCT WARRANTY INFORMATION
PACKAGED WITH EACH REFURBISHED PRODUCT.
For customer use:
Enter below the Model No. and Serial No. which is located either on the rear, bottom or side of the cabinet. Retain this
information for future reference.
Model No.: Serial No.:
Purchase date: Name of dealer:
G-4
VICTOR COMPANY OF JAPAN, LIMITED
EN
JVC
1297OFMMDWJEM
Loading...
