iSP99
Quickstart Guide English ( 3 – 11 )
Guía de inicio rápido Español ( 12 – 20 )
Appendix English ( 22 )
2
Quickstart Guide (English)
Introduction
Thank you for purchasing the Charge Time. At ION, your entertainment is as important to us as
it is to you. That’s why we design our products with one thing in mind—to make your life more
fun and more convenient.
Box Contents
Charge Time
Power Adapter
Micro-USB Cable
1/8" (3.5 mm) Stereo Aux Cable
Quickstart Guide
Safety & Warranty Manual
Support
For the latest information about this product (documentation, technical specifications, system
requirements, compatibility information, etc.) and product registration, visit ionaudio.com.
For additional product support, visit ionaudio.com/support.
3
Features
Top Panel
1
2
4
3
4
5
768 9
1. Qi Charging Pad: Place your Qi-compatible device here to wirelessly charge it. See
Operation > Using the Qi Charging Pad for more information.
2. Alarm Button: Press and hold this button for 2 seconds to adjust the alarm time. See
Operation > Using the Alarm for more information.
3. Clock Button: Press and hold this button for 2 seconds to adjust the time.
4. Down Button (): Tap this button to briefly display the current alarm time. Press and
hold this button for 2 seconds to turn the alarm on or off.
5. Up Button (): Press and hold this button for 2 seconds to change the clock format
setting. Tap this button to toggle between 12 Hour and 24 Hour clock format, and press
and hold it to confirm the setting.
6. Play/Pause Button: Tap this button to play, pause or resume audio from a connected
device. Press and hold this button to disconnect a Bluetooth device.
7. Minus Button (-): Tap this button to skip to the previous track on a connected device.
Press and hold this button to decrease the volume.
8. Plus Button (+): Tap this button to skip to the next track on a connected device. Press
and hold this button to increase the volume.
9. Qi LED: When a Qi-compatible device is charging, this LED will be lit solid green. If a
charging connection cannot be established, the LED will flash red and green. If the
charging area cannot detect a Qi-compatible device at all, the LED will not be lit.
5
Front Panel
1
5
3
2
4
1. Bluetooth LED: This LED will be lit solid when a Bluetooth device is connected.
2. Alarm LED: This LED will be lit solid when an alarm is enabled.
3. Display: Shows the current time, alarm time, or temperature.
4. PM LED: This LED will be lit to indicate PM time.
5. Microphone: This microphone will pick up your voice when receiving calls on a connected
device.
6
Rear Panel
3
2
1
1. Power Input: Use the included power adapter to connect this input to a power outlet.
2. Aux Input: This stereo 1/8” (3.5 mm) input can be used to connect a CD player, MP3
player, or other audio source.
Note: Only one audio source (Bluetooth, Aux or USB) can play at a time.
3. Temperature Gauge: This gauge will take the current temperature to show on the display.
4. USB Port: Connect a USB flash drive to this port to play back MP3 or WAV audio files.
Use the Play/Pause and Minus/Plus (-/+) buttons to control playback and volume.
5. USB Charge Port: Connect a device's charge cable here to charge it. You can
simultaneously charge one device using the wireless Qi pad and one device using the
wired charge port.
Note: Playing music may reduce the rate of charging per device.
4
5
7
Operation
Using the Qi Charging Pad
To wirelessly charge your Qi-compatible device, place it on Charge Time in the Qi charging
area. When a successful charging connection is made, the Qi LED will be lit green and remain
solid to indicate the device is charging.
If the charging area cannot establish a charging connection with a device, the Qi LED will flash
green and red to alert you. Depending on the device, it may be necessary to move the device
to a specific location on the top panel of Charge Time to successfully connect. This is normal
for Qi charging pads.
If the charging area cannot detect any Qi-compatible device, the Qi LED will not be lit.
Note:
• Do not leave non-Qi compatible devices in the charging area for extended periods, as
this may reduce the lifetime of the Qi charging capabilities.
• Do not place metallic objects, magnetic objects, or credit cards on the Qi landing pad.
These will interfere with the Qi charging.
• Some thick protective cases may inhibit the device from Qi charging.
• If your phone vibrates, it might shift off of the Qi landing pad. It is encouraged to turn off
‘vibrate’ while Qi charging.
• Qi charging may not engage if the device is simultaneously connected to a USB port.
• It is normal for your phone to get warmer while charging. To extend the lifespan of your
battery, if the battery gets too warm, certain phones may have software designed to limit
charging above 80 percent.
• It is recommended to charge in a cool location to optimize charging times.
8
