Intel MFSYS25V2, MFS5520VIBR, MFS5520VIR, MFS2600K, MFS2600KIB Configuration Manual

Revision 2.7
June, 2012
Enterprise Platforms and Services Marketing
Intel® Modular Server
Spares/Parts List and Configuration Guide
July 12
Intel® Modular Server Configuration Guide
Page 2 of 15
1. Table of Contents
1. TABLE OF CONTENTS 2
2. REVISION HISTORY 3
3. INTEL MODULAR SERVER CONFIGURATION CHART 4
4. PRODUCTION ORDER CODES 5
5. MFS2600KI BOXED AND TRAY PROCESSOR ORDER CODES 7
6. MFS5520VIR BOXED PROCESSOR ORDER CODES 8
7. MFS5520VIR TRAY PROCESSOR ORDER CODES 9
8. VMWARE VSPHERE* AND VCENTER* SERVER SKUS 10
9. SYMANTEC BACKUP EXEC 2010 SKUS 13
July 12
Intel® Modular Server Configuration Guide
Page 3 of 15
Mar ‘12
Rev 2.6b
BETA WIP. Added King Island compute module (MFS2600KI), Xeon® E5-2600 SKUs, VMware and Symantec SKUs
Apr ‘12
Rev 2.6c
SILVER WIP. Added silver King Island compute module (MFS2600KISPP)
May ‘12
Rev 2.6d
GOLD WIP. Add On-site Repair and Extended Warranty SKUs, updated VMware SKUs, removed MFCMM, MIDPLANE
Jun ‘12
Rev 2.7
GOLD FINAL. Removed MFS2600KISPP (silver) SKU
Revision History
INFORMATION IN THIS DOCUMENT IS PROVIDED IN CONNECTION WITH INTEL® PRODUCTS. NO LICENSE, EXPRESS OR IMPLIED, BY ESTOPPEL OR OTHERWISE, TO ANY INTELLECTUAL PROPERTY RIGHTS IS GRANTED BY THIS DOCUMENT. EXCEPT AS PROVIDED IN INTEL'S TERMS AND CONDITIONS OF SALE FOR SUCH PRODUCTS, INTEL ASSUMES NO LIABILITY WHATSOEVER, AND INTEL DISCLAIMS ANY EXPRESS OR IMPLIED WARRANTY, RELATING TO SALE AND/OR USE OF INTEL PRODUCTS INCLUDING LIABILITY OR WARRANTIES RELATING TO FITNESS FOR A PARTICULAR PURPOSE, MERCHANTABILITY, OR INFRINGEMENT OF ANY PATENT, COPYRIGHT OR OTHER INTELLECTUAL PROPERTY RIGHT.
Intel products are not intended for use in medical, life saving, life sustaining applications. Intel may make changes to specifications and product descriptions at any time, without notice.
Intel server boards, server chassis, and processors may contain design defects or errors known as errata, which may cause the product to deviate from published specifications. Current characterized errata are available on request.
Intel, Intel Xeon, Pentium, and the Intel logo are trademarks or registered trademarks of Intel Corporation or its subsidiaries in the United States and other countries.
*Other names and brands may be claimed as the property of others. Copyright © 2012, Intel Corporation
July 12
Intel® Modular Server Configuration Guide
Page 4 of 15
The Intel® Modular Server Configuration Chart
A) Chassis
Up to 6 Server Compute Modules
B) Server Compute Module: Required
MFS2600KI or MFS5520VIR  Supports multi-core Intel® Xeon® Processors  Up to 16 DDR3 DIMMs, depending on compute module  Supports Optional Dual Gigabit Mezzanine expansion card
C) Storage Hard Disk Drive: Required
Up to fourteen 2.5” SAS drives on MFSYS25V2
D) Hard Disk Drive Carrier:
14 are included in MFSYS25V2
E) Hot Swappable I/O Fan Module: Included
F) Hot Swappable Main Fan Module: Included G) Power Supply Module: 2 Included, 2 Optional
N + 1 Redundancy
H) Storage Control Module: 1 Included, 1 Optional
Up to 2 Storage Control Modules for redundancy
I) Management Module: Included J) Ethernet Switch Module: 1 Included, 1 Optional
Up to 2 Ethernet Switch Modules  Each module features 10/100/1000GbE Full Duplex Ports
MFSYS25V2
** Power Supply Notes
A minimum of one 1000-Watt power supply is required to turn on a compute module  One power supply will support 1 compute module plus all other modules in the system  Two power supplies will support up to 3 compute modules (in any slot) plus all other modules in the system
Three power supplies will support up to 6 compute modules (in any slot) plus all other modules in the system  Any additional power supplies above minimum required (based on configuration) provides redundancy
July 12
Intel® Modular Server Configuration Guide
Page 5 of 15
Production Product Order Codes
Product Code
MM
Description
MFSYS25V2
910774
Intel® Modular Server System MFSYS25V2, chassis with integrated 2.5" shared
HDD bay. Contains 5 server blanks, 14 2.5” HDD carriers, main and IO fans, 2 power
supplies (2 PSU fans), 1 GbE switch (and 1 blank), 1 storage module with battery backup (and 1 blank), and 1 management module. It will not include any hard drives, compute modules or power cords. *Contains new MFCMM2 & MFMIDPLANE2
MFS5520VIBR
905717
Intel® Compute Module MFS5520VIR (bulk pack), server board in a diskless compute module enclosure. It will include two passive heatsinks but not include CPUs or memory.
**Bulk packs are still ordered as individual units, therefore qty’s of 3 must be ordered.
MFS5520VIR
905716
Intel® Compute Module MFS5520VIR, server board in a diskless compute module enclosure. It will include two passive heatsinks but not include CPUs or memory.
MFS2600KI
919955
Intel® Compute Module MFS2600KI, server board in a diskless compute module enclosure. Includes two passive heatsinks but no CPUs or memory.
MFS2600KIB
920014
Intel® Compute Module MFS2600KI (3 Pack), server board in a diskless
compute module enclosure. Includes two passive heatsinks but no CPUs or memory. **Bulk packs are still ordered as individual units, therefore qty’s of 3 must be ordered.
Product Code
MM
Description
MFCMM2
910036
Intel® Management Module MFCMM2, management module for MFSYS25V2
MFMIDPLANE2
910888
Midplane for MFSYS25V2 chassis which includes SD Flash
AXXSCM3S
891831
Intel® Storage Controller, SAS storage module (including battery backup)
AXXSW1GB
891842
Intel® Gigabit Ethernet Switch, GB ethernet switch module
AXXPSU
902463
1000Watt Power Supply Module
AXXGBIOMEZ
891844
(Bulk pack) Dual Gigabit Ethernet I/O Expansion Mezzanine Card for MFS5000SI (Qty 3 in box)
**Bulk packs are still ordered as individual units, therefore qty’s of 3 must be ordered.
AXXGBIOMEZV
901362
(Bulk pack) Dual Gigabit Ethernet I/O Expansion Mezzanine Card for MFS5520VIR (Qty 3 in box)
**Bulk packs are still ordered as individual units, therefore qty’s of 3 must be ordered.
AXXMFRAIL
908287
Tool-less Rail kit. Ordering code changed per PCN110223 - 00
AXXTM3SATA
903639
(Bulk pack) 2.5” SATA to SAS Converter Board (Qty 5 in box) **Bulk packs are still ordered as individual units, therefore qty’s of 5 must be ordered.
System and Servers
Optional Spares & Accessories
July 12
Intel® Modular Server Configuration Guide
Page 6 of 15
Optional Spares & Accessories Cont’d
Product Code
MM
Description
MFSVRT
917138
Intel® Modular Server Virtualization Manager - virtualization management and hypervisor integrated into Intel Modular Server GUI, Paper Pack ID key. Supported on the MFSYS25V2 chassis only, and requires MFSLUNKEY. See note at bottom.
MFSLUNKEY
901238
Intel® Shared LUN Paper Pack ID Key
MFSLUNCOPY
903085
Intel® Modular Server Storage Management Pack (formerly LUN Copier) Paper Pack ID Key
MFSADVMGMT
906993
Intel® Modular Server Advanced Management Pack Paper Pack ID Key
MFSCMBBU
892207
Storage Battery back-up spare
MFHDDBAY25
892137
2.5" HDD Bay Module. Kit includes interposer & storage backplane, bezel with 8 screws. No HDD carriers
MFHDDBAY35
892139
3.5" HDD Bay Module. Kit includes interposer & storage backplane, bezel with 8 screws. No HDD carriers. To use MFHDDBAY35 in MFSYS25, new MFIOFAN is required if not using MFSYS25 TA# D91400-008 or greater.
MFPSUFAN
892195
Blank Power Supply Fan module
MFMAINFAN
892170
Main Fan module
MFIOFAN
899168
IO Fan module. When using MFHDDBAY35 in MFSYS25, MM# 899168 is required if not using MFSYS25 with TA# D91400-006 or greater.
FXX25HDDCAR
881681
2.5” hard drive carrier blank – spare. As used on other EPSD systems. MOQ: 10
FPWRCABLENA
879287
Power Cord – North American
FXX10DVCARBLK
880265
3.5” hard drive carrier blank – spare. As used on other EPSD systems. MOQ: 10
SVCORMFSY
916903
Intel® On-site Repair for the Intel(R) Modular Server System. Available in all 50 US states.
SVCEWMFSY
911296
Two year extended warranty for Intel® Modular Server Systems that support two processors. Available in the US, Canada, EU, Switzerland and South Africa.
SVCEWMFCP
911297
Two year extended warranty for Intel® Modular Server Compute Modules. Available in the US, Canada, EU, Switzerland and South Africa.
Note for MFSVRT: The Intel® Modular Server Virtualization Manager key includes a free Intel® Modular Server Software Maintenance key which allows software updates for a period of one year from the date the Virtualization Manager key is initially installed. During this one year period you will be able to install any available product software updates which includes firmware for individual chassis components, management firmware, server BIOS, user interface, and virtualization software subject to the terms and conditions of the End User License Agreement. At the end of the free one year period a new Intel® Modular Server Software Maintenance key must be purchased and installed in order to install any software updates.
July 12
Intel® Modular Server Configuration Guide
Page 7 of 15
Supported Boxed Processors for MFS2600KI
Product Code
SL
MM
Description
BX80621E52603
SR0LB
919828
Boxed Intel® Xeon® Processor E5-2603 (10M Cache, 1.80 GHz, 6.40 GT/s Intel® QPI) FC-LGA10
BX80621E52609
SR0LA
919829
Boxed Intel® Xeon® Processor E5-2609 (10M Cache, 2.40 GHz, 6.40 GT/s Intel® QPI) FC-LGA10
BX80621E52620
SR0KW
919838
Boxed Intel® Xeon® Processor E5-2620 (15M Cache, 2.00 GHz, 7.20 GT/s Intel® QPI) FC-LGA10
BX80621E52630
SR0KV
919839
Boxed Intel® Xeon® Processor E5-2630 (15M Cache, 2.30 GHz, 7.20 GT/s Intel® QPI) FC-LGA10
BX80621E52640
SR0KR
919840
Boxed Intel® Xeon® Processor E5-2640 (15M Cache, 2.50 GHz, 7.20 GT/s Intel® QPI) FC-LGA10
BX80621E52650
SR0KQ
919841
Boxed Intel® Xeon® Processor E5-2650 (20M Cache, 2.00 GHz, 8.00 GT/s Intel® QPI) FC-LGA10
BX80621E52660
SR0KK
919842
Boxed Intel® Xeon® Processor E5-2660 (20M Cache, 2.20 GHz, 8.00 GT/s Intel® QPI) FC-LGA10
Product Code
SL
MM
Description
CM8062100856501
SR0LB
919254
Intel® Xeon® Processor E5-2603 (10M Cache, 1.80 GHz, 6.40 GT/s Intel® QPI) FC-LGA10, Tray
CM8062107186604
SR0LA
919251
Intel® Xeon® Processor E5-2609 (10M Cache, 2.40 GHz, 6.40 GT/s Intel® QPI) FC-LGA10, Tray
CM8062101048401
SR0KW
919196
Intel® Xeon® Processor E5-2620 (15M Cache, 2.00 GHz, 7.20 GT/s Intel® QPI) FC-LGA10, Tray
CM8062101038801
SR0KV
919193
Intel® Xeon® Processor E5-2630 (15M Cache, 2.30 GHz, 7.20 GT/s Intel® QPI) FC-LGA10, Tray
CM8062107185405
SR0KM
919077
Intel® Xeon® Processor E5-2630L (15M Cache, 2.00 GHz, 8.00 GT/s Intel® QPI) FC-LGA10, Tray
CM8062100856401
SR0KR
919160
Intel® Xeon® Processor E5-2640 (15M Cache, 2.50 GHz, 7.20 GT/s Intel® QPI) FC-LGA10, Tray
CM8062100856218
SR0KQ
919090
Intel® Xeon® Processor E5-2650 (20M Cache, 2.00 GHz, 8.00 GT/s Intel® QPI) FC-LGA10, Tray
CM8062107185309
SR0KL
919073
Intel® Xeon® Processor E5-2650L (20M Cache, 1.80 GHz, 8.00 GT/s Intel® QPI) FC-LGA10, Tray
CM8062107184801
SR0KK
919070
Intel® Xeon® Processor E5-2660 (20M Cache, 2.20 GHz, 8.00 GT/s Intel® QPI) FC-LGA10, Tray
Supported Tray Processors for MFS2600KI
July 12
Intel® Modular Server Configuration Guide
Page 8 of 15
Supported Boxed Processors for MFS5520VIR
Product Code
MM
SL
Description
BX80602X5570
901025
SLBF3
2.93GHz 1333MHz 8MB Quad-Core Intel® Xeon® Processor X5570
BX80602X5560
901026
SLBF4
2.8GHz 1333MHz 8MB Quad-Core Intel® Xeon® Processor X5560
BX80602X5550
901027
SLBF5
2.66GHz 1333MHz 8MB Quad-Core Intel® Xeon® Processor X5550
BX80602E5540
901028
SLBF6
2.53GHz 1066MHz 8MB Quad-Core Intel® Xeon® Processor E5540
BX80602E5530
901029
SLBF7
2.4GHz 1066MHz 8MB Quad-Core Intel® Xeon® Processor E5530
BX80602E5520
901030
SLBFD
2.26GHz 1066MHz 8MB Quad-Core Intel® Xeon® Processor E5520
BX80602E5506
901031
SLBF8
2.13GHz 800MHz 4MB Quad-Core Intel® Xeon® Processor E5506
BX80602E5504
901032
SLBF9
2GHz 800MHz 4MB Quad-Core Intel® Xeon® Processor E5504
BX80602E5502
901022
SLBEZ
1.86GHz 800MHz 4MB Dual-Core Intel® Xeon® Processor E5502
BX80602L5530
903280
SLBGF
2.4GHz 1066MHz 8MB Quad-Core Intel® Xeon® Processor L5530
BX80614X5670
907466
SLBV7
2.93GHz, 12MB L3 Cache, 1333 MHz, 6C Intel® Xeon® Processor X5670
BX80614X5660
907464
SLBV6
2.80GHz, 12MB L3 Cache, 1333 MHz, 6C Intel® Xeon® Processor X5560
BX80614X5650
907463
SLBV3
2.66GHz, 12MB L3 Cache, 1333 MHz, 6C Intel® Xeon® Processor X5650
BX80614E5640
907460
SLBVC
2.66GHz, 12MB L3 Cache, 1066 MHz, 4C Intel® Xeon® Processor E5640
BX80614E5630
907459
SLBVB
2.53GHz, 12MB L3 Cache, 1066 MHz, 4C Intel® Xeon® Processor E5630
BX80614E5620
907461
SLBV4
2.4GHz, 12MB L3 Cache, 1066 MHz, 4C Intel® Xeon® Processor E5620
BX80614L5640
907462
SLBV8
2.26GHz, 12MB L3 Cache, 1333 MHz, 6C Intel® Xeon® Processor L5640
BX80614L5630
907465
SLBVD
2.13GHz, 12MB L3 Cache, 1066 MHz, 4C Intel® Xeon® Processor L5630
July 12
Intel® Modular Server Configuration Guide
Page 9 of 15
Supported Tray Processors for MFS5520VIR
Product Code
MM
SL
Description
AT80602000765AA
900835
SLBF3
2.93GHz 1333MHz 8MB Quad-Core Intel® Xeon® Processor X5570
AT80602000768AA
900836
SLBF4
2.8GHz 1333MHz 8MB Quad-Core Intel® Xeon® Processor X5560
AT80602000771AA
900837
SLBF5
2.66GHz 1333MHz 8MB Quad-Core Intel® Xeon® Processor X5550
AT80602000789AA
900838
SLBF6
2.53GHz 1066MHz 8MB Quad-Core Intel® Xeon® Processor E5540
AT80602000792AA
900839
SLBF7
2.4GHz 1066MHz 8MB Quad-Core Intel® Xeon® Processor E5530
AT80602002091AA
900840
SLBFD
2.26GHz 1066MHz 8MB Quad-Core Intel® Xeon® Processor E5520
AT80602000798AA
900841
SLBF8
2.13GHz 800MHz 4MB Quad-Core Intel® Xeon® Processor E5506
AT80602000801AA
900842
SLBF9
2GHz 800MHz 4MB Quad-Core Intel® Xeon® Processor E5504
AT80602000804AA
900400
SLBEZ
1.86GHz 800MHz 4MB Dual-Core Intel® Xeon® Processor E5502
AT80602002937AB
901504
SLBGF
2.4GHz 1066MHz 8MB Quad-Core Intel® Xeon® Processor L5530
AT80602000810AA
900843
SLBFA
2.26GHz 1066MHz 8MB Quad-Core Intel® Xeon® Processor L5520
AT80602002712AA
900833
SLBFH
2.13GHz 800MHz 4MB Quad-Core Intel® Xeon® Processor L5506
AT80614005130AA
907411
SLBV7
2.93GHz, 12MB L3 Cache, 1333 MHz, 6C Intel® Xeon® Processor X5670
AT80614005127AA
907409
SLBV6
2.80GHz, 12MB L3 Cache, 1333 MHz, 6C Intel® Xeon® Processor X5560
AT80614004320AD
907406
SLBV3
2.66GHz, 12MB L3 Cache, 1333 MHz, 6C Intel® Xeon® Processor X5650
AT80614005466AA
907416
SLBVC
2.66GHz, 12MB L3 Cache, 1066 MHz, 4C Intel® Xeon® Processor E5640
AT80614005463AA
907415
SLBVB
2.53GHz, 12MB L3 Cache, 1066 MHz, 4C Intel® Xeon® Processor E5630
AT80614005073AB
907407
SLBV4
2.4GHz, 12MB L3 Cache, 1066 MHz, 4C Intel® Xeon® Processor E5620
AT80614005133AB
907412
SLBV8
2.26GHz, 12MB L3 Cache, 1333 MHz, 6C Intel® Xeon® Processor L5640
AT80614005484AA
907417
SLBVD
2.13GHz, 12MB L3 Cache, 1066 MHz, 4C Intel® Xeon® Processor L5630
July 12
Intel® Modular Server Configuration Guide
Page 10 of 15
VMware vSphere* and vCenter* Product Descriptions – Overview
Essentials
VMware vSphere 5 Essentials Bundle for 3 hosts (Max 2 processors per host) and 192 GB vRAM entitlement
with 1 year VMware Subscription.
Essentials Plus
VMware vSphere 5 Essentials Plus Bundle for 3 hosts (Max 2 processors per host) and 192 GB vRAM entitlement
with 1 year VMware Basic (12x5) Support and Subscription
with 1 year VMware Production (24x7) Support and Subscription
Standard
VMware vSphere 5 Standard for 1 processor (with 32 GB vRAM entitlement per processor)
with 1 year VMware Basic (12x5) Support and Subscription
with 1 year VMware Production (24x7) Support and Subscription
Enterprise
VMware vSphere 5 Enterprise for 1 processor (with 64 GB vRAM entitlement per processor)
with 1 year VMware Basic (12x5) Support and Subscription
with 1 year VMware Production (24x7) Support and Subscription
Enterprise Plus
VMware vSphere 5 Enterprise Plus for 1 processor (with 96 GB vRAM entitlement per processor)
with 1 year VMware Basic (12x5) Support and Subscription
with 1 year VMware Production (24x7) Support and Subscription
VMware vCenter* Server Standard for vSphere 5
VMware vCenter Server 5 Standard for vSphere 5 (Per Instance)
One instance of vCenter Server is required to centrally manage virtual machines and their hosts and to enable all VMware vSphere features on Standard, Enterprise and Enterprise Plus editions.
with 1 year VMware Basic (12x5) Support and Subscription
with 1 year VMware Production (24x7) Support and Subscription
VMware vSphere* software is available as an accessory when ordering an Intel® Server Board or Intel® Server System. Customers can only order these SKUs at the time they are ordering an Intel® Server Board or
Intel® Server System. These SKUs cannot be ordered individually. Licensing Per Processor with vRAM Entitlements: VMware vSphere 5 is licensed on a per-processor basis
with a vRAM entitlement. Each VMware vSphere 5 processor license comes with an entitlement to a certain amount of vRAM capacity, or memory configured to virtual machines. For more information, VMware’s licensing whitepaper can be found at http://www.vmware.com/products/vsphere/overview.html.
VMware vSphere* and vCenter* Server SKUs
Each VMware vSphere SKU contains a paper certificate with a software product activation code. As directed on the certificate, the end user must register the product activation code with VMware at http://www.vmware.com/code/intel to access VMware Software, Support and Subscription Services.
VMware vSphere* and vCenter* Server Editions All VMware vSphere SKUs (except Essentials) are bundled with either 1 year VMware Basic (12x5) or with 1 year
VMware Production (24x7) Support and Subscription. The Essentials SKU is bundled with 1 year VMware Subscription.
July 12
Intel® Modular Server Configuration Guide
Page 11 of 15
VMware vSphere* and VMware vCenter* – Order Codes:
Product Code
UPC
MM
Description
Minimum
Order
Quantity
VMW5ESS
7 35858 22474 1
918769
Paper certificate containing software license activation code for VMware vSphere 5 Essentials Bundle for 3 hosts (Max 2 processors per host) and 192 GB vRAM entitlement with 1 year VMware Subscription.
1
VMW5ESSPLUS
7 35858 22475 8
918774
Paper certificate containing software license activation code VMware vSphere 5 Essentials Plus Bundle for 3 hosts (Max 2 processors per host) and 192 GB vRAM entitlement with 1 year VMware Basic (12x5) Support and Subscription.
1
VMW5ESSPLUSP
7 35858 22476 5
918768
Paper certificate containing software license activation code for VMware vSphere 5 Essentials Plus Bundle for 3 hosts (Max 2 processors per host) and 192 GB vRAM entitlement with 1 year VMware Production (24x7) Support and Subscription.
1
VMW5STD
7 35858 22477 2
918773
Paper certificate containing software license activation code for VMware vSphere 5 Standard for 1 processor (with 32 GB vRAM entitlement per processor) with 1 year VMware Basic (12x5) Support and Subscription.
1
VMW5STDP
7 35858 22478 9
918767
Paper certificate containing software license activation code for VMware vSphere 5 Standard for 1 processor (with 32 GB vRAM entitlement per processor) with 1 year VMware Production (24x7) Support and Subscription.
1
VMW5ENT
7 35858 22479 6
918772
Paper certificate containing software license activation code for VMware vSphere 5 Enterprise for 1 processor (with 64 GB vRAM entitlement per processor) with 1 year VMware Basic (12x5) Support and Subscription.
1
VMW5ENTP
7 35858 22484 0
918770
Paper certificate containing software license activation code for VMware vSphere 5 Enterprise for 1 processor (with 64 GB vRAM entitlement per processor) with 1 year VMware Production (24x7) Support and Subscription.
1
VMW5ENTPLUS
7 35858 22480 2
918771
Paper certificate containing software license activation code for VMware
1
July 12
Intel® Modular Server Configuration Guide
Page 12 of 15
vSphere 5 Enterprise Plus for 1 processor (with 96 GB vRAM entitlement per processor) with 1 year VMware Basic (12x5) Support and Subscription.
VMW5ENTPLUSP
7 35858 22481 9
918760
Paper certificate containing software license activation code for VMware vSphere 5 Enterprise Plus for 1 processor (with 96 GB vRAM entitlement per processor) with 1 year VMware Production (24x7) Support and Subscription.
1
VMW5VCSTD
7 35858 22482 6
918742
Paper certificate containing software license activation code for VMware vCenter Server 5 Standard for vSphere 5 (Per Instance) with 1 year VMware Basic (12x5) Support and Subscription.
1
VMW5VCSTDP
7 35858 22483 3
918759
Paper certificate containing software license activation code for VMware vCenter Server 5 Standard for vSphere 5 (Per Instance) with 1 year VMware Production (24x7) Support and Subscription.
1
July 12
Intel® Modular Server Configuration Guide
Page 13 of 15
Symantec Backup Exec 2010 SKUs
Symantec Backup Exec 2010
Provides an all-in-one solution for small offices to consolidate and manage many application workloads while reducing hardware and operating costs with a low up-front investment.
One Backup Exec Server (per server)
Symantec Backup Exec 2010 for Windows Small Business Server
The perfect data protection solution for Microsoft* Windows Small Business Server Standard and Premium editions. This robust solution provides integrated deduplication, granular restore features, open file protection, disaster recovery and backup protection for Microsoft Exchange, SharePoint Services, SQL and Windows workstations.
One Backup Exec for Windows Small Business Server (per server)  One Agent for Microsoft Exchange server  One Agent for Microsoft SQL Server  One Agent for Microsoft Exchange Server  One Agent for Microsoft Sharepoint Server  Desktop/laptop option (up to 75)  System Recovery for one Windows server  System Recovery for one Windows Small Business server
Symantec Backup Exec 2010 Microsoft Exchange Suite
Provides complete protection for your business-critical email server running Microsoft Exchange.
One Backup Exec Server (per server)  One Agent for Microsoft* Exchange Server (per server)
Symantec Backup Exec 2010 Microsoft SQL Suite
Provides complete protection for a business-critical transactional server running Microsoft SQL
One Backup Exec Server (per server) One Agent for Microsoft* SQL Server (per server)
Symantec Backup Exec 2010 Multi-Server Suite
Provides a Remote Agent, Continuous Protection Agent capabilities, and also includes the Advanced Open File Option and Intelligent Disaster Recovery Option.
One Backup Exec Server (per server)  Three Agents for Microsoft* Windows Systems (per server)
Symantec Backup Exec 2010 VMware Infrastructure Suite
Backup for an unlimited number of guests running on VMware* virtualization environments on one physical server.
One Backup Exec Server (per server)  One Agent for VMware Virtual Infrastructure* (per server)
Symantec Backup Exec 2010 Microsoft Hyper-V Suite
Backup for an unlimited number of guests running on Microsoft Hyper-V* on one physical server.
One Backup Exec Server (per server)  One Agent for Microsoft Hyper-V (per server)
Symantec Backup Exec 2010 Multi-Server DeDuplication Suite
Backup for four Windows Servers, including deduplication option
One Backup Exec Server (per server)  Three Agents for Microsoft Windows Systems (per server)  One Option for Deduplication (per server)
Symantec Backup Exec 2010 Exchange DeDuplication and Archiving Suite
Backup for one Windows Server with Microsoft Exchange, including deduplication and archiving options:
One Backup Exec Server (per server)  One Agent for Microsoft Exchange Server (per server)
Each SKU contains a paper certificate with a Voucher key code. As directed on the certificate under “Frequently Asked Questions”, the end user must go to the Symantec licensing portal at http://licensing.Symantec.com to
redeem their Voucher key. A Sales Order Number is also on the certificate and required for redemption. Please follow all the steps to obtain serial numbers and register for support.
Symantec Backup Exec 2010 Suites
All SKUs are bundled with 1 year Symantec Essentials (24x7) support.
July 12
Intel® Modular Server Configuration Guide
Page 14 of 15
One Option for Deduplication (per server)  One Option for Microsoft Exchange Mailbox Archiving (up to 10
mailboxes)
Product Code
UPC
MM
Description
Minimum
Order
Quantity
SYMCBE
7 35858 21992 1
911526
Paper certificate containing voucher key for one Backup Exec Media Server license with 1 year Symantec Essentials 24x7 Support.
1
SYMCBESBS
7 35858 21996 9
911532
Paper certificate containing voucher key for one Backup Exec for Windows* Small Business Server (SBS), agent for Microsoft Exchange, agent for Microsoft SQL, agent for Microsoft Sharepoint, agent for Windows systems (1 license), Desktop and Laptop option (up to 75 licenses), and Backup Exec System Recovery 2010 (1 license for server and SBS server) with 1 year Symantec Essentials 24x7 Support.
1
SYMCBE3WIN
7 35858 21993 8
911554
Paper certificate containing voucher key for one Backup Exec Media Server license and three Agent for Windows Systems with 1 year Symantec Essentials 24x7 Support.
1
SYMCBEEXC
7 35858 21994 5
911533
Paper certificate containing voucher key for one Backup Exec Media Server license and agent for Microsoft Exchange Server 2003, 2007 and, 2010 SP1 with 1 year Symantec Essentials 24x7 Support.
1
SYMCBESQL
7 35858 21997 6
911534
Paper certificate containing voucher key for one Backup Exec Media Server license and agent for Microsoft SQL Server 2008 R2, 2005, and 2000 users with granular protection on 32­and 64-bit systems down to the individual database or file group with 1 year Symantec Essentials 24x7 Support.
1
SYMCBEVMW
7 35858 21998 3
911536
Paper certificate containing voucher key for one Backup Exec Media Server license and one Backup Exec 2010 Agent for VMware Virtual Infrastructures with 1 year Symantec Essentials 24x7 Support.
1
SYMCBEHYP
7 35858 21995 2
911543
Paper certificate containing voucher key for one Backup Exec Media Server license and one Backup Exec 2010 Agent for Microsoft Hyper-V license with 1 year Symantec Essentials 24x7 Support.
1
SYMCDEDUP
7 35858 21999 0
911544
Paper certificate containing voucher key for one Backup Exec Media Server license, three Agent for Windows Systems, and one
1
Symantec Backup Exec 2010 – Order Codes:
July 12
Intel® Modular Server Configuration Guide
Page 15 of 15
Deduplication Option license which will support your entire media server environment with 1 year Symantec Essentials 24x7 Support.
SYMCDEDUPA
7 35858 22000 2
911545
Paper certificate containing voucher key for one Backup Exec Media Server license, one Deduplication Option license, one Exchange Archive option (10 pack), and one Agent for Exchange with 1 year Symantec Essentials 24x7 Support.
1
Loading...
