MB935

Socket LGA775 Pentium® 4

Intel® Q35 Chipset

Sever Motherboard

USER’S MANUAL

Version 1.0

Acknowledgments

Award is a registered trademark of Award Software International, Inc.

PS/2 is a trademark of International Business Machines Corporation.

Intel and Pentium 4 are registered trademarks of Intel Corporation.

Microsoft Windows is a registered trademark of Microsoft Corporation.

Winbond is a registered trademark of Winbond Electronics Corporation.

All other product names or trademarks are properties of their respective owners.

ii

MB935 User’s Manual

Table of Contents



Introduction .......................................................

1

Product Description.............................................................

1

Checklist..............................................................................

2

Specifications ......................................................................

3

Board Dimensions ...............................................................

4

Installations .......................................................

5

Installing the CPU ...............................................................

6

ATX Power Installation ......................................................

7

Installing the Memory .........................................................

7

Setting the Jumpers .............................................................

8

Connectors on MB935 ......................................................

12

BIOS Setup.......................................................

19

Drivers Installation ......................................

41

Intel Chipset Device Software Installation........................

42

VGA Drivers Installation ..................................................

45

IDE Controller Drivers Installation...................................

48

Intel PRO LAN Drivers Installation..................................

50

Appendix ...........................................................

53

A. I/O Port Address Map...................................................

53

B. Interrupt Request Lines (IRQ)......................................

54

C. Watchdog Timer Configuration....................................

55

D. Digital I/O Sample Code ..............................................

59

MB935 User’s Manual

iii

The MB935 Motherboard

iv

MB935 User’s Manual

INTRODUCTION

Introduction

Product Description

The MB935 LGA 775 Pentium® 4 motherboard incorporates the Intel Q35 chipset that can utilize a single LGA775 processor of up to 4.0GHz or higher and supports FSB frequency of 800/1066 Mhz/1333Mhz 200MHz (800MT/s), 266MHz (1066MT/s), and 333MHz (1333MT/s) HCLK respectively.

The Q35 chipset is designed for use with the Core.2 processor family, including a faster 1333 MHz system bus. The integrated GMCH component provides the CPU interface, DDR2 interface, Hub Interface.

Four DDR2 memory sockets support DDR2 667/800 SDRAM DIMM modules of up to 8GB in capacity.

The board is designed with six Intel 82574L PCI Express Gigabit LAN controllers. Four Serial-II ATA connectors offer 3Gb/s data throughput speed - faster than the most advanced parallel ATA.

Additional expansion is provided by two PCI slot if the board is used with the IP325 backplane bridge board. Other advanced features include four USB 2.0 ports, digital I/O, four serial ports, and watchdog timer function. Dimensions of the board are 13.98” by 7.28”.

Remarks:

MB935 supports the Intel Core 2 Duo and Intel Core 2 Quad processors and Intel Celeron 400 (Conroe-L) Sequence processor.

MB935 User’s Manual

1

INTRODUCTION

Checklist

Your MB935 Pentium® 4 motherboard package should include the items listed below:

The MB935 motherboard

This User’s manual

1 VGA cable

1 IDE cable

1 USB cable

1 PS/2 Keyboard/Mouse cable

1 SATA cable

1 Serial-Port cable

1 CD containing the following:

Chipset Drivers

Flash Memory Utility

Reminder:

About SATA: When using the legacy operating system, only one controller is available and these ports are SATA port 0,1(CN5, CN6). We suggest that the legacy operating system should be installed on these SATA ports.

2

MB935 User’s Manual







INTRODUCTION























Specifications





























Product Name

MB935







CPU Support

Socket LGA775, Supports the Intel Core 2 Duo and Intel









Core2 Quad processors, and Intel Celeron 400 (Conroe-L)









Sequence processor.







CPU Voltage

0.5V~1.6V (VRD 11.0)







System Speed

Up to 3.8GHz+







CPU FSB

800MHz/1066MHz /1333MHz







Green /APM

APM1.2







CPU Socket

LGA 775







Chipset

Intel® Bearlake Chipset









Q35+ICH9







BIOS

Award BIOS; supports ACPI







VGA

Q35 built-in, supports CRT







LAN

Intel 82574L PCI Express Gigabit LAN controller x 6







Memory type

CN4 & CN9 LAN support hardware bypass







Support Dual Channel









DDR2 DIMM Module x 4, 667/800MHz









(Without ECC function), Max. 8GB







LPC I/O

Winbond W83627EHG: COM1(RS-232), COM2(RS-232),









Hardware monitoring









Fintek F81216: COM3/4 (RS-232)



RTC/CMOS

Battery

Keyboard/Mouse

PATA

SATA2 connectors RJ45 connectors USB connectors

COM connectors Power Connector Backplane Bridge Board

Front side Bridge Board

LAN bypass Function

Watchdog Timer

System Voltages

Dimensions

Built in ICH9 Lithium battery

PS/2 Keyboard/Mouse connector

ITE IT8211 PCI to PATA controller for two PATA channel support

IDE connector x 1 + Compact Flash socket Type II x 1 IDE1(44pin/2.0mm)supports Ultra DMA 33/66/100 Supports 4 x SATA2

Six RJ45 connectors

ICH9 built in USB Version 2.0, support 4 ports (D-type connector x 2 port & pin header x 2 port)

4 ports (D-type x 1 port, pin header x3 ports) ATX 24-pin

With PCI BUS Gold finger (PICMG REV: 2.0 Spec.) connect to Backplane bridge board IP325 32bit/33MHz PCI-32 slots x 4

With 40 pin 2mm connector to connect ID370 Front side bridge board

PCI Express Gigabit CN4, 9 RJ45 support Relay Switch by pass function.

Supports 256 segments (0, 1, 2…255. Sec/min) +5V, +12V, -12V, 5VSB, -5V, 3.3V

13.98“ x 7.28“

MB935 User’s Manual

3

INTRODUCTION



Board Dimensions

4

MB935 User’s Manual

INSTALLATIONS

Installations

This section provides information on how to use the jumpers and connectors on the MB935 in order to set up a workable system. The topics covered are:

Installing the CPU........................................................................

6

ATX Power Installation ...............................................................

7

Installing the Memory..................................................................

7

Setting the Jumpers ......................................................................

8

Connectors on MB935 ...............................................................

12

MB935 User’s Manual

5

INSTALLATIONS

Installing the CPU

The MB935 motherboard supports an LGA 775 processor socket for Intel Core 2 Duo and Intel Core2 Quad processors, and Intel Celeron 400(Conroe-L) Sequence processor.

The LGA 775 processor socket comes with a lever to secure the processor. Refer to the pictures below, from left to right, on how to place the processor into the CPU socket. Please note that the cover of the

LGA775 socket must always be installed during transport to avoid damage to the socket.

6

MB935 User’s Manual

INSTALLATIONS

ATX Power Installation

The system power is provided to the motherboard with the ATX1 and ATX_12V power connectors. ATX1 is a 24-pin power connector and ATX_12V is a 8-pin 12V power connector.

The 24-pin power connector can to be connected to a standard 20-pin ATX power connector in a standard ATX power supply (Min. 400watt).

Note: The power supply 5VSB voltage must be at least 2A.

Installing the Memory

The MB935 motherboard supports four DDR2 memory sockets for a maximum total memory of 8GB in DDR memory type. It supports DDR2 667/800.

Basically, the system memory interface has the following features: Supports two 64-bit wide DDR data channels

Available bandwidth up to 6.4GB/s (DDR2 800) for single-channel mode and 12.8GB/s (DDR2 800) in dual-channel mode.

Supports 256Mb, 512Mb, 1Gb DDR2 technologies. Supports only x8, x16, DDR2 devices with four banks Supports only unbuffered DIMMs

Supports opportunistic refresh

Up to 32 simultaneously open pages (four per row, four rows maximum)

Dual Channel Memory Configuration

If you want to operate the Dual Channel Technology, please note the following explanations due to the limitation of Intel chipset specifications.

1.Dual Channel mode will not be enabled if only one DDR II memory module is installed.

2.To enable Dual Channel mode with two or four memory modules (it is recommended to use memory modules of identical brand, size, chips, and speed), you must install them into DIMM sockets of the same color. The following is a Dual Channel Memory configuration table:

(DS: Double Side, SS: Single Side)



DDRII1

DDRII2

DDRII3

DDRII4

2MemoryModules

DS/SS

X

DS/SS

X



X

DS/SS

X

DS/SS

4MemoryModules

DS/SS

DS/SS

DS/SS

DS/SS

MB935 User’s Manual

7

INSTALLATIONS

Setting the Jumpers

Jumpers are used on MB935 to select various settings and features according to your needs and applications. Contact your supplier if you have doubts about the best configuration for your needs. The following lists the connectors on MB935 and their respective functions.

Jumper Locations on MB935.................................................................

9

JP1, JP2: Watchdog Timer & LAN1/LAN2 Bypass Settings..............

10

JP9: Configure and Recovery (Factory use only) ................................

10

JP16: Clear CMOS Contents ...............................................................

10

JP17: Power ON Setting ......................................................................

11

8

MB935 User’s Manual

INSTALLATIONS

Jumper Locations on MB935

Jumpers on MB935...........................................................................

Page

JP1, JP2: Watchdog Timer & LAN1/LAN2 Bypass Settings .............

10

JP9: Configure and Recovery (Factory use only)................................

10

JP16: Clear CMOS Contents ...............................................................

10

JP17: Power ON Setting......................................................................

11

MB935 User’s Manual

9

INSTALLATIONS

JP1, JP2: Watchdog Timer & LAN1/LAN2 Bypass Settings



JP1, JP2 Setting

Function











JP2 Pin 1-2 & 3-4

System will bypass LANs upon the time out

Open

of watchdog timer.

JP1 Pin 1-2



Closed



JP2 Pin 1-2 & 3-4

System LANs bypass function controlled by

Open

SIO GPIO15.

JP1 Pin 2-3



Closed



JP2 Pin 1-2 & 3-4

System will reboot upon the time out of

Closed

watchdog timer.

JP1 Pin 1-2



Closed (Default)



JP9: Configure and Recovery (Factory use only)

JP9

Setting

Function



Pin 1-2

Normal (default)



Short/Closed







Pin 2-3

Configure



Short/Closed







Open

Recovery

JP16: Clear CMOS Contents

Use JP16 to clear the CMOS contents. Note that the ATX-power connector should be disconnected from the board before clearing CMOS.

JP1

Setting

Function



Pin 1-2

Normal



Short/Closed







Pin 2-3

Clear CMOS



Short/Closed





10

MB935 User’s Manual

INSTALLATIONS

JP17: Power ON Setting



JP17

Setting



Function



Pin 1-2

Short/Closed Power on by power supply AC on

Pin 2-3

Short/Closed Power on by system button

MB935 User’s Manual

11

INSTALLATIONS

Connectors on MB935

The connectors on MB935 allow you to connect external devices such as keyboard, mouse, hard disk drives, printers… etc. The following table lists the connectors on MB935 and their respective functions.

Connector Locations on MB935..........................................................

13

ATX1: 24-pin ATX Power Connector.................................................

14

ATX_12V1: ATX 12V Power Connector ...........................................

14

DIMM1, 2: Channel A DDR2 Socket .................................................

14

DIMM3, 4 Channel B DDR2 Socket...................................................

14

FAN1/2/3: CPU Fan Power Connector ...............................................

14

FAN4: System Fan Power Connector.................................................

15

CN1: Slim Type II Compact Flash Connector.....................................

15

CN2: COM1 Serial Port.......................................................................

15

CN3: USB Connector ..........................................................................

15

CN4, CN9, CN10, CN11, CN12, CN13: LAN Connectors.................

15

CN5, CN6, CN7, CN8: SATA HDD Connector .................................

15

CN14: Front Side Bridge Board to ID370 ...........................................

16

IDE1: Primary and Secondary IDE Connectors ..................................

16

J1, J2, J5: COM3, COM2, COM4 Serial Ports....................................

17

J3: Keyboard / Mouse Connector ........................................................

18

J4: SPI Debug Tools Port (Factory use only) ............................................

18

J6: USB Connector ..............................................................................

18

J7: VGA CRT Connector.....................................................................

18

12

MB935 User’s Manual

INSTALLATIONS

Connector Locations on MB935

MB935 User’s Manual

13

INSTALLATIONS

ATX1: 24-pin ATX Power Connector

Signal Name

Pin #

Pin #

Signal Name

3.3V

13

1

3.3V

-12V

14

2

3.3V

Ground

15

3

Ground

PS-ON

16

4

+5V

Ground

17

5

Ground

Ground

18

6

+5V

Ground

19

7

Ground

-5V

20

8

Power good

+5V

21

9

5VSB

+5V

22

10

+12V

+5V

23

11

+12V

Ground

24

12

+3.3V

ATX_12V1: ATX 12V Power Connector

Signal Name

Pin #

Pin #

Signal Name

+12V

5

1

Ground

+12V

6

2

Ground

+12V

7

3

Ground

+12V

8

4

Ground

DIMM1, 2: Channel A DDR2 Socket

DIMM1, 2 are the first-channel DDR2 sockets.

DIMM3, 4 Channel B DDR2 Socket

DIMM3, 4 are the second-channel DDR2 sockets.

FAN1/2/3: CPU Fan Power Connector

FAN1/2/3 are 3-pin headers for CPU fan power. The fan must be a 12V (500mA) fan.

Pin #

Signal Name

1

Ground

2

+12V

3

Rotation detection

14

MB935 User’s Manual

INSTALLATIONS

FAN4: System Fan Power Connector

Pin # Signal Name

1Ground

2+12V

3 Rotation detection

4 Control

CN1: Slim Type II Compact Flash Connector

CN2: COM1 Serial Port

CN2 (COM1) is a DB-9 connector.

Signal Name

Pin #

Pin #

Signal Name

DCD, Data carrier detect

1

6

DSR, Data set ready

RXD, Receive data

2

7

RTS, Request to send

TXD, Transmit data

3

8

CTS, Clear to send

DTR, Data terminal ready

4

9

RI, Ring indicator

GND, ground

5

10

Not Used

CN3: USB Connector

CN4, CN9, CN10, CN11, CN12, CN13: LAN Connectors

CN4: LAN1

CN9: LAN2

CN10: LAN3

CN11: LAN4

CN12: LAN5

CN13: LAN6

CN5, CN6, CN7, CN8: SATA HDD Connector

Pin #

Signal Name

1

Ground

2

TX+

3

TX-

4

Ground

5

RX-

6

RX+

7

Ground

MB935 User’s Manual

15

INSTALLATIONS

CN14: Front Side Bridge Board to ID370

Signal Name

Pin #

PWR-SW

1

Reset-SW

3

Speaker

5

VCC

7

GND(PWR LED)

9

HDD LED

11

RELAY LED

13

GND

15

GND

17

GPO0

19

GPO1

21

GPO2

23

GPO3

25

GPO4

27

GPO5

29

GPO6

31

GPO7

33

VCC

35

GPIO26

37

GPIO27

39

GPIO28

41

VCC3

43





Pin #

Signal Name

2

GND

4

GND

6

VCC

8

VCC

10

Pull up to VCC

12

Pull up to VCC

14

Pull up to VCC

16

GND

18

GND

20

GPI0

22

GPI1

24

GPI2

26

GPI3

28

GPI4

30

GPI5

32

GPI6

34

GPI7

36

VCC

38

GPIO32

40

GPIO56

42

GPIO57

44

VCC3





IDE1: Primary and Secondary IDE Connectors

16

MB935 User’s Manual

























INSTALLATIONS













































































































Signal Name

Pin #

Pin #



Signal Name





















Reset IDE

1

2



Ground





















Host data 7

3

4



Host data 8





















Host data 6

5

6



Host data 9





















Host data 5

7

8



Host data 10





















Host data 4

9

10



Host data 11





















Host data 3

11

12



Host data 12





















Host data 2

13

14



Host data 13





















Host data 1

15

16



Host data 14





















Host data 0

17

18



Host data 15





















Ground

19

20



Key





















DRQ0

21

22



Ground





















Host IOW

23

24



Ground





















Host IOR

25

26



Ground





















IOCHRDY

27

28



Host ALE





















DACK0

29

30



Ground











































































IRQ14

31

32



No connect







IDE1























Address 1

33

34



No connect





















Address 0

35

36



Address 2





















Chip select 0

37

38



Chip select 1





















Activity

39

40



Ground





















VCC

41

42



VCC





















Ground

43

44



N.C.



J1, J2, J5: COM3, COM2, COM4 Serial Ports

Pin #

Signal Name (RS-232)

1

DCD, Data carrier detect

2

RXD, Receive data

3

TXD, Transmit data

4

DTR, Data terminal ready

5

Ground

6

DSR, Data set ready

7

RTS, Request to send

8

CTS, Clear to send

9

RI, Ring indicator

10

No Connect.

MB935 User’s Manual

17

BIOS SETUP

J3: Keyboard / Mouse Connector

J3 is a 10-pin header connector, has functions for both keyboard and mouse. The following table shows the pin assignments of this connector.

Signal Name

Pin #

Pin #

Signal Name

Protect pin

10



5

N.C.

KB clock

9



4

Mouse clock

KB data

8



3

Mouse data

VCC

7



2

VCC

Ground

6



1

Ground

J4: SPI Debug Tools Port (Factory use only)

J6: USB Connector









Signal Name

Pin #



Pin #

Signal Name

VCC

1



5

Ground

USB2-

2



6

USB3+

USB2+

3



7

USB3-

Ground

4



8

VCC

J7: VGA CRT Connector









Signal Name

Pin

Pin

Signal Name

R

1

2



+5V

G

3

4



GND

B

5

6



NC

NC

7

8



SPD1

GND

9

10



Hsync

GND

11

12



Vsync

GND

13

14

SPCLK

GND

15







J8: PICMG 2.0 Gold Finger (to IP325)

PCIE_1: PCIE x1 Gold Finger (to IP325)

18

MB935 User’s Manual

BIOS SETUP

BIOS Setup

This chapter describes the different settings available in the Award BIOS that comes with the board. The topics covered in this chapter are as follows:

BIOS Introduction ........................................................................

20

BIOS Setup...................................................................................

20

Standard CMOS Setup .................................................................

22

Advanced BIOS Features .............................................................

25

Advanced Chipset Features ..........................................................

28

Integrated Peripherals...................................................................

28

Power Management Setup............................................................

33

PNP/PCI Configurations ..............................................................

36

PC Health Status...........................................................................

37

Frequency/Voltage Control ..........................................................

38

Load Fail-Safe Defaults................................................................

39

Load Optimized Defaults .............................................................

39

Set Supervisor/User Password......................................................

39

Save & Exit Setup ........................................................................

39

Exit Without Saving .....................................................................

39

MB935 User’s Manual

19

BIOS SETUP

BIOS Introduction

The Award BIOS (Basic Input/Output System) installed in your computer system’s ROM supports Intel processors. The BIOS provides critical low-level support for a standard device such as disk drives, serial ports and parallel ports. It also adds virus and password protection as well as special support for detailed fine-tuning of the chipset controlling the entire system.

BIOS Setup

The Award BIOS provides a Setup utility program for specifying the system configurations and settings. The BIOS ROM of the system stores the Setup utility. When you turn on the computer, the Award BIOS is immediately activated. Pressing the <Del> key immediately allows you to enter the Setup utility. If you are a little bit late pressing the <Del> key, POST (Power on Self Test) will continue with its test routines, thus preventing you from invoking the Setup. If you still wish to enter Setup, restart the system by pressing the ”Reset” button or simultaneously pressing the <Ctrl>, <Alt> and <Delete> keys. You can also restart by turning the system off and back on again. The following message will appear on the screen:

Press <DEL> to Enter Setup

In general, you press the arrow keys to highlight items, <Enter> to select, the <PgUp> and <PgDn> keys to change entries, <F1> for help and <Esc> to quit.

When you enter the Setup utility, the Main Menu screen will appear on the screen. The Main Menu allows you to select from various setup functions and exit choices.

20

MB935 User’s Manual







BIOS SETUP





























Phoenix - AwardBIOS CMOS Setup Utility

















Standard CMOS Features

Frequency/Voltage Control









Advanced BIOS Features

Load Fail-Safe Defaults









Advanced Chipset Features

Load Optimized Defaults









Integrated Peripherals

Set Supervisor Password









Power Management Setup

Set User Password









PnP/PCI Configurations

Save & Exit Setup









PC Health Status

Exit Without Saving









ESC : Quit

Ç È Æ Å : Select Item









F10 : Save & Exit Setup











Time, Date, Hard Disk Type…

















The section below the setup items of the Main Menu displays the control keys for this menu. At the bottom of the Main Menu just below the control keys section, there is another section, which displays information on the currently highlighted item in the list.

Note: If the system cannot boot after making and saving system changes with Setup, the Award BIOS supports an override to the CMOS settings that resets your system to its default.

Warning: It is strongly recommended that you avoid making any changes to the chipset defaults. These defaults have been carefully chosen by both Award and your system manufacturer to provide the absolute maximum performance and reliability. Changing the defaults could cause the system to become unstable and crash in some cases.

MB935 User’s Manual

21

BIOS SETUP

Standard CMOS Setup

“Standard CMOS Setup” choice allows you to record some basic hardware configurations in your computer system and set the system clock and error handling. If the motherboard is already installed in a working system, you will not need to select this option. You will need to run the Standard CMOS option, however, if you change your system hardware configurations, the onboard battery fails, or the configuration stored in the CMOS memory was lost or damaged.

Phoenix - AwardBIOS CMOS Setup Utility

Standard CMOS Features















Date (mm:dd:yy)

Wed, Oct 3, 2007



Item Help





Time (hh:mm:ss)

16 : 11 : 00



Menu Level >





IDE Channel 0 Master

None



Change the day, month,





IDE Channel 0 Slave

None



Year and century





IDE Channel 1 Master

None









IDE Channel 1 Slave

None









IDE Channel 2 Master

None









IDE Channel 3 Master

None









Video

EGA/VGA









Halt On

All , But Keyboard









Base Memory

640K









Extended Memory

2086912K









Total Memory

2087936K



















At the bottom of the menu are the control keys for use on this menu. If you need any help in each item field, you can press the <F1> key. It will display the relevant information to help you. The memory display at the lower right-hand side of the menu is read-only. It will adjust automatically according to the memory changed. The following describes each item of this menu.

Date

The date format is:

Day :

Sun to Sat

Month :

1 to 12

Date :

1 to 31

Year :

1999 to 2099

To set the date, highlight the “Date” field and use the PageUp/ PageDown or +/- keys to set the current time.

22

MB935 User’s Manual

BIOS SETUP

Time

The time format is: Hour : 00 to 23

Minute : 00 to 59 Second : 00 to 59

To set the time, highlight the “Time” field and use the <PgUp>/ <PgDn> or +/- keys to set the current time.

IDE Channel Master/Slave

ICH9 supports 4 Serial ATA connectors; ITE controller support 1 CF and 1 IDE connectors.

The onboard Serial ATA connectors provide Primary and Secondary channels for connecting up to four Serial ATA hard disks . Each channel can support up to two hard disks; the first is the “Master” and the second is the “Slave”.

Press <Enter> to configure the hard disk. The selections include Auto, Manual, and None. Select ‘Manual’ to define the drive information manually. You will be asked to enter the following items.

Capacity : Capacity/size of the hard disk drive

Cylinder : Number of cylinders

Head : Number of read/write heads

Precomp : Write precompensation

Landing Zone : Landing zone

Sector : Number of sectors

The Access Mode selections are as follows:

CHS

(HD < 528MB)

LBA

(HD > 528MB and supports Logical Block Addressing)

Large

(for MS-DOS only)

Auto



MB935 User’s Manual

23

BIOS SETUP

Video

This field selects the type of video display card installed in your system. You can choose the following video display cards:

EGA/VGA

For EGA, VGA, SEGA, SVGA



or PGA monitor adapters. (default)

CGA 40

Power up in 40 column mode.

CGA 80

Power up in 80 column mode.

MONO

For Hercules or MDA adapters.

Halt On

This field determines whether or not the system will halt if an error is detected during power up.

No errors

The system boot will not be halted for any error



that may be detected.

All errors

Whenever the BIOS detects a non-fatal error,



the system will stop and you will be prompted.

All, But Keyboard

The system boot will not be halted for a



keyboard error; it will stop for all other errors

All, But Diskette

The system boot will not be halted for a disk



error; it will stop for all other errors.

All, But Disk/Key

The system boot will not be halted for a key-



board or disk error; it will stop for all others.

24

MB935 User’s Manual

BIOS SETUP

Advanced BIOS Features

This section allows you to configure and improve your system and allows you to set up some system features according to your preference.

Phoenix - AwardBIOS CMOS Setup Utility

Advanced BIOS Features















CPU Feature

Press Enter



ITEM HELP





Hark Disk Boot Priority

Press Enter



Menu Level >





CD-ROM Boot Priority

Press Enter









CPU L3 Cache

Enabled









Quick Power On Self Test

Enabled









First Boot Device

Removable









Second Boot Device

Hard Disk









Third Boot Device

Legacy LAN









Boot Other Device

Enabled









Boot Up NumLock Status

On









Gate A20 Option

Fast









Typematic Rate Setting

Disabled









Typematic Rate (Chars/Sec)

6









Typematic Delay (Msec)

250









Security Option

Setup









APIC Mode

Enabled









MPS Version Control for OS

1.4









OS Select For DRAM>64MB

Non-OS2









Report No FDD For WIN 95

No









Delay For HDD(Secs)

0









Small Logo (EPA) Show

Disabled



















CPU Feature

Press Enter to configure the settings relevant to CPU Feature.

Hard Disk Boot Priority

Press Enter to configure the settings.

CD-ROM Boot Priority

Press Enter to configure the settings.

CPU L3 Cache

Cache memory is additional memory that is much faster than conventional DRAM (system memory). CPUs from 486-type on up contain internal cache memory, and most, but not all, modern PCs have additional (external) cache memory. When the CPU requests data, the system transfers the requested data from the main DRAM into cache memory, for even faster access by the CPU. By default, these items are enabled.

Quick Power On Self Test

When enabled, this field speeds up the Power On Self Test (POST) after the system is turned on. If it is set to Enabled, BIOS will skip some items.

MB935 User’s Manual

25

BIOS SETUP

First/Second/Third Boot Device

These fields determine the drive that the system searches first for an operating system.

Boot Other Device

These fields allow the system to search for an OS from other devices other than the ones selected in the First/Second/Third Boot Device.

Boot Up NumLock Status

This allows you to activate the NumLock function after you power up the system.

Gate A20 Option

This field allows you to select how Gate A20 is worked. Gate A20 is a device used to address memory above 1 MB.

Typematic Rate Setting

When disabled, continually holding down a key on your keyboard will generate only one instance. When enabled, you can set the two typematic controls listed next. By default, this field is set to Disabled.

Typematic Rate (Chars/Sec)

When the typematic rate is enabled, the system registers repeated keystrokes speeds. Settings are from 6 to 30 characters per second.

Typematic Delay (Msec)

When the typematic rate is enabled, this item allows you to set the time interval for displaying the first and second characters. By default, this item is set to 250msec.

26

MB935 User’s Manual

BIOS SETUP

Security Option

This field allows you to limit access to the System and Setup. The default value is Setup. When you select System, the system prompts for the User Password every time you boot up. When you select Setup, the system always boots up and prompts for the Supervisor Password only when the Setup utility is called up.

APIC Mode

APIC stands for Advanced Programmable Interrupt Controller. The default setting is Enabled.

MPS Version Control for OS

This option is specifies the MPS (Multiprocessor Specification) version for your operating system. MPS version 1.4 added extended configuration tables to improve support for multiple PCI bus configurations and improve future expandability. The default setting is

1.4.

OS Select for DRAM > 64MB

This option allows the system to access greater than 64MB of DRAM memory when used with OS/2 that depends on certain BIOS calls to access memory. The default setting is Non-OS/2.

Report No FDD For WIN 95

If you are using Windows 95/98 without a floppy disk drive, select Enabled to release IRQ6. This is required to pass Windows 95/98's SCT test. You should also disable the Onboard FDC Controller in the Integrated Peripherals screen when there's no floppy drive in the system. If you set this feature to Disabled, the BIOS will not report the missing floppy drive to Win95/98.

Delay For HDD (Secs)

The default setting of the HDD delay is 0.

Small Logo (EPA) Show

The EPA logo appears at the right side of the monitor screen when the system is boot up. The default setting is Disabled.

MB935 User’s Manual

27

BIOS SETUP

Advanced Chipset Features

This Setup menu controls the configuration of the chipset.

Phoenix - AwardBIOS CMOS Setup Utility

Advanced Chipset Features













DRAM Timing Selectable

By SPD

ITEM HELP





CAS Latency Time

Auto

Menu Level >





DRAM RAS# to CAS# Delay

Auto







DRAM RAS# Precharge

Auto







Precharge dealy (tRAS)

Auto







System Memory Frequency

By SPD







System BIOS Cacheable

Enabled







Memory Hole at 15M-16M

Disabled







PCI Express Root Port Func

Press Enter







** VGA Setting **









PEG/On Chip VGA Control

Auto







On-Chip Frame Buffer Size

8MB







DVMT Mode

DVMT







DVMT/FIXED memory Size

128MB















DRAM Timing Selectable

This option refers to the method by which the DRAM timing is selected. The default is By SPD.

CAS Latency Time

You can select CAS latency time in HCLKs of 3/3 or 4/4. The system board designer should set the values in this field, depending on the DRAM installed. Do not change the values in this field unless you change specifications of the installed DRAM or the installed CPU. The choices are 3, 4 and 5.

DRAM RAS# to CAS# Delay

This option allows you to insert a delay between the RAS (Row Address Strobe) and CAS (Column Address Strobe) signals. This delay occurs when the SDRAM is written to, read from or refreshed. Reducing the delay improves the performance of the SDRAM.

DRAM RAS# Precharge

This option sets the number of cycles required for the RAS to accumulate its charge before the SDRAM refreshes.

Precharge delay (tRAS)

The default setting for the Active to Precharge Delay is Auto.

28

MB935 User’s Manual

BIOS SETUP

System Memory Frequency

This field sets the frequency of the DRAM memory installed. The default setting is Auto. The other settings are DDR667 and DDR800.

System BIOS Cacheable

The setting of Enabled allows caching of the system BIOS ROM at F000h-FFFFFh, resulting in better system performance. However, if any program writes to this memory area, a system error may result.

Memory Hole At 15M-16M

In order to improve performance, certain space in memory can be reserved for ISA cards. This memory must be mapped into the memory space below 16 MB. The choices are Enabled and Disabled.

PCI Express Root Port Func

Press Enter to configure this field.

VGA Setting

The fields under the On-Chip VGA Setting and their default settings are: PEG/On Chip VGA Control: Auto

On-Chip Frame Buffer Size: 8MB DVMT Mode: DVMT DVMT/Fixed Memory Size: 128MB

MB935 User’s Manual

29

BIOS SETUP

Integrated Peripherals

This section sets configurations for your hard disk and other integrated peripherals.. Details follow.

Phoenix - AwardBIOS CMOS Setup Utility

Integrated Peripherals













OnChip IDE Device

Press Enter

ITEM HELP





SuperIO Device

Press Enter

Menu Level >





2nd SuperIO Device

Press Enter







USB Device Setting

Press Enter

















Phoenix - AwardBIOS CMOS Setup Utility







OnChip IDE Device







IDE HDD Block Mode

Enabled

ITEM HELP





IDE DMA transfer access

Enabled







IDE Primary Master PIO

Auto

Menu Level >





IDE Primary Slave PIO

Auto







IDE Primary Master UDMA

Auto







IDE Primary Slave UDMA

Auto







On-Chip Secondary PCI IDE

Enabled







IDE Secondary Master PIO

Auto







IDE Secondary Slave PIO

Auto







IDE Secondary Master UDMA

Auto







IDE Secondary Slave UDMA

Auto







LEGACY Mode Support

Enabled







Robson Support

Disabled



















Phoenix - AwardBIOS CMOS Setup Utility







SuperIO Device







POWER ON Function

BUTTON ONLY

ITEM HELP





KB Power ON Password

Enter







Hot Key power ON

Ctrl-F1

Menu Level >





Onboard Serial Port 1

3F8/IRQ4





Onboard Serial Port 2

2F8/IRQ3



















Phoenix - AwardBIOS CMOS Setup Utility







2nd IO Device







Onboard Serial Port 3

230

ITEM HELP





Serial Port 3 Use IRQ

IRQ5

Menu Level >





Onboard Serial Port 4

238







Serial Port 4 Use IRQ

IRQ7



















Phoenix - AwardBIOS CMOS Setup Utility







2nd IO Device







USB 1.0 Controller

Enabled

ITEM HELP





USB 2.0 Controller

Enabled

Menu Level >





USB Keyboard Function

Enabled







USB Mouse Function

Enabled







USB Storage Function

Enabled







USB Mass Storage Device Boot Setting















30

MB935 User’s Manual

BIOS SETUP

IDE HDD Block Mode

This field allows your hard disk controller to use the fast block mode to transfer data to and from your hard disk drive.

OnChip Primary/Secondary PCI IDE

The integrated peripheral controller contains an IDE interface with support for two IDE channels. Select Enabled to activate each channel separately.

IDE Primary/Secondary Master/Slave PIO

These fields allow your system hard disk controller to work faster. Rather than have the BIOS issue a series of commands that transfer to or from the disk drive, PIO (Programmed Input/Output) allows the BIOS to communicate with the controller and CPU directly.

The system supports five modes, numbered from 0 (default) to 4, which primarily differ in timing. When Auto is selected, the BIOS will select the best available mode.

IDE Primary/Secondary Master/Slave UDMA

These fields allow your system to improve disk I/O throughput to 33Mb/sec with the Ultra DMA/33 feature. The options are Auto and

Disabled.

Robson Support

Robson is the code name for a new Intel® platform technology that uses non-volatile memory (Flash memory) to increase system responsiveness and make multi-tasking faster.

Power ON Function

This field is related to how the system is powered on – such as with the use of conventional power button, keyboard or hot keys. The default is

BUTTON ONLY.

MB935 User’s Manual

31

BIOS SETUP

KB Power ON Password

This field allows users to set the password when keyboard power on is the mode of the Power ON function.

Hot Key Power ON

This field sets certain keys, also known as hot keys, on the keyboard that can be used as a ‘switch’ to power on the system.

Onboard Serial Port

These fields allow you to select the onboard serial ports and their addresses. The default values for these ports are:

Serial Port 1

3F8/IRQ4

Serial Port 2

2F8/IRQ3

Serial Port 3

230/IRQ5

Serial Port 4

238/IRQ7

USB Controller

By default, this field is set to Enabled.

USB 2.0 Controller

The options for this field are Enabled and Disabled. By default, this field is set to Enabled. In order to use USB 2.0, necessary OS drivers must be installed first. Please update your system to Windows 2000 SP4 or

Windows XP SP1.

USB Keyboard Function

By default, this field is set to Enabled.

USB Mouse Function

By default, this field is set to Enabled.

USB Storage Function

By default, this field is set to Enabled.

32

MB935 User’s Manual

BIOS SETUP

Power Management Setup

The Power Management Setup allows you to save energy of your system effectively.

Phoenix - AwardBIOS CMOS Setup Utility

Power Management Setup

PCI Express PM Function ACPI Function

ACPI Suspend Type Run VGABIOS if Resume Power Management Video Off Method

Video Off In Suspend Suspend Type Modem Use IRQ Suspend Mode

HDD Power Down Soft-Off by PWR-BTTN CPU THRM-Throttling Wake-Up by PCI Card Power On by Ring

USB KB Wake-Up From S3

Resume by Alarm Date (of Month) Alarm

Time (hh:mm:ss) Alarm

** Reload Global Timer Events ** Primary IDE 0

Primary IDE 1 Secondary IDE 0 Secondary IDE 1 FDD, COM, LPT Port PCI PIRQ[A-D] # HPET Support HPET Mode

Press Enter

ITEM HELP



Enabled









S1(POS)

Menu Level >



Auto





User Define





DPMS





Yes





Stop Grant





3





Disabled





Disabled





Instant-Off





50%





Disabled





Disabled





Disabled





Disabled





0





0 : 0 : 0





Disabled





Disabled





Disabled





Disabled





Disabled





Disabled





Enabled





32-bit Mode











ACPI Function

Enable this function to support ACPI (Advance Configuration and Power Interface).

ACPI Suspend Type

The default setting for this field is S1(POS), Power On Suspend.

Power Management

This field allows you to select the type of power saving management modes. There are four selections for Power Management.

Min. Power Saving

Minimum power management

Max. Power Saving

Maximum power management.

User Define

Each of the ranges is from 1 min. to



1hr. Except for HDD Power Down



which ranges from 1 min. to 15 min.

MB935 User’s Manual

33

BIOS SETUP

Video Off Method

This field defines the Video Off features. There are three options.

V/H SYNC + Blank

Default setting, blank the screen and turn



off vertical and horizontal scanning.

DPMS

Allows BIOS to control the video display.

Blank Screen

Writes blanks to the video buffer.

Video Off In Suspend

When enabled, the video is off in suspend mode. The default setting is

Yes.

Suspend Type

The default setting for the Suspend Type field is Stop Grant.

Modem Use IRQ

This field sets the IRQ used by the Modem. By default, the setting is 3.

Suspend Mode

When enabled, and after the set time of system inactivity, all devices except the CPU will be shut off.

HDD Power Down

When enabled, and after the set time of system inactivity, the hard disk drive will be powered down while all other devices remain active.

Soft-Off by PWRBTN

This field defines the power-off mode when using an ATX power supply. The Instant Off mode allows powering off immediately upon pressing the power button. In the Delay 4 Sec mode, the system powers off when the power button is pressed for more than four seconds or enters the suspend mode when pressed for less than 4 seconds.

CPU THRM-Throttling

When the system enters Doze mode, the CPU clock runs only part of the time. You may select the percent of time that the clock runs.

Wake up by PCI Card

By default, this field is disabled.

Power On by Ring

This field enables or disables the power on of the system through the modem connected to the serial port or LAN.

34

MB935 User’s Manual

BIOS SETUP

Resume by Alarm

This field enables or disables the resumption of the system operation. When enabled, the user is allowed to set the Date and Time.

Reload Global Timer Events

The HDD, FDD, COM, LPT Ports, and PCI PIRQ are I/O events that can prevent the system from entering a power saving mode or can awaken the system from such a mode. When an I/O device wants to gain the attention of the operating system, it signals this by causing an IRQ to occur. When the operating system is ready to respond to the request, it interrupts itself and performs the service.

Notes:

HPET (High Precision Event Timer) is meant to supplement and replace the 8254 Programmable Interval Timer (PIT) and the Real-time clock's (RTC) periodic interrupt function. Compared to these older timer circuits, the HPET has higher frequency (at least 10 MHz) and wider 64-bit counters (although they can be driven in 32-bit mode).

MB935 User’s Manual

35

BIOS SETUP

PNP/PCI Configurations

This option configures the PCI bus system. All PCI bus systems on the system use INT#, thus all installed PCI cards must be set to this value.

Phoenix - AwardBIOS CMOS Setup Utility

PnP/PCI Configurations













Init Display First

PCI Slot

ITEM HELP





Reset Configuration Data

Disabled

Menu Level





Resources Controlled By

Auto (ESCD)

Select Yes if you are





using a Plug and Play





IRQ Resources

Press Enter





capable operating





DMA Resources

Press Enter





system Select No if













PCI/VGA Palette Snoop

Disabled

you need the BIOS to





configure non-boot









devices





PCI Express relative items









Maximum Payload Size

128















Init Display First

The default setting is PCI Slot.

Reset Configuration Data

This field allows you to determine whether to reset the configuration data or not. The default value is Disabled.

Resources Controlled by

This PnP BIOS can configure all of the boot and compatible devices automatically with the use of a use a PnP operating system such as Windows 95.

PCI/VGA Palette Snoop

Some non-standard VGA display cards may not show colors properly. This field allows you to set whether or not MPEG ISA/VESA VGA cards can work with PCI/VGA. When this field is enabled, a PCI/VGA can work with an MPEG ISA/VESA VGA card. When this field is disabled, a PCI/VGA cannot work with an MPEG ISA/VESA card.

36

MB935 User’s Manual

BIOS SETUP

PC Health Status

This section shows the parameters in determining the PC Health Status. These parameters include temperatures, fan speeds and voltages.

Phoenix - AwardBIOS CMOS Setup Utility

PC Health Status









ITEM HELP





Shutdown Temperature

Disabled







CPU Warning Temperature

Disabled



Menu Level >





System Temp.

45°C/113°F









CPU Temp.

52°C/125°F









FAN1 Speed

5463 RPM









FAN2 Speed

5463 RPM









FAN3 Speed

5388 RPM









Vcore(V)

1.02 V









+12V

12.03 V









Vmem

1.89 V









-5V

-5.33 V









+5V

4.94 V









-12V

-12.0 V









3.3V

3.32V









VBAT

3.21 V









5VSB(V)

4.96 V









1st Smart Fan Temperature

Disabled































Shutdown Temperature

This field allows the user to set the temperature by which the system automatically shuts down once the threshold temperature is reached. This function can help prevent damage to the system that is caused by overheating.

CPU Warning Temperature

This field allows the user to set the temperature so that when the temperature is reached, the system sounds a warning. This function can help prevent damage to the system that is caused by overheating.

Temperatures/Voltages

These fields are the parameters of the hardware monitoring function feature of the motherboard. The values are read-only values as monitored by the system and show the PC health status.

Smart Fan Temperature

This field enables or disables the smart fan feature. At a certain temperature, the fan starts turning. Once the temperature drops to a certain level, it stops turning again.

MB935 User’s Manual

37

BIOS SETUP

Frequency/Voltage Control

This section shows the user how to configure the processor frequency.

Phoenix - AwardBIOS CMOS Setup Utility

Frequency/Voltage Control













CPU Clock Ratio Unlock

Disabled

ITEM HELP





CPU Clock Ratio

9X

Menu Level >





Auto Detect PCI Clk

Disabled







Spread Spectrum Modulated

Disabled















Auto Detect PCI Clk

This field enables or disables the auto detection of the PCI clock.

Spread Spectrum Modulated

This field sets the value of the spread spectrum. The default setting is Disabled. This field is for CE testing use only.

38

MB935 User’s Manual

BIOS SETUP

Load Fail-Safe Defaults

This option allows you to load the troubleshooting default values permanently stored in the BIOS ROM. These default settings are non-optimal and disable all high-performance features.

Load Optimized Defaults

This option allows you to load the default values to your system configuration. These default settings are optimal and enable all high performance features.

Set Supervisor Password

These two options set the system password. Supervisor Password sets a password that will be used to protect the system and Setup utility. User Password sets a password that will be used exclusively on the system. To specify a password, highlight the type you want and press <Enter>. The Enter Password: message prompts on the screen. Type the password, up to eight characters in length, and press <Enter>. The system confirms your password by asking you to type it again. After setting a password, the screen automatically returns to the main screen.

To disable a password, just press the <Enter> key when you are prompted to enter the password. A message will confirm the password to be disabled. Once the password is disabled, the system will boot and you can enter Setup freely.

Save & Exit Setup

This option allows you to determine whether or not to accept the modifications. If you type “Y”, you will quit the setup utility and save all changes into the CMOS memory. If you type “N”, you will return to Setup utility.

Exit Without Saving

Select this option to exit the Setup utility without saving the changes you have made in this session. Typing “Y” will quit the Setup utility without saving the modifications. Typing “N” will return you to Setup utility.

MB935 User’s Manual

39

BIOS SETUP

This page is intentionally left blank.

40

MB935 User’s Manual

DRIVERS INSTALLATION

Drivers Installation

This section describes the installation procedures for software and drivers under the Windows 98SE, Windows ME, Windows 2000 and Windows XP. The software and drivers are included with the motherboard. If you find the items missing, please contact the vendor where you made the purchase. The contents of this section include the following:

Intel Chipset Device Software Installation ................................

42

VGA Drivers Installation...........................................................

45

IDE Controller Drivers Installation............................................

48

Intel PRO LAN Drivers Installation ..........................................

50

IMPORTANT NOTE:

After installing your Windows operating system (Windows 98SE/ME/2000/XP), you must install first the Intel Chipset Software Installation Utility before proceeding with the drivers installation.

When IDE Device (HDD, CDROM, etc.) is to be used, one must use a USB-FDD device (with the IDE device driver floppy diskette inserted) to install the drivers when Windows is initializing. When Windows is starting, press F6 and follow the proceeding instructions. The IDE device drivers can be found in the driver DVD disc that is provided with the motherboard with location in D:\SCSI\ITE8211\DISK\ (assuming D: is the DVD ROM drive).

MB935 User’s Manual

41

DRIVER INSTALLATION

Intel Chipset Device Software Installation

The Intel Chipset Drivers should be installed first before the software drivers to enable Plug & Play INF support for Intel chipset components. Follow the instructions below to complete the installation under Windows 98SE/ME/2000/XP.

1. Insert the CD that comes with the board. Click Intel and then Intel(R) Q35 Chipset Drivers.

2. Click Intel(R) Chipset Software Installation Utility.

42

MB935 User’s Manual

DRIVERS INSTALLATION

3. When the Welcome screen appears, click Next to continue. Click Yes to accept the software license agreement and proceed with the installation process.

MB935 User’s Manual

43

DRIVER INSTALLATION

5. On Readme Information screen, click Next to continue installation.

6. When Setup is complete, click Finish to complete the setup process.

44

MB935 User’s Manual

DRIVERS INSTALLATION

VGA Drivers Installation

To install the VGA drivers, follow the steps below to proceed with the installation.

1.Insert the CD that comes with the motherboard. Click Intel and then

Intel(R) Q35 Chipset Drivers.

2.Click Intel(R) Q35 Chipset Family Graphics Driver.

MB935 User’s Manual

45

DRIVER INSTALLATION

3. When the Welcome screen appears, click Next to continue. Click Yes to agree with the license agreement and continue installation.

46

MB935 User’s Manual

DRIVERS INSTALLATION

4. Click Next to continue the setup process. Restart the computer as prompted and for changes to take effect.

MB935 User’s Manual

47

DRIVER INSTALLATION

IDE Controller Drivers Installation

Follow the steps below to install IDE Controller Drivers.

1. Insert the CD that comes with the motherboard. Click SCI/SATA Card and then ITE8211 IDE Drivers . When the Welcome screen appears, click Next to continue.

48

MB935 User’s Manual

DRIVERS INSTALLATION

4. Select Type as ‘Typical’ and click Next to continue. Restart when promoted and finish the installation process.

MB935 User’s Manual

49

DRIVER INSTALLATION

Intel PRO LAN Drivers Installation

Follow the steps below to complete the installation of the Intel PRO LAN drivers.

1. Insert the CD that comes with the motherboard. Click LAN Card and then Intel(R) PRO 82574L LAN Drivers.

2. Click Install Drivers and Software. When the Welcome screen appears, click Next to continue.

3. Click Next to to agree with the license agreement.

50

MB935 User’s Manual

DRIVERS INSTALLATION

4. Click the Drivers checkbox as shown below and click Next to continue installation. Then, click Install to begin the installation.

5. When InstallShield Wizard has completed installation, click Finish.

MB935 User’s Manual

51

DRIVER INSTALLATION

This page is intentionally left blank.

52

MB935 User’s Manual

APPENDIX

Appendix

A. I/O Port Address Map

Each peripheral device in the system is assigned a set of I/O port addresses which also becomes the identity of the device. The following table lists the I/O port addresses used.

Address

Device Description

000h - 01Fh

DMA Controller #1

020h - 03Fh

Interrupt Controller #1

040h - 05Fh

Timer

060h - 06Fh

Keyboard Controller

070h - 07Fh

Real Time Clock, NMI

080h - 09Fh

DMA Page Register

0A0h - 0BFh

Interrupt Controller #2

0C0h - 0DFh

DMA Controller #2

0F0h

Clear Math Coprocessor Busy Signal

0F1h

Reset Math Coprocessor

1F0h - 1F7h

IDE Interface

278 - 27F

Parallel Port #2(LPT2)

2F8h - 2FFh

Serial Port #2(COM2)

2B0 - 2DF

Graphics adapter Controller

378h - 3FFh

Parallel Port #1(LPT1)

360 - 36F

Network Ports

3B0 - 3BF

Monochrome & Printer adapter

3C0 - 3CF

EGA adapter

3D0 - 3DF

CGA adapter

3F0h - 3F7h

Floppy Disk Controller

3F8h - 3FFh

Serial Port #1(COM1)

MB935 User’s Manual

53

APPENDIX

B. Interrupt Request Lines (IRQ)

Peripheral devices use interrupt request lines to notify CPU for the service required. The following table shows the IRQ used by the devices on board.

Level

Function

IRQ0

System Timer Output

IRQ1

Keyboard

IRQ2

Interrupt Cascade

IRQ3

Serial Port #2

IRQ4

Serial Port #1

IRQ5

Reserved

IRQ6

Floppy Disk Controller

IRQ7

Parallel Port #1

IRQ8

Real Time Clock

IRQ9

Reserved

IRQ10

Reserved

IRQ11

Reserved

IRQ12

PS/2 Mouse

IRQ13

80287

IRQ14

Primary IDE

IRQ15

Secondary IDE

54

MB935 User’s Manual

APPENDIX

C. Watchdog Timer Configuration

The WDT is used to generate a variety of output signals after a user programmable count. The WDT is suitable for use in the prevention of system lock-up, such as when software becomes trapped in a deadlock. Under these sort of circumstances, the timer will count to zero and the selected outputs will be driven. Under normal circumstance, the user will restart the WDT at regular intervals before the timer counts to zero.

SAMPLE CODE:

This code and information is provided "as is" without warranty of any kind, either expressed or implied, including but not limited to the implied warranties of merchantability and/or fitness for a particular purpose.

;[]================================================

; Name

: Enable_And_Set_Watchdog

; IN

: AL - 1sec ~ 255sec

; OUT

: None

;[]================================================

Enable_And_Set_Watchdog

Proc Near

push ax

;save time interval

call Unlock_Chip



mov cl, 2Bh



call Read_Reg



and al, NOT 10h



call Write_Reg

;set GP24 as WDTO

mov cl, 07h



mov al, 08h



call Write_Reg

;switch to LD8

MB935 User’s Manual

55

APPENDIX

mov cl, 0F5h



call Read_Reg



and al, NOT 08h



call Write_Reg

;set count mode as second

pop ax



mov cl, 0F6h



call Write_Reg

;set watchdog timer

mov al, 01h



mov cl, 30h



call Write_Reg

;watchdog enabled

call Lock_Chip



ret



Enable_And_Set_Watchdog

Endp

;[]=============================================== ; Name : Disable_Watchdog

; IN

: None

; OUT

: None

;[]===============================================

Disable_Watchdog Proc

Near

call Unlock_Chip



mov cl, 07h



mov al, 08h



call Write_Reg

;switch to LD8

xor al, al



mov cl, 0F6h



call Write_Reg

;clear watchdog timer

xor al, al



mov cl, 30h



call Write_Reg

;watchdog disabled

call Lock_Chip ret

Disable_Watchdog Endp ;[]===============================================

56

MB935 User’s Manual

APPENDIX

;Name : Unlock_Chip

;IN : None

;OUT : None ;[]===============================================

Unlock_Chip

Proc

Near

Mov dx, 4Eh



mov al, 87h



out

dx, al



out

dx, al



ret







Unlock_Chip

Endp



;[]================================================

;Name : Lock_Chip

;IN : None

;OUT : None ;[]================================================

Unlock_Chip Proc Near mov dx, 4Eh

mov al, 0AAh out dx, al

ret Unlock_Chip Endp

;[]================================================

;Name : Write_Reg

;IN : CL - register index

;AL - Value to write

;OUT : None ;[]================================================ Write_Reg Proc Near

push ax mov dx, 4Eh mov al,cl out dx,al pop ax

inc dx out dx,al ret

Write_Reg Endp ;[]================================================

MB935 User’s Manual

57

APPENDIX

;Name : Read_Reg

;IN : CL - register index

; OUT : AL - Value to read ;[]=================================================

==





Read_Reg

Proc

Near

Mov al, cl



mov dx, 4Eh



out

dx, al



inc

dx



in

al, dx



ret





Read_Reg

Endp



;[]================================================

58

MB935 User’s Manual

APPENDIX

D. Digital I/O Sample Code

Filename: W627hf.h //=====================================================================

//

//THIS CODE AND INFORMATION IS PROVIDED "AS IS" WITHOUT WARRANTY OF ANY

//KIND, EITHER EXPRESSED OR IMPLIED, INCLUDING BUT NOT LIMITED TO THE

//IMPLIED WARRANTIES OF MERCHANTABILITY AND/OR FITNESS FOR A PARTICULAR

//PURPOSE.

//

//=====================================================================

#ifndef __W627HF_H



#define __W627HF_H

1

//=====================================================================

#define W627_IOBASE

0x4E

//=====================================================================

#define

W627HF_INDEX_PORT

(W627_IOBASE+0)

#define

W627HF_DATA_PORT

(W627_IOBASE+1)

//===================================================================== #define W627HF_REG_LD 0x07 //=====================================================================

#define W627HF_UNLOCK

0x87

#define

W627HF_LOCK

0xAA

//===================================================================== void Set_W627HF_LD( unsigned char);

void Set_W627HF_Reg( unsigned char, unsigned char); unsigned char Get_W627HF_Reg( unsigned char);

//===================================================================== #endif //__W627HF_H

MB935 User’s Manual

59

APPENDIX

Filename: W627hf.cpp //=====================================================================

//

//THIS CODE AND INFORMATION IS PROVIDED "AS IS" WITHOUT WARRANTY OF ANY

//KIND, EITHER EXPRESSED OR IMPLIED, INCLUDING BUT NOT LIMITED TO THE

//IMPLIED WARRANTIES OF MERCHANTABILITY AND/OR FITNESS FOR A PARTICULAR

//PURPOSE.

//

//===================================================================== #include "W627HF.H"

#include <dos.h> //===================================================================== void Unlock_W627HF (void);

void Lock_W627HF (void); //===================================================================== void Unlock_W627HF (void)

{

outportb(W627HF_INDEX_PORT, W627HF_UNLOCK); outportb(W627HF_INDEX_PORT, W627HF_UNLOCK);

}

//===================================================================== void Lock_W627HF (void)

{

outportb(W627HF_INDEX_PORT, W627HF_LOCK);

}

//===================================================================== void Set_W627HF_LD( unsigned char LD)

{

Unlock_W627HF();

outportb(W627HF_INDEX_PORT, W627HF_REG_LD); outportb(W627HF_DATA_PORT, LD); Lock_W627HF();

}

//===================================================================== void Set_W627HF_Reg( unsigned char REG, unsigned char DATA)

{

Unlock_W627HF(); outportb(W627HF_INDEX_PORT, REG); outportb(W627HF_DATA_PORT, DATA); Lock_W627HF();

}

//===================================================================== unsigned char Get_W627HF_Reg( unsigned char REG)

{

unsigned char Result; Unlock_W627HF(); outportb(W627HF_INDEX_PORT, REG);

Result = inportb(W627HF_DATA_PORT); Lock_W627HF();

return Result;

}

//===================================================================== File of the Main.cpp

60

MB935 User’s Manual

APPENDIX

//=====================================================================

//THIS CODE AND INFORMATION IS PROVIDED "AS IS" WITHOUT WARRANTY OF ANY

//KIND, EITHER EXPRESSED OR IMPLIED, INCLUDING BUT NOT LIMITED TO THE

//IMPLIED WARRANTIES OF MERCHANTABILITY AND/OR FITNESS FOR A PARTICULAR

//PURPOSE.

//===================================================================== #include <dos.h>

#include <conio.h> #include <stdio.h> #include <stdlib.h> #include "W627HF.H"

//===================================================================== void ClrKbBuf(void);

int main (int argc, char *argv[]); //===================================================================== int main (int argc, char *argv[])

{

unsigned char ucDO = 0;

//data for digital output

unsigned char ucDI;

//data for digital input

unsigned char ucBuf;



Set_W627HF_LD( 0x07);

//switch to logic device 7

Set_W627HF_Reg(0xF1, 0x00);

//clear

ucDI = Get_W627HF_Reg(0xF1) & 0x0F;



ClrKbBuf();

while(1)

{

ucDO++;

Set_W627HF_Reg(0xF1, ((ucDO & 0x0F) << 4)); ucBuf = Get_W627HF_Reg(0xF1) & 0x0F;

if (ucBuf != ucDI)

{

ucDI = ucBuf;

printf("Digital I/O Input Changed. Current Data is 0x%X\n",ucDI);

}

if (kbhit())

{

getch();

break;

}

delay(500);

}

return 0;

}

//===================================================================== void ClrKbBuf(void)

{

while(kbhit())

{ getch(); }

}

//---------------------------------------------------------------------------

MB935 User’s Manual

61

APPENDIX

This page is intentionally left blank.

62

MB935 User’s Manual
