WHAT
’
• Intel Mobile Pentium
S NEW
III 600 MHz
processors with SpeedStep™
technology
• 12.1” TFT XGA display
• Four Easy Access Internet
buttons
• Armada E and M Common
Preinstalled Sof tw ar e
AT A GLANCE
• Intel Mobile Pentium
III 600 MHz
with SpeedStep™ technology, or
500 MHz proces sors
• 12.1” or 11.3” TFT XGA displays
• Ultralight weight (3.2 t o 3.4 lbs or
1.5 to 1.6 kg depending on
configuration)
• Less than 1 in/(2.3 cm) thin
• 64MB SDRAM upgradeable –
320MB
• Up to 12GB SMART hard dr iv es
• User removable hard drive
• Integrated Mini PCI modem/ or
Mini PCI modem/NIC combo on
select models
• Keyboard 95% of full size
• Full set of system ports
• Dual Install Windows
2000/Windows NT 4.0 or Dual
Install Windo ws 95/98
• Protected by a one-year ,
Worldwide Limited Warranty —
Certain restrictions and ex clusions
apply. Consul t the Compaq
Customer Support Center for
details.
WHAT’S
SPECIAL
• Ultralight weight (3.2 t o 3.4 lbs or
1.5 to 1.6 kg depending on
configuration)
• Optional Mobile Expansi on Unit
with Multime dia, storage an d
enhanced sec urity features
• Less than 1 inch thin (2.3cm)
• High Capacity Travel Battery
(optional)
• Magnesium display enclosure
• Common docking solutions across
the Armada E and M Series
• Industry leading PC lifecycle
solutions
QUICKSPECS
Overview
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
1. Color Display
.
.
.
.
2. Suspend/Resume Button
.
.
.
.
.
3. Easy Access Internet Buttons
.
.
.
.
4. System ports (USB, Serial, Parallel, IR, VGA)
.
.
.
.
.
5. 102 Key Keyboard (95% of fullsize)
.
.
.
.
6. RJ-11 port (Internal modem models only)
.
.
.
.
.
7. Power/Battery light
.
.
.
.
8. PC Card Slot
.
.
.
.
9. 3D Touchpad Pointing Device
.
.
.
.
.
10. Audio-In/Out ports
.
.
.
.
11. Mobile Expansion Unit (Optional)
.
.
.
.
.
12. Common Armada MultiBay (supports second Hard
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
Drive, CD-RW, SuperDisk 2X LS-120, Battery, 24X
CD-ROM or 4X/8X DVD-ROM)
Compaq Armada M300
13. Diskette Drive Bay
14. System Connector
15. Stereo Speakers
16. Diskette Drive Release Latch
17. AC Power Connector
18. USB Port
19. MEU Ports (Serial, Parallel, Docking, VGA , PS/2)
20. Hard Drive Bay
21. Security Cable Slot
22. On/Off Button
23. AC Power Connector
24. RJ-45 port (Network models only)
25. Li-Ion Battery
1 DA-10381-00A-016 — 12.06.2000
MODELS
Armada M300
Available in multiple
configurations
QUICKSPECS
Standard Features
.
.
.
.
Processor and Panels – One of the following:
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
12.1-inch color TFT XGA with 1024 x 768 resolution (up to 16.7M colors internal)
600MHz on Intel Mobile Pentium
11.3-inch color TFT XGA with 1024 x 768 resolution (up to 16.7M colors internal)
600MHz on Intel Mobile Pentium
500MHz on Intel Mobile Pentium
Note: Mobile Pentium III processors, 600MHz and above, feature Intel SpeedStep™ technology.
Note: Mobile Pentium III processors feature 256KB integrated cache.
Memory
Standard 64 MB 100 MHz SDRAM
Maximum 320 MB 100 MHz SDRAM (adding 256MB to open slot)
Note: Due to the non-industry standard nature of some third-party 256 MB Memory modules, we strongly
recommend using only Compaq branded 256 MB Memory modules to ensure compatibility.
Communications
Type I Mini PCI
Compaq Global Mini PCI 56K (V.90) Modem or
Compaq 56K (V.90) Modem plus Intel® PRO/100+ NIC
Note: Designed only to allow faster downloads from v.90 compliant sources. Maximum achievable download
transmission rates currently do not reach 56 KB/s, and will vary with line conditions.
Note: Modem availability is subject to country regulatory approval.
Keyboard
95% of full-size 102-key compatible keyboard with isolated, inverted-T cursor control keys, and right-control key,
special feature hotkeys for instant access to power conservation, QuickLock / QuickBlank (ex: FN+F6), toggle
between internal and external, or simultaneous displays, battery gauge, speaker volume control, brightness and
contrast.
Easy Access Internet Buttons
The Armada M300 comes with four Easy Access Internet Buttons allowing quick access to your most popular
Internet sites, files and applications. The buttons come pre-set; however, they are user-customizable and
designed to increase productivity by providing one-touch access.
Pointing Device
Touchpad with integrated pick buttons / “Double Tap” mouse-like buttons
PC Card Slots
One Type II PC Card Slot which supports both 32-bit CardBus (Full support in Windows 9.x and Windows 2000)
and 16-bit PC Cards.
Storage
Diskette Drives 1.44 MB
Optical Drives 24X CD-ROM Drive or
8X DVD-ROM Drive
Hard Drives One of the following:
12-GB SMART
6-GB SMART
Multimedia
Compaq Premier•Sound™ for enhanced stereo audio (with optional MEU)
Integrated 16-bit Sound Blaster Pro-compatible stereo audio
Integrated speaker and microphone
Software volume control
Headphone-out
Microphone-in
Software MPEG1 support
DVD movie playback software
8X DVD-ROM Drive with DVD movie playback (on select models)
24X Max CD-ROM Drive (on select models)
PCI graphics
4 MB SGRAM
III processor
®
III processor
®
III processor
Compaq Armada M300
2 DA-10381-00A-016 — 12.06.2000
QUICKSPECS
Standard Features
.
.
.
.
Interfaces
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
PC Card Slot One Type II
Enhanced Parallel Port EPP/ECP 1
Serial Port 1
External Monitor 1
Headphone/Line-out 1
Microphone in 1
AC Power 1
RJ-11 (modem) 1 (Model dependent)
RJ-45 (NIC) 1 (Model dependent)
Infrared Port 1 (4 Mb/s support)
USB Port 1
LED Status Indicators 7
Graphics
ATI RAGE LT Pro, 4MB of SGRAM
Operating System – One of the following:
Dual Install Windows 2000 / Windows NT 4.0
Note: On Dual Install systems, the end user must make a one-time selection at initial start up. End users who
need to change to another Operating System (OS) other than the one originally selected must obtain a
new license for that OS.
Dual Install Windows 98 / Windows 95
Note: On Dual Install systems, the end user must make a one-time sele ction at initial start up. End users who
need to change to another Operating System (OS) other than the one originally selected must obtain a
new license for that OS.
Note: Effective September 30, 2000 all newly announced Armada Notebooks will offer only the Windows 98
operating system. Windows 95 will be available on select Armada Notebooks through December 31,
2000. Provisions are in place through the Compaq custom configuration program for those customers
who still wish to use Windows 95.
Software
Compaq Insight Management Agents
Compaq Intelligent Manageability
Diagnostics for Windows 2000, 9.x or NT
DVD Solution (with optional MEU)
Compaq Power Management
Compaq Security Management
Online Safety and Comfort Guide
Fax Central for Windows 2000, 98 and NT
Online Safety and Comfort Guide
Acrobat Reader
Reference Guide
System Recovery
Each unit is shipped with a CD kit for quick recovery (erases hard disk and restores manufacturer installed
image) and software recovery (installs only selected standard software)
Intelligent Manageability
Compaq Intelligent Manageability, a key component of PC Lifecycle Solutions, is the broad set of manageability
features found on all Compaq Deskpro desktops, Armada portables, Professional Workstation, and ProLiant
server products. These best-in-class features on PC clients comply with industry standards, such as DMI and
Wired for Management, while pioneering new ground in client manageability. Compaq introduced the industry’s
first line of manageable clients in 1995 and has been driving the industry ever since. With Compaq’s lifecycle
management philosophy, enterprises have all of the pieces for end-to-end management and proven tools for
hassle-free management of PCs and significantly lower Total Cost of Ownership.
Intelligent Manageability offers solutions in the areas of Initial Configuration and Deployment, Asset Tracking
and Security, Software Updating and Management, and Fault Notification and Recovery. For more information,
visit our website: www.compaq.com/im.
Compaq Armada M300
(IrDA 4 MB compliant. IR performance will vary depending on
performance of IR peripherals and application used.)
3 DA-10381-00A-016 — 12.06.2000
QUICKSPECS
Standard Features
.
.
.
.
Security
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
Configuration Control Hardware
Memory Change Alert
Ownership Tag
Setup Password
Power-On Password
DriveLock
QuickLock
QuickBlank
Enabled for PC SmartCard options
Power Supply
External AC Adapter; 6-foot power cord included. Total length including External AC adapter is 12 feet (3.66
Meters)
Battery
Li-Ion batteries are supported, with up to two hours of battery life supported with the standard 4 cell main
battery; up to three hours when using a MultiBay battery in the Mobile Expansion Unit. An optional HighCapacity Travel Battery* is also available which provides up to 3 hours of battery life.
Note: An Armada M300 with the High-Capacity Travel Battery attached to the unit cannot be placed in an
ArmadaStation EM, Convenience Base EM, or Port Replicator EM
Note: Actual results may vary with individual usage. When tested in standard configuration, using the Ziff-
Davis BatteryMark Test version 2.0, the battery life of the Armada M300 will range up to 2 hours.
Standard configuration at time of announce is considered to be one battery, a 1024x768 (High color – 16
Bit color) panel set at 50% brightness, 64MB RAM, and no drives other than the hard drive active.
Power Conservation
Intel SpeedStep Technology (allows a Battery Optimized Mode where CPU draws 50% of normal power yet
affords 70 to 80% of maximum PIII processing speed)
Hibernation
Instant-on via Standby
Pop-ups with three presets
One custom level of power conservation
ACPI compliant
MultiBay Devices (with optional MEU)
Supports swapping with power or in suspend mode under Windows 9.x, Windows 2000 and NT4.0
Supports Hot Swapping : CD-ROM, DVD-ROM, MultiBay Battery
Supports swapping with power or in suspend mode Secondary Hard Drive, 2X LS-120
Service and Support
Compaq Services includes a one-year, Worldwide Limited Warranty, pick-up or carry-in, toll-free 7 x 24
hardware technical phone support. Optional services include; upgrade to three years standard warranty, onsite
warranty, application and operating system support.
Note: Certain restrictions and exclusions apply. Consult the Compaq Customer Support Center for details.
Model Naming Convention
The Etymology of a Model Name:
Compaq Armada M300
4 DA-10381-00A-016 — 12.06.2000
QUICKSPECS
Compaq Armada M300
Standard Features
.
.
.
.
Models
.
.
.
.
AM3 P3600T2X126458 Display 12.1-inch color TFT X GA Optical Drive None
191911-xx2 Processor Intel Pentium III 600-MHz Hard Drive 12-GB SMART
AM3 P3600T2X1264N2 Display 12.1-inch color TFT XGA Optical Drive None
191911-xx8
AM3 P3600T2X12C6458
180400-xx2 Processor Intel Pentium III 600-MHz Hard Drive 12-GB SMART
AM3 P3600T2X12C64N2 Display 12.1-inch color TFT XGA Optical Drive None
180400-xx8
AM3 P3600T2X12C6458 N Display 12.1-inch color TFT XGA Optical Drive None
180400-xx3 Processor Intel Pentium III 600-MHz Hard Drive 12-GB SMART
.
.
.
.
.
.
.
.
.
.
.
Cache Memory 256-KB integrated Modem
.
.
.
.
Memory Graphics ATI RAGE LT Pro - 4MB of SGRAM
.
.
.
.
.
Standard 64 MB Audio Compaq Premier•Sound™
.
.
.
.
.
Maximum 320 MB Software Windows 98/95 (Dual Install)
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
Processor Intel Pentium III 600-MHz Hard Drive 12-GB SMART
.
.
.
.
.
Cache Memory 256-KB integrated Modem
.
.
.
.
Memory Graphics ATI RAGE LT Pro - 4MB of SGRAM
.
.
.
.
.
Standard 64 MB Audio Compaq Premier•Sound™
.
.
.
.
.
Maximum 320 MB Software Windows 2000/NT 4.0 (Dual Install)
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
Display 12.1-inch color TFT X GA Optical Drive None
.
.
.
.
.
.
.
.
.
Cache Memory 256-KB integrated Modem Mini-PCI v.90 modem / 10/100 TX NIC
.
.
.
.
.
.
.
.
.
Memory Graphics ATI RAGE LT Pro - 4MB of SGRAM
.
.
.
.
Standard 64 MB Audio Compaq Premier•Sound™
.
.
.
.
.
Maximum 320 MB Software Windows 98/95 (Dual Install)
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
Processor Intel Pentium III 600-MHz Hard Drive 12-GB SMART
.
.
.
.
.
Cache Memory 256-KB integrated Modem Mini-PCI v.90 modem / 10/100 TX NIC
.
.
.
.
.
.
.
.
Memory Graphics ATI RAGE LT Pro - 4MB of SGRAM
.
.
.
.
.
Standard 64 MB Audio Compaq Premier•Sound™
.
.
.
.
Maximum 320 MB Software Windows 2000/NT 4.0 (Dual Install)
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
Cache Memory 256-KB integrated Modem
.
.
.
.
.
.
.
.
Memory Graphics ATI RAGE LT Pro - 4MB of SGRAM
.
.
.
.
.
Standard 64 MB Audio Compaq Premier•Sound™
.
.
.
.
.
Maximum 320 MB Software Windows 98/95 (Dual Install)
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
Combo
Combo
Mini-PCI v.90 modem / 10/100 TX NIC
Combo
5 DA-10381-00A-016 — 12.06.2000
QUICKSPECS
Compaq Armada M300
Standard Features
.
.
.
.
.
.
.
AM3 P3600T2X12C64N2N Display 12.1-inch color TFT XGA Optical Drive None
180400-xx9
AM3 P3600T1X66458 Display 11.3-inch color TFT XGA Optical Drive None
180427-xx2 Processor Intel Pentium III 600-MHz Hard Drive 6-GB SMART
AM3 P3600T1X664N2 Display 11.3-inch color TFT XGA Optical Drive None
180427-xx8
AM3 P3600T1X6C6458
180428-xx2 Processor Intel Pentium III 600-MHz Hard Drive 6-GB SMART
AM3 P3600T1X6C64N2 Display 11.3-inch color TFT X GA Optical Drive None
180428-xx8
.
.
.
.
.
Processor Intel Pentium III 600-MHz Hard Drive 12-GB SMART
.
.
.
.
.
Cache Memory 256-KB integrated Modem Mini-PCI v.90 modem / 10/100 TX NIC
.
.
.
.
.
.
.
.
Memory Graphics ATI RAGE LT Pro - 4MB of SGRAM
.
.
.
.
.
Standard 64 MB Audio Compaq Premier•Sound™
.
.
.
.
.
Maximum 320 MB Software Windows 2000/NT 4.0 (Dual Install)
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
Cache Memory 256-KB integrated Modem
.
.
.
.
.
Memory Graphics ATI RAGE LT Pro - 4MB of SGRAM
.
.
.
.
.
Standard 64 MB Audio Compaq Premier•Sound™
.
.
.
.
.
Maximum 320 MB Software Windows 98/95 (Dual Install)
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
Processor Intel Pentium III 600-MHz Hard Drive 6-GB SMART
.
.
.
.
.
Cache Memory 256-KB integrated Modem
.
.
.
.
.
Memory Graphics ATI RAGE LT Pro - 4MB of SGRAM
.
.
.
.
.
Standard 64 MB Audio Compaq Premier•Sound™
.
.
.
.
.
Maximum 320 MB Software Windows 2000/NT 4.0 (Dual Install)
.
.
.
.
.
.
.
.
.
.
.
.
.
.
Display 11.3-inch color TFT X GA Optical Drive None
.
.
.
.
.
.
.
.
.
.
Cache Memory 256-KB integrated Modem Mini-PCI v.90 modem / 10/100 TX NIC
.
.
.
.
.
.
.
.
Memory Graphics ATI RAGE LT Pro - 4MB of SGRAM
.
.
.
.
.
Standard 64 MB Audio Compaq Premier•Sound™
.
.
.
.
.
Maximum 320 MB Software Windows 98/95 (Dual Install)
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
Processor Intel Pentium III 600-MHz Hard Drive 6-GB SMART
.
.
.
.
.
Cache Memory 256-KB integrated Modem Mini-PCI v.90 modem / 10/100 TX NIC
.
.
.
.
.
.
.
.
Memory Graphics ATI RAGE LT Pro - 4MB of SGRAM
.
.
.
.
.
Standard 64 MB Audio Compaq Premier•Sound™
.
.
.
.
.
Maximum 320 MB Software Windows 2000/NT 4.0 (Dual Install)
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
Combo
Combo
Combo
6 DA-10381-00A-016 — 12.06.2000
QUICKSPECS
Compaq Armada M300
Standard Features
.
.
AM3 P3600T1X6C6458N Display 11.3-inch color TFT XGA Optical Drive None
180428-xx3
AM3 P3600T1X6C64N2N Display 11.3-inch color TFT X GA Optical Drive None
180428-xx9 Processor Intel Pentium III 600-MHz Hard Drive 6-GB SMART
AM3 P3500T1XC126458 Display 11.3-inch color TFT XGA Optical Drive None
165288-xx2 Processor Intel Pentium III 500-MHz Hard Drive 12-GB SMART
AM3 P3500T1XC126458 Display 11.3-inch color TFT XGA Optical Drive None
165288-xx6 Processor Intel Pentium III 500-MHz Hard Drive 12-GB SMART
AM3 P3500T1XC1264N2 Display 11.3-inch color TFT XGA Optical Drive None
165288-xx8 Processor Intel Pentium III 500-MHz Hard Drive 12-GB SMART
.
.
.
.
.
Processor Intel Pentium III 600-MHz Hard Drive 6-GB SMART
.
.
.
.
.
Cache Memory 256-KB integrated Modem Mini-PCI v.90 modem / 10/100 TX NIC
.
.
.
.
.
.
.
.
Memory Graphics ATI RAGE LT Pro - 4MB of SGRAM
.
.
.
.
.
Standard 64 MB Audio Compaq Premier•Sound™
.
.
.
.
.
Maximum 320 MB Software Windows 98/95 (Dual Install)
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
Cache Memory 256-KB integrated Modem
.
.
.
.
.
.
.
.
.
Memory Graphics ATI RAGE LT Pro - 4MB of SGRAM
.
.
.
.
Standard 64 MB Audio Compaq Premier•Sound™
.
.
.
.
.
Maximum 320 MB Software Windows 2000/NT 4.0 (Dual Install)
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
Cache Memory 256-KB integrated Modem Mini-PCI v.90 modem / 10/100 TX NIC
.
.
.
.
.
.
.
.
Memory Graphics ATI RAGE LT Pro - 4MB of SGRAM
.
.
.
.
.
Standard 64 MB Audio Compaq Premier•Sound™
.
.
.
.
.
Maximum 320 MB Software Windows 98/95 (Dual Install)
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
Cache Memory 256-KB integrated Modem Mini-PCI v.90 modem / 10/100 TX NIC
.
.
.
.
.
.
.
.
.
Memory Graphics ATI RAGE LT Pro - 4MB of SGRAM
.
.
.
.
Standard 64 MB Audio Compaq Premier•Sound™
.
.
.
.
.
Maximum 320 MB Software Windows NT 4.0
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
Cache Memory 256-KB integrated Modem Mini-PCI v.90 modem / 10/100 TX NIC
.
.
.
.
.
.
.
.
Memory Graphics ATI RAGE LT Pro - 4MB of SGRAM
.
.
.
.
.
Standard 64 MB Audio Compaq Premier•Sound™
.
.
.
.
Maximum 320 MB Software Windows 2000/NT 4.0 (Dual Install)
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
Combo
Mini-PCI v.90 modem / 10/100 TX NIC
Combo
Combo
Combo
Combo
7 DA-10381-00A-016 — 12.06.2000
QUICKSPECS
Compaq Armada M300
Options
.
.
.
.
Memory
.
.
.
.
256-MB Memory Upgrade
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
(Due to the non-industry standard nature of some third-party 256 MB Memory modules, we
strongly recommend using only Compaq branded 256 MB Memory modules to ensure
compatibility.)
128-MB Memory Upgrade
64-MB Memory Upgrade
32-MB Memory Upgrade
Monitors
TFT8020 Flat Panel Color 18-inch (carbon)
TFT5010 Flat Panel Color 15-inch (carbon)
TFT5005 Flat Panel Color 15-inch (carbon)
V710 Color 17-inch
P1100 Color 21-inch
S910 Color 19-inch
MultiBay Hard Drives
20-GB 4200 rpm SMART Ultra ATA/66 Hard Drive
10-GB 4200 rpm SMART Ultra ATA/66 Hard Drive
12-GB 4200 rpm SMART Ultra ATA/66 Hard Drive
6-GB 4200 rpm SMART Ultra ATA/66 Hard Drive
MultiBay Storage Drives
CD-RW
SuperDisk 2X LS-120
24X CD-ROM Drive
8X DVD-ROM Drive
Mobile Expansion Unit (MEU)
MEU with 24X Max CD-ROM Drive (Data transfer rates will vary from 150 KB/s to 3600 KB/s.)
MEU with 8X DVD-ROM Drive
Connectivity
Compaq M420 56K Global Modem
10/100 TX PC Card UTP Controller
100Base TX Ethernet Upgrade
1394 PC Card
For additional compatible PC Cards, view the Compaq PC Card Solutions List on the Compaq
website at: http://www.compaq.com/support/techpubs/pcmcia/
Note: Designed only to allow faster downloads from v.90 compliant sources. Maximum achievable
download transmission rates currently do not reach 56 KB/s, and will vary with line
conditions. Modem only supports Windows 9.x and Windows NT 4.0.
Wireless Connectivity
Compaq WL100 11 Mbps Wireless LAN PC Card
Compaq WL400 11 Mbps Wireless LAN Hardware Access Point
Compaq WL300 Software Access Point 11Mbps
For more information on Compaq WLAN Wireless LAN solutions visit:
http://www.compaq.com/products/wlan/wl100-specifications.html
Expansion Bases
ArmadaStation EM
ArmadaStation EM With Intel NIC
ArmadaStation EM With 3Com NIC
ArmadaStation Tower Stand
Convenience Base EM
Convenience Base EM With Intel NIC
Convenience Base EM With 3Com NIC
161554-B21
400313-B21
400312-B21
400311-B21
159244-001
154486-001
201430-001
187895-001
325606-001
138485-001
212790-B25
212789-B25
163531-B25
173395-B25
136186-B25
197895-B25
298452-B25
138230-B25
134097-B21
187774-B21
317900-001
335506-B21
225435-001
177593-B25
146927-001
158603-001
157209-B21
383500-xx1
120266-xx1
120264-xx1
123129-B25
382500-xx1
120971-xx1
120970-xx1
8 DA-10381-00A-016 — 12.06.2000
QUICKSPECS
Compaq Armada M300
Options
.
.
.
.
.
Expansion Bases (continued)
.
.
.
.
Convenience Base Monitor Cover
.
.
.
.
.
Port Replicator EM
.
.
.
.
PCI IBM Token Ring Card
.
.
.
.
PCI CardBus Reader
.
.
.
.
.
Note: The Armada M300 requires the optional Mobile Expansion Unit (MEU) for docking with any
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
Power
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
Input Devices
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
Security
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
Useful Accessories
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
Carrying Cases
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
of the expansion bases listed above
Note: An Armada M300 with the High-Capacity Travel Battery attached to the unit cannot be
placed in any EM docking solution
.
Primary Battery (4-cells)
High Capacity Travel Battery
Note: An Armada M300 with the High-Capacity Travel Battery attached to the unit cannot be
placed in any EM docking solution.
Common Armada Power Solutions – Armada E500, Armada M300 and Armada M700
MultiBay Battery (6-c ells)
External Battery Charger
AC Adapter 50W
Auto Power Adapter/ Charger
Aircraft Power Adapter
AC Line Cord (10-ft)
External Enhanced III Keyboard (carbon)
Compaq 2 Button Mouse (carbon)
USB 2 Button Scroll Mouse (carbon)
External 10-Key Numeric Keypad (carbon)
Biometric PC Card
Security Cable Lock
Compaq Smart Card PC Card Reader
Compaq Armada Headset with microphone
MP1400 Microportable Projector
MP1600 Microportable Projector
MP1800 Microportable Projector
Multimedia Adapter & Remote Kit (comes with the MP1800)
MP1600 Video Adapter
MP1600 Lamp replacement kit
MP1800/1400 Lamp replacement kit
Compaq Value Case
Compaq Workstation Case
Compaq Global Case
Compaq Professional Case (nylon)
Compaq Professional Case (leather)
Armada M300 and Armada M700 specific
Compaq M Series Portfolio Case
Compaq Ultralight Case
For additional Compaq Brand cases, call 1-800-888-5903.
122931-xx1
382300-xx1
133749-B21
127397-B25
134096-B21
134099-B21
387937-B25
135555-xxx
120765-xxx
401043-B25
386504-B21
217932-xx2
118003-008
103180-B21
195255-B25
294317-B21
146805-B25
294316-B21
135646-B25
220460-001
174626-xx4
386202-xx2
180226-xx1
174963-001
116298-001
118052-001
189789-001
294266-B21
294267-B21
294268-B21
401366-B21
401367-B21
167337-B21
167336-B21
9 DA-10381-00A-016 — 12.06.2000
QUICKSPECS
Memory
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
STANDARD MEMORY
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
STANDARD MEMORY
.
.
.
.
WITH OPTIONAL MEMORY UPGRADES
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
64 MB installed on board (1 slot available)
Standard Slot
64 MB
Support for up to 320 MB of SDRAM is available with the installation of optional SDRAM
Memory Upgrades.
Up To Slot
128 MB
196 MB
320 MB
Note: This chart does not represent all possible memory configurations. Due to the non-
industry standard nature of some third-party 256 MB Memory modules, we strongly
recommend using only Compaq branded 256 MB Memory modules to ensure
compatibility.
Following are memory options available from Compaq:
• 256-MB 100 MHz Memory Upgrade 161554-B21
• 128-MB 100 MHz Memory Upgrade 400313-B21
• 64-MB 100 MHz Memory Upgrade 400312-B21
• 32-MB 100 MHz Memory Upgrade 400311-B21
Note: Due to the non-industry standard nature of some third-party 256 MB Memory modules,
we strongly recommend using only Compaq branded 256 MB Memory modules to
ensure compatibility.
Compaq Armada M300
Compaq Armada M300
1
EMPTY
1
10 DA-10381-00A-016 — 12.06.2000
1MultiBay
2 Diskette Drive Bay
3 Hard Drive Bay
QUICKSPECS
Storage
.
.
.
.
DRIVE SUPPORT
.
.
.
.
.
System Drive Support Quantity
.
.
.
.
.
.
.
Removable Media
.
.
.
.
1.44-MB Diskette Drive Up to 1 External con nects via parallel port
.
.
.
.
.
.
.
.
.
Hard Drives
.
.
.
.
12-GB SMART Hard Drive Up to 1 Hard Drive Bay
.
.
.
6-GB SMART Hard Driv e Up to 1 Hard Drive Bay
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
MEU Drive Support Quantity
.
.
.
.
.
.
.
Removable Media
.
.
.
.
.
1.44-MB Diskette Drive Up to 1 Diskette Drive Bay
.
.
.
24X Max CD-ROM Drive Up to 1 MultiBay
.
.
.
.
8X DVD-ROM Drive Up to 1 MultiBay
.
.
.
.
SuperDisk 2X LS-120 Up to 1 MultiBay
.
.
.
.
Hard Drives
.
.
.
.
12-GB SMART Hard Drive Up to 1 MultiBay
.
.
.
.
6-GB SMART Hard Driv e Up to 1 MultiBay
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
Supported
Supported
Drive Bay
Supported
Drive Bay
Supported
Compaq Armada M300
11 DA-10381-00A-016 — 12.06.2000
QUICKSPECS
Technical Specifications
.
System Unit Dimensions (HxWxD)
12.1-Inch Color TFT XGA
Display
.
.
.
.
.
.
12.1” TFT panel display 0.89 x 10.5 x 9.5 in/ 2.2 x 26.6 x 24.2 cm
.
.
.
.
11.3” TFT panel display 0.89 x 10.47 x 9 in/ 2.3 x 26.4 x 22.9 cm
.
.
.
.
.
Weight
.
.
.
.
Min/Max 3.18 lbs to 3.37 lbs/1.44 kg to 1.53 kg
.
.
.
.
.
Stand-Alone Power Requirements
.
.
.
.
.
Nominal Operating Voltage (Li-Ion) 14.2 VDC
.
.
.
.
Maximum Operating Power 35W
.
.
.
.
.
Peak Operating Power 40W
.
.
.
.
.
Temperature
.
.
.
.
Operating 50° to 95°F/10° to 35°C
.
.
.
.
.
Non-operating –4° to 140°F/–20° to 60°C
.
.
.
.
.
Relative Humidity (non-condensing)
.
.
.
.
Operating 10% to 90% relative humidity, non-condensing
.
.
.
.
.
Non-operating 5% to 90% relative humidity, 101.6°F/38.7°C Maximum
.
.
.
.
.
.
.
.
Shock
.
.
.
.
.
Operating 10 G, 11 ms, half-sine
.
.
.
.
.
Non-operating 60 G, 11 ms, half-sine
.
.
.
.
Vibration
.
.
.
.
.
Operating 0.5 G, 10 to 500 Hz, 0.5 Oct/Min sweep rate
.
.
.
.
Non-operating 1.0 G, 10 to 500 Hz, 0.5 Oct/Min sweep rate
.
.
.
.
.
Maximum Altitude (unpressurized)
.
.
.
.
.
Operating 0-10,000 ft/3,048 m (14.7 to 10.1 psia)
.
.
.
.
Non-operating 0-30,000 ft/9,144 m (14.7 to 4.4 psia)
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
Dimensions (HxW) 10.3x7.8 in (26.1x19.9 cm)
.
.
.
.
Diagonal Size 12.1 in (30.7 cm)
.
.
.
.
.
Mounting Internal
.
.
.
.
.
Number of Colors 16M
.
.
.
.
Contrast Ratio 125:1
.
.
.
.
.
Brightness 130 nit typical AC only/70 on battery115 nit minimum
.
.
.
.
.
Pixel Resolution
.
.
.
.
Pitch 0.264 x 0.264 mm
.
.
.
.
.
Format 1024x768
.
.
.
.
.
Configuration RGB Stripe
.
.
.
.
Backlight CCFT
.
.
.
.
.
Character Display 80 x 25
.
.
.
.
Total Power Consumption 4W
.
.
.
.
.
Refresh 640 x 480, 800 x 600, 1024 x 768, 1280 x 1024, 1600 x
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
Compaq Armada M300
wet bulb temperature
1200
12 DA-10381-00A-016 — 12.06.2000
Display
Hard Drives
QUICKSPECS
Compaq Armada M300
Technical Specifications
.
.
Dimensions (HxW) 7.5 x 10.1 in/19 x 25.6 cm11.3-Inch Color TFT XGA
.
.
.
.
.
Diagonal Size 11.3 in/28.7 cm
.
.
.
.
.
Mounting Internal
.
.
.
.
Number of Colors 16M
.
.
.
.
.
Contrast Ratio 125:1
.
.
.
.
.
Brightness 120 to 150 nit AC only/80 on battery
.
.
.
.
Pixel Resolution
.
.
.
.
.
Pitch 0.264 x 0.264 mm
.
.
.
.
.
Format 800 x 600
.
.
.
.
Configuration RGB Stripe
.
.
.
.
.
Backlight CCFT
.
.
.
.
Character Display 80 x 25
.
.
.
.
.
Total Power Consumption 4W
.
.
.
.
.
Refresh 640 x 480, 800 x 600, 1024 x 768, 1280 x 1024, 1600 x
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
12 GB Capacity
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
6 GB Capacity
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
12 GB
Height 9.5 mm Single Track 4 ms
Width 2.5 in/63.5 mm Average 13 ms (read)
Interface ATA Full-Stroke 23 ms
Transfer Rate Rotational Speed 4200 rpm
Synchronous 33.3 MB/s Operating Temperature 41° to 131°F/5° to 55°C
(Maximum)
6 GB
Height 9.5 mm Single Track 4 ms
Width 2.5 in/63.5 mm Average 13 ms (read)
Interface ATA Full-Stroke 23 ms
Transfer Rate Rotational Speed 4200 rpm
Synchronous 33.3 MB/s Operating Temperature 41° to 131°F/5° to 55°C
(Maximum)
1200
Seek Time (typical reads, including settling)
Seek Time (typical reads, including settling)
13 DA-10381-00A-016 — 12.06.2000
QUICKSPECS
Technical Specifications
.
Diskette Drive Diskette Size 3.5 in
External AC Adapter Weight 0.55 lb/0.25 kg
.
.
.
.
.
.
.
.
Weight 0.47 lb/0.21 kg
.
.
.
.
Light On drive
.
.
.
.
.
Height 0.55in/1.4 cm
.
.
.
.
.
Bytes per Sector 512
.
.
.
.
Sectors per track
.
.
.
.
.
High density 18 (1.44 MB)/15 (1.2 MB)
.
.
.
.
.
Low density 9
.
.
.
.
Tracks per side
.
.
.
.
.
High density 80 (1.44 MB)/80 (1.2 MB)
.
.
.
.
Low density 80
.
.
.
.
.
Read/Write heads 2
.
.
.
.
.
Access Times
.
.
.
.
Track-to track (high/low) 3 ms/6 ms
.
.
.
.
.
Average (high/low) 94 ms/174 ms
.
.
.
.
.
Settling time 15 ms
.
.
.
.
Latency average 100 ms
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
Power Supply (Input)
.
.
.
.
.
Operating Voltage 90 to 260 VAC RMS
.
.
.
.
.
Operating Current 1.1 A RMS
.
.
.
.
Operating Frequency Range 47 to 63 Hz AC
.
.
.
.
.
Maximum Transient 4/50 kV
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
Compaq Armada M300
14 DA-10381-00A-016 — 12.06.2000
QUICKSPECS
Compaq Armada M300
Technical Specifications
.
Li-Ion Battery Pack Dimensions (HxWxD) 0.9 x 10.47 x 0.9 in/2.3 x 26.6 x 2.3 cm
(4-cell) Weight 0.48 lb/0.21 kg
Li-Ion Battery Pack
High-Capcaity
(4-cell) Weight 0.93 lb/0.42 kg
Mobile Expansion Unit Dimensions (HxWxL) 0.9 x 10.47 x 9 in/2.3 x 26.6 x 22.9 cm
(Optional)
.
.
.
.
.
.
.
.
.
.
.
Cells 4 Li-Ion
.
.
.
.
Energy
.
.
.
.
.
Voltage 14.4 V
.
.
.
.
.
Amp-hour capacity 1.69 Ah
.
.
.
.
Watt-hour capacity 27Wh
.
.
.
.
.
Temperature
.
.
.
.
.
Operating 41° to 95°F/5° to 35°C
.
.
.
.
Non-operating –22° to 140°F/–30° to 60°C
.
.
.
.
.
.
.
.
.
.
.
.
.
.
Dimensions (HxWxD) 1.8 x 10.6 x 1.2 in/4.6 x 26.6 x 3.2 cm
.
.
.
.
.
.
.
.
.
.
.
.
.
.
Cells 4 Li-Ion
.
.
.
.
Energy
.
.
.
.
.
Voltage 14.4 V
.
.
.
.
.
Amp-hour capacity 2.8 Ah
.
.
.
.
Watt-hour capacity 34Wh
.
.
.
.
.
Temperature
.
.
.
.
Operating 41° to 95°F/5° to 35°C
.
.
.
.
.
Non-operating –22° to 140°F/–30° to 60°C
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
Weight With CD 1.9 lbs/.86 kg
.
.
.
.
.
.
.
.
Ports Parallel, serial, (2) PS/2, USB, VGA, Audio in/out
.
.
.
.
.
Connectors 220-pin docking connector, system docking connector
.
.
.
.
Audio (2) Stereo speakers
.
.
.
.
.
FDD Support Supports M300 Diskette Drive
.
.
.
.
.
MultiBay Support CD-ROM, 4X/8X DVD-ROM, 2X SuperDisk LS-120,
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
With DVD 1.85 lbs/.84 kg
second Hard Drive, second Battery
15 DA-10381-00A-016 — 12.06.2000
24X Max CD-ROM Drive
(Supported in opti onal MEU)
8X DVD ROM Drive
(Supported in opti onal MEU)
QUICKSPECS
Compaq Armada M300
Technical Specifications
.
.
Applicable Disk CD-ROM (Mode 1, 2 and 3), CD-XA ready (Mode 2,
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
Center Hole Diameter 0.59 in/15 mm
.
.
.
.
.
Disk Diameter 12 cm, 8 cm
.
.
.
.
Disk Thickness 1.2 mm
.
.
.
.
.
Track Pitch 1.6 µm
.
.
.
.
.
Access Times (typical reads, including settling)
.
.
.
.
Random < 150 ms
.
.
.
.
.
Full-Stroke < 300 ms
.
.
.
.
.
Audio Output Level
.
.
.
.
Line-out 0.7 Vrms
.
.
.
.
.
Cache Buffer 128 KB
.
.
.
.
.
Data Transfer Rate (typical, including settling)
.
.
.
.
Sustained (16X) 150 KB/s (sustained 1X)
.
.
.
.
.
Variable 1500 to 3600 KB/s (10X to 24X)
.
.
.
.
.
Normal PIO Mode 4 (single burst) 16.66 MB/s
.
.
.
.
Start-up Time < 8 sec
.
.
.
.
.
Stop Time < 4 sec
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
Center Hole Diameter 0.59 in/0.39 cm
.
.
.
.
.
.
.
.
.
Disk Diameter 12 cm/8 cm
.
.
.
.
Disk Thickness 1.2 mm
.
.
.
.
.
Track Pitch 0.74 µm
.
.
.
.
.
Access Times (typical reads, including settling)
.
.
.
.
Random < 150 ms
.
.
.
.
.
Full-Stroke < 225 ms
.
.
.
.
.
Audio Output Level
.
.
.
.
Line out 0.7 Vrms
.
.
.
.
.
Cache Buffer 128 KB/s (minimum)
.
.
.
.
.
Data Transfer Rate (typical, including settling)
.
.
.
.
Sustained (16X) 150 KB/s
.
.
.
.
.
Sustained 4X DVD 5,520 KB/s
.
.
.
.
.
Normal PIO Mode 4 (single burst) 16.6 MB/s
.
.
.
.
Start-up Time < 15 sec
.
.
.
.
.
Stop Time < 6 sec
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
Form 1 and 2), CD-I ready (Mode 2, Form 1 and 2), CDR (read only), CD Plus, Photo CD (Single and Multisession),
CD-Extra, Video CD, CD-WO (fixed packets only),
CD-Bridge
16 DA-10381-00A-016 — 12.06.2000
Compaq 56K(V.90) plus
Intel PRO/100+ Mini PCI
QUICKSPECS
Compaq Armada M300
Technical Specifications
.
.
Form Factor Mini-PCI Type 1B per Specification
.
.
.
.
.
.
.
.
OS Support (with all released Service Packs)
.
.
.
.
.
.
.
.
.
.
.
.
Power Management Support APM Revision 1.2, ACPI, Compaq Power
.
.
.
.
.
.
.
.
Approvals/Certifications
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
Modem Device Driver Name Compaq 56K (V.90) Mini PCI
.
.
.
.
.
Data Mode Capabilities V.90 (a-law, mu-law)
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
Fax Mode Capabilities TIA-578-S (Class 1)
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
Command Set V.250 (Partial)
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
Windows 95 (OSR2.x), Windows 98 (Gold, SE)
Windows NT4.0, Windows 2000, DOS Application
Support under Windows
Management Extensions for Windows NT
UL, CSA, NEMKO, CCIB, Industry Canada, FCC Part
68, CTR21, FCC Part 15 Class B, Canadian ICES003 Class B, C.I.S.P.R.22, Australian ACA, CE
Mark, Other Countries
K56flex (a-law, mu-law)
V.8bis
V.80
V42.bis, MNP5 (Compression)
V.42 (LAPM, MNP2-4) (Error Correction)
V.34 (file date: 10/96)
Optional symbol rates: 2800, 3429
Asymmetric Symbol rates
Synchronous primary channel data signaling rates:
3600, 31200
Automatic rate re-negotiation
V.32bis
V.32
V.23
V.22bis
V.22
V.21
Bell 212A
Bell 103J
T.30, T.4 (Group 3)
V.17
V.29
V.27ter
V.21 Channel 2
TIA-602
Identification: +GMI, +GMM, +GMR
Port control :+IPR, +ICF, +IFC, + Iirr
Modulation: +MS, +MR, +MA
Error control: +ES, +ER, +EB, +ESR, +ETBM
Data compression: +DS, +DR
V.251
17 DA-10381-00A-016 — 12.06.2000
QUICKSPECS
Compaq Armada M300
Technical Specifications
.
Intel PRO/100+ Mini PCI Ethernet Features 10 Mbps Ethernet: IEEE 802.3 standard 10Base T
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
Data Link Layers IEEE 802.2 LLC
.
.
.
.
.
.
.
.
Software support Artisoft Lantastic 7.0, 8.0, Dedicated Server 1.1
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
Protocol support TCP/IP
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
100 Mbps Ethernet: IEEE 802.3u standard 100Base
TX
Full Duplex at 10 and 100Mbps
Auto-Negotiation
Wake on LAN from all power managed states,
including soft off (S5)
Boot on LAN from OFF
Lower Power State on Link Loss
SNAP
Banyan 7.x, 8.5x
IBM LAN Server Version 1.2, 1.3, 2.0, 4.0
Microsoft NT 3.51, NT 4.0. Windows 2000
Novell Netware 3.1x, 4.x, 5.x
Novell IPX/SPX and Microsoft compatible
Novel IPX ODI
Microsoft NetBEUI
Sun Microsystems PC-NFS
Banyan Vines Ethernet
IBM DLC
18 DA-10381-00A-016 — 12.06.2000
Loading...
