Intel® Desktop Board D848PMB Product Guide

Order Number: C54219-002

Revision History

Revision Revision History Date

-001

If an FCC declaration of conformity marking is present on the board, the following statement applies:

First release of the Intel

Desktop Board D848PMB Product Guide.

FCC Declaration of Conformity

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

For questions related to the EMC performance of this product, contact:

Intel Corporation 5200 N.E. Elam Young Parkway Hillsboro, OR 97124 1-800-628-8686

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and the receiver.

• Connect the equipment to an outlet on a circuit other than the one to which the receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

Canadian Department of Communications Compliance Statement

This digital apparatus does not exceed the Class B limits for radio noise emissions from digital apparatus set out in the Radio Interference Regulations of the Canadian Department of Communications.

Le présent appareil numerique német pas de bruits radioélectriques dépassant les limites applicables aux appareils numériques de la classe B prescrites dans le Réglement sur le broullage radioélectrique édicté par le ministére des Communications du Canada.

Disclaimer

Information in this document is provided in connection with Intel® products. No license, express or implied, by estoppel or otherwise, to any intellectual property rights is granted by this document. Except as provided in Intel’s Terms and Conditions of Sale for such products, Intel assumes no liability whatsoever, and Intel disclaims any express or implied warranty, relating to sale and/or use of Intel products including liability or warranties relating to fitness for a particular purpose, merchantability, or infringement of any patent, copyright or other intellectual property right. Intel products are not intended for use in medical, life saving, or life sustaining applications. Intel may make changes to specifications and product descriptions at any time, without notice.

Desktop Board D848PMB may contain design defects or errors known as errata which may cause the product to deviate from published specifications. Current characterized errata are available on request.

Contact your local Intel sales office or your distributor to obtain the latest specifications and before placing your product order.

Copies of documents which have an ordering number and are referenced in this document, or other Intel literature, may be obtained from Intel Corporation by going to the World Wide Web site at: http://www.intel.com/ or by calling 1-800-548-4725.

Intel, Pentium, and Celeron are registered trademarks of Intel Corporation or its subsidiaries in the United States and other countries.

* Other names and brands may be claimed as the property of others.

October 2003

Preface

This Product Guide gives information about board layout, component installation, BIOS Setup menus, and regulatory requirements for Intel

Desktop Board D848PMB.

Intended Audience

The Product Guide is intended for technically qualified personnel. It is not intended for general audiences.

Information Layout

The chapters in this Product Guide are arranged as follows:

• 1 Desktop Board Features

• 2 Installing and Replacing Desktop Board Components

desktop board and other hardware components.

• 3 Updating the BIOS

• 4 Using the BIOS Setup Program

• 5 Desktop Board Resources

• A Error Messages and Indicators

• B Regulatory Compliance

: a summary of product features.

: instruction on how to install the

: instructions on how to update the BIOS.

: contents of the BIOS Setup menus and submenus

: information about connectors and desktop board resources.

: information about BIOS error messages and beep codes.

: safety and EMC regulations, product certification.

Conventions

The following conventions are used in this manual:

WARNING

Warnings indicate conditions that, if not observed, can cause personal injury.

CAUTION

Cautions warn the user about how to prevent damage to hardware or loss of data.

NOTE

Notes call attention to important information.

iii

Intel Desktop Board D848PMB Product Guide

Terminology

The table below gives descriptions to some common terms used in the product guide.

Term Description

GB Gigabyte (1,073,741,824 bytes)

GHz Gigahertz (one billion hertz)

KB Kilobyte (1024 bytes)

MB Megabyte (1,048,576 bytes)

Mbit Megabit (1,048,576 bits)

MHz Megahertz (one million hertz)

Contents

1 Desktop Board Features

Manufacturing Options.......................................................................................................... 11

Supported Operating Systems .............................................................................................. 11

Desktop Board Components ................................................................................................. 12

Processor.............................................................................................................................. 14

Main Memory ........................................................................................................................15

Intel® 848P Chipset............................................................................................................... 16

Audio Subsystem .................................................................................................................. 16

Input/Output (I/O) Controller.................................................................................................. 17

LAN Subsystem (Optional).................................................................................................... 17

LAN Subsystem Software ............................................................................................ 17

RJ-45 LAN Connector LEDs ........................................................................................ 17

Hi-Speed USB 2.0 Support ................................................................................................... 18

Enhanced IDE Interface........................................................................................................ 18

Accelerated Graphics Port (AGP) ......................................................................................... 18

BIOS...................................................................................................................................... 19

PCI Auto Configuration ................................................................................................19

IDE Auto Configuration ................................................................................................19

Security Passwords...................................................................................................... 19

Chassis Intrusion................................................................................................................... 19

Power Management Features............................................................................................... 20

ACPI............................................................................................................................. 20

Power Connectors........................................................................................................ 20

Fan Connectors............................................................................................................ 20

Fan Speed Control (Intel® Precision Cooling Technology) .......................................... 20

Suspend to RAM (Instantly Available PC Technology) ................................................21

Resume on Ring ..........................................................................................................22

Wake from USB ...........................................................................................................22

Wake from PS/2 Keyboard/Mouse............................................................................... 22

PME# Wakeup Support................................................................................................ 22

Speaker................................................................................................................................. 22

Battery................................................................................................................................... 22

Real-Time Clock.................................................................................................................... 22

2 Installing and Replacing Desktop Board Components

Before You Begin.................................................................................................................. 23

Installation Precautions......................................................................................................... 24

Installation Instructions.......................................................................................................... 24

Ensure Electromagnetic Compatibility (EMC) Compliance ..........................................24

Chassis and Component Certifications ........................................................................25

Prevent Power Supply Overload ..................................................................................25

Place Battery Marking ..................................................................................................25

Use Only for Intended Applications.............................................................................. 25

Installing the I/O Shield ......................................................................................................... 26

Installing and Removing the Desktop Board .........................................................................27

Intel Desktop Board D848PMB Product Guide

Installing and Removing a Processor.................................................................................... 28

Installing a Processor................................................................................................... 28

Installing the Processor Fan Heat Sink ........................................................................28

Connecting the Processor Fan Heat Sink Cable.......................................................... 29

Removing the Processor.............................................................................................. 29

Installing and Removing Memory.......................................................................................... 30

Installing DIMMs........................................................................................................... 31

Removing DIMMs......................................................................................................... 31

Installing and Removing an AGP Card .................................................................................32

Installing an AGP Card................................................................................................. 32

Removing the AGP Card.............................................................................................. 32

Connecting the IDE Cable..................................................................................................... 33

Connecting the Serial ATA Cable .........................................................................................34

Connecting Internal Headers ................................................................................................35

Connecting the Front Panel Header............................................................................. 36

Connecting USB 2.0 Headers ......................................................................................36

Installing a Front Panel Audio Solution ........................................................................ 37

Add-In Card and Peripheral Interface Connectors ................................................................ 38

Connecting Hardware Control and Power Cables ................................................................39

Connecting the Chassis Intrusion Cable ......................................................................40

Connecting Fans ..........................................................................................................40

Connecting Power Cables............................................................................................ 40

Setting the BIOS Configuration Jumper Block ...................................................................... 41

Clearing Passwords ..............................................................................................................42

Replacing the Battery............................................................................................................ 43

3 Updating the BIOS

Updating the BIOS with the Intel® Express BIOS Update Utility ...........................................47

Updating the BIOS with the Iflash Memory Update Utility..................................................... 48

Obtaining the BIOS Update File................................................................................... 48

Updating the BIOS ....................................................................................................... 48

Recovering the BIOS ...................................................................................................49

4 Using the BIOS Setup Program

Maintenance Menu................................................................................................................52

Main Menu ............................................................................................................................53

Advanced Menu .................................................................................................................... 54

PCI Configuration Submenu ........................................................................................55

Boot Configuration Submenu .......................................................................................56

Peripheral Configuration Submenu ..............................................................................57

ATA/IDE Configuration Submenu ................................................................................59

PATA and SATA Submenus ........................................................................................ 60

Diskette Configuration Submenu .................................................................................62

Event Log Configuration Submenu .............................................................................. 63

Video Configuration Submenu ..................................................................................... 64

USB Configuration Submenu .......................................................................................65

Chipset Configuration Submenu .................................................................................. 66

Fan Control Submenu ..................................................................................................68

Hardware Monitoring Submenu ...................................................................................69

Security Menu ....................................................................................................................... 70

Power Menu .......................................................................................................................... 71

ACPI Submenu ............................................................................................................72

Boot Menu............................................................................................................................. 73

Boot Device Priority Submenu ..................................................................................... 74

Hard Disk Drives Submenu.......................................................................................... 75

Removable Devices Submenu..................................................................................... 76

ATAPI CD-ROM Drives................................................................................................ 77

Exit Menu .............................................................................................................................. 78

5 Desktop Board Resources

Memory Map ......................................................................................................................... 79

DMA Channels...................................................................................................................... 79

Interrupts............................................................................................................................... 80

A Error Messages and Indicators

BIOS Beep Codes.................................................................................................................81

BIOS Error Messages ........................................................................................................... 82

B Regulatory Compliance

Safety Regulations................................................................................................................ 85

European Union Declaration of Conformity Statement ......................................................... 85

Product Ecology Statements................................................................................................. 86

EMC Regulations .................................................................................................................. 87

Product Certification Markings (Board Level)........................................................................ 88

Contents

Figures

1. Desktop Board Components ..........................................................................................12

2. Location of Standby Power Indicator.............................................................................. 21

3. Installing the I/O Shield................................................................................................... 26

4. Location of Desktop Board Mounting Screw Holes ........................................................ 27

5. Installing a Processor ..................................................................................................... 28

6. Connecting the Processor Fan Heat Sink Cable to the Processor Fan Connector ........29

7. Installing a Memory Module............................................................................................ 30

8. Removing the AGP Card ................................................................................................32

9. Connecting the IDE Cable ..............................................................................................33

10. Connecting the Serial ATA Cable................................................................................... 34

11. Internal Headers............................................................................................................. 35

12. PCI Bus Add-in Card and Peripheral Interface Connectors ...........................................38

13. Location of Hardware Control Headers and Power Connectors..................................... 39

14. Location of the BIOS Configuration Jumper Block ......................................................... 41

15. Removing the Battery..................................................................................................... 46

vii

Intel Desktop Board D848PMB Product Guide

Tables

1. Feature Summary............................................................................................................. 9

2. Manufacturing Options ...................................................................................................11

3. Desktop Board Components ..........................................................................................13

4. Supported Processors ....................................................................................................14

5. RJ-45 10/100 Ethernet LAN Connector LEDs ................................................................17

6. Front Panel Header (J9J1) ............................................................................................. 36

7. USB 2.0 Headers (J9F1 and J9H1)................................................................................ 36

8. Front Panel Audio Header Signal Names (J9A2) ...........................................................37

9. Jumper Settings for the BIOS Setup Program Modes (J9J4)......................................... 41

10. BIOS Setup Program Menu Bar ..................................................................................... 51

11. BIOS Setup Program Function Keys ..............................................................................52

12. Maintenance Menu......................................................................................................... 52

13. Main Menu...................................................................................................................... 53

14. Advanced Menu.............................................................................................................. 54

15. PCI Configuration Submenu........................................................................................... 55

16. Boot Configuration Submenu .........................................................................................56

17. Peripheral Configuration Submenu ................................................................................57

18. ATA/IDE Configuration Submenu................................................................................... 59

19. SATA and PATA Submenus........................................................................................... 60

20. Diskette Configuration Submenu.................................................................................... 62

21. Event Log Configuration Submenu................................................................................. 63

22. Video Configuration Submenu........................................................................................ 64

23. USB Configuration Submenu .........................................................................................65

24. Chipset Configuration Submenu..................................................................................... 66

25. Hardware Management .................................................................................................. 68

26. Hardware Monitoring Submenu...................................................................................... 69

27. Security Menu................................................................................................................. 70

28. Power Menu ...................................................................................................................71

29. ACPI Submenu............................................................................................................... 72

30. Boot Menu ...................................................................................................................... 73

31. Boot Device Priority Submenu........................................................................................ 74

32. Hard Disk Drives Submenu ............................................................................................ 75

33. Removable Devices Submenu ....................................................................................... 76

34. ATAPI CD-ROM Drives Submenu.................................................................................. 77

35. Exit Menu........................................................................................................................ 78

36. System Memory Map...................................................................................................... 79

37. DMA Channels ...............................................................................................................79

38. Interrupts ........................................................................................................................80

39. Beep Codes.................................................................................................................... 81

40. BIOS Error Messages..................................................................................................... 82

41. Safety Regulations .........................................................................................................85

42. EMC Regulations............................................................................................................ 87

43. Product Certification Markings........................................................................................ 88

viii

1 Desktop Board Features

Table 1 describes the major features of Intel® Desktop Board D848PMB.

Table 1. Feature Summary

Form Factor MicroATX 9.6-inches by 8.5-inches

Processor Support for:

Pentium® 4 processor (1.60a, 1.80a, 2a, 2.2 GHz or higher) with 800/533/400 MHz front side bus (FSB) frequency in the mPGA478-pin package

Celeron processor (2 GHz or higher) with 400 MHz FSB frequency in the mPGA478-pin package

82848P Memory Controller Hub (MCH) with Accelerated Hub Architecture (AHA) bus

82801EB I/O Controller Hub (ICH5) with support for up to eight Hi-Speed Universal Serial Bus 2.0 (USB 2.0) ports

— Four ports routed to the back panel

— Four ports routed to the internal USB headers

Main Memory

Chipset

Graphics

Audio

Peripheral Interfaces

• Intel

• Two 184-pin, 2.5 V SDRAM Dual Inline Memory Module (DIMM) sockets

• Single channel 400/333/266 MHz DDR SDRAM interface

• Designed to support up to 2 GB of system memory

Intel® 848P chipset consisting of:

• Intel

• 4 Mbit Firmware Hub (FWH)

• Intel 848P chipset

• 1.5 V and 0.8 V only AGP connector

• Single AGP port via the connector

• AGP 3.0 including 1x/4x/8x AGP data transfers and 1x/4x/8x Fast Writes

• Intel 848P chipset (AC ’97)

• Two channel audio

• RealTek ALC202A

• Up to eight USB 2.0 ports

• Two IDE interfaces with Ultra DMA-33 and ATA-66/100 support

• Two Serial ATA (SATA) connectors

• One diskette drive interface

• One parallel port

• One serial port

• PS/2* keyboard and mouse ports

continued

Intel Desktop Board D848PMB Product Guide

Table 1. Feature Summary (continued)

Expansion Capabilities

BIOS

Power Management

Hardware Management

• Up to three PCI bus add-in card connectors (SMBus routed to PCI

connector 2)

• One AGP connector

• Intel/AMI BIOS

• 4 Mbit symmetrical flash memory

• Support for SMBIOS

• Support for Advanced Configuration and Power Interface (ACPI)

• Suspend to RAM (STR)

• Wake on USB, PCI, RS-232, PS/2, LAN, and front panel

• Hardware monitor with:

• Three fan sensing inputs used to monitor fan activity

• Temperature sensing

• Intel

• Voltage sensing to detect out of range values

Precision Cooling Technology fan speed control that automatically

adjusts chassis fan speeds based on system temperature

Related Links:

For more information about Intel Desktop Board D848PMB, including the Technical Product Specification (TPS), BIOS updates, and device drivers, go to:

http://support.intel.com/support/motherboards/desktop/

Manufacturing Options

Table 2 below describes the manufacturing options for Desktop Board D848PMB.

Table 2. Manufacturing Options

Option Description

LAN

82562EX 10/100 Mbit/sec Platform LAN Connect (PLC) device and

Intel RJ-45 connector

Supported Operating Systems

The desktop board supports the following operating systems:

• Microsoft Windows* XP

• Microsoft Windows 2000

• Microsoft Windows Me

• Microsoft Windows 98 SE

Desktop Board Features

Intel Desktop Board D848PMB Product Guide

Desktop Board Components

Figure 1 shows the approximate location of the major components on Desktop Board D848PMB.

Line

USB 2.0 Devices

USB 2.0

Devices

Figure 1. Desktop Board Components

OM16350

Table 3. Desktop Board Components

Label Description

A Front panel audio header

B CD-ROM audio connector (ATAPI-style)

C AGP connector

D Rear chassis fan header (fan speed control)

E 12 V processor core voltage connector

F Processor socket

G Processor fan header

H Intel 82848P (MCH)

I DIMM socket

J Main power connector

K Diskette drive connector

L Secondary IDE connector

M Primary IDE connector

N Front chassis fan connector (fan speed control)

O Chassis intrusion header

P Serial ATA connectors

Q BIOS configuration jumper

R Alternate power/sleep LED header

S Front panel header

T USB 2.0 header

U Intel 82801EB (ICH5)

V USB 2.0 header

W Battery

X PCI bus add-in card connectors

Y Speaker

Z Auxiliary line-in connector (ATAPI-style)

Desktop Board Features

Related Links:

Go to the following links for the latest information about:

• Intel Desktop Board D848PMB, http://www.intel.com/design/motherbd

• Processors, http://support.intel.com/support/motherboards/desktop

• Audio software and utilities, http://www.intel.com/design/motherbd

• LAN software and drivers, http://www.intel.com/design/motherbd

Intel Desktop Board D848PMB Product Guide

Processor

CAUTION

Failure to use an ATX12V power supply, or not connecting the 12 V processor core voltage power supply connector to Desktop Board D848PMB may result in damage to the desktop board and/or power supply.

Desktop Board D848PMB supports a single Intel Pentium 4 processor or Intel Celeron processor. Processors are not included with the desktop board and must be purchased separately.

The processor connects to the Intel desktop board through the mPGA478-pin socket. The Intel processors may be removed and replaced to accommodate supported higher speed processors. Desktop Board D848PMB supports the processors listed in Table 4.

Table 4. Supported Processors

Type

Intel® Pentium® 4 processor featuring Hyper-Threading Technology

Intel Pentium 4 processor

Intel® Celeron® processor

Designation (GHz)

3, 2.80C, 2.60C, and 2.40C 800 512

3.06 533 512

2.8, 2.66, 2.53, 2.4B, and

2.26

2.6, 2.5, 2.40, 2.20, 2A,

1.80A, and 1.60A

2.2, 2.1, and 2.0 400 128

FSB Frequency (MHz)

533 512

400 512

L2 Cache (KB)

Desktop Board D848PMB requires an ATX12V compliant power supply to function according to desktop board specifications. The board has two ATX12V compliant power supply connectors that are needed to provide extra power to the Intel 848P chipset and Intel processor.

Related Links:

Go to the following link or sections in this manual for:

• The latest information on supported Intel processors for Desktop Board D848PMB

http://support.intel.com/support/motherboards/desktop/

• Instructions on installing or upgrading the processor, page 28 in Chapter 2

Desktop Board Features

Main Memory

NOTE

To be fully compliant with all applicable Intel® SDRAM memory specifications, the board should be populated with DIMMs that support the Serial Presence Detect (SPD) data structure. If your memory modules do not support SPD, you will see a notification to this effect on the screen at power up. The BIOS will attempt to configure the memory controller for normal operation.

The desktop board supports system memory as defined below:

• Single channel and up to two 184-pin Double Data Rate (DDR) SDRAM Dual Inline Memory

Module (DIMMs) connectors with gold-plated contacts.

• Supported memory configurations are:

Memory Speed Processor

DDR400 Pentium 4 processor 800 MHz 400 MHz

DDR333

Pentium 4 processor 800 MHz 320 MHz

Pentium 4 processor 533 MHz 333 MHz

Pentium 4 processor or Celeron processor

Pentium 4 processor 533 MHz or 400 MHz 266 MHz DDR266

Celeron processor 400 MHz 266 MHz

Front Side Bus Frequency

400 MHz 266 MHz

Memory Speed Outcome

• Support for:  Unbuffered, non-registered DIMMs  Serial Presence Detect (SPD) memory only  Support for Suspend to RAM (STR), S3 ACPI state  Non-ECC DDR (ECC memory will run in non-ECC mode)  2.5 V memory

Related Links:

Go to the following links or section in this manual for:

• The latest list of tested memory, http://support.intel.com/support/motherboards/desktop/

• SDRAM specifications, http://www.intel.com/technology/memory/pcsdram/spec/

• Installing memory, page 30 in Chapter 2

Intel Desktop Board D848PMB Product Guide

Intel® 848P Chipset

The Intel 848P chipset consists of the following devices:

• Intel 82848P Memory Controller Hub (MCH) with AHA bus

• Intel 82801EB I/O Controller Hub (ICH5) with AHA bus

• Firmware Hub (FWH)

Audio Subsystem

The audio subsystem features the following:

• Intel 82801EB I/O Controller Hub (ICH5)

• RealTek ALC202A codec

• Microphone input that supports a single dynamic, condenser, or electret microphone

The subsystem has the following connectors:

• ATAPI-style CD-ROM connector

• Front panel audio connector, including pins for:  Line out  Mic in

• Back panel audio connectors that are configurable through the audio devices drivers.  Line in or Rear left/right out  Line out or Front left/right out  Mic in or Center LFE out

Related Links:

Go to the following link or sections in this manual for more information about:

• Audio drivers and utilities, http://support.intel.com/support/motherboards/desktop/

• Location of the internal audio connectors, page 35 in Chapter

• Installing the front panel audio solution, page 37 in Chapter 2

Desktop Board Features

Input/Output (I/O) Controller

The super I/O controller features the following:

• Low pin count (LPC) interface

• One serial port

• One parallel port with Extended Capabilities Port (ECP) and Enhanced Parallel Port

(EPP) support

• Serial IRQ interface compatible with serialized IRQ support for PCI systems

• PS/2-style mouse and keyboard interfaces

• Interface for one 1.2 MB, 1.44 MB, or 2.88 MB diskette drive

• Intelligent power management, including a programmable wake up event interface

• PCI power management support

LAN Subsystem (Optional)

The optional LAN provides a Fast PCI LAN subsystem. The LAN subsystem provides the following functions:

• Basic 10/100 Ethernet LAN (Intel 82562EX)

• Support for RJ-45 connector with status indicator LEDs

• Programmable transit threshold

• Configurable EEPROM that contains the MAC address

LAN Subsystem Software

For LAN software and drivers, refer to the D848PMB link on Intel’s World Wide Web site at:

http://support.intel.com/support/motherboards/desktop

RJ-45 LAN Connector LEDs

Two LEDs are built into the RJ-45 LAN connector. Table 5 describes the LED states when the board is powered up and the 10/100 Ethernet LAN subsystem is operating.

Table 5. RJ-45 10/100 Ethernet LAN Connector LEDs

LED Color LED State Indicates

Green

Off LAN link is not established.

On (steady state) LAN link is established.

On (brighter and pulsing) The computer is communicating with another computer on the

LAN.

Off 10 Mbit/sec data rate is selected. Yellow

On 100 Mbit/sec data rate is selected.

Intel Desktop Board D848PMB Product Guide

Hi-Speed USB 2.0 Support

NOTE

Computer systems that have an unshielded cable attached to a USB port might not meet FCC Class B requirements, even if no device or a low-speed USB device is attached to the cable. Use a shielded cable that meets the requirements for a full-speed USB device.

The desktop board supports up to eight USB 2.0 ports via ICH5; four ports routed to the back panel and four routed to the internal USB 2.0 headers. USB 2.0 ports are backward compatible with USB 1.1 devices. USB 1.1 devices will function normally at USB 1.1 speeds.

Disabling Hi-Speed USB in the BIOS reverts all USB 2.0 ports to USB 1.1 operation. This may be required to accommodate operating systems that do not support USB 2.0.

NOTE

USB devices are limited to USB 1.1 transfer rates prior to operating system and driver initialization.

Enhanced IDE Interface

The ICH5’s IDE interface handles the exchange of information between the processor and peripheral devices like hard disks, CD-ROM drives, and Iomega Zip* drives inside the computer. The interface supports:

• Up to four IDE devices (such as hard drives)

• ATAPI-style devices (such as CD-ROM drives)

• Older PIO Mode devices

• Ultra DMA-33 and ATA-66/100 protocols

• Laser Servo (LS-120) drives

Accelerated Graphics Port (AGP)

NOTE

Desktop Board D848PMB is only compatible with 0.8 V and 1.5 V AGP cards.

The AGP connector is keyed for 0.8 V and 1.5 V AGP cards only; the connector is not mechanically compatible with legacy 3.3 V AGP cards. Do not attempt to install a legacy 3.3 V AGP card.

AGP is a high-performance interface for graphics-intensive applications, such as 3D graphics. AGP is independent of the PCI bus and is intended for exclusive use with graphical display devices.

The AGP 3.0 connector supports 8x, 4x, and 1x AGP cards.

Related Links:

For information about installing the AGP card, see page 32 in Chapter 2.

Desktop Board Features

BIOS

The BIOS provides the Power-On Self-Test (POST), the BIOS Setup program, the PCI and IDE auto-configuration utilities, and the video BIOS. The BIOS is stored in the Firmware Hub.

The BIOS can be updated by following the instructions in Chapter 3 on page 47.

PCI Auto Configuration

If you install a PCI add-in card in your computer, the PCI auto-configuration utility in the BIOS automatically detects and configures the resources (IRQs, DMA channels, and I/O space) for that add-in card. You do not need to run the BIOS Setup program after you install a PCI add-in card.

IDE Auto Configuration

If you install an IDE device (such as a hard drive) in your computer, the IDE auto-configuration utility in the BIOS automatically detects and configures the device for your computer. You do not need to run the BIOS Setup program after installing an IDE device. You can override the autoconfiguration options by specifying manual configuration in the BIOS Setup program.

To use ATA-66/100 features, the following items are required:

• An ATA-66/100 peripheral device

• An ATA-66/100 compatible cable

• ATA-66/100 operating system device drivers

Security Passwords

The BIOS includes security features that restrict whether the BIOS Setup program can be accessed and who can boot the computer. A supervisor password and a user password can be set for the Setup and for booting the computer, with the following restrictions:

• The supervisor password gives unrestricted access to view and change all Setup options. If only the supervisor password is set, pressing <Enter> at the password prompt of Setup gives the user restricted access to Setup.

• If both the supervisor and user passwords are set, you must enter either the supervisor password or the user password to access Setup. Setup options are then available for viewing and changing depending on whether the supervisor or user password was entered.

• Setting a user password restricts who can boot the computer. The password prompt is displayed before the computer is booted. If only the supervisor password is set, the computer boots without asking for a password. If both passwords are set, you can enter either password to boot the computer.

Chassis Intrusion

The board supports a chassis security feature that detects if the chassis cover has been removed. The security feature uses a mechanical switch on the chassis that can be connected to the chassis intrusion header on the desktop board. See Figure 13 on page 39 for the location of the chassis intrusion header.

Intel Desktop Board D848PMB Product Guide

Power Management Features

Power management is implemented at several levels, including:

• Advanced Configuration and Power Interface (ACPI)

• Hardware support:  Power connectors  Fan connectors  Fan Speed Control  Suspend to RAM (Instantly Available PC technology)  Resume on Ring  Wake from USB  Wake from PS/2 keyboard/mouse  PME# wakeup support

ACPI

ACPI gives the operating system direct control over the power management and Plug & Play functions of a computer. The use of ACPI with the desktop board requires an operating system that provides full ACPI support.

Power Connectors

The desktop board has two power connectors. See Figure 13 on page 39 for the location of the power connectors.

Fan Connectors

The desktop board has two chassis fan connectors (Intel Precision Cooling Technology) and one processor fan connector. See Figure 13 on page 39 for the location of the fan connectors.

Fan Speed Control (Intel® Precision Cooling Technology)

Intel Precision Cooling Technology automatically adjusts the chassis fan speeds depending on the system’s temperature. This feature reduces system fan noise by lowering the speed of the chassis fans connected to the front and rear chassis fan connectors. The processor fan connector is not controlled.

The fan speed control feature can be disabled in the BIOS, resulting in the chassis fans always operating at full speed. This feature should be disabled if a self-controlled fan is attached to a chassis fan connector.

Overall system noise reduction will vary based on system configuration and environment.

Desktop Board Features

Suspend to RAM (Instantly Available PC Technology)

CAUTION

For Instantly Available PC technology, the 5 V standby line for the power supply must be capable of delivering adequate +5 V standby current. Failure to provide adequate standby current when using this feature can damage the power supply and/or effect ACPI S3 sleep state functionality.

Instantly Available PC technology enables the board to enter the ACPI S3 (Suspend-to-RAM) sleep state. While in the S3 sleep state, the computer will appear to be off. When signaled by a wake-up device or event, the system quickly returns to its last known awake state.

The desktop board’s standby power indicator, shown in Figure 2, is lit when there is standby power to the system. This includes the memory modules and PCI bus connectors, even when the computer appears to be off.

If the system has a dual-colored power LED on the front panel, the sleep state is indicated by the LED turning amber.

CR8H1

Figure 2. Location of Standby Power Indicator

OM16351

CAUTION

Power supplies used with this desktop board must be able to provide enough standby current to support the standard Instantly Available (ACPI S3 sleep state) configuration. If the standby current necessary to support multiple wake events from the PCI and/or USB buses exceeds power supply capacity, the desktop board may lose register settings stored in memory.

Resume on Ring

The operation of Resume on Ring can be summarized as follows:

• Resumes operation from either ACPI S1 or ACPI S3 state

• Requires only one call to access the computer

• Detects incoming call similarly for external and internal modems

• Requires modem interrupt be unmasked for correct operation

Wake from USB

USB bus activity wakes the computer from an ACPI S1 or S3 state.

NOTE

Wake from USB requires the use of a USB peripheral that supports Wake from USB.

Wake from PS/2 Keyboard/Mouse

PS/2 keyboard/mouse activity wakes the computer from an ACPI S1 or S3 state.

PME# Wakeup Support

When the PME# signal on the PCI bus is asserted, the computer wakes from an ACPI S1, S3, or S5 state.

Speaker

A speaker is mounted on the desktop board. The speaker provides audible error code (beep code) information during the Power-On Self-Test (POST). For a list of the beep codes, see Table 39 on page 81.

Battery

The battery on the desktop board keeps the values in CMOS RAM and the clock current when the computer is turned off. See page 43 in Chapter 2 for instructions on how to replace the battery.

Real-Time Clock

The desktop board has a time-of-day clock and 100-year calendar. The battery on the desktop board keeps the clock current when the computer is turned off.

2 Installing and Replacing Desktop

Board Components

This chapter tells you how to:

• Install the I/O shield

• Install and remove the desktop board

• Install and remove a processor and memory

• Install and remove an AGP card

• Connect the IDE and Serial ATA cables

• Connect internal headers

• Locate the add-in card and peripheral interface connectors

• Connect hardware control and power cables

• Set the BIOS configuration jumper

• Clear passwords

• Replace the battery

Before You Begin

WARNINGS

The procedures in this chapter assume familiarity with the general terminology associated with personal computers and with the safety practices and regulatory compliance required for using and modifying electronic equipment.

Disconnect the computer from its power source and from any telecommunications links, networks, or modems before performing any of the procedures described in this chapter. Failure to disconnect power, telecommunications links, networks, or modems before you open the computer or perform any procedures can result in personal injury or equipment damage. Some circuitry on the board can continue to operate even though the front panel power button is off.

CAUTION

Many of the internal and front panel connectors provide operating voltage (+5 V dc and +12 V dc, for example) to devices inside the computer chassis, such as fans and internal peripherals. These connectors are not overcurrent protected. Do not use these connectors for powering devices external to the computer chassis. A fault in the load presented by the external devices could cause damage to the computer, the interconnecting cable, and the external devices themselves.

Intel Desktop Board D848PMB Product Guide

Follow these guidelines before you begin:

• Always follow the steps in each procedure in the correct order.

• Set up a log to record information about your computer, such as model, serial numbers,

installed options, and configuration information.

• Electrostatic discharge (ESD) can damage components. Perform the procedures described in this chapter only at an ESD workstation using an antistatic wrist strap and a conductive foam pad. If such a station is not available, you can provide some ESD protection by wearing an antistatic wrist strap and attaching it to a metal part of the computer chassis.

Installation Precautions

When you install and test the Intel desktop board, observe all warnings and cautions in the installation instructions.

To avoid injury, be careful of:

• Sharp pins on connectors

• Sharp pins on printed circuit assemblies

• Rough edges and sharp corners on the chassis

• Hot components (like processors, voltage regulators, and heat sinks)

• Damage to wires that could cause a short circuit

Observe all warnings and cautions that instruct you to refer computer servicing to qualified technical personnel.

Installation Instructions

CAUTION

Follow these guidelines to meet safety and regulatory requirements when installing this board assembly.

Read and adhere to all of these instructions and the instructions supplied with the chassis and associated modules. If the instructions for the chassis are inconsistent with these instructions or the instructions for associated modules, contact the supplier’s technical support to find out how you can ensure that your computer meets safety and regulatory requirements. If you do not follow these instructions and the instructions provided by chassis and module suppliers, you increase safety risk and the possibility of noncompliance with regional laws and regulations.

Ensure Electromagnetic Compatibility (EMC) Compliance

Before computer integration, make sure that the power supply and other modules or peripherals, as applicable, have passed Class B EMC testing and are marked accordingly.

In the installation instructions for the host chassis, power supply, and other modules pay close attention to the following:

• Product certifications or lack of certifications

• External I/O cable shielding and filtering

• Mounting, grounding, and bonding requirements

• Keying connectors when mating the wrong connectors could be hazardous

Installing and Replacing Desktop Board Components

If the power supply and other modules or peripherals, as applicable, are not Class B EMC compliant before integration, then EMC testing is required on a representative sample of the newly completed computer.

Chassis and Component Certifications

Ensure that the chassis and certain components; such as the power supply, peripheral drives, wiring, and cables; are components certified for the country or market where used. Agency certification marks on the product are proof of certification. Typical product certifications include:

• In Europe The CE marking signifies compliance with all applicable European requirements. If the chassis and other components are not properly CE marked, a supplier’s Declaration of Conformity statement to the European EMC directive and Low Voltage directive (as applicable), should be obtained. Additionally, other directives, such as the Radio and Telecommunications Terminal Equipment (R&TTE) directive may also apply depending on product features.

• In the United States A certification mark by a Nationally Recognized Testing Laboratory (NRTL) such as UL, CSA, or ETL signifies compliance with safety requirements. Wiring and cables must also be UL listed or recognized and suitable for the intended use. The FCC Class B logo for home or office use signifies compliance with electromagnetic interference (EMI) requirements.

• In Canada A nationally recognized certification mark such as CSA or cUL signifies compliance with safety requirements. The Industry Canada statement at the front of this product guide demonstrates compliance with Canadian EMC regulations. Industry Canada recognizes and accepts FCC certification as denoting compliance with national electromagnetic interference (emissions) requirements.

Prevent Power Supply Overload

Do not overload the power supply output. To avoid overloading the power supply, make sure that the calculated total current loads of all the modules within the computer is less than the output current rating of each of the power supplies output circuits.

Place Battery Marking

There is insufficient space on this desktop board to provide instructions for replacing and disposing of the Lithium ion coin cell battery. For system safety certification, the following statement or equivalent statement is required to be permanently and legibly marked on the chassis near the battery.

CAUTION

Risk of explosion if the battery is replaced with an incorrect type. Batteries should be recycled where possible. Disposal of used batteries must be in accordance with local environmental regulations.

Use Only for Intended Applications

All Intel desktop boards are evaluated as Information Technology Equipment (I.T.E.) for use in personal computers for installation in homes, offices, schools, computer rooms, and similar locations. The suitability of this product for other applications or environments, such as medical, industrial, alarm systems, test equipment, etc. may require further evaluation.

Intel Desktop Board D848PMB Product Guide

Installing the I/O Shield

The desktop board comes with an I/O shield. When installed in the chassis, the shield blocks radio frequency transmissions, protects internal components from dust and foreign objects, and promotes correct airflow within the chassis.

Install the I/O shield before installing the desktop board in the chassis. Place the shield inside the chassis as shown in Figure 3. Press the shield into place so that it fits tightly and securely. If the shield doesn’t fit, obtain a properly-sized shield from the chassis supplier.

Figure 3. Installing the I/O Shield

OM16288

Installing and Replacing Desktop Board Components

Installing and Removing the Desktop Board

WARNING

Only qualified technical personnel should do this procedure. Disconnect the computer from its power source before performing the procedures described here. Failure to disconnect the power before you open the computer can result in personal injury or equipment damage.

NOTE

Refer to Appendix B for regulatory requirements.

Refer to your chassis manual for instructions on installing and removing the desktop board.

Figure 4 shows the location of the six mounting holes for Desktop Board D848PMB.

OM16352

Figure 4. Location of Desktop Board Mounting Screw Holes

Intel Desktop Board D848PMB Product Guide

Installing and Removing a Processor

Instructions on how to install the processor to the desktop board are given below.

Installing a Processor

CAUTION

Before installing or removing the processor, make sure that AC power has been removed by unplugging the power cord from the computer; the standby power LED should not be lit (see Figure 2 on page 21). Failure to do so could damage the processor and the board.

To install a processor, follow these instructions:

1. Observe the precautions in “Before You Begin” on page 23.

2. Locate the processor socket and raise the socket lever completely.

3. Install the processor so that the corner with the triangle marking (A) is aligned with the corner where the lever is attached to the socket (see Figure 5).

4. Lower the lever to its original position.

mPGA478B

OM15028

Figure 5. Installing a Processor

Installing the Processor Fan Heat Sink

Desktop Board D848PMB has an integrated processor fan heat sink retention mechanism (RM). For instructions on how to install the processor fan heat sink to the integrated processor fan heat sink RM, refer to the boxed processor manual or the Intel World Wide Web site at:

http://support.intel.com/support/processors/pentium4/intnotes478.htm

Installing and Replacing Desktop Board Components

Connecting the Processor Fan Heat Sink Cable

Connect the processor fan heat sink cable to the processor fan connector (see Figure 6).

OM16353

Figure 6. Connecting the Processor Fan Heat Sink Cable to the Processor Fan Connector

Removing the Processor

For instruction on how to remove the processor fan heat sink and processor, refer to the processor installation manual or the Intel World Wide Web site at:

http://support.intel.com/support/processors/pentium4/intnotes478.htm

Intel Desktop Board D848PMB Product Guide

Installing and Removing Memory

CAUTION

To be fully compliant with all applicable Intel SDRAM memory specifications, the board requires DIMMs that support the Serial Presence Detect (SPD) data structure. You can access the PC Serial Presence Detect Specification at:

http://www.intel.com/technology/memory/pcsdram/spec/

Desktop Board D848PMB has a single channel 184-pin DIMM socket arranged as DIMM 0 and DIMM 1 as shown in Figure 7.

Refer to the “Main Memory” section on page 15 for memory requirements.

DIMM 0 DIMM 1

OM16354

Figure 7. Installing a Memory Module

Installing and Replacing Desktop Board Components

Installing DIMMs

CAUTION

Install memory in the DIMM sockets prior to installing an AGP video card to avoid interference with the memory retention mechanism.

To install DIMMs, follow these steps:

1. Observe the precautions in “Before You Begin” on page 23.

2. Turn off all peripheral devices connected to the computer. Turn off the computer and disconnect the AC power cord.

3. Remove the computer’s cover and locate the DIMM sockets (see Figure 7).

4. Remove the AGP video card if it interferes with the DIMM clips from being easily opened and closed.

5. Make sure the clips at either end of the DIMM socket(s) are pushed outward to the open position.

6. Holding the DIMM by the edges, remove it from its anti-static package.

7. Position the DIMM above the socket. Align the small notch in the bottom edge of the DIMM with the key in the socket (see inset in Figure 7).

8. Insert the bottom edge of the DIMM into the socket.

9. When the DIMM is inserted, push down on the top edge of the DIMM until the retaining clips snap into place. Make sure the clips are firmly in place.

10. Reinstall the AGP card if it was removed prior to installing the DIMMs.

11. Replace the computer’s cover and reconnect the AC power cord.

Removing DIMMs

To remove a memory module, follow these steps:

1. Observe the precautions in “Before You Begin” on page 23.

2. Turn off all peripheral devices connected to the computer. Turn off the computer.

3. Remove the AC power cord from the computer.

4. Remove the computer’s cover.

5. Remove the AGP card if it interferes with the DIMM clips from being easily opened and closed.

6. Gently spread the retaining clips at each end of the DIMM socket. The DIMM pops out of the socket.

7. Hold the DIMM by the edges, lift it away from the socket, and store it in an anti-static package.

8. Reinstall the AGP card if you removed it before taking out the DIMMs.

9. Reinstall and reconnect any parts you removed or disconnected to reach the DIMM sockets.

10. Replace the computer’s cover and reconnect the AC power cord.

Intel Desktop Board D848PMB Product Guide

Installing and Removing an AGP Card

CAUTION

When installing any AGP card in the desktop board, ensure that it is fully seated in the AGP connector before you power on the system. If the card is not fully seated in the AGP connector, an electrical short may result across the AGP connector pins. Depending on the over-current protection of the power supply, certain board components and/or traces may be damaged.

The AGP connector supports 1.5 V (4x and 1x) and 0.8 V (8x) AGP cards. The desktop board has an integrated AGP card retention mechanism (RM).

Installing an AGP Card

Follow these instructions to install an AGP card:

1. Observe the precautions in “Before You Begin” on page 23.

2. Place the card in the AGP connector.

3. Press down on the card until it is completely seated in the AGP connector and the card retention notch snaps into place around the RM pin.

4. Secure the card’s metal bracket to the chassis back panel with a screw.

Removing the AGP Card

Follow these instructions to remove the AGP card from the RM (see Figure 8):

1. Observe the precautions in “Before You Begin” on page 23.

2. Remove the screw (B) that secures the card’s metal bracket (A) to the chassis back panel.

3. Push back on the RM lever (C), as shown in Figure 8, until the retention pin completely clears the notch in the card.

4. Pull the card straight up (D).

Figure 8. Removing the AGP Card

OM15031

Installing and Replacing Desktop Board Components

Connecting the IDE Cable

The two IDE cables support the Ultra DMA-33 and ATA-66/100 transfer protocols. Each of the cables can connect two drives to the desktop board. Figure 9 shows the correct installation of the cable.

NOTE

ATA-66/100 compatible cables are backward compatible with drives using slower IDE transfer protocols. If an ATA-66/100 disk drive and a disk drive using any other IDE transfer protocol are attached to the same cable, the maximum transfer rate between the drives may be reduced to that of the slowest drive.

NOTE

Do not connect an ATA device as a slave on the same IDE cable as an ATAPI master device. For example, do not connect an ATA hard drive as a slave to an ATAPI CD-ROM drive.

For correct function of the cable:

• Observe the precautions in “Before You Begin” on page 23.

• Attach the cable end with the single connector to the Intel desktop board (A).

• Attach the cable end with the two closely spaced connectors to the drives (B).

Figure 9. Connecting the IDE Cable

OM16355

Intel Desktop Board D848PMB Product Guide

Connecting the Serial ATA Cable

The SATA cable (4-conductor) supports the Serial ATA protocol and connects a single drive to the desktop board. Either end of the cable can be connected to the SATA drive or the connector on the board (see Figure 10).

For correct cable function:

1. Observe the precaution in “Before You Begin” on page 23.

2. Attach either cable end to the connector (A) on the board.

3. Attach either cable end to the connector (B) on the drive.

Figure 10. Connecting the Serial ATA Cable

OM16376

Installing and Replacing Desktop Board Components

Connecting Internal Headers

Figure 11 shows the location of internal headers.

1 3 5 7

J9C2

J9F1

J9H1

1 3 5 7 9

2 4 6 8 10

4 6

J8A1

1 2

3 4

J8B2

654

J9H3

OM16362

Item Description

A CD-ROM audio

B Front panel audio

C Auxiliary line-in

D USB 2.0

E Front panel

F Alternate power/sleep LED

Figure 11. Internal Headers

Intel Desktop Board D848PMB Product Guide

Connecting the Front Panel Header

Before connecting the front panel header, observe the precautions in “Before You Begin” on page 23. Figure 11-D on page 35 shows the location of the front panel header. Table 6 shows the pin assignments for the front panel header.

Table 6. Front Panel Header (J9H3)

Pin Signal In/Out Description Pin Signal In/Out Description

Hard Drive Activity LED Power LED

1 HD_PWR Out Hard disk LED pull-

up (330 Ω) to +5 V

3 HDA# Out Hard disk active LED 4 HDR_BLNK_YEL Out Front panel yellow

Reset Switch On/Off Switch

5 Ground Ground 6 SWITCH_ON# In Power switch

7 FP_RESET# In Reset switch 8 Ground Ground

9 +5 V Out Power 10 N/C Not connected

2 HDR_BLNK_GRN Out Front panel green

LED

Connecting USB 2.0 Headers

Before connecting USB 2.0 headers, observe the precautions in “Before You Begin” on page 23. Figure 11-B and -C on page 35 shows the location of the USB 2.0 headers. Table 7 shows the pin assignments for the headers.

Table 7. USB 2.0 Headers (J9F1 and J9H1)

USB Port A USB Port B

Pin Signal Name Pin Signal Name

1 Power 2 Power

3 D- 4 D-

5 D+ 6 D+

7 Ground 8 Ground

9 Key (no pin) 10 Not connected

Note: USB ports may be assigned as needed.

Installing and Replacing Desktop Board Components

Installing a Front Panel Audio Solution

Figure 11-A shows the location of the front panel audio header. Table 8 shows the pin assignments for the front panel audio header.

Table 8. Front Panel Audio Header Signal Names (J8A1)

Pin Signal Name Pin Signal Name

1 AUD-MIC 2 AUD-GND

3 AUD-MIC-BIAS 4 AUD-VCC

5 AUD-FPOUT-R 6 AUD-RET-R

7 HP-ON 8 KEY

9 AUD-FPOUT-L 10 AUD-RET-L

To install the cable that connects the front panel audio solution to the front panel audio header, follow these steps:

1. Observe the precautions in “Before You Begin” on page 23.

2. Turn off all peripheral devices connected to the computer. Turn off the computer and disconnect the AC power cord.

3. Remove the cover.

4. Locate the front panel audio header. Remove the two jumpers from the header to disable the back panel audio connectors.

5. Install a correctly keyed and shielded front panel audio cable.

6. Connect the audio cable to the front panel audio solution.

7. Replace the cover.

To restore back panel operations, follow these steps:

1. Observe the precautions in “Before You Begin” on page 23.

2. Turn off all peripheral devices connected to the computer. Turn off the computer and disconnect the AC power cord.

3. Remove the cover.

4. Remove the front panel audio cable.

5. Install a jumper on pins 5-6 (rear R channel).

6. Install a jumper on pins 9-10 (rear L channel).

7. Replace the cover.

NOTE

The line out connector, located on the back panel, is designed to power either headphones or amplified speakers only. Poor audio quality may occur if passive (non-amplified) speakers are connected to this output.

Intel Desktop Board D848PMB Product Guide

Add-In Card and Peripheral Interface Connectors

Figure 12 shows the PCI bus add-in card and peripheral interface connectors for Desktop Board D848PMB.

B CAD

Item Description Item Description

A PCI bus add-in card connector 3 E Floppy drive B

C PCI bus add-in card connector 1 G Secondary IDE D AGP

PCI bus add-in card connector 2 (SMBus routed)

F Primary IDE

Figure 12. PCI Bus Add-in Card and Peripheral Interface Connectors

OM16361

Installing and Replacing Desktop Board Components

Connecting Hardware Control and Power Cables

Figure 13 shows the location of the chassis intrusion and fan headers and power connectors.

Chassis rear fan

J6B1

12 V

Processor core

voltage

Chassis intrusion

J7H1

Chassis

front fan

J7H2

Main power

Processor

fan

J2F1

2 1

OM16360

Figure 13. Location of Hardware Control Headers and Power Connectors

Intel Desktop Board D848PMB Product Guide

Connecting the Chassis Intrusion Cable

Connect the chassis intrusion cable to the header shown in Figure 13.

Connecting Fans

Connect the processor’s fan heat sink cable to the processor fan header on the board. Connect chassis fan cables to the board fan headers. See Figure 13 for fan header locations.

Connecting Power Cables

CAUTION

Failure to use an ATX12V power supply, or not connecting the 12 V processor core voltage power supply connector to the desktop board may result in damage to the desktop board and/or power supply.

Figure 13 shows the location of power connectors.

1. Observe the precautions in “Before You Begin” on page 23.

2. Connect the 12 V processor core voltage power supply cable to the 2x2 connector.

3. Connect the main power cable to the 2x10 connector.

Installing and Replacing Desktop Board Components

Setting the BIOS Configuration Jumper Block

CAUTION

Always turn off the power and unplug the power cord from the computer before changing the jumper. Moving the jumper with the power on may result in unreliable computer operation.

The location of the desktop board’s BIOS configuration jumper is shown in Figure 14.

J8H3

OM16356

Figure 14. Location of the BIOS Configuration Jumper Block

The three-pin BIOS jumper block enables all board configurations to be done in BIOS Setup. Table 9 shows the jumper settings for the Setup program modes.

Table 9. Jumper Settings for the BIOS Setup Program Modes (J9J4)

Jumper Setting Mode Description

Normal (default) (1-2) The BIOS uses the current configuration and passwords for

booting.

Configure (2-3) After the Power-On Self-Test (POST) runs, the BIOS displays

the Maintenance Menu. Use this menu to clear passwords.

Recovery (None) The BIOS recovers data from a recovery diskette in the event of

a failed BIOS update.

Intel Desktop Board D848PMB Product Guide

Clearing Passwords

This procedure assumes that the board is installed in the computer and the configuration jumper block is set to normal mode.

1. Observe the precautions in “Before You Begin” on page 23.

2. Turn off all peripheral devices connected to the computer. Turn off the computer. Disconnect the computer’s power cord from the AC power source (wall outlet or power adapter).

3. Remove the computer cover.

4. Find the configuration jumper block (see Figure 14).

5. Place the jumper on pins 2-3 as shown below.

6. Replace the cover, plug in the computer, turn on the computer, and allow it to boot.

7. The computer starts the Setup program. Setup displays the Maintenance menu.

8. Use the arrow keys to select Clear Passwords. Press <Enter> and Setup displays a pop-up screen requesting that you confirm clearing the password. Select Yes and press <Enter>. Setup displays the maintenance menu again.

9. Press <F10> to save the current values and exit Setup.

10. Turn off the computer. Disconnect the computer’s power cord from the AC power source.

11. Remove the computer cover.

12. To restore normal operation, place the jumper on pins 1-2 as shown below.

13. Replace the cover, plug in the computer, and turn on the computer.

Installing and Replacing Desktop Board Components

Replacing the Battery

A coin-cell battery (CR2032) powers the real-time clock and CMOS memory. When the computer is not plugged into a wall socket, the battery has an estimated life of three years. When the computer is plugged in, the standby current from the power supply extends the life of the battery. The clock is accurate to ± 13 minutes/year at 25 ºC with 3.3 VSB applied.

When the voltage drops below a certain level, the BIOS Setup program settings stored in CMOS RAM (for example, the date and time) might not be accurate. Replace the battery with an equivalent one. Figure 15 on page 46 shows the location of the battery.

CAUTION

PRECAUTION

Risque d'explosion si la pile usagée est remplacée par une pile de type incorrect. Les piles usagées doivent être recyclées dans la mesure du possible. La mise au rebut des piles usagées doit respecter les réglementations locales en vigueur en matière de protection de l'environnement.

FORHOLDSREGEL

Eksplosionsfare, hvis batteriet erstattes med et batteri af en forkert type. Batterier bør om muligt genbruges. Bortskaffelse af brugte batterier bør foregå i overensstemmelse med gældende miljølovgivning.

OBS!

Det kan oppstå eksplosjonsfare hvis batteriet skiftes ut med feil type. Brukte batterier bør kastes i henhold til gjeldende miljølovgivning.

VIKTIGT!

Risk för explosion om batteriet ersätts med felaktig batterityp. Batterier ska kasseras enligt de lokala miljövårdsbestämmelserna.

VARO

Räjähdysvaara, jos pariston tyyppi on väärä. Paristot on kierrätettävä, jos se on mahdollista. Käytetyt paristot on hävitettävä paikallisten ympäristömääräysten mukaisesti.

VORSICHT

Bei falschem Einsetzen einer neuen Batterie besteht Explosionsgefahr. Die Batterie darf nur durch denselben oder einen entsprechenden, vom Hersteller empfohlenen Batterietyp ersetzt werden. Entsorgen Sie verbrauchte Batterien den Anweisungen des Herstellers entsprechend.

Intel Desktop Board D848PMB Product Guide

AVVERTIMENTO

Esiste il pericolo di un esplosione se la pila non viene sostituita in modo corretto. Utilizzare solo pile uguali o di tipo equivalente a quelle consigliate dal produttore. Per disfarsi delle pile usate, seguire le istruzioni del produttore.

PRECAUCIÓN

Existe peligro de explosión si la pila no se cambia de forma adecuada. Utilice solamente pilas iguales o del mismo tipo que las recomendadas por el fabricante del equipo. Para deshacerse de las pilas usadas, siga igualmente las instrucciones del fabricante.

WAARSCHUWING

Er bestaat ontploffingsgevaar als de batterij wordt vervangen door een onjuist type batterij. Batterijen moeten zoveel mogelijk worden gerecycled. Houd u bij het weggooien van gebruikte batterijen aan de plaatselijke milieuwetgeving.

ATENÇÃO

Haverá risco de explosão se a bateria for substituída por um tipo de bateria incorreto. As baterias devem ser recicladas nos locais apropriados. A eliminação de baterias usadas deve ser feita de acordo com as regulamentações ambientais da região.

AŚCIAROŽZNAŚĆ

Існуе рызыка выбуху, калі заменены акумулятар неправільнага тыпу. Акумулятары павінны, па магчымасці, перепрацоўвацца. Пазбаўляцца ад старых акумулятараў патрэбна згодна з мясцовым заканадаўствам па экалогіі.

UPOZORNÌNÍ

V případě výměny baterie za nesprávný druh může dojít k výbuchu. Je-li to možné, baterie by měly být recyklovány. Baterie je třeba zlikvidovat v souladu s místními předpisy o životním prostředí.

Προσοχή

Υπάρχει κίνδυνος για έκρηξη σε περίπτωση που η µπαταρία αντικατασταθεί από µία λανθασµένου τύπου. Οι µπαταρίες θα πρέπει να ανακυκλώνονται όταν κάτι τέτοιο είναι δυνατό. Η απόρριψη των χρησιµοποιηµένων µπαταριών πρέπει να γίνεται σύµφωνα µε τους κατά τόπο περιβαλλοντικούς κανονισµούς.

VIGYÁZAT

Ha a telepet nem a megfelelő típusú telepre cseréli, az felrobbanhat. A telepeket lehetőség szerint újra kell hasznosítani. A használt telepeket a helyi környezetvédelmi előírásoknak megfelelően kell kiselejtezni.

Installing and Replacing Desktop Board Components

AWAS

Risiko letupan wujud jika bateri digantikan dengan jenis yang tidak betul. Bateri sepatutnya dikitar semula jika boleh. Pelupusan bateri terpakai mestilah mematuhi peraturan alam sekitar tempatan.

OSTRZEŻENIE

Istnieje niebezpieczeństwo wybuchu w przypadku zastosowania niewłaściwego typu baterii. Zużyte baterie należy w miarę możliwości utylizować zgodnie z odpowiednimi przepisami ochrony środowiska.

PRECAUŢIE

Risc de explozie, dacă bateria este înlocuită cu un tip de baterie necorespunzător. Bateriile trebuie reciclate, dacă este posibil. Depozitarea bateriilor uzate trebuie să respecte reglementările locale privind protecţia mediului.

ВНИМАНИЕ

При использовании батареи несоответствующего типа существует риск ее взрыва. Батареи должны быть утилизированы по возможности. Утилизация батарей должна проводится по правилам, соответствующим местным требованиям.

UPOZORNENIE

Ak batériu vymeníte za nesprávny typ, hrozí nebezpečenstvo jej výbuchu. Batérie by sa mali podľa možnosti vždy recyklovať. Likvidácia použitých batérií sa musí vykonávať v súlade s miestnymi predpismi na ochranu životného prostredia.

POZOR

Zamenjava baterije z baterijo drugačnega tipa lahko povzroči eksplozijo. Če je mogoče, baterije reciklirajte. Rabljene baterije zavrzite v skladu z lokalnimi

okoljevarstvenimi predpisi.

การระวัง

ระวังการระเบิดที่เกิดจากเปลี่ยนแบตเตอรี่ผิดประเภท หากเป็นไปได้ ควรนำแบตเตอรี่ไปรีไซเคิล การทิ้งแบตเตอรี่ใช้แล้วต้องเป็นไปตามกฎข้อบังคับด้านสิ่งแวดล้อมของท้องถิ่น.

UYARI

Yanlış türde pil takıldığında patlama riski vardır. Piller mümkün olduğunda geri dönüştürülmelidir. Kullanılmış piller, yerel çevre yasalarına uygun olarak atılmalıdır.

OСТОРОГА

Використовуйте батареї правильного типу, інакше існуватиме ризик вибуху. Якщо можливо, використані батареї слід утилізувати. Утилізація використаних батарей має бути виконана згідно місцевих норм, що регулюють охорону довкілля.

Intel Desktop Board D848PMB Product Guide

To replace the battery, follow these steps:

1. Observe the precautions in “Before You Begin” (see page 23).

2. Turn off all peripheral devices connected to the computer. Disconnect the computer’s power cord from the AC power source (wall outlet or power adapter).

3. Remove the computer cover.

4. Locate the battery on the board (see Figure 15).

5. With a medium flat-bladed screwdriver, gently pry the battery free from its connector. Note the orientation of the “+” and “-” on the battery.

6. Install the new battery in the connector, orienting the “+” and “-” correctly.

7. Replace the computer cover.

OM16357

Figure 15. Removing the Battery

3 Updating the BIOS

This chapter tells you how to update the BIOS by either using the Intel® Express BIOS Update utility or the Iflash Memory Update utility, and how to recover the BIOS if an update fails.

Updating the BIOS with the Intel® Express BIOS Update Utility

With the Intel Express BIOS Update utility you can update the system BIOS while in the Windows environment. The BIOS file is included in an automated update utility that combines the functionality of the Intel installation wizards.

To update the BIOS with the Intel Express BIOS Update utility:

1. Go to the Intel World Wide Web site:

http://support.intel.com/support/motherboards/desktop/

2. Navigate to the Desktop Board D848PMB page and click the Express BIOS Update utility file for the Desktop Board D848PMB BIOS.

3. Download the file to your hard drive. (You can also save this file to a diskette. This is useful if you are updating the BIOS for multiple identical systems.)

4. Close all other applications. This step is required. Your system will be rebooted at the last Express BIOS Update window.

5. Double-click the executable file from the location on your hard drive where it was saved. This runs the update program.

6. Follow the instructions provided in the dialog boxes to complete the BIOS update.

Flash Memory Update Utility and the ease-of use of Windows-based

Intel Desktop Board D848PMB Product Guide

Updating the BIOS with the Iflash Memory Update Utility

With the Iflash Memory Update utility you can update the system BIOS from a floppy disk or other bootable media. The utility available from the Web provides a simple method for creating a bootable flash memory update floppy that will automatically update your BIOS.

Obtaining the BIOS Update File

You can update to a new version of the BIOS by using the BIOS update file. The BIOS update file is a compressed self-extracting archive that contains all the files you need to update the BIOS. The BIOS update file contains:

• New BIOS files

• BIOS recovery files

• Iflash Memory Update utility

You can obtain the BIOS update file through your computer supplier or by navigating to the Desktop Board D848PMB page on the Intel World Wide Web site:

http://support.intel.com/support/motherboards/desktop

NOTE

Review the instructions distributed with the update utility before attempting a BIOS update.

The Intel Flash Memory Update Utility allows you to:

• Update the BIOS in flash memory

• Update the language section of the BIOS

Updating the BIOS

CAUTION

The AUTOEXEC.BAT file provided with the update files updates the BIOS. Do not interrupt the process or the system may not function.

1. Boot the computer with the BIOS update diskette in drive A. During system boot, the

AUTOEXEC.BAT file provided with the update files will automatically run the BIOS update

process.

2. When the update process is complete, the monitor will display a message telling you to remove the diskette and to reboot the system.

3. As the computer boots, check the BIOS identifier (version number) to make sure the update was successful. If a logo appears, press

<Esc> to view the POST messages.

Updating the BIOS

Recovering the BIOS

It is unlikely that anything will interrupt the BIOS update; however, if an interruption occurs, the BIOS could be damaged. The following steps explain how to recover the BIOS if an update fails. The following procedure uses recovery mode for the Setup program. See page 41 for more information on Setup modes.

NOTE

Because of the small amount of code available in the boot block area, there is no video support. You will not see anything on the screen during this procedure. Monitor the procedure by listening to the speaker and looking at the diskette drive LED.

1. Turn off the computer, disconnect the computer’s power cord, and disconnect all external peripherals.

2. Remove the computer cover and locate the configuration jumper block (see Figure 14).

3. Remove the jumper from all pins as shown below to set recovery mode for Setup.

4. Insert the bootable BIOS update diskette into diskette drive A.

5. Replace the computer cover, connect the power cord, turn on the computer, and allow it to boot. The recovery process will take a few minutes.

6. Listen to the speaker:

• Upon applying power, drive A will begin to show activity. In about a minute, two beeps

are heard and drive A activity ceases (temporarily) indicating the successful recovery of the BIOS core. Drive A activity will begin again followed by two more beeps indicating the successful recovery of the boot block. This sequence of events indicates a successful BIOS recovery.

• A series of continuous beeps indicates a failed BIOS recovery.

7. If recovery fails, return to step 1 and repeat the recovery process.

8. If recovery is successful, turn off the computer, and disconnect its power cord.

9. Remove the computer cover and continue with the following steps.

10. On the jumper block, reinstall the jumper back on pins 1-2 as shown below to set normal mode for Setup.

11. Leave the update diskette in drive A, replace the computer cover, and connect the computer’s power cord.

12. Turn on the computer and continue with the BIOS update.

Intel Desktop Board D848PMB Product Guide

4 Using the BIOS Setup Program

The BIOS Setup program can be used to view and change the BIOS settings for the computer. The BIOS Setup program is accessed by pressing the <F2> key after the Power-On Self-Test (POST) memory test begins and before the operating system boot begins.

NOTE

The BIOS Setup menus described in this section may not show the latest settings. For the latest BIOS settings, refer to the Intel Intel World Wide Web site:

http://support.intel.com/support/motherboards/desktop

NOTE

For reference purposes, you should write down the current Setup settings. When you make changes to the settings, update this record.

NOTE

The Setup menus described in this section apply to the desktop boards with BIOS identifier MB84810A.86A. Boards with other BIOS identifiers might have differences in some of the Setup menu screens.

Table 10 shows the BIOS Setup program menu bar.

Desktop Board D848PMB Technical Product Specification or the

Table 10. BIOS Setup Program Menu Bar

Maintenance Main Advanced Security Power Boot Exit

Clears passwords and Boot Integrity Service (BIS)* credentials, and configures extended configuration memory settings

* For information about the BIS, refer to the Intel Web site at:

http://developer.intel.com/design/security/index1.htm

Allocates resources for hardware components

Configures advanced features available through the chipset

Sets passwords and security features

Configures power management features

Selects boot options and power supply controls

Saves or discards changes to set program options

Intel Desktop Board D848PMB Product Guide

Table 11 shows the function keys available for menu screens.

Table 11. BIOS Setup Program Function Keys

BIOS Setup Program Function Key Description

<←> or <→> <↑> or <↓>

<Tab> Moves cursor to the next field

<Enter> Executes command or selects the submenu

<F9> Load the default configuration values for the current menu

<F10> Save the current values and exits the BIOS Setup program

<Esc> Exits the menu

Selects a different menu screen

Moves cursor up or down

Maintenance Menu

Maintenance Main Advanced Security Power Boot Exit

CPU Frequency [13 To 1 Ratio]

Clear All Passwords

Clear BIS credentials

CPU Stepping Signature [F29] CPU Microcode Update Rev. [<none loaded>]

Enter F1 General Help P9 Setup Defaults F10 Save and Exit ESC Exit

← → ↑ ↓

Select Screen Select Item Select→ Sub-Menu

The menu shown in Table 12 is used to clear the Setup passwords. Setup only displays this menu in configure mode. See page 41 for information about setting configure mode.

Table 12. Maintenance Menu

Feature Options Description

CPU Frequency

Clear All Passwords

Clear BIS Credentials

CPU Stepping Signature No options Displays processor’s Stepping Signature.

CPU Microcode Update Revision No options Displays processor’s Microcode Update Revision.

* For information about the BIS, refer to the Intel Web site at:

http://developer.intel.com/design/security/index1.htm

No options

• Ok

• Cancel

• Ok

• Cancel

Clears both the user and supervisor passwords.

Clears the Wired for Management Boot Integrity Service (BIS) credentials.

Main Menu

Main Advanced Security Power Boot Exit

BIOS Version xxxxx10A.86A.xxxx.xxx

Processor Type Intel(R) Pentium(R) 4 Hyper-Threading Technology [Enabled] Processor Speed X.XX GHz System Bus Speed XXX MHz System Memory Speed XXX MHz

Cache RAM XXX KB

Total Memory XXX MB Memory Mode Dual Channel

Memory Channel A Slot 0 XXX MB (DDRYYY) Memory Channel A Slot 1 Not Installed Memory Channel B Slot 0 XXX MB (DDRYYY) Memory Channel B Slot 1 Not Installed Enter Select f Sub-Menu F1 General Help

Additional System Information P9 Setup Defaults F10 Save and Exit Language [English] ESC Exit

System Time [xx.xx.xx]

Using the BIOS Setup Program

← → ↑ ↓

Select Screen Select Item

Table 13 describes the Main Menu. This menu reports processor and memory information and is used to configure the system date and system time.

Table 13. Main Menu

Feature Options Description

BIOS Version No options Displays the version of the BIOS.

Processor Type No options Displays processor type.

Hyper-Threading Technology

Processor Speed No options Displays processor speed.

System Bus Speed No options Displays the system bus speed.

System Memory Speed No options Displays the system memory speed.

Cache RAM No options

Total Memory No options Displays the total amount of RAM.

Memory Mode No options

Additional System Information

Language

System Time

• Enabled (default)

• Disabled

No options

• English (default)

• Français

Hour, minute, and second

Enables or disables Hyper-Threading Technology.

Displays the size of second-level cache and whether it is ECC-capable.

Displays the amount and type of RAM in the memory banks.

Displays manufacturer, product, and product version and serial number.

Selects the current default language used by the BIOS.

Specifies the current time.

Intel Desktop Board D848PMB Product Guide

Advanced Menu

Main Advanced Security Power Boot Exit

Setup Warning: Setting items on this screen to incorrect values may cause your system to malfunction!

` PCI Configuration ` Boot Configuration ` Peripheral Configuration ` IDE Configuration ` Diskette Configuration ` Event Log Configuration ` Video Configuration ` USB Configuration ` Chipset Configuration Enter Select ` Sub-Menu ` Fan Control Configuration F1 General Help ` Hardware Management P9 Setup Defaults

F10 Save and Exit ESC Exit

← → ↑ ↓

Select Screen Select Item

Table 14 describes the Advanced Menu. This menu is used to set advanced features that are available through the chipset.

Table 14. Advanced Menu

Feature Options Description

PCI Configuration No options Configures individual PCI slot’s IRQ priority. When selected,

displays the PCI Configuration submenu.

Boot Configuration No options Configures Plug & Play and the Numlock key, and resets

configuration data. When selected, displays the Boot Configuration submenu.

Peripheral Configuration No options Configures peripheral ports and devices. When selected,

displays the Peripheral Configuration submenu. IDE Configuration No options Specifies type of connected IDE device. Diskette Configuration No options Configures the floppy drive(s). When selected, displays the

Diskette Configuration submenu. Event Log Configuration No options Configures event logging. When selected, displays the Event

Log Configuration submenu. Video Configuration No options Configures video features. When selected, displays the

Video Configuration submenu. USB Configuration No options Configures USB features. When selected, displays the USB

Configuration submenu. Chipset Configuration No options Configures chipset features. When selected, displays the

Chipset Configuration submenu. Fan Control Configuration No options Configures fan control features. When selected, displays the

Fan Control Configuration submenu. Hardware Management No options Configures hardware management. When selected, displays

the Hardware Management submenu.

PCI Configuration Submenu

Main Advanced Security Power Boot Exit

PCI Configuration

PCI Slot 1 IRQ Priority [Auto] PCI Slot 2 IRQ Priority PCI Slot 3 IRQ Priority PCI Slot 4 IRQ Priority PCI Slot 5 IRQ Priority

Enter Select ` Sub-Menu F1 General Help P9 Setup Defaults F10 Save and Exit ESC Exit

Using the BIOS Setup Program

← → ↑ ↓

Select Screen Select Item

The submenu shown in Table 15 is used to configure the IRQ priority of PCI slots individually.

Table 15. PCI Configuration Submenu

Feature Options Description

PCI Slot 1 IRQ Priority PCI Slot 2 IRQ Priority PCI Slot 3 IRQ Priority PCI Slot 4 IRQ Priority PCI Slot 5 IRQ Priority

• Auto (default)

• 3

• 5

• 9

• 10

• 11

Allows selection of IRQ priority.

Intel Desktop Board D848PMB Product Guide

Boot Configuration Submenu

Main Advanced Security Power Boot Exit

Boot Configuration

Plug & Play O/S [No] Numlock [On]

Enter Select ` Sub-Menu F1 General Help P9 Setup Defaults F10 Save and Exit ESC Exit

← → ↑ ↓

Select Screen Select Item

The submenu shown in Table 16 is used to set the Plug & Play options and the power-on state of the Numlock key.

Table 16. Boot Configuration Submenu

Feature Options Description

Plug & Play O/S

Numlock

• No (default)

• Yes

• Off

• On (default)

Specifies if manual configuration is desired. No lets the BIOS configure all devices in the system. This setting is appropriate when using a Plug and Play operating system. Yes lets the operating system configure Plug & Play (PnP) devices not required for boot if your system has a Plug & Play operating system. This option is available for use during lab testing.

Specifies the power-on state of the Numlock feature on the numeric keypad of the keyboard.

Peripheral Configuration Submenu

Main Advanced Security Power Boot Exit

Peripheral Configuration

Serial Port A [Auto] Parallel Port [Auto] Mode [Bi-directional] LAN Device [Enabled] Audio [Enabled]

Enter Select ` Sub-Menu F1 General Help P9 Setup Defaults F10 Save and Exit ESC Exit

Using the BIOS Setup Program

← → ↑ ↓

Select Screen Select Item

This submenu shown in Table 17 is used for configuring computer peripherals.

Table 17. Peripheral Configuration Submenu

Feature Options Description

Serial Port A

Base I/O Address (This feature is present only when Serial Port A is set to Enabled)

Interrupt (This feature is present only when Serial Port A is set to Enabled)

Parallel Port

• Disabled

• Enabled

• Auto (default)

• 3F8 (default)

• 2F8

• 3E8

• 2E8

• IRQ 3

• IRQ 4 (default)

• Disabled

• Enabled

• Auto (default)

Configures serial port A. Auto assigns the first free COM port, normally COM1,

the address 3F8h, and the interrupt IRQ4. An * (asterisk) displayed next to an address indicates a conflict with another device. Specifies the base I/O address for serial port A, if serial port A is Enabled.

Specifies the interrupt for serial port A, if serial port A is Enabled.

Configures the parallel port. Auto assigns LPT1 the address 378h and the

interrupt IRQ7. An * (asterisk) displayed next to an address indicates

a conflict with another device.

continued

Intel Desktop Board D848PMB Product Guide

Table 17. Peripheral Configuration Submenu (continued)

Feature Options Description

Mode

Base I/O Address (This feature is present only when Parallel Port is set to Enabled)

Interrupt (This feature is present only when Parallel Port is set to Enabled)

LAN Device (This feature is present only when there is onboard LAN)

Audio

• Output only

• Bi-directional (default)

• EPP

• ECP

• 378 (default)

• 278

• IRQ 5

• IRQ 7 (default)

• Disabled

• Enabled (default)

• Disabled

• Enabled (default)

Selects the mode for the parallel port. Not available if the parallel port is disabled.

Output Only operates in AT*-compatible mode.

Bi-directional operates in PS/2-compatible mode.

EPP is Extended Parallel Port mode, a high-speed

bi-directional mode.

ECP is Enhanced Capabilities Port mode, a highspeed bi-directional mode.

Specifies the base I/O address for the parallel port, if Parallel Port is Enabled.

Specifies the interrupt for the parallel port, if Parallel Port is Enabled.

Enables or disables the LAN device.

Enables or disables onboard audio.

ATA/IDE Configuration Submenu

Main Advanced Security Power Boot Exit

IDE Configuration

ATA/IDE Configuration [Legacy] Legacy IDE Channels [PATA Pri and Sec] PCI IDE Bus Master [Enabled] Hard Disk Pre-Delay [Disabled]

` [PATA Primary Master : xxxxxxx] ` [PATA Primary Slave : Not Detected] ` [PATA Secondary Master : xxxxxxx] ` [PATA Secondary Master : Xxxxxxx]

Enter Select ` Sub-Menu F1 General Help P9 Setup Defaults F10 Save and Exit ESC Exit

Using the BIOS Setup Program

← → ↑ ↓

Select Screen Select Item

This submenu shown in Table 18 is used to configure IDE device options.

Table 18. ATA/IDE Configuration Submenu

Feature Options Description

ATA/IDE Configuration

Legacy IDE Channels

PCI IDE Bus Master

Hard Disk Pre-Delay

• Disabled

• Legacy

• Enhanced (default)

• PATA Pri only

• PATA Sec only

• PATA Pri and Sec (default)

• SATA P0/P1 only

• SATA P0/P1, PATA Sec

• SATA P0/P1, PATA Pri

• Disabled

• Enabled (default)

• Disabled (default)

• 3 Seconds

• 6 Seconds

• 9 Seconds

• 12 Seconds

• 15 Seconds

• 21 Seconds

• 30 Seconds

Specifies the integrated IDE controller.

Disabled disables the integrated IDE controller. Legacy enables up to two IDE channels for OS

requiring legacy IDE operation. Enhanced all SATA and PATA resources

Configures PATA and SATA resources for OS requiring legacy IDE operation.

Allows a PCI device to initiate a transaction as a master.

Specifies the hard disk drive pre-delay. Causes the BIOS to insert a delay before attempting to detect IDE drives in the system.

Intel Desktop Board D848PMB Product Guide

PATA and SATA Submenus

Advanced Security Boot Exit Main Power

` [SATA Port-0 :

Type Maximum Capacity

Configuration Options Selected by BIOS

LBA Mode : Block Mode: PIO Mode : Mode 4 Ultra DMA : Mode 6 Cable Detected : Serial

Enter Select ` Sub-Menu F1 General Help P9 Setup Defaults F10 Save and Exit

Xxxxxxxx ]

[Auto] [Auto]

[Supported] 16 sectors

ESC Exit

← → ↑ ↓

Select Screen Select Item

There are four IDE submenus: Primary master, primary slave, secondary master, and secondary slave. Table 19 shows the format of these IDE submenus. For brevity, only one example is shown.

Table 19. SATA and PATA Submenus

Feature Options Description

Drive Installed None Displays the type of drive installed.

Type

Maximum Capacity None Displays the capacity of the drive.

LBA Mode Control

(Note)

Block Mode

PIO Mode

(Note)

• Auto (default)

• User

None Specifies LBA mode control.

• Disabled

• Auto (default)

• 0

• 1

• 2

• 3

• 4

Specifies the IDE configuration mode for IDE devices.

Auto fills-in capabilities from ATA/ATAPI device.

User allows capabilities to be changed.

Check the hard disk drive’s specifications for optimum setting.

Specifies the PIO mode.

continued

Table 19. SATA and PATA Submenus (continued)

Feature Options Description

DMA Mode

• Auto (default)

• SWDMA 0

• SWDMA 1

• SWDMA 2

• MWDMA 0

• MWDMA 1

• MWDMA 2

• UDMA 0

• UDMA 1

• UDMA 2

• UDMA 3

• UDMA 4

• UDMA 5

S.M.A.R.T.

• Auto (default)

• Disable

• Enable

Cable Detected

(Note)

Note: These configuration options appear only if an IDE device is installed.

None Displays the type of cable connected to the IDE interface:

Specifies the Ultra DMA mode for the drive.

Self-monitoring analysis and reporting technology.

40-conductor or 80-conductor (for ATA-66/100 devices) or Serial ATA.

Using the BIOS Setup Program

Intel Desktop Board D848PMB Product Guide

Diskette Configuration Submenu

Main Advanced Security Power Boot Exit

Diskette Configuration

Diskette Controller [Enabled]

Floppy A [1.44/1.25MB 3½"]

Diskette Write Protect [Disabled]

Enter Select ` Sub-Menu F1 General Help P9 Setup Defaults F10 Save and Exit ESC Exit

← → ↑ ↓

Select Screen Select Item

This submenu shown in Table 20 is used to configure the floppy drive.

Table 20. Diskette Configuration Submenu

Feature Options Description

Diskette Controller

Floppy A

Diskette Write Protect

• Disabled

• Enabled (default)

• Disabled

• 360 KB 5¼”

• 1.2 MB 5¼”

• 720 KB 3½”

• 1.44 MB 3½” (default)

• 2.88 MB 3½”

• Disabled (default)

• Enabled

Configures the integrated floppy controller.

Selects the floppy drive type.

Disables or enables diskette drive write protection.

Event Log Configuration Submenu

Main Advanced Security Power Boot Exit

Event Log Configuration

Event Log [Space Available]

View Event Log

Clear Event Log Event Logging [Enabled] ECC Event Logging [Enabled]

Mark Events As Read

Enter Select ` Sub-Menu F1 General Help P9 Setup Defaults F10 Save and Exit ESC Exit

Using the BIOS Setup Program

← → ↑ ↓

Select Screen Select Item

The submenu shown in Table 21 is used to configure the event logging features.

Table 21. Event Log Configuration Submenu

Feature Options Description

Event Log No options Indicates if there is space available in the event log.

View Event Log [Enter] Displays the contents of the DMI event log.

Clear Event Log No options Discards all events in the event log.

Event Logging

ECC Event Logging

Mark Events As Read [Enter] Marks all DMI events in the event log as read.

• Disabled

• Enabled (default)

• Disabled

• Enabled (default)

Enables or disables event logging.

Enabled allows logging of DMI events.

Intel Desktop Board D848PMB Product Guide

Video Configuration Submenu

Main Advanced Security Power Boot Exit

Video Configuration

AGP Aperture Size [ 64MB] Primary Video Adapter [AGP] Frame Buffer Size [1MB]

Enter Select ` Sub-

F1 General Help P9 Setup Defaults F10 Save and Exit ESC Exit

← → ↑ ↓

Select Screen Select Item

The submenu shown in Table 22 is used to configure video features.

Table 22. Video Configuration Submenu

Feature Options Description

AGP Aperture Size

Primary Video Adapter

Frame Buffer Size

• 4 MB

• 8 MB

• 16 MB

• 32 MB

• 64 MB (default)

• 128 MB

• 256 MB

• AGP (default)

• PCI

• 512 KB

• 1 MB (default)

• 8 MB

Amount of system memory available for direct access by the graphics device.

Allows selecting an AGP or PCI video controller as the display device that will be active when the system boots.

Controls how much system RAM is reserved for use by the internal graphics device.

USB Configuration Submenu

Main Advanced Security Power Boot Exit

USB Configuration

High-Speed USB [Enabled] Legacy USB Support [Enabled]

Enter Select ` Sub-Menu F1 General Help P9 Setup Defaults F10 Save and Exit ESC Exit

Using the BIOS Setup Program

← → ↑ ↓

Select Screen Select Item

The submenu shown in Table 23 is used to configure USB features.

Table 23. USB Configuration Submenu

Feature Options Description

High Speed USB

Legacy USB Support

• Disabled

• Enabled (default)

• Disabled

• Enabled (default)

Disable this option when a USB 2.0 driver is not available.

Enables support for legacy USB.

Intel Desktop Board D848PMB Product Guide

Chipset Configuration Submenu

Main Advanced Security Power Boot Exit

Chipset Configuration

Setup Warning: Setting items on this screen to incorrect values may cause your system to malfunction!

ISA Enable Bit [Enabled] PCI Latency Timer [32] CSA Device [Auto]

Do you wish to continue? [Continue] Burn-In Mode [Default]

Enter Select ` Sub-Menu F1 General Help Extended Configuration [Default] P9 Setup Defaults

Chipset Memory Timing Control F10 Save and Exit

Graphics Core Frequency [Auto] ESC Exit SDRAM Frequency [Auto]

← → ↑ ↓

Select Screen Select Item

The submenu shown in Table 24 is used to configure advanced chipset features.

Table 24. Chipset Configuration Submenu

Feature Options Description

ISA Enable Bit

PCI Latency Timer

CSA Device

Do you wish to continue?

Burn-In Mode

• Enabled (default)

• Disabled

• 32 (default)

• 64

• 96

• 128

• 160

• 192

• 224

• 248

• Auto (default)

• Disable

• No (default)

• Continue

• Default (default)

• -2.0%

• -1.0%

• +1.0%

• +2.0%

• +3.0%

• +4.0%

Some older expansion devices require this option to be enabled.

Set PCI latency time.

Alters host and I/O clock frequencies.

continued

Using the BIOS Setup Program

Table 25. Chipset Configuration Submenu (continued)

Feature Options Description

Extended Configuration

Graphics Core Frequency

SDRAM Frequency

SDRAM Timing Control

CPC Override

SDRAM RAS Act. To Pre.

SDRAM CAS# Latency

SDRAM RAS# to CAS# delay

SDRAM RAS# Precharge

• Default (default)

• User Defined

• Auto (default)

• 266 MHz

• 333-320 MHz

• Auto (default)

• 266 MHz

• 333 MHz

• 400 MHz

• Auto (default)

• Manual – Aggressive

• Manual – User Defined

• Auto (default)

• Enabled

• Disabled

• 8 (default)

• 7

• 6

• 5

• 2.0

• 2.5

• 3.0 (default)

• 4

• 3 (default)

• 2

• 4

• 3 (default)

• 2

Chooses the default or user defined settings for the extended configuration options.

Allows override of detected graphics core frequency value.

Allows override of detected memory frequency value.

Auto allows timings to be programmed according to the memory detected.

Manual – Aggressive selects the most aggressive user defined timings.

Manual – User Defined allows manual override of detected SDRAM settings.

Controls Command Per Clock/1n rule mode. When enabled, allows DRAM controller to attempt Chip Select assertions in two consecutive common clocks.

Selects length of time from read to pre-change. Corresponds to tRAS, min.

Selects the number of clock cycles required to address a column in memory. Corresponds to CL.

Selects the number of clock cycles between addressing a row and addressing a column. Corresponds to tRCD.

Selects the length of time required before accessing a new row.

Intel Desktop Board D848PMB Product Guide

Fan Control Submenu

Main Advanced Security Power Boot Exit

Fan Control Configuration

Setup Warning: These options will not take effect until power has been completely removed from the system. After saving the BIOS settings and turning the system off, unplug the power cord from the system and wait for at least 30 seconds before reapplying power and turning the system back on.

Fan Control [Enabled] Lowest Fan Speed [Slow] Enter Select ` Sub-Menu F1 General Help P9 Setup Defaults F10 Save and Exit ESC Exit

← → ↑ ↓

Select Screen Select Item

The menu shown in Table 25 is used to configure hardware management features.

Table 25. Hardware Management

Feature Options Description

Fan Control

Lowest Fan Speed

• Disabled

• Enabled (default)

• Slow (default)

• Off

Disables or enables system fan control.

This option defines the fan speed at the lowest system temperature. Slow allows the fans to continue to run at a reduced speed at low system temperatures. Off turns off the fans at low system temperatures.

Hardware Monitoring Submenu

Main Advanced Security Power Boot Exit

Hardware Monitoring

Note: These measurements are approximate and should not be used for validation purposes.

Processor Zone Temperature 44oC/111oF System Zone 1 Temperature 37oC/98oF System Zone 2 Temperature 35oC/95oF

Processor Fan Speed 2394 RPM Rear Fan Speed (J1B1) 0 RPM Rear Fan Speed (J5B1) 0 RPM Front Fan Speed 0 RPM

+1.5Vin 1.480 V Enter Select ` Sub-Menu Vccp 1.447 V F1 General Help +3.3Vin 3.258 V P9 Setup Defaults +5Vin 5.026 V F10 Save and Exit 12Vin 11.625 V ESC Exit

Using the BIOS Setup Program

← → ↑ ↓

Select Screen Select Item

Table 26. Hardware Monitoring Submenu

Feature Options Description

Processor Zone Temperature No option Displays processor zone temperature.

System Zone 1 Temperature No option Displays system zone 1 temperature.

System Zone 2 Temperature No option Displays system zone 2 temperature.

Processor Fan Speed No option Displays processor fan speed.

Rear Fan Speed

VREG Fan Speed No option Displays VREG fan speed.

Front Fan Speed No option Displays front fan speed.

No option Displays rear fan speed.

Intel Desktop Board D848PMB Product Guide

Security Menu

Main Advanced Security Power Boot Exit

Supervisor Password : Not Installed User Password : Not Installed

Set Supervisor Password Set User Password

Chassis Intrusion [Disabled]

Enter Select ` Sub-Menu F1 General Help P9 Setup Defaults F10 Save and Exit ESC Exit

← → ↑ ↓

Select Screen Select Item

The menu shown in Table 27 is used to set passwords and security features.

Table 27. Security Menu

If no password entered previously:

Feature Options Description

Supervisor Password No options Reports if there is a supervisor password set.

User Password No options Reports if there is a user password set.

Set Supervisor Password Password can be up to seven

alphanumeric characters.

Set User Password Password can be up to seven

alphanumeric characters.

Clear User Password

(Note 1)

User access Level

(Note 2)

Chassis Intrusion

Notes:

1. This feature appears only if a user password has been set.

2. This feature appears only if both a user password and a supervisor password have been set.

• Yes (default)

• No

• Limited

• No access

• View Only

• Full (default)

• Disabled (default)

• Enabled

Specifies the supervisor password.

Specifies the user password.

Clears the user password.

Sets BIOS Setup Utility access rights for user level.

Enables or disables the chassis intrusion feature.

Power Menu

Main Advanced Security Power Boot Exit

` ACPI

After Power Failure [Last State]

The options below are not related to ACPI and may be ignored when shutting down using an ACPI OS.

Wake on PCI PME [Stay Off]

Enter Select ` Sub-Menu F1 General Help P9 Setup Defaults F10 Save and Exit ESC Exit

Using the BIOS Setup Program

← → ↑ ↓

Select Screen Select Item

The menu shown in Table 28 is used to set power management features.

Table 28. Power Menu

Feature Options Description

ACPI No Options When selected, displays the ACPI submenu.

After Power Failure

Wake on PCI PME

• Stay Off

• Last State (default)

• Power On

• Stay Off (default)

• Power-On

Determines the mode of operation if a power loss occurs.

Stay Off keeps the power off until the power button is pressed.

Last State restores the previous power state before power loss occurred.

Power On restores power to the computer.

Determines how the system responds to a PCI-PME wake up event.

Intel Desktop Board D848PMB Product Guide

ACPI Submenu

Main Advanced Security Power Boot Exit

Advanced Configuration and Power Interface

ACPI Suspend State [S1 State] Wake on LAN from S5 [Stay Off]

Enter Select ` Sub-Menu F1 General Help P9 Setup Defaults F10 Save and Exit ESC Exit

S1 is the safest mode

ut consumes more power. S3 consumes low power but drivers may not support this state.

← → ↑ ↓

Select Screen Select Item

The submenu represented in Table 29 is for setting the ACPI features.

Table 29. ACPI Submenu

Feature Options Description

ACPI Suspend Mode

Wake on LAN* from S5

• S1 State (default)

• S3 State

• Stay Off (default)

• Power On

Specifies the ACPI sleep state.

In ACPI soft-off mode only, determines how the system responds to a LAN wake up event when the system is in the ACPI soft-off mode.

Boot Menu

Main Advanced Security Power Boot Exit

Silent BOOT [Enabled] Intel ® Rapid BIOS Boot [Enabled] Scan User Flash Area [Enabled] PXE Boot to LAN [Disabled] USB Boot [Enabled]

` Boot Device Priority ` Hard Disk Drives ` Removable Devices ` ATAPI CD-ROM Drives

Enter Select ` Sub-Menu F1 General Help P9 Setup Defaults F10 Save and Exit ESC Exit

Using the BIOS Setup Program

← → ↑ ↓

Select Screen Select Item

The menu shown in Table 30 is used to set the boot features and the boot sequence.

Table 30. Boot Menu

Feature Options Description

Silent Boot

Intel® Rapid BIOS Boot

Scan User Flash Area

PXE Boot to LAN

USB Boot

Boot Device Priority No options Specifies the boot sequence from the available types of

Hard Disk Drives No options Specifies the boot sequence from the available hard

Removable Devices No options Specifies the boot sequence from the available removable

ATAPI CD-ROM Drives No options Specifies the boot sequence from the available ATAPI

• Disabled

• Enabled (default)

• Disabled

• Enabled (default)

• Disabled

• Enabled (default)

• Disabled (default)

• Enabled

• Disabled

• Enabled (default)

Disabled displays normal POST messages.

Enabled displays OEM logo instead of POST messages.

Allows BIOS to skip certain tests while booting.

Enables the BIOS to scan the flash ROM for user binary files that are executed at boot time.

Disables or enables PXE boot to LAN.

Disables or enables booting to USB boot devices.

boot devices.

disk drives.

devices.

CD-ROM drives.

Intel Desktop Board D848PMB Product Guide

Boot Device Priority Submenu

Main Advanced Security Power Boot Exit

1st Boot Device [1st FLOPPY DRIVE] 2nd Boot Device [xxxxxxxxxxx] 3rd Boot Device [xxxxxxxxxxx]

Enter Select ` Sub-Menu F1 General Help P9 Setup Defaults F10 Save and Exit ESC Exit

Specifies the boot sequence from the available devices.

A device enclosed in parenthesis has been disabled in the corresponding type menu.

← → ↑ ↓

Select Screen Select Item

The submenu represented in Table 31 is for setting boot devices priority.

Table 31. Boot Device Priority Submenu

Feature

1st Boot Device

Boot Device

Options Description

• Removable Device

• Hard Drive

• ATAPI CD-ROM

• Disabled

Specifies the boot sequence from the available devices. To specify boot sequence:

1. Select the boot device with <↑> or <↓>.

2. Press <Enter> to set the selection as the intended boot device.

The operating system assigns a drive letter to each boot device in the order listed. Changing the order of the devices changes the drive lettering. The default settings for the first through final boot devices are, respectively listed below. The BIOS supports up to sixteen total boot devices in any combination of the boot device types below, with respect to these maximums per type.

• Removable Device (maximum of four).

• Hard Drive (maximum of 12).

• ATAPI CD-ROM (maximum of four).

• A device enclosed in parenthesis has been disabled in the

corresponding type menu.

Hard Disk Drives Submenu

Main Advanced Security Power Boot Exit

1st Drive [xxxxxxxxxxxxx] 2nd Drive [xxxxxxxxxxxxx] 3rd Drive [xxxxxxxxxxxxx] 4th Drive [xxxxxxxxxxxxx]

Enter Select ` Sub-Menu F1 General Help P9 Setup Defaults F10 Save and Exit ESC Exit

Using the BIOS Setup Program

Specifies the boot sequence from the available devices. Select the boot device with UpArrow or DownArrow key. Press Enter to set the selections as the intended boot device. ARMD = ATAPI Removable Media Device.

← → ↑ ↓

Select Screen Select Item

The submenu shown in Table 32 is for setting hard disk drives.

Table 32. Hard Disk Drives Submenu

Feature Options Description

1st Hard Disk Drive

(Note)

Note: This boot device submenu appears only if at least one boot device of this type is installed. This list will display up to

12 hard disk drives, the maximum number of hard disk drives supported by the BIOS.

Dependent on installed hard drives

Specifies the boot sequence from the available hard disk drives. To specify boot sequence:

1. Select the boot device with <↑> or <↓>.

2. Press <Enter> to set the selection as the intended boot device.

Intel Desktop Board D848PMB Product Guide

Removable Devices Submenu

Main Advanced Security Power Boot Exit

1st Drive [1st FLOPPY DRIVE]

Enter Select ` Sub-Menu F1 General Help P9 Setup Defaults F10 Save and Exit ESC Exit

← → ↑ ↓

Select Screen Select Item

The submenu in shown Table 33 is for setting removable devices.

Table 33. Removable Devices Submenu

Feature Options Description

1st Removable Device

(Note)

Note: This boot device submenu appears only if at least one boot device of this type is installed. This list will

display up to four removable devices, the maximum number of removable devices supported by the BIOS.

Dependent on installed removable devices

Specifies the boot sequence from the available removable devices. To specify boot sequence:

1. Select the boot device with <↑> or <↓>.

2. Press <Enter> to set the selection as the intended boot device.

ATAPI CD-ROM Drives

Main Advanced Security Power Boot Exit

1st Drive [xxxxxxx]

Drive [xxxxxxx]

Enter Select ` Sub-Menu F1 General Help P9 Setup Defaults F10 Save and Exit ESC Exit

Using the BIOS Setup Program

← → ↑ ↓

Select Screen Select Item

The submenu shown in Table 34 is for setting ATAPI CD-ROM drives.

Table 34. ATAPI CD-ROM Drives Submenu

Feature Options Description

1st ATAPI CD-ROM Drive

(Note)

Note: This boot device submenu appears only if at least one boot device of this type is installed. This list will display

up to four ATAPI CD-ROM drives, the maximum number of ATAPI CD-ROM drives supported by the BIOS.

Dependent on installed ATAPI CD-ROM drives

Specifies the boot sequence from the available ATAPI CD-ROM drives. To specify boot sequence:

1. Select the boot device with <↑> or <↓>.

2. Press <Enter> to set the selection as the intended boot device.

Intel Desktop Board D848PMB Product Guide

Exit Menu

Main Advanced Security Power Boot Exit

Exit Saving Changes Exit Discarding Changes Load Optimal Defaults Load Custom Defaults Save Custom Defaults Discard Changes

Enter Select ` Sub-Menu F1 General Help P9 Setup Defaults F10 Save and Exit ESC Exit

← → ↑ ↓

Select Screen Select Item

The menu shown in Table 35 is used to exit the BIOS Setup program, saving changes, and loading and saving defaults.

Table 35. Exit Menu

Feature Description

Exit Saving Changes Exits and saves the changes in CMOS SRAM.

Exit Discarding Changes Exits without saving any changes made in the BIOS Setup program.

Load Optimal Defaults Loads optimal defaults.

Load Custom Defaults Loads the custom defaults for Setup options.

Save Custom Defaults Saves the current values as custom defaults. Normally, the BIOS reads the

Setup values from flash memory. If this memory is corrupted, the BIOS reads the custom defaults. If no custom defaults are set, the BIOS reads the factory defaults.

Discard Changes Discards changes without exiting Setup. The option values present when the

computer was turned on are used.

5 Desktop Board Resources

Memory Map

Table 36. System Memory Map

Address Range (decimal) Address Range (hex) Size Description

1024 K - 2097152 K 100000 - 7FFFFFF 2047 MB Extended Memory

960 K - 1024 K F0000 - FFFFF 64 KB Runtime BIOS

896 K - 960 K E0000 - EFFFF 64 KB Reserved

800 K - 896 K C8000 - DFFFF 96 KB Available high DOS memory (open to the

PCI bus)

640 K - 800 K A0000 - C7FFF 160 KB Video memory and BIOS

639 K - 640 K 9FC00 - 9FFFF 1 KB Extended BIOS data (movable by

memory manager software)

512 K - 639 K 80000 - 9FBFF 127 KB Extended conventional memory

0 K - 512 K 00000 - 7FFFF 512 KB Conventional memory

DMA Channels

Table 37. DMA Channels

DMA Channel Number Data Width System Resource

0 8 or 16 bits

1 8 or 16 bits Parallel port

2 8 or 16 bits Floppy drive

3 8 or 16 bits Parallel port (for ECP or EPP)

4 8 or 16 bits DMA controller

5 16 bits Open

6 16 bits Open

7 16 bits Open

Intel Desktop Board D848PMB Product Guide

Interrupts

Table 38. Interrupts

IRQ System Resource

NMI I/O channel check

0 Reserved, interval timer

1 Reserved, keyboard buffer full

2 Reserved, cascade interrupt from slave PIC

3 COM2*

4 COM1*

5 LPT2 (Plug and Play option) **

6 Floppy drive controller

7 LPT1*

8 Real time clock

9 **

10 **

11 **

12 Onboard mouse port (if present, else user available)

13 Reserved, math coprocessor

14 Primary IDE (if present, else user available)

15 Secondary IDE (if present, else user available)

* Default, but can be changed to another IRQ. ** Dynamically allocated for all PCI/AGP devices and slots.

A Error Messages and Indicators

Desktop Board D848PMB reports POST errors in two ways:

• By sounding a beep code

• By displaying an error message on the monitor

BIOS Beep Codes

The BIOS beep codes are listed in Table 39. The BIOS also issues a beep code (one long tone followed by two short tones) during POST if the video configuration fails (a faulty video card or no card installed) or if an external ROM module does not properly checksum to zero.

Table 39. Beep Codes

Number of Beeps Description

1 Refresh failure

2 Parity cannot be reset

3 First 64 K memory failure

4 Timer not operational

5 Processor failure (Reserved; not used)

6 8042 GateA20 cannot be toggled (memory failure or not present)

7 Exception interrupt error

8 Display memory R/W error

9 (Reserved; not used)

10 CMOS Shutdown register test error

11 Invalid BIOS (such as, POST module not found)

Intel Desktop Board D848PMB Product Guide

BIOS Error Messages

When a recoverable error occurs during the POST, the BIOS displays an error message describing the problem.

Table 40. BIOS Error Messages

Error Message Explanation

GA20 Error An error occurred with Gate-A20 when switching to protected

mode during the memory test.

Pri Master HDD Error Pri Slave HDD Error Sec Master HDD Error Sec Slave HDD Error

Pri Master Drive - ATAPI Incompatible Pri Slave Drive - ATAPI Incompatible Sec Master Drive - ATAPI Incompatible Sec Slave Drive - ATAPI Incompatible

A: Drive Error B: Drive Error

CMOS Battery Low The battery may be losing power. Replace the battery soon.

CMOS Display Type Wrong The display type is different than what has been stored in CMOS.

CMOS Checksum Bad The CMOS checksum is incorrect. CMOS memory may have been

CMOS Settings Wrong CMOS values are not the same as the last boot. These values

CMOS Date/Time Not Set The time and/or date values stored in CMOS are invalid. Run

DMA Error Error during read/write test of DMA controller.

FDC Failure Error occurred trying to access diskette drive controller.

HDC Failure Error occurred trying to access hard disk controller.

Checking NVRAM..... NVRAM is being checked to see if it is valid.

Update OK! NVRAM was invalid and has been updated.

Updated Failed NVRAM was invalid but was unable to be updated.

Keyboard Is Locked The system keyboard lock is engaged. The system must be

Keyboard Error Error in the keyboard connection. Make sure keyboard is

KB/Interface Error Keyboard interface test failed.

Could not read sector from corresponding drive.

Corresponding drive is not an ATAPI device. Run Setup to make sure device is selected correctly.

No response from the diskette drive.

Check Setup to make sure type is correct.

corrupted. Run Setup to reset values.

have either been corrupted or the battery has failed.

Setup to set correct values.

unlocked to continue to boot.

connected properly.

continued

Error Messages and Indicators

Table 40. BIOS Error Messages (continued)

Error Message Explanation

Memory Size Decreased Memory size has decreased since the last boot. If no memory was

removed, then memory may be bad.

Memory Size Increased Memory size has increased since the last boot. If no memory was

added, there may be a problem with the system.

Memory Size Changed

No Boot Device Available System did not find a device to boot.

Off Board Parity Error

On Board Parity Error A parity error occurred in onboard memory. This error is followed

Parity Error A parity error occurred in onboard memory at an unknown

NVRAM / CMOS / PASSWORD cleared by Jumper

<CTRL_N> Pressed CMOS is ignored and NVRAM is cleared. User must enter Setup.

Memory size has changed since the last boot. If no memory was added or removed, then memory may be bad.

A parity error occurred on an offboard card. This error is followed by an address.

by an address.

address.

NVRAM, CMOS, and passwords have been cleared. The system should be powered down and the jumper removed.

Intel Desktop Board D848PMB Product Guide

B Regulatory Compliance

This appendix contains the following regulatory compliance information for Desktop Board D848PMB:

• Safety regulations

• European Union Declaration of Conformity statement

• Product Ecology statements

• Electromagnetic Compatibility (EMC) regulations

• Product certification markings

Safety Regulations

Desktop Board D848PMB complies with the safety regulations stated in Table 41 when correctly installed in a compatible host system.

Table 41. Safety Regulations

Regulation Title

UL 60950 3rd ed., 2000/CSA C22.2 No. 60950-00

EN 60950:2000

IEC 60950, 3rd Edition, 1999

Bi-National Standard for Safety of Information Technology Equipment including Electrical Business Equipment. (USA and Canada)

The Standard for Safety of Information Technology Equipment including Electrical Business Equipment. (European Union)

The Standard for Safety of Information Technology Equipment including Electrical Business Equipment. (International)

European Union Declaration of Conformity Statement

We, Intel Corporation, declare under our sole responsibility that the product Intel® Desktop Board D848PMB is in conformity with all applicable essential requirements necessary for CE marking, following the provisions of the European Council Directive 89/336/EEC (EMC Directive) and Council Directive 73/23/EEC (Safety/Low Voltage Directive).

The product is properly CE marked demonstrating this conformity and is for distribution within all member states of the EU with no restrictions.

This product follows the provisions of the European Directives 89/336/EEC and 73/23/EEC.

Intel Desktop Board D848PMB Product Guide

Dansk Dette produkt er i overensstemmelse med det europæiske direktiv 89/336/EEC & 73/23/EEC.

Dutch Dit product is in navolging van de bepalingen van Europees Directief 89/336/EEC & 73/23/EEC.

Suomi Tämä tuote noudattaa EU-direktiivin 89/336/EEC & 73/23/EEC määräyksiä.

Français Ce produit est conforme aux exigences de la Directive Européenne 89/336/EEC &

73/23/EEC.

Deutsch Dieses Produkt entspricht den Bestimmungen der Europäischen Richtlinie 89/336/EEC & 73/23/EEC.

Icelandic Þessi vara stenst reglugerð Evrópska Efnahags Bandalagsins númer 89/336/ EEC & 73/23/EEC.

Italiano Questo prodotto è conforme alla Direttiva Europea 89/336/EEC & 73/23/EEC.

Norsk Dette produktet er i henhold til bestemmelsene i det europeiske direktivet 89/336/ EEC &

73/23/EEC.

Portuguese Este produto cumpre com as normas da Diretiva Européia 89/336/EEC & 73/23/EEC.

Español Este producto cumple con las normas del Directivo Europeo 89/336/EEC & 73/23/EEC.

Svenska Denna produkt har tillverkats i enlighet med EG-direktiv 89/336/EEC & 73/23/EEC.

Product Ecology Statements

The following information is provided to address worldwide product ecology concerns and regulations.

Disposal Considerations

This product contains the following materials that may be regulated upon disposal: lead solder on the printed wiring board assembly.

Recycling Considerations

Intel encourages its customers to recycle its products and their components (e.g., batteries, circuit boards, plastic enclosures, etc.) whenever possible. In the U.S., a list of recyclers in your area can be found at:

http://www.eiae.org

In the absence of a viable recycling option, products and their components must be disposed of in accordance with all applicable local environmental regulations.

Regulatory Compliance

EMC Regulations

Desktop Board D848PMB complies with the EMC regulations stated in Table 42 when correctly installed in a compatible host system.

Table 42. EMC Regulations

Regulation Title

FCC Class B

ICES-003 (Class B) Interference-Causing Equipment Standard, Digital Apparatus. (Canada)

EN55022: 1998 (Class B)

EN55024: 1998

AS/NZS 3548 (Class B)

CISPR 22, 3rd Edition, (Class B)

CISPR 24: 1997

Title 47 of the Code of Federal Regulations, Parts 2 and 15, Subpart B, Radio Frequency Devices. (USA)

Limits and methods of measurement of Radio Interference Characteristics of Information Technology Equipment. (European Union)

Information Technology Equipment – Immunity Characteristics Limits and methods of measurement. (European Union)

Australian Communications Authority, Standard for Electromagnetic Compatibility. (Australia and New Zealand)

Limits and methods of measurement of Radio Disturbance Characteristics of Information Technology Equipment. (International)

Information Technology Equipment – Immunity Characteristics – Limits and Methods of Measurement. (International)

Korean Class B statement translated as follows: this is household equipment that is certified to comply with EMC requirements. You may use this equipment in residential environments and other non-residential environments.

Intel Desktop Board D848PMB Product Guide

Product Certification Markings (Board Level)

Desktop Board D848PMB has the following product certification markings:

Table 43. Product Certification Markings

Description Mark

UL joint US/Canada Recognized Component mark. Includes adjacent UL file number for Intel desktop boards: E210882 (component side).

FCC Declaration of Conformity logo mark for Class B equipment; includes Intel name and D848PMB model designation (component side).

CE mark. Declares compliance to European Union (EU) EMC directive (89/336/EEC) and Low Voltage directive (73/23/EEC) (component side). The CE mark should also be on the shipping container.

Australian Communications Authority (ACA) C-tick mark. Includes adjacent Intel supplier code number, N-232. The C-tick mark should also be on the shipping container.

Japan VCCI (Voluntary Control Council for Interference) mark.

Taiwan BSMI (Bureau of Standards, Metrology, and Inspection) mark. Includes adjacent Intel registration number, D33025.
