February 20, 2002
Contents
ReleaseNotes for the Cisco 811and 813Routers
for CiscoIOS Release 12.1(2)XF
These release notes describe new features and significant software components for the Cisco 811
and 813 Routersthat support Cisco IOS Release 12.1(2)XF5. These release notes are updated as needed
to describe new memory requirements, new features, new hardware support, software platform
deferrals, microcode or modem code changes, related document changes, and any other important
changes. Use these release notes with the Cross-Platform Release Notes for Cisco IOS Release
12.1 located on Cisco.com and the Documentation CD-ROM.
For a list of the software caveats that apply to Release 12.1(2)XF5, refer to the section “Caveats” and
to the online Caveats for Cisco IOS Release 12.1 T document. The caveats document is updated for
every 12.1 T maintenance release and is located on Cisco.com and the Documentation CD-ROM.
These release notes discuss the following topics:
• System Requirements, page 1
• New and Changed Information, page 6
• Limitations and Restrictions, page 7
• Important Notes, page 9
• Caveats, page 11
• Related Documentation, page 13
• Obtaining Documentation, page 21
• Obtaining Technical Assistance, page 22
Corporate Headquarters: Cisco Systems, Inc., 170 West Tasman Drive, San Jose, CA 95134-1706 USA
Copyright © 2000–2002. Cisco Systems, Inc. All rights reserved.
78-11070-02, Rev. H0
System Requirements
System Requirements
This section describes the system requirements for Release 12.1(2)XF5 and includes the following
sections:
• Memory Requirements
• Hardware Supported, page 2
• Determining Your Software Release, page 3
• Upgrading to a New Software Release, page 3
• Feature Set Tables, page 4
Memory Requirements
This section describes the memory requirements for the Cisco IOS feature sets supported by Cisco IOS
Release 12.1(2)XF5 on the Cisco 811 and 813 Routers.
Table 1 Memory Requirements for the Cisco 811 and 813 Routers
Platforms Image Name Image
Cisco 811
and 813
Hardware Supported
Cisco IOS Release 12.1(2)XF5 supports the following Cisco 800 series routers:
• Cisco 811
• Cisco 813
For detailed descriptions of new hardware features, see New and Changed Information, page 6.
Table 2 Supported Interfaces for the Cisco 800 Series
Router Ethernet LAN Ports Ethernet WAN Ports
Cisco 811 One 10BaseT (RJ-45) • One ISDN BRI U,
Cisco 813 One 10BaseT (RJ-45)
Required
Flash
Memory
IP c800-y6-mw 4 MB 8 MB RAM
IP Plus c800-sy6-mw 4 MB 8 MB RAM
IP/IPX Plus c800-nsy6-mw 4 MB 8 MB RAM
IP/FW c800-oy6-mw 4 MB 8 MB RAM
IP/FW Plus IPSec 56 c800-osy656i-mw 8 MB 8 MB RAM
IP/IPX/FW Plus IPSec 56 c800-nosy656i-mw 8 MB 8 MB RAM
integrated DSU (RJ-11),
• One ISDN BRI S/T (R-J45)
• One ISDN BRI U,
4-port hub
integrated DSU (RJ-11),
• One ISDN BRI S/T (R-J45)
Required
DRAM
Memory
Analog Phone
Ports
– RJ-45
Two (RJ-11) RJ-45
Runs
From
Console
Ports
Release Notes for the Cisco 811 and 813 Routers for Cisco IOS Release 12.1(2)XF
2
78-11070-02, Rev. H0
Cisco 811 and 813 Routers
The Cisco 811 and 813 Routers provide the following key hardware features:
• Flash memory: Default is 4 MB and is expandable to 12 MB. Additional Flash memory is installed
using Intel “Mini-Card” technology.
• Dynamic RAM: Default is 8 MB and is expandable to 16 MB, which must be obtained from
Cisco Systems.
• The central processing unit is a 33 MHz MPC 850 processor.
• Routers mounted on a wall.
Determining Your Software Release
To determine the version of Cisco IOS software currently running on your Cisco 800 series router, log
in to the router and enter the show version EXEC command. The following sample output from the
show version command indicates the version number on the second output line:
router> show version
Cisco Internetwork Operating System Software
IOS (tm) 800 Software (c800-y6-mw), Version 12.1(2)XF5, RELEASE SOFTWARE
System Requirements
Additional command output lines include more information, such as processor revision numbers,
memory amounts, hardware IDs, and partition information.
Upgrading to a New Software Release
For information about upgrading to a new software release, refer to the Cisco IOS Upgrade Ordering
Instructions product bulletin located at the following URL:
http://www.cisco.com/warp/public/cc/cisco/mkt/ios/prodlit/957_pp.htm.
Alternatively, the Cisco IOS Software page on Cisco.com has a variety of information, including
upgrade information, organized by release. If you have a Cisco.com account and log in, you can go
directly to: http://www.cisco.com/kobayashi/sw-center/sw-ios.shtml.
If you have a Cisco.com account and log in, you can reach the new software release upgrade page by
going to www.cisco.com and following this path: Service & Support: Software Center: Cisco IOS
Software: Product Bulletins: Software: General System Software Bulletins: Cisco IOS Upgrade
Ordering Instructions, No. 957
You can also reach the IOS Upgrade Planner, which allows you more flexibility to browse for your
preferred software, by going to www.cisco.com and following this path: Service & Support: Software
Center: IOS Upgrade Planner.
78-11070-02, Rev. H0
Release Notes for the Cisco 811 and 813 Routers for Cisco IOS Release 12.1(2)XF
3
System Requirements
Feature Set Tables
The Cisco IOS software is packaged in feature sets consisting of software images—depending on the
platform. Each feature set contains a specific set of Cisco IOS features. Release 12.1(2)XF5 supports
the same feature sets as Releases 12.1 and 12.1 T, but Release 12.1(2)XF5 can include new features
supported by the Cisco 811 and 813 Routers. Table 3 lists the feature sets supported by the Cisco 811
and 813 Routers.
Table 3 Feature Sets Supported by the Cisco 811 and 813 Routers
Image Name Feature Set Matrix Terms Software Image Platform
Cisco 800 Series IOS IP IP c800-y6-mw Cisco 811 and 813
Cisco 800 Series IOS IP Plus IP Plus c800-sy6-mw Cisco 811 and 813
Cisco 800 Series IOS IP/IPX Plus IP/IPX Plus c800-nsy6-mw Cisco 811 and 813
Cisco 800 Series IOS IP/FW IP/FW c800-oy6-mw Cisco 811 and 813
Cisco 800 Series IOS IP/FW Plus IPSec 56 IP/FW Plus IPSec 56 c800-osy656i-mw Cisco 811 and 813
Cisco 800 Series IOS IP/IPX/FW Plus IPSec 56 IP/IPX/FW Plus IPSec 56 c800-nosy656i-mw Cisco 811 and 813
Table 4 lists the features and feature sets supported by the Cisco 811 and 813 Routers in Cisco IOS
Release 12.1(2)XF5. The table uses the following conventions:
• Yes—The feature is supported in the software image.
• No—The feature is not supported in the software image.
Note These feature set tables only contain a selected list of features. These tables are not
cumulative—nor do they list all the features in each image.
Table 4 Feature List by Feature Set for the Cisco 811 and 813 Routers
Feature Sets
IP/FW
Features IP IP Plus
Address Conservation
IP/IPX
Plus IP/FW
Plus
IPSec 56
NAT Yes Yes Yes Yes Yes Yes
Ease of Use and Deployment
Auto SPID/SWITCH Connection Yes Yes Yes Yes Yes Yes
Cisco Fast Step Software, Version 2.5 Yes Yes Yes Yes Yes Yes
Configuration Express Yes Yes Yes Yes Yes Yes
Easy IP Phase I and II Yes Yes Yes Yes Yes Yes
TFTP Client Server Yes Yes Yes Yes Yes Yes
INS 64 Telephone Features (813 model only)
IP/IPX/FW
Plus
IPSec 56
Call Blocking on Caller ID Yes Yes Yes Yes Yes Yes
Caller ID Yes Yes Yes Yes Yes Yes
Release Notes for the Cisco 811 and 813 Routers for Cisco IOS Release 12.1(2)XF
4
78-11070-02, Rev. H0
System Requirements
Table 4 Feature List by Feature Set for the Cisco 811 and 813 Routers
Feature Sets
IP/FW
Features IP IP Plus
IP/IPX
Plus IP/FW
Plus
IPSec 56
Call Waiting Yes Yes Yes Yes Yes Yes
Distinctive Ringing Yes Yes Yes Yes Yes Yes
E Ya Yo Yes Yes Yes Yes Yes Yes
I Number Yes Yes Yes Yes Yes Yes
ISDN Voice Priority Yes Yes Yes Yes Yes Yes
Nariwake Yes Yes Yes Yes Yes Yes
Troublesome Call Refusing Yes Yes Yes Yes Yes Yes
Voice Warp Yes Yes Yes Yes Yes Yes
Voice Warp Select Yes Yes Yes Yes Yes Yes
LAN
IP/IPX/FW
Plus
IPSec 56
IP Yes Yes Yes Yes Yes Yes
IPX No No Yes No No Yes
NetBIOS Access Lists, Name Caching Yes Yes Yes Yes Yes Yes
Transparent Bridging Yes Yes Yes Yes Yes Yes
Management
CiscoView Yes Yes Yes Yes Yes Yes
SNMP, Telnet, Console Port Yes Yes Yes Yes Yes Yes
SNTP Yes Yes Yes Yes Yes Yes
Syslog Yes Yes Yes Yes Yes Yes
TACACS+ No Yes Yes No Yes Yes
Routing
IP Enhanced IGRP No Yes Yes No Yes Yes
IP Multicast (Relay Only) No Yes Yes No Yes Yes
IP-Policy Routing Yes Yes Yes Yes Yes Yes
IPX WAN No No Yes No No Yes
RIP, RIPv2, Triggered RIP Yes Yes Yes Yes Yes Yes
Security (Basic)
GRE Tunneling No Yes Yes No Yes Yes
NAT Yes Yes Yes Yes Yes Yes
PAP, CHAP, Local Password, MSCHAP Yes Yes Yes Yes Yes Yes
Route and Router Authentication Yes Yes Yes Yes Yes Yes
Token Card Authentication Yes Yes Yes Yes Yes Yes
78-11070-02, Rev. H0
Release Notes for the Cisco 811 and 813 Routers for Cisco IOS Release 12.1(2)XF
5
System Requirements
Table 4 Feature List by Feature Set for the Cisco 811 and 813 Routers
Feature Sets
IP/FW
Features IP IP Plus
Security (Enhanced)
IP/IPX
Plus IP/FW
Plus
IPSec 56
Cisco IOS Firewall No No No Yes Yes Yes
Context Based Access Control Lists No No No Yes Yes Yes
Denial of Service Detection No No No Yes Yes Yes
IPSec Encryption w/ 56-bit DES No No No No Yes Yes
Java Blocking No No No Yes Yes Yes
Real-time Alerts No No No Yes Yes Yes
Voice Features (Supplementary)
Call Conference Yes Yes Yes Yes Yes Yes
Call Hold / Retrieve Yes Yes Yes Yes Yes Yes
Call Transfer Yes Yes Yes Yes Yes Yes
Voice Priority Yes Yes Yes Yes Yes Yes
WAN
IP/IPX/FW
Plus
IPSec 56
Frame Relay (Leased Line Only) Yes Yes Yes Yes Yes Yes
ISDN Yes Yes Yes Yes Yes Yes
ISDN Lease Line Yes Yes Yes Yes Yes Yes
ML-PPP, PPP Compression Yes Yes Yes Yes Yes Yes
WAN Optimization
BOD Yes Yes Yes Yes Yes Yes
DDR Yes Yes Yes Yes Yes Yes
IPX and SPX Spoofing No Yes No No No Yes
ISDN Caller ID Callback Yes Yes Yes Yes Yes Yes
Snapshot Routing Yes Yes Yes Yes Yes Yes
STAC Compression Yes Yes Yes Yes Yes Yes
Weighted Fair Queuing Quality of Service Yes Yes Yes Yes Yes Yes
X.25 ID No Yes Yes No Yes Yes
Release Notes for the Cisco 811 and 813 Routers for Cisco IOS Release 12.1(2)XF
6
78-11070-02, Rev. H0
New and Changed Information
The following sections list the new hardware and software features supported by the Cisco 800 series
for Release 12.1 T:
New Hardware and Software Features in Release 12.1(2)XF3
The following sections list the new hardware and software features supported by the Cisco Cisco 811
and 813 Routers for Release 12.1(2)XF3.
Cisco 811 and 813 Routers
Cisco 800 series routers provide network connectivity for small offices and corporate telecommuters.
The Cisco 811 and 813 routers additionally supply value-added services, such as virtual private
networks (VPNs), managed network services, point of sale (POS) applications, and secure Internet
access.
System Requirements
New Software Features in Release 12.1(1)
For information regarding the features supported in Cisco IOS Release 12.1, refer to the Cross-Platform
Release Notes and New Feature Documentation links at the following location on Cisco.com:
http://www.cisco.com/univercd/cc/td/doc/product/software/ios121/index.htm
This URL is subject to change without notice. If it changes, point your web browser to Cisco.com, and
click on the following path:
Service & Support: Technical Documents: Documentation Home Page: Cisco IOS Software
Configuration: Cisco IOS Release 12.1: Cisco IOS Release 12.1
Limitations and Restrictions
Supported MIBs
Table 5 lists the MIBs supported by the Cisco 800 series routers. Each group of MIBs corresponds to a
specific group of images.
Table 5 MIBs Supported by the Cisco 800 Series Routers
Image Names MIBs
c800-sy6-mw
c800-osy6-mw
c800-osy656i-mw
c800-nsy6-mw
c800-nosy656i-mw
c800-osy6-mw
CISCO-IPMROUTE-MIB
CISCO-SYSLOG-MIB
ENTITY-MIB (added)
IPMROUTE-MIB
RFC1382-MIB (X25MIB)
78-11070-02, Rev. H0
Release Notes for the Cisco 811 and 813 Routers for Cisco IOS Release 12.1(2)XF
7
System Requirements
Table 5 MIBs Supported by the Cisco 800 Series Routers
Image Names MIBs
c800-nsy6-mw
c800-nosy656i-mw
NOVELL-IPX-MIB
NOVELL-RIPSAP-MIB
OLD-CISCO-NOVELL-MIB
c800-osy656i-mw
CISCO-IP-ENCRYPTION-MIB
c800-nosy656i-m
c800-y6-mw
c800-oy6-mw
c800-sy6-mw
c800-osy6-mw
c800-osy656i-mw
c800-nsy6-mw
c800-nosy656i-mw
CISCO-BULK-FILE-MIB
CISCO-CALL-HISTORY-MIB
CISCO-CAR-MIB
CISCO-IMAGE-MIB (added)
CISCO-IP-STAT-MIB
CISCO-ISDN-MIB
CISCO-ISDNU-IF-MIB
CISCO-MEMORY-POOL-MIB
CISCO-PING-MIB
CISCO-SNAPSHOT-MIB
CISCO-TCP-MIB
OLD-CISCO-CHASSIS-MIB
OLD-CISCO-CPU-MIB
OLD-CISCO-FLASH-MIB (added)
OLD-CISCO-INTERFACES-MIB
OLD-CISCO-IP-MIB
OLD-CISCO-MEMORY-MIB
OLD-CISCO-SYSTEM-MIB
OLD-CISCO-TCP-MIB
IF-MIB
ISDN-MIB
SNMPv2-MIB
TCP-MIB
UDP-MIB
RFC1213-MIB (MIBII)
RFC1381-MIB (LAPBMIB)
RFC1398-MIB (ETHERMIB)
Release Notes for the Cisco 811 and 813 Routers for Cisco IOS Release 12.1(2)XF
8
78-11070-02, Rev. H0
Important Notes
The following sections contain important notes about Cisco IOS Release 12.1(2)XF5 that can apply to
the Cisco 811 and 813 Routers. (Also, see the “Caveats” section on page 11.)
Caveat CSCdr91706 and IOS HTTP Vulnerability
A defect in multiple releases of Cisco IOS software causes a Cisco router or switch to halt and reload
if the IOS HTTP service is enabled and you browse to http://router-ip/anytext?/ and enter the enable
password when it is requested. This defect can be exploited to produce a denial of service (DoS) attack.
This vulnerability can only be exploited if the enable password is known or not set.
The vulnerability, identified as Cisco bug ID CSCdr91706, affects virtually all mainstream Cisco
routers and switches running Cisco IOS software releases 12.0 through 12.1, inclusive. This is not the
same defect as CSCdr36952.
The vulnerability has been corrected and Cisco is making fixed releases available for free to replace all
affected IOS releases. Cisco urges all customers to upgrade to releases that are not vulnerable to this
defect as listed in the complete advisory,which is available at: http://www.cisco.com/warp/public/707/
ioshttpserverquery-pub.shtml. You are strongly encouraged to read the complete advisory.
System Requirements
B Channel Activation
When a call comes in, a B channel is activated. If the amount of traffic on the B channel exceeds a
threshold, the other B channel is activated. If the amount of traffic falls below the threshold, one of the
B channels is deactivated. The B channel that is initially activated when the call comes in is not
necessarily B1 nor is the B channel that is deactivated when the traffic level lessens necessarily B2.
Cisco 800 Series Router Clock—CSCdp09409
To run IPSec successfully, the Cisco 800 series router clock needs to be set accurately.Cisco 800 series
router clocks are set and maintained using Simple Network Time Protocol (SNTP). For best results, set
up a Network Time Protocol (NTP) server to periodically send time information messages to Cisco 800
series routers. See the SNTP configuration and command reference documentation for configuration
instructions. If you do not have an NTP server, you must reset the Cisco 800 series router clock using
the clock set command each time you restart the router.
The SNTP configuration documentation is available in the chapter “Monitoring the Router and
Network” in the “System Management” volume of the Configuration Fundamentals Configuration
Guide in the Cisco IOS documentation set. The SNTP command reference documentation is available
in the chapter “Router and Network Monitoring Commands” in the “System Management Commands”
volume of the Configuration Fundamentals Command Reference manual in the Cisco IOS
documentation set.
78-11070-02, Rev. H0
Release Notes for the Cisco 811 and 813 Routers for Cisco IOS Release 12.1(2)XF
9
System Requirements
CiscoView Application Support
The CiscoView application supports the Cisco 800 series routers. The CiscoView application provides
dynamic status, statistics, and comprehensive configuration information for Cisco switches, routers,
concentrators, and adapters. It displays a graphical view of Cisco devices. This network management
tool also provides configuring and monitoring functions and offers basic troubleshooting tips.
Dial Peer Limitation
The isdn answer1 and isdn answer2 commands determine which called telephone numbers, for
example, 555-1111 and 555-2222, a Cisco 800 series router can answer. Using these commands limits
a router to using the two dial peers that contain the telephone numbers 555-1111 and 555-2222. (When
not using these commands, a router can use up to six dial peers.) A sample scenario in which the isdn
answer1 and isdn answer2 commands are used is when a Cisco 801 or Cisco 803 router is connected
with other ISDN devices to an ISDN S-bus.
Downloading Images
Before attempting to download new images, you must first delete files in the router Flash memory. Be
sure to use the delete command, not command erase, to free up space. Entering erase removes all files,
including the configuration.
Excessive ISDN Line Activation
The following protocols send updates that can cause an ISDN line to be activated excessively, thereby
increasing your monthly ISDN line cost:
• IP
• User Datagram Protocol (UDP)
• IPX
• Cisco Discovery Protocol (CDP)
• Simple Network Time Protocol (SNTP)
See the Cisco 800 Series Routers Software Configuration Guide to set up extended access lists to
preventIP, UDP,IPX, and SNTP updates from activating the ISDN line. For CDP, make certain that you
enter the no cdp enable command to disable CDP.
Hanging During Boot
If an illegal console configuration is issued to the router, the console fails the POST tests during boot
and causes the router to halt. The only way to recover from this state is to pull apart the soldered boot
Flash and re-burn the Boot ROM. This problem has been resolved in TinyROM version 1.0(3), a
downloadable ROM upgrade available from Cisco.com. Contact Cisco to upgrade to this version or
later, and prevent this problem from occurring.
10
Release Notes for the Cisco 811 and 813 Routers for Cisco IOS Release 12.1(2)XF
78-11070-02, Rev. H0
Phone Mate Answering Machine Model 9200
A Phone Mate answering machine model 9200 failed to recognize the ringing signal sent by AMD R79
ringing SLIC. This was confirmed by testing against Phone Mate model 3750 and newer model 9300.
PPP over Frame Relay Support (RFC-1973)
Cisco 800 series routers do not support PPP protocol over Frame Relay.
TACACS+ with AAA
Cisco 800 series routers now support the Terminal Access Controller Access Control System Plus
(TACACS+) protocol through Telnet. TACACS+ is a Cisco proprietary authentication protocol that
provides remote access authentication and related network security services, such as event logging.
User passwords are administered in a central database, rather than in individual routers. TACACS+ also
supports separate modular authentication, authorization, and accounting (AAA) facilities that are
configured at individual routers.
For information on how to configure TACACS+, refer to the “Configuring TACACS+” chapter in the
Security Configuration Guide. For information on TACACS+ commands, refer to the “TACACS,
Extended TACACS, and TACACS+ Commands” chapter in the Security Command Reference.
Cisco 800 series routers do not support the following protocols:
• TACACS, an older access protocol now deprecated by Cisco, or Extended TACACS, an extension
to the TACACS protocol.
• RADIUS or Kerberos protocols.
System Requirements
ROM Monitor set stop-bits Parameter
This release supports the setting of 1 only, for the ROM monitor set stop-bits parameter.
Caveats
Caveats describe unexpected behavior or defects in Cisco IOS software releases. Severity 1 caveats are
the most serious caveats, severity 2 caveats are less serious, and severity 3 caveats are the least serious
of these three severity levels.
All caveats in Release 12.1(2)T are also in Release 12.1(2)XF5. For information on caveats in Cisco
IOS Release 12.1(2)T,refer to the Caveats for Cisco IOS Release 12.1 T document. For information on
caveats in Cisco IOS Release 12.1, refer to the Caveats for Cisco IOS Release 12.1 document. These
publications list severity 1 and 2 caveats, and are located on Cisco.com and the Documentation
CD-ROM.
Note If you have an account with Cisco.com, you can also use the Bug Toolkit to find select caveats of
any severity. Toreach the Bug Toolkit,log in toCisco.com and click Service & Support: Technical
Assistance Center: Tool Index: Bug Toolkit. Another option is to go to
http://www.cisco.com/cgi-bin/Support/Bugtool/launch_bugtool.pl.
78-11070-02, Rev. H0
Release Notes for the Cisco 811 and 813 Routers for Cisco IOS Release 12.1(2)XF
11
System Requirements
Resolved Caveats - Release 12.1(2)XF5
This section describes unexpected behavior that is fixed in Release 12.1(2)XF5.
Management
CSCdw65903
An error can occur with management protocol processing. Please use the following URL for
further information:
http://www.cisco.com/cgi-bin/bugtool/onebug.pl?bugid=CSCdw65903
Caveats Resolved in Release 12.1(2)XF4
This section describes possibly unexpected behavior by software Release 12.1(2)XF4.
CSCdt11503
An unexpected router reset might occur when OID fields larger than 256 are received.
CSCdt96253
CRC-32 compensation vulnerability.
CSCdt93862
Access level issue while using the Web interface.
CSCdt57231
SSH SSH_MSG_IGNORE messages for terminal echo tests.
Open Caveats—Release 12.1(2)XF3
This section describes possibly unexpected behavior by Release 12.1(2)XF3.
CSCds04747
Connection setup improvements.
CSCds32217
Release Notes for the Cisco 811 and 813 Routers for Cisco IOS Release 12.1(2)XF
12
D-write community string readable with read-only community, Cisco IOS.
78-11070-02, Rev. H0
Resolved Caveats—Release 12.1(2)XF2
This section describes possibly unexpected behavior by software releases prior to Release 12.1(2)XF2
that have been resolved in Release 12.1(2)XF2 and above.
CSCds05811
If secondary IP addresses are configured on either an Ethernet or FastEthernet interface and the
running-config is saved to NVRAM, when the router is reloaded the secondary IP addresses disappear
from the configuration. This caveat is identical to the caveats: CSCdr51651, CSCdr72866,
CSCdr72868, and CSCdr77724, as well as cases A445655, A519050, and A466616. The problem was
originally found in Release 12.1(2)T. This caveat is fixed in Cisco IOS Release 12.1(2)XF2.
Open Caveats—Release 12.1(2)XF1
This section describes possibly unexpected behavior by Release 12.1(2)XF1.
CSCds37736
System Requirements
Cisco 801 through 804 router initialization ignores the CPU type and always loads the micro code for
the MPC850.
Open Caveats—Release 12.1(2)XF
This section describes possibly unexpected behavior by Release 12.1(2)XF.
CSCdr49075
On a Cisco 800 series router, the configurationfor the second POTS port might not take effect if a called
party number for an incoming call on an ISDN line is not provided.
Related Documentation
The following sections describe the documentation available for the Cisco 811 and 813 Routers.
Typically, these documents consist of hardware and software installation guides, Cisco IOS
configuration and command references, system error messages, feature modules, and other documents.
Documentation is available as printed manuals or electronic documents, except for feature modules,
which are available online on Cisco.com and the Documentation CD-ROM.
Use these release notes with the documents listed in the following sections:
• Release-Specific Documents
• Platform-Specific Documents
• Feature Modules
• Cisco IOS Software Documentation Set
78-11070-02, Rev. H0
Release Notes for the Cisco 811 and 813 Routers for Cisco IOS Release 12.1(2)XF
13
System Requirements
Release-Specific Documents
The following documents are specific to Release 12.1. They are located on Cisco.com and the
Documentation CD-ROM:
• Release Notes for Cisco IOS Release 12.1
–
To reach the Cross-Platform Release Notes for Cisco IOS Release 12.1 from Cisco.com, click
on this path (under the heading Service & Support):
Technical Documents: Documentation Home Page: Cisco IOS Software Configuration:
Cisco IOS Release 12.1: Release Notes: Cross-Platform Release Notes
–
To reach the Cross-Platform Release Notes for Cisco IOS Release 12.1 on the Documentation
CD-ROM, click on this path:
Cisco Product Documentation: Cisco IOS Software Configuration: Cisco IOS
Release 12.1: Release Notes: Cross-Platform Release Notes
• Product bulletins, field notices, and other release-specific documents
To reach these documents from Cisco.com, click on this path (under the heading
Service & Support):
Technical Documents: Product Bulletins
• Caveats for Cisco IOS Release 12.1 and 12.1 T
The Caveats for Cisco IOS Release 12.1 and Caveats for Cisco IOS Release 12.1 T documents
contain caveats applicable to all platforms for all maintenance releases of Release 12.1.
–
To reach the caveats document from Cisco.com, click on this path (under the heading
Service & Support):
Technical Documents: Documentation Home Page: Cisco IOS Software Configuration:
Cisco IOS Release 12.1: Caveats
–
To reach the caveats document on the Documentation CD-ROM, click on this path:
Cisco Product Documentation: Cisco IOS Software Configuration: Cisco IOS
Release 12.1: Caveats
Note If you have an account with Cisco.com, you can also use the Bug Toolkit to find
select caveats of any severity. To reach the Bug Toolkit, log in toCisco.com and
click Service & Support: Technical Assistance Center: Tool Index: Bug
Toolkit. Another option is to go to
http://www.cisco.com/cgi-bin/Support/Bugtool/launch_bugtool.pl.
Platform-Specific Documents
These documents are available for the Cisco 811 and 813 Routers on Cisco.com and the
Documentation CD-ROM:
Cisco 811 and 813 Routers
• Cisco 811 and Cisco 813 Routers Hardware Installation Guide
• Quick Start Guide: Setting Up Cisco 811 and Cisco 813 Routers
Release Notes for the Cisco 811 and 813 Routers for Cisco IOS Release 12.1(2)XF
14
78-11070-02, Rev. H0
• Cisco 800 Series Routers Software Configuration Guide
• Release Notes for Cisco 800 Routers
On Cisco.com at:
On the Documentation CD-ROM at:
Feature Modules
Feature modules describe new features supported by Release 12.1 and are updates to the Cisco IOS
documentation set. A feature module consists of a brief overview of the feature, benefits, configuration
tasks, and a command reference. As updates, the feature modules are available online only. Feature
module information is incorporated in the next printing of the Cisco IOS documentation set.
To reach the Release 12.1 feature modules:
• From Cisco.com, click on this path (under the heading Service & Support):
• From the Documentation CD-ROM, click on this path:
System Requirements
–
Technical Documents: Documentation Home Page: Access Servers and Access Routers:
Fixed Configuration Access Routers: Cisco 811 and Cisco 813 Routers
–
Technical Documents: Documentation Home Page: Access Servers and Access Routers:
Fixed Configuration Access Routers: Cisco 801–804 Routers
–
Cisco Product Documentation: Access Servers and Access Routers: Fixed Configuration
Access Routers: Cisco 811 and Cisco 813 Routers
–
Cisco Product Documentation: Access Servers and Access Routers: Fixed Configuration
Access Routers: Cisco 801–804 Routers
Technical Documents: Documentation Home Page: Cisco IOS Software Configuration:
Cisco IOS Release 12.1: New Feature Documentation: New Features in 12.1-Based Limited
Lifetime Releases: New Features in 12.1X Releases: New Features in 12.1(1)X Releases
Cisco Product Documentation: Cisco IOS Software Configuration: Cisco IOS Release 12.1:
New Feature Documentation: New Features in 12.1-Based Limited Lifetime Releases: New
Features in 12.1X Releases: New Features in 12.1(1)X Releases
Feature Navigator
Feature Navigator is a web-based tool that enables you to quickly determine which Cisco IOS software
images support a particular set of features and which features are supported in a particular Cisco IOS
image. Feature Navigator is available 24 hours a day, 7 days a week.
To access Feature Navigator,you must have an account on Cisco.com. If you haveforgottenor lost your
account information, e-mail the Contact Database Administration group at cdbadmin@cisco.com. If
you do not have an account on Cisco.com, go to http://www.cisco.com/registerandfollowthe directions
to set up an account.
78-11070-02, Rev. H0
Release Notes for the Cisco 811 and 813 Routers for Cisco IOS Release 12.1(2)XF
15
System Requirements
To use Feature Navigator, you must have a JavaScript-enabled web browser such as Netscape 3.0 or
later, or Internet Explorer 4.0 or later. Internet Explorer 4.0 always has JavaScript enabled. To enable
JavaScriptfor Netscape 3.x or Netscape 4.x, follow the instructions provided with the web browser.For
JavaScript support and enabling instructions for other browsers, check with the browser vendor.
Feature Navigator is updated when major Cisco IOS software releases and technology releases occur.
You can access Feature Navigator at the following URL:
http://www.cisco.com/go/fn
Cisco IOS Software Documentation Set
The Cisco IOS software documentation set consists of the Cisco IOS configuration guides, Cisco IOS
command references, and several other supporting documents that are shipped with your order in
electronic form on the Documentation CD-ROM—unless you specifically ordered printed versions.
Documentation Modules
Each module in the Cisco IOS documentation set consists of two types of books: a configuration guide
and a corresponding command reference. Chapters in a configuration guide describe protocols,
configuration tasks, Cisco IOS software functionality, and contain comprehensive configuration
examples. Chapters in a command reference provide complete command syntax information. Use each
configurationguide with its corresponding command reference. The Cisco IOS software documentation
set is available on Cisco.com and on the Documentation CD-ROM.
On Cisco.com at:
Technical Documents: Documentation Home Page: Cisco IOS SoftwareConfiguration: Cisco IOS
Release 12.1: Configuration Guides and Command References
On the Documentation CD-ROM at:
Cisco Product Documentation: Cisco IOS Software Configuration: Cisco IOS Release 12.1:
Configuration Guides and Command References
Release 12.1 Documentation Set
Table 6 describes the contents of the Cisco IOS Release 12.1 software documentation set, which is
available in both electronic and printed form.
Note You can find the most current Cisco IOS documentation on Cisco.com and the
Documentation CD-ROM. These electronic documents may contain updates and
modifications made after the hard-copy documents were printed.
On Cisco.com at:
Technical Documents: Documentation Home Page: Cisco IOS SoftwareConfiguration: Cisco IOS
Release 12.1
On the Documentation CD-ROM at:
Cisco Product Documentation: Cisco IOS Software Configuration: Cisco IOS Release 12.1
Release Notes for the Cisco 811 and 813 Routers for Cisco IOS Release 12.1(2)XF
16
78-11070-02, Rev. H0
System Requirements
Table 6 Cisco IOS Software Release
12.1
Documentation Set
Books Chapter Topics
• Cisco IOS ConfigurationFundamentals Configuration
Guide
• Cisco IOS Configuration Fundamentals Command
Reference
Configuration Fundamentals Overview
Using the Command-Line Interface (CLI)
Using Configuration Tools
Configuring Operating Characteristics
Managing Connections, Menus, and System Banners
Using the Cisco Web Browser
Using the Cisco IOS File System
Modifying, Downloading, & Maintaining Configuration Files
Loading and Maintaining System Images
Maintaining Router Memory
Rebooting a Router
Configuring Additional File Transfer Functions
Monitoring the Router and Network
Troubleshooting a Router
Performing Basic System Management
System Management Using System Controllers
Web Scaling Using WCCP
Managing Dial Shelves
• Cisco IOS Apollo Domain, Banyan VINES, DECnet,
ISO CLNS, and XNS Configuration Guide
• Cisco IOS Apollo Domain, Banyan VINES, DECnet,
ISO CLNS, and XNS Command Reference
Overview of Apollo Domain, Banyan VINES, DECNET, ISO
CLNS, and XNS
Configuring Apollo Domain
Configuring Banyan VINES
Configuring DECnet
Configuring IOS CLNS
Configuring XNS
• Cisco IOS AppleTalk and Novell IPX Configuration
Guide
• Cisco AppleTalk and Novell IPX Command Reference
• Cisco IOS Bridging and IBM Networking
Configuration Guide
• Cisco IOS Bridging and IBM Networking Command
Reference, Volume I
• Cisco Bridging and IBM Networking Command
Reference, Volume II
AppleTalk and Novel IPX Overview
Configuring AppleTalk
Configuring Novell IPX
Overview of SNA Internetworking
Overview of Bridging
Configuring Transparent Bridging
Configuring Source-Route Bridging
Configuring Token Ring Inter-Switch Link
Configuring Token Ring Route Switch Module
Overview of IBM Networking
Configuring Remote Source-Route Bridging
Configuring Data-Link Switching Plus+
Configuring Serial Tunnel and Block Serial Tunnel
Configuring LLC2 and SDLC Parameters
Configuring IBM Network Media Translation
Configuring Frame Relay Access Support
Configuring NCIA Server
Configuring the Airline Product Set
Configuring DSPU and SNA Service Point Support
Configuring SNA Switching Services
Configuring Cisco Transaction Connection
Configuring Cisco Mainframe Channel Connection Adapters
78-11070-02, Rev. H0
Release Notes for the Cisco 811 and 813 Routers for Cisco IOS Release 12.1(2)XF
17
System Requirements
Table 6 Cisco IOS Software Release
12.1
Documentation Set (continued)
Books Chapter Topics
(Continued)
• Cisco IOS Bridging and IBM Networking
Configuration Guide
• Cisco IOS Bridging and IBM Networking Command
Configuring CLAW and TCP/IP Offload Support
Configuring CMPC and CSNA
Configuring CMPC+
Configuring the TN3270 Server
Reference, Volume I
• Cisco Bridging and IBM Networking Command
Reference, Volume II
• Cisco IOS Dial Services Configuration Guide:
Terminal Services
• Cisco IOS Dial Services Configuration Guide:
Network Services
• Cisco IOS Dial Services Command Reference
Large-Scale Dial Solutions
Cost-Control Solutions
Virtual Private Networks
X.25 on ISDN Solutions
Telco Solutions
Dial-Related Addressing Services
Internetworking Dial Access Scenarios
Preparing for Dial Access
Modem Configuration and Management
ISDN and Signalling Configuration
PPP Configuration
Dial-on-Demand Routing Configuration
Dial-Backup Configuration
Terminal Service Configuration
• Cisco IOS Interface Configuration Guide
• Cisco IOS Interface Command Guide
Interface Configuration Overview
Configuring LAN Interfaces
Configuring Serial Interfaces
Configuring Logical Interfaces
• Cisco IOS IP and IP Routing Configuration Guide
• Cisco IOS IP and IP Routing Command Reference
IP Overview
Configuring IP Addressing
Configuring DHCP
Configuring IP Services
Configuring Mobile IP
Configuring On-Demand Routing
Configuring RIP
Configuring IGRP
Configuring OSPF
Configuring IP Enhanced IGRP
Configuring Integrated IS-IS
Configuring BGP
Configuring Multicast BGP (MBGP)
Configuring IP Routing Protocol-Independent Features
Configuring IP Multicast Routing
Configuring Multicast Source Discovery Protocol
Configuring PGM Router Assist
Configuring Unidirectional Link Routing
Using IP Multicast Tools
18
Release Notes for the Cisco 811 and 813 Routers for Cisco IOS Release 12.1(2)XF
78-11070-02, Rev. H0
System Requirements
Table 6 Cisco IOS Software Release
12.1
Documentation Set (continued)
Books Chapter Topics
• Cisco IOS Multiservice Applications Configuration
Guide
• Cisco IOS Multiservice Applications Command
Reference
Multiservice Applications Overview
Configuring Voice over IP
Configuring Gatekeepers (Multimedia Conference Manager)
Configuring Voice over Frame Relay
Configuring Voice over ATM
Configuring Voice over HDLC
Configuring Voice-Related Support Features
Configuring PBX Signaling
Configuring Store and Forward Fax
Configuring Video Support
Configuring Head-End Broadband Access Router Features
Configuring Subscriber-End Broadband Access Router
Features
Configuring Synchronized Clocking
• Cisco Quality of Service Solutions Configuration
Guide
• Cisco IOS Quality of Service Solutions Command
Reference
Quality of Service Overview
Classification Overview
Configuring Policy-Based Routing
Configuring QoS Policy Propagation via Border Gateway
Protocol
Configuring Committed Access Rate
Congestion Management Overview
Configured Weighted Fair Queueing
Configuring Custom Queueing
Configuring Priority Queueing
Congestion Avoidance Overview
Configuring Weighted Random Early Detection
Policing and Shaping Overview
Configuring Generic Traffic Shaping
Configuring Frame Relay and Frame Relay Traffic Shaping
Signalling Overview
Configuring RSVP
Configuring Subnetwork Bandwidth Manager
Configuring RSVP-ATM Quality of Service Internetworking
Link Efficiency Mechanisms Overview
Configuring Link Fragmentation and Interleaving for Multilink
PPP
Configuring Compressed Real-Time Protocol
IP to ATM CoS Overview
Configuring IP to ATM CoS
QoS Features for Voice Introduction
78-11070-02, Rev. H0
Release Notes for the Cisco 811 and 813 Routers for Cisco IOS Release 12.1(2)XF
19
System Requirements
Table 6 Cisco IOS Software Release
12.1
Documentation Set (continued)
Books Chapter Topics
• Cisco IOS Security Configuration Guide
• Cisco IOS Security Command Reference
TACACS+ Commands
Access Control Lists: Overview and Guidelines
Cisco Secure Integrated Software Firewall Overview
Configuring Lock-and-Key Security (Dynamic Access Lists)
Configuring IP Session Filtering (Reflexive Access Lists)
ConfiguringTCP Intercept (Prevent Denial-of-Service Attacks)
Configuring Context-Based Access Control
Configuring Cisco Secure Integrated Software Intrusion
Detection System
Configuring Authentication Proxy
Configuring Port to Application Mapping
IP Security and Encryption Overview
Configuring IPSec Network Security
Configuring Certification Authority Interoperability
Configuring Internet Key Exchange Security Protocol
Configuring Passwords and Privileges
Neighbor Router Authentication: Overview and Guidelines
Configuring IP Security Options
• Cisco IOS Switching Services Configuration Guide
• Cisco IOS Switching Services Command Reference
Configuring MPLS
Configuring IP Multilayer Switching
Configuring IP Multicast Multilayer Switching
Configuring IPX Multilayer Switching
Configuring Multicast Distributed Switching
Routing Between VLANs Overview
ConfiguringRouting Between VLANs with ISL Encapsulation
Configuring Routing Between VLANs with IEEE 802.10
Encapsulation
Configuring Routing Between VLANs with IEEE 802.1Q
Encapsulation
LAN Emulation Overview
Configuring LAN Emulation
Configuring Token Ring LANE
MPOA Overview
Configuring the MPOA Client
Configuring the MPOA Server
Configuring Token Ring LANE for MPOA
20
Release Notes for the Cisco 811 and 813 Routers for Cisco IOS Release 12.1(2)XF
78-11070-02, Rev. H0
System Requirements
Table 6 Cisco IOS Software Release
Books Chapter Topics
• Cisco IOS Wide-AreaNetworking Configuration Guide
• Cisco IOS Wide-AreaNetworking Command Reference
• Cisco IOS Configuration Guide Master Index
• Cisco IOS Command Reference Master Index
• Cisco IOS Command Summary
• Cisco IOS Debug Command Reference
• Cisco IOS Dial Services Quick Configuration Guide
• Cisco IOS New Features Index
(Cisco.com and Documentation CD only)
• Cisco IOS System Error Messages
Note Cisco Management Information Base (MIB) User Quick Reference is no longer published.
If you have an account with Cisco.com, you can find latest list of MIBs supported by
Cisco. Toreach the Cisco Network Management Toolkit, press Login at Cisco.com and go
to Software Center: Network Mgmt Products: Cisco Network Management Toolkit.
12.1
Documentation Set (continued)
Wide-Area Networking Overview
Configuring ATM
Frame Relay
Frame Relay-ATM Internetworking
Configuring SMDS
Configuring X.25 and LAPB
Obtaining Documentation
World Wide Web
You can access the most current Cisco documentation on the WorldWideWebat http://www.cisco.com,
http://www-china.cisco.com, or http://www-europe.cisco.com.
Documentation CD-ROM
Cisco documentation and additional literature are available in a CD-ROM package, which ships with
your product. The Documentation CD-ROM is updated monthly.Therefore, it is probably more current
than printed documentation. The CD-ROM package is available as a single unit or as an annual
subscription.
Ordering Documentation
Registered Cisco.com users can order the Documentation CD-ROM and other Cisco Product
documentation through our online Subscription Services at
http://www.cisco.com/cgi-bin/subcat/kaojump.cgi.
78-11070-02, Rev. H0
Release Notes for the Cisco 811 and 813 Routers for Cisco IOS Release 12.1(2)XF
21
System Requirements
Nonregistered Cisco.com users can order documentation through a local account representative by
calling Cisco’s corporate headquarters (California, USA) at 408 526-4000 or, in North America, call
800 553-NETS (6387).
Obtaining Technical Assistance
Cisco provides Cisco.com as a starting point for all technical assistance. Warranty or maintenance
contract customers can use the Technical Assistance Center. All customers can submit technical
feedback on Cisco documentation using the web, e-mail, a self-addressed stamped response card
included in many printed documents, or by sending mail to Cisco.
Cisco.com
Cisco continues to revolutionize how business is done on the Internet. Cisco.com is the foundation of a
suite of interactive, networked services that provides immediate, open access to Cisco information and
resources at anytime, from anywhere in the world. This highly integrated Internet application is a
powerful, easy-to-use tool for doing business with Cisco.
Cisco.com’s broad range of features and services helps customers and partners to streamline business
processes and improve productivity.Through Cisco.com, you will findinformation about Cisco and our
networking solutions, services, and programs. In addition, you can resolve technical issues with online
support services, download and test software packages, and order Cisco learning materials and
merchandise. Valuable online skill assessment, training, and certification programs are also available.
Customers and partners can self-register on Cisco.com to obtain additional personalized information
and services. Registered users may order products, check on the status of an order and view benefits
specific to their relationships with Cisco.
You can access Cisco.com in the following ways:
• WWW: www.cisco.com
• Telnet: cco.cisco.com
• Modem using standard connection rates and the following terminal settings: VT100 emulation;
8 data bits; no parity; and 1 stop bit.
–
From North America, call 408 526-8070
–
From Europe, call 33 1 64 46 40 82
You can e-mail questions about using Cisco.com to cco-team@cisco.com.
Technical Assistance Center
The Cisco Technical Assistance Center (TAC) is available to warranty or maintenance contract
customers who need technical assistance with a Cisco product that is under warranty or covered by a
maintenance contract.
To display the TAC web site that includes links to technical support information and software upgrades
and for requesting TAC support, use www.cisco.com/techsupport.
To contact by e-mail, use one of the following:
Release Notes for the Cisco 811 and 813 Routers for Cisco IOS Release 12.1(2)XF
22
78-11070-02, Rev. H0
System Requirements
Language E-mail Address
English tac@cisco.com
Hanzi (Chinese) chinese-tac@cisco.com
Kanji (Japanese) japan-tac@cisco.com
Hangul (Korean) korea-tac@cisco.com
Spanish tac@cisco.com
Thai thai-tac@cisco.com
In North America, TAC can be reached at 800 553-2447or 408 526-7209. For other telephone numbers
and TAC e-mail addresses worldwide, consult the following web site:
http://www.cisco.com/warp/public/687/Directory/DirTAC.shtml.
Software Configuration Tips on the Cisco Technical Assistance Center
Home Page
If you have a Cisco.com log-in account, you can access the following URL, which contains links and
tips on configuring your Cisco products:
http://www.cisco.com/public/technotes/tech_sw.html
This URL is subject to change without notice. If it changes, point your Web browser to
Cisco.com, press Login, and click on this path: Technical Assistance Center: Technical Tips.
The following sections are provided from the Technical Tips page:
• Access Dial Cookbook—Contains common configurations or recipes for configuring various
access routes and dial technologies.
• Field Notices—Notifies you of any critical issues regarding Cisco products and includes problem
descriptions, safety or security issues, and hardware defects.
• Frequently Asked Questions—Describes the most frequently asked technical questions about Cisco
hardware and software.
• Hardware—Provides technical tips related to specific hardware platforms.
• Hot Tips—Describes popular tips and hints gathered from the Cisco Technical Assistance Center
(TAC). Most of these documents are available from the TAC Fax-on-demand service. To reach
Fax-on-demand and receive documents at your fax machine from the United States, call
888-50-CISCO (888-502-4726). From other areas, call 650-596-4408.
• Internetworking Features—Lists tips on using Cisco IOS software features and services.
• Sample Configurations—Provides actual configuration examples that are complete with topology
and annotations.
Documentation Feedback
If you are reading Cisco product documentation on the World Wide Web, you can submit technical
comments electronically.Click Feedback in the toolbar and select Documentation. After youcomplete
the form, click Submit to send it to Cisco.
78-11070-02, Rev. H0
Release Notes for the Cisco 811 and 813 Routers for Cisco IOS Release 12.1(2)XF
23
System Requirements
You can e-mail your comments to bug-doc@cisco.com.
To submit your comments by mail, for your convenience many documents contain a response card
behind the front cover. Otherwise, you can mail your comments to the following address:
Cisco Systems, Inc.
Document Resource Connection
170 West Tasman Drive
San Jose, CA 95134-9883
We appreciate and value your comments.
This document is to be used in conjunction with the documents listed in the “Related Documentation” section on page 13.
CCIP, the Cisco Powered Network mark, the Cisco Systems Verified logo, Cisco Unity, Fast Step, Follow Me Browsing, FormShare, Internet Quotient, iQ Breakthrough, iQ
Expertise, iQ FastTrack, the iQ Logo, iQ Net Readiness Scorecard, Networking Academy, ScriptShare, SMARTnet, TransPath, and Voice LAN are trademarks of Cisco Systems,
Inc.; Changing the Way We Work, Live, Play, and Learn, Discover All That’s Possible, The Fastest Way to Increase Your Internet Quotient, and iQuick Study are service marks
of Cisco Systems, Inc.; and Aironet, ASIST, BPX, Catalyst, CCDA, CCDP, CCIE, CCNA, CCNP, Cisco, the Cisco Certified Internetwork Expert logo, Cisco IOS, the Cisco IOS
logo, Cisco Press, Cisco Systems, Cisco Systems Capital, the Cisco Systems logo, Empowering the Internet Generation,Enterprise/Solver, EtherChannel, EtherSwitch, GigaStack,
IOS, IP/TV, LightStream, MGX, MICA, the Networkers logo, Network Registrar, Packet, PIX, Post-Routing, Pre-Routing, RateMUX, Registrar, SlideCast, StrataView Plus,
Stratm, SwitchProbe, TeleRouter, and VCO are registered trademarks of Cisco Systems, Inc. and/or its affiliates in the U.S. and certain other countries.
All other trademarks mentioned in this document or Web site are the property of their respective owners. The use of the word partner does not imply a partnership relationship
between Cisco and any other company. (0201R)
Copyright © 2000–2002, Cisco Systems, Inc.
All rights reserved.
Release Notes for the Cisco 811 and 813 Routers for Cisco IOS Release 12.1(2)XF
24
78-11070-02, Rev. H0
Loading...
