HP Z640 Workstation User Manual

QuickSpecs

HP Z640 Workstation

Overview

c04400040 — DA – 15080 Worldwide — Version 6 — April 1, 2015

Page 1

HP Z640 Workstation

1.

Integrated Front Handle

4.

HDD Activity LED

2.

Dedicated 9.5mm Optical Drive Bay

5.

Front I/O: 4 USB 3.0 with Charging Port (topmost port),

QuickSpecs

HP Z640 Workstation

Overview

c04400040 — DA – 15080 Worldwide — Version 6 — April 1, 2015

Page 2

3.

Power Button

1 Microphone, 1 Headset

6.

2 External 5.25” Bays

12.

Intel Xeon Processors: E5-1600 v3 family or E5-2600 v3 family

7.

2 Internal 3.5” Bays

13.

4 DIMM Slots for DDR4 ECC Registered Memory

8.

6 6Gb/s SATA Ports

14.

2nd CPU and Memory Riser Module with 4 DIMM slots

9.

Rear Flip-Up Handle

15.

2 PCIe x16 Gen 3 Slots

10.

925W, 90% Efficient Power Supply

16.

1 PCIe x8 Gen 3, 1 PCIe x1 Gen 2, 1 PCIe x4 Gen 2, 1 PCI Slot

11.

Rear I/O: Rear Power Button, 4 USB 3.0, 2 USB 2.0, PS/2 Ports, 1 RJ-45 to Integrated GbE, 1 Audio Line In, 1 Audio Line Out

Form Factor

Rackable Minitower

Overview

QuickSpecs

HP Z640 Workstation

Overview

c04400040 — DA – 15080 Worldwide — Version 6 — April 1, 2015

Page 3

Operating Systems

Preinstalled:

 Windows 7 Professional 64-bit  Windows 8.1 Pro 64-bit  Windows 8.1 Pro 64 downgrade to Windows 7 Professional 64-bit

Windows 8.1 Emerging Market

 Ubuntu 14.04  HP Installer Kit for Linux (includes drivers for 64-bit OS versions of RHEL 6.6, RHEL 7, SUSE Linux

Enterprise Desktop 11, Ubuntu 14.04)

 Red Hat Enterprise Linux Desktop (Paper license with 1 year support; no preinstalled OS)

Supported:

 Windows 7 Enterprise 64-bit  Windows 8/8.1 Enterprise 64-bit  Red Hat Enterprise Linux Desktop 6, 7  SUSE Linux Enterprise Desktop 11 SP3

Notes: For detailed OS/hardware support information for Linux, see:

http://www.hp.com/support/linux_hardware_matrix

Available Processors

Name

Cores

Clock

Speed

(GHz)

Cache

(MB)

Memory

Speed (MHz)

QPI (GT/s)

Hyper-

Threading

Featuring

Intel® vPro™

Technology

Intel® Turbo

Boost

Technology1

TDP

(W)

Intel® Xeon® E5-1680 v3 processor

8

3.2

20

2133

–

YES

3, 6

140

Intel Xeon E5-1660 v3 processor

8

3.0

20

2133

–

YES

3, 5

140

Intel Xeon E5-1650 v3 processor

6

3.5

15

2133

–

YES

1, 3

140

Intel Xeon E5-1630 v3 processor

4

3.7

10

2133

–

YES

1, 1

140

Intel Xeon E5-1620 v3 processor

4

3.5

10

2133

–

YES

1, 1

140

Intel Xeon E5-1607 v3 processor

4

3.1

10

1866 – NO

YES

N/A

140

Intel Xeon E5-1603 v3 processor

4

2.8

10

1866 – NO

YES

N/A

140

Intel Xeon E5-2699 v3 processor

18

2.3

45

2133

9.6

YES

5, 13

145

Intel Xeon E5-2697 v3 processor

14

2.6

35

2133

9.6

YES

5, 10

145

Intel Xeon E5-2695 v3 processor

14

2.3

35

2133

9.6

YES

5, 10

120

Intel Xeon E5-2683 v3 processor

14

2.0

35

2133

9.6

YES

5, 10

120

Intel Xeon E5-2690 v3 processor

12

2.6

30

2133

9.6

YES

5, 9

135

Intel Xeon E5-2680 v3 processor

12

2.5

30

2133

9.6

YES

4, 8

120

QuickSpecs

HP Z640 Workstation

Overview

c04400040 — DA – 15080 Worldwide — Version 6 — April 1, 2015

Page 4

Intel Xeon E5-2670 v3 processor

12

2.3

30

2133

9.6

YES

3, 8

120

Intel Xeon E5-2660 v3 processor

10

2.6

25

2133

9.6

YES

3, 7

105

Intel Xeon E5-2650 v3 processor

10

2.3

25

2133

9.6

YES

3, 7

105

Intel Xeon E5-2667 v3 processor

8

3.2

20

2133

9.6

YES

2, 4

135

Intel Xeon E5-2640 v3 processor

8

2.6

20

1866

8.0

YES

2, 8

90

Intel Xeon E5-2630 v3 processor

8

2.4

20

1866

8.0

YES

2, 8

85

Intel Xeon E5-2643 v3 processor

6

3.4

20

2133

9.6

YES

2, 3

135

Intel Xeon E5-2620 v3 processor

6

2.4

15

1866

8.0

YES

2, 8

85

Intel Xeon E5-2609 v3 processor

6

1.9

15

1600

6.4

NO

YES

N/A

85

Intel Xeon E5-2603 v3 processor

6

1.6

15

1600

6.4

NO

YES

N/A

85

Intel Xeon E5-2637 v3 processor

4

3.5

15

2133

9.6

YES

1, 2

135

Intel Xeon E5-2623 v3 processor

4

3.0

10

1866

8.0

YES

3, 5

105

1

The specifications shown in this column represent the following: (all core maximum turbo steps, one core maximum turbo steps). Turbo boost stepping occurs in 100MHz increments. Processors that do not have turbo functionality are denoted as N/A.

NOTE: Z640 systems configured with an E5-1600 series processor may not add a 2nd processor. To support two processors, an E5-2600 series processor must be chosen.

Available Processor Disclaimers

When ordering two processors, the second processor must be the same as the first. Intel processor numbers are not a measurement of higher performance. Processor numbers differentiate features within each processor family, not across different processor families. See:

http://www.intel.com/products/processor_number/ for details.

Multi-Core technologies are designed to improve performance of multithreaded software products and hardware-aware multitasking operating systems and may require appropriate operating system software for full benefits; check with software provider to determine suitability; Not all customers or software applications will necessarily benefit from use of these technologies.

64-bit computing on Intel® 64 architecture requires a computer system with a processor, chipset, BIOS, operating system, device drivers, and applications enabled for Intel® 64 architecture. Processor will not operate (including 32-bit operation) without an Intel® 64 architecture-enabled BIOS. Performance will vary depending on your hardware and software configurations. See: http://www.intel.com/info/em64t for more information.

Color

Hematite Brushed Aluminum and HP Black

I/O Expansion Slots(see system board section for more details)

Slot 1 (top): PCI Express Gen2 x1 with open-ended connector* Full-height, Half-length (Not available when 2nd processor/memory module is installed)

QuickSpecs

HP Z640 Workstation

Overview

c04400040 — DA – 15080 Worldwide — Version 6 — April 1, 2015

Page 5

Slot 2:

PCI Express Gen3 x16 Full-height, Full-length (with extender)

Slot 3:

PCI Express Gen2 x4 with open-ended connector* Full-height, Full-length (with extender)

Slot 4:

PCI Express Gen3 x8 with open-ended connector* Full-height, Full-length (with extender)

Slot 5:

PCI Express Gen3 x16 Full-height, Full-length (with extender)

Slot 6:

PCI 32bit/33MHz Full-height, Full-length (with extender)

* Open-ended connector allows a greater bandwidth (e.g., x16) card to be installed physically into a lower bandwidth connector/slot.

Expansion Bays (see Storage section for more details)

2 internal 3.5" bays (with acoustic dampening rail assemblies preinstalled) 2 external 5.25" bays

 3rd and 4th 3.5" HDD each occupy one external bay  3rd and 4th 2.5" HDD/SSD occupy a single external bay within a 2:1 carrier

1 dedicated 9.5mm slim optical disk drive bay

Front I/O

4 USB 3.0, 1 Headset, 1 Microphone

Rear I/O

4 USB 3.0, 2 USB 2.0, 2 PS/2, 1 RJ-45 (NIC), 1 Audio Line-In, 1 Audio Line-Out. Serial supported with optional connector on PCI bracket cabled to system board connector.

Internal USB

2 USB 2.0 ports available with a single 2x5 header. The 2x5 header can be converted to a standard (Type-A) USB connector through the use one HP Internal USB Port Kit (EM165AA). This port kit uses one half of the 2x5 header. The 2x5 header also supports up to one 15-in-1 Media Card Reader. 1 USB 3.0 port available by a 2x10 header.

Chassis Dimensions (H x W x D)

Footprint Dimensions:

H: 17.45” [442.9mm] W: 6.75” [171.45mm] D: 18.3” [464.8mm] (measured to the rear of service panel)

Maximum Dimensions:

H: 17.45” [442.9mm] W: 6.75” [171.45mm] D: 18.65” [473.3mm] (measured to rear PCIe retainer clips)

Rack utilization: 4U

QuickSpecs

HP Z640 Workstation

Overview

c04400040 — DA – 15080 Worldwide — Version 6 — April 1, 2015

Page 6

System Weight

Actual weight depends upon configuration Minimum configuration: 15.0 kg (33.1 lbs.) Typical configuration: 17.0 kg (37.5 lbs.) Maximum configuration: 21.8 kg (48.0 lbs.)

Temperature

Operating:

5° to 35°C (40° to 95° F)

Non-operating

-40° to 60°C (-40° to 140°F)

Humidity

Operating:

8% to 85% relative humidity, non-condensing

Non-operating

8% to 90% relative humidity, non-condensing

Maximum Altitude (nonpressurized)

Operating:

3,048m (10,000ft)

Non-operating

9,144m (30,000ft)

Power Supply

Tool-free 925W 90% Efficient wide-ranging, active Power Factor Correction, with two graphics power cables

The Power Supply Efficiency Report for this product may be found at this link:

http://www.plugloadsolutions.com/psu_reports/HEWLETT%20PACKARD_D12925P1A_925W_ECOS%203892_Report%20(2).pdf

Interfaces Supported

15-in-1 Media Card Reader (optional) 6-channel SATA interfaces (6 @ 6.0 Gb/s). 6 channels are eSATA configurable for use with eSATA CTO/AMO Kit (No hot plug / hot swap supported). USB 2.0, USB 3.0 Factory integrated RAID available for SATA/SAS drives (RAID 0, 0 Data, 1, 5, and 10)

Workstation ISV Certifications

See the latest list of certifications at

http://www.hp.com/united-states/campaigns/workstations/partnerships.html

QuickSpecs

HP Z640 Workstation

Supported Components

c04400040 — DA – 15080 Worldwide — Version 6 — April 1, 2015

Page 7

Processors

Factory

Configured

Option

Kit

Option Kit Part Number

Support

Notes

Intel Xeon E5-1600 v3 Series CPU

Intel Xeon E5-1680 v3 3.2 2133 8C CPU

Y

N

Intel Xeon E5-1660 v3 3.0 2133 8C CPU

Y

N

Intel Xeon E5-1650 v3 3.5 2133 6C CPU

Y

N

Intel Xeon E5-1630 v3 3.7 2133 4C CPU

Y

N

Intel Xeon E5-1620 v3 3.5 2133 4C CPU

Y

N

Intel Xeon E5-1607 v3 3.1 1866 4C CPU

Y

N

Intel Xeon E5-1603 v3 2.8 1866 4C CPU

Y

N

Factory

Configured

Option

Kit

Option Kit Part

Number

Support

Notes

Z640 Intel Xeon E5-2600 v3 Series CPU

Xeon E5-2699 v3 2.3 2133 18C CPU

Y

J9P85AA

Xeon E5-2697 v3 2.6 2133 14C CPU

Y

J9P86AA

Xeon E5-2695 v3 2.3 2133 14C CPU

Y

J9P87AA

Xeon E5-2683 v3 2.0 2133 14C CPU

Y

J9P90AA

Xeon E5-2690 v3 2.6 2133 12C CPU

Y

J9P88AA

Xeon E5-2680 v3 2.5 2133 12C CPU

Y

J9P91AA

Xeon E5-2670 v3 2.3 2133 12C CPU

Y

J9P92AA

Xeon E5-2660 v3 2.6 2133 10C CPU

Y

J9P94AA

Xeon E5-2650 v3 2.3 2133 10C CPU

Y

J9P95AA

Xeon E5-2667 v3 3.2 2133 8C CPU

Y

J9P89AA

Xeon E5-2640 v3 2.6 1866 8C CPU

Y

J9P97AA

Xeon E5-2630 v3 2.4 1866 8C CPU

Y

J9P98AA

Xeon E5-2643 v3 3.4 2133 6C CPU

Y

J9P93AA

Xeon E5-2620 v3 2.4 1866 6C CPU

Y

J9Q00AA

Xeon E5-2609 v3 1.9 1600 6C CPU

Y

J9Q01AA

Xeon E5-2603 v3 1.6 1600 6C CPU

Y

J9Q02AA

Xeon E5-2637 v3 3.5 2133 4C CPU

Y

J9P96AA

Xeon E5-2623 v3 3.0 1866 4C CPU

Y

J9P99AA

Note 1: When ordering two processors, the second processor must be the same as the first. Intel processor numbers are not a measurement of higher performance. Processor numbers differentiate features within each processor family, not across different processor families. See:

http://www.intel.com/products/processor_number/ for details.

Multi-Core technologies are designed to improve performance of multithreaded software products and hardware-aware multitasking operating systems and may require appropriate operating system software for full benefits; check with software provider to determine suitability; Not all customers or software applications will necessarily benefit from use of these technologies. 64-bit computing on Intel® 64 architecture requires a computer system with a processor, chipset, BIOS, operating system, device drivers, and applications enabled for Intel® 64 architecture. Processor will not operate (including 32-bit operation) without an Intel® 64 architecture-enabled BIOS. Performance will vary depending on your hardware and software configurations. See: http://www.intel.com/info/em64t for more information.

QuickSpecs

HP Z640 Workstation

Supported Components

c04400040 — DA – 15080 Worldwide — Version 6 — April 1, 2015

Page 8

Z640 processor AMO kits include:

- 2nd CPU/Memory Module (riser)

- processor

- heatsink

First processor (CPU0) upgrades are not supported by HP.

Monitors / Displays

Factory

Configured

Option

Kit

Option Kit Part

Number

Support

Notes

HP Z Display Z30i 30-inch IPS LED Backlit Monitor

HP Z Display Z27i 27-inch IPS LED Backlit Monitor

HP Z Display Z24i 24-inch IPS LED Backlit Monitor

HP Z Display Z23i 23-inch IPS LED Backlit Monitor

HP Z Display Z22i 21.5-inch IPS LED Backlit Monitor

HP DreamColor Z27x Professional Display

HP DreamColor Z24x Professional Display

QuickSpecs

HP Z640 Workstation

Supported Components

c04400040 — DA – 15080 Worldwide — Version 6 — April 1, 2015

Page 9

Storage/Hard Drives

SAS Hard Drives

Factory

Configured

Option

Kit

Option

Kit Part

Number

Support

Notes

SAS Hard Drives for HP Workstations

600GB SAS 15K rpm 6Gb/s 3.5" HDD

Y

VM647AA

300GB SAS 15K rpm 6Gb/s 3.5" HDD

Y

LU967AA

HP 1.2TB SAS 10K SFF HDD

Y

E2P04AA

HP 600GB SAS 10K SFF HDD

Y

A2Z21AA

HP 300GB SAS 10K SFF HDD

Y

A2Z20AA

600GB SAS 15K SFF HDD

Y

L5B75AA

300GB SAS 15K SFF HDD

Y

L5B74AA

NOTES: Up to (4) 3.5-inch 15K rpm SAS drives: 300, 600 GB; 2.4 TB max Up to (4) 2.5-inch 15K rpm SAS drives: 300, 600 GB; 2.4 TB max Up to (4) 2.5-inch 10K rpm SAS drives: 300, 600 GB, 1.2 TB; 4.8 TB max SAS controller add-in card required 3rd and 4th SFF SAS HDDs will be automatically installed into a single 2:1 5.25" external bay adapter Removable Boot Drive option

SATA Hard Drives

SATA Hard Drives for HP Workstations

500GB SATA 7200 rpm 6Gb/s 3.5" HDD

Y

LQ036AA

1TB SATA 7200 rpm 6Gb/s 3.5" HDD

Y

LQ037AA

2.0TB SATA 7200 rpm 6Gb/s 3.5" HDD

Y

QB576AA

3.0TB SATA 7200 rpm 6Gb/s 3.5" HDD

Y

QF298AA

4TB SATA 7200 rpm 6Gb/s 3.5" HDD

Y

K4T76AA

500GB SATA 7.2K SED SFF HDD

Y

D8N29AA

NOTES:

Up to (4) 3.5-inch 7200 rpm SATA drives: 500 GB, 1.0, 2.0, 3.0, 4.0* TB; 16.0 TB max Up to (1) 2.5-inch SATA Self-Encrypting Drive (SED): 500 GB Opal 1 Removable Boot Drive option

SATA Solid State Drives (SSDs)

HP Solid State Drives (SSDs) for Workstations

HP 128GB SATA 6Gb/s SSD

Y

A3D25AA

HP 256GB SATA 6Gb/s SSD

Y

A3D26AA

HP 512GB SATA 6Gb/s SSD

Y

D8F30AA

HP 1TB SATA 6Gb/s SSD

Y

F3C96AA

Intel Pro 1500 180GB SATA SSD

Y

F5Z70AA

Samsung Enterprise 240GB SATA SSD

Y

F0W94AA

Samsung Enterprise 480GB SATA SSD

Y

F0W95AA

HP 256GB SATA 6Gb/s SED Opal 2 SSD

QuickSpecs

HP Z640 Workstation

Supported Components

c04400040 — DA – 15080 Worldwide — Version 6 — April 1, 2015

Page 10

NOTES:

Up to (4) 2.5-inch 6Gb/s SATA Solid State Drives: 128, 256, 512 GB, 1 TB; 4.0 TB max Up to (1) 2.5-inch 6Gb/s SATA Self-Encrypting Solid State Drive (SED SSD): 256 GB Opal 2 Up to (4) 2.5-inch Intel Pro 1500 6Gb/s SATA Solid State Drive: 180 GB; 720 GB max Up to (4) 2.5-inch Samsung Enterprise 6Gb/s SATA Solid State Drives: 240, 480 GB; 1.9 TB max 3rd and 4th SSDs will be automatically installed into a single 2:1 5.25" external bay adapter

PCIe SSDs

PCIe SSDs for HP Workstations

HP Z Turbo Drive 512GB SSD

Y

G3G89AA

HP Z Turbo Drive 256GB SSD

Y

G3G88AA

NOTES:

Up to (2) PCI Express Solid State Drives: 256, 512 GB; 1.0 TB max PCIe SSDs are not available with SAS controller or SAS HDDs

NOTES

For hard drives, 1 GB = 1 billion bytes; TB = 1 trillion bytes. Actual formatted capacity is less. Up to 12 GB of hard drive (or system disk) is reserved for the system recovery software (XP and XP Pro). Up to 3 GB of system disk is reserved for system recovery software (Vista).

Hard Drive Controllers

Factory

Configured

Option

Kit

Option Kit Part

Number

Support

Notes

Integrated SATA 6.0 Gb/s Controller

Y

N

Six ports

Factory integrated RAID on motherboard for SATA drives

RAID 0 Configuration – Striped Array

Y

N

Note 1

RAID 1 Configuration – Mirrored Array

Y

N Note 1

RAID 10 Configuration - Striped/Mirrored Array

Y

N Note 1

RAID 0 Data Configuration -- Boot/OS Drive + 2 Drive Striped Array

Y

N Note 1

LSI 9217-4i4e 8-port SAS 6Gb/s RAID Card

Y

E0X20AA

LSI 9270-8i SAS 6Gb/s ROC RAID Card and iBBU9 Battery Backup Unit

LSI 9270-8i SAS 6Gb/s ROC RAID Card

Y

E0X21AA

SATA hardware RAID is supported on Linux systems that have support for the Intel RSTe technology. The Linux kernel, with built-in software RAID, provides excellent functionality and performance. It is a good alternative to hardware-based RAID. Please visit

http://www.hp.com/support/linux_hardware_matrix for RAID capabilities with Linux.

All drives must be identical in type and capacity. RAID arrays greater than 2 TB are fully supported. NOTE 1: Requires hard drives with identical speed, capacity, and interface. Specific user-configured hardware SAS RAID configurations are supported on this Linux system. For details, please visit http://www.hp.com/support/linux_hardware_matrix NOTE 2: Specific user-configured hardware SAS RAID configurations are supported on this Linux system. IS: Striping of 2 or more HDDs into a single logical volume

QuickSpecs

HP Z640 Workstation

Supported Components

c04400040 — DA – 15080 Worldwide — Version 6 — April 1, 2015

Page 11

IM: Mirroring of 2 HDDs into a single logical volume IME: Mirroring of 3 or more HDDs into a single logical volume. For details, please visit http://www.hp.com/support/linux_hardware_matrix

Graphics

Factory

Configured

Option Kit

Part

Number

Support Notes

Supported

# of cards

Mixed?

Professional 2D

NVIDIA NVS 310 512MB Graphics

Y

A7U59AA

Note 1, 2

4

-

NVIDIA NVS 315 1GB Graphics

Y

E1U66AA

Note 2

4

-

NVIDIA NVS 510 2GB Graphics

Y

C2J98AA

Note 1

2

-

Graphics Cable Adapters

Factory

Configured

Option Kit

Part

Number

Support Notes

Supported

# of cards

Mixed?

HP DisplayPort To DVI-D Adapter (4-Pack)

Y N 1

-

HP DisplayPort To VGA Adapter 2nd

Y N 1

-

HP DisplayPort To DVI-D Adapter (6-Pack)

Y N 1

-

HP DisplayPort To DVI-D Adapter (2-Pack)

Y N 1

-

HP DisplayPort to Dual Link DVI Adapter

Y

NR078AA

1

-

HP DisplayPort To VGA Adapter

Y

AS615AA

1

-

HP DisplayPort To DVI-D Adapter

Y

FH973AA

1

-

Entry 3D

NVIDIA Quadro K420 1GB Graphics

Y

J3G86AA

2

-

NVIDIA Quadro K620 2GB Graphics

Y

J3G87AA

2

-

Mid-range 3D

NVIDIA Quadro K2200 4GB Graphics

Y

J3G88AA

2

-

AMD FirePro W2100 2GB Graphics

Y

J3G91AA

2 -

AMD FirePro W5100 4GB Graphics

Y

J3G92AA

2

High End 3D

NVIDIA Quadro K4200 4GB Graphics

Y

J3G89AA

2

-

NVIDIA Quadro K5200 8GB Graphics

Y

J3G90AA

2

-

NVIDIA Quadro K6000 12GB Graphics

Y

C2J96AA

1

No

AMD FirePro W7100 8GB Graphics

Y

J3G93AA

2

NOTE 1: If 1st card is NVS 510, 2nd card must be NVS 510 or NVS 310. NOTE 2: 4th NVS 310 or NVS 315 supported as AMO-only

High Performance GPU Computing

Factory

Configured

Option

Kit

Option Kit Part

Number

Support Notes

NVIDIA Tesla K40 Workstation Coprocessor

Y

F4A88AA

Note 1

QuickSpecs

HP Z640 Workstation

Supported Components

c04400040 — DA – 15080 Worldwide — Version 6 — April 1, 2015

Page 12

NOTE 1: Tesla K40 is supported with QK5200, QK620 or QK2200. Not supported with 2 graphics cards. Not supported with OS WIN7 32-bit. Not supported with OS WIN8.0.

Memory

CTO

DDR4-2133 ECC Registered DIMMs

Option Kit Part

Number

Support Notes

4GB DDR4-2133 ECC Registered RAM

J9P81AA

1,2

8GB DDR4-2133 ECC Registered RAM

J9P82AA

1,2

16GB DDR4-2133 ECC Registered RAM

J9P83AA

1,2

32GB DDR4-2133 ECC Load Reduced (LR) RAM

J9P84AA

1,2

NOTES:

For details on the supported memory configurations on the HP Z640 Workstation, please refer to the System Technical Specifications - System Board section of this document. Each processor supports up to 4 channels of DDR4 memory. To realize full performance at least 1 DIMM must be inserted into each channel.

With single-processor configurations, 4 DIMM slots are available. 4 additional DIMM slots are available with the 2nd CPU & Memory Module.

The CPUs determine the speed at which the memory is clocked. If an 1866MT/s capable CPU is used in the system, the maximum speed the memory will run at is 1866MT/s, regardless of the specified speed of the memory.

ONLY registered and load reduced DDR4 DIMMs are supported. DDR3 DIMMs ARE NOT SUPPORTED.

Factory

Configured

Option

Kit

Option

Kit Part

Number

Support

Notes

Integrated Realtek HD ALC221 Audio

Y

N

Factory

Configured

Option

Kit

Option

Kit Part

Number

Support Notes

HP SlimTray Optical Drives

HP 9.5mm Slim SuperMulti DVD Writer

Y

K3R64AA

HP 9.5mm Slim DVD-ROM Drive

Y

K3R63AA

Note 1

HP 9.5mm Slim BDXL Blu-Ray Writer

Y

K3R65AA

Note 2

HP DX115 Removable Drive Enclosure

HP DX115 Removable HDD Frame/Carrier

N

Y

FZ576AA

Note 3

HP DX115 Removable HDD Carrier

N

Y

NB792AA

Note 4

HP 15-in-1 Media Card Reader

Y

G1S79AA

Multimedia and Audio Devices

Optical and Removable Storage

QuickSpecs

HP Z640 Workstation

Supported Components

c04400040 — DA – 15080 Worldwide — Version 6 — April 1, 2015

Page 13

Actual speeds may vary. Does not permit copying of commercially available DVD movies or other copyright protected materials. Intended for creation and storage of your original material and other lawful uses. Double Layer discs can store more data than single layer discs. However, double-layer discs burned with this drive may not be compatible with many existing single-layer DVD drives and players.

With Blu-ray, certain disc, digital connection, compatibility and/or performance issues may arise, and do not constitute defects in the product. Flawless playback on all systems is not guaranteed. In order for some Blu-ray titles to play, they may require a DVI or HDMI digital connection and your display may require HDCP support. HD-DVD movies cannot be played on this workstation.

NOTE 1: Not supported as a 2nd Optical Drive. NOTE 2: Cannot be ordered in combination with another Blu-ray Writer. NOTE 3: Only one DX115 device can be installed into Z640. This device can only be installed into the top

optical (5.25") bay. NOTE 4: Carrier requires a Z640 to have the DX115 frame installed. This part number is for the carrier only.

Controller Cards

Factory

Configured

Option Kit

Option Kit Part

Number

Support Notes

HP IEEE 1394b FireWire® PCIe Card

Y

NK653AA

HP Thunderbolt™ 2 PCIe 1-port I/O Card

Y

F3F43AA

Note 1

NOTE 1: Compatible with NVIDIA Quadro K620, K2200, K4200, and K5200 only.

Factory

Configured

Option Kit

Option Kit Part

Number

Support Notes

Integrated Intel I218LM PCIe GbE Controller

Y

N

Intel Ethernet I210-T1 PCIe NIC

Y

E0X95AA

HP X520 10GbE Dual Port Adapter

Y

C3N52AA

HP 10GbE SFP+ SR Transceiver

Y

C3N53AA

HP 10GbE SFP+ SR Transceiver

Y

C3N53AA

HP 361T PCIe Dual Port Gigabit NIC

N

Y

C3N37AA

Note 1

Intel 7260 802.11 a/b/g/n PCIe WLAN NIC*

Y

F2P07AA

NOTE 1: "Gigabit" Ethernet indicates compliance with IEEE standard 802.3ab for Gigabit Ethernet, and does not connote actual operating speed of 1 Gb/sec. For high speed transmission, connection to a Gigabit Ethernet server and network infrastructure is required.

* Wireless access point and internet service required. Availability of public wireless access points limited.

Factory

Option Kit

Option Kit Part

Support Notes

Networking and Communications

Racking and Physical Security

QuickSpecs

HP Z640 Workstation

Supported Components

c04400040 — DA – 15080 Worldwide — Version 6 — April 1, 2015

Page 14

Configured

Number

HP Solenoid Hood Lock & Hood Sensor

Y

N

HP Business PC Security Lock Kit

N Y PV606AA

HP Z6/8 Adjustable Rail Rack Kit, Flush Mount

N Y B8S55AA

Input Devices

Factory

Configured

Option Kit

Option Kit Part

Number

Support Notes

HP PS/2 Keyboard

Y Y QY774AA

HP USB Keyboard

Y Y QY776AA

HP USB Smart Card Keyboard

Y Y E6D77AA

HP Wireless Keyboard and Mouse

Y Y QY449AA

HP PS/2 Mouse

Y Y QY775AA

HP USB Optical Mouse

Y Y QY777AA

HP USB 1000dpi Laser Mouse

Y Y QY778AA

HP USB Optical 3-Button 2.9M OEM Mouse

Y Y ET424AA

HP SpaceMouse Pro USB 3D Input Device

N Y B4A20AA

HP SpacePilot Pro 3D USB Intelligent Controller

N

Y

WH343AA

Other Hardware

Factory

Configured

Option Kit

Option Kit Part

Number

Support

Notes

HP Internal USB Port Kit

N Y EM165AA

Note 1

HP eSATA PCI Cable Kit

N Y GM110AA

Note 2

HP Serial Port Adapter

Y Y PA716A

HP Optical Bay HDD Mounting Bracket

N Y NQ099AA

HP Power Cord Kit

N Y DM293A

HP Workstation Mouse Pad

Y

N

Japan only

HP ENERGY STAR® Enabled Configuration

Y

N

Note 1: The HP Internal USB Port kit has a single USB 2.0 type A connector. Note 2: No hot plug / hot swap supported

Software

Factory

Configured

Option Kit

Part Number

Support Notes

HP Performance Advisor

Y Y Note 1

HP Remote Graphics Software (RGS) 6.0

Y Y Note 2

MS Office Home & Business 2013

Y N Note 3

Cyberlink Media Suite & PowerDVD

Y

N

Foxit PhantomPDF Express

Y N

NOTE 1: Available as a free download here: http://www.hp.com/go/performanceadvisor NOTE 2: Supported operating systems:

QuickSpecs

HP Z640 Workstation

Supported Components

c04400040 — DA – 15080 Worldwide — Version 6 — April 1, 2015

Page 15

• Windows 7 Professional 32/64

• Windows 8 Professional 32/64

• RHEL v6.5

• SLED 11 SP3

For more information, go to: http://www.hp.com/go/rgs

NOTE 3: Must select as a Configure to Order option.

Operating Systems

Support Notes

Windows 8.1 Pro 64-bit

Windows 8.1 Pro Downgrade to Windows 7 Professional 64-bit

Windows® 7 Professional (MSNA) 64-bit

(National Academic)

HP Linux Installer Kit

Red Hat Enterprise Linux (RHEL) Workstation - Paper License (1yr)

Note 1

Ubuntu 14.04

NOTE 1: This second OS must be ordered with the HP Linux Installer Kit as the first OS.

QuickSpecs

HP Z640 Workstation

System Technical Specifications

c04400040 — DA – 15080 Worldwide — Version 6 — April 1, 2015

Page 16

System Board

System Board Form Factor

Main System Board: 24 x 31 cm

9.6 x 12.2 inches

2nd CPU/Memory Board (optional):

14.9 x 29.2 cm

5.85 x 11.50 inches

Processor Socket

LGA2011R3 1st CPU on system board 2nd CPU on optional 2nd CPU/Memory Module

CPU Bus Speed

QPI: Up to 9.6GT/second, depending on processor

Chipset

Intel C612 Chipset

Super I/O Controller

Nuvoton NPCD379H (SIO-12)

Memory Expansion Slots

4 on system board(CPU0) + 4 on optional 2nd CPU/Memory Module(CPU1)

Memory Type Supported

DDR4, RDIMM (Registered), ECC: 4GB, 8GB and 16GB DDR4, LRDIMM (Load Reduced), ECC: 32GB

Memory Modes

NUMA (Non-Uniform Memory Architecture), Memory Node Interleave

Memory Speed Supported

1600MT/s, 1866MHz and 2133MT/s

QuickSpecs

HP Z640 Workstation

System Technical Specifications

c04400040 — DA – 15080 Worldwide — Version 6 — April 1, 2015

Page 17

Single Processor

CPU 0

Front Slots

Rear Slots

Capacity

Notes

DIMM1

DIMM3

DIMM6

DIMM8

Rating

4 GB

*

4 GB Fair

8 GB

4 GB 8 GB

4 GB

Good

Fair

12 GB

4 GB

4 GB 4 GB

Better

16 GB

4 GB 8 GB

4 GB

4 GB 4 GB

8 GB

Best

Good

24 GB

~

8 GB

4 GB

4 Gb

8 GB

Better

32 GB

8 GB

16 GB

8 GB

8 GB 8 GB 16 GB

Best

Good

48 GB

~

16 GB

8 GB

16 GB

Better

64 GB

~ 16 GB

32 GB

16 GB

16 GB 32 GB

Best

Good

128 GB

32 GB

Best

Slot Load Order

1 3 4 2

Dual Processor

CPU 0

CPU 1

Front Slots

Rear Slots

Front Slots

Rear Slots

Capacity

Notes

DIMM1

DIMM3

DIMM6

DIMM8

DIMM1

DIMM2

DIMM3

DIMM4

Rating

8 GB

4 GB 4 GB Fair

16 GB

4 GB 8 GB

4 GB 4 GB

8 GB

4 GB Good

Fair

32 GB

4 GB 8 GB

16 GB

4 GB

4 GB 8 GB

16 GB

4 GB

4 GB 8 GB

Best

Good

Fair

48 GB

~

8 GB

4 GB

8 GB

4 GB

8 GB

Better

64 GB

8 GB

Best

96 GB

~

16 GB

8 GB

16 GB

8 GB

16 GB

Better

128 GB

16 GB 32 GB

16 GB

16 GB 32 GB

16 GB

16 GB 32 GB

Best

Good

256 GB

32 GB

Best

Slot Load Order

1 5 7 3 2 6 8 4

QuickSpecs

HP Z640 Workstation

System Technical Specifications

c04400040 — DA – 15080 Worldwide — Version 6 — April 1, 2015

Page 18

Memory Loading Order:

Load Order for Single Processor Configuration

Load Order for Dual Processor Configuration

Maximum Memory

Supports up to 256GB with two processors. Please refer to the table above for details on how supported memory configurations are installed in your system.

* For 32 bit operating systems, there is a memory limit of 4GB.

~ Although technically possible, these configurations are not available to order at this time.

Memory Configuration (Supported)

 Not all memory configurations possible are represented above.  Only Registered and LR ECC DIMMs are supported.  Do not install memory modules into memory slots if corresponding processor is not installed.  Dual processor configurations with memory modules installed for only one processor is not

supported.

 RDIMM (Registered) and LRDIMM (Load Reduced) memory cannot be mixed. All memory

installed in the system must be either RDIMM or LRDIMM.

PCI Express Connectors

Slot 1 (top):

PCI Express Gen2 x1 with open-ended connector* Full-height, Half-length (not available when 2nd CPU/Memory Module is installed)

Slot 2:

PCI Express Gen3 x16 Full-height, Full-length (with extender)

Slot 3:

QuickSpecs

HP Z640 Workstation

System Technical Specifications

c04400040 — DA – 15080 Worldwide — Version 6 — April 1, 2015

Page 19

PCI Express Gen2 x4 with open-ended connector* Full-height, Full-length (with extender)

Slot 4:

PCI Express Gen3 x8 with open-ended connector* Full-height, Full-length (with extender)

Slot 5:

PCI Express Gen3 x16 Full-height, Full-length (with extender)

* Open-ended connector allows a greater bandwidth (e.g. x16) card to be installed physically into a lower bandwidth connector/slot

PCI Connectors (5.0V)

Slot 6:

PCI 32bit/33MHz Full-height, Full-length (with extender)

Supported Drive Interfaces

SATA

2 SATA @6Gb/s, supports RAID 0, 1 and NCQ. 4 sSATA @6Gb/s, Supports RAID 0,1,10 and NCQ. Factory integrated RAID is Microsoft Windows only.

Serial Attached SCSI

Requires Optional PCIe card

Integrated RAID

SATA: RAID 0, 1

SSATA: RAID 0, 1, 10

RAID 0 configuration - striped array (supported and configure to order)

RAID 1 configuration - mirrored array (supported and configure to order)

RAID 5 parity striping (supported but not configure to order)

RAID 10 striped and mirrored array.

*HW RAID functionality not supported by Linux. Use SW RAID functionality provided in the Red Hat Operating system instead

Integrated Graphics

No

Network Controller

Integrated Intel I-218 Gbit LAN

Memory Integrated 3KB receive buffer and 3KB transmit buffer

Data rates supported 10/100/1000 Mb/s

Compliance IEEE 802.1as, 802.1p,

802.1Q, 802.3, 802.3ab, 802.3az, 802.3i

802.3u, 802.3x, 802.3z

Bus architecture PCIe 1.0 x1 and SMBus

Power requirement 0.5 watts

Boot ROM support

Network transfer rates:

10BASE-T (half-duplex) 10 Mb/s

10BASE-T (full-duplex) 20 Mb/s

QuickSpecs

HP Z640 Workstation

System Technical Specifications

c04400040 — DA – 15080 Worldwide — Version 6 — April 1, 2015

Page 20

100BASE-TX (half-duplex) 100 Mb/s

1000BASE-T (full-duplex) 2000 Mb/s

100BASE-TX (full-duplex) 200 Mb/s

Management capabilities: WOL, auto MDI crossover, PXE, Multi-port teaming, RSS, Advanced cable diagnostics. AMT 9.1 support, vPro compliant

SATA Connectors

Supported on all SATA and sSATA ports configurable with optional eSATA* After-Market Option cable kit) * hot plug / hot swap not supported with eSATA

IEEE 1394 Connector(s)

Front

None

Rear

2 IEEE 1394b (requires optional PCIe card)

Internal

None

USB Connector(s)

Front

4 - USB 3.0

Rear

4 - USB 3.0 2 - USB 2.0

Internal

One 2x5 header with two USB 2.0 ports. The 2x5 header can be converted to a standard (Type-A) USB connector through the use one HP Internal USB Port Kit (EM165AA). This port kit uses one half of the 2x5 header. One 2x10 header with one USB 3.0 port.

HD Integrated Audio

Realtek ALC221 Flash ROM

Yes

CPU Fan Header

One for each CPU socket

Chassis Fan Header

Rear System Chassis Fan Header Front System Chassis Fan Header

CMOS Battery Holder – Lithium

Yes Power Supply Headers

Yes

Power Switch, Power LED & Hard Drive LED Header

Yes (includes speaker and intrusion sensor signals)

Clear Password Jumper

Yes

Serial Port

One internal header

Parallel Port

No

Keyboard/Mouse

PS/2

QuickSpecs

HP Z640 Workstation

System Technical Specifications

c04400040 — DA – 15080 Worldwide — Version 6 — April 1, 2015

Page 21

Z640 Required Power Supply Info

Power Supply

925W 90% Efficient, Custom PSU

(Wide Ranging, Active PFC)

Operating Voltage Range

90–269 VAC

Rated Voltage Range

100–240 V

118 V

Rated Line Frequency

50–60 Hz

400 Hz

Operating Line Frequency Range

47–66 Hz

393–407 Hz

Rated Input Current

11.3 A @ 100-240 V

11.3 A @ 400 V

Heat Dissipation (Configuration and software dependent)

Typical = 2105 btu/hr (530 kcal/hr)

Maximum = 3629 btu/hr (914 kcal/hr)

Power Supply Fan

92x25 mm variable speed

ENERGY STAR Qualified (Configuration dependent)

Yes

80 PLUS® Compliant

Yes, 90% Efficient

The Z640 925W power supply efficiency report can be found at this link:

http://www.plugloadsolutions.com/psu_reports/HEWLETT%20PACKARD_D

12-925P1A_925W_ECOS%203892_Report%20(2).pdf

FEMP Standby Power Compliant @115V (<2W in S5 - Power Off)

Yes

EuP Compliant @ 230V (<0.5 W in S5 - Power Off)

Yes

CECP Compliant @ 220V (<4W in S3 - Suspend to RAM)

Yes; Configuration dependent

Power Consumption in sleep mode (as defined by ENERGY STAR) - Suspend to RAM (S3) (Instantly Available PC)

<20W

Built-in Self-Test LED

Yes

Surge Tolerant Full Ranging Power Supply (withstands power surges up to 2000V)

Yes

Access Panel Solenoid Lock Header

Yes

Access Panel Intrusion

Yes

Sensor Header

Integrated in Front User Interface (Power Switch, Power LED, HDD LED, Speaker) Cable

Multibay Header

No

Integrated Gigabit Ethernet

Integrated Intel I-218 Gbit LAN

Wake on LAN

Yes

ASF 1.0/2.0 (Alert Standard Format)

No

TPM

Infineon TPM 1.2 Certified

Password Clear Header

Yes

AUX IN (audio)

No

Clear CMOS Button

Yes

Memory Fan Header

CPU0 Memory Fan Header; CPU1 Memory Fan Header

QuickSpecs

HP Z640 Workstation

System Technical Specifications

c04400040 — DA – 15080 Worldwide — Version 6 — April 1, 2015

Page 22

Example Z640 Configuration #1

ENERGY STAR QUALIFIED

Processor

1x Intel Xeon E5-1603 v3 (Quad-core)

Memory

1x 4GB DDR4-2133 (Registered DIMM)

Graphics

1x NVIDIA NVS 310

Disks/Optical

1x 500GB SATA 7200 ; 1x Slim DVD-ROM SATA

Power Supply

925W 90% Custom PSU

Other

N/A

Energy Consumption

115 VAC

230 VAC

100 VAC

LAN Enabled

LAN Disabled

LAN Enabled

LAN Disabled

LAN Enabled

LAN Disabled

Windows Idle (S0)

56.68 W

55.98 W

55.96 W

Windows Busy Typ (S0)

110.76 W

106.57 W

110.89 W

Windows Busy Max (S0)

114.16 W

112.25 W

114.16 W

Sleep (S3)

2.26 W

2.16 W

2.49 W

2.39 W

2.25 W

2.15 W

Off (S5)

0.924 W

0.805 W

1.02 W

0.992 W

0.815 W

0.792 W

Zero Power Mode (ErP)

0.203 W

0.388 W

0.201 W

Heat Dissipation**

115 VAC

230 VAC

100 VAC

LAN Enabled

LAN Disabled

LAN Enabled

LAN Disabled

LAN Enabled

LAN Disabled

Windows Idle (S0)

193.39 btu/hr

191.00 btu/hr

190.94 btu/hr

Windows Busy Typ (S0)

377.91 btu/hr

363.61 btu/hr

378.36 btu/hr

Windows Busy Max (S0)

389.51 btu/hr

383.00 btu/hr

389.51 btu/hr

Sleep (S3)

7.72 btu/hr

7.37 btu/hr

8.51 btu/hr

8.17 btu/hr

7.69 btu/hr

7.33 btu/hr

Off (S5)

3.15 btu/hr

2.75 btu/hr

3.48 btu/hr

3.38 btu/hr

2.78 btu/hr

2.70 btu/hr

Zero Power Mode (ErP)

0.695 btu/hr

1.325 btu/hr

0.668 btu/hr

Example Z640 Configuration #2

Processor

2x Intel Xeon E5-2643 v3 (Dual Six-core)

Memory

8x 8GB DDR4-2133 (Registered DIMM)

Graphics

1x NVIDIA Quadro K5200

Disks/Optical

4x 2TB SATA 7200 ; 1x Slim SuperMulti DVDRW SATA

Power Supply

925W 90% Custom PSU

Other

N/A

Energy Consumption

115 VAC

230 VAC

100 VAC

LAN Enabled

LAN Disabled

LAN Enabled

LAN Disabled

LAN Enabled

LAN Disabled

Windows Idle (S0)

82.62 W

82.36 W

83.10 W

Windows Busy Typ (S0)

399.09 W

397.52 W

399.46 W

Windows Busy Max (S0)

497.57 W

495.56 W

492.48 W

Sleep (S3)

4.718 W

4.612 W

4.864 W

4.759 W

4.699 W

4.581 W

Off (S5)

0.992 W

0.813 W

1.042 W

0.988 W

0.823 W

0.793 W

Zero Power Mode (ErP)

0.204 W

0.384 W

0.202 W

Heat Dissipation**

115 VAC

230 VAC

100 VAC

LAN Enabled

LAN Disabled

LAN Enabled

LAN Disabled

LAN Enabled

LAN Disabled

Windows Idle (S0)

281.90 btu/hr

281.01 btu/hr

283.54 btu/hr

Windows Busy Typ (S0)

1361.70 btu/hr

1356.34 btu/hr

1362.95 btu/hr

Windows Busy Max (S0)

1697.71 btu/hr

1690.85 btu/hr

1680.34 btu/hr

Sleep (S3)

16.09

15.74

16.60

16.24

16.03

15.63

SYSTEM CONFIGURATION

QuickSpecs

HP Z640 Workstation

System Technical Specifications

c04400040 — DA – 15080 Worldwide — Version 6 — April 1, 2015

Page 23

btu/hr

Off (S5)

3.15 btu/hr

2.77 btu/hr

3.56 btu/hr

3.37 btu/hr

2.81 btu/hr

2.71 btu/hr

Zero Power Mode (ErP)

0.694 btu/hr

1.311 btu/hr

0.689 btu/hr

System Configuration (Entry level)

Processor Info

1x Intel Xeon E5-2650 v3 2.30 GHz

Memory Info

2x 8 GB DDR4-2133 MT/s RDIMM

Graphics Info

1x NVIDIA NVS 310

Disks/Optical/Floppy

1x 1 TB SATA 7200 RPM 1x Blu-ray DVD-RW

Declared Noise Emissions (in accordance with ISO 7779 and ISO 9296)

Sound Power (LWAd, bels)

Deskside Sound Pressure

(LpAm, decibels)

Idle

3.3

16

Hard drive Operating (random reads)

3.5

17

DVD-ROM Operating (sequential reads)

4.5

31

System Configuration (High-end)

Processor Info

2x Intel Xeon E5-2697 v3 2.60 GHz

Memory Info

8x 16 GB DDR4-2133 MT/s ACPI RDIMM

Graphics Info

1x NVIDIA Quadro K4200

Disks/Optical/Floppy

2x 600 GB SAS 15K RPM 3.5” HDD 1x Blu-ray DVD-RW

Declared Noise Emissions (in accordance with ISO 7779 and ISO 9296)

Sound Power (LWAd, bels)

Deskside Sound Pressure

(LpAm, decibels)

Idle

4.4

27

Hard drive Operating (random reads)

4.8

29

DVD-ROM Operating (sequential reads)

4.7

31

Environmental Requirements

Temperature

Operating: 5°C to 35°C (40°F to 95°F) Non-operating: -40°C to 60°C (-40°F to 140°F)

Humidity

Operating: 8% to 85% RH, non-condensing Non-operating: 8% to 90% RH, non-condensing

Maximum Altitude

Operating: 3,048 m (10,000 ft) Non-operating: 9,144 m (30,000 ft)

Dynamic (new)

Shock Operating: ½-sine: 40 g, 2-3ms (~62 cm/sec)

DECLARED NOISE EMISSIONS

ENVIRONMENTAL DATA

QuickSpecs

HP Z640 Workstation

System Technical Specifications

c04400040 — DA – 15080 Worldwide — Version 6 — April 1, 2015

Page 24

Non-operating: ½-sine: 160 cm/s, 2-3ms (~105 g) square: 20 g, 422 cm/s

NOTE: Values represent individual shock events and do not indicate repetitive shock events.

Vibration Operating random: 0.5 g (rms), 5-300 Hz, up to 0.0025 g²/Hz Non-operating random: 2.0 g (rms), 5-500 Hz, up to 0.0150 g²/Hz

NOTE: Values do not indicate continuous vibration.

Cooling

Above 1524m (5,000 ft.) altitude, maximum operating temperature is derated by 1°C (1.8°F) per 305m (1,000 ft.) elevation increase

Physical Security and Serviceability

Access Panel

Tool-less Includes system board and memory information

Optical Drive

Tool-less, no carrier or rails required

Hard Drives

Tool-less

Integrated blind-mate drive carriers

Optional 5.25" external bay carriers

Expansion Cards

Tool-less

Processor Socket

1st socket on main system board. 2nd socket on optional 2nd CPU/Memory Module.

Green User Touch Points

Yes, on primary serviceable components

Color-coordinated Cables and Connectors

Yes

Memory

Tool-less

System Board

Tool-less 2nd CPU/Memory Module: Tool-less

Dual Color Power and HD LED on Front of Computer

Yes

Configuration Record SW

Yes

Over-Temp Warning on Screen

Yes, at POST screen on reboot.

Restore CD/DVD Set

Yes, restores the computer to its original factory shipping image - Can be obtained via HP Support.

Dual Function Front Power Switch

Yes, also acts as a reset switch when held for 4 seconds.

QuickSpecs

HP Z640 Workstation

System Technical Specifications

c04400040 — DA – 15080 Worldwide — Version 6 — April 1, 2015

Page 25

Padlock Support

No

Cable Lock Support

Yes, Kensington Cable Lock (optional): Prevents entire system theft only. 3mm x 7mm slot at rear of system

Universal Chassis Clamp Lock Support

No

Solenoid Lock and Hood Sensor

Access Panel Solenoid Lock: Yes (optional). Activated remotely to prevent system entry. Access Panel Intrusion Sensor: Yes (optional).

Rear Port Control Cover

No

Removable Media Write/Boot Control

Yes, user can prevent the workstation from writing to or booting from removable media.

Power-On Password

Yes, prevents an unauthorized person from booting up the computer.

Setup Password

Yes, prevents an unauthorized person from changing the system configuration.

3.3V Aux Power LED on System PCA

Yes

NIC LEDs (integrated) (Green & Amber)

Yes

CPUs and Heatsinks

CPU heatsink removal requires a T-15 Torx or flat blade screwdriver. CPU removal is tool-less.

Power Supply Diagnostic LED

Yes

Front Power Button

Yes

Rear Power Button

Yes

Front Power LED

Yes, white (normal), red (fault)

Front Hard Drive Activity LED

Yes, green

Front ODD Activity LED

Yes

Internal Speaker

Yes

System/Emergency ROM

Recovers corrupted system BIOS

Flash Recovery

Cooling Solutions

Air cooled forced convection

Power Supply Fans

1 - 92mm

QuickSpecs

HP Z640 Workstation

System Technical Specifications

c04400040 — DA – 15080 Worldwide — Version 6 — April 1, 2015

Page 26

CPU Heatsink Fan

1st CPU: 1 - 92mm Optional 2nd CPU: 1 - 92mm

Memory Heatsink Fan

Optional 2nd CPU/Memory Module: rear bank: 1 - 80mm.

HP Vision Diagnostics Offline Edition

HP Vision Diagnostics Offline Edition The diagnostics utility enables you to perform testing and to view critical computer hardware and software configuration information from various sources. This utility enables you to:

 Run diagnostics  View the hardware configuration of the system

Key features and benefits HP Vision Diagnostics simplifies the process of effectively identifying, diagnosing, and isolating the hardware issues. In addition to robust management tools, service tools can be invaluable in quickly resolving system problems. To streamline the service process and resolve problems quickly, it is necessary to have the right information available at the time that a service call is placed. The primary information requirement, which is also the one that provides the greatest Vision into potential system issues, is the configuration of the system. Vision diagnostics helps provide higher system availability. Typical uses of the Vision Diagnostics are:

 Testing and diagnosing apparent hardware failures  Documenting system configurations for upgrade planning, standardization, inventory

tracking, disaster recovery, and maintenance

 Sending configuration information to another location for more in-depth analysis

Entered using F2

Access Panel Key Lock

Yes, prevents removal of the access panel and all internal components including devices installed in the external 5.25" bays.

ACPI-Ready Hardware

Advanced Configuration and Power Management Interface (ACPI).

 Allows the system to wake from a low power mode  Controls system power consumption, making it possible to place individual cards and

peripherals in a low-power or powered-off state without affecting other elements of the system

Trusted Platform Module Chip

Yes, Infineon TPM 1.2 Certified

Integrated Chassis Handles

Yes

Power Supply

Tool-less. Includes integrated handle.

PCI Card Retention

Yes, tool-less Rear (all) Middle (full-height cards)

QuickSpecs

HP Z640 Workstation

System Technical Specifications

c04400040 — DA – 15080 Worldwide — Version 6 — April 1, 2015

Page 27

Front (full-length cards with extender)

Flash ROM

SPI ROM

Diagnostic Power Switch LED on board

Yes

Clear Password Jumper

Yes

Clear CMOS Button

Yes

CMOS Battery Holder

Yes

DIMM Connectors

Yes

BIOS 32-bit Services

Standard BIOS 32-Bit Service Directory Proposal v0.4

PCI 3.0 Support

Full BIOS support for PCI Express through industry standard interfaces

ATAPI

ATAPI Removable Media Device BIOS Specification Version 1.0

BBS

BIOS Boot Specification v1.01

WMI Support

WMI is Microsoft's implementation of Web-Based Enterprise Management (WBEM) for Windows. WMI is fully compliant with the Distributed Management Task Force (DMTF) Common Information Model (CIM) and WBEM specifications.

BIOS Boot Spec 1.01+

Provides more control over how and from what devices the workstation will boot

BIOS Power On

Users can define a specific date and time for the system to power on

ROM Based Computer Setup Utility (F10)

Review and customize system configuration settings controlled by the BIOS

System/Emergency ROM Flash Recovery with Video

Recovers system BIOS in corrupted Flash ROM

Replicated Setup

Saves BIOS settings to diskette or USB flash device in human readable file. Repset.exe utility can then replicate these settings on machines being deployed without entering Computer Configuration Utility (F10 Setup).

SMBIOS

System Management BIOS 2.7 for system management information

Boot Control

Disables the ability to boot from removable media on supported devices

Memory Change Alert

Alerts management console if memory is removed or changed

BIOS

QuickSpecs

HP Z640 Workstation

System Technical Specifications

c04400040 — DA – 15080 Worldwide — Version 6 — April 1, 2015

Page 28

Thermal Alert

Monitors the temperature state within the chassis. Three modes:

 NORMAL - normal temperature ranges.  ALERTED - excessive temperatures are detected. Raises a flag so action can be taken to avoid

shutdown or provide for a smoother system shutdown.

 SHUTDOWN - excessive temperatures are encountered. Automatically shuts down the

computer without warning before hardware component damage occurs.

Remote ROM Flash

Provides secure, fail-safe ROM image management from a central network console

ACPI (Advanced Configuration and Power Management Interface)

Allows the system to enter and resume from low power modes (sleep states). Enables an operating system to control system power consumption based on the dynamic workload. Makes it possible to place individual cards and peripherals in a low-power or powered-off state without affecting other elements of the system. Supports ACPI 4.0 for full compatibility with 64-bit operating systems.

Ownership Tag

A user-defined string stored in non-volatile memory that is displayed in the BIOS splash screen

Remote Wakeup/Remote Shutdown

System administrators can power on, restart, and power off a client computer from a remote location

Instantly Available PC (Suspend to RAM - ACPI sleep state S3)

Allows for very low power consumption with quick resume time

Remote System Installation via F12 (PXE

2.1) (Remote Boot from Server)

Allows a new or existing system to boot over the network and download software, including the operating system

ROM revision levels

Reports the system BIOS revision level in Computer Configuration Utility (F10 Setup). Version is available through an industry standard interface (SMBIOS) so that management SW applications can use and report this information.

System board revision level

Allows management SW to read revision level of the system board Revision level is digitally encoded into the HW and cannot be modified

Start-up Diagnostics (Power-on Self-Test)

Assesses system health at boot time with selectable levels of testing

Auto Setup when new hardware installed

System automatically detects the addition of new hardware

Keyboard-less Operation

The system can be booted without a keyboard

Localized ROM Setup

Common BIOS image supports System Configuration Utility (F10 Setup) menus in 12 languages with local keyboard mappings

Asset Tag

Allows the user or MIS to set a unique tag string in non-volatile memory

QuickSpecs

HP Z640 Workstation

System Technical Specifications

c04400040 — DA – 15080 Worldwide — Version 6 — April 1, 2015

Page 29

Per-slot Control

Allows I/O slot parameters (option ROM enable/disable, bus latency) to be configured individually

Adaptive Cooling

Fan control parameters are set according to detected hardware configuration for optimal acoustics

Pre-boot Diagnostics

Early (pre-video) critical errors are reported via beeps and blinks on the power LED

Industry Standard Specification Support

UEFI Specification Revision

2.3.1

Industry Standard

Revision Supported by the BIOS

ACPI

Advanced Configuration and Power Management Interface, Version 4.0

ATA (IDE)

AT Attachment 6 with Packet Interface (ATA/ATAPI-6), Revision 3b

CD Boot

"El Torito" Bootable CD-ROM Format Specification Version 1.0

EDD

 Enhanced Disk Drive Specification Version 1.1  BIOS Enhanced Disk Drive Specification Version 3.0

EHCI

Enhanced Host Controller Interface for Universal Serial Bus, Revision 1.0

PCI

 PCI Local Bus Specification, Revision 2.3  PCI Power Management Specification, Revision 1.1  PCI Firmware Specification, Revision 3.0, Draft 0.7

PCI Express

PCI Express Base Specification, Revision 2.0 PCI Express Base Specification, Revision 3.0

PMM

POST Memory Manager Specification, Version 1.01

SATA

 Serial ATA Specification, Revision 1.0a  Serial ATA 3 Gb/s: Serial ATA Specification, Revision 2.5  Serial ATA 6 Gb/s: Serial ATA Specification, Revision 3.0

SPD

PC SDRAM Serial Presence Detect (SPD) Specification, Revision 1.2B

TPM

Trusted Computing Group TPM Specification Version 1.2

UHCI

Universal Host Controller Interface Design Guide, Revision 1.1

USB

Universal Serial Bus Revision 1.1 Specification

QuickSpecs

HP Z640 Workstation

System Technical Specifications

c04400040 — DA – 15080 Worldwide — Version 6 — April 1, 2015

Page 30

Universal Serial Bus Revision 2.0 Specification

Universal Serial Bus Revision 3.0 Specification

SMBIOS

System Management BIOS Reference Specification, Version 2.7

External BIOS Simulator found at: http://h20464.www2.hp.com/index.html

Eco-Label Certifications & Declarations

This product has received or is in the process of being certified to the following approvals and may be labeled with one or more of these marks:

 ENERGY STAR® (energy-saving features available on selected configurations-Windows only)  US Federal Energy Management Program (FEMP)  China Energy Conservation Program  The ECO Declaration (TED)

Batteries

The battery in this product complies with EU Directive 2006/66/EC Battery size: CR2032 (coin cell) Battery type: Lithium Metal

The battery in this product does not contain:

 Mercury greater than 5ppm by weight  Cadmium greater than 10ppm by weight  Lead greater than 40ppm by weight

Restricted Material Usage

This product meets the material restrictions specified in HP's General Specification for the Environment. http://www.hp.com/hpinfo/globalcitizenship/environment/pdf/gse.pdf Hewlett-Packard is committed to compliance with all applicable environmental laws and regulations, including the European Union Restriction of Hazardous Substances (RoHS) Directive. HP's goal is to exceed compliance obligations by meeting the requirements of the RoHS Directive on a worldwide basis.

Low Halogen Statement

This product is low-halogen except for power cords, external cables and peripherals. The following customer-configurable internal components may not be low-halogen: 3 ½" SAS HDDs, LSI 9270-8i SAS ROC RAID Card, and LSI 9217-4i4e SAS ROC RAID Card. Service parts obtained after purchase may not be low-halogen.

End-of-Life Management and Recycling

Hewlett-Packard offers end-of-life HP product return and recycling programs in many geographic areas. To recycle your product, please go to: http://www.hp.com/recycle or contact your nearest HP sales office. Products returned to HP will be recycled, recovered or disposed of in a responsible manner. This product is greater than 90% recyclable by weight when properly disposed of at end of life.

Hewlett-Packard Corporate Environmental Information

For more information about HP's commitment to the environment:

Global Citizenship Report: http://www.hp.com/hpinfo/globalcitizenship/gcreport/index.html

Eco-label certifications:

http://www.hp.com/hpinfo/globalcitizenship/environment/productdesign/ecolabels.html

Social and Environmental Responsibility

QuickSpecs

HP Z640 Workstation

System Technical Specifications

c04400040 — DA – 15080 Worldwide — Version 6 — April 1, 2015

Page 31

ISO 14001 certificates:

http://www.hp.com/hpinfo/globalcitizenship/environment/operations/envmanagement.html

Additional Information

 This HP product is designed to comply with the Waste Electrical and Electronic Equipment

(WEEE) Directive – 2002/96/EC.

 http://www.hp.com/hpinfo/globalcitizenship/environment/productdata/disassemblyworksta

tio.html

 Plastics parts weighing over 25 grams used in the product are marked per ISO 11469 and

ISO1043.

 EPEAT Gold - ENERGY STAR qualified configurations of this product are in compliance with the

IEEE 1680 (EPEAT) standard at the Gold level where HP registers workstation products. See

http://ww2.epeat.net/CompanyDetail.aspx?CompanyID=24 for registration status in your

country.

Packaging

HP Workstation product packaging meets the HP General Specification for the Environment at

http://www.hp.com/hpinfo/globalcitizenship/society/gen_specifications.html

 Does not contain restricted substances listed in HP Standard 011-1 General Specification for

the Environment

 Does not contain ozone-depleting substances (ODS)  Does not contain heavy metals (lead, mercury, cadmium or hexavalent chromium) in excess of

100 ppm sum total for all heavy metals listed

 Maximizes the use of post-consumer recycled content materials in packaging materials  All packaging material is recyclable  All packaging material is designed for ease of disassembly  Reduced size and weight of packages to improve transportation fuel efficiency  Plastic packaging materials are marked according to ISO 11469 and DIN 6120 standards

formatting

Packaging Materials

Internal

Cushions and plastic bags made of low density polyethylene (LDPE).

External

Outer carton, accessories carton, and insert made of corrugated paper board.

Manageability

Industry Standard Specifications

This product meets the following industry standard specifications for manageability functionality:

 DASH 1.1 required functionalities via Intel LAN on motherboard

Intel Active Management Technology (AMT)

Intel® Active Management Technology (AMT) 9.1

An advanced set of remote management features and functionality providing IT administrators the latest and most effective tools to remotely discover, heal, and protect networked client systems regardless of the system's health or power state. AMT 9.1 includes the following advanced management functions:

 Power Management (on, off, reset, graceful shutdown, sleep and hibernate)  Support in Max Power Savings (Shutdown and Hibernate Modes)  Hardware Inventory (includes BIOS and firmware revisions)

QuickSpecs

HP Z640 Workstation

System Technical Specifications

c04400040 — DA – 15080 Worldwide — Version 6 — April 1, 2015

Page 32

 Hardware Alerting  Agent Presence  System Defense Filters  Serial Over LAN (SOL)  IDE Redirect  ME Wake-on-LAN (WOL)  DASH 1.1 compliance  IPv6 Support  Fast Call for Help - a client inside or outside the firewall may initiate a call for help via BIOS

screen, periodic connections, or alert triggered connection

 Remote Scheduled Maintenance - pre-schedule when the system connects to the IT or service

provider console for maintenance.

 Remote Alerts - automatically alert IT or service provider if issues arise  Access Monitor - Provides oversight into Intel® AMT actions to support security requirements  PC Alarm Clock  Microsoft NAP Support  Host Base set-up and configuration  Management Engine (ME) firmware roll back  Local Time Sync to UTC  Remote Memory Dump Command – Creates memory dump for debug

Intel® vPro™ Technology

The HP Z640 Workstation supports Intel® vPro™ technology when configured as outlined below:

 Intel® Xeon® processor E5-1600 v3 product family or E5-2600 v3 product family featuring

Intel® vPro™ Technology

 Intel® C612 chipset  Intel® I218LM GbE LAN

Remote Manageability Software Solutions

The HP Z640 Workstation is supported on the following remote manageability software consoles:

 LANDesk Management Suite (HP recommended solution)  Microsoft System Center Configuration Manager  HP Client Automation Enterprise

For questions or support for manageability needs, please visit http://www.hp.com/go/easydeploy

System Software Manager

For questions or support for SSM, please visit: http://www.hp.com/go/ssm

Service, Support, and Warranty

On-site Warranty and Service (Note 1): Three-years, limited warranty and service offering delivers onsite, next business-day (Note 2) service for parts and labor and includes free telephone support (Note

3) 8am - 5pm. Global coverage (Note 2) ensures that any product purchased in one country and

transferred to another, non-restricted country will remain fully covered under the original warranty and service offering.

NOTE 1: Terms and conditions may vary by country. Certain restrictions and exclusions apply.

NOTE 2: On-site service may be provided pursuant to a service contract between HP and an authorized

HP third-party provider, and is not available in certain countries. Global service response times are based on commercially reasonable best effort and may vary by country.

NOTE 3: Technical telephone support applies only to HP-configured, HP and HP-qualified, third-party hardware and software. Toll-free calling and 24x7 support service may not be available in some

QuickSpecs

HP Z640 Workstation

System Technical Specifications

c04400040 — DA – 15080 Worldwide — Version 6 — April 1, 2015

Page 33

countries.

HP Care Pack Services extend service contracts beyond the standard warranties. Service starts from date of hardware purchase. To choose the right level of service for your HP product, use the HP Care Pack Services Lookup Tool at http://www.hp.com/go/lookuptool. Additional HP Care Pack Services information by product is available at http://www.hp.com/hps/carepack. Service levels and response times for HP Care Packs may vary depending on your geographic location.

Product Change Notification

 Program to proactively communicate Product Change Notifications (PCNs) and Customer

Advisories by email to customers, based on a user-defined profile.

 PCNs provide advance notification of hardware and software changes to be implemented in

the factory providing time to plan for transition.

 Customer Advisories provide concise, effective problem resolution, greatly reducing the need

to call technical support.

QuickSpecs

HP Z640 Workstation

Stable & Consistent Offerings

c04400040 — DA – 15080 Worldwide — Version 6 — April 1, 2015

Page 34

As part of its commitment to hardware, software, and solution innovation, HP is proud to introduce this breakthrough platform configuration stability to HP Workstation customers. HP Stable & Consistent Offerings are built on the foundation of a carefully chosen set of components designed and tested to work with HP Z Workstation platforms through their end of life. These components and their corresponding HP Workstation platform compatibility are outlined in this section.

HP Stable & Consistent Offerings are available worldwide to all HP Workstation customers—no special programs, no additional cost—no kidding. Simply select your hardware and software components when you customize your HP Workstation and be assured that you’ll be able to buy that same configuration throughout the lifecycle of the product.

Processors

Product #

Offering

J6F20AV

Intel Xeon E5-1620 v3 3.5GHz 4-core 10MB 2133

J6F31AV

Intel Xeon E5-2643 v3 3.4GHz 6-core 20MB 2133 1st

J6F49AV

Intel Xeon E5-2643 v3 3.4GHz 6-core 20MB 2133 2nd

J6F38AV

Intel Xeon E5-2620 v3 2.4GHz 6-core 15MB 1866 1st

J6F56AV

Intel Xeon E5-2620 v3 2.4GHz 6-core 15MB 1866 2nd

J6F36AV

Intel Xeon E5-2630 v3 2.4GHz 8-core 20MB 1866 1st

J6F54AV

Intel Xeon E5-2630 v3 2.4GHz 8-core 20MB 1866 2nd

Hard Drives

Product #

Offering

J3J74AV

500GB 7200 RPM SATA 1st Hard Disk Drive

J3J95AV

500GB 7200 RPM SATA 2nd Hard Disk Drive

J3K16AV

500GB 7200 RPM SATA 3rd Hard Disk Drive

J3K36AV

500GB 7200 RPM SATA 4th Hard Disk Drive

J3J75AV

1TB 7200 RPM SATA 1st Hard Disk Drive

J3J96AV

1TB 7200 RPM SATA 2nd Hard Disk Drive

J3K17AV

1TB 7200 RPM SATA 3rd Hard Disk Drive

J3K37AV

1TB 7200 RPM SATA 4th Hard Disk Drive

Graphics

Product #

Offering

J1P91AV

NVIDIA NVS 510 2GB 1st Graphics

J1Q03AV

NVIDIA NVS 510 2GB 2nd Graphics

J1P93AV

NVIDIA Quadro K620 2GB 1st Graphics

J1Q05AV

NVIDIA Quadro K620 2GB 2nd Graphics

J1P94AV

NVIDIA Quadro K2200 4GB 1st Graphics

J1Q06AV

NVIDIA Quadro K2200 4GB 2nd Graphics

J1P98AV

AMD FirePro W2100 2GB 1st Graphics

J1Q09AV

AMD FirePro W2100 2GB 2nd Graphics

Memory

Product #

Offering

G8X26AV

8GB DDR4-2133 (1x8GB) Registered RAM 1CPU

G8X30AV

16GB DDR4-2133 (2x8GB) Registered RAM 1CPU

G8X37AV

16GB DDR4-2133 (2x8GB) Registered RAM 2CPU

G8X31AV

32GB DDR4-2133 (4x8GB) Registered RAM 1CPU

G8X38AV

32GB DDR4-2133 (4x8GB) Registered RAM 2CPU

QuickSpecs

HP Z640 Workstation

Stable & Consistent Offerings

c04400040 — DA – 15080 Worldwide — Version 6 — April 1, 2015

Page 35

G8X41AV

64GB DDR4-2133 (8x8GB) Registered RAM 2CPU

G8X32AV

32GB DDR4-2133 (2x16GB) Registered RAM 1CPU

G8X40AV

32GB DDR4-2133 (2x16GB) Registered RAM 2CPU

G8X33AV

64GB DDR4-2133 (4x16GB) Registered RAM 1CPU

G8X42AV

128GB DDR4-2133 (8x16GB) Registered RAM 2CPU

Optical and Removable Storage

Product #

Offering

F2D70AV

Slim SuperMulti DVDRW SATA 1st Optical Disk Drive

G8U64AV

Slim SuperMulti DVDRW SATA 2nd Optical Disk Drive

QuickSpecs

HP Z640 Workstation

Technical Specifications - Hard Drives

c04400040 — DA – 15080 Worldwide — Version 6 — April 1, 2015

Page 36

SAS Hard Drives for HP Workstations

600GB SAS 15K rpm 6Gb/s

3.5" HDD

Capacity

600GB

Height

1 in; 2.54 cm

Width Media Diameter

3.5 in; 8.9 cm

Physical Size

4 in; 10.17 cm

Interface

SAS

Synchronous Transfer Rate (Maximum)

6.0 Gb/s

Buffer

16 MB

Buffer

16 MB

Seek Time (typical reads, includes controller overhead, including settling)

Single Track

0.2 ms

Average

3.4 ms

Full Stroke

6.6 ms

Rotational Speed

15,000 rpm

Logical Blocks

1,172,123,568 - 512 byte blocks

Operating Temperature

50° to 95° F (10° to 35° C)

300GB SAS 15K rpm 6Gb/s

3.5" HDD

Capacity

300GB

Height

1 in; 2.54 cm

Width Media Diameter

3.5 in; 8.9 cm

Physical Size

4 in; 10.17 cm

Interface

SAS

Synchronous Transfer Rate (Maximum)

6Gb/s

Buffer

16MB

Seek Time (typical reads, includes

controller overhead, including settling)

Single Track

0.2 ms (max)

Average

3.4 ms

Full Stroke

6.6 ms

Rotational Speed

15,000 rpm

Logical Blocks

585,937,500

Operating Temperature

50° to 95° F (10° to 35° C)

600GB SAS 15K SFF HDD

Capacity

600GB

Height

5.9 in; 15 cm

Width

Media Diameter

3.5 in; 8.9 cm

Interface

12Gb/s SAS

Synchronous Transfer Rate (Maximum)

Up to 1200 MB/s (SAS single port)

Buffer

128MB

Seek Time (typical reads, includes controller overhead, including settling)

Average

2.0ms Rotational Speed

15K rpm

Operating Temperature

41° to 131° F (5° to 55° C)

STORAGE/HARD DRIVES

QuickSpecs

HP Z640 Workstation

Technical Specifications - Hard Drives

c04400040 — DA – 15080 Worldwide — Version 6 — April 1, 2015

Page 37

600GB SAS 15K SFF HDD

Capacity

600GB

Height

5.9 in; 15 cm

Width

Media Diameter

3.5 in; 8.9 cm

Interface

12Gb/s SAS

Synchronous Transfer Rate (Maximum)

Up to 1200 MB/s (SAS single port)

Buffer

128MB

Seek Time (typical reads, includes controller overhead, including settling)

Average

2.0ms Rotational Speed

15K rpm

Operating Temperature

41° to 131° F (5° to 55° C)

300GB SAS 10K rpm 6Gb/s

3.5" HDD

Capacity

300GB

Height

0.6 in; 1.53 cm

Width Media Diameter

2.5 in; 6.36 cm

Physical Size

2.75 in; 6.99 cm

Interface

SAS

Synchronous Transfer Rate (Maximum)

Up to 600 MB/s

Buffer

64MB

Cache

multi-segmentable cache buffer

Seek Time (typical reads, includes controller overhead, including settling)

Single Track

0.4 ms (max)

Average

3.6 ms

Full Stroke

7.3 ms

Rotational Speed

10,000 rpm

Logical Blocks

585,937,500

Operating Temperature

41° to 131° F (5° to 55° C)

HP 600GB SAS 10K SFF HDD

Capacity

600GB

Height

0.6 in; 1.53 cm

Width Media Diameter

2.5 in; 6.36 cm

Physical Size

2.75 in; 6.99 cm

Interface

SAS 6Gb/s

Synchronous Transfer Rate (Maximum)

Up to 600MB/s Buffer

64MB

Cache

multi-segmentable cache buffer

Seek Time (typical reads, includes controller overhead, including settling)

Single Track

0.4 ms (max)

Average

3.6 ms

Full Stroke

7.3 ms

Rotational Speed

10,000 rpm

Logical Blocks

1,172,123,568

Operating Temperature

41° to 131° F (5° to 55° C)

HP 1.2TB SAS 10K SFF HDD Capacity

1.2TB

Height

0.6 in; 1.53 cm

QuickSpecs

HP Z640 Workstation

Technical Specifications - Hard Drives

c04400040 — DA – 15080 Worldwide — Version 6 — April 1, 2015

Page 38

Width

Media Diameter

2.5 in; 6.36 cm

Physical Size

2.75 in; 6.99 cm

Interface

SAS 6Gb/s

Synchronous Transfer Rate (Maximum)

Up to 600MB/s

Buffer

64MB

Cache

multi-segmentable cache buffer

Seek Time (typical reads, includes controller overhead, including settling)

Single Track

0.18ms (max)

Average

3.5ms

Full Stroke

7.17ms

Rotational Speed

10,000 rpm

Logical Blocks

2,344,225,968

Operating Temperature

41° to 131° F (5° to 55° C)

SATA Hard Drives for HP Workstations

500GB SATA 7200 rpm 6Gb/s

3.5" HDD

Capacity

500GB

Height

1 in; 2.54 cm

Width Media Diameter

3.5 in; 8.9 cm

Physical Size

4 in; 10.17 cm

Interface

Serial ATA (6.0Gb/s), NCQ enabled

Synchronous Transfer Rate (Maximum)

Up to 600MB/s

Buffer

16MB

Seek Time (typical reads, includes controller overhead, including settling)

Single Track

2 ms

Average

11 ms

Full Stroke

21 ms

Rotational Speed

7,200 rpm

Logical Blocks

976,773,168

Operating Temperature

41° to 131° F (5° to 55° C)

1TB SATA 7200 rpm 6Gb/s

3.5" HDD

Capacity

1 Terabyte (1000 GB)

Height

1 in; 2.54 cm

Width Media Diameter

3.5 in; 8.9 cm

Physical Size

4 in; 10.17 cm

Interface

Serial ATA (6.0Gb/s), NCQ enabled

Synchronous Transfer Rate (Maximum)

Up to 600 MB/s

Interface

Serial ATA (6.0Gb/s), NCQ enabled

Synchronous Transfer Rate (Maximum)

Up to 600 MB/s

Buffer

64MB

Seek Time (typical reads, includes controller overhead, including settling)

Single Track

2 ms

Average

11 ms

Full Stroke

21 ms

QuickSpecs

HP Z640 Workstation

Technical Specifications - Hard Drives

c04400040 — DA – 15080 Worldwide — Version 6 — April 1, 2015

Page 39

Rotational Speed

7,200 rpm

Logical Blocks

1,953,525,168

Operating Temperature

41° to 131° F (5° to 55° C)

2.0TB SATA 7200 rpm 6Gb/s

3.5" HDD

Capacity

2TB

Height

1 in; 2.54 cm

Width Media Diameter

3.5 in; 8.9 cm

Physical Size

4 in; 10.17 cm

Interface

Serial ATA (6.0 Gb/s), NCQ Enabled

Synchronous Transfer Rate (Maximum)

Up to 600MB/s

Buffer

64MB

Seek Time (typical reads, includes controller overhead, including settling)

Single Track

1.0 ms

Average

11 ms

Full Stroke

18 ms

Rotational Speed

7,200 rpm

Logical Blocks

3,907,029,168

Operating Temperature

41° to 131° F (5° to 55° C)

3.0TB SATA 7200 rpm 6Gb/s

3.5" HDD

Capacity

3.0TB

Height

1 in; 2.54 cm

Width Media Diameter

3.5 in; 8.9 cm

Physical Size

4.0 in; 10.17 cm

Interface

Serial ATA (6.0Gb/s), NCQ enabled

Synchronous Transfer Rate (Maximum)

Up to 6.0 Gb/s

Buffer

64MB

Seek Time (typical reads, includes controller overhead, including settling)

Single Track

0.6 ms

Average

11 ms

Full Stroke

Not specified

Rotational Speed

7200 rpm

Operating Temperature

41° to 140° F (5° to 60° C)

4TB SATA 7200 rpm 6Gb/s

3.5" HDD

Capacity

4TB

Height

1 in; 2.54 cm

Width Media Diameter

3.5 in; 8.9 cm

Physical Size

4 in; 10.17 cm

Interface

Serial ATA (6Gb/s), NCQ enabled

Synchronous Transfer Rate (Maximum)

Up to 600MB/s

Buffer

128MB

Seek Time (typical reads, includes controller overhead, including settling)

Single Track

0.7ms

Average

8.5ms

Full Stroke

15.7ms

Rotational Speed

7,200 rpm

Operating Temperature

5° to 60° F (-15° to 15.56° C)

500GB SATA 7.2K SED SFF

Capacity

500GB

QuickSpecs

HP Z640 Workstation

Technical Specifications - Hard Drives

c04400040 — DA – 15080 Worldwide — Version 6 — April 1, 2015

Page 40

HDD

Height

0.275 in; 0.7 cm

Width Media Diameter

2.5 in; 6.36 cm

Physical Size

2.75 in; 6.99 cm

Interface

Serial ATA (6Gb/s)

Synchronous Transfer Rate (Maximum)

Up to 600MB/s

Buffer

32MB

Seek Time (typical reads, includes controller overhead, including settling)

Single Track

1ms

Average

4.2ms

Full Stroke

25ms (typical)

Rotational Speed

7,200 rpm

Operating Temperature

32° to 140° F (0° to 60° C)

SATA SSDs for HP Workstations

HP 128GB SATA 6Gb/s SSD

Capacity

128GB

Height

0.28 in; 0.7 cm

Width

Physical Size

2.5 in; 6.36 cm

Interface

SATA 6Gb/s

Synchronous Transfer Rate (Maximum)

Up to 500MB/s (Sequential Read)

Operating Temperature

32° to 158° F (0° to 70° C)

HP 256GB SATA 6Gb/s SSD

Capacity

256GB

Height

0.28 in; 0.7 cm

Interface

6Gb/s SATA

Synchronous Transfer Rate (Maximum)

Up to 500MB/s (Sequential Read)

Operating Temperature

32° to 158° F (0° to 70° C)

HP 512GB SATA 6Gb/s SSD

Capacity

512GB

Height

0.28 in; 0.7 cm

Width

Physical Size

2.5 in; 6.36 cm

Interface

SATA 6Gb/s

Synchronous Transfer Rate (Maximum)

Up to 500MB/s (Sequential Read)

Operating Temperature

32° to 158° F (0° to 70° C)

HP 1TB SATA 6Gb/s SSD

Capacity

1TB

Height

0.28 in; 0.7 cm

Width

Physical Size

2.5 in; 6.36 cm

Interface

SATA 6Gb/s

Synchronous Transfer Rate (Maximum)

Up to 550MB/s (Sequential Read)

Operating Temperature

32° to 158° F (0° to 70° C)

Samsung Enterprise 240GB SATA SSD

Capacity

240GB

Width

Physical Size

2.5 in; 6.36 cm

Interface

SATA 6Gb/s

Synchronous Transfer Rate (Maximum)

600 Mb/s

Samsung Enterprise 480GB SATA SSD

Capacity

480GB

Width

Physical Size

2.5 in; 6.36 cm

QuickSpecs

HP Z640 Workstation

Technical Specifications - Hard Drives

c04400040 — DA – 15080 Worldwide — Version 6 — April 1, 2015

Page 41

Interface

SATA 6Gb/s

Synchronous Transfer Rate (Maximum)

600 Mb/s

Intel Pro 1500 180GB SATA SSD

Capacity

180GB

Width

Physical Size

3.5 in; 8.9 cm

Interface

6Gb/s SATA

Synchronous Transfer Rate (Maximum)

600 Mb/s

Operating Temperature

32° to 158° F (0° to 70° C)

PCIe SSDs for HP Workstations

HP Z Turbo Drive 256GB SSD

Capacity

256GB

Interface

PCI Express 2.0 x4 electrical x4 physical

Operating Temperature

32° to 158° F (0° to 70° C)

HP Z Turbo Drive 512GB SSD

Capacity

512GB

Interface

PCI Express 2.0 x4 electrical x4 physical

Operating Temperature

32° to 158° F (0° to 70° C)

QuickSpecs

HP Z640 Workstation

Technical Specifications - Hard Drive Controllers

c04400040 — DA – 15080 Worldwide — Version 6 — April 1, 2015

Page 42

LSI 9217-4i4e 8-port SAS 6Gb/s RAID Card

PCI Bus

8 lanes, PCI Express 3.0

RAID Levels

Offers Integrated RAID (0, 1, 1E and 10)

PCI Data Burst Transfer Rate

Half Duplex x8, PCIe, 8000 MB/s

SAS Bandwidth

Half Duplex

600 MB/s per lane

PCI Card Type

3.3V Add-in Card

PCI Voltage

12 V ± 10%

PCI Power

9.8W typical, Airflow min 200 LFM

Bracket

Full height and low profile

Certification Level

PCI Express 3.0 compliant

SAS Processor

LSI SAS2308/ Fusion MPT 2.0

Internal Connectors

One x4 internal mini-SAS (SFF8087)

External Connectors

One x4 external mini-SAS (SFF8088)

Maximum Number of SCSI Devices

256 Non-RAID SAS/SATA devices

LED Indicators

N/A

LSI 9270-8i SAS 6Gb/s ROC RAID Card and iBBU9 Battery Backup Unit

PCI Bus

x8 lane PCIe 3.0 compliant

RAID Levels

RAID 0, 1, 5, and 6 RAID spans 10, 50 and 60

PCI Card Type

Low profile, single PCIe slot design with full height bracket.

PCI Voltage

+3.3V Add-in Card

PCI Power

+3.3V, +12V

Certification Level

PCI-Express 3.0

IO Bus

Eight 6Gb/s and 3Gb/s compatible SAS/SATA ports

SAS Processor

LSISAS2208 Dual-Core RAID on Chip (ROC)

Internal Connectors

Two SAS SFF8087 x4 (Mini-SAS)

External Connectors

None

Maximum Number of SCSI Devices

Up to 128 SAS and/or SATA hard drives and SSDs

NOTE: HP Workstations do not support this many internal drives.

LED Indicators

Heartbeat LED on card

HARD DRIVE CONTROLLERS

QuickSpecs

HP Z640 Workstation

Technical Specifications - Graphics

c04400040 — DA – 15080 Worldwide — Version 6 — April 1, 2015

Page 43

NVIDIA NVS 310 512MB Graphics

Form Factor

Low Profile:

2.713 inches in height × 6.150 inches in length Weight: ~142 grams

Graphics Controller

NVIDIA NVS 310 GPU: GF119-825

Bus Type

PCI Express x16, 2.0 compliant

Memory

Size: 512MB DDR3 Clock: 875Mhz Memory Bandwidth: 14GB/s

Connectors

2 x DisplayPort

Maximum Resolution

Up to 2560 x 1600 (digital display) per display.

Image Quality Features

The following video formats are supported:

- MPEG2

- MPEG4 Part 2 Advanced Simple Profile

- H.264 SVC codec support

- Support for 3D Blu Ray

- VC1

- DivX version 3.11 and later

- MVC

A full range of video resolutions are supported including 1080p, 1080i, 720p, 480p and 480i. The NVS 310 GPU provides hardware acceleration for the computationally intensive parts of video processing, as well as provides improved video playback speeds via faster decode and transcode.

Display Output

Up to 2 displays in the following configurations:

DisplayPort output:

 Drives two DisplayPort enabled digital display at resolutions up to

2560 × 1600 at 60 Hz with reduced blanking, when connected natively using the 2 DisplayPort connectors on the NVS 310 graphics card

 Supports 2 monitors up to resolution of 1920 × 1200 at 60 Hz with

reduced blanking using DisplayPort 1.2 multi stream topology technology.

DVI-D output:

 Drives two digital display at resolutions up to 1920 × 1200 at 60

Hz with reduced blanking using DisplayPort to DVI-D single-link cable adaptors

 Drives two digital display at resolutions up to 2560× 1600 at 60 Hz

with reduced blanking using DisplayPort to DVI-D dual-link cable adaptors

HDMI output:

 NVS 310 is capable of driving two high definition (HD) panels up to

resolutions of 1920 × 1080P at 60 Hz using DisplayPort to HDMI cable adaptors

VGA display output:

 Drives two analog display at resolutions up to 1920 × 1200 at 60

GRAPHICS

QuickSpecs

HP Z640 Workstation

Technical Specifications - Graphics

c04400040 — DA – 15080 Worldwide — Version 6 — April 1, 2015

Page 44

Hz using DisplayPort to VGA cable adaptor

Shading Architecture

Shader Model 5.0

Supported Graphics APIs

DX11, OpenGL 4.1

Available Graphics Drivers

Windows 8 Genuine Windows 7 Professional (64-bit and 32-bit) Microsoft Windows XP Professional (64-bit and 32-bit) Red Hat Enterprise Linux(RHEL) SUSE Linux Enterprise Desktop 11 (64-bit and 32-bit)

HP qualified drivers may be preloaded or the latest HP qualified drivers are available from the HP support Web site:

http://welcome.hp.com/country/us/en/support.html

SUSE Linux Enterprise drivers may also be obtained from:

ftp://download.nvidia.com/novell or http://www.nvidia.com

Note

1. The thermal solution used on this card is an active fan heatsink.

2. Factory configured NVS 310 graphics card have no cable adpaters included. Adapters must be ordered separately.

3. Option kit NVS 310 includes 2 DP to DVI-D cable adapters.

NVIDIA NVS 315 1GB Graphics (for HP Workstations)

Form Factor

Low Profile:

2.713 inches in height × 5.7 inches in length Weight: ~142 grams

Graphics Controller

NVIDIA NVS 315 (using GF119-825 GPU) Number of Cores: 48 CUDA cores Max. Power: 19.3W Cooling Solution: Active fan heatsink

Bus Type

PCI Express x16, 2.0 compliant

Memory

Size: 1GB DDR3 Clock: 875Mhz Memory Bandwidth: 14GB/s

Connectors

DMS-59 output Cables included:

- For CTO: DMS-59 to DVI cable

- For AMO: DMS-59 to DVI cable and DMS-59 to VGA cable

Maximum Resolution

Maximum number of displays supported: 2

Maximum Resolution Support:

- DMS-59 to VGA: 2048 x 1536 @ 85Hz

- DMS-59 to DVI: 1980 x 1200 @ 60Hz

- DMS-59 to DP: 2560 x 1600 @ 60Hz

Image Quality Features

See Display Output section.

The following video formats are supported:

- MPEG2

- MPEG4 Part 2 Advanced Simple Profile

- H.264 SVC codec support

- Support for 3D Blu Ray

- VC1

- DivX version 3.11 or later

A full range of video resolutions are supported including 1080p, 1080i,

QuickSpecs

HP Z640 Workstation

Technical Specifications - Graphics

c04400040 — DA – 15080 Worldwide — Version 6 — April 1, 2015

Page 45

720p, 480p and 480i. The NVS 315 GPU provides hardware acceleration for the computationally intensive parts of video processing, as well as provides improved video playback speeds via faster decode and transcode.

Display Output

Up to 2 displays using one of the following DMS-59 cables: DMS-59 to DVI DMS-59 to VGA DMS-59 to DP

DisplayPort output:

- Drives two DisplayPort enabled digital displays at resolutions up to 2560 × 1600 at 60 Hz with reduced blanking, when connected via the DMS-59 to DP adapter.

DVI-D output:

- Drives two digital displays at resolutions up to 1920 × 1200 at 60 Hz with reduced blanking using DMS-59 to DVI-D single-link cable adaptor

VGA display output:

- Drives two analog displays at resolutions up to 2048 × 1536 at 85 Hz using DMS-59 to VGA cable adaptor.

Shading Architecture

Shader Model 5.0

Supported Graphics APIs

DX11, OpenGL 4.3

Available Graphics Drivers

Windows 8 Microsoft Windows 7 Professional (64-bit and 32-bit) Microsoft Windows XP Professional (64-bit and 32-bit) Red Hat Enterprise Linux(RHEL) SUSE Linux Enterprise Desktop 11 (64-bit and 32-bit)

HP qualified drivers may be preloaded or the latest HP qualified drivers are available from the HP support Web site:

http://welcome.hp.com/country/us/en/support.html

SUSE Linux Enterprise drivers may also be obtained from:

ftp://download.nvidia.com/novell or http://www.nvidia.com

Notes

1. The thermal solution used on this card is an active fan heatsink.

2. Factory configured graphics card includes DMS-59 to DVI cable.

3. Option kit graphics card includes DMS-59 to DVI and DMS-59 to VGA cables (one each).

NVIDIA NVS 510 2GB Graphics

Form Factor

Low Profile, 2.713 inches × 6.3 inches, single slot

Graphics Controller

NVS 510 GPU Core Clock: 797 MHz Memory Clock: 891 MHz CUDA Cores: 192

Bus Type

PCI Express x16, Generation 2.0

Memory

2GB DDR3

Connectors

Four mini-DisplayPort. Four mini-DisplayPort to DisplayPort adapters included. (DisplayPort to DVI-D, DisplayPort to VGA, DisplayPort to HDMI, and DisplayPort to Dual-Link DVI adapters available as separate accessories)

Maximum Resolution

Mini-DisplayPort connectors support ultra-high-resolution panels (up to

QuickSpecs

HP Z640 Workstation

Technical Specifications - Graphics

c04400040 — DA – 15080 Worldwide — Version 6 — April 1, 2015

Page 46

3840 x 2160 @ 60Hz)

NOTE: This card supports up to four displays. For Windows XP, only 2 active displays are supported.

Image Quality Features

10-bit internal display processing, including hardware support for 10-bit scan-out

Display Output

DisplayPort with Multi-Stream Technology (MST) and High Bit Rate 2 (HBR2) support.

Digital Display Support

1. DisplayPort Output

- Drives four DisplayPort enabled digital display at resolutions up to 3840 × 2160 at 60 Hz with reduced blanking, when connected natively using the 4 DisplayPort connectors on the NVS 510 graphics card.

- DisplayPort Multi-Stream Topology (MST) Technology: Supports various combinations of display resolutions and number of displays when using DisplayPort multi stream topology technology - up to a maximum of 4 monitors at a resolution of 1920 × 1200 at 60 Hz with reduced blanking.

2. DVI-D Output

- Drives four digital displays at resolutions up to 1920 × 1200 at 60 Hz with reduced blanking using DisplayPort to DVI-D single-link cable adaptors.

- Drives four digital displays at resolutions up to 2560× 1600 at 60 Hz with reduced blanking using DisplayPort to DVI-D dual-link cable adaptors.

3. HDMI Output

- The NVS 510 graphics board is capable of driving four high definition (HD) panels up to resolutions of 1920 × 1080P at 60 Hz using DisplayPort to HDMI cable adaptors.

Analog Display Support

1. VGA display output

- Drives four analog displays at resolutions up to 1920 × 1200 at 60 Hz using DisplayPort to VGA cable adaptors.

Supported Graphics APIs

Full Microsoft DirectX 11, Shader Model 5.0 support Full OpenGL 4.3 support

Available Graphics Drivers

Genuine Windows 7 Professional (64-bit and 32-bit) Microsoft Windows XP Professional (64-bit and 32-bit) Red Hat Enterprise Linux(RHEL) 6 Desktop/Workstation SUSE Linux Enterprise Desktop 11 (64-bit and 32-bit)

HP qualified drivers may be preloaded or available from the HP support Web site:

http://welcome.hp.com/country/us/en/support.html

Power Consumption

33.4 Watts

Note

Heatsink cooler design is active.

Graphics Cable Adapters

Note

Graphics Cable Adapter option choice is available starting Feb 1 2013 for the following graphics cards: NVS 310, Quadro 410, Quadro K5000, FirePro V3900, FirePro W7000

QuickSpecs

HP Z640 Workstation

Technical Specifications - Graphics

c04400040 — DA – 15080 Worldwide — Version 6 — April 1, 2015

Page 47

New Graphics Cards introduced after Feb 1 2013 will be eligible for choosing Graphics Cable Adapters, unless otherwise specified.

No cable choice for NVS 300, NVS 510.

Maximum number of cables allowed is 8.

NVIDIA Quadro K420 1GB Graphics

Form Factor

Low Profile:

2.713 inches × 6.3 inches, single slot

Graphics Controller

NVIDIA Quadro K420 GPU: GK107

Bus Type

PCI Express x16, 2.0 compliant

Memory

Size: 1GB DDR3 Clock: 891MHz Memory Bandwidth: 29GB/s

Connectors

One dual-link DVI-I connector

One DisplayPort connector

Maximum Resolution

VGA (via adapter cable):

 2048 × 1536 × 32 bpp at 85 Hz

Dual-link DVI

 2560 × 1600 × 32 bpp at 60 Hz (reduced blanking)

Single-link DVI

 1920 × 1200 × 32 bpp at 60 Hz (reduced blanking)

DisplayPort 1.2

 3840 × 2160 × 30 bpp at 60 Hz

RAMDAC

400 MHz integrated RAMDAC

Display Output

Maximum number of displays supported: 2

Shading Architecture

Shader Model 5.0

Supported Graphics APIs

DX11, OpenGL 4.4

Programming support for CUDA C, CUDA C++, DirectCompute 5.0, OpenCL, Python, and Fortran

Available Graphics Drivers

Microsoft Windows 8.1 Microsoft Windows 8 Microsoft Windows 7

Linux

Notes

1. Factory configured Quadro K420 does not include any video adapters. Adapters must be ordered separately.

2. Option kit Quadro K420 includes one DP to DVI-D adapter.

NVIDIA Quadro K620 2GB Graphics

Form Factor

2.713” H x 6.3” L

Single Slot, Low Profile Full Height Profile bracket installed Low Profile bracket included

QuickSpecs

HP Z640 Workstation

Technical Specifications - Graphics

c04400040 — DA – 15080 Worldwide — Version 6 — April 1, 2015

Page 48

Weight: 133 grams

Graphics Controller

NVIDIA Quadro K620 Graphics Card GM107 GPU 384 CUDA cores Max Power: 45 Watts

Bus Type

PCI Express 2.0 x16

Memory

2 GB GDDR3, 900 MHz 128-bit memory I/O path 29 GB/s memory bandwidth

Connectors

1 DL-DVI(I) output, 1 DisplayPort output Factory Configured: No video cable adapter included Option Kit: One DP-to-DVI adapter included with card

Additional DVI-to-VGA, DisplayPort-to-VGA or DisplayPort-to-DVI adapters are available as Factory Configuration or Option Kit accessories

Maximum Resolution

DisplayPort 1.2:

- up to 4096x2160 x 30 bpp @ 60Hz

- supports High Bit Rate 2 (HBR2) and Multi-Stream Transport (MST)

Dual Link DVI(I) output:

- up to 2560 x 1600 x 32 bpp @ 60Hz

Single Link-DVI(I) output:

- up to 1920 x 1200 x 32 bpp @ 60Hz

Image Quality Features

10-bit internal display processing pipeline 10-bit scan-out support

Display Output

1 Dual-link DVI-I connector

1 Display Port connector

Shading Architecture

Full Microsoft DirectX 11.1 Shader Model 5.0

Supported Graphics APIs

OpenGL 4.4 DirectX 11.1 API support includes:

CUDA C, CUDA C++, DirectCompute 5.0, OpenCL, Java, Python, and Fortran

Available Graphics Drivers

Microsoft Windows 8.1 Microsoft Windows 8 Microsoft Windows 7 Linux

HP qualified drivers may be preloaded or available from the HP support Web site:

http://welcome.hp.com/country/us/en/support.html

SUSE Linux Enterprise drivers may also be obtained from:

ftp://download.nvidia.com/novell or http://www.nvidia.com

Notes

1. Factory configured Quadro K620 does not include a video cable

adapter. Video cable adapters must be ordered separately.

2. Quadro K620 offered as an Option Kit (AMO) includes one DP-to-

DVI video cable adapter. Additional cables must be ordered

QuickSpecs

HP Z640 Workstation

Technical Specifications - Graphics

c04400040 — DA – 15080 Worldwide — Version 6 — April 1, 2015

Page 49

separately.

NVIDIA Quadro K2200 4GB Graphics

Form Factor

4.38” H x 7.97” L Single Slot, Full Height Weight: 240 grams

Graphics Controller

NVIDIA Quadro K2200 Graphics Card GM107 GPU 640 CUDA cores Max Power: 67.7 Watts

Bus Type

PCI Express 2.0 x16

Memory

4 GB GDDR5, 2500 MHz 128-bit memory I/O path 80 GB/s memory bandwidth

Connectors

1 DL-DVI(I) output, 2 DisplayPort outputs Factory Configured Option: No video cable adapter included Option Kit: One DP-to-DVI adapter included with card

Additional DVI-to-VGA, DisplayPort-to-VGA or DisplayPort-to-DVI adapters are available as accessories

Maximum Resolution

DisplayPort:

- up to 4096 x 2160 x 30 bpp @ 60Hz

- supports High Bit Rate 2 (HBR2) and Multi-Stream Transport (MST)

DL-DVI(I) output:

- up to 2560 x 1600 x 32 bpp @ 60Hz

Display Output

VGA:

 Requires use of DVI-to-VGA and/or DP-to-VGA video cable

adapters

 400 MHz integrated RAMDAC  Max resolution: 2048 x 1536 x 32 bpp @ 85 Hz

DL-DVI(I):

 Max resolution: 2560 x 1600 x 32 bpp @ 60 Hz

SL-DVI(I):

 Max resolution: 1920 x 1200 x 32 bpp @ 60 Hz

DisplayPort:

 Supports HBR2 and MST  Max resolution: 4096 x 2160 x 30 bpp @ 60 Hz (only one monitor

can be connected to a Quadro K2200 DisplayPort connector at this resolution)

 Max number of DisplayPort daisy-chained monitors or hub

connected monitors from a single Quadro K2200 DisplayPort connector: 4 with maximum resolution of 1920 x 1200

Maximum number of monitors across all available Quadro K2200 outputs is

4.

Shading Architecture

Full Microsoft DirectX 11.1 Shader Model 5.0

Supported Graphics APIs

OpenGL 4.4 DirectX 11.1 API support includes:

QuickSpecs

HP Z640 Workstation

Technical Specifications - Graphics

c04400040 — DA – 15080 Worldwide — Version 6 — April 1, 2015

Page 50

CUDA C, CUDA C++, DirectCompute 5.0, OpenCL, Java, Python, and Fortran

Available Graphics Drivers

Microsoft Windows 8.1 Microsoft Windows 8 Microsoft Windows 7 Linux

HP qualified drivers may be preloaded or available from the HP support Web site: http://welcome.hp.com/country/us/en/support.html

Note

1. Quadro K2200 offered as Factory Configured Option does not

include a video cable adapter. Video cable adapters must be ordered separately.

2. Quadro K2200 offered as an Option Kit includes one DP-to-DVI

video cable adapter. Additional cables must be ordered separately.

3. A total maximum of 4 active monitors are supported across all

display output types. This may be accomplished by using daisy chained DisplayPort 1.2 displays or a DisplayPort 1.2 hub device.

4. A DisplayPort hub device may be used to connect multiple

DisplayPort monitors to a single Quadro K2200 DisplayPort output.

AMD FirePro W2100 2GB Graphics

Form Factor

Low Profile, half length (full-height bracket included)

Graphics Controller

AMD FirePro™ W2100 professional graphics

Power: <50W Cooling: Active

Bus Type

PCI Express® x8, Generation 3.0

Memory

2GB DDR3 memory Memory Bandwidth: 14.4 GB/s

Connectors

2x Display Port 1.2 connectors

Factory Configured: No video cable adapter included Option Kit: One DP-to-DVI adapter included with card

Additional DisplayPort-to-VGA or DisplayPort-to-DVI adapters are available as Factory Configuration or Option Kit accessories.

Maximum Resolution

DisplayPort 1.2:

- up to 4096x2160 x 30 bpp @ 60Hz

Dual Link DVI(I) (requires adapter cable):

- up to 2560 x 1600 x 32 bpp @ 60Hz

Single Link-DVI(I)(requires adapter):

- up to 1920 x 1200 x 32 bpp @ 60Hz

VGA(requires adapter):

- up to 1920 x 1200 x 32 bpp @ 60Hz

Display Output

2 x DisplayPort® 1.2

Shading Architecture

Shader Model 5.0

Supported Graphics APIs

OpenCL™ 1.2, DirectX® 11 and OpenGL 4.4

Available Graphics

Windows 8.1 (64-bit and 32-bit)

QuickSpecs

HP Z640 Workstation

Technical Specifications - Graphics

c04400040 — DA – 15080 Worldwide — Version 6 — April 1, 2015

Page 51

Drivers

Windows 7 (64-bit and 32-bit) Red Hat Enterprise Linux (RHEL) SUSE Linux Enterprise Desktop 11(64-bit and 32-bit) Ubuntu

HP qualified drivers may be preloaded or available from the HP support Web site:

http://welcome.hp.com/country/us/en/support.html

NOTE: Depending on the card model, native DisplayPort™ connectors

and/or certified DisplayPort™ active or passive adapters to convert your monitor’s native input to your card’s DisplayPort™ or Mini-DisplayPort™

connector(s) may be required. See www.amd.com/firepro for details.

AMD FirePro W5100 4GB Graphics

Form Factor

Full height, single slot (6.75” X 4.376”)

Graphics Controller

AMD FirePro W5100 graphics GPU Frequency: 930Mhz GPU: 768 Stream Processors organized into 12 Compute Units Power: <75 Watts Cooling: Active Bus Type

PCI Express® x16, Generation 3.0

Memory

4GB GDDR5 memory Memory Bandwidth: up to 96 GB/s Memory Width: 128 bit

Connectors

4x Display Port 1.2 connectors with HBR2 and MST support.

Factory Configured: No video cable adapter included After market option kit: No video cable adapter included

Additional DisplayPort-to-VGA or DisplayPort-to-DVI adapters are available as Factory Configuration or Option Kit accessories.

Maximum Resolution

DisplayPort:

- 4096x2160 @24bpp 60Hz

Dual Link DVI:

- 2560x1600 (requires DP to DL-DVI adapter)

Single Link DVI:

- 1920x1200 (requires DP to DVI adapter)

VGA:

- 1920x1200 (requires DP to VGA adapter) Image Quality Features

Advanced support for 8-bit, 10-bit, and 16-bit per RGB color component. High bandwidth scaler for high quality up and downscaling

QuickSpecs

HP Z640 Workstation

Technical Specifications - Graphics

c04400040 — DA – 15080 Worldwide — Version 6 — April 1, 2015

Page 52

Display Output

Max number of monitors supported using DisplayPort 1.2a:

- 4 direct attached monitors

- 6 using DP 1.2a with MST and HBR2 enabled monitors

Monitor chaining from a single DisplayPort (subject to a max of 6 total monitors across all outputs, requires use of DisplayPort enabled monitors supporting MST and HBR2):

- one 4096x2160 display

- two 2560x1600 displays

- four 1920x1200 displays

Shading Architecture

Shader Model 5.0

Supported Graphics APIs

OpenGL 4.4 OpenCL 1.2 and 2.0 DirectX 11.2 / 12 AMD Mantle

Available Graphics Drivers

Windows 8.1 / 8 (64-bit and 32-bit) Windows® 7 (64-bit and 32-bit) Linux

HP qualified drivers may be preloaded or available from the HP support Web site:

http://welcome.hp.com/country/us/en/support.html

Notes

1. AMD Eyefinity technology supports up to six DisplayPort™ monitors on

an enabled graphics card. Supported display quantity, type and resolution vary by model and board design; confirm specifications with manufacturer before purchase. To enable more than two displays, or multiple displays from a single output, additional hardware such as DisplayPort-ready monitors or DisplayPort 1.2 MST-enabled hubs may be required. A maximum of two active adapters is recommended for consumer systems. See www.amd.com/eyefinityfaq for full details.

Form Factor

Full height, single slot (6.75” X 4.376”)

NVIDIA Quadro K4200 4GB Graphics

Form Factor

4.376” H x 9.5” L

Single Slot, Full Height Weight: ~458 grams (without extender)

Graphics Controller

NVIDIA Quadro K4200 Graphics Card Kepler GK104 GPU 1344 CUDA cores Max Power: 108 Watts

Bus Type

PCI Express 2.0 x16

Memory

4 GB GDDR5, 2700 MHz 256-bit memory I/O path 173 GB/s memory bandwidth

Connectors

1 DL-DVI(I) output, 2 DisplayPort outputs CTO: No video cable adapter included

QuickSpecs

HP Z640 Workstation

Technical Specifications - Graphics

c04400040 — DA – 15080 Worldwide — Version 6 — April 1, 2015

Page 53

AMO: One DP-to-DVI adapter included with card

Additional DVI-to-VGA, DisplayPort-to-VGA or DisplayPort-to-DVI adapters are available as accessories

Maximum Resolution

DisplayPort:

- up to 3840 x 2160 x 30 bpp @ 60Hz

- supports High Bit Rate 2 (HBR2) and Multi-Stream Transport (MST)

DL-DVI(I) output:

- up to 2560 x 1600 x 32 bpp @ 60Hz

Image Quality Features

 10-bit internal display processing pipeline  10-bit scan-out support

Display Output

VGA:

- requires use of DVI-to-VGA and/or DP-to-VGA video cable adapters

- 400 MHz integrated RAMDAC

- Max resolution: 2048 x 1536 x 32 bpp @ 85 Hz

DL-DVI(I):

- Max resolution: 2560 x 1600 x 32 bpp @ 60 Hz

SL-DVI(I):

- Max resolution: 1920 x 1200 x 32 bpp @ 60 Hz

DisplayPort:

- Supports HBR2 and MST

- Max resolution: 3840 x 2160 x 30 bpp @ 60 Hz (only one monitor can be connected to a Quadro K4200 DisplayPort connector at this resolution)

- Max number of DisplayPort daisy-chained monitors or hub connected monitors from a single Quadro K4200 DisplayPort connector: 4 with maximum resolution of 1920 x 1200

HDMI:

- Requires use of DP-to-HDMI cable

- Max Resolution: 1920 x 1080 x 32 bpp @ 60Hz

Maximum number of monitors across all available Quadro K4200 outputs is

4.

Shading Architecture

Full Microsoft DirectX 11 Shader Model 5.0

Supported Graphics APIs

OpenGL 4.4 DirectX 11.1 API support includes: CUDA C, CUDA C++, DirectCompute 5.0, OpenCL, Java, Python, and Fortran

Available Graphics Drivers

Microsoft Windows 8.1 Microsoft Windows 8 Microsoft Windows 7 Linux

HP qualified drivers may be preloaded or available from the HP support Web site:

http://welcome.hp.com/country/us/en/support.html

Notes

1. Quadro K4200 offered as CTO does not include a video cable

adapter. Video cable adapters must be ordered separately.

QuickSpecs

HP Z640 Workstation

Technical Specifications - Graphics

c04400040 — DA – 15080 Worldwide — Version 6 — April 1, 2015

Page 54

2. Quadro K4200 offered as AMO includes one DP-to-DVI video cable

adapter. Additional cables must be ordered separately.

3. A total maximum of 4 active monitors are supported across all

display output types. This may be accomplished by using daisy chained DisplayPort 1.2 displays or a DisplayPort 1.2 hub device.

4. A DisplayPort hub device may be used to connect multiple

DisplayPort monitors to a single Quadro K4200 DisplayPort output. A DisplayPort hub device may be used to connect multiple DisplayPort monitors to a single Quadro K4000 DisplayPort output.

NVIDIA Quadro K5200 8GB Graphics

Form Factor

4.376” H x 10.5” L Dual Slot Weight: ~880 grams (without extender)

Graphics Controller

NVIDIA Quadro K5200 GK110 GPU 2304 CUDA cores Max Power: 150 Watts

Bus Type

PCI Express 3.0 x16

Memory

8GB GDDR5 256-bit memory I/O path 192GB/s memory bandwidth

Connectors

DVI-I (1), DVI-D (1), DP (2)

Factory configured option: No adapter included with card. Option Kit: No adaptor included with card.

DVI to VGA, DisplayPort to VGA, DisplayPort to DVI, and DisplayPort to Dual-Link DVI adapters available as accessories

Image Quality Features

 DisplayPort with Multi-Stream Technology (MST) and High Bit Rate

2 (HBR2), HDMI 1.4, and HDCP support

 NVIDIA 3D Vision™ technology

Display Output

400 MHz integrated RAMDAC

 Maximum resolution over VGA (through DVI to VGA cable): 2048 ×

1536 × 32 bpp at 85 Hz

Dual-link internal TMDS (DVI 1.0)

 Maximum resolution over digital port (single GPU and SLI mode):

2560 × 1600 × 32 bpp at 60 Hz (reduced blanking)

Single-link internal TMDS (DVI 1.0)

 Maximum resolution over digital port (single GPU and SLI

mode):1920 × 1200 × 32 bpp at 60 Hz (reduced blanking)

DisplayPort with MST and HBR2.

 Maximum resolution: 4096 × 2160 × 30 bpp at 60Hz  Maximum resolution: 2560 x 1600 × 30 bpp at 120Hz

HDMI

● Maximum resolution: 1920 × 1080 × 32 bpp at 60Hz

QuickSpecs

HP Z640 Workstation

Technical Specifications - Graphics

c04400040 — DA – 15080 Worldwide — Version 6 — April 1, 2015

Page 55

Shading Architecture

Shader model 5.0 Support

Supported Graphics APIs

OpenGL 4.4 DirectX 11

API support for NVIDIA’s CUDA™ C, CUDA C++, DirectCompute 5.0, OpenCL,

Java, Python, Fortran

Available Graphics Drivers

Windows 8 Genuine Windows 7 Professional (64-bit and 32-bit) Red Hat Enterprise Linux (RHEL) 6 Desktop/Workstation (64-bit) Red Hat Enterprise Linux (RHEL) 7 Desktop/Workstation SUSE Linux Enterprise Desktop 11 SP3 (64-bit)

HP qualified drivers may be preloaded or available from the HP support Web site:

http://welcome.hp.com/country/us/en/support.html

Note

1. NVIDIA GRID VGX Pass Through feature supported on NVIDIA

Quadro K5200 to enable direct mapping of GPU to Virtual Machine.

2. No display output adapter included.

NVIDIA Quadro K6000 12GB Graphics

Form Factor

4.376” H x 10.5” L

Dual Slot Power: 234 Watts Weight: ~880 grams

Graphics Controller

NVIDIA Quadro K6000 Graphics Card based on the GK180 GPU Core Count: 2880 Base Clock: 797 MHz Boost Clock: 902 MHz

Bus Type

PCI Express 3.0 x16

Memory

12GB GDDR5 384-bit memory I/O path 288 GB/s memory bandwidth ECC Memory

Connectors

DVI-I (1), DVI-D (1), DP (2), Optional 3D Stereo bracket with 3-pin mini-DIN connector.

Factory configured option: No adapter included with card.

Option Kit: No adaptor included with card.

DVI to VGA, DisplayPort to VGA, DisplayPort to DVI, and DisplayPort to Dual-Link DVI adapters available as accessories.

Image Quality Features

 DisplayPort with Multi-Stream Technology (MST) and High Bit Rate

2 (HBR2), HDMI 1.4, and HDCP support

 NVIDIA 3D Vision™ technology  NVIDIA Premium Mosaic and nView

Display Output

400 MHz integrated RAMDAC

 Maximum resolution over VGA (through DVI to VGA cable): 2048 ×

QuickSpecs

HP Z640 Workstation

Technical Specifications - Graphics

c04400040 — DA – 15080 Worldwide — Version 6 — April 1, 2015

Page 56

1536 × 32 bpp at 85 Hz

Dual-link internal TMDS (DVI 1.0)

 Maximum resolution over digital port (single GPU and SLI mode):

2560 × 1600 × 32 bpp at 60 Hz (reduced blanking)

Single-link internal TMDS (DVI 1.0)

 Maximum resolution over digital port (single GPU and SLI

mode):1920 × 1200 × 32 bpp at 60 Hz (reduced blanking)

DisplayPort with MST and HBR2.

 Maximum resolution: 3840 × 2160 × 36 bpp at 60Hz

HDMI

● Maximum resolution: 1920 × 1080 × 32 bpp at 60Hz

Shading Architecture

Shader Model 5.0 Full IEEE 764-2008 32-bit and 64-bit precision

Supported Graphics APIs

Full OpenGL 4.3 Full DirectX 11 CUDA API support includes: CUDA C, CUDA C++, DirectCompute 5.0, OpenCL, Java, Python, and Fortran

Available Graphics Drivers

Windows 8 Windows 7 Professional (64-bit and 32-bit) Red Hat Enterprise Linux (RHEL) 6 Desktop/Workstation SUSE Linux Enterprise Desktop 11 (64-bit and 32-bit)

HP qualified drivers may be preloaded or available from the HP support Web site:

http://welcome.hp.com/country/us/en/support.html

Note

1. NVIDIA GRID VGX Pass Through feature supported on NVIDIA

Quadro K6000 to enable direct mapping of GPU to Virtual Machine.

2. No display output adapter included.

AMD FirePro W7100 8GB Graphics

Form Factor

Full height, single slot (9.5” X 4.376”)

Graphics Controller

AMD FirePro W7100 graphics GPU: 1792 Stream Processors organized into 28 Compute Units Power: <75 Watts Cooling: Active

Bus Type

PCI Express® x16, Generation 3.0

Memory

8GB GDDR5 memory Memory Bandwidth: up to 176 GB/s Memory Width: 256 bit

Connectors

4x Display Port 1.2a connectors with HBR2 and MST support.

QuickSpecs

HP Z640 Workstation

Technical Specifications - Graphics

c04400040 — DA – 15080 Worldwide — Version 6 — April 1, 2015

Page 57

Factory Configured: No video cable adapter included After market option kit: No video cable adapter included

Additional DisplayPort-to-VGA or DisplayPort-to-DVI adapters are available as Factory Configuration or Option Kit accessories.

Maximum Resolution

DisplayPort:

- 4096x2160 @24bpp 60Hz

Dual Link DVI:

- 2560x1600 (requires DP to DL-DVI adapter)

Single Link DVI:

- 1920x1200 (requires DP to DVI adapter)

VGA:

- 1920x1200 (requires DP to VGA adapter)

Image Quality Features

Advanced support for 8-bit, 10-bit, and 16-bit per RGB color component. High bandwidth scaler for high quality up and downscaling

Display Output

Max number of monitors supported using DisplayPort 1.2a:

- 4 direct attached monitors

- 6 using DP 1.2a with MST and HBR2 enabled monitors

Monitor chaining from a single DisplayPort (subject to a max of 6 total monitors across all outputs, requires use of DisplayPort enabled monitors supporting MST and HBR2):

- one 4096x2160 display

- two 2560x1600 displays

- four 1920x1200 displays

Shading Architecture

Shader Model 5.0

Supported Graphics APIs

OpenGL 4.4 OpenCL 1.2 and 2.0 DirectX 11.2 / 12 AMD Mantle

Available Graphics Drivers

Windows 8.1 / 8 (64-bit and 32-bit) Windows® 7 (64-bit and 32-bit) Linux

HP qualified drivers may be preloaded or available from the HP support Web site:

http://welcome.hp.com/country/us/en/support.html

Notes

1. AMD Eyefinity technology supports up to six DisplayPort™ monitors on

an enabled graphics card. Supported display quantity, type and resolution vary by model and board design; confirm specifications with manufacturer before purchase. To enable more than two displays, or multiple displays from a single output, additional hardware such as DisplayPort-ready monitors or DisplayPort 1.2 MST-enabled hubs may be required. See

QuickSpecs

HP Z640 Workstation

Technical Specifications - Graphics

c04400040 — DA – 15080 Worldwide — Version 6 — April 1, 2015

Page 58

www.amd.com/eyefinityfaq for full details.

2. OpenGL 4.4 support available with driver 14.301.xxx or later.

3. OpenCL 2.0 support planned in driver updates for early 2015.

4. For HP Z440 Workstation configurations, the HP Z4 Fan and Front Card Guide Kit, which is available both CTO (G8T99AV) and AMO (J9P80AA), is required.

QuickSpecs

HP Z640 Workstation

Technical Specifications - High Performance GPU Computing

c04400040 — DA – 15080 Worldwide — Version 6 — April 1, 2015

Page 59

NVIDIA Tesla K40 Workstation Compute Processor

Form Factor

Size: 4.376 inches by 10.5 inches Slots: Dual Slot Power Connectors: One 6-pin and one 8-pin Weight: ~826 grams

System Interface

PCI Express Gen3 ×16

Video Outputs

None.

Memory

12GB GDDR5, memory path: 384-bit memory clock: 3Ghz

Peak Memory Bandwidth

288 GB/s

Supported APIs

CUDA, OpenACC, OpenCL 1.2 API support includes: C, C++, Java, Python, and Fortran

Supported Operating Systems

Windows 8 (64-bit) Genuine Windows 7 Professional (64-bit) Red Hat Enterprise Linux (RHEL) 5, 6 Desktop/Workstation (64-bit) SUSE Linux Enterprise Desktop 11 (64-bit)

HP qualified drivers may be preloaded or available from the HP support Web site:

http://welcome.hp.com/country/us/en/support.html

Novell SUSE Linux Enterprise drivers may also be obtained from:

ftp://download.nvidia.com/novell or http://www.nvidia.com

Processor Cores

GK110B GPU Base Clock: 745 MHz Boost Clock: up to 875 MHz 2888 CUDA cores

Power Consumption

~235 Watts

NOTE: A 1125W PSU is required for any K40 configuration on the Z820

HIGH PERFORMANCE GPU COMPUTING

QuickSpecs

HP Z640 Workstation

Technical Specifications - Optical and Removable Storage

c04400040 — DA – 15080 Worldwide — Version 6 — April 1, 2015

Page 60

HP 9.5mm Slim SuperMulti DVD Writer

Description

9.5mm height, tray-load

Mounting Orientation

Either horizontal or vertical

Interface Type

SATA/ATAPI

Dimensions (WxHxD)

128 x 9.5 x 127mm

Supported Media Types

DVD-RAM DVD+R DVD+RW DVD+R DL DVD-R DL DVD-R DVD-RW CD-R CD-RW

Disc Capacity

DVD-ROM

8.5 GB DL or 4.7 GB standard

Full Stroke DVD

< 200 ms (seek)

Full Stroke CD

< 200 ms (seek)

Maximum Data Transfer Rates

CD ROM Read

CD-ROM, CD-R Up to 24X CD-RW Up to 24X

DVD ROM Read

DVD-RAM Up to 8X DVD+RW Up to 8X DVD-RW Up to 8X DVD+R DL Up to 8X DVD-R DL Up to 8X DVD-ROM Up to 8X DVD-ROM DL Up to 8X DVD+R Up to 8X DVD-R Up to 8X

Power

Source

SATA DC power receptacle

DC Power Requirements

5 VDC ± 5%-100 mV ripple p-p

DC Current

5 VDC -< 800 mA typical, <1600 mA maximum

Operating Environmental (all conditions noncondensing)

Temperature

41° to 122° F (5° to 50° C)

Relative Humidity

10% to 80%

Maximum Wet Bulb Temperature

84° F (29° C)

Operating Systems Supported

Windows 8.1, Windows 8 32-bit and 64-bit, Windows 7 Professional 32-bit and 64-bit, Windows Vista Business 64*, Windows Vista Business 32*, Windows Vista Home Basic 32*, Windows 2000, Windows XP Professional or Windows XP Home 32*. Red Hat Enterprise Linux(RHEL) WS4**, 5, 6 Desktop/Workstation SUSE Linux Enterprise Desktop 10 & 11

No driver is required for this device. Native support is provided by the operating system.

OPTICAL AND REMOVABLE STORAGE

QuickSpecs

HP Z640 Workstation

Technical Specifications - Optical and Removable Storage

c04400040 — DA – 15080 Worldwide — Version 6 — April 1, 2015

Page 61

Kit Contents

9.5mm Slim SuperMulti DVD Writer, 5.25" ODD Bay adapter/carrier, slim SATA data/power cable, installation guide

HP 9.5mm Slim DVD-ROM Drive

Description

9.5mm height, tray-load

Mounting Orientation

Either horizontal or vertical

Interface Type

SATA / ATAPI

Dimensions (WxHxD)

128 x 9.5 x 127mm

Disc Capacity

DVD-ROM

Single layer: Up to 4.7 GB Double layer: Up to 8.5 GB

Access Times

DVD-ROM Single Layer

< 110 ms (typical)

CD-ROM Mode 1

< 110 ms (typical)

Full Stroke DVD

< 230 ms (typical)

Full Stroke CD

< 220 ms (typical)

Power

Source

SATA DC power receptacle

DC Power Requirements

5 VDC ± 5%-100 mV ripple p-p

DC Current

5 VDC – <800mA typical, < 1600 mA maximum

Operating Environmental (all conditions noncondensing)

Temperature

41° to 122° F (5° to 50° C)

Relative Humidity

10% to 80%

Maximum Wet Bulb Temperature

84° F (29° C)

Operating Systems Supported

Windows 8.1, Windows 8 32-bit and 64-bit, Windows 7 Professional 32-bit and 64-bit, Windows Vista Business 64*, Windows Vista Business 32*, Windows Vista Home Basic 32*, Windows 2000, Windows XP Professional or Windows XP Home 32*. Red Hat Enterprise Linux(RHEL) WS4**, 5, 6 Desktop/Workstation SUSE Linux Enterprise Desktop 10 & 11

No driver is required for this device. Native support is provided by the operating system.

Kit Contents

9.5mm Slim DVD-ROM Drive, 5.25" ODD Bay adapter/carrier, slim SATA data/power cable, installation guide

HP 9.5mm Slim BDXL BluRay Writer

Description

9.5mm height, tray-load

Mounting Orientation

Either horizontal or vertical

Interface Type

SATA/ATAPI

Dimensions (WxHxD)

128 x 9.5 x 127mm

Supported Media Types

BD-ROM BD-R BD-RE DVD-RAM DVD+R DVD+RW DVD+R DL DVD-R DL

QuickSpecs

HP Z640 Workstation

Technical Specifications - Optical and Removable Storage

c04400040 — DA – 15080 Worldwide — Version 6 — April 1, 2015

Page 62

DVD-R DVD-RW CD-R CD-RW

Disc Capacity

DVD-ROM

8.5 GB DL or 4.7 GB standard

Blu-ray

25 GB (single-layer) 50 GB (dual-layer) 100/128 GB (BDXL)

Full Stroke DVD

< 230 ms (seek)

Full Stroke CD

< 220 ms (seek)

Blu-ray

< 230 ms (seek) (Full Stroke Blu-ray)

Startup Time

(Time to drive ready from tray loading) BD-ROM (SL/DL) 25S / 28S BD-R (SL/DL) 25S / 28S BD-RE (SL/DL) 25S / 28S DVD-ROM (SL/DL) 18S / 18S DVD-R (SL/DL) 25S / 25S DVD-RW 25S DVD+R (SL/DL) 25S / 25S DVD+RW 25S DVD-RAM 45S CD-ROM 15S

Maximum Data Transfer Rates

CD ROM Read

CD-ROM, CD-R Up to 24X CD-RW Up to 24X

DVD ROM Read

DVD-RAM Up to 8X DVD+RW Up to 8X DVD-RW Up to 8X DVD+R DL Up to 8X DVD-R DL Up to 8X DVD-ROM Up to 8X DVD-ROM DL Up to 8X DVD+R Up to 8X DVD-R Up to 8X

Blu-ray

BD-ROM Up to 6X BD-ROM DL Up to 6X BD-R Up to 6X BD-R DL Up to 6X BD-R Up to 6X BD-RE SL/DL Up to 6X

Power

Source

SATA DC power receptacle

DC Power Requirements

5 VDC ± 5%-100 mV ripple p-p

DC Current

5 VDC -900 mA typical, 2000mA maximum

Operating Environmental (all conditions noncondensing)

Temperature

41° to 122° F (5° to 50° C)

Relative Humidity

10% to 80%

Maximum Wet Bulb Temperature

84° F (29° C)

Operating Systems

Windows 8.1, Windows 8 32-bit and 64-bit, Windows 7 Professional 32-bit

QuickSpecs

HP Z640 Workstation

Technical Specifications - Optical and Removable Storage

c04400040 — DA – 15080 Worldwide — Version 6 — April 1, 2015

Page 63

Supported

and 64-bit, Windows Vista Business 64*, Windows Vista Business 32*, Windows Vista Home Basic 32*, Windows 2000, Windows XP Professional or Windows XP Home 32*. Red Hat Enterprise Linux(RHEL) WS4**, 5, 6 Desktop/Workstation SUSE Linux Enterprise Desktop 10 & 11

No driver is required for this device. Native support is provided by the operating system.

Kit Contents

9.5mm Slim BDXL Blu-Ray Writer, 5.25" ODD Bay adapter/carrier, slim SATA data/power cable, installation guide

As Blu-ray is a new format containing new technologies, certain disc, digital connection, compatibility and/or performance issues may arise, and do not constitute defects in the product. Flawless playback on all systems is not guaranteed. In order for some Blu-ray titles to play, they may require a DVI or HDMI digital connection and your display may require HDCP support. HD-DVD movies cannot be played on this workstation.

HP DX115 Removable Drive Enclosure

Interface Type

Compatible with SAS or SATA controllers. Offers 6Gb/s performance when used with 6Gb/s HDDs.

Dimensions (WxHxD)

147.6mm W x 41.1mm H x 205mm L (5.81” W x 1.62” H x 8.08” L)

Approvals

Frame and Carrier: 1.73 kg (3.8 lbs.) Carrier: 0.45 kg (1 lbs.)

HP 15-in-1 Media Card Reader

Description

Supports hardware ECC (Error Correction Code) function Supports hardware CRC (Cyclic Redundancy Check) function Supports MS 4-bit parallel transfer mode Supports MS-PRO 4-bit parallel transfer mode Supports MS PRO-HG Duo 4-bit parallel transfer mode Supports SD 4-bit parallel transfer mode Supports UHS-104 SD 4-bit card (version 3.0) Supports CF v6.0 with PIO mode 6 and Ultra DMA 7 mode

Interface Type

USB 3.0 High-speed interface Note: If there is a USB2 connection, USB2 transfer speeds are supported.

Dimensions (WxHxD)

4.9 x 4 x 1 in (124.5 x 101.6 x 25.4 mm) Fits conveniently in the 5.25" drive bay.

Supported Media Types

CompactFlash Type I CompactFlash Type II Microdrive Secure Digital Card (SD) Secure Digital High Capacity (SDHC) SD Extended Capacity Memory Card (SDXC) SD Ultra High Speed II(SD UHSII) Memory Stick Memory Stick Select Memory Stick Duo (MS Duo) Memory Stick PRO (MS PRO) Memory Stick PRO Duo (MS PRO Duo) Memory Stick PRO-HG Duo

QuickSpecs

HP Z640 Workstation

Technical Specifications - Optical and Removable Storage

c04400040 — DA – 15080 Worldwide — Version 6 — April 1, 2015

Page 64

MagicGate Memory Stick (MG) MagicGate Memory Stick Duo

These additional media types are supported with a card adapter. Memory Stick Micro (M2) miniSD miniSD High Capacity Micro SD Memory Card (MicroSD) Micro SD High Capacity Memory Card (MicroSDHC)

Test Parameters/Conditions - Power applied, unit operating on system ±5%

Operating Systems Supported

Windows 8 Pro (64-bit)* Windows 8.1 (64-bit)* Windows 8 (64-bit)* Windows 7 Ultimate (32-bit)** Windows 7 Ultimate (64-bit)** Windows 7 Professional (32-bit)** Windows 7 Professional (64-bit)** Windows 7 Home Basic** Windows 7 Home Premium (32-bit)** Windows 7 Home Premium (64-bit)** Windows Vista Business 64 Windows Vista Business 32 Windows Vista Home Basic 32 Windows XP Professional Windows XP Home 32 No driver is required for this device. Native support is provided by the operating system.

Not all features are available in all editions of Windows 8. Systems may require upgraded and/or separately purchased hardware, drivers and/or software to take full advantage of Windows 8 functionality. See

http://www.microsoft.com.

Not all features are available in all editions of Windows 7. This system may require upgraded and/or separately purchased hardware to take full advantage of Windows 7 functionality. Seehttp://www.microsoft.com/windows/windows-7/ for details.

Kit Contents

Windows 8 Pro (64-bit)* Windows 8.1 (64-bit)* Windows 8 (64-bit)* Windows 7 Ultimate (32-bit)** Windows 7 Ultimate (64-bit)** Windows 7 Professional (32-bit)** Windows 7 Professional (64-bit)** Windows 7 Home Basic** Windows 7 Home Premium (32-bit)** Windows 7 Home Premium (64-bit)** Windows Vista Business 64 Windows Vista Business 32 Windows Vista Home Basic 32 Windows XP Professional Windows XP Home 32 No driver is required for this device. Native support is provided by the operating system.

QuickSpecs

HP Z640 Workstation

Technical Specifications - Optical and Removable Storage

c04400040 — DA – 15080 Worldwide — Version 6 — April 1, 2015

Page 65

Not all features are available in all editions of Windows 8. Systems may require upgraded and/or separately purchased hardware, drivers and/or software to take full advantage of Windows 8 functionality. See

http://www.microsoft.com.

Not all features are available in all editions of Windows 7. This system may require upgraded and/or separately purchased hardware to take full advantage of Windows 7 functionality. Seehttp://www.microsoft.com/windows/windows-7/ for details.

Approvals

USB-IF, WHQL, Compliant with USB Mass Storage Class Bulk only Transport Specification Rev. 1.0, Compliant Intel Front Panel I/O Connectivity Design Guide V. 1.3, FCC, CE, BSMI, C-Tick, VCCI, MIC, cUL, TUVT Weight

0.35 lbs. (0.16 kg)

QuickSpecs

HP Z640 Workstation

Technical Specifications – Controller Cards

c04400040 — DA – 15080 Worldwide — Version 6 — April 1, 2015

Page 66

HP IEEE 1394b FireWire PCIe Card

Data Transfer Rate

Supports up to 800 Mb/s

Devices Supported

IEEE-1394 compliant devices

Bus Type

PCIe card full height PCIe slots

Ports

Two IEEE-1394b bilingual 9-Pin connectors (Rear)

Internal Connectors

One 10-Pin Header connector

System Requirements

Windows 8.1 64-bit, Windows 7 Professional 32-bit and 64-bit, SLED 11 and RHEL 6. Intel i5 series or higher processor, min 2GB of RAM, 20GB Hard Drive, CD-ROM drive, built in sound system, Available PCIe slot.

Temperature – Operating

50° to 131° F (10° to 55° C)

Temperature – Storage

-22° to 140° F (-30° to 60° C)

Relative Humidity – Operating

20% to 80%

Compliances

FCC Part 15B, cULus 60950, CE Mark EN55022B(1995)/EN55024-1998 STD, Taiwan BSMI CNS13438, Korea MIC

Operating Systems Supported

Windows 8.1 64-bit, Windows 7 Professional 32-bit and 64-bit

HP Thunderbolt-2 PCIe 1port I/O Card

Data Transfer Rate

Supports up to 20 Gb/s (20,000 Mb/s)

Devices Supported

Thunderbolt™ certified devices

Bus Type

PCIe card, full or half height PCIe slots

Ports

One Thunderbolt™ 2 external 20-Pin output connectors (Rear) One full size DisplayPort input connector (Rear)

Internal Connectors

One 5-Pin header connector

System Requirements

Genuine Windows 7 Professional 64-bit, Genuine Windows 8.1 64-bit, Intel i5 series or higher processor, 4-GB RAM, 20-GB Hard Drive, available PCIe slot.

Temperature - Operating

50° to 131° F (10° to 55° C)

Temperature - Storage

-22° to 140° F (-30° to 60° C)

Relative Humidity Operating

20% to 80%

Compliances

FCC Part 15B, cULus 60950, CE Mark EN55022B(1995)/EN55024-1998 STD, Taiwan BSMI CNS13438, Korea MIC

Operating Systems Supported

Genuine Windows 7 Professional 64-bit, Genuine Windows 8.1 64-bit..

Kit Contents

HP Thunderbolt™ 2 PCIe 1-port I/O Card, full height and half height bracket, DisplayPort to DisplayPort cable, internal header cables (2), user documentation and warranty card.

CONTROLLER CARDS

QuickSpecs

HP Z640 Workstation

Technical Specifications - Networking and Communications

c04400040 — DA – 15080 Worldwide — Version 6 — April 1, 2015

Page 67

Integrated Intel I218LM PCIe GbE Controller

Connector

RJ-45 (motherboard integration)

Controller

Intel I218LM GbE platform LAN connect networking controller

Memory

3 KB FIFO packet buffer memory (both Tx and Rx)

Data Rates Supported

10/100/1000 Mbps

Compliance

802.1as, 802.1p, 802.1Q, 802.3, 802.3ab, 802.3az, 802.3i, 802.3u, 802.3x,

802.3z

Bus Architecture

PCI Express 1.1 (x1) and SMBus

Data Transfer Mode

PCIe-based interface for active state operation (S0 state) and SMBus for host and management traffic (Sx low power state)

Power Requirement

Requires 3.3V only (integrated regulators)

Boot ROM Support

Yes

Network Transfer Mode

Full-duplex; Half-duplex (not supported for the 1000BASE-T transceiver)

Network Transfer Rate

10BASE-T (half-duplex) 10 Mbps 10BASE-T (full-duplex) 20 Mbps 100BASE-TX (half-duplex) 100 Mbps 100BASE-TX (full-duplex) 200 Mbps 1000BASE-T (full-duplex) 2000 Mbps

Management Capabilities

WOL, auto MDI crossover, PXE, Multi-port teaming, RSS, Advanced cable diagnostics AMT 9.1 support, vPro compliant

HP X520 10GbE Dual Port Adapter

Hardware Certifications

FCC B, UL, CE, VCCI, BSMI, CTICK, KCC

HP 10GbE SFP+ SR Transceiver

Operating Temperature

0C to 45C (32F to 113F)

Operating Humidity

0% to 85%, noncondensing

Dimensions (H x W x D)

0.47(h) x 0.54(w) x 2.19(d)inches (1.19 x 1.38 x 5.57 cm)

HP 10GbE SFP+ SR Transceiver

Connector

Two RJ-45

Controller

Intel® Ethernet I350 Controller

Data Rates Supported

10/100/1000 Mbps, Half- and full-duplex

Compliance

802.3, 802.3u, 802.3x, 802.3ab, 802.3ad, 802.1p, 802.1Q, 802.3az, IEEE 1588 PCIe v2.0 standard RoHS (6 of 6) FCC (U.S. only) Class B DOC (Canada) Class B CE EN 55024, EN55022 Class B VCCI Class II UL 1950 CSA 950 EN 60950 CE ACPI 1.1a

NETWORKING AND COMMUNICATIONS

QuickSpecs

HP Z640 Workstation

Technical Specifications - Networking and Communications

c04400040 — DA – 15080 Worldwide — Version 6 — April 1, 2015

Page 68

Microsoft WHQL (Windows Hardware Quality Labs)

Data Path Width

Four lane (x4) PCI Express compatible with x4, x8, and x16 PCI Express slots

Power Requirement

4.1W idle without EEE link partner

3.2W idle with EEE link partner

4.2W maximum

Network Transfer Rate

10BASE-T (half-duplex) 10 Mb/s 10BASE-T (full-duplex) 20 Mb/s 100BASE-TX (half-duplex) 100 Mb/s 100BASE-TX (full-duplex) 200 Mb/s 1000BASE-T (full-duplex) 2000 Mb/s Operating Temperature

32° to 131° F (0° to 55° C )

Operating Humidity

10% to 95% non-condensing

Dimensions (H x W x D)

5.3 x 2.5 in (13.50cm x 6.4 cm) (without brackets)

Operating System Driver Support

Windows 7 Professional 32-bit and 64-bit. Red Hat Enterprise Linux(RHEL) WS4, 5, 6 Desktop/Workstation Novell SLED 10 & SLED 11

Kit Contents

HP 361T PCIe Dual Port Gigabit NIC PCA with a standard height bracket attached to it (the low profile bracket is included in the clamshell that the PCA ships in) Product Warranty statement and the Quick Install Card (QIC).

Intel X540-T2 10GbE Dual Port Adapter

Operating Temperature

32° to 131° F (0° to 55° C)

Operating Humidity

5% to 95% non-condensing

Dimensions (H x W x D)

Standard PCIe with full height bracket installed, half height bracket included.

0.7 x 2.7 x 6.0 in

Operating System Driver Support

The HP driver drop is a unified package that includes the X540-T2 driver. It is the same driver as is used for the 561T. Currently, it includes drivers for Win7-32, Win7-x64, Win8-x64, and Win81-x64.

Kit Contents

Intel X540 10Gb Ethernet Dual port adapter, Installation guide, Warranty card.

NOTES

Windows Server 2012 R2, Windows Server 2012, Windows 8, Windows Server 2008 R2, Windows 7, Windows Server 2008 SP2, Windows Vista SP2, Windows Server 2003 R2, Windows Server 2003 SP2, Linux Stable Kernel version 3.x, 2.6,x, Red Hat Enterprise Linux 5, 6, SUSE Linux Enterprise Server 10, 11, FreeBSD 9, VMware ESX/ESXi. Note: Not all OS's supported on all HP Z Workstations.

HP 361T PCIe Dual Port Gigabit NIC

Connector

Two RJ-45

Controller

Intel® Ethernet I350 Controller

Data Rates Supported

10/100/1000 Mbps, Half- and full-duplex

Compliance

802.3, 802.3u, 802.3x, 802.3ab, 802.3ad, 802.1p, 802.1Q, 802.3az, IEEE 1588 PCIe v2.0 standard RoHS (6 of 6) FCC (U.S. only) Class B DOC (Canada) Class B

QuickSpecs

HP Z640 Workstation

Technical Specifications - Networking and Communications

c04400040 — DA – 15080 Worldwide — Version 6 — April 1, 2015

Page 69

CE EN 55024, EN55022 Class B VCCI Class II UL 1950 CSA 950 EN 60950 CE ACPI 1.1a Microsoft WHQL (Windows Hardware Quality Labs)

Data Path Width

Four lane (x4) PCI Express compatible with x4, x8, and x16 PCI Express slots

Power Requirement

4.1W idle without EEE link partner

3.2W idle with EEE link partner

4.2W maximum

Network Transfer Rate

10BASE-T (half-duplex) 10 Mb/s 10BASE-T (full-duplex) 20 Mb/s 100BASE-TX (half-duplex) 100 Mb/s 100BASE-TX (full-duplex) 200 Mb/s 1000BASE-T (full-duplex) 2000 Mb/s

Operating Temperature

32° to 131° F (0° to 55° C )

Operating Humidity

10% to 95% non-condensing

Dimensions (H x W x D)

5.3 x 2.5 in (13.50cm x 6.4 cm) (without brackets)

Operating System Driver Support

Windows 7 Professional 32-bit and 64-bit. Red Hat Enterprise Linux(RHEL) WS4, 5, 6 Desktop/Workstation Novell SLED 10 & SLED 11

Kit Contents

HP 361T PCIe Dual Port Gigabit NIC PCA with a standard height bracket attached to it (the low profile bracket is included in the clamshell that the PCA ships in) Product Warranty statement and the Quick Install Card (QIC).

Intel 7260 802.11 a/b/g/n PCIe WLAN NIC

Operating Humidity

Operating 10% to 90% (non-condensing) Non-operating 5% to 95% (non-condensing)

Dimensions (H x W x D)

Native HMC: 26.8 x 30.0 x 2.4 mm Carrier Card Assembly 3.3 x 4.7 in (84 x 119 mm)

Kit Contents

PCIe x1 card with full height bracket, rf antenna, antenna cable, separate low profile bracket, software CD and warranty.

NOTES:

1. WLAN supplier's client utility is required for Cisco Compatible Extensions support with

Microsoft Windows XP. WLAN may also be compatible with certain third-party software supplicants. WLAN supplier IHV extensions required for Cisco Compatible Extensions support for Microsoft Windows Vista.

2. Check latest software/driver release for updates on supported security features.

3. Maximum output power may vary by country according to local regulations.

4. In Power Save Polling mode and on battery power.

5. Receiver sensitivity is measured at a packet error rate of 8% for 802.11b (CCK modulation)

and a packet error rate of 10% for 802.11a/g (OFDM modulation).

QuickSpecs

HP Z640 Workstation

Summary of Changes

c04400040 — DA – 15080 Worldwide — Version 6 — April 1, 2015

Page 70

Date of change:

Version History:

Description of change:

August 21

V1

Added

Style and technical specifications,

October 1, 2014

From v1 to v2

Added

Cyberlink Power2Go on supported components: software, Foxit PhantomPDF Express to supported components: software, note to supported components: memory, Optical drives, DVD, BD-XL specs

Changed

Processor table with corrected turbo specs for E5-1660v3, Declared Noise Emissions section, stable & consistent offerings,system technical specifications: system board, supported components: optical and removable storage, supported components: graphics, Zero-ed out Noise Emissions

Removed

"Cyberlink MediaSuite" from supported components: software

January 1, 2015

From v3 to v4 Added

HP 256 GB SED Opal 2 SSD, AMD FirePro W7100 GPU, Intel X540 and Ubuntu OS

Changed

OS Overview Section, Chassis Dimensions, Power Suply note and links

February 1, 2015

From v4 to v5

Added

Windows 8.1 EM, AMD FirePro W5100 4GB specs, HP DX115 notes

Changed

Internal I/O USB from Overview and System Board sections

Removed

NVIDIA Tesla K20c Compute Processor from High Performance GPU Computing

March 1, 2015

From v5 to v6

Added

OS Support, RAID Interfaces Support, 600 and 300 GB SAS 15K SFF HDD, 4TB SATA HDD

Changed

Linux Installer Kit, Hard Drives description notes, ACPI support from BIOS section

April 1, 2015

From v6 to v7

Changed

Hard Drive and Memory Notes from Supported Components section. Memory Speed Supported and Memory Info from System Board section

SUMMARY OF CHANGES

QuickSpecs

HP Z640 Workstation

c04400040 — DA – 15080 Worldwide — Version 6 — April 1, 2015

Page 71

© 2014 Hewlett-Packard Development Company, L.P. The information contained herein is subject to change without notice. The only warranties for HP products and services are set forth in the express warranty statements accompanying such products and services. Nothing herein should be construed as constituting an additional warranty. HP shall not be liable for technical or editorial errors or omissions contained herein. Intel, Xeon, and QuickPath are trademarks of Intel Corporation in the U.S. and other countries. Microsoft and Windows are U.S. registered trademarks of Microsoft Corporation.
