HP ProBook 640 G8 Datasheet

Datasheet

HP ProBook 640 G8 Notebook PC

Modern design for the enterprise

The new modern design of the HP ProBook
640 brings style to the enterprise and
delivers the performance, durability, security,
and manageability required for today’s
workforce. Flexible configuration options fit a
range of users and budgets.

HP recommends Windows 10 Pro for
business

Easy to carry where the day takes you

Confidently carry this durable laptop with you knowing it’s built to last and made to
travel. The slim yet durable HP ProBook 640 features an aluminum chassis, an 88­percent screen-to-body ratio, and a spill resistant keyboard.

Made for the enterprise

With an optional quad-core 11th Gen Intel® Core™ vPro® processor, this globally
available PC is easy to service, drives performance and has long battery life, and
optional Thunderbolt™ docking. The optional Opal2 SSD provides for highly
secure storage for the enterprise.

Work with peace of mind

Security features from HP work together to create an always-on, always-acting,
resilient defense. From the BIOS to the browser, above and below the OS, these
constantly evolving solutions help protect your PC from threats.

You will appreciate the style of the aluminum chassis and the confidence that comes
from 120,000 hours of the HP Total Test process and MIL-STD 810H testing.

Help speed up demanding business applications with an optional quad-core 11th
Gen Intel® Core™ vPro® processor with breakthrough Intel® Iris® Xᵉ graphics.

Enjoy the consistent feel and extremely quiet typing experience of the redesigned
keyboard with rubber dome keys.

Get going fast with Connected Modern Standby and wake your PC from the optional
match-on-sensor fingerprint sensor.

Instantly block prying eyes by making your screen appear dark and unreadable from
the side with optional HP Sure View Gen3.

Firmware attacks can completely devastate your PC. Stay protected with HP Sure
Start Gen6, the self-healing BIOS that automatically recovers itself from attacks or
corruption.

Quickly transition to desktop productivity with a single USB-C® cable. The optional
HP Thunderbolt™ Dock G2 delivers enterprise manageability and you can add an
optional audio module.

Never wonder if someone is watching you with the added peace-of-mind that
comes from the integrated HP Privacy Camera, with a physical shutter to protect
from malicious surveillance.

The HP ProBook 640 uses recycled materials in the keyboard, speakers, and
packaging—this ENERGY STAR® certified PC earns an EPEAT® Gold rating in the
U.S.

2,3 1

4 5

6,7

1,2,3,16

8

9

10

11,12,13

14

15

Data sheet | HP ProBook 640 G8 Notebook PC

HP recommends Windows 10 Pro for business

HP ProBook 640 G8 Notebook PC Specifications Table

Available Operating Systems

Windows 10 Pro 64 – HP recommends Windows 10 Pro for business
Windows 10 Home 64
Windows 10 Home Single Language 64
FreeDOS

Processor family 11th Generation Intel® Core™ i7 processor; 11th Generation Intel® Core™ i5 processor; 11th Generation Intel® Core™ i3 processor

Available Processors

Intel® Core™ i3-1115G4 with Intel® UHD Graphics (up to 4.1 GHz with Intel® Turbo Boost Technology, 6 MB L3 cache, 2 cores); Intel®
Core™ i5-1135G7 with Intel® UHD Graphics 620 (up to 4.2 GHz with Intel® Turbo Boost Technology, 8 MB L3 cache, 4 cores); Intel® Core™
i7-1165G7 (up to 4.7 GHz with Intel® Turbo Boost Technology, 12 MB L3 cache, 4 cores); Intel® Core™ i7-1185G7 (up to 4.8 GHz with
Intel® Turbo Boost Technology, 12 MB L3 cache, 4 cores), supports Intel® vPro® Technology; Intel® Core™ i7-1145G7 (up to 4.4 GHz with
Intel® Turbo Boost Technology, 8 MB L3 cache, 4 cores), supports Intel® vPro® Technology

Maximum memory

32 GB DDR4-3200 SDRAM
Both slots are customer accessible/upgradeable. Supports dual channel memory.

Memory slots 2 SODIMM

Internal storage

up to 512 GB Intel® PCIe® NVMe™ QLC M.2 SSD with 32 GB Intel® Optane™ memory H10
128 GB up to 1 TB PCIe® Gen3x2 NVMe™ M.2 SSD TLC
256 GB up to 512 GB PCIe® Gen3x4 NVMe™ M.2 SED SSD TLC
256 GB up to 512 GB PCIe® NVMe™ Value M.2 SSD

Display size (diagonal, metric) 35.56 cm (14")

Display

35.6 cm (14") diagonal, FHD (1920 x 1080), touch, narrow bezel, anti-glare, 250 nits, 45% NTSC; 35.6 cm (14") diagonal, FHD (1920 x

1080), IPS, narrow bezel, anti-glare, 1000 nits, 100% sRGB, HP Sure View integrated privacy screen; 35.6 cm (14") diagonal, FHD (1920 x

1080), IPS, narrow bezel, anti-glare, 400 nits, low power, 100% sRGB; 35.6 cm (14") diagonal, FHD (1920 x 1080), IPS, narrow bezel,
anti-glare, 250 nits, 45% NTSC; 35.6 cm (14") diagonal, HD (1366 x 768), narrow bezel, anti-glare, 250 nits, 45% NTSC

Available Graphics

Integrated: Intel® Iris® Xᵉ Graphics; Intel® UHD Graphics
Discrete: NVIDIA® GeForce® MX450 (2 GB DDR5 dedicated)
(Support HD Decode, DX12, and HDMI 1.4b.)

Audio Dual stereo speakers, dual array microphone

Ports and Connectors

2 SuperSpeed USB Type-A 5Gbps signaling rate (1 charging, 1 power); 1 SuperSpeed USB Type-C® 10Gbps signaling rate (USB Power
Delivery, DisplayPort™ 1.4); 1 headphone/microphone combo; 1 HDMI 1.4b; 1 AC power
(HDMI cable sold separately.)
Optional Ports: 1 SIM card slot (optional); 1 RJ-45 (optional)

Input devices HP Premium Keyboard, spill-resistant with optional backlit ; Clickpad with multi-touch gesture support;

Communications

Integrated 10/100/1000 GbE NIC; Realtek 10/100/1000 GbE NIC ; Intel® 9560 802.11a/b/g/n/ac (2x2) Wi-Fi® and Bluetooth® 5 combo,
non-vPro®; Intel® AX201 Wi-Fi 6 (2x2) and Bluetooth® 5 combo, non-vPro® ;

Camera 720p HD camera; IR Camera

Software

HP Connection Optimizer; HP Image Assistant; HP Hotkey Support; HP Noise Cancellation Software; HP Support Assistant; HP Power
Manager; HP WorkWell; myHP; HP Privacy Settings; HSA Fusion for Commercial; HSA Telemetry for Commercial; Touchpoint Customizer
for Commercial; HP Notifications

Security management

Absolute persistence module; HP DriveLock and Automatic DriveLock; HP Secure Erase; Preboot authentication; TPM 2.0 embedded
security chip shipped with Windows 10 (Common Criteria EAL4+ Certified); HP Sure Click; Windows Defender; HP BIOSphere Gen5; HP
Sure Sense; BIOS Update via Network; Master Boot Record Security; Support for chassis padlocks and cable lock devices; HP Sure Start
Gen6; HP Sure Admin; HP Sure Run Gen4; HP Sure Recover Gen4; HP Client Security Manager Gen7

Security Software Licenses HP Pro Security Edition (select models)

Fingerprint reader Fingerprint sensor (select models)

Management features

HP Driver Packs; HP System Software Manager (SSM); HP BIOS Config Utility (BCU); HP Client Catalog; HP Manageability Integration Kit
Gen3

Power

HP Smart 65 W External AC power adapter; HP Smart 45 W External AC power adapter; HP Smart 65 W USB Type-C® adapter; HP Smart
45 W USB Type-C® adapter

Battery type HP Long Life 3-cell, 45 Wh polymer

Dimensions 32.19 x 21.39 x 1.99 cm

Weight Starting at 1.38 kg (Weight will vary by configuration.)

Energy efficiency compliance

ENERGY STAR® certified; EPEAT® registered where applicable. EPEAT registration varies by country. See www.epeat.net for registration
status by country.

Sustainable impact specifications Low halogen; TCO 5.0 Certified

Warranty

1 year standard parts and labor limited warranty (1-1-0), depending on country (upgrades available). 1 year limited warranty on primary
battery.


