QuickSpecs
HP ProBook 430 G4 Notebook PC
HP ProBook 440 G4 Notebook PC
HP ProBook 450 G4 Notebook PC
HP ProBook 470 G4 Notebook PC
Overview
Not all configuration components are available in all regions/countries.
Americas – HP ProBook 430, 440, 450 & 470 G4 Notebook PC – October 2016 - c05254141
Page 1
Front
1.
Microphones (2)
8.
Hard drive LED
2.
Webcam light
9.
SD Card reader
3.
Webcam
10.
Headphone/Microphone combo jack
4.
Wireless on/off button
11.
USB 2.0 port (power port)
5.
Speaker mute button
12.
Security lock slot
6.
Fingerprint reader
13.
Power button
7.
Touchpad
HP ProBook 430 G4 Notebook PC
QuickSpecs
HP ProBook 430 G4 Notebook PC
HP ProBook 440 G4 Notebook PC
HP ProBook 450 G4 Notebook PC
HP ProBook 470 G4 Notebook PC
Overview
Not all configuration components are available in all regions/countries.
Americas – HP ProBook 430, 440, 450 & 470 G4 Notebook PC – October 2016 - c05254141
Page 2
Rear
1.
USB-C port
4.
External VGA monitor port
2.
USB 3.0 port
5.
Ethernet port (RJ-45)
3.
HDMI port
6.
Power connector
QuickSpecs
HP ProBook 430 G4 Notebook PC
HP ProBook 440 G4 Notebook PC
HP ProBook 450 G4 Notebook PC
HP ProBook 470 G4 Notebook PC
Overview
Not all configuration components are available in all regions/countries.
Americas – HP ProBook 430, 440, 450 & 470 G4 Notebook PC – October 2016 - c05254141
Page 3
Front
1.
Microphones (2)
8.
Hard drive LED
2.
Webcam light
9.
SD Card reader
3.
Webcam
10.
Headphone/Microphone combo jack
4.
Wireless on/off button
11.
USB 2.0 port (power port)
5.
Speaker mute button
12.
Security lock slot
6.
Fingerprint reader
13.
Power button
7.
Touchpad
HP ProBook 440 G4 Notebook PC
QuickSpecs
HP ProBook 430 G4 Notebook PC
HP ProBook 440 G4 Notebook PC
HP ProBook 450 G4 Notebook PC
HP ProBook 470 G4 Notebook PC
Overview
Not all configuration components are available in all regions/countries.
Americas – HP ProBook 430, 440, 450 & 470 G4 Notebook PC – October 2016 - c05254141
Page 4
Rear
1.
USB Type-CTM port
4.
External VGA monitor port
2.
USB 3.0 port
5.
Ethernet port (RJ-45)
3.
HDMI port
6.
Power connector
QuickSpecs
HP ProBook 430 G4 Notebook PC
HP ProBook 440 G4 Notebook PC
HP ProBook 450 G4 Notebook PC
HP ProBook 470 G4 Notebook PC
Overview
Not all configuration components are available in all regions/countries.
Americas – HP ProBook 430, 440, 450 & 470 G4 Notebook PC – October 2016 - c05254141
Page 5
Front
1.
Microphones (2)
9.
SD Card reader
2.
Webcam light
10.
USB-C port
3.
Webcam
11.
USB 3.0 port
4.
Wireless on/off button
12.
HDMI port
5.
Speaker mute button
13.
External VGA monitor port
6.
Fingerprint reader
14.
Power connector
7.
Touchpad
15.
Power button
8.
Hard drive LED
HP ProBook 450 G4 Notebook PC
QuickSpecs
HP ProBook 430 G4 Notebook PC
HP ProBook 440 G4 Notebook PC
HP ProBook 450 G4 Notebook PC
HP ProBook 470 G4 Notebook PC
Overview
Not all configuration components are available in all regions/countries.
Americas – HP ProBook 430, 440, 450 & 470 G4 Notebook PC – October 2016 - c05254141
Page 6
Rear
1.
Optical drive
4.
Ethernet port (RJ-45)
2.
Headphone/Microphone combo jack
5.
Security lock slot
3.
USB 2.0 ports (2)
QuickSpecs
HP ProBook 430 G4 Notebook PC
HP ProBook 440 G4 Notebook PC
HP ProBook 450 G4 Notebook PC
HP ProBook 470 G4 Notebook PC
Overview
Not all configuration components are available in all regions/countries.
Americas – HP ProBook 430, 440, 450 & 470 G4 Notebook PC – October 2016 - c05254141
Page 7
Front
1.
Microphones (2)
9.
SD Card reader
2.
Webcam light
10.
USB-C port
3.
Webcam
11.
USB 3.0 port
4.
Wireless on/off button
12.
HDMI port
5.
Speaker mute button
13.
External VGA monitor port
6.
Fingerprint reader
14.
Power connector
7.
Touchpad
15.
Power button
8.
Hard drive LED
HP ProBook 470 G4 Notebook PC
QuickSpecs
HP ProBook 430 G4 Notebook PC
HP ProBook 440 G4 Notebook PC
HP ProBook 450 G4 Notebook PC
HP ProBook 470 G4 Notebook PC
Overview
Not all configuration components are available in all regions/countries.
Americas – HP ProBook 430, 440, 450 & 470 G4 Notebook PC – October 2016 - c05254141
Page 8
Right
1.
Optical drive
4.
Ethernet port (RJ-45)
2.
Headphone/Microphone combo jack
5.
Security lock slot
3.
USB 2.0 ports (2)
QuickSpecs
HP ProBook 430 G4 Notebook PC
HP ProBook 440 G4 Notebook PC
HP ProBook 450 G4 Notebook PC
HP ProBook 470 G4 Notebook PC
Overview
Not all configuration components are available in all regions/countries.
Americas – HP ProBook 430, 440, 450 & 470 G4 Notebook PC – October 2016 - c05254141
Page 9
1. Windows 10 or FreeDOS 2.0
2. Choice of Intel® Core™ processors
3. Full size HP Premium Keyboard, spill-resistant keyboard with a thin layer of Mylar film to prevent minor spills; full
separate numeric keypad (on 450/470 only)
4. Separate launch buttons provide easy access to wireless on/off and speaker mute.
5. Function keys provide control of features including: standby mode, display brightness, external display, microphone
mute, volume down, volume up, and backlight toggle for backlit keyboard (select models only).
6. Large Clickpad with gestures support
7. Enhanced security features with preinstalled software and hardware options
8. Optional HD webcam with dual-microphone array for video conferencing
9. HDMI port for connecting to high-resolution displays
10. Choice of displays
o HP ProBook 430 G4
o 13.3" diagonal Full HD anti-glare Ultraslim LED-backlit (1920 x 1080) Non-Touch
o 13.3" diagonal HD anti-glare Slim LED-backlit (1366 x 768) Non-Touch
o 13.3” diagonal HD Slim LED-backlit (1366 x 768) Touch
o HP ProBook 440 G4
o 14" diagonal Full HD anti-glare slim LED-backlit (1920 x 1080) Non-Touch
o 14" diagonal HD anti-glare Slim LED-backlit (1366 x 768) Non-Touch
o 14” diagonal HD Slim LED-backlit (1366 x 768) Touch
o HP ProBook 450 G4
o 15.6" diagonal Full HD anti-glare slim LED-backlit (1920 x 1080) Non-Touch
o 15.6" diagonal HD anti-glare Slim LED-backlit (1366 x 768) Non-Touch
o 15.6" diagonal HD Slim LED-backlit touch screen (1366 x 768) Touch
o HP ProBook 470 G4
o 17.3" diagonal Full HD anti-glare flat LED backlit (1920 x 1080) Non-Touch
o 17.3" diagonal HD+ anti-glare flat LED backlit (1600 x 900) Non-Touch
11. Flexible wireless connectivity options
12. Battery life
o HP ProBook 430 G4 up to 16hrs (SSD), or 13hrs (HDD)
o HP ProBook 440 G4 up to 15hrs 30mins (SSD), or 12hrs 30mins (HDD)
o HP ProBook 450 G4 up to 14hrs 15mins (SSD), or 12hrs (HDD)
o HP ProBook 470 G4 up to 12hrs 45mins (SSD), or 11hrs (HDD)
13. HP 3-cell, 48 WHr Li-ion battery
14. Passed MIL-STD testing
1
1. MIL STD 810G testing was not intended to demonstrate fitness for U.S. Department of Defense contract requirements or
for military use. Test results are not a guarantee of future performance under these test conditions. Damage under the
MIL STD test conditions or any accidental damage requires an optional HP Accidental Damage Protection Care Pack.
NOTE: See important legal disclosures for all listed specs in their respective features sections.
At a Glance
QuickSpecs
HP ProBook 430 G4 Notebook PC
HP ProBook 440 G4 Notebook PC
HP ProBook 450 G4 Notebook PC
HP ProBook 470 G4 Notebook PC
Features
Not all configuration components are available in all regions/countries.
Americas – HP ProBook 430, 440, 450 & 470 G4 Notebook PC – October 2016 - c05254141
Page 10
HP ProBook 430 G4 Notebook PC
HP ProBook 440 G4 Notebook PC
HP ProBook 450 G4 Notebook PC
HP ProBook 470 G4 Notebook PC
Preinstalled
Windows 10 Pro 641
Windows 10 Pro (National Academic only) 1
Windows 10 Home 641
Windows 10 Home Single Language 641
Windows 10 Home 64 (National Academic only) 1
FreeDOS 2.0
Web only support
Windows 10 Pro 641
Windows 10 Home 641
Windows 10 Enterprise 641
1.Not all features are available in all editions or versions of Windows. Systems may require upgraded and/or separately
purchased hardware, drivers, software or BIOS update to take full advantage of Windows functionality. Windows 10 is
automatically updated, which is always enabled. ISP fees may apply and additional requirements may apply over time for
updates. See http://www.microsoft.com.
NOTE:
Your product does not support Windows 8 or Windows 7
In accordance with Microsoft’s support policy, HP does not support the Windows® 8 or Windows 7 operating system on
products configured with Intel and AMD 7th generation and forward processors or provide any Windows® 8 or Windows 7
drivers on http://www.support.hp.com.
PRODUCT NAMES
OPERATING SYSTEMS
QuickSpecs
HP ProBook 430 G4 Notebook PC
HP ProBook 440 G4 Notebook PC
HP ProBook 450 G4 Notebook PC
HP ProBook 470 G4 Notebook PC
Features
Not all configuration components are available in all regions/countries.
Americas – HP ProBook 430, 440, 450 & 470 G4 Notebook PC – October 2016 - c05254141
Page 11
HP ProBook 430 G4
Intel® Core™ i3-7100U Intel® HD Graphics 620 (2.4GHz, 3MB L3 Cache, 2 core)
1,2
Intel® Core™ i5-7200U Intel® HD Graphics 620 (2.5GHz, up to 3.1 GHz with Intel Turbo Boost Technology,
3MB L3 Cache, 2 core)
1,2
Intel® Core™ i5-7300U Intel® HD Graphics 620 (2.6GHz, up to 3.5 GHz with Intel Turbo Boost Technology, 3MB L3 Cache, 2
core)
1,2
Intel® Core™ i7-7500U Intel® HD graphics 620 (2.7GHz, up to 3.5 GHz with Intel Turbo Boost Technology,
4MB L3 Cache, 2 core)
1,2
Intel® Pentium® 4415U with Intel® HD Graphics (2.3 GHz, 2 MB cache, 2 cores)
1,2
Intel® Celeron® 3865U with Intel® HD Graphics (1.8 GHz, 2 MB cache, 2 cores)
1,2
HP ProBook 440 G4
Intel® Core™ i3-7100U Intel® HD Graphics 620 (2.4GHz, 3MB L3 Cache, 2 core)
1,2
Intel® Core™ i5-7200U Intel® HD Graphics 620 (2.5GHz, up to 3.1 GHz with Intel Turbo Boost Technology
3MB L3 Cache, 2 core)
1,2
Intel® Core™ i5-7300U Intel® HD Graphics 620 (2.6GHz, up to 3.5 GHz with Intel Turbo Boost Technology, 3MB L3 Cache, 2
core)
1,2
Intel® Core™ i7-7500U Intel® HD graphics 620 (2.7GHz, up to 3.5 GHz with Intel Turbo Boost Technology,
4MB L3 Cache, 2 core)
1,2
Intel® Pentium® 4415U with Intel® HD Graphics (2.3 GHz, 2 MB cache, 2 cores)
1,2
Intel® Celeron® 3865U with Intel® HD Graphics (1.8 GHz, 2 MB cache, 2 cores)
1,2
HP ProBook 450 G4
Intel® Core™ i3-6006U Intel® HD Graphics 520 (2.0GHz, 3MB L3 Cache, 2 core)
1,2
Intel® Core™ i3-7100U Intel® HD Graphics 620 (2.4GHz, 3MB L3 Cache, 2 core)
1,2
Intel® Core™ i5-7200U Intel® HD Graphics 620 (2.5GHz, up to 3.1 GHz with Intel Turbo Boost Technology,
3MB L3 Cache, 2 core)
1,2
Intel® Core™ i7-7500U Intel® HD graphics 620 (2.7GHz, up to 3.5 GHz with Intel Turbo Boost Technology,
4MB L3 Cache, 2 core)
1,2
Intel® Pentium® 4415U with Intel® HD Graphics (2.3 GHz, 2 MB cache, 2 cores)
1,2
Intel® Celeron® 3865U with Intel® HD Graphics (1.8 GHz, 2 MB cache, 2 cores)
1,2
HP ProBook 470 G4
Intel® Core™ i3-7100U Intel® HD Graphics 620 (2.4GHz, 3MB L3 Cache, 2 core)
1,2
Intel® Core™ i5-7200U Intel® HD Graphics 620 (2.5GHz, up to 3.1 GHz with Intel Turbo Boost Technology,
3MB L3 Cache, 2 core)
1,2
Intel® Core™ i7-7500U Intel® HD graphics 620 (2.7GHz, up to 3.5 GHz with Intel Turbo Boost Technology,
4MB L3 Cache, 2 core)
1,2
1. Multicore is designed to improve performance of certain software products. Not all customers or software
applications will necessarily benefit from use of this technology. Performance and clock frequency will vary
depending on application workload and your hardware and software configurations. Intel’s numbering is not a
measurement of higher performance.
2. HD content required to view HD images.
NOTE: Processor speed denotes maximum performance mode; processors will run at lower speeds in battery optimization
mode.
PROCESSORS
QuickSpecs
HP ProBook 430 G4 Notebook PC
HP ProBook 440 G4 Notebook PC
HP ProBook 450 G4 Notebook PC
HP ProBook 470 G4 Notebook PC
Features
Not all configuration components are available in all regions/countries.
Americas – HP ProBook 430, 440, 450 & 470 G4 Notebook PC – October 2016 - c05254141
Page 12
Integrated with processor
Integrated
HP ProBook 430/440/450
Intel® HD Graphics 620
1
Note: View processor section for details.
Discrete2
HP ProBook 450/470
NVIDIA® GeForce® 930MX (2GB DDR3 dedicated, switchable)
1. HD content required to view HD images.
2.NVIDIA® Optimus™ technology requires an Intel processor, plus an NVIDIA® GeForce® discrete graphics configuration and is
available on Windows 10 Professional OS. With NVIDIA® Optimus™ technology, full enablement of all discrete graphics video
and display features may not be supported on all systems (e.g. OpenGL applications will run on the integrated GPU or the
APU as the case may be).
HP ProBook 430 G4
Internal
Non-Touch
33.7 cm (13.3") diagonal HD1 anti-glare LED-backlit (1366 x 768)
33.7 cm (13.3") diagonal FHD1 anti-glare LED-backlit (1920 x 1080)
Touch
33.78 cm (13.3") diagonal HD1 touch screen (1366 x 768)
NOTE: Only available with Windows 10.
External
Up to 32-bit per pixel color depth
VGA
Port supports resolutions up to 2048 x 1536 external resolution @60 Hz
HDMI
Supports direct connection to high-definition displays with up to 4096 x 2160 @24 Hz
resolution and 7-channel audio with one convenient cable (Cable not included)
HP ProBook 440 G4
Internal
Non-Touch
35.5 cm (14") diagonal HD1 anti-glare LED-backlit (1366 x 768)
35.5 cm (14") diagonal FHD1 anti-glare LED-backlit (1920 x 1080)
Touch
35.56 cm (14") diagonal HD1 touch screen (1366 x 768)
CHIPSET
GRAPHICS
DISPLAYS
QuickSpecs
HP ProBook 430 G4 Notebook PC
HP ProBook 440 G4 Notebook PC
HP ProBook 450 G4 Notebook PC
HP ProBook 470 G4 Notebook PC
Features
Not all configuration components are available in all regions/countries.
Americas – HP ProBook 430, 440, 450 & 470 G4 Notebook PC – October 2016 - c05254141
Page 13
NOTE: Only available with Windows 10.
External
Up to 32-bit per pixel color depth
VGA
Port supports resolutions up to 2048 x 1536 external resolution @60 Hz
HDMI
Supports direct connection to high-definition displays with up to 4096 x 2160 @24 Hz
resolution and 7-channel audio with one convenient cable (Cable not included.)
HP ProBook 450 G4
Internal
Non-Touch
39.6 cm (15.6") diagonal HD1 anti-glare LED-backlit (1366 x 768)
39.6 cm (15.6") diagonal FHD1 anti-glare LED-backlit (1920 x 1080)
Touch
39.6 cm (15.6") diagonal HD1 touch screen (1366 x 768)
External
Up to 32-bit per pixel color depth
VGA
Port supports resolutions up to 2048 x 1536 external resolution @ 60 Hz
HDMI
Supports direct connection to high-definition displays with up to 4096 x 2160 @24 Hz
resolution and 7-channel audio with one convenient cable (not included)
HP ProBook 470 G4
Internal
Non-Touch
43.9 cm (17.3") diagonal HD+1 anti-glare LED-backlit (1600 x 900)
43.9 cm (17.3") diagonal FHD1 anti-glare LED-backlit (1920 x 1080)
External
Up to 32-bit per pixel color depth
VGA
Port supports resolutions up to 2048x1536 external resolution @ 60 Hz
HDMI
Supports direct connection to high-definition displays with up to 4096 x 2160 @24 Hz
resolution and 7-channel audio with one convenient cable (not included)
1. HD content required to view HD images.
NOTE: Resolutions are dependent upon monitor capability, and resolution and color depth settings.
QuickSpecs
HP ProBook 430 G4 Notebook PC
HP ProBook 440 G4 Notebook PC
HP ProBook 450 G4 Notebook PC
HP ProBook 470 G4 Notebook PC
Features
Not all configuration components are available in all regions/countries.
Americas – HP ProBook 430, 440, 450 & 470 G4 Notebook PC – October 2016 - c05254141
Page 14
HP ProBook 430 and 440 G4
Hard Drives
Supports SATA, 7mm, 2.5" Hard Drives
500 GB - 7200 RPM Hard Drive
500 GB – SSHD (hybrid) (8 GB Cache)
1 TB - 5400 RPM Hard Drive
Mini Card Solid State Drive
M.2 (NGFF) 2280 Solid State Drive
128 GB SATA-3 Value Solid State Drive
256 GB SATA-3 Value Solid State Drive
HP ProBook 450 and 470 G4
Hard Drives
Supports SATA, 7mm/9.5mm, 2.5" Hard Drives
500 GB (5400 rpm) SSHD (Hybrid) (8 GB Cache)
500 GB (7200) rpm Hard Drive
1 TB (5400 rpm) Hard Drive
2 TB (5400 rpm) Hard Drive
Mini Card Solid State Drive
M.2 (NGFF) 2280 Solid State Drive
128 GB SATA-3 Value Solid State Drive
256 GB SATA-3 Value Solid State Drive
Dual Solid State Drive
256 GB + 256 GB SATA-3 Value Solid State Drive
HP 3D DriveGuard (Windows only)
The hard drive is mounted directly to the notebook frame, reducing the transmission of shock to the hard drive
NOTE: For Solid State Drives or Hard Drives, GB = 1 billion bytes. TB = 1 trillion bytes. Actual formatted capacity is less. Up to
30 GB (for Windows 10) is reserved for system recovery software.
STORAGE AND DRIVES
QuickSpecs
HP ProBook 430 G4 Notebook PC
HP ProBook 440 G4 Notebook PC
HP ProBook 450 G4 Notebook PC
HP ProBook 470 G4 Notebook PC
Features
Not all configuration components are available in all regions/countries.
Americas – HP ProBook 430, 440, 450 & 470 G4 Notebook PC – October 2016 - c05254141
Page 15
HP ProBook 430 and 440
External
Support Optional1 External USB Drive CD/DVD R/RW
HP ProBook 4503 and 4703
Fixed Optional1 Optical Drive
9.0 mm SATA:
DVD-ROM1
DVD+/-RW SuperMulti DL Drive
1,2
Weight saver3
1. Sold separately as an optional feature,
2. For Blu-ray drives, certain disc, digital connection, compatibility and/or performance issues may arise, and do not
constitute defects in the product. Flawless playback on all systems is not guaranteed. In order for some Blu-ray titles to
play, they may require an HDMI digital connection and your display may require HDCP support. HD-DVD disks cannot be
played on this drive. Note that DVD-RAM cannot read or write to 2.6 GB Single Sided/5.2 GB Double Sided – Version 1.0
media. Actual speeds may vary. Don’t copy copyright-protected materials. Double Layer discs can store more data than
single layer discs; discs burned with this drive may not be compatible with many existing single-layer DVD drives and
players.
3. No Optical option (weight saver) supported
Two SODIMM slots:
Both slots are customer accessible / upgradeable
DDR4 PC4 SODIMMS, system runs at 2133
Supports Dual Channel Memory
Standard
4 GB Total System Memory (4 GB x 1)
8 GB Total System Memory (4 GB x 2) (Dual Channel)
8 GB Total System Memory (8 GB x 1)
16 GB Total System Memory (8 GB x 2) (Dual Channel)
Maximum
Up to 16 GB (8GBx2)
Dual-channel
Maximized dual-channel performance requires SODIMMs of the same size and speed in both memory slots.
NOTE: Due to the non-industry standard nature of some third-party memory modules, we recommend HP branded memory
to ensure compatibility. If you mix memory speeds, the system will perform at the lower memory speed. With Windows
Starter 32-bit operating systems, the amount of usable memory is dependent upon your configuration, so that above 3 GB all
memory may not be available due to system resource requirements.
OPTICAL DRIVES
MEMORY
QuickSpecs
HP ProBook 430 G4 Notebook PC
HP ProBook 440 G4 Notebook PC
HP ProBook 450 G4 Notebook PC
HP ProBook 470 G4 Notebook PC
Features
Not all configuration components are available in all regions/countries.
Americas – HP ProBook 430, 440, 450 & 470 G4 Notebook PC – October 2016 - c05254141
Page 16
HP ProBook 430
Wireless LAN (WLAN)
1,2
Realtek 802.11b/g/n (1x1) and Bluetooth® 4.0 Combo
Intel® Dual Band Wireless-AC 3168 802.11a/b/g/n/ac (1x1) WiFi and Bluetooth® 4.2 Combo
Intel® Dual Band Wireless-AC 8265 802.11a/b/g/n/ac (2x2) WiFi and Bluetooth® 4.2 Combo (non-vPro)
Intel® Dual Band Wireless-AC 7265 802.11a/b/g/n/ac (2x2) WiFi and Bluetooth® 4.2 Combo (non-vPro)
HP ProBook 440 G4
Wireless LAN (WLAN)
1,2
Realtek 802.11b/g/n (1x1) and Bluetooth® 4.0 Combo
Intel® Dual Band Wireless-AC 3168 802.11a/b/g/n/ac (1x1) WiFi and Bluetooth® 4.2 Combo
Intel® Dual Band Wireless-AC 8265 802.11a/b/g/n/ac (2x2) WiFi and Bluetooth® 4.2 Combo (non-vPro)
Intel® Dual Band Wireless-AC 7265 802.11a/b/g/n/ac (2x2) WiFi and Bluetooth® 4.2 Combo (non-vPro)
HP ProBook 450 G4
Wireless LAN (WLAN)
1
Realtek 802.11b/g/n (1x1) and Bluetooth® 4.0 Combo
Intel® Dual Band Wireless-AC 3168 802.11a/b/g/n/ac (1x1) WiFi and Bluetooth® 4.2 Combo
Intel® Dual Band Wireless-AC 8265 802.11a/b/g/n/ac (2x2) WiFi and Bluetooth® 4.2 Combo (non-vPro)
Intel® Dual Band Wireless-AC 7265 802.11a/b/g/n/ac (2x2) WiFi and Bluetooth® 4.2 Combo (non-vPro)
HP ProBook 470 G4
Wireless LAN (WLAN)
1,2
Realtek 802.11b/g/n (1x1) and Bluetooth® 4.0 Combo
Intel® Dual Band Wireless-AC 3168 802.11a/b/g/n/ac (1x1) WiFi and Bluetooth® 4.2 Combo
Intel® Dual Band Wireless-AC 8265 802.11a/b/g/n/ac (2x2) WiFi and Bluetooth® 4.2 Combo (non-vPro)
Intel® Dual Band Wireless-AC 7265 802.11a/b/g/n/ac (2x2) WiFi and Bluetooth® 4.2 Combo (non-vPro)
1. Wireless access point and Internet service required and sold separately. Availability of public wireless access points
limited. The specifications for the 802.11ac WLAN are draft specifications and are not final. If the final specifications
differ from the draft specifications, it may affect the ability of the notebook to communicate with other 802.11ac
WLAN devices.
2. Sold separately or as an optional feature.
Communications
Realtek RTL8111HSH (10/100/1000)
NOTE: The term "10/100/1000" or "Gigabit" Ethernet indicates compatibility with IEEE standard 802.3ab for Gigabit Ethernet,
and does not connote actual operating speed of 1 Gb/s. For high-speed transmission, connection to a Gigabit Ethernet server
and network infrastructure is required.
NETWORKING/COMMUNICATIONS
AUDIO/MULTIMEDIA
QuickSpecs
HP ProBook 430 G4 Notebook PC
HP ProBook 440 G4 Notebook PC
HP ProBook 450 G4 Notebook PC
HP ProBook 470 G4 Notebook PC
Features
Not all configuration components are available in all regions/countries.
Americas – HP ProBook 430, 440, 450 & 470 G4 Notebook PC – October 2016 - c05254141
Page 17
Audio
Two stereo speakers
Integrated microphone (dual-microphone array when equipped with optional webcam)
Headphone/microphone combo jack
Webcam
Optional1 720p HD2 webcam3
1. Sold separately as an optional feature.
2. HD content required to view HD images.
3. Internet access required.
HP Premium Keyboard
The HP spill-resistant keyboard is designed using a thin layer of Mylar film under the keyboard. The 101/102-key compatible
keyboard features a full-pitch key layout with desktop keyboard features, such as editing keys, both left and right control and
alt keys, and function keys. US and International key layouts are available.
NOTE 1: Includes a separate numeric keypad (HP ProBook 450 and 470 only.)
NOTE 2: Backlit keyboard available as an option.
Buttons and Function Keys
Separate launch buttons provide easy access to wireless on/off and speaker mute. Function keys provide control of features
including: standby mode, display brightness, external display, microphone mute, volume down, volume up, and backlight
toggle for backlit keyboard (select models only).
Function Keys
ESC: system information
F1 - Sleep
F2 - Blank
F3 - Backlight Toggle (for backlit keyboard) or Blank
F4 - Display Switching
F5 - Brightness Down
F6 - Brightness Up
F7 - Blank
F8 - Volume Down
F9 - Volume Up
F10 - Mic Mute
F11 - Blank
F12 – NumLock (430/440); Blank (450/470)
Hidden Fuctions
o Fn+R = Break
o Fn+S = Sys Rq
o Fn+C = Scroll Lock
Pointing Devices
Clickpad with gestures support, two-way scroll
KEYBOARDS/POINTING DEVICES/BUTTONS & FUNCTION KEYS
QuickSpecs
HP ProBook 430 G4 Notebook PC
HP ProBook 440 G4 Notebook PC
HP ProBook 450 G4 Notebook PC
HP ProBook 470 G4 Notebook PC
Features
Not all configuration components are available in all regions/countries.
Americas – HP ProBook 430, 440, 450 & 470 G4 Notebook PC – October 2016 - c05254141
Page 18
Touchpad
Taps enabled as default
Gestures
Enabled by default Win 10
2 Finger Scrolling
2 Finger Zoom (Pinch)
OSD (enable/disable)
3 finger tap = Cortana
3 finger flick = App switch
4 finger tap = Action Center
Disabled by default Win 10
3 Finger Flick
2 Finger Rotate
Momentum Motion
1 Finger Vertical Scroll
BIOS
HP BIOSphere1
HP DriveLock | HP Automatic DriveLock
HP BIOS Protection2
BIOS Update via Network
Master Boot Record Security
Power On Authentication
Pre-Boot Security
Secure Erase
3
Hybrid Boot
Measure Boot
Secure Boot
Absolute Persistence Module4
Multi Media
Cyberlink Power Media Player12
Native Miracast Support5
Communication
HP Mobile Connect
6,11
HP Value Add Software
HP 3D DriveGuard
HP ePrint Driver7
HP Hotkey Support
SOFTWARE AND SECURITY
QuickSpecs
HP ProBook 430 G4 Notebook PC
HP ProBook 440 G4 Notebook PC
HP ProBook 450 G4 Notebook PC
HP ProBook 470 G4 Notebook PC
Features
Not all configuration components are available in all regions/countries.
Americas – HP ProBook 430, 440, 450 & 470 G4 Notebook PC – October 2016 - c05254141
Page 19
HP Recovery Manager
HP Support Assistant
Microsoft Products
Buy Office
Bing Search
Skype for Business certification8
Manageability
HP Driver Packs9
HP SoftPaq Download Manager (SDM)
HP System Software Manager (SSM)9
HP BIOS Config Utility (BCU)9
HP Client Catalog9
HP CIK for Microsoft SCCM9
LANDESK Management
10
For more information on HP Client Management Solutions, refer to: www.hp.com/go/clientmanagement.
Client Security Software
HP Security Manager
Microsoft Defender
Standard
TPM 2.0 (1.2 optional)
HP Fingerprint Reader
Security lock slot
Pre-boot Authentication
For more information on HP Client Security Software Suite, refer to www.hp.com/go/clientsecurity.
1 Available only on business PCs with HP BIOS. HP BIOSphere features may vary depending on the PC platform &
configuration.
2 May require a manual recovery step if all copies of BIOS are compromised or deleted. BIOS adheres to NIST SP800-147.
3 For the methods outlined in the National Institute of Standards and Technology Special Publication 800-88.
4 Absolute agent is shipped turned off, and will be activated when customers activate a purchased subscription.
Subscriptions can be purchased for terms ranging multiple years. Service is limited, check with Absolute for availability
outside the U.S. The Absolute Recovery Guarantee is a limited warranty. Certain conditions apply. For full details visit:
http://www.absolute.com/company/legal/agreements/ computrace-agreement. Data Delete is an optional service
provided by Absolute Software. If utilized, the Recovery Guarantee is null and void. In order to use the Data Delete
service, customers must first sign a Pre-Authorization Agreement and either obtain a PIN or purchase one or more RSA
SecurID tokens from Absolute Software.
5 Miracast is a wireless technology your PC can use to project your screen to TVs, projectors, and streaming media players that also
support Miracast. You can use Miracast to share what you’re doing on your PC and present a slide show. For more information:
http://windows.microsoft.com/en-us/windows-8/project-wireless-screen-miracast
6 HP Mobile Connect is only available on preconfigured devices with WWAN. For geographic availability refer to
www.hp.com/go/mobileconnect
7 Requires an Internet connection to HP web-enabled printer and HP ePrint account registration (for a list of eligible printers,
supported documents and image types and other HP ePrint details, see www.hp.com/go/eprintcenter). Requires optional broadband
QuickSpecs
HP ProBook 430 G4 Notebook PC
HP ProBook 440 G4 Notebook PC
HP ProBook 450 G4 Notebook PC
HP ProBook 470 G4 Notebook PC
Features
Not all configuration components are available in all regions/countries.
Americas – HP ProBook 430, 440, 450 & 470 G4 Notebook PC – October 2016 - c05254141
Page 20
module. Broadband use requires separately purchased service contract. Check with service provider for coverage and availability in
your area. Separately purchased data plans or usage fees may apply. Print times and connection speeds may vary.
8 Skype is not offered in China.
9 Not preinstalled, however available on manageability website.
10 Subscription required.
11 Not supported in HP ProBook 470 G4
12 Not supported in HP ProBook 430 and 440 G4. Only available with optical drive.
QuickSpecs
HP ProBook 430 G4 Notebook PC
HP ProBook 440 G4 Notebook PC
HP ProBook 450 G4 Notebook PC
HP ProBook 470 G4 Notebook PC
Features
Not all configuration components are available in all regions/countries.
Americas – HP ProBook 430, 440, 450 & 470 G4 Notebook PC – October 2016 - c05254141
Page 21
Power Supply
HP ProBook 430
45 W Smart AC adapter
HP ProBook 440 /450 G4
45 W Smart AC adapter
65 W Smart AC adapter
HP ProBook 470 G4
65 W Smart AC adapter
Battery
HP 3-cell, Long Life 48 WHr Li-ion
NOTE: Battery is internal and not replaceable by customer.
Battery life1
Platform
Other HW Details
Battery
SSD
HDD
HP Probook 430 G4
Optimal SKU
3 cell (48Whr)
Up to 16 hrs
Up to 13 hrs and 15 mins
HP Probook 440 G4
Optimal SKU
3 cell (48Whr)
Up to 15 hrs and 30 mins
Up to 12 hrs and 30 mins
HP Probook 450 G4
Optimal SKU
3 cell (48Whr)
Up to 14 hrs and 15 mins
Up to 12 hrs
HP Probook 470 G4
Optimal SKU
3 cell (48Whr)
Up to 12 hrs and 45 mins
Up to 11 hrs
1. Windows 10/MM14 battery life will vary depending on various factors including product model, configuration, loaded
applications, features, use, wireless functionality, and power management settings. The maximum capacity of the battery
will naturally decrease with time and usage. See www.bapco.com for additional details
HP ProBook 430 G4
Weight
Starting at 1.49 kg (3.28 lbs)
Dimensions (w x d x h)
Non-Touch
33 x 23.35 x 1.98 cm (front to rear)
12.99 x 9.19 x 0.78 in (front to rear)
Touch
33.02 x 23.38 x 2.13 cm
13 x 9.20 x 0.84 in
HP ProBook 44O G4
Weight
Starting at 1.64 kg (3.61 lbs)
POWER
WEIGHTS & DIMENSIONS
QuickSpecs
HP ProBook 430 G4 Notebook PC
HP ProBook 440 G4 Notebook PC
HP ProBook 450 G4 Notebook PC
HP ProBook 470 G4 Notebook PC
Features
Not all configuration components are available in all regions/countries.
Americas – HP ProBook 430, 440, 450 & 470 G4 Notebook PC – October 2016 - c05254141
Page 22
Dimensions (w x d x h)
Non-Touch
34.32 x 23.90 x 2.03 cm
13.51 x 9.41 x 0.80 in
Touch
34.34 x 23.94 x 2.19 cm
13.52 x 9.43 x 0.86 in
HP ProBook 45O G4
Weight
Starting at 2.04 kg (4.49 lbs)
Dimensions (w x d x h)
Non-Touch
38.20 x 26.30 x 2.44 cm
15.04 x 10.35 x 0.96 in
Touch
38.22 x 26.35 x 2.61 cm
15.05 x 10.37 x 1.03 in
HP ProBook 47O G4
Weight
Starting at 2.63 kg (5.79 lbs)
Dimensions (w x d x h)
Non-Touch
41.68 x 28 x 2.58 cm
16.41 x 11.02 x 1.02 in
NOTE: Height varies depending upon where on the notebook the measurement is made.
Weight varies by configuration and components.
Ports
430/440
1 USB 3.0
1 USB 2.0 (power port)
1 USB Type-C™
1 HDMI
1 headphone/microphone combo
1 AC power
1 RJ-45
1 VGA
450/470
1 USB 3.0
2 USB 2.0
1 USB Type-C™
1 HDMI
1 headphone/microphone combo
PORTS/SLOTS
QuickSpecs
HP ProBook 430 G4 Notebook PC
HP ProBook 440 G4 Notebook PC
HP ProBook 450 G4 Notebook PC
HP ProBook 470 G4 Notebook PC
Features
Not all configuration components are available in all regions/countries.
Americas – HP ProBook 430, 440, 450 & 470 G4 Notebook PC – October 2016 - c05254141
Page 23
1 AC power
1 RJ-45
1 VGA
NOTE: All cables are not included and sold separately.
Digital Media Slots
Multi Media Reader Slot
Supports SD, SDHC, SDXC
HP Services offers 3-year and 1-year limited warranties and 90-day software limited warranty options depending
on country. Batteries have a default one year limited warranty except for Long Life batteries which will have same
1-year or 3-year limited warranty as the platform. On-site service and extended coverage is also available. HP Care
Pack Services
1,2
are optional extended service contracts that go beyond the standard limited warranties. To choose
the right level of service for your HP product, use the HP Care Pack Services Lookup Tool at
http://www.hp.com/go/cpc.
1. Sold separately or as an optional feature.
2. Service levels and response times for HP Care Packs may vary depending on your geographic location. Service starts
on date of hardware purchase. Restrictions and limitations apply. HP services are governed by the applicable HP
terms and conditions of service provided or indicated to Customer at the time of purchase. Customer may have
additional statutory rights according to applicable local laws, and such rights are not in any way affected by the HP
terms and conditions of service or the HP Limited Warranty provided with your HP Product. To choose the right level
of service for your HP product, use the HP Care Pack Services Lookup Tool at: http://www.hp.com/go/cpc.
SERVICE AND SUPPORT
QuickSpecs
HP ProBook 430 G4 Notebook PC
HP ProBook 440 G4 Notebook PC
HP ProBook 450 G4 Notebook PC
HP ProBook 470 G4 Notebook PC
Technical Specifications
Not all configuration components are available in all regions/countries.
Americas – HP ProBook 430, 440, 450 & 470 G4 Notebook PC – October 2016 - c05254141
Page 24
Stand-Alone Power
Requirements (AC Power)
Nominal Operating Voltage
19 V
Average Operating Power
Win 10
ProBook 430
Integrated graphics
6.78W
ProBook 440
Integrated graphics
6.78W
Discrete graphics
4.49W
ProBook 450
Integrated graphics
8.89W
Discrete graphics
6.79W
ProBook 470
Discrete graphics
5.71W
Max Operating Power
Discrete < 65W
UMA < 45W
Temperature
Operating
32° to 95° F (0° to 35° C) (not writing optical)
41° to 95° F (5° to 35° C) (writing optical)
Non-operating
-4° to 140° F (-20° to 60° C)
Relative Humidity
Operating
10% to 90%, non-condensing
Non-operating
5% to 95%, 101.6° F (38.7° C) maximum wet bulb temperature
Shock
Operating
40 G, 2 ms, half-sine
Non-operating
200 G, 2 ms, half-sine
Random Vibration
Operating
0.75 grms
Non-operating
1.50 grms
Altitude (unpressurized)
Operating
-50 to 10,000 ft (-15.24 to 3,048 m)
Non-operating
-50 to 40,000 ft (-15.24 to 12,192 m)
Planned Industry Standard
Certifications
UL
Yes
CSA
Yes
FCC Compliance
Yes
ENERGY STAR 6.0®
Select models1
EPEAT
Registered Gold in United States2
ICES
Yes
Australia /
NZ A-Tick Compliance
Yes
CCC
Yes
Japan VCCI Compliance
Yes
KC
Yes
BSMI
Yes
CE Marking Compliance
Yes
BNCI or BELUS
Yes
CIT
Yes
GOST
Yes
Saudi Arabian Compliance (ICCP)
Yes
SABS
Yes
SYSTEM UNIT
QuickSpecs
HP ProBook 430 G4 Notebook PC
HP ProBook 440 G4 Notebook PC
HP ProBook 450 G4 Notebook PC
HP ProBook 470 G4 Notebook PC
Technical Specifications
Not all configuration components are available in all regions/countries.
Americas – HP ProBook 430, 440, 450 & 470 G4 Notebook PC – October 2016 - c05254141
Page 25
UKRSERTCOMPUTER
Yes
1. Configurations of the HP ProBook 430 G4, HP ProBook 440 G4, HP ProBook 450 G4 and HP ProBook 470 G4 that are
ENERGY STAR® qualified are identified as HP ProBook 430 G4 ENERGY STAR, HP ProBook 440 G4 ENERGY STAR, HP
ProBook 450 G4 ENERGY STAR and HP ProBook 470 G4 ENERGY STAR on HP websites and on http://www.energystar.gov.
2. EPEAT® registration varies by country. See http://www.epeat.net for registration status by country. EPEAT status listed
above applies to U.S. For accessibility information on HP products, please visit: http://www.hp.com/accessibility.
Panel LCD 13.3 FHD AG
WLED UWVA 45%cg
220nitsnits eDP Ultraslim
2.85mm
Active Area (W x H)
293.47 x 165.08 mm
Dimensions (W x H)
306.8x195.7
Diagonal Size
13.3 (inch)
Thickness
2.85mm max.
Weight
260 g max
Interface
eDP 1.2
Surface Treatment
Anti-Glare (AG)
Contrast Ratio
600:1 (typical)
Refresh Rate
60 Hz
Brightness
220 nits
Pixel Resolution - Format
1920 x 1080 (FHD)
Pixel Resolution - Configuration
RGB
Backlight
LED
Color Gamut Coverage
45%
Color Depth
6 bits + Hi FRC
Viewing Angle
UWVA 85/85/85/85
Touch Point Supported
N/A
Other Features
N/A
Pen Enabled
No
Panel LCD 13.3 HD AG WLED
SVA 45%cg 220nits eDP
Slim
Active Area (W x H)
293.42 x 164.97 (mm)
Dimensions (W x H)
314.6 x 189.2 (mm) max
Diagonal Size
13.3 (inch)
Thickness
3.0 (mm) max
Weight
260 g max
Interface
eDP 1.2
Surface Treatment
Anti-Glare (AG)
Contrast Ratio
300:1 (typical)
Refresh Rate
60 Hz
Brightness
220 nits
Pixel Resolution - Format
1366 x 768 (HD)
Pixel Resolution - Configuration
RGB
Backlight
LED
DISPLAYS
QuickSpecs
HP ProBook 430 G4 Notebook PC
HP ProBook 440 G4 Notebook PC
HP ProBook 450 G4 Notebook PC
HP ProBook 470 G4 Notebook PC
Technical Specifications
Not all configuration components are available in all regions/countries.
Americas – HP ProBook 430, 440, 450 & 470 G4 Notebook PC – October 2016 - c05254141
Page 26
Color Gamut Coverage
45%
Color Depth
6 bits + Hi FRC
Viewing Angle
SVA 45/45/25/35
Touch Point Supported
10-point multi-touch
Other Features
AS
Pen Enabled
No
Panel LCD 14.0 FHD AG
WLED SVA 45%cg 220nits
eDP Slim
Active Area (W x H)
309.40 x 173.89 (mm)
Dimensions (W x H)
320.9 x 205.6 (mm) max
Diagonal Size
14 (inch)
Thickness
3.0 (mm) max
Weight
290 g max
Interface
eDP 1.2
Surface Treatment
Anti-Glare (AG)
Contrast Ratio
300:1 (typical)
Refresh Rate
60 Hz
Brightness
220 nits
Pixel Resolution - Format
1920 x 1080 (FHD)
Pixel Resolution - Configuration
RGB
Backlight
LED
Color Gamut Coverage
45%
Color Depth
6 bits + Hi FRC
Viewing Angle
SVA 45/45/25/35
Touch Point Supported
N/A
Other Features
N/A
Pen Enabled
No
QuickSpecs
HP ProBook 430 G4 Notebook PC
HP ProBook 440 G4 Notebook PC
HP ProBook 450 G4 Notebook PC
HP ProBook 470 G4 Notebook PC
Technical Specifications
Not all configuration components are available in all regions/countries.
Americas – HP ProBook 430, 440, 450 & 470 G4 Notebook PC – October 2016 - c05254141
Page 27
Panel LCD 14.0 HD AG WLED
SVA 45%cg 220nits eDP
Slim
Active Area (W x H)
309.40 x 173.95 (mm)
Dimensions (W x H)
320.9 x 205.6 (mm) max
Diagonal Size
14 (inch)
Thickness
3.0 (mm) max
Weight
290 g max
Interface
eDP 1.2
Surface Treatment
Anti-Glare (AG)
Contrast Ratio
300:1 (typical)
Refresh Rate
60 Hz
Brightness
220 nits
Pixel Resolution - Format
1366 x 768 (HD)
Pixel Resolution - Configuration
RGB
Backlight
LED
Color Gamut Coverage
45%
Color Depth
6 bits + Hi FRC
Viewing Angle
SVA 40/40/15/30
Touch Point Supported
10-point multi-touch
Other Features
AS
Pen Enabled
No
Panel LCD 15.6 FHD AG
WLED SVA 45%cg 220nits
eDP Slim
Active Area (W x H)
344.2 x 193.5 (mm)
Dimensions (W x H)
360 x 224.3 (mm) max
Diagonal Size
15.6 (inch)
Thickness
3.2 (mm) max
Weight
370 g max
Interface
eDP 1.2
Surface Treatment
Anti-Glare (AG)
Contrast Ratio
300:1 (typical)
Refresh Rate
60 Hz
Brightness
220 nits
Pixel Resolution - Format
1920 x 1080 (FHD)
Pixel Resolution - Configuration
RGB
Backlight
LED
Color Gamut Coverage
45%
Color Depth
6 bits + Hi FRC
Viewing Angle
SVA 45/45/25/35
Touch Point Supported
N/A
Other Features
N/A
QuickSpecs
HP ProBook 430 G4 Notebook PC
HP ProBook 440 G4 Notebook PC
HP ProBook 450 G4 Notebook PC
HP ProBook 470 G4 Notebook PC
Technical Specifications
Not all configuration components are available in all regions/countries.
Americas – HP ProBook 430, 440, 450 & 470 G4 Notebook PC – October 2016 - c05254141
Page 28
Pen Enabled
No
Panel LCD 15.6 HD AG WLED
SVA 45%cg 220nits eDP
Slim
Active Area (W x H)
344.2 x 193.5 (mm)
Dimensions (W x H)
360 x 224.3 (mm) max
Diagonal Size
15.6 (inch)
Thickness
3.2 (mm) max
Weight
370 g max
Interface
eDP 1.2
Surface Treatment
Anti-Glare (AG)
Contrast Ratio
300:1 (typical)
Refresh Rate
60 Hz
Brightness
220 nits
Pixel Resolution - Format
1366 x 768 (HD)
Pixel Resolution - Configuration
RGB
Backlight
LED
Color Gamut Coverage
45%
Color Depth
6 bits + Hi FRC
Viewing Angle
SVA 45/45/25/35
Touch Point Supported
10-point multi-touch
Other Features
AS
Pen Enabled
No
Panel LCD 17.3 FHD AG
WLED UWVA 72%cg 300nits
eDP Flat 4.0mm
Active Area (W x H)
381.89 x 214.81 (mm)
Dimensions (W x H)
400 x 233.3 (mm) max
Diagonal Size
17.3 (inch)
Thickness
4.0 (mm) max
Weight
550 g max
Interface
eDP 1.3
Surface Treatment
Anti-Glare (AG)
Contrast Ratio
600:1 (typical)
Refresh Rate
60 Hz
Brightness
300 nits
Pixel Resolution - Format
1920 x 1080 (FHD)
Pixel Resolution - Configuration
RGB
Backlight
LED
Color Gamut Coverage
72%
Color Depth
6 bits + Hi FRC
Viewing Angle
UWVA 85/85/85/85
QuickSpecs
HP ProBook 430 G4 Notebook PC
HP ProBook 440 G4 Notebook PC
HP ProBook 450 G4 Notebook PC
HP ProBook 470 G4 Notebook PC
Technical Specifications
Not all configuration components are available in all regions/countries.
Americas – HP ProBook 430, 440, 450 & 470 G4 Notebook PC – October 2016 - c05254141
Page 29
Touch Point Supported
N/A
Other Features
N/A
Pen Enabled
No
Panel LCD 17.3 HD+ AG
WLED SVA 60%cg 220nits
eDP Flat
Active Area (W x H)
382.08 x 214.92 (mm)
Dimensions (W x H)
398.6 x 251 (mm) max
Diagonal Size
17.3 (inch)
Thickness
4.0 (mm) max
Weight
550 g max
Interface
eDP 1.3
Surface Treatment
Anti-Glare (AG)
Contrast Ratio
300:1 (typical)
Refresh Rate
60 Hz
Brightness
220 nits
Pixel Resolution - Format
1600 x 900 (HD+)
Pixel Resolution - Configuration
RGB
Backlight
LED
Color Gamut Coverage
60%
Color Depth
6 bits + Hi FRC
Viewing Angle
SVA 45/45/25/35
Touch Point Supported
N/A
Other Features
N/A
Pen Enabled
No
QuickSpecs
HP ProBook 430 G4 Notebook PC
HP ProBook 440 G4 Notebook PC
HP ProBook 450 G4 Notebook PC
HP ProBook 470 G4 Notebook PC
Technical Specifications
Not all configuration components are available in all regions/countries.
Americas – HP ProBook 430, 440, 450 & 470 G4 Notebook PC – October 2016 - c05254141
Page 30
500 GB* 5400 rpm SMART
SATA Hybrid HDD/SSHD
Drive Weight
0.20 lbs (92 g) ~ 0.21 lbs (95 g)
Rotation Speed
5400 rpm
Cache Buffer
64 MB
NAND Type/Size
TLC/8GB
Height
0.28 in (7 mm)
Width
2.75 in (69.85 mm)
Interface
ATA-8, SATA 3.0
Interface Transfer Rate
600 MB/s
Seek Time
Single Track
2 ms
Average
12 ms
Maximum
22 ms
Logical Blocks
976,773,168
Operating Temperature
32° to 140° F (0° to 60° C) [top cover temp]
Security Features
ATA Security
Other Features
S.M.A.R.T., NCQ, Ultra DMA
500 GB* 7200 rpm SATA
Hard Drive
Drive Weight
0.20 lbs (92 g) ~ 0.21 lbs (95 g)
Rotation Speed
7200 rpm
Cache Buffer
Up to 32 MB
NAND Type/Size
N/A
Height
0.28 in (7 mm)
Width
2.75 in (69.85 mm)
Interface
ATA-8, SATA 3.0
Interface Transfer Rate
600 MB/s
Seek Time
Single Track
2 ~ 1.5 ms
Average
11 ~ 13 ms
Maximum
18 ~ 22 ms
Logical Blocks
976,773,168
Operating Temperature
32° to 140° F (0° to 60° C) [top cover temp]
Security Features
ATA Security
Other Features
S.M.A.R.T., NCQ, Ultra DMA
1TB* 5400 rpm 9.5mm
SATA Hard Drive
Drive Weight
0.25 lbs (115 g) ~ 0.22 lbs (102 g)
Rotation Speed
5400 rpm
Cache Buffer
8 MB
NAND Type/Size
N/A
STORAGE AND DRIVES
HARD DRIVES
QuickSpecs
HP ProBook 430 G4 Notebook PC
HP ProBook 440 G4 Notebook PC
HP ProBook 450 G4 Notebook PC
HP ProBook 470 G4 Notebook PC
Technical Specifications
Not all configuration components are available in all regions/countries.
Americas – HP ProBook 430, 440, 450 & 470 G4 Notebook PC – October 2016 - c05254141
Page 31
Height
0.37 in (9.5 mm)
Width
2.75 in (69.85 mm)
Interface
ATA-8, SATA 3.0
Interface Transfer Rate
600 MB/s
Seek Time
Single Track
2 ms
Average
13 ms
Maximum
15 ~ 22 ms
Logical Blocks
1,953,525,168
Operating Temperature
32° to 140° F (0° to 60° C) [top cover temp]
Security Features
ATA Security
Other Features
S.M.A.R.T., NCQ, Ultra DMA
1TB* 5400 rpm 7mm SATA
Hard Drive
Drive Weight
0.21 lbs (94 g)
Rotation Speed
5400 rpm
Cache Buffer
Up to 32 MB
NAND Type/Size
N/A
Height
0.28 in (7.2 mm)
Width
2.75 in (69.85 mm)
Interface
ATA-8, SATA 3.0
Interface Transfer Rate
600 MB/s
Seek Time
Single Track
2 ms
Average
12 ~ 13 ms
Maximum
18 ~ 22 ms
Logical Blocks
1,953,525,168
Operating Temperature
32° to 140° F (0° to 60° C) [top cover temp]
Security Features
ATA Security
Other Features
S.M.A.R.T., NCQ, Ultra DMA
2TB 5400 rpm 9.5mm SATA
Hard Drive
Drive Weight
0.29lbs (130 g)
Rotation Speed
5400 rpm
Cache Buffer
32 MB
NAND Type/Size
N/A
Height
0.37 in (9.5 mm)
Width
2.75 in (69.85 mm)
Interface
ATA-8, SATA 3.0
Interface Transfer Rate
600 MB/s
Seek Time
Single Track
2 ms
Average
12 ms
Maximum
22 ms
QuickSpecs
HP ProBook 430 G4 Notebook PC
HP ProBook 440 G4 Notebook PC
HP ProBook 450 G4 Notebook PC
HP ProBook 470 G4 Notebook PC
Technical Specifications
Not all configuration components are available in all regions/countries.
Americas – HP ProBook 430, 440, 450 & 470 G4 Notebook PC – October 2016 - c05254141
Page 32
Logical Blocks
3,907,029,168
Operating Temperature
32° to 140° F (0° to 60° C) [top cover temp]
Security Features
ATA Security
Other Features
S.M.A.R.T., NCQ, Ultra DMA
SOLID STATE DRIVES
QuickSpecs
HP ProBook 430 G4 Notebook PC
HP ProBook 440 G4 Notebook PC
HP ProBook 450 G4 Notebook PC
HP ProBook 470 G4 Notebook PC
Technical Specifications
Not all configuration components are available in all regions/countries.
Americas – HP ProBook 430, 440, 450 & 470 G4 Notebook PC – October 2016 - c05254141
Page 33
SSD 128GB 2280 M2 SATA-3
Value
Form-Factor (I/O)
M.2 2280
Capacity
128 GB
NAND Type
TLC
Weight
0.01 lb (6 g) ~ 0.02 lb (10 g)
Height
0.09 in (2.3 mm)
Width
0.87 in (22 mm)
Interface
ATA-8, SATA 3.0
Sequential Read (Up to MB/s)
530 ~ 535
Sequential Write (Up to MB/s)
185 ~ 515
Logical Blocks
250,069,680
Operating Temperature
32° to 158°F (0° to 70°C) [ambient temp]
Security Features
ATA Security
Other Features
DIPM; TRIM; DEVSLP
SSD 256GB 2280 M2 SATA-3
Value
Form-Factor (I/O)
M.2 2280
Capacity
256 GB
NAND Type
TLC
Weight
0.01 lb (6 g) ~ 0.02 lb (10 g)
Height
0.09 in (2.3 mm)
Width
0.87 in (22 mm)
Interface
ATA-8, SATA 3.0
Sequential Read (Up to MB/s)
530 ~ 535
Sequential Write (Up to MB/s)
330 ~ 515
Logical Blocks
500,118,192
Operating Temperature
32° to 158°F (0° to 70°C) [ambient temp]
Security Features
ATA Security
Other Features
DIPM; TRIM; DEVSLP
SOLID STATE DRIVES
QuickSpecs
HP ProBook 430 G4 Notebook PC
HP ProBook 440 G4 Notebook PC
HP ProBook 450 G4 Notebook PC
HP ProBook 470 G4 Notebook PC
Technical Specifications
Not all configuration components are available in all regions/countries.
Americas – HP ProBook 430, 440, 450 & 470 G4 Notebook PC – October 2016 - c05254141
Page 34
DVD+/-RW SuperMulti
DL Drive
Access Times
Random
<140ms CD (typical)
< 160ms DVD (typical)
Weight
150g max.
Max Data Transfer Rate
24X CD-ROM
8X DVD-ROM
24X CD-R
10X CD-RW
8X DVD+R
8X DVD+RW
8X DVD-R
6X DVD-RW
6X - DVD+R Dual Layer
6X - DVD-R Dual Layer
5X DVD-RAM
Transfer Mode
UDMA Mode 5
Interface
Gen 1 SATA
Supported Media (read)
CD-DA, CD-TEXT, CD-ROM, CD-ROM XA, MIXED MODE CD, CD-I, CD-I Bridge
(Photo-CD, Video CD), Multisession CD (Photo-CD, CD-EXTRA, Portfolio, CDR, CD-RW), CD-R, CD-RW, DVD-ROM (DVD-5, DVD-9, DVD-10, DVD-18), DVDR, DVD-RW, DVD+R, DVD+RW, DVD-RAM
Supported Media (write)
CD-R, CD-RW, DVD+R, DVD+RW, DVD-R, DVD-RW, DVD-RAM, DVD+R DL,
DVD-R DL
Max Media Capacity
(read)
8.5 GB
Max Media Capacity
(write)
8.5 GB
Transport
Tray Loading
DVD-ROM Drive
Access Times
Random
< 140ms CD (typical)
< 160ms DVD (typical)
Max Data Transfer Rate
24X CD-ROM
8X-DVD
Transfer Mode
UDMA Mode 5
Interface
Gen 1 SATA
Supported Media (read)
CD-DA, CD-TEXT, CD-ROM, CD-ROM XA, MIXED MODE CD, CD-I, CD-I Bridge
(Photo-CD, Video CD), Multisession CD (Photo-CD, CD-EXTRA, Portfolio, CDR, CD-RW), CD-R, CD-RW, DVD-ROM (DVD-5, DVD-9, DVD-10, DVD-18), DVDR, DVD-RW, DVD+R, DVD+RW, DVD-RAM
Supported Media (write)
None
Max Media Capacity
(read)
8.5GB
OPTICAL DRIVES
QuickSpecs
HP ProBook 430 G4 Notebook PC
HP ProBook 440 G4 Notebook PC
HP ProBook 450 G4 Notebook PC
HP ProBook 470 G4 Notebook PC
Technical Specifications
Not all configuration components are available in all regions/countries.
Americas – HP ProBook 430, 440, 450 & 470 G4 Notebook PC – October 2016 - c05254141
Page 35
Transport
Tray Loading
QuickSpecs
HP ProBook 430 G4 Notebook PC
HP ProBook 440 G4 Notebook PC
HP ProBook 450 G4 Notebook PC
HP ProBook 470 G4 Notebook PC
Technical Specifications
Not all configuration components are available in all regions/countries.
Americas – HP ProBook 430, 440, 450 & 470 G4 Notebook PC – October 2016 - c05254141
Page 36
HP Synaptics
Fingerprint Reader
(optional)
Mobile Voltage Operation
3.0V-3.6V Single Supply
Operating Temperature
32° – 158°F (0° – 70°C)
Current Consumption @
3.3V
Less than 70 mA peak imaging and scrolling
Less than 25 mA hardware finger detection
Advanced Power Management
High-Rate Image Capture
Up to 240 image frames /sec
ESD Resistance
IEC 61000-4-2 Level 4 (±15KV)
Detection Matrix
200 pixel wide fingerpring image
16.5 mm x 3 mm sensor area
508 dpi resolution, 256 levels of grayscale
Realtek 802.11 b/g/n
(1x1) + Bluetooth® Combo
Wireless LAN Standards
IEEE 802.11b
IEEE 802.11g
IEEE 802.11n
Interoperability
Wi-Fi certified
Frequency Band
802.11b/g/n
2.402 – 2.482 GHz
Note:
The FCC has declared as of September 1, 2014 products that utilize
passive scanning on channel 12/13 and are capable of transmitting must
fully comply with requirements of 15.247 or otherwise disable those
channels.
Data Rates
802.11b: 1, 2, 5.5, 11 Mbps
802.11g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
802.11n: MCS 0 ~ MCS 07, (20MHz)
Modulation
Direct Sequence Spread Spectrum
BPSK, QPSK, CCK, 16-QAM, 64-QAM,
Security1
IEEE and WiFi compliant 64 / 128 bit WEP encryption for a/b/g
mode only
AES-CCMP: 128 bit in hardware
802.1x authentication
WPA, WPA2: 802.1x. WPA-PSK, WPA2-PSK, TKIP, and AES.
WPA2 certification
IEEE 802.11i
Cisco Certified Extensions, all versions through CCX4 and CCX Lite
WAPI
Network Architecture
Ad-hoc (Peer to Peer)
SECURITY
NETWORKING/COMMUNICATIONS
WLAN
QuickSpecs
HP ProBook 430 G4 Notebook PC
HP ProBook 440 G4 Notebook PC
HP ProBook 450 G4 Notebook PC
HP ProBook 470 G4 Notebook PC
Technical Specifications
Not all configuration components are available in all regions/countries.
Americas – HP ProBook 430, 440, 450 & 470 G4 Notebook PC – October 2016 - c05254141
Page 37
Models
Infrastructure (Access Point Required)
Roaming
IEEE 802.11 compliant roaming between access points
Output Power2
802.11b : +16dBm minimum
802.11g : +14dBm minimum
802.11a : +14dBm minimum
802.11n HT20(2.4GHz) : +13dBm minimum
802.11n HT40(2.4GHz) : +13dBm minimum
802.11n HT20(5GHz) : +12dBm minimum
802.11n HT40(5GHz) : +12dBm minimum
Power Consumption
Transmit: 2.0 W (max)
Receive: 1.6 W (max)
Idle mode (PSP): 180 mW (WLAN Associated)
Idle mode: 60 mW (WLAN unassociated)
Radio disabled: 30 mW
Power Management
ACPI and PCI Express compliant power management
802.11 compliant power saving mode
Receiver Sensitivity3
802.11b, 1Mbps : -94dBm maximum
802.11b, 11Mbps : -86dBm maximum
802.11g, 6Mbps : -88dBm maximum
802.11g, 54Mbps : -74dBm maximum
802.11a, 6Mbps : -86dBm maximum
802.11a, 54Mbps : -72dBm maximum
802.11n, MCS07 : -69dBm maximum
802.11n, MCS15 : -66dBm maximum
Antenna type
High efficiency antenna with spatial diversity, mounted in the display
enclosure
Two embedded 2.4 GHz antennas are provided to the card to support
WLAN and Bluetooth communications
(Support Dual antenna or Single antenna, depend on platform
requirement)
Form Factor
PCI-Express M.2 MiniCard
Dimensions
Type 2230 : 2.3 x 22.0 x 30.0 mm
Or
Type 1630 : 2.3 x 16.0 x 30.0 mm
Weight
Type 2230 : 2.8g
QuickSpecs
HP ProBook 430 G4 Notebook PC
HP ProBook 440 G4 Notebook PC
HP ProBook 450 G4 Notebook PC
HP ProBook 470 G4 Notebook PC
Technical Specifications
Not all configuration components are available in all regions/countries.
Americas – HP ProBook 430, 440, 450 & 470 G4 Notebook PC – October 2016 - c05254141
Page 38
Or
Type 1630 : 2g
Operating Voltage
3.3v +/- 9%
Temperature
Operating
Non-operating
14° to 158° F (–10° to 70° C)
–40° to 176° F (–40° to 80° C)
Humidity
Operating
Non-operating
10% to 90% (non-condensing)
5% to 95% (non-condensing)
Altitude
Operating
Non-operating
0 to 10,000 ft (3,048 m)
0 to 50,000 ft (15,240 m)
LED Activity
LED Amber – Radio OFF; LED White – Radio ON
1. Check latest software/driver release for updates on supported security features.
2. Maximum output power may vary by country according to local regulations.
3. Receiver sensitivity is measured at a packet error rate of 8% for 802.11b (CKK modulation)
and a packet error rate of 10% for 802.11a/g (OFDM modulation).
Intel 802.11 a/b/g/n/AC
(1x1) Bluetooth® Combo
Wireless LAN Standards
IEEE 802.11a
IEEE 802.11b
IEEE 802.11g
IEEE 802.11n
IEEE 802.11ac
Interoperability
Wi-Fi certified
Frequency Band
802.11b/g/n
2.402 – 2.482 GHz
Note:
The FCC has declared as of January 1, 2015 products that utilize
passive scanning on channel 12/13 and are capable of
transmitting must fully comply with requirements of 15.247 or
otherwise disable those channels.
802.11a/n
4.9 – 4.95 GHz (Japan)
5.15 – 5.25 GHz
5.25 – 5.35 GHz
5.47 – 5.725 GHz
5.825 – 5.850 GHz
Note:
Indonesia only supports 5.725 - 5.825 GHz (CH149 - CH161)
Data Rates
802.11b: 1, 2, 5.5, 11 Mbps
802.11g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
802.11a: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
802.11n: MCS 0 ~ MCS 15, (20MHz, and 40MHz)
802.11ac : MCS0 ~ MCS7, (1SS) (20MHz, 40MHz, and 80MHz)
Modulation
Direct Sequence Spread Spectrum
BPSK, QPSK, CCK, 16-QAM, 64-QAM, 256-QAM
QuickSpecs
HP ProBook 430 G4 Notebook PC
HP ProBook 440 G4 Notebook PC
HP ProBook 450 G4 Notebook PC
HP ProBook 470 G4 Notebook PC
Technical Specifications
Not all configuration components are available in all regions/countries.
Americas – HP ProBook 430, 440, 450 & 470 G4 Notebook PC – October 2016 - c05254141
Page 39
Security1
IEEE and WiFi compliant 64 / 128 bit WEP encryption for a/b/g
mode only
AES-CCMP: 128 bit in hardware
802.1x authentication
WPA, WPA2: 802.1x. WPA-PSK, WPA2-PSK, TKIP, and AES.
WPA2 certification
IEEE 802.11i
Cisco Certified Extensions, all versions through CCX4 and CCX Lite
WAPI
Network Architecture
Models
Ad-hoc (Peer to Peer)
Infrastructure (Access Point Required)
Roaming
IEEE 802.11 compliant roaming between access points
Output Power2
802.11b : +16dBm minimum
802.11g : +14dBm minimum
802.11a : +14dBm minimum
802.11n HT20(2.4GHz) : +14dBm minimum
802.11n HT40(2.4GHz) : +12dBm minimum
802.11n HT20(5GHz) : +14dBm minimum
802.11n HT40(5GHz) : +12dBm minimum
802.11ac 80MHz(5GHz) : +11dBm minimum
Power Consumption
Transmit: 2.0 W (max)
Receive: 1.6 W (max)
Idle mode (PSP): 180 mW (WLAN Associated)
Idle mode: 50 mW (WLAN unassociated)
Connect Standby: 10 mW (WLAN+BT)
Radio disabled: 5 mW
Power Management
ACPI and PCI Express compliant power management
802.11 compliant power saving mode
Receiver Sensitivity3
802.11b, 1Mbps : -94dBm maximum
802.11b, 11Mbps : -86dBm maximum
802.11g, 6Mbps : -88dBm maximum
802.11g, 54Mbps : -74dBm maximum
802.11a, 6Mbps : -88dBm maximum
802.11a, 54Mbps : -74dBm maximum
802.11n, MCS07 : -69dBm maximum
802.11n, MCS15 : -66dBm maximum
802.11ac, 1SS, MCS-0 : -86dBm maximum
802.11ac, 1SS, MCS-9 : -61dBm maximum
802.11ac, 2SS, MCS-0 : -83dBm maximum
802.11ac, 2SS, MCS-9 : -58dBm maximum
Antenna type
High efficiency antenna with spatial diversity, mounted in the display
enclosure
Two embedded dual band 2.4/5 GHz antennas are provided to the card to
support WLAN MIMO communications and Bluetooth communications
Form Factor
PCI-Express M.2 MiniCard
Dimensions
Type 2230 : 2.3 x 22.0 x 30.0 mm
Or
Type 1630 : 2.3 x 16.0 x 30.0 mm
QuickSpecs
HP ProBook 430 G4 Notebook PC
HP ProBook 440 G4 Notebook PC
HP ProBook 450 G4 Notebook PC
HP ProBook 470 G4 Notebook PC
Technical Specifications
Not all configuration components are available in all regions/countries.
Americas – HP ProBook 430, 440, 450 & 470 G4 Notebook PC – October 2016 - c05254141
Page 40
Weight
Type 2230 : 2.8g
Or
Type 1630 : 2g
Operating Voltage
3.3v +/- 9%
Temperature
Operating
Non-operating
14° to 158° F (–10° to 70° C)
–40° to 176° F (–40° to 80° C)
Humidity
Operating
Non-operating
10% to 90% (non-condensing)
5% to 95% (non-condensing)
Altitude
Operating
Non-operating
0 to 10,000 ft (3,048 m)
0 to 50,000 ft (15,240 m)
LED Activity
LED Amber – Radio OFF; LED White – Radio ON
4. Check latest software/driver release for updates on supported security features.
5. Maximum output power may vary by country according to local regulations.
6. Receiver sensitivity is measured at a packet error rate of 8% for 802.11b (CKK modulation)
and a packet error rate of 10% for 802.11a/g (OFDM modulation).
Intel 802.11 a/b/g/n/AC
(2x2) Bluetooth® 4.2
Combo
Wireless LAN Standards
IEEE 802.11a
IEEE 802.11b
IEEE 802.11g
IEEE 802.11n
IEEE 802.11ac
Interoperability
Wi-Fi certified
Frequency Band
802.11b/g/n
2.402 – 2.482 GHz
Note:
The FCC has declared as of January 1, 2015 products that utilize
passive scanning on channel 12/13 and are capable of
transmitting must fully comply with requirements of 15.247 or
otherwise disable those channels.
802.11a/n
4.9 – 4.95 GHz (Japan)
5.15 – 5.25 GHz
5.25 – 5.35 GHz
5.47 – 5.725 GHz
5.825 – 5.850 GHz
Note:
Indonesia only supports 5.725 - 5.825 GHz (CH149 - CH161)
Data Rates
802.11b: 1, 2, 5.5, 11 Mbps
802.11g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
802.11a: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
802.11n: MCS 0 ~ MCS 15, (20MHz, and 40MHz)
802.11ac : MCS0 ~ MCS7, (1SS) (20MHz, 40MHz, and 80MHz)
Modulation
Direct Sequence Spread Spectrum
BPSK, QPSK, CCK, 16-QAM, 64-QAM, 256-QAM
Security1
IEEE and WiFi compliant 64 / 128 bit WEP encryption for a/b/g
QuickSpecs
HP ProBook 430 G4 Notebook PC
HP ProBook 440 G4 Notebook PC
HP ProBook 450 G4 Notebook PC
HP ProBook 470 G4 Notebook PC
Technical Specifications
Not all configuration components are available in all regions/countries.
Americas – HP ProBook 430, 440, 450 & 470 G4 Notebook PC – October 2016 - c05254141
Page 41
mode only
AES-CCMP: 128 bit in hardware
802.1x authentication
WPA, WPA2: 802.1x. WPA-PSK, WPA2-PSK, TKIP, and AES.
WPA2 certification
IEEE 802.11i
Cisco Certified Extensions, all versions through CCX4 and CCX Lite
WAPI
Network Architecture
Models
Ad-hoc (Peer to Peer)
Infrastructure (Access Point Required)
Roaming
IEEE 802.11 compliant roaming between access points
Output Power2
802.11b : +16dBm minimum
802.11g : +14dBm minimum
802.11a : +14dBm minimum
802.11n HT20(2.4GHz) : +14dBm minimum
802.11n HT40(2.4GHz) : +12dBm minimum
802.11n HT20(5GHz) : +14dBm minimum
802.11n HT40(5GHz) : +12dBm minimum
802.11ac 80MHz(5GHz) : +11dBm minimum
Power Consumption
Transmit: 2.0 W (max)
Receive: 1.6 W (max)
Idle mode (PSP): 180 mW (WLAN Associated)
Idle mode: 50 mW (WLAN unassociated)
Connect Standby: 10 mW (WLAN+BT)
Radio disabled: 5 mW
Power Management
ACPI and PCI Express compliant power management
802.11 compliant power saving mode
Receiver Sensitivity3
802.11b, 1Mbps : -94dBm maximum
802.11b, 11Mbps : -86dBm maximum
802.11g, 6Mbps : -88dBm maximum
802.11g, 54Mbps : -74dBm maximum
802.11a, 6Mbps : -88dBm maximum
802.11a, 54Mbps : -74dBm maximum
802.11n, MCS07 : -69dBm maximum
802.11n, MCS15 : -66dBm maximum
802.11ac, 1SS, MCS-0 : -86dBm maximum
802.11ac, 1SS, MCS-9 : -61dBm maximum
802.11ac, 2SS, MCS-0 : -83dBm maximum
802.11ac, 2SS, MCS-9 : -58dBm maximum
Antenna type
High efficiency antenna with spatial diversity, mounted in the display
enclosure
Two embedded dual band 2.4/5 GHz antennas are provided to the card to
support WLAN MIMO communications and Bluetooth communications
Form Factor
PCI-Express M.2 MiniCard
Dimensions
Type 2230 : 2.3 x 22.0 x 30.0 mm
Or
Type 1630 : 2.3 x 16.0 x 30.0 mm
Weight
Type 2230 : 2.8g
QuickSpecs
HP ProBook 430 G4 Notebook PC
HP ProBook 440 G4 Notebook PC
HP ProBook 450 G4 Notebook PC
HP ProBook 470 G4 Notebook PC
Technical Specifications
Not all configuration components are available in all regions/countries.
Americas – HP ProBook 430, 440, 450 & 470 G4 Notebook PC – October 2016 - c05254141
Page 42
Or
Type 1630 : 2g
Operating Voltage
3.3v +/- 9%
Temperature
Operating
Non-operating
14° to 158° F (–10° to 70° C)
–40° to 176° F (–40° to 80° C)
Humidity
Operating
Non-operating
10% to 90% (non-condensing)
5% to 95% (non-condensing)
Altitude
Operating
Non-operating
0 to 10,000 ft (3,048 m)
0 to 50,000 ft (15,240 m)
LED Activity
LED Amber – Radio OFF; LED White – Radio ON
1. Check latest software/driver release for updates on supported security features.
2. Maximum output power may vary by country according to local regulations.
3. Receiver sensitivity is measured at a packet error rate of 8% for 802.11b (CKK modulation)
and a packet error rate of 10% for 802.11a/g (OFDM modulation).
HP Integrated Module with Bluetooth 4.0/4.1/4.2 Wireless Technology
Bluetooth Specification
4.0/4.1/4.2 Compliant
Frequency Band
2402 to 2480 MHz
Number of Available
Channels
Legacy : 0~79 (1 MHz/CH)
BLE : 0~39 (2 MHz/CH)
Data Rates and
Throughput
Legacy : 3 Mbps data rate; throughput up to 2.17 Mbps
BLE : 1 Mbps data rate; throughput up to 0.2 Mbps
Legacy : Synchronous Connection Oriented links up to 3, 64 kbps, voice
channels
Legacy : Asynchronous Connection Less links 2178.1 kbps/177.1 kbps
asymmetric (3-DH5) or 864 kbps symmetric (3-EV5)
Transmit Power
The Bluetooth component shall operate as a Class II Bluetooth device with
a maximum transmit power of + 4 dBm for BR and EDR.
Intel® 802.11 a/b/g/n/ac
(2x2) +Bluetooth® 4.2
Combo
Wireless LAN Standards
IEEE 802.11a
IEEE 802.11b
IEEE 802.11g
IEEE 802.11n
IEEE 802.11ac
Interoperability
Wi-Fi certified
Frequency Band
802.11b/g/n
2.402 – 2.482 GHz
Note:
The FCC has declared as of January 1, 2015 products that utilize
passive scanning on channel 12/13 and are capable of
transmitting must fully comply with requirements of 15.247 or
otherwise disable those channels.
802.11a/n
4.9 – 4.95 GHz (Japan)
5.15 – 5.25 GHz
5.25 – 5.35 GHz
QuickSpecs
HP ProBook 430 G4 Notebook PC
HP ProBook 440 G4 Notebook PC
HP ProBook 450 G4 Notebook PC
HP ProBook 470 G4 Notebook PC
Technical Specifications
Not all configuration components are available in all regions/countries.
Americas – HP ProBook 430, 440, 450 & 470 G4 Notebook PC – October 2016 - c05254141
Page 43
5.47 – 5.725 GHz
5.825 – 5.850 GHz
Note: Indonesia no support this band
Data Rates
802.11b: 1, 2, 5.5, 11 Mbps
802.11g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
802.11a: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
802.11n: MCS 0 ~ MCS 15, (20MHz, and 40MHz)
802.11ac : MCS0 ~ MCS9, (1SS, and 2SS) (20MHz, 40MHz, and
80MHz)
Modulation
Direct Sequence Spread Spectrum
BPSK, QPSK, CCK, 16-QAM, 64-QAM, 256-QAM
Security1
IEEE and WiFi compliant 64 / 128 bit WEP encryption for a/b/g
mode only
AES-CCMP: 128 bit in hardware
802.1x authentication
WPA, WPA2: 802.1x. WPA-PSK, WPA2-PSK, TKIP, and AES.
WPA2 certification
IEEE 802.11i
Cisco Certified Extensions, all versions through CCX4 and CCX Lite
WAPI
Network Architecture
Models
Ad-hoc (Peer to Peer)
Infrastructure (Access Point Required)
Roaming
IEEE 802.11 compliant roaming between access points
Output Power2
802.11b : +16dBm minimum
802.11g : +14dBm minimum
802.11a : +14dBm minimum
802.11n HT20(2.4GHz) : +14dBm minimum
802.11n HT40(2.4GHz) : +12dBm minimum
802.11n HT20(5GHz) : +14dBm minimum
802.11n HT40(5GHz) : +12dBm minimum
Power Consumption
Transmit: 2.0 W (max)
Receive: 1.6 W (max)
Idle mode (PSP): 180 mW (WLAN Associated)
Idle mode: 50 mW (WLAN unassociated)
Connect Standby: 10 mW (WLAN+BT)
Radio disabled: 5 mW
Power Management
ACPI and PCI Express compliant power management
802.11 compliant power saving mode
Receiver Sensitivity3
802.11b, 1Mbps : -94dBm maximum
802.11b, 11Mbps : -86dBm maximum
802.11g, 6Mbps : -88dBm maximum
802.11g, 54Mbps : -74dBm maximum
802.11a, 6Mbps : -88dBm maximum
802.11a, 54Mbps : -74dBm maximum
802.11n, MCS07 : -69dBm maximum
802.11n, MCS15 : -66dBm maximum
QuickSpecs
HP ProBook 430 G4 Notebook PC
HP ProBook 440 G4 Notebook PC
HP ProBook 450 G4 Notebook PC
HP ProBook 470 G4 Notebook PC
Technical Specifications
Not all configuration components are available in all regions/countries.
Americas – HP ProBook 430, 440, 450 & 470 G4 Notebook PC – October 2016 - c05254141
Page 44
802.11ac, 1SS, MCS-0 : -86dBm maximum
802.11ac, 1SS, MCS-9 : -61dBm maximum
802.11ac, 2SS, MCS-0 : -83dBm maximum
802.11ac, 2SS, MCS-9 : -58dBm maximum
Antenna type
High efficiency antenna with spatial diversity, mounted in the display
enclosure
Two embedded dual band 2.4/5 GHz antennas are provided to the card to
support WLAN MIMO communications and Bluetooth communications
Form Factor
PCI-Express M.2 MiniCard
Dimensions
Type 2230 : 2.3 x 22.0 x 30.0 mm
Or
Type 1630 : 2.3 x 16.0 x 30.0 mm
Weight
Type 2230 : 2.8g
Or
Type 1630 : 2g
Operating Voltage
3.3v +/- 9%
Temperature
Operating
Non-operating
14° to 158° F (–10° to 70° C)
–40° to 176° F (–40° to 80° C)
Humidity
Operating
Non-operating
10% to 90% (non-condensing)
5% to 95% (non-condensing)
Altitude
Operating
Non-operating
0 to 10,000 ft (3,048 m)
0 to 50,000 ft (15,240 m)
LED Activity
LED Amber – Radio OFF; LED White – Radio ON
1. Check latest software/driver release for updates on supported security features.
2. Maximum output power may vary by country according to local regulations.
3. Receiver sensitivity is measured at a packet error rate of 8% for 802.11b (CKK modulation)
and a packet error rate of 10% for 802.11a/g (OFDM modulation).
HP Integrated Module with Bluetooth 4.0/4.1/4.2 Wireless Technology
Bluetooth Specification
4.0/4.1/4.2 Compliant
Frequency Band
2402 to 2480 MHz
Number of Available
Channels
Legacy : 0~79 (1 MHz/CH)
BLE : 0~39 (2 MHz/CH)
Data Rates and
Throughput
Legacy : 3 Mbps data rate; throughput up to 2.17 Mbps
BLE : 1 Mbps data rate; throughput up to 0.2 Mbps
Legacy : Synchronous Connection Oriented links up to 3, 64 kbps, voice
channels
Legacy : Asynchronous Connection Less links 2178.1 kbps/177.1 kbps
asymmetric (3-DH5) or 864 kbps symmetric (3-EV5)
Transmit Power
The Bluetooth component shall operate as a Class II Bluetooth device with
a maximum transmit power of + 4 dBm for BR and EDR.
Realtek Ethernet
(10/100/1000)
Ethernet Features
10 Mbit/s operation (10BASE-T; IEEE 802.3i; IEEE 802.3 clauses 13-14)
100 Mbit/s operation (100BASE-TX; IEEE 802.3u; IEEE 802.3 clauses 21-
30)
COMMUNICATIONS
QuickSpecs
HP ProBook 430 G4 Notebook PC
HP ProBook 440 G4 Notebook PC
HP ProBook 450 G4 Notebook PC
HP ProBook 470 G4 Notebook PC
Technical Specifications
Not all configuration components are available in all regions/countries.
Americas – HP ProBook 430, 440, 450 & 470 G4 Notebook PC – October 2016 - c05254141
Page 45
1000 Mbit/s operation (1000BASE-T; IEEE 802.3ab; IEEE 8023 clauses 40)
Auto-Negotiation (Automatic Speed Selection)
Full Duplex Operation at all Speeds, Half Duplex operation at 10 and 100
Mbit/s
IEEE 802.1p QoS (Quality of Service) Support
IEEE 802.1q VLAN support
IEEE 802.3x Flow Control (IEEE 802.3 clauses 31-32; configurable)
IEEE 802.3az EEE (Energy Efficient Ethernet)
Jumbo Frame 9K
Auto MDI/MDIX Crossover cable detection
Power
Management
ACPI compliant - multiple power modes
Situation-sensitive features reduce power consumption
Advanced link down power saving for reducing link down power
consumption
Performance
Features
TCP/IP/UDP Checksum Offload (configurable)
Protocol Offload (ARP & NS)
Large send offload and Giant send offload
Receiving Side Scaling
Manageability
Wake-on-LAN from standby and hibernation (Magic Packet and Microsoft
Wake-Up Frame); Wake-on-LAN from off (Magic Packet only)
PXE 2.1 Remote Boot
Statistics Gathering (SNMP MIB II, Ethernet-like MIB, Ethernet MIB (802.3x,
clause 30))
Comprehensive diagnostic and configuration software suite
Virtual Cable Doctor for Ethernet cable status
Interface
PCI Express 1.1to fully support ASPM L0s/L1 and CLKREQ
NIC Device Driver Name
Realtek PCIe GBE Ethernet Family Controller
QuickSpecs
HP ProBook 430 G4 Notebook PC
HP ProBook 440 G4 Notebook PC
HP ProBook 450 G4 Notebook PC
HP ProBook 470 G4 Notebook PC
Technical Specifications
Not all configuration components are available in all regions/countries.
Americas – HP ProBook 430, 440, 450 & 470 G4 Notebook PC – October 2016 - c05254141
Page 46
Hardware
Implementation
Conexant CX7700
Function Key Volume
Controls
Volume up, volume down, and mute
Full Duplex
Yes
Microphone In
Stereo
Headphone/Line Out
Stereo
Integrated Microphone
Yes, dual digital microphone array
Audio Output Quality
Frequency Response
20Hz – 20kHz
Signal to Noise Ratio
106 dB (DAC), 102dB (ADC)
Total Harmonic Distortion
91dB THD+n on Line Out/HP (0.003%)
Play Sampling Rate(s)
Up to 192kHz
Record Sampling Rate(s)
Up to 96Khz
DAC
16, 20 or 24-bit
ADC
16, 20 or 24-bit
Integrated Stereo
Speakers
Power Rating
2 Watts
Impedance
4 Ohms
HP 45W Smart AC Adapter
Dimensions (H x W x D)
3.74 x 1.57 x 1.04 in (9.5 x 4.0 x 2.65 cm)
Weight
0.386 lb (175g) max
Input
90 to 265 VAC
Input Efficiency
87.74% at 115Vac and 88.4% at 230Vac
Input frequency range
47 to 63 Hz
Input AC current
1.4 A at 90 VAC
Output
Output power
45W
DC output
19.5V
Hold-up time
5 msec at 115 VAC input
Output current limit
<8.0A
Connector
4.5mm Barrel Type, 3 pin/grounded, mates with interchangeable cords
Environmental Design
Operating
32° to 95° F (0° to 35° C)
temperature
Non-operating (storage)
temperature
-4° to 185° F (-20° to 85° C)
Altitude
0 to 16,400 ft (0 to 5,000 m)
Humidity
20% to 95%
AUDIO/MULTIMEDIA
POWER
QuickSpecs
HP ProBook 430 G4 Notebook PC
HP ProBook 440 G4 Notebook PC
HP ProBook 450 G4 Notebook PC
HP ProBook 470 G4 Notebook PC
Technical Specifications
Not all configuration components are available in all regions/countries.
Americas – HP ProBook 430, 440, 450 & 470 G4 Notebook PC – October 2016 - c05254141
Page 47
Storage Humidity
10% to 95%
EMI and Safety
Certifications
*CE Mark - full compliance with LVD and EMC directives
* Worldwide safety standards - IEC60950, EN60950, UL60950, Class1,
SELV; Agency approvals - C-UL-US, NORDICS, DENAN, EN55022 Class B,
FCC Class B, CISPR22 Class B, CCC, NOM-1 NYCE.
* MTBF - over 200,000 hours at 25°C ambient condition.
HP 65W AC Adapter, nPFC
3Pin RC 4.5mm
Dimensions
4.25 x 1.85 x 1.47 in (10.8 x 4.7 x 3.74 cm)
Weight
1.81 lb (250g) max
Input
100 to 240 VAC
Input Efficiency
88% min at 115 VAC and 89% min at 230
VAC
Input frequency range
47 to 63 Hz
Input AC current
1.7 A at 90 VAC
Output
Output power
65W
DC output
19.5V
Hold-up time
5 msec at 115 VAC input
Output current limit
<11A, Over voltage protection- 29V max
automatic shutdown
Connector
4.5mm Barrel Type, 3 pin/grounded, mates with interchangeable cords
Environmental Design
Operating
32° to 104° F (0° to 40° C)
temperature
Non-operating (storage)
temperature
-4° to 149° F (-20° to 65° C)
Altitude
0 to 10,000 ft (0 to 3,048 m)
Humidity
20% to 80%
Storage Humidity
10% to 90%
EMI and Safety
Certifications
*CE Mark - full compliance with LVD and EMC directives
* Worldwide safety standards - IEC60950, EN60950, UL60950, Class1,
SELV; Agency approvals - C-UL-US, NORDICS, DENAN, EN55022 Class B,
FCC Class B, CISPR22 Class B, CCC, NOM-1 NYCE.
* MTBF - over 200,000 hours at 25°C ambient condition.
HP 3-cell, Long Life 48
WHr Li-ion
HP ProBook 430
/440/450/470 G4
Dimensions (H x W x L)
7.0. x180.48x88.95 mm
(0.273 x 7.09 x 3.49 inch)
Weight
0.22 kg (0.48lb)
Cells/Type
3cell Lithium-Ion
Energy
Voltage
11.4V/ 10.95V
QuickSpecs
HP ProBook 430 G4 Notebook PC
HP ProBook 440 G4 Notebook PC
HP ProBook 450 G4 Notebook PC
HP ProBook 470 G4 Notebook PC
Technical Specifications
Not all configuration components are available in all regions/countries.
Americas – HP ProBook 430, 440, 450 & 470 G4 Notebook PC – October 2016 - c05254141
Page 48
Amp-hour capacity
4.212Ah /4.385Ah
Watt-hour capacity
48Wh
Temperature
Operating (Charging)
32˚ to 113˚ F (0˚ to 45˚ C)
Operating (Discharging)
14˚ to 122˚ F (-10˚ to 60˚ C)
Non-operating
-4˚ to 122˚ F (-20˚ to 60˚ C)
Battery Re-Charge Time
System in OFF or Standby
Mode
<3 hours
Fuel Gauge LED
No
Warranty
3-year
Optional Travel Battery
Available
No
Country of Origin
China
Eco-Label Certifications & declarations
This product has received or is in the process of being certified to the following
approvals and may be labeled with one or more of these marks:
IT ECO declaration
US ENERGY STAR®
EPEAT <Gold> registered in the United States. See http://www.epeat.net
for registration status in your country.
System Configuration
The configuration used for the Energy Consumption and Declared Noise Emissions
data for the Notebook model is based on a “Typically Configured Notebook”.
Energy Consumption
(in accordance with US ENERGY STAR®
test method)
115VAC, 60Hz
230VAC, 50Hz
100VAC, 60Hz
Normal Operation (Short idle)
6.85 W
6.99 W
6.85 W
Normal Operation (Long idle)
3.22 W
3.42 W
3.31 W
Sleep
0.51 W
0.55 W
0.52 W
Off
0.31 W
0.42 W
0.30 W
Note:
Energy efficiency data listed is for an ENERGY STAR® compliant product if offered
within the model family. HP computers marked with the ENERGY STAR® Logo are
compliant with the applicable U.S. Environmental Protection Agency (EPA) ENERGY
STAR® specifications for computers. If a model family does not offer ENERGY STAR®
compliant configurations, then energy efficiency data listed is for a typically
configured PC featuring a hard disk drive, a high efficiency power supply, and a
Microsoft Windows® operating system.
ENVIRONMENTAL
ProBook 430 G4
QuickSpecs
HP ProBook 430 G4 Notebook PC
HP ProBook 440 G4 Notebook PC
HP ProBook 450 G4 Notebook PC
HP ProBook 470 G4 Notebook PC
Technical Specifications
Not all configuration components are available in all regions/countries.
Americas – HP ProBook 430, 440, 450 & 470 G4 Notebook PC – October 2016 - c05254141
Page 49
Heat Dissipation*
115VAC, 60Hz
230VAC, 50Hz
100VAC, 60Hz
Normal Operation (Short idle)
23 BTU/hr
24 BTU/hr
23 BTU/hr
Normal Operation (Long idle)
11 BTU/hr
12 BTU/hr
11 BTU/hr
Sleep
2 BTU/hr
2 BTU/hr
2 BTU/hr
Off
2 BTU/hr
1 BTU/hr
1 BTU/hr
*NOTE: Heat dissipation is calculated based on the measured watts, assuming the
service level is attained for one hour.
Declared Noise Emissions
(in accordance with
ISO 7779 and ISO 9296)
Sound Power
(L
WAd
, bels)
Sound Pressure
(L
pAm
, decibels)
Typically Configured – Idle
2.8
15
Fixed Disk – Random writes
2.8
15
Longevity and Upgrading
This product can be upgraded, possibly extending its useful life by several years.
Upgradeable features and/or components contained in the product may include:
• 3 USB ports
• 1 PC card slot (type I/II)
• 1 ExpressCard/54 slot
• 1 IEEE 1394 Port
• 2 SODIMM memory slots
• Optional expansion base docking station
• 1 multi-bay II storage port
• Interchangeable HDD??
Spare parts are available throughout the warranty period and or for up to “5” years
after the end of production.
Batteries
This battery(s) in this product comply with EU Directive 2006/66/EC
Batteries used in the product do not contain:
Mercury greater the1ppm by weight
Cadmium greater than 20ppm by weight
Battery size: CR2032 (coin cell)
Battery type: Lithium
Additional Information
This product is in compliance with the Restrictions of Hazardous
Substances (RoHS) directive - 2011/65/EC.
This HP product is designed to comply with the Waste Electrical and
Electronic Equipment (WEEE) Directive – 2002/96/EC.
This product is in compliance with California Proposition 65 (State of
California; Safe Drinking Water and Toxic Enforcement Act of 1986).
This product is in compliance with the IEEE 1680 (EPEAT) standard at the
<Gold> level, see www.epeat.net
Plastics parts weighing over 25 grams used in the product are marked per
ISO11469 and ISO1043.
This product contains 0% post-consumer recycled plastic (by wt.)
This product is 94.7% recycle-able when properly disposed of at end of
life.
Packaging Materials
External:
PAPER/Corrugated
340.5 g
QuickSpecs
HP ProBook 430 G4 Notebook PC
HP ProBook 440 G4 Notebook PC
HP ProBook 450 G4 Notebook PC
HP ProBook 470 G4 Notebook PC
Technical Specifications
Not all configuration components are available in all regions/countries.
Americas – HP ProBook 430, 440, 450 & 470 G4 Notebook PC – October 2016 - c05254141
Page 50
Internal:
PLASTIC/EPE-Expanded Polyethylene
49 g PLASTIC/Polyethylene low density
9.1 g
The plastic packaging material contains at least 0% recycled content.
The corrugated paper packaging materials contains at least 80.0% recycled
content.
Material Usage
This product does not contain any of the following substances in excess of
regulatory limits (refer to the HP General Specification for the Environment at
http://www.hp.com/hpinfo/globalcitizenship/environment/pdf/gse.pdf):
Asbestos
Certain Azo Colorants
Certain Brominated Flame Retardants – may not be used as flame
retardants in plastics
Cadmium
Chlorinated Hydrocarbons
Chlorinated Paraffins
Formaldehyde
Halogenated Diphenyl Methanes
Lead carbonates and sulfates
Lead and Lead compounds
Mercuric Oxide Batteries
Nickel – finishes must not be used on the external surface designed to be
frequently handled or carried by the user.
Ozone Depleting Substances
Polybrominated Biphenyls (PBBs)
Polybrominated Biphenyl Ethers (PBBEs)
Polybrominated Biphenyl Oxides (PBBOs)
Polychlorinated Biphenyl (PCB)
Polychlorinated Terphenyls (PCT)
Polyvinyl Chloride (PVC) – except for wires and cables, and certain retail
packaging has been voluntarily removed from most applications.
Radioactive Substances
Tributyl Tin (TBT), Triphenyl Tin (TPT), Tributyl Tin Oxide (TBTO)
Packaging Usage
HP follows these guidelines to decrease the environmental impact of product
packaging:
Eliminate the use of heavy metals such as lead, chromium, mercury and
cadmium in packaging materials.
Eliminate the use of ozone-depleting substances (ODS) in packaging
materials.
Design packaging materials for ease of disassembly.
Maximize the use of post-consumer recycled content materials in
packaging materials.
Use readily recyclable packaging materials such as paper and corrugated
materials.
Reduce size and weight of packages to improve transportation fuel
efficiency.
Plastic packaging materials are marked according to ISO 11469 and DIN
6120 standards.
QuickSpecs
HP ProBook 430 G4 Notebook PC
HP ProBook 440 G4 Notebook PC
HP ProBook 450 G4 Notebook PC
HP ProBook 470 G4 Notebook PC
Technical Specifications
Not all configuration components are available in all regions/countries.
Americas – HP ProBook 430, 440, 450 & 470 G4 Notebook PC – October 2016 - c05254141
Page 51
End-of-life Management and Recycling
Hewlett-Packard offers end-of-life HP product return and recycling programs in
many geographic areas. To recycle your product, please go to:
http://www.hp.com/go/reuse-recycle or contact your nearest HP sales office.
Products returned to HP will be recycled, recovered or disposed of in a responsible
manner.
The EU WEEE directive (2002/95/EC) requires manufacturers to provide treatment
information for each product type for use by treatment facilities. This information
(product disassembly instructions) is posted on the Hewlett Packard web site at:
http://www.hp.com/go/recyclers. These instructions may be used by recyclers and
other WEEE treatment facilities as well as HP OEM customers who integrate and resell HP equipment.
Hewlett-Packard Corporate
Environmental Information
For more information about HP’s commitment to the environment:
Global Citizenship Report
http://www.hp.com/hpinfo/globalcitizenship/gcreport/index.html
Eco-label certifications
http://www8.hp.com/us/en/hp-information/environment/ecolabels.html
ISO 14001 certificates:
http://h20195.www2.hp.com/V2/GetDocument.aspx?docname=c0475584
2
and
http://www.hp.com/hpinfo/globalcitizenship/environment/pdf/cert.pdf
ProBook 440 G4
Eco-Label Certifications & declarations
This product has received or is in the process of being certified to the following
approvals and may be labeled with one or more of these marks:
IT ECO declaration
US ENERGY STAR®
EPEAT <Gold> registered in the United States. See http://www.epeat.net for
registration status in your country.
System Configuration
The configuration used for the Energy Consumption and Declared Noise Emissions
data for the Notebook model is based on a “Typically Configured Notebook”.
Energy Consumption
(in accordance with US ENERGY STAR®
test method)
115VAC, 60Hz
230VAC, 50Hz
100VAC, 60Hz
Normal Operation (Short idle)
4.92 W
4.93 W
4.91 W
Normal Operation (Long idle)
2.33 W
2.25 W
2.29 W
Sleep
0.38 W
0.40 W
0.34 W
Off
0.19 W
0.24 W
0.190 W
Note:
Energy efficiency data listed is for an ENERGY STAR® compliant product if offered
within the model family. HP computers marked with the ENERGY STAR® Logo are
compliant with the applicable U.S. Environmental Protection Agency (EPA)
ENERGY STAR® specifications for computers. If a model family does not offer
ENERGY STAR® compliant configurations, then energy efficiency data listed is for
QuickSpecs
HP ProBook 430 G4 Notebook PC
HP ProBook 440 G4 Notebook PC
HP ProBook 450 G4 Notebook PC
HP ProBook 470 G4 Notebook PC
Technical Specifications
Not all configuration components are available in all regions/countries.
Americas – HP ProBook 430, 440, 450 & 470 G4 Notebook PC – October 2016 - c05254141
Page 52
a typically configured PC featuring a hard disk drive, a high efficiency power
supply, and a Microsoft Windows® operating system.
ProBook 450 G4
Eco-Label Certifications &
declarations
This product has received or is in the process of being certified to the
following approvals and may be labeled with one or more of these
marks:
IT ECO declaration
US ENERGY STAR®
EPEAT <Gold> registered in the United States. See
http://www.epeat.net for registration status in your country.
System Configuration
The configuration used for the Energy Consumption and Declared Noise
Emissions data for the Notebook model is based on a “Typically
Configured Notebook”.
Energy Consumption
(in accordance with US
ENERGY STAR® test method)
115VAC, 60Hz
230VAC, 50Hz
100VAC, 60Hz
Normal Operation
(Short idle)
5.57 W
5.82 W
5.72 W
Normal Operation
(Long idle)
3.07 W
3.12 W
2.92 W
Sleep
0.50 W
0.53 W
0.50 W
Off
0.17 W
0.25 W
0.17 W
Note:
Energy efficiency data listed is for an ENERGY STAR® compliant product if offered within the
model family. HP computers marked with the ENERGY STAR® Logo are compliant with the
applicable U.S. Environmental Protection Agency (EPA) ENERGY STAR® specifications for
computers. If a model family does not offer ENERGY STAR® compliant configurations, then
energy efficiency data listed is for a typically configured PC featuring a hard disk drive, a high
efficiency power supply, and a Microsoft Windows® operating system.
ProBook 470 G4
Eco-Label Certifications &
declarations
This product has received or is in the process of being certified to the following approvals and
may be labeled with one or more of these marks:
IT ECO declaration
US ENERGY STAR®
EPEAT <Gold> registered in the United States. See http://www.epeat.net for
registration status in your country.
System Configuration
The configuration used for the Energy Consumption and Declared Noise Emissions data for the
Notebook model is based on a “Typically Configured Notebook”.
Energy Consumption
(in accordance with US
ENERGY STAR® test method)
115VAC, 60Hz
230VAC, 50Hz
100VAC, 60Hz
QuickSpecs
HP ProBook 430 G4 Notebook PC
HP ProBook 440 G4 Notebook PC
HP ProBook 450 G4 Notebook PC
HP ProBook 470 G4 Notebook PC
Technical Specifications
Not all configuration components are available in all regions/countries.
Americas – HP ProBook 430, 440, 450 & 470 G4 Notebook PC – October 2016 - c05254141
Page 53
Normal Operation (Short idle)
8.12 W
8.16 W
8.09 W
Normal Operation (Long idle)
3.12 W
3.14 W
3.11 W
Sleep
0.34 W
0.40 W
0.33 W
Off
0.18 W
0.27 W
0.17 W
Note:
Energy efficiency data listed is for an ENERGY STAR® compliant product if offered within the
model family. HP computers marked with the ENERGY STAR® Logo are compliant with the
applicable U.S. Environmental Protection Agency (EPA) ENERGY STAR® specifications for
computers. If a model family does not offer ENERGY STAR® compliant configurations, then
energy efficiency data listed is for a typically configured PC featuring a hard disk drive, a high
efficiency power supply, and a Microsoft Windows® operating system.
QuickSpecs
HP ProBook 430 G4 Notebook PC
HP ProBook 440 G4 Notebook PC
HP ProBook 450 G4 Notebook PC
HP ProBook 470 G4 Notebook PC
Options and Accessories (sold separately and availability may vary by country)
Not all configuration components are available in all regions/countries.
Americas – HP ProBook 430, 440, 450 & 470 G4 Notebook PC – October 2016 - c05254141
Page 54
Type
Decription
Part Number
Docking
HP 3001pr USB 3 Port Replicator
F3S42AA
HP 3005pr USB 3.0 Port Replicator
Y4H06AA
Input/Output
HP Stylish USB Keyboard and Mouse
H4B80AA#xxx
HP Stylish Wireless Keyboard and Mouse
H4B79AA#xxx
HP Slim BT Keyboard
H4Q44AA#xxx
HP USB Essential Keyboard and Mouse
H6L29AA
HP 2.4 GHz Keyboard and Mouse
G1K29AA#xxx
HP Ultra Mobile Wireless Mouse
H6F25AA#xxx
HP Comfort Grip Wireless Mouse
H2L63AA
HP 3-Button USB Laser Mouse
H4B81AA
HP USB Travel Mouse
G1K28AA
HP Ultrathin Wireless Mouse SE
L9V77AA
HP Ultrathin Wireless Mouse
L9V78AA
HP HDMI to DVI Adapter
F5A28AA
HP Wireless Display Adapter
J1V25AA#xxx
HP UC Wireless Mono Headset
W3K08AA
HP UC Wireless Duo Headset
W3K09AA
Power
HP 65W Smart AC Adapter
H6Y89AA#xxx
HP 90W Smart AC Adapter
H6Y90AA#xxx
HP 65W Slim AC Adapter
H6Y82AA#xxx
HP Power Bank
N9F71AA#xxx
Storage
HP External USB Optical Drive
F2B56AA
HP 500GB 7200rpm HDD
F3B97AA
Security
HP UltraSlim Keyed Cable Lock
H4D73AA
HP Essential Combination Lock
T0Y16AA
HP Combination Lock
T0Y15AA
HP Keyed Cable lock
T0Y14AA
HP Keyed Cable Lock 10mm
T1A62AA
UCC
HP Conferencing Keyboard
K8P74AA#xxx
HP Speaker Phone
K7V16AA
HP Wired Headset
K7V17AA
QuickSpecs
HP ProBook 430 G4 Notebook PC
HP ProBook 440 G4 Notebook PC
HP ProBook 450 G4 Notebook PC
HP ProBook 470 G4 Notebook PC
Summary of Changes
Not all configuration components are available in all regions/countries.
Americas – HP ProBook 430, 440, 450 & 470 G4 Notebook PC – October 2016 - c05254141
Page 55
Date of change:
Version History:
Description of change:
© Copyright 2016 HP Development Company, L.P. The information contained herein is subject to change without notice. The only
warranties are contained in the limited warranty statements accompanying such products and services. Nothing herein should be
construed as constituting an additional warranty. HP shall not be liable for technical or editorial errors or omissions contained
herein. Bluetooth is a trademark of its proprietor used by HP Inc. under license. ENERGY STAR is a registered trademark of the U.S.
Environmental Protection Agency. Bluetooth is a trademark of its proprietor and used by HP Inc. under license. Intel and Core are a
trademarks of Intel Corporation in the U.S. and other countries. USB Type-C™ and USB-C™ are trademarks of USB Implementers
Forum. NVIDIA and GeForce and Optimus are trademarks and/or registered trademarks of NVIDIA Corporation in the U.S. and other
countries. All other trademarks are the property of their respective owners.
Loading...
