HP OMNIBOOK 6100 User Manual

HP Notebook PC

Reference Guide

Notice

This manual and any examples contained herein are provided “as is” and are subject to change without notice. Hewlett-Packard Company makes no warranty of any kind with regard to this manual, including, but not limited to, the implied warranties of merchantability and fitness for a particular purpose. Hewlett-Packard Co. shall not be liable for any errors or for incidental or consequential damages in connection with the furnishing, performance, or use of this manual or the examples herein.

Consumer transactions in Australia and the United Kingdom: The above disclaimers and limitations shall not apply to Consumer transactions in Australia and the United Kingdom and shall not affect the statutory rights of Consumers.

© Copyright Hewlett-Packard Company 2001. All rights reserved. Reproduction, adaptation, or translation of this manual is prohibited without prior written permission of Hewlett-Packard Company, except as allowed under the copyright laws.

The programs that control this product are copyrighted and all rights are reserved. Reproduction, adaptation, or translation of those programs without prior written permission of Hewlett-Packard Co. is also prohibited.

Portions of the programs that control this product may also be copyrighted by Microsoft Corporation, SystemSoft Corp., Phoenix Technologies, Ltd., ATI Technologies Inc., and Adobe Systems Incorporated. See the individual programs for additional copyright notices.

This product incorporates copyright protection technology that is protected by method claims of certain U.S. patents and other intellectual property rights owned by Macrovision Corporation and other rights owners. Use of this copyright protection technology must be authorized by Macrovision Corporation and is intended for home and other limited viewing uses only unless otherwise authorized by Macrovision Corporation. Reverse engineering or disassembly is prohibited.

Microsoft®, MS-DOS®, and Windows® are U.S. registered trademarks of Microsoft Corporation. Pentium® and the Intel Inside logo are U.S. registered trademarks and Celeron™ and SpeedStep™ are U.S. trademarks of Intel Corporation. TrackPoint™ is a U.S. trademark of International Business Machines. Adobe® and Acrobat® are trademarks of Adobe Systems Incorporated.

Hewlett-Packard Company HP Notebook Customer Care 1000 NE Circle Blvd., MS 425E Corvallis, OR 97330

2 Reference Guide

CAUTION

Important Safety Information

To reduce the risk of fire, use only No. 26 AWG or larger telecommunications line cord to connect a modem to the telephone wall jack.

When using your computer with a telephone connection, always follow basic safety precautions to reduce the risk of fire, electric shock, and injury to persons:

• Do not use this product with a telephone connection near water (for example, near a bathtub, sink, swimming pool, or in a wet basement).

• Avoid using a telephone connection (other than a cordless type) during an electrical storm. There may be a remote risk of electric shock from lightning.

• Do not use a telephone connection to report a gas leak in the vicinity of the leak.

• Use only the power cord and batteries indicated in this manual. Do not dispose of

batteries in a fire. They may explode. Check with local codes for possible special disposal instructions.

HP Software Product License Agreement

Your HP product contains software programs. CAREFULLY READ THIS LICENSE AGREEMENT BEFORE PROCEEDING TO OPERATE THIS EQUIPMENT. RIGHTS IN THE SOFTWARE ARE OFFEREDONLY ON THE CONDITION THAT THE CUSTOMER AGREES TO ALL TERMS AND CONDITIONS OF THE LICENSE AGREEMENT. PROCEEDING TO OPERATE THE EQUIPMENT INDICATES YOUR ACCEPTANCE OF THESE TERMS AND CONDITIONS. IF YOU DO NOT AGREE WITH THE TERMS OF THE LICENSE AGREEMENT, YOU MUST NOW EITHER REMOVE THE SOFTWARE FROM YOUR HARD DISK DRIVE AND DESTROY THE MASTER DISKETTES, OR RETURN THE COMPLETE HP PRODUCT AND SOFTWARE FOR A FULL REFUND. PROCEEDING WITH CONFIGURATION SIGNIFIES YOUR ACCEPTANCE OF THE LICENSE TERMS.

UNLESS OTHERWISE STATED BELOW, THIS HP SOFTWARE LICENSE AGREEMENT SHALL GOVERN THE USE OF ALL SOFTWARE THAT IS PROVIDED TO YOU AS PART OF THE HP PRODUCT AND SHALL SUPERSEDE ANY OTHER SOFTWARE WARRANTY STATEMENT THAT MAY BE INCLUDED IN THIS HP PRODUCT OR MAY BE FOUND ONLINE.

Operating system and software applications by Microsoft are licensed to you under the Microsoft License Agreement contained in the Microsoft documentation or displayed on your screen when Microsoft Software Products are launched. Other non-HP Software and Operating Systems are covered by the appropriate vendor license. The following License Terms govern the use of the HP software:

Reference Guide 3

USE. Customer may use the software on any one HP product. Customer may not network the software or otherwise use it on more than one HP product. Customer may not reverse assemble or decompile the software unless authorized by law.

COPIES AND ADAPTATIONS. Customer may make copies or adaptations of the software a) for archival purposes or (b) when copying or adaptation is an essential step in the use of the software with an HP product so long as the copies and adaptations are used in no other manner.

OWNERSHIP. Customer agrees that he/she does not have any title or ownership of the software, other than ownership of the physical media. Customer acknowledges and agrees that the software is copyrighted and protected under the copyright laws. Customer acknowledges and agrees that the software may have been developed by a third party software supplier named in the copyright notices included with the software, who shall be authorized to hold the Customer responsible for any copyright infringement or violation of this Agreement.

PRODUCT RECOVERY CD-ROM. If your HP product was shipped with a product recovery CD-ROM: (i) The product recovery CD-ROM and/or support utility software may only be used for restoring the hard disk of the HP product with which the product recovery CD-ROM was originally provided. (ii) The use of any operating system software by Microsoft contained in any such product recovery CD-ROM shall be governed by the Microsoft License Agreement.

TRANSFER OF RIGHTS IN SOFTWARE. Customer may transfer rights in the software to a third party only as part of the transfer of all rights and only if Customer obtains the prior agreement of the third party to be bound by the terms of this License Agreement. Upon such a transfer, Customer agrees that his/her rights in the software are terminated and that he/she will either destroy his/her copies and adaptations or deliver them to the third party.

SUBLICENSING AND DISTRIBUTION. Customer may not lease, sublicense the software or distribute copies or adaptations of the software to the public in physical media or by telecommunication without the prior written consent of Hewlett-Packard.

TERMINATION. Hewlett-Packard may terminate this software license for failure to comply with any of these terms provided Hewlett-Packard has requested Customer to cure the failure and Customer has failed to do so within thirty (30) days of such notice.

UPDATES AND UPGRADES. Customer agrees that the software does not include updates and upgrades which may be available from Hewlett-Packard under a separate support agreement.

EXPORT CLAUSE. Customer agrees not to export or re-export the software or any copy or adaptation in violation of the U.S. Export Administration regulations or other applicable regulation.

U.S. GOVERNMENT RESTRICTED RIGHTS. Use, duplication, or disclosure is subject to HP standard commercial license terms and for non-DOD Departments and Agencies of the U.S. Government, the restrictions set forth in FAR 52.227-19(c)(1-2) (June 1987) Hewlett-Packard Company, 3000 Hanover Street, Palo Alto, CA 94304 U.S.A. Copyright (c) 2000 Hewlett-Packard Company. All Rights Reserved. Customer further agrees that

4 Reference Guide

Software is delivered and licensed as “Commercial computer software” as defined in DFARS 252-227-7014 (June 1995) or as a “commercial item” as defined in FAR

2.101(a), or as “Restricted computer software” as defined in FAR 52.227-19 (or any

equivalent agency regulation or contract clause), whichever is applicable. The Customer agrees that it has only those rights provided for such Software by the applicable FAR or DFARS clause or the HP standard software agreement for the product involved.

Support Policy for Support Pack of Operating Systems. HP provides end user support for HP PCs that use Microsoft Operating Systems, including its latest service packs. This support will be available within 30 days of the software being released.

Edition History

Edition 2 ............................................August 2001

This manual is printed on recycled paper.

Reference Guide 5

Contents

Getting Started with Your HP Notebook .....................................................................11

Taking Inventory.........................................................................................................12

What’s in the box? ................................................................................................12

To buy accessories ................................................................................................13

To find more information...................................................................................... 14

Identifying Parts of the Computer...............................................................................15

Front View ............................................................................................................15

Back View............................................................................................................. 16

Bottom View......................................................................................................... 17

Status Lights.......................................................................................................... 18

Setting Up Your Computer......................................................................................... 20

Step 1: Install the battery.......................................................................................20

Step 2: Connect AC power....................................................................................22

Step 3: Connect a phone line.................................................................................23

Step 4: Turn on the computer................................................................................ 24

Step 5: Set up Windows ........................................................................................24

Step 6: Register your notebook .............................................................................25

What to do next..................................................................................................... 26

To connect to the Internet......................................................................................26

Basic Operation ..............................................................................................................27

Operating Your Computer ..........................................................................................28

To turn the computer on and off............................................................................28

To reset the computer............................................................................................ 29

To change the boot device.....................................................................................30

To use the pointing devices...................................................................................30

To use the Fn hot keys ..........................................................................................32

To use the One-Touch buttons ..............................................................................33

To use the Windows and Applications keys..........................................................34

To use the embedded keypad ................................................................................34

To use the ALT GR key........................................................................................ 35

To adjust the display .............................................................................................35

To adjust the volume.............................................................................................36

To change computer settings for a presentation.................................................... 37

To work with CDs and DVDs ...............................................................................38

Securing Your Computer............................................................................................ 39

To set up password protection...............................................................................39

To attach a security cable......................................................................................40

To protect against viruses......................................................................................41

To set PC identification......................................................................................... 41

To lock the hard disk drive....................................................................................42

Reference Guide 7

Working in Comfort with a Notebook PC.................................................................. 43

Taking Care of Your Computer.................................................................................. 45

To protect your hard disk drive............................................................................. 45

To maintain your computer................................................................................... 45

To safeguard your data.......................................................................................... 46

To extend the life of the display............................................................................ 46

To clean your computer.........................................................................................47

Batteries and Power Management ................................................................................49

Managing Power Consumption...................................................................................50

How the computer manages power automatically.................................................50

To manage power manually.................................................................................. 53

Using Battery Power...................................................................................................54

To check battery status.......................................................................................... 54

To respond to a low-battery warning ....................................................................55

To recharge the battery..........................................................................................55

To use additional batteries.....................................................................................55

To get the most from your batteries ......................................................................56

To maximize processor speed ...............................................................................57

Modem and Network Connections................................................................................ 59

Using the Modem........................................................................................................60

To connect the modem.......................................................................................... 60

To connect to the Internet......................................................................................62

To disconnect from the Internet ............................................................................63

To dial in to a network ..........................................................................................63

To change your modem settings............................................................................63

To send and receive e-mail....................................................................................64

To send and receive faxes (Windows 98)..............................................................65

To send and receive faxes (Windows 2000)..........................................................66

To send and receive faxes (Windows XP) ............................................................67

Connecting to a LAN..................................................................................................68

To connect to a LAN............................................................................................. 68

Making Wireless Connections ....................................................................................69

To prepare for connections (Windows 98 or 2000)...............................................69

To prepare for connections (Windows XP)...........................................................71

To turn wireless communication on and off..........................................................72

Add-On Devices ..............................................................................................................75

Using Plug-In Modules...............................................................................................76

To install hot-swap support (Windows 98) ...........................................................76

To replace a plug-in module..................................................................................76

To connect the floppy disk drive to the parallel port.............................................78

To insert or remove a CD or DVD........................................................................ 79

To play DVD movies ............................................................................................80

8 Reference Guide

To create or copy CDs...........................................................................................80

Connecting PC Cards.................................................................................................. 81

To insert or remove a PC Card.............................................................................. 81

Connecting External Devices......................................................................................83

To identify connectors for external devices ..........................................................83

To connect a printer or other parallel device.........................................................84

To connect an external keyboard or mouse...........................................................84

To connect a USB device......................................................................................85

To connect an audio device................................................................................... 85

To use an external monitor.................................................................................... 86

To use a TV set as a monitor................................................................................. 88

To connect a serial device..................................................................................... 88

To connect an infrared device............................................................................... 89

To use a docking product...................................................................................... 90

Installing Additional RAM .........................................................................................93

To install a RAM expansion module.....................................................................93

To remove a RAM expansion module ..................................................................95

Replacing the Hard Disk Drive................................................................................... 96

To replace the hard disk drive............................................................................... 96

To replace the hard disk drive holder.................................................................... 97

To prepare a new hard disk drive.......................................................................... 98

Troubleshooting and Maintenance................................................................................99

Troubleshooting Your Computer..............................................................................100

Audio Problems...................................................................................................100

CD-ROM and DVD Problems ............................................................................101

Display Problems ................................................................................................103

Docking Problems...............................................................................................104

Hard Disk Drive Problems.................................................................................. 105

Heat Problems..................................................................................................... 106

Infrared Problems................................................................................................ 106

Keyboard and Pointing Device Problems ...........................................................107

LAN problems.....................................................................................................109

Memory Problems...............................................................................................110

Modem Problems ................................................................................................110

PC Card (PCMCIA) Problems............................................................................ 113

Performance Problems ........................................................................................114

Power and Battery Problems............................................................................... 115

Printing Problems................................................................................................ 118

Serial, Parallel, and USB Problems..................................................................... 118

Startup Problems................................................................................................. 120

Wireless Problems............................................................................................... 121

Testing the Hardware................................................................................................ 123

To run the e-Diagtools diagnostic test.................................................................123

Configuring the Computer........................................................................................ 125

To run the BIOS Setup utility .............................................................................125

To set up TopTools .............................................................................................131

Reference Guide 9

Reinstalling and Updating Software ......................................................................... 132

To recover the factory installation of your hard disk ..........................................132

To create a boot disk (Windows 98 or 2000) ......................................................133

To replace a damaged Recovery CD................................................................... 133

To update the BIOS............................................................................................. 134

To update Windows drivers ................................................................................134

HP Support and Service............................................................................................... 135

Getting Assistance for Your Computer..................................................................... 136

To get help from the web ....................................................................................136

To contact HP for support or service...................................................................136

To receive repair service ..................................................................................... 139

To prepare your computer for shipment.............................................................. 139

Hewlett-Packard Limited Warranty Statement .........................................................140

Reference Information .................................................................................................143

Hardware Specifications........................................................................................... 144

Modem Reference Information................................................................................. 147

Modem Reference (Ambit) .................................................................................147

Modem Reference (3Com/US Robotics) ............................................................154

Safety Information ....................................................................................................159

Power Cords........................................................................................................159

Ergonomics .........................................................................................................160

Battery Safety...................................................................................................... 160

Laser Safety.........................................................................................................161

LED Safety.......................................................................................................... 161

Exposure to Radio Frequency Radiation.............................................................162

Regulatory Information.............................................................................................163

U.S.A...................................................................................................................163

Canada.................................................................................................................164

European Union ..................................................................................................165

Japan ...................................................................................................................167

Russia.................................................................................................................. 167

International ........................................................................................................167

Index .............................................................................................................................. 169

10 Reference Guide

Getting Started with Your HP Notebook

Reference Guide 11

Getting Started with Your HP Notebook

Taking Inventory

Congratulations! Your notebook computer sets a new standard in personal computing. Although compact and easy to carry, your computer is made with the quality and attention to detail that are the hallmark of Hewlett-Packard.

Your computer has several features that make it convenient to use:

• Two buttons provide convenient options for starting and stopping the computer.

• Volume controls are located within easy reach on the computer’s right side, and the

audio-off button and light let you cut off all sound quickly when needed.

• All cable connectors are near the back of the computer, keeping cables away from your working area.

This manual shows how to set up and operate your computer, as well as what to do if you run into trouble.

What’s in the box?

• HP notebook PC.

• Main battery (installed).

• CD-ROM, DVD, or similar drive module (installed).

• Floppy disk drive module (with certain models).

• AC adapter and power cord.

• Quick Start sheet.

• Startup Guide.

• Recovery CD, for restoring Windows and all software included with your computer.

• Microsoft Windows manual.

• CD with special software (for models with certain drive modules).

In addition, your HP notebook includes preinstalled software. (The exact software installed depends on your particular notebook model.)

12 Reference Guide

Getting Started with Your HP Notebook

Taking Inventory

To buy accessories

You can buy accessories for your computer online. For the latest accessories and options, visit the HP Notebook Web site (www.hp.com/notebooks).

HP currently offers docking solutions, plug-in modules, cables, and other accessories, such as the following:

• AC adapter.

• Floppy disk drive module.

• External floppy disk drive cable.

• Plug-in modules, such as CD-ROM drive, DVD drive, CD read/write drive, Zip drive,

second hard disk drive.

• Replacement hard disk drive module.

• Main battery.

• Secondary battery.

• External battery charger.

• Docking products.

Reference Guide 13

Getting Started with Your HP Notebook

Taking Inventory

To find more information

The following table lists other sources of information about your computer and related products.

Source Description and Location

Startup Guide

Online Reference Guide

Online HP Notes

Microsoft Windows manual

HP Notebook Web Site

HP Customer Care Web Site

Corporate Evaluator’s Guide

This printed manual introduces your computer. It also contains setup instructions, basic operation guidelines, troubleshooting information, and warranty information.

The full Reference Guide is shipped on the computer’s hard drive, and provides a complete source for operating and maintaining the computer. Look in the online HP Library, or on the Recovery CD in \hp\Library. For Windows XP, the HP Library is in the Help and Support Center.

For late-breaking information available after the manuals were completed, see the HP Notes in the online HP Library, or on the Recovery CD in \hp\Library.

This is shipped with your computer and contains information about using the version of Microsoft Windows shipped with your computer.

www.hp.com/notebooks. www.europe.hp.com/notebooks (European mirror).

www.hp.com/go/support.

This provides information about installing alternate operating systems, as well as how to configure your notebook computer in a corporate, networked environment. Located at the HP Customer Care Web site.

14 Reference Guide

Getting Started with Your HP Notebook

Identifying Parts of the Computer

Front View

1. One-Touch buttons.

2. Sleep button. Suspends and resumes operation.

3. Keyboard status lights (left to right: Caps Lock, Num Lock, Keypad Lock, Scroll Lock).

4. Power slide button. Turns the computer on and off.

5. Built-in microphone.

6. Pointing stick (pointing device).

7. Touch pad, click and scroll buttons.

8. Main status lights (left to right): power mode, hard disk activity, charging status for main battery, and charging status for secondary battery.

Reference Guide 15

9. Module eject latch.

10. Volume control.

11. Audio-off button and audio-off light.

12. Audio jacks (left to right): audio out (headphones), external microphone, audio in.

13. Infrared port.

14. S-video port (TV-out).

15. System-off switch.

16. Kensington lock slot (security connector).

17. Computer open/close latch.

Getting Started with Your HP Notebook

Identifying Parts of the Computer

Back View

18. PS/2 keyboard or PS/2 mouse port (supports Y adapter).

19. Two universal serial bus ports (USB).

20. Serial port (COM1). Use this port for a serial mouse, modem, printer, or other serial device.

21. Parallel port (LPT1). Use this port for a parallel printer or other parallel device, or to connect the floppy disk drive externally.

22. External monitor port.

23. Docking port.

24. AC adapter jack.

25. Modem port (on certain models).

26. LAN port.

27. PC Card and CardBus slots (upper and lower).

28. Wireless on-off button and indicator light (on certain models).

16 Reference Guide

Getting Started with Your HP Notebook

Identifying Parts of the Computer

Bottom View

29. Plug-in module bay. Can contain a CD-ROM or DVD drive, floppy disk drive, secondary battery, or other plug-in module.

30. Main battery.

31. Main battery latch.

32. Hard disk drive.

33. RAM cover.

34. Mini-PCI cover (no user parts inside).

Reference Guide 17

Getting Started with Your HP Notebook

Identifying Parts of the Computer

Status Lights

The computer includes a number of status lights that report power and battery status, drive activity, and keyboard functions such as Caps Lock and Num Lock.

The following diagram shows the status lights on the front of the computer.

1. Power mode.

• On: the computer is on (even if the display is off).

• Blinking: the computer is in Standby mode.

• Off: the computer is off or in Hibernate mode.

2. Hard disk drive activity.

• On: computer is accessing the hard disk drive.

3. Main battery status.

• Green: the AC adapter is connected and the battery is fully charged.

• Amber: the AC adapter is connected and the battery is charging.

• Blinking: the AC adapter is connected and the battery is missing or has a fault.

• Off: the AC adapter is not connected.

4. Secondary battery status.

• Green: the AC adapter is connected and the battery is fully charged.

• Amber: the AC adapter is connected and the battery is charging.

• Blinking: the battery has a fault.

• Off: the AC adapter is not connected, a secondary battery is not installed, or the

battery is not charging.

18 Reference Guide

Getting Started with Your HP Notebook

Identifying Parts of the Computer

The keyboard status lights, located above the keyboard, indicate the states of the keyboard locks.

1. Caps Lock. Caps Lock is active.

2. Num Lock. Num Lock is active. (The Keypad Lock must also be on to use the embedded keypad.)

3. Keypad Lock. The embedded keypad is active (Fn+F8). Num Lock must also be on for the numeric keys—otherwise, cursor control is active (as marked on an external keyboard).

4. Scroll Lock. Scroll Lock is active.

Reference Guide 19

Getting Started with Your HP Notebook

Setting Up Your Computer

WARNING

Improper use of keyboards and other input devices has been associated with ergonomic injury. For information about reducing your risk, see Working in Comfort in the online HP Library, or visit our ergonomics Web site, www.hp.com/ergo. For a summary about working with a notebook computer, see “Working in Comfort with a Notebook PC” on page 43.

If you are using your notebook computer as your primary computer, or using it for extended periods, you should use it with a full-size keyboard, monitor, and mouse. HP docking accessories offer quick, easy connections to these devices. This can reduce the risk of ergonomic injury. See Working in Comfort in the online HP Library.

When you set up your computer for the first time, you’ll install and charge the battery, connect the AC adapter, turn on the computer, and run the Windows setup program.

Step 1: Install the battery

Do not mutilate or puncture batteries. Do not dispose of batteries in fire, or they can burst or explode, releasing hazardous chemicals. Rechargeable batteries must be recycled or disposed of properly.

Your computer is shipped with the battery installed. If the battery has been removed, you should install it:

1. Turn the computer upside down.

2. Insert the front (rounded) end of the battery into the battery compartment on the bottom of the computer, and lower the back end in until it clicks into place.

20 Reference Guide

Getting Started with Your HP Notebook

Setting Up Your Computer

To remove the battery

1. Before removing the battery, do one of the following:

• Shut down the computer or put it into Hibernate mode.

• Plug in the AC adapter.

2. Slide the battery’s release latch, then lift the battery out of its compartment.

Reference Guide 21

Getting Started with Your HP Notebook

Setting Up Your Computer

Step 2: Connect AC power

CAUTION

Use only the HP AC adapter included with your computer (or other approved adapter). Using any other AC adapter could damage the computer and may void your warranty (see the warranty statement in this manual).

• Plug in the AC adapter, and connect it to the AC adapter jack on the back of the computer. The computer’s battery then starts charging.

While the battery is charging, you can continue with step 3.

22 Reference Guide

Getting Started with Your HP Notebook

Setting Up Your Computer

Step 3: Connect a phone line

If your computer does not include a built-in modem, you can skip this step. Also, if you prefer, you can instead connect to a PC Card modem or an external modem.

1. Make sure the telephone line is an analog line, sometimes called a data line. (You must not use a digital line.)

2. Connect the telephone cord into a telephone jack. If the plug on the phone cord doesn’t fit the jack, you may need to use an adapter.

3. Plug the other end of the phone cord into the built-in modem.

For details about using the modem, see “Using the Modem” on page 60.

Reference Guide 23

Getting Started with Your HP Notebook

Setting Up Your Computer

Step 4: Turn on the computer

• Press the blue sleep button above the keyboard. The computer then boots up, and Windows starts automatically.

Hint

If your computer does not turn on when operating on battery power, the battery may be out of power. Plug in the AC adapter and press the blue sleep button again. Leave the AC adapter plugged in for at least an hour—or 2–3 hours to charge it fully.

Step 5: Set up Windows

Your notebook computer has Microsoft Windows preinstalled on its hard disk drive. The first time you turn on your computer, the Windows Setup program runs automatically so you can customize your setup.

1. Follow the Setup program’s instructions as they appear on the screen. If the program prompts you to enter the Product ID code, you will find this code on the bottom of the computer.

2. If your computer has a modem, check the modem’s country or region settings:

• Windows 98: click Start, Settings, Control Panel, double-click Modems, then

click Dialing Properties.

• Windows 2000: click Start, Settings, Control Panel, double-click Phone and

Modem Options, then click Edit on the Dialing Rules tab.

• Windows XP: click Start, Control Panel, Printers and Other Hardware, Phone and

Modem Options, then click Edit on the Dialing Rules tab.

24 Reference Guide

Getting Started with Your HP Notebook

Setting Up Your Computer

Step 6: Register your notebook

Be sure to register your computer. Registering is free and fast, and ensures you will receive quicker, more personalized support. The information you provide during registration allows us to provide you with better products and services.

Registering your computer does the following:

• Records your ownership of the computer with Hewlett-Packard and provides access to service, support, and information.

• Records your ownership of the Windows 98 or XP operating system with Microsoft. If you have Windows 2000, please contact Microsoft separately to register the operating system.

You can register while setting up Windows, or later in any of three ways: by modem, by phone, or by fax. For some countries and models, an HP notebook registration icon is available on the desktop.

By modem

If your computer does not have a built-in modem, you can register after you set up a PC Card modem or an external modem—or you can register by phone or fax.

• If you are not prompted to register, you can click the Register button in the welcome screen. Make sure the phone line is connected to the modem port and follow the onscreen instructions.

If you choose not to register right away, you can do so by modem later by doubleclicking the Registration icon on the desktop (if available). Make sure the phone line is connected and follow the onscreen instructions. The icon disappears after you register.

By phone

You can register by calling your HP Customer Care Center. See “To contact HP for support or service” on page 136 for the phone number.

By fax

If you have a printer connected to your computer, you can print a registration form and fax it to HP. Double-click the HP Notebook Registration icon on the desktop (if available), and print the registration form. You will find the fax number on the form.

Reference Guide 25

Getting Started with Your HP Notebook

Setting Up Your Computer

What to do next

Here are a few things you may want to try at this point:

• If you’re not familiar with the version of Windows installed on your computer, click Start, Help (Windows 98 or 2000) or Start, Tour Windows XP, or check the Windows manual to discover what’s new.

• If your computer includes a DVD drive or CD-RW drive, you also received special software for the drive—find the software CD in the box. Click Start, Programs (Windows 98 or 2000) or Start, All Programs, Multimedia (Windows XP)—if the software isn’t listed, install it by inserting the CD in the drive. Follow the instructions displayed—run Setup on the CD if it doesn’t run automatically.

See the online Reference Guide to learn more about using and maintaining your computer.

To connect to the Internet

If you are connected to a wired or wireless LAN with Internet access or your computer has a modem (built-in, PC Card, or external), you can connect to the Internet. For details, see “Using the Modem” on page 60, “Connecting to a LAN” on page 68, or “Making Wireless Connections” on page 69.

26 Reference Guide

Basic Operation

Reference Guide 27

Basic Operation

Operating Your Computer

You can start and stop your computer using its blue sleep button. However, at certain times you may want to use other methods to start or stop the computer—depending on power considerations, types of active connections, and start-up time.

To turn the computer on and off

Power mode To enter this mode

On mode

Power mode status light is green.

Standby mode Saves significant power. Turns off the display and other components. Maintains current session in RAM. Restarts quickly. Restores network connections. Power mode status light is amber.

Hibernate mode Saves maximum power. Saves current session to disk, then shuts down. Restores network connections. Power mode status light is off.

Shut down (off) Saves maximum power. Turns off without saving current session. At startup, resets everything, starts a new session, and restores network connections. Power mode status light is off.

To turn on: Press the blue sleep button to restart, or to resume your session from Standby or Hibernate mode.

You can also customize the way these power modes work. See “How the computer manages power automatically” on page 50.

Press the blue sleep button.

Press blue sleep button –or– click Start, Shut Down, Standby (Windows 98 or 2000) –or– click Start, Turn Off Computer, Stand By (Windows XP) –or– allow timeout.

Press Fn+F12 –or– click Start, Hibernate (Windows 98) –or– click Start, Shut Down, Hibernate (Windows 2000) –or– allow timeout.

Click Start, Shut Down, Shut down (Windows 98 or 2000) –or– click Start, Turn Off Computer, Turn Off (Windows XP) –or– slide the power button (only if the Start menu procedure doesn’t work).

28 Reference Guide

Basic Operation

Operating Your Computer

To reset the computer

Occasionally, you may find that Windows or the computer has stopped responding, and will not let you turn the computer off. If this happens, try the following in the order listed.

• If possible, shut down Windows:

Windows 98 or 2000: press CTRL+ALT+DEL, click Shut Down, and press the blue sleep button to restart.

Windows XP: press CTRL+ALT+DEL, then click Shut Down, Restart.

–or, if this fails–

• Slide and hold the power button for 4 seconds, until the display shuts down, then press the blue sleep button to restart.

–or, if this fails–

• Insert a straightened paper clip into the system-off switch on the right side of the computer, then press the blue sleep button to restart.

Reference Guide 29

Basic Operation

Operating Your Computer

To change the boot device

The computer normally boots from its internal hard disk. You can also boot the computer from a floppy disk drive in the module bay, a CD-ROM or similar drive in the module bay, or an internal network interface card (Intel Boot Agent).

1. Click Start, Shut Down (or Turn Off Computer), Restart.

2. When the HP logo appears, press ESC to display the Boot menu.

3. Use the arrow keys to select the boot device, and press ENTER.

If you want to boot from a specific device whenever it is present, change the boot order using the BIOS Setup utility—see “To run the BIOS Setup utility” on page 125.

To use the pointing devices

Your computer includes two built-in pointing devices: the pointing stick and touch pad.

1. Pointing stick (pressure-sensitive pointing device).

2. Click buttons and scroll button. The click buttons work like the left and right buttons on a standard mouse. The scroll button scrolls the contents of a window.

3. Touch pad (touch-sensitive pointing device).

4. Click buttons. These also work like the left and right buttons on a standard mouse.

You can use Mouse in Control Panel or the touch pad icon in the taskbar to customize the operation of your computer’s pointing devices (pointing stick, touch pad, and external mouse): you can change the left, right, and scroll button actions, double-click speed, pointer speed, and more.

30 Reference Guide

Basic Operation

Operating Your Computer

Moving and selecting

1. Place your hands in a normal typing position.

2. Pointing stick. With your index finger, press the pointing stick in the direction you want the pointer to move.

Touch pad. Move a thumb or finger across the touch pad in the direction you want the pointer to move.

3. Use the left and right click buttons, which function like the left and right buttons on a mouse, to make your selection:

• To open an application, move the pointer over the icon and double-click the left

button.

• To make menu selections, move the pointer to the menu item and click the left

button.

• To open the shortcut menu for an item, move the pointer over the item and click

the right button.

• To drag an item, move the pointer over the item. Then press and hold the left

button while you move the pointer to the new location, and release the button.

In addition, you can tap the touch pad to select items and use other advanced touch pad features. For more information, double-click the touch pad icon in the taskbar, then click Help in the tab for a particular feature.

Scrolling with the scroll button

• Press the lower end of the scroll button to scroll down through the contents of a window. Press the upper end to scroll up.

Disabling one pointing device

If you prefer to use only one of your computer’s built-in pointing devices, you can disable the other. We recommend this practice to optimize performance. For example, if you notice that your hand inadvertently contacts the touch pad and moves the cursor while you’re typing, consider disabling the touch pad.

1. Click Start, Settings, Control Panel, then double-click Mouse (Windows 98 or 2000), or click Start, Control Panel, Printers and Other Hardware, Mouse (Windows XP).

–or–

Double-click the touch pad icon in the taskbar.

Reference Guide 31

Basic Operation

Operating Your Computer

2. Click the TouchPad tab, and select the device you want to disable from the pull-down menu.

3. Select Disable This Device near the bottom of the window.

4. Click OK.

To use the Fn hot keys

The combination of the Fn key plus another key creates a hot key—a shortcut key sequence—for various system controls. To use a hot key, press and hold Fn, press the appropriate second key, then release both keys.

This hot key Does this

Fn+F1 Decreases the display brightness.

Fn+F2 Increases the display brightness.

Fn+F5

Fn+F7 Audio mute.

Fn+F8

Fn+F12 Enters Hibernate mode.

Fn+NumLock Toggles Scroll Lock on and off.

Toggles among the built-in display, an external display, and simultaneous display on both.

Toggles the built-in keypad on and off. Does not affect an external keyboard. If Num Lock is on, then the numeric functions are active; otherwise, cursor control is active (as marked on an external keyboard).

External PS/2 keyboards support only Fn+F5, Fn+F7, and Fn+F12. To use these, press and hold left CTRL+left ALT, press the appropriate second key, then release both keys. A USB keyboard does not support Fn hot keys.

32 Reference Guide

Basic Operation

Operating Your Computer

To use the One-Touch buttons

Your computer includes four One-Touch buttons that can start any application or open a document or web site with a single press.

• Press the One-Touch button to open the corresponding application, document, or web site.

Your computer is preconfigured to access the following services:

1. Internet web site (if you have an Internet provider)

2. Outlook Express e-mail software

3. HP Presentation Ready

4. Button 4 (varies by region)

To reprogram a One-Touch button

1. Click Start, Settings, Control Panel, then double-click Keyboard (Windows 98 or

2000), or click Start, Control Panel, Printers and Other Hardware, Keyboard (Windows XP).

2. On the One-Touch tab, click the button you want to reprogram.

3. Type a label for the button, then select the application, document, folder, or web site you want the button to open.

4. If you want a label to appear onscreen when you press a One-Touch button, select that option on the Onscreen Display tab.

Reference Guide 33

Basic Operation

Operating Your Computer

To use the Windows and Applications keys

The Windows key brings up the Windows Start menu. This is the same as clicking the Start button on the taskbar.

The Applications key brings up the shortcut menu for the current application. This is the same menu that appears when you right-click while pointing at the application.

This key combination Does this

Windows key+E Runs Windows Explorer.

Windows key+F1 Runs Windows Help.

Windows key+F Runs Windows Find: File or Folders (Windows 98 or 2000) or Search (Windows XP).

Windows key+M Minimizes all displayed windows.

Shift+Windows key+M Returns all minimized windows to original size.

Windows key+R Runs the Windows Run dialog box.

To use the embedded keypad

Your computer’s built-in keyboard includes an embedded keypad you can use to type numbers and arithmetic operators. The keys in this keypad are marked using light gold characters.

• Press Fn+F8 to turn on the embedded keypad.

• Hold Fn while typing a key to turn the embedded keypad on temporarily.

When the embedded keypad is active, you can use Num Lock to change how the keypad functions:

• Num Lock on: the keys enter the numbers and arithmetic operators printed in light gold on the keyboard.

• Num Lock off: the keys act as cursor control keys, as marked on an external keyboard.

34 Reference Guide

Basic Operation

Operating Your Computer

To use the ALT GR key

Non-U.S. keyboards have an ALT GR key to the right of the spacebar. This is a shift key that provides access to certain special keyboard characters.

• For a character in the lower-right corner of a key, press and hold ALT GR to type the character.

Hint

1. Shifted.

2. Unshifted.

3. ALT GR.

To adjust the display

Changing the brightness

• Press Fn+F1 or Fn+F2 to decrease or increase (respectively) the display’s brightness.

–or–

• Click Start, Programs, HP Display Settings, HP Display Settings (Windows 98 or

2000) or Start, All Programs, Hewlett-Packard, Notebook, HP Display Settings, HP Display Settings (Windows XP). You have the option of adding a display settings icon in the taskbar for quick access.

To maximize your battery operating time, set the brightness to the lowest level you can view comfortably.

Changing display settings

You can customize a number of display settings for your computer, such as color depth and screen area.

1. Click Start, Settings, Control Panel, then double-click Display (Windows 98 or 2000), or click Start, Control Panel, Appearance and Themes, Display (Windows XP).

2. Click the Settings tab, then make the settings you want.

Reference Guide 35

Basic Operation

Operating Your Computer

The computer has an LCD display, which behaves differently from a normal computer monitor. If you change the display resolution, the desktop changes size, but the objects on it do not. You normally won’t change the resolution except to use an external monitor.

Changing icon and label sizes

To enlarge icons and labels on your screen when using a high-resolution display, use HP Desktop Zoom.

• Click Start, Programs (or All Programs), Hewlett-Packard, Notebook, Desktop Zoom, Desktop Zoom. If this program is not installed on your computer, you can download it from the HP Customer Care Web site (www.hp.com/go/support).

Using an external monitor

If you want, you can attach an external monitor to your notebook computer. See “To use an external monitor” on page 86.

To adjust the volume

From the computer

• To increase the volume, press the rear half of the volume control on the right side of the computer.

• To decrease the volume, press the front half of the volume control.

• To toggle the standard mute function, press Fn+F7.

With the audio-off button

Your computer includes an audio-off button you can use to temporarily disconnect the speakers without changing the volume or mute settings. This feature is handy when you want to block all speaker output regardless of what your computer is doing.

• To toggle the speaker connection on and off, press the audio-off button on the right side of the computer. The audio-off light turns on when the speakers are disconnected.

In Windows

1. Click the Volume icon in the taskbar (if not present, see Windows Help).

2. Drag the volume control bar up or down to adjust the volume.

3. To temporarily silence the speakers without changing the volume setting, click Mute.

36 Reference Guide

Basic Operation

Operating Your Computer

To change computer settings for a presentation

When you show a presentation to an audience, you’ll often want to adjust some of your video and power settings for the show. You can easily do this with HP Presentation Ready, an application that automatically adjusts your computer for slide shows and similar presentations, and also opens the presentation itself. Once the presentation is through, HP Presentation Ready automatically returns your computer to its normal settings.

To prepare for the presentation

1. Click Start, Programs (or All Programs), Hewlett-Packard, Notebook, HP Presentation Ready, Configure.

–or–

Click the HP Presentation Ready icon in the taskbar (if present), then click Configure.

2. Select the presentation you want to show. If you don’t select one, you can choose one when you start the show.

3. If you want to change the video or power settings for the show, click Settings.

To show the presentation

• Press the HP Presentation Ready One-Touch button.

–or–

Click Start, Programs, Hewlett-Packard, Notebook, HP Presentation Ready, Start Presentation (Windows 98 or 2000) or Start, All Programs, Hewlett-Packard, Notebook, HP Presentation Ready, Start Presentation (Windows XP).

–or–

Click the HP Presentation Ready icon in the taskbar (if present), then click Start Presentation.

To adjust settings during the presentation, press the One-Touch button or click the taskbar icon and choose Configure.

To end the presentation and restore the computer’s normal settings, close the presentation application or click the taskbar icon and choose Stop Presentation.

Reference Guide 37

Basic Operation

Operating Your Computer

To work with CDs and DVDs

If you have a DVD drive module, you can play DVD movies—see “To play DVD movies” on page 80. If you have a CD-RW drive module, you can write and copy CDs— see “To create or copy CDs” on page 80.

38 Reference Guide

Basic Operation

Securing Your Computer

To set up password protection

You can protect your computer from access by another user when you set up password protection, which is available through Windows and through the BIOS Setup utility. For complete protection, set passwords in Windows as well as through BIOS Setup.

To cancel password protection, set an empty password.

BIOS Setup Utility

1. Click Start, Shut Down (or Turn Off Computer), Restart.

2. When the HP logo appears, press F2 to enter BIOS Setup.

3. From the Security menu, enter or modify the Administrator Password or User Password as needed. See “Security Menu” on page 128.

4. Press F10 to save and exit BIOS Setup.

Windows 98

1. Click Start, Settings, Control Panel, then double-click Passwords.

2. Click the Change Passwords tab, then click Change Windows Password and set a password.

3. Click Start, Settings, Control Panel, then double-click Power Management.

4. On the Advanced tab, select the option to prompt for a password when the computer leaves Standby mode.

Windows 2000

1. Press CTRL+ALT+DEL, then select option to change password.

2. Create or modify your Windows password.

3. Click Start, Settings, Control Panel, then double-click Power Options.

4. On the Advanced tab, select the option to prompt for a password when the computer leaves Standby mode.

For Windows 2000, to protect against unauthorized undocking while the computer is running, press CTRL+ALT+DEL and click Lock Computer before leaving it unattended, or set up a screen saver with a password in Control Panel Display.

Reference Guide 39

Basic Operation

Securing Your Computer

Windows XP

1. Click Start, Control Panel, User Accounts, then select your account.

2. Click Create a Password, then set the password.

3. Click Start, Control Panel, Performance and Maintenance, Power Options.

4. On the Advanced tab, select the option to prompt for a password when the computer leaves Standby mode.

For Windows XP, to protect against unauthorized undocking while the computer is running, set up a screen saver with a password in Control Panel Display.

To attach a security cable

Your computer includes a built-in connector you can use to secure the computer with a cable and a lock (such as the Kensington MicroSaver lock system, available at many computer stores).

1. Wrap the cable around a secure object, such as a table leg.

2. Loop the cable to create a slip knot around the stationary object, and make sure it can’t slip off.

3. Insert the lock into the security connector on the right side of the computer and release the key. Store the key in a safe place away from the computer.

40 Reference Guide

Basic Operation

Securing Your Computer

To protect against viruses

Virus-protection software can help protect the integrity of your data. This is especially important if you use the Web.

Your computer comes equipped with VirusScan or Norton AntiVirus software. If you have VirusScan, you must install it before you can use it.

1. Click Start, Programs, VirusScan, Setup.

2. Follow the instructions as they appear on the screen.

Once installed, you can get detailed instructions from the software’s online Help.

To set PC identification

Pavilion models

HP TopTools and PC identification are not supported on Pavilion models.

You must have BIOS administrator password authority to set a PC identification number.

1. If you have not already installed HP TopTools, do so now. See “To set up TopTools” on page 131.

2. Click Start, Programs (or All Programs), HP TopTools, HP TopTools, then click Security.

3. In the “Identification String” box, type a unique set of characters that will identify your PC. You can type up to 80 characters including spaces and special characters. Do not press ENTER when typing.

4. Click Apply.

5. Type your BIOS administrator password and press ENTER.

Reference Guide 41

CAUTION

Basic Operation

Securing Your Computer

To lock the hard disk drive

The computer enables you to lock its internal hard disk drive to help keep your information secure. Hard disk drive lock does not protect a second hard disk drive installed in the module bay.

When you enable hard disk drive lock, the current BIOS user password (or administrator password if that is the only password set) is encoded on the hard disk drive.

If you move the hard disk drive to another computer, you can’t access the drive until you set the user (or administrator) password to match the drive’s password. After you

match the drive’s password, you can change the computer (and drive) password. If you forget the password, you cannot recover your data.

1. Click Start, Shut Down (or Turn Off Computer), Restart.

2. When the HP logo appears, press F2 to enter the BIOS Setup utility.

3. From the Security menu, enable Password Required to Boot.

4. From the Security menu, enable Internal hard disk drive lock.

5. Press F10 to save and exit BIOS Setup.

42 Reference Guide

Basic Operation

Working in Comfort with a Notebook PC

WARNING

Note

Improper use of keyboards and other input devices has been associated with ergonomic injury. For more information about reducing your risk, visit our ergonomics Web site at www.hp.com/ergo—or see Working in Comfort in the online HP Library.

You can use your HP notebook computer virtually anywhere, anytime. The following recommendations should help you work more comfortably.

Note that if you are using your portable computer as your primary computer, or using it for extended periods, you should use it with a full-size keyboard, monitor, and mouse. This will give your portable computer the adjustability and comfort features of a desktop unit. HP docking accessories offer quick, easy connections to these devices. More information on how to prepare your workspace environment and set up your HP equipment is available in Working in Comfort, which is preloaded on the hard disk in the HP Library and available on the Recovery CD in \hp\Library—as well as at www.hp.com/ergo.

Your Mobile Work Environment

• Use a chair that provides good support for your lower back. If an adjustable chair is not available, you can use a pillow or rolled-up towel to provide lower back support.

• Try to keep your thighs parallel to the floor and your feet flat on the floor. In a mobile environment, you can do this by using a phone book or briefcase to support your feet.

• Adjust the height of either your work surface or chair to keep your arms in a neutral position. Your arms should be relaxed and loose, elbows at your sides, with the forearms and hands parallel with the floor.

• Position your notebook computer display to minimize glare and reflection. For example, on an airplane, lower the window shade, or in a hotel room, draw the curtains. You also should maintain a comfortable viewing distance–approximately 40 to 60 cm (16 to 24 inches). Adjust the angle of your display to help keep your head angled slightly downward in a comfortable position.

Reference Guide 43

Basic Operation

Working in Comfort with a Notebook PC

Using Your Mobile Computer

• Position the computer so your wrists and hands are in a neutral position. Your wrists should be as straight as possible and should not have to bend sideways or more than 10 degrees up or down. If your notebook computer does not have a built-in palm rest, you can use a rolled-up towel.

• Try to type as lightly as possible. The notebook keyboard requires little force to activate.

• Take frequent, short rest breaks–this is especially important in a mobile computing environment.

• Portable computers weigh between approximately 1.4 and 3.7 kilos (3 and 8 pounds). When traveling, be sure to carry your computer properly to minimize strain on your body. Shift the bag containing your notebook equipment frequently between your left and right hands and shoulders.

44 Reference Guide

Basic Operation

Taking Care of Your Computer

Use the following recommendations to maintain your computer during everyday use and prevent potential physical damage or data loss.

To protect your hard disk drive

Hard disk drives, as well as other internal components, are not indestructible and can be damaged by inappropriate handling and operation.

• Avoid bumps or jolts.

• Do not operate the computer while traveling over bumpy terrain.

• Suspend or shut down the computer before transporting it. This turns off the hard

drive. A drop of a few inches onto a rigid surface while the hard drive is operating could destroy data or damage the drive.

• Carry the computer in a padded case to protect against bumps and jolts.

• Set down the computer gently.

To maintain your computer

• Provide adequate ventilation around the computer. Always set the computer on a flat surface, so that air can flow freely around and underneath it.

• Always shut down the computer or put it in Hibernate mode before putting it in a carrying case or other enclosed space.

• Do not pick up or carry the computer by its display.

• Observe the temperature limits and other specifications listed in “Hardware

Specifications” on page 144. Do not use the computer outside in the rain or snow (inclement weather). If the computer is cold, warm it gradually to avoid condensation.

Reference Guide 45

Basic Operation

Taking Care of Your Computer

To safeguard your data

• Do not use a pointing device or activate any other device that interrupts operation while the system is starting or stopping.

• Back up your work regularly. Copy files to floppy, tape, or network drives.

• Use a virus-scanning program (such as the VirusScan or Norton AntiVirus program

included with your computer) to check the integrity of your files and operating system. Since new viruses appear frequently, you will also want to update the program’s virus definitions from time to time; updates are on the Web at www.networkassociates.com for VirusScan, or www.symantec.com for Norton AntiVirus.

• Check your disk using the scandisk utility (Windows 98) or the Tools tab in the disk’s Properties window (Windows 2000 or XP).

To extend the life of the display

• Set the display brightness to the lowest comfortable level (Fn+F1).

• When working at your desk, connect an external monitor and turn off the internal

display (Fn+F5).

• If you are not using an external monitor, set the Turn off monitor timeouts (for both AC and battery operation) to the shortest comfortable interval.

• Avoid using a screen saver or other software that prevents the computer from changing to Display-off or Standby mode after a timeout period. If you use a screen saver, enable the option to shut off the display after a time delay.

• Do not disable Display-off or Standby timeouts.

• If you are using AC power and have no external monitor attached, put the computer in

Display-off or Standby mode when not in use.

46 Reference Guide

Basic Operation

Taking Care of Your Computer

To clean your computer

• You can clean the computer with a soft cloth dampened with clean water or with water containing a mild detergent. Do not use an excessively wet cloth, and take care to keep water out of the case.

• Do not use abrasive cleaners, especially on the display. Do not apply any cleaner directly to the display. Instead, apply the cleaner to a soft cloth and then gently wipe the display.

• You can clean the keyboard with a vacuum cleaner to remove accumulated dust.

Reference Guide 47

Batteries and Power Management

Reference Guide 49

Batteries and Power Management

Managing Power Consumption

When you’re running your computer on battery power, you will want to maximize operating time without compromising performance. Your computer is designed to help you reduce power consumption and extend battery life without needing to turn it off.

• During idle periods, the computer automatically enters power-saving modes after specified timeout periods. You can adjust these timeouts to suit your working habits.

• You can manually send the computer into a power-saving mode at any time by pressing the appropriate key—see “To manage power manually” on page 53.

How the computer manages power automatically

Your computer automatically enters Hibernate mode and Standby mode, and turns off the hard disk and display based on values set in Power Options or Power Management in Control Panel or in the BIOS Setup utility.

Automatic action Occurs after… To resume…

Turns off hard disk.

Turns off the hard disk drive. This is usually set to occur shortly after the display is turned off.

Turns off display.

Turns off the display to conserve battery power and extend the life of the display.

Enters Standby mode.

Maintains your current session in RAM, and turns off the display and other components to conserve battery power.

Enters Hibernate mode. Saves your current session to the hard disk, then turns off the computer.

Lowers CPU speed (SpeedStep only). Switches to the lower CPU speed to use power more efficiently. See below.

The hard disk is not accessed for the specified interval.

No keyboard, pointing device, or other input activity occurs for the specified interval.

No pointing devices are used, no disk drive is accessed, and no port (serial, parallel, or IR) is active for the specified interval.

The computer stays in Standby mode for the specified interval.

The AC adapter is unplugged. Plug in the AC adapter.

Begin using the computer: the hard disk turns on when needed.

Press any key or move a pointing device to turn on the display.

Press the blue sleep button to return to your current session.

Press the blue sleep button to restore your previous session.

50 Reference Guide

Batteries and Power Management

Managing Power Consumption

CAUTION

Make a habit of saving your work before allowing your computer to enter Standby mode. If power is interrupted while the computer is in Standby mode, any information that was not saved will be lost.

The computer can also enter Hibernate mode if battery power reaches a critically low level. (See “To respond to a low-battery warning” on page 55.) If this happens, you will find on resuming that all your data has been saved, but some functions may be disabled. To resume normal operation, restore power by connecting an AC adapter or installing a charged battery, then shut the computer off and restart it.

Changing timeout settings and creating power schemes

You can adjust the periods of non-use after which your computer automatically shuts down components or enters a power-saving mode. You can also save these settings as a power scheme.

1. Open Power Options or Power Management in Control Panel:

• Windows 98 or 2000: click Start, Settings, Control Panel, then double-click

Power Options (Windows 2000) or Power Management (Windows 98).

• Windows XP: click Start, Control Panel, Performance and Maintenance, Power

Options.

2. Click the Power Schemes tab, and enter the settings you want. If you don’t want a particular timeout to occur, set the value to Never. See Windows Help for details.

If you want to save the settings as a power scheme, click Save As and enter a name for the scheme.

CAUTION

For Windows 98, change the Hibernate timeout in BIOS Setup—see “To run the BIOS Setup utility” on page 125.

For Windows 2000 or XP, do not disable Hibernate support in the Power settings, or you will lose any unsaved data if the computer’s battery runs down completely.

Reference Guide 51

Batteries and Power Management

Managing Power Consumption

Managing CPU power

If your computer contains a multispeed processor with Intel SpeedStep Technology, the taskbar in Windows 98 or 2000 contains an Intel SpeedStep Technology icon. This feature enables the processor to automatically switch to lower, power-saving speeds or to higher-performance speeds according to the workload.

You can customize SpeedStep to best suit your working environment.

• Windows 98 or 2000: Double-click the Intel SpeedStep Technology icon in the taskbar, then select the battery and AC options you want. The Max Battery option uses the lowest processor speeds for maximum battery time. The Auto option uses medium and high processor speeds.

• Windows XP: Click Start, Control Panel, Performance and Maintenance, Power Options. On the Power Schemes tab, select a power scheme. This scheme automatically controls the processor speeds:

• The Max Battery scheme uses the lowest processor speeds while running on

battery power, but uses medium and high processor speeds on AC power.

• The Portable/Laptop option uses medium and high processor speeds on battery

and AC power.

See Windows Help for additional information about power schemes.

52 Reference Guide

Batteries and Power Management

Managing Power Consumption

To manage power manually

In addition to allowing the computer to enter its power-saving modes automatically, you can also put it into any of the following three modes whenever you need to.

Power mode Does this… Use when… To enter this mode…

Standby Maintains your current

session in RAM, and turns off the display and other components.

Hibernate Saves the current session to

disk, then shuts down. Provides maximum power savings while still allowing you to recover the current session.

Off Turns off your computer,

providing maximum power savings. The current session will not be saved, and any unsaved data will be lost.

You will be away from your computer for a short time.

You will be away from your computer for several hours, but want to continue your session.

You’re done with your work.

Press blue sleep button –or– click Start, Shut Down, Standby (Windows 98 or 2000) –or– click Start, Turn Off Computer, Stand By (Windows XP).

Press Fn+F12 –or– click Start, Shut Down, Hibernate (Windows 2000) –or– click Start, Hibernate (Windows 98).

Reference Guide 53

Batteries and Power Management

Using Battery Power

To check battery status

From the battery status lights

Your computer has two battery status lights, one for the main battery and one for an optional secondary battery in the module bay, see “Bottom View” on page 17.

From the Windows taskbar

The Windows taskbar can display a power icon that provides detailed battery status information (see Windows Help for details). The icon looks like a battery when AC is not connected.

• Place the pointer over the power icon to display the remaining battery charge. This value is shown as either a percentage of charge remaining, or as time remaining.

• Double-click the power icon to open the Battery Meter window.

From the Windows Control Panel

• Windows 98 or 2000: click Start, Settings, Control Panel, then double-click Power. This provides access to all of Windows’ power-information options.

• Windows XP: click Start, Control Panel, Performance and Maintenance, Power Options, then click the Power Meter tab to see the battery status. The Alarms and Advanced tabs provide additional Windows’ power-information options.

On the battery

1. Remove the battery from the computer—see “Step 1: Install the battery” on page 20.

2. Press the contact pad on the back of the battery. The number of lights that turn on indicates the remaining charge (each light represents 20% of a full charge).

54 Reference Guide

Note

Batteries and Power Management

Using Battery Power

To respond to a low-battery warning

The computer automatically alerts you when the battery power drops to a critically low level. The computer first emits a high-pitched beep or displays a warning message. Then, if you do not restore power within a short time, the computer goes into Hibernate mode.

Once the computer enters Hibernate mode in this way, you won’t be able to turn it on again until you restore power by doing one of the following:

• Replace the battery with a charged one. See “Step 1: Install the battery” on page 20.

• Plug in the AC adapter. See “Step 2: Connect AC power” on page 22.

• Install a charged secondary battery in the plug-in module bay. See “To use additional

batteries” on page 55.

If you plug in the AC adapter, you can continue to work while your battery recharges.

To recharge the battery

CAUTION

The AC adapter is normally warm whenever plugged into an AC outlet. The computer is normally warm while recharging. Don’t recharge the computer in a briefcase or other confined space, or its battery could overheat.

• To recharge the main battery, plug the AC adapter into the computer.

• To recharge a secondary battery, plug the AC adapter into the computer and insert the

battery into the module bay.

The main battery will recharge first, then the secondary battery will recharge. To get the longest operating time, wait until the battery’s charge is below 50% before

recharging, then charge it fully (100%). Charging can take up to approximately 2 hours. You can continue working while the battery charges.

A fully charged battery can operate the computer for up to approximately 4–5 hours, depending on your computer’s model, power management settings, and level of use.

To use additional batteries

You can install a secondary battery in your computer’s plug-in module bay. See “Using Plug-In Modules” on page 76 for information about installing plug-in modules. For instructions on replacing the main battery, see “Step 1: Install the battery” on page 20.

Reference Guide 55

Batteries and Power Management

Using Battery Power

To get the most from your batteries

Follow these suggestions to make your battery’s power last as long as possible.

• Plug in the AC adapter, especially when using a drive in the module bay, or any external connections such as a PC Card or a modem.

• Set the display brightness to the lowest comfortable level (Fn+F1).

• Put the computer in Standby mode whenever you are not using it for a short while:

press the blue sleep button for approximately one second, or click Start, Shut Down (or Turn Off Computer), Standby.

• Put the computer in Hibernate mode whenever you want to save your current session, but will not be using the computer for several hours: press Fn+F12.

• Set the automatic timeout settings to emphasize saving power. If your computer has a multispeed processor and uses Windows 98 or 2000, use the lower speed on battery power (the default settings conserve battery power)—see “How the computer manages power automatically” on page 50.

• If your computer has a wireless on-off button, turn off the wireless function when you’re not using it. Press the wireless on-off button so the light turns off.

• Change settings in BIOS Setup to emphasize low power use—see “To run the BIOS Setup utility” on page 125. You can set the graphics mode and display backlight to use reduced power.

• If you have an I/O PC Card—that is, a PC Card having an external connection, such as a network card—remove it when you’re not using it. Some I/O cards use significant power even while they’re inactive.

• If you work with an application that uses the serial port or an I/O PC Card, exit the application when you finish using it.

• Install another battery—see “To use additional batteries” on page 55.

• If your main battery is rated at 11.1 volts (check its label), purchase a replacement

main battery, which is rated at 14.8 volts.

56 Reference Guide

Batteries and Power Management

Using Battery Power

In addition, follow these suggestions to extend the life of your batteries.

• Do not leave batteries unused for long periods. If you have more than one, rotate them.

• If you normally use AC power, make a practice of using the battery as your power source at least once a week.

• Unplug the AC adapter when the computer is not in use.

• To preserve the life of a battery, be sure to charge it regularly.

• For long-term storage, the battery must be charged 20–50% to minimize capacity loss

by self-discharge and to avoid deterioration of performance. Storing a fully charged battery can cause higher self-discharge and reduce its discharge capacity—even after recharging—as compared to a battery stored when charged 20–50%.

• To maintain maximum battery capacity and accuracy of the battery gauge, perform this procedure about once a month:

1. Charge the battery to 100%.

2. Disconnect the AC adapter, and use the computer until the battery is fully

discharged and the computer goes into hibernation.

3. Connect the AC adapter and charge the battery to 100% with no power

interruptions.

To maximize processor speed

If your computer contains a multispeed processor with Intel SpeedStep Technology, the processor can automatically switch to lower, power-saving speeds or to higherperformance speeds according to the workload. See “How the computer manages power automatically” on page 50.

Reference Guide 57

Modem and Network Connections

Reference Guide 59

Modem and Network Connections

Using the Modem

If your computer has a modem port, you can connect your modem to a telephone line and communicate with other computers throughout the world. You can explore the Internet, send and receive e-mail messages, and use your PC to send and receive faxes. Your computer contains several software programs that work with your modem:

• Internet Explorer, for browsing the World Wide Web

• Outlook Express, for sending and receiving e-mail messages

• Windows XP Fax Console, Windows 2000 fax software, or QuickLink with Windows

98, for sending and receiving faxes

The modem is a high-speed 56-Kbps modem. For best performance, you can connect to any Internet Service Provider (ISP) or modem network that has V.90 interoperable modems. Check with your ISP for a list of telephone numbers that support V.90.

Note that the maximum speed for faxing is 14.4 Kbps. Even though the modem is capable of downloading at 56 Kbps, your ISP or modem network may not operate at this speed or support this technology. Please check with your service provider for information on its capabilities. Furthermore, download transmission rates depend on the condition of the telephone line.

CAUTION

To connect the modem

To reduce the risk of fire, use only No. 26 AWG or larger telecommunications line cord to connect the modem to the telephone wall jack.

1. Check that the telephone line is an analog line, sometimes called a data line. (You must not use a digital line.)

2. Connect a telephone cord with an RJ-11 plug into a telephone jack. If the plug on the phone cord doesn’t fit the jack, you may need to use an adapter.

60 Reference Guide

Modem and Network Connections

Using the Modem

3. Plug the other end of the phone cord the built-in modem.

CAUTION

4. Check your modem’s country or region settings:

• Windows 98: click Start, Settings, Control Panel, double-click Modems, then

click Dialing Properties.

• Windows 2000: click Start, Settings, Control Panel, double-click Phone and

Modem Options, then click Edit on the Dialing Rules tab.

• Windows XP: click Start, Control Panel, Printers and Other Hardware, Phone and

Modem Options.

Your built-in modem may not work with multiple phone lines or a private branch exchange (PBX), cannot be connected to a coin-operated telephone, and does not work with party lines. Some of these connections may result in excess electrical voltage and could cause a malfunction in the internal modem. Check your telephone line type prior to connecting your phone line.

Special restrictions in certain countries

• Many countries impose a blackout period after a modem repeatedly fails to connect to a service provider. The number of failed attempts and the period you must wait before trying again differ from country to country: check with your telephone company.

For example, if you are dialing from Italy and fail to connect to your server or cancel the connection, you must wait one minute before dialing that number again. If you dial before then, you will get an error message that says “delay.” After the fourth failed connection, you must wait one hour before trying the number again. If you dial before the hour is up, you will get a message that says “black list.”

Reference Guide 61

Modem and Network Connections

Using the Modem

• When using a modem in the Republic of South Africa, an external surge protector may be necessary in order to prevent computer damage by lightning or other electrical surges. Connect any approved surge protector to the modem cable whenever you are using the modem.

To connect to the Internet

Signing up with an Internet Service Provider

Before you can connect to the Internet, you need to set up an account with an Internet Service Provider (ISP). For some countries and models, Hewlett-Packard provides easy Internet signup so that you can connect quickly to an ISP.

1. Connect your built-in modem—see the previous topic. (If your computer does not have a built-in modem, you can instead use a PC Card modem or an external modem.)

2. If available, double-click the Connect to the Internet or Easy Internet Signup icon on the desktop. This launches the Internet Connection or New Connection wizard, which helps you locate an ISP in your area, transfer an existing Internet account to this computer, or set up an Internet connection manually.

–or– If available, click Start, Programs, Online Services (Windows 98 or 2000) or Start,

All Programs, Easy Internet Signup (Windows XP), and select one of the listed ISPs. This begins the registration process for the ISP you choose.

Connecting to the Internet

1. Double-click the Internet Explorer icon on the desktop. For your first connection, you’ll be prompted for information about your connection.

2. Click the Connect button in the Dial-up Connection or Network Connections window.

For Windows 98 or 2000, when you are successfully connected to the Internet, you’ll see a connect icon (two connected computers) in the taskbar. For Windows XP, to display an icon for your connection, open Network Connections in Control Panel, right-click the connection, select Properties, and select the icon option.

62 Reference Guide

Modem and Network Connections

Using the Modem

To disconnect from the Internet

You remain connected to the Internet until you shut down the computer, disconnect the phone line from the computer, or give a command to hang up the connection.

• Double-click the connect icon in the taskbar, and click Disconnect. (For Windows XP, you can enable this icon as described in “To connect to the Internet,” above.)

–or– For Windows XP, click Start, Control Panel, Network and Internet Connections,

Network Connections, then right-click the connection and select Disconnect.

To dial in to a network

You can use the modem to dial in to a LAN (local area network) that supports dial-in connections. This gives you access to network resources from a remote location.

• See Windows Help for information about setting up and using dial-in network connections—click Start, Help (or Help and Support).

To change your modem settings

The modem is already set up to be compatible with telephone systems and modems in most areas. However, in some situations, you may have to change modem settings to match local conditions. If you have questions about local requirements, contact your telephone company.

• Control Panel. Open Modems (Windows 98) or Phone and Modem Options (Windows 2000 or XP) in Control Panel to change many modem settings.

For Windows 98, on the General tab click Properties to set connection speeds or special dialing options.

For Windows 2000 or XP, on the Modems tab click Properties to set connection speeds, or on the Dialing Rules tab click Edit to set dialing options.

• Communications software. Many communications applications provide options for controlling modem settings. See the help for your software.

Reference Guide 63

Modem and Network Connections

Using the Modem

• AT commands. You can control many aspects of modem operation using modem AT commands. AT commands are special strings of characters sent to the modem to set up specific conditions. Those command strings normally start with “AT”. For a list of AT commands for the built-in modem, see “Modem Reference Information” on page 147.

For Windows 98, open Modems in Control Panel. On the General tab, click Properties, then on the Connections tab click Advanced. You can type AT commands in the space for extra settings.

For Windows 2000 or XP, open Phone and Modem Options in Control Panel. On the Modems tab, click Properties. You can type AT commands on the Advanced tab in the space for extra settings.

For example, to force a built-in Ambit modem to connect with the V.34 modulation, you can use the +MS command as shown in table of AT commands—type AT+MS=11 in the space for extra settings.

To send and receive e-mail

Sending and receiving e-mail requires an e-mail account with an Internet Service Provider or with your company’s communications system. If you are using AOL, e-mail services are part of your AOL service. For another ISP, you can use Outlook Express (included with your computer) or an e-mail system of your choice. This topic includes instructions for using Outlook Express.

To start Outlook Express

1. Click Start, Programs (or All Programs), Outlook Express, or double-click Outlook Express on the desktop (if available).

2. If you are not currently connected to the Internet, the Dial-up Connection window appears. Choose Connect to connect to the Internet.

To send an e-mail message

1. In Outlook Express, click the New Mail or Create Mail tool on the toolbar.

2. Fill in the information in the New Message window.

3. When you’re finished, click the Send button.

64 Reference Guide

Modem and Network Connections

Using the Modem

To receive e-mail messages

1. In Outlook Express, click the Send/Recv tool on the toolbar to have Outlook deliver new messages.

2. Click the Inbox folder to view the list of messages. Unread messages appear bold on the screen.

3. To view a message, click it once. (Or double-click to view the message in its own window.)

To send and receive faxes (Windows 98)

Sending and receiving faxes requires just a telephone connection—you don’t need an Internet connection. You can use the modem and fax software to send and receive faxes on your computer. QuickLink fax software is included with Windows 98 on the hard disk.

To start QuickLink

• Click Start, Programs, QuickLink, QuickLink.

The first time you start QuickLink, the Setup Wizard steps you through the process of setting options and customizing the program for your personal use. Follow the onscreen instructions. If you’re unsure which setting to choose, accept the default choice.

To send a fax

1. In QuickLink, click the QuickFax tool on the main toolbar.

2. Enter the fax number and the recipient’s name and company.

3. Type the message body in the QuickFax Note area.

4. Click Send Fax.

If instead you want to send a document as a fax, open the document in its application window, then open the Print dialog box. Change the selected printer to QuickLink, then print it.

To receive faxes

Faxes are automatically received when QuickLink is running in an open or minimized window. New faxes are indicated in the status box in the QuickLink window. To receive a fax manually, follow these steps.

1. When a fax call is coming in, click Start on the menu bar.

2. Click Manual Fax Receive.

Reference Guide 65

Modem and Network Connections

Using the Modem

To view and print a fax

1. In QuickLink, click the Fax Viewer tool on the toolbar.

2. Click Yes to view the fax now.

3. Click the printer icon to print the fax.

To send and receive faxes (Windows 2000)

To set up for faxing

1. Click Start, Settings, Control Panel, Fax. Enter your fax information.

2. On the Advanced Options tab, add a fax printer.

If you do not want to receive faxes, stop here.

3. On the Advanced Options tab, open the Fax Service Management window.

4. In the list under Fax, click Devices, then right-click the modem and click Properties.

5. On the General tab, enable the modem to receive faxes.

6. On the Received Faxes tab, select the option to save faxes in a folder.

To send a fax

• Click Start, Programs, Accessories, Communications, Fax, Send Cover Page Fax. Follow the instructions to create and send the fax.

If instead you want to send a document as a fax, open the document in its application window, then open the Print dialog box. Change the selected printer to the fax printer, then print it.

To receive, view, and print faxes

If you enabled the modem to receive faxes, they are automatically received.

1. Click Start, Programs, Accessories, Communications, Fax, My Faxes.

2. In the Received Faxes folder, double-click the fax.

3. To print, click File, Print.

66 Reference Guide

Modem and Network Connections

Using the Modem

To send and receive faxes (Windows XP)

Sending and receiving faxes requires just a telephone connection—you don’t need an Internet connection. You can use the modem and fax software to send and receive faxes on your computer. Fax Console fax software is included with Windows XP.

To set up Fax Console

Before you can use Fax Console, you need to install it.

1. Click Start, Control Panel, Add or Remove Programs.

2. Click Add/Remove Windows Components, select Fax Services, and follow the instructions on the screen. You may need the Windows CD to complete installation, or when prompted for the file path, enter c:\i386.

To start Fax Console

• Click Start, All Programs, Accessories, Communications, Fax, Fax Console.

The first time you start Fax Console, the Fax Configuration Wizard steps you through the process of setting options and customizing the program for your personal use. Follow the onscreen instructions. If you’re not sure which setting to choose, accept the default choice.

To send a fax

• Click Start, All Programs, Accessories, Communications, Fax, Send a Fax, then follow the instructions that appear on the screen.

If instead you want to send a document as a fax, open the document in its application window, then open the Print dialog box. Change the selected printer to Fax, then print it.

To receive faxes

Faxes are automatically received when Fax Console is running in an open or minimized window. New faxes are indicated in the status box in the Fax Console window. To receive a fax manually:

• When a fax call is coming in, click Receive now on the Fax Console menu bar.

To view and print a fax

1. In the Fax Console tree, click Inbox, then double-click the fax you want to view.

2. Click the printer icon to print the fax.

Reference Guide 67

Modem and Network Connections

Connecting to a LAN

Connecting to a local area network (LAN) gives you access to network resources, such as printers and file servers on your corporate network, and possibly to the Internet.

To connect to a LAN

1. Check that the existing LAN supports Ethernet 10Base-T (10 Mbps) or 100Base-TX

(100 Mbps) connections.

2. Plug the LAN cable (not supplied) into the built-in LAN port. The cable must have an

RJ-45 connector.

3. Windows 98: open Network (or Network Connections) in Control Panel to set up

support for a LAN connection on your network. For example, you can add the Microsoft TCP/IP protocol.

Windows 2000 or XP: automatically detects and sets up a LAN connection. To edit settings, open Network and Dial-up Connections in Control Panel.

See Windows Help for information about setting up and using LAN connections—click Start, Help (or Help and Support). Contact your network administrator for network information.

Two lights next to the LAN port indicate the status of the connection:

• The yellow light indicates network activity.

• The green light indicates that a link is established to the network.

68 Reference Guide

Modem and Network Connections

Making Wireless Connections

If your computer includes a wireless on-off button—located on the left side of the computer near the front—you can connect by radio to a wireless local area network (LAN) and access computers and other resources on the network.

A wireless network provides all the functions of a typical “wired” network, but also provides for “roaming.” Since your computer connects to the network by radio rather than through cables, you can move from place to place within the network—from your office to a conference room, for example—and remain on the network the entire time.

To prepare for connections (Windows 98 or 2000)

Before you can connect your computer to a particular 802.11 wireless network, you have to configure the computer for the specific type of connection: “AdHoc” or “Infrastructure.”

Computer-to-Computer Connection (AdHoc)

An AdHoc network provides a wireless connection from your computer directly to one or more computers with wireless capabilities, even if they aren’t connected to a LAN. You can then share resources such as shared files, printers, and Internet connections with the other computers.

1. Click the wireless link icon in the taskbar and select Advanced Configuration.

–or–

Click Start, Programs, HP Wireless LAN, Configuration Utility.

2. On the Configuration tab, set these parameters:

Mode: AdHoc.

SSID: any name; must be identical for all computers connecting to each other. Do not use a name that is used by a nearby access point.

AdHoc Channel: must be identical for all computers connecting to each other. Do not use a channel that is the same as or adjacent to a channel already being used by a nearby access point.

Reference Guide 69

Modem and Network Connections

Making Wireless Connections

3. If the computers use encrypted communication, use the Encryption tab to set the following parameters, which must be identical for all computers that will connect to each other:

• Encryption: 64-bit or 128-bit.

• Passphrase (if available) or Key: see the hint below.

The computers automatically connect whenever they’re within range of each other and wireless communication is turned on—see “To turn wireless communication on and off,” below.

LAN Connection (Infrastructure)

In an infrastructure network, your computer connects to a LAN (local area network) through a wireless access point. This gives you access to the resources on the network, such as printers, file servers, and possibly the Internet. Your network administrator can provide the settings you’ll need to connect to the wireless access point, as well as the additional settings you’ll need for the network itself.

1. Set up your computer for your local network:

Windows 98: open Network in Control Panel to set up support for a LAN connection on your network.

Windows 2000: automatically detects and sets up a LAN connection. To edit settings, open Network and Dial-up Connections in Control Panel.

2. Click the wireless link icon in the taskbar and select Advanced Configuration.

–or–

Click Start, Programs, HP Wireless LAN, Configuration Utility.

3. On the Configuration tab, set these parameters:

Mode: Infrastructure.

SSID: the ID used by the access point. “ANY” connects to the access point with the strongest signal, regardless of its SSID.

4. If your wireless network uses encrypted communication, use the Encryption tab to set these parameters—see the network administrator for the required settings:

• Encryption: 64-bit or 128-bit.

• Passphrase (if available) or Key: see the hint below.

The computer automatically connects to the infrastructure network whenever it’s within range of an access point and wireless communication is turned on—see “To turn wireless communication on and off,” below.

70 Reference Guide

Modem and Network Connections

Making Wireless Connections

Hint

If you are connecting to an access point or computer that is using Lucent/Agere-based software, you must set up compatible encryption on your computer. You can enter the encryption key manually. If you know only the Lucent/Agere passphrase, you must convert it to the corresponding key. If this option is not available on the Encryption tab, click Start, Programs, HP Wireless LAN, and use the encryption key converter.

To prepare for connections (Windows XP)

Before you can connect your computer to a particular 802.11 wireless network, you have to configure the computer for the specific wireless connection.

Connecting to an Existing Wireless Network

You can connect to an access point that gives you access to a local area network, or you can connect directly to other computers in an “adhoc” network.

1. Click Start, Settings, Control Panel, Network and Internet Connections, Network Connections.

2. Double-click the wireless connection to show its status, then click Properties.

3. On the General tab, edit network settings as needed for your local network. See your network administrator. You can also display an icon in the taskbar when connected to a network.

4. On the Wireless Networks tab, view the wireless networks available within range. Each network SSID is listed. Click the network you want and click Configure.

5. If the wireless network uses standard encrypted communication, uncheck the automatic key option, then select the following parameters—see your network administrator for the required settings:

• Key: ASCII passphrase or hexadecimal key string.

• Key format: ASCII for passphrase, hexadecimal for key string.

• Key length: smaller number for 64-bit encryption, larger number for 128-bit.

6. Click OK to save the configuration. This network is added to your list of preferred networks.

The computer automatically connects to the first preferred network that’s within range if wireless communication is turned on—see “To turn wireless communication on and off,” below.

Reference Guide 71

Modem and Network Connections

Making Wireless Connections

Hint

If you are connecting to non-Windows XP access points or computers that are using software from different manufacturers, you must set up compatible encryption on your computer. You can use the same hexadecimal encryption key on all units. If you know only an ASCII passphrase, you should convert it to the corresponding hexadecimal key. Click Start, All Programs, HP Wireless LAN, and use the encryption key converter.

Creating a New Computer-to-Computer Network (AdHoc)

You can set up a new network available to other local computers.

1. Click Start, Settings, Control Panel, Network and Internet Connections, Network Connections.

2. Double-click the wireless connection to show its status, then click Properties.

3. On the Wireless Networks tab, click Add to create a new network.

4. Type a name for the new network.

5. If you want to use encrypted communication, uncheck the automatic key option, then select the following parameters:

• Key: ASCII passphrase or hexadecimal key string.

• Key format: ASCII for passphrase, hexadecimal for key string.

• Key length: smaller number for 64-bit encryption, larger number for 128-bit.

6. Mark the option to make this a computer-to-computer (adhoc) network.

7. Click OK to save the configuration. This network is added to your list of preferred networks and becomes available to other computers.

Important

To turn wireless communication on and off

Wireless networks and cellular modems are examples of devices that use wireless communication. Such devices may be restricted in some situations or environments, such as when traveling in an airplane. If in doubt, be sure to ask for authorization before turning on your computer’s wireless networking.

In Italy, Singapore, and possibly other countries, you are required to ask the responsible authority for a license paid for by you before using the wireless function.

72 Reference Guide

Modem and Network Connections

Making Wireless Connections

Turning on communication and making a connection

1. If the computer isn’t on, turn it on.

2. The wireless indicator light is lit whenever the wireless function is on. If the indicator isn’t lit, do one of the following:

Press the wireless on-off button.

–or–

Click the wireless link icon in the taskbar and select Wireless Radio On.

If you’re within range of your wireless network, your computer automatically connects. To check the status of your wireless connection, click the wireless link icon in the taskbar and select Wireless Status.

Turning off communication and ending a connection

1. Important: close any files that reside on other network computers.

2. To turn off the wireless function without turning off the computer, do one of the following:

Press the wireless on-off button.

–or–

Click the wireless link icon in the taskbar and select Wireless Radio Off.

Suspending or shutting down the computer also turns off the wireless function.

Reference Guide 73

Add-On Devices

Reference Guide 75

Add-On Devices

Using Plug-In Modules

You can use any compatible plug-in module with your computer’s module bay, such as:

• CD-ROM, CD-RW, DVD, or similar drive.

• Zip drive.

• Second hard drive.

• Floppy disk drive.

• Secondary battery.

CAUTION

Never remove a plug-in module without first notifying Windows—see “To replace a plug-in module” on page 76. Otherwise, you could lose data.

To install hot-swap support (Windows 98)

If your computer uses Windows 98, it also includes “hot-swap” software that lets you swap most modules in the computer’s plug-in bay without needing to shut down and reboot the computer.

If a BayManager icon is displayed in the taskbar, hot-swap support is already installed. If the icon is not present, you can install the software as follows:

• Click Start, Programs, Softex BayManager, Setup, then follow the onscreen instructions.

To replace a plug-in module

Windows 98 uses hot-swap software to let you swap most plug-in modules without shutting down the computer. Before replacing a hard drive module, however, you must first shut down the computer.

When a drive module is present, Windows 2000 displays the Unplug or Eject Hardware icon—and Windows XP displays the Safely Remove Hardware icon—at the right end of the taskbar.

76 Reference Guide

Add-On Devices

Using Plug-In Modules

CAUTION

Before disconnecting a CD-ROM drive, DVD drive, or any other type of drive, you must either use the icon in the taskbar or shut down the computer—otherwise, you could lose data.

Exception: for Windows 98, you must shut down the computer before connecting or disconnecting a hard disk drive.

Handle and store a module carefully when it’s out of the computer. Do not drop it or apply excessive pressure to its surfaces—this could damage its internal mechanisms. Do not touch the metallic pins on the computer’s connectors, module connectors, or cable connectors. Static electricity can damage internal components.

1. Close all files that are open from the plug-in module.

2. Windows 98: if the BayManager icon is present in the taskbar, right-click the icon, then click Remove/Swap Bay Device. When prompted, remove the module if one is present. Don’t click OK until you’ve inserted the desired module, if any.

Windows 2000 or XP: left-click the Unplug or Eject Hardware or Safely Remove Hardware icon on the taskbar, and select the module you want to remove. When prompted to remove the module, click OK. (You don’t have to do this if the bay is empty or contains a battery.)

–or–

For any system: shut off the computer. Click Start, Shut Down, Shut down (Windows 98 or 2000) or Start, Turn Off Computer, Turn Off (Windows XP).

Important: for Windows 98, you must shut off the computer if you are removing or inserting a hard disk drive in the module bay.

3. Press the button on the module release latch, and slide the latch toward the front of the computer.

Reference Guide 77

Add-On Devices

Using Plug-In Modules

4. Grasp the module and pull it out.

5. Slide the new plug-in module into the computer until it clicks into place.

6. For Windows 98, click OK to close the BayManager window.

If you have a CD-ROM drive or other module in the module bay, you can connect the floppy disk drive to the parallel port. See the next topic.

To connect the floppy disk drive to the parallel port

If you prefer, you can connect the floppy disk drive to your computer’s parallel port using an external floppy drive cable, available from HP.

• Connect the F2008 cable directly to the floppy drive and to the computer parallel port.

Before disconnecting the floppy disk drive, use the icon in the taskbar to stop the drive, or else shut down the computer. See “To replace a plug-in module” on page 76.

78 Reference Guide

Add-On Devices

Using Plug-In Modules

To insert or remove a CD or DVD

CAUTION

Do not remove a CD or DVD while the computer is reading it. Otherwise, the computer could stop responding and you could lose data.

Be sure to press the CD or DVD onto the spindle. You can damage the disk or drive if you just lay it on the tray.

1. Press the button on the face of the CD-ROM or DVD drive. If you are using this drive for the first time, be sure to remove the cardboard packing insert.

2. Place the CD into the drive (label facing up) and gently press down to seat it on the spindle.

–or–

Remove the CD.

3. Slide the tray back into the module to close it.

If your computer loses power, or if you have removed the CD-ROM or DVD module from the computer, you can manually open the drive to remove a CD. Insert a straightened paper clip into the recessed hole on the front of the drive to open it.

Reference Guide 79

Add-On Devices

Using Plug-In Modules

To play DVD movies

If your computer came with a DVD drive, it also includes DVD player software that lets you play DVD movies. Click Start, Programs (Windows 98 or 2000) or Start, All Programs, Multimedia, DVD Player (Windows XP)—if InterVideo WinDVD or DVD Express is not listed, do the following.

• Run Setup on the software CD to install the player software.

To play DVD movies on a TV, see “To use a TV set as a monitor” on page 88.

To create or copy CDs

If your computer came with a CD-RW drive, it also includes software that lets you copy or create CDs. Click Start, Programs (Windows 98 or 2000) or Start, All Programs, Multimedia, CD Writer (Windows XP)—if Adaptec Easy CD, Veritas CDRW, or RecordNow is not listed, do the following.

• Run Setup on the software CD to install the CD-RW software.

Refer to the software’s help for details about creating or copying CDs. HP recommends using HP C4403A (CD-R) or C4404A (CD-RW) media—read and write quality may vary for other media.

80 Reference Guide

Add-On Devices

Connecting PC Cards

The computer’s PC Card slots are available for storing data and expanding the communication capabilities of the computer. The computer supports standard Type I, II, and III PC Cards (PCMCIA and CardBus), and can hold two Type I or II cards or one Type III card.

The lower slot supports Zoomed Video, which allows a zoomed video card to show highquality multimedia presentations.

To insert or remove a PC Card

Inserting a PC Card

1. Hold the PC Card with its face up and its connector holes toward the card slot.

2. Slide the PC Card all the way into the slot. Most cards are properly seated when the outer edge is flush with the casing of the computer, but some cards are designed to protrude from the case.

Reference Guide 81

CAUTION

Add-On Devices

Connecting PC Cards

Removing a PC Card

Before removing a PC Card, you must use the PC Card, Eject Hardware, or Safely Remove Hardware icon in the taskbar, or shut down the computer. Otherwise, you could lose data.

1. Before removing the card, click the PC Card, Eject Hardware, or Safely Remove Hardware icon in the taskbar, then click Stop. This protects your data and helps avoid unexpected problems.

If needed, you can restart the card by removing and then reinserting it.

2. Press the eject button to pop the button out, then press it in to eject the PC Card.

Finding tested PC Cards

For the current listing of PC Cards that have been tested and approved for use with your computer, visit the Accessories section of the HP Notebook Web site (www.hp.com/notebooks).

82 Reference Guide

Add-On Devices

Connecting External Devices

To identify connectors for external devices

The diagram below shows your computer’s connectors for external devices.

1. PS/2 keyboard or PS/2 mouse port (supports Y adapter).

2. Two universal serial bus (USB) ports.

3. Serial port (COM1).

4. Parallel port (LPT1). Use this port for a parallel printer or other parallel device, or to connect the floppy disk drive externally.

5. External monitor port.

6. Docking port.

7. Modem port (on certain models).

8. LAN port.

9. PC Card and CardBus slots (upper and lower). See “Connecting PC Cards” on page 81.

The computer also includes an infrared port, audio ports, and an S-video port on its right side.

Reference Guide 83

Add-On Devices

Connecting External Devices

Note

Before you connect any device, check its documentation to see if you need to make any settings or adjustments to the equipment before using it. This might include setting switches to configure the equipment so that it will operate properly with your computer and the software you plan to use.

To connect a printer or other parallel device

The computer’s parallel port uses a standard 25-pin connector, most commonly used for connecting dot-matrix, ink-jet, and laser printers. You can also use it to connect a parallel Zip drive.

• Connect the cable from the parallel printer or other parallel device to the computer’s parallel port.

To connect an external keyboard or mouse

• Plug a USB mouse or keyboard into a USB port on the computer.

–or–

• Plug a PS/2 mouse or keyboard into a PS/2 port on the computer.

The pointing stick and touch pad are normally disabled while an external PS/2 mouse is connected.

Note

To connect a PS/2 mouse and keyboard at the same time, use the HP F1469A Y adapter.

To use hot keys from an external PS/2 keyboard, substitute left CTRL+left ALT for the computer Fn key. For example, to access Fn+F12, press left CTRL+left ALT+F12. Only Fn+F5, Fn+F7, and Fn+F12 are supported on an external PS/2 keyboard. A USB keyboard does not support Fn hot keys.

84 Reference Guide

Note

CAUTION

Add-On Devices

Connecting External Devices

To connect a USB device

Your computer’s universal serial bus (USB) provide a bi-directional serial interface for adding peripheral devices such as game controllers, serial and parallel ports, and scanners on a single bus.

• Attach the device’s USB cable to one of the computer’s USB ports. Windows automatically recognizes the USB device. Some USB devices can be connected to the computer in series—this is called a daisy-chain connection.

If you have problems making this connection, contact the device manufacturer and the HP Customer Care Web site (www.hp.com/go/support) for the latest version of the driver for the device.

To connect an audio device

Your computer includes a built-in microphone (just in front of the blue sleep button) that you can use to record voice, sound, and music. You can also plug in a stereo input source (such as a CD player), an external microphone, external speakers, or headphones.

The audio jacks are three-terminal stereo jacks. They are not compatible with twoterminal mono plugs. Connecting a mono plug into the speaker-out jack may damage the computer.

Note

• Attach the audio cable to the corresponding audio port on the computer.

When you plug a device into the external microphone port, the built-in microphone automatically turns off. When you plug a device into the audio out port, the built-in speakers automatically turn off.

Reference Guide 85

Add-On Devices

Connecting External Devices

To use an external monitor

Connecting an external monitor

1. Click Start, Shut Down, Shut down (Windows 98 or 2000) or Start, Turn Off Computer, Turn Off (Windows XP).

2. Connect the monitor cable from the monitor to the monitor port on the rear of the computer.

3. Connect the monitor to a power source and turn it on.

4. Press the blue sleep button to turn on the computer.

Switching the display to the external monitor

• Press Fn+F5 (or CTRL+ALT+F5 on an external keyboard) to cycle through the display options: notebook display, external monitor, both.

–or–

Click Start, Programs, HP Display Settings, HP Display Settings (Windows 98 or

2000) or Start, All Programs, Hewlett-Packard, Notebook, HP Display Settings, HP Display Settings (Windows XP).

You can also add a display settings icon in the taskbar for quick access.

• If you need to use both displays at once, press Fn+F5 repeatedly until the image shows on both displays. With the default display settings, the external monitor uses the same settings as the internal display. The external monitor displays the same image as the internal display, regardless of the screen area, colors, and other settings, and the refresh rate is the same for as the internal display (60 Hz). If you use only the external monitor, you can select different settings that aren’t limited by the internal display. If you need to increase the refresh rate on the external monitor, you can switch to only the external monitor. An alternative is to make one display a “secondary” display so you can select independent refresh rates:

1. Click Start, Settings, Control Panel, then double-click Display (Windows 98 or

2000), or click Start, Control Panel, Appearance and Themes, Display (Windows XP).

2. On the Settings tab, click the Advanced button, then the Displays or Monitor tab.

Set the refresh rate on the Monitor tab.

86 Reference Guide

Add-On Devices

Connecting External Devices

Adjusting monitor resolution and other settings

1. Click Start, Settings, Control Panel, then double-click Display (Windows 98 or 2000), or click Start, Control Panel, Appearance and Themes, Display (Windows XP).

2. On the Settings tab, adjust the Screen area. Other settings are also available.

For an external monitor, the computer supports screen area settings up to 1600 × 1200, color settings up to 16M (24- or 32-bit), and refresh rates up to at least 75 Hz. Lower screen area settings support higher refresh rates, except that 1400 × 1050 supports only 60 Hz. The capabilities of external monitors vary greatly, and the display quality of your monitor may not be optimal at higher settings.

Using dual display mode (Windows 98 or XP)

You can extend your desktop by connecting an external monitor to your computer.

1. Click Start, Settings, Control Panel, then double-click Display (Windows 98), or click Start, Control Panel, Appearance and Themes, Display (Windows XP).

2. Click the Settings tab.

3. Windows 98: right-click display 2, and select Enabled.

Windows XP: click the second display, then select the option to extend the desktop.

You can set different resolutions and numbers of colors for each display. However, using the Extended Desktop requires video memory to be shared. For this reason, higher resolutions and higher numbers of colors may cause unexpected behavior on the displays. We recommend starting with 1024 × 768 resolution on the external display and 64K colors (16-bit) on both displays. You can try higher settings to see whether they work for your applications. In addition, certain operations such as playing DVDs and running 3D graphics require extra video memory, so you may have to use lower display settings.

Changing display actions

With a display attached, you can use the BIOS Setup utility to change certain display behaviors, such as stretching the image to fill the screen at lower resolutions. See “To run the BIOS Setup utility” on page 125.

For a display connected to a video adapter in a docking system, the docking display is automatically selected when it is detected. To change this behavior, change the Primary Video Adapter setting in BIOS Setup.

Reference Guide 87

Add-On Devices

Connecting External Devices

To use a TV set as a monitor

You can connect a television set or other video device to your computer to use as a display. The computer’s built-in display remains active when you connect a TV set.

To connect a TV set

You can connect a TV set using a standard S-video cable, or an HP F1459A compositevideo adapter with a standard RCA-type video cable.

1. Connect a video cable from the TV set to the S-video port. (You don’t need to turn the computer off to do this.)

2. Connect the TV set to a power source and turn it on.

To activate the TV display

• Restart the computer: click Start, Shut Down (or Turn Off Computer), Restart.

–or–

1. Click Start, Settings, Control Panel, then double-click Display (Windows 98 or 2000), or click Start, Control Panel, Appearance and Themes, Display (Windows XP).

2. On the Settings tab, click Advanced.

3. On the Displays tab, activate the TV output.

To play DVD movies on the TV

• Open Display in Control Panel, click the Settings tab, then click Advanced and make the TV a “primary” display.

• Optional: connect an audio cable from the computer’s audio out jack to the TV audio input.

To connect a serial device

The computer includes a standard 9-pin serial port that you can use to connect devices such as external modems and fax modems. If needed, you can set the serial port’s address in the BIOS Setup utility.

• Connect the device’s serial cable to the computer’s serial port.

88 Reference Guide

Add-On Devices

Connecting External Devices

To connect an infrared device

Your computer includes an infrared port—located below the volume control on the right side of the computer—which provides wireless, serial communication between the computer and other infrared devices such as printers or other computers.

By default, the infrared port is not enabled, so you must enable it before you can use it.

1. Enable the infrared port in the BIOS Setup utility—see “To run the BIOS Setup utility” on page 125.

2. Windows 98 only: click Start, Run, and type c:\hp\drivers\fir\quikbeam\setup.exe to install the QuickBeam software. For more information, see the Readme file in the same directory.

Using the infrared port

• Make sure the infrared ports of your computer and the other device lie in as straight a line as possible. The two ports should be no more than 1 meter apart, with no obstructions in between. Noise from nearby equipment can cause transmission errors.

• To check the status of communications, open Infrared (Windows 98) or Wireless Link (Windows 2000 or XP) in Control Panel.

Disabling the infrared port

You should generally disable infrared communication when you aren’t using it.

1. Close any applications that are using infrared, and any folders on an infrared link.

2. Click Start, Settings, Control Panel (Windows 98 or 2000) or Start, Control Panel, Printers and Other Hardware (Windows XP).

3. Windows 98: double-click Infrared and disable communications.

Windows 2000: double-click Wireless Link and disable the hardware.

Windows XP: click Wireless Link. On the Hardware tab click Properties, and disable

the device in the pull-down menu.

Printing to an infrared printer

• Install your printer and assign it to the computer’s infrared port. You can then print from your applications as you would to any other printer.

Reference Guide 89

Add-On Devices

Connecting External Devices

Transferring files through an infrared connection

You can use your computer’s infrared port to transfer files.

• For Windows 98, use the built-in Direct Cable Connection software. You will first need to install the software as follows:

1. Click Start, Settings, Control Panel, then double-click Add/Remove Programs.

2. Click Windows Setup, double-click Communications, and select the Direct Cable

Connection checkbox.

• For Windows 2000 or XP, use Wireless Link.

See the Windows online help for instructions on using Direct Cable Connection or Wireless Link.

To use a docking product

Pavilion models

For Pavilion models, docking is supported with only the F1451 port replicator.

A docking product provides your computer with external connections that you can leave in place whenever you remove the computer from your desk. Instead of disconnecting and reconnecting peripheral devices, you can simply undock and dock the computer.

For more information about using docking products, see the User’s Guide that shipped with your dock.

Installing a docking tray

Your dock requires a tray that accommodates your specific computer model. Install this tray prior to connecting the computer to the dock. If you don’t have a tray labeled for the Omnibook 6000 or Pavilion series, you’ll need to purchase HP accessory F2012A.

1. Slide the rear of the tray into the dock as shown on the dock label.

90 Reference Guide

Add-On Devices

Connecting External Devices

2. Push down firmly on both sides of the tray until it snaps into place.

To remove a tray from the dock, pull the latch (at the center front of the dock) towards you until the tray pops free.

Docking the computer

The computer can be on, suspended, or off when docking.

1. Connect power to the dock—the type of connection depends on the dock. See the manual that came with the dock.

2. Place the computer on the dock platform, with the rear of the computer facing the dock’s docking connector. Make sure the computer’s PC Card eject buttons are in.

Reference Guide 91

Add-On Devices

Connecting External Devices

3. Position your fingers on the platform grips as shown below. Use your thumbs to push the computer into the dock until the computer slides into place.

Undocking the computer

1. Press the undock button on the front of the dock and wait for the undock light to blink. Then position your thumb as shown and pull the release lever forward.

2. Remove the computer from the dock.

92 Reference Guide

Add-On Devices

Installing Additional RAM

The computer has no memory (RAM) built in but has two slots that hold two RAM modules. At least one slot contains a RAM module installed at the factory. You can use both slots to expand your RAM. Use HP PC-133 or higher SDRAM only.

To install a RAM expansion module

You’ll need a small Phillips screwdriver for these steps.

CAUTION

Your computer’s chips are extremely sensitive to static electricity, and can be permanently damaged by it. Handle the RAM module only by its edges. Before installing the memory module, discharge your body’s static electricity by touching the metal shielding around the connectors on the rear of the computer.

1. Click Start, Shut Down, Shut down (Windows 98 or 2000) or Start, Turn Off Computer, Turn Off (Windows XP).

2. Important: unplug the AC adapter, if present, and remove the battery. Remove the secondary battery if one is installed.

3. Turn the unit bottom-side up, loosen the screws holding the RAM cover, and remove the cover. (The cover retains the screws.)

Reference Guide 93

Add-On Devices

Installing Additional RAM

4. Insert the RAM board into the connector at about a 30° angle until it is fully inserted. Then press down at both sides until both latches snap closed.

Note

5. Replace the cover.

6. Insert the battery.

For Windows 98: if you increase your computer’s memory to more than 768 MB, the computer will not be able to hibernate unless you also increase the size of the Utility partition on the hard disk—see “To recover the factory installation of your hard disk” on page 132.

94 Reference Guide

CAUTION

Add-On Devices

Installing Additional RAM

To remove a RAM expansion module

You may want to remove a RAM module so you can install a larger one. You’ll need a small Phillips screwdriver for these steps.

1. Click Start, Shut Down, Shut down (Windows 98 or 2000) or Start, Turn Off Computer, Turn Off (Windows XP).

2. Important: unplug the AC adapter, if present, and remove the battery. Remove the secondary battery if one is installed.

3. Turn the unit bottom-side up, loosen the screws holding the RAM cover, and remove the cover. (The cover retains the screws.)

4. Release the two latches at the sides of the RAM board, so the free edge of the board pops up.

5. Pull the board out of the connector.

6. Replace the cover.

7. Insert the battery.

Reference Guide 95

Add-On Devices

Replacing the Hard Disk Drive

To replace the hard disk drive

You’ll need a small Phillips screwdriver for this procedure.

1. Unplug the AC adapter if you’re using one, and remove the battery.

2. Turn the unit bottom side up and remove all three hard drive screws.

3. Raise the cover on the end of the drive so that its retainer tab is free of the computer casing, then gently pull the hard drive out of the computer.

Important

4. Gently slide the new drive into the hard drive compartment. Press firmly to make sure the connector seats properly.

5. Slide the cover down into place (so the retainer tab engages the casing), and reinstall the hard drive screws.

If you are installing a new hard disk drive, you should create a Utility partition on the drive before loading any software. See “To recover the factory installation of your hard disk” on page 132.

96 Reference Guide

Add-On Devices

Replacing the Hard Disk Drive

To replace the hard disk drive holder

If you are installing a new hard drive that does not have a cover, you can remove the cover parts from the old hard drive. You’ll need a small Phillips screwdriver for this procedure.

1. Remove all four screws from the holder and drive case, then lift the drive out of the holder.

2. Notice that the hard drive has a pin connector attachment at one end. Carefully remove this connector from the end of the drive. Work alternately at each end so that the connector slides off evenly without bending the connector pins.

3. Carefully put the pin connector attachment back onto the pins on the end of the new hard drive. Work alternately at each end so that the connector slides on evenly without bending the connector pins.

4. Insert the connector through the end of the holder, and lower the drive into the holder.

5. Reinstall the screws into the holder and drive case.

Reference Guide 97

Add-On Devices

Replacing the Hard Disk Drive

To prepare a new hard disk drive

When you install a new hard disk drive, you also need to prepare it to be able to work with your computer.

• If you want to restore the Windows software and operating system that were originally installed on your computer, you can do so using the Recovery CD that also came with your computer. See “To recover the factory installation of your hard disk” on page 132.

• If you want to use the hard disk with other than the original software and operating system, prepare the hard disk as described in the Corporate Evaluator’s Guide, available at the HP Customer Care Web site (www.hp.com/go/support).

• If you want to prepare a second hard disk module in the plug-in module bay, follow these steps.

Windows 98

1. Install the second hard drive and reboot the computer.

2. Click Start, Run and type fdisk.

3. When prompted, choose to enable large disk support.

4. Choose option 5 to change a current disk drive, then select drive number 2.

5. Choose option 1 to create a DOS partition, and let it use the entire drive.

6. When the process finishes, press ESC to exit.

7. Restart the computer.

8. Double-click My Computer.

9. Right-click the new hard disk drive (may be drive D), then click Format. Follow

the displayed instructions.

Windows 2000 or XP

1. Install the second hard drive.

2. Click Start, Settings, Control Panel, then double-click Administrative Tools

(Windows 2000), or click Start, Control Panel, Performance and Maintenance, Administrative Tools (Windows XP).

3. Double-click Computer Management, then click Disk Management in the tree.

4. In the lower-right pane, right-click the unused area of the new disk (probably

disk 1) and click Create Partition. Follow the displayed instructions to create an NTFS partition that uses the entire drive.

98 Reference Guide

Troubleshooting and Maintenance

Reference Guide 99

Troubleshooting and Maintenance

Troubleshooting Your Computer

This section contains solutions to a many types of problems you might have with your computer. Try the solutions one at a time, in the order in which they are presented.

Here are some other sources of information for troubleshooting:

• Open the HP web-based troubleshooting tool: double-click the HP Instant Support icon on the Windows desktop (Windows 98 or 2000) or click Start. Help and Support, (Windows XP). Search or browse the troubleshooting database for the information related to your problem.

• Click Start, Help (Windows 98 or 2000) or Start, Help and Support, Fixing a Problem (Windows XP), and use the Windows troubleshooters.

• See the Microsoft Windows manual shipped with the computer.

• See the HP Notes in the online HP Library for updated information.

• Find technical tips and software updates for the computer at the HP Customer Care

Web site (www.hp.com/go/support).

• Test your computer by running the e-Diagtools test program. See “Testing the Hardware” on page 123.

• Contact your dealer or Hewlett-Packard—see “To contact HP for support or service” on page 136. Please have your computer with you when you call.

Audio Problems

If no sound is audible

• Press the back end of the volume control several times.

• Click the speaker icon on the taskbar (if present), and make sure that Mute is not

checked and the Volume Control slider is not set to the bottom.

• Press the audio-off button on the right side of the computer once or twice until the indicator light goes off.

• When you are operating your computer in MS-DOS mode (for example, when running MS-DOS games), you may find that the sound does not operate properly. Use Windows applications for full use of sound capabilities.
