Administrator’s Guide

HP Jetdirect Print Servers

Models: 175x

310x

380x

en3700

200m

250m

280m

610n

615n

620n

680n

The information contained in this document is subject to change without notice.

The only warranties for HP products and services are set forth in the express warranty statements accompanying such products and services. Nothing herein should be construed as constituting an additional warranty. HP shall not be liable for technical or editiorial errors or omissions contained herein.

Edition 3, 1/2004

Trademark Credits

Microsoft®, MS-DOS®, Windows®, are U.S. registered trademarks of Microsoft Corporation. NetWare® and Novell® are registered trademarks of Novell Corporation. IBM®, IBM Warp Server®, Operating System/2® are registered trademarks of International Business Machines Corp. Ethernet is a registered trademark of Xerox Corporation. PostScript is a trademark of Adobe Systems, Incorporated. UNIX® is a registered trademark of the Open Group.

Table of Contents

1. Introducing the HP Jetdirect Print Server

Introduction ............................................................................. 7

Supported Print Servers.......................................................... 8

Supported Network Protocols ................................................. 9

Security Protocols .................................................................. 11

Supplied Manuals .................................................................. 14

HP Support ............................................................................ 14

Product Registration.............................................................. 16

2. HP Software Solutions Summary

Introduction ........................................................................... 17

HP Jetdirect Wireless Setup Wizard .................................... 20

HP Install Network Printer Wizard (Windows)................... 21

HP Jetdirect Printer Installer for UNIX .............................. 22

HP Web Jetadmin.................................................................. 23

Internet Printer Connection Software.................................. 26

HP IP/IPX Printer Gateway for NDPS................................. 29

HP WPS Assistant (Mac OS X) ............................................. 31

HP LaserJet Utilities for Mac OS......................................... 32

3. TCP/IP Configuration

Introduction ........................................................................... 38

Default IP Address ................................................................ 39

Using BOOTP/TFTP .............................................................. 44

Using DHCP........................................................................... 64

Using RARP ........................................................................... 72

Using the arp and ping Commands ...................................... 74

Using Telnet........................................................................... 76

Using the Embedded Web Server ....................................... 100

Using the Printer Control Panel ......................................... 101

Moving to Another Network................................................ 102

4. Using the Embedded Web Server

Introduction ......................................................................... 103

Requirements....................................................................... 105

Viewing the Embedded Web Server ................................... 106

HP Jetdirect Home Tab ....................................................... 109

Networking Tab ................................................................... 111

Other Links .......................................................................... 155

ENWW iv

5. Configuring for LPD Printing

Introduction ......................................................................... 157

LPD Setup Overview ........................................................... 159

LPD on UNIX Systems ........................................................ 161

LPD on Windows NT/2000 Systems ................................... 165

LPD on Windows XP Systems............................................. 170

LPD on Mac OS Systems..................................................... 173

6. FTP Printing

Introduction ......................................................................... 175

Requirements....................................................................... 175

Print Files ............................................................................ 176

Using FTP Printing ............................................................. 176

Example of an FTP Session................................................. 181

7. Security Features

Introduction ......................................................................... 182

Using Security Features...................................................... 186

8. Troubleshooting the HP Jetdirect Print Server

Introduction ......................................................................... 188

Resetting to Factory Defaults ............................................. 189

General Troubleshooting ..................................................... 191

Troubleshooting Wireless Print Servers ........................... 199

Troubleshooting an LPD UNIX Configuration .................. 205

9. HP Jetdirect Configuration Page

Introduction ......................................................................... 207

Configuration Page Format................................................. 208

Configuration Page Messages ............................................. 210

Error Messages .................................................................... 232

A. TCP/IP Overview

Introduction ......................................................................... 243

IP Address ............................................................................ 244

Configuring IP Parameters ................................................. 247

Subnets................................................................................. 248

Gateways.............................................................................. 249

Syslog Server ....................................................................... 249

ENWW v

B. HP Jetdirect 802.11b Wireless Print Servers

Introduction ..........................................................................252

Basic HP Jetdirect Wireless Concepts ................................253

Installation Overview...........................................................263

C. The HP Jetdirect Control Panel Menu

Introduction ..........................................................................276

Classic Control Panel ...........................................................277

Graphical Control Panel ......................................................283

D. OpenSSL Statements

Index

ENWW vi

Introducing the HP Jetdirect Print Server

Introduction

HP Jetdirect print servers allow you to connect printers and other devices directly to a network. By attaching a device directly to a network, you can install it in a convenient location and share it with multiple users. In addition, a network connection allows data transfers to or from the device at network speeds.

HP Jetdirect internal print servers are installed in HP printers that have a compatible input/output (I/O) slot. HP Jetdirect external print servers connect printers to the network by adapting the printer’s USB port to the network.

Note Unless otherwise specified, the term print server in

this manual refers to the HP Jetdirect print servers and not a separate computer running print server software.

When connected through a wireless connection to your network, an HP Jetdirect wireless print server provides the same printing services as Jetdirect print servers connected by network cables. For more information on HP wireless print servers, see

Appendix B

ENWW 7

Supported Print Servers

The features described in this guide support the following HP Jetdirect print servers with firmware versions specified:

Table 1.1 Supported Products

Model Product

Number

175x J6035C USB 1.1 10/100TX Limited* M.25.xx

310x J6038A USB 1.1 10/100TX Full** Q.25.xx series

en3700 J7942A USB 2.0 10/100TX Full** A.25.xx series

380x J6061A USB 1.1 802.11b

200m J6039C LIO slot 10/100TX Limited* P.25.xx series***

250m J6042B LIO slot 10/100TX Full** N.25.xx series

280m J6044A LIO slot 802.11b

610n J4167A EIO slot Token

615n J6057A EIO slot 10/100TX Full** R.25.xx series

620n J7934A EIO slot 10/100TX Full** C.25.xx series

680n J6058A EIO slot 802.11b

* Limited support includes TCP/IP, IPX Direct Mode, AppleTalk (EtherTalk), LPD/Windows.

** Full support includes TCP/IP, IPX/SPX, AppleTalk (EtherTalk), LPR/LPD, Security. See Table 1.2

*** Not Upgradeable. For feature upgrades, you must purchase a new product that contains updated firmware.

Printer Connect

Network Connect

Wireless

Ring

Wireless

Network Protocol Support

Full** S.25.xx series

Full** T.25.xx series

Full (excludes AppleTalk)**

Full** U.25.xx series

Firmware Version

series***

L.25.xx series

The installed firmware version can be identified using various methods, including the HP Jetdirect configuration page (see

Chapter 9 Chapter 4

updates, see “Firmware

ENWW Introducing the HP Jetdirect Print Server 8

), Telnet (see Chapter 3), embedded Web server (see ), and network management applications. For firmware

Upgrades”.

Note When upgrading a supported print server, you may

need to perform the upgrade twice if it contains a firmware version prior to X.24.00. This will be necessary if you want the print server to support management tools (for example, the embedded Web server) using non-English languages.

Supported Network Protocols

Note For HP Jetdirect wireless print servers, this section

assumes that a wireless connection to your network has been established.

The supported network protocols, and popular network printing environments that use those protocols, are listed in Table 1.2

Table 1.2 Supported Network Protocols (1 of 2)

Supported Network Protocols

TCP/IP Microsoft Windows 98/Me/NT4.0/2000/XP

* Refer to the current HP Jetdirect product data sheets for additional network systems and versions. For operation with other network environments, consult your system vendor or authorized HP dealer.

** For these network systems, contact your network system vendor for software, documentation, and support.

*** Windows IP/IPX Direct Mode printing and LPD/Windows supported. NetWare is not supported. IPP is not supported. LPD/UNIX is not supported.

ENWW Introducing the HP Jetdirect Print Server 9

Network Printing Environments* Product Support

(32- and 64-bit), Direct Mode Novell NetWare 5, 6 using NDPS UNIX and Linux, including:

Hewlett-Packard HP-UX, Sun Microsystems Solaris (SPARCsystems only), IBM AIX**, HP MPE-iX**, RedHat

Linux, SuSE Linux LPR/LPD (Line Printer Daemon) IPP (Internet Printing Protocol) FTP (File Transfer Protocol)

J6035C (175x)*** J6038A (310x) J7942A (en3700) J6061A (380x) J6039C (200m)*** J6042B (250m) J6044A (280m) J4167A (610n) J6057A (615n) J7934A (620n) J6058A (680n)

Table 1.2 Supported Network Protocols (2 of 2)

Supported

Network Printing Environments* Product Support Network Protocols

IPX/SPX and compatible

Novell NetWare

Microsoft Windows 98/Me/NT4.0/2000/XP

(32-bit only), Direct Mode

J6035C (175x)*** J6038A (310x) J7942A (en3700) J6061A (380x) J6039C (200m)*** J6042B (250m) J6044A (280m) J4167A (610n) J6057A (615n) J7934A (620n) J6058A (680n)

AppleTalk (EtherTalk

only)

Apple Mac OS J6035C (175x)

J6038A (310x) J7942A (en3700) J6061A (380x) J6039C (200m) J6042B (250m) J6044A (280m) J6057A (615n) J7934A (620n) J6058A (680n)

DLC/LLC Microsoft Windows NT**

Artisoft LANtastic**

J6038A (310x) J7942A (en3700) J6061A (380x) J6042B (250m) J6044A (280m) J4167A (610n) J6057A (615n) J7934A (620n) J6058A (680n)

* Refer to the current HP Jetdirect product data sheets for additional network systems and versions. For operation with other network environments, consult your system vendor or authorized HP dealer.

** For these network systems, contact your network system vendor for software, documentation, and support.

*** Windows IP/IPX Direct Mode printing and LPD/Windows supported. NetWare is not supported. IPP is not supported. LPD/UNIX is not supported.

ENWW Introducing the HP Jetdirect Print Server 10

If not supplied with this product, HP network setup and management software for supported systems may be obtained from HP support at:

http://www.hp.com/support/net_printing

For software to set up network printing on other systems, contact your system vendor.

Security Protocols

SNMP (IP and IPX)

SNMP (Simple Network Management Protocol) is used by network management applications for device management. HP Jetdirect print servers support SNMP and standard MIB-II (Management Information Base) objects on both IP and IPX networks.

HP Jetdirect 175x and 200m print servers support an SNMP v1/v2c agent only.

Full-featured HP Jetdirect print servers support an SNMP v1/v2c agent, and an SNMP v3 agent for enhanced security.

HTTPS

Full-featured HP Jetdirect print servers support HTTPS (Secure Hyper Text Transfer Protocol) for secure, encrypted management communications between the embedded Web server and your Web browser.

Value-based print servers (for example, HP Jetdirect 175x and 200m) do not support HTTPS.

ENWW Introducing the HP Jetdirect Print Server 11

Authentication (Wireless Print Servers)

Server-Based Authentication

HP Jetdirect 802.11b wireless print servers support popular authentication server-based methods for network access based on IEEE 802.1x Extensible Authentication Protocol (EAP), including:

● LEAP (Lightweight Extensible Authentication Protocol). LEAP

is a proprietary protocol from Cisco Systems, Inc. It uses passwords for mutual authentication between a client and a network authentication server. Dynamic encryption keys are used for secure communications.

● PEAP (Protected Extensible Authentication Protocol). PEAP is

a mutual authentication protocol that uses digital certificates for network server authentication and passwords for client authentication. For additional security, the authentication exchanges are encapsulated within TLS (Transport Layer Security). Dynamic encryption keys are used for secure communications.

● EAP-MD5 (EAP using Message Digest Algorithm 5, RFC 1321).

EAP-MD5 is a one-way authentication protocol that authenticates the client using a password protected by the MD5 encryption algorithm.

● EAP-TLS (EAP using Transport Layer Security, RFC 2716).

EAP-TLS is a mutual authentication protocol based on X.509-compliant digital certificates for authentication of both the client and the network authentication server. Dynamic encryption keys are used for secure communications.

● EAP-TTLS (EAP using Tunneled Transport Layer Security).

EAP-TTLS is an EAP-TLS extension that supports:

■ mutual authentication through client and server

X.509-compliant digital certificates, or

■ one-way authentication through certificate-based server

authentication followed by tunneled password-based client authentication. For additional security, the authentication exchanges are encapsulated within TLS (Transport Layer Security).

TTLS uses dynamic encryption keys for secure communications.

ENWW Introducing the HP Jetdirect Print Server 12

Without an Authentication Server

For small office networks that do not have an authentication server, HP Jetdirect wireless print servers support network authentication using Extensible Authentication Protocol with a Pre-shared key (EAP/PSK). Using a pass-phrase entered by the user, the print server generates a pre-shared key used for network access and communications.

When configured for EAP/PSK authentication, the print server uses Wi-Fi Protected Access (WPA) dynamic encryption protocols for wireless communications.

Encryption

HP Jetdirect 802.11b wireless print servers support static WEP (Wired Equivalent Privacy) encryption. For static WEP encryption, a network WEP key of fixed length (40/64-bit or 104/128-bit) is shared by each device on the network.

Depending on your wireless print server model, the following dynamic encryption protocols are supported:

● dynamic WEP

● Wi-Fi Protected Access (WPA)

Note If not supported by your HP Jetdirect wireless print

server, EAP/PSK authentication and Robust

encryption will not be displayed as a selectable

configuration option.

When dynamic encryption is used, encryption keys are periodically changed automatically and provide enhanced security because they will likely change before someone can decipher them.

In dynamic WEP encryption, each device on the wireless network is assigned a different encryption key that expires at preset intervals and is then replaced.

WPA encryption is an enhanced version of dynamic WEP and offers improved security. For example, new encryption keys are generated for fixed amounts of data (10 kilobytes) transmitted by a device on the network.

ENWW Introducing the HP Jetdirect Print Server 13

Supplied Manuals

The manuals listed below are supplied with your print server or with printers that have factory-installed print servers.

● Getting Started Guide, User Guide or equivalent printer

documentation (shipped with printers that have factory-installed HP Jetdirect print servers).

● This manual, the HP Jetdirect Print Server Administrator’s

Guide.

● HP Jetdirect Setup Guide (for 615n/620n print servers only),

supplied on CD-ROM with off-the-shelf print servers).

● The HP Jetdirect Wireless Print Server Setup Guides (for 680n

and 380x print servers only, supplied with off-the-shelf print servers).

● The HP Jetdirect Print Server User’s Guides (for

175x/310x/en3700 and 200m/250m/280m print servers, supplied on CD-ROM with off-the-shelf print servers).

HP Support

HP Online Support

Click your way to a quick solution! The HP Web site

http://www.hp.com/support/net_printing

is a great place to start for answers to questions about your HP Jetdirect print server — 24 hours a day, 7 days a week.

Firmware Upgrades

Hewlett-Packard offers downloadable firmware upgrades for HP Jetdirect print servers that contain upgradeable memory (HP Jetdirect 175x and 200m products are not upgradeable). The upgrades are available from the World Wide Web at:

http://www.hp.com/go/webjetadmin_firmware

ENWW Introducing the HP Jetdirect Print Server 14

Firmware Installation Tools

Firmware upgrades for supported HP Jetdirect print servers may be installed over a network using one of the following firmware installation tools:

● HP Jetdirect Download Manager (Windows). HP Jetdirect

Download Manager can be downloaded from HP online support at:

http://www.hp.com/go/dlm_sw

● HP Web Jetadmin may be used on supported systems. For more

information on HP Web Jetadmin, visit:

http://www.hp.com/go/webjetadmin/

● For firmware versions x.24.00 and later, the embedded Web

server resident on the print server provides a firmware upgrade feature using your Web browser. For more information see

Chapter 4

● For firmware versions x.22.00 and later, FTP (File Transfer

Protocol) may be used to transfer a firmware upgrade image file to the print server. To start an FTP session, use the device IP address or host name. If a password is set, it must be entered to log into the device. After user login, typical FTP commands to upgrade the device are illustrated below:

ftp> bin ftp> hash ftp> cd /download ftp> put <firmware image filename; specify full pathname> ftp>######### <Wait for FTP to complete the download> ftp> bye

ENWW Introducing the HP Jetdirect Print Server 15

HP Support By Phone

Highly trained technicians are ready to take your call. For the most recent HP support telephone numbers and available services worldwide, visit:

http://www.hp.com/support/support_assistance

Note For toll-free support in the USA and Canada, call

1-800-HPINVENT or 1-800-474-6836.

Note Telephone fees are the responsibility of the caller.

Rates may vary. Contact your local telephone company for current rates.

Product Registration

To register your HP Jetdirect print server, use the following HP Web page:

http://www.hp.com/go/jetdirect_register

ENWW Introducing the HP Jetdirect Print Server 16

HP Software Solutions Summary

Introduction

HP provides a variety of software solutions to set up or manage your HP Jetdirect-connected network devices. See Table 2.1 determine which software is best for you.

Note For more information on these and other solutions,

visit HP online support at:

to help you

http://www.hp.com/support/net_printing

Table 2.1 Software Solutions (1 of 3)

Operating Environment Function Remarks

HP Jetdirect Wireless Setup Wizard (Windows)

Windows 98, Me, NT 4.0, 2000, XP (32-bit only), Server 2003

HP Install Network Printer Wizard (Windows)

Windows 98, Me, NT 4.0, 2000, XP* (Direct Mode IP and IPX), Server 2003

NetWare 4.x, 5.x, 6.0 (IPX/SPX only)

*IPX/SPX not supported on Windows XP 64-bit edition.

Configure a single HP Jetdirect wireless print server for a wireless connection to your network.

(Note: This wizard does not install the printer on your system.)

Install a single network printer on your system for peer-to-peer (direct mode) or client-server (shared) printing.

● Runs from CD-ROM on

a wireless computer

● Allows you to set IP

address parameters

● Installable version that

runs from your hard disk is available

● Simple printer

installation, typically integrated with printer system software

● Runs from CD-ROM

● Installable version that

runs from your hard disk is available

ENWW 17

Table 2.1 Software Solutions (2 of 3)

Operating Environment Function Remarks

HP Jetdirect Printer Installer for UNIX

HP-UX 10.x-10.20, 11.x Solaris 2.6, 7, 8

(SPARCsystems only) TCP/IP

HP Web Jetadmin

(See the HP Website for supported system updates.)

Windows NT 4.0, 2000, XP Professional, Server 2003

HP-UX* Solaris* Red Hat Linux, SuSE Linux NetWare* TCP/IP, IPX/SPX *Supports queue creation

and peripheral management from HP Web Jetadmin hosted on Windows NT 4.0, 2000, XP, Server 2003.

Fast and easy installation of HP Jetdirect-connected printers.

Remote installation, configuration, and management of HP Jetdirect-connected print servers, non-HP printers that support the standard MIBs, and printers with embedded Web servers.

Alerts and consumables management.

Remote firmware upgrades for HP Jetdirect print servers.

● Supplied on the HP

Jetdirect CD-ROM, and may be downloaded from HP’s Website

● HP’s preferred solution

for ongoing management and installation of multiple printers anywhere on your intranet

● Browser-based

management

Asset tracking and utilization analysis.

Internet Printer Connection Software

Windows NT 4.0, 2000 (Intel)

TCP/IP only Note: Microsoft Internet

Printing software is also integrated with Windows 2000.

Printing through the Internet to Internet Printing Protocol (IPP)-enabled HP Jetdirect-connected printers.

● Allows economical

distribution of high-quality hardcopy documents over the Internet, replacing fax, mail, and overnight services

● Requires HP Jetdirect

print server (firmware version x.20.00 or later)

● IPP is not supported on

value-based products, such as 175x, 200m

ENWW HP Software Solutions Summary 18

Table 2.1 Software Solutions (3 of 3)

Operating Environment Function Remarks

HP IP/IPX Printer Gateway for NDPS

NetWare 5.x, 6.0 (IPX only)

HP WPS Assistant (Mac OS X)

Mac OS X 10.1.5 or later Configuration of HP

HP LaserJet Utilities for Mac OS

Mac OS 9.x, X (Classic Mode)

Simplified installation, printing, and bidirectional management of HP Jetdirect-connected printers under Novell Distributed Print Services (NDPS).

Allows automatic discovery and installation of HP Jetdirect-connected printers into NDPS.

Jetdirect wireless print servers with a connection to your network.

Configuration and management of HP Jetdirect-connected printers.

● Frees up user licenses

● Allows disabling of

SAPs to reduce network traffic

● Requires HP Jetdirect

firmware version x.20.00 or later

● Requires HP Jetdirect

wireless print servers with firmware version x.24.00 or later

● Distributed on the HP

Jetdirect CD-ROM

ENWW HP Software Solutions Summary 19

HP Jetdirect Wireless Setup Wizard

The HP Wireless Setup Wizard is a software utility that configures your HP Jetdirect wireless print server with a wireless connection to your network.

Note that the HP Wireless Setup Wizard does not install the printer on your system. After a wireless network connection is established, you must use other HP printer installation utilities, or standard Operating System tools, to install the printer on your network systems. When installing the printer on a system, the wireless printer should appear like any other printer on your network.

The HP Wireless Setup Wizard is provided on CD-ROM with each HP Jetdirect wireless print server. The wizard must be run on a supported wireless computer that has been preconfigured to communicate with the HP Jetdirect print server. A version of the HP Wireless Setup Wizard that runs from your system disk is also available, and can be downloaded from HP online support at:

www.hp.com/go/jdwsw_software

Note Although primarily intended for configuration of

wireless networking parameters, the HP Wireless Setup Wizard also allows you to preconfigure a valid IP address on the print server, as required (for example, to accommodate special DHCP requirements or Access List restrictions).

Requirements

● Wireless computer, typically a laptop PC

● Microsoft Windows XP (32-bit only), Windows 2000, Windows NT

4.0, Windows 98, Windows Me

ENWW HP Software Solutions Summary 20

HP Install Network Printer Wizard (Windows)

The HP Install Network Printer Wizard is a software module for quick and easy printer installation on a TCP/IP or IPX/SPX network. The wizard allows you to configure the printer with IP parameters on a TCP/IP network, or NDS/Bindery objects on a Novell NetWare IPX/SPX network.

The HP Install Network Printer Wizard is included on the HP Jetdirect CD-ROM supplied with standalone HP Jetdirect products. The wizard is run through the Install selection on the Jetdirect CD-ROM interface. The wizard runs from the CD-ROM, although some files may be temporarily stored and then removed from your system disk after a system reboot.

In addition, a version of this wizard is typically integrated with your printer system installation software and runs from a CD-ROM supplied with HP network-ready printers. However, this version may not support Novell NetWare network installations.

A version that runs from your system disk is also available and can be downloaded from HP online support at:

http://www.hp.com/go/inpw_sw

Requirements

● Microsoft Windows XP, Windows 2000, Windows NT 4.0,

Windows 98/Me, Server 2003

◆ TCP/IP or IPX/SPX network protocol

● Novell NetWare 4.x, 5.x, 6.0

◆ Novell Client software for Microsoft Windows

98/NT 4.0/2000/XP

◆ Queue Server Mode

◆ IPX/SPX network protocol

● The correct printer driver

● Printer connection to the network through an HP Jetdirect

print server

ENWW HP Software Solutions Summary 21

HP Jetdirect Printer Installer for UNIX

The HP Jetdirect Printer Installer for UNIX contains support for HP-UX and Solaris systems. The software installs, configures and provides diagnostics capabilities for HP printers connected to TCP/IP networks using full-featured HP Jetdirect print servers. Value-based print servers, such as 175x and 200m, are not supported.

The software is distributed through the following methods:

● HP Jetdirect CD-ROM, provided with standalone HP Jetdirect

print servers

● Anonymous FTP site at ftp.hp.com (Directory:

/pub/networking/software)

● HP online support at:

http://www.hp.com/support/net_printing

For system requirements and installation information, see the documentation provided with the software.

ENWW HP Software Solutions Summary 22

HP Web Jetadmin

HP Web Jetadmin is an enterprise management tool that allows you to remotely install, configure and manage a wide variety of HP and non-HP network printing devices simply through a standard Web browser. HP Web Jetadmin can be used to proactively manage both individual or groups of devices.

While HP Web Jetadmin supports devices that contain Standard Printer MIB (Management Information Base) objects for common management, it is well-integrated with HP Jetdirect print servers and HP printers to provide enhanced management features.

To use HP Web Jetadmin, see the online help and documentation supplied with the software.

System Requirements

HP Web Jetadmin software runs on Microsoft Windows NT 4.0, Windows 2000, Windows XP Professional, Windows Server 2003, Red Hat Linux, and SuSE Linux systems. For information on supported operating systems, clients, and compatible browser versions, visit HP online support at

http://www.hp.com/go/webjetadmin

Note When installed on a supported host server,

HP Web Jetadmin can be accessed from any client

through a compatible Web browser by browsing to

the HP Web Jetadmin host. This allows printer

installation and management on Novell NetWare

and other networks.

ENWW HP Software Solutions Summary 23

Installing HP Web Jetadmin

Before installing the HP Web Jetadmin software, you must have administrator or root privileges on the local system:

1. Download the installation files from HP online support at

http://www.hp.com/go/webjetadmin

2. Follow the instructions on the screen to install the HP Web Jetadmin software.

Note Installation instructions are also contained in the

HP Web Jetadmin install file.

Verifying Installation and Providing Access

● Verify that the HP Web Jetadmin software is correctly installed

by navigating to it with your browser as shown in the following example:

http://systemname.domain:port/

where systemname.domain is the host name of your Web server and port is the port number assigned during installation. By default, the port number is 8000.

● Provide users access to HP Web Jetadmin software by adding a

link to your Web server’s home page that is addressed to HP Web Jetadmin’s URL. For example:

http://systemname.domain:port/

ENWW HP Software Solutions Summary 24

Configuring and Modifying a Device

Using your browser, navigate to HP Web Jetadmin’s URL. For example:

http://systemname.domain:port/

Follow the instructions on the appropriate home page to configure or modify your printer.

Note You can also substitute the systemname.domain

with the TCP/IP address.

Removing HP Web Jetadmin Software

To remove HP Web Jetadmin software from your Web server, use the uninstall program provided with the software package.

ENWW HP Software Solutions Summary 25

Internet Printer Connection Software

Full-featured HP Jetdirect print servers (firmware version x.20.00 or later) support the Internet Printing Protocol (IPP). Value-based print servers, such as 175x and 200m, are not supported.

Using the appropriate software on your system, you can create an IPP print path from your system to a supported HP Jetdirect-connected printer over the Internet.

Note For incoming print path requests, the network

administrator must configure the firewall to accept incoming IPP requests. Security features available in the software are currently limited.

Features and benefits provided by Internet printing include:

● High-quality, time-sensitive documents can be printed remotely,

in full-color or black-and-white

● Documents can be printed remotely at a fraction of the cost of

current methods (such as fax, mail, or overnight delivery services)

● The traditional LAN printing model can be extended to that of

an Internet Printing Model

● IPP requests for sending print jobs can be transmitted outbound

through firewalls

HP-Supplied Software

HP Internet Printer Connection software allows you to set up Internet printing from Windows NT 4.0 and Windows 2000 clients.

1. To obtain the software:

Download the HP Internet Printer Connection software from HP online support at:

http://www.hp.com/support/net_printing

ENWW HP Software Solutions Summary 26

2. To install the software and set up the print path to the printer, follow the instructions provided with the software. Contact your network administrator to get the IP address or URL of the printer to complete the setup.

HP Software System Requirements

● Computer running Microsoft Windows NT 4.0 (Intel-based) or

Windows 2000

● IPP-enabled HP Jetdirect print server (firmware must be at

revision x.20.00 or later)

HP Software Supported Proxies

Web proxy with support for HTTP v1.1 or greater (may not be needed if printing over an intranet).

Microsoft Supplied Software

Note Contact Microsoft for support of Windows IPP

software.

Windows 2000/XP Integrated Software

On Windows 2000/XP systems, an alternative to using the HP supplied software is to use the IPP-client software integrated with Windows 2000/XP. The IPP implementation on the HP Jetdirect print server is compatible with Windows 2000/XP IPP-client software.

To set up a print path to an HP Jetdirect-connected Internet printer using the Windows 2000/XP IPP-client software, proceed as follows:

1. Open the Printers folder (click Start, select Settings, and select Printers).

2. Run the Add Printer wizard (double-click Add Printer), then click Next.

3. Select the option for a network printer and click Next.

ENWW HP Software Solutions Summary 27

4. Select Connect to a printer on the Internet and enter the print server’s URL:

http://IP_address[/ipp/port#]

where IP_address is the IP address configured on the HP Jetdirect print server. [/ipp/port#] identifies the port number on a multi-port HP Jetdirect external print server (port1, port2, or port3) that the printer is connected to (default is /ipp/port1).

Examples:

http://192.160.45.40 An IPP connection to HP Jetdirect

610N/615N internal print server with IP address 192.160.45.40. (“/ipp/port1” is assumed and not required.)

http://192.160.45.39/ipp/port2 An IPP connection to HP Jetdirect

external print server with IP address

192.160.45.39 and the printer on port 2

Then click Next.

5. You will be prompted for a printer driver (the HP Jetdirect print server does not contain printer drivers, so your system cannot automatically obtain the driver). Click OK to install the printer driver onto your system and follow the instructions on the screen. (You may need your printer CD-ROM to install the driver.)

6. To complete the print path setup, follow the instructions on the screen.

Windows Me IPP Client

The IPP implementation on the HP Jetdirect print server is compatible with Windows Me IPP-client software. The IPP client is installed from the Add-Ons folder on the Windows Me CD-ROM. For installation and setup of a Windows Me IPP client, see the instructions provided with the Windows Me CD-ROM.

Novell Supplied Software

The HP Jetdirect print server is compatible with IPP running on NetWare 5.1 with SP1 or later. For NetWare client support, refer to your NetWare technical documentation or contact Novell.

ENWW HP Software Solutions Summary 28

HP IP/IPX Printer Gateway for NDPS

NDPS (Novell Distributed Print Services) is a printing architecture developed by Novell in partnership with Hewlett-Packard. NDPS simplifies and streamlines the administration of network printing. It eliminates the need to set up and link print queues, printer objects, and print servers. Administrators can use NDPS to manage networked printers within supported NetWare environments.

The HP IP/IPX Printer Gateway is a NetWare Loadable Module (NLM) developed by HP to provide functionality and compatibility with Novell's NDPS for full-featured HP Jetdirect print servers. Value-based print servers, such as 175x and 200m, are not supported.

The HP Gateway seamlessly integrates HP Jetdirect-attached printers into the NDPS environment. Using the HP Gateway, an administrator can view statistics, configure gateway settings, and configure printing for HP Jetdirect-connected printers.

Features

Features and benefits provided by the HP Gateway and NDPS include:

● Smart detection of printers in NetWare 5.x, 6.0 environments

● Automatic installation of printers using IP/IPX

● Tight integration with Novell's NDS and NWAdmin

● Status updates from printers

● Simplified Automatic Driver Download

● Reduced SAP Traffic

● Reduced number of required NetWare User Licenses

● Native TCP/IP printing with NetWare 5.x, 6.0

ENWW HP Software Solutions Summary 29

To Get the Software

The HP IP/IPX Printer Gateway is included with all current versions of NDPS. Novell NetWare 5.x and 6.0 includes NDPS. To obtain the most recent software version, or to obtain the related documentation:

■ Visit http://www.hp.com/go/hpgate_sw

■ Select and follow the instructions for downloading drivers and

software.

System requirements and Novell Client support are included in the documentation supplied with the software.

ENWW HP Software Solutions Summary 30

HP WPS Assistant (Mac OS X)

This utility allows you to configure an HP Jetdirect wireless print server (WPS) with a connection to your Mac OS network.

To use this utility, the HP Jetdirect wireless print server must be in a factory-default state. Proceed as follows:

1. Insert the CD-ROM into your Mac OS system (version X 10.1.5 or later).

2. Select and open the HPJETDIRECT CD-ROM icon.

3. If provided, read the release notes for updated information.

4. Select and open the HP WPS Assistant folder.

5. Run the HP WPS Assistant utility, then follow the instructions on the screen.

Note Optionally, for Mac OS 9.x or X systems, you may

use the embedded Web server to configure a network connection. See Appendix B

Once a wireless connection has been created, you will need to use other utilities (such as the HP LaserJet Utility for Mac OS) to configure and manage your printer for printing.

ENWW HP Software Solutions Summary 31

HP LaserJet Utilities for Mac OS

The HP LaserJet Utilities for Mac OS allow you to configure and manage your HP Jetdirect-connected printers on AppleTalk networks. This section describes software installation and use of the HP LaserJet Utilities. In addition, it describes how to use the Chooser to select and set up a Mac OS computer to print to your HP printer.

Installing the Printer Software

If the HP LaserJet Utility was included on your printer’s CD-ROM, see your printer documentation for installation instructions, then skip to the next section to configure the printer.

If you are installing the HP LaserJet Utility from the HP Jetdirect CD-ROM, use the following installation instructions.

Note If you are installing the HP LaserJet Utility from a

source other than the CD-ROM, see the README file that accompanies the software for installation instructions.

Note Automatic virus detection programs might interfere

with the installation of this software. Turn off any such programs that are active on your Mac OS computer before proceeding with the installation process.

1. Insert the CD-ROM into the CD-ROM drive.

2. In the HP Installer window, double-click the installation icon for the software in the language you want.

3. Follow the instructions on the screen.

For more information about configuring your printer driver, see the online documentation provided on the CD-ROM that came with the printer.

ENWW HP Software Solutions Summary 32

Configuring the Printer

The HP LaserJet Utility allows printer settings such as printer name and preferred zone to be configured from your Mac OS system. Hewlett-Packard recommends that only network administrators use the printer configuration capabilities of this utility.

If this printer is to be serviced by a print spooler, set up the printer's name and zone before configuring the spooler to capture the printer.

Running the HP LaserJet Utility

1. With the printer turned on and online, and the print server connected to the printer and to the network, double-click the HP LaserJet Utility icon.

2. If the printer’s name is not listed as the target printer, click Select Printer. The Select a Target Printer window appears.

■ Select the zone, if necessary, from the AppleTalk Zones list in

which the printer resides. The zone the printer is in is shown on the configuration page. See the hardware installation guide for your print server or your printer's Getting Started guide for instructions on printing a configuration page.

■ Select the printer from the Available Printers list and

click OK.

Verifying Network Configuration

To verify your current network configuration, print a Jetdirect configuration page. If you have not printed a configuration page from your printer, see the hardware installation guide for your print server or your printer documentation for instructions (see Chapter

9 for more information). If your printer has a control panel, make

sure a 1 minute, then print the page. The current configuration is listed under “AppleTalk” on the configuration page.

Note If you have multiple printers on your network, you

ENWW HP Software Solutions Summary 33

READY message appears on the control panel for at least

need to print a configuration page to identify the printer’s name and zone.

Renaming the Printer

The factory supplies a default name for your printer.

Hewlett-Packard highly recommends that you rename your printer to avoid having multiple printers with similar names on your network.

CAUTION After you have renamed the printer and have set up

print queues to that printer, use caution when changing the printer name again. If you rename the printer again, the queues for that printer will no longer function.

Note The name may be up to 32 characters in length.

A warning beep indicates that an illegal character was typed. For illegal characters, see the Help system integrated with the software.

You can name your printer anything you like—for example, “Michael’s LaserJet 4000.” The HP LaserJet Utility has the ability to rename devices located in different zones, as well as the local zone (no zones need to be present in order to use the HP LaserJet Utility).

1. Select the Settings icon from the scrolling icon list. The Please select a setting: dialog appears.

2. Select Printer Name in the list.

3. Click Edit. The Set Printer Name dialog box appears.

4. Type the new name.

5. Click OK.

Note If you try to name your printer the same name

as another printer, an alert dialog box appears directing you to select another name. To select another name, repeat steps 4 and 5.

6. If your printer is on an EtherTalk network, continue with the next section, “Selecting a Zone

ENWW HP Software Solutions Summary 34

.”

7. To exit, select Quit from the File menu.

Notify everyone on your network of the new name for your printer so they can select the printer in the Chooser.

Selecting a Zone

The HP LaserJet Utility allows you to select a preferred zone for your printer on a Phase 2 EtherTalk network. Instead of your printer remaining on the default zone, which is set by the router, this utility lets you select the zone on which your printer appears. The zones on which your printer can reside are limited by your network configuration. The HP LaserJet Utility only enables

you to select a zone that is already configured for your network.

Zones are groups of computers, printers, and other AppleTalk devices. They can be grouped by physical location (for example, Zone A may contain all the printers on the network in building A). They may also be grouped logically (for example, all printers used in the finance department).

1. Select the Settings icon from the scrolling icon list. The Please Select a Setting: dialog box appears.

2. Select Printer Zone in the list and click Edit. The Select a Zone dialog box appears.

3. Select your preferred network zone from the Select a Zone: list and click Set Zone.

4. To exit, select Quit from the File menu.

Notify everyone on your network of the new zone for your printer so they can select the printer in the Chooser.

Selecting Your Printer

1. Select the Chooser from the Apple menu.

2. Select the printer icon for use with your printer. If the appropriate printer icon does not appear in the Chooser, or you are not sure which icon to select for your printer, see “Installing

the Printer Software” in this chapter.

ENWW HP Software Solutions Summary 35

3. If AppleTalk is not active, an alert dialog box appears on your screen. Select OK. The Active button turns on.

If your network is linked to other networks, the AppleTalk Zones list dialog box appears in the Chooser.

4. If applicable, select the zone in the AppleTalk Zones scrolling list where your printer is located.

5. Select the printer name you want to use from the list of printer names in the upper-right area of the Chooser. If the printer's name does not appear in the list, make sure the following tasks have been performed:

■ the printer is turned on and is online.

■ the print server is connected to the printer and to the network.

■ the printer cable connections are secure.

READY message should appear if the printer has a control panel

display. See Chapter 8

for more information.

Note If your printer is the only name listed in the

dialog box, you must still select it. Your printer

remains selected until you select a different printer with the Chooser.

6. Click Setup or Create in the Chooser; then, if prompted, select the appropriate PostScript Printer Description file (PPD) for the printer. For more information, see the online documentation.

7. Set Background Printing to ON or OFF.

If background printing is turned OFF when you send a print job to the printer, status messages appear on your screen and you have to wait until the messages clear before continuing your work. If background printing is turned ON, the messages are redirected to the PrintMonitor and you can continue working while the printer is printing your job.

8. Exit the Chooser.

To display your user name on the network when you are printing documents, go into the Control Panel on your Mac OS computer, select Sharing Setup, then type your owner name.

ENWW HP Software Solutions Summary 36

Testing the Configuration

1. Select Print Window from the File menu, or if no window is open, select Print Desktop.

The Print dialog box appears.

2. Click Print.

If the printer prints the job, you have connected your printer to your network correctly. If your printer does not print, see

Chapter 8

ENWW HP Software Solutions Summary 37

TCP/IP Configuration

Introduction

To operate properly on a TCP/IP network, the HP Jetdirect print server must be configured with valid TCP/IP network configuration parameters, such as an IP address that is valid for your network. For general information on TCP/IP networks, see Appendix A

Server-Based and Manual TCP/IP Configuration

When in a factory-default state and powered on, the HP Jetdirect print server will try to obtain its TCP/IP configuration using a server-based method, such as BOOTP/TFTP, DHCP/TFTP, or RARP. These server-based methods are described later in this chapter.

The print server may also be configured manually. Manual-based tools include Telnet, a Web browser, the printer control panel, arp and ping commands (when the default IP address is 192.0.0.192), or SNMP-based management software. TCP/IP configuration values assigned manually will be retained when powered off/on.

The print server can be reconfigured to use either server-based or manual configuration of TCP/IP settings at any time.

ENWW 38

Default IP Address

When in a factory-default state (for example, when shipped from the factory or after a cold-reset), the HP Jetdirect print server has no IP address. A default IP address may or may not be assigned depending on the network environment.

Default IP Address Will Not Be Assigned

A default IP address will not be assigned if a server-based method (such as BOOTP or DHCP) is successful. And if the print server is powered off/on, the same method will again be used to retrieve IP configuration settings. If this method now fails to retrieve the IP configuration settings (for example, the BOOTP or DHCP server is no longer available), a default IP address will not be assigned. Instead, the print server will continue to send IP configuration requests indefinitely. You must cold-reset the print server to change this behavior.

In addition, a default IP address will not be assigned if a network cable is not attached to a wired print server.

Default IP Address Will Be Assigned

A default IP address will be assigned if the factory-default methods fail, or if the print server has just been reconfigured by an administrator to use a server-based method (such as BOOTP or DHCP) that fails.

If a default IP address is assigned, the address will depend on the network to which the print server is connected. The print server senses broadcast packets on the network to determine the appropriate default IP settings:

● On small private networks that adhere to automated,

standards-based IP address assignments, the print server uses a link-local addressing technique to assign a unique IP address. Link-local addressing may be referenced as Auto IP. The IP address assigned will be in the range of 169.254.1.0 to

169.254.254.255 (commonly referenced as 169.254/16), and should be valid. However, it can be further modified for your network using supported TCP/IP configuration tools if necessary.

ENWW TCP/IP Configuration 39

With link-local addresses, subnetting is not used. The subnet mask will be 255.255.0.0, and cannot be changed.

Link-local addresses will not route off the local link, and access to or from the Internet will not be available. The default gateway address will be the same as the link-local address.

If a duplicate address is sensed, the HP Jetdirect print server will automatically reassign its address, if necessary, in accordance with standard link-local addressing methods.

● On large or enterprise IP networks, a temporary address of

192.0.0.192 will be assigned until it is reconfigured with a valid address through supported TCP/IP configuration tools. We refer to this address as Legacy Default IP.

● On mixed-environment networks, the self-assigned default IP

address may be either 169.254/16 or 192.0.0.192. In this case, you should verify on the Jetdirect configuration page that the assigned default IP address is as expected.

The IP address configured on your print server may be determined by inspecting the Jetdirect configuration page for the print server. See Chapter 9

Default IP Address Configuration Options

Default IP Parameter

A Default IP configuration parameter on the print server controls the default IP method.

When the print server is in a factory-default state, this parameter is undefined. If the print server is initially configured with a default IP address (either a link-local or 192.0.0.192 IP address), the Default IP parameter will be assigned either Auto IP or Legacy Default IP to match. This parameter setting will determine the IP address to use when the print server is unable to obtain an IP address from the network during a forced TCP/IP reconfiguration (for example, when manually configured to use BOOTP or DHCP).

The Default IP parameter can be changed through a supported configuration tool, such as Telnet, a Web browser, and SNMP management applications.

ENWW TCP/IP Configuration 40

DHCP Requests Enable/Disable

When a default IP address is assigned, you can choose to send, or not send, periodic DHCP requests. DHCP requests are used to retrieve IP configuration settings from a DHCP server on the network. By default, this parameter is enabled, allowing DHCP requests to be transmitted. However, this parameter may be disabled through supported configuration tools such as Telnet, a Web browser, and SNMP management applications.

HP Jetdirect Wireless Print Server. When initially powered on, a factory-default wireless print server that has no connection to a network will likely self-assign a link-local IP address. If a network connection to a DHCP server-based network is made, the IP address will likely be reconfigured because DHCP requests on the print server are enabled by default.

Default IP on Wireless and Wired Print Servers

Wired and wireless print servers may have different default IP configuration results:

● When powered on, a factory-default wired print server will

systematically use BOOTP, DHCP, and RARP to retrieve its IP settings. Up to two minutes are used. If configuration is not successful, a default IP address will be assigned as described previously.

● For a factory-default wireless print server, a network connection

must first be configured before it can communicate on a network. Therefore, retrieval of IP settings from a network is limited to about four seconds. During this time, a single BOOTP request is transmitted, and broadcast packets are sensed. Because a response from a BOOTP server on an Ad Hoc network is unlikely, and the number of broadcast packets sensed will be minimal, a default IP configuration using link-local addressing is likely.

However, the IP configuration may change once the wireless print server is connected a DHCP network because the sending of DHCP requests will be enabled by default.

Configuration tools that require a specific default IP address to initially communicate with a factory-default print server may not work without modification. For the default IP address settings on the print server, see the Jetdirect configuration page.

ENWW TCP/IP Configuration 41

TCP/IP Configuration Tools

Depending on your printer and operating system, an HP Jetdirect print server can be configured with valid TCP/IP parameters for your network in the following ways:

● Using Software. You can use your printer installation

software or the HP Jetdirect print server installation software on supported systems. For more information see Chapter 2

Software Solutions Summary”.

To configure a wireless print server with a valid IP address before a wireless connection is established, use the HP Jetdirect Wireless Setup Wizard (Windows) or the embedded Web server. Printer installation software may be used for IP configuration of network-connected printers only.

● BOOTP/TFTP. You can download the data from a

network-based server using BOOTP (Bootstrap Protocol) and TFTP (Trivial File Transfer Protocol) each time the printer is turned on. For more information, see “Using BOOTP/TFTP

The BOOTP daemon, bootpd, must be running on a BOOTP server that is accessible by the printer.

● DHCP/TFTP. You can use Dynamic Host Configuration

Protocol (DHCP). This protocol is supported in HP-UX, Solaris, Red Hat Linux, SuSE Linux, Windows NT/2000/XP, NetWare and Mac OS systems. (Refer to your network operating system manuals to verify that your server operating system supports DHCP.) For more information, see “Using DHCP

”.

, “HP

”.

Note Linux and UNIX systems: For more information,

see the bootpd man page.

On HP-UX systems, a sample DHCP configuration file (dhcptab) may be located in the /etc directory.

Since HP-UX presently does not provide Dynamic Domain Name Services (DDNS) for its DHCP implementations, HP recommends that you set all print server lease durations to infinite. This ensures that print server IP addresses remain static until such time as Dynamic Domain Name Services are provided.

ENWW TCP/IP Configuration 42

● RARP. A network-based server can use RARP (Reverse Address

Resolution Protocol) to answer the print server's RARP request and supplying the print server with the IP address. The RARP method only allows you to configure the IP address. For more information, see “Using RARP

● arp and ping commands. (For print servers configure with

”.

Legacy default IP address 192.0.0.192 only) You can use the arp and ping commands from your system. For more information, see “Using the arp and ping Commands

● Telnet. You can set configuration parameters using Telnet. In

”.

order to set configuration parameters, set up a Telnet connection from your system to the HP Jetdirect print server using the default IP address. Once configured, the print server saves the configuration when powered off/on. For more information, see “Using Telnet

● Embedded Web server. You can browse to the embedded Web

”.

server on the HP Jetdirect print server and setting the configuration parameters. For more information, see Chapter 4

● Printer Control Panel. (Internal Jetdirect print servers only)

You can manually enter the configuration data using the printer control panel keys. The control panel method allows you to configure only a limited subset of configuration parameters (IP address, subnet mask, default gateway address, and idle timeout). Therefore, control panel configuration is recommended only during troubleshooting or for simple installations. If control panel configuration is used, the print server saves the configuration when powered off/on. For more information, see “Using the Printer Control Panel

”.

ENWW TCP/IP Configuration 43

Using BOOTP/TFTP

Note For HP Jetdirect wireless print servers, this section

assumes that a wireless connection to your network has been established.

BOOTP (Bootstrap Protocol) and TFTP (Trivial File Transfer Protocol) provide a convenient way to automatically configure the HP Jetdirect print server for TCP/IP network operation. When powered on, the Jetdirect print server sends a BOOTP request message onto the network. A properly configured BOOTP server on the network will respond with a message that contains basic network configuration data for the Jetdirect print server. The BOOTP server’s response may also identify a file that contains extended configuration data for the print server. The Jetdirect print server downloads this file using TFTP. This TFTP configuration file may be located on the BOOTP server, or a separate TFTP server.

BOOTP/TFTP servers are typically UNIX or Linux systems. Windows NT/2000 and NetWare servers can respond to BOOTP requests. Windows NT/2000 servers are configured through Microsoft DHCP services (see Using DHCP NT/2000 systems may require third-party software for TFTP support. For setup of NetWare BOOTP servers, refer to your NetWare documentation.

). However, Windows

Note If the Jetdirect print server and BOOTP/DHCP

server are located on different subnets, IP configuration may fail unless the routing device supports “BOOTP Relay” (allows the transfer of BOOTP requests between subnets).

ENWW TCP/IP Configuration 44

Why Use BOOTP/TFTP?

Using BOOTP/TFTP to download configuration data has the following benefits:

● Enhanced configuration control of the HP Jetdirect print server.

Configuration by other methods, such as a printer control panel, are limited to select parameters.

● Ease of configuration management. Network configuration

parameters for the entire network can be in one location.

● Ease of HP Jetdirect print server configuration. Complete

network configuration can be automatically downloaded each time the print server is powered on.

Note BOOTP operation is similar to DHCP, but the

resulting IP parameters will be the same when powered off/on. In DHCP, IP configuration parameters are leased and may change over time.

When in its factory-default state and powered on, the HP Jetdirect print server will attempt to automatically configure itself using several dynamic methods, one of which is BOOTP.

BOOTP/TFTP on UNIX

This section describes how to configure the print server using BOOTP (Bootstrap Protocol) and TFTP (Trivial File Transfer Protocol) services on UNIX servers. BOOTP and TFTP are used to download network configuration data from a server to the HP Jetdirect print server over the network.

Systems That Use Network Information Service (NIS)

If your sys t e m uses NIS, y o u may nee d t o rebuild t h e N I S map wit h the BOOTP service before performing the BOOTP configuration steps. Refer to your system documentation.

ENWW TCP/IP Configuration 45

Configuring the BOOTP Server

For the HP Jetdirect print server to obtain its configuration data over the network, the BOOTP/TFTP servers must be set up with the appropriate configuration files. BOOTP is used by the print server to obtain entries in the /etc/bootptab file on a BOOTP server, while TFTP is used to obtain additional configuration information from a configuration file on a TFTP server.

When the HP Jetdirect print server is powered on, it broadcasts a BOOTP request that contains its MAC (hardware) address. A BOOTP server daemon searches the /etc/bootptab file for a matching MAC address, and if successful, sends the corresponding configuration data to the Jetdirect print server as a BOOTP reply. The configuration data in the /etc/bootptab file must be properly entered. For a description of entries, see “Bootptab File Entries

”.

The BOOTP reply may contain the name of a configuration file containing enhanced configuration parameters. If the HP Jetdirect print server finds such a file, it will use TFTP to download the file and configure itself with these parameters. For a description of entries, see “TFTP Configuration File Entries

“. Configuration

parameters retrieved through TFTP are optional.

Note HP recommends that the BOOTP server be located

on the same subnet as the printers it serves.

BOOTP broadcast packets may not be forwarded by routers unless the routers are properly configured.

ENWW TCP/IP Configuration 46

Bootptab File Entries

An example of a /etc/bootptab file entry for an HP Jetdirect print server is provided below:

picasso:\

:hn:\ :ht=ether:\ :vm=rfc1048:\ :ha=0001E6123456:\ :ip=192.168.40.39:\ :sm=255.255.255.0:\ :gw=192.168.40.1:\ :lg=192.168.40.3:\ :T144=“hpnp/picasso.cfg”:

Note that the configuration data contains “tags” to identify the various HP Jetdirect parameters and their settings. Entries and tags supported by the HP Jetdirect print server (firmware version x.24.00 or later) are listed in Table 3.1

Table 3.1 Tags Supported in a BOOTP/DHCP Boot file (1 of 4)

Item RFC

2132 Option

Description

nodename -- The name of the peripheral. This name identifies an entry

ht -- The hardware type tag. For the HP Jetdirect print server,

vm -- The BOOTP report format tag (required). Set this

ha -- The hardware address tag. The hardware (MAC) address

ip -- The IP address tag (required). This address will be the

ENWW TCP/IP Configuration 47

point to a list of parameters for a specific peripheral.

nodename

example above,

set this to ether (for Ethernet) or token (for Token Ring). This tag must precede the ha tag.

parameter to rfc1048.

is the link-level, or station address of the HP Jetdirect print server. It can be found on the HP Jetdirect configuration page as the HARDWARE ADDRESS. On HP Jetdirect external print servers, it is printed on a label attached to the print server.

HP Jetdirect print server’s IP address.

must be the first field in an entry. (In the

nodename

is “picasso”.)

Table 3.1 Tags Supported in a BOOTP/DHCP Boot file (2 of 4)

Item RFC

2132 Option

Description

sm 1 The subnet mask tag. The subnet mask will be used by

the HP Jetdirect print server to identify the portions of an IP address that specify the network/subnetwork number and the host address.

gw 3 The gateway IP address tag. This address identifies the

IP address of the default gateway (router) that the HP Jetdirect print server will use for communications with other subnets.

ds 6 DNS (Domain Name System) server’s IP address tag.

Only a single name server can be specified.

lg 7 The syslog server’s IP address tag. It specifies the server

that the HP Jetdirect print server sends syslog messages to. For more information, see Appendix A

hn 12 The host name tag. This tag does not take a value but

causes the BOOTP daemon to download the host name to the HP Jetdirect print server. The host name will be printed on the Jetdirect configuration page, or returned on an SNMP sysName request by a network application.

dn 15 Domain name tag. Specifies the domain name for the

HP Jetdirect print server (for example, support.hp.com). It does not include the host name; it is not the Fully Qualified Domain Name (such as printer1.support.hp.com).

ef 18 Extensions file tag that specifies the relative path name of

the TFTP configuration file. Note: This tag is similar to the vendor-specific tag T144,

described below.

na 44 Tag for IP addresses of the NetBIOS-over-TCP/IP Name

Server (NBNS). A primary and secondary server may be specified in order of preference.

lease-time 51 DHCP IP address lease duration time (seconds).

tr 58 DHCP T1 timeout, specifying the DHCP lease renewal

time (seconds).

ENWW TCP/IP Configuration 48

Table 3.1 Tags Supported in a BOOTP/DHCP Boot file (3 of 4)

Item RFC

2132 Option

Description

tv 59 DHCP T2 timeout, specifying the DHCP lease rebind time

(seconds).

T69 69 The IP address (in hexadecimal) of the preferred outgoing

e-mail SMTP (Simple Mail Transport Protocol) server, for use with supported Scan devices.

T144 -- An HP-proprietary tag that specifies the relative path nam e

of the TFTP configuration file. Long path names may be truncated. The path name must be in double quotes (for example,

“pathname”

“TFTP Configuration File Entries

). For file format information, refer to

“.

Note: Standard BOOTP option 18 (extensions file path) also allows a standard tag (ef) to specify the relative path name of the TFTP configuration file.

T145 -- Idle Timeout option. An HP-proprietary tag to set the idle

timeout (seconds), which is the amount of time that a print data connection may remain idle before being closed. The range is 1 - 3600 seconds.

T146 -- Buffer Packing option. An HP-proprietary tag to set buffer

packing for TCP/IP packets. 0 (default): Normal data buffers are packed before sending

to the printer. 1: Disable buffer packing. Data is sent to the printer

when received.

T147 -- Write Mode option. An HP-proprietary tag that controls the

TCP PSH flag setting for device-to-client data transfers. 0 (default): disables this option, flag not set. 1: all-push option. The push bit is set in all data packets. 2: eoi-push option. The push bit is set only for data packets

that have an End-of-Information flag set.

T148 -- IP Gateway Disable option. An HP-proprietary tag to

prevent configuration of a Gateway IP address. 0 (default): allows an IP address. 1: prevents a Gateway IP address to be configured.

ENWW TCP/IP Configuration 49

Table 3.1 Tags Supported in a BOOTP/DHCP Boot file (4 of 4)

Item RFC

2132 Option

Description

T149 -- Interlock Mode option. An HP-proprietary tag that specifies

T150 -- TFTP server’s IP address option. An HP-proprietary tag to

T151 -- Network Configuration option. An HP-proprietary tag to

whether an acknowledgement (ACK) on all TCP packets is required before the printer is allowed to close a Port 9100 print connection. To accommodate multiport print servers, a Port Number and Option value are specified, in the form:

Port Number

Option

< enables.

Example: 2 1 specifies <Port 2>, <interlock enabled>

specify the TFTP server’s IP address where the TFTP configuration file is located.

specify either “BOOTP-ONLY” or “DHCP-ONLY” requests be sent.

Option

>: Port Numbers can be 1 (default), 2, or 3.

>: Option value 0 (default) disables interlock, 1

A colon (:) indicates the end of a field, and a backslash (\) indicates that the entry is continued on the next line. Spaces are not allowed between the characters on a line. Names, such as host names, must begin with a letter and can contain only letters, numbers, periods (for domain names only), or hyphens. The underline character (_) is not allowed. Refer to your system documentation or online help for more information.

TFTP Configuration File Entries

To provide additional configuration parameters for your HP Jetdirect print server, such as SNMP (Simple Network Management Protocol) or non-default settings, an additional configuration file can be downloaded using TFTP. This TFTP configuration file’s relative path name is specified in the BOOTP reply using the /etc/bootptab file’s T144 vendor-specific tag (or the “ef” standard BOOTP tag) entry. An example of a TFTP configuration file is provided below (the symbol ‘#’ denotes a remark and is not included in the file).

ENWW TCP/IP Configuration 50

# Example of an HP Jetdirect TFTP Configuration File

# Allow only Subnet

# Up to 10 ‘allow’ entries can be written through TFTP.

# Up to 10 ‘allow’ entries can be written through Telnet

# or embedded Web server.

# ‘allow’ may include single IP addresses.

allow:

# Disable Telnet

telnet-config: 0

# Enable the embedded Web server

ews-config: 1

# Detect SNMP unauthorized usage

auth-trap: on

# Send Traps to

trap-dest:

# Specify the Set Community Name

set-cmnty-name: 1homer2

# End of file

192.168.10.0 255.255.255.0

192.168.10.1

192.168.10 access to peripheral.

192.168.10.1

ENWW TCP/IP Configuration 51

Table 3.2 lists the supported TFTP parameters (HP Jetdirect

firmware version x.25.00 or later).

Table 3.3

describes the TFTP parameters.

Table 3.2 List of Supported TFTP Parameters (1 of 2)

General

● passwd:

● sys-location:

● sys-contact:

TCP/IP Main

● host-name:

● domain-name:

● dns-svr:

TCP/IP Print Options

● 9100-printing:

● ftp-printing:

● ipp-printing:

● lpd-printing:

● banner:

TCP/IP Raw Print Ports

● raw-port:

TCP/IP Access Control

● allow: netnum [mask]

TCP/IP Other Settings

● syslog-config:

● syslog-svr:

● syslog-max:

● syslog-priority:

● syslog-facility:

● slp-config:

● ttl-slp:

● mdns-config:

● mdns-service-name:

● mdns-pri-svc:

● ssl-state:

● tftp-parameter-attribute:

● pri-wins-svr:

● sec-wins-svr:

● smtp-svr:

● interlock:

● buffer-packing:

● write-mode:

● mult-tcp-conn:

● ipv4-multicast:

● idle-timeout:

● user-timeout:

● ews-config:

● tcp-mss:

● tcp-msl:

● telnet-config:

● default-ip:

● default-ip-dhcp:

● web-refresh:

ENWW TCP/IP Configuration 52

Table 3.2 List of Supported TFTP Parameters (2 of 2)

SNMP

● snmp-config:

● get-cmnty-name:

● set-cmnty-name:

IPX/SPX

● ipx-config:

● ipx-unit-name:

● ipx-frametype:

● ipx-sapinterval:

● ipx-nds-tree:

AppleTalk

● appletalk:

● name-override:

DLC/LLC

● dlc/llc:

Other Settings

● link-type:

● webscan-config:

● scan-idle-timeout:

● scan-email-config:

Support

● support-name:

● support-number:

● auth-trap:

● trap-dest:

● ipx-nds-context:

● ipx-job-poll:

● ipx-banner:

● ipx-eoj:

● ipx-toner-low:

● MFP-config:

● usb-mode:

● status-page-lang:

● support-url:

● tech-support-url:

ENWW TCP/IP Configuration 53

Table 3.3 TFTP Configuration File Parameters (1 of 10)

General

passwd:

A password (up to 16 alphanumeric characters) that allows administrators to control changes of HP Jetdirect print server configuration parameters through Telnet, HP Web Jetadmin, or embedded Web server. The password may be cleared by a cold reset.

sys-location:

Identifies the physical location of the printer (SNMP sysLocation object). Only printable ASCII characters are allowed. The maximum length is 64 characters. The default location is undefined. (Example: 1st floor, south wall)

sys-contact:

ASCII character string (up to 64 characters) that identifies the person who administers or services the printer (SNMP sysContact object). This may include how to contact this person. The default contact is undefined.

ssl-state:

Sets the print server’s security level for Web communications: 1 (default): Forced redirection to the HTTPS port. Only HTTPS (secure HTTP)

communications can be used. 2: Disable forced redirection to HTTPS. Both HTTP and HTTPS communications

can be used.

tftp-parameter-attribute:

Specifies whether TFTP parameters can be manually overwritten on the print server (for example, through Telnet) after it has been configured by TFTP.

tftp-ro (default): Do not allow TFTP parameters to be manually changed, and always overwrite manual configurations.

tftp-rw: Allow TFTP parameters to be manually changed, and always overwrite manual configurations.

manual-ro: Do not allow TFTP parameters to overwrite manually configured parameters.

TCP/IP Main

host-name:

Specifies the node name that will appear on the Jetdirect configuration page. Default is NPIxxxxxx, where xxxxxx is the last six digits of the LAN hardware address.

domain-name:

The domain name for the device (for example, support.hp.com). It does not include the host name; it is not the Fully Qualified Domain Name (such as printer1.support.hp.com).

dns-svr:

The IP address of the DNS (Domain Name System) server.

ENWW TCP/IP Configuration 54

Table 3.3 TFTP Configuration File Parameters (2 of 10)

pri-wins-svr:

The IP address of the primary Windows Internet Name Service (WINS) server.

sec-wins-svr:

The IP address of the secondary Windows Internet Name Service (WINS) server.

smtp-svr:

The IP address of the outgoing e-mail Simple Mail Transport Protocol (SMTP) server, for use with supported Scan devices.

TCP/IP Print Options

9100-printing:

Enables or disables printing to TCP port 9100 on the print server. 0 disables, 1 (default) enables.

ftp-printing:

Enables or disables the ability to print through FTP: 0 disables, 1 (default) enables.

ipp-printing:

Enables or disables the ability to print through IPP: 0 disables, 1 (default) enables.

lpd-printing:

Enables or disables LPD (Line Printer Daemon) printing services on the Jetdirect print server. 0 disables, 1 (default) enables.

banner:

A port-specific parameter that specifies printing an LPD banner page. 0 disables banner pages. 1 (default) enables banner pages.

interlock:

Specifies whether an acknowledgement (ACK) on all TCP packets is required before the printer is allowed to close a Port 9100 print connection. To accommodate multiport print servers, a Port Number and Option value are specified. Port Numbers can be 1 (default), 2, or 3. Option value 0 (default) disables interlock, 1 enables. For example,

“interlock 2 1” specifies Port 2, interlock enabled.

buffer-packing:

Enables or disables buffer packing for TCP/IP packets. 0 (default): is normal, the data buffer is packed before sending to the printer. 1: disables buffer packing, data is sent to the printer as it is received.

ENWW TCP/IP Configuration 55

Table 3.3 TFTP Configuration File Parameters (3 of 10)

write-mode:

Controls the setting of the TCP PSH flag for device-to-client data transfers. 0 (default): disables this option, flag is not set. 1: all-push option. The push bit is set in all data packets. 2: eoi-push option. The push bit is set only for data packets that have an

End-of-Information flag set.

mult-tcp-conn:

Enables or disables multiple TCP connections. 0 (default): allows multiple connections. 1: disables multiple connections.

TCP/IP Raw Print Ports

raw-port:

Specifies additional ports for printing to TCP port 9100. Valid ports are 3000 to 9000, which are application-dependent.

TCP/IP Access Control

allow: netnum [mask]

Makes an entry into the host access list stored on the HP Jetdirect print server. Each entry specifies a host or network of hosts that are allowed to connect to the printer. The format is “allow: netnum [mask]” where netnum is a network number or host IP address, and mask is an address mask of bits applied to the network number and host address to verify access. Up to 10 access list entries are allowed. If there are no entries, all hosts are permitted access. For example,

allow: 192.0.0.0 255.0.0.0 allows hosts on network 192. allow: 192.168.1.2 allows a single host. In this case, the default mask

255.255.255.255 is assumed and is not required. allow: 0 This entry clears the host access list.

For additional information, see Chapter 7

TCP/IP Other Settings

syslog-config:

Enables or disables syslog server operation on the print server: 0 disables, 1 (default) enables.

syslog-svr:

The syslog server’s IP address. It specifies the server that the HP Jetdirect print server sends syslog messages to. For more information, see Appendix A

syslog-max:

Specifies the maximum number of syslog messages that can be sent by the HP Jetdirect print server on a per-minute basis. This setting allows administrators to control the log file size. The default is 10 per minute. If it’s set to zero, the number of syslog messages is not restricted.

ENWW TCP/IP Configuration 56

Table 3.3 TFTP Configuration File Parameters (4 of 10)

syslog-priority:

Controls the filtering of syslog messages sent to the syslog server. The filter range is 0 to 8, with 0 being the most specific and 8 the most general. Only messages that are lower than the filter level specified (or higher in priority) are reported. The default is 8, messages of all priorities are sent. If 0, all syslog messages are disabled.

syslog-facility:

A code used to identify the source facility of a message (for example, to identify the source of selected messages during troubleshooting). By default, the HP Jetdirect print server uses LPR as the source facility code, but local user values of local0 through local7 can be used to isolate individual or groups of print servers.

slp-config:

Enables or disables the Service Location Protocol (SLP) operation on the print server: 0 disables, 1 (default) enables.

ttl-slp:

Specifies the IP multicast “Time To Live” (TTL) setting for Service Location Protocol (SLP) packets. The default value is 4 hops (the number of routers from the local network). The range is 1-15. When set to a -1, multicast capability is disabled.

mdns-config:

Enables or disables Multicast Domain Name System (mDNS) services. 0 disables, 1 (default) enables. mDNS is typically used on small networks for IP address and name resolution (through UDP port 5353) where a conventional DNS server is neither used or available.

mdns-service-name:

Specifies an alphanumeric string of up to 64 ASCII characters assigned to this device or service. This name is persistent and is used to resolve a particular device or service if socket information (such as the IP address) changes from session to session. Apple Rendezvous will display this service. The default service name is the printer model and the LAN Hardware (MAC) address.

mdns-pri-svc:

Specifies the mDNS highest priority service to use for printing.To set this parameter, choose one of the following printing option numbers:

1: Port 9100 printing 2: IPP port printing 3: The default LPD raw queue 4: The default LPD text queue 5: The default LPD auto queue 6: The default LPD binps (binary postscript) queue 7 through 12: If user-specified LPD queues are defined, corresponds to

user-specified LPD queues 5 through 10. The default selection will depend on the printer, typically port 9100 printing or LPD

binps.

ENWW TCP/IP Configuration 57

Table 3.3 TFTP Configuration File Parameters (5 of 10)

ipv4-multicast:

Enables or disables the receipt and transmission of IP version 4 multicast packets by the print server. 0 disables, 1 (default) enables.

idle-timeout:

The number of seconds that an idle print data connection is allowed to remain open. Since the card supports only a single TCP connection, the idle timeout balances the opportunity of a host to recover or complete a print job against the ability of other hosts to access the printer. The acceptable values range from 0 to 3600 (1 hour). If “0” is typed, the timeout mechanism is disabled. The default is 270 seconds.

user-timeout:

An integer (1..3600) that specifies the number of seconds that your Telnet or FTP session can be idle before it will be automatically disconnected. The default is 900 seconds. 0 disables the timeout.

CAUTION: Small values, such as 1-5, may effectively disable the use of Telnet. A Telnet session may terminate before any changes can be made.

ews-config:

Enables or disables the print server’s embedded Web server to change configuration values: 0 disables, 1 (default) enables.

tcp-mss:

Specifies the maximum segment size (MSS) that the HP Jetdirect print server will advertise for use when communicating with local subnets (Ethernet MSS=1460 bytes or more) or remote subnets (MSS=536 bytes):

0 (default): All networks are assumed to be local (Ethernet MSS=1460 bytes or more).

1: Use MSS=1460 bytes (or more) for subnets, and MSS=536 bytes for remote networks.

2: All networks are assumed to be remote (MSS=536 bytes), except the local subnet.

MSS affects performance by helping to prevent IP fragmentation that may result in data retransmission.

tcp-msl:

Specifies the maximum segment life (MSL) in seconds. The range is 5 - 120 seconds. The default is 15 seconds.

telnet-config:

If set to 0, this parameter instructs the print server not to allow incoming Telnet connections. To regain access, change the setting in the TFTP configuration file and power cycle the print server, or cold reset the print server to factory default values. If this parameter is set to 1, incoming Telnet connections are allowed.

ENWW TCP/IP Configuration 58

Table 3.3 TFTP Configuration File Parameters (6 of 10)

default-ip:

Specifies the IP address to use when the print server is unable to obtain an IP address from the network during a forced TCP/IP reconfiguration (for example, when powered off/on or manually configured to use BOOTP/DHCP).

DEFAULT_IP: sets the legacy default IP address 192.0.0.192. AUTO_IP: sets a link-local IP address 169.254.x.x. The initial setting is determined by the IP address obtained when first powered on.

default-ip-dhcp:

Specifies whether DHCP requests will be periodically transmitted when a legacy default IP address 192.0.0.192 or link-local IP address 169.254.x.x has been automatically assigned.

0: Disables DHCP requests. 1 (default): Enables DHCP requests.

web-refresh:

Specifies the time interval (1 -99999 seconds) for embedded Web server diagnostic page updates. If set to 0, the refresh rate is disabled.

SNMP

snmp-config:

Enables or disables SNMP operation on the print server. 0 disables, 1 (default) enables SNMP.

CAUTION: Disabling SNMP will disable all SNMP agents (SNMP v1, v2, v3) as well as communications with HP Web Jetadmin. In addition, firmware upgrades through current HP downloading utilities will be disabled.

get-cmnty-name:

Specifies a password that determines which SNMP GetRequests the HP Jetdirect print server will respond to. This is optional. If a user-specified get community name is set, the print server will respond to either a user-specified community name or the factory-default. The community name must be ASCII characters. The maximum length is 255 characters.

set-cmnty-name:

Specifies a password that determines which SNMP SetRequests (control functions) the HP Jetdirect print server will respond to. The community name of an incoming SNMP SetRequest must match the print server’s “set community name” for the print server to respond. (For additional security, you may limit configuration access through the print server’s host access list). Community names must be ASCII characters. The maximum length is 255 characters.

auth-trap:

Configures the print server to send (on) or not send (off) SNMP authentication traps. Authentication traps indicate that an SNMP request was received, but the community name check failed. The default is “on.”

ENWW TCP/IP Configuration 59

Table 3.3 TFTP Configuration File Parameters (7 of 10)

trap-dest:

Enters a host’s IP address into the HP Jetdirect print server’s SNMP trap destination list. The command format is:

trap-dest:

ip-address

The default community name is ”public”; the default SNMP port number is ”162”. The port number cannot be specified without a community name.

If a ”trap-community-name” command is followed by ”trap-dest” commands, the trap community name will be assigned to those entries unless a different community name is specified in each ”trap-dest” command.

To delete the table, use ”trap-dest: 0”. If the list is empty, the print server does not send SNMP traps. The list may contain

up to three entries. The default SNMP Trap Destination List is empty. To receive SNMP traps, the systems listed on the SNMP trap destination list must have a trap daemon to listen to those traps.

IPX/SPX

ipx-config:

Enables or disables IPX/SPX protocol operation on the print server: 0 disables, 1 (default) enables.

ipx-unit-name:

A user-assigned alphanumeric name assigned to the print server (31 characters maximum). By default, the name will be NPIxxxxxx, where xxxxxx are the last six digits of the LAN hardware address.

ipx-frametype:

Specify the IPX frame type setting available for your print server model: AUTO (default), EN_SNAP, EN_8022, EN_8023, EN_II, TR_8022, TR_SNAP.

ipx-sapinterval:

Specifies the time interval (1 to 3600 seconds) that the HP Jetdirect print server waits between Service Advertising Protocol (SAP) broadcasts on the network. The default is 60 seconds. 0 disables SAP broadcasts.

ipx-nds-tree:

Identifies the name of the Novell Directory Services (NDS) tree for this printer.

ipx-nds-context:

An alphanumeric string, up to 256 characters, that specifies the NDS context for the HP Jetdirect print server.

ipx-job-poll:

Specifies the time interval (seconds) that the HP Jetdirect print server will wait to check for print jobs in a print queue.

[community name] [port number]

ENWW TCP/IP Configuration 60

Table 3.3 TFTP Configuration File Parameters (8 of 10)

ipx-banner:

Enables or disables printing an IPX banner page. 0 disables banner pages. 1 (default) enables banner pages.

ipx-eoj:

Enables or disables IPX end-of-job notification. 0 disables, 1 (default) enables.

ipx-toner-low:

Enables or disables IPX toner-low notification. 0 disables, 1 (default) enables.

AppleTalk

appletalk:

Enables or disables AppleTalk (EtherTalk) protocol operation on the print server: 0 disables, 1 (default) enables.

name-override:

(External print servers only) Specifies the name of the AppleTalk network. Up to 32 characters may be used.

DLC/LLC

dlc/llc:

Enables or disables DLC/LLC protocol operation on the print server: 0 disables, 1 (default) enables.

Other Settings

link-type:

(10/100 Fast Ethernet) Sets the print server’s link speed (10 or 100 Mbps) and communication mode (Full- or Half-Duplex). Selections are AUTO, 100FULL, 100HALF, 10FULL, 10HALF.

For AUTO (default), the print server uses autonegotiation to determine the link speed and mode. If autonegotiation fails, then 100HALF is set.

webscan-config:

Enables or disables the Web Scan feature on the print server when connected to a supported device. 0 disables, 1 (default) enables.

scan-idle-timeout:

Specifies the number of seconds (1 - 3600) that an idle scan connection is allowed to remain open. 0 disables the timeout. The default is 300 seconds.

scan-email-config:

Enable or disable the scan-to-email feature in the Web Scan server. 0 disables, 1 (default) enables.

ENWW TCP/IP Configuration 61

Table 3.3 TFTP Configuration File Parameters (9 of 10)

MFP-config:

Enable or disable print server support of the client software provided with your multifunction or all-in-one peripheral.

0 (default): disables client software support (allows printing only). 1: enables client software support (allows printing and scanning).

usb-mode:

Specifies the communication mode over the USB port on the HP Jetdirect print server.

● Auto (default): Automatically negotiates and sets the the highest

communication mode possible for the attached printer or device.

● MLC: (Multiple Logical Channels) An HP-proprietary communication mode that

allows multiple channels of simultaneous print, scan and status communications.

● BIDIR: A standard connection that supports bi-directional communications

between the printer and print server. The print server sends print data and receives status from the printer.

● UNIDIR: A standard connection in which data is transferred in one direction

only (to the printer).

status-page-lang:

Specifies the page description language (PDL) that the print server will use to send the Jetdirect configuration/status page to the printer.

● Auto (default): The PDL is auto-detected when the print server is powered on

or after a cold-reset.

● PCL: Hewlett-Packard Printer Control Language

● ASCII: Standard ascii characters

● HPGL2: Hewlett-Packard Graphics Language (v2)

● PS: Postscript language

ENWW TCP/IP Configuration 62

Table 3.3 TFTP Configuration File Parameters (10 of 10)

Support

support-name:

Typically used to identify the name of a person to contact for support of this device.

support-number:

Typically used to specify a phone number or extension to call for support of this device.

support-url:

A Web URL for product information on this device over the Internet or an intranet.

tech-support-url:

A Web URL for technical support over the Internet or an intranet.

ENWW TCP/IP Configuration 63

Using DHCP

Note For HP Jetdirect wireless print servers, this section

assumes that a wireless connection to your network has been established.

Dynamic Host Configuration Protocol (DHCP, RFC 2131/2132) is one of several auto configuration mechanisms that the HP Jetdirect print server uses. If you have a DHCP server on your network, the HP Jetdirect print server automatically obtains its IP address from that server and registers its name with any RFC 1001 and 1002-compliant dynamic name services as long as a WINS (Windows Internet Naming Service) server IP address has been specified.

A TFTP (Trivial File Transfer Protocol) configuration file may also be used with DHCP to configure extended parameters. For more information on TFTP parameters, see “Using BOOTP/TFTP

Note DHCP services must be available on the server.

Refer to your system documentation or online help to install or enable DHCP services.

”.

Note If the Jetdirect print server and BOOTP/DHCP

server are located on different subnets, IP configuration may fail unless the routing device allows the transfer of DHCP requests between subnets.

ENWW TCP/IP Configuration 64

UNIX Systems

For more information on setting up DHCP on UNIX systems, see the bootpd man page.

On HP-UX systems, a sample DHCP configuration file (dhcptab) may be located in the /etc directory.

Since HP-UX presently does not provide Dynamic Domain Name Services (DDNS) for its DHCP implementations, HP recommends that you set all print server lease durations to “infinite”. This ensures that print server IP addresses remain static until dynamic domain name services are provided.

Windows Systems

HP Jetdirect print servers support IP configuration from a Windows NT or 2000 DHCP server. This section describes how to set up a pool, or “scope,” of IP addresses that the Windows server can assign or lease to any requester. When configured for BOOTP or DHCP operation and powered on, the HP Jetdirect print server automatically sends a BOOTP or DHCP request for its IP configuration. If properly set up, a Windows DHCP server will respond with the print server’s IP configuration data.

Note This information is provided as an overview. For

specific information or for additional support, see the information supplied with your DHCP server software.

Note To avoid problems resulting from IP addresses

that change, HP recommends that all printers be assigned IP addresses with infinite leases or reserved IP addresses.

ENWW TCP/IP Configuration 65

Windows NT 4.0 Server

To set up a DHCP scope on a Windows NT 4.0 server, perform the following steps:

1. At the Windows NT server, open the Program Manager window and double-click the Network Administrator icon.

2. Double-click the DHCP Manager icon to open this window.

3. Select Server and select Server Add.

4. Type the server IP address, then click OK to return to the DHCP Manager window.

5. In the list of DHCP servers, click on the server you have just added, then select Scope and select Create.

6. Select Set up the IP Address Pool. In the IP Address Pool section, set up the IP address range by typing the beginning IP address in the Start Address box and the ending IP address in the End Address box. Also type the subnet mask for the subnet to which the IP address pool applies.

The starting and ending IP addresses define the end points of the address pool assigned to this scope.

Note If desired, you can exclude ranges of IP addresses

within a scope.

7. In the Lease Duration section, select Unlimited, then select OK.

HP recommends that all printers be assigned infinite leases to avoid problems resulting from IP addresses that change. Be aware, however, that selecting an unlimited lease duration for the scope causes all clients in that scope to have infinite leases.

If you want clients on your network to have finite leases, you can set the duration to a finite time, but you should configure all printers as reserved clients for the scope.

ENWW TCP/IP Configuration 66

8. Skip this step if you have assigned unlimited leases in the previous step. Otherwise, select Scope and select Add Reservations to set up your printers as reserved clients. For each printer, perform the following steps in the Add Reserved Clients window to set up a reservation for that printer:

a. Type the selected IP address.

b. Obtain the MAC address or hardware address from the

configuration page, and type this address in the Unique Identifier box.

c. Type the client name (any name is acceptable).

d. Select Add to add the reserved client. To delete a

reservation, in the DHCP Manager window, select Scope and select Active Leases. In the Active Leases window, click on the reservation you want to delete and select Delete.

9. Select Close to return to the DHCP Manager window.

10. Skip this step if you are not planning to use WINS (Windows Internet Naming Service). Otherwise perform the following steps when configuring your DHCP server:

a. From the DHCP Manager window, select DHCP Options

and select one of the following:

Scope — if you want Name Services only for the selected scope.

Global — if you want Name Services for all scopes.

b. Add the server to the Active Options list. From the DHCP

Options window, select WINS/NBNS Servers (044) from the Unused Options list. Select Add, then select OK.

A warning may appear requesting that you set the node type. You do this in step 10d.

c. You must now provide the IP address of the WINS server

by doing the following:

● Select Value, then Edit Array.

● From the IP Address Array Editor, select Remove to

delete any undesired addresses previously set. Then type in the IP address of the WINS server and select Add.

ENWW TCP/IP Configuration 67

● Once the address appears in the list of IP addresses,

select OK. This returns you to the DHCP Options window. If the address you have just added appears in the list of IP addresses (near the bottom of the window) return to step 10d. Otherwise, repeat step 10c.

d. In the DHCP Options window, select WINS/NBT Node

Type (046) from the Unused Options list. Select Add to add the node type to the Active Options list. In the Byte box, type 0x4 to indicate a mixed node, and select OK.

11. Click Close to exit to Program Manager.

Windows 2000 Server

To set up a DHCP scope on a Windows 2000 server, perform the following steps:

1. Run the Windows 2000 DHCP manager utility. Click Start, then select Settings and Control Panel. Open the Administrative Tools folder and run the DHCP utility.

2. In the DHCP window, locate and select your Windows 2000 server in the DHCP tree.

If your server is not listed in the tree, select DHCP and click the Action menu to add the server.

3. After selecting your server in the DHCP tree, click the Action menu and select New Scope. This runs the Add New Scope Wizard.

4. In the Add New Scope Wizard, click Next.

5. Enter a Name and Description for this scope, then click Next.

6. Enter the range of IP addresses for this scope (beginning IP address and ending IP address). Also, enter the subnet mask. then click Next.

Note If subnetting is used, the subnet mask defines

which portion of an IP address specifies the subnet and which portion specifies the client device. For more information, see Appendix A

7. If applicable, enter the range of IP addresses within the scope to be excluded by the server. Then click Next.

ENWW TCP/IP Configuration 68

8. Set the IP address lease duration for your DHCP clients. Then click Next.

HP recommends that all printers be assigned reserved IP addresses. This can be accomplished after you set up the scope (see step 11

9. Select No to configure DHCP options for this scope later. Then click Next.

To configure DHCP options now, select Yes and click Next.

a. If desired, specify the IP address of the router (or default

gateway) to be used by clients. Then click Next.

b. If desired, specify the Domain Name and DNS (Domain

Name System) servers for clients. Click Next.

c. If desired, specify WINS server names and IP addresses.

Click Next.

d. Select Yes to activate the DHCP options now, and click

Next.

10. You have successfully set up the DHCP scope on this server. Click Finish to close the wizard.

11. Configure your printer with a reserved IP address within the DHCP scope:

a. In the DHCP tree, open the folder for your scope and select

Reservations.

b. Click the Action menu and select New Reservation.

c. Enter the appropriate information in each field, including

the reserved IP address for your printer. (Note: the MAC address for your HP Jetdirect-connected printer is available on the HP Jetdirect configuration page.)

d. Under “Supported types”, select DHCP only, then click

Add. (Note: Selecting Both or BOOTP only will result in a configuration through BOOTP due to the sequence in which HP Jetdirect print servers initiate configuration protocol requests.)

e. Specify another reserved client, or click Close. The

reserved clients added will be displayed in the Reservations folder for this scope.

12. Close the DHCP manager utility.

ENWW TCP/IP Configuration 69

NetWare Systems

NetWare 5.x servers provide DHCP configuration services for network clients, including the HP Jetdirect print server. To set up DHCP services on a NetWare server, refer to Novell documentation and support.

To Discontinue DHCP Configuration

CAUTION Changes to an IP address on your HP Jetdirect

print server may require updates to printer or system printing configurations for clients or servers.

If you do not want your HP Jetdirect print server configured through DHCP, you must reconfigure the print server with a different configuration method.

1. (For internal print servers) If you use the printer control panel to set Manual or BOOTP configuration, then DHCP will not be used.

2. You can use Telnet to set Manual (status indicates “User Specified”) or BOOTP configuration, then DHCP will not be used.

3. You can manually modify the TCP/IP parameters through a supported Web browser using the Jetdirect embedded Web server or HP Web Jetadmin.

If you change to BOOTP configuration, the DHCP-configured parameters are released and the TCP/IP protocol is initialized.

If you change to Manual configuration, the DHCP-configured IP address is released and the user-specified IP parameters are used.

Therefore, if you manually provide the IP address, you should also manually set all of the configuration parameters, such as subnet mask, default gateway, and idle timeout.

ENWW TCP/IP Configuration 70

Note If you choose to re-enable a DHCP configuration,

the print server will acquire its configuration information from a DHCP server. This means that when you choose DHCP and complete your configuration session (using Telnet, for example), the TCP/IP protocol for the print server is re-initialized and all current configuration information is deleted. The print server then attempts to acquire new configuration information by sending DHCP requests on the network to a DHCP server.

For DHCP configuration through Telnet, refer to “Using Telnet” in this chapter.

ENWW TCP/IP Configuration 71

Using RARP

Note For HP Jetdirect wireless print servers, this section

assumes that a wireless connection to your network has been established.

This section describes how to configure the print server using the Reverse Address Resolution Protocol (RARP) on UNIX and Linux systems.

This setup procedure enables the RARP daemon running on your system to respond to a RARP request from the HP Jetdirect print server and to supply the IP address to the print server.

1. Turn the printer off.

2. Log onto your UNIX or Linux system as a superuser.

3. Make sure the RARP daemon is running on your system by typing the following command at the system prompt:

ps -ef | grep rarpd (Unix)

ps ax | grep rarpd (BSD or Linux)

4. The system response should be similar to the following:

861 0.00.2 24 72 5 14:03 0:00 rarpd -a

860 0.00.5 36 140 5 14:03 0:00 rarpd -a

5. If the system does not display a process number for the RARP daemon, see the rarpd man page for instructions on starting the RARP daemon.

6. Edit the /etc/hosts file to add your designated IP address and node name for the HP Jetdirect print server. For example:

192.168.45.39 laserjet1

ENWW TCP/IP Configuration 72

7. Edit the /etc/ethers file (/etc/rarpd.conf file in

HP-UX 10.20) to add the LAN hardware address/station address (from the configuration page) and the node name for the HP Jetdirect print server. For example:

00:01:E6:a8:b0:00 laserjet1

Note If your system uses Network Information Service

(NIS), you need to incorporate changes to the NIS host and ethers databases.

8. Turn the printer on.

9. To verify that the card is configured with the correct IP address, use the ping utility. At the prompt, type:

ping <IP address>

where <IP address> is the assigned address from RARP.

10. If ping does not respond, see Chapter 8

ENWW TCP/IP Configuration 73

Using the arp and ping Commands

Note For HP Jetdirect wireless print servers, this section

assumes that a wireless connection to your network has been established.

You can configure an HP Jetdirect print server with an IP address using an ARP (Address Resolution Protocol) command from a supported system. The protocol is not routable, that is, the workstation from which the configuration is made must be located on the same network segment as the HP Jetdirect print server.

Using the arp and ping commands with HP Jetdirect print servers requires the following:

● Windows NT/2000/XP or UNIX system configured for TCP/IP

operation

● HP Jetdirect firmware version x.20.00 or later

● A legacy default IP address 192.0.0.192 has been set on the print

server

● The LAN hardware (MAC) address of the HP Jetdirect print

server (specified on an HP Jetdirect configuration page, or on a label attached to HP Jetdirect external print servers)

Note On some systems, superuser rights may be required

for the arp command.

After an IP address is assigned through arp and ping commands, use other tools (such as Telnet, embedded Web server, or HP Web Jetadmin software) to configure other IP parameters.

To configure a Jetdirect print server, use the following commands:

arp -s <IP address> <LAN hardware address>

ping <IP address>

where <IP address> is the desired IP address to be assigned to the print server. The arp command writes the entries to the arp cache on the workstation, and the ping command configures the IP address on the print server.

ENWW TCP/IP Configuration 74

Depending on the system, the LAN hardware address may require a specific format.

For example:

● For Windows NT 4.0, 2000, XP

arp -s 192.168.45.39 00-01-E6-a2-31-98

ping 192.168.45.39

● For UNIX

arp -s 192.168.45.39 00:01:E6:a2:31:98

ping 192.168.45.39

Note Once the IP address has been set on the print server,

additional arp and ping commands will be ignored. Once the IP address is configured, arp and ping cannot be used unless the print server is reset to factory values (see Chapter 8

On UNIX systems, the arp -s command may vary between different systems.

Some BSD-based systems expect the IP address (or host name) in reverse order. Other systems may require additional parameters. See your system documentation for specific command formats.

ENWW TCP/IP Configuration 75

Using Telnet

Note For HP Jetdirect wireless print servers, this section

assumes that a wireless connection to your network has been established.

This section describes how to configure the print server (firmware version x.25.01 or greater) using Telnet.

Although a Telnet connection may be protected by an administrator password, Telnet connections are not secure. For networks with high security levels, Telnet connections can be disabled on the print server using other tools (for example, TFTP, embedded Web server, or HP Web Jetadmin software).

Creating a Telnet Connection

To use Telnet commands with the HP Jetdirect print server, a route must be available from your workstation to the print server. If the print server and your computer must have a similar IP address, that is, the network portion of their IP addresses match, chances are that a route will exist. For information on IP address structure, see Appendix A

If their IP addresses do not match, then you can either change your workstation’s IP address to match, or you can try an operating system command to create a route to the print server. (For example, if the print server is configured with a legacy default IP address

192.0.0.192, a route will not likely exist.)

On Windows systems, you can use aroute command at a Windows command (DOS) prompt to create a route to the print server.

For information on system command prompts, see your Windows online help. On Windows NT systems, the command prompt utility is in the Programs folder (click Start, Programs, Command Prompt). On Windows 2000/XP systems, it is in the Accessories folder in the Programs folder.

ENWW TCP/IP Configuration 76

To use the route command, you will also need the IP address of your workstation. To view it, you can enter the appropriate command at the command prompt:

C:\> ipconfig (on Windows NT/2000/XP)

C:\> winipconfig (on Windows 98)

To create a route from the system command prompt, enter the following command:

route add <Jetdirect IP Address> <system IP Address>

where <Jetdirect IP address> is the IP address configured on the HP Jetdirect print server, and <system IP address> is the IP address of the workstation's network card that is attached to the same physical LAN as the print server.

For example, to create a route from your workstation with IP address 169.254.2.1 to a print server with a default IP address of

192.0.0.192, try this command:

route add 192.0.0.192 169.254.2.1

CAUTION Using Telnet to manually set an IP address will

override dynamic IP configuration (such as BOOTP, DHCP, or RARP), resulting in a static configuration. In a static configuration, the IP values are fixed and the operation of BOOTP, DHCP, RARP and other dynamic configuration methods may no longer function.

Whenever you are manually changing an IP address, you should also reconfigure the subnet mask and default gateway at the same time.

ENWW TCP/IP Configuration 77

A Typical Telnet Session

Initiating a typical Telnet session is illustrated below.

ENWW TCP/IP Configuration 78

To set configuration parameters, you must set up a Telnet session from your system to the HP Jetdirect print server.

1. Type the following at the system prompt:

telnet <IP address>

where <IP address> is the IP address listed on the Jetdirect configuration page. See Chapter 9

2. A connection to the HP Jetdirect print server will be displayed. If the server responds with “connected to IP address”, press Enter twice to make sure that the Telnet connection is initialized.

3. If prompted for a user name and password, enter the correct values.

By default, the Telnet interface does not require a user name or password. If an administrator password has been set, you will be prompted for a user name and this password before you can enter and save Telnet command settings.

4. By default, a Command Line interface is provided. To configure parameters using a Menu interface, enter Menu. For more information, see “User Interface Options

”.

For a list of supported commands and parameters, see “Telnet

Commands and Parameters”.

User Interface Options

The HP Jetdirect print server provides two interface options to enter Telnet commands: a Command Line Interface (Default) a Menu Interface

ENWW TCP/IP Configuration 79

and

Command Line Interface (Default)

Using the Telnet command line interface, you can set configuration parameters using the following procedures:

Note During a Telnet session, enter ? to view available

configuration parameters, the correct command format, and a list of commands.

To list additional (or advanced) commands, enter the command advanced befored entering ?..

To display current configuration information, enter /.

1. At the Telnet prompt “>” type:

then press Enter, where <parameter> refers to the configuration parameter you are defining, and <value> refers to the definitions you are assigning to that parameter. Each parameter entry is followed by a carriage return.

See Table 3.4

for configuration parameters (firmware version

x.25.00 or later).

2. Repeat the previous step to set any additional configuration parameters.

3. When you have finished typing the configuration parameters, type exit or quit (depending on your system).

When prompted whether to save settings that you have changed, enter Y (default) for Yes, or N for No.

If you enter save instead of exit or quit, you will not be prompted to save settings.

ENWW TCP/IP Configuration 80

Telnet Commands and Parameters. Table 3.4 lists the

available Telnet commands and parameters.

Note If a parameter is supplied dynamically (for example,

from a BOOTP or DHCP server), its value cannot be changed using Telnet without first setting Manual configuration. To set Manual configuration, see the ip-config command.

Whenever you are manually changing an IP address, you should also reconfigure the subnet mask and default gateway at the same time.

Table 3.4 Telnet Commands and Parameters (1 of 18)

User Control Commands

Command Description

? Displays the Help and Telnet commands.

/ Displays current values.

menu Displays the Menu Interface

parameters.

advanced Enables the Advanced commands. Help (?) will include the

Advanced commands in the list.

general Disables the Advanced commands. Help (?) will not include

Advanced commands (default).

save Save the configuration values and exit the session.

exit Exit the session.

export Export the settings to a file for editing, and importing through

Telnet or TFTP (this command is only supported by systems, such as UNIX, that support input/output redirection).

General Settings

Command Description

passwd Set the administrator password (shared with the embedded

Web server and HP Web Jetadmin). For example,

“passwd jd1234 jd1234” sets the password to jd1234.

Note that “jd1234” is entered twice for confirmation. Up to 16 alphanumeric characters may be used. When

initiating the next Telnet session, you will be prompted for a user name and this password.

To clear the password, enter the command without password and confirmation entries.

Passwords may be cleared by a cold reset.

for access to configuration

ENWW TCP/IP Configuration 81

Table 3.4 Telnet Commands and Parameters (2 of 18)

sys-location Alpha-numeric string (up to 255 characters), typically used

to identify a location.

sys-contact Alpha-numeric string (up to 255 characters), typically used

to identify the name of a network or device administrator.

ssl-state Sets the print server’s security level for Web

communications: 1 (default): Forced redirection to the HTTPS port. Only

HTTPS (secure HTTP) communications can be used. 2: Disable forced redirection to HTTPS. Both HTTP and

HTTPS communications can be used.

security-reset Reset security settings on the print server to factory default

Wireless 802.11Main Settings

Command Description

network-type Specify the 802.11 wireless network topology:

desired-ssid Specify the desired Service Set Id entifier (SSID), or Network

encryption Specify the use of encryption. 0 (default) disables, 1

wep-key-method Specify the format for WEP key entry. WEP key entries must

values. 0 (default) does not reset, 1 resets the security settings.

Infrastructure: The print server will communicate on the network with other wired or wireless devices through an Access Point.

Ad Hoc: (default) The print server will communicate with other wireless devices directly, without using an Access Point.

Name, for the print server. Up to 32 alphanumeric characters may be used.

The factory-default SSID is hpsetup in Ad Hoc mode. An Infrastructure network SSID of hpsetup should not be used.

If the ssid command is issued without an entry (a blank SSID), the desired SSID will be assigned <AUTO>, where it will associate with the first network that matches its authentication settings.

enables.

be of the proper length. ASCII: (default) Use alphanumeric ASCII characters (0 - 9,

a - z, A - Z). For 40/64-bit encryption, enter 5 characters. For 104/128-bit encryption, enter 13 characters. ASCII entries are case-sensitive.

HEX: Use hexadecimal digits (0 - 9, a - f, A - F). For 40/64-bit encryption, enter10 hexadecimal digits. For 104/128-bit encryption, enter 26 hexadecimal digits. HEX entries are not case-sensitive.

ENWW TCP/IP Configuration 82

Table 3.4 Telnet Commands and Parameters (3 of 18)

wep-key Specify a static WEP (Wired Equivalent Privacy) encryption

key. The print server can store up to four WEP keys using four key positions (Key 1, 2, 3, 4). To enter a WEP key, specify the key position followed by the encryption key value. For example,

wep-key 1 0123456789net

assigns Key 1 with a 128-bit WEP key specified by the value 0123456789net.

You can use the wep-key-method command to specify the format of the key value (hexadecimal digits, or alphanumeric ASCII characters). Alternatively, you can insert an optional parameter (ASCII or HEX) after the key position. For example,

wep-key 1 ASCII 0123456789net

assigns Key 1 with a 128-bit WEP key specified by the alphanumeric ASCII characters 0123456789net.

When assigning static WEP keys, ensure that key positions and key values match other wireless devices on the network. Ensure that all key values entered are of the same length, and that WEP key lengths use the proper number of characters or digits.

transmit-key Specify the WEP key position (1, 2, 3, 4) that the print server

desired-channel (Ad Hoc) Specify a desired channel that the print server will

auth-type Specify a link-based authentication method for the print

will use for encrypted communications. For example,

transmit-key 2

specifies that Key 2 will be used for encrypted communications.

use for Ad Hoc network association requests.

10: (default) Use channel 10 (2457 MHz). 11: Use Channel 11 (2462 MHz).

The print server will use this channel to broadcast its availability if it fails to detect and associate with the specified Ad Hoc network on any channel.

server before network access is allowed. Open: (default) Use Open System authentication if your

wireless network does not require authentication for network access. However, your network may still use encryption keys for data security.

Shared_Key: Use Shared Key authentication if your network requires that each device be configured with the same secret WEP key for network access.

The use of the Shared_Key option is not valid with the wpa-auth-type command settings (802.1x or PSK).

ENWW TCP/IP Configuration 83

Table 3.4 Telnet Commands and Parameters (4 of 18)

server-auth This command requires that you specify a dynamic

encryption option (dynamic-encrypt command) and EAP

802.1x authentication (wpa-auth-type command). Use this command to specify server-based authentication methods used on your network. For a brief description of supported authentication protocols, see Chapter 1

None: (default) Server-based network authentication is not used.

EAP_MD5: An authentication method that uses 802.1x EAP and MD5 (Message-Digest Algorithm 5, RFC 1321). It requires that a user name and password be configured on the device. Use the svr-auth-user and svr-auth-pass commands to specify a user name and password, respectively.

EAP_TLS: An authentication method that uses 802.1x EAP-TLS (Extensible Authentication Protocol - Transport Layer Security, RFC 2716). It requires a user name and an installed X.509-compliant digital certificate for device validation. In addition, a CA (Certificate Authority) certificate used to validate the authentication server must be installed. Use the svr-auth-user command to specify a user name. To install certificates, use the embedded Web server. See

Chapter 4

LEAP: An authentication method that uses LEAP (Lightweight Extensible Authentication Protocol). LEAP is a Cisco Systems, Inc. proprietary protocol. LEAP requires a user name and password. Use the svr-auth-user and svr-auth-pass commands to specify a user name and password, respectively.

PEAP: An authentication method that uses PEAP (Protected Extensible Authentication Protocol). PEAP requires a user name and password for client validation. In addition, a CA (Certificate Authority) certificate used to validate the authentication server must be installed. Use the svr-auth-user and svr-auth-pass commands to specify a user name and password, respectively. To install certificates, use the embedded Web server. See Chapter 4

EAP_TTLS: An authentication method that uses TTLS (Tunneled Transport Layer Security). EAP-TTLS is an EAP-TLS extension that also uses X.509-compliant digital certificates. TTLS requires a user name and password for client validation. In addition, a CA (Certificate Authority) certificate used to validate the authentication server must be installed. Use the svr-auth-user and svr-auth-pass commands to specify a user name and password, respectively. To install certificates, use the embedded Web server. See Chapter 4

svr-auth-user Specify a user name for server-based authentication. Up to

128 alphanumeric characters may be used.

ENWW TCP/IP Configuration 84

Table 3.4 Telnet Commands and Parameters (5 of 18)

svr-auth-pass Specify a password for server-based authentication. Up to

128 alphanumeric characters may be used.

svr-auth-id Specify the CA certificate character string that will be used

to identify and validate the authentication server. This string will be compared to an identification string received from the authentication server. For string comparison, you can specify whether an exact match is required:

RIGHT_MOST (default): The string entry will be compared to the right-most characters in the CA certificate string.

USE_EXACT: The string entry must exactly match the authentication server’s string.

wpa-auth-type This command is not compatible with the Shared Key

psk-passphrase Specify a pass-phrase that is used to generate a network

dynamic-encrypt Select a supported dynamic encryption option:

authentication option in the auth-type command. Use this command to specify a supported EAP authentication type:

802.1x: Select this option on an EAP network that uses an authentication server. Use the server-auth command to specify the EAP/802.1x protocols used on your network. Use the dynamic-encrypt command to specify a dynamic encryption option.

PSK: Select this option on EAP networks where an authentication server is not used. Instead, a Pre-shared key provides device authentication. A Pre-shared key is generated when you specify a network pass-phrase using the psk-passphrase command. The dynamic-encrypt command should be set to the Robust option.

Pre-shared key. A pass-phrase must be from 8 to 63 ASCII characters in the hexadecimal range 21 through 7E (characters 0-9, a-z, A-Z and numerous special characters including !, @, #, $, %, ^, &, (, ), _, +, =, -, {, }, [, ], \, /, “, <, >, ?, “, ‘, ~).

Basic: Dynamic WEP encryption is supported. Robust: Dynamic Wi-Fi Protected Access (WPA) and WEP

encryption protocols are supported. Use the wpa-auth-type command to select a compatible

EAP authentication type:

● For EAP/PSK authentication, the print server should use

Robust encryption (WPA encryption protocols).

● For EAP/802.1x authentication (LEAP only), the print

server should use Basic encryption.

● For EAP/802.1x aut hentication (PEAP, TLS, T TLS only),

the print server may use either Basic encryption or Robust encryption depending on your network.

Dynamic encryption protocols are under the control of the authentication server and also must be supported by the Access Point.

ENWW TCP/IP Configuration 85

Table 3.4 Telnet Commands and Parameters (6 of 18)

802.11 Wireless Diagnostics

Command Description

Current SSID (Read-only parameter) The network name (SSID) to which

Current Channel (Read-only parameter) The channel that the wireless print

Signal Strength (Read-only parameter) The strength of the radio signal

Access Point Mac (Read-only parameter) The Media Access Control (MAC)

TCP/IP Main Settings

Command Description

host-name Alphanumeric string (up to 32 characters), to assign or

ip-config Specify the configuration method:

ip IP address for the print server, in dotted notation. For

the wireless print server connected.

server is currently using.

received by the print server. <blank>: No radio signal detected while the print server is

scanning.

No Signal: No radio signal detected on any channel. Poor/Marginal/Good/Excellent: Indicates the detected

signal strength level.

address of the Access Point used for Infrastructure mode communications. For example,

00:a0:f8:38:7a:f7

specifies that the Access Point with MAC address 00a0f8387af7 was used for communicating on the network.

change the name of the network device. For example,

“host-name printer1” assigns the name “printer1” to the

device.

manual: The print server will wait for IP parameters using manual tools (such as Telnet, embedded Web server, control panel, installation/management software). Status will be User Specified.

bootp: The print server will send BOOTP requests on the network for dynamic IP configuration.

dhcp: The print server will send DHCP requests on the network for dynamic IP configuration.

example:

ip-config manual

ip 192.168.45.39

where ip-config specifies manual configuration and ip manually sets the IP address 192.168.45.39 on the print server.

Specifying 0.0.0.0 clears the IP address. If you exit and save a new IP address, it must be specified

on the next Telnet connection.

ENWW TCP/IP Configuration 86

Table 3.4 Telnet Commands and Parameters (7 of 18)

subnet-mask A value (in dotted notation) that identifies the network and

host portions of an IP address in received messages. For example,

subnet-mask 255.255.255.0

stores the subnet mask value 255.255.255.0 on the print server. The value 0.0.0.0 disables the subnet mask. For more information see Appendix A

default-gw The IP address of a default gateway, in dotted notation.

For example,

default-gw 192.168.40.1

assigns 192.168.40.1 as the IP address of the default gateway for the print server.

Note: If the HP Jetdirect print server is configured by DHCP and you manually change the subnet mask or the default gateway address, you should manually change the print server’s IP address. This will release the DHCP-assigned address back to the DHCP IP address pool.

Config Server (Read-only parameter) The IP address of the server (such

as a BOOTP or DHCP server) that last configured the IP address on the HP Jetdirect print server.

TFTP Server (Read-only parameter) The IP address of the TFTP server

that provided TFTP parameters to the HP Jetdirect print server.

TFTP Filename (Read-only parameter) The path and TFTP filename on the

TFTP server. For example,

hpnp/printer1.cfg

domain-name The domain name for the device. For example,

domain-name support.hp.com

assigns support.hp.com as the domain name. The domain name does not include the host name; it is not

the Fully Qualified Domain Name (such as printer1.support.hp.com).

dns-svr IP address of the DNS (Domain Name System) server.

pri-wins-svr The IP address of the primary Windows Internet Name

Service (WINS) server, in dotted notation.

sec-wins-svr The IP address of the secondary Windows Internet Name

Service (WINS) server, in dotted notation.

smtp-svr (SMTP Mail Server) The IP address of the outgoing e-mail

Simple Mail Transport Protocol (SMTP) server, for use with supported Scan devices.

ENWW TCP/IP Configuration 87

Table 3.4 Telnet Commands and Parameters (8 of 18)

TCP/IP Print Options

Command Description

9100-printing Enables or disables printing to TCP port 9100 on the print

ftp-printing Enables or disables the ability to print through FTP. 0

ipp-printing Enables or disables the ability to print using IPP. 0 disables,

lpd-printing Enables or disables the ability to print using LPD. 0 disables,

banner Enables or disables printing an LPD banner page. 0 disables

interlock Specifies whether an acknowledgement (ACK) on all TCP

mult-tcp-conn (Restrict Mult Prt) Enables or disables multiple TCP

buffer-packing Enables or disables buffer packing for TCP/IP packets.

write-mode Controls the setting of the TCP PSH flag for device-to-client

TCP/IP LPD Queues

Command Description

addq Adds a user-defined queue. The queue name (up to 32

deleteq Delete a user-specified queue. The queue name must be

server. 0 disables, 1 (default) enables.

disables, 1 (default) enables. (TCP ports 20, 21)

1 (default) enables. (TCP port 631)

1 (default) enables.(TCP port 515)

banner pages. 1 (default) enables banner pages.

packets is required before the printer is allowed to close a Port 9100 print connection. To accommodate multiport print servers, a Port Number and Option value are specified. Port Numbers can be 1 (default), 2, or 3. Option value 0 (default) disables interlock, 1 enables. For example,

interlock 2 1 specifies Port 2, interlock enabled.

connections. 0 (default): allows multiple connections. 1: disables multiple connections.

0 (default): is normal, the data buffer is packed before sending to the printer.

1: disables buffer packing, data is sent to the printer as it is received.

data transfers. 0 (default): disables this option, flag is not set. 1: all-push option. The push bit is set in all data packets. 2: eoi-push option. The push bit is set only for data packets

that have an End-of-Information flag set.

displayable ASCII characters), prepend string name, append string name, and processing queue (typically, RAW) must be specified in the command line. Up to six user-defined queues may be added.

specified in the deleteq command line.

ENWW TCP/IP Configuration 88

Table 3.4 Telnet Commands and Parameters (9 of 18)

defaultq Name of the queue to be used if the queue specified for a

print job is unknown. By default, the default queue is AUTO.

addstring Adds a user-defined character string that may be prepended

or appended to print data. Up to eight character strings may be specified. A string name and the charac ter string contents are specified in the addstring command line.

deletestring Deletes a user-defined string. The string name is specified

TCP/IP Raw Print Ports

Command Description

raw-port Specifies additional ports for printing to TCP port 9100. Valid

TCP/IP Access Control

Command Description

allow Makes an entry into the host access list stored on the

TCP/IP Other Settings

Command Description

syslog-config Enables or disables syslog server operation on the print

syslog-svr The syslog s erver’s IP address in dotted notation. It specifies

in the deletestring command line.

ports are 3000 to 9000, which are application-dependent. Up to two ports can be specified.

HP Jetdirect print server. Each entry specifies a host or network of hosts that are allowed to connect to the printer. The format is “allow netnum [mask]” where netnum is a network number or host IP address, and mask is an address mask of bits applied to the network number and host address to verify access. Up to 10 access list entries are allowed. If there are no entries, all hosts are permitted access. For example,

allow 192.0.0.0 255.0.0.0

allows hosts on network 192.

allow 192.168.1.2

allows a single host. In this case, the default mask

255.255.255.255 is assumed and is not required. allow 0 clears the host access list.

For additional information, see Chapter 7

server: 0 disables, 1 (default) enables. (UDP port 514)

the server that the HP Jetdirect print server sends syslog messages to. For example,

syslog-svr: 192.168.40.1

assigns 192.168.40.1 as the IP address of that server. For more information, see Appendix A

ENWW TCP/IP Configuration 89

Table 3.4 Telnet Commands and Parameters (10 of 18)

syslog-max Specifies the maximum number of syslog messages that

can be sent by the HP Jetdirect print server on a per-minute basis. This setting allows administrators to control the log file size. The default is 10 per minute. If it’s set to zero, the number of syslog messages is not restricted.

syslog-priority Controls the filtering of syslog messages sent to the syslog

server. The filter range is 0 to 8, with 0 being the most specific and 8 the most general. Only messages that are lower than the filter level specified (or higher in priority) are reported. The default setting is 8, where messages of all priorities are sent.

If 0, all syslog messages are disabled.

syslog-facility A code used to identify the source facility of a message (for

slp-config Enables or disables the Service Location Protocol (SLP)

mdns-config Enables or disables Multicast Domain Name System

mdns-service-name Specifies an alphanumeric string of up to 64 ASCII

mDNS Domain Name

example, to identify the source of selected messages during troubleshooting). By default, the HP Jetdirect print server uses LPR as the source facility code, but local user values of local0 through local7 can be used to isolate individual or groups of print servers.

operation on the print server: 0 disables, 1 (default) enables. SLP is used by selected HP software applications (through UDP port 427) to automate device discovery.

(mDNS) services. 0 disables, 1 (default) enables. mDNS is typically used on small networks for IP address and name resolution (through UDP port 5353) where a conventional DNS server is not available.

characters assigned to this device or service. This name is persistent and is used to resolve a particular device or service if socket information (such as the IP address) changes from session to session. Apple Rendezvous will display this service. The default service name is the printer model and the LAN Hardware (MAC) address.

(Read-only parameter) Specifies the mDNS domain name assigned to the device, in the form <host name>.local. If a user-specifed host name has not been assigned, the default host name NPIxxxxxx is used, where xxxxxx are the last 6 digits of the LAN hardware (MAC) address.

ENWW TCP/IP Configuration 90

Table 3.4 Telnet Commands and Parameters (11 of 18)

mdns-pri-svc Specifies the mDNS highest priority service to use for

printing.To set this parameter, choose one of the following printing option numbers:

corresponds to user-specified LPD queues 5 through 10. The default selection will depend on the printer, typically port

9100 printing or LPD binps.

ttl-slp Specifies the IP multicast “Time To Live” (TTL) setting for

Service Location Protocol (SLP) packets. The default value is 4 hops (the number of routers from the local network). The range is 1-15. When set to a -1, multicast capability is disabled.

ipv4-multicast Enables or disables the receipt and transmission of IP

version 4 multicast packets by the print server. 0 disables, 1 (default) enables.

idle-timeout An integer (1..3600) that specifies the number of seconds

user-timeout An integer (1..3600) that specifies the number of seconds

cold-reset Sets TCP/IP factory default settings. After a cold reset,

ews-config Enables or disables the print server’s embedded Web

an idle print data connection is allowed to remain open. For example,

idle-timeout 120

assigns 120 seconds as the desired idle timeout value. The default is 270 seconds. If set to 0, the connection will

not terminate and other hosts will not be able to make a connection.

that your Telnet or FTP session can be idle before it will be automatically disconnected. The default is 900 seconds. 0 disables the timeout.

CAUTION: Small values, such as 1-5, may effectively disable the use of Telnet. A Telnet session may terminate before any changes can be made.

power cycle the print server. Parameters for other subsystems, such as IPX/SPX or AppleTalk, are not affected.

server. 0 disables, 1 (default) enables. For more information, see Chapter 4

ENWW TCP/IP Configuration 91

Table 3.4 Telnet Commands and Parameters (12 of 18)

tcp-mss Specifies the maximum segment size (MSS) that the

HP Jetdirect print server will advertise for use when communicating with local subnets (Ethernet MSS=1460 bytes or more) or remote subnets (MSS=536 bytes):

0: (default) All networks are assumed to be local (Ethernet MSS=1460 bytes or more).

1: Use MSS=1460 bytes (or more) for subnets, and MSS=536 bytes for remote networks.

2: All networks are assumed to be r emote (MSS=536 bytes), except the local subnet.

MSS affects performance by helping to prevent IP Fragmentation that may result in data retransmission.

tcp-msl Specifies the maximum segment life (MSL) in seconds. The

range is 5 - 120 seconds. The default is 15 seconds.

default-ip Specifies the IP address to use when the print server is

unable to obtain an IP address from the network during a forced TCP/IP reconfiguration (for example, when powered off/on or manually configured to use BOOTP/DHCP).

DEFAULT_IP: sets the legacy default IP address

192.0.0.192. AUTO_IP: sets a link-local IP address 169.254.x.x. The initial setting is determined by the IP address obtained

when first powered on.

default-ip-dhcp Specifies whether DHCP requests will be periodically

TCP/IP Diagnostics

Command Description

Last Config IP (Read-only parameter) The IP address of the system from

TCP Conns Refused (Read-only parameter) The number of client TCP

TCP Access Denied (Read-only parameter) The number of times that client

DHCP Lease Time (Read-only parameter) DHCP IP address lease duration

DHCP Renew Time (Read-only parameter) DHCP T1 timeout, specifying the

transmitted when a legacy default IP address 192.0.0.192 or link-local IP address 169.254.x.x has been automatically assigned.

0: Disables DHCP requests. 1 (default): Enables DHCP requests.

which the HP Jetdirect print server’s IP address was configured.

connections that are refused by the print server.

systems were denied access to the print server because there was no allowable entry in the print server’s host access list.

time (seconds).

DHCP lease renewal time (seconds).

ENWW TCP/IP Configuration 92

Table 3.4 Telnet Commands and Parameters (13 of 18)

DHCP Rebind Time (Read-only parameter) DHCP T2 timeout, specifying the

DHCP lease rebind time (seconds).

SNMP Main Settings

Command Description

snmp-config Enables or disables SNMP operation on the print server.

get-cmnty-name Specifies a password that determines which SNMP

set-cmnty-name Specifies a password that determines which SNMP

default-get-cmnty Enables or disables the default Get community name.

SNMP Traps

Command Description

auth-trap Configures the print server to send (on) or not send (off)

0 disables, 1 (default) enables SNMP. CAUTION: Disabling SNMP will disable all SNMP agents

(SNMP v1, v2, v3) as well as communications with management applications, such as HP Web Jetadmin. In addition, firmware upgrades through current HP downloading utilities will be disabled.

GetRequests the HP Jetdirect print server will respond to. This is optional. If a user-specified get community name is set, the print server will respond to either a user-specified community name or the factory-default. The community name must be ASCII characters. The maximum length is 255 characters.

SetRequests (control functions) the HP Jetdirect print server will respond to. The community name of an incoming SNMP SetRequest must match the print server’s “set community name” for the print server to respond. (For additional security, you may limit configuration access through the print server’s host access list.) Community names must be ASCII characters. The maximum length is 255 characters.

0 disables, 1 (default) enables. Disabling this parameter may prohibit communications with

SNMP management applications.

SNMP authentication traps. Authentication traps indicate that an SNMP request was received, but the community name check failed. 0 is off, 1 (default) is on.

ENWW TCP/IP Configuration 93

Table 3.4 Telnet Commands and Parameters (14 of 18)

trap-dest Enters a host IP address into the HP Jetdirect print server’s

SNMP trap destination list. The command format is:

trap-dest:

ip-address

The default community name is ‘public’; the default SNMP port number is ‘162’. The port number cannot be specified without a community name.

To delete the table, use ‘trap-dest: 0’. If the list is empty, the print server does not send SNMP

traps. The list may contain up to three entries. The default SNMP Trap Destination List is empty. To receive SNMP traps, the systems listed on the SNMP trap destination list must have a trap daemon to listen to those traps.

IPX/SPX Settings

Command Description

ipx-config Enables or disables IPX/SPX protocol operation on the print

server. 0 disables, 1 (default) enables. For example,

ipx-config 0 will disable IPX/SPX operation.

ipx-unitname (Print Server Name) A user-assigned alphanumeric name

assigned to the print server (31 characters maximum). By default, the name will be NPIxxxxxx, where xxxxxx are the last six digits of the LAN hardware address.

Address (Read-only parameter) Identifies the IPX network and node

numbers detected on the network, in the form NNNNNNN:hhhhhhhh (hexadecimal), where NNNNNNNN is the network number and hhhhhhhh is the LAN hardware address of the print server.

ipx-frametype Specifies the IPX frame type settings available for your print

server model: AUTO (default), EN_SNAP, EN_8022, EN_8023, EN_II, TR_8022, TR_SNAP. For more information, see Chapter 9

ipx-sapinterval Specifies the time interval (1 to 3600 seconds) that the

HP Jetdirect print server waits between Service Advertising Protocol (SAP) broadcasts on the network. The default is 60 seconds. 0 disables SAP broadcasts.

ipx-nds-tree An alphanumeric string, up to 31 characters, that specifies

the NDS tree name for the print server.

ipx-nds-context An alphanumeric string, up to 256 characters, that specifies

the NDS context for the HP Jetdirect print server.

ipx-job-poll Specifies the time interval (1 to 255 seconds) that the

HP Jetdirect print server will wait to check for print jobs in a print queue. The default is 2 seconds.

ipx-banner Enables or disables printing an IPX banner page through

Printer Job Language (PJL). 0 disables banner pages. 1 (default) enables banner pages.

ipx-eoj Enables or disables IPX end-of-job notification through PJL.

0 disables, 1 (default) enables.

[community name] [port number]

ENWW TCP/IP Configuration 94

Table 3.4 Telnet Commands and Parameters (15 of 18)

ipx-toner-low Enables or disables IPX toner-low notification through PJL.

0 disables, 1 (default) enables.

source-route (Token Ring only) Configures the HP Jetdirect print server

with the IPX/SPX source routing used on the network. auto (default): Source routing is automatically sensed from

the network. off: Packets are transmitted without source routing. The print

server will only respond to stations on the same ring. single r: All packets are sent with source routing. The Single

Route method is used for broadcasts and when the route is unknown.

all rt: All packets are sent with source ro uting. The All Routes method is used for broadcasts and when the route is unknown.

AppleTalk Settings

Command Description

appletalk Enables or disables AppleTalk (EtherTalk) protocol

name-override (External print servers only) Specifies the name of the

Name (Read-only parameter) The name of the printer on the

Print Type (Read-only parameter) Specifies the AppleTalk network

Zone (Read-only parameter) The name of the AppleTalk network

Phase (Read-only parameter) AppleTalk phase 2 (P2) is

Status (Read-only parameter) Indicates the current AppleTalk

operation on the print server. 0 disables, 1 (default) enables. For example,

at-config 0 will disable AppleTalk operation

AppleTalk network. Up to 32 characters may be used.

AppleTalk network. A number after the name indicates that there are multiple devices with this name, and this is the Nth instance of the name.

printer type reported by the Jetdirect print ser ver. Up to three print types may be reported.

zone on which the printer is located.

preconfigured on the HP Jetdirect print server.

configuration status. READY: Indicates the HP Jetdirect print server is awaiting

data. DISABLED: Indicates that AppleTalk was manually

disabled. INITIALIZING: Indicates that the print server is registering

the node address or name. An additional status message may also be displayed.

ENWW TCP/IP Configuration 95

Table 3.4 Telnet Commands and Parameters (16 of 18)

DLC/LLC Settings

Command Description

dlc/llc-config Enables or disables DLC/LLC protocol operation on the print

strict-8022 Controls DLC/LLC protocol interpretation:

Other Settings

Command Description

link-type (10/100 Fast Ethernet) Sets the print server’s link speed (10

laa Specifies a locally administered address (LA A) that replaces

webscan-config (Web Scan Config) Enables or disables the Web Scan

scan-idle-timeout Specifies the number of seconds (1 - 3600) that an idle scan

scan-email-config (Email Scan Config) Enable or disable the scan-to-email

MFP-config (MFP config) Enable or disable print server support of the

server. 0 disables, 1 (default) enables. For example,

dlc/llc-config 0 will disable DLC/LLC operation.

0 (default): disables, that is, provides loose interpretation. 1: enables, that is, provides strict interpretation).

or 100 Mbps) and communication mode (Full- or Half-Duplex). Selections are AUTO, 100FULL, 100HALF, 10FULL, 10HALF.

For AUTO (default), the print server uses autonegotiation to determine the link speed and mode. If autonegotiation fails, then 100HALF is set.

the factory-assigned LAN Hardware (MAC) address. If LAA is used, a user-specified string of exactly 12 hexadecimal digits must be entered.

For Token Ring print servers, the LAA address must start with hexadecimal 40 through 7F.

For Ethernet print servers, the LAA address must start with hexadecimal X2, X6, XA, or X E, where X is any hexadecimal digit 0 through F.

The default address is the factory-assigned address.

feature on the print server when connected to a supported device. 0 disables, 1 (default) enables.

connection is allowed to remain open. 0 disables the timeout. The default is 300 seconds.

feature in the Web Scan server. 0 disables, 1 (default) enables.

client software provided with your multifunction or all-in-one peripheral.

0 (default): disables client software support (allows printing only).

1: enables client software support (allows printing and scanning).

ENWW TCP/IP Configuration 96

Table 3.4 Telnet Commands and Parameters (17 of 18)

usb-mode Spec ifies the communication mode over the US B port on the

HP Jetdirect print server.

● Auto (default): Automatically negotiates and sets the

highest communication mode possible for the attached printer or device.

● MLC: (Multiple Logical Channels) An HP-proprietary

communication mode that allows multiple channels of simultaneous print, scan and status communications.

● BIDIR: A standard connection that supports

bi-directional communications between the printer and print server. The print server sends print data and receives status from the printer.

● UNIDIR: A standard connection in which data is

transferred in one direction only (to the printer).

usb-speed (Read-only parameter, USB 2.0 products only) Specifies the

status-page-lang Specifies the printer job language (PJL) that the print server

Support Settings

Command Description

Web JetAdmin URL (Read-only parameter) If HP Web Jetadmin discovers this

Web JetAdmin Name

support-name Typically used to identify the name of a person to contact for

support-number Typically used to specify a phone or extension number to

autonegotiated communication speed over the USB connection between the HP Jetdirect print server and the device.

● Full Speed: 12 Mbits/sec as specified in the USB v2.0

specifications, compatible with USB v1.1 specifications.

● Hi-Speed: 480 Mbits/sec for USB v2.0 devices only.

● Disconnected: The USB port is not connected.

will use to send the Jetdirect configuration/status page to the printer.

● Auto (default): The PDL is auto-detected when the print

server is powered on or after a cold-reset.

● PCL: Hewlett-Packard Printer Control Language

● ASCII: Standard ascii characters

● HPGL2: Hewlett-Packard Graphics Language (v2)

● PS: Postscript language

device, the URL to access HP Web Jetadmin will be specified.

(Read-only parameter) If HP Web Jetadmin discovers this device, the name of the HP Web Jetadmin host will be specified (if known).

support of this device.

call for support of this device.

ENWW TCP/IP Configuration 97

Table 3.4 Telnet Commands and Parameters (18 of 18)

support-url A Web URL address for product information on this device

over the Internet or an intranet.

tech-support-url A Web URL address for technical support over the Internet

or an intranet.

Menu Interface

An optional Menu interface is displayed when you type menu at the Telnet command prompt. The Menu interface eliminates the need to memorize commands, and provides structured menu lists for easy access to configuration parameters.

Figure 3.1

illustrates the Menu interface, using the TCP/IP menus

as an example.

● From the Main Menu screen, select and enter a menu number.

If there are submenus, select and enter a submenu number.

● If you want to change a parameter setting, enter “Y” (for “Yes”)

when prompted.

Changes to parameters are made by editing the setting through the use of the Backspace key. If an unrecognized value is entered, the correct entry options will be displayed.

Note Changes are not saved on the Jetdirect print server

until you exit a menu and, when prompted, choose to save your changes.

ENWW TCP/IP Configuration 98

Figure 3.1 Example: Using the Menu Interface

Main Menu

-------------------------------

1. General Menu

2. TCP/IP Menu...

3. SNMP Menu...

4. IPX/SPX Menu

5. AppleTalk Menu

6. DLC/LLC Menu

7. Other Settings

8. Support Settings

9. Wireless Settings ?. Help e. Exit Menu

0. Exit Telnet Enter Selection => 2

For the TCP/IP Menu, select 2.

-------------------------------

1. TCP/IP - Main Settings

2. TCP/IP - Print Options

3. TCP/IP - Raw Print Ports

4. TCP/IP - Access Control

5. TCP/IP - Other Settings

6. TCP/IP - Diagnostics

0. Return to Main Menu

TCP/IP Menu

For parameters listed in TCP/IP Main Settings,

Enter Selection => 1

TCP/IP - Main Settings

-------------------------------

Host Name : printer1 IP Config Method : USER SPECIFIED IP Address : 192.168.45.39 Subnet Mask : 255.255.0.0 Default Gateway : 192.168.40.1 Config Server : 192.168.2.21 TFTP Server : 192.168.2.21 TFTP File Name : hpnp/print.cfg Domain Name : Not Specified DNS Server : Not Specified Pri WINS Server : Not Specified Sec WINS Server : Not Specified SMTP Mail Server : Not Specified

Would you like to change any of the settings? (Y/[N]):Y

select 1.

To edit these parameters, enter Y. Use the Backspace key to edit the parameters.

Changes are not saved until you save them when you exit the session.

ENWW TCP/IP Configuration 99

Using Telnet to Erase the Existing IP Settings

To erase the IP address during a Telnet session, use the following command line entries:

1. Type cold-reset, then press Enter.

2. Type quit, then press Enter to exit Telnet.

3. Power the print server off/on.

Note This procedure resets all TCP/IP parameters, but

only affects the TCP/IP subsystem. Parameters for other subsystems such as IPX/SPX or AppleTalk are not affected.

To reset all parameters to factory default values, refer to Chapter 8

Using the Embedded Web Server

You can set IP parameters on HP Jetdirect print servers that support the embedded Web server. For more information, refer to

Chapter 4

ENWW TCP/IP Configuration 100

HP JetDirect 175x, JetDirect 200m, JetDirect 250m, JetDirect 280m, JetDirect 310x Administrator Guide

Specifications and Main Features

Frequently Asked Questions

User Manual

Introduction

Supported Print Servers

Supported Network Protocols

Security Protocols

HTTPS

Authentication (Wireless Print Servers)

Supplied Manuals

HP Support

HP Online Support

Firmware Upgrades

HP Support By Phone

Product Registration

HP Software Solutions Summary

Introduction

HP Jetdirect Wireless Setup Wizard

Requirements

HP Install Network Printer Wizard (Windows)

Requirements

HP Jetdirect Printer Installer for UNIX

HP Web Jetadmin

System Requirements

Installing HP Web Jetadmin

Configuring and Modifying a Device

Internet Printer Connection Software

HP-Supplied Software

Microsoft Supplied Software

Novell Supplied Software

HP IP/IPX Printer Gateway for NDPS

Features

To Get the Software

HP WPS Assistant (Mac OS X)

HP LaserJet Utilities for Mac OS

Installing the Printer Software

Configuring the Printer

Verifying Network Configuration

Renaming the Printer

Selecting a Zone

Selecting Your Printer

Testing the Configuration

TCP/IP Configuration

Introduction

Server-Based and Manual TCP/IP Configuration

Default IP Address

Default IP Address Will Not Be Assigned

Default IP Address Will Be Assigned

Default IP Address Configuration Options

Default IP on Wireless and Wired Print Servers

TCP/IP Configuration Tools

Using BOOTP/TFTP

Why Use BOOTP/TFTP?

BOOTP/TFTP on UNIX

Using DHCP

UNIX Systems

Windows Systems

NetWare Systems

To Discontinue DHCP Configuration

Using RARP

Using the arp and ping Commands

Using Telnet

Creating a Telnet Connection

A Typical Telnet Session

User Interface Options

Using Telnet to Erase the Existing IP Settings

Using the Embedded Web Server
